N411i_StarHub_v1.2_English_master Software version: FADD0C0N_C34
Personalization: 34_002_SI_FADD0C0N_N411i.ini
Emergency Services and Safety
Precautions
Emergency Services
To make an emergency call in any country
Press 1 1 2 .
Ask the operator for the service which you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain Rescue Services. Give your position and, if possible, remain stationary to maintain phone contact.
The 112 emergency number service is available on every digital network service. The number 999 is an alternative emergency number for the UK only, and can only be used with a valid SIM card.
2Due to the nature of the cellular system, the success of emergency calls cannot be guaranteed.
General Care
A cellphone contains delicate electronic circuitry, magnets, and battery systems. You should treat it with care and give particular attention to the following points.
•Do not allow the phone or its accessories to come into contact with liquid or moisture at any time.
•Do not place anything in the folded phone.
•Do not expose your phone to extreme high or low temperatures.
•Do not expose your phone to naked flame, cigars or cigarettes.
•Do not paint your phone.
•Do not drop or subject your phone to rough treatment.
•Do not place the phone alongside computer disks, credit cards, travel cards and other magnetic media. The information contained on disks or cards may be affected by the phone.
•Do not leave the phone or the battery in places where the temperature could exceed 60°C; e.g. on a car dashboard or on a window sill, behind glass in direct sunlight, etc.
•Do not remove the phone’s battery while the phone is switched on.
•Take care not to allow metal objects, such as coins or key rings, to contact or shortcircuit the battery terminals.
•Do not dispose of battery packs in a fire. Your phone's Li-ion batteries may be safely disposed of at Li-ion recycling points. For more specific battery and power supply information, see page 3.
•Do not put your phone's battery in your mouth as battery electrolytes may be toxic if swallowed.
•Do not attempt to dismantle the phone or any of its accessories.
•This equipment is fitted with an internal battery that can only be replaced by a qualified service engineer. There is a risk of explosion if the battery is replaced by an incorrect type. Dispose of the used battery in accordance with the manufacturer's instructions.
•Using any battery pack, AC adapter, Vehicle power adapter (option) or accessory not specified by the manufacturer for use with this phone creates a potential safety hazard.
•The earpiece may become warm during normal use and the unit itself may become warm during charging.
•Use a damp or anti-static cloth to clean the phone. Do NOT use a dry cloth or electrostatically charged cloth. Do not use chemical or abrasive cleaners as these could damage the case.
•Remember to recycle: the cardboard packaging supplied with this phone is ideal for recycling.
•Do not leave the battery pack empty or disconnected for a long time, otherwise some data may be initialized.
•Your phone contains metal which may cause you an itch, a rash or eczema depending on your constitution or physical condition.
•Take care not to put your phone in the back pocket of your trousers or skirt and then sit on it. Also, do not put your phone at the bottom of bag where it may subject to excessive weight or pressure.
Doing so may damage the LCD and camera lens and cause them malfunction.
•Take care not to hold the Light too close to your or other people’s eyes when the Light is lit.
•Do not aim or direct the InfraRed (IR) data port towards your or other people’s eyes when using the IR data exchange.
•The foam covers the earpiece of the headset. Do not put any other part of the headset in your ears.
Aircraft Safety
•Switch off your phone and remove its battery when inside or near aircraft. The use of cellphones in aircraft is illegal. It may be dangerous to the operation of the aircraft and it may disrupt the cellular network. Failure to observe this instruction may lead to suspension or denial of cellphone service to the offender, or legal action, or both.
•Do not use your phone on the ground without the permission of the ground crew.
Hospital Safety
•Switch off your phone in areas where the use of cellphones is prohibited. Follow the instructions given by the respective medical facility regarding the use of cellphones on their premises.
General Safety
•Observe ‘Turn off 2-way radio’ signs, such as those near stores of fuel, chemicals or explosives.
•Do not allow children to play with the phone, charger or batteries.
•Small parts are included in your phone. Keep them out of reach of small children, for whom it could be a choking hazard.
•The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected if a cellphone is used next to them. Observe any warning signs and manufacturer's recommendations.
•If you have a weak heart, you should take extra precautions when setting functions such as the Vibrator and Ringer volume functions for incoming calls.
•If you set the Vibrator setting to anything other than OFF, be careful that the phone is not near a source of heat (e.g. a heater) and that it does not fall from a desk due to the vibration.
Road Safety
•You MUST exercise proper control of your vehicle at all times. Give full attention to driving.
•Observe all the recommendations contained in your local traffic safety documentation.
•Pull off the road and park before making or answering a call if driving conditions so require.
•You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an emergency.
•Switch off your phone at a refuelling point, such as a petrol station, even if you are not refuelling your own car.
•Do not store or carry flammable or explosive materials in the same compartment where a radio transmitter, such as a cellphone, is placed.
•Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment can advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio transmissions, consult your dealer and do not switch on your phone until it has been checked by qualified approved installers.
Vehicles Equipped with an Air Bag
An air bag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.
Third Party Equipment
The use of third party equipment, cables or accessories, not made or authorized by NEC, may invalidate the warranty of your cellphone and also adversely affect the phone’s operation. For example use only the NEC mains cable supplied with the AC charger.
Service
The cellphone, batteries and charger contain no user-serviceable parts. We recommend that your NEC cellphone is serviced or repaired by an NEC authorized service centre. Please contact your Service Provider or NEC for advice.
Non-Ionizing Radiations
The radio equipment shall be connected to the antenna via a non-radiating cable (e.g. coax).
The antenna shall be mounted in a position such that no part of the human body will normally rest close to any part of the antenna unless there is an intervening metallic screen, for example, the metallic roof.
Use only an antenna that has been specifically designed for your phone. Use of unauthorized antennas, modifications or attachments could damage your phone and may violate the appropriate regulations, causing loss of performance and radio frequency (RF) energy above the recommended limits.
Efficient Use
For optimum performance with minimum power consumption, note the following:
•Your phone has the internal antenna. Do not cover part of the internal antenna of the phone with your hands. This affects call quality, may cause the phone to operate at a higher power level than needed and may shorten talk and standby times.
Radio Frequency Energy
Your phone is a low-power radio transmitter and receiver. When it is turned on, it intermittently receives and transmits radio frequency (RF) energy (radio waves). The system that handles the call controls the power level at which the phone transmits.
