NEC LT170 User Manual

LT170

Portable Projector

User’s Manual

IMPORTANT INFORMATION

Safety Cautions

Precautions

Please read this manual carefully before using your NEC LT170 Projec­tor and keep the manual handy for future reference. Your serial number is
located on the bottom of your projector. Record it here:

CAUTION

To turn off main power, be sure to remove the plug from power
outlet.
The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.

CAUTION

TO PREVENT SHOCK, DO NOT OPEN THE CABINET.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED NEC SERVICE PER­SONNEL.

This symbol warns the user that uninsulated voltage within the
unit may be sufficient to cause electrical shock. Therefore, it is
dangerous to make any kind of contact with any part inside of
the unit.

This symbol alerts the user that important information concern­ing the operation and maintenance of this unit has been pro­vided.
The information should be read carefully to avoid problems.

WARNING

TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S PLUG WITH AN EXTENSION CORD
OR IN AN OUTLET UNLESS ALL THREE PRONGS CAN BE FULLY
INSERTED.
DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COM­PONENTS INSIDE. ALL SERVICING MUST BE DONE BY QUALI­FIED NEC SERVICE PERSONNEL.

DOC Compliance Notice

This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

Acoustic Noise Information Ordinance-3. GSGV:

The sound pressure level is less than 70 dB (A) according
to ISO 3744 or ISO 7779.

RF Interference

WARNING

The Federal Communications Commission does not allow any
modifications or changes to the unit EXCEPT those specified by
NEC Soluctions (America), Inc. in this manual. Failure to comply
with this government regulation could void your right to operate
this equipment. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residen­tial installation. This equipment generates, uses, and can radi­ate radio frequency energy and, if not installed and used in ac­cordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equip­ment does cause harmful interference to radio or television re­ception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

In UK, a BS approved power cable with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cable is not
supplied with this equipment please contact your supplier.

Important Safeguards

These safety instructions are to ensure the long life of your projector and
to prevent fire and shock. Please read them carefully and heed all warn­ings.

Installation

1. For best results, use your projector in a darkened room.

2. Place the projector on a flat, level surface in a dry area away from
dust and moisture.

To avoid premature lamp failure, do not tilt the front of the projector
up or down by more than 10° from level.

3. Do not place your projector in direct sunlight, near heaters or heat
radiating appliances.

4. Exposure to direct sunlight, smoke or steam can harm internal com­ponents.

5. Handle your projector carefully. Dropping or jarring can damage in­ternal components.

6. Do not place heavy objects on top of the projector.

7. If you wish to have the projector installed on the ceiling:

a. Do not attempt to install the projector yourself.

b. The projector must be installed by qualified technicians in order

to ensure proper operation and reduce the risk of bodily injury.

c. In addition, the ceiling must be strong enough to support the pro-

jector and the installation must be in accordance with any local
building codes.

d. Please consult your dealer for more information.

8. Do not use the projector upside down on the surface of a tall cabinet,
a table, or a floor. Doing so can hit the POWER button before you
notice.

WARNING TO CALIFORNIA RESIDENTS:

Handling the cables supplied with this product, will expose you to
lead, a chemical known to the State of California to cause birth de­fects or other reproductive harm. Wash hands after handling.

Copyright© 2003 by NEC Viewtechnology, Ltd.

E-2

COMPUTER

S-VID

EO IN

AUDIO IN

VIDEO IN

IMPORTANT INFORMATION

Fire and Shock Precautions

1. Ensure that there is sufficient ventilation and that vents are unob­structed to prevent the build-up of heat inside your projector. Allow at
least 4 inches (10 cm) of space between your projector and a wall.

2. Prevent foreign objects such as paper clips and bits of paper from
falling into your projector.

Do not attempt to retrieve any objects that might fall into your projec­tor. Do not insert any metal objects such as a wire or screwdriver into
your projector. If something should fall into your projector, disconnect
it immediately and have the object removed by a qualified NEC ser­vice personnel.

3. Do not place any liquids on top of your projector.

4. Do not look into the lens while the projector is on. Serious damage to
your eyes could result.

5. Keep any items such as magnifying glass out of the light path of the
projector. The light being projected from the lens is extensive, there­fore any kind of abnormal objects that can redirect light coming out of
the lens, can cause unpredictable outcome such as fire or injury to
the eyes.

6. Do not cover the lens with anything other than the built-in lens shutter
while the projector is on. Doing so can lead to melting of the cover
and possibly burning your hands due to the heat emitted from the
light output.

7. The projector is designed to operate on a power supply of 100-120 or
200-240 V 50/60 Hz AC. Ensure that your power supply fits this re­quirement before attempting to use your projector.

8. Handle the power cable carefully and avoid excessive bending.
A damaged cord can cause electric shock or fire.

9. If the projector is not to be used for an extended period of time, dis­connect the plug from the power outlet.

10. Do not touch the power plug during a thunderstorm. Doing so can
cause electrical shock or fire.

11. Do not handle the power plug with wet hands.

Lamp Replacement

•To replace the lamp, follow all instructions provided on page E-35.

• Be sure to replace the lamp when the message "The lamp has
reached the end of its usable life. Please replace the lamp." ap­pears. If you continue to use the lamp after the lamp has reached the
end of its usable life, the lamp bulb may shatter, and pieces of glass
may be scattered in the lamp case. Do not touch them as the pieces
of glass may cause injury.

If this happens, contact your NEC dealer for lamp replacement.

• Allow a minimum of 60 seconds to elapse after turning off the projec­tor. Then disconnect the power cable and allow 60 minutes to cool
the projector before replacing the lamp.

What's in the Box?

Make sure your box contains everything listed. If any pieces are missing,
contact your dealer.
Please save the original box and packing materials if you ever need to
ship your LT170 Projector.

O

F
F

V
ID

P
0

EO

W
E

A

R

U

T
O

AU

S

A

-

D

V

O

T

ID

J

N

O

.

E

O

C
O

M
P

CO

U
T

E

M

R

P
.

AS

PEC

E
NTER

T

M
EN

U

H

E
L

P

CA

P
I

FR

N

C

T

C

EEZE

U

E

R

E

L

P

R
E

T

E

N

C

E

R

Y

U

O

B

S

D
N

A
T

/S

N

T

O

C

E

L

E

S

R

E

W

O

S

P

U

U

T

N

A

E

T

M

S
P
M

A
L

M
O

O
Z

S

U
C

O
F

PUSH

Projector

C

­M

U

M

T

U

E
T
E

M
A

G
N

I
F
Y

Remote control
(7N900431)

Batteries

CAUTION

1. Do not try to touch the ventilation outlet on the rear as it can become
heated while the projector is turned on.

2. Do no use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can cause
damage to the projector.

3. When carrying the projector, heed the following:

* Use the supplied soft carrying case. Before putting the projector in

the soft carrying case, be sure to close the lens shutter so as not
to mar the lens.

* Do not handle the projector roughly.

* Do not send the soft carrying case by parcel delivery service or

cargo shipment. The projector inside the soft carr ying case could
be damaged. (However, it is possible to use it as a carrier case on
board.)

4. Select “High” in the Fan mode if you continue to use the projector for
consecutive days. (From the menu, select [To Advanced Menu] →
[Setup 2] → [Fan Mode].)

5. Do not unplug the power cable from the wall outlet under any one of
the following circumstances.

Doing so can cause damage to the projector:

* While the Hour Glass icon appears.

* While the cooling fans are running. (The cooling fans continue to

work for 60 seconds after the projector is turned off).

Soft carrying case and its accessory pouch
(24BS7281)

1

Band (24B17871)
Use for bundling cables.

Flat-blade screwdriver
(24C05941)

Tr ipod adapter
(24H49051)

For North America only

Registration card
Limited warranty

For Europe only

Guarantee policy

E-3

Power cable
(US: 7N080206)
(EU: 7N080005)

2

RGB signal cable
(7N520012)

CD-ROM
User’s manual

Quick

Connect

Guide

Important

Information

TABLE OF CONTENTS

IMPORTANT INFORMATION ................................E-2

Safety Cautions ........................................................................... E-2

What's in the Box? ...................................................................... E-3

INTRODUCTION.................................................... E-5

Introduction to the Projector ....................................................... E-5

Part Names of the Projector ........................................................ E-6

Top Features ............................................................................. E-7

Terminal Panel Features ............................................................ E-7

Part Names of the Remote Control ........................................... E-8

Battery Installation ................................................................. E-9

Remote Control Precautions .................................................. E-9

Operating Range for Wireless Remote Control ...................... E-9

INSTALLATION AND CONNECTIONS ...............E-10

Setting Up the Screen and the Projector .................................... E-10

Selecting a Location ............................................................... E-10

Throw Distance and Screen Size ............................................. E-11

Making Connections .................................................................. E-12

Connecting Your PC or Macintosh Computer ......................... E-12

To connect SCART output (RGB) ............................................ E-13

Connecting Your DVD Player .................................................. E-14

Connecting Your VCR or Laser Disc Player............................. E-15

Attaching the Projector to a Tripod ......................................... E-16

Connecting the Supplied Power Cable .................................... E-17

PROJECTING AN IMAGE (BASIC OPERATION) ......

Tur ning on the Projector ............................................................ E-18

Selecting a Source ..................................................................... E-19

Adjusting the Picture Size and Position ..................................... E-19

Correcting the Vertical Keystone Distortion ............................... E-20

Optimizing RGB Picture Automatically ....................................... E-21

Tur ning Up or Down Volume ..................................................... E-21

Tur ning off the Projector ............................................................ E-22

After Use ................................................................................... E-22

E-18

Advanced Manu .......................................................... E-32

[Image]

Auto Adjust / Horizontal / Vertical / Clock / Phase /

Noise Reduction / Flicker Reduction .................................... E-32

[Setup 1]

Lamp Mode / Language / Menu Color Select /
Menu Display Time /Background / Orientation /

Cabinet Button / Security/ Portrait ....................................... E-33

[Setup 2]

Power Management / Auto Start / Fan Mode / Signal Select E-33

[Information]

Page 1-4 .............................................................................. E-34

[Default]

Factory Default / Clear Lamp Hour Meter ............................. E-34

MAINTENANCE................................................... E-35

Replacing the Lamp ................................................................... E-35

Cleaning the Cabinet and the Lens ............................................. E-36

TROUBLESHOOTING......................................... E-37

Power Indicator (POWER) ......................................................... E-37

Status Indicator (STATUS) ......................................................... E-37

Lamp Indicator (LAMP) ............................................................. E-37

Common Problems & Solutions ................................................ E-38

SPECIFICATIONS ............................................... E-39

APPENDIX ........................................................... E-40

Cabinet Dimensions ................................................................... E-40

Pin Assignments of D-Sub COMPUTER Input Connector .......... E-40

Compatible Input Signal List ..................................................... E-41

TravelCare Guide........................................................................ E-42

CONVENIENT FEATURES ................................. E-24

Tur ning Off the Image and Sound .............................................. E-24

Freezing a Picture ...................................................................... E-24

Enlarging and Moving a Picture ................................................. E-24

Getting the Information ............................................................. E-24

Security ..................................................................................... E-24

USING ON-SCREEN MENU................................ E-27

Basic Menu Operation ............................................................... E-27

Using the Menus ..................................................................... E-27

Adjusting and Setting Items .................................................... E-28

List of Menu Items .................................................................... E-29

Menu Elements .......................................................................... E-30

Menu Descriptions & Functions ................................................ E-31

Basic Menu .................................................................. E-31

Auto Adjust Executed .............................................................. E-31

Aspect Ratio ........................................................................... E-31

Picture Management ............................................................... E-31

Brightness .............................................................................. E-32

Contrast .................................................................................. E-32

Sharpness ............................................................................... E-32

Color ....................................................................................... E-32

Hue ......................................................................................... E-32

Keystone ................................................................................. E-32

E-4

INTRODUCTION

Introduction to the Projector

This section introduces you to your new LT170 Projector and describes the features and
controls.

Congratulations on Your Purchase of The LT170 Projector

The LT170 is one of the very best projectors available today. The LT170 enables you to project
precise images up to 200 inches (measured diagonally) from your PC or Macintosh computer
(desktop or notebook), VCR, DVD player, document camera, or a laser disc player.
You can use the projector on a tabletop or cart, you can use the projector to project images
from behind the screen, and the projector can be permanently mounted on a ceiling*
remote control can be used wirelessly.

