NEC Express Server Express5800 Series

Express5800/R110g-1E EXP283A/EXP284A User’s Guide

Model Number: N8100-2180F/2181F/2182F/2183F

Chapter 1 General Description Chapter 2 Preparations Chapter 3 Setup Chapter 4 Appendix

10.106.03-101.01

June. 2014, 1st Edition

Documents for This Product

Documents for this product are provided as booklets ( ) or as electronic manuals ( ) in the EXPRESSBUILDER disc ( ).

Precautions for Use

Getting Started

EXPRESSBUILDER

PDF

User’s Guide

Chapter 1: General Description Overviews, names, and functions of the server’s parts

Chapter 2: Preparations Installation of additional options, connection of peripheral devices,

Chapter 4: Appendix Specifications and other information

Chapter 3: Setup System BIOS configurations and summary of EXPRESSBUILDER

Describes points of caution to ensure the safe use of this server. Read these cautions before using this server.

Describes how to use this server, from unpacking to operations. See this guide at first and confirm an outline of this product.

and proper location for this server

PDF

Installation Guide (Windows)

Chapter 1: Installing Windows Installation of Windows and drivers, and important information for

Chapter 2: Installing the Bundled

PDF

Maintenance Guide

Chapter 1: Maintenance Server maintenance and troubleshooting

Chapter 2: Useful Features The details of system BIOS settings, RAID Configuration Utility, and

PDF

Notations Used in This Document

Notations used in the text

In addition to safety-related symbols urging caution, three other types of notations are used in this document. These notations have the following meanings.

Important Indicates critical items that must be followed when handling the server or operating software. If

the procedures described are not followed, server failure, data loss, and other serious

malfunctions could occur. Note Indicates items that must be confirmed when handling the server or operating software. Tips Indicates information that is helpful to keep in mind when using this server.

Optical disk drive

This server is equipped with one of the following drives, dep ending on the purchase order. These drives are referred to as optical disk drives in this document.

 DVD-ROM drive  DVD Super MULTI drive

Hard disk drive

Unless otherwise stated, hard disk drive described in this document refers to the following.

 Hard disk drive (HDD)  Solid state drive (SSD)

Removable media

Unless otherwise stated, removable media described in this document refers to the following.

 USB flash drive  Flash FDD

Express5800/R110g-1E User’s Guide

Notations Used in This Document

Abbreviations of Operating Systems (Windows)

Windows Operating Systems are referred to as follows.

See Chapter 1 (1.2 Supported Windows OS) in Installation Guide (Windows) for detailed information.

Notations in this document Official names of Windows

Windows Server 2012 R2 Standard

Windows Server 2012 R2

Windows Server 2012 R2 Datacenter

Windows Server 2012 Standard

Windows Server 2012

Windows Server 2012 Datacenter

Windows Server 2008 R2 Standard

Windows Server 2008 R2

Windows Server 2008 R2 Enterprise Windows Server 2008 Standard

Windows Server 2008 *

Windows Server 2008 Enterprise

* Windows Server 2008 is 32-bit(x86) only in this manual.

Express5800/R110g-1E User’s Guide

Trademarks

EXPRESSSCOPE is a registered trademark of NEC Corporation. Microsoft, Windows, Windows Server, Windows Vista, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States. AT is a registered trademark of International Business Machines Corporation of the United States and other countries. LSI and the LSI logo design are trademarks or registered trademarks of LSI Corporation. Adobe, th e Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated. PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group. Linux is a trademark or registered trademark of Linus Torvalds in Japan and other countries. Red Hat® and Red Hat Enterprise Linux are trademarks or registered trademarks of Red Hat, Inc. in the United States and other countries.

All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respecti ve trademark owners.

License Notification

The System BIOS of this product contains open source software for the following license.

EDK FROM TIANOCORE.ORG

following conditions are met:

Redistributions of source code must retain the above copyright notice, this list of conditions and the following

disclaimer.

- Redistributions in binary form must reproduce the above copyright notice, this list of conditions and th e following

disclaimer in the documentation and/or other materials provided with the distribution. Neither the name of the Intel Corporation nor the names of its contributors may be used to en dorse or promote

products derived from this software without specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Copyright (c) 2004 - 2007, Intel Corporation All rights reserved. This program and the accompanying materials are licensed and made av ailable under the terms and conditions of the BSD License which accompanies thi s distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Express5800/R110g-1E User’s Guide

Regulatory Notices

FCC Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Industry Canada Class A Emission Compliance Statement/ Avis de conformité à la réglementation d'Industrie Canada:

CAN ICES-3(A)/NMB-3(A)

CE / Australia and New Zealand Statement

This is a Class A product. In domestic environment this product may cause radio interference in which case the user may be required to take adequate measures (EN55022).

BSMI Statement

Disposing of your used product

In the European Union

EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes Information and Communication Technology (ICT) equipment or electrical accessories, such as cables or DVDs. When disposing of used products, you should comply with applicable legislation or agreements you may have. The mark on the electrical and electronic products only applies to the current European Union Member States.

Outside the European Union

If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority and ask for the correct method of disposal.

Express5800/R110g-1E User’s Guide

Turkish RoHS information relevant for Turkish market

EEE Yönetmeliğine Uygundur

CCC声明

部件名称

印刷线路板 ×○○○○○ HDD、DVD等 ×○○○○○ 机箱、支架 ○○○○○○ 电源 ×○○○○○ 键盘 ×○○○○○

其他（电缆、鼠标

○：表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006标准规定的限量要求以下。 ×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ /T 11 363 -2 006 标准规定的限量要求。

铅

×○○○○○

汞

有毒有害物质或元素

镉

六价铬

多溴联苯

多溴二苯醚

Vietnam RoHS information relevant for Vietnam market

Regulatory Notices

Complying with "CIRCULAR, No.30/2011/TT-BCT (Hanoi, August 10 2011), Temporary regulations on content limit for certain hazardous substances in electrical products"

Declaration of Conformity

with the requirements of Technical Regulation on the Restriction Of the use of certain Hazardous

Substances in Electrical and Electronic Equipment

(adopted by Order №1057 of Cabinet of Ministers of Ukraine)

The Product is in conformity with the requirements of Technical Regulation on the Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment (TR on RoHS).

The content of hazardous substance with the exemption of the applications listed in the Annex №2 of TR on RoHS:

Lead (Pb) – not over 0,1wt % or 1000wt ppm;

2. Cadmium (Cd) – not over 0,01wt % or 100wt ppm;

3. Mercury (Hg) – not over 0,1wt % or 1000wt ppm;

4. Hexavalent chromium (Cr6+) – not over 0,1wt % or 1000wt ppm;

5. Polybrominated biphenyls (PBBs) – not over 0,1wt % or 1000wt ppm;

6. Polybrominated diphenyl ethers (PBDEs) – not over 0,1wt % or 1000wt ppm.

Express5800/R110g-1E User’s Guide

Regulatory Notices

Декларація про Відповідність

Вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в

електричному та електронному обладнанні

(затвердженого Постановою №1057 Кабінету Міністрів України)

Виріб відповідає вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (ТР ОВНР).