Exposure to Radio Frequency Energy
Your phone is designed not to exceed the limits for exposure to RF energy set by national authorities and international health agencies. * These limits are part of comprehensive guidelines and establish permitted levels of radio wave exposure for the general population. The guidelines were developed by independent scientific
organizations such as ICNIRP (International Commission on Non-Ionizing Radiation Protection) through periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health, and to account for any variations in measurements. *Examples of radio frequency exposure guidelines and standards that your phone is designed to conform to:
•ICNIRP, “Guidelines for limiting exposure to time-varying electric, magnetic, and electromagnetic fields (up to 300 G Hz)-International Commission on Non-Ionizing Radiation Protection (ICNIRP)”.
Health Physics, vol. 74. pp, 494-522, April 1998.
•99/519/EC Council Recommendation on the limitation of exposure to the general public to electromagnetic fields 0 Hz-300 GHz, Official Journal of the European Communities, July 12,1999.
•ANSI/IEEE C95.1-1992. “Safety levels with respect to human exposure to radio frequency electromagnetic fields, 3kHz to 300 GHz”. The Institute of Electrical and Electronics Engineers Inc., New York, 1991.
•FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications Commission (FCC), August 1996.
•Radio communications (Electromagnetic Radiation Human Exposure) Standard 2003, Australian Communications Media Authority.
Declaration of Conformity
•This product complies with the requirements of the R&TTE Directive 1999/5/EC. The ‘Declaration of Conformity’ leaflet can be found within this box.
Licenses
•T9® Text Input and the T9 logo are registered trademarks of Tegic Communication. “T9 Text Input is licensed under one or more of the following:
U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548, 6,307,549, and 6,636,162, 6,646,573; Australian Pat. Nos. 727539, 746674, and 747901; Canadian Pat. Nos. 1,331,057, 2,302,595, and 2,227,904; Japan Pat. No. 3532780, 3492981; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK1010924; Republic of Singapore Pat. No. 51383, 66959, and 71979; European. Pat. Nos. 0 842 463 (96927260.8), 1 010 057 (98903671.0), 1 018 069 (98950708.2); Republic of Korea Pat. Nos. KR201211B1 and KR226206B1. People’s Republic of China Pat. Application Nos. 98802801.8, 98809472.X and 96196739.0; Mexico Pat. No. 208141; Russian Federation Pat. No. 2206118; and additional patents are pending worldwide”
•USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4
VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO
(A) DATA OR INFORMATION ENCODED BY A CONSUMER FOR PERSONAL AND NON-COMMERCIAL USE WITHOUT REMUNERATION; (B) DATA OR INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY; AND (C) OTHER USES SPECIFICALLY AND SEPARATELY LICENSED BY MPEG LA, L.L.C.
•Helvetica is a registered Trademark of Heidelberger Druckmaschinen AG which may be registered in certain jurisdictions.
•©2002 Music Airport Inc., http://www.music-airport.com/
•Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc in the U.S. and other countries.
ii Emergency Services and Safety Precautions
•This product contains ACCESS Co., LTD’s Compact NetFront™ Plus internet browser software.
Copyright © 1998-2005 ACCESS CO., LTD.
Compact NetFront™ is a registered trademark or
trademark of ACCESS CO., LTD in Japan and selected countries worldwide.
•This product contains ACCESS CO., LTD’s JV-Lite2™ Java virtual machine software. Copyright © 2000-2005 ACCESS CO., LTD.
JV-Lite2™ is a registered trade mark or trademark of ACCESS COl, LTD, in Japan and selected countries world wide.
•Copyright 2005 Aplix Corporation and eSOL Co., Ltd. All Rights Reserved.
•This Mobile Printing Ready product is designed to provide easy printing from mobile phones. This product follows Mobile Imaging and Printing Consortium (MIPC) guidelines version 1.0 for PictBridge.
•The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by NEC is under license. Other trademarks and trade names are those of their respective owners.
•This product contains ACCESS CO., LTD's IrFront® Infrared communication software. Copyright ©1996-2005 ACCESS CO.,LTD.
•i-mode and i-mode logos are trademarks or registered trademarks of NTT DoCoMo.
For the purpose of improvement, the specifications for this product and its accessories are subject to complete or partial change without prior notice.
Emergency Services and Safety Precautions iii
The instructions in this user’s manual make use of the shortcuts selection except special cases.
The following markers are used throughout the user’s manual to attract your attention:
This type of paragraph will contain details of where to find information related to the topic in question. 2 This type of paragraph will contain information worth noting.
,This type of paragraph will contain important information.
This type of description will contain procedures to operate your phone.
Menu shortcuts selection
The alternative shortcuts method of selection lets you jump straight to a menu or function without highlighting an icon and scrolling through the intermediate menu options. The selection is made by pressing numbers which relate to the displayed menu options.
2 The instructions in this user’s manual make use of the shortcuts selection, except in special cases.
Reading the titles
Some titles in this manual contain information on how to access the functions. In these titles, M stands for , the numbers indicate the menu shortcut numbers (see “Overview of menu function” on page xi for details) and ... (three periods) indicate that there are more operations described in the paragraph.
Reading the procedures
“Highlight” means to use the four way navigation keys ( “Select” means to highlight an item and then press .
▼
▼
) to move the area emphasized with different colouring.
Procedures are written omitting the verb “press”, except in some special cases.
For example, 1 2 means to:
Start from the standby screen Press to display the Main menu screen
Press 1 to display the Settings screen Press 2 to display the Phone modes screen
Simple procedures are connected by arrows ( ).
Check box/Radio button
A check box enables/disables an option out of a set of options, and multiple check boxes can be selected at the same time. On the other hand, selecting a radio button automatically cancels the previous selection, so only one radio button can be selected at one time.
A check box/radio button option can be selected/cancelled by highlighting it and pressing .
iv Before You Start
Desktop icon area
This area contains the automatically displayed and the manually created desktop icons. They provide shortcuts to certain items/functions.
Help area |
|
This area contains clock |
|
information and help |
|
information appropriate |
|
for the current screen |
SK1/SK2 |
(e.g. key presses |
|
remaining when |
This area contains context |
composing a message). sensitive descriptions of the Softkeys’ functions appropriate for the current screen.
Menu title
Status bar area
This area contains icons which indicate the battery strength, new SMS/MMS message(s), signal strength, etc. (see page viii).
Shortcut number
Press the appropriate number to jump straight to a next menu. The row colour is changed when selected (e.g. to activate/ deactivate a facility).
Shortcut
menu number
The current menu number is displayed.
Page scroll bar
Displayed when you can press ▼ to scroll to the next page.
Next menu icon
Displayed when you can press ▼ or the shortcut number to show the next menu.
,The Liquid Crystal Displays (LCD) on your phone are manufactured using high-precision technology. Even so, the LCD may contain pixels (dots) that fail to light or that remain permanently lit. Note that this is normal and does not indicate a problem with your display.
