NEC LCD1810X User Manual

MultiSync LCD

User’s Manual

1810X

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM1

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM2

Declaration of the Manufacture

We hereby certify that the colour monitors

MultiSync LCD

1810X (LH-18S01)

MultiSync LCD1810X (LH-18S01-BK)

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

and marked with

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM3

NEC Home Electronics, LTD.

686-1, Nishioi Oi-Machi

Ashigarakami-gun

Kanagawa 258-8533, Japan

Safety Instruction

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

Caution:
When operating the LH-18S01/LH-18S01-BK with a 220-240V AC

power source in Europe except UK, use the power cord provided with
the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cord is not
supplied with this equipment please contact your supplier.

When operating the LH-18S01/LH-18S01-BK with a 220-240V AC
Power source in Australia, use the power cord provided with the
monitor.

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric
shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has
been included. Therefore, it should be read carefully in order to avoid any problems.

For all other cases, use a power cord that matches the AC voltage of the
power outlet and has been approved by and complies with the safety
standard of your particular country.

ENERGY STAR is a U.S. registered trademark.
As an ENERGY STAR Partner, NEC Technologies has determined that this product meets the ENERGY
STAR guidelines for energy efficiency. The ENERGY STAR emblem does not represent EPA
endorsement of any product or service.
IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of International Business
Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM and ColorControl are trademarks
of NEC Home Electronics, Ltd.
MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home Electronics,
Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland,
Norway and Saudi Arabia.
All other trademarks or registered trademarks are property of their respective owners.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM4

For the Customer to use in U.S.A or Canada.
Canadian Department of Communications Compliance

Statement

DOC: This Class B digital apparatus meets all requirements of the

Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouiller du Canada.

C-UL: Bears the C-UL Mark and is in compliance with Canadian
Safety Regulations according to C.S.A. C22.2 #950.
Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de
sûrele Canadiens selon CAN/CSA C22.2 No. 950.

FCC Information

1. Use the attached specified cables with the LH-18S01/LH-18S01­BK colour monitors so as not to interfere with radio and television
reception.

(1) The power supply cord you use must have been approved by

and comply with the safety standards of U.S.A.,and meet the
following condition.

Power supply cord Non shield type,3-conductor

Length 1.8m

Plug shape

(2) Please use the supplied DVI to DFP adapter.
(3) Please use the supplied shielded video signal cable, 15-

pin mini D-SUB to DVI cable or DVI-D to DVI-D cable.

2. This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy, and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM5

cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and
receiver.

- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

- Consult your dealer or an experienced radio/TV
technician for help.

If necessary, the user should contact the dealer or an
experienced radio/television technician for additional
suggestions. The user may find the following booklet,
prepared by the Federal Communications Commission,
helpful: “How to Identify and Resolve Radio-TV Interference
Problems. ” This booklet is available from the U.S.
Government Printing Office, Washington, D.C., 20402, Stock
No. 004-000-00345-4.

DECLARATION OF CONFORMITY

This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions. (1)This device may not cause harmful interference,and (2) this device
must accept any interference received ,including interference that may cause undesired
operation.

U.S. Responsible Party: NEC Technologies,Inc.
Address: 1250 North Arlington Heights Road

Itasca,Illinois 60143-1248

Tel.No.: [phone]

Type of Product: Computer Monitor
Equipment Classification: Class B Peripheral

Models: MultiSync LCD1810X , LH-18S01

MultiSync LCD1810X , LH-18S01-BK

We hereby declare that the equipment specified above

conforms to the technical standards as specified in the FCC Rules.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM6

TCO'95

LH-18S01-BK

Congratulations! You have just

purchased a TCO'95 approved and
labelled product! Your choice has
provided you with a product
developed for professional use.
Your purchase has also contributed
to reducing the burden on the
environment and also, to the further
development of environmentally
adapted electronics products.

Why do we have
environmentally labelled computers?

In many countries, environmental labelling has become an established
method for encouraging the adaptation of goods and services to the
environment. The main problem, as far as computers and other electronics
equipment are concerned, is that environmentally harmful substances
are used both in the products and during the manufacturing. Since it has
not been possible for the majority of electronics equipment to be recycled
in a satisfactory way, most of these potentially damaging substances
sooner or later enter Nature.

There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of both the
work (internal) and natural (external) environments. Since all methods
of conventional electricity generation have a negative effect on the
environment (acidic and climate-influencing emissions, radioactive
waste, etc.), it is vital to conserve energy. Electronics equipment in offices
consume an enormous amount of energy since they are often left running
continuously.

What does labelling involve?

This product meets the requirements for the TCO'95 scheme which
provides for international and environmental labelling of personal

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM7

computers. The labelling scheme was developed as a joint effort by the
TCO (The Swedish Confederation of Professional Employees),
Naturskyddsforeningen (The Swedish Society for Nature Conservation)
and NUTEK (The National Board for Industrial and Technical
Development in Sweden).