Вміст небезпечних речовин у випадках, не обумовлених в Додатку №2 ТР ОВНР, :

ь (Pb) – не перевищує 0,1 % ваги речовини або в концентрації до 1000 частин на

1. свине

мільйон;

2. кадмій (Cd) – не перевищує 0,01 % ваги речовини або в концентрації до 100 частин на мільйон;

3. ртуть (Hg) – не перевищує 0,1 % ваги речовини або в концентрації до 1000 частин на

мільйон;

4. шестивалентний хром (Cr6+) – не перевищує 0,1 % ваги речовини або в концентрації до

на мільйон;

1000 ча

стин

5. полібромбіфеноли (PBB) – не перевищує 0,1% ваги речовини або в концентрації до 1000

частин на мільйон;

6. полібромдефенілові ефіри (PBDE) – не перевищує 0,1 % ваги речовини або в

концентрації до 1000 частин на мільйон.

Декларация о Соответствии

Требованиям Технического Регламента об Ограничении Использования некоторых Вредных

Веществ в электрическом и электронном оборудовании

(утверждённого Постановлением №1057 Кабинета Министров Украины)

Изделие соответствует требованиям Технического Регламента об Ограничении Использования некоторых Вредных Веществ в электрическом и электронном оборудовании (ТР ОИВВ).

Содержание вредных веществ в случаях, не предусмотренных Дополнением №2 ТР ОИВВ:

) – не превышает 0,1 % веса вещества или в концентрации до 1000

1. свине

ц (Pb

миллионных частей;

2. кадмий (Cd) – не превышает 0,01 % веса вещества или в концентрации до 100 миллионных частей;

3. ртуть (Hg) – не превышает 0,1 % веса вещества или в концентрации до 1000 миллионных частей;

4. шестивалентный хром (C r6+)– не превышает 0,1 % веса вещества или в концентрации до 1000 миллионных частей;

5. по

либром

бифенолы (PBB) – не превышает 0,1 % веса вещества или в концентрации до

1000 миллионных частей;

6. полибромдифеноловые эфиры (PBDE) – не превышает 0,1 % веса вещества или в

концентрации до 1000 миллионных частей.

Express5800/R110g-1E User’s Guide

Warnings and Additions to This Document

W arnings and Additions to This Document

1. Unauthorized reproduction of the contents of this document, in part or in its entirety, is prohibited.

2. This document is subject to change at any time without notice.

3. Do not make copies or alter the document content without permission from NEC Corporation.

4. If you have any concerns, or discover errors or omissions in this document, contact your sales representative.

5. Regardless of article 4, NEC Corporation does not take responsibility for effects resulting from your operations.

6. The sample values used in this document are not the actual values.

Keep this document for future reference.

Latest editions

This document was created based on the information available at the time of its creation. T he screen images, messages and procedures are subject to change without notice. Substitute as appropriat e when content has been modified.

The most recent version of the guide, as well as other related docume nts, is also available for download from the following website.

http://www.nec.com/

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

The following provides information required to use yo ur ser ver safely and properl y. For details of names in this section, see Names and Functions of Parts in this document.

Safety precautions

Follow the instructions in this document for the safe use of the NEC Express server. This guide describes hazardous parts of the server, possible hazards, and how to avoid them. Server

components with possible danger are indicated with a warning label placed on or around them. WARNING or CAUTION is used to indicate a danger in this guide or on warning labels. Each term is defined as

follows:

WARNING

Precautions and notices against hazards are presented with one of the following three symbols. Each symbol is defined as follows:

CAUTION

Indicates there is a risk of death or serious personal injury

Indicates there is a risk of burns, other personal injury, or property damage

Attention This symbol indicates the presence of a hazard if

the instruction is ignored.

Prohibited Action

Mandatory Action

An image in the symbol illustrates the hazard type.

This symbol indicates prohibited actions. An image in the symbol illustrates a particular prohibited action.

This symbol indicates mandatory actions. An image in the symbol illustrates a mandatory action to avoid a particular hazard.

(Example)

(Electric shock risk)

(Example)

(Do not disassemble)

(Example)

(Disconnect a plug)

Express5800/R110g-1E User’s Guide

(A label example used in this guide)

Symbol to draw

attention

Description of a warning

Precautions for Use (Be Sure to Read)

Term indicating a degree of danger

WARNING

Use only the specified outlet

Use a grounded outlet with the specified voltage. Use of an improper power source may cause a fire or a power leak.

Symbols used in this document and on warning labels

Attentions

Indicates the presence of electric shock hazards.

Indicates the presence of a hot surface or component. Touching this surface could result in bodily injury.

Indicates there is a risk of explosion.

Indicates there is a risk of fire or fumes.

Indicates there is a risk of electric shock for the multiple receiving.

Indicates the presence of mechanical parts that can result in bodily injury.

Indicates the presence of mechanical parts that can result in pinching or other bodily injury.

Indicates the presence of laser beam that cause blindness.

Indicates a general notice or warning that cannot be specifically identified.

Prohibited Actions

Do not disassemble, repair, or modify the server. Otherwise, an electric shock or fire may be caused.

Do not touch the component specified by this symbol. Otherwise, an electric shock or burn may be caused.

Do not place the server near the fire. Otherwise, a fire may be caused.

Mandatory Actions

Unplug the power cord of the server. Otherwise, an electric shock or fire may be caused.

Make sure equipment is properly grounded. Otherwise, an electric shock or fire may be caused.

Do not touch the server with wet hand. Otherwise, an electric shock may be caused.

Do not use the server in the place where water or liquid may pour. Otherwise, an electric shock or fire may be caused.

Indicates a general prohibited action that cannot be specifically identified.

Indicates a mandatory action that cannot be specifically identified. Make sure to follow the instruction.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Safety notes

This section provides notes on using the server safely. Read this section carefully to ensure proper and safe use of the server. For symbols, see Safety precautions.

General

Do not use the server for services where human life may be at stake or high reliability is required.

This server is not intended for use in medical, nuclear, aerospace, mass transit or other applications where human life may be at stake or high reliability is required, nor is it intended for use in controlling such applications. We disclaim liability for any personal injury and property damages caused by such use of this server.

Do not use the server if any smoke, odor, or noise is present.

If smoke, odor, or noise is present, immediately turn off the server and disconnect the power plug from the outlet, then contact the store where you purchased the product or your sales representative. Using the server in such conditions may cause a fire.

Do not insert needles or metal objects.

Do not insert needles or metal objects into ventilation holes in the server or openings in the optical disk drive. Doing so may cause an electric shock.

Use a rack that conforms to the designated standard

This server can be mounted onto a 19-inch rack that conforms to EIA standards. Do not mount the server onto any rack that does not conform to EIA standards. Doing so may cause a server malfunction, personal injury, or damage to peripheral devices. For more information about racks that can be used with the server, consult with your sales representative.