Before You Start v
Side up key |
Softkey 1 (SK1) |
|
|
MENU ( |
) key |
Side down key |
Celar (CLR)/Back key |
|
|
Send ( |
) key |
Earpiece
Main-LCD
Select ( ) key
4 way navigation ( ) key Softkey 2 (SK2)
Phonebook ( ) key
End/on-off ( ) key
Alphanumeric keys
Mouthpiece
Charger connector cover
Speaker
2nd-LCD
LED/Light
Camera
Through-hole for straps
Earphone jack cover
Rear cover for battery
IR port
,Be careful not to put your finger or foreign objects in the hinge of the phone when your phone is opened.
vi Before You Start
Keypad shortcuts
The following operations are available from the standby screen.
Key |
Operation that involves pressing a key |
See |
Operation that involves pressing and holding a key |
See |
|
page |
page |
||||
|
|
|
|||
|
|
|
|
|
|
|
Accessing the Main menu screen |
xi |
Setting/Cancelling the Side key lock |
22 |
|
|
|
|
|
|
|
SK1 |
Accessing the Mail screen |
45 |
Accessing the Inbox screen |
46 |
|
SK2 |
Accessing the i-mode menu screen |
41 |
Accessing the Java™ applications screen |
70 |
|
|
Accessing the Phonebook list screen |
51 |
Accessing the Message screen |
29 |
|
|
|
|
|
|
|
▲ |
Accessing the Phone modes screen |
23 |
Setting the phone to Meeting mode/Returning to the previous mode |
23 |
|
▼ |
Accessing the My data screen |
64 |
Accessing the voice recall |
8 |
|
|
|
|
|
|
|
▼ |
Accessing the received calls list |
12 |
– |
– |
|
|
|
|
|
|
|
▼ |
Accessing the missed calls list |
12 |
– |
– |
|
|
|
|
|
|
|
|
Accessing the dialled calls list |
12 |
– |
– |
|
|
Highlighting a desktop icon |
21 |
Accessing the homepage |
42 |
|
|
|
|
|
|
|
|
Ending a call or returning to the standby screen |
– |
Powering off |
5 |
|
|
|
|
|
|
|
CLR |
Cancelling the Cell Broadcast message display |
35 |
Deleting all the automatically displayed desktop icons |
20 |
|
Deleting character or returning to the previous screen |
– |
Deleting all characters when you enter text |
– |
||
|
|||||
|
|
|
|
|
|
1 |
Entering phone numbers |
6 |
Calling the Voice mail centre |
57 |
|
2 to 9 |
Entering phone numbers |
6 |
One-touch dial to the corresponding number in the phonebook(SIM) |
8 |
|
0 |
Entering phone numbers |
6 |
Entering + when you make an international call |
14 |
|
# |
Entering # |
6 |
Entering a pause |
– |
|
|
Entering |
6 |
Switching the ALS line 1/2 (if the SIM card supports ALS) |
22 |
|
|
|
|
|
|
|
|
Accessing the volume control screen when your phone is open |
22 |
|
|
|
Side up |
(Use ▲ ▼, Side keys or 0 to 9 keys to adjust the volume.) |
Accessing the camera view finder screen |
58 |
||
|
|||||
|
Activating the ring silencer function when you receive a call |
22 |
|
|
|
|
Accessing the volume control screen when your phone is open |
22 |
Turning on the light |
|
|
Side down |
(Use ▲ ▼, Side keys or 0 to 9 keys to adjust the volume.) |
– |
|||
|
|||||
|
|
|
(To turn it off, press any key or open/close your phone.) |
|
|
|
Activating the ring silencer function when you receive a call |
22 |
|
||
|
|
|
Before You Start vii
Main-LCD
Indicates the battery level.
Indicates the battery charging status (fast, slow, stop).
Indicates that there is a new SMS in your phone.
Indicates that there is a new SMS on the network.
Indicates that the SIM memory is full.
Indicates that the Inbox in your phone is full.
(pink)
Indicates that there are mail and MMS on the server.
(yellow)
Indicates that there is a new mail/MMS in your phone.
viii Before You Start
2This yellow icon blinks while a mail/MMS is being downloaded.
Indicates that the memory for mail/MMS is full. (red, green/red, green)
Indicates that new voice mail messages are on the network (No ALS or ALS Line 1/ALS Line 1 and 2/ALS Line 2).
Indicates secured communication on WTLS in i- mode browsing.
Indicates that your phone is connected to a GPRS modem such as PC.
(gray)
Indicates that the phone is in the GSM (Global System for Mobile communication) network service area and GPRS is active.
(yellow)
Indicates that the GPRS is available and i-mode (PDP Context) is active.
Indicates that the i-mode connection is carried out.
Indicates that the i-mode lock is on.
2No icon appears when the phone is outside the GSM network service area, or when the phone is in the GSM network service area and GPRS is not attached.
Indicates that Bluetooth is set to on, Bluetooth is in operation, IR modem is set to on.
Indicates the line status (No ALS or ALS Line 1/ ALS Line 2). The icon with displayed in red indicates that the ALS line 1 or 2 is unencrypted/ no ALS.
Indicates the signal strength level.
Appears when you are outside the service area.
Network name (indicated in orange when using roaming service)
Desktop icons
See “Desktop icons” on page 20 for details
Indicates the call diversion is set.
Indicates the Meeting mode, Pocket mode, Car mode.
2 No icon appears for the Normal mode.
Indicates sound-off, vibrator-on, sound-off/ vibrator-on.
Indicates alarm-on.
Indicates the auto start of a Java™ application has failed.
Date
Day of week
Remote time
Local time
17
Indicates that you can use the options menu by pressing .
Indicates that you can use the phonebook list by pressing .
Indicates the usable keys in black, while using i- mode or a Java™ application is in operation.
Indicates that the help display is available by pressing when using SIM toolkit.
Indicates that a Java™ application is in operation.
<When the camera/video view finder is in operation>
Indicates single/burst mode (camera).
Indicates the video mode is on or the video is recording.
Indicates that the self timer is on.
Indicates the quality of the picture (super fine, fine, normal, economy or super economy).
Indicates the quality of the video.
Indicates the photo/video screen size.
Indicates the shooting environment.
Indicates the brightness setting. The “+2” setting is the brightest.
Indicates the zoom level.
<When the video preview is in operation>
Indicates the video mode is set to on, the video is playing, on pause, fast forwarding, or rewinding.
Indicates the track information of the video (the video only, the audio only, and the video and audio).
Indicates the video is played in normal/enlarged screen size.
Displays the current volume level. The 0 is mute and 9 is the maximum.