The requirements cover a wide range of issues: environment, ergonomics,
usability, emission of electrical and magnetic fields, energy consumption
and electrical and fire safety.

The environmental demands concern restrictions on the presence and
use of heavy metals, brominated and chlorinated flame retardants, CFCs
(freons) and chlorinated solvents, among other things. The product must
be prepared for recycling and the manufacturer is obliged to have an
environmental plan which must be adhered to in each country where the
company implements its operational policy.

The energy requirements include a demand that the computer and/or
display, after a certain period of inactivity, shall reduce its power
consumption to a lower level in one or more stages. The length of time
to reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for example,
in respect of the reduction of electric and magnetic fields, physical and
visual ergonomics and good usability.

On the back page of this folder, you will find a brief summary of the
environmental requirements met by this product. The complete
environmental criteria document may be ordered from:

TCO Development Unit t

S-114 94 Stockholm
Sweden

Fax: [phone]
Email (Internet): [e-mail]

Current information regarding TCO'95 approved and labelled products
may also be obtained via the Internet, using the address:

http://www.tco-info.com/

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM8

TCO'95 is a co-operative project between TCO (The Swedish
Confederation of Professional Employees), Naturskyddsforeningen
(The Swedish Society for Nature Conservation) and NUTEK (The
National Board for Industrial and Technical Development in Sweden).

Environmental Requirements

Brominated flame retardants

Brominated flame retardants are present in printed circuit boards, cables,
wires, casings and housings. In turn, they delay the spread of fire. Up to
thirty percent of the plastic in a computer casing can consist of flame
retardant substances. These are related to another group of environmental
toxins, PCBs, which are suspected to give rise to similar harm, including
reproductive damage in fisheating birds and mammals, due to the bio­accumulative * processes. Flame retardants have been found in human
blood and researchers fear that disturbances in foetus development may
occur.

TCO'95 demand requires that plastic components weighing more than
25 grams must not contain organically bound chlorine and bromine.

Lead**

Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher doses, causes
lead poisoning.

TCO'95 requirement permits the inclusion of lead since no replacement
has yet been developed.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-generating
layers of certain computer displays. Cadmium damages the nervous
system and is toxic in high doses.

TCO'95 requirement states that batteries may not contain more than 25
ppm (parts per million) of cadmium. The colour-generating layers of
display screens must not contain any cadmium.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM9

Mercury**

Mercury is sometimes found in batteries, relays and switches. Mercury
damages the nervous system and is toxic in high doses.

TCO'95 requirement states that batteries may not contain more than 25
ppm (parts per million) of mercury. It also demands that no mercury is
present in any of the electrical or electronics components concerned
with the display unit. Mercury is, for the time being, permitted in the
back light system of flat panel monitors as there today is no commercially
available alternative. TCO aims on removing this exception when a
mercury free alternative is available.

* Bio-accumulative is defined as substances which accumulate within living organisms
** Lead, Cadmium and Mercury are heavy metals which are Bio-accumul

CFCs (freons)

CFCs (freons) are sometimes used for washing printed circuit boards
and in the manufacturing of expanded foam for packaging. CFCs break
down ozone and thereby damage the ozone layer in the stratosphere,
causing increased reception on Earth of ultraviolet light with consequent
increased risks of skin cancer (malignant melanoma).

The relevant TCO'95 requirement: Neither CFCs nor HCFCs may be
used during the manufacturing of the product or its packaging.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM10

TCO'99

LH-18S01
Congratulations!

You have just purchased a TCO'99
approved and labelled product! Your choice
has provided you with a product developed
for professional use. Your purchase has also
contributed to reducing the burden on the
environment and also to the further
development of environmentally adapted
electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established
method for encouraging the adaptation of goods and services to the
environment. The main problem, as far as computers and other
electronics equipment are concerned, is that environmentally harmful
substances are used both in the products and during their manufacture.
Since it is not so far possible to satisfactorily recycle the majority of
electronics equipment, most of these potentially damaging substances
sooner or later enter nature.

There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of both the
work (internal) and natural (external) environments. Since all methods
of electricity generation have a negative effect on the environment (e.g.
acidic and climate-influencing emissions, radioactive waste), it is vital
to save energy. Electronics equipment in offices is often left running
continuously and thereby consumes a lot of energy.

What does labelling involve?

This product meets the requirements for the TCO'99 scheme which
provides for international and environmental labelling of personal
computers. The labelling scheme was developed as a joint effort by
the TCO (The Swedish Confederation of Professional Employees),

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM11

Svenska Naturskyddsforeningen (The Swedish Society for Nature
Conservation) and Statens Energimyndighet (The Swedish National
Energy Administration).

Approval requirements cover a wide range of issues: environment,
ergonomics, usability, emission of electric and magnetic fields,
energy consumption and electrical and fire safety.

The environmental demands impose restrictions on the presence and
use of heavy metals, brominated and chlorinated flame retardants,
CFCs (freons) and chlorinated solvents, among other things. The
product must be prepared for recycling and the manufacturer is
obliged to have an environmental policy which must be adhered to
in each country where the company implements its operational policy.

