EXPRESSSCOPE Engine 3

User’s Guide

4 4

1. Overview

2. Configuring the Host System

3. Configuring a Management PC

4. Networking

5. Using Remote Management

6. Command Line Interface

7. WS-Management (Web Service for Management)

8. Troubleshooting

NEC Express Server Express5800 Series

1-1th Edition Sep, 201

TRADEMARKS AND PATENTS

EXPRESSSCOPE is registered trademarks of NEC Corporation. EXPRESSBUILDER and ESMPRO are registered trademarks of NEC Corporation. Microsoft, Windows and Windows Vista, Windows Media Player are registered trademarks of Microsoft Corporation in the United States and other countries. Firefox is registered trad emarks of the Mozilla Foundation. Java is registered trademarks of Oracle and/or its affiliates .

NOTES

(1) No part of this manual may be reproduced in any form without the prior written permission of

NEC Corporation. (2) The contents of this User’s Guide may be revised without prior notice. (3) The contents of this User's Guide shall not be copied or altered without the prior written

permission of NEC Corporation. (4) All efforts have been made to ensure the accuracy of all information in this User's Guide. If you

notice any part unclear, incorrect, or omitted in this User's Guide, contact the sales agent where

you purchased this product. (5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or

consequential damages arising from the use of this User's Guide regardless of Item (4).

ABOUT THIS USER' S GUIDE

This User's Guide provides the instructions for properly using the EXPRESSSCOPE Engine 3. Please keep this document at hand for a quick reference and use it when you encounter any questions or troubles while using the EXPRESSSCOPE Engine 3 for remote control, monitoring, and management of the host system.

Tabl e of Cont e nts

Trademarks and Patents .............................................................................................................................. 2

Notes ........................................................................................................................................................... 2

About This User' s Guide ............................................................................................................................. 2

Symbols ....................................................................................................................................................... 5

Preface ........................................................................................................................................................ 6

1. Overview ..................................................................................................................................... 7

2. Configuring the Host System ................................................................................................... 8

Default Network Settings ............................................................................................................................. 8

Management LAN Settings .......................................................................................................................... 9

3. Configuring a Management PC .............................................................................................. 12

Setting your browser .................................................................................................................................. 12

Supported browsers ................................................................................................................................... 12

J2SE Runtime Environment ....................................................................................................................... 13

4. Networking ............................................................................................................................... 14

TCP/IP Ports .............................................................................................................................................. 14

5. Using Remote Management ................................................................................................... 15

Overview .................................................................................................................................................... 15

Connecting to the web server .................................................................................................................... 15

Login and logout ........................................................................................................................................ 17

HEADER MENU ........................................................................................................................................ 18

SERVER PANEL ........................................................................................................................................ 20

SYSTEM .................................................................................................................................................... 21

REMOTE ACCESS .................................................................................................................................... 23

Remote KVM/media ................................................................................................................................... 24

CONFIGURATION ..................................................................................................................................... 27

UPDATE..................................................................................................................................................... 34

6. Command Line Interface ......................................................................................................... 35

Overview .................................................................................................................................................... 35

Connecting to BMC .................................................................................................................................... 35

Login and logout ........................................................................................................................................ 36

Login ..................................................................................................................................................... 36

Logout ................................................................................................................................................... 36

Basic Commands ....................................................................................................................................... 37

Remote Control .......................................................................................................................................... 41

Power ON ............................................................................................................................................. 41

Forced Power OFF ............................................................................................................................... 41

OS Shutdown ........................................................................................................................................ 41

System Reset ....................................................................................................................................... 41

Remote Console ................................................................................................................................... 42

UID Switch Control ............................................................................................................................... 44

System Event Log ...................................................................................................................................... 46

Viewing system event log ..................................................................................................................... 46

Setting of system event log ................................................................................................................... 47

Access Log ................................................................................................................................................ 48

Viewing access log ............................................................................................................................... 48

Clearing access log .............................................................................................................................. 50

Setting access log ................................................................................................................................. 50

User Settings ............................................................................................................................................. 52

Network Settings ........................................................................................................................................ 53

Power Consumption Control ...................................................................................................................... 59

Confirming System Information .................................................................................................................. 62

Special Extended Commands .................................................................................................................... 66

Stat e Acquisition ................................................................................................................................... 66

Power State acquisition .................................................................................................................... 66

Lamp State acq uis iti on ..................................................................................................................... 66

Interrupt Generation for OS Dump ........................................................................................................ 68

7. WS-Management (Web Service fo r Management) ................................................................ 69

Overview .................................................................................................................................................... 69

Power Control ............................................................................................................................................ 69

Power ON ............................................................................................................................................. 70

Forced Power OFF ............................................................................................................................... 70

OS Shutdown ........................................................................................................................................ 72

System Reset ....................................................................................................................................... 73

Interrupt Generation for OS Dump ........................................................................................................ 74

Sensor Information ..................................................................................................................................... 76

Enumeration of All Sensors .................................................................................................................. 76

Retrieving Specified Sensor .................................................................................................................. 76

8. Troubleshooting ...................................................................................................................... 78

Error messages .......................................................................................................................................... 78

About ECO Setting ..................................................................................................................................... 78

About Network information ......................................................................................................................... 78

Others Tips ................................................................................................................................................. 78

License Notes ................................................................................................................................ 80

GNU General Public License ................................................................................................................ 80

GNU Lesser General Public Licsense .................................................................................................. 86

OpenSSL Toolkit ................................................................................................................................... 94

MIT License .......................................................................................................................................... 97

BSD License ......................................................................................................................................... 98

SHA2 ................................................................................................................................................ 98

HMAC-SHA2 .................................................................................................................................... 98

lighttpd .............................................................................................................................................. 99

NET-SNMP ..................................................................................................................................... 100

TCP Wrapper ................................................................................................................................. 106

Other open source software programs ............................................................................................... 106

OpenSSH ....................................................................................................................................... 106

OpenSLP ........................................................................................................................................ 111

OpenLDAP ..................................................................................................................................... 111

sblim-sfcb ....................................................................................................................................... 112

SQLite ............................................................................................................................................ 113

MD2 ................................................................................................................................................ 113

MD5 ................................................................................................................................................ 114

ExploerCanvas ............................................................................................................................... 114

js-tables .......................................................................................................................................... 114

IPA Font License Agreement v1.0 .................................................................................................. 118

Oracle Code sample License Note ................................................................................................. 120

Notice

Items to be observed or points to be noted when using this product.

Items to be checked when using this product or software.

Information useful or convenient for you.

Example of troubles occurred.

SYMBOLS

The following symbols are used throughout this manual.

- 5 -

PREFACE

The EXPRESSSCOPE Engine 3 enables you to monitor the operating status of the host system (power supplies, fans, temperature and so forth), to operate the host system’s keyboard, video, and mouse (KVM) from a remote console* and to access to CD-ROM/Floppy disk drives on a remote site*. The EXPRESSSCOPE Engine 3 is enabled by a system management LSI called “BMC (Baseboard Management Controller)” and thus referred to as the “BMC” hereinafter in this User’s Guide. *The Remote KVM and Remote Media functions are optional.

- 6 -

1. Overview

The host system comes standard with the BMC (system management LSI) and a management LAN port dedicated to the BMC. By connecting the management LAN port to your network, you can monitor and control the host system from a remote site via a Web browser and SSH client.

With the optional N8115-04 Remote KVM and Media License, you can operate the host system’s KVM (keyboard, video, and mouse) from a remote console and access CD-ROM/DVD-ROM/floppy disk drives and USB memory in a remote site(Remote KVM/media).

- 7-

For security reasons, change the above default settings (IP address, User Refer to “Chapter 5: Using Remote Management” for details.

2. Configuring the Host System

This chapter describes the settings necessary to configure the BMC in the host system.

DEFAULT NETWORK SETTINGS

The B MC’s default network settings are as follows:

IP Address: 192.168.1.1 User Name: Administrator Password: Administrator

• Connect the management LAN port to the private network on which the default IP address “192.168.1.1”is reachable. If the default IP address is not reachable on the network, assign a new IP address to the management LAN by using the Server Configuration Utility of the Off-line Tool in the host system. Refer to “Management LAN Settings” in the next page for the settings.

Name, and Password) to the ones appropriate in your network environment.

• The remot e management function is enabled by default. (In some systems, the remote management function is disabled by default.) So, If the remote management function is not used, disable this settings by using the Server Configuration Utilit y of the Off-line Tool. Refer to "Management LAN Settings" in the next page for the settings.

- 8-

Setting item

Web Brows er

Off-line

On-line

(Windows/Linux)

BMC LAN Setting Management LAN Port

Connection Type

IP Address

DHCP

Service Settings HTTP/HTTPS/SSH

BMC Initialization

Notice

If you set [Enabled] the ‘Shared BMC LAN’, the system LAN port that

please select [Disabled] to disable ‘Shared BMC LAN’ .

MANAGEMENT LAN SETTINGS

You can configure basic setting of management LAN set tings of BMC for remote management using Web server function and command line interface of BMC by using some tools

• Web Brows er Please refer to Chapter 5 for details.

• Server Configuration Utility (Off-line)

Press the F4 key during POST(Power on Self test) or displaying logo immediately

after p ower on or reset the host system to enter the Server Configuration Utility.

• Server Configuration Utility (On-line Windows/Linux). It is possible to install it from NEC EXPRESSBUILDER of the host system attachment.

The item that can be set with each tool is different. Please refer to help of each tool for details of a set item.

Shared LAN Port or

Subnet Mask Default Gateway

Management LAN / Shared BMC LAN

The function for BMC to use operation LAN of the host system is called Shared BMC LAN.

Select [Enabled] to share a system LAN port with BMC LAN. If you use a management LAN port for the BMC, select [Disabled]. The management LAN port is not available when this setting is set [Enabled]. (Default setting is [Enabled]. In some systems, this menu is not supported. Please refer to the User's Guide of your host system for more details.)

Server Configuration Utility

is shared and BMC are not able to communicate directly. To the system LAN port that is shared be able to communicate with BMC,

- 9-

Notice

Select [Auto Negotiation] if the link speed and duplex mode

the management LAN.

Connection Type

Select appropriate setting for link speed and duplex mode which you need. Following settings are available. (Default setting is [Auto Negotiation].)

- Auto Negotiation

- 100Mbps Full Duplex

- 100Mbps Half Duplex

- 10Mbps Full Duplex

- 10Mbps Half Duplex

(Connection Type) of the switch (such as HUB) connected to the Management LAN is [Auto Negotiation]. If you would like to use the other setting (not “Auto Negotiation”), at first, select the other setting of the switch (such as HUB) connected to the management LAN, and then select the same setting as the switch to the Connection Type of

IP Address

If DHCP is not used to automatically obtain an IP address, enter the BMC’s IP address. If DHCP has been used, an automatically obtained IP address will appear. (Default setting is 192.168.1.1.)

Subnet Mask

If DHCP is not used to automatically obtain a subnet mask IP address, enter the subnet mask of your management LAN. If DHCP has been used, an automatically obtained subnet mask IP address will appear. (Default setting is 255.255.255.0.)

Default Gateway

If DHCP is not used to automatically obtain a default gateway IP address, enter the default gateway of your management LAN. If DHCP has been used, an automatically obtained default gateway will appear. (Default setting is 0.0.0.0.)

DHCP

If you want to obtain an IP address, choose [Enabled]. If you want to manually configure an IP address, choose [Disabled]. (Default setting is [Disabled](*).)

Web Inte r face:

HTTP Interface

Select [Enabled] to use the Web Server function using the HTTP. If not, select [Disabled]. (Default setting is [Enabled](*). )

HTTP Port Number

Specify the HTTP port number. (Default setting is 80.)

HTTPS Interface

Select [Enabled] to use the Web Server function using the HTTPS(SSL). If not, select [Disabled]. (Default setting is [Enabled](*).)

HTTPS Port Number

Specify the HTTPS(SSL)port number. (Default setting is 443.)

- 10-

Notice

These BMC Management LAN-related settings of BMC are not

the BMC reset button,

The BMC Initialization also deletes the settings for NEC ESMPRO

you change the BMC settings.

Command Line Interface:

SSH

Select [Enabled] to use the Command Line Interface using SSH. If not, select [Disabled]. (Default setting is [Enabled](*).)

SSH Port Number

Specify the BMC’s SSH port number. (Default setting is 22.)

BMC Initialization

The BMC Configuration will be cleared. Please use this function when you forgot your user name and password, etc. for remote management via a Web browser and command line interface. This function will be executed when you select "YES" on confirmation menu which appears after pressing the “Enter” key. This menu invokes the BMC configuration clear operation after selecting the "YES".

•

changed to default settings by executing the "Load Setup Default" of BIOS Setup Utility. (Execute the "BMC Initialization" to set default settings to the BMC Management LAN settings.)

• When "BMC Initialization" is executed, BMC is reset. It will take

about two minutes by the time initialization is completed after it executes it. During the initialization , D o not shutdown the system, reboot the system, or perform any switch operation after pressing

Manager(a software application bundled for remote management). Be sure to perform a backup for the NEC ESMPRO Manager settings before

* In some systems, the default settings are different for DCHP, HTTP, HTTPS, and/or SSH.

- 11-

3. Configuring a Management PC

This chapter describes the settings necessary for the remote management PC that will be connected to the host system.

SETTING YOUR BROWSER

Configure the following settings:

- Enable SSL.

- Allow Java Script execution.

- Allow Java execution.

- Accept Cookies.

- Allow Popup.

- Enable Stylesheet.

- Enable HTTP1.1.

* If you use Microsoft Internet Explorer, the following configurations are required.

- Add BMC’s address to Trusted Sites.

- Set Trusted Site's security level to Medium.

- If Enhanced Security is enabled, adding [about:blank] to Trusted Sites is required.

- If the “Do Not Save Encrypted Pages To Disk” of [Internet Options]-[Advanced]-[Security] Is check on, un-check this item is required.

- If the “Play animations in web pages” of [Internet Options]-[Advanced]-[Multimedia] is check off, check this item is required.

* If you use Mozilla Firefox (Supported only on Linux OS), below configuration is required.

- Enter URL "about:config" and change the value of "network.http.max-persistent-connections-per-server" to 4 .

