NEC Express5800-R120d-1E Configuration Guide

NEC Express5800/R120d-1E
Configuration Guide
Introduction
guide will ensure fast and proper configuration of your NEC Express5800 server.
December 21, 2012 Revision 4.0
NEC Corporation
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Contents
TECHNICAL SPECIFICATION ........................................................................................ 3
Key Features .......................................................................................................................................... 3
Specification .......................................................................................................................................... 3
EXTERNAL VIEWS ....................................................................................................... 10
Front and Rear Views ......................................................................................................................... 10
Dimensions (mm) ................................................................................................................................ 11
CONFIGURATION DIAGRAM ....................................................................................... 12
EXPANSION SLOT ........................................................................................................ 12
SERVER CONFIGURATION ......................................................................................... 13
1 Base Models ................................................................................................................................. 13
2 Processors and Heat Sink .......................................................................................................... 14
3 Memory ......................................................................................................................................... 15
3.1 Memory Configuration........................................................................................................ 15
4 Internal Hard Disk Drives ............................................................................................................ 18
4.1 RAID Configuration ............................................................................................................ 18
4.2 Hot Plug 2.5-inch Drive Configuration ............................................................................... 20
4.3 Hot Plug 3.5-inch Drive Configuration ............................................................................... 29
5 Optical Drive ................................................................................................................................. 31
6 PCI Riser Card / PCI Card ........................................................................................................... 32
6.1 Network Interface Controller .............................................................................................. 32
6.2 External Storage Controller ............................................................................................... 33
6.3 Serial Port Adapter ............................................................................................................. 34
7 Other Add-in Components .......................................................................................................... 34
7.1 Power Supply ..................................................................................................................... 34
7.2 Trusted Platform Module Kit .............................................................................................. 34
7.3 Internal Flash Memory ....................................................................................................... 34
7.4 Flash FDD .......................................................................................................................... 35
7.5 Front Bezel ......................................................................................................................... 35
8 Add-on Components ................................................................................................................... 35
8.1 17-inch LCD Console Drawer ............................................................................................ 36
8.2 KVM Switch ........................................................................................................................ 36
8.3 Cable Management Arm .................................................................................................... 36
8.4 Server Management License ............................................................................................. 37
REFERENCES............................................................................................................... 38
Server Management ............................................................................................................................ 38
OS Support Matrix for PCI Cards ...................................................................................................... 39
Supported PCI Cards and Installable Slots ...................................................................................... 39
Maximum power consumption .......................................................................................................... 40
Copyright Notice and Liability Disclaimer ........................................................................................ 41
REVISION HISTORY ..................................................................................................... 42
NEC Corporation Revision 4.0 – December 21, 2012 2
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Processor
Type
Intel® Xeon® processor E5-2403
Intel® Xeon® processor E5-2407
Intel® Xeon® processor E5-2420
Intel® Xeon® processor E5-2430
Clock speed
1.80 GHz
2.20 GHz
1.90 GHz
2.20 GHz
Number of Processors
1 or 2
Cache
10 MB
15 MB
Cores and Threads
4C-4T
6C-12T
Chipset
Intel® C602 Chipset
Memory
Type
DDR3-1333 ECC Unbuffered Low Power DIMM, DDR3-1600 and DDR3-1066 ECC Registered Low Power DIMM
Standard Capacity
0 GB
Maximum Capacity
384 GB (12 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS HDD: 7.2 TB (8 x 900 GB) SATA HDD: 8 TB (8 x 1 TB) SAS SSD: 3.2 TB (8 x 400 GB)
Storage Controller
SATA : 3Gb/s and 6Gb/s (Integrated) SAS: 6Gb/s (Optional)
RAID
SATA : RAID 0/1/10(Standard), RAID 5/6/50/60 (Optional) SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8 with optional drive cage
Expansion Slots
Standard
Total: 3 slots available 1 x PCIe 3.0 x16 (x16 connector)
1 x PCIe 2.0 x4 (x8 connector) 1 x PCIe 3.0 x8 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 1
Interfaces
9 x USB2.0 (2 x front, 4 x rear, 3 x internal) 2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear) 1 to 2 x Serial (9-pin mini D-sub, RS232-C, 1 to 2 x rear)
4 x 1000BASE-T LAN connector (RJ-45, 4 x rear) 1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, non-hot plug
Redundant Power Supply
Optional, hot plug

Technical Specification

Key Features

High performance with the latest Intel® Xeon® processor E5-2400 product family Up to 384 GB of memory capacity, supporting high speed and energy efficient DDR3-1600 memory High energy efficiency with power capping feature and 80 PLUS® Platinum power supply Up to eight 2.5-inch drives in 1U dense form factor

Specification

2.5-inch Drive Model (1 / 2)

NEC Corporation Revision 4.0 – December 21, 2012 3
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Power Supply
1 to 2 x 450 Watt or 800 Watt 80 PLUS® Platinum certified hot plug PSU 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
Max. Config, Idling
175 VA / 175 Watt
175 VA / 175 Watt
183 VA / 182 Watt
183 VA / 182 Watt
Max. Config, Operating
411 VA / 403 Watt
438 VA / 430 Watt
497 VA / 487 Watt
499 VA / 489 Watt
Acoustical Noise (Sound Pressure
Level) 2
Max. Config, Idling
43.5 dB
Max. Config, Operating
57.1 dB
Dimensions (W x D x H )
439.8 x 682.1 x 43.4 mm / 17.3 x 26.9 x 1.7 in (1U)
Weight (Minimum / Maximum)
13 kg / 18.0 kg, 28.66 lbs. / 39.68 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80% Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, C-TICK, CE, UL, CB, KC, BSMI, CCC, RoHS, WEEE
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2003 R2, Standard Edition Microsoft® Windows Server® 2003 R2, Enterprise Edition Microsoft® Windows Server® 2003 R2, Standard x64 Edition Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition Microsoft® Windows Server® 2008 Standard Microsoft® Windows Server® 2008 Enterprise Microsoft® Windows Server® 2008 Standard (x64) Microsoft® Windows Server® 2008 Enterprise (x64) Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Enterprise Microsoft® Windows Server® 2012 Standard 3 Microsoft® Windows Server® 2012 Datacenter 3 Red Hat Enterprise Linux 5.7 or later (x86)
4
Red Hat Enterprise Linux 5.7 or later (EM64T)
4
Red Hat Enterprise Linux 6.1 or later (x86)
4
Red Hat Enterprise Linux 6.1 or later (x86_64)
4
VMware ESX 4.1Update 2 VMware ESXi 5.0 Update 1 VMware ESXi 5.1
Model
R120d-1E
Processor
Type
Intel® Xeon® processor E5-2430L
Intel® Xeon® processor E5-2450
Intel® Xeon® processor E5-2470
Clock speed
2 GHz
2.10 GHz
2.30 GHz
Number of Processors
1 or 2
Cache
15 MB
20 MB
Cores and Threads
6C-12T
8C-16T
Chipset
Intel® C602 Chipset
1
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
2
Noise emission was measured at the bystander positions in accordance with ISO 7779. The actual value may
vary by the operating environment.
3
For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
4
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html

