Contents

Your new NEC Technologies MultiSync® M Series monitor box*
should contain the following:

• MultiSync M Series Monitor with removable tilt/swivel base
MultiSync M500™, JC-1572VMA-2
MultiSync M700™, JC-1735VMA-2

• Power Cord

• Captive Combined

Signal Cable

• User’s Manual

• Registration Card

User’s Manual

* Remember to save your original box

and packing material to transport
or ship the monitor.

78133441 6/24/98, 7:50 AM3

Power Cord

Captive Combined

Signal Cable

Registration Card

Note: You can now register your
product on the Internet at
http://www.prodreg.com/nec

1

Quick Start

To attach the MultiSync® M Series monitor to your system, follow
these instructions:

1. Turn off the power to your computer and MultiSync monitor.

2. If necessary, install the display card into your system. For more information,

refer to the display card manual.

3. For the PC: Connect the MultiSync M Series 15-pin mini D-SUB of the captive

combined signal cable to the connector of the display card in your system
(Figure A.1). Tighten all screws.

Captive Combined
Signal Cable

15-pin mini D-SUB

Figure A.1

For the Mac: Connect the MultiSync M Series Macintosh cable adapter (not
included) to the monitor connector on the Macintosh (Figure B.1). Attach the
15-pin mini D-SUB end of the captive combined signal cable to the Macintosh
cable adapter on the computer (Figure B.1). Tighten all screws.

NOTE: To obtain the MultiSync M Series cable adapter, call

NEC Technologies at [phone].

78133441 6/24/98, 7:50 AM4

Computer

Figure B.1

2

Mac Adapter

(Not included)

Captive Combined
Signal Cable

15-pin mini D-SUB

Quick Start

4.

Locate the audio output connection on the component(s) which will serve as the
source(s) for the built-in speakers. (The component(s) could be your system, CD­ROM, sound card, etc.).

5.

Once you have determined the source, identify the connector present from the
source and connect the stereo input cable.

Headphone

Headphones may be connected to the “Headphones” output on the left of the
monitor’s bezel marked “ ”. While the headphones are connected, the
sound from the speakers will be disabled. Headphones can be purchased from
your local electronics store.

Microphone

Connect
rear of your system. (Figure A.1, B.1)

NOTE: There is a microphone hole on the

6. Connect one end of the power cable to the MultiSync M Series monitor and

the other end to the power outlet. (Figure C.1)

7. Turn on your MultiSync monitor and computer.

NOTE: If you have any problems, please refer to the Troubleshooting section of

stereo male mini jack cable

to the microphone (MIC IN) input on the

front

of the monitor marked

“ ”
This is the location of the built-in microphone. This is not to be used for
the input for the mini jack cable. (Figure D.1)

this User’s Manual.

.

Power Outlet

CONTROL

78133441 6/24/98, 7:50 AM5

PROCEEDEXIT

Power

Cord

Figure C.1

MUTE

RESET

Figure D.1

3

Controls

OSM™ buttons on the front of the monitor function as follows:

Main Menu Sub-Menu

EXIT Exits the OSM controls. Exits to the OSM main menu.
CONTROL Moves the highlighted Moves the highlighted area

/ area up/down to select up/down to select one of the

one of the controls. controls.

CONTROL Moves highlighted Moves the bar in the + or –
+/– area left/right to select direction to increase or

one of the controls. decrease the adjustment.

PROCEED Has no function. Only executes control

or enters sub, sub-menu.

RESET/ Resets all the controls within Resets the highlighted control
MUTE the highlighted menu to the factory setting.

to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning window

will appear allowing you to cancel the reset function.

NOTE ON OSM does not need to be activated to operate the mute function
MUTE for the speakers. To quickly turn off the sound of the speakers,
BUTTON: simply press the MUTE button. To disable the mute function and

restore the sound, press the MUTE button again.

Speaker Controls

Volume: Increases or decreases the sound output of speakers/headphones.
Treble: Increases or decreases the treble.
Bass: Increases or decreases the bass.
Balance:

For additional sound controls, please see the Tools icon.

Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Degauss: Eliminates the buildup of stray magnetic fields which alter the correct

scan of the electron beams and affect the purity of the screen colors, focus and
convergence. When activated, your screen image will jump and waver a bit as
the screen is demagnetized.
Caution: Please allow a minimum of 20 minutes to elapse between uses of the
Degauss Control.