SUPPORTED BROWSERS

The following browsers are supported by Windows Vista (SP2), Windows 7, Windows 8, Windows 8.1, Windows Server 2008, Windows Server 2008 R2 (SP1), Windows Server 2012 and Windows Server 2012 R2:

- Microsoft Internet Explorer 8.0

- Microsoft Internet Explorer 9.0

- Microsoft Internet Explorer 10.0

- Microsoft Internet Explorer 11.0

The following browser is supported by Red Hat Enterprise Linux WS (version 6.5 or more)

and Red Hat Enterprise Linux Client (version 6.5 or more):

- Firefox ESR 17 or ESR 24

It’s recommended that a brow ser be applied the latest service pack and the security patch.

- 12-

Notice

If you open multiple BMC Web using Tab browser, you may not use

Notice

If you use Java7, you may see the dialog of ‘Running this application

Notice

If you use Java7, you may see the dialog of ‘Block potentially unsafe

panel.

Notice

If you use Java7, it may take some time to start for certificate

again from the browser.

J2SE RUNTIME ENVIRONMENT

The management PC requires Java2 Runtime Environment (JRE), Standard Edition 7.0. JRE is available free of charge from Oracle Corporation. For security reasons, you are

recommended to use the latest JRE update. In addition, it is recommended to use the 32 bit JRE on the 64 bit Browser.

It is necessary to set the following in the Java control panel.

- Add BMC’s IP address (both HTTP/HTTPS) to [Exception Site List]-[Security].

- If the [Enable the next-generation Java Plug-in (requires browser restart)]-[Java Plug-in]-[Advanced] is not checked, please check. This item is req u ir e d.

Remote KVM/Media successfully. I n this case, please use another browser instead of browser’s tab.

may be a security risk’. In this case, you need to check ‘I accept the risk and want to run this application’ and press Run button.

components from being run?’. In this case, you need to press ‘Don’t Block’ button or please choose the ‘Enable-hide warning and run with protections’ from the Mixed code of Advanced menu of Java control

revocation checking of the signed Java Applet/Application. In this case, once you need to close the browser and choose the ‘Do not check (not recommended)’ from the [Perform certificate revocation checks on] of Advanced menu of Java control panel and then login

- 13-

Module name

Port #

Protocol

Direction

Module name

Port #



5123(FD) (*2)



5127(FD) (*2)

(Non-Encryption)



(Encryption)



(Non-Encryption)



(Encryption)



SSH client

Dynamic(*1)

TCP



BMC

22(*3)

SMTP server

25(*4)

TCP



BMC

Dynamic

LDAP server

389(*5)

TCP



BMC

Dynamic

SNMP server

162

UDP



BMC

Dynamic

BMC doesn't support connection via HTTP proxy server.

Notice

It is recommended to use the network in more than 100BASE-TX

4. Networking

TCP/IP PORTS

The BMC uses the TCP/IP ports listed below. If you use the BMC in a firewall environment, you need to allocate the port numbers (shown in the right column) to the individual non-block ports.

Remote Media (Non-Encryption)

Remote Media (Encryption)

Web browser

Remote KVM Console

Dynamic(*1) TCP

BMC 5120(CD/DVD)

5122(USB MEM)

BMC 5124(CD/DVD)

5126(USB MEM)

BMC 80(*3)

BMC 443(*3)

BMC 7578(*2)

BMC 7582(*2)

*1 The Dynamic ports are dynamically allocated ports and usually ranged from 1024 to

65535. *2 Go to [Configuration]-[System Operation] to change the port number. *3 Go to [Configuration]-[Network]-[Service] to change the port number. *4 Go to [Configuration]-[Alert:]-[Mail Alert] to change the port number. *5 Go to [Configuration]-[User Management]-[LDAP] to change the port number.

(10Mbps bandwidth or more) for remote management feature.

- 14-

The “BMC_HostPort” URL includes the BMC’s IP address or host name

(default), you may omit the port number.

For security reasons, you are recommended to use HTTPS (SSL)

When you connect via SSL, security warning messages may appear.

5. Using Remote Management

OVERVIEW

The B MC Web Server function allows you to control the host system’s power and KVM from a remote console via a Web browser.

Part of the above function is implemented by Java Applet.

CONNECTING TO THE WEB SERVER

Access the following URL from the Web browser on the remote management PC:

http://BMC_HostPort or https://BMC_HostPort

and a colon followed by a port number for HTTP or HTTPS connection: e.g. 192.168.1.1:80 If the port number is 80 for HTTP or 443 for HTTPS

connection. For better communication performance, use HTTP on a secured network.

- 15-

If you did not register the SSL server certificate, the following page is

displayed and HTTPS connection is blocked. In this case, select "Continue to this website" to continue (The image if you are using Internet Explorer is as follows).

- 16-

Notice

You can select the display language only in the login page. If you language in the login page.

Notice

Do not use the “Reload” button in your browser after login.

LOGIN AND LOGOUT

When the login page appears, input the user name and password, and then click [Login].

1. The display language can be selected to English or Japanese.

2. The online help is displayed.

3. Please input username and password.

4. Secure Mode(HTTPS) or Non Secure Mode(HTTP) can be selected.

5. Please push "Login" button.

6. Server Name (BMC’s IP address) is displayed (*). (*) Even if you use IPv6 address to login to BMC, BMC’s IP address is displayed as IPv4

address.

want to change the language after login, log out once and change the

- 17-

Notice

If the browser is slow during login procedure, please restart your

Notice

BMC FW will be restarted very rare. In this case, it does not affect the

use it via network.

Notice

If it is repeatedly login to the BMC without logout normally, you

and try again or press BMC reset button of the host system.

Notice

543

Logout

Click “Logout” in the upper right corner of the window. When a confirmation dialog appears, click [OK] to log out.

After you log out, y ou return to the login page. Besides, all the remote device windows that were opened during login will be closed.

brower or logout.

software on the host system OS, but an existing network connection to the BMC will be disconnected, so, please connect again when you

cannot login to the BMC because it is reached to the maximum number of simultaneous login users caused by the HTTPS sessions that are not terminated and are remained or because it is reached to the maximum number of simultaneous login users (4). In this case, please wait for the BMC’s automatic logout time (30 minutes or more),

or shortly after the BMC reset. In this case, please try to login again.

HEADER MENU

- 18-

1. Login user name is displayed.

2. Login user’s privilege is displayed.

3. The environment of management PC is displayed, and set by clicking "Environment"..

4. License information is displayed.

5. The online help is displayed.

- 19-

Even if actual UID LED is not mounted into the host system, the UID

LED indicator of the Server Panel functions as virtual UID LED.

Refer to Maintenance Guide of the system for the message displayed

in the Virtual LCD.

SERVER PANEL

The server panel is displayed under a browser after log in. The server panel has following functions.

1. The virtual LCD that displays the state of the host system.

2. The Button to start RemoteKVM/Media

3. The button that minimizes the server panel.

4. The power switch and a lamp of the host system. The state of the power supply of the

host system is shown.

5. The UID(Unit ID) switch and a lamp of the host system.

6. The status lamp and power capping lamp of the host system. The state of the host

system is shown.

7. The login status to the BMC, the remote media usage condition and automatic video

record setting, whether the video data is recorded or not, and alert setting are displayed.

- 20-

SYSTEM

A. The system tab. BMC supported functions are displayed. B. The menu that can be selected in the system tab is displayed. C. Information selected by B is displayed. The screen of "Summary" is displayed in the

above-mentioned example. Menu 1 Summary

The state of information and BMC of the host system is displayed.

2 Component

Only items supported with the host system are displayed for each item of composition information. (processor, memory, temper ature, voltage, fan, power, power supply, battery, drive, RAID, network and ME). Moreover, the item supported with the host system might not be displayed depending on the state of the system power supply and the presence state of the components such as devices.

3 IPMI Information

Information (SEL,SDR,FRU,MC) is displayed in accordance with IPMI and it backs up. The preserved backup data can be referred to from the server management software (ESRAS utility and off-line maintenance utility).

4 Access Information

- 21-

Notice

If the hardware clock setting (RTC) is set by the host system OS to

occur.

Notice

When the AC power of the host system is turned off, the video record erased.

Notice

The video record data during BIOS POST will be overwritten at next

is deleted manually.

Notice

If the automatic video recording is run opening the Remote

video recording without opening the Remote KVM/Media.

Notice

If the host system power on by the AC-LINK with the automatic video

(recommends 70 seconds or more).

5 Statistics Information

The Power Graph which shows power consumption changes of latest 10 minutes or 24

hours are displayed. 6 Video Record Information(*)

If the automatic video recording function is enabled from configuration tab, the video records which were recorded at the time of BIOS POST or OS stall are displayed. Also you can playback or download or delete them.

(*) The video length is maximum 5 minutes but it might be shorter than 5 minutes depending on the size limit of regions of video record data or the size of the resolution of screen to be recorded.

the time in UTC offset, The timestamp of SEL (System Event Log) will be set to the time in UTC offset instead of local timestamp. Please notice that the time difference between UTC time and local time will

data that was saved by the automatic video recording function will be

collection time. On the other hand, the video record data during OS stall will be saved and not be collected at next collection time until it

KVM/Media, the video record data on the playback screen might be displayed broken very rarely. In this case, please run the automatic

recording is enabled, the video record data during BIOS POST might not be collected even if the AC-LINK delay time to the DC ON is short. In this case, please set the AC-LINK delay time to 65 seconds or more

- 22-

REMOTE ACCESS

A. The remote access tab. BMC supported functions are displayed. B. The menu that can be selected in the remote acces s tab is displayed C. Information selected by B is displayed. The screen of "Power Control" is displayed in the

above-mentioned example.

Menu 1 Power Control

Select Boot device of the host system, powering on/off, power cycle, reset the system, and shutdown the OS.

2 System Operation

Start RemoteKVM/Media, turn on/off of UID lamp, press Dump switch and reset BMC.

3 Session Management

The user who is logging in BMC can be managed.

4 License Information

The license to use remote KVM/media is registered.

- 23-

Notice

If you execute “power cycle” under the condition that the “Power

button of the host system.

Notice

Click “BMC Reset” only if a problem occurs in EXPRESSSCOPE

operation after clicking the “BMC Res et” for approximately 3 minutes.

The connections with Web browser and SSH client are disconnected if you reset the BMC.

Clicking the “BMC Reset” cannot reboot the server.

Save” is enabled by BIOS Setup Utility, the powering on after the powering off will not work. In this case, please try to press power

Engine 3 (BMC). Do not click “BMC Reset” in usual operation. Do not shutdown the system, reboot the system, or perform any switch

REMOTE KVM/MEDIA

I. Video

The features such as Refresh screen, Low bandwidth mode (Normal, 8bpp, 8bpp B&W, 16bpp display mode are supported depending on the network bandwidth.), manual video recording, capture screen, full screen are available.

II. Keyboard

The features such as user defined macros, virtual keyboard (software keyboard) for Japanese/English/French/German are available.

III. Mouse

The features such as changing or synchronizing the mouse cursor, changing the mouse coordinate mode are available.

IV. Media

Enable or disable the remote device and open the rem ote med i a window to connect or disconnect the remote media.

V. Power

You can do the power on, power off, power cycle, reset, OS Shutdown, NMI dump (If the memory dump is set on the host system OS.) to the host system.

- 24-

The host system detects remote media as following devices: Remote

AMI Remote USB Mem

The access lamp comes to remain lighting after it connects it according to the kind of the floppy disk drive of management PC.

Notice

When the operation into which the resolution on the host system side

KVM again.

Notice

When you log on to the BMC from the host system, do not access the will not be able to use keyboard and mouse.

Notice

On some browsers, if you want to start the Remote KVM/Media, you please download again by pressing ‘Retry’.

Notice

If the mouse pointer is not displayed properly on Remote KVM/Media,

box for [Display pointer trails]-[Visibility].

VI. Users

Display the user information that is using the Remote KVM/Media. Up to 2 users can use Remote KVM/Media simultaneously.

VII. View

Control the visibility of tool bar (control box area and hot key area). The ‘Request Full Control’ menu will be displayed for the Remote KVM/Media that is launched as view only mode and it is possible to request for permission to the Remote KVM/Media that is launched as full control mode.

VIII. Info

Display the version information.

devices are disabled just after the remote KVM/Media is started. It is displayed only when they are enabled from the “Media” menu.

• AMI Remote FD

• AMI Remote CD/DVD

•

frequently changes after remote KVM is started, the remote KVM connection might be disconnect. In that case, please start remote

Remote KVM Console from a Web browser in the host system. You

may see the dialog ‘jviewer.jnlp couldn’t be downloaded’. In this case,

please try the following setting on the host system OS.

- Lowered one scale from "Full" to "None" side on the [Hardware acceleration]-[Troubleshoot]-[Advanced settings]-[Screen Resolution]-[Display] of Control Panel.

- Uncheck the box for [Enhance pointer precision]-[Motion]-[Pointer Options]-[Mouse Properties] of Control Panel. Also, try to check the

- 25-

Notice

If you change keyboard language after adding user defined macro on

language.

Notice

If the manual video recording is run under ‘8bpp B&W’ mode which

software.

the Remote KVM/Media, the user defined macro that was created with the previous keyboard language might not work well because some keyboard key has different key code depending on the language. In this case, please create the macro again with the current keyboard

was set by Low bandwidth mode, the created video file (AVI formatted) might not be playback by Windows Media Player. In this case, please try to install the codec pack which includes Motion JPEG codec to the management PC or try the other playback

- 26-

CONFIGURATION

A. The configuration tab. BMC supported functions are displayed. B. The menu that can be selected in the configuration tab is displayed C. Information selected by B is displayed. The screen of "ECO" is displayed in the

above-mentioned example.

Menu 1 Network

Set IP address and the service of the BMC and the SSL public key can be made.

2 User Management

Maintain user and Active directory/LDAP setting, register the SSH public Key.

3 Alert

The setting of which it alerts by using E-mail and SNMP from BMC can be done.

4 System Operation

Set the RemoteKVM/Media configuration.

5 Miscellaneous

- 27-

Notice

The strings “InternalUseOnly”, “MWA”, “AccessByEM-Poem”,

IPMI command tool, you can use User ID from 6 to 16.