2nd-LCD
Indicates the battery level.
Indicates the battery charging status (fast, slow, stop).
Indicates that there is a new SMS in your phone.
Indicates that there is a new SMS on the network.
Indicates that the SIM memory is full.
Indicates that the Inbox in your phone is full. (pink)
Indicates that there are mail and MMS on the server.
(yellow)
Indicates that there is a new mail/MMS in your mobile phone.
2This yellow icon blinks while a mail/MMS is being downloaded.
Indicates that the memory for a mail/MMS is full
(red, green/red, green)
Indicates that a new voice mail message is on the network (No ALS or ALS Line 1/ALS Line 1 and 2/ALS Line 2).
Indicates the Bluetooth is on, Bluetooth is in active, IR modem is set to on.
Before You Start ix
Indicates the signal strength level.
Appears when you are outside the service area.
Indicates that the phone is in the Meeting/Pocket/ Car mode.
2 No icon appears for the Normal mode.
<When 2nd-LCD is used as the camera view finder screen>
Indicates the battery level.
Indicates the battery charging status (fast, slow, stop).
Indicates single or burst mode of the camera. (blue, red)
Indicates that the video mode is on or the video is recording.
Indicates the photo/video screen size.
Indicates that the self timer is on.
x Before You Start
Standby screen |
Main menu screen |
|
CLR |
|
|
|
The Main menu has a set of icons for its top levels of options which can be selected either
using a combination of the 4-way navigation key (▲ ▼ ▼ ▼ ) and |
(menu selection), |
or just the keypad (shortcuts selection). |
|
2The title of the selected option will be displayed in the Help area.
2SIM toolkit icon is displayed only when your SIM card supports this function.
2With the Main menu screen displayed, 0 to display your own number.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Key |
Main menu |
Second level menu |
|
Key |
Main menu |
Second level menu |
|
Key |
Main menu |
Second level menu |
||||
1 |
Settings |
Phone |
|
3 |
i-mode |
i-mode |
|
7 |
Java |
Programs |
||||
|
|
|
|
|
|
|
|
|
Settings |
|
|
|
|
Prog backlight |
|
|
|
Phone modes |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
4 |
Phonebook |
Lists |
|
8 |
Accessory |
MP3 player |
||
|
|
|
Main-LCD |
|||||||||||
|
|
|
|
|
|
|
|
|
Information # |
|
|
|
|
Calculator |
|
|
|
2nd-LCD |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
Call options |
|
|
|
|
Clock alarm |
|
|
|
Power saving |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
5 |
Camera |
Camera |
|
|
|
|
Scheduler |
|
|
|
|
Calls |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
Video recorder |
|
|
|
|
ToDo list |
|
|
|
Security |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
6 |
My data |
Videos |
|
|
|
|
Notepad |
|
|
|
|
Network |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
Sounds |
|
|
|
|
Voice memo |
|
|
|
Reset settings |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
Pictures |
|
|
|
|
Currency |
2 |
Message |
Inbox |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
MP3 |
|
|
|
|
External connection |
|
|
|
Drafts |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Synchronization |
|
|
|
Outbox |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
9 |
SIM toolkit |
|
|
|
|
|
Sent |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Folder1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Folder2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CB |
|
|
|
|
|
|
|
|
|
|
Before You Start xi
Getting Started |
1 |
|
|
Basic Calls & Phone Use |
6 |
|
|
Text Entry |
16 |
|
|
Desktop icons |
20 |
|
|
Settings (M1) |
22 |
|
|
Message (M2) |
29 |
|
|
i-mode (M3) |
36 |
|
|
Phonebook (M4) |
51 |
|
|
Camera (M5) |
58 |
|
|
My data (M6) |
64 |
|
|
Java™ (M7) |
70 |
|
|
Accessory (M8) |
72 |
|
|
Bluetooth (M891) |
81 |
|
|
IR Data Exchange |
84 |
|
|
Index |
87 |
|
|
Emergency Services and Safety Precautions |
i |
Before You Start |
iv |
User’s manual conventions............................................. |
iv |
Display information .......................................................... |
v |
Parts and functions ......................................................... |
vi |
LCD and displayed icons ............................................... |
viii |
Overview of menu function ............................................. |
xi |
Getting Started |
1 |
Preparing the phone ........................................................ |
1 |
Standby and talk times..................................................... |
4 |
Checking the battery ........................................................ |
4 |
Low battery alarm ............................................................ |
4 |
Other battery alarms ........................................................ |
4 |
Start-up ............................................................................ |
4 |
Basic Calls & Phone Use |
6 |
Making basic calls............................................................ |
6 |
Ending a call .................................................................... |
6 |
Receiving an incoming call .............................................. |
6 |
Unsuccessful calls ........................................................... |
7 |
Emergency calls............................................................... |
7 |
Last number redial ........................................................... |
8 |
One-touch dial.................................................................. |
8 |
Fast dialling...................................................................... |
8 |
Displaying your own phone number (M0/M416) .............. |
8 |
Voice recall ...................................................................... |
8 |
Options menu (during a call)............................................ |
9 |
Putting a call on hold........................................................ |
9 |
Mute ................................................................................. |
9 |
Call transfer.................................................................... |
10 |
Multi-party calls.............................................................. |
10 |
Recording a call ............................................................. |
11 |
Scratchpad number........................................................ |
11 |
Call options (M43).......................................................... |
11 |
Call settings (M16)......................................................... |
13 |
International dialling codes ............................................ |
14 |
Roaming......................................................................... |
15 |
Text Entry |
16 |
Mode change ................................................................. |
16 |
T9® English text input .................................................... |
16 |
Normal text input............................................................ |
17 |
Numeric input................................................................. |
17 |
T9® Chinese Stroke input .............................................. |
18 |
T9® Pinyin input (Simplified Chinese) ............................ |
18 |
T9® Zhuyin input (Traditional Chinese).......................... |
18 |
Key allocations............................................................... |
18 |
Desktop icons |
20 |
Settings (M1) |
22 |
Phone (M11) .................................................................. |
22 |
Phone modes (M12) ...................................................... |
23 |
Main-LCD (M13) ............................................................ |
25 |
2nd-LCD (M14) .............................................................. |
25 |
Power saving (M15) ....................................................... |
25 |
Calls (M16)..................................................................... |
26 |
Security (M17)................................................................ |
26 |
Network (M18) ............................................................... |
27 |
Reset settings (M19)...................................................... |
27 |
Contents |
xiii |
Message (M2) |
29 |
Message overview ......................................................... |
29 |
Reading a message (M21) ............................................ |
30 |
Creating a message....................................................... |
34 |
Cell broadcast (M27) ..................................................... |
35 |
i-mode (M3) |
36 |
i-mode operation guide .................................................. |
36 |
i-mode screen ................................................................ |