Use the server only under the specified environment

Do not install the server rack in any environment that is not suitable for installation. Installation in an unsuitable environment is harmful for the server and other systems installed in the rack

and may cause fire or personal injury due to the rack falling. For a detailed explanation on installation environments or seismic reinforcement, see the instruction manual supplied with the rack or consult with your sales representative.

WARNING

Keep water or foreign matter away from the server.

Do not let any liquid such as water or foreign materials including pins or paper clips enter the server. Failure to follow this warning may cause an electric shock, a fire, or failure of the server. When such things accidentally enter the server, immediately turn off the power and disconnect the power plug from the outlet. Do not disassemble the server, and contact the store where you purchased the product or your sales representative.

CAUTI ON

Express5800/R110g-1E User’s Guide

Rack installation

Precautions for Use (Be Sure to Read)

Do not attempt to carry or install the server alone

More than two people are required to carry or install the rack. Otherwise, the rack may fall, resulting in personal injury or damage to peripheral devices. In particular, tall racks such as a 42U rack become unstable unless steadied with a stabilizer. Make sure that two or more people hold the rack to carry or install the rack.

Do not install with the load weight distributed unevenly

To avoid unevenly distributing the load of the rack and server, install a stabilizer or connect multiple racks to distribute the weight. Otherwise, the rack may fall, resulting in personal injury.

Do not install components alone, and check the door hinge pins of the rack

Two or more people are required to install the rack components such as the door or rails. When installing the door, make sure that both upper and lower hinge pins are held in place. Inco mplete attachment may cause components to fall off as well as personal injury.

Do not extend any device from the rack that is not stabilized

When extending a device from the rack, make sure that the rack is stable (by using a stabilizer or seismic reinforcement). Otherwise, the rack may fall, resulting in personal injury.

Do not extend more than one device out of the rack

Extending multiple devices from the rack may cause the rack to fall, resulting in personal injury. Extend only one device at one time.

Do not exceed the rated capacity of the power supply when connecting devices

To prevent burn injuries, fire, and damage to the server, make sure the load on the branch circuit that supplies power to the rack will not exceed the rated load. For inquiries regarding the installation or wiring of the power supply system, consult with the company that performed the installation or wiring, or the power company that services your area.

CAUTI ON

Express5800/R110g-1E User’s Guide

Power supply and power cord use

Precautions for Use (Be Sure to Read)

Do not hold the power plug with a we t hand.

Do not disconnect/connect the plug while your hands are wet. Failure to follow this warning may cause an electric shock.

Do not connect the ground wire to a gas pipe.

Never connect the ground wire to a gas pipe. Failure to follow this warning may cause a gas explosion.

Power supply cord

This server may be shipped with multiple power supply which requires more than one connector to AC mains.

The AC power cord(s) is consider as the mains disconnected device for the server, always disconnect the power supply cord(s) before opening up or servicing the server.

Power supply

The power supplies in your system may produce high voltages and energy hazards, which can cause bodily harm. Unless you are instructed otherwise, only trained service technicians are authorized to remove the covers and access of the components inside the system.

Plug into a proper power source.

Use a grounded outlet with the specified voltage. Use of an outlet with a voltage other than that specified causes fire and electrical leakage. Do not install the server in any environment that requires an extension cord. Connecting to a cord that does not conform to the power supply specs of the server causes overheating, resulting in fire.

If you want to use an AC cord set with a ground wire of class 0I, be sure to connect the ground wire before inserting the power plug into the outlet. Before disconnecting the ground wire, be sure to disconnect the power plug from the output.

WARNING

CAUTI ON

Do not connect many cords into a single outlet by using extension cords.

The electric current exceeding the rated flow overheats the outlet, which may cause a fire.

Insert the power plug into the outlet as far as it goes.

Heat generation resulting from a halfway inserted power plug (imperfect contact) may cause a fire. Heat will also be generated if condensation is formed on dusty blades of the halfway inserted plug, increasing the possibility of fire.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Do not use any unauthorized interface cable.

Use only the interface cables provided with the server. Electric current that exceeds the amount allowed could cause fire. Also, observe the following precautions to prevent electrical shock or fire caused by a damaged power cord.

 Do not stretch the cord harness  Do not bend the power cord.  Do not twist the power cord  Do not step on the power cord.  Uncoil the power cord before use  Do not secure the power cord with staples or

equivalents

Do not use the attached power cord for any other devices or usage.

The power cord that comes with your server is designed aiming to connect with this server and to use with the server, and its safety has been tested. Do not use the attached power cord for any other purpose. Doing so may cause a fire or an electric shock.

Do not pull out a cord by gripping the cord part.

Pull a cord straight out by gripping the connector part. Pulling a cord by gripping the cord part or applying extra pressure to the connector part may damage the cord part, which may cause a fire or electric shock.

CAUTI ON

 Do not pinch the power cord  Keep chemicals away from the power cord  Do not place any object on the power cord  Do not alter, modify, or repair the power cord  Do not use a damaged power cord (replace the

damaged power cord with a power cord of the same standard. For information on replacing the power cord, contact the store where you purchased the product or a sales representative)

Express5800/R110g-1E User’s Guide

Installation, relocation, storage, and connection

Precautions for Use (Be Sure to Read)

CAUTI ON

Do not attempt to lift the server by holding the front bezel.

Securely hold the server by the base to move or lift. Do not attempt to lift it by holding the front bezel. Doing so may cause the front bezel to come off, which may cause not only breakage of the server but also cause the server to fall on to persons resulting in personal injury.

Do not install the server in any place other than specified.

Do not install the server in the following places or any place other than specified in this User's Guide. Failure to follow this instruction may cause a fire.

 A dusty place  A humid place such as near a boiler  A place exposed to direct sunlight  An unstable place

Do not use the server in an environment where corrosive gas is presen t

Do not install the server in a place subject to corrosive gases including sodium chloride, sulfur dioxide, hydrogen sulfide, nitrogen dioxide, chlorine, ammonia, or ozone. Do not install the server in an environment that contains dust, chemicals that accelerate corrosion such as NaCl or sulfur, or conductive materials. Failure to follow this warning may cause the wiring on the printed wiring board to short-circuit, leading to fire. If you have any questions, contact the store where you purchased the product or a sales representative.

Do not install the server while the cover is removed

Do not install the server to a rack while the cover or other relevant items removed. Not only will the cooling effect within the server decrease, causing the server to malfunction, but also may allow dust to enter the server, resulting in fire or electrical shock.

Do not get your fingers caught in the rails

When mounting/removing the server onto/from the rack, be careful to avoid getting your fingers caught in the rails or cutting your fingers on the rails.

Do not apply any weight on the server when it is extended from the rack

Do not apply force on the server when it is extended from the rack. Doing so cause the frames to bend, which makes it impossible to be mounted on the rack. It also may cause the server to fall, resulting in personal injury.

Do not attempt to connect or disconnect the interface cable while the pow er cord is plugged into an outlet

Be sure to unplug the power cord from a power outlet before connecting/disconnecting any interface cable to/from the server. If the server is off-powered but its power cord is plugged to a power source, touching a cable or connector may cause an electric shock or a fire resulted from a short circuit.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

CAUTI ON

Use only the specified interface cable.