Web Br owser

Management LAN

Connection Type

Auto Negotiation

DHCP

Disable

IP address

192.168.1.1

Subnet Mask

255.255.255.0

Default Gateway

0.0.0.0

DNS Server

0.0.0.0

Host Name

Blank

"BMC" + MAC

Set the behavior when the SEL repository is full, the access log setting, AC-LINK setting, PEF setting, management setting from the management software, and the automatic video recording setting.

6 ECO

Power consumption and the throttling situation are displayed and the power capping can be set.

7 System BIOS

Some functions of System BIOS can be set.

8 Battery Controller

If the host system is equipped with a battery, various functions of Battery Controller can be set.

9 Backup/Restore

Backup and Restore each item that was set.

“Administrator” are reserved by BMC. Please do not add or remove these characters as User Name. The user account is synchronized with the IPMI user account. If you want to add or remove users in the

For each BMC setting, the “Default” value of the setting from Web browser of BMC, Server Configuration Utility, NEC ESMPRO Manager and the initial value of BMC Initialization are as the following table (There are some items of Server Configuration Utility, NEC ESMPRO Manager that are not displayed in the Menu.). “No change” in “BMC Initial izat io n ” means that the setting values from the Web Browser/Server Configuration Utility/NEC ESMPRO manager are preserved by executing BMC Initialization.

Server Configuration

Menu Setting

Utility NEC ESMPRO

BMC Initialization

Manager “Default” value

Network

- 28-

address

Domain Name

Blank

Limitation Type

Allow All

IPv6

Disable

IPv6 Address Assignment

Mode

IPv6 Static Address

0::0

IPv6 Prefix Length

IPv6 Gateway Address

0::0

0::0 HTTPS

Enable

HTTPS Port

443

HTTP

Enable

HTTP Port

SSH

Enable

SSH Port

Active Directory Authentication

Disable

Authentication User

Blank

Authentication Password

Blank

User Domain Name

Blank

Timeout

120

Domain Controller Server

Address１

Domain Controller Server

Address2

Domain Controller Server

Address3

Group Name

Blank

Group Domain

Blank

Privilege

Administrator

LDAP Authentication

Disable

IP address

0.0.0.0

Blank

Port

389

Search Base

Blank

Bind Domain Name

Blank

Bind Password

Blank

Group Name

Blank

Group Search Base

Blank

Blank Privilege

Administrator

Mail Alert

Disable

Waiting time for SMTP server's

response

To:1

Enable

Blank

To:2

Disable

Blank

To:3

Disable

Blank

From

Blank

Reply-To

Blank

Dynamic Dynamic

User

Management

0.0.0.0 Blank Blank Blank Blank Blank

30 30

Alert

- 29-

Subject

Blank

Subject Option

Disable

X-Priority

Enable

Date Formats

MM/DD/YYYY

SMTP Server

0.0.0.0

Port

Authentication

Disable

Enable

Authentication Type

All checked

User Name

Blank

Password

Blank

Alert Level

Error, Warning

Separate Setting

SNMP Alert

Disable

Computer Name

Blank

Community Name

public

Alert Process

One Alert Receiver

Alert Acknowledge

Enable

Disable

Alert Receiver1

Enable

Disable

Alert Receiver2

Disable

Alert Receiver3

Disable

Alert Level

Error, Warning

Separate Setting

Alert Retry Count

3 0 Alert Timeout

Remote KVM Console

Encryption

Port (No Encryption)

7578

Port (Encryption)

7582

Cursor Mode

Dual

Single

Coordinate Mode

Absolute(*4)

Absolute

Remote Media Encryption

Enable

Disable

Port (No Encryption)

5120

Port (Encryption)

5124

Aggressive Mode(*1)

Disable

Disable(*10)

Maximum Power Consumption(*5)

Maximum Power

Consumption(*10)

Correction time limit

2(*6)

2(*10)

Shutdown System

Disable

Disable(*10)

Non-Aggressive Mode(*2)

Disable

Disable(*10)

Maxim um Power

10(*7)

Maximum Power

10(*10)

System

Operation

ECO

Keyboard Language

Power Threshold(Pa)

Enable Disable

When login in

Japanese;

Japanese, When

English

Power Threshold(Pn)

- 30-

Consumption -

Correction time limit

10(*8)

10(*10)

Safe Power Capping

Disable

Disable(*10)

Boot Time Configuration(*3)

Disable

Disable(*10)

Performance

Optimized

Performance

Optimized(*10)

Disable CPU Cores

0(*10)

Behavior when SEL repository

is full

Overwrite oldest

SEL

Overwrite oldest

SEL (*9)

Access Log HTTP

Disable

HTTPS

Disable

SSH

Disable

Operation

Disable

Power Restore Delay AC-LINK

Last state

No change

Minimum

configurable time

Platform Event Filtering

Enable

Disable

ESMPRO Management

no change

Disable

Authentication Key

guest

Blank

Redirection (LAN)

Enable

Disable

Automatic Video Recording

Disable

POST Error Pause

Enable/Disable

Enable

Memory Error

Boot/Halt

Boot

CLI SETUP

Enable/Disable

Disable

Miscellaneous

Performance Mode

Delay Time

No change

*1: This menu is shown as “Critical Power Capping” in some host system. *2: This menu is not supported in some host system. *3: This menu is not supported in some host system. *4: This value is “Relative” in some host system or depending on the revision of the BMC. *5: The default value is ‘settable maximum’ in some host system. The ‘settable maximum’ is

equal to ’Maximum Configuration’ in some host system. *6: The default value is ‘settable minimum’ in some host system. *7: The default value is ‘Power Threshold(Pa) -10’ or ‘The settable minimum +10’ ,whichever

is greater in some host system. The ‘settable minimum’ is equal to ‘Minimum Configuration’ in some host system.

*8: The default value is ‘settable minimum’ in some host system. *9: This value is “Stop logging SEL ” in some host system or depending on the revision of the

BMC. *10: This value is “Blank” in some host system or depending on the revision of the BMC.

For each System BIOS setting, the possible values and the value of BIOS Initialization are as the following table.

Item N ame Setting Possible Values(*1)

BIOS Basic

BIOS Initialization

(*2)

- 31-

Power Save (*3)

Enable/Disable

Disable

Serial Port A

Enable/Disable

Enable

2E8h

3F8hBlank

IRQ 3 IRQ 4

Serial Port B

Enable/Disable

Enable

2E8h

3F8h

IRQ 3 IRQ 4

Disabled

Serial Port B

VT100+

PC-ANSI

9600

115200

7 8

None

Odd

1 2

None

Hardware RTS/CTS

Continue C.R. after POST

Enable/Disable

Enable

Serial Port A

Serial Port B

Console

Redirection

Serial A Base I/O

Serial A Interrupt

Serial B Base I/O

Serial B Interrupt

BIOS Redirection Port

Terminal Type

Baud Rate

Data Bits

2F8h 3E8h

Serial Port A

VT-UTF8

19200 57600

3F8h

IRQ 4

2F8h

IRQ 3

Disabled

VT100+

115200

Parity

Stop Bits

Flow Control

Even

None

Hardware RTS/CTS

*1: The value might be different according to the system. *2: The value that is set when shipping. The value might be different according to the syst em. *3: If the “Power Save” is enabled, then Power ON following Power OFF by the Power Cycle

will not be performed.

- 32-

Example of an E-mail alert:

Virtual LCD Message:

Asset Tag: xxx-xxxxxx-xxx

Notice

Following contents are sent as E-mail alert.

System Rear FAN4 Lower Non-Critical Event Information:

Record ID: 0AA0h Timestamp: 10/13/2011 17:59:23 Severity: Non-critical Description: Fan(Speed) - Error Lower Non-critical - going low Dump: A0 0A 02 FB 26 97 4E 20 00 04 04 43 01 57 FF B6

URL: http://192.168.1.11:80 https://192.168.1.11:443

BMC Network Information: BMC IP Address: 192.168.1.1 BMC Host Name: BMCxxxxxxxxxxxx

Firmware Revision: System BIOS Revision: x.x.xxxx BMC Firmware Revision: xx.xx SDR Revision: SDR Version xx.xx

Product Information: Manufacturer: xxx Product Name: xxxxxxxxxxx/xxxxx-xx Part/Model Number: [xxxxx-xxxxx] Version: FR1.0 Serial Number: xxxxxxx

• You should use a straight through ethernet cable if you set

10Mbps or 100Mbps as ‘Connection Type’ of Network.

- 33-

Notice

When you update the BMC firmware, you need to check “Apply

UPDATE

A. The update tab. BMC supported functions are displayed. B. The menu that can be selected in the update tab is displayed C. Information selected by B is displayed. The screen of "BMC Firmware" is displayed in the

above-mentioned example.

Menu 1 BMC Firmware

Update the BMC firmware regardless of power-off/on of the host system.

2 System BIOS

Update the System BIOS regardless of power-off/on of the host system.

Immediate” befor e proceeding to “Start Update”.

- 34-

To use Command Line Interface, you need to change the

You can change the BMC’s SSH port number by using the Off-line

SSH: 22

A security warning messages regarding your server certificate may

6. Command Line Interface

OVERVIEW

With the BMC Command Line Interface, you can control the host system from a remote SSH client. The BMC supports SSH (Version 2) protocol.

CONNECTING TO BMC

Access the BMC IP address or DNS host name from SSH client on the remote management PC.

configuration of the command line interface (SSH) to be enabled by any of the setting of the Off-line Server Configuration Utility or On-line Server Configuration Utility or Setting of Web browser. Refer to the “ Host System”.

Management LAN Settings” in the “Chapter 2: Configuring the

Server Configuration Utility, On-line Server Configuration Utility or a web browser. The default settings are as follows:

be displayed when you access the BMC from a SSH client.

- 35-

The user account is common to the one for a remote management function via web browser.

The number of users who can log in the system using the command

in via the command line interface.

Only a single user among users who are using the command line

cannot use a character-based remote console.

Enter your user name and passwo rd at login prompt. A command prompt will be displayed after l ogin. Also you can login by using public key authentication.

line interface at the same time is four users or less. Therefore, you cannot log in the system when other four users have been logging in the system using SSH clients via the command line interface. Check whether other three users are logging in the system, if you cannot log

interface or NEC ESMPRO Manager can use a character-based remote console via the command line interface. Check whether another user is using a character-based remote console, if you

Refer to the “CONFIGURATION” in the Chapter 5: Using Remote

Management” for registering SSH public key.

Logout

Enter the “exit” command at the comma nd prompt. The SSH client will be disconnected from the BMC after logout.

- 36-

The user must have an account as the following user level to use the

command.

BASIC COMMANDS

This section describes basic commands to use them as the command line interface. These basic commands manage the host system by using the concept of command (verb) and target (Managed Element) proposed by DMTF (Distributed Management Task Force).

Each basic command functions to a specified target. The target points the managed element by address path much like the path to a file in a file system.

Both absolute path, which is started from "/", and relative path are available for pointing the target. Specifically, "." and ".." are supported. The "." means the current default target and the ".." means the parent target.

Each basic command functions to the current default target when the <target>, which is an argument pointing a target for the command, is not specified to the basic command. The current default target can be changed by the cd command. The current default target is "/admin1" when the command line interface session is started.

The current default target is displayed at the left side of the command prompt ( "->"). Help string, command syntax, of each command appears when "-h" option is specified as the

<options> of the command. The argument placed between "[" and "]" is omissible.

basic commands:

• cd, exit, help, show and version can be used under an account as

all user levels.

• stop, start and reset are needed an account as operator or

administrator user level to use these commands.

• set is needed an account as administrator user level to use this

Maximum number of input character for command line interface is 250.

Syntax:

cd [<options>] [<target>]

Description:

The cd command changes the current default target to the target specified by the <targe t > argument.

exit

Syntax:

exit [<options>]

Description:

The exit command terminates and logs out the user session.

- 37-

Notice

Reset the BMC only if a problem occurs in the BMC and don't reset and SSH client are disconnected if you reset the BMC.

help

Syntax:

help [<options>] [<help topics>]

Description:

A basic command, <command>, can be specified for the <help topics>. The help command displays the help string for specified basic command when <command> argument is specified.

reset

Syntax:

reset [<options>] [<target>]

Description:

The reset command performs a hardware reset on the <target>. /admin1/system1 and /admin1/sp1 are available for the <target> of the reset command.

For /admin1/system1, the host system is reset. For /admin1/sp1, the BMC is reset.

the BMC in normal operation. Also the connections with Web browser

set

Syntax:

set [<options>] [<target>] <propertyname>=<value>

Description:

The set command is used to set the value of one or more properties of target specified by the <target>. The command accepts a target specified by the <target> and series of <propertyname>=<value> pairs which is will try and apply. The <propertyname> means a name of property set by the command. The <value> means a new value set by the command.

One or more <propertyname>=<value> pairs can be specified by delimiting between each pair in space.

The set command requires <propertyname>=<value> command line argument except when -h is specified as the <options>.

show

Syntax:

show [<options>] [<target>] [<properties>]

Description:

- 38-

Notice

It may take about 1 minute to display the target information

The show command is used to display information about the target specified by the <targe t > argument.

The command displays the target specified by the <target> as the first line of the information. It displays the current default target in the first line if <target> is not specified.

The default behavior of the command for the target specified by the <target> is as follows. The command display targets which are contained by the specified target after the "Targets" string. The command displays properties which are contained by the specified target after the "Properties" string. The properties are displayed in the form of property=value. The command displays basic commands (verbs) and special extended commands which are available for the specified target after the "Verbs" string.

The command displays the property specified by the <properties> in the form of property=value if the <properties> is specified. The command displays all properties which are contained by the specified target if the <properties> is not specified.

There is -display <arg values> option which can be specified by the <options> for the show command. The option can control the type of information that is displayed about the target specified by the <target>. Valid option argument values as the <arg values> for this option include "targets", "properties", "verbs", and "all". The option argument values can select the above "Targets", "Propert ies" and "Verbs" information that is displayed. “all” displays the whole. The default for the -display option control is "all".

depending on the configuration of the host system.

start

Syntax:

start [<options>] [<target>]

Description:

/admin1/system1 and /admin1/system1/textredirectsvc1 are available for the target of the start command.

