Nec V404-T, V484-T, V554-T User Manual

Large Format Display
User’s Manual
MultiSync V404-T MultiSync V484-T MultiSync V554-T
Please fi nd your model name in the label on the backside of monitor.

Index

DECLARATION OF CONFORMITY....................................................................................................................... English-1
Important Information ............................................................................................................................................. English-2
WARNING ............................................................................................................................................... English-2
Safety Precautions, Maintenance & Recommended Use ...................................................................................... English-3
Contents ................................................................................................................................................................. English-5
Installation .............................................................................................................................................................. English-5
Parts Name and Functions .................................................................................................................................... English-9
CAUTION ................................................................................................................................................ English-2
Safety Precautions and Maintenance ...................................................................................................... English-3
Recommended Use ................................................................................................................................. English-3
Ergonomics .............................................................................................................................................. English-4
Cleaning the Panel .................................................................................................................................. English-4
Cleaning the Cabinet ............................................................................................................................... English-4
Attaching Mounting Accessories .............................................................................................................. English-7
Control Panel ........................................................................................................................................... English-9
Terminal Panel ......................................................................................................................................... English-10
Wireless Remote Control ......................................................................................................................... English-12
Operating Range for the Remote Control ................................................................................................ English-13
Wiring Diagram ........................................................................................................................................ English-16
Connecting a Personal Computer ........................................................................................................... English-17
Connecting a Player or Computer with HDMI .......................................................................................... English-17
Connecting a Computer with DisplayPort ................................................................................................ English-17
Connecting a USB device with USB port ................................................................................................. English-18
For using Touch Panel ............................................................................................................................. English-18
Power ON and OFF Modes ..................................................................................................................... English-19
Power Indicator ........................................................................................................................................ English-20
Using Power Management ...................................................................................................................... English-20
Aspect ...................................................................................................................................................... English-20
Media Player ............................................................................................................................................ English-21
Displayable/playable fi les ........................................................................................................................ English-21
File display screen ................................................................................................................................... English-23
Slideshow display .................................................................................................................................... English-24
Media Player settings .............................................................................................................................. English-24
NETWORK & OTHER SETTINGS .......................................................................................................... English-25
Using SHARED SD card SETTINGS ...................................................................................................... English-26
Using CONTENTS COPY ....................................................................................................................... English-27
Using Emergency contents ...................................................................................................................... English-27
Information OSD ...................................................................................................................................... English-27
Picture Mode ........................................................................................................................................... English-28
INPUT ...................................................................................................................................................... English-32
PICTURE ................................................................................................................................................. English-32
AUDIO ..................................................................................................................................................... English-34
SCHEDULE ......................................................................................................................
MULTI INPUT .......................................................................................................................................... English-36
OSD ......................................................................................................................................................... English-38
MULTI DISPLAY ...................................................................................................................................... English-38
DISPLAY PROTECTION ......................................................................................................................... English-40
CONTROL ............................................................................................................................................... English-40
OPTION ................................................................................................................................................... English-43
SYSTEM .................................................................................................................................................. English-44
Connecting to a Network ......................................................................................................................... English-50
Network Setting by Using an HTTP Browser ........................................................................................... English-50
....................... English-35

DECLARATION OF CONFORMITY

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Boulevard, Suite 1100 Itasca, Illinois 60143 Tel. No.: (630) 467-3000
Type of Product: Display Monitor
Equipment Classifi cation: Class B Peripheral
Model: MultiSync V404-T (V404-T) MultiSync V484-T (V484-T) MultiSync V554-T (V554-T)
We hereby declare that the equipment speciÞ ed above
conforms to the technical standards as speciÞ ed in the FCC Rules.
FCC Information
1. Use the attached specifi ed cables with this color monitor so as not to interfere with radio and television reception. (1) Please use the supplied power cord or equivalent to ensure FCC compliance. (2) Please use the supplied shielded video signal cable.
2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult your dealer or an experienced radio/TV technician for help.
English
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may fi nd the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Offi ce, Washington, D.C., 20402, Stock No. 004-000-00345-4.
Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. OmniColor is a registered trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland. DisplayPort and DisplayPort Compliance Logo are trademarks owned by Video Electronics Standards Association in the United States and other countries. All other brands and product names are trademarks or registered trademarks of their respective owners.
The terms HDMI and HDMI High-Defi nition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and other countries and areas.
microSD and microSD SDHC logos are trademarks of SD-3C, LLC.
CRESTRON and ROOMVIEW are registered trademarks of Crestron Electronics, Inc. in the United States and other countries.
GPL/LGPL Software Licenses The product includes software licensed under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), and others. For more information on each software, see “readme.pdf” inside the “about GPL&LGPL” folder on the supplied CD-ROM.
Apple and Macintosh are trademarks of Apple Inc., registered in the U.S. and other countries. Adobe and the Adobe logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
English-1

Important Information

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM
WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION: Please use the power cord provided with this monitor in accordance with the table below. If a power cord is not supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.
This symbol warns user that uninsulated voltage within the unit may have suffi cient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.
Plug Type North America
Plug Shape
Region
Voltage
* When operating the MultiSync monitor with its AC 125-240V power supply, use a power supply cord that matches the power
supply voltage of the AC power outlet being used.
NOTE: This product can only be serviced in the country where it was purchased.
Use the power cord which has BSMI mark at both ends when you use this monitor in Taiwan.
• The intended primary use of this product is as an Information Technical Equipment in an offi ce or domestic environment.
• The product is intended to be connected to a computer and is not intended for the display of television broadcast signals.
U.S.A./
Canada
120*
Taiwan
110
European
Continental
EU (except U.K.) U.K. China Japan
230 230 220 100
U.K. Chinese Japanese
English-2