2.5-inch Drive Model (2 / 2)

NEC Corporation Revision 4.0 – December 21, 2012 4
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Memory
Type
DDR3-1333 ECC Unbuffered Low Power DIMM, DDR3-1600 and DDR3-1066 ECC Registered Low Power DIMM
Standard Capacity
0 GB
Maximum Capacity
384 GB (12 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS HDD: 7.2 TB (8 x 900 GB) SATA HDD: 8 TB (8 x 1 TB) SAS SSD: 3.2 TB (8 x 400 GB)
Storage Controller
SATA : 3Gb/s and 6Gb/s (Integrated) SAS: 6Gb/s (Optional)
RAID
SATA : RAID 0/1/10(Standard), RAID 5/6/50/60 (Optional) SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8 with optional drive cage
Expansion Slots
Standard
Total: 3 slots available 1 x PCIe 3.0 x16 (x16 connector)
1 x PCIe 2.0 x4 (x8 connector) 1 x PCIe 3.0 x8 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 1
Interfaces
9 x USB2.0 (2 x front, 4 x rear, 3 x internal) 2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear) 1 to 2 x Serial (9-pin mini D-sub, RS232-C, 1 to 2 x rear)
4 x 1000BASE-T LAN connector (RJ-45, 4 x rear) 1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, non-hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1 to 2 x 450 Watt or 800 Watt 80 PLUS® Platinum certified hot plug PSU 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
Max. Config, Idling
183 VA / 180 Watt
183 VA / 183 Watt
183 VA / 183 Watt
Max. Config, Operating
474 VA / 465 Watt
520 VA / 511 Watt
522 VA / 512 Watt
Acoustic Noise (Sound Pressure Level) 2
Max. Config, Idling
43.5 dB
Max. Config, Operating
53.1 dB
57.1 dB
Dimensions (W x D x H )
439.8 x 682.1 x 43.4 mm / 17.3 x 26.9 x 1.7 in (1U)
Weight (Minimum / Maximum)
13 kg / 18.0 kg, 28.66 lbs. / 39.68 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80% Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, C-TICK, CE, UL, CB, KC, BSMI, CCC, RoHS, WEEE
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2003 R2, Standard Edition Microsoft® Windows Server® 2003 R2, Enterprise Edition Microsoft® Windows Server® 2003 R2, Standard x64 Edition Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition Microsoft® Windows Server® 2008 Standard Microsoft® Windows Server® 2008 Enterprise Microsoft® Windows Server® 2008 Standard (x64) Microsoft® Windows Server® 2008 Enterprise (x64)
NEC Corporation Revision 4.0 – December 21, 2012 5
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Enterprise Microsoft® Windows Server® 2012 Standard 3 Microsoft® Windows Server® 2012 Datacenter 3 Red Hat Enterprise Linux 5.7 or later (x86)
4
Red Hat Enterprise Linux 5.7 or later (EM64T)
4
Red Hat Enterprise Linux 6.2 or later (x86)
4
Red Hat Enterprise Linux 6.2 or later (x86_64)
4
VMware ESX 4.1 Update 2 VMware ESXi 5.0 Update 1 VMware ESXi 5.1
Model
R120d-1E
Processor
Type
Intel® Xeon® processor E5-2403
Intel® Xeon® processor E5-2407
Intel® Xeon® processor E5-2430
Clock speed
1.80 GHz
2.20 GHz
2.20 GHz
Number of Processors
1 or 2
Cache
10 MB
15 MB
Cores and Threads
4C-4T
6C-12T
Chipset
Intel® C602 Chipset
Memory
Type
DDR3-1333 ECC Unbuffered Low Power DIMM, DDR3-1600 and DDR3-1066 ECC Registered Low Power DIMM
Standard Capacity
0 GB
Maximum Capacity
384 GB (12 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
12 TB (4 x 3 TB)
Storage Controller
3Gb/s and 6Gb/s (Integrated)
RAID
RAID 0/1/10(Standard), RAID 5/6/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays [free]
4
Expansion Slots
Standard
Total: 3 slots available 1 x PCIe 3.0 x16 (x16 connector) 1 x PCIe 2.0 x4 (x8 connector)
1 x PCIe 3.0 x8 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 1
1
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
2
Noise emission was measured at the bystander positions in accordance with ISO 7779. The actual value may
vary by the operating environment.
3
For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
4
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html

3.5-inch Drive Model (1 / 2)

NEC Corporation Revision 4.0 – December 21, 2012 6
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Interfaces
9 x USB2.0 (2 x front, 4 x rear, 3 x internal) 2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear) 1 to 2 x Serial (9-pin mini D-sub, RS232-C, 1 to 2 x rear)
4 x 1000BASE-T LAN connector (RJ-45, 4 x rear) 1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, non-hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1 to 2 x 450 Watt 80 PLUS® Platinum certified hot plug PSU 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
Max. Config, Idling
150 VA / 150 Watt
150 VA / 150 Watt
158 VA / 157 Watt
Max. Config, Operating
289 VA / 284 Watt
312 VA / 306 Watt
394 VA / 387 Watt
Acoustic Noise (Sound Pressure
Level) 2
Max. Config, Idling
43.5 dB
Max. Config, Operating
57.1 dB
Dimensions (W x D x H )
439.8 x 682.1 x 43.4 mm / 17.3 x 26.9 x 1.7 in (1U)
Weight (Minimum / Maximum)
13 kg / 18.0 kg, 28.66 lbs. / 39.68 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80% Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, C-TICK, CE, UL, CB, KC, BSMI, CCC, RoHS, WEEE
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2003 R2, Standard Edition Microsoft® Windows Server® 2003 R2, Enterprise Edition Microsoft® Windows Server® 2003 R2, Standard x64 Edition Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition Microsoft® Windows Server® 2008 Standard Microsoft® Windows Server® 2008 Enterprise Microsoft® Windows Server® 2008 Standard (x64) Microsoft® Windows Server® 2008 Enterprise (x64) Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Enterprise Microsoft® Windows Server® 2012 Standard 3 Microsoft® Windows Server® 2012 Datacenter 3 Red Hat Enterprise Linux 5.7 or later (x86)
4
Red Hat Enterprise Linux 5.7 or later (EM64T)
4
Red Hat Enterprise Linux 6.2 or later (x86)
4
Red Hat Enterprise Linux 6.2 or later (x86_64)
4
VMware ESX 4.1 Update 2 VMware ESXi 5.0 Update 1 VMware ESXi 5.1
1
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
2
Noise emission was measured at the bystander positions in accordance with ISO 7779. The actual value may
vary by the operating environment.
3
For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
4
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
NEC Corporation Revision 4.0 – December 21, 2012 7
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Processor
Type
Intel® Xeon® processor E5-2430L
Intel® Xeon® processor E5-2450
Clock speed
2 GHz
2.10 GHz
Number of Processors
1 or 2
Cache
15 MB
20 MB
Cores and Threads
6C-12T
8C-16T
Chipset
Intel® C602 Chipset
Memory
Type
DDR3-1333 ECC Unbuffered Low Power DIMM, DDR3-1600 and DDR3-1066 ECC Registered Low Power DIMM
Standard Capacity
0 GB
Maximum Capacity
384 GB (12 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
12 TB (4 x 3 TB)
Storage Controller
3Gb/s and 6Gb/s (Integrated)
RAID
RAID 0/1/10(Standard), RAID 5/6/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
4
Expansion Slots
Standard
Total: 3 slots available 1 x PCIe 3.0 x16 (x16 connector) 1 x PCIe 2.0 x4 (x8 connector)
1 x PCIe 3.0 x8 (x8 connector) dedicated RAID slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 1
Interfaces
9 x USB2.0 (2 x front, 4 x rear, 3 x internal) 2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear) 1 to 2 x Serial (9-pin mini D-sub, RS232-C, 1 to 2 x rear) 4 x 1000BASE-T LAN connector (RJ-45, 4 x rear)
1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, non-hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1-2 x 450 Watt 80 PLUS® Platinum certified hot plug PSU 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power Consumption
Max. Config, Idling
158 VA / 155 Watt
158 VA / 157 Watt
Max. Config, Operating
375 VA / 368 Watt
478 VA / 472 Watt
Acoustic Noise (Sound Pressure
Level) 2
Max. Config, Idling
43.5 dB
Max. Config, Operating
53.1dB
57.1 dB
Dimensions (W x D x H )
439.8 x 682.1 x 43.4 mm / 17.3 x 26.9 x 1.7 in (1U)
Weight (Minimum / Maximum)
13 kg / 18.0 kg, 28.66 lbs. / 39.68 lbs.
Temperature, Relative Humidity (non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80% Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, C-TICK, CE, UL, CB, KC, RoHS, WEEE
Operating Systems and Virtualization Software
Microsoft® Windows Server® 2003 R2, Standard Edition Microsoft® Windows Server® 2003 R2, Enterprise Edition Microsoft® Windows Server® 2003 R2, Standard x64 Edition