The start command performs a power on to the host system if /admin1/system1 is specified by the <target>.

The start command starts a character-based remote console if /admin1/system1/ textredirectsvc1 is specified by the <target>.

stop

Syntax:

stop [<options>] [<target>]

Description:

The stop command performs a normal power off request (OS shutdown request) or a forced power off request.

/admin1/system1 is available for the target of the stop command. The stop command

- 39-

with no option as the <options> performs a normal power off request (OS shutdown request) to the host system if /admin1/system1 is specified by the <target>. The command with -f (or -force) as the <options> performs a forced power off request to the host system if /admin1/system1 is specified by the <target>.

version

Syntax:

version [<options>]

Description:

The version command is used to display the version of the command line protocol specification which is supported.

- 40-

Notice

Performing remote control when the operating system is running may The user must have an account as operator or administrator for

remote control.

The above OS shutdown is equivalent to pressing the POWER switch must be set to shut down when you power off the system.

An above system reset is failed when the power of the host system is

REMOTE CONTROL

You can perform remote control of the host system at the command prompt.

cause the loss of data in the host system.

Power ON

Enter the following command at the command prompt.

start /admin1/system1

Forced Power OFF

Enter the following command at the command prompt.

stop -force /admin1/system1

stop -f /admin1/system1

OS Shutdown

Enter the following command at the command prompt.

stop /admin1/system1

when the power of the host system is o n. Your operating system

System Reset

Enter the following command at the command prompt.

reset /admin1/system1

off.

- 41-

Notice

The standard serial port B (COM B) on the host system cannot be occupies the serial port B.

To use a character-based remote console, set appropriate settings for

your host system.

Only a single user among users who are using the command line

remote console.

Remote Console

To start a character-based remote console, enter the following command at the command prompt.

start /admin1/system1/textredirectsvc1

To return f rom the character-based remote console to the command interface session, enter the <ESC>stop keys (<ESC>key, <s>key, <t>key, <o>key and <p>key) during the character-based remote console.

used for connecting another device in this cases because the BMC

the console redirection function of the host system's serial port on the BIOS Setup Utility in advance.

Especially, please use the following items by the following setting:

• BI O S Redirection Port : Serial Port B

• Baud Rate : 19.2K

• Flow Control: CTS/RTS

• Terminal Type: PC ANSI

For the system BIOS Setup Utility, please refer to the User's Guide of

interface or NEC ESMPRO Manager (a software application bundled for remote management) can use a character-based remote console via the command line interface or NEC ESMPRO Manager. Once the first user uses the character-based remote console, other users cannot use any character-based remote console from any SSH clients or NEC ESMPRO Manager. Check whether another user is using a character-based remote console, if you cannot use a character-based

To show the usage status of the character-based remote console by other users of the command line interface or NEC ESMPRO Manager, enter the following command at the command prompt.

show /admin1/system1/textredirectsvc1/textredirectsap1

You can confirm the usage state by value of EnabledState of the "Properties" which is displayed by the command. EnabledState=2 : Using the character-based remote console by current user or other user. EnabledState=6 : Not in use.

- 42-

Please confirm in advance whether it is OK to stop the

The user must have an account as administrator for stopping the

To stop t he character-based remote console using by other user forcibly, enter the following command at the command prompt.

set /admin1/system1/textredirectsvc1/textredirectsap1 EnabledState=6

character-based remote console using by other user forcibly.

character-based remote console forcibly.

- 43-

Notice

The user must have an account as administrator for UID Switch set command for the UID Switch Control.

If the UID LED is not mounted into the host system, the “UID Switch

description of the UID LED.

UID Switch Control

You can turn on/off the UID (Unit ID) LED on the host system by the virtual UID switch throug h the command line interface. T his function is available only in the host system with UID LED.

Control (turning on or turning off the UID LED) because of using the

Tur ni ng on UID LED

Enter the following command at the command prompt. State of the UID LED becomes same state of turning on the LED by using UID (Unit ID) switch of the host system.

set /admin1/system1/led1 ActivateState=2

Tur ni ng of f UID LED

Enter the following command at the command prompt. State of the UID LED becomes same state of turning off the LED by using UID (Unit ID) switch of the host system.

set /admin1/system1/led1 ActivateState=4

Confirmation of state of turning on UID LED

Enter the following command at the command prompt.

show /admin1/system1/led1

You can conf irm the state of the UID LED by value of ActivateState of the "Properties" which is displayed by the command. ActivateState=2 : UID LED state is turned on by UID switch . ActivateState=3 : UID LED sate is blinking by the management software . ActivateState=4 : UID LED state is turned off by UI D switch .

Control” function works only to the virtual UID LED of the Server Panel. Please refer to the User’s Guide of your host system for the

- 44-

state) only by the UID switch control.

• The UID LED will blink (flash) when it is controlled by Chassis

Identify function of management software such as NEC ESMPRO Manager. The UID LED will turn on when it is controlled by pushing the UID switch of the host system or using UID switch control function of BMC's web server or command line interface. For actual display state of the UID LED, blinking (flashing) the UID LED is higher priority than turning on it when it is controlled at a same time (blinking state AND turning on state).

• Blinking (flashing) UID LED by management software can be

turned off (release the blinking state) only by management software. Turning on UID LED by UID switch control (actual switch of the host system or the function of BMC's web server or command line interface) can be turned off (release turning on

- 45-

To show the total number of system event log records more than 1000

SYSTEM EVENT LOG

You can display system event log and modify setting of the system event log through the command line interface.

Viewing system event log

To move the current default target to /admin1/system1/log1, enter the following command at the command prompt.

cd /admin1/system1/log1

Here, to confirm the total number of system event log records, enter the following command. The "Targets" section reported by the following command indicates the "record<N>" target(s). <N> means any value between 1 and the total number of the system event log records.

show

event logs, it may take about tens of seconds.

Next, when the following command is input, information of a specific record is displayed at "Properties" section: Here, <N> means record number which you would like to confirm.

show record<N>

For example, enter the following command when you would like to confirm the number 1 record.

show record1

The example of displaying information in this case is shown below.

-> show record1 Command Status: COMMAND COMPLET ED

ufip=/admin1/system1/log1/record1

Properties:

RecordID=1 CreationTimeStamp=20110324130745.000000+000 RecordFormat=*RecordID*RecordType*TimeStamp*GeneratorID*EvMRev*Sens orType*SensorNumber*EventType*EventData1*EventData2*EventData3* RecordData=*1*2*1300972065*32*4*16*9*111*66*143*255*

Verbs:

cd exit help show version

- 46-

The user must have an account as administrator for modifying the

Setting of s ystem event log

To move the current default target to /admin1/system1/log1, enter the following command at the command prompt.

cd /admin1/system1/log1

The "Properties" section reported by the following command indicates the current setting of system event log.

show

Enter the following command if you would like to modify a property of the setting of system event log .

set <Property>=<New value>

The properties which the system event log target contains are as follows:

• oemnec_selbehavior This specifies the behavior when the system event log repository is full. The valid

values for this property are followings. This is the dynamic setting. 0 : Stop logging the system event log. The system event log is not recorded any more

when the system event log is full.

1: Clear all system event logs. All system event logs are cleared when the system

event log is full.

2: Overwrite oldest system event log. Oldest system event log is overwritten with new

system event log when the system event log is full.

For example, enter the following command when you would like to enable the auto clear of system event log.

set oemnec_selbehavior=1

setting of the system event log.

- 47-

The user must have an account as administrator for clearing and

The following are events supported by the Access Log function.

Start the remote KVM

User Information is not registered by logout events for SSH

ACCESS LOG

You can display, clear, and set the access log for the management LAN.

setting the access log.

• Login and logout events for HTTP, HTTPS, and SSH connections

• System control (Power OFF/ON, system reset, etc…) via Web

browser.

• Modify the setting (Network setting, etc…) via Web browser.

•

connections.

Vie win g ac ce ss lo g

To move the current default target to /admin1/sp1/log1/record1, enter the following command at the command prompt.

cd /admin1/sp1/log1/record1

Enter the following command, if you would like to confirm the access log.

show

The example of displaying the access log is shown below.

timestamp user ipaddress protocol event

----------------+-----------+-----------------------+--------------+-----------------------------------------06/10/2009 ope 192.168.2.14 SSH Login Successful

----------------------------------------------------------------------------------------------------------------06/10/2009 admin 192.168.2.14 SSH Login Successful 13:53:14

----------------------------------------------------------------------------------------------------------------06/10/2009 user 192.168.2.14 HTTP Login Successful 13:55:49

-----------------------------------------------------------------------------------------------------------------

13:52:19

- 48-

You can display only access log that corresponded to the specified from following condition.

• timestamp Specify the date by the following format: MM/DD/YYYY

• user Specify the user name.

• ipaddress Specify the IP address on the remote management PC by the following format:

XXX.XXX.XXX.XXX

• protocol Specify the following protocol: HTTP, HTTPS, SSH

• event Specify the following event: normal, error

“normal” means not error event. ”error” means error event.

You can change the displaying sequence of access log and display the specified number of access log by the specified from following options.

• oemnec_headlog <number> Display from <number> head of the access log.

• oemnec_taillog <number> Display from <number> back of the access log.

Enter the following command when you would like to use the above condition.

e.g.1) Display the access log whose username is Administrator.

show user==Administrator

e.g.2) Display the access log whose IP address is 192.168.1.100 and protocol is HTTP and

event is error.

show ipaddress==192.168.1.100,protocol==HTTP,event==error

e.g.3) Display from 100 back of the access log whose timestamp is 10/10/2010 and protocol

is HTTPS.

show –oemnec_taillog 100 timestamp==01/01/2010,protocol==HTTPS

- 49-

Access log might not be correctly displayed with timestamp condition

about the log of recorded from AC ON to DC ON on host system.

Clearing ac cess log

To move the current default target to /admin1/sp1/log1/record1, enter the following command at the command prompt.

cd /admin1/sp1/log1/record1

Enter the following command, if you would like to clear the access log.

delete

Setting acce ss log

To move the current default target to /admin1/sp1/log1, enter the following command at the command prompt.

cd /admin1/sp1/log1

Enter the following command, if you would like to confirm the access log as properties of the access log target which is /admin1/sp1/log1.

show

Enter the following command if you would like to modify a property of the setting access log.

set <Property>=<New value>

The properties which the access log target contains are as follows:

• oemnec_operationlog_enable This specifies whether access log for the system control and the BMC setting

modification via Web browser is enabled. The valid values for this property are "2" and "3". "2" means that the access log is enabled. "3" means that the access log is disabled. This is the dynamic setting.

• oemnec_sshlog_enable This specifies whether access log for login/logout of SSH is enabled. The valid values

for this property are "2" and "3". "2" means that the access log is enabled. "3" means that the access log is disabled. This is the dynamic setting.

• oemnec_httpslog_enable This specifies whether access log for login/logout of HTTP S is enabled. The valid

values for this property are "2" and "3". "2" means that the access log is enabled. "3"

- 50-

means that the access log is disabled. This is the dynamic setting.

• oemnec_httplog_enable This specifies whether access log for login/logout of HTTP is enabled. The valid

values for this property are "2" and "3". "2" means that the access log is enabled. "3" means that the access log is disabled. This is the dynamic setting.

For example, enter the following command when you would like to use the access log for login/logout of HTTPS.

set oemnec_httpslog_enable=2

- 51-

Notice

IPMI command tool, you can use User ID from 6 to 16.

Notice

A user name can contain up to 15 alphanumeric characters, including

except for “ (space)”, ““(quotation marks)”, “&”, “?”, “=”, “¥”, “#”.

Notice

You should set appropriate value to all properties for the user to login

USER SETTINGS

This section describes how to confirm and modify the user account through the command line interface. To move the current default target to an user account target which you would like to confi rm or (and) modify, enter the following command at the command prompt. <N> means any value between 1 and 12: Therefore you can select a user account between account1 and account12. The <N> corresponds to an order from the list of user accounts top on the user account configuration page through a Web browser.

cd /admin1/sp1/account<N>

Enter the following command, if you would like to confirm the information which the selected

user account has as its pr operties.

show

Enter the following command if you would like to modify a property of the selected user account.

set <Property>=<New value>

The properties which the selected user account target contains are as follows:

• UserID This corresponds to a user name (login name). It becomes effective at next login if you

change it.

• UserPassword This is the user password (only can be changed). "UserPassword=" is displayed but

the password setting, value of this property, is not displayed when this property is displayed. It becomes effective at next login if you change it.

• oemnec_Group This specifies the user level. The valid values for this property are "User", "Operator"

and "Administrator". It becomes effective at next login if you change it.

The strings “InternalUseOnly”, “MWA”, “AccessByEM-Poem”, “Administrator” are reserved by BMC. Please do not add or remove these characters as User Name. The user account is synchronized with the IPMI user account. If you want to add or remove users in the

“- (minus)” and “_ (underscore)”. “- (minus)” can not be used for the top of a user name. The password accepts up to 19 ASCII characters,

with it.

- 52-

NETWORK SETTINGS

This section describes how to confirm and modify the network setting for management LAN through the command line interface. To move the current default target to /admin1/sp1/enetport1, enter the following command at the command prompt:

cd /admin1/sp1/enetport1

Enter the following command, if you would like to confirm properties of the Ethernet port target which is /admin1/sp1/enetport1.

show

The properties which the Ethernet port target contains are as follows:

• PermanentAddress This specifies the MAC address for the management LAN. This property is read-only.

• AutoSense This indicates whether Auto Negotiation is enabled for the LAN Connection T y pe

setting of the management LAN. Note that, the valid values for this property are "TRUE" and "FALSE". "TRUE" means that the Auto Negotiation is enabled. "FALSE" means that the Auto Negotiation is disabled. This property is read-only.

• FullDuplex This indicates whether Full Duplex Mode is enabled for the LAN Connection Type

setting of the management LAN when the Auto Negotiation (AutoSense) is disabled (FALSE). The value of this property is not displayed when the Auto Negotiation (AutoSense) is enabled (TRUE). This property is read-only.

