NEC PlasmaSync 42VP4, PlasmaSync 42VP4D, PX-42VP4A, PX-42VP4DP-A, PX-42VP4DA Specifications

PlasmaSync

®

42VP4 and 42VP4D

a view

from all

angles

Whatever the angle, clear images give you
a clear advantage

Stop them in their tracks!

NEC’s new 42” Public Display Series PlasmaSync
monitors draw your audience right into your
message and command their attention. Super
bright images, pure reds and saturated colors
combined with built in stereo audio make sure
your message is always loud and clear no matter
what your environment or your angle. In areas
with direct lighting an anti-glare filter on the
42VP4D keeps images vibrant and contrast high
while the 42VP4 features an anti-reflective filter
for areas with controlled lighting. Either way, the
view will be picture perfect every time.

A sleek new design with cable management
system, programmable timer and portrait
capability make them the perfect choice for any
public environment. No matter how you look at it,
the new 42” Public Display Series gives you a
clear opportunity to get their attention
and sell!

42VP4, Anti-Reflective (AR) filter

42VP4D, Anti-Glare (AG) filter

digital AccuDevice

MASS (Mass Area Superior Sampling

Technology)

industry-lowest

power consumption

20% brighter

cable mangement

programmable timer

motion compensated

3D scan conversion

3/2 pull down

The 42VP4D features
an anti-glare filter
which diffuses direct
light sources. Image
is easy to see under
even severe lighting
conditions

The 42VP4 features
an anti-reflective
filter for controlled
lighting situations.
Provides a sharp
and crisp image.

capsulated

color filter



superior image no matter how you view it

The 42 Public Display Series offers wide VGA native
resolution to give your ideas more power and clarity than
ever. The monitor ’s wide VGA panel provides a sharp, crisp
display of high-resolution text and graphics and its
progressive scan driving method offers stable, flicker-free
images. Advanced AccuBlend scan conversion provides
high quality scaling for non-native resolutions signals. And
sophisticated video signal processing, including motion­compensated 3D scan conversion and 3/2 pull down
processing, delivers smooth, lifelike video. NEC ’s patented
Capsulated Color Filter ensures realistic color and it’s
further enhanced by AccuCrimson technology for the
purest reds possible.

connect every which way

Connect to multiple sources from video to HD to RGB.
Signal loop-out capability allows a source to easily be
looped from one monitor to the next allowing you to
connect 4 displays without the use of an external DA*.

suit your style with portrait or landscape

Depending on your needs, you can display in either portrait
or landscape orientation.

matrixing simplified

The built-in matrix gives you greater flexibility by allowing
you to arrange the monitors in a 2x2 (84”) or 3x3 (126”)
matrix without an external processor. The Auto ID feature
allows the setup of the matrix to be simpler. The repeat
timer allows two different matrix settings, creating a self
running demo.

adjustment
capabilities

orientation

features

special

digital AccuDevice and MASS technology for smooth lines

The newly developed Digital AccuDevice, delivers jitter free images and reduces distortion. MASS
technology smooths jagged lines and corrects color bleeds for clear stable color images and easy-to­read text.

save your screen with AccuShield phosphor protection

Your screen stays protected from image retention with the most comprehensive set of built in modes
including programmable Orbiter, Inverse RGB, All-White, Pixel Refresh and Brightness Limiter.

your message gets heard

No need to purchase and attach a separate audio component to your monitor. The built in stereo
amplifier provides 8W x 8W making sure your message is loud and clear.

convenient and sleek

The cabinet design allows for a small form PC to be attached solving the problem of source equipment
location. A cable management system allows you to achieve a clean appearance without costly
enclosures.

fanless design for quiet operation

The 42VP4 and 42VP4D features a fanless design in both portrait and landscape for silent operation no
matter what environment it is in.

virtually self-operating

A programmable timer can be set up to virtually operate itself by setting power on/off, changing inputs
and selecting AccuShield modes.

ecological design

Power consumption 275W is the lowest in the industry.

external control and self diagnostics

A complete set of RS232 commands allow monitor functions to be operated remotely via serial
communications. In addition, operating problems can be identified and communicated via RS232 or
front bezel LED lights through its self diagnostics system.

portrait positioning

NEC ’s patented Capsulated Color Filter ensures realistic color and it’s further enhanced by

AccuCrimson technology for the purest reds possible.

without AccuCrimson

AccuShield showing inverse RGB function

on screen menu

with AccuCrimson

landscape positioning

menu
enter

volume

down/
cursor

down

volume

up/

cursor

up

cursor

left

cursor

right

input

select

PlasmaSync
42VP4 and 42VP4D

NEC 120204

For more information, call (800) NEC-INFO
or visit www.necvisualsystems.com

NEC is a registered trademark of NEC Corporation.
All other trademarks are the property of their respective owners.
All specifications subject to change without notice.