Adjusts the balance between the right and left speakers/headphones.

Brightness/Contrast Control

78133441 6/24/98, 7:50 AM6

4

Controls

Size and Position

Left/Right: Moves the image horizontally (left or right).
Up/Down: Moves the image vertically (up or down).
Narrow/Wide: Increases or decreases the horizontal size of the image.
Tall/Short: Increases or decreases the vertical size of the image.

Color Control/AccuColor

Color presets 1 through 5 select the desired color setting. The bar is replaced by
the color setting choice from 1 to 5. Each color setting is adjusted at the factory
to the stated degree Kelvin. If a setting is adjusted, the name of the setting will
change from degree Kelvin to Custom.
Color Gain: Increases or decreases red, green or blue depending upon which is
selected. The change in color will appear on screen and the direction (increase or
decrease) will be shown by the bars.

Geometry Controls

Geometry Controls Menu

The Geometry controls allow you to adjust the curvature or angle of the sides of
your display.
Sides In/Out (pincushion): Increases or decreases the curvature of the sides either
inward or outward.
Sides Left/Right (pincushion balance): Increases or decreases the curvature of
the sides either to the left or right.
Sides Tilt (parallelogram): I
left or right.
Sides Align (trapezoidal): Increases or decreases the bottom of the screen to be
the same as the top.
Rotate (raster rotation)(M700 Only): Rotates the entire display clockwise or
counterclockwise.

ncreases or decreases the tilt of the sides either to the

®

Tools

Provides a list of optional adjustments which include the following:

Surround Mode: Provides 4 preset sound settings for various applications.
Voice/Standard Mode: For use with standard applications and

This mode is factory preset and will remain
sound setting is selected.

Music/Game Mode: Maximizes the treble setting.
Movie/TV Mode: Maximizes the bass setting.

78133441 6/24/98, 7:50 AM7

as the primary setting unless another

5

telephony functions.

Controls

Mono to Stereo Mode: Converts the mono input to stereo sound for a simulated
surround effect.

This bar provides adjustment for changing the level of sound effects, acting as an
equalizer.

NOTE: Select desired setting based upon your application.

Language: OSM™ menus are available in 6 languages.
OSM Position: You can choose where you would like the OSM image to appear

on your screen. Selecting OSM Position allows you to manually adjust the OSM
menu left, right, up or down.
OSM Turn Off: The OSM menu will stay on as long as it is in use. In the OSM
Turn Off sub-menu, you can select how long the monitor waits after the last
touch of a button to shut off the OSM menu. The preset choices are 10, 20, 30,
60, 120 seconds.

O

SM Lock Out: This control completely locks out access to all OSM functions.

When attempting to activate OSM while in the lock out mode, a screen will appear
indicating that OSM is locked out. To activate the OSM Lock Out function, press
PROCEED, then and hold down simultaneously. To de-activate the OSM Lock
Out, press PROCEED, then and hold down simultaneously.
Vertical Linearity: This selection allows you to adjust the spacing of the area on
the screen. The purpose of this control is to ensure that a one-inch circle is a true
one-inch circle wherever it is on the screen. The best way to determine the
vertical linearity is as follows:

• Draw equally spaced horizontal lines using a drawing application that has a ruler.

• Use the Vertical control to adjust the spacing between the lines near the center of your screen.

• Use the Vertical Balance control to adjust the lines near the top and bottom of your screen.

IPM™ System: On: The IPM System works normally and all stages

of energy savings are utilized.

Off: The Off Mode of the IPM System is not used.

NOTE:For standard systems and graphics boards, keep the
factory setting at ON.

6

78133441 6/24/98, 7:50 AM8

Controls

Factory Preset: Selecting Factory Preset allows you to reset all OSM settings back
to the factory settings. A warning statement will appear to confirm that you do
want to reset ALL settings. Individual settings can be reset by highlighting the
control to be reset and pressing the RESET button.

Information

Provides you with additional information which includes the following:
Fitness Tips: The Fitness Tips provide you with helpful reminders to periodically
rest your eyes. You may select how frequently the reminders are displayed based
upon your individual needs. Select an interval from 15, 30, 45, 60, 90, 120
minutes for the tips to appear. When the tips appear, follow the advice of the tips
and press EXIT to clear.
For additional information on setting up a healthy work environment, see page 9.
Display Mode: Indicates the current mode and frequency setting of the monitor.