3.5-inch Drive Model (2 / 2)

NEC Corporation Revision 4.0 – December 21, 2012 8
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Model
R120d-1E
Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition Microsoft® Windows Server® 2008 Standard Microsoft® Windows Server® 2008 Enterprise Microsoft® Windows Server® 2008 Standard (x64) Microsoft® Windows Server® 2008 Enterprise (x64) Microsoft® Windows Server® 2008 R2 Standard Microsoft® Windows Server® 2008 R2 Enterprise Microsoft® Windows Server® 2012 Standard 3 Microsoft® Windows Server® 2012 Datacenter 3 Red Hat Enterprise Linux 5.7 or later (x86)
4
Red Hat Enterprise Linux 5.7 or later (EM64T)
4
Red Hat Enterprise Linux 6.2 or later (x86)
4
Red Hat Enterprise Linux 6.2 or later (x86_64)
4
VMware ESX 4.1 Update 2 VMware ESXi 5.0 Update 1 VMware ESXi 5.1
1
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
2
Noise emission was measured at the bystander positions in accordance with ISO 7779. The actual value may
vary by the operating environment.
3
For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
4
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
NEC Corporation Revision 4.0 – December 21, 2012 9
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Legend
A.
Drive Bays
J.
BMC RESET Switch
B.
Pull-out tab
K.
DUMP Switch
C.
USB Connectors
L.
RESET Switch
D.
Data LAN 1 Activity LED
M.
UID LED Button/LED
E.
Data LAN 2 Activity LED
N.
POWER Button/LED
F.
Data LAN 3 Activity LED
O.
VGA Connector
G.
Data LAN 4 Activity LED
P.
Optional 2.5-inch Drive Bay
H.
Hard Drive Activity LED
Q.
Optical Drive Bay
I.
System Status LED
A Q D F H N J K L M E G I P B C O
Q E G
I A D F H N J K L M B C O

External Views

Front and Rear Views

Front View for 2.5-inch Drive Model

Front View for 3.5-inch Drive Model

NEC Corporation Revision 4.0 – December 21, 2012 10
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Legend
A.
PCI Slot (Low Profile)
G.
LAN Connector
B.
PCI Slot (Low Profile)
H.
USB Connector
C.
Power Supply
I.
UID LED Button/LED
D.
AC Inlet
J.
Management LAN Connector
E.
AC Power LED
K.
Serial Port Connector
F.
Additional PS Slot
L.
VGA Connector
35.0
682.1
908.2
439.8
479.7
44.4
43.4
482.4
43.1
818.9 *
C
D
G H I J K
L
E A B
F

Rear View

Dimensions (mm)

NEC Corporation Revision 4.0 – December 21, 2012 11
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Legend
#1A
PCIe 3.0 x8, x8 connector, for a dedicated RAID controller
#1B
PCIe 3.0 x16, x16 connector, Low-profile, up to 170 mm length
#1C
PCIe 2.0 x4, x8 connector, Low-profile, up to 170 mm length
2.5-inch
Drive Cage
CHASSIS
FRONT
CHASSIS
REAR
CHASSIS
TOP
6 2.5-inch Drives
PCIe 3.0
PCIe 2.0
#1B#1C
Hot plug
Power
Supply #1
Cooling Fan
Cooling
Fan
Processor #2
6 DIMM
Slots
Hot plug
Power Supply #1
Hot plug
Power Supply #2
RAID Slot
Processor #1
Optical Drive
Bay
Hot plug
Power
Supply #2
1 DIMM Slots
6 DIMM Slots
Optical
Drive Bay
2 RAID BBU
Slots
Cooling
Fan
3.5-inch
Drive Cage
CHASSIS
FRONT
CHASSIS
REAR
CHASSIS
TOP
4 3.5-inch Drives
PCIe 3.0
PCIe 2.0
#1B#1C
Hot plug
Power
Supply #1
Cooling Fan
Cooling
Fan
Processor #2
6 DIMM
Slots
Hot plug
Power Supply #1
Hot plug
Power Supply #2
RAID Slot
Processor #1
Optical Drive
Bay
Hot plug
Power
Supply #2
1 DIMM Slots 6 DIMM Slots
Optical
Drive Bay
2 RAID BBU
Slots
Cooling
Fan
#1C #1B
#1A

Configuration Diagram

2.5-inch Drive Model

Legend: Minimum required components Standard Components

3.5-inch Drive Model

Legend: Minimum required components Standard Components

Expansion Slot

NEC Corporation Revision 4.0 – December 21, 2012 12
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Product Name / Description
Part Number
NEC Express5800/R120d-1E Server
no processor, no RAM, no HDD, no ODD Including: 6 x 2.5-inch hot plug drive cage, 1 x 450 Watt 80 PLUS® Platinum hot plug power supply,
EXPRESSBUILDER DVD
N8100-1954F
NEC Express5800/R120d-1E Server
no processor, no RAM, no HDD, no ODD Including: 6 x 2.5-inch drive cage, 1 x 800 Watt 80 PLUS® Platinum hot plug power supply, EXPRESSBUILDER DVD
N8100-1955F
Product Name / Description
Part Number
NEC Express5800/R120d-1E Server
no processor, no RAM, no HDD, no ODD Including: 4 x 3.5-inch hot plug drive cage, 1 x 450 Watt 80 PLUS® Platinum hot plug power supply, EXPRESSBUILDER DVD
N8100-1956F

Server Configuration

1 Base Models

2.5-inch Drive Model

NOTE:
The base model must be ordered with a processor kit.