Safety Precautions, Maintenance & Recommended Use

Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE
FOLLOWING WHEN SETTING UP AND USING
THE MULTI-FUNCTION MONITOR:
• DO NOT OPEN THE MONITOR. There are no user
serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualifi ed service personnel.
• Do not bend, crimp or otherwise damage the power cord.
• Do not place any heavy objects on the power cord.
Damage to the cord may cause shock or fi re.
• The power supply cord you use must have been
approved by and comply with the safety standards of your country. (Type H05VV-F 3G 0.75 mm Europe).
• In UK, use a BS-approved power cord with molded
plug having a black (5 A) fuse installed for use with this monitor.
• The power cable connector is the primary means of
detaching the system from the power supply. The monitor should be installed close to a power outlet, which is easily accessible.
• Do not spill any liquids into the cabinet or use your
monitor near water.
• Do not insert objects of any kind into the cabinet slots,
as they may touch dangerous voltage points, which can be harmful or fatal or may cause electric shock, fi re or equipment failure.
• Do not place this product on a sloping or unstable cart,
stand or table, as the monitor may fall, causing serious damage to the monitor.
• Do not mount this product upside down for an extended
period of time as it may cause permanent damage to the screen.
• Do not place any objects onto the monitor and do not use
the monitor outdoors.
• If glass is broken, handle with care.
• Temperature controlled fans are implemented in this
monitor. For reliable performance and long useful life of this product, it is mandatory to not cover any vents on the monitor.
• If monitor or glass is broken, do not come in contact with
the liquid crystal and handle with care.
• Allow adequate ventilation around the monitor, so that
heat can properly dissipate. Do not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of the monitor.
• Handle with care when transporting. Save packaging for
transporting.
• If using the cooling fan continuously, it is recommended to
wipe holes clean a minimum of once a month.
• To ensure the monitor’s reliability, please clean the holes
at the back side of the cabinet at least once a year to remove dirt and dust.
2
should be used in
• When using a LAN cable, do not connect to a peripheral device with wiring that might have excessive voltage.
• Do not use the monitor in high temperature, humid, dusty, or oily areas.
• Do not use monitor under rapid temperature and humidity change condition and avoid cold air from air-conditioning outlet directly, as it may shorten the lifetime of the monitor or cause condensation. If condensation of water has happened, let the monitor stand unplugged until the condensation has disappeared.
• The touch panel glass is not safety glass and is not laminated. As with other glass, the touch panel glass may break into sharp pieces if misused, dropped, or otherwise subjected to a substantial shock. If touch panel glass happens to break, please use care to avoid injury.
• DO NOT tap the monitor with hard or pointed object, such as a pen, or pencil.
Connecting to a TV*
• Cable distribution system should be grounded (earthed) in accordance with ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.
• The screen of the coaxial cable is intended to be connected to earth in the building installation.
Under the following conditions immediately disconnect your monitor from the wall outlet and refer servicing to qualifi ed service personnel:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet has been damaged.
• If you notice any structural damage such as cracks or unnatural wobbling.
• If the monitor does not operate normally by following operating instructions.
Recommended Use
• For the monitor’s optimum performance, allow 20 minutes for warming up.
• Rest your eyes periodically by focusing on an object at least 5 feet away. Blink often.
• Position the monitor at a 90° angle to windows and other light sources to minimize glare and refl ections.
• Clean the LCD monitor surface with a lint-free, non­abrasive cloth. Avoid using any cleaning solution or glass cleaner!
• Adjust the monitor’s brightness, contrast and sharpness controls to enhance readability.
• Avoid reproduction of still patterns on the monitor for long periods of time to avoid image persistence (after image effects).
• Get regular eye checkups.
English
* The product you purchased may not have this feature.
English-3
Ergonomics
To realize the maximum ergonomic benefi ts, we recommend the following:
• Use the preset Size and Position controls with standard signals.
• Use the preset Color Setting.
• Use non-interlaced signals.
• Do not use primary color blue on a dark background, as it is diffi cult to see and may produce eye fatigue due to insuffi cient contrast.
• Suitable for entertainment purposes at controlled luminous environments, to avoid disturbing refl ections from the screen.
Cleaning the Panel
• When the panel is dusty, please gently wipe with a soft cloth.
• Please do not rub the panel with hard material.
• Please do not apply pressure to the panel surface.
• Please do not use OA cleaner as it will cause deterioration or discoloration on the surface.
Cleaning the Cabinet
• Unplug the power supply
• Gently wipe the cabinet with a soft cloth
• To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and follow with a dry cloth.
NOTE: DO NOT clean with benzene thinner, alkaline
detergent, alcoholic system detergent, glass cleaner, wax, polish cleaner, soap powder, or insecticide. Rubber or vinyl should not be in contact with the cabinet for an extended period of time. These types of fl uids and materials can cause the paint to deteriorate, crack or peel.
English-4

Contents

For contents, please refer to the contents sheet.