Use only interface cables provided by NEC and locate a proper device and connector before connecting a cable. Using an authorized cable or connecting a cable to an improper destination may cause a short circuit, resulting in a fire. Also, observe the following notes on using and connecting an interface cable.

 Do not use any damaged cable connector.  Do not step on the cable.  Do not place any object on the cable.  Do not use the server with loose cable connections.  Do not use any damaged cable.

Cleaning and working with internal devices

WARNING

Do not disassemble, repair, or alter the server.

Never attempt to disassemble, repair, or alter the server on any occasion except as described in this document. Failure to follow this warning may cause not only malfunction of the server but also an el ectric shock or fire.

Do not look into the optical disk drive

A laser beam used in the optical disk is harmful to the eyes. Do not look into or insert a mirror into the drive while the drive is powered on. If a laser beam (which is invisible) enters your eyes, you may lose your eyesight.

Do not attempt to remove lithium, NiMH, or Li-ion batteries by yourself.

The server contains the lithium, NiMH, or Li-ion battery (some optional devices have a lithium, NiMH, or Li-ion battery installed). Do not remove the battery by yourself. Placing a battery close to a fire or in the water may cause an explosion.

When the server does not operate appropriately due to the dead battery, contact the store you purchased the product or your sales representative. Do not attempt to disassemble the server to replace or recharge the battery by yourself.

Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the NEC. Do not dispose of batteries in a fire or with ho usehold waste. Contact your local waste disposal agency for the address of the nearest battery deposit site

Disconnect the power plug before cleaning the server.

Be to power off the server and disconnect the power plug from a power outlet before cleaning or installing/removing internal optional devices. Touching any internal device of the server with its power cord connected to a power source may cause an electric shock even of the server is off-powered. Occasionally disconnect the power plug from the outlet and clean the plug with a dry cloth. Heat will be generated if condensation is formed on a dusty plug, which may cause a fire.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

During operation

CAUTI ON

High temperature

Components including internal hard disk drives in the server are extremely hot just after the server is turned off. Allow the surface to cool before installing/removing.

Secure cables or cards in place

Be sure to secure the power cord, interface cables, and cards in place. Incomplete installation causes a loose connection, resulting in smoke or fire

Electric shock

The hard disk drives and power supply unit (only when two redundant power supplies are installed) support hot swapping. If replacing a component when the electrical current is being supplied, use extreme caution not to get electric shock by touching terminal parts of the internal components.

CAUTI ON

Do not pull out or remove the server from the rack.

Do not pull the server out of the rack or remove it from the rack. In addition to causing equipment to not function properly, separating the server from the rack may result in personal injury.

Avoid contact with the server during thunderstorms.

Do not touch any part of the server including the cables when a thunderstorm is approaching. Also, do not connect or disconnect any devices. There may be a risk of electric shock from lightning strike.

Keep animals away from the server.

Keep animals such as pets away from the server. Pet hair or other waste enters the server, which may cause a fire or electric shock.

Do not leave the optical disk drive tray open.

Dust may get in the server when the tray is open, which may result in a malfunction. In addition, bumping the open tray could cause personal injury.

Do not remove the server from the rack while it is operating.

Do not pull out or remove the server from the rack while the server is running. In addition to ca using equipment to not function properly, separating the server from the rack may result in personal injury.

Do not place any object on top of servers.

Separating the server from the rack may result in personal injury and damage to nearby personal belongings.

Do not get yourself caught in the fan

Keep your hands and hair away from the cooling fan at the rear of the server during operation. Failure to observe this warning may cause your hands or hair to catch in the fan, resulting in personal injury.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Warning labels

Warning labels are attached on or near the components with potential hazards to draw attention from us ers to potential hazards involved in handling the server. T his label is either attached or printed on the comp onent. Do not remove or black out this label and keep it clean. If no label is attached or printed on the server, or if there is a label coming off or stained, contact your sales representative.

External view

2.5-inch drive model

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

3.5-inch drive model

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Handling precautions

Confirm the following precautions.  Do not use any cell phone or PHS and switch off them near the server. Electric waves from such devices

can cause server to malfunction.

 Install the server in an appropriate place. F or details a bout the installation location, see Chapter 2 (2.

Installation and Connection).

 Make sure that the server is off and unplug the po wer cord before co nnecting/removing cables to/from

peripheral devices, if they are not plug-and-play devices.

 Connect the provided power cord to a 100/200 VAC outlet.

 Make sure that the access LED on the server is off before turning off the power or ejecting an optical disk.

 Wait for at least 30 seconds before turning on the server after turning off the server. If any Uninterruptible

Power Supply (UPS) unit is connected, set it to wait for at least 30 seconds before turning on the server after power off. If the optional RAID Controller N8103-168 is installed, wait for at least 90 seconds before turning on the server after turning off the power.

 Turn off the server and unplug the power cord before moving it.

 Regularly clean the server to prevent various types of failure. See Chapter 1 (2. Daily Maintenance) in

"Maintenance Guide" for details about cleaning.

 Check the system clock approximatel y once per month. Use of a time server (NTP server) is

recommended.

 We recommend you store the server at room temperature. Keep the following storage conditions.

Temperature: 10C to 55C, Humidity: 20% to 80%, No condensation of moisture

 Do not use the server, or removable/backup media such as tape cartridges when moving them from a cold

place to a warm place. The condensation will occur and cause malfunctions and fai lures when these are used in such state. Use the server after waiting sufficiently. Reference: Time effective at avoiding condensation in winter (10C or more differences between the room temperature and atmospheric temperature)

 Disk devices: Approximately 2 to 3 hours  Tape media: Approximately 1 day

 If you use the third party optional device to the server, and it causes failure, a charge for repairing must be

paid even within warranty period.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Anti-static measure

This product contains static-sensitive electronic components. Follow the measures below to avoid a failure caused by static electricity when installing or uninstalling any option al device.

● Wearing Anti-static Wrist Strap or Anti-static Gloves

Wear a wrist strap on your wrist and connect the wire to the chassis. If there is no wrist strap, touch an unpainted metal surface of the chassis connected to the ground to discharge static electricity from your body before touching the component. Touch the metal part occasionally to discharge the static electricity while working on the component.

● Checking the Workplace

 Work on an anti-static floor or concrete floor.  If you work on a place where static electricity is likely to be generated (e.g. carpet), be sure to provide

anti-static protection.

● Using the Work Table

Place the server on a mat with Electrostatic Discharge (ESD) protection.

● Clothing

 Do not wear wool or synthetic clothes.  Wear anti-static shoes.  Remove any kind of metal accessories such as a ring, bracelet or wrist watch.

● Handling of Components

 Keep the component in an anti-static bag until you install it to the server.  Hold the component by the edges to avoid touching any terminals or mounting parts.  Place the component in an anti-static bag when storing or moving them.