3.5-inch Drive Model

NOTE:
The base model must be ordered with a processor kit.
NEC Corporation Revision 4.0 – December 21, 2012 13
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
CPU
1 Processor Required
Xeon E5-2403 Processor Kit
Intel® Xeon ® Processor E5-2403 (1.80 GHz, 4C/4T, 10 MB)
N8101-560F
Xeon E5-2407 Processor Kit
Intel® Xeon ® Processor E5-2407 (2.20 GHz, 4C/4T, 10 MB)
N8101-561F
Xeon E5-2420 Processor Kit
Intel® Xeon ® Processor E5-2420 (1.90 GHz, 6C/12T, 15 MB)
NOTE: The kit is supported on 2.5-inch drive model only.
N8101-562F
Xeon E5-2430 Processor Kit
Intel® Xeon ® Processor E5-2430 (2.20 GHz, 6C/12T, 15 MB)
N8101-563F
Xeon E5-2430L Processor Kit
Intel® Xeon ® Processor E5-2430L (2 GHz, 6C/12T, 15 MB)
N8101-564F
Xeon E5-2450 Processor Kit
Intel® Xeon ® Processor E5-2450 (2.10 GHz, 8C/16T, 20 MB)
N8101-565F
Xeon E5-2470 Processor Kit
Intel® Xeon ® Processor E5-2470 (2.30 GHz, 8C/16T, 20 MB)
NOTE: The kit is supported on 2.5-inch drive model only.
N8101-567F
Heat Sink
1st
Processor Heat Sink
For 1st Processor
(Standard)
2nd
Processor Heat Sink
For 2nd Processor, including cooling fan kit
N8101-576F

2 Processors and Heat Sink

Available sockets: 2
NOTE:
Minimum one processor kit from above must be installed. The processors must be identical to configure dual processor system.
NEC Corporation Revision 4.0 – December 21, 2012 14
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Independent Channel
Memory Sparing
Memory Lockstep
Memory Mirroring
Performance
Best
Better
Better
Good
Data Protection
No
Multiple single bit error protection
No
Multiple single bit and multi bit error protection
Redundancy
No
Partly
No
Fully
Data Correction
ECC, x4 SDDC 1
ECC, x4 SDDC
ECC, x8 SDDC
ECC, x4 SDDC
Available Memory
Full physical memory
2/3 physical memory
Full physical memory
Half physical memory
Available Memory Channels
3 3 2
2
Notes
-
All DIMMs in the system must be identical.
Paired DIMMs must be identical.
Paired DIMMs must be identical.
Category
Product Name / Description
Part Number
Unbuffered DIMM (UDIMM)
4GB DDR3-1333 UNB Memory Kit
1x 4GB Unbuffered ECC DIMM, DDR3L-1333(PC3L-10600)
NOTE: The x4 SDDC is not supported.
N8102-455F
Registered DIMM (RDIMM)
2GB DDR3-1600 REG Memory Kit
1x 2GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
NOTE: The x4 SDDC is not supported.
N8102-488F
4GB DDR3-1600 REG Memory Kit
1x 4GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-489F
8GB DDR3-1600 REG Memory Kit
1x 8GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-490F
16GB DDR3-1600 REG Memory Kit
1x 16GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-491F
32GB DDR3-1066 REG Memory Kit
1x 32GB Registered ECC DIMM, DDR3L-1066(PC3L-8500)
N8102-492F

3 Memory

3.1 Memory Configuration

Refer to the section in accordance with your memory configuration:
Independent Channel Configuration: Refer to 3.1.1 Memory Sparing Configuration: Refer to 3.1.2 Memory Mirroring / Memory Lockstep Configuration: Refer to 3.1.3
Memory Configuration Feature Comparison
See the table below for feature comparisons of memory configurations supported.
N8102-455F 4GB DDR3-1333 UNB Memory Kit and N8102-488F 2GB DDR3-1600 REG Memory Kit
do not support x4 SDDC.
3.1.1 Independent Channel Configuration
Available slots: 6 per processor
NOTE:
Minimum one memory kit per processor must be installed. It is recommended to install three identical memory kits for triple-channel symmetric memory
configurations to increase memory transfer speed.
Mix configurations of UDIMM/RDIMM are not supported.
NEC Corporation Revision 4.0 – December 21, 2012 15
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Product Name / Description
Part Number
16GB DDR3-1600 REG Memory Kit
2x 8GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-497
32GB DDR3-1600 REG Memory Kit
2x 16GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-498
Product Name / Description
Part Number
4GB DDR3-1600 REG Memory Kit
2x 2GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-493
8GB DDR3-1600 REG Memory Kit
2x 4GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-494
16GB DDR3-1600 REG Memory Kit
2x 8GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-495
32GB DDR3-1600 REG Memory Kit
2x 16GB Registered ECC DIMM, DDR3L-1600(PC3L-12800)
N8102-496
Processor
Type
Populated DIMMs
# of DIMMs per
processor
Memory Power
Setting
DIMM Speed
E5-2403
UDIMM: 4GB RDIMM: 2 GB, 4 GB, 8 GB,16 GB
- - 1066 MHz
E5-2407
RDIMM: 32 GB
- - 800 MHz
E5-2420
UDIMM: 4GB
Up to 3 DIMMs
-
1333 MHz
E5-2430
4 or more DIMMs
-
1066 MHz
E5-2430L
RDIMM: 2 GB, 4 GB, 8 GB,16 GB
- - 1333 MHz
RDIMM: 32 GB
- - 800 MHz
E5-2450
UDIMM: 4GB
Up to 3 DIMMs
-
1333 MHz
E5-2470
4 or more DIMMs
-
1066 MHz
RDIMM: 2 GB, 4 GB, 8 GB,16 GB
-
Low (1.35V)
1333 MHz
-
Normal (1.5V)
1600 MHz
RDIMM: 32 GB
- - 800 MHz
3.1.2 Memory Sparing Configuration
Available slots: 6 per processor
NOTE:
Minimum one memory kit per processor must be installed. The memory kits must be identical. The logical memory capacity becomes three-fourths of physical capacity.
3.1.3 Memory Mirroring / Memory Lockstep Configuration
Available slots: 6 per processor
NOTE:
Minimum one memory kit per processor must be installed. The logical memory capacity becomes a half of physical capacity.
Maximum Memory Speed
See the table below for the actual maximum memory transfer speed in Independent Channel / Memory Sparing Configuration.
DDR3 memory speed depends on the type of DIMMs, the native memory bus speed of the memory controller and memory configuration. All memory buses operate at the clock frequency of the DIMM with the lowest frequency.
NEC Corporation Revision 4.0 – December 21, 2012 16
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Maximum Memory Size Supported by Operating Systems
Maximum Available Memory
Microsoft Windows Server 2003 R2, Standard Edition Microsoft Windows Server 2008 Standard
4 GB
4 GB (HW-DEP enabled) App. 2 GB (HW-DEP disabled)
Microsoft Windows Server 2003 R2, Standard x64 Edition Microsoft Windows Server 2008 Standard (x64) Microsoft Windows Server 2008 R2 Standard
32 GB
32 GB
Microsoft Windows Server 2003 R2, Enterprise Edition Microsoft Windows Server 2008 Enterprise
64 GB
64 GB
Microsoft Windows Server 2003 R2, Enterprise x64 Edition
1 TB
384 GB
Microsoft Windows Server 2008 Enterprise (x64) Microsoft Windows Server 2008 R2 Enterprise
2 TB
384 GB
Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Datacenter
4 TB
384 GB
Red Hat Enterprise Linux 5 Red Hat Enterprise Linux 6
16 GB
16 GB
Red Hat Enterprise Linux 5 (EM64T)
1 TB
384 GB
Red Hat Enterprise Linux 6 (x86_64)
2 TB
384 GB
VMware ESX 4.11
256 GB or 1 TB
256 GB or 384 GB
VMware ESXi 5.0 / 5.12
2 TB
384 GB
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system. The maximum available memory is less than the maximum physical memory supported by your system
because some chipsets require PCI resource space of about 750MB. PCI resource requirements vary depending on the type and the number of PCI cards you are using.
1
Up to 255 GB of the main memory is available to each virtual machine
2
Up to 1 TB of the main memory is available to each virtual machine.
NEC Corporation Revision 4.0 – December 21, 2012 17
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Non-RAID
RAID 5/6/50/60
1 GB Cache/ Battery
512 MB Cache
Refer to 4.2.1
Refer to 4.2.3
Refer to 4.2.4
Refer to 4.2.5
RAID 0/1/10
SATA
SAS, SATA
SAS, SATA
SAS, SATA
Available Interface
Embedded SATA RAID Controller
Optional RAID Controller
Refer to 4.2.2
SATA
1 GB Cache/ CacheVault
Refer to 4.2.6
SAS, SATA
RAID 0/1/10
RAID 5/6/50/60
1 GB Cache/ Battery
512 MB Cache
Refer to 4.2.8
Refer to 4.2.9
SAS, SATA
SAS, SATA
Available Interface
Refer to 4.2.7
SAS, SATA
1 GB Cache/ CacheVault
Refer to 4.2.10
SAS, SATA