40 |
i-mode menu screen ...................................................... |
41 |
iMenu screen ................................................................. |
44 |
Mail screen .................................................................... |
45 |
i-mode glossary ............................................................. |
49 |
Phonebook (M4) |
51 |
Phonebook types ........................................................... |
51 |
Accessing your phonebook (M4) ................................... |
52 |
Phonebook list Options menu........................................ |
52 |
Personal data Options menu ......................................... |
56 |
Voice mail (M417).......................................................... |
57 |
Camera (M5) |
58 |
Notes on using the camera............................................ |
58 |
Taking a picture (M51)................................................... |
59 |
Recording a video (M52) ............................................... |
61 |
My data (M6) |
64 |
Videos (M61) ................................................................. |
64 |
Sounds (M62) ................................................................ |
64 |
Pictures (M63) ............................................................... |
65 |
MP3 (M64) ..................................................................... |
67 |
xiv Contents |
|
File selector Options menu ............................................ |
67 |
Java™ (M7) |
70 |
Programs (M71)............................................................. |
70 |
Prog backlight (M72)...................................................... |
71 |
Accessory (M8) |
72 |
MP3 player (M81) .......................................................... |
72 |
Calculator (M82) ............................................................ |
73 |
Clock alarm (M83) ......................................................... |
73 |
Scheduler (M84) ............................................................ |
74 |
ToDo list (M85) .............................................................. |
76 |
Notepad (M86)............................................................... |
77 |
Voice memo (M87) ........................................................ |
78 |
Currency (M88).............................................................. |
79 |
External connection (M89)............................................. |
79 |
Synchronization (M80)................................................... |
80 |
Bluetooth (M891) |
81 |
Using Bluetooth connection ........................................... |
81 |
IR Data Exchange |
84 |
Positioning of the phones .............................................. |
84 |
IR send .......................................................................... |
84 |
IR receive (M8921) ........................................................ |
85 |
IR modem (M8922)........................................................ |
85 |
Index |
87 |
Before trying to use your phone, make sure that a valid Subscriber Identity Module (SIM) card is inserted and the battery is charged.
SIM card
Before using your phone, you must sign-up with one of the digital network service providers. In addition to your subscription details you will receive a personal SIM (Subscriber Identity Module) card which is inserted into your phone.
If the SIM card is removed, the phone becomes unusable until a valid SIM card is fitted. It is possible to transfer your SIM card to another compatible phone and resume your network subscription. The screen on your phone will display appropriate messages if no SIM card is fitted.
,If the phone, or the SIM card, is lost or stolen then you should contact your service provider immediately in order to bar it from use.
2 The phone supports a number of languages and the keyboard symbols have been chosen for world-wide operation. 2 The digital technology of your phone helps to ensure that your conversations are kept secure.
2 The SIM card contains personal data such as your electronic phonebook, messages (see “Message (M2)” on page 29) and also details of the network services you have subscribed to. The phone will not work (except for emergency calls on some networks) unless a valid SIM card is fitted.
,Be sure to turn the phone off before inserting and removing a SIM card. Otherwise damage to the SIM card can occur.
Inserting a SIM card
,Be sure to turn the phone off before removing the battery pack.
While pressing down the areas marked with of the rear cover as indicated by arrow , slide the rear cover about 3 mm in the direction of arrow with your finger tip. Then, lift the cover up in the direction of arrow to remove it.
Lift the finger tab of the battery pack up in the direction of arrow . Then lift the battery pack out in the direction of arrow .
With the metal part facing down, insert the straight end of the SIM card under the holder in the direction of arrow . Slide the SIM card all the way until it reaches the end.
,Be careful not to damage electric parts of the SIM holder when inserting a SIM card.
Insert the two tabs on the battery pack into the slots on the phone in the direction of arrow , making sure that the tabs on the battery pack fit properly into the slots on the phone. Then, press the battery pack down in the direction of arrow to clip it into the phone.
,Make sure that the battery pack is securely attached to the phone and align the rear cover with the grooves on the phone so that there is a gap of about 3 mm at the end of the cover. After making sure that there is no gap between the rear cover and the phone body, slide the rear cover in the direction of arrow until you hear a click.
Getting Started 1
|
Slots |
|
Finger tab |
Battery |
Tabs |
|
|
Rear cover |
Holder |
|
About 3 mm About 3 mm
Check that there is no gap SIM card between the rear cover
and the phone body.
,. If the SIM card is not fully inserted when the battery is replaced, damage to the SIM card can occur.
If the SIM card is already fitted, see “Start-up” on page 4.
Removing a SIM card
With the battery removed, push the short and straight end of the SIM card with your thumb to slide it gently in the direction of arrow Lift the SIM card after it is completely removed from the holder.
,Be careful not to damage electric parts of the SIM holder when removing a SIM card.
2 Getting Started
Charging the battery
Before trying to use your phone, insert the phone’s battery, and connect the NEC battery charger (AC adapter) supplied with your phone to a suitable mains power socket.
Pull open the charger connector cover gently.
,Be careful when handling the charger connector cover. Do not pull strongly.
With the arrow marks of the charger plug facing up, hold the buttons on both sides of the charger plug with your thumb and index finger.
Press the buttons as indicated by the arrow marks on the charger plug and insert the plug into the charger connector.
,Make sure to insert the charger plug with the arrow marks facing up. Otherwise, damage to the charger connector can occur when disconnecting the charger plug.
2If your phone is turned on and charging starts, the battery charging icon will be displayed. LED will turn on in red while charging. When charging is complete, the LED will turn off.
2You are recommended to switch off the phone while charging. If you need to receive calls, your phone can be switched on and left in standby while being charged, although the total time taken to charge is then increased.
After the charging is complete, press the buttons of the charger plug as indicated by the arrow marks on the charger plug ( ) and gently pull straight out of the charger connector ( ).
,Make sure to press both buttons when disconnecting the charger plug from the charger connector. If you pull the charger plug forcibly without pressing the buttons, damage to the charger connector can occur.
The icons show the charging status of battery.
Charger connector
Press Press
Arrow marks |
Charger plug |
|
Make sure to hold the charger plug with the arrow marks facing up and press both buttons.
Charger connector
Press Press
Charger plug
Pull straight
Make sure to press both buttons and gently pull the charger plug straight.
Fast battery charging |
Slow battery charging while the phone is in use |
Battery charging stopped due to overheat |
,Using any battery pack, AC adapter, vehicle power adapter (option) not specified by NEC for use with this phone can be dangerous and may invalidate any warranty and approval given to the cellphone. Do not leave the charger connected to the mains supply when it is not in use.