1

Do not attempt to mount the projector on a ceiling yourself. The projector must be installed

*

by qualified technicians in order to ensure proper operation and reduce the risk of bodily
injury.
In addition, the ceiling must be strong enough to support the projector and the installation
must be in accordance with any local building codes. Please consult your dealer for more
information.

Features you'll enjoy:

•Auto vertical keystone correction up to +/- 30 degrees

• Security feature prevents the projector from being used by unauthorized individuals.

Password protection prevents unauthorized individuals from changing projector settings.

Cabinet Button Lock helps prevent unauthorized adjustments to the projector.

• One touch projection angle adjustment

• Manual lens shutter for protecting the lens

• Supplied carrying case with pouch for accessories

• Short focal length lens

• Remote features one touch source change buttons

•New Color Management system

•Newly designed menu system with dial control

• Multi-language on-screen menu

• The projector can be used with a tripod

• NEC’s exclusive Advanced AccuBlend intelligent pixel blending technology - an extremely

accurate image compression technology - offers image display from sources up to UXGA
(1600 ⳯ 1200) resolution*

• Supports most IBM VGA, SVGA, XGA , SXGA/UXGA (with Advanced AccuBlend)*

Macintosh, component signal (YCbCr/ YPbPr) or any other RGB signals within a horizontal
frequency range of 24 to 100 kHz and a vertical frequency range of 50 to 120 Hz. This
includes NTSC, PAL, PAL-N, PAL-M, PAL60, SECAM and NTSC4.43 standard video sig­nals.

2

*

A UXGA (1600 ⳯ 1200) and SXGA image (1280 ⳯ 1024) are displayed with NEC’s Ad­vanced AccuBlend.

2

.

1

. The

2

,

NOTE: Composite video standards are as follows:
NTSC: U.S. TV standard for video in U.S. and Canada.
PAL: TV standard used in Western Europe.
PAL-N: TV standard used in Argentine, Paraguay and Uruguay.
PAL-M: TV standard used in Brazil.
PAL60: TV standard used for NTSC playback on PAL TVs.
SECAM: TV standard used in France and Eastern Europe.
NTSC4.43: TV standard used in Middle East countries.

E-5

INTRODUCTION

C

O

M

P

U

T

E

R

S

-V

ID

E

O

IN

A

U

D

IO

IN

V

ID

E

O

IN

PUSH

Part Names of the Projector

Zoom Ring

Focus Ring

Remote Sensor

Lens

Lens Shutter Lever

Opens or closes the lens shutter.

Adjustable Tilt Foot

Adjustable Tilt Foot Button

Controls

R

E
T

E

N

C

E

R

Y

U

O

B

S

D
N

A
T

/S

T

C

M
O

O
Z

S

U
C

O
F

H
S

U
P

C

L

O

S

E

N

E

L

O

E

S

R
E

W

O

S

P

U

U

T

N

A

E

T

M

S

P

M
A

L

Ventilation (inlet)

Te rminal Panel

AC Input
Connect the supplied power cable's two-pin plug here, and
plug the other end into an active wall outlet.

Fine Adjustment Ring for Tilt Foot

Lamp Cover

PUSH

FO

C
U

S

ZO

O
M

LAMP

MENU

STATUS

POWER

ON/STAND BY

S

E

L

E

C

T

S
O
U

R

ENTER

C
E

Fine Adjustment Ring for Tilt Foot

Lamp Cover Screw

Ventilation (outlet)

Monaural Speaker (0.5W)

Built-in Security Slot (

)*

* This security slot supports the MicroSaver® Security System. MicroSaver® is a registered trademark of Kensington Microware Inc. The logo is

trademarked and owned by Kensington Microware Inc.

E-6

INTRODUCTION

Top Features

56

E

L

C

E

T

S

4

3

2

LAMP

STATUS

POWER

MENU

ON/STAND BY

SOURCE
ENTER

17

1. POWER Button (ON / STAND BY)( )

Use this button to turn the power on and off when the main power is
supplied and the projector is in standby mode.
To turn on the projector, press and hold this button for a minimum of
two seconds. To turn off the projector, press this button twice.

2. POWER Indicator

When this indicator is green, the projector is on; when this indicator is
orange, it is in standby mode. See the Power Indicator section on page
E-37 for more details.

3. STATUS Indicator

If this light blinks red rapidly, it indicates that an error has occurred, the
lamp cover is not attached properly or the projector has overheated. If
this light remains orange, it indicates that you have pressed a cabinet
button while the Cabinet Button is locked. See the Status Indicator
section on page E-37 for more details.

4. LAMP Indicator

If this light blinks red rapidly, it's warning you that the lamp has reached
the end of its usable life. After this light appears, replace the lamp as
soon as possible (See page E-35). If this is lit green continually, it
indicates that the lamp mode is set to Eco. See the Lamp Indicator
section on page E-37 for more details.

5. MENU Button

Displays the menu. Press again to close the menu.

6. SELECT +/–, Volume Dial

* When the menu is displayed, rotating the dial makes menu selec-

tions. See page E-27.

* When the menu is not displayed, rotating the dial increases or de-

creases the volume. See page E-21.

7. SOURCE/ENTER Button

* When the menu is not displayed, this button works as the SOURCE

button. A press of the SOURCE button displays the Source Select
screen. See page E-19.

* When the menu is displayed, this button works as the ENTER but-

ton. A press of the ENTER button executes your menu selection and
activates items selected from the menu. See page E-27.

Terminal Panel Features

1453 2

AC IN

S-VIDEO IN

AUDIO IN

1. COMPUTER / Component Input Connector (Mini D-Sub 15 Pin)
Connect your computer or other analog RGB equipment such as IBM
compatible or Macintosh computers. Use the supplied RGB cable to
connect to your computer. This also serves as a component input con­nector that allows you to connect a component video output of compo­nent equipment such as a DVD player (optional adapter ADP-CV1
required). This connector also suppor ts SCART output signal. See page
E-13 for more details.

2. VIDEO IN Connector (RCA)
Connect a VCR, DVD player, laser disc player, or document camera
here to project video.

3. S-VIDEO IN Connector (Mini DIN 4 Pin)
Here is where you connect the S-Video input from an external source
like a VCR.

NOTE: S-Video provides more vivid color and higher resolution than the tradi­tional composite video format.

4. AUDIO IN Mini Jack (Stereo Mini)
This is where you connect the audio output from your computer or
DVD player. A commercially available audio cable is required.

5. Maintenance Terminal
For service use only.

VIDEO IN

COMPUTER

E-7

INTRODUCTION

Part Names of the Remote Control

3
4

5
7

9

OFF

VIDEO

AUTO ADJ.

AUTO

P0WER ON

COMPUTER

S-VIDEO

ENTER

COMP.

ASPECT

1

2
6

8

10

11

13
14
15

17

1. Infrared Transmitter
Direct the remote control toward the remote sensor on the projector
cabinet.

2. POWER ON Button
When the main power is supplied, you can use this button to turn your
projector on.

NOTE: To turn on the projector, press and hold the POWER ON button for a
minimum of two seconds.

3. POWER OFF Button
You can use this button to turn your projector off.

NOTE: To turn off the projector, press the POWER OFF button twice.

4. VIDEO Button
Press this button to select a video source from a VCR, DVD player,
laser disc player or document camera.

5. S-VIDEO Button
Press this button to select an S-Video source from a VCR.

6. COMPUTER Button
Press this button to select Computer input.

7. AUTO ADJ. Button
Use this button to adjust an RGB source for an optimal picture.
See page E-21.

8. ASPECT Button
Press this button to display the Aspect Ratio select screen. See page
E-31.

9. 왖왔왗왘 Button
왖왔 : Use these buttons to select the menu of the item you wish to

adjust.

왗왘 : Use these buttons to change the level of a selected menu item.

When no menus appear, these buttons work as a volume con­trol.

When an image is magnified, the 왖왔왗왘 button moves the image.

MENU

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

CANCEL

12

16

10. ENTER Button
Executes your menu selection and activates items selected from the
menu.

11. MENU Button
Displays the menu for various settings and adjustments.
Press again to close the menu.

12. CANCEL Button
Pressing this button will return to the previous menu. While you are in
the Basic menu, pressing this button will close the menu.

13. HELP Button
Provides the projector information.

14. PICTURE Button
Press this button to display the Picture adjustment screen such as
Brightness, Contrast, Sharpness, Color and Hue. See page E-32.

15. PIC-MUTE Button
This button turns off the image and sound for a short period of time.
Press again to restore the image and sound.

16. FREEZE Button
This button will freeze a picture. Press again to resume motion.

17. MAGNIFY (+)(–) Button
Use this button to adjust the image size up to 400%.
The image is magnified about the center of the screen. See page E-

24.

E-8

INTRODUCTION

Battery Installation

1. Press firmly and slide the battery cover off.

1

2

2. Remove both old batteries and install new ones (AAA). Ensure that
you have the batteries' polarity (+/-) aligned correctly.

3. Slip the cover back over the batteries until it snaps into place. Do not
mix different types of batteries or new and old batteries.

Remote Control Precautions

• Handle the remote control carefully.

• If the remote control gets wet, wipe it dry immediately.

•Avoid excessive heat and humidity.

• If you will not be using the remote control for a long time, remove the
batteries.

• Do not place the batteries upside down.

• Do not use new and old batteries together, or use different types of
batteries together

Operating Range for Wireless Remote Control

7m / 22 feet

Remote sensor on

30°

30°

Remote control

Actual operating range may differ from the above drawing.

• The infrared signal operates by line-of-sight up to a distance of about
22 feet/7 m and within a 60-degree angle of the remote sensor on the
projector cabinet.

• The projector will not respond if there are objects between the remote
control and the sensor, or if strong light falls on the sensor. Weak bat­teries will also prevent the remote control from properly operating the
projector.

projector cabinet

E-9

INSTALLATION AND CONNECTIONS

This section describes how to set up your projector and how to connect video and audio sources.

1

3

2

To the wall outlet.

Your projector is simple to set up and
use. But before you get started, you
must first:

 Set up a screen and the projector.

 Connect your computer or video

equipment to the projector. See
pages E-12 to 15.

 Connect the supplied power cable.

See page E-17.

NOTE: Ensure that the power cable and any
other cables are disconnected before mov­ing the projector. When moving the projec­tor or when it is not in use, close the lens
shutter.

Setting Up the Screen and the Projector

Selecting a Location

The further your projector is from the screen or wall, the larger the image. The minimum size the image can be is approximately 30" (0.76 m) measured
diagonally when the projector is roughly 44.5 inches (1.1 m) from the wall or screen. The largest the image can be is 200" (5.0 m) when the projector is
about 305.5 inches (7.8 m) from the wall or screen. Use the drawing below as a guide.

Screen size (Unit: cm / inch)

406.4 (W) ⳯ 304.8 (H) / 160 (W) ⳯ 120 (H)

365.8 (W) ⳯ 274.3 (H) / 144 (W) ⳯ 108 (H)

200"

Screen size

180"

304.8 (W) ⳯ 228.6 (H) / 120 (W) ⳯ 90 (H)

150"

243.8 (W) ⳯ 182.9 (H) / 96 (W) ⳯ 72 (H)

203.2 (W) ⳯ 152.4 (H) / 80 (W) ⳯ 60 (H)

162.6 (W) ⳯ 121.9 (H) / 64 (W) ⳯ 48 (H)

121.9 (W) ⳯ 91.4 (H) / 48 (W) ⳯ 36 (H)

81.3 (W) ⳯ 61.0 (H) / 32 (W) ⳯ 24 (H)

61.0 (W) ⳯ 45.7 (H) / 24 (W) ⳯ 18 (H)

Lens center

30"

1.1

44.5

60"

40"

1.5/59.8

120"

100"

80"

3.1/121.3

2.3/90.6

4.6/182.7

3.9/152.2

5.8/228.7

7.8/305.5

7.0/274.8

Distance (Unit: m/inch)

CAUTION:To avoid premature lamp failure, do not tilt the front of
the projector up or down by more than 10° from level.

E-10

INSTALLATION AND CONNECTIONS

Throw Distance and Screen Size

The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation.

Distance Chart

Screen Height

Screen Size B C

inch

30
40
60
67
72
80
84

90
100
120
150
180
200

inch

24
32
48
54
58
64
67
72
80

96
120
144
160

inch

108
120

Screen Width

Screen Diagonal

B = Vertical distance between lens center and screen center
C = Throw distance
D = Vertical distance between lens center and top of screen (bottom of

Screen center

(B)

(D)

screen for desktop)
α = Throw angle

NOTE: Distances may vary +/-5%.