Installation

This device cannot be used or installed without the Tabletop Stand or other mounting accessory for support. For proper installation it is strongly recommended to use a trained, NEC authorized service person. Failure to follow NEC standard mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty does not cover damage caused by improper installation. Failure to follow these recommendations could result in voiding the warranty.
Mounting
DO NOT mount the monitor yourself. Please ask your supplier. For proper installation it is strongly recommended to use a trained, qualifi ed technician. Please inspect the location where the unit is to be mounted. Mounting on wall or ceiling is the customer’s responsibility. Not all walls or ceilings are capable of supporting the weight of the unit. Product warranty does not cover damage caused by improper installation, re­modeling, or natural disasters. Failure to comply with these recommendations could result in voiding the warranty.
DO NOT block ventilated openings with mounting accessories or other accessories.
For NEC Qualifi ed Personnel:
To ensure safe installation, use two or more brackets to mount the unit. Mount the unit to at least two points on the installation location.
English
To prevent the LCD monitor from falling off from the wall or ceiling, NEC strongly recommends using a wire.
Please install LCD monitor in a spot of the wall or ceiling strong enough to support the monitor.
Prepare the LCD monitor using mounting accessories such as hook, eyebolt or mounting parts and then secure the LCD monitor with a wire. The installed wire must not be tight.
Please make sure the mounting accessories are strong enough to support the LCD monitor before mounting it.
Please use the two optional speaker mounting holes. (Recommended Fasten Force: 139 - 189N•cm).
Landscape installation
Please note the following when mounting on wall or ceiling
• When using mounting accessories other than those that are NEC approved, they must comply with the VESA­compatible (FDMlv1) mounting method.
• NEC recommends mounting interfaces that comply with UL1678 standard in North America.
• NEC strongly recommends using size M6 screws (10-12 mm + thickness of bracket and washers in length). If using screws longer than 10-12 mm, check the depth of the hole. (Recommended Fasten Force: 470 - 635N•cm). Bracket hole should be under Ø 8.5 mm.
• Prior to mounting, inspect the installation location to ensure that it is strong enough to support the weight of the unit so that the unit will be safe from harm.
• For detailed information, refer to the instructions included with the mounting equipment.
• Make sure that there is no gap between the monitor and the bracket.
• When used in a video wall confi guration for a longer time, slight expansion of the monitors may happen due to temperature changes. Due to this it is recommended that over one millimeter gap is kept between adjacent monitor edges.
under
Ø 8.5 mm
Unit
No thread
4 mm
No gap
10-12 mm
Mounting Bracket
Washers
Screw
Thickness of bracket and washers
Portrait installationVESA Mounting Interface (M6)
Installing a wire to a monitor with no speakers installed
Please use eyebolts to install a wire to the monitor.
Less than 12 mm
Installing a wire to a monitor with installed speakers
Please use speaker mounting parts to install a wire to the monitor. Optional speaker is installed on the back of the LCD monitor:
English-5
Mounting location
• The ceiling and wall must be strong enough to support the monitor and mounting accessories.
• DO NOT install in locations where a door or gate can hit the unit.
• DO NOT install in areas where the unit will be subjected to strong vibrations and dust.
• DO NOT install the monitor next to a location where the main power supply is fed into the building.
• DO NOT install the monitor in a location where people can easily grab and hang onto the unit or the mounting equipment.
• Allow for adequate ventilation or provide air conditioning around the monitor, so that heat can properly dissipate away from the monitor and from the mounting equipment.
Mounting on ceilings
• Ensure that the ceiling is sturdy enough to support the weight of the unit and the mounting equipment over time, against earthquakes, unexpected vibrations, and other external forces.
• Be sure the unit is mounted to a solid structure within the ceiling, such as a support beam. Secure the monitor using bolts, spring lock washers, washer and nut.
• DO NOT mount to areas that have no supporting internal structure. DO NOT use wood screws or anchor screws for mounting. DO NOT mount the unit to ceiling or to hanging fi xtures.
Maintenance
• Periodically check for loose screws, gaps, distortions, or other problems that may occur with the mounting equipment. If a problem is detected, please refer to qualifi ed personnel for service.
• Regularly check the mounting location for signs of damage or weakness that may occur over time.
Orientation
• When using the monitor in the portrait position, it should be rotated clockwise so that the left side is moved to the top, right side is moved to the bottom. This will allow for proper ventilation and will extend the lifetime of the monitor. Improper ventilation may shorten the lifetime of the monitor.
LED Indicator
• When using the monitor in the portrait position, the NEC logo ornament position can be changed.
Changing NEC logo ornament position
Removing the logo ornament: Insert a thin stick (less than 3 mm diameter) into the hole in the bottom of logo ornament and remove the logo ornament by pushing up it from the bottom.
Attaching the logo ornament: Hook the part (1) of logo ornament into the bezel and press in.
3.6 mm
2 mm
English-6
Attaching Mounting Accessories
The monitor is designed for use with the VESA mounting system.
1. Attach Mounting Accessories
Be careful to avoid tipping the monitor when attaching accessories.
VESA Mounting Interface (M6)
300 mm
Mounting accessories can be attached with the monitor in the face down position. To avoid damaging the front face, place the protective sheet on the table underneath the LCD monitor. The protective sheet was wrapped around the LCD monitor in the original packaging. Make sure there is nothing on the table that can damage the monitor.
When using mounting accessories other than NEC compliant and approved, they must comply with the VESA Flat Display Mounting Interface Standard (FDMI).
NOTE: Prior to installation, be sure to place the monitor
on a fl at area with adequate space.
2. Using an Option Board
1. Turn off the main power switch.
2. Place the monitor face down on the protective sheet. NOTE: Be sure to place the monitor on a fl at and adequate space.
3. Remove the attached slot cover by unscrewing the installed screws (Figure 1).
4. Insert the option board into the monitor and fi x it with the removed screws (Figure 2).
NOTE: Please contact your supplier for available option
boards. Do not apply excessive force to manipulate the option board before fi xing it with screws. Make sure that the board is inserted into the slot in the correct orientation.
CAUTION: Ensure the option board is attached by the
removed screws. As falling the option board may expose you to danger.
(Recommended Fasten Force: 139 - 189N•cm).
300 mm
Figure 2
3. Using Wall Mount Adapter
If the mounting accessory interferes with ventilation hole, use the included wall mount adaptors (Dia. 14 mm) and screws. If the adaptor screws are too long, include a washer to reduce the depth. Washer not included.
Wall mount adapter (Dia. 14 mm)
Unit
10-12 mm
18 mm
Mounting bracket
Washer
Wall mount adapter screw
English
Figure 1
Pictured mounting solutions may not be available in some countries.
English-7
4. Installing and removing the optional table top stand
CAUTION: Installing and removing the stand must be done
by two or more people.
5. Ventilation Requirements
When mounting in an enclosed space or recessed area, leave adequate room between the monitor and the enclosure to allow heat to disperse, as shown below.
For installation follow the instructions included with the stand or mounting equipment. Use only those devices recommended by the manufacturer.
NOTE: Use ONLY screws which are supplied with the
optional table top stand.
When installing the LCD monitor stand, handle the unit with care to avoid pinching your fi ngers.
NOTE: Use the ST-401. Please refer to the ST-401
user’s manual for more detail.
NOTE: DO NOT use the monitor on the fl oor with the table
top stand. Please use this monitor on a table or with a mounting accessory for support.
Height adjustment
1. The lines on the stand pole are indicators of the height
adjustment (Figure 3). Please adjust the pipe to the lines.
Pipe
V554-T
V484-T
100 mm
100 mm
100 mm
100 mm
Must be under 35 Degree Celsius.
30 mm
Allow adequate ventilation or provide air conditioning around the monitor, so that heat can properly dissipate away from the unit and the mounting equipment; especially when you use monitors in a multiple screen confi guration.
NOTE: The sound quality of the internal speakers will be
different depending on the acoustics of the room.
V404-T
Adjust the pipe to a line.
Figure 3
2. Please install the stand pole and the pipe with included
screws. Please screw the two screw holes at the pipe (Figure 4).
Pipe
Stand pole
Figure 4
NOTE: Installing the monitor at the wrong height can
cause tipping. Please install your monitor at proper height.
When the monitor is moved after the stands are attached, do not drag the monitor with the stands in contact with the fl oor. It may cause damage to the touch panel function.
English-8