4 Internal Hard Disk Drives

4.1 RAID Configuration

Refer to the section in accordance with your disk form factor and RAID configuration.
4.1.1 2.5-inch Drive Model Up to six 2.5-inch Drives
Up to eight 2.5-inch Drives
NOTE:
Up to four hard drives can be installed in the Embedded SATA configuration. Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Hot plug insertion/removal are not supported in the Embedded SATA non-RAID controller. All drives within a RAID array should be of the same type, capacity and rotation speed. Use the same rotational speed of the SAS hard drives. To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in
order to minimize the risk of becoming multiple hard drives failure during the RAID rebuilding process.
Up to two different kinds of drives can be mixed in one system For optional RAID controller driver to install Windows Server 2003 R2, download from the NEC
website at:
http://www.nec.com/en/global/prod/express/download/index.html
NEC Corporation Revision 4.0 – December 21, 2012 18
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Non-RAID
RAID 5/6/50/60
1 GB Cache/ Battery
512 MB Cache
Refer to 4.3.1
Refer to 4.3.3
Refer to 4.3.4
Refer to 4.3.5
RAID 0/1/10
SATA
SATA
SATA
SATA
Available Interface
Embedded SATA RAID Controller
Optional RAID Controller
Refer to 4.3.2
SATA
1 GB Cache/ CacheVault
Refer to 4.3.6
SATA
4.1.2 3.5-inch Drive Model
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Embedded SATA RAID Controller does not support RAID 10 configured with 2TB and 3TB HDDs. Hot plug insertion/removal is not supported with the Embedded SATA non-RAID controller. All hard drives within a RAID array should be of the same capacity. For optional RAID controller driver to install Windows Server 2003 R2, download from the NEC
website at:
http://www.nec.com/en/global/prod/express/download/index.html
NEC Corporation Revision 4.0 – December 21, 2012 19
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA
(Standard)
Cable
Required
Internal SATA Cable
4 x Single SATA to 1 x mini-SAS
(Standard)
Drive Cage
Required
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA, RAID 0/1/10 capable
(Standard)
Cable
Internal SATA Cable
4 x Single SATA to 1 x mini-SAS
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358

4.2 Hot Plug 2.5-inch Drive Configuration

4.2.1 Up to four Drives with Embedded SATA non-RAID Controller
NOTE:
Hot plug insertion/removal is not supported with the Embedded SATA non-RAID controller.
4.2.2 Up to four Drives with Embedded SATA RAID Controller
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 4.0 – December 21, 2012 20
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i RAID 0/1, 512 MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
6 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.3 Up to six Drives with RAID 0/1 Controller with 512 MB Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system
NEC Corporation Revision 4.0 – December 21, 2012 21
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 512MB cache, Int.8, PCIe 2.0 x8 ,
SAS 6Gb/s, SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
6 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.4 Up to six Drives with RAID 5/6 Controller with 512 MB Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard drives failures, is recommended as the redundancy becomes invalid during the system recovery.
NEC Corporation Revision 4.0 – December 21, 2012 22
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID 0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
6 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.5 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard
NEC Corporation Revision 4.0 – December 21, 2012 23
drives failures, is recommended as the redundancy becomes invalid during the system recovery.
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9265CV-8i (with CV) RAID0/1/5/6/10/50/60, 1GB Cache, Int. 8ports, PCIe 3.0(x8), 6Gb/s, flash cache protection modules included
N8103-152
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
6 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.6 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard drives failures, is recommended as the redundancy becomes invalid during the system recovery.
For VMware ESXi 5.x installation, to download the CIM provider is required.
NEC Corporation Revision 4.0 – December 21, 2012 24
For VMware ESXi 5.x systems, monitoring the status of a RAID array with NEC ESMPRO is not
supported.
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i RAID 0/1, 512 MB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Optional Drive Cage
Required
2.5-inch Hot Plug Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-45
Drive
8 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.7 Up to eight Drives with RAID 0/1 Controller with 512 MB Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. Since redundancy becomes invalid during the system recovery, it is recommended to obtain a RAID controller for RAID 6 (N8103-150/-151) to configure with RAID 6 or RAID 60, which supports two hard drives failures, in order to improve the reliability.
NEC Corporation Revision 4.0 – December 21, 2012 25
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 512MB cache, Int.8, PCIe 2.0 x8 ,
SAS 6Gb/s, SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Optional Drive Cage
Required
2.5-inch Hot Plug Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-45
Drive
8 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.8 Up to eight Drives with RAID 5/6 Controller with 512 MB Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard drives failures, is recommended as the redundancy becomes invalid during the system recovery.
NEC Corporation Revision 4.0 – December 21, 2012 26
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID 0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS 9267-8i
NOTE:
- SSD used for cache is required.
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Optional Drive Cage
Required
2.5-inch Hot Plug Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-45
Drive
8 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.9 Up to eight Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard drives failures, is recommended as the redundancy becomes invalid during the system recovery.
NEC Corporation Revision 4.0 – December 21, 2012 27
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9265CV-8i (with CV) RAID0/1/5/6/10/50/60, 1GB Cache, Int. 8ports, PCIe 3.0(x8), 6Gb/s, flash cache protection modules included
N8103-152
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Internal SAS/SATA Cable
two set of 1 x mini-SAS to 4 x Single SATA
(Standard)
Drive Cage
2.5-inch Hot Plug Drive Cage Kit
6 x 2.5-inch hot plug hard drive bays
(Standard)
Optional Drive Cage
Required
2.5-inch Hot Plug Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-45
Drive
8 slots available
SAS HDD
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB HDD
1x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB HDD
1x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
73.2GB HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS SSD
100GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, SLC, 2.5-inch, 6Gb/s
N8150-709
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, SCL, 2.5-inch, 6Gb/s
N8150-710
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.10 Up to eight Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed. Up to two different kinds of drives can be mixed in one system A large-capacity RAID array configuration requires long-time rebuilding when to recover from the
failure. In order to improve the reliability, RAID 6 or RAID 60 configuration, which supports two hard drives failures, is recommended as the redundancy becomes invalid during the system recovery.
NEC Corporation Revision 4.0 – December 21, 2012 28
For VMware ESXi 5.x installation, to download the CIM provider is required. For VMware ESXi 5.x systems, monitoring the status of a RAID array with NEC ESMPRO is not
supported.
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA
(Standard)
Cable
Internal SATA Cable
4 x Single SATA to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA, RAID 0/1/10 capable
(Standard)
Cable
Internal SATA Cable
4 x Single SATA to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355