• PortType This indicates Link Speed ("10Base-T" or "100Base-TX") for the LAN Connection Type

Followings describe how to confirm and modify the access limitation setting for management LAN through the command line interface. To move the current default target to /admin1/sp1/enetport1/lanendpt1, enter the following command at the command prompt:

cd /admin1/sp1/enetport1/lanendpt1

Enter the following command, if you would like to confirm properties of th e access limitation target which is /admin1/sp1/enetport1/lanendpt1.

show

Enter the following command if you would like to modify a property of the access limitation target.

set <Property>=<New value>

- 53-

Clear all oemnec_allowedaccessips/oemnec_deniedaccessips values, management LAN.

The communication with NEC ESMPRO Manager is also restricted by

Manager.

To r est r i ct access by IP address used by logging in to the BMC's SSH

IP address which is previously used by the BMC's SSH server.

You can set the access restriction settings to 222 characters. The

characters.

The properties which the access limitation target contains are as follows:

• oemnec_allowedaccessips This specifies the IP addresses that permit a ccess to the management LAN. Divide IP

address by "," (ex. 192.168.1.2, 192.168.1.2, …) or use asterisk (ex. 192.168.1.*), if you would like to set multiple permit IP address. Set "0.0.0.0" or no <value> (*) to this property, if you would like to clear the value of this property, It becomes effective at next login if you change it. The value of this property is cleared if oemnec_deniedaccessips is set.

* "Set no <value>" means to input [Enter] key next to "=" key like following example.

set oemnec_allowedaccessips=[Enter]

• oemnec_deniedaccessips This specifies the IP addresses that reject access to the management LAN. Divide IP

address by "," (ex. 192.168.1.2, 192.168.1.2, …) or use asterisk (ex. 192.168.1.*), if you would like to set multiple reject IP address. Set "0.0.0.0" or no <value> (*) to this property, if you would like to clear the value of this property, It becomes effective at next login if you change it. The value of this property is cleared if oemnec_allowedaccessips is set.

* "Set no <value>" means to input [Enter] key next to "=" key like following example.

set oemnec_deniedaccessips=[Enter]

For example, enter the following command when you would like to permit access from

192.168.1.* and 192.168.3.4. set oemnec_allowedaccessips=192.168.1.*,192.168.3.4

if you would like NOT to restrict access by IP address for the

this configuration. Permit the IP address used by the communication with NEC ESMPRO Manager if you would like to use NEC ESMPRO

server is impossible. So, if you would like to restrict the IP address, the following procedures are necessary.

At first, log out of current BMC's SSH session using the IP address and lo g in to the B MC's SSH server once again by using other IP address permitted by oemnec_allowedaccessips / oemnec_deniedaccessips (Access Permission Address) Configuration. Then change the configuration for NOT permitting the

indication by the show command is displayed to 255 characters. The access restriction settings from Web browser are possible to 255

- 54-

Followings describe how to confirm and modify the DHCP setting for management LAN through the command line interface. To move the current default target to /admin1/sp1/enetport1/lanendpt1/ipendpt1, enter the following command at the command prompt:

cd /admin1/sp1/enetport1/lanendpt1/ipendpt1

Enter the following command, if you would like to confirm properties of th e DHCP target which is /admin1/sp1/enetport1/lanendpt1/ipendpt1.

show

Enter the following command if you would like to modify a property of the DHCP target.

set <Property>=<New value>

The properties which the DHCP target contains are as follows:

• AddressOrigin This specifies whether DHCP is enabled for the management LAN. Note that, the valid

values for this property are "3" and "4". "3" means that the DHCP is disabled. "4" means that the DHCP is enabled. This is the dynamic setting.

• IPv4Address This specifies the IP address for the management LAN. This property is read-only.

• SubnetMask This specifies the subnet mask for the management LAN. This property is read-only.

For example, enter the following command when you would like to enable DHCP. set AddressOrigin=4

Followings describe how to confirm the gateway setting for management LAN through the command line interface. To move the current default target to /admin1/sp1/enetport1/lanendpt1/ipendpt1/gateway1, enter the following command at the command prompt:

cd /admin1/sp1/enetport1/lanendpt1/ipendpt1/gateway1

Enter the following command, if you would like to confirm properties of th e gateway target which is /admin1/sp1/enetport1/lanendpt1/ipendpt1/gateway1.

show

The properties which the gateway target contains are as follows:

• InfoFormat The value is "3". This specifies the AccessInf o is IPv4 address. This property is

read-only.

- 55-

• AccessInfo This specifies the IP address of the default gateway for the management LAN. This

property is read-only.

Followings describe how to confirm and modify the network setting with disabling DHCP for management LAN through the command line interface. To move the current default target to /admin1/sp1/enetport1/lanendpt1/ipendpt1/staticipsettings1, enter the following command at the command prompt:

cd /admin1/sp1/enetport1/lanendpt1/ipendpt1/staticipsettings1

Enter the following command, if you would like to confirm properties of th e static network setting target which is /admin1/sp1/enetport1/lanendpt1/ipendpt1/staticipsettings1.

show

Enter the following command if you would like to modify a property of the static network setting target.

set <Property>=<New value>

The properties which the static network setting target contains are as follows:

• IPv4Address This specifies the IP address for the management LAN when DHCP is disabled. This

is the dynamic setting.

• SubnetMask This specifies the subnet mask for the management LAN when DHCP is disabled.

This is the dynamic setting.

• GatewayIPv4Address This specifies the IP address of the default gateway for the management LAN when

DHCP is disabled. This is the dynamic setting

Followings describe how to confirm and modify the HTTP service for management LAN through the command line interface. To move the current default target to /admin1/sp1/httpsvc1, enter the following command at the command prompt:

cd /admin1/sp1/httpsvc1

Enter the following command, if you would like to confirm properties of th e HTTP servi ce target which is /admin1/sp1/httpsvc1.

show

Enter the following command if you would like to modify a property of the HTTP service target.

- 56-

set <Property>=<New value>

The properties which the HTTP service target contains are as follows:

• EnabledState This specifies whether HTTP port is enabled for the management LAN. The valid

values for this property are "2" and "3". "2" means that the HTTP port is enabled. "3" means that the HTTP port is disabled. This is the dynamic setting.

• oemnec_httpport This specifies the HTTP port for the management LAN. This is the dynamic setting.

Followings describe how to confirm and modify the HTTPS service for management LAN through the command line interface. To move the current default target to /admin1/sp1/httpssvc1, enter the following command at the command prompt:

cd /admin1/sp1/httpssvc1

Enter the following command, if you would like to confirm properties of th e HTTPS service target which is /admin1/sp1/httpssvc1.

show

Enter the following command if you would like to modify a property of the HTTPS service target.

set <Property>=<New value>

The properties which the HTTPS service target contains are as follows:

• EnabledState This specifies whether HTTPS port is enabled for the management LAN. The valid

values for this property are "2" and "3". "2" means that the HTTPS port is enabled. "3" means that the HTTPS port is disabled. This is the dynamic setting.

• oemnec_httpsport This specifies the HTTPS port for the management LAN. This is the dynamic setting.

Followings describe how to confirm and modify the SSH service for management LAN through the command line interface. To move the current default target to /admin1/sp1/sshsvc1, enter the following command at the command prompt:

cd /admin1/sp1/sshsvc1

Enter the following command, if you would like to confirm properties of the SSH service target which is /admin1/sp1/sshsvc1.

show

- 57-

Enter the following command if you would like to modify a property of the SSH service target.

set <Property>=<New value>

The properties which the SSH service target contains are as follows:

• EnabledState This specifies whether SSH por t is enabled for the management LAN. The valid

values for this property are "2" and "3". "2" means that the SSH port is enabled. "3" means that the SSH port is disabled. This is the dynamic setting.

• oemnec_sshport This specifies the SSH port for the management LAN. This is the dynamic setting.

- 58-

The user must have an account as administrator for controlling the power consumption.

POWER CONSUMPTION CONTROL

You can control the power consumption of the host system through the command line interface.

To move the current default target to /admin1/system1, enter the following command at the command prompt:

cd /admin1/system1

State confirmation and modification of Power Consumption Control

Enter the following command, if you would like to confirm properties related to the power consumption.

show

Enter the following command if you would like to modify a property related to the power consumption.

set <Property>=<New value>

The properties related to power consumption on /admin1/system1 are as follows. The “()” of the property name is a property name in the specific product. “oemnec_ProcessorCoreDisableMax”, “oemnec_ProcessorCoreDisable”, “oemnec_BootPerfomanceOptimized”, “oemnec_BootTimeConfig”, “oemnec_NonAggressiveModeCorrectionTimeLimit”, “oemnec_NonAggressiveModeCapvalue”, “oemnec_NonAggressiveModeSetableCapvalue”, “oemnec_NonAggressiveMode” don’t display at specific product:

• EnabledState The value is always "2".This specifies whether SSH port is enabled for the

management LAN. This property is read-only.

• oemnec_SafePowerCapping This specifies whether fault check of the power consumption sensor is enabled. The

valid values for this property are "enabled" and "disabled". "enabled" means that the fault check is enabled. "disable" means that t he fault check is disabled. Default setting is "disabled".

• oemnec_ProcessorCoreDisableMax This specifies Max Core number which can be set from

oemnec_ProcessorCoreDisable property. This property is not displayed if oemnec_BootTimeConfig is disabled.

• oemnec_ProcessorCoreDisable This specifies the number of CPU core to disable. This is the dynamic setting. This

property is not displayed if oemnec_BootTimeConfig is disabled.

- 59-

• oemnec_BootPerformanceOptimized This specifies whether Performance Optimized mode is enabled. This is the dynamic

setting. This property is not displayed if oemnec_BootTimeConfig is disabled.

• oemnec_BootTimeConfig This specifies whether BootingMode is enabled. This is the dynamic setting. Default

value is “disabled”. This property supported by specific product.

• oemnec_NonAggressiveModeCorrectionTimeLimit Specify the maximum time to take corrective actions in order to bring the system

power consumption back to the specified ‘Power Threshold (Pn)’ before generating System Event Log and sending alert. This is the dynamic setting. This property is not displayed if oemnec_NonAggressiveMode is disabled.

• oemnec_NonAggresiveModeCapvalue This specifies the value of the power consumption starting he power consumption

control. This is the dynamic setting. This property is not displayed if oemnec_NonAggressiveMode is disabled.

• oemnec_NonAggressiveModeSetableCapvalue This specifies the value range of the settable oemnec_NonAggressiveModeCapvalue.

This property is read-only. This property is not displayed if oemnec_NonAggressiveMode is disabled.

• oemnec_NonAggressiveMode Non-Aggressive Mode brings the system power consumption under the specified

upper limit threshold without extremely decreasing system performance. The valid values for this property are "enabled" and "disabled". "enabled" means that the power control is enabled. "disable" means that the power control is disabled. Default setting is "disabled".

• oemnec_ExceptionAction_Shutdown_Enable This specifies whether the shutdown function of the system is enabled when power

consumption control is of no effect within a given oemnec_AggressiveModeCorrectionTimeLimit after the power consumption pass oemnec_AggressiveModeCapvalue. The valid values for this property are "enabled" and "disabled". "enabled" means that the shutdown function is enabled. "disable" means that the shutdown function is disabled. This is the dynamic setting. This property is not displayed if oemnec_AggressiveMode is disabled.

• oemnec_AggressiveModeCorrectionTimeLimit (oemnec_CorrectionTimeLimit) The shutdown of the system will be done according to setting of

oemnec_ExceptionAction_Shutdown_Enable when power consumption control is of no effect within a given oemnec_AggressiveModeCorrectionTimeLimit (seconds) after the power consumption pass oemnec_AggresiveModeCapvalue. This is the dynamic setting. This property is not displayed if oemnec_AggressiveMode is disabled.

• oemnec_AggresiveModeCapvalue (oemnec_PowerCapvalue)

- 60-

Notice

The system performance, such as frequency of CPU, decreases for

This specifies the value of the power consumption starting he power consumption control. This is the dynamic setting. This property is not displayed if oemnec_AggressiveMode is disabled.

• oemnec_AggressiveModeSetablePowerCapvalue (oemnec_setablePowerCapvalue) This specifies the value range of the settable oemnec_AggressiveModeCapvalue.

This property is read-only. This property is not displayed if oemnec_AggressiveMode is disabled.

• oemnec_AggressiveMode (oemnec_CriticalPowerCapSensor) This specifies whether the power consumption control under the specified upper limit

threshold is enabled. The valid values for this property are "enabled" and "disabled". "enabled" means that the power control is enabled. "disable" means that the power control is disabled. Default setting is "disabled".

reducing power consumption when the power control is enabled.

- 61-

The values of the properties for items not supported by the host

a power supply and mounting such as a device of the system either.

CONFIRMING SYSTEM INFORMATION

This section describes how to confirm the system information (product, BIOS/BMC firmware revision, MAC address of System LAN, CPU, Memory) through the command line interface.

system is not displayed for the system information. Moreover, the values of the properties for items supported with the host system might not be displayed the system information according to a state of

Confirming Product Information

You can confirm the product information through the command line interface by entering following the basic command at the command prompt.

show /admin1/system1

In this case, value of oemnec_productname property indicates "Product Name" information at the "Properties" section. Also value of oemnec_modelnumber property indicates "Part / Model Number" information and value of oemnec_serialnumber property indicates "Product Serial Number" information. These properties for the product information are read-only.

Confirming MAC address of System LAN

To move the current default target to /admin1/system1, enter the following command at the command prompt.

cd /admin1/system1

Here, to confirm all the targets for System LAN (onboard LAN), enter the following command at the command prompt. All the System LAN targets are represented as enetport<N> strings at "Targets" section. <N> means value of one-origin integer.

show

Next, when the following command is input, the MAC address of the System LAN target is appeared at the right side of "PermanentAddress=" string. <N> means the number of the System LAN target which you would like to confirm.

show enetport<N>

For example, enter the following command when you would like to confirm the MAC address of LAN P ort1.

show enetport1

- 62-

Confirming System BIOS revision

You can confirm the System BIOS revision through the command line interface by entering following the basic command at the command prompt.

show /admin1/system1/swid1

In this case, the System BIOS revision is appeared at the right side of "VersionString=" string in the "Properties" section.