Parts Name and Functions

Control Panel

POWER button ( )
Switches the power on/standby. See also page 19.
MUTE button (MUTE)
Switches the audio mute on/off.
INPUT/SET button (INPUT/SET)
INPUT: Toggle switches between below inputs. [DVI], [HDMI1], [HDMI2], [DisplayPort1], [DisplayPort2], [VGA (YPbPr/RGB)], [VIDEO], [MP], [OPTION*]). These are available inputs only, shown as their factory preset name. SET: When OSD is shown, this button acts as “set button” when you made selection. *: This function depends on which option board you are using.
PLUS button (+)
1. Increases the audio output level when the OSD menu is
turned off.
Acts as (+) button to increase the adjustment with OSD
2.
menu.
MINUS button (-)
1. Decreases the audio output level when the OSD menu is
turned off.
2. Acts as (-) button to decrease the adjustment with OSD
menu.
MENU/EXIT button (MENU/EXIT)
Activates the OSD menu when the OSD menu is turned off. Acts as EXIT button within the OSD to move to previous menu.
Remote control sensor and Power Indicator
Receives the signal from the remote control (when using the wireless remote control). See also page 13. Glows blue when the LCD monitor is in active mode*. Green and Amber blink alternately is the “SCHEDULE SETTINGS” function enabled* When a component failure is detected within the monitor, the indicator will blink red or blink a combination of red and blue. * If “OFF” is selected in the “POWER INDICATOR” (see page 42), LED will not glow when the LCD monitor is in active mode. *1 If “OFF” is selected in the “SCHEDULE INDICATOR” (see page 42), LED will not glow. NOTE: Please refer to the POWER INDICATOR (see page 42).
1
.
Room light sensing sensor
Detects the level of ambient light, allowing the monitor to make automatic adjustments to the backlight setting, resulting in a more comfortable viewing experience. Do not cover this sensor. See page 42.
English
UP button ( )
Activates the OSD menu when the OSD menu is turned off. Acts as adjustment items within the OSD menu.
button to move the highlighted area up to select
DOWN button ( )
Activates the OSD menu when the OSD menu is turned off. Acts as adjustment items within the OSD menu.
OSD is an abbreviation of On Screen Display.
button to move the highlighted area down to select
English-9

Terminal Panel

USB Upstream
AC IN connector
Connects with the supplied power cord.
Main Power Switch
On/Off switch to turn main power ON/OFF.
AUDIO IN1/IN2
To input audio signal from external equipment such as a computer or player.
VGA IN (mini D-Sub 15 pin)
To input analog RGB signals from a personal computer or from other RGB equipment. This input can be used with an RGB or YPbPr source. Please select signal type in TERMINAL SETTINGS. See page 37. NOTE: When you use this connector for YPbPr, please use a suitable signal cable. If you have any questions, please ask your supplier.
DisplayPort OUT
To output DisplayPort signals. Outputs DisplayPort1 signal.
DisplayPort IN1/IN2
To input DisplayPort signals.
HDMI IN1/IN2
To input digital HDMI signals.
DVI IN (DVI-D)
To input digital RGB signals from a computer or HDTV device having a digital RGB output. * This connector does not support analog input.
microSD card slot
Insert a microSD memory card. To use Media player, please connect a microSD memory card to this port (See page 18). To install the microSD card slot cover, please refer to “Installing microSD card slot cover” (See page 23).
USB port
USB1: Downstream port (USB Type-A). To connect USB devices. USB2: Upstream port (USB Type-B). To connect external equipment such as a computer. To use the touch panel function and to control the monitor from connected external equipment, please use this port. USB CM1 (2A): Power supply port. USB CM2: Service port. This port is for future software upgrades. USB MP: USB storage device port. To use Media player, please connect USB storage device to this port (See page 18). MP is an abbreviation of Media Player.
VIDEO IN
To input a composite video signal.
LAN port IN1/IN2 (RJ-45)
LAN connection. See page 47 and 50. NOTE: Please give priority for use to LAN1.
AUDIO OUT
To output the audio signal from the AUDIO IN1/IN2, DisplayPort and HDMI to an external device (stereo receiver, amplifi er, etc.). NOTE: This connector is not a Headphone terminal.
RS-232C IN (D-Sub 9 pin)
Connect RS-232C input from external equipment such as a computer in order to control RS-232C functions.
REMOTE IN
Use the optional sensor unit by connecting it to your monitor.
NOTE: Do not use this connector unless specifi ed.
English-10
Internal/External speaker switch
: Internal speaker : External speaker. NOTE: Please turn off the monitor’s main power when you use the Internal/External speaker switch.
EXTERNAL SPEAKER TERMINAL
To output the audio signal. Red terminal is plus (+). Black terminal is minus (-). NOTE: This speaker terminal is for 15 W + 15 W (8 ohm) speaker.
Internal speaker Option board slot
Slot 2 type accessory is available. Please contact your supplier for detailed information. NOTE: Please contact your supplier for available option board.
Kensington Lock
For security and theft prevention.
Rating label
Intelligent wireless data sensor
Sensor for wireless communication of monitor for information and settings.
Option speaker mounting hole
NOTE: Please contact your supplier for available optional
speaker.
English
English-11