Screen Bottom

Lens Center

Throw Angle (α)

Throw Distance (C

α

D

Wide – TeleDiagonal Width Height

inch

inch
18
24
36
40
43
48
50
54
60
72
90

10
14
16
17
19
20
22
24
29
36
43
48

7

42 - 47
57 - 63
86 - 95

96 - 106
104 - 114
115 - 127
121 - 133
130 - 143
145 - 159
174 - 191
218 - 240
262 - 288
291 - 320

inch

11
12

2
2
4
4
4
5
5
5
6
7
9

Wide – Tele

degree

9.7 - 8.7

9.5 - 8.7

9.5 - 8.6

9.5 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.5

9.4 - 8.5

9.4 - 8.5

)

Screen Size B C

mm

mm

762

610

1016

813

1524

1219

1702

1361

1829

1463

2032

1626

2134

1707

2286

1829

2540

2032

3048

2438

3810

3048

4572

3658

5080

4064

mm
457
610

914
1021
1097
1219
1280
1372
1524
1829
2286
2743
3048

mm

183
244
366
408
439
487
512
548
609
731

914
1097
1219

Wide – TeleDiagonal Width Height

mm
1070 - 1190
1450 - 1590
2190 - 2410
2450 - 2700
2640 - 2900
2930 - 3230
3080 - 3390
3300 - 3640
3680 - 4050
4420 - 4860
5530 - 6090
6650 - 7310
7390 - 8130

mm

102
110
122
128
137
153
183
229
275
305

D

46
61
92

α

Wide – Tele

degree

9.7 - 8.7

9.5 - 8.7

9.5 - 8.6

9.5 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.6

9.4 - 8.5

9.4 - 8.5

9.4 - 8.5

WARNING
* Installing your projector on the ceiling must be done by a quali-

fied technician. Contact your NEC dealer for more information.

* Do not attempt to install the projector yourself.

• Only use your projector on a solid, level surface. If the projector falls to
the ground, you can be injured and the projector severely damaged.

• Do not use the projector where temperatures vary greatly. The projec­tor must be used at temperatures between 41˚F (5˚C) and 95˚F (35˚C).

• Do not expose the projector to moisture, dust, or smoke. This will harm
the screen image.

• Ensure that you have adequate ventilation around your projector so
heat can dissipate. Do not cover the vents on the side or the front of
the projector.

Reflecting the Image

Using a mirror to reflect your projector's image enables you to enjoy a
much larger image. Contact your NEC dealer if you need a mirror. If you're
using a mirror and your image is inverted, use the MENU button and
SELECT dial on your projector cabinet or the MENU and the 왖왔왗왘
buttons on your remote control to correct the orientation. (See page E-

33.)

E-11

INSTALLATION AND CONNECTIONS

Making Connections

NOTE: When using with a notebook PC, be sure to connect between the projector and the notebook PC before turning on the power to the notebook PC. In most cases
signal cannot be output from RGB output unless the notebook PC is turned on after connecting with the projector.

* If the screen goes blank while using your remote control, it may be the result of the computer's screen-saver or power management software.
* If you accidentally hit the POWER button on the remote control, wait 60 seconds and then press the POWER button again to resume.

Connecting Your PC or Macintosh Computer

Audio cable (not supplied)

IBM PC or Compatibles (Desktop type)
or Macintosh (Desktop type)

PHONE

NOTE: For older Macintosh,
use a commercially available
pin adapter (not supplied) to
connect to your Mac's video
port.

AUDIO IN

AC IN

AUDIO IN

S-VIDEO IN

VIDEO IN

COMPUTER

COMPUTER

RGB signal cable (supplied)
To mini D-Sub 15-pin connector on the pro­jector. It is recommended that you use a
commercially available distribution amplifier
if connecting a signal cable longer than the
supplied one.

PHONE

IBM VGA or Compatibles (Notebook type)
or Macintosh (Notebook type)

Connecting your PC or Macintosh computer to your projector will enable you to project your computer's screen image for an impressive presentation.
To connect to a PC or Macintosh, simply:

1. Turn off the power to your projector and computer.

2. Use the supplied signal cable to connect your PC or Macintosh to the projector.

3. Turn on the projector and the computer.

4. If the projector goes blank after a period of inactivity, it may be caused by a screen saver installed on the computer you've connected to the projector.

E-12

INSTALLATION AND CONNECTIONS

C
O
M

P
U
T
E
R

S

­V
I
D
E
O

I
N

A

U
D
I
O
I
N

V
I
D
E
O

I
N

To connect SCART output (RGB)

Before connections: An exclusive SCART adapter (ADP-SC1) and a commercially available SCART cable are required for this connection.

NOTE: Audio signal is not available for this connection.

Projector

Video equipment such as DVD player

COMPUTER

AC IN

S-VIDEO IN

VIDEO IN

Commercially available
SCART cable

Female

AUDIO IN

ADP-SC1

COMPUTER

To COMPUTER connector

1. Turn off the power to the projector and your video equipment.

2. Use the NEC ADP-SC1 SCART adapter and a commercially available
SCART cable to connect the COMPUTER input of your projector and
a SCART output (RGB) of your video equipment.

3. Turn on the power to the projector and your video equipment.

4. Use the COMPUTER button on the remote control to select the COM­PUTER input.

Using the projector in portrait mode

When connecting with a Tablet PC, you can display an image in portrait
mode with the projector on its side.

• Place the projector on a location such as a table with the terminal
panel side up.

• Be sure to place the projector on a flat level surface.

•Auto Keystone correction feature is not available.

• The on-screen menu will not be rotated.

• If the image is displayed upside down, select [Advanced menu] →
[Setup 1] → [Portrait] → [0°] or [180°] for display orientation of your
PC. See also page E-33 for Portrait.

5. Press the MENU button on the remote control to display the menu.

6. From the menu, select [To Advanced Menu]

→

[Setup 2] → [Signal
Select Computer] → [Scart].
SCART is a standard European audio-visual connector for TVs, VCRs
and DVD players. It is also referred to as Euro-connector.

NOTE: The ADP-SC1 SCART adapter is obtainable from your NEC dealer in Eu­rope. Contact your NEC dealer in Europe for more information.

P
U
S
H

F
O

Z

C

O

U

O

S

M

L
A
M
S
T
P
A

P

T

O

M

U

W

E

S

E

N

R

U

O
N
/
S
T
A
N
D

S

B

E

Y

L

E

C

T

S
O
E
U
N
R
T
C
E
E
R

The projected image is displayed at a lower level than
the normal position. Adjust the projection angle and
position for the correct position of the projected image
on screen.

E-13

INSTALLATION AND CONNECTIONS

Connecting Your DVD Player

Audio Equipment

AUDIO IN

LR

AUDIO IN

AC IN

AUDIO IN

S-VIDEO IN

VIDEO IN

COMPUTER

COMPUTER

L R

AUDIO OUT

Optional 15-pin-to-RCA
(female)⳯3 cable (ADP-CV1)

YCbCr

Component

Component video RCA
(not supplied)

DVD player

⳯

3 cable

Audio cable
(not supplied)

You can connect your projector to a DVD player with component output or Video output. To do so, simply:

1. Turn off the power to your projector and DVD player.

2. If your DVD player has the component video (Y,Cb,Cr) output, use a commercially available component video cable (RCA

⳯

3) and the optional 15-

pin-to-RCA (female)⳯3 cable to connect your DVD player to the COMPUTER input connector on the projector.

For a DVD player without component video (Y,Cb,Cr) output, use common RCA cables (not provided) to connect a composite VIDEO output of the
DVD player to the Video Input of the projector.

3. Turn on the projector and DVD player.

NOTE: Refer to your DVD player's owner's manual for more information about your DVD player's video output requirements.

E-14

INSTALLATION AND CONNECTIONS

Connecting Your VCR or Laser Disc Player

S-VIDEO IN

AC IN

Video cable (not supplied)

VCR/ Laser disc player

AUDIO OUT

L R

S-VIDEO IN

VIDEO IN

AUDIO IN

S-VIDEO VIDEO

VIDEO OUT

VIDEO IN

COMPUTER

S-Video cable (not supplied)

Audio equipment

AUDIO IN

LR

Audio cable (not supplied)

Use common RCA cables (not provided) to connect your VCR, laser disc player or document camera to your projector.
To make these connections, simply:

1. Turn off the power to the projector and VCR, laser disc player or document camera.

2. Connect one end of your RCA cable to the video output connector on the back of your VCR or laser disc player, connect the other end to the Video
input on your projector. Use an audio cable (not supplied) to connect the audio from your VCR or laser disc player to your audio equipment (if your
VCR or laser disc player has this capability). Be careful to keep your right and left channel connections correct for stereo sound.

3. Turn on the projector and the VCR or laser disc player.

NOTE: Refer to your VCR or laser disc player owner's manual for more information about your equipment's video output requirements.

E-15

INSTALLATION AND CONNECTIONS

COMPUTER

S-VIDEO IN

AUDIO IN

VIDEO IN

Attaching the Projector to a Tripod

The projector can be used with a camera tripod.
To attach the projector to a tripod, use the supplied tripod adapter.

CAUTION

Care should be taken in handling a tripod.
Using the tripod on an unstable surface may result in the
tripod falling over or the projector falling which may result
in damage to the projector and possible personal injury.
Read the instructions supplied with your tripod for handling
and cautions.

• Use a tripod that can fully support the weight of the pro-

jector (approximately 5.5 lb/2.5 kg including attachment).

• Place the tripod with its feet fully open and weight evenly

distributed for stability.

• When using a tripod with a geared elevator, do not ex-

tend the geared elevator.

• When displaying an image in portrait mode (with the

projector on its side) (page E-13), be sure the tripod is
balanced for stability. Failure to do so may result in the
tripod falling over.

Preparation:

1. Disconnect all the cables.

2. A flat-blade screwdriver is required for attaching the sup-

plied three (3) screws. Use the supplied flat-blade screw­driver.

3. Attach the projector to the tripod.

Open the tripod to a fully extended position for greatest stability.

E

NTER

C

E
R
U
O

S

D BY

N
A
T

/S
N

T

O

C

E

L

E

S

ER

OW

S

P

NU

ATU

ME

ST

P

LAM

M
O

O
Z

S
U

C
O
F

H
S
U
P

C

L

O

S

E

4. Connect all the cables.

1. Turn the projector upside down.

Place the projector on a soft cloth so as not to scratch the cabinet
surface.

2. Attach the supplied tripod adapter to the bottom of the
projector.

Secure the tripod adapter to the projector with the supplied (3) screws.

E-16

INSTALLATION AND CONNECTIONS

COM

PUTER

S-V

IDE

O IN

AUDIO IN

VIDE

O IN

POWER

POWER

Connecting the Supplied Power Cable

Connect the supplied power cable to the projector.
First connect the supplied power cable's two-pin plug to the AC IN of the
projector, and then connect the other plug of the supplied power cable in
the wall outlet.

MENU

R

E
T

E

N

E

Y

OURC

B

S

D

N
A

T

/S
N

T

O

C

E

L

E

S

R

E

W

O

S

P

U

U

T

N

A

E

T

M

S

P

M

A
L

M

O
O

Z

S
U

C

O
F

H
S

U
P

The projector will go into its standby mode and the power indicator will
glow orange.

LAMP

STATUS

POWER

POWER

ON/STAND BY

E

L

C

E

T

S

MENU

LAMP

STATUS

POWER

POWER

ON/STAND BY

SOURCE
ENTER

CAUTION:

Do not unplug the power cable from the wall outlet under any one of the
following circumstances.
Doing so can cause damage to the projector:
* While the Hour Glass icon appears.

* While the cooling fans are running. (The cooling fans continue to work

for 60 seconds after the projector is turned off).

E-17

PROJECTING AN IMAGE (BASIC OPERATION)

C

O

M

P

U

T

E

R

S

-V

ID

E

O

IN

A

U

D

IO

I

N

V

I

D

E

O

I

N

This section describes how to turn on the projector and to project a pic­ture onto the screen.

Tur ning on the Projector

Before you turn on your projector, ensure that the computer or video
source is turned on and that your lens shutter is open.