The energy requirements include a demand that the computer and/or
display, after a certain period of inactivity, shall reduce its power
consumption to a lower level in one or more stages. The length of
time to reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for
example, in respect of the reduction of electric and magnetic fields,
physical and visual ergonomics and good usability.

Below you will find a brief summary of the environmental
requirements met by this product. The complete environmental
criteria document may be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden
Fax: [phone]

Email (Internet): [e-mail]

Current information regarding TCO'99 approved and labelled
products may also be obtained via the Internet, using the address:

http://www.tco-info.com/

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM12

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires,
casings and housings. Their purpose is to prevent, or at least to delay the
spread of fire. Up to 30% of the plastic in a computer casing can consist
of flame retardant substances. Most flame retardants contain bromine
or chloride, and those flame retardants are chemically related to another
group of environmental toxins, PCBs. Both the flame retardants
containing bromine or chloride and the PCBs are suspected of giving
rise to severe health effects, including reproductive damage in fish-eating
birds and mammals, due to the bio-accumulative* processes. Flame
retardants have been found in human blood and researchers fear that
disturbances in foetus development may occur.

The relevant TCO'99 demand requires that plastic components weighing
more than 25 grams must not contain flame retardants with organically
bound bromine or chlorine. Flame retardants are allowed in the printed
circuit boards since no substitutes are available.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour­generating layers of certain computer displays. Cadmium damages
the nervous system and is toxic in high doses.

The relevant TCO'99 requirement states that batteries, the colour-generating
layers of display screens and the electrical or electronics components must
not contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. It
damages the nervous system and is toxic in high doses.

The relevant TCO'99 requirement states that batteries may not contain any
mercury. It also demands that mercury is not present in any of the electrical
or electronics components associated with the labelled unit.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM13

CFCs (freons)

The relevant TCO'99 requirement states that neither CFCs nor HCFCs
may be used during the manufacture and assembly of the product. CFCs
(freons) are sometimes used for washing printed circuit boards. CFCs
break down ozone and thereby damage the ozone layer in the
stratosphere, causing increased reception on earth of ultraviolet light
with e.g. increased risks of skin cancer (malignant melanoma) as a
consequence.

Lead**

Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher doses, causes
lead poisoning.

The relevant TCO´99 requirement permits the inclusion of lead since
no replacement has yet been developed.

* Bio-accumulative is defined as substances which accumulate within living organisms
** Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM14

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM15

E - 1

Introduction to the NEC MultiSync LCD

English

Introduction to the NEC MultiSync LCD1810X

Congratulations on your purchase of the NEC MultiSync LCD1810X
true colour monitor!

Deutsch

ambix Technology

Dual input technology allowing both analog and digital inputs through
one connector (DVI-I) as well as additional legacy analog support
through a traditional 15-pin VGA connector. Provides traditional
MultiSync technology compatibility for analog as well as TMDS
(Transition Minimized Differential Signal) based digital compatibility

Français

for digital inputs. TMDS-based digital interfaces include DVI-D, DFP
and P&D.

DVI-I

The integrated interface ratified by the Digital Display Working Group
(DDWG) that allows both digital and analog connectors through one
port. The “I” stands for integration for both digital and analog. The digital

Español

portion is TMDS based.

1810X

DVI-D

The digital only subset of DVI ratified by the Digital Display Working
Group (DDWG) for digital connections between computers and displays.
As a digital only connector, analog support is not provided for through
a DVI-D connector. As a TMDS based digital only connection, only a

Italiano

simple adapter is necessary for compatibility between DVI-D and other
TMDS based digital connectors such as DFP and P&D.

DFP

Digital Flat Panel - An all digital interface for flat panel monitors signal
compatible with DVI. As TMDS based digital only connection, only a
simple adapter is necessary for compatibility between DFP and other

Appendix

TMDS based digital connectors such as DVI and P&D.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM16

Introduction to the NEC MultiSync LCD1810X E - 2

P&D

Plug and Display - The VESA standard for digital flat panel monitor
interfaces. It is more robust than DFP since it allows for other options
through a single connector (options like USB, analog video and IEEE­1394- 995). The VESA committee has recognized that DFP is a subset
of P&D. As a TMDS based connector (for the digital input pins), only a
simple adapter is necessary for compatibility between P&D and other
TMDS based digital connectors such as DVI and DFP.

NuCycle Plastic

A special silicone compound for PC resin, being extremely flame­retardant, safe and environmentally friendly.

Wide Viewing Angle Technology

Allows the user to be able to see the monitor from any angle(160 degrees)
from any orientation – Portrait or Landscape. Provides full 160˚ viewing
angles either up, down, left or right.

English

Deutsch

Français

Reduced Footprint

Provides the ideal solution for environments requiring superior image
quality but with size and weight limitations. The monitor’s small footprint
and low weight allow it to be moved or transported easily from one
location to another.