● Handling of Cables

When connecting a cable (e.g., LAN cable), static electricity may also be charged due to friction against the floor. Connecting the charged cable with an I/O device may cause damage to the devices in the system. It is recommended to use a product such as electrostatic discharge kit to eliminate the static charge before connecting the cable.

● Installing and Uninstalling the Optional Device

 To avoid electric hazard and malfunction, be sure to turn off the power switch of the server and unplug

the power cord from the outlet before installing or uninstalling any optional device. If the device is hot-swappable, you do not need to turn off the power switch and unplug the power cord.

 The device contains static-sensitive electronic components. When installing or uninstalling the optional

device, wear an anti-static wrist strap on your wrist to avoid a failure caused by the static electricity. To use the strap, connect the wire to the chassis.

Express5800/R110g-1E User’s Guide

Precautions for Use (Be Sure to Read)

Tips for your health and safety

Using a computer extensively may affect different parts of your body. Here are tips you should follow while working on a computer to minimize strain on your body.

Keep proper posture

The basic body position for using a computer is sitting straight with your hands on the keyboard parallel with the floor, and your eyes directed slightly downward toward the monitor. With the proper posture described above, no unnecessary strain is applied on any part of your body, in other words when your muscles are most relaxed.

Working on the computer with bad posture such as hunching over or being too close to the monitor could cause fatigue or deteriorated eyesight.

Adjust the angle of your display

Most display units are designed for adjustment of the horizontal and vertical angles. This adjustment is important to prevent the screen from reflecting bright lights and to make the display contents easy to see. Working without adjusting the display to a comfortable angle makes it difficult for you to maintain a proper posture and you will get tired easily. Adjust the viewing angle before use.

Adjust the brightness and contrast of the display

Display screens have functions to control brightness and contrast. The most suitable brightness/contrast depends on age, individuals, and environment, so adjust it to suit your preferences. A too bright or too dark display is bad for your eyes.

Adjust the angle of keyboard

Some keyboards are ergonomically designed, which allow the angle to be adjusted. Adjusting the angle of the keyboard is effective to reduce tension on your shoulders, arms, and fingers.

Clean your equipment

Keeping your equipment clean is important not only for the appearance but also for functional and safety reasons. A dusty monitor makes it difficult to see the display contents, so clean it regularly.

Take rest breaks

When you feel tired, take a break. Light exercise is also recommended.

Express5800/R110g-1E User’s Guide

NEC Express5800 Series Express5800/R110g-1E

General Description

This chapter introduces the features of this server and explains the name of each part.

1. Introduction

2. Accessories Explains the server's accessories.

3. Standard Features Explains the server's feature.

4. Names and Functions of Parts

Explains the name of each part contained in this server.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

1. Introduction

Introduction

Thank you for purchasing this NEC Express5800 Series product. This high performance server is powered by the latest microprocessor "I ntel® Xeon® processor / Pentium® processor ".

NEC’s latest technology and architectures realize high-power and high-speed operation that cannot be matched by existing servers. The server is designed with consideration of not only reliabilit y but also ex pandability, which enables you to use it as a network server.

To use the server correctly and to bring out the server's performance, read this document carefully.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

2. Accessories

Accessories

The carton box contains various accessories which are required for setup or maintenance. Make sure you have them all for future use.

 Tool for Removing Slide Rails (outer rails)  EXPRESSBUILDER*1  Getting Started  Cable Ties (for securing AC power cord)  SDR Update CD-ROM  Power Cord  Front Bezel

*1 Instruction manuals are stored in the PDF format on the EXPRESSBUILDER disc. Install Adobe Reader into

your computer to read them.

Make sure you have all accessories and inspect them. If an accessory is missing or d amaged, contact your sales representative.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

3. Standard Features

Standard Features

The server has the following standard features:

High performance

 Intel® Xeon® processor / Pentium® processor  High-speed memory access (DDR3L 16 00 supported)*  High-speed disk access (SATA2 6 Gbps, SAS 6 Gbps supported)  High-speed 1000BASE-T (2 ports) interface (1Gbps/100Mbps/10Mbps supported)

High reliability

 Memory monitoring feature (error correction/error detection)  Memory degeneracy feature (logical isolation of a failed device)  Bus parity error detection  Temperature detection  Error detection  Internal fan monitoring feature  Internal voltage monitoring feature  RAID system (disk array)  Auto rebuild feature (hot swapping supported)  BIOS password feature  The security lock that comes with Front Bezel  Redundant Fan (optional)  Redundant Power Unit

Management Utilities

* : Intel

Pentium® processor G3240 is running at 1333MHz.

 NEC ESMPRO  ExpressUpdate  Remote controlling feature (EXPRESSSCOPE Engine 3)  RAID system management utility (Universal RAID Utility)  Hard disk drive monitoring

Power saving and noiseless design

 Power monitoring feature  Power control feature  80 PLUS® Platinum certified high effici ency power supply unit (for non-redundant power supply)  80 PLUS® Gold certified high efficiency power supply unit (for redundant power supply)  Fan control appropriate to environment, work load, an d configuration  Enhanced Intel SpeedStep® Technology supported

Expandability

 PCI Express 3.0 (x16 lanes): 1 slot (low profile)  PCI Express 2.0 (x4 lanes): 1 slot (low profile)  Large capacity memory of up to 32 GB  Hard disk drive bay

2.5-inch drive model: Standard 6 slots, 8 slots max. (cannot be used if using optical disk drive)

3.5-inch drive model: 4 slots

 Optical disk drive bay provided as standard  USB3.0 interface (requires the supporting OS)  Three LAN ports (one for management LAN)

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

Ready to use

 Hard disk drives can be installed with one-touch setup, which requires no cables (hot swap supported)

Various built-in Features

 El Torito Bootable CD-ROM (no emulation mode) format supported  Software power-off  Remote power-on feature  AC-Link feature  Remote console feature  Power switch mask  Baseboard Management Cont roller (BMC) conforming to IPMI v2.0

Self-diagnosis

 Power On Self-Test (POST)  Test and Diagnosis (T&D) utility

Easy setup

3. Standard Features

 EXPRESSBUILDER (OS setup utility)  BIOS setup utility (SETUP)

Maintenance features

 Off-line tools  Memory dump feature using the DUMP switch  Feature to back up and restore BIOS/BMC settings using the EXPRESSS COPE profile key

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

3. Standard Features

3.1

Management Features

The hardware components of the server provide operation control/reliability features as shown below. Additionally, NEC ESMPRO Agent, which is provided in EXPRESSBUILDER, enables you to collectively manage the state of your systems. You can also monitor the status of the server from a PC to manage th e network where NEC ESMPRO Manager provided in EXPRESSBUILDER is installed.

The features available on this server are as shown in the table below.

Function Availability Description

Hardware Shows physical hardware information.

System

I/O device

System environment

Software Network BIOS Local polling Storage File system RAID System Others*

Memory bank Device info CPU

Monitors temperatures, fans, voltage, power supply, doors, and others. Temperature Fan Voltage Power supply Door

   



   

     

 

Shows physical memory information. Shows information specific to the server. Shows physical CPU information. Shows logical CPU information and monitors the load factor.