ZOOM

S

FOCU

PUSH

C

L

O

S

E

Only after you press the POWER (ON/STAND BY) button on the projec­tor cabinet or POWER ON button on the remote control for a minimum of
2 seconds will the power indicator turn to green and the projector be­come ready to use.

OFF

VIDEO

AUTO ADJ.

AUTO

P0WER ON

S-VIDEO

ENTER

COMPUTER

COMP.

ASPECT

E

L

C

E

T

S

MENU

LAMP

STATUS

POWER

ON/STAND BY

SOURCE
ENTER

NOTE: To turn the projector on by plugging in the power cable, use the menu and
enable the “Auto Start” feature. (See page E-33)

Note on Startup screen (Menu Language Select screen)

When you first turn on the projector, you will get the Startup screen. This
screen gives you the opportunity to select one of the 7 menu languages.

NOTE: If you want, you can select one of the 20 menu language later. See "Lan­guage" on page E-33.

To select a menu language, follow these steps:

1. Use the dial to select one of the 7 languages for the menu.
When using the remote control, keep pressing the 왔 button several
times until your language is highlighted.

2. Press the ENTER button to execute the selection.

OFF

P0WER ON

COMPUTER

VIDEO

S-VIDEO

AUTO ADJ.

AUTO

ENTER

MENU CANCEL

COMP.

ASPECT

LAMP

STATUS

POWER

MENU

ON/STAND BY

E

L

E

S

SOURCE
ENTER

C

T

After this has been done, you can proceed to the menu operation.

NOTE: Immediately after turning on the projector, screen flicker may occur. This
is not a malfunction. Wait 3 to 5 minutes until the lamp lighting is stabilized.

When the Lamp mode is set to Eco, the Lamp indicator will light green.

If one of the following things happens, the projector will not turn on.

* If the internal temperature of the projector is too high, the projector

detects abnormal high temperature. In this condition the projector will
not turn on to protect the internal system. If this happens, wait for the
projector's internal components to cool down.

* When the lamp reaches its end of usable life, the projector will not tur n

on. If this happens, replace the lamp.

* If the lamp fails to light, and if the STATUS indicator flashes on and off

in a cycle of six times, wait a full minute and then turn on the power.

If one of the following things happen, the projector will mute a picture. If it
continues muting for 15 minutes, the projector will go into standby mode.

*Turning on the power with the lens shutter closed.

* Closing the lens shutter during operation.

* Directing the lens downward by more than 60° from level during

operation.

*Turning on the power with the lens directed down by more than 60°

from level.

OFF

P0WER ON

E

L

C

E

T

S

MENU

LAMP

STATUS

POWER

ON/STAND BY

SOURCE
ENTER

COMPUTER

VIDEO

S-VIDEO

AUTO ADJ.

AUTO

ENTER

MENU CANCEL

COMP.

ASPECT

E-18

PROJECTING AN IMAGE (BASIC OPERATION)

Z

O

O

M

F

O

C

U

S

L

A

M

P

M

E

N

U

S

O

U

R

C

E

E

N

T

E

R

S

T

A

T

U

S

P

O

W

E

R

O

N

/

S

T

A

N

D

B

Y

S

E

L

E

C

T

CO

M

PUTER

S-VIDEO

IN

AU

DIO

IN

VID

EO

IN

PU

SH

C

L

O

S

E

1

3

2

C

O

M

P

U

T

E

R

S

-

V

ID

E

O

I

N

A

U

D

I

O

I

N

V

I

D

E

O

I

N

Selecting a Source

Selecting the computer or video source

Using the cabinet buttons

E

L

C

E

T

S

MENU

LAMP

STATUS

POWER

ON/STAND BY

Press and quickly release the SOURCE button on the projector cabinet
to display the Source list. Each time the SOURCE button is pressed,
each source name will be highlighted in sequence. Highlighting a source
name will display an hour glass icon in one second. After that the input
signal will be selected.

Using the Remote Control

OFF

P0WER ON

VIDEO

S-VIDEO

AUTO ADJ.

AUTO

ENTER

MENU

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

SOURCE
ENTER

COMPUTER

COMP.

ASPECT

Press any one of the COMPUTER, VIDEO or
S-VIDEO buttons.

CANCEL

Move the projector left to center the image horizontally on the screen.

Adjust the Tilt Foot

1. Lift the front part of the projector.

PUSH

Push and hold the

symbol of the Adjustable Tilt Foot button on
the front top of the projector to extend the adjustable tilt feet up to a
maximum height.

Adjustable Tilt Foot

Adjustable Tilt Foot Button

2. Lower the front of the projector to the desired height (max. 40mm/1.6”)
and release the Adjustable Tilt Foot Button to lock the Adjustable tilt
foot. There is approximately 10 degrees of up and down adjustment
for the front of the projector.

NOTE: If no input signal is available, the projector will display a blue background
(factory preset).

Adjusting the Picture Size and Position

Place your projector on a flat level surface and ensure that the projector
is square to the screen.

Lift the front edge of the projector to center the image vertically.
* If the projected image does not appear square to the screen then use

the Keystone feature for proper adjustment. See page E-20.

R
E

4

S
U

C
O
F

H
S

U
P

C

L

O

S

E

T

N
E

Y
B

SOURCE

D

N
A

T
/S

N

T

O

C

E

L

E

S

R

E

W

O

S

P

U

U

T

N

A

E

T

M

S

P

M
LA

M

O
O
Z

NOTE: You can rotate the Fine Adjustment rings of both tilt feet on the left and
right sides of the cabinet front for fine adjustment of the tilt feet.

CAUTION:
Do not use the tilt-foot for purposes other than originally intended.
Misuses such as gripping the tilt-foot or hanging on the wall can
cause damage to the projector.

E-19

PROJECTING AN IMAGE (BASIC OPERATION)

Zoom

Use the ZOOM ring to finely adjust the image size on the screen.

PUSH

FO

ZOOM

CUS

You can use the ZOOM ring to enlarge or reduce an image size.

Focus

Use the FOCUS ring to obtain the best focus.

PUSH

ZOOM

FOCUS

2. Select the Keystone function. Rotate the SELECT +/- dial to select
“Keystone” and then press the ENTER button.

The three options will be displayed.

Correcting the Vertical Keystone Distortion

Auto Keystone Correction

The Auto Keystone correction feature will correct the vertical distortion of
a projected image on the screen. No special operation required. Just put
the projector on a flat surface.
Note that the vertical keystone angle can be corrected between 30 de­grees upward and 30 degrees downward of projector tilt from level.

NOTE: Keystone correction angle could be less than 30 degrees for some signals
that have a high resolution or frequency such as UXGA.

Manual Keystone Correction

You can also correct the vertical keystone distortion manually.
To do so:

1. Press the MENU button.
The menu will be displayed.

3. Rotate the SELECT +/- dial to select “Manual” and then press the
ENTER button.

The Keystone adjustment bar will be displayed.

4. Correct the vertical distortion.
Rotate the SELECT +/– dial to correct the vertical keystone distor­tion.

5. Press the ENTER button to take effect.

6. Press the MENU button to close the menu.

NOTE:

•You can save the changes by selecting “Manual (Save)” when you turn off the
projector.

• When you use the projector in portrait mode, vertical keystone distortion
looks horizontal keystone distortion.

E-20

PROJECTING AN IMAGE (BASIC OPERATION)

Optimizing RGB Picture Automatically

Adjusting the Image Using Auto Adjust

Optimizing RGB image automatically.

Using the cabinet buttons

1. Press the MENU button .
The Basic menu will be displayed. Make sure that “Auto Adjust Ex­ecuted” is selected.

E

L

C

E

T

S

MENU

MENU

SOURCE
ENTER

L

E

S

SOURCE
ENTER

E

C

T

LAMP

STATUS

POWER

ON/STAND BY

2. Press the ENTER button to optimize an RGB image automatically.
The Hour Glass icon will appear. It takes some seconds to optimize an
RGB image.

LAMP

STATUS

POWER

ON/STAND BY

Using the remote control

Press the AUTO ADJ. button

OFF

P0WER ON

VIDEO

S-VIDEO

AUTO ADJ.

AUTO

ENTER

MENU CANCEL

The Hour Glass icon will appear. It takes some
seconds to optimize an RGB image.

COMPUTER

COMP.

ASPECT

This function adjusts the clock frequencies that eliminate the horizontal
banding in the image. This function also adjusts the clock phase to re­duce video noise, dot interference or cross talk. (This is evident when
part of your image appears to be shimmering.)
This adjustment may be necessary when you connect your computer for
the first time.

NOTE:

• Some signals may not be displayed correctly or take time.

• The Auto Adjust function does not work for component and video signal.

• If the Auto Adjust operation cannot optimize the RGB signal, try to adjust Clock
and Phase manually. See page E-32.

Tur ning Up or Down Volume

Sound level from the speaker on the projector can be adjusted when the
menu is not displayed.

E

L

C

E

T

S

MENU

OFF

VIDEO

AUTO ADJ.

AUTO

SOURCE
ENTER

P0WER ON

S-VIDEO

COMPUTER

COMP.

ASPECT

increase volume

LAMP

decrease volume

STATUS

POWER

ON/STAND BY

E-21

decrease volume

ENTER

MENU CANCEL

increase volume

PROJECTING AN IMAGE (BASIC OPERATION)

C

O

M

P

U

T

E

S

-V

ID

E

O

I

N

A

U

D

IO

IN

V

ID

E

O

IN

S-VIDEO IN

AUDIO IN

VI

Tur ning off the Projector

To turn off the projector:

First, press the POWER (ON/STAND BY) button on the projector cabinet
or the POWER OFF button on the remote control. The “Power Off / Are
you sure?” message will appear.

E

L

C

E

T

S

MENU

OFF

P0WER ON

COMPUTER

VIDEO

COMP.

S-VIDEO

AUTO

ASPECT

ENTER

MENU CANCEL

SOURCE
ENTER

LAMP

STATUS

POWER

ON/STAND BY

AUTO ADJ.

Secondly, press the ENTER button or press the POWER (ON/STAND
BY) or the POWER OFF button again.
The power indicator will glow orange. After the projector turns off, the
cooling fans keep operating for 60 seconds (Cooling-off time).
Lastly unplug the power cable. The power indicator will go out.

CAUTION
Do not unplug the power cable from the wall outlet under any one of
the following circumstances. Doing so can cause damage to the
projector:

• While the Hour Glass icon appears.

• While the cooling fans are running. (The cooling fans continue to
work for 60 seconds after the projector is turned off).

After Use

Preparation: Make sure that the projector is not turned on.

1. Unplug the power cable.

2. Disconnect any other cables.

3. Retract adjustable tilt feet if extended.

R
E
T

E

N

E

RC

Y

OU

B

S

D
N

A
T

S
/

N

T

O

C

E

L

E

S

R

E

W
O

S

P

U

U

T

N

A

E

T

M

S

P

M

A

2

1



Lift the front part of the projector.



Push and hold the
extend the adjustable tilt feet up to a maximum height.



Lower the front of the projector while pressing and holding the
Adjustable Tilt Foot button until retracting the Adjustable Tilt Foot
down to a minimum height.

4. Use the Lens Shutter lever to close the lens shutter.

ZOOM

FOCUS

H
S

U

P

3

C

L

O

S

E

PUSH

symbol of the Adjustable Tilt Foot button to

US

FOC

H

PUS

L

ER
T

E

EN

RC

U
O

S

T

C

E

L

E

S

U

N
E

M

M

OO
Z

5. Put the projector and its accessories in the soft carrying case.
See “Using the Soft Carrying Case” on the following page.

E-22

PROJECTING AN IMAGE (BASIC OPERATION)

PUSH

Using the Soft Carrying Case

The accessory pouch can be attached to the soft carrying case as shown in the drawing.

* Placing the projector and its accessories in the soft carrying case

Put through

Put through and fix it

Work should be done on a flat level surface to prevent overturning.

Quick Guide

P

U
S
H

FOCUS

ZOOM

L

A
M

M

P

E

ST

N

U
A
T
U

P

S
O
W
E

R

S

E

L

E

C

O

T

N
/S
T
A

N

D

S

B

O
U

Y

R

E

C

N

E

T

E
R

Projector

* The length of the belt is adjustable.