78133441 6/24/98, 7:50 AM9

7

Recommended Use

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MULTISYNC® M SERIES COLOR MONITOR:

• DO NOT OPEN THE MONITOR. There are no user serviceable parts inside
and opening or removing covers may expose you to dangerous shock hazards
or other risks. Refer all servicing to qualified service personnel.

• Allow adequate ventilation around the monitor so that heat can properly
dissipate. Do not block ventilated openings or place the monitor near a
radiator or other heat sources. Do not put anything on top of monitor.

• Do not spill any liquids into the cabinet or use your monitor near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch

dangerous voltage points, which can be harmful or fatal or may cause electric
shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may
cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as the
monitor may fall, causing serious damage to the monitor.

• Keep the monitor away from high capacity transformers, electric motors and
other devices such as external speakers or fans, which may create strong
magnetic fields.

• If possible, position the monitor so that it is facing the east to minimize the
effects of the earth’s magnetic field.

• Changing the direction of the monitor while it is powered on may cause image
discoloration. To correct this, turn the monitor off for 20 minutes before
powering it back on.

• The power cable connector is the primary means of detaching the system from
the power supply. The monitor should be installed close to a power outlet
which is easily accessible.

• Handle with care when transporting. Save packaging for transporting.

Immediately unplug your monitor from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If the monitor does not operate normally by following operating

instructions.

8

78133441 6/24/98, 7:50 AM10

Recommended Use

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR

CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE MONITOR:

• Adjust the monitor height so that the top of the screen is at or slightly below
eye level. Your eyes should look slightly downward when viewing the middle
of the screen.

• Position your monitor no closer than 12 inches and no further away than 28 inches
from your eyes. The optimal distance is 18 inches.

• Rest your eyes periodically by focusing on an object at least 20 feet away.
Blink often.

• Position the monitor at a 90° angle to windows and other light sources to
minimize glare and reflections. Adjust the monitor tilt so that ceiling lights do
not reflect on your screen.

• If reflected light makes it hard for you to see your screen, use an anti-glare filter.

• Clean your monitor regularly. Use a lint-free, non-abrasive cloth and a

non-alcohol, neutral, non-abrasive cleaning solution or glass cleaner to
minimize dust.

• Adjust the monitor’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

• Position whatever you are looking at most of the time (the screen or

reference material) directly in front of you to minimize turning your head
while you are typing.

• Get regular eye checkups.

For more detailed information on setting up a healthy work environment, call NEC
at [phone], NEC FastFacts
document #900108 or write the American National Standard for Human Factors
Engineering of Visual Display Terminal Workstations – ANSI-HFS Standard
No. 100-1988 – The Human Factors Society, Inc. P.O. Box 1369, Santa Monica,
California 90406.

™

information at [phone] and request

9

78133441 6/24/98, 7:50 AM11

Specifications

Monitor MultiSync® M500

™

Notes

Specifications Monitor

Picture Tube Diagonal: 15 inch 90° deflection, 0.25 mm mask pitch,

Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms Positive

Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 69 kHz Automatically

Range Vertical: 55 Hz to 120 Hz Automatically

Maximum Resolution 1280 x 1024 @ 65 Hz

Resolutions Supported 640 x 480 @ 60 to 120 Hz

Resolution based on
vertical frequencies only

Active Display Area Horizontal:
(Factory Setting) Vertical:

Active Display Area

(Full Scan)
Power Supply
Current Rating 1.8A @ 100
Dimensions

Weight 15.0 kg

Environmental Considerations

Viewable Image Size: 13.8 inch CromaClear

horizontal and

Operating Temperature: 10°C to +35°C

Storage Temperature: -20°C to +60°C

Radius: 1080 mm phosphor, multi-layered, anti-static screen

Sync: Separate sync. TTL Level

Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative

800 x 600 @ 55 to 110 Hz
832 x 624 @ 55 to 110 Hz
1024 x 768 @ 55 to 85 Hz
1152 x 870 @ 55 to 75 Hz
1280 x 1024 @ 55 to 65 Hz

260 mm/10.2 inches Dependent upon signal timing used,
195 mm/7.7 inches and does not include border area.

280 mm/11 inches Dependent upon signal timing used,
210 mm/8.3 inches and does not include border area.