Colour Control system

Allows you to adjust the colours on your screen and customize the colour
accuracy of your monitor to a variety of standards.

OSM (On-Screen Manager) Controls

Allow you to quickly and easily adjust all elements of your screen image
via simple to use on-sreen menus.

ErgoDesign Features

Enhance human ergonomics to improve the working environment,
protect the health of the user and save money. Examples include OSM
controls for quick and easy image adjustments, tilt/swivel pivot stand
for preferred angle of viewing, small footprint and compliance with
MPRII and TCO guidelines for lower emissions.

Español

Italiano

Appendix

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM17

E - 3 Introduction to the NEC MultiSync LCD1810X

English

Pivoting Stand

Allows users to adjust the monitor to the orientation that best fits their
application, either Landscape orientation for wide documents, or portrait
orientation for the ability to preview a full page on one screen at one time.

Deutsch

The Portrait orientation is also perfect for full screen video conferencing.

Plug and Play

The Microsoft solution with the Windows operating system facilitates
setup and installation by allowing the monitor to send its capabilities
(such as screen size and resolutions supported) directly to your computer,
automatically optimizing display performance.

Français

IPM (Intelligent PowerManager) System

Provides innovative power-saving methodes that allow the monitor to
shift to a lower power consumption level when on but not in use, saving
two-thirds of your monitor energy cost, reducing emissions and lowering
the air conditioning cost of the workplace.

Multiple frequency Technology

Español

Automatically adjusts monitor to the display card’s scanning frequency,
thus displaying the resolution required.

FullScan Capability

Allows you to use the entire screen area in most resolutions, significantly
expanding image size.

Italiano

VESA Standard Mounting Interface

Allows users to connect their MultiSync monitor to any VESA standard
third party mounting arm or bracket. Allows for the monitor to be
mounted on a wall or an arm using any third party compliant device.

DVI/D-SUB

Appendix

Offers dual inputs, allowing you to connect the monitor to one system
via the included DVI cable and to another system via a standard D-Sub
cable (not included). You can easily switch between computers with a
touch of a button on the up-front control panel.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM18

Contents of Package E - 4

Contents of Package

Your new MultiSync LCD monitor box should contain the following:

Video Signal Cable

(15-pin mini D-SUB to DVI)

Video Signal Cable

(DVI-D to DVI-D cable)

MultiSync LCD1810X monitor

English

Deutsch

Français

Español

– NEC MultiSync LCD1810X (Model LH-18S01/LH-18S01-BK)
– AC power cable
– DVI to DFP adapter
– Video Signal Cable (15-pin mini D-SUB to DVI)
– Video Signal Cable (DVI-D to DVI-D)
– User’s manual.
– NEC LCD Setup Software, Pivot Software and other helpful

files.

Remember to save the original box and packing materials to transport or
ship the monitor.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM19

Italiano

Appendix

E - 5 Recommended Use

English

Recommended Use

Safety Precautions and Maintenance

For optimum performance, please note the following when setting up

Deutsch

and using the MultiSync LCD colour monitor:

• DO NOT OPEN THE MONITOR. There are no user
serviceable parts inside and opening or removing covers may
expose you to dangerous shock hazards or other risks. Refer
all servicing to qualified service personnel.

Français

Español

• Allow adequate ventilation around the monitor so that heat can

• Do not spill any liquids into the cabinet or use your monitor

• Do not insert objects of any kind into the cabinet slots, as they

• Do not place any heavy objects on the power cord. Damage to

• Do not place this product on a sloping or unstable cart, stand or

Italiano

• The power cable connector is the primary means of detaching

Appendix

• When operating the MultiSync LCD monitor with its AC100-

properly dissipate. Do not block ventilated openings or place
the monitor near a radiator or other heat sources. Do not put
anything on top of monitor.

near water.

may touch dangerous voltage points, which can be harmful or
fatal or may cause electric shock, fire or equipment failure.

the cord may cause shock or fire.

table, as the monitor may fall, causing serious damage to the
monitor.

the system from the power supply. The monitor should be
installed close to a power outlet that is easily accessible.

120V power supply, use a power supply cord that matches the
power supply voltage of the AC power outlet being used. The
power supply cord you use must have been approved by and
comply with the safety standards of your country.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM20

Recommended Use E - 6

• Handle with care when transporting. Save packaging for trans­porting.

• The inside of the fluorescent tube located within the LCD moni­tor contains mercury. Please follow the bylaws or rules of your
local municipality to dispose of this tube properly.

Immediately unplug your monitor from the wall outlet and refer servic­ing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled or objects have fallen into the monitor.

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet is damaged.

English

Deutsch

Français

Español

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM21

Italiano

Appendix

E - 7 Recommended Use

English

CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR
CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK
THE FOLLOWING WHEN YOU POSITION THE MONITOR:

Deutsch

• For optimum performance, allow 20 minutes for warm-up.