A
U

E
N
T

E
R

M

E
N
U

H
E

L
P

C
A

P
I

F

N

C

R

T

C

E

U

E

E

R

Z

E

L

E
P
C

­M
U

M

T

U

E

T

E

M

A
G
N
I
F
Y

Remove

RGB signal cable

Power cable

O
F
F

V
I

P

D

0

E

W

O

E

A

R

U
T
O

S

A

-V

D

O

T

ID

J

N

O

.

EO

C

O

M

P

C

U

O

T
E

M

R

P

.

A
S
P
E
C
T

Remote control

E-23

CONVENIENT FEATURES

Tur ning Off the Image and Sound

Press the PIC-MUTE button to turn off the image and sound for a short
period of time. Press again to restore the image and sound.

MENU

CANCEL

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

Freezing a Picture

Press the FREEZE button to freeze a picture. Press again to resume
motion.

MENU

CANCEL

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

Enlarging and Moving a Picture

Getting the Information

You get the information about the signal and projector settings.

MENU

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

CANCEL

MENU

CANCEL

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

Display Information

Exit Information

Security

A keyword can be set for your projector to avoid operation by an unau­thorized user using the Menu. When a keyword is set, turning on the
projector will display the Keyword input screen. Unless the correct key­word is entered, the projector cannot project an image.

To set a keyword:

1. Press the MENU button.
The Basic menu will be displayed.

You can enlarge the picture up to 400 percent.
To do so:

1. Press the MAGNIFY (+) button to magnify the picture.
To move the magnified image, use the

MENU

CANCEL

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

OFF

P0WER ON

COMPUTER

VIDEO

COMP.

S-VIDEO

AUTO ADJ.

AUTO

ASPECT

ENTER

MENU CANCEL

왖왔왗왘

button.

2. Press the MAGNIFY (-) button to return the image to the original size.

MENU

CANCEL

HELP

FREEZE


PC-MUTE MAGNIFY

MUTE

2. Rotate the SELECT +/- dial to select [To Advanced Menu] and press
the ENTER button.
The Advanced menu will be displayed.

E-24

CONVENIENT FEATURES

3. Rotate the SELECT +/- dial to select [Setup1] - [Security] and press
the ENTER button.
The Security menu will be displayed.

4. Rotate the SELECT +/- dial to select [Keyword] and press the ENTER
button.
The software keyboard will be displayed.

5. Use the SELECT +/- dial to type a keyword in the Input field.
Selected characters will be displayed in Input field.
* The keyword must be no more than 10 alphanumeric characters.

Typing a keyword
*To select a character, rotate the SELECT+/- dial to highlight the

character you want to select and press the ENTER button.

*To delete a character, rotate the SELECT+/- dial to highlight

and press the ENTER button. The character at the far right will be
deleted.

*For the selected keyword to take effect, rotate the SELECT+/- dial

to highlight

*To cancel the selected keyword, rotate the SELECT+/- dial to high-

light

6. After finishing typing keyword, rotate the SELECT+/- dial to highlight
[Exit] and press the ENTER button.
The confirmation screen will be displayed.

and press the ENTER button.

and press the ENTER button.

To turn on the projector when Security is enabled:

1. Press and hold the POWER (ON/STAND BY) button for a minimum of
2 seconds.
The projector will turn on and display a message to the effect that the
projector is security-protected.

2. Press the MENU button.
The Keyword input screen will be displayed.

3. Enter your keyword.
For entering your keyword, see Step 5 in “To set a keyword”.

4. Select

The unlock condition is maintained until the main power is turned off by
unplugging the power cable.

and press the ENTER button.

The Security is unlocked. You can view a projected image.

7. Rotate the SELECT +/- dial to select [Yes] and press the ENTER but­ton.
The Security function is enabled.

E-25

CONVENIENT FEATURES

To disable the Security function:

1. Press the MENU button.
The Basic menu will be displayed.

2. Rotate the SELECT +/- dial to select [To Advanced Menu] and press
the ENTER button.
The Advanced menu will be displayed.

NOTE:

If you forget your keyword, contact your dealer. Your dealer will provide you
with your keyword in exchange for your request code. Your request code is
displayed in the Keyword input screen. In this example “K992-45L8-JNGJ­4XU9-1YAT-EEA2” is a request code.

3. Rotate the SELECT +/- dial to select [Setup1] - [Security] and press
the ENTER button.
The Keyword input screen will be displayed.

4. Enter your keyword.
For entering your keyword, see Step 5 in “To set a keyword”.

5. Rotate the SELECT +/– dial to select
ton.
The Security is unlocked. The Security menu will be displayed.

6. Rotate the SELECT +/- dial to select [Security] and press the ENTER
button.

7. Rotate the SELECT +/- dial to select [Disable] and press the ENTER
button.
This will disable the Security function and return to the Security menu.

8. Rotate the SELECT +/- dial to select [Exit] and press the ENTER.

9. Press the MENU button to close the menu.

and press the ENTER but-

E-26

USING ON-SCREEN MENU

Basic Menu Operation

The Menu consists of Basic and Advanced. While the Basic menu con­tains minimum essentials of menus and commands, the Advanced menu
contains all the available menus and commands.

The Basic menu is accessed by pressing the MENU button.
Selecting “To Advanced Menu” in Basic menu will go to the Advanced
menu.

Using the Menus

For Basic menu

1. Press the MENU button to display the Basic menu.

2. Rotate the SELECT +/- dial to highlight the menu item you want to
adjust or set.
The example below is for Picture Management.

4. Rotate the SELECT +/- dial to highlight the item you want to adjust or
set.
The example below is for Graphic.

5. Press the ENTER button.
The item is selected. This will return to the Basic menu.

6. Press the MENU button to close the menu.

NOTE:

* The menu will automatically disappear if no operation is made for 45 seconds.
* The menu display time (default 45 seconds) can be changed. See page E-33.

* The on-screen menu may not be displayed correctly while interlaced motion

video image is projected.

For Advanced menu

1. Press the MENU button to display the Basic menu.

3. Press the ENTER button.
The Picture Management item will be displayed on its right side.

2. Rotate the SELECT +/- dial to highlight [To Advanced menu] and press
the ENTER button.
The Advanced menu will be displayed.

E-27

USING ON-SCREEN MENU

3. Rotate the SELECT +/- dial clockwise.
Keep rotating the SELECT +/- dial until the highlight reaches [Noise
Reduction]. When the highlight reaches [Flicker Reduction], [Setup 1]
menu will be displayed.

Keep rotating the SELECT +/- dial clockwise and the menu items will
sequence as follows: [Image] → [Setup 1] → [Setup 2] → [Information] →
[Default] → [Image] → ...

Keep rotating the SELECT +/- dial counterclockwise and the menu items
will sequence as follows: [Default] → [Information] → [Setup 2] → [Setup
1] → [Image] → [Default] → ...

Adjusting and Setting Items

For Adjusting items

2. Press the ENTER button.
The selected item will be displayed.

3. Rotate the SELECT +/- dial to highlight the item you want to set.

4. Press the ENTER button.
This will return to the previous menu.

NOTE:

The ENTER/SOURCE button on the cabinet works as:
* Execute menu selection.
* Adjust the slide bar.

* Display the submenu

1. Rotate the SELECT +/- dial to highlight the menu item you want to
adjust.

2. Press the ENTER button.

3. Rotate the SELECT +/- dial to adjust the item.

4. Press the ENTER button.

Changes will take effect.

For Selecting items

1. Rotate the SELECT +/- dial to highlight the menu item you want to set.

E-28

USING ON-SCREEN MENU

List of Menu Items

Basic Menu

Menu items Items

Auto Adjust Executed
Aspect Ratio
Picture Management

Brightness
Contrast
Sharpness
Color
Hue
Keystone
To Advanced Menu

Normal, Wide, Zoom, Cinema, Native
Presentation, Video, Movie, Graphic, sRGB, User
User Setting

Auto, Manual, Manual (Save)

Base Setting (Presentation, Video, Movie, Graphic, sRGB)
Gamma Correction (Dynamic, Black Detail, Natural)
Brightness R
Brightness G
Brightness B
Contrast R
Contrast G
Contrast B
White Peaking

Advanced Menu

Category Menu items Items


Setup 1

Setup 2

Information

Default

Auto Adjust
Horizontal
Vertical
Clock
Phase
Noise Reduction
Flicker Reduction
Lamp Mode
Language

Menu Color Select
Menu Display Time
Background
Orientation
Cabinet Button
Security

Portrait
Power Management
Auto Start
Fan Mode
Signal Select

Page 1
Page 2
Page 3
Page 4
Factory Default (Current Signal)
Factory Default (All Data)
Clear Lamp Hour Meter

Computer
Video
S-Video

On, Off

On, Off
On, Off
Normal, Eco
English, Deutsch, Français, Italiano, Español, Svenska,
Nederlands, Suomi,
Color, Monochrome
Manual, Auto 5 sec, Auto 15 sec, Auto 45 sec
Blue, Black, Logo
Desktop Front, Ceiling Rear, Desktop Rear, Ceiling Front
Lock, Unlock
Security (Enable, Disable)
Keyword
0°, 180°
On, Off
On, Off
High, Auto
RGB/Component, RGB, Component, Scart
Auto, NTSC3.58, NTSC4.43, PAL, PAL-M, PAL-N, PAL60, SECAM
Auto, NTSC3.58, NTSC4.43, PAL, PAL-M, PAL-N, PAL60, SECAM
Source Index, Horizontal Frequency, Vertical Frequency, Sync Polarity
Signal Type, Video Type, Sync Type, Interlace
Remaining Lamp Time, Lamp Hour Meter, Projector Usage
Version (BIOS, Firmware, Data, GUI)

, Magyar, Norsk, Polski,

,,

, Türkçe, Cesky,

, Português,

E-29

USING ON-SCREEN MENU

Menu Elements

<Basic menu>

Highlight

Check mark

Slide bar

Return key symbol

Source

Title

<Advanced menu>

Key symbol

Thermometer symbol

Radio button

Menu windows or dialog boxes typically have the following elements:

Title ........................... Indicates the menu title.

Highlight .................... Indicates the selected menu or item.

Source ....................... Indicates the currently selected source.

Return key symbol .... Indicates further choices are available.

Radio button .............. Use this round button to select an option in a dialog box.

Check mark ............... Indicates the item is selected.

Slide bar .................... Indicates settings or the direction of adjustment.

Key symbol ................ Indicates the Cabinet Button is locked.

Thermometer symbol

.......... Indicates the lamp mode is forcibly set to Eco mode because the internal temperature is too high.

E-30

USING ON-SCREEN MENU

Menu Descriptions & Functions

Basic Menu

[Auto Adjust Executed]

Optimizing RGB image automatically. (See page E-21)

Selecting Aspect Ratio [Aspect Ratio]

Aspect Ratio allows you to select the best Aspect mode to display your
source image. You can also display the Aspect Ratio window by pressing
the “ASPECT” button on the remote control. (See page E-8).

When 4:3 is selected from the source (i.e. DVD player), the following
selections will display:

Normal Wide Zoom Cinema Native

Native (COMPUTER only): Turns off the Advanced AccuBlend fea­ture. The projector displays the current image in its true resolution.

NOTE:

*While you are displaying an image with higher resolution than the projector’s

native resolution, “Native” is not available.

* Selecting “Cinema” will display the Cinema Position slide bar which allows

you to adjust the vertical position of the image on the screen.

Copyright

Please note that using this projector for the purpose of commercial gain or the
attraction of public attention in a venue such as a coffee shop or hotel and
employing compression or expansion of the screen image with a "Aspect Ra­tio" setting may raise concern about the infringement of copyrights which are
protected by copyright law.

[Picture Management]

This option allows you to adjust neutral tint for yellow, cyan or magenta.
There are 5 factory presets optimized for various types of images, or you
can set user adjustable settings.

Presentation .. Recommended for making a presentation using a

PowerPoint file

Video ............. Recommended for regular picture such as TV program

Movie ............. Recommended for movie

Graphic .......... Recommended for graphics

sRGB ............. Standard color values

User ............... User adjustable

Standard

4:3 Aspect

When 16:9 is selected from the source (i.e. DVD player), the follow­ing selections will display:

Normal Wide Zoom Cinema Native

16:9 image

displayed in

4:3 mode

Left and right

stretched

Left and right

stretched

Left and right

stretched

Left and right

stretched to

display the true

aspect

NOTE: When “sRGB”, “Graphic”, “Video” or “Movie” is selected, the bright­ness decreases slightly when compared to “Presentation”. This is not a mal­function.