Wireless Remote Control

UP/DOWN button ( / )
Acts as to select adjustment items within the OSD menu. Small screen which adjusted PIP (picture in picture) mode moves up or down.
button to move the highlighted area up or down
MINUS/PLUS (-/+) button
Increases or decreases the adjustment level within the OSD menu settings. Small screen which adjusted “PIP” mode moves left or right and increases or decreases the size.
SET/POINT ZOOM button
SET: When OSD is shown, this button acts as “set button” when you made selection. POINT ZOOM: When OSD is not shown, this button acts as “point zoom button”.
VOLUME UP/DOWN button (VOL +/-)
Increases or decreases audio output level.
POWER ON/STANDBY button
Switches the power on/standby.
INPUT button
Selects input signal. Input signal for MEDIA PLAYER is shown as MP.
OPTION MENU button KEYPAD
Press the buttons to set and change passwords, change channel and set REMOTE ID. Below buttons are used for CEC (See page 43) and Media Player function (See page 21):
, 2 , 3 , 5 , 6 .
1
ENT button*
1
DISPLAY button
Turns on/off the information OSD. See page 27. If you lock remote control buttons using the IR LOCK SETTINGS function, you can unlock the buttons by holding down this DISPLAY button for more than 5 seconds.
MENU button
Turns on/off the menu mode.
AUTO SET UP button
Enters auto setup menu. See page 33.
CH/ZOOM UP/DOWN button (CH/ZOOM +/-)*
Increases or decreases POINT ZOOM level. Please refer to POINT ZOOM (See page 58).
GUIDE button*
1
1
MUTE button
Turns on/off the mute function.
PICTURE MODE button
Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [CUSTOM1], [CUSTOM2], [SVE-(1-5) SETTINGS]. See page 30.
HIGHBRIGHT: For moving images such as DVD. STANDARD: For images. sRGB: For text based images. CINEMA: For movies. CUSTOM1 and CUSTOM2: Activates auto dimming function. See page 42. SVE-(1-5) SETTINGS: For images and movies.
ASPECT button
Selects picture aspect, [FULL], [WIDE]*, [DYNAMIC]*, [1:1], [ZOOM] and [NORMAL]. See page 20.
* HDMI1, HDMI2, VGA (YPbPr) inputs only.
AUDIO INPUT button
Selects audio input source [IN1], [IN2], [HDMI1], [HDMI2], [DisplayPort1], [DisplayPort2], [OPTION]*
1
, [MP].
STILL button
ON/OFF button: Activates/deactivates still picture mode. CAPTURE button: Captures still picture. NOTE: This function is released when selecting MULTI
PICTURE MODE, TEXT TICKER, SCREEN SAVER, POINT ZOOM, IMAGE FLIP except for NONE, SUPER in INPUT CHANGE, TILE MATRIX. CLOSED CAPTION is not available when STILL is active. If input signal is OPTION, this button’s actions depend on which option board you are using.
EXIT button
Returns to previous menu within OSD menu.
*1: This button’s action depends on which option board you are using.
English-12
IMAGE FLIP button
Toggle switches between [H FLIP], [V FLIP], [180° ROTATE] and [NONE]. See page 34.
ACTIVE PICTURE button
Selects active picture.
MULTI PICTURE button
ON/OFF button: Toggle switches between ON and OFF.
See page 20. MODE button: Selects a mode from PIP (picture in picture) or PBP (picture by picture).
CHANGE button: Swaps images between two pictures. PICTURE ASPECT button: Selects active picture frame
aspect. NOTE: Enable to change each multi picture size by pressing SET/POINT ZOOM button during multi picture mode.
REMOTE ID button
Activates the REMOTE ID function. See page 46.
MTS button*
button*
Activates closed captioning. NOTE: VIDEO input only.
*1: This button’s action depends on which option board you are using. Refer to the option board’s user’s manual for further information.
1
1

Operating Range for the Remote Control

Points the top of the remote control toward the LCD monitor’s remote control sensor during button operation.
Uses the remote control within a distance of about 7 m (23 ft.) from remote control sensor or at a horizontal and vertical angle of within 30° within a distance of about 3.5 m (10 ft.).
Caution: Important, the remote control
system may not function when direct sunlight or strong illumination strikes the remote control sensor or when there is an object in the path.
English
NOTE: The buttons with no explanation do not function.
Handling the remote control
• Do not expose to strong shock.
• Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately.
• Avoid exposure to heat and steam.
• Except to install the batteries, do not open the remote control.
English-13