Shows logical memory information and monitors the status. Shows information on I/O devices (floppy disk drive, serial ports,

parallel ports, keyboard, mouse, and video).

Monitors the temperature inside of the chassis. Monitors the fans. Monitors the voltage inside of the chassis. Monitors the power supply unit. Monitors chassis intrusion (open/close of the covers and doors on the



chassis). Shows service, driver, and OS information. Shows network (LAN) information and monitors packets. Shows BIOS information. Monitors the values of MIB items obtained by NEC ESMPRO Agent. Monitors controllers and storage devices including hard disk drives. Shows the file system configuration and monitors the free space.



Universal RAID Utility will monitor the RAID System. Monitors OS stall using the Watch Dog Timer. Performs alert processing after an OS STOP error occurs.

: Supported. : Partially supported. : Unsupported. *: Not displayed on the NEC ESMPRO Manager screen.

Tips

Express5800/R110g-1E User’s Guide

NEC ESMPRO Manager and NEC ESMPRO Agent are supplied with the server as standard. For how to install and use each software component, refer to the explanation of the component.

Chapter 1 General Description

3. Standard Features

3.2

Firmware and Software Version Management

You can manage the version of firmware or software on the server and update them with an update package by using NEC ESMPRO Manager and ExpressUpdate Agent.

This feature automatically updates multiple packages without stopping the system by using NE C ESMPRO Manager.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.1

Names and Functions of Parts

The names and the functions of the server's parts are as follows.

Front View (With Front Bezel)

(1) Front Bezel (optional)

The cover to protect the front and top of the server.

(2) Key Slot

Bezel Lock Key can be inserted into Key Slot to lock Front Bezel.

(3) POWER LED (green/amber)

After the power cord is connected, this LED lights amber during initialization of system. This LED lights green when the power is ON.

(4) Disk Access LED (green/amber)

This LED lights or flashes green when the internal hard disk drive or optical disk drive is being accessed. The LED lights amber if a hard disk drive error occurs.

(5) LINK/ACT LED (green)

This LED turns on when the server is connected to the network. Sequential numbers 1 and 2 indicate LAN connectors 1 and 2, respectively.

(6) Unit ID (UID) LED (blue)

This LED turns on when the UID switch is pressed. Commands from the software also cause it to turn on or flash.

(7) STATUS LED (green/amber)

This LED indicates the server status. It lights green when the server is operating normally. If an abnormality is detected, it turns on or flashes amber.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.2

Front View (Without Front Bezel)

2.5-inch drive model: x6 HDD model

(8)

(3) (11) (12) (9)(6)

(5)-1

(5)-2 (4)

(13)-1

(13)-2 (13)-3

(10)

(7)

(16) (14)-0 (15) (14)-2 (15)

(14)-1 (15) (14)-3 (15) (14)-5

2.5-inch drive model: x8 HDD model

(14)-4

(15)

(8)

3.5-inch drive model

(8)

(5)-1

(3) (11) (12) (9)(6)

(4) (5)-2 (7) (10)

(16) (14)-2 (15) (14)-4 (15)

(15) (15) (14)-1 (14)-0

(3) (11) (12) (9)(6)

(5)-1

(14)-6

(14)-3 (15) (14)-5 (15) (14)-7

(15)

(4) (5)-2 (7) (10)

(16)

(15) (15) (14)-2 (14)-3 (15) (15)

Express5800/R110g-1E User’s Guide

(14)-1 (14)-0

(13)-1

(13)-2 (13)-3

Chapter 1 General Description

4. Names and Functions of Parts

(8) USB Connectors (front)

These connectors are used to connect devices that support

the USB interface. Blue connector: for USB3.0 Black connector: for USB2.0

(9) BMC RESET Switch

The switch to reset BMC of this server. Use the switch only

when there is something wrong with EXPRESSSCOPE

Engine 3 (BMC).

To use this switch, press it at least five seconds.

(10) DUMP Switch (NMI)

When the switch is pressed, memory dump is performed.

(11) POWER Switch

The switch to turn the server on and off. Press once to turn

on the server. The LED lights green when it is on. Press it

again to turn off the server. Hold down the switch for 4

seconds or more to forcibly turn off the server.

(12) Unit ID (UID) Switch

The switch to turn on and off the UID LEDs provided at the

front and rear of the server. Pressing the switch once turns

on the UID LED and pressing once more turns off the LED.

Commands from the software also cause it to turn on or

flash.

(13) Optical Disk Drive Bay

Either of the following drives can be installed. – DVD-ROM drive – DVD SuperMULTI drive (13) - 1 Access LED for optical disk (13) - 2 Eject button (13) - 3 Eject hole

(14) 2.5-inch/3.5-inch Hard Disk Drive Bay

The bay where hard disk drives are installed. The sequential numbers indicate the corresponding slot numbers. All bays include dummy trays.

(15) DISK LED (green/amber)

The LED provided for each hard disk drive This LED light turns green when a hard disk drive is being accessed. The light turns amber if a hard disk drive is broken and it flashes green and amber alternately when a hard disk drive is being rebuilt in the RAID system

(16) Pull-out Tab

A label indicating the part number and serial number of the server is located on Pull-out Tab.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.3

Rear View

<Non-Redundant Power Supply Unit Model>

(1)

<Redundant Power Suppl

(1)-1

(1)-2

(2) (3) (4)

(6) (8) (7) (9)(4) (5)

Unit Model>

(2) (3) (4)

(5)

(3) (4) (5)

(10)

(11)-1A

(11)-1B

(6) (8)(7) (9)(4) (5)

(1) AC Inlet

This socket is used to connect the power cord.

The sequential numbers indicate the corresponding slot

numbers.

(2) Serial Port A (COM A) Connector

This connector is used to connect devices that support a

serial interface. Note that it is not possible to directly

connect to a dedicated line.

(3) LINK/ACT LED (green)

The LED indicates the access status of LAN. (4) LAN Connectors

LAN connectors support 1000BASE-T/100BASE-TX

/10BASE-T.

If Shared BMC LAN feature is enabled in ROM Utility, LAN

connector 1 can also be used as the management LAN

connector. Sharing port is not recommended from the point

of performance and security.

(5) SPEED LED (green/amber)

The LED indicates the transfer speed of LAN ports. (6) Display Connector

The connector to connect a display.

(10)

(7) DC Power LED (green)

This LED lights amber during BMC initialization. The LED lights green when the power is ON.

(8) USB Connectors

These connectors are used to connect devices that support the USB interface.

(9) Management LAN Connector

A LAN connector which supports 100BASE-TX. This port is used for connection with EXPRESSSCOPE Engine 3, and cannot be used as a data transmission port. cannot be used when Shared BMC LAN feature is used.

(10) UID (Unit ID) Switch/LED (blue)

The switch to turn on and off the UID LEDs provided at the front and rear of the server. Pressing the switch once turns on the UID LED and pressing once more turns off the LED.

(11) PCI Slot

The slot is used to install the low profile type PCI board. The sequential numbers indicate the corresponding slot numbers.