User Setting (when using User)

When selecting a user adjustable preset (User Setting), the submenu
will be displayed.
You can customize each gamma or color. To do so, first select “User
Setting” and press the ENTER button, and then proceed with the fol­lowing steps.

Selecting Base Setting [Base setting]

This feature allows you to use white balance or gamma values as
reference data to optimize for various types of images. You can select
one of the following five settings.

• Presentation

• Video

• Movie

• Graphic

• sRGB

Selecting Gamma Correction Mode [Gamma Correction]

Each mode is recommended for :

Dynamic ......... For true color reproduction of natural tones

Natural ........... Normal settings

Black Detail .... For dark portions of a picture

E-31

USING ON-SCREEN MENU

Adjusting White Balance [Brightness R/G/B, Contrast R/G/B]

This allows you to adjust the white balance. Brightness for each color
(RGB) is used to adjust the black level of the screen; Contrast for each
color (RGB) to adjust the white level of the screen.

Selecting White Peaking [White Peaking]

Adjust the brightness of the white areas. As the picture becomes dim,
it looks more natural.

NOTE: The White Peaking option is not available when “Presentation” is selected
in “Base Setting”.

[Brightness]

Adjusts the brightness level or the back raster intensity.

[Contrast]

Adjusts the intensity of the image according to the incoming signal.

[Sharpness]

Controls the detail of the image for Video.

[Color]

Increases or decreases the color saturation level (not valid for RGB).

[Hue]

Varies the color level from +/- green to +/-blue. The red level is used as
reference. This adjustment is only valid for Video and Component inputs
(not valid for RGB).

NOTE: Some Picture items cannot be available depending on the input signal.

Input signal Brightness Contrast Sharpness Color Hue

RGB
(Computer)
Component
(Computer)
Video and S-Video Yes Yes Yes Yes Yes*

Yes Yes Yes N o No

Yes Yes Yes Yes*

1

No

2

Yes: Available No: Not available

*1Available on DVD (15 kHz), but not available on HDTV, 525p (480p)

and 750p (720p).

2

*

Available on NTSC only.

Correcting Vertical Keystone Distortion [Keystone]

Corrects vertical keystone distortion.

Auto ............... Corrects vertical keystone distortion automatically. See

page E-20.

Manual ........... Allows you to manually correct vertical keystone dis-

tortion.

Manual (Save) This option enables you to save your current keystone

correction settings. The settings are saved when you
turn off the projector.

When you select “Manual” or “Manual (Save)“, you can correct keystone
distortion using the Keystone slide bar.

Advanced Menu

[Image]

Enabling Auto Adjust [Auto Adjust]

When “Auto Adjust” is set to “On”, the projector automatically determines
the best resolution for the current RGB input signal to project an image
using NEC’s Advanced AccuBlend Intelligent Pixel Blending Technology.
The image can be automatically adjusted for position and stability;
“Horizontal Position”, “Vertical Position”, “Clock” and “Phase”.

On .................. Automatically adjusts image “Horizontal Position”, “Ver-

tical Position”, “Clock” and “Phase”.

Off .................. User can adjust the image display functions (“Horizon-

tal Position”, “Vertical Position”, “Clock” and “Phase”)
manually.

Adjusting Position/Clock (when Auto Adjust is off)

This allows you to manually adjust the image horizontally and vertically,
and adjust Clock and Phase.

[Horizontal/Vertical]

Adjusts the image location horizontally and vertically.
This adjustment is made automatically when the Auto Adjust is turned
on.

[Clock]

Use this item with the “Auto Adjust off” to fine tune the computer im­age or to remove any vertical banding that might appear. This function
adjusts the clock frequencies that eliminate the horizontal banding in
the image. This adjustment may be necessary when you connect your
computer for the first time. This adjustment is made automatically when
the Auto Adjust is turned on.

[Phase]

Use this item to adjust the clock phase or to reduce video noise, dot
interference or cross talk. (This is evident when part of your image
appears to be shimmering.)
Use “Phase” only after the “Clock” is complete.
This adjustment is made automatically when the Auto Adjust is turned
on.

Turning On Noise Reduction [Noise Reduction]

Reduces video noise.

NOTE: The lower the Noise Reduction level, the better the image quality by way
of higher video bandwidth.

Turning On Flicker Reduction [Flicker Reduction]

Reduces flicker which can occur in an interlaced signal.

NOTE: When the Flicker Reduction is ON, jagged lines can be visible depending
on the signal. In that case, select OFF.

E-32

USING ON-SCREEN MENU

[Setup1]

Selecting Lamp Mode [Lamp Mode]

This feature enables you to select two brightness modes of the lamp:
Normal and Eco modes. The lamp life can be extended by using the
Eco mode.
Normal Mode ...

Eco Mode ...... Select this mode to increase the lamp life (80% Bright-

NOTE: Thermometer symbol indicates the lamp mode is forcibly set to Eco
mode because the internal temperature is too high.

Selecting Menu Language [Language]

You can choose one of 20 languages for on-screen instructions.

Selecting Menu Color [Menu Color Select]

You can choose between two color modes for menu color: color and
monochrome.

Selecting Menu Display Time [Menu Display Time]

This option allows you to select how long the projector waits after the
last touch of a button to turn off the menu.
The preset choices are “Manual”, “Auto 5 sec”, “Auto 15 sec”, and
“Auto 45 sec”. The “Auto 45 sec” is the factory preset.

Selecting a Color or Logo for Background [Background]

Use this feature to display a black/ blue screen or logo when no signal
is available.

Selecting Projector Orientation [Orientation]

This sets the orientation of the image for your type of application. The
options are:
desktop front projection, ceiling rear projection, desktop rear projec­tion, and ceiling front projection.

Disabling the Cabinet Buttons [Cabinet Button]

This option turns on or off the Cabinet Button Lock function.

NOTE:

* This Cabinet Button Lock does not affect the remote control functions.
* When the cabinet buttons are locked, pressing and holding the MENU button

for about 10 seconds will change the setting to unlock.

* Key symbol indicates the Cabinet Button is locked.

Enabling Security function [Security]

This option allows you to prevent the projector from being used by
unauthorized individuals.
See page E-24 for details.

Selecting Display Orientation [Portrait]

This allows you to select the projector's display orientation when you
display an image in portrait mode with the projector on its side. See
page E-13. You can rotate the projected image 0° or 180° clockwise
depending on your PC.
The default setting is 180°.

This is the default setting (100% Brightness).

ness).

[Setup2]

Enabling Power Management [Power Management]

When this option is on and there is no input for five minutes or more,
the projector will automatically turn itself off.

Enabling Auto Start [Auto Start]

Tu rns the projector on automatically when the power cable is inserted
into an active power outlet.
This eliminates the need to always use the POWER (ON/STAND BY)
button on the projector cabinet or the POWER OFF button on the re­mote control.

Enabling High Speed Fan Mode [Fan Mode]

This option allows you to select two modes for fan speed: High mode
and Auto mode.

High ............... The built-in fans run at a fixed high speed.

Auto ............... The built-in fans automatically run at a variable speed

according to the internal temperature.

When you wish to cool down the temperature inside the projector
quickly, select “High”.

NOTE: Select High Speed Fan mode if you continue to use the projector for
consecutive days.

Selecting Signal Format [Signal Select]

<Computer>
Allows you to choose “RGB” for an RGB source such as a computer,
or “Component” for a component video source such as a DVD player.
Normally select “RGB/Component” and the projector automatically
detects a component signal. However there may be some component
signals that the projector is unable to detect. If this is the case, select
“Component”. Select “Scart” for the European Scart.

<Video & S-Video>
This feature enables you to select composite video standards manu­ally. Normally select “Auto”.
When you select the video standard for Video and S-Video, select the
video standard from the pull-down menu.
This must be done for Video and S-Video respectively.

E-33

USING ON-SCREEN MENU

Information Default

Displays the status of the current signal and lamp usage. This item has
four pages. The information included is as follows:

[Page 1]
Source Index
Horizontal Frequency
Ver tical Frequency
Sync Polarity

[Page 2]
Signal Type
Video Type
Sync Type
Interlace

* The progress indicator shows the percentage of remaining lamp life.

The value informs you of the amount of lamp usage. When the remain­ing lamp time reaches 0, the Remaining Lamp Time bar indicator
changes from 0% to 100 Hours and starts counting down.
If the remaining lamp time reaches 0 hours, the projector will not turn
on regardless of whether the lamp mode is set to Normal or Eco.

[Page 3]
Remaining Lamp Time (%)*
Lamp Hour Meter (H)
Projector Usage

[Page 4]
Version (BIOS/Firmware/Data/GUI)

Returning to Factory Default [Factory Default]

The Factory Default feature allows you to change adjustments and set­ting to the factory preset for source except the following:

<Current Signal>
Resets the adjustments for the current signal to the factory preset levels.
The items that can be reset are: Brightness, Contrast, Color, Hue, Sharp­ness, Aspect Ratio, Horizontal Position, Vertical Position, Clock, Phase
and Picture Management.

<All Data>
Reset all the adjustments and settings for all the signals to the factory
preset.
The items can be reset except Language, Security, Remaining Lamp
Time, Lamp Hour Meter and Projector Usage. To reset the lamp usage
time, see “Clear Lamp Hour Meter” .

Clearing Lamp Hour Meter [Clear Lamp Hour Meter]

Resets the lamp clock back to zero. Selecting this option displays submenu
for a confirmation.

NOTE: The projector will turn off and go into standby mode after 1600 hours (up
to 2100 hours in Eco mode) of service. If this happens, press the “HELP” button
on the remote control for ten seconds to reset the lamp clock back to zero. Do this
only after replacing the lamp.

E-34

MAINTENANCE

AM

S

ND

E

N

SO

T

E

L

A
M

P

M

E
N

U

S
O

U
R

C

E

E

N
T

E
R

S
T

A
T

U

S

P

O

W

E
R

O
N

/S
T

A

N

D
B

Y

S

E

L

E

C

T

This section describes the simple maintenance procedures you should
follow to replace the lamp and clean the filter.

Replacing the Lamp

After your lamp has been operating for 1500 hours (up to 2000 hours in
Eco mode) or longer, the LAMP indicator in the cabinet will blink red and
the message will appear. Even though the lamp may still be working,
replace it at 1500 (up to 2000 hours in Eco mode) hours to maintain
optimal projector performance.

CAUTION

• DO NOT TOUCH THE LAMP immediately after it has been used. It
will be extremely hot. Turn the projector off, wait 60 seconds, and
then unplug the power cable. Allow at least one hour for the lamp
to cool before handling.

• DO NOT REMOVE ANY SCREWS except the lamp cover screw
and the lamp case screw. You could receive an electric shock.

• The projector will turn off and go into stand by mode after 1600
(up to 2100 hours in Eco mode) hours of service. If this happens,
be sure to replace the lamp. If you continue to use the lamp after
1500 hours (up to 2000 hours in Eco mode) of use, the lamp bulb
may shatter, and pieces of glass may be scattered in the lamp
case. Do not touch them as the pieces of glass may cause injury.
If this happens, contact your NEC dealer for lamp replacement.

To replace the lamp:

NOTE: The replacement lamp comes with a flat-blade screwdriver. Use the screw­driver to remove the lamp cover and lamp housing.

1. Loosen the lamp cover screw until the screwdriver goes into a free­wheeling condition. Press firmly and slide the lamp cover off. The lamp
cover screw is not removable.

Catch

3. Inser t a new lamp housing until the lamp housing is plugged into the
socket.

CAUTION
Do not use a lamp other than the NEC replacement lamp (LT70LP).
Order this from your NEC dealer.

Secure it in place with the screw.
Be sure to tighten the screw.

L

A
M

L
A

M

M

P

E

S

N

T

U

A

TU

P

S

O

W

E
R

O
N

/S

T

A
N

D

B

Y

M

P

E

S

N

T

U

A

T
U

P

S
O
W

E

R

O

N

/S

T
A

N

D

B

Y

E
N

4. Reattach the lamp cover.
Slide the lamp cover back until it snaps into place.

Tighten the lamp cover screw.
Be sure to tighten the screw.

LAMP

L

STATU

POWER

ON/STA

MENU

STATUS

POWER

ON/STAND BY

S

E

L

E

C

T

S

O

U
R

ENTER

C
E

1

2

2. Loosen the screw securing the lamp housing until the screwdriver goes
into a freewheeling condition. The screw is not removable.