• Adjust the monitor height so that the top of the screen is at or

• Position your monitor no closer than 40 cm and no further away

Français

• Rest your eyes periodically by focusing on an object at least 6

• Position the monitor at a 90° angle to windows and other light

Español

• If reflected light makes it hard for you to see your screen, use

• Clean the LCD monitor surface with a lint-free, non-abrasive

• Adjust the monitor’s brightness and contrast controls to enhance

Italiano

• Use a document holder placed close to the screen.

slightly below eye level. Your eyes should look slightly down­ward when viewing the middle of the screen.

than 70 cm from your eyes. The optimal distance is 53 cm for
the MultiSync LCD

1810X monitor.

m away. Blink often.

sources to minimize glare and reflections. Adjust the monitor
tilt so that ceiling lights do not reflect on your screen.

an anti-glare filter.

cloth. Avoid using any cleaning solution or glass cleaner!

readability.

• Position whatever you are looking at most of the time (the screen
or reference material) directly in front of you to minimize turn­ing your head while you are typing.

Appendix

• Avoid displaying fixed patterns on the monitor for long periods
of time to avoid image persistence (after-image effects).

• Get regular eye checkups.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM22

Installation E - 8

Installation

Connection to your Personal Computer

The MultiSync LCD1810X true colour monitor complements PC
compatible computers. Your system has one of two configurations:

– the video controller is built into the computer.
– the video controller is in the form of a display card (sometimes

referred to as graphics card, video adapter or graphics board).

Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which connector is the video connector,
refer to your computer or display card manual.

To attach the MultiSync LCD1810X monitor to your system,
follow these instructions:

1. Turn off the power of your computer.

2. For the PC with DVI digital output: Connect the DVI-D to

DVI-D signal cable to the connector of the display card in your
system (Figure A.1). Tighten all screws.

English

Deutsch

Français

Español

For the PC with DFP digital output: Connect DVI to DFP
Adapter to the computer (Figure A.2).

Attach DVI-D to DVI-D cable to the DVI to DFP Adapter.
Tighten all screws.

For the PC with Analog output: Connect the 15-pin mini D­SUB to DVI signal cable to the connector of the display card
in your system (Figure A.3).

To connect a secondary PC with analog output, connect the
15-pin mini D-SUB to 15-pin mini D-SUB signal cable (not
include) to the connector of the display card in your system.

For the Mac: Connect the MultiSync Macintosh cable adapter to
the computer (Figure B.1). Attach the 15-pin mini D-SUB signal
cable to the MultiSync Macintosh cable adapter (Figure B.1).

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM23

Italiano

Appendix

E - 9 Installation

English

NOTE: Some Macintosh systems do not require a Macintosh cable adapter.

3. Remove connector cover. Connect the DVI signal cable to the
connector on the back of the monitor. Connect the 15-pin mini

Deutsch

NOTE: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or shorten the
module’s life.

Français

D-SUB signal cable (not included) to the connector on the back
of the monitor. Place the video signal cable (Figure C.1).

Replace connector cover.

4. Connect one end of the power cord to the AC inlet on the back of
the monitor and the other end to the power outlet (Figure D.1).

5. Turn on the monitor (Figure E.1) and the computer.

6. To complete the setup of your MultiSync LCD monitor, use
the following OSM controls:

Español

NOTE: If you have any problems, please refer to the Troubleshooting
section of this User’s Manual.

Italiano

NOTE: Refer to User's Manual in the NEC LCD Setup Software CD
case for installation and operation of this software.

• Auto Adjust Contrast (Analog input only)

• Auto Adjust (Analog input only)

Refer to the Controls section of this User’s Manual for a full
description of these OSM controls.

Using headphones

1. Connect the audio cable to “Line-in” on the back of the monitor
and the other end to the “Audio out” terminal of the computer.

Appendix

Replace connector cover.

2. Headphones may be connected to the “Headphones” output on
the right side of the monitor (Figure F.1). Headphones can be
purchased from your local electronics store.

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM24

Installation E - 10

Figure A.1 Figure A.2 Figure A.3

English

Deutsch

Français

Español

Macintosh Cable
Adapter
(not included)

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM25

Figure B.1

Italiano

Appendix

Macintosh G3 and G4 do not
need a Macintosh cable adapter

E - 11 Installation

English

Deutsch

Français

Connector
Cover

Español

FigureD.1

FigureC.1

Power Cord

Mini
D-SUB

DVI

Italiano

Appendix

Figure E.1

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM26

Power
Button

Figure F.1

Installation E - 12

Raise and Lower Monitor Screen

The monitor may be raised or lowered in either Portrait or Landscape
mode.

English

To raise or lower screen, place hands on each side of the monitor and
lift or lower to the desired height (Figure RL.1).

Screen Rotation

Before rotating, the screen must be raised to the highest level to avoid
knocking the screen on the desk or pinching your fingers.

To raise the screen, place hands on each side of the monitor and lift up
to the highest position (Figure RL.1).

To rotate screen, place hands on each side of the monitor screen and
turn clockwise from Landscape to Portrait or counter-clockwise from
Portrait to Landscape (Figure R.1).