Confirming BMC firmware revision

You can confirm the BMC firmware revision through the command line interface by entering following the basic command at the command prompt.

show /admin1/sp1/swid1

In this case, the BMC firmware revision is appeared at the right side of "VersionString=" string in the "Properties" section. Also the SDR revision is appeared at the right side of " oemnec_sdrversion =" string.

Confirming CPU Information

To move the current default target to /admin1/system1, enter the following command at the command prompt.

cd /admin1/system1

Here, to confirm all the targets for CPU, enter the following command at the command prompt. All the CPU targets are represented as cpu<N> strings at "Targets" section. <N> means value of one-origin integer.

show

Next, when the following command is input, information of a specific CPU target is displayed at "Properties" section. Here, <N> means CPU target number which you would like to confirm.

show cpu<N>

The EnabledState property of the CPU target indicates the CPU status. "2" indicates CPU installed. No value (Only "EnabledState=" string is displayed.) indicates CPU not installed. "3" indicates that the CPU is defected. The values of the other properties (such as oemnec_clock) are not displayed (Only property name with "=" string is displayed.). if the CPU is not installed (Only "EnabledState=" string is displayed.). Also, the values of the properties not supported by the host system are not displayed.

- 63-

For example, enter the following command when you would like to confirm the infor mation of CPU1.

show cpu1

The example of displaying information in this case is shown below. ufip=/admin1/system1/cpu1

Properties:

EnabledState=enabled oemnec_clock=2660MHz oemnec_validcore=4 oemnec_maxcore=4 oemnec_validthread=8 oemnec_maxthread=8 oemnec_l1cache=256KB oemnec_l2cache=1024KB oemnec_l3cache=8192KB

Verbs:

cd exit help show version

- 64-

Confirming Memory Information

To move the current default target to /admin1/system1, enter the following command at the command prompt.

cd /admin1/system1

Here, to confirm all the targets for memory (DIMM), enter the following command at the command prompt. All the memory (DIMM) targets are represented as memory<N> strings at "Targets" section. <N> means value of one-origin integer.

show

Next, when the following command is input, information of a specific memory (DIMM) target is displayed at "Properties" section. Here, <N> means memory (DIMM) target number which you would like to confirm.

show memory<N>

The EnabledState property of the memory target indicates the memory (DIMM) status. "2" indicates memory (DIMM) installed. "3" indicates memory (DIMM) error. If the memory (DIMM) is not installed the target will not be displayed. Also, the values of the properties not supported by the host system are not displayed.

For example, enter the following command when you would like to confirm the information of memory1 (CPU1_DIMM1).

show memory1

The example of displaying information in this case is shown below. ufip=/admin1/system1/memory1

Properties:

enabledstate=2 oemnec_slotname=CPU1_DIMM1 oemnec_clocksize=1024MB 1066MHz

Verbs:

cd exit help show version

- 65-

Commands to acquire the state are executable in all user levels.

SPECIAL EXTENDED COMMANDS

This section describes the special extended command which can do state acquisition (powerstate, lampstate) and interrupt generation for OS dump (nmidump). The special extended commands use the syntaxes different from the basic command's ones.

S tate Acqui sition

You can acquire the state of the system at the command prompt:

Power State acquisition

Power state acquisition command (powerstate) is executable only when current default target is "/admin1" or "/admin1/system1".

Enter the following command, if the current default target is not "/admin1" and "/admin1/system1".

cd /admin1

cd /admin1/system1

Enter the following command at the command prompt:

powerstate

One of the following responses is returned according to the power state.

power on

System power is on.

power off

System power is off.

Lamp State acquisition

Lamp state acquisition command (lampstate) is executable only when current default target is "/admin1", "/admin1/system1" or “/admin1/system1/led1”.

Enter the following command, if the current default target is not "/admin1", "/admin1/system1" or “/admin1/system1/led1”.

cd /admin1

cd /admin1/system1

cd /admin1/system1/led1

- 66-

The state of the STATUS LED and the meaning are different according to the system. Refer to the User’s Guide of the system for details.

If the UID LED is not mounted into the host system, the “UID LED

the description of the UID LED.

Status LED state acquisition

Enter the following command at the command prompt:

lampstate -statuslamp

One of the following responses is returned according to the ST ATUS LED state.

off

STATUS LED is turned off.

green on

STATUS LED lights in green.

green blink

STATUS LED is blinking in green.

amber on

STATUS LED lights in amber.

amber blink

STATUS LED is blinking in amber.

red on

STATUS LED lights in red.

red blink

STATUS LED is blinking in red.

UID LED State acquisition

Enter the following command at the command prompt:

lampstate -uidlamp

One of the following responses is returned according to actual display state of the UID LED.

off

UID LED is turned off.

UID LED is turned on (lights).

blink

UID LED is blinking (flashing ).

State acquisition” function works only to the virtual UID LED of the Server Panel. Please refer to the User’s Guide of your host system for

- 67-

Notice

The user must have an account as operator or administrator for

The above command behavior is equivalent to pressing the DUMP

Interrupt Generation for OS Dump

You can execute OS dump by entering following command at the command prompt.

nmidump /admin1/system1

executing the nmidump command.

switch on the host system.

- 68-

EXPRESSSCOPE Engine 3 implementation of WS-Management

1.0.0.

EXPRESSSCOPE Engine 3 is confirmed the WS-Management operation

Windows Remote Management (WinRM) 2.0

Notice

To use WS-Management, you need to configure HTTPS connection to 2: Configuring the Host System”.

The user must have an account as operator or administrator for power control.

Notice

Performing power control when the operating system is running may

7. WS-Management (Web Service for Management)

OVERVIEW

With the WS-Management Protocol, you can control the host system and check the sensor of host system.

complies with the specification, DTMF Web Services for Management

with the following tools that support the WS-Management protocol.

•

be enabled. Refer to the “Management LAN Settings” in the “Chapter

POWER CONTROL

You can perform power control of the host system.

cause the loss of data in the host system.

- 69-

Please change according to your environment.

Engine 3.

Power ON

Create the file input-RequestPowerStateChange2.xml and enter the following command, if you use WinRM.

winrm invoke RequestPowerStateChange “http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_PowerManagementSer vice?__cimnamespace=root/cimv2+Name=Host Power Management Service+CreationClassName=CIM_PowerManagementService+SystemName=Unkn own.IPMI_BMC_DeviceID.136+SystemCreationClassName=CIM_HostComputerSyst em” -r:https://IP_ADDRESS/wsman -username:USERNAME -password:PASSWORD

-auth:basic -encoding:utf-8 -format:xml -file:input-RequestPowerStateChange2.xml

-skipCAcheck -skipCNcheck -skipRevocationcheck input-RequestPowerStateChange2.xml <n1:RequestPowerStateChange_INPUT

xmlns:n1="http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Power ManagementService" xmlns:wsa="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:wsman="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <n1:PowerState>2</n1:PowerState> <n1:ManagedElement> <wsa:ReferenceParameters> <wsman:ResourceURI>http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/ CIM_HostComputerSystem</wsman:ResourceURI> <wsman:SelectorSet> <wsman:Selector Name='__cimnamespace'>root/cimv2</wsman:Selector> <wsman:Selector Name='CreationClassName'>CIM_HostComputerSystem</wsman:Selector> <wsman:Selector Name='Name'>Unknown.IPMI BMC DeviceID.136</wsman:Selector> </wsman:SelectorSet> </wsa:ReferenceParameters> </n1:ManagedElement> </n1:RequestPowerStateChange_INPUT>

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

Forced Power OFF

Create the file input-RequestPowerStateChange6.xml and enter the following command, if you use WinRM.

- 70-

Please change according to your environment.

Engine 3.

own.IPMI_BMC_DeviceID.136+SystemCreationClassName=CIM_HostComputerSyst em” -r:https://IP_ADDRESS/wsman -username:USERNAME -password:PASSWORD

-auth:basic -encoding:utf-8 -format:xml -file:input-RequestPowerStateChange6.xml

-skipCNcheck -skipCAcheck -skipRevocationcheck input-RequestPowerStateChange6.xml <n1:RequestPowerStateChange_INPUT

xmlns:n1="http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Power ManagementService" xmlns:wsa="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:wsman="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <n1:PowerState>6</n1:PowerState> <n1:ManagedElement> <wsa:ReferenceParameters> <wsman:ResourceURI>http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/ CIM_HostComputerSystem</wsman:ResourceURI> <wsman:SelectorSet> <wsman:Selector Name='__cimnamespace'>root/cimv2</wsman:Selector> <wsman:Selector Name='CreationClassName'>CIM_HostComputerSystem</wsman:Selector> <wsman:Selector Name='Name'>Unknown.IPMI BMC DeviceID.136</wsman:Selector> </wsman:SelectorSet> </wsa:ReferenceParameters> </n1:ManagedElement> </n1:RequestPowerStateChange_INPUT>

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

- 71-

The above OS shutdown is equivalent to pressing the POWER switch must be set to shut down when you power off the system.

Please change according to your environment.

Engine 3.

OS Shutdown

Create the file input-RequestPowerStateChange8.xml and enter the following command, if you use WinRM.

-auth:basic -encoding:utf-8 -format:xml -file:input-RequestPowerStateChange8.xml

-skipCAcheck -skipCNcheck -skipRevocationcheck input-RequestPowerStateChange8.xml <n1:RequestPowerStateChange_INPUT

xmlns:n1="http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Power ManagementService" xmlns:wsa="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:wsman="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <n1:PowerState>8</n1:PowerState> <n1:ManagedElement> <wsa:ReferenceParameters> <wsman:ResourceURI>http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/ CIM_HostComputerSystem</wsman:ResourceURI> <wsman:SelectorSet> <wsman:Selector Name='__cimnamespace'>root/cimv2</wsman:Selector> <wsman:Selector Name='CreationClassName'>CIM_HostComputerSystem</wsman:Selector> <wsman:Selector Name='Name'>Unknown.IPMI BMC DeviceID.136</wsman:Selector> </wsman:SelectorSet> </wsa:ReferenceParameters> </n1:ManagedElement> </n1:RequestPowerStateChange_INPUT>

when the power of the host system is on. Your operating system

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

- 72-

Please change according to your environment.

Engine 3.

System Reset

Create the file input-RequestPowerStateChange10.xml and enter the following command, if you use WinRM.

winrm invoke RequestPowerStateChange “http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_PowerManagementServic e?__cimnamespace=root/cimv2+Name=Host Power Management Service+CreationClassName=CIM_PowerManagementService+SystemName=Unknown .IPMI_BMC_DeviceID.136+SystemCreationClassName=CIM_HostComputerSystem”

-r:https://IP_ADDRESS/wsman -username:USERNAME -password:PASSWORD

-auth:basic -encoding:utf-8 -format:xml -file:input-RequestPowerStateChange10.xml

-skipCAcheck -skipCNcheck -skipRevocationcheck input-RequestPowerStateChange10.xml <n1:RequestPowerStateChange_INPUT

xmlns:n1="http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Power ManagementService" xmlns:wsa="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:wsman="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <n1:PowerState>10</n1:PowerState> <n1:ManagedElement> <wsa:ReferenceParameters> <wsman:ResourceURI>http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/ CIM_HostComputerSystem</wsman:ResourceURI> <wsman:SelectorSet> <wsman:Selector Name='__cimnamespace'>root/cimv2</wsman:Selector> <wsman:Selector Name='CreationClassName'>CIM_HostComputerSystem</wsman:Selector> <wsman:Selector Name='Name'>Unknown.IPMI BMC DeviceID.136</wsman:Selector> </wsman:SelectorSet> </wsa:ReferenceParameters> </n1:ManagedElement> </n1:RequestPowerStateChange_INPUT>

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

- 73-

The above command behavior is equivalent to pressing the DUMP switch on the host system.

Change according to your environment.

Engine 3.

Notice

Performing interrupt generation for OS dump when the operating

Interrupt Generation for O S Dump

Create the file input-RequestPowerStateChange11.xml and enter the following command, if you use WinRM.

winrm invoke RequestPowerStateChange “http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_PowerManagementServic e?__cimnamespace=root/cimv2+Name=Host Power Management Service+CreationClassName=CIM_PowerManagementService+SystemName=Unknown .IPMI_BMCDeviceID.136+SystemCreationClassName=CIM_HostComputerSystem”

-r:https://IP_ADDRESS/wsman -username:USERNAME -password:PASSWORD

-auth:basic -encoding:utf-8 -format:xml -file:input-RequestPowerStateChange11.xml

-skipCAcheck -skipCNcheck -skipRevocationcheck input-RequestPowerStateChange11.xml <n1:RequestPowerStateChange_INPUT

xmlns:n1="http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Power ManagementService" xmlns:wsa="http://schemas.xmlsoap.org/ws/2004/08/addressing" xmlns:wsman="http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd"> <n1:PowerState>11</n1:PowerState> <n1:ManagedElement> <wsa:ReferenceParameters> <wsman:ResourceURI>http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/ CIM_HostComputerSystem</wsman:ResourceURI> <wsman:SelectorSet> <wsman:Selector Name='__cimnamespace'>root/cimv2</wsman:Selector> <wsman:Selector Name='CreationClassName'>CIM_HostComputerSystem</wsman:Selector> <wsman:Selector Name='Name'>Unknown.IPMI BMC DeviceID.136</wsman:Selector> </wsman:SelectorSet> </wsa:ReferenceParameters> </n1:ManagedElement> </n1:RequestPowerStateChange_INPUT>

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

system is running may cause the loss of data in the host system.

- 74-

- 75-

Change according to your environment.

Engine 3.

SENSOR INFORMATION

You can get sensor information either by enumeration of all sensors or by retrieving specified sensor.