AC 100 – 120 V, 50/60 Hz

–

120 V

372 mm (W) x 406 mm (H) x 405 mm (D)

14.6 inches (W) x 16 inches (H) x 15.9 inches (D)

33.1 lbs

Humidity: 30% to 80%

Feet: 0 to 10,000 Feet

Humidity: 10% to 90%

Feet: 0 to 45,000 Feet

®

CRT, medium-short persistence

coating, semi-dark-tint screen, Invar Shadow
Mask and OptiClear® screen surface.

Maximum resolution based on horizontal
and vertical frequemcies.

Some systems may not support
all modes listed.

78133441 6/24/98, 7:50 AM12

NOTE: Technical specifications are subject to change without notice.

10

Monitor MultiSync® M700

™

Notes

Specifications Monitor

Picture Tube Diagonal: 17 inch 90° deflection, 0.25 mm mask pitch,

Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms

Display Colors Analog input: Unlimited number of Colors Depends on display card used.

Synchronization Horizontal: 31 kHz to 69 kHz Automatically

Range Vertical: 55 Hz to 120 Hz Automatically

Maximum Resolution 1280 x 1024 @ 65 Hz

Resolutions Supported 640 x 480 @ 60 to 120 Hz

Resolution based on

vertical frequencies only

Active Display Area Horizontal:

(Factory Setting) Vertical:

Active Display Area

(Full Scan)
Power Supply
Current Rating 2.2A @ 100
Dimensions

Weight 18.8 kg

Environmental Considerations

Viewable Image Size: 15.6 inch CromaClear

horizontal and

Operating Temperature: 10°C to +35°C

Storage Temperature: -20°C to +60°C

Radius: 1210 mm phosphor, multi-layered, anti-static screen

Sync: Separate sync. TTL Level

Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative

800 x 600 @ 55 to 110 Hz
832 x 624 @ 55 to 110 Hz
1024 x 768 @ 55 to 85 Hz
1152 x 870 @ 55 to 75 Hz
1280 x 1024 @ 55 to 65 Hz

306 mm/12.0 inches Dependent upon signal timing used,
230 mm/9.1 inches and does not include border area.

316 mm/12.4 inches Dependent upon signal timing used,
237 mm/9.3 inches and does not include border area.

AC 100 – 120 V, 50/60 Hz

–

120 V

403 mm (W) x 451 mm (H) x 450 mm (D)

15.9 inches (W) x 17.8 inches (H) x 17.7 inches (D)

41.4 lbs

Humidity: 30% to 80%

Feet: 0 to 10,000 Feet

Humidity: 10% to 90%

Feet: 0 to 45,000 Feet

®

CRT, medium-short persistence

coating, semi-dark-tint screen, Invar Shadow
Mask and OptiClear® screen surface.

Maximum resolution based on horizontal
and vertical frequemcies.

Some systems may not support
all modes listed.

78133441 6/24/98, 7:50 AM13

NOTE: Technical specifications are subject to change without notice.

11

Features

CromaClear® CRT: Delivers images with more clarity than found in traditional
CRT’s. Phosphors appear elliptical when illuminated, resulting in screen images
with more depth and dimension.

OptiClear® Screen Surface: Reduces reflection and glare and increases contrast
without sacrificing focus level, clarity or brightness. Along with the flat square
technology CRT, a high contrast screen with 0.25 mm mask pitch delivers crisp,
clean text and graphics.

Invar Shadow Mask: Holes in the thin metal sheet behind the glass of the CRT
surface correspond to each phosphor dot on the inner surface of the CRT’s
faceplate, allowing the correct electron beam (red, green, blue) to hit the correct
color phosphor for improved focus, brightness and color.

AccuColor® Control System: Allows you to adjust the colors on your screen and
customize the color accuracy of your monitor to a variety of standards.

OSM™ (On-Screen Manager) Controls: Allow you to quickly and easily adjust all
elements of your screen image via simple to use on-screen menus.

ErgoDesign® Features: Enhance human ergonomics to improve the working
environment, protect the health of the user and save money. Examples include
OSM controls for quick and easy image adjustments, tilt/swivel base for pre­ferred angle of vision and compliance with MPRII guidelines for lower emissions.

Plug and Play: The Microsoft® solution with the Windows®95 operating system
facilitates setup and installation by allowing the monitor to send its capabilities
(such as screen size and resolutions supported) directly to your computer,
automatically optimizing display performance.

IPM™ (Intelligent Power Manager) System: Provides innovative power-saving
methods that allow the monitor to shift to a lower power consumption level when
on but not in use, saving two-thirds of your monitor energy costs, reducing
emissions and lowering the air conditioning costs of the workplace.