To toggle the orientation of the OSM menu between Landscape and
Portrait modes, press the RESET button while OSM menu is off.

Tilt and Swivel

Grasp both sides of the monitor screen with your hands and adjust the
tilt and swivel as desired (Figure TS.1).

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting purposes:

1. Disconnect all cables.

Deutsch

Français

Español

Italiano

2. Place hands on each side of the monitor and lift up to the highest
position (Figure RL.1).

3. Place monitor face down on a non-abrasive surface (Place the
screen on a 55mm platform so that the stand is parallel with
the surface.) (Figure S.1).

4. Press the " " portion with your index finger and at the same
time slide the lower stand cover. (Figure S.2)

Next, lift up the stand, remove the lower stand cover, then go
on to remove the upper stand cover. (Figure S.3)

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM27

Appendix

E - 13 Installation

English

Deutsch

Figure RL.1

Français

Español

Italiano

Appendix

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM28

Figure R.1

Figure TS.1

Installation E - 14

Return the stand to its original position, remove the 4 screws
that connect the monitor to the stand, and lift off the stand
assembly. (Figure S.4)

English

5. Reverse this process to reattach stand.

NOTE: Use only VESA-compatible alternative mounting method.

55mm

Figure S.1

4

3

1

2

Figure S.4Figure S.3Figure S.2

Caution: To fulfil the safety requirements the monitor must be mounted
to an arm which guaranties the necessary stability under consideration
of the weight of the monitor.
The LCD monitor shall only be used with an approved arm (e.g. GS mark).

Deutsch

Français

Español

Italiano

CN912B-2/LCD1810X/78135322 00.5.26, 0:03 PM29

Appendix

E - 15 Controls

English

Controls

DVI/D-SUB : Allows you to change between the DVI-analog, DVI­digital and D-SUB signal inputs.

Deutsch

OSM Controls

OSMMUTE

Français

EXIT CONTROL PROCEED RESET

DVI/D-SUB

The OSM controls on the front of the monitor provide the following
functions:

Español

To access OSM menu, press any of the control buttons ( , , , ) or the
PROCEED button.
To mute sound function, press the EXIT button.
To rotate OSM between Landscape and Portrait modes, press the RESET button.
NOTE: OSM menu must be closed in order to rotate and mute.

Main Menu Sub-Menu

EXIT

Exits the OSM controls. Exits to the OSM main menu.

Italiano

CONTROL /

CONTROL / Moves the highlighted area Moves the bar left /

PROCEED

Appendix

RESET

Moves the highlighted area
up/down to select one of the
controls

left / rights to select right to increase or
control menus. decrease the adjustment.

Has no function.

Resets the highlighted contol
menu to the factory setting.

Moves the highlighted area
up/down to select one of the
controls

Activates Auto Adjust feature.
In Tool and Information Mode,
opens additional window.
Resets the highlighted contol
to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning window will
appear allowing you to cancel the RESET function by pressing the EXIT button.

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM30

Controls E - 16

Brightness/Contrast Controls

BRIGHTNESS

Adjusts the overall image and background screen brightness.

CONTRAST

Adjusts the image brightness in relation to the background.

AUTO ADJUST CONTRAST (Analog input only)

Adjusts the image displayed for non-standard video inputs.

Auto Adjust (Analog input only)

Automatically adjusts the Image Position, H. Size and Fine
settings.

NOTE: Manual adjustment of the H/V Position and Image
Adjust H. Size / Fine controls may be required to complete
setup of your MultiSync monitor.

Position Controls (Analog input only)

LEFT/RIGHT

Controls Horizontal Image Position within the display area
of the LCD.

DOWN/UP

Controls Vertical Image Position within the display area of
the LCD.

AUTO ADJUST

Automatically sets the Horizontal and Vertical Image
Position within the display area of the LCD.

English

Deutsch

Français

Español

Italiano

Image Adjust Controls (Analog input only)

H. SIZE

Adjusts the horizontal size by increasing or decreasing this
setting.

FINE

Improves focus, clarity and image stability by increasing or
decreasing this setting.

AUTO ADJUST

Automatically adjust H.SIZE and FINE settings.

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM31

Appendix

E - 17 Controls

English

Colour Control System

Five colour presets select the desired colour setting. Each
colour setting is adjusted at the factory.

Deutsch

R,G,B: Increases or decreases Red, Green or Blue colour
depending upon which is selected. The change in colour will
appear on screen and the direction (increase or decrease)
will be shown by the bars.

Tools 1

SMOOTHING

Français

Español

Italiano

Appendix

Select one of three image sharpness settings. This function
is only valid when the expanded display function (expansion
function) is on.

TEXT MODE

Use this to display text clearly.

NORMAL MODE

This sharpness is between TEXT and GRAPHIC MODE.

GRAPHIC MODE

This mode is suited for images and photographs.

EXPANSION MODE

Sets the zoom method.

FULL SCREEN

The image is expanded to 1280 x 1024, regardless of the
resolution.