,Do not try to charge the battery if the ambient temperature is below 5°C (41°F) or above 35°C (95°F).
,DO NOT connect a charger or any other external DC source until the phone’s battery is inserted.
2If the phone does not respond, please wait for a few minutes. The charging will then start.
2If you use the phone while charging, handle the phone carefully since the cable or adapter is connected.
2If you make/receive a call while charging, the charging may temporarily be interrupted.
2Charging takes approximately 3 hours with your phone turned off.
2Even if the phone remains connected to the charger, battery residual capacity may decrease when the phone is used for video recording, playing or other battery consuming operation.
Getting Started 3
,IMPORTANT BATTERY CHARGING INFORMATION
Charging a very low battery
The battery’s charge continues to drop after the low battery warning is displayed. In extreme cases where the battery is left uncharged for some considerable time after this warning, a trickle charge is used to slowly top-up the battery to the safe level at which the fast charging can begin. The phone can be in trickle charge for a few minutes before the fast charging starts.
Your phone works closely with the network you are using to provide the services you need, and the standby and talk times achieved will depend on how you use the phone and choices made by the network operator.
In particular, factors such as your location within the network, the frequency at which this location is updated, the type of SIM card you have, your reception of area messages or cell broadcast messages and the use of full rate or enhanced full rate speech, will affect both standby and talk times.
Check icon at the top of the standby screen.
The number of blocks on the icon shows the charge of your battery pack.
Full battery power |
Partial battery power |
Low battery power |
Battery empty |
When the battery voltage falls below the working level, a low battery warning is displayed on the screen accompanied by LED illumination and a short tone along with an empty battery icon. The phone will automatically power down shortly afterwards.
2 Please charge the battery as much as possible when the battery is very low.
Your phone may display warnings when the battery temperature is too high, or the voltage of the battery or the charger is over the appropriate level. Follow the instruction given by these warnings immediately.
Switching the phone on
Hold down for about a second to switch on. The screen will display the selected greeting (if set, see page 25) and the phone is then in standby.
2You may need to charge the battery before using your phone.
2When your phone is turned on, the specified ringer may sound.
4 Getting Started
2If your phone is accidentally turned off while downloading or deleting Java™ application, it will take longer than usual to start up the phone the next time you turn on the power.
Switching the phone off
Hold down until the display shows the switch off message.
PIN code
The SIM card issued by your service provider has a security feature called PIN code protection. The Personal Identification Number (PIN) is a number put on to the card by your service provider, and is 4 to 8 digits long. Some service providers supply SIM cards which will cause your phone to prompt for a PIN code when it is turned on. If this is the case, enter your code with the phone’s keypad. If you insert a SIM card other than your own, information such as call logs may be lost (see “Security (M17)” on page 26 for details).
Getting Started 5
You make a simple call in the same way as you would with a normal phone, except that you need to press after entering the area Subscriber Trunk Dialling (STD) code and the phone number. To make international calls, you must first enter the international dialling code (see page 14).
2Use the full STD area code even if you are calling to a person in the same town. If the numbers are too long to be displayed within one line, after pressing , excess part is deleted and ‘...’ is added at its end.
2The main-LCD display shows the strength of the radio signal that links your phone to the network. The maximum signal strength is shown by 4 shaded blocks and the minimum signal strength by 1 block.
Starting a call
Key in the phone number. Check the number on the display or SK1 to send the input number to start the call
Before the other party answers the call, you can end the call by pressing briefly, pressing SK2 or closing your phone. When you use the headset, you can also end the call by pressing and holding the button on it.
2 When connecting a wired headset and Bluetooth headset at the same time, the wired headset will not work.
When the call is sent, the screen displays the number called, the name stored in the phonebook and a connection graphic or a Calling Line Identification (CLI) picture that has been allocated to the number called (see page 55).
Correcting mistakes
Use the
▼
and
▼
to move the cursor and then CLR to clear individual digits, or hold down CLR to completely clear a phone number.
While talking, SK2 or briefly, or close your phone. The phone returns to the standby screen.
2If is held down, your phone will turn off.
2When you use the headset, you can also end a call by pressing and holding the button on it.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
2You cannot end a call by closing your phone when the headset is connected.
When someone calls your number, the ringer will play (if set - see page 24), the LED glows in the specified colour, and the phone number of the caller may be displayed if the calling line identification facility is available and the caller has activated the feature. If the caller’s phone number has been related and stored in your phonebook with a name and a CLI picture (see page 55), that name and picture will be displayed. If the caller has withheld their identity,
6 Basic Calls & Phone Use
the screen will give a message that the caller’s number is being withheld. If the origin of the call cannot be determined, no information is displayed on the screen.
2 You also have options for holding and forwarding calls. These options depend on your network and your subscription arrangements.
Accepting an incoming call
While receiving an incoming call, or SK1
2When you use the headset, you can also accept an incoming call by pressing the button on it.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
2When Auto answer function (see page 24) is set to on and a headset is connected to the phone, the incoming call is automatically accepted after several rings.
2You can accept an incoming call by opening your phone, when Fold answer function (see page 22) is set to on.
2You can set your phone to answer a call when any key is pressed (see “Any key answer” on page 22).
Rejecting an incoming call
While receiving an incoming call, or SK2 briefly or close your phone.
2When you use the headset, you can also reject an incoming call by pressing and holding the button on it.
2You cannot reject a call by closing your phone when the headset is connected.
2When connecting a wired headset and Bluetooth headset, the wired headset will not work.
If your phone receives a call and you do not answer it, the main-LCD will display a desktop icon of the phone number (or the name if stored) of the caller (if available).If your phone is closed, the 2nd-LCD will also display a missed call icon, and you can display the details by pressing Side up. This information is stored in the missed calls list. Up to 20 missed calls are stored in this list.
2If you are making a call, the phone gives priority to receiving a call unless you have already pressed . See also: “Call diversion (M161)” on page 13 and “Call waiting and holding (M162)” on page 14.
See also: “Call options (M43)” on page 11.
If dialled call is not successfully connected, the display will give an appropriate message.
If your phone has the auto redial function activated, the number will be automatically called again after a short delay (see page 14).
The standard emergency number of 112 can be used.
Key in 1 1 2 or SK1 to connect the call to the local emergency services.
2 On some networks, emergency calls can be made using the 112 number without a SIM card inserted.
Basic Calls & Phone Use 7
You can redial the last number you called.
Ensure that the standby screen is displayed and no phone number is shown twice to dial the last number you called.
See also: “Call options (M43)” on page 11.