Enumeration of All Sensors

Enter the following command, if you enumerate numeric sensors (e.g.: temperature, voltage) with WinRM.

winrm enumerate http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_NumericSensor

-username:USERNAME -password:PASSWORD -r:https://IP_ADDRESS/wsman

-auth:basic -encoding:utf-8 -skipCAcheck -skipCNcheck -skipRevocationcheck

Enter the following command, if you enumerate non-numeric sensors (e.g.: PSU, HDD) with WinRM.

winrm enumerate http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_Sensor

-username:USERNAME -password:PASSWORD -r:https://IP_ADDRESS/wsman

-auth:basic -encoding:utf-8 -skipCAcheck -skipCNcheck -skipRevocationcheck

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

Retrieving Specified Sensor

You can retrieve the sensor by specifying sensor number. Enter the following command, if you retrieve the sensor of sensor number 48 with the

WinRM.

winrm get "http://schemas.dmtf.org/wbem/wscim/1/cim-schema/2/CIM_NumericSensor?Syste mCreationClassName=CIM_ComputerSystem+CreationClassName=CIM_NumericS ensor+SystemName=Unknown.IPMI BMC DeviceID.136+DeviceID=1.48.0.136.1.99"

-r:https://IP_ADDRESS/wsman -username:USERNAME -password:PASSWORD

-auth:basic -encoding:utf-8 -skipCAcheck -skipCNcheck -skipRevocationcheck

- 76-

Change according to your environment.

Engine 3.

Specify the “Device ID” returned in the response of enumerating all

“IP_ADDRESS” : IP address of EXPRESSSCOPE Engine 3. “USERNAME/PASSWORD”: username/password of EXPRESSSCOPE

sensors.

- 77-

8. Troubleshooting

ERROR MESSAGES

Abnormality occurs while using remote management, and the error dialog might be displayed in management PC. Please refer to the list of the message of the online help for the main message and the coping process.

ABOUT ECO SETTING

The electric power value may not be reached to Power Cap Value.  The electric power value might not necessarily reach even the value of Power Cap value. The electric power control lowers the power consumption of the system by lowering the frequency of CPU/Memory. When CPU/Memory Throttling value reaches 100%, the electric power value doesn't fall any more.

“Failed to access BMC.” error has occurred while executing ECO setting.  If you execute ECO setting during shutdown the OS of the host system, ECO setting may not be set correctly. I n this case, please execute again after shutdown process is finished.

For more detail about the Power Monitoring and Power Control Function, please reference the following site.

http://www.58support.nec.co.jp/global/download/index.html [Others] - [Technology papers]

ABOUT NETWORK INFORMATION

Please note that the “Link stat us”(*) may not be displayed correctly depending on the O S of the host sys tem, because the link status of the system LAN can not get properly depending on the version of the LAN drivers that are used by the OS. (*) [System] - [Component] - [Network] - [System LAN Information]

OTHERS TIPS

Should you have troubles while using the BMC for remote control, monitoring, and management of the host system, please first check the system according to the online help to troubleshoot your issue prior to sending it for repair.

For the issues regarding your system operation, please refer to the User’s Guide attached to your system.

If your issue is not described below, or should the provided instructions do not resolve your

- 78-

issue, please contact your service center.

- 79-

License Notes

This product includes open source software programs described below.

GNU General Public License

• Busybox

• Linux Kernel

• U-Boot

• stunnel

GNU GENERAL PUBLIC LICENSE Version 2, June 1991

Copyright (C) 1989, 1991 Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program whose authors commit to using it. (Some other Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free p rograms; and that you know you can do these things.

To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to c e r tain responsibil ities for you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make s ure that they, too, receive or can get the source code. And you mus t show them t hese terms so they know their rights.

We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal p ermission to copy, distribute and/or modify the software.

Also, for each author's protection and ours, we want to make certain that ever yone understa nds that there is no warranty for this free

- 80-

software. If the software is modified by someone else and passed on, we want its recipients to know that wha t they have i s not the original, so that any problems introduced by other s will not reflect on the original authors' reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program wil l individua lly obtain p atent licenses, in effec t making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all.

The precise terms and conditions for copying, distribution and modification follow.

GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program" means eithe r the Program or any derivative work under copyright law: that is to say, a work containing the Pr ogram or a portion of it, either verbatim or with modifications and/or translated into another language. (Hereinafter, translation is included without limitation in the term "modification".) Each licensee is addressed as "you".

Activities other than copying, distribution and modification are no t covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output fro m the Program is covered only if its co ntents constitute a work based on the Program (independent of having be en made by running the Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such modifications o r wor k u nde r the terms of Section 1 above, provided that you also meet all of these conditions:

a) You must cause the modified files to carry prominent notices stating that you changed t he files and t he date of any change.

b) You must cause any work t hat you distri bute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License.

- 81-

c) If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announceme nt including an appropriate copyright notice a nd a notice that there is no warranty (or else, sa yin g tha t you provide a warranty) and that users may redistribute the program under these conditions, and telling the use r how to view a copy of thi s License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Program, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections whe n you di str ib ute them as separate wor ks. But when you distribute the same sections as part of a whole which is a work based on the Program, the distribution o f t he whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to cla im rights or contest your rights to work written entire ly by you; rather, the intent is to exercise the right to control the d istr ibution of derivative or collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Pr ogram (or with a work ba sed on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following:

a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software inter change; or ,

b) Accompany it with a written offer, valid for a t le a st three years, to give any third pa rty, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,

c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definitio n files, plus the scripts used to control compilation and installation of the executable. However, as a special exception, the source code distributed need not include

- 82-

anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though t hird partie s are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you under this License will not have their licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distrib ute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other rea son (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneo usly your obligations under this License and any other pertinent obligations, then as a cons equence you may not distribute the Program at all. For example, if a patent license would not permit royalt y-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only wa y you could satisfy bot h it and this License would be to refrain entirely from distributi on of the Program.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intende d to apply in other circumstances.

It is not the purpose of this section t o induce you to infringe any patents or other property right c la ims or to contest validity of any such claims; this section has the sole purpose of protecting t he integrity of the free software distribution system, which is

- 83-

implemented by public license practices. Many people have made generous contributions to the wide range of software distributed through that system in reliance o n consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thor oughly clear what is believed to be a consequence of the rest of this License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who pla ces the Program under this License may add an explicit geographica l distribution limitation excluding those countries, so that distrib ution is permitted only in or among countries not thus excluded. In suc h case, this Li cense incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be similar in spirit to the present ver sion, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation. If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the shari ng and reuse of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIE S PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIE S OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR COR RECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR D AM AGE S, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTI AL DAM AGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER

- 84-

PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the be st way to achieve this is to make it free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively convey the exclusion o f warranty; and each file s hould have a t least the "copyright" line and a pointer to where the full notice is found.

<one line to gi ve the program's name and a brief idea of what it does.> Copyright (C) <year> <name of author>

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation; either version 2 of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA.

Also add information on how to contact you by electronic and paper mail.

If the program is interactive, make it output a short notice like this when it starts in an interactive mode :

Gnomovision version 69, Copyright (C) year name of author Gnomovision comes with ABSOLUTELY NO WARRANTY; for details type `show w'. This is free software, and you are welcome to redistribute it under certain conditions; type `show c' for de ta ils.

The hypothetical com mands `show w' and `show c' should show the appropriate parts of the General Public License. Of course, the commands you use may be called s omething other than `show w' and `show c'; they could even be mouse-clicks or menu items--whatever suits your program.

You should also get your employer ( i f you work as a programmer) or your school, if any, to sign a "copyright disclaimer" for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the program `Gnomovision' (which makes passes at compilers) written by James Hacker.

<signature of Ty Coon>, 1 April 1989 Ty Coon, President of Vice

- 85-

This General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications wit h the library. If this is what you want to do, use the GNU Lesser General Public License instead of this License.

GNU Lesser Ge neral Public Licsense

• glibc

GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999

Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

[This is the first released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2, hence the version number 2.1.]

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public Licenses are intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users.

This license, the Lesser General Public License, applies to some specially designated software packages--typically libraries--of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully about whe ther this license or the ordinary General Public License is the better strategy to use in any particular case, based on the explanations below.

When we speak of free software, we are referring to freedom of use, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive source code or can get it if you want it; that you can change the software and use pieces of it in new free programs; and that you are infor med that you ca n do these thing s .

To protect your rights, we need to make restrictions that forbid distributo rs to deny you these rights or to ask you to surrender these rights. These re str ic tions translate to certain responsibili ties for you if you distribute copies of the libra ry or if you modify it.

For example, if you distribute copie s o f the libr a ry, whether gratis or for a fee, you must give the recipie nts all the rights that we ga ve you. You must make sure that they, too, receive or can get the source code. If you link other code with the library, you must provide complete object files to the recipie nts, so that they can relink them with the library after making changes to the library and recompiling it. And you must show them these ter ms s o they know their rights.

- 86-

We protect your rights wit h a two-step method: (1) we copyright the library, and (2) we offer you this license, which g ives you legal permission to copy, distribute and/or modify the library.

To protect each distributor, we want to make it very clear that there is no warranty for the free libr a ry. Also, if the library is modified by someone else and passed on, the recipients should know that what they have is not the original ve rsion, so tha t the origi nal author's reputation will not be affected b y pro blems that might be introduced by others.

Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the ful l freedom of use specified in this license.

Most GNU software, including some libraries, is covered by the ordinary GNU General Public License. This license, the GNU Lesser General Public License, applies to certain designated libraries, and is quite different from the ordinary General Public License. We use this license for certain librarie s in or der to permit linking those libraries into non-free programs.

When a program is linked with a library, whether statically or using a shared library, the combination of the two is legally speaki ng a combined work, a derivative of the original library. The ordinary General Public License therefore permits such linking only if the entire combination fits its criteria of freedom. The Lesser General Public License permits more lax criteria for linking other code with the library.

We call this license the "Lesser" General Public License because it does Less to protect the user's freedom than the ordinary General Public License. It also provides other free software developers Less of an advantage over competing non-free programs. These disadvantages are the reason we use the ordinary General Public License for many libraries. However, the Lesser license provides advantages in certain special circumstances.

For example, on rare occasions, there may be a special need to encourage the widest possible use of a certain library, so that it becomes a de-facto standard. To achieve this, non-free programs must be allowed to use the library. A more frequent case is that a free library does the same job as widely used non-free libraries. In this case, there is little to gain by limitin g the free library to free software only, so we use the Lesser General Public License.

In other cases, permission to use a particular library in non-free programs enables a greater number of people to use a large body of free software. For example, permission to use the GNU C Library in non-free programs enables many more people to use the whole GNU operating system, as well as its variant, the GNU/Linux operating system.

Although the Lesser General Public License is Less protective of the users' freedom, it does ensure that the user of a program that is

- 87-

linked with the Library has the freed om and the wherewithal to run that program using a modified version of the Library.

The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference between a "work based on the libra ry" and a "work that uses the library". The former contains code derived from the library, whereas the latter must be combined with the library in order to run.

GNU LESSER GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License Agreement applies to any software library or other program which contains a notice placed by the copyright holder or other authorized party saying it may be distributed under the terms of this Lesser General Public License (a lso c a lle d "this License"). Each licensee is addressed as "you".

A "library" means a collection of software functions and/or data prepared so as to be conveniently linked with application programs (which use some of those functions and data) to form executables.

The "Library", below, refers to any such software library or work which has been distributed under these terms. A "work based on the Library" means either the Library or any derivative work under copyright law: that is to say, a work containing the Library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term "modification".)

"Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilatio n and installation of the library.

Activities other than copying, distr ibution and modification are not covered by this License; they are outside its scope. The act of running a pr ogram using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing it). Whether that is true de pends on what the Library does and what the program that uses the Library does.

1. You may copy and distribute verbatim copies of the Library's complete source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and distribute a copy of t his License along with the Library.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.

2. You may modify your copy or copies of the Library or any portion of it, thus forming a work based on the Library, and copy and

- 88-

distribute such modifications o r wor k u nde r the terms of Section 1 above, provided that you also meet all of these conditions:

a) The modified work must itself be a software library.

b) You must cause the files modified to carry prominent notices stating that you changed t he files and t he date of any change.

c) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this Lice ns e .

d) If a facility in the modified Library refers to a function or a table of data to be supplied by an application program that uses the facility, other than as an argument passed when the facility is invoked, then you must make a good fait h effort to ensure that, in the event an a pplication does not s upply such f unction or table, the facility still operates, and per forms whatever part of its purpose remains meaningful.

(For example, a function in a library to compute square roots has a purpose that is entirely well-defined independent of the application. Therefore, Subsection 2d requires that any application-supplied function or table used by this function must be optional: if the application does not supply it, the square root function must still compute square roots.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the Library, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections whe n you di str ib ute them as separate wor ks. But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to c laim rights or contest your rights to work written entire ly by you; rather, the intent is to exercise the right to control the d istr ibution of derivative or collective works based on the Library.

In addition, mere aggregation of another work not based on the Library with the Library (or with a work based on the Library) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

3. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the Library. To do this, you must alter all the notices that refer to this License, so that they refer to the ordinary GNU General Public License, version 2, instead of to this License . (If a newe r version than version 2 of the ordinary GNU General Public License has appeared, then you can specify that versio n instead if you wish.) Do not make any other change in these notices.

Once this change is made in a given co py, it is irreversible for that copy, so the ordinary GNU General Public License applies to all

- 89-

subsequent copies and derivative works made from that copy.

This option is useful when you wish to copy part of the code of the Library into a program that is not a library.

4. You may copy and distribute the Library (or a portion or derivative of it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange.

If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are not compelled to copy the source along with the object code.

5. A program that contains no derivative of any portion of the Library, but is designed to work with the Library by being compiled or linked with it, is called a "work that uses the Library". Such a work, in isol ation, is not a derivative work of t he Library, and therefore falls outside the scope of this License.

However, linking a "work that uses the Library" with the Library creates an executable that is a derivative of the Library (because it contains portions of the Library), rather tha n a "work that uses the library". The executable is therefore covered by this License. Section 6 states terms for distr ibution of such executables.

When a "work that uses the Library" uses material from a header file that is part of the Library, the object code for the work may be a derivative work of the Library even though the source code is not. Whether this is true is especially significant if the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true is not prec isely defined by law.

If such an object file uses only numerical parameters, data structure layouts and accessors, and small macros and small inline functions (ten lines or less in length), then the use of the object file is unrestricted, regardless of whether it is legally a derivative work. (Exec utables cont aining this object code plus portions of the Library will still fall under Section 6.)

Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section 6. Any executa bles containing that work also fall under Section 6, whether or not they are linked directly with the Library itself.

6. As an exception to the Sections above, you may also combine or link a "work that uses the Library" with the Library to produce a work containing portions of the Library, a nd distribute that work under terms of your choice, provided that the terms permit modification of the work for the customer's own use and reverse engineering for debugging such modifications.