4.3 Hot Plug 3.5-inch Drive Configuration

4.3.1 Up to four Drives with Embedded SATA non-RAID Controller
NOTE:
Hot plug insertion/removal is not supported with the configuration.
4.3.2 Up to four Drives with Embedded SATA RAID Controller
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Embedded SATA RAID Controller does not support RAID 10 configured with 2 TB and 3 TB HDDs. All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 4.0 – December 21, 2012 29
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i RAID 0/1/10, 512MB cache, Int. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 512MB cache, Int.8, PCIe 2.0 x8 , SAS 6Gb/s, SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 3 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-355
4.3.3 Up to four Drives with RAID 0/1 Controller with 512 MB Cache
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.3.4 Up to four Drives with RAID 5/6 Controller with 512 MB Cache
NOTE:
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 4.0 – December 21, 2012 30
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9267-8i RAID 0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0 x8, SAS 6Gb/s, SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-153
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 3 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-355
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9265CV-8i (with CV) RAID0/1/5/6/10/50/60, 1GB Cache, Int. 8ports, PCIe 3.0(x8), 6Gb/s, flash cache protection modules included
N8103-152
Cable
Internal SAS/SATA Cable
1 x mini-SAS to 1 x mini-SAS
(Standard)
Drive Cage
3.5-inch Hot Plug Drive Cage Kit
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 1 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 2 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1x 3 TB SATA HDD, 3. 5-inch, 6Gb/s, 7,200 rpm
N8150-355
4.3.5 Up to four Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.3.6 Up to four Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All hard drives within a RAID array should be of the same capacity. For VMware ESXi 5.x installation, to download the CIM provider is required. For VMware ESXi 5.x systems, monitoring the status of a RAID array with NEC ESMPRO is not
supported.
NEC Corporation Revision 4.0 – December 21, 2012 31
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Internal
1 slot available
Internal Slim DVD-ROM drive
Slim DVD-ROM drive
N8151-100
Internal DVD Super Multi Drive
Slim DVD Super Multi drive, not including writing software
N8151-104F
External
External DVD-ROM drive
Slim DVD-ROM drive, Bus powered, 0.8 A required
N8160-85
Category
Product Name / Description
Part Number
GbE
1000BASE-T Adapter
Broadcom ® BCM5718 Gigabit Ethernet Controller PCIe 2.0 x1
N8104-138
Dual Port 1000BASE-T Adapter
Broadcom ® BCM5718 Gigabit Ethernet Controller PCIe 2.0 x1
N8104-132
Quad Port 1000BASE-T Adapter
Broadcom ® BCM5719 Gigabit Ethernet Controller PCIe 2.0 x4
NOTE:
- Network cables with RJ-45 plug covers cannot be used.
- Jumbo frames are supported.on Windows Server 2008 R2
and Redhat Enterprise Linux operating systems.
N8104-133
10GbE
Ctrlr
10GBASE Adapter (SFP+/2ch)
Broadcom NetXtreme II BCM957711 10G SFP+ Dual Port Network Interface Card PCIe 2.0 x8
NOTE:
- N8104-129 SFP+ Module is required to connect with an
optical cable.
- Up to 2 SFP+ Modules can be installed.
- Supports up to 2 adapters covering 10Gb Converged Network
Adapter and 10Gb Network Adapter.
N8104-128
Dual Port 10Gb Converged Network Adapter
BROCADE 1020 Dual Port 10Gbps Converged Network Adapter PCIe 2.0 x8, 2 x SFP modules
NOTE:
- Supports up to two adapters of10Gb Converged Network
Adapter and 10Gb Network Adapter.
N8104-131
Module
SFP+ Module (10G-SR)
1 x SFP+ Module for N8104-128
N8104-129

5 Optical Drive

NOTE:
Up to 1 optical drive can be connected.

6 PCI Riser Card / PCI Card

Please refer to Supported PCI Cards and Installable Slots with regard to the position of PCI slot which can mount PCI card supported.

6.1 Network Interface Controller

NEC Corporation Revision 4.0 – December 21, 2012 32
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Network Interface
Team
Operating Systems
1GbE NIC
Embedded 1GbE NIC and N8104-138/-132/-133
Up to four teams per one system Up to four ports per one team
Windows Server 2003 R2 Windows Server 2008 Windows Server 2008 R2 Red Hat Enterprise Linux
10GbE NIC
N8104-128
Up to two teams per one system Up to two ports per one team
Windows Server 2008 Windows Server 2008 R2 Red Hat Enterprise Linux
Categor
Network Interface
Operating Systems
1GbE
Embedded 1GbE NIC
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
N8104-138
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
N8104-132
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
N8104-133
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
10GbE
N8104-128
Windows Server 2008, Windows Server 2008 R2, Red Hat Linux, VMware
Category
Product Name / Description
Part Number
Controller
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9285-8e RAID0/1/5/6/10/50/60, 1GB, Ext. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 6Gb/s
N8103-160
RAID BBU
RAID Battery Backup Unit
for LSI MegaRAID SAS 9285-8e
N8103-162
NIC Teaming feature – NIC Teaming and bonding features
See the table below for supported network interfaces and OS combinations. Windows supports BASP (Broadcom Advanced Server Program) teaming while Linux supports teaming
with bonding function supported by OS.
NOTE:
NIC Teaming feature is not supported on iSCSI interfaces. The network interfaces for NIC teaming must be the same. When 10GbE and 1GbE NIC teaming are mixed, the teams must be up to four per one system.
Using iSCSI
See the table below for supported network interfaces and OS combinations.
NOTE:
NIC Teaming feature is not supported on iSCSI interfaces.