Remove the lamp housing by pulling out the handle.

NOTE: There is an interlock on this case to prevent the risk of electrical shock.
Do not attempt to circumvent this interlock.

Interlock

LAMP

MENU

STATUS

POWER

ON/STAND BY

L
A

M

M

P

E

S

N

T

U

A

T

U

P

S

O

W

E

R

O

N

/S

T

A

N

D
B

Y

5. After you install a new lamp, select the menu

→

[Default] → [Clear

Lamp Hour Meter] to reset the lamp usage hours.

NOTE: When the lamp exceeds 1600 hours (up to 2100 hours in Eco mode) of
service, the projector cannot turn on and the menu is not displayed. If this
happens, press the Help button on the remote control for a minimum of 10
seconds while in standby mode. When the lamp time clock is reset to zero, the
LAMP indicator goes out.

E-35

MAINTENANCE

COMPUTER

S-VIDEO IN

AUDIO IN

VIDEO IN

C

O

M

P

U

T

E

R

S

-

V

I

D

E

O

I

N

A

U

D

I

O

I

N

V

I

D

E

O

I

N

Cleaning the Cabinet and the Lens

S

U
C
FO

H
S
U

P

M

O
O
Z

T

C

E

L

E

S

E

C
R
U

R

O

E

S

T

N
E

U

N
E
M

Y

B
P
M

D

S

A

N

L

U

A

T

T

A

S
/

T

R

S

N

E

O
W
O

P

1. Turn off the projector before cleaning.

2. Clean the cabinet periodically with a damp cloth. If heavily soiled, use
a mild detergent. Never use strong detergents or solvents such as
alcohol or thinner.

3. Use a blower or lens paper to clean the lens, and be careful not to
scratch or mar the lens.

R

E
T

N
E

Y

B

SOURCE

D

N
A

T
/S

N

T

O

C

E

L

E

S

R

E

W

O

S

P

U

U

T

N

A

E

T

M

S
P
M

A
L

M
O
O

Z

S

U

C
O

F

H
S
U

P

C

L

O

S

E

E-36

TROUBLESHOOTING

This section helps you resolve problems you may encounter while setting up or using the projector.

Power Indicator (POWER)

Indicator Condition

Off

Blinking light

Steady light

Status Indicator (STATUS)

Blinking light

Green

Orange

Green
Orange

Indicator Condition

Off

Red

0.5 sec ON,

0.5 sec OFF

0.5 sec ON,

0.5 sec OFF

1 cycle (0.5 sec ON,

2.5 sec OFF)

2 cycle (0.5 sec ON,

0.5 sec OFF)

Projector Condition Note

The main power is not supplied
The projector is getting ready
to turn on.
The projector is cooling down.

The projector is turned on.
The projector is in Standby.

Projector Condition Note

Normal
Lamp cover error or lamp
housing error
Temperature error

–
Wait for a moment.

Wait for a moment.

–
–

–
Replace the lamp cover or
lamp housing correctly.
The projector is overheated.
Move the projector to a cooler
location.

Green

Steady light

Lamp Indicator (LAMP)

Blinking light

Steady light

Orange

Indicator Condition

Red

Red

Green

Off

3 cycle (0.5 sec ON,

0.5 sec OFF)

4 cycle (0.5 sec ON,

0.5 sec OFF)

6 cycle (0.5 sec ON,

0.5 sec OFF)

Power Failure

Fan error

Lamp error

Re-firing the lamp

Cabinet button is locked

Projector Condition Note

Normal
Lamp has reached its end of
life. Lamp replacement mes­sage will be displayed.
Lamp has been used beyond
its limit. The projector will not
turn on until the lamp is re­placed.
Lamp mode is set to Eco mode

Power supply unit will not work cor­rectly. Contact your dealer.
Fans will not work correctly.

Lamp fails to light. Wait a full
minute and then turn on again.
The projector is re-firing.

You have pressed cabinet but­ton when Cabinet Button is
locked.

–
Replace the lamp.

Replace the lamp.

–

E-37

TROUBLESHOOTING

Common Problems & Solutions

Problem Check These Items

Does not turn on

No picture

Image isn’t square to the
screen

Picture is blurred

• Check that the power cable is plugged in and that the power button on the projector cabinet or the remote
control is on. See page E- 17.

• Check to see if the Cabinet Button Lock function is enabled.If this function is enabled, cancel it by pressing and
holding the MENU button on the cabinet for a minimum of 10 seconds or using the menu with the remote
control. See page E-33.

• Ensure that the lamp cover or lamp housing is installed correctly. See page E-35.

• Check to see if the projector has overheated or the lamp has reached the end of its usable life. If there is
insufficient ventilation around the projector or if the room where you’re presenting is particularly warm, move
the projector to a cooler location.

• Use the COMPUTER, VIDEO or S-VIDEO button on the remote control or the SOURCE button on the cabinet to
select your source (Computer, Video or S-Video). See page E-19.

• Ensure your cables are connected properly.

• Use menus to adjust the brightness and contrast. See page E-32.

• Open the lens shutter. See page E-18.

• Reset the settings or adjustments to factory preset levels using “Factory Default” in the menu. See page E-34.

• Enter your registered keyword if the Security function is enabled. See page E-24.

• When using with a notebook PC, be sure to connect between the projector and the notebook PC before turning
on the power to the notebook PC. In most cases signal cannot be output from RGB output unless the notebook
PC is turned on after connecting with the projector.

• If the screen goes blank while using your remote control, it may be the result of the computer's screen-saver
or power management software.

• If you accidentally hit the POWER button on the remote control, wait 60 seconds and then press the POWER
button again to resume.

• Reposition the projector to improve its angle to the screen. See page E-19.

• Use the Keystone correction function to correct the trapezoid distortion. See page E-20.

• Adjust the focus. See page E-20.

• Reposition the projector to improve its angle to the screen. See page E-19.

• Ensure that the distance between the projector and screen is within the adjustment range of the lens. See page
E-11.

• Condensation may form on the lens if the projector is cold, brought into a warm place and is then turned on.
Should this happen, let the projector stand until there is no condensation on the lens.

Image is scrolling verti­cally, horizontally or
both

Remote control does
not work

Indicator is lit or blink­ing

Cross color in RGB
mode

• Use the COMPUTER, VIDEO or S-VIDEO button on the remote control or the SOURCE button on the cabinet to
select the source you want to input. See page E-19.

• Install new batteries. See page E-9.

• Make sure there are no obstacles between you and the projector.

• Stand within 22 feet (7 m) of the projector. See page E-9.

• See the Power/Status/Lamp Indicator on page E-37.

• If Auto Adjust is off, turn it on or adjust the image manually with Horizontal / Vertical / Clock / Phase in the
menu. See page E-32.

E-38

SPECIFICATIONS

This section provides technical information about the LT170 Projector's performance

Model Number LT170

Optical

DMD Single Chip Digital Micromirror Device (DMD)
Resolution 1024⳯768 pixels native*, up to UXGA with Advanced AccuBlend
Lens Manual zoom and focus: F=2.0 (Wide)-2.13 (Tele), f=25.7 - 28.3mm
Lamp 145W
Image Size 30 - 200 inches (0.8 - 5.1 m) diagonal
Projection Distance 3.51 - 26.67 ft / 1.07 (Wide) - 8.13 m (Tele)
Projection Angle Tele : 8.6°/ Wide : 9.5°
Keystone Correction +/- 30 degrees electronic (auto)

Electrical

Inputs 1 RGB/Component (D-Sub 15 Pin), 1 S-Video (DIN 4 Pin), 1 Video (RCA), 1 Stereo Mini Audio
Video Compatibility NTSC, NTSC4.43, PAL, PAL-60, PAL-N, PAL-M, SECAM, HDTV: 1080i, 1080i/50Hz, 720p, 576p, 480p, 480i/60Hz
Scan Rate Horizontal: 15 kHz to 100 kHz (RGB: 24 kHz or over) / Vertical: 50 Hz to 120 Hz
Video Bandwidth RGB: 100 MHz (-3dB)
Color Reproduction 16.7 million colors simultaneously, Full color
Horizontal Resolution NTSC / NTSC4.43/PAL/PAL-M/PAL-N/PAL60: 540 TV lines

External Control RS232, IR
Sync Compatibility Separate Sync / Composite Sync / Sync on G
Built-in Speaker 0.5W (monaural)
Power Requirement 100 - 240V AC, 50 / 60 Hz
Input Current 2A (Max.)
Power Consumption 196W(4W in Standby mode)

SECAM: 300 TV lines
YCbCr: 540 TV lines
RGB: 1024 dots (H)⳯768 dots (V)

Mechanical

Installation Orientation Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear
Dimensions 4.8" (W)⳯3.3" (H)⳯11.0" (D)

123mm (W)⳯85mm (H)⳯280mm (D)

Net Weight 3.9 lbs / 1.8 kg
Environmental Considerations

Regulations UL Approved (UL 60950, CSA 60950)

For additional information visit:

US : http://www.necvisualsystems.com
Europe : http://www.nec-europe.com/
Global : http://www.nec-pj.com/

* Effective pixels are more than 99.99%.

The specifications are subject to change without notice.

(not including protrusions)

Operational Temperatures : 41° to 95°F (5° to 35°C), 20% to 80% humidity (non-condensing)
Storage Temperatures : 14° to 122°F (-10° to 50°C), 20% to 80% humidity (non-condensing)

Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS CISPR 22 Class B
Meets EMC Directive (EN55022:1998, EN55024-1998, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)

E-39

APPENDIX

Cabinet Dimensions

110 (4.33")

ENTER
SOURCE

MENU

S

T

E

C

L

E

ON/STAND BY

POWER

STATUS

LAMP

280 (11.0")

286.5 (11.28")

COMPUTER

VIDEO IN

S-VIDEO IN

AUDIO IN

ZOOM

PUSH

FOCUS

123 (4.84")

2.8 (0.11")

Lens center

Lens center

E

S

O

L

C

60 (2.36")

Pin Assignments of D-Sub COMPUTER Input Connector

Mini D-Sub 15 Pin Connector

51423

10

6978

1112131415

Signal Level
Video signal : 0.7Vp-p (Analog)
Sync signal : TTL level

Pin No. RGB Signal (Analog) YCbCr Signal

1 Red Cr
2 Green or Sync on Green Y
3 Blue Cb
4 Ground
5 Ground
6 Red Ground Cr Ground
7 Green Ground Y Ground
8 Blue Ground Cb Ground

9 No Connection
10 Sync Signal Ground
11 Scart Sync
12 Bi-directional DATA (SDA)
13 Horizontal Sync or Composite Sync
14 Vertical Sync
15 Data Clock

AC IN

Unit = mm (inch)

88 (3.46")

E-40

APPENDIX

Compatible Input Signal List

Signal Resolution Frequency H. Refresh Rate

NTSC – 15.734 60
PA L–15.625 50
PAL60 – 15.734 60
SECAM – 15.625 50
VESA 640 ⳯ 480 31.47 59.94
IBM 640 ⳯ 480 31.47 60
MAC 640 ⳯ 480 31.47 60
MAC 640 ⳯ 480 34.97 66.67
MAC 640 ⳯ 480 35 66.67
VESA 640 ⳯ 480 37.86 72.81
VESA 640 ⳯ 480 37.5 75
IBM 640 ⳯ 480 39.375 75
VESA 640 ⳯ 480 43.269 85.01
IBM 720 ⳯ 350 31.469 70.09
VESA 720 ⳯ 400 37.927 85.04
IBM 720 ⳯ 350 39.44 87.85
IBM 720 ⳯ 400 39.44 87.85
VESA 800 ⳯ 600 35.16 56.25
VESA 800 ⳯ 600 37.879 60.32
VESA 800 ⳯ 600 48.077 72.19
VESA 800 ⳯ 600 46.88 75
VESA 800 ⳯ 600 53.674 85.06
MAC 832 ⳯ 624 49.725 74.55
VESA 1024 ⳯ 768 35.5 43 Interlaced
VESA 1024 ⳯ 768 48.363 60
VESA 1024 ⳯ 768 56.476 70.07
MAC 1024 ⳯ 768 60.241 74.93
VESA 1024 ⳯ 768 60.023 75.03

VESA 1024 ⳯ 768 68.677 85
# VESA 1152 ⳯ 864 67.5 75
#MAC 1152 ⳯ 870 68.681 75.06
# SUN 1152 ⳯ 900 61.796 65.95
# SGI 1152 ⳯ 900 71.736 76.05
# VESA 1280 ⳯ 960 60 60
# VESA 1280 ⳯ 1024 63.981 60.02
#MAC 1280 ⳯ 1024 69.89 65.18
#HP 1280 ⳯ 1024 78.125 72.01
# SUN 1280 ⳯ 1024 81.13 76.11
# VESA 1280 ⳯ 1024 79.976 75.03
# VESA 1280 ⳯ 1024 91.146 85.02
# SXGA+ 1400 ⳯ 1050 – –
#

SDTV(576i)(625i)
#

SDTV(576p)(625p)
#

HDTV
#
#
#
# VESA 1600 ⳯ 1200 75.0 60
# VESA 1600 ⳯ 1200 81.25 65
# VESA 1600 ⳯ 1200 87.5 70
# VESA 1600 ⳯ 1200 93.75 75

(1080i)(1125i)

HDTV

(1080i)(1125i)
HDTV (720p)(750p)
SDTV (480p)(525p)

DVD YCbCr – 15.734 59.94 Interlaced
DVD YCbCr – 15.625 50 Interlaced

( Dots ) ( kHz ) ( Hz )

– 15.6 50

– 31.5 50
1920 ⳯ 1080 33.75 60 Interlace
1920 ⳯ 1080 28.125 50 Interlace
1280 ⳯ 720 45 60 Progressive

– 31.47 59.94 Progressive

# : Images in above flagged with # are compressed with Advanced AccuBlend.

NOTE: Some composite sync signals may not be displayed correctly.