You must give prominent notice with eac h copy of the work that the Library is used in it and that the Library and its use are covered by

- 90-

this License. You must supply a copy of this License. If the work during execution disp l ays copyright notices, you must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this License. Also, you must do one of these thi ngs:

a) Accompany the work with the complete corresponding machine-readable source code for the Library including whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the work is an executable linked with the Library, with the complete machine-readable "work that uses the Library", as object code and/or source code, so that the user can modify the Library and then relink to produce a modified executable containing the modified Libra ry. (It is understood that the user who changes the contents of definitions files in the Library will not necessarily be able to recompile the application to use the modi fi ed definit ions.)

b) Use a suitab l e shared library mechanism for lin king with the Library. A suitable mechanism is one that (1) uses at run time a copy of the library already present on the user's computer syst em, rather than copying library functions into the executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified ver sio n is interface-compatible with the version that the work wa s made wit h.

c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials specified in Subsection 6a, above, for a charge no more than the cost of performi ng this distribution.

d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specified materials from the same place.

e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy.

For an executable, the required form of the "work that uses the Library" must include any data and utility programs needed for reproducing the executable from it. However, as a special exception, the materials to be distributed need not include anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on) of the operating system on which the executable r uns, unless that component itself accompanies the executable.

It may happen that this requirement contra dicts the license restrictions of other propr ie ta ry libra r ie s that d o not normally accompany the operating system. Such a contradiction means you cannot use both them and the Library together in an executable that you distribute.

7. You may place library facilities that are a work based on the Library side-by-side in a single library together wit h o ther library facilities not covered by this License, and distribute such a combined library, provided that the separate distribution of the work based on the Library and of the other libra ry facilities is otherwise

- 91-

permitted, and provided that you do these two things:

a) Accompany the combined library with a copy of the same work based on the Library, unco mbined with any other library facilities. This must be distributed under the te rms of the Sections above.

b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and expla ining where to find the accompanying uncombined form of the same work.

8. You may not copy, modify, sublicense, link with, or distribute the Library except as expressly provided under this License. Any attempt otherwise to copy, modify, sublicense, link with, or distribute the Library is void, and will automatically terminate your rights under this License. However, parties who have received copies, or rights, from you unde r this License will not have their licenses terminated so long as such parties remain in full compliance.

9. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Library or its der ivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Library (or any work based on the Library), you indicate your acceptance of this License to do so, and all its terms and conditions for co pying, distributing or modifying the Library or works based on it.

10. Each time you redistribute the Library (or any work based on the Library), the recipient automatically receives a license from the original licensor to copy, distribute, link with or modify the Library subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties with this License.

11. If, as a consequence of a court judgment or allegation of patent infringement or for any other rea son (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneo usly your obligations under this License and any other pertinent obligations, then as a cons equence you may not distribute the Librar y at all. For example, if a patent license would not permit royalt y-free redistribution of the Library by all those who receive copies directly or indirectly through you, then the only wa y you could satisfy bot h it and this License would be to refrain entirely from distribution of the Library.

If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply, and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infr inge any patents or other property right c la ims or to contest validity of any such claims; this section has the sole purpose of protecting t he integrity of the free software distribution system which is implemented by public license practices. Many people have made

- 92-

generous contributions to the wide range of software distributed through that system in reliance o n consistent application of that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thor oughly clear what is believed to be a consequence of the rest of this License.

12. If the distribution and/or use of the Library is restricted in certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the Library under this License may add an explicit geographical distri bution limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this License.

13. The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to time. Such new versions will be similar in spir it to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Library specifies a version number of this License which applies to it and "any later version", you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation. If the Library does not specify a license version number, you may choose any version ever published by the Free Software Foundation.

14. If you wish to incorporate parts of the Library into other free programs whose distribution conditions are incompatible with these , write to the author to ask for pe rmission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

NO WARRANTY

15. BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE LIBRARY, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE LIBRARY "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PART I CULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND P E RFO RMANCE OF THE LIBRARY I S WITH YOU. SHOULD THE LIBRARY PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

16. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE LIBRARY AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE LIBRARY ( I NCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A

- 93-

FAILURE OF THE LIBRARY TO OPERATE WITH ANY OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Libraries

If you develop a new library, and you want it to be of the greatest possible use to the public, we recommend making it free software that everyone can redistribute and change. You can do so by permitting redistribution under these ter ms (o r, alternatively, under the terms of the ordinary General Public License).

To apply these terms, attach the followi ng notices to the library. It is safest to attach them to the start of each source file to most effectively convey the exclusion o f warranty; and each file s hould have a t least the "copyright" line and a pointer to where the full notice is found.

<one line to give the library's name and a brief idea of what it does.> Copyright (C) <year> <name of author>

This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your option) any later version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty o f MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA

Also add information on how to contact you by electronic and paper mail.

You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright disclaimer" for the library, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the library `Frob' (a library for tweaking knobs) written by James Random Hacker.

<signature of Ty Coon>, 1 April 1990 Ty Coon, President of Vice

That's all there is to it!

OpenSSL Toolkit

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit ( This product includes cryptographic software written by Eric Young (eay@cryptsoft.com).

http://www.openssl.org/).

- 94-

LICENSE ISSUES ==============

The OpenSSL toolkit stays under a dual license, i.e. both the conditions o f the OpenSSL License and the original SSLeay license appl y to the toolkit. See below for the actual license texts. Actually both licenses are BSD-style Open Source licenses. In case of any license issues related to OpenSSL please contact openssl-core@openssl.org.

OpenSSL License

---------------

/* ==================================================================== * Copyright (c) 1998-2011 The OpenSSL Project. All rights reserved. * * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * * 1. Redistributions of source code must retain the above copyright * notice, this list of conditions a nd the following disclaimer. * * 2. Redistributions in binary form must reproduce the above copyright * notice, this list of conditions a nd the following disclaimer in * the documentation and/or other materials provided with the * distribution. * * 3. All advertising materials mentioning features or use of this * software must display the following acknowledgment: * "This product includes software developed by the OpenSSL Project * for use in the OpenSSL Toolkit. (http://www.openssl.org/)" * * 4. The names "OpenSS L Toolkit" and "OpenSSL Project" must not be used to * endorse or promote products derived from this software without * prior written permission. For written permission, please contact * openssl-core@openssl.org. * * 5. Products derived from this software may not be called "OpenSSL" * nor may "OpenSSL" appear in their names without prior written * permission of the OpenSSL Project. * * 6. Redistributions of any form whatsoever must retain the following * acknowledgment: * "This product includes software developed by the OpenSSL Project * for use in the OpenSSL Toolkit (http://www.openssl.org/)" * * THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY * EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, T HE * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR * PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR * ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENT AL, * SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT * NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; * LOSS OF USE, DATA, OR PROFITS; OR BUSINESS I N TERRUPTION) * HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHE R IN CONTRACT, * STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) * ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED

- 95-

* OF THE POSSIBILITY OF SUCH DAMAGE. * ==================================================================== * * This product includes cryptographic software written by Eric Young * (eay@cryptsoft.com). This product includes software written by Tim * Hudson (tjh@cryptsoft.com). * */

Original SSLeay License

-----------------------

/* Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) * All rights reserved. * * This package is an SSL imple mentatio n written * by Eric Young (eay@cryptsoft.com). * The implementation was written so as to conform with Netscapes SSL. * * This library is free for commercial and non-commercial use as long as * the following conditions ar e a hea r e d to. The following conditions * apply to all code found in this distribution, be it the RC4, RSA, * lhash, DES, etc., code; not just the SSL code. The SSL documentation * included with this distribution is covered by the same copyright terms * except that the holder is Tim Hudson (tjh@cryptsoft.com). * * Copyright remains Eric Young's, and as such any Copyright notices in * the code are not to be removed. * If this package is used i n a product, Eric Young should be given attribution * as the author of the parts of the library used. * This can be in the form of a textual message at program star tup or * in documentation (online or textual) provided with the package. * * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the copyright * notice, this list of conditions a nd the following disclaimer. * 2. Redistributions in binary form must reproduce the above copyright * notice, this list of conditions a nd the following disclaimer in the * documentation and/or other materials provided with the distribu tion. * 3. All advertising materials mentioning features or use of this software * must display the following acknowledgement: * "This product includes cryptographic software written by * Eric Young (eay@cryptsoft.com)" * The word 'cryptographic' can be left out if the rouines from the library * being used are not cryptographic related :-). * 4. If you include any Windows specific code (or a derivative thereof) from * the apps directory (application code) you must include an acknowledgement: * "This product includes software written by Tim Hudson (tjh@cryptsoft.com)" * * THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND * ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE * ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE * FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL * DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS * OR SERVICES; LOSS OF USE, DATA, OR PROFITS; O R BUSINESS INTERRUPTION)

- 96-

* HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHE R IN CONTRACT, STRICT * LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY W AY * OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILIT Y OF * SUCH DAMAGE. * * The licence and distribution terms for any publically available version or * derivative of this code cannot be changed. i.e. this code cannot simply be * copied and put under another distribution licence * [including the GNU Public Licence.] */

MIT License

• iniParser

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without re str iction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice and this permission notice shall be included in all copies or substantial portio ns of t he Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIE S OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. I N NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

- 97-

BSD License

SHA2

/* * FIPS 180-2 SHA-224/256/384/512 implementation * Last update: 02/02/2007 * Issue date: 04/30/2005 * * Copyright (C) 2005, 2007 Olivier Gay <olivier.gay@a3.epfl.ch> * All rights re serv ed. * * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright * notice, this list of conditions and the following disclaimer. * 2. Redistributions in binary form must reproduce the above copyright * notice, this list of conditions and the following disclaimer in the * documentation and/or other materials provided with the distribution. * 3. Neither the name of the project nor the names of its contributors * may be used to endorse or promote products derived from this software * without specific prior written permission. * * THIS SOFTWARE IS PROVIDED BY THE PROJECT AND CONTRIBUTORS ``AS IS'' AND * ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE * ARE DISCLAIMED. IN NO EVENT SHALL THE PROJECT OR CONTRIBUTORS BE LIABLE * FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL * DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS * OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) * HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT * LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY * OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF * SUCH DAMAGE. */

HMAC-SHA2

/* * HMAC-SHA-224/256/384/512 implementation * Last update: 06/15/2005 * Issue date: 06/15/2005 * * Copyright (C) 2005 Olivier Gay <olivier.gay@a3.epfl.ch> * All rights re serv ed. * * Redistribution and use in source and binary forms, with or without

- 98-

* modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright * notice, this list of conditions and the following disclaimer. * 2. Redistributions in binary form must reproduce the above copyright * notice, this list of conditions and the following disclaimer in the * documentation and/or other materials provided with the distribution. * 3. Neither the name of the project nor the names of its contributors * may be used to endorse or promote products derived from this software * without specific prior written permission. * * THIS SOFTWARE IS PROVIDED BY THE PROJECT AND CONTRIBUTORS ``AS IS'' AND * ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE * IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE * ARE DISCLAIMED. IN NO EVENT SHALL THE PROJECT OR CONTRIBUTORS BE LIABLE * FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL * DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS * OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) * HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT * LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY * OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF * SUCH DAMAGE. */

lighttpd

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

- Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

- Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

- Neither the name of the 'incremental' nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

- 99-

ARE DISCLAIMED. IN NO EV ENT SHALL THE COPYRIGHT OWNER OR CONTR IBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

NET-SNMP

Various copyrights apply to this package, listed in various separate parts below. Please make sure that you read all the parts.

---- Part 1: CMU/UCD copyright notice: (BSD like) -----

Permission to use, copy , modify and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of CMU and The Regents of the University of California not be used in advertising or publicity pertaining to distribution of the software without specific written permission.

CMU AND THE REGENTS OF THE UNIVERSITY OF CALIFORNIA DISCLAIM ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL CMU OR THE REGENTS OF THE UNIVERSITY OF CALIFORNIA BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM THE LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

---- Part 2: Networks Associates Technology, Inc copyright notice (BSD) -----

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

- 100-

NEC Express5800-R120f-2M, Express5800-R120e-2M, Express5800-R120e-1M, Express5800-R120d-2M, Express5800-R120d-1M User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

TRADEMARKS AND PATENTS

NOTES

ABOUT THIS USER' S GUIDE

SYMBOLS

PREFACE

1. Overview

2. Configuring the Host System

DEFAULT NETWORK SETTINGS

MANAGEMENT LAN SETTINGS

3. Configuring a Management PC

SETTING YOUR BROWSER

SUPPORTED BROWSERS

J2SE RUNTIME ENVIRONMENT

4. Networking

TCP/IP PORTS

5. Using Remote Management

OVERVIEW

CONNECTING TO THE WEB SERVER

LOGIN AND LOGOUT

HEADER MENU

SERVER PANEL

SYSTEM

REMOTE ACCESS

REMOTE KVM/MEDIA

CONFIGURATION

UPDATE

6. Command Line Interface

OVERVIEW

CONNECTING TO BMC

Logout

BASIC COMMANDS

REMOTE CONTROL

Power ON

Forced Power OFF

OS Shutdown

System Reset

Remote Console

UID Switch Control

SYSTEM EVENT LOG

Viewing system event log

Setting of s ystem event log

ACCESS LOG

Vie win g ac ce ss lo g

Clearing ac cess log

Setting acce ss log

USER SETTINGS

NETWORK SETTINGS

POWER CONSUMPTION CONTROL

CONFIRMING SYSTEM INFORMATION

SPECIAL EXTENDED COMMANDS

S tate Acqui sition

Power State acquisition

Lamp State acquisition

Interrupt Generation for OS Dump

7. WS-Management (Web Service for Management)

OVERVIEW

POWER CONTROL

Power ON

Forced Power OFF

OS Shutdown

System Reset

Interrupt Generation for O S Dump

SENSOR INFORMATION

Enumeration of All Sensors

Retrieving Specified Sensor

8. Troubleshooting

ERROR MESSAGES

ABOUT ECO SETTING

ABOUT NETWORK INFORMATION

OTHERS TIPS

License Notes

GNU General Public License

GNU Lesser Ge neral Public Licsense

OpenSSL Toolkit

MIT License

BSD License