6.2 External Storage Controller

6.2.1 RAID Controller
NOTE:
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in
order to minimize the risk of becoming multiple hard drives failure during the RAID rebuilding process.
It is recommended to set RAID array configuration drives less than eight to minimize the risk of
becoming multiple hard drives failure.
NEC Corporation Revision 4.0 – December 21, 2012 33
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Fibre Channel
Fibre Channel Controller (1ch)
Emulex LightPulse LPe1250-F8 Host Bus Adapter 8Gb/s, Optical, PCIe 2.0(x8)
N8190-153
Fibre Channel Controller (2ch)
Emulex LightPulse LPe12002-M8 Host Bus Adapter 8Gb/s, Optical, PCIe 2.0(x8)
N8190-154
SAS
SAS Controller
LSI SAS9212-4i4 Host Bus Adapter 6Gb/s SAS, Int. 4(7-pin SATA ) / ext. 4(SFF-8088), PCIe 2.0(x8)
N8103-142
Product Name / Description
Part Number
Serial Port Adapter
Serial port fixed to PCI bracket
N8117-01A
Product Name / Description
Part Number
450W Hot Plug Power Supply
1 x 450 Watt 80 PLUS® Platinum Power Supply
N8181-86F
800W Hot Plug Power Supply
1 x 800 Watt 80 PLUS® Platinum Power Supply
N8181-87F
Product Name / Description
Part Number
Trusted Platform Module Kit
TPM 1.2 module
N8115-11
6.2.2 Fibre Channel / SAS Controller

6.3 Serial Port Adapter

NOTE:
Up to one Serial Port Adapter can be installed.

7 Other Add-in Components

7.1 Power Supply

NOTE:
The power units must be the same to configure redundancy. Use the NEC Power Supply Selector to select appropriate size for power units. For details, please
visit the NEC website at:
http://www.nec.com/en/global/prod/express/collateral/tools/PowerSelector_G01.xls

7.2 Trusted Platform Module Kit

NOTE:
The kit is not available in China. The kit is not removable after attachment. "TPM Support" in BIOS setup menu must be activated prior to use of this product. To use Windows BitLocker drive encryption, be sure to keep the "recovery password" of BitLocker
function. The recovery password is required to restore data for hardware replacement during a system error.
NEC Corporation Revision 4.0 – December 21, 2012 34
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Product Name / Description
Part Number
Internal Flash Memory
Internal flash memory to enable software and tools in the EXPRESSBUILDER DVD without DVD media
NOTE: Before use, software and tools must be copied from the EXPRESSBUILDER DVD to the
flash memory. The following operations can be performed with the flash memory:
- Installation of Windows server with express setup
- Installation of Starter Packthe package of NEC qualified drivers and system setting
tools
- Installation of NEC ESMPRO Agent and Universal RAID Utility
- Performance of the Test and Diagnosis Tool
N8115-10
Category
Product Name / Description
Part Number
External
Flash FDD
USB flash emulating USB floppy disk, Native capacity 1.44 MB
N8160-86
Product Name / Description
Part Number
Front Bezel
Front bezel for R120d-1E
N8146-32F

7.3 Internal Flash Memory

7.4 Flash FDD

Choose the Flash FDD if you need to prepare an alternative device for a floppy drive.
NOTE:
Up to one drive can be connected.

7.5 Front Bezel

NEC Corporation Revision 4.0 – December 21, 2012 35
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Category
Product Name / Description
Part Number
Drawer w/ KVM
Drawer
17-inch LCD Console Drawer (8port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM switch, 1U height
N8143-77F
Cable
Switch Unit Connection Cable Set (USB, 1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB, 3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(03)
Switch Unit Connection Cable Set (USB, 5m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(05)
Drawer w/o KVM
Drawer
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height, 4-pin USB B to 4-pin USB A cable 2 m, PS/2 Y-splitter cable 2m, 15-pin mini D-sub VGA cable 2 m
N8143-76F
17inch LCD Console Drawer (1port)
17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad with 3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8 m, Two PS/2 cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m
N8143-84F
Keypad
Keyboard Unit (JP)
JP 108-keys Keyboard with 10-key for N8143-84F 17inch LCD Console Drawer (1port)
N8143-85
Keyboard Unit (UK)
UK 104-keys Keyboard with 10-key, for N8143-84F 17inch LCD Console Drawer (1port)
N8143-87
Category
Product Name / Description
Part Number
KVM Switch
Server Switch Unit (8 server)
1U USB 8 port KVM switch
N8191-12F
Cable
KVM
Switch Unit Connection Cable Set (USB,1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB,3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(03)
Switch Unit Connection Cable Set (USB,3m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
K410-118(05)
Cascading
Switch Unit Connection Cable 1.8 m
1.8 m, 1 x 15-pin mini D-sub - 1x 15-pin mini D-Sub / 2x PS/2
K410-119(1A)

8 Add-on Components

8.1 17-inch LCD Console Drawer

8.2 KVM Switch

NEC Corporation Revision 4.0 – December 21, 2012 36
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Product Name / Description
Part Number
Cable Management Arm 1U Kit
For R120d-1E
N8143-79
Product Name / Description
Part Number
Remote KVM and Media License Kit
License for one server. Remote KVM and remote media are enabled regardless of OS status.
Remote KVM:
- Displays a graphics console on the web browser of the remote terminal (PC/server).
- Controls keyboard and mouse via the remote terminals' web browser
Remote media: Enables the user to use the CD / DVD / FD / Flash memory of the remote terminals
(PC/server) as if accessing the local drives.
NOTE: Remote KVM and remote media features are not available for virtual machines.
N8115-04

8.3 Cable Management Arm

NOTE:
The Cable Management Arm cannot be attached when the back parts of the slide-rail are removed.