Setup

1. Determine the installation location
CAUTION: Installing your LCD monitor must be done by a
qualifi ed technician. Contact your supplier for more information.
CAUTION:
CAUTION: Do not mount or operate the monitor upside
CAUTION: This LCD monitor has internal temperature
IMPORTANT: Lay the protective sheet beneath the
MOVING OR INSTALLING THE LCD MONITOR MUST BE DONE BY TWO OR MORE PEOPLE. Failure to follow this caution may result in injury if the LCD monitor falls.
down.
sensors and cooling fans, including a fan for the option board. If the LCD monitor becomes too hot, the cooling fans will turn on automatically. The option board’s fan is active although the temperature is lower than normal operating temperature for cooling the option board. If the LCD monitor becomes overheated while the cooling fan is running, a “Caution” warning will appear. If the “Caution” warning appears, stop using the unit and allow it to cool. Using the cooling fans will reduce the likelihood of early unit failure and may help reduce image degradation and “Image Persistance”. If the LCD monitor is used in an enclosed area or if the LCD panel is covered with a protective screen, please check the inside temperature of the monitor by using the “HEAT STATUS” control in the OSD (see page 40). If the temperature is higher than the normal operating temperature, please turn the cooling fan to ON within the FAN CONTROL menu within the OSD (see page 40).
monitor, so as not to scratch the LCD panel. The protective sheet was wrapped around the monitor when it was packaged.
NEC recommends the following battery use:
• Place “AAA” size batteries matching the (+) and (-) signs on each battery to the (+) and (-) signs of the battery compartment.
• Do not mix battery brands.
• Do not combine new and old batteries. This can shorten battery life or cause liquid leakage of batteries.
• Remove dead batteries immediately to prevent battery acid from leaking into the battery compartment.
• Do not touch exposed battery acid, it may injure your skin.
NOTE: If you do not intend to use the Remote Control for
a long period of time, remove the batteries.
3. Connect external equipment
(See pages 16, 17 and 18)
• To protect the external equipment; turn off the main power before making connections.
• Refer to the user’s manual of your equipment for further information.
NOTE: Do not connect/disconnect cables when turning
on the monitor or other external equipment, as this may result in a loss of the monitor image.
4. Connect the supplied power cord
• The equipment should be installed close to an easily accessible power outlet.
• Please fasten power cord to the LCD monitor by attaching the screw and clamp.
• Fully insert the prongs into the power outlet socket. A loose connection may cause image degradation.
NOTE: Please refer to the “Safety Precautions and
Maintenance” section of this user’s manual for proper selection of an AC power cord. (Recommended Fasten Force: 139 - 189N•cm).
2. Install the remote control batteries
The remote control is powered by two 1.5V AAA batteries. To install or replace batteries:
A. Press and slide to open the cover. B. Align the batteries according to the (+) and (–) indications
inside the case.
C. Replace the cover. CAUTION: Incorrect usage of batteries can result in leaks or
bursting.
English-14
Screw
Clamp
5. Switch on the power of all the attached external equipment
When connected with a computer, switch on the power of the computer fi rst.
6. Operate the attached external equipment
Show the signal on the screen from the desired input source.
7. Adjust the sound
Make volume adjustments when required.
8. Adjust the screen (See pages 33 and 34)
Make adjustments to the image position, if necessary.
9. Adjust the image (See page 32 and 33)
Make adjustments such as backlight or contrast when required.
10. Recommended Adjustments
To reduce the risk of the “Image Persistence”, please adjust the following items based on the application being used: “SCREEN SAVER”, “SIDE BORDER COLOR” (See page 40), “DATE & TIME” (See page 36), “SCHEDULE SETTINGS” (See page 35). It is recommended that the “FAN CONTROL” setting (See page 40) be checked ON also.
English
English-15

Connections

USB port
(Type-A)
USB port
(Type-
NOTE: Do not connect or disconnect cables when turning on the monitor’s main power or other external equipment’s power,
as this may result in a loss of the monitor image.
NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.
Before making connections:
* First turn off the power of all the attached equipment and make connections. * Refer to the user’s manual included with each separate piece of equipment. * Connecting or disconnecting a USB storage device or a microSD memory card to the monitor when the monitor’s main
power is off.