KEEP ASPECT

The image is expanded without changing the aspect ratio.

EXPANSION OFF

The image is not expanded.

CUSTOM (DIGITAL INPUT ONLY)

Select one of four expansion rates.
In this mode the resolution may be low and there may be

blank areas. This mode is for use with special video cards.

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM32

Controls E - 18

VIDEO DETECT

Selects the method of video detection when two computers
are connected.

NONE

The monitor will not switch the video inputs automatically,
only by user control.

FIRST DETECT

The video input has to be switched to “FIRST DETECT”
mode. When current video input signal is not present,
then the monitor searches for a video signal from the other
video input port. If the video signal is present in the other
port, then the monitor switches the video source input
port to the new found video source automatically. The
monitor will not look for other video signals while the
current video source is present.

LAST DETECT

The video input has to be switched to the “LAST DE­TECT” mode. When the monitor is displaying a signal
from the current source and a new secondary source is
supplied to the monitor, then the monitor will automati­cally switch to the new video source. When current video
input signal is not present, then the monitor searches for
a video signal from the other video input port. If the video
signal is present in the other port, then the monitor
switches the video source input port to the new found
video source automatically.

DVI SELECTION

This function is selected the DVI input mode. When the DVI
selection has been changed, you must restart your computer.

DIGITAL

DVI digital input is available.

ANALOG

DVI analog input is available.

SOUND

Adjusts the volume of the earphones jack.

English

Deutsch

Français

Español

Italiano

Appendix

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM33

E - 19 Controls

English

Tools 2

LANGUAGE

OSM control menus are available in seven languages.

Deutsch

Français

Español

Italiano

Appendix

OSM POSITION

You can choose where you would like the OSM control im­age to appear on your screen. Selecting OSM Location al­lows you to manually adjust the position of the OSM con­trol menu left, right, up or down.

OSM TURN OFF

The OSM control menu will stay on as long as it is in use. In
the OSM Turn Off sub-menu, you can select how long the
monitor waits after the last touch of a button to shut off the
OSM control menu. The preset choices are 10, 20, 30, 60
and 120 seconds.

OSM LOCK OUT

This control completely locks out access to all OSM control
functions. When attempting to activate OSM controls while
in the Lock Out mode, a screen will appear indicating the
OSM controls are locked out. To activate the OSM Lock
Out function, simultaneously press and hold down the
PROCEED and
Out mode, again simultaneously press and hold down the
PROCEED and

FACTORY PRESET

Selecting Factory Preset allows you to reset all OSM control
settings back to the factory settings. The RESET button will
need to be held down for several seconds to take effect. Indi­vidual settings can be reset by highlighting the control to be
reset and pressing the RESET button.

RESOLUTION NOTIFIER

This optimal resolution is 1280 x 1024. If ON is selected, a
message will appear on the screen after 30 seconds, notifying
you that the resolution is not at 1280 x 1024.

button(s). To de-activate the OSM Lock
button(s).

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM34

Controls E - 20

Information

DISPLAY MODE

Provides information about the current resolution display
and technical data including the preset timing being used
and the horizontal and vertical frequencies.

MONITOR INFO

Indicates the model and serial numbers of your monitor.

OSM Warning

No Signal: This function gives a warning when there is no signal

present. After power is turned on or when there is a change of
input signal or video is inactive, the No Signal window will
appear. The PROCEED button opens the DVI SELECTION
CONTROL, as indicated in the section for DVI selection.

Resolution Notifier: This function gives a warning of use with
optimized resolution. After power is turned on or when there is
a change of input signal or the video signal doesn’t have proper
resolution, the Resolution Notifier window will open. This
function can be disabled in the TOOL menu.

Out of Range: This function gives a recommendation of the
optimized resolution and refresh rate. After the power is turned
on or there is a change of input signal or the video signal doesn’t
have proper timing, the Out Of Range menu will appear. The
PROCEED button opens the DVI SELECTION CONTROL,
as indicated in the section for DVI selection.

English

Deutsch

Français

Español

Italiano

NOTE: If “
switch to DVI SELECTION.

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM35

CHANGE DVI SELECTION” is displayed,

Appendix

E - 21 Specifications

English

Specifications

MultiSync LCD1810X

Display 46 cm (18.1 inch) viewable image size; 1280 x 1024

Deutsch

Input Signal Video Analog 0.7 Vp-p 75 Ω
(Analog)

Français

Input Signal TMDS

Español

(Digital)

native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);

2

0.28 mm dot pitch; 200 cd/m

white luminance, typical;

300:1 contrast ratio, typical

Sync Separate sync. TTL Level

Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative)
(TTL Level)
Sync on Green video (Positive) 0.7
Vp-p and sync. Negative 0.3 Vp-p

Display Colours Analog/Digital: 16,777,216

(Depends on the graphics board)

Synchronisation Horizontal 31.0 kHz to 82.0 kHz (Automatically)
Range

Italiano

Resolutions Landscape 720 x 400*
Supported 640 x 480*
(Analog/Digital) 800 x 600*