One-touch dial for the phonebook (SIM) is available by pressing and holding the number keys between 2 and 9.
2A number for the One-touch dial corresponds to the location number in the phonebook (SIM).
2One-touch dial is available only for the phone numbers with the location number 2 to 9 stored in the phonebook (SIM).
You can make a call to the phone number in the phonebook (Phone/SIM) with just a few press of button.
To fast-dial the phone number in the phonebook (SIM), use the following procedure:
From the standby screen, key in the Location number of a personal data in the phonebook (SIM) #. The corresponding personal data is displayed.
to dial the phone number.
To fast-dial the phone number in the phonebook (Phone), use the following procedure:
From the standby screen, key in the Abbreviated Dialing Number (ADN) of a personal data in the phonebook (Phone) . The corresponding personal data is displayed.
Use the
▼
and
▼
keys to choose the phone number (if there are more than one), then to dial the phone number.
0 or
4 1 6
You can store up to 10 voice recall recordings which can be allocated to a personal data stored in the phonebook (Phone). To store the voice recall sound, see page 55. To use the voice recall function, use the following procedure:
Press and hold
2 When you use the headset, you can also activate the voice recall function by pressing and holding the button on it from the standby screen.
8 Basic Calls & Phone Use
Within 4 seconds, say the word or words you have recorded to identify the record you wish to recall. If the word or words were recognized, the first phone number of the personal data stored in the phonebook (Phone) will be called automatically.
During a call, |
to display the options menu |
||
No. |
Options menu (during a call) |
|
|
1 |
Main menu |
|
Displays the Main menu screen. See “Overview of menu function” on page xi for details. |
2 |
Hold/Retrieve |
|
Puts the call(s) on hold or retrieves the call(s). |
3 |
Mute/Unmute |
|
Mutes or unmutes your voice to all active calls. |
4 |
Transfer call |
|
Enables to transfer the call and connect other parties. |
|
|
|
2 After transferring the call, your call will be dropped. |
5 |
Add to conference |
Merges calls and makes a multi-party call. |
|
6 |
Private call |
|
Make a private call to the highlighted party within the multi-party call. |
7 |
Record call |
|
Records the call while talking. |
8 |
Disconnect party |
|
Disconnects the highlighted party. |
9 |
Switch call to Bluetooth/Switch |
Switches the audio path state of the call. |
|
|
call to phone |
|
2 You can also switch call to Bluetooth or phone by pressing and holding #. |
|
|
|
2 This option is available only when the Bluetooth device is connected to the phone. |
0 |
Bluetooth On |
|
Activates the Bluetooth device. |
2 Depending on the conditions, some options may be displayed in gray and not be available.
To put the received or dialled call on hold, SK1 or 2. To retrieve the call, SK1 or
2 again.
You can mute the sound from the mouthpiece during a call. When your call is muted, the other party cannot hear any sound from your phone, but you can still hear the sound from the other party.
To mute the sound during a call, 3. To retrieve the sound,
3 again.
2 The mute function is automatically released after the call ends.
Basic Calls & Phone Use 9
2 The mute function is not available while using the headset.
When you have an active call and a held call, you can transfer the call and connect the two parties, then you can drop from the line while leaving those two calls active.
To transfer the call, |
4. |
2 After dropping from the call with the other two parties, if you have a call waiting, you can proceed the call with it.
,Call transfer facility is SIM dependent.
If your SIM card is multi-party enabled, you can make a conference call to more than one caller. To create the multi-party calls, at least 3 parties, including the host, are needed.
Receiving the second call
SK1 or to accept the second call SK2 or
5 to merge both calls to initiate a multi-party call.
2 When you accept the second call, the first call will be put on hold.
Making the second call
SK1 to put the first call on hold Key in the phone number SK1 or to make the second call After the second participant answers, SK2 or
5 to merge both calls to initiate a multi-party call.
Putting the multi-party calls on hold
SK1 or 2 to put all calls on hold To retrieve the call, SK1 or
2 again.
2 You can put the multi-party calls on hold only when you are a host of the multi-party calls.
Making a private call
While on the multi-party call, you can make a private call to a specific party.
To make a private call, highlight the desired party you want to make a private call to 6
To end a private call and return to the normal multi-party call 5
2While you are on a private call, other parties can continue with their conversation.
2You can make a private call only when you are a host of the multi-party calls.
Ending the multi-party calls
To end the multi-party calls, or SK2.
10 Basic Calls & Phone Use
To disconnect a specific party on a multi-party call, highlight the party you wish to disconnect 8
2You can disconnect a specific party on the multi-party calls only when you are a host of the multi-party calls.
,Multi-party call facilities are network dependent.
You can record the conversation during the call.
During a call, press and hold or 7 to display the Voice memo screen SK1 to start the recording SK1 to pause and SK2 to stop the recording
2 To play the recording, see “Recording/playing voice memo or setting speaker” on page 78.
Your phone has a scratchpad facility that enables you to take down a phone number during a call and then make a call to it when you have finished. This scratchpad number can be stored in memory for future use.
Noting & calling a scratchpad number
During a call, key in the number to be placed in the scratchpad. It will be shown on your phone’s screen when the call is finished. The number will still be displayed
to dial the displayed number.
From Call options, you can display the list of missed, received and dialled calls, the duration of the last call made and all calls, charge information and the redial blacklist.
4 3 to display the Call options screen.
No. |
Call options |
|
|
1 |
Missed calls |
Displays the list of missed calls. You can also access this function by pressing▼ from the standby screen. |
|
2 |
Received calls |
Displays the list of received calls. You can also access this function by pressing ▼ from the standby screen. |
|
3 |
Dialled calls |
Displays the list of dialled calls. You can also access this function by pressing |
from the standby screen. |
4 |
Last call duration |
Displays the duration of the last call made on your phone. |
|
|
|
SK1 to reset the display to zero. |
|
5Total calls duration Displays the duration of the total calls made on your phone.
SK1 1 to reset the duration of the total dialled calls, 2 to reset the duration of the total received calls, or 3 to reset the duration of all calls.