Wiring Diagram

USB devices
such as
USB port
(Type-A)
USB cable
Computer (USB)*
Stereo Amplifi er
VCR Player or
DVD Player (Video)
USB port
(Type-BB))
1, *2
USB1
USB2
USB CM1 (2A)
USB CM2
USB MP
USB camera or
USB memory
Devices that
require power
supply:
Ex: MP-02,
Multi presenter
stick
USB storage
device
Computer (Digital)
DVD Player (HDMI) or
Computer (HDMI)
AV Amplifi er
DVD Player
(HDMI)
DVD Player or
Computer
Solid lines = video signal Dotted lines = audio signal
*: Multiple monitors that are daisy-chained have a limit to the connectable monitors. *1: The device connected to USB2 can control the device connected to USB1. *2: The device connected to USB2 allows the touch panel function to work.
Connected equipment
AV
Connecting terminal
DVI DVI MODE: DVI-HD DVI IN1/IN2 DVI HDMI IN1 VIDEO LEVEL: RAW/EXPAND* HDMI IN2 VIDEO LEVEL: RAW/EXPAND*
DisplayPort IN1 VIDEO LEVEL: RAW/EXPAND* DisplayPort IN2 VIDEO LEVEL: RAW/EXPAND*
Setting in
TERMINAL SETTINGS
3
3
3
3
VGA (RGB, YPbPr) VGA MODE: RGB VGA (RGB) IN1/IN2 VGA (RGB/YPbPr) VGA (RGB, YPbPr) VGA MODE: YPbPr VGA (YPbPr) IN1/IN2 VGA (RGB/YPbPr)
PC
VIDEO IN — VIDEO IN1/IN2 VIDEO
Option board slot (SLOT2) VIDEO LEVEL: RAW/EXPAND*
DVI DVI MODE: DVI-PC/DVI-HD DVI IN1/IN2 DVI HDMI IN1 VIDEO LEVEL: RAW/EXPAND* HDMI IN2 VIDEO LEVEL: RAW/EXPAND*
DisplayPort IN1 VIDEO LEVEL: RAW/EXPAND* DisplayPort IN2 VIDEO LEVEL: RAW/EXPAND*
3
3
3
3
3
VGA (RGB, YPbPr) VGA MODE: RGB VGA (RGB) IN1/IN2 VGA (RGB/YPbPr) VGA (RGB, YPbPr) VGA MODE: YPbPr VGA (YPbPr) IN1/IN2 VGA (RGB/YPbPr)
VIDEO IN — VIDEO IN1/IN2 VIDEO
Option board slot (SLOT2) VIDEO LEVEL: RAW/EXPAND*
3
*3: Please set appropriate setting for input signal.
DVD Player
(HDMI)AVAmplifi er
Computer (DisplayPort)
Computer (DisplayPort)
Second monitor*
Computer (Analog)
DVD Player (component)
Computer
DVD Player Stereo Amplifi er
VCR player or DVD player
Input signal
name
Connecting audio terminal
Input button in remote control
HDMI1 HDMI1 HDMI1
HDMI2 HDMI2 HDMI2 DisplayPort 1 DisplayPort 1 DisplayPort 1 DisplayPort 2 DisplayPort 2 DisplayPort 2
OPTION OPTION (ANALOG/DIGITAL)*
3
OPTION
HDMI1 HDMI1 HDMI1
HDMI2 HDMI2 HDMI2 DisplayPort 1 DisplayPort 1 DisplayPort 1 DisplayPort 2 DisplayPort 2 DisplayPort 2
OPTION OPTION (ANALOG/DIGITAL)*
3
OPTION
English-16

Connecting a Personal Computer

Connecting your computer to your LCD monitor will enable you to reproduce your computer’s video signal output. Some display cards may not be able to support the required resolution for proper image reproduction. Your LCD monitor shows proper image by adjusting the factory preset timing signal automatically.
<Typical factory preset signal timing>
Resolution
640 x 480 31.5 kHz 60 Hz Yes Yes Yes Yes Yes Yes
800 x 600 37.9 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1024 x 768 48.4 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1280 x 720 45.0 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1280 x 768 47.8 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1280 x 800 49.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1280 x 960 60.0 kHz 60 Hz Yes Yes No No No No
1280 x 1024 64 kHz 60 Hz Yes Yes Yes Yes Yes Yes
1360 x 768 47.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1366 x 768 47.7 kHz 60 Hz Yes Yes Yes Yes Yes Yes
1400 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes Yes Yes
1440 x 900 55.9 kHz 60 Hz Yes Yes Yes Yes Yes Yes
1600 x 1200 75.0 kHz 60 Hz Yes Yes Yes Yes Yes Yes Compressed image 1680 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes Yes Yes 1920 x 1080 67.5 kHz 60 Hz Yes Yes Yes Yes Yes Yes Recommended resolution 1920 x 1200 74.6 kHz 60 Hz Yes No Yes Yes Yes Yes Compressed image 1920 x 2160 133.3 kHz 60 Hz No No Yes Yes Yes Yes Compressed image 3840 x 2160 65.7 kHz 30 Hz No No No No Yes Yes Compressed image 3840 x 2160 67.5 kHz 30 Hz No No Yes Yes No No Compressed image 3840 x 2160 133.3 kHz 60 Hz No No No Yes No Yes* Compressed image 3840 x 2160 135.0 kHz 60 Hz No No No Yes No Yes* Compressed image 4096 x 2160 54.0 kHz 24 Hz No No Yes Yes No No Compressed image
*: Only HBR2 is set.
Scanning frequency
Horizontal Vertical MODE1 MODE2 1.1a 1.2
VGA DVI
• If you use with a Apple Macintosh® series computer device, set “Mirroring” to off on your device.
®
Refer to your Apple Macintosh
series computer user’s manual for more information about your computer’s video output
requirements and any special identifi cation or confi guration your monitor’s image and monitor may require.
• Input TMDS signals conforming to DVI standards.
• To maintain the image reproduction quality, use a cable that conforms to DVI standards.
HDMI DisplayPort
Remarks
English

Connecting a Player or Computer with HDMI

• Please use an HDMI cable with HDMI logo.
• It may take a moment for the signal to appear.
• Some display cards or drivers may not display an image correctly.
• When you use a computer with HDMI, please set OVER SCAN to “AUTO” or “OFF” (see page 34).
• Please check display card when image is compressed with 1920 x 1080.
• To output HDMI audio, set [HDMI1] or [HDMI2] at AUDIO INPUT in OSD or choose [HDMI1] or [HDMI2] by remote control AUDIO INPUT button.
• If the input resolution is 3840 x 2160 (60 Hz), please set MODE2 at HDMI in TERMINAL SETTINGS (See page 37).
• If the monitor’s main power is turned on after a connected computer to the monitor is turned on, sometimes images are not displayed. In this case, please turn off the computer then turn it on again.