This port

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.4

External View

3.5-inch drive model

2.5-inch drive model

(2)

(1)

(1) Top Cover (2) Release Button

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.5

Internal View

The images below do not show the duct.

2.5-inch drive model (non-redundant fan / non-redundant power supply/ x6 HDD model)

(1)

(10)

(1 1)

(9)-0

(8)-6

(9)-1

(8)-5

(9)-2

(8)-4

(9)-3

(9)-4

(9)-5

(5)

(2)

(6)

(7)

(4)

(3)

(8)-1

(8)-2

(8)-3

(1) Front Panel Board (2) Backplane (3) Power Supply Unit (4) DIMM (optional) (5) Motherboard (6) PCI Riser Card (7) Processor (attached under the heat sink)

(8) Cooling Fan

(9) 2.5-inch Hard Disk Drive Bay

(10) Optical Disk Drive (optional) (11) Pull-out Tab

-1 BPB_FAN1

-2 BPB_FAN3

-3 BPB_FAN5

-4 BPB_FAN7

-5 BPB_FAN9

-6 BPB_FAN11

The sequential numbers indicate the corresponding slot numbers.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

2.5-inch drive model (redundant fan / redundant power supply

(8)-4

(8)-5

(8)-6

(1)

(9)-0

(9)-1

(10)

(9)-2

(9)-3

(9)-4

(9)-5

(9)-6

(1) Front Panel Board (2) Backplane (3) Power Supply Unit (4) DIMM (optional) (5) Motherboard (6) PCI Riser Card (7) Processor (attached under the heat sink)

(8)-3

(9)-7

x8 HDD model)

(5) (6) (7)

(4)

(3)

(8)-1

(8)-2

(2)

(8) Cooling Fan

-1 BPB_FAN1 BPB_FAN2

-2 BPB_FAN3 BPB_FAN4

-3 BPB_FAN5 BPB_FAN6

-4 BPB_FAN7 BPB_FAN8

-5 BPB_FAN9 BPB_FAN10

-6 BPB_FAN11 BPB_FAN12

(9) 2.5-inch Hard Disk Drive Bay

The sequential numbers indicate the corresponding slot numbers.

(10) Pull-out Tab

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

3.5-inch drive model (non-redundant fan / non-redundant power supply model)

4. Names and Functions of Parts

(8)-4

(8)-5

(8)-6

(1)

(9)-0

(1 1)

(9)-1

(9)-2

(10)

(1) Front Panel Board (2) Backplane (3) Power Supply Unit (4) DIMM (optional) (5) Motherboard (6) PCI Riser Card (7) Processor (attached under the heat sink)

(9)-3

(5)

(8)-3

(2)

(8) Cooling Fan

-1 BPB_FAN1

-2 BPB_FAN3

-3 BPB_FAN5

-4 BPB_FAN7

-5 BPB_FAN9

-6 BPB_FAN11

(9) 3.5-inch Hard Disk Drive Bay

The sequential numbers indicate the corresponding slot numbers.

(10) Optical Disk Drive (optional) (11) Pull-out Tab

(6)

(8)-2

(7)

(4)

(3)

(8)-1

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

3.5-inch drive model (redundant fan / redundant power supply model)

4. Names and Functions of Parts

(9)-0

(1 1)

(1)

(9)-1

(10)

(8)-6

(9)-2

(8)-5

(8)-4

(9)-3

(5) (6) (7)

(4)

(3)

(8)-1

(8)-2

(8)-3

(2)

(1) Front Panel Board (2) Backplane (3) Power Supply Unit (4) DIMM (optional) (5) Motherboard (6) PCI Riser Card (7) Processor (attached under the heat sink)

(8) Cooling Fan

-1 BPB_FAN1 BPB_FAN2

-2 BPB_FAN3 BPB_FAN4

-3 BPB_FAN5 BPB_FAN6

-4 BPB_FAN7 BPB_FAN8

-5 BPB_FAN9 BPB_FAN10

-6 BPB_FAN11 BPB_FAN12

(9) 3.5-inch Hard Disk Drive Bay

The sequential numbers indicate the corresponding slot numbers.

(10) Optical Disk Drive (optional) (11) Pull-out Tab

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.6

Motherboard

(5) (6)

(7)

(8)

(1 1)

(9)

(10)

(12)

Rear

(13) (14)

(15)

(4) (3)-1 (3)-2

(16)

(17)

(18) (19) (20) (22) (21)

(3)-3

(3)-4

(2)

(1)

(28) (27)

(26)

(25)-4 (25)-5

(23)

(24)

Front

(1) Power Connector (2) PM-BUS Connector (3) DIMM Slots

(the number after hyphen indicates slot number)

(4) Power Connector (CPU) (5) Serial Port (COM A) Connector (6) VGA Connector (7) Power LED (rear) (8) LAN1 Connector (9) LAN2 Connector (10) LAN Connector for Management (11) USB Connector (rear) (12) UID Switch (rear) (13) Lithium Battery (14) PCI Riser Card Connector (dedicated to low profile

cards)

For the supported PCI card specifications, see Chapter 2 (1.12 PCI card).

(15) SPI Flash Mezzanine Connector

EXPRESSSCOPE profile key (SPI memory) has been installed, where BIOS and BMC configuration data is stored. Move it when replacing MB to keep using the data.

(16) Serial Port (COM B) Connector

(17) Internal Flash Memory Connector (18) Front Panel Connector (19) HDD BP Connector (20) Clear CMOS Jumper (21) RAID Configuration Jumper (22) Clear Password Jumper (23) SAS/Serial ATA Connector (24) USB Connector (front) (25) Serial ATA Connector

(the number after hyphen indicates connector number)

(26) TPM Kit Connector (27) SGPIO Connector (28) Processor (CPU) Socket

* Only the connectors used for server upgrades and

maintenance (such as replacing parts) are listed here. Use other connectors or parts without any change.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4. Names and Functions of Parts

4.7

Status Indicators

This section explains the indication and meanings of the server LEDs.

4.7.1

POWER LED ( )

POWER LED indicates the power ON/OFF status of the server. The following table lists POWER LED patterns.

POWER LED pattern Description On (green) The server is normally powered on. On (amber) The power cord is plugged in and BMC is being initialized.

Off The server is off-powered.

4.7.2

STATUS LED ( )

STATUS LED lights green while hardware is operating norm ally. STATUS LED is off or lights/flashes amber if there is a hardware failure.

The server can be powered on after the amber LED is unlit.

The following table lists STATUS LED patterns, their description and solution.

Tips

Refer to the system event log (SEL) by using NEC ESMPRO or the offline maintenance utility to view the cause of failure.

STATUS LED pattern Description Solution

On (green) Normal state Flashing (green) Memory is in a degraded state

Uncorrectable memory errors have often occurred.

Operating while CPU error is detected.

Off The power is off. Turn on the server.

POST is in progress.

Watchdog timer expired. An uncorrectable error in memory was

detected. A PCI bus error was detected. Memory dump is being requested.

DUMP Switch was pressed. Note It remains green when the dump is

caused by software.