NEC Solutions (America), Inc.
Visual Systems Division
1250 Arlington Heights Rd., Suite 500
Itasca, IL 60143-1248

Specifications

Model Number PX-42VP4A / PX-42VP4DA
Diagonal Screen Size 42"
Screen Aspect Ratio 16 to 9
Active Screen Area 921mm x 518 mm
Native Pixel Resolution 853 vertical dots x 480 horizontal rows
Pixel Pitch 1.08 mm square
Front Filter Type AR - Anti-reflective (PX-42VP4A)

AG - Anti-glare (PX-42VP4DA)
Color Processing (4096 steps) 68.7 billion colors
Viewing Angle 160 degrees
Horizontal Frequency Range 15.5 to 110.0 kHz auto, step scan
Vertical Frequency Range 50 to120 Hz auto, step scan
PC Signal Compatibility VGA 640x480 @ 60,72,75,85,100, 120 Hz

SVGA 800x600 @ 56, 60, 72,75,85,100,120 Hz

XGA 1024x768 @ 60,70,75, 85, 100 Hz

SXGA 1280x1024 @ 60, 75, 85, 100 Hz

UXGA 1600x1200 @ 60, 65, 70, 75, 85 Hz

WideVGA 848x480, 852 x 480 @ 60 Hz

WideXGA 1360 x 765 @60 Hz
Macintosh Compatibility 640x480, 832x624, 1024x768, 1152x870
Video Signal Compatibility PAL, SECAM, 3.58/4.43 NTSC
HD Video Signal Compatibility 480p 480i, 525p, 525i, 540p, 625p, 625i, 720p,1035i, 1080i
Input Terminals RGB 1 (analog) 15-pin mini D-sub (common use with RGB out, selectable)

RGB 2 (analog) 5 BNC (RGB/HV) (common use with 5BNC Y/Pb/Pr input, selectable)

RGB 3 (digital) 29-pin DVI (digital only)

Video 1 Composite BNC x 1 (common use with video out, selectable)

Video 2 Composite RCA x 1

Video 3 S-Video 4-Pin DIN

HD Video 1 1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr)

HD Video 2 1 set BNC Component (Y,Pb,Pr/Y,Cb,Cr)

(common use with 5BNC Y/Pb/Pr input,selectable)

Audio 3 sets RCA stereo + external speaker jacks
Output terminals RGB (analog) 15 PIN mini D-sub (common use with RGB1, selectable)

Video Composite BNC (common use with Video1, selectable)
Audio Internal amplifier, 8W x 2 output power
External Control 9-pin mini D-Sub, RS232
User Controls Direct Access Power on/off, input selection, volume up/down, OSM access, (Control

Lock Switch located on input panel)

Remote Control Power on/off, input select, volume, mute, wide, display, off-timer, OSM

control, cursor, pointer, zoom, auto, select

OSM Picture - Contrast, brightness, sharpness, color, tint, color temperature, white

balance, picture mode, noise reduction, gamma, low tone and color tune

Audio - bass, treble, balance and audio input
Image Adjust - aspect ratio mode, vertical position, horizontal position,

vertical height, horizontal width, fine picture, picture adjust, auto picture
Option 1 - OSM on/off, BNC Input, D-sub Input, RGB select, HD select,
Input Skip, All Reset

Option 2 - Pwr. Management, Cinema Mode, Long Life Mode
Option 3 - T imer, Pwr. On mode, Control Lock, IR Remote, Loop Out, ID

Number, Video Wall

Advanced OSM, Language, Color System, Source Information
Plug & Play DDC1, DDC2B (RGB3 is DDC2B only)
Power Requirements 120V 50/60 Hz
Power Consumption 275 W Typical, 3.7 Amp Maximum
Standby Power 0.9W
Dimensions (WxHxD) - 40.1 x 24.0 x 3.5 inches, 1018 x 610 x 89mm (without base)
Weight 28.5 kg, 62.8 lbs. (without tabletop stand)
Environmental Considerations Operating Temperature 32 - 104 degrees F (0 - 40 degrees C)

Operating Humidity 20 - 80%
Operating Altitude 0 - 9180 feet (0 - 2800m)
Storage Temperature 14 - 122 degrees F (-10 - 50 degrees C)
Storage Humidity 10 - 90%

Storage Altitude 0 to 9840 feet (0 - 3000m)
Warranty 1 Year Parts & Labor Standard
Regulatory FCC Class A, UL1950, CSA950
Included Accessories AC Power Cord, User Manual, Remote Control, Batteries, Cable Clamps
Optional Accessories Tabletop Stand PX-ST1U

Attachable Speakers PX-42SP1U

Terminal Cover PX-CV1U

Fixed Wall Mount FWMK

Tilt Wall Mount TWMK

Ceiling Mount CMK

Fixed Wall Mount for PC FWMKPC

Tilit Wall Mount for PC TWMKPC

Ceiling Mount for PC CMKPC
*Signal DA is required for sending a signal to more than 4 monitors simultaneously.

Service and Support

The PlasmaSync 42VP4 and 42VP4D are supported by NEC’s
industry leading service and support programs. It comes with
a standard 1-year manufacturer’s warranty plus an extended
warranty option that provides two additional years of
coverage and is available from your authorized NEC Visual
Systems Division dealer.

Video 1 / Video Out

Audio 1

RGB2 / DVD2 / HD2 Input

RGB1 / RGB Out

DVI

Audio 3

Video 2
Video 3

DVD1 / HD1

Audio 2

External Control

Remote In / Out

36.3”

(921mm)

40.1”

(1018mm)

24”

(610mm)

3.5”

(89mm)

20.4”

(518mm)