Connecting a Computer with DisplayPort

• Please use DisplayPort cable with DisplayPort compliance logo.
• To use the DisplayPort out connector, please refer to Video out (See page 61).
• It may take a moment for the signal to appear.
• When connecting a DisplayPort cable to a component with a signal conversion adapter, an image may not appear.
• Select DisplayPort cables feature a locking function. When removing this cable, hold down the top button to release the lock.
• To output DisplayPort audio, set [DisplayPort1] or [DisplayPort2] at AUDIO INPUT in OSD or choose [DisplayPort1] or [DisplayPort2] by remote control AUDIO INPUT button.
• To display individual images at each connected monitors with the DisplayPort out connector, please set DisplayPort1.2 and MST at DisplayPort in the TERMINAL SETTINGS (See page 37).
• If the monitor’s main power is turned on after a connected computer to the monitor is turned on, sometimes images are not displayed. In this case, please turn off the computer then turn it on again.
English-17

Connecting a USB device with USB port

USB1: USB downstream port (Type-A). Connect a USB compatible fl ash memory or keyboard to Down Stream Port.
USB2: USB upstream port (Type-B). Connect to a USB compatible computer with a USB cable. A USB compatible computer connected to USB2 can control the devices connected to USB1. The device connected to USB2 allows the touch panel function to work.
USB CM1 (2A): Power supply port. Please refer to the specifi cations page for power supply information (see pages 65, 66 and 67).
USB CM2: Service port. Please do not connect devices.
USB MP: USB downstream port (Type-A). To use Media player function, please use this port.
• Please make sure about the connector shape and orientation when connecting the USB cable.
• Depending on the use of computer BIOS, OS or device, the USB function may not be working. In this case, please check user’s manual of your computer or device, or contact your supplier for detailed information.
• Before turning off the main power switch of the monitor or shutting down Windows remove the USB cable from the monitor. You may lose data when the computer crashes.
• It may take a few seconds until the monitor recognizes the USB input. Do not disconnect the USB cable or disconnect and reconnect the USB cable before the monitor recognizes the input.
• You can set power supply for USB CM1 (2A) at USB POWER in the OSD menu (see page 43).
• Please use a USB cable which supports 2A to USB CM1 (2A).
• Please refer to the USB in the OSD menu (See page 43) for the USB setting.
NOTE: USB CM1 (2A) and USB CM2 are not corresponding port.
Please refer to the connection (See page 16) to connect USB devices to the monitor.
®
, please turn off the USB function and

For using Touch Panel

1. Turn off the monitor.
2. Install the equipment.*
- Using slot 2 type PC: Connect the slot 2 type PC into the option board slot. NOTE: Please refer to the slot 2 type PC’s manual for connection. NOTE: When you set option board accessory other than slot 2 type PC, touch function may not work.
- Using external computer: Connect the B type connector to the USB upstream port on the left back side of the monitor and the A type connector to the downstream port on the external computer (Figure 1).
3. Turn on the monitor.
*1: Please contact your NEC customer support for more detailed information.
Please contact your NEC customer support for the setting of the touch panel function in multiple screens.
Monitor Setting
Select the input signal.
- Using slot 2 type PC: Select [OPTION]
- Using external computer: Select the input signal which is supplied by the computer connected to USB connector.
NOTE: Please refer to “The touch panel does not respond” in
“Troubleshooting” when the touch panel function does not work.
1
A: Sensor
B Type
A Type
Computer
Figure 1
English-18

Basic Operation

Power ON and OFF Modes
The LCD monitor power indicator will turn blue while powered on. NOTE: The Main Power switch must be in the ON position in order to power up the monitor using the remote control or the
Power button.
OFF
Main Power Switch
ON
English
Power Button
Using the remote control
POWER ON button
English-19
Power Indicator
LED indicator
status and
lighting pattern
Glowing blue Normal Blinking green*
Glowing amber The monitor has been past a
Blinking amber The monitor has been past a
Glowing red Turn off the monitor by the
*1: Time setting for AUTO POWER SAVE is available at POWER SAVE (See page 40).
1
Meeting one of the conditions below when the monitor has been past a certain amount of time with no signal input which you set.
• The monitor is with an option
• INPUT DETECT is set to a
• USB POWER is set to ON.
• DisplayPort is set to MST.
certain amount of time with [network signal input] + [no AV signal input which you set].
certain amount of time with [network signal input] + [no AV signal input which you set].
remote control or the monitor button.
Condition Recovery
board.
setting except for NONE.
1. Turn on the monitor by the remote control or the monitor button.
2. Send an AV signal input to the monitor.
Turn on the monitor by the remote control or the monitor button.
NOTE: If the indicator is glowing a combination of long
and short in red, a certain failure might have occurred, please contact your supplier.
Using Power Management
This LCD monitor follows the VESA approved DPM Display Power Management function. The power management function is an energy saving function that automatically reduces the power consumption of the monitor when the keyboard or the mouse has not been used for a fi xed period. This allows your LCD monitor to enter a Power Management mode if the monitor’s POWER SAVE function is set to ENABLE then a certain amount of time is past since the monitor recognized “no signal input”. It will increase the life and decrease the power consumption of the monitor.
NOTE: Depending on the computer and display card
used, this function may not operate. After the video signal was lost, the monitor automatically goes into OFF at a preset time period.
Aspect
For MP, VIDEO
FULL ZOOM NORMAL
For DVI, DisplayPort1, DisplayPort2, VGA (RGB), OPTION*
FULL 1:1 ZOOM NORMAL
For VGA (YPbPr), HDMI1, HDMI2
FULL WIDE DYNAMIC 1:1 ZOOM NORMAL
*1: This function depends on which option board you are using.
Aspect ratio
of image
Unchanged view*
Recommended selection
3
for picture aspect*
NORMAL
4:3
DYNAMIC
FULL
Squeeze
WIDE
Letterbox
*3 Grey areas indicate unused portions of the screen.
NORMAL: Reproduces the aspect ratio that is sent from the source.
FULL: Fills the entire screen. WIDE: Expands a 16:9 letter box signal to fi ll the entire
screen. DYNAMIC: Expands a 4:3 pictures to fi ll the entire screen
with non-linearity. Some of the outside image area will be cut off due to expansion.
1:1: Shows the image in a 1 by 1 pixel format.
ZOOM
The image can be expanded beyond the active screen area. The image which is outside of the active screen area is not shown.
ZOOM
1
3
English-20
ZOOM