Reduced Magnetic Field™ Technology: Reduces magnetic and alternating electric
field emissions and static electricity, addressing ergonomic concerns regarding
potential risks from extended computer monitor use.

Multiple Frequency Technology: Automatically adjusts monitor to the display
card’s scanning frequency, thus displaying the resolution required.

FullScan™ Capability: Allows you to use the entire screen area in most resolu­tions, significantly expanding image size.

OSM Display Screen Copyright 1998 by NEC Technologies, Inc.

12

78133441 6/24/98, 7:50 AM14

Troubleshooting

No picture

• Display card should be completely seated in its slot.

• Power Button and computer power switch should be in the ON position.

• Signal cable should be completely connected to display card/computer.

• Check connector for bent or pushed-in pins.

Image is scrolling or unstable

• Signal cable should be completely attached to the computer.

• Check pin assignments and signal timings of the monitor and your
display card with respect to recommended timings and pin assignments.

• If the Macintosh cable adapter is used, check for prior connection or
make sure the display card is Macintosh compatible and that the card is
properly seated in the computer.

LED on monitor is not lit

• Power Button should be in the ON position and power cord should
be connected.

Picture is fuzzy or color looks blotchy

• Adjust Brightness and Contrast Controls.

• Access the Degauss Control through OSM™ controls. Activate the
Degauss Control.
CAUTION: A minimum interval of 20 minutes should elapse before the

Deguass Control is used a second time when not switching
between modes.

Picture bounces or a wavy pattern is present
in the picture

• Move electrical devices that may be causing electrical interference away
from the monitor.

• See inside cover of User’s Manual for FCC information.

Edges of the display image are not square

• Use the OSM Geometry Controls to straighten the edges.

• If possible, position the front of the monitor facing east.

Display image is not centered, too small, or too large

• Use the OSM Size and Position Controls to adjust the image.

No sound

• Check to see if speaker cable is properly connected.

• Check to see if mute is activated.

• Check to see if volume in OSM is set at minimum.

Microphone not functioning

• Check to see if microphone cable is properly connected.

• Switch microphone and speaker connector.

(no green, orange, yellow color can be seen)

78133441 6/24/98, 7:50 AM15

13

References

• BBS [phone]

NEC Technologies’ Remote Bulletin Board System is an electronic service
accessible with your system and a modem. Communication parameters
are: 300/1200/2400/9600/14.4k/28.8k bps, no parity, 8-data bits,
1 stop bit

• Customer Service/
Technical Support [phone]

Fax [phone]

• Direct Sales [phone]

• Electronic Channels:

Internet e-mail: [e-mail]
Internet ftp site: ftp.nectech.com
CompuServe: go NECTECH
World Wide Web: http://www.nec.com
Windows® 95 INF File: http://www.nec.com/drivers/graphic.htm

then download the file NECMSINF.ZIP

• FastFacts™ Information [phone]

INFORMATION DESCRIPTION DOCUMENT #

MultiSync® M500™ and Detailed monitor information 157201
MultiSync M700™ monitors

Glossary Definition of terms related 900203

to functions, features and
installation of the
MultiSync monitor

More Information Names and addresses of 900204

other groups involved in
standards and features of
the MultiSync monitor

Macintosh Connection Detailed information on 153006

connecting the MultiSync
monitor to a Macintosh

Healthy Work Environment Detailed information on 900108

setting up a healthy work
environment

• Literature & Sales Info (800) NEC-INFO [[phone]]

• MultiSync Fulfillment [phone]

[For software & accessories]

• TeleSales [phone]

78133441 6/24/98, 7:50 AM16

14

Limited Warranty

NEC Technologies, Inc. (hereinafter “NECTECH”), warrants this Product to be free from defects in
material and workmanship and, subject to the conditions set forth below, agrees to repair or
replace any part of the enclosed unit which proves defective for a period of three (3) years from
the date of first consumer purchase. Spare parts are warranted for ninety (90) days.

This warranty gives you specific legal rights and you may also have other rights which vary
from state to state. This warranty is limited to the original purchaser of the Product and is not
transferable. This warranty covers only NECTECH-supplied components. Service required as
a result of third party components is not covered under this warranty. In order to be covered
under this warranty, the Product must have been purchased in the U.S.A. or Canada by the
original purchaser. This warranty only covers Product distribution in the U.S.A. or Canada
by NECTECH. Any use or installation outside the U.S.A. or Canada will void this warranty.