8.4 Server Management License

The server integrates the EXPRESSSCOPE Engine 3 as standard. Refer to Server Management for the standard management features. For more extensive remote KVM and remote media features, choose the following kit.
NEC Corporation Revision 4.0 – December 21, 2012 37
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Standard
With Remote KVM
and Media License
kit
Hardware monitoring
Temperature/voltage/power/ fan /degeneration (memory/hard drive)


Hardware configuration information collection


Hardware event log collection


Boot monitoring
BIOS/POST stall, Booting, OS stall, shutdown
1
1
Alerting
HW error, Boot error , and OS panic (by SNMP, E-Mail)

Remote KVM (via LAN)
POST/BIOS setup, ROM utility
2

Panic screen, Boot screen
2, 3, 4

CUI-based screen (OS console)
2, 4

GUI-based screen (OS console)
-

Remote control (via LAN)
Remote reset/power on-off/ dump


Remote power capping


BIOS/BMC FW update


Remote BIOS setup(partial configuration only)


OS shutdown
1
1
Remote media (CD/DVD/FD/USB)
-

CLP (Command Line Protocol) (DMTF compliant)


Remote control via Web browser (multi user login at the same time)


Scheduling (without UPS)
1
1
Maintenance
EXPRESSSCOPE® Profile key (Backup/restore BIOS/BMC setup information)


Others
Set automatic IP address via DNS/DHCP


LDAP/Active Directory verification/user control


Clock synchronization of main unit and the RTC


Access log collection


Industry standard
IPMI
2.0
2.0

References

Server Management

The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system management features listed in the table below.
1
The feature is not supported on VMware ESXi systems.
2
The optional serial port is not available for the feature.
3
Monitoring boot screens is not supported on VMware systems.
4
In VMware systems, only the direct console user interface is supported.
NEC Corporation Revision 4.0 – December 21, 2012 38
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Part number
Product Name
WS 2012
WS 2008R2
WS 2008
WS 2008 x64
WS 2003R2
WS 2003R2 x64
RHEL 6
RHEL 6 x64
RHEL 5
RHEL 5 x64
ESXi 5.1
ESXi 5.0
ESX 4.1
-
Embedded SATA non-RAID Controller


- - Embedded SATA RAID Controller
-

- - - - - - - - Embedded 1GbE NIC

N8103-149
RAID Controller (512 MB, RAID 0/1)

N8103-150
RAID Controller (512 MB, RAID 0/1/5/6)

N8103-151
RAID Controller (1 GB,RAID 0/1/5/6)

N8103-152
RAID Controller (1 GB,RAID 0/1/5/6)


-
-

N8103-160
RAID Controller (1 GB,RAID 0/1/5/6)

N8103-142
SAS Controller


-
N8190-153
Fibre Channel Controller

N8190-154
Fibre Channel Controller (2ch)

N8104-138
1000BASE-T adapter

N8104-132
Dual Port 1000BASE-T Adapter

N8104-133
Quad Port 1000BASE-T Adapter

N8104-128
10GBASE adapter (SFP+/2ch)


-
-

N8104-131
Dual Port 10Gb Converged Network Adapter


-
-


- - -
Slots
Part Number
Product Name
#1A
#1B
#1C
N8103-149
RAID Controller (512 MB, RAID 0/1)

- - N8103-150
RAID Controller (512 MB, RAID 0/1/5/6)

- - N8103-151
RAID Controller (1 GB,RAID 0/1/5/6)

-
-
N8103-152
RAID Controller (1 GB,RAID 0/1/5/6)

-
-
N8103-160
RAID Controller (1 GB,RAID 0/1/5/6)
-


N8103-142
SAS Controller
-


N8190-153
Fibre Channel Controller
-


N8190-154
Fibre Channel Controller (2ch)
-


N8104-138
1000BASE-T adapter
-


N8104-132
Dual Port 1000BASE-T Adapter
-


N8104-133
Quad Port 1000BASE-T Adapter
-


N8104-128
10GBASE adapter (SFP+/2ch)
-


N8104-131
Dual Port 10Gb Converged Network Adapter
-


N8117-01A
Serial Port Adapter
-



OS Support Matrix for PCI Cards

Supported PCI Cards and Installable Slots

NEC Corporation Revision 4.0 – December 21, 2012 39
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Processors
E5-2403
E5-2407
E5-2420
E5-2430
E5-2430L
E5-2450
E5-2470
200 VAC input
800 Watt PSU
407 VA / 399 Watt
434 VA / 426 Watt
493 VA / 483 Watt
495 VA / 485 Watt
470 VA / 461 Watt
515 VA / 506 Watt
517 VA / 507 Watt
450 Watt PSU
307 VA / 301 Watt
316 VA / 311 Watt
400 VA /393 Watt
402 VA / 396 Watt
362 VA / 356 Watt
469 VA / 461 Watt
470 VA / 462 Watt
100 VAC input
800 Watt PSU
411 VA / 403 Watt
438 VA / 430 Watt
497 VA / 487 Watt
499 VA / 489 Watt
474 VA / 465 Watt
520 VA / 511 Watt
522 VA / 512 Watt
450 Watt PSU
310 VA /304 Watt
319 VA / 314 Watt
404 VA / 396 Watt
406 VA / 399 Watt
365 VA / 359 Watt
473 VA / 465 Watt
474 VA / 466 Watt
Processors
E5-2403
E5-2407
E5-2430
E5-2430L
E5-2450
200 VAC input
450 Watt PSU
287 VA / 282 Watt
309 VA / 303 Watt
391 VA / 384 Watt
372 VA / 365 Watt
474 VA / 468 Watt
100 VAC input
450 Watt PSU
289 VA / 284 Watt
312 VA / 306 Watt
394 VA / 387 Watt
375 VA / 368 Watt
478 VA / 472 Watt

Maximum power consumption

See the table below for the maximum power consumption based on type of power supplies installed. The power consumption was measured in 40 degree Celsius (104 degree Fahrenheit) environment.

2.5-inch Drive Model

3.5-inch drive model

NEC Corporation Revision 4.0 – December 21, 2012 40
CONFIGURATION GUIDE – NEC Express5800/R120d-1E

Copyright Notice and Liability Disclaimer

The information contained herein is subject to change without notice. Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries Intel and Xeon are registered trademarks or trademarks of Intel Corporation or its subsidiaries in the United
States and other countries. Linux is a trademark of Linus Torvalds. Red Hat is a registered trademark of Red Hat, Inc. in the U.S. All other products, brands, or trade names used in this document are trademarks or registered trademarks
of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less.
NEC Corporation Revision 4.0 – December 21, 2012 41
CONFIGURATION GUIDE – NEC Express5800/R120d-1E
Revision
Date
Description
4.0
December 21, 2012
Other:
Add Windows Server 2012 to the list of operating system supported Support N8103-152 RAID Controller on VMware ESXi 5.x systems Support 10GbE NIC teaming with two or more 10GbE NIC cards. Update OS support matrix
3.0
October 31, 2012
New products added:
RAID Controller (1GB, RAID 0/1/5/6) / N8103-152 200GB SSD / N8150-711
400GB SSD / N8150-712
Discontinued products removed:
100GB SSD / N8150-707 SAS Controller / N8103-104A
Other:
Add VMware ESXi 5.1 to the list of operating system supported Support bonding feature on Linux operating system using 10GbE NIC Update Regulatory list Update OS support matrix
2.0
August 3, 2012
New products added:
17-inch LCD Console Drawer (1port) / N8143-84F Keyboard Unit (JP) / N8143-85 Keyboard Unit (UK) / N8143-87 Switch Unit Connection Cable 1.8 m / K410-119(1A)
Other:
Add description for expansion slots Update maximum memory speed table Support jumbo frames in quad-channel 1GbE NIC
Add description for using iSCSI Add OS support information for embedded controllers into support matrix table Add maximum power consumption table Remove 2.5-inch 10Krpm SATA drives
1.0
May 14, 2012
Initial release

Revision History

NEC Corporation Revision 4.0 – December 21, 2012 42
Loading...