Signals other than those specified in the table above may not be displayed correctly. If this should happen, change
the refresh rate or resolution on your PC. Refer to Display Properties help section of your PC for procedures.

UXGA (1600⳯1200) is supported for separate sync signal only.

E-41

APPENDIX

TravelCare Guide

TravelCare - a service for international travelers

This product is eligible for "TravelCare", NEC's unique international war­ranty.
Please note that TravelCare coverage differs in part from coverage un­der the warranty included with the product.

Services offered with TravelCare

This warranty allows customers to receive service on their product at
the NEC and NEC-designated service stations in the countries listed
herein when temporarily traveling internationally for business or plea­sure.
For details on services offered by the different service stations, please
refer to the "List of TravelCare Outlets" below.

1 Repair services

The product will be repaired and delivered within 10 business days,
not including shipping time.
During the term of warranty, the cost of maintenance parts, labor
costs for repairs and shipping costs within the service station's cov­erage area are covered by the warranty.

2 Replacement product rental service

If the customer desires, he or she can rent a replacement product
while the original product is being repaired.
Fee: US$200 for 12 days
This fee must be paid at the local service station in cash or credit
card.
The $200 rental fee is non-refundable even if the customer rents it
less than 12 days before returning.
The replacement product will be delivered within 3 business days.
If the customer did not return the replacement product within 12 days,
the customer will be charged the price of the unit.
If the customer returned the replacement product in a faulty or dam­aged condition, the repair cost will be charged to the customer.
Note that this service is not offered in all countries and regions. Please
refer to the "List of TravelCare Outlets".
In addition, this replacement product rental service is not offered af­ter the product's warranty has expired.

Term of warranty

1

a. Upon presentation of the warranty or receipt received upon pur-

chase:

Valid for the term indicated on the warranty or the normal term of
warranty for the country of purchase.

b. When only the product is brought in:

Valid for a period of within 14 months of the date of manufacture
indicated by the serial number attached to the product.

2 When a product whose term of warranty is expired is brought in:

Repairs will be offered for a fee. In this case the customer is not
eligible for the replacement product rental service.

3 In the following cases, repairs may be charged, even if the product's

warranty is still in effect:

1) If the term of warranty, model name, serial number and name of
the store of purchase are not indicated on the warranty or have
been altered.

2) Problems or damage caused by dropping or shocks during ship­ment or movement by the customer or by improper handling by
the customers.

3) Problems or damage caused by improper usage or unwarrant­able alterations or repairs by the customer.

4) Problems or damage caused by fire, salt damage, gas damage,
earthquakes, lightning damage, storm or flood damage or other
natural disasters or such external factors as dust, cigarette
smoke, abnormal voltage, etc.

5) Problems or damage caused by use in hot or humid places, in
vehicles, boats or ships, etc.

6) Problems or damage caused by expendable supplies or devices
connected to the product other than those designated by NEC.

7) Problems caused by natural consumption, wear or deterioration
of parts under normal usage conditions.

8) Problems or damage to lamps and other expendable supplies,
included parts or optional parts.

9) Other conditions stipulated in the warranty included with the prod­uct also apply.

NOTE: The product can be used overseas with voltages of 100 to 120V and 200
to 240V by using a power cable suited for the standards and power source volt­age of the country in which the product is being used.

List of TravelCare Outlets

This list applies as of June 1, 2002.
For the most up-to-date information, please refer to the websites of the
service stations in the various countries on the List of TravelCare Out­lets or to the NEC website at http://www.nec-pj.com.

In Europe

NEC Europe, Ltd. / European Technical Centre

Address: Unit G, Stafford Park 12, Telford TF3 3BJ, U.K.
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.neceur.com

(Regions Covered)
EU: Austria*, Belgium*, Denmark*, Finland*, France*, Germany*,

Greece*, Ireland*, Italy*, Luxembourg*, The Netherlands*,
Por tugal*, Spain*, Sweden* and the United Kingdom*

EEA: Norway*, Iceland and Liechtenstein

In North America

NEC Solutions (America), Inc.

Address: 1250 Arlington Heights Road, Itasca,

Illinois 60143, U.S.A.
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.necvisualsystems.com

(Regions Covered)
U.S.A. *, Canada*

In Oceania

NEC Australia Pty., Ltd.

Address: New South Wales;

184 Milperra Road, Reversby 2212

Victoria;

480 Princess Hwy Noble Park 3174

South Australia;

84A Richmond Road, Keswick 5035

Queensland;

116 Ipswich Road, Woollongabba 4102

Western Australia;

45 Sarich Court Osborne Park 6017
Telephone: 131 632 (from domestic)

[phone] (from overseas)
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.nec.com.au

(Regions Covered)
Australia*, New Zealand

E-42

APPENDIX

In Asia and Middle East

NEC Viewtechnology, Ltd.

Address: 686-1, Nishioi, Oi-Machi, Ashigarakami-Gun,

Kanagawa 258-0017, Japan
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.nec-pj.com

(Regions Covered)
Japan*

NEC Hong Kong Ltd.

Address: 11th Floor, Tower B, New Mandarin Plaza, 14

Science Museum Road,

Tsim Sha Tsui East, Kowloon, Hong Kong
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.nec.com.hk

(Regions Covered)
Hong Kong

NEC Taiwan Ltd.

Address: 7F, No.167, SEC.2, Nan King East Road, Taipei,

Taiwan, R.O.C.
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.nec.com.tw

(Regions Covered)
Taiwan

NEC Singapore Pte. Ltd

Address: 401 Commonwealth Drive, #07-02, Haw Par

Technocentre, Singapore 149598
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.nec.com.sg

(Regions Covered)
Singapore

Hyosung Data System, Ltd.

Address: 7th Floor, Cheongdam Building, 52,

Cheongdam-Dong,

Kangnam-Ku, Seoul, Korea 135-100
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]

(Regions Covered)
South Korea

Lenso Communication Co., Ltd.

Address: 292 Lenso House 4, 1st Floor, Srinakarin Road,

Huamark, Bangkapi, Bangkok 10240, Thailand
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]
WEB Address: http://www.lenso.com

(Regions Covered)
Thailand

ABBA Electronics L.L.C.

Address: Tariq Bin Ziyad Road, P.O.Box 327, Dubai,

United Arab Emirates
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]

(Regions Covered)
United Arab Emirates

Samir Photographic Supplies

Address: P.O.Box 599, Jeddah 21421, Saudi Arabia
Telephone: [phone]
Fax Line: [phone]
Email Address: [e-mail]

(Regions Covered)
Saudi Arabia

NOTE: In countries designated with an asterisk(*), replacement product rental
service are offered.

E-43

APPENDIX

Date: / / ,

TO: NEC or NEC's Authorized Service Station:
FM:

P-1/ ,

(Company & Name with signature)

Dear Sir (s),
I would like to apply your TravelCare Service Program based on attached registration and qualification sheet and agree with your
following conditions, and also the Service fee will be charged to my credit card account, if I don't return the Loan units within the
specified period. I also confirm following information is correct. Regards.

Application Sheet for TravelCare Service Program

Country,
product purchased :

User's Company Name :

User's Company Address :
Phone No., Fax No. :

User's Name :

User's Address :

Phone No., Fax No. :

Local Contact office :

Local Contact office Address :

Phone No., Fax No. :

User's Model Name :

Date of Purchase :

Serial No. on cabinet :

Problem of units per User :

Required Service : (1) Repair and Return (2) Loan unit

Requested period of Loan unit :

Payment method : (1) Credit Card (2) Travelers Cheque (3) Cash

In Case of Credit Card :
Card No. w/Valid Date :

E-44

APPENDIX

Condition of your TravelCare Service Program

Enduser is requested to understand following conditions of TravelCare
Service Program and complete the necessary information on the
application sheet.

1. Service Options:

There are 3 types of "Service" available. Enduser has to understand
following condition and is required to fill in the Application Sheet.

1) Repair and Return:

The 'Faulty unit' is sent or collected from the customer. It is repaired
and returned within 10 days to the customer, excluding transport time.

There may have a case, repair and return can't be done by NEC
Authorized Service Station, because of shortage of spare parts due
to same model is not sold in the territory.

2) Repair and Return with Loan: (This service is limited to some Ser­vice Stations)

This service is offered to the Enduser, who cannot wait until their unit
is repaired.

The customer can borrow a unit for $200 up to 12 days. Customer
then sends in inoperable unit to nearest NEC Authorized Service
Station for service. In order to prevent collection problem, Enduser is
required to fill in Application Sheet.

Enduser needs to confirm the availability of the Service to NEC Au­thorized Service Stations.

3) Loan Only:

For this service, NEC Authorized Service Station supplies the cus­tomer with a loan unit for US$200 up to 12 days. Customer keeps the
inoperable unit and when customer returns home, customer arranges
to have the projector serviced in the home country.

5. Loan Service Charges and Conditions:

Upon acceptance of this NEC Projector, Customer agrees to assume
liability for this loan unit.

The current cost of use of this loan unit is $200.00 USD for 12 calendar
days.
If Customer does not return the unit within the 12 calendar days, Cus­tomer will be charged the next highest cost up to and including the full
list price to Credit Cards, which price will be informed by NEC Autho­rized Service Stations. Please see the attached listing of contacts for
each country to arrange for pickup of the loan unit.

If you return to their country of origin with the loan unit, you will be
charged additional freight to return the unit to the loaning country.

Thank you for your understanding of this program.

2. Warranty Exclusions:

This program does not apply if the Projector's serial number has been
defaced, modified or removed.
If, in the judgement of NEC Authorized Service Station or its agent the
defects or failures result from any cause other than fair wear and tear or
NEC neglect, or fault including the following without limitation:

1) Accidents, transportation, neglect, misuse, abuse, water, dust, smoke
or default of or by the Customer its employees or agents or any third
party;

2) Failure or fluctuation of electrical power, electrical circuitry, air condi­tioning, humidity control or other environmental conditions such as
use it in smoking area;

3) Any fault in the attachments or associated products or components
(whether or not supplied by NEC or its agents which do not form part
of the Product covered by this warranty);

4) Any act of God, fire, flood, war, act of violence or any similar occur­rence;

5) Any attempt by any person other than any person authorized by NEC
to adjust, modify, repair, install or service the product.

6) Any Cross-border charges such as, duty, insurance, tax etc.

3. Charges for Warranty Exclusions and Out of Warranty Case:

In case faulty unit is under warranty exclusions case or under Out of
Warranty period, NEC Authorized Service Station will Inform estimation
of actual service cost to the Enduser with reason.

4. Dead on Arrival (DOA):

Enduser must take this issue up with their original supplier in the coun­try of purchase.
NEC Authorized Service Station will repair the DOA unit as a Warranty
repair, but will not exchange DOA unit with new units.

E-45

Ver. 1 9/03