Appendix

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM36

Vertical 56.0 Hz to 85.0 Hz (Automatically)

1

: VGA text

1

at 60 Hz to 85 Hz

1

at 56 Hz to 85 Hz

1

832 x 624*
1024 x 768*
1152 x 900*
1280 x 960*
1280 x 1024*

Portrait 480 x 640*

600 x 800*
624 x 832*
768 x 1024*
960 x 1280*
1024 x 1280*

at 75 Hz

1

at 60 Hz to 85 Hz

1*3

at 66 Hz (SUN)

1*3

at 60 Hz to 75 Hz

2

at 60 Hz to 75 Hz

1

at 60 Hz to 85 Hz

1

at 56 Hz to 85 Hz

1

at 75 Hz

1

at 60 Hz to 85 Hz

1*3

at 60 Hz to 75 Hz

2

at 60 Hz to 75 Hz

Specifications E - 22

Active Display Landscape Horizontal 359 mm
Area*

4

Vertical 287 mm

Portrait Horizontal 287 mm

Vertical 359 mm

Power supply AC 100-120 V / 220-240 V 50/60 Hz

Current Rating 0.6 A @ 100-120 V / 0.3 A @ 220-240 V
Dimensions Landscape 454mm(W) x 462mm(H) x 218mm(D)

Portrait 382mm(W) x 498mm(H) x 218mm(D)
Hight Adjust 70mm

English

Deutsch

Weight 8.4 kg
Operating Temperature 5° C to + 35° C

Environmental
Considerations Humidity 30% to 80%

Storage Temperature -10° C to + 60° C
Environmental
Considerations Humidity 10% to 85%

1

Interpolated Resolutions: when resolutions are shown that are lower than the pixel

*

count of the LCD module, text may appear choppy or lines may appear to be bold.
This is normal and necessary for all current flat panel technologies, each dot on the
screen is actually one pixel, so to expand resolutions to full screen, an interpolation
of the resolution must be done. When the interpolated resolutions is not an exact
multiple of the native resolution, the mathematical interpolation necessary may cause
some lines to appear thicker than others.

2

*

NEC cites recommended resolutions at 60 Hz for optimal display performance. The
number of colors that can be displayed at frequencies above 70 Hz decreases.

3

*

The number of colors that can be displayed decreases.

4

*

Active display area is dependent upon the signal timing.

Technical specifications are subject to change without notice.

Français

Español

Italiano

Appendix

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM37

E - 23 Troubleshooting/Support

English

Troubleshooting/Support

Problem Check These Items

Deutsch

No picture - The signal cable should be completely connected

Français

Español

Power Button does Unplug the power cord of the monitor from the AC
not respond outlet to turn off and reset the monitor, or

Image persistence Image persistence is when a “ghost” of an image

Italiano

Appendix

to the display card/computer.

- The display card should be completely seated in its
slot.

- Power button and computer power switch should
be in the ON position.

- Check to make sure that a supported mode has been
selected on the display card or system being used.
(Please consult display card or system manual to
change graphics mode.)

- Check the monitor and your display card with
respect to compatibility and recommended settings.

- Check the signal cable connector for bent or pushed­in pins.

- Check that the DVI/D-SUB button is in the correct
position.

simultaneously press the RESET and Power buttons.

remains on the screen even after the monitor has been
turned off. Unlike CRT monitors, LCD monitors’
image persistence is not permanent. To alleviate
image persistence, turn the monitor off for as long as
an image was displayed. If an image was on the
monitor for one hour and a ”ghost” of that image
remains, the monitor should be turned off for one
hour to erase the image.
NOTE: As with all personal display devices, NEC
recommends using a screen saver at regular intervals
whenever the screen is idle.

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM38

Troubleshooting/Support E - 24

Problem Cheak These Items

Image is unstable, - Signal cable should be completely attached to the
unfocused or computer.
swimming is - Use the OSM Image Adjust controls to focus and
apparent adjust display by increasing or decreasing the Fine

Control.
When the display mode is changed, the OSM Image
Adjust settings may need to be re-adjusted.

- Check the monitor and your display card with respect
to compatibility and recommended signal timings.

- If your text is garbled, change the video mode to
non-interlace and use 60Hz refresh rate.

LED on monitor is - Power Switch should be in the ON position and
not lit (no green or power cord should be connected.
amber colour can be - Make certain the computer is not in a power-saving
seen) mode (touch the keyboard or mouse).

Display image is - Use the OSM Image Adjust controls to increase or
not sized properly decrease the H. Size.

- Check to make sure that a supported mode and signal
timing has been selected on the display card or system
being used. (Please consult display card or system
manual to change graphics mode or refresh rate.)

No Video If no video is present on the screen, turn the Power

button off and on again.

English

Deutsch

Français

Español

CN912B-2/LCD1810X/78135322 00.5.26, 0:04 PM39

Italiano

Appendix