Basic Calls & Phone Use 11
No. |
Call options |
|
|
|
|
6 |
Charge info |
Displays the charge information (Advice of Charge - AoC). |
|||
|
|
,The AoC facility is SIM card and network dependent. |
|||
|
|
|
2 To reset the display to zero, set the maximum charges or edit the unit price, you may be prompted to enter the |
||
|
|
|
|
PIN2 code. |
|
|
|
1 |
|
Total charge |
Displays the total charge. |
|
|
|
|
|
SK1 to reset the display to zero. |
|
|
2 |
|
Maximum charge |
Displays the maximum charge. |
|
|
|
|
|
Key in the maximum number of units allowed SK1 |
|
|
3 |
|
Unit price |
Displays the unit price. |
|
|
|
|
|
Highlight the whole number (integer), the decimal number or the currency field Key |
|
|
|
|
|
in the required value for the whole number and decimal number fields. For the currency |
|
|
|
|
|
field, key in the currency type using a maximum of three characters SK1 |
7 |
Redial blacklist |
Accesses the numbers in the blacklist. |
|||
|
|
2 If dialled call is not successfully connected (e.g. number busy), the auto redial facility will be offered (see page 14). |
|||
|
|
|
If you have set auto redial and the call still fails, the number called will be added to the blacklist. |
2 Depending on the conditions, some options may be displayed in gray and not be available.
Display missed/received/dialled calls Options menu (M431M/M432M/M433M)
▼ or |
4 3 1 for missed calls, |
Highlight a number in the list
▼
or 4 3 2 for received calls, or
or
4 3 3 for dialled calls.
No. |
Missed calls/Received calls/Dialled calls Options menu |
|
1 |
Call |
Calls the current number. |
2 |
Create message |
Creates a new message to the highlighted phone number. |
3 |
Add to phonebook |
Adds the current number to the phonebook. |
|
|
1 to add it as a new personal data, 2 to add it to an existing personal data Press the appropriate number for |
|
|
the storage destination Press the appropriate number for the phonebook data field to copy the current number |
|
|
to. |
4 |
Delete one |
Deletes the current number. |
5 |
Delete all |
Deletes all the numbers in the list. |
6 |
Info |
Displays information on the current number. |
12 Basic Calls & Phone Use
No. |
Missed calls/Received calls/Dialled calls Options menu |
|
7 |
Add desktop icon |
Creates a desktop icon of the selected number. |
8 |
Items/Page |
Selects either to display 4 or 8 phone numbers in one screen. |
2 Depending on the conditions, some options may be displayed in gray and not be available.
From the Calls screen, you can change various call settings: the call diversion, call waiting and holding, auto redial and line identification.
Call diversion (M161)
Setting Call diversion
|
1 6 1 |
▼ or▼ select the type of call you wish to divert from Speech, Data or Fax. |
2 There will be a delay while your phone checks its divert status with your network.
Highlight one of the conditions When the phone number field of a divert condition is highlighted, either enter the phone number to divert to, or delete any existing phone number.
If you have made any mistake, highlight the appropriate field SK1 to clear any mistakes.
If the settings are correct,
,There will be a short delay while the network sends the divert status of your phone.
,There may be an additional charge for this service depending on your network.
,There may be unavailable settings depending on your network.
Call diversion edit options menu
Highlight the required edit field
No. |
Call diversion edit options menu |
|
1 |
Copy |
Copies the number in the edit field. |
2 |
Paste |
Pastes the previously copied number. |
3 |
Disable all |
Disables the numbers from all the fields. |
4 |
Phonebook |
Displays the phonebook to insert a number in the edit field. |
5 |
Add to phonebook |
Adds the number to the phonebook as a new personal data or saves the number in an existing personal data. |
2 Depending on the conditions, some options may be displayed in gray and not be available.
Basic Calls & Phone Use 13
Call waiting and holding (M162)
This facility informs you that another call is being made to your phone while an existing call is in progress.
Setting up call waiting
1 6 2 1 1 to activate, 1 2 to deactivate the call waiting, or 2 to check the status of call waiting.
Using call waiting
If you are on a call and another comes in, you will be alerted by a beep in the earpiece SK1 to accept the incoming call.
To switch the calls, SK1
To merge the calls, SK2 (see “Multi-party calls” on page 10).
To end the current call,
To retrieve the held call SK1
Auto redial (M163)
With the auto redial facility, your phone will redial a number up to 10 times if the first attempt fails. A tone will be heard at each redial attempt. Your phone cannot connect a call if the other party is busy or if there are network problems. Pressing SK2 during a redial attempt will abort it.
1 6 3 1 to activate or 2 to deactivate the auto redial facility.
Line ID (M164)
,The line ID (identification) facility is network dependent.
The line ID facility enables you to choose whether or not to send your own phone number when you make a call and also whether or not to display a caller’s phone number when you receive a call.
1 6 4 to display the Line ID screen with a over an activated line and a over a deactivated line.
To set the status of each line (see the table on the right), highlight a line (the line will flash when selected).
SK1 to set the line identification on or off to save the current settings.
Line type |
Setting |
Outgoing |
Send own # |
|
Show connected # |
Incoming |
Show Incoming # |
|
Return own # |
When you make an international call from any country, you must start by dialling a special international access code. Your phone has the facility to prefix a + symbol to the numbers, so that you need not enter the access code for the country that you are calling from.
Entering international dialling codes
Hold down 0. The 0 character displayed will change to a + character Key in the country code, area code, and phone number that you wish to call. The UK country code is always 44, no matter what country you are dialling from. For example, a typical UK number of 0131 1234567 is entered as:
International access |
country code |
area code |
phone number |
+ |
44 |
131 |
1234567 |
14 Basic Calls & Phone Use
,You will be charged for calls forwarded to you while roaming.
The roaming facility enables you to use your phone in many parts of the world and pay all charges through your normal service provider. Your network operator usually has agreements with named networks in other countries so that automatic roaming can take place with these named networks. The phone also allows you to set network preferences of your own.
When dialling, you will need to add the international access codes if required. So, storing all numbers with the codes (such as +44 for UK) is helpful (see “Entering international dialling codes”).
2 Before leaving your home country, you should select any preferences such as bar calls or call diversion.
Setting Automatic or Manual network selection (M181)
1 8 1 1 to select the automatic mode or 2 to select the manual mode.
,Before you manually select a network, ensure it is covered under the agreement you have with your service provider.
New search (M182)
1 8 2 to search the available networks Highlight the desired network
to connect to it.
Viewing/editing network list (M183)
,Before editing your network list, please consult with your service provider.
1 8 3 to read the network list in the SIM memory Highlight the required network
No. SIM list Options menu
1 |
Add |
Adds a new network to the list. |
2 |
Move |
Moves the highlighted network within the list. |
|
|
Use and to move the network SK1 |
3 |
Remove |
Deletes the highlighted network. |
2 Depending on the conditions, some options may be displayed in gray and not be available.
Selecting the frequency band (M184)
You have to select the frequency band to suit the location. 1 8 4 Select the required frequency band.
2 Frequency bands must be adjusted to suit the location when roaming (Europe, US, etc.), for the phone to work properly.
Basic Calls & Phone Use 15