Proof of Purchase will be required by NECTECH to substantiate date of purchase. Such proof
of purchase must be an original bill of sale or receipt containing name and address of seller,
purchaser, and the serial number of the product.

It shall be your obligation and expense to have the Product shipped, freight prepaid, or
delivered to the authorized reseller from whom it was purchased or other facility authorized
by NECTECH to render the services provided hereunder in either the original package or a
similar package affording an equal degree of protection. All Products returned to NECTECH
for service MUST have prior approval, which may be obtained by calling 1-800-632-4662.

The Product shall not have been previously altered, repaired, or serviced by anyone other
than a service facility authorized by NECTECH to render such service, the serial number
of the product shall not have been altered or removed. In order to be covered by this warranty
the Product shall not have been subjected to displaying of fixed images for long periods of
time resulting in Image persistence (afterimage effects), accident, misuse or abuse or operated
contrary to the instructions containedin the User’s Manual. Any such conditions will void this
warranty.

NECTECH SHALL NOT BE LIABLE FOR DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL,
OR OTHER TYPES OF DAMAGES RESULTING FROM THE USE OF ANY NECTECH
PRODUCT OTHER THAN THE LIABILITY STATED ABOVE. THESE WARRANTIES ARE IN LIEU OF
ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR THE
LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES SO THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.

This Product is warranted in accordance with the terms of this limited warranty. Consumers are
cautioned that Product performance is affected by system configuration, software, the application,
customer data, and operator control of the system, among other factors. While NECTECH Products
are considered to be compatible with many systems, specific functional implementation by the
customers of the Product may vary. Therefore, suitability of a Product for a specific purpose or
application must be determined by consumer and is not warranted by NECTECH.

For the name of your nearest authorized NECTECH service facility, contact NECTECH
at 1-800-632-4662.

78133441 6/24/98, 7:50 AM17

15

Notes

78133441 6/24/98, 7:50 AM18

Notes

78133441 6/24/98, 7:50 AM19

NEC Multimedia Series

The information disclosed in this document, including all designs and related materials, is the valuable property of NEC
Technologies and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this
document, including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights
are expressly granted to others.

The NEC Technologies product(s) discussed in this document are warranted in accordance with the terms of the Limited
Warranty Statement accompanying each product. However, actual performance of each such product is dependent upon
factors such as system configuration, customer data and operator control. Since implementation by customers of each
product may vary, the suitability of specific product configurations and applications must be determined by the customer
and is not warranted by NEC Technologies.

To allow for design and specification improvements, the information in this document is subject to change at any time
without notice. Reproduction of this document or portions thereof without prior approval of NEC Technologies is
prohibited.

DECLARATION OF CONFORMITY

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.

U.S. Responsible Party: NEC Technologies, Inc.

PROPRIETARY NOTICE AND LIABILITY DISCLAIMER

Address: 1250 N. Arlington Heights Road, Suite 500

Tel. No.: [phone]

Type of Product: Computer Monitor
Equipment Classification: Class B Peripheral
Models: JC-1572VMA-2 and JC-1735VMA-2

We hereby declare that the equipment specified above

conforms to the technical standards as specified in the FCC Rules.

Itasca, Illinois 60143

MultiSync is a registered trademark of NEC Technologies, Inc. in the U.S. and of NEC Home Electronics, Ltd. in Canada, UK, Germany, France,
Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland, Norway and Saudi Arabia. CromaClear, AccuColor, OptiClear and
ErgoDesign are registered trademarks of NEC Technologies, Inc. in the U.S. and Canada. M500, M700, Reduced Magnetic Field, IPM, FastFacts,
FullScan and OSM are trademarks of NEC Technologies, Inc. in the U.S. NEC is a registered trademark of NEC Corporation Copyright 1998
by NEC Technologies, Inc. OSM Display Screens Copyright 1998 by NEC Technologies, Inc. Windows is a registered trademark of Microsoft
Corporation. All other brands and product names are trademarks or registered trademarks of their respective owners.

As a Energy Star Partner, NEC Technologies has determined that this product meets the Energy Star guidelenes for energy efficiency.
The Energy Star emblem does not represent EPA endorsement of any product or service.

Part No. 78133441

Printed in Taiwan R.O.C.

78133441 6/24/98, 7:50 AM20