Find the device in degraded state by using the BIOS setup utility SETUP, and replace it as soon as possible.

STATUS LED turns green after the POST process.

Turn the power off and then turn it on. If the POST screen displays any error message, take notes of the message, and contact your sales representative.

Wait until the memory dump is complete.



Express5800/R110g-1E User’s Guide

Chapter 1 General Description

STATUS LED pattern Description Solution

On (amber) A temperature alarm was detected.

Flashing (amber)

4. Names and Functions of Parts

Check the internal fan for dusts. Also check if the fan unit is properly connected. If the LED indication does not change when the fans are normal, contact your sales

representative. A voltage alarm was detected. Contact your sales representative. A CPU temperature alarm was detected. A CPU error was detected.

SMI timeout was detected Contact your sales representative. Sensor error was detected. Failure of the power supply unit was

detected A fan alarm was detected.

A temperature warning was detected.

A voltage warning was detected Contact your sales representative. An error was detected on either of the

hard disk drives when the RAID system is configured.

Turn the power off and then turn it on. If the

POST screen displays any error message, take

notes of the message, and contact your sales

representative.

Contact your sales representative.

Check if the internal cooling fan cable is

properly connected.

Check the internal cooling fan for dusts. Also

check if the fan unit is properly connected.

4.7.3

LINK/ACT LED ( 1, 2)

LINK/ACT LED at the front of the server lights green when it is connecting to LAN and flashes when transmitting or receiving data on LAN. The number next to the icon indicates a LAN port number.

4.7.4

Disk Access LED ( )

DISK Access LED indicates the status of HDDs. The following table lists DISK Access LED patterns.

DISK Access LED pattern Description On (green)/Flashing green Hard disk drive or optical disk drive is being accessed. On (amber) Hard disk drive is failing.

Off Hard disk drive is halted.

4.7.5

Optical Disk Access LED

The LED for optical disk drive at the front of the server flashes when a CD or DVD is being accessed.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4.7.6

UID LED (ID)

The UID LED is provided one each at the front and rear of the server. This LED is used to identify the target server among multiple servers installed in a rack.

The following table lists UID LED patterns.

UID LED pattern Description

On (blue) UID Switch is on.

Flashing blue The server is received the command from the management software. Off UID Switch is off.

4.7.7

LED on a hard disk drive

DISK LED on a hard disk drive indicates several states.

4. Names and Functions of Parts

UID LED turns off when UID Switch is pressed again.

DISK LED

3.5-inch hard disk drive

2.5-inch hard disk drive

DISK LED

The following table lists DISK LED patterns.

DISK LED pattern Description On (green)/Flashing green Hard disk drive is being accessed. On (amber) Hard disk drive is failing in RAID system.

Flashing green and amber alternately Rebuild is in progress.

Rebuild starts automatically when the broken HDD is replaced. (Auto Rebuild Feature)

Off Hard disk drive is halted.

Important Observe the following precautions whenever you use the auto rebuild feature.

 Do not turn off or reboot the server while a hard disk drive is being rebuilt.  Wait at least 90 seconds before installing a hard disk drive after removing one.  Do not replace a hard disk drive while another hard disk drive is being rebuilt.

Express5800/R110g-1E User’s Guide

Chapter 1 General Description

4.7.8

LEDs for LAN connectors

The three LAN connectors provided at the rear of the server have two LEDs each.

4. Names and Functions of Parts

LINK/ACT

LED

SPEED

LED

LAN ports

LINK/ACT

LED

Management

LAN connector

 LINK/ACT LED

This LED indicates the state of the LAN port. The following table lists LINK/ACT LED patterns.

LINK/ACT LED pattern Description

On (green) The server is connected with network correctly. Flashing (green) The server is accessing network. Off The server is disconnected from network.

 SPEED LED

SPEED

LED

This LED indicates which network interface is used.

 Two onboard LANs ( 1, 2) support 1000BASE-T, 100BASE-TX, and 10BASE-T.  Management LAN ( M) supports 100BASE-TX, and 10BASE-T.

The following table lists LINK/ACT LED patterns.

SPEED LED pattern Description On (amber) The port is operating with 1000BASE-T interface. On (green) The port is operating with 100BASE-TX interface.

Off The port is operating with 10BASE-T interface.

Express5800/R110g-1E User’s Guide

NEC Express5800 Series Express5800/R110g-1E

This chapter describes preparations for using this server.

1. Installing Internal Optional Devices

You can skip this section if you did not purchase any optional devices.

2. Installation and Connection

Place the server in a proper location and connect some cables following this section.

Preparations

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.1

Installing Internal Optional Devices

This section describes the instructions for installing supported optional devices and precautio ns. If you did not purchase any optional device requiring installation, you can skip this section.

Important

Safety Precautions

Be sure to observe the following precautions to install and remove optional devices properly and safely.

 If use the third party optional device to the server, and it causes fail ure, a

charge for repairing must be paid even within the warranty period.

WARNING

Be sure to observe the following precautions to use the server safety. Failure to observe the precautions may cause death or serious injury. For details, refer to Safety precautions in Precautions for Use.

 Do not disasse mble, repair, or modify the server.  Do not remove the lithium battery, NiMH battery, or Li-ion battery.  Disconnect the power plug when installing and removing devices.

CAUTION

Be sure to observe the following precautions to use the server safely. Failure to observe the precautions may cause burns, injury, and property damage. For details, refer to Safety precautions in Precautions for Use.

 Do not drop  Do not leave the server being pulled out.  Make sure to complete installation.  Do not install with the cover removed.  Do not get your fingers caught.  High temperature  Electrical shock

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.2

Anti-static Measures

This product contains static-sensitive electronic components. Follow the measures below to avoid a failure caused by static electricity when installing or uninstalling any option al device.

● Wearing Anti-static Wrist Strap Or Anti-static Gloves

● Checking the Workplace

 Work on an anti-static floor or concrete floor.  If you work on a place where static electricity is likely to be generated (e.g. carpet), be sure to provide

anti-static protection.

● Using the Work Table

Place the server on a mat with Electrostatic Discharge (ESD) protection.

● Clothing

 Do not wear wool or synthetic clothes.  Wear anti-static shoes.  Remove any kind of metal accessories such as a ring, bracelet or wrist watch.

● Handling of Components

● Handling of Cables

● Installing and Uninstalling the Optional Device

 To avoid electric hazard and malfunction, be sure to turn off the power switch of the server and unplug

the power cord from the outlet before installing or uninstalling any optional device. If the device is hot-swappable, you do not need to turn off the power switch and unplug the power cord.

 The device contains static-sensitive electronic components. When installing or uninstalling the optional

device, wear an anti-static wrist strap on your wrist to avoid a failure caused by the static electricity. To use the strap, connect the wire to the chassis.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.3

Overview of Installation and Removal

Install/remove components by using the following procedure. The internal components except for hard disk drives must be installed or removed after dismounting the server

from the rack. See Chapter 2 (2. Installation and Connection) for details.

 Do not drop the server  Do not lea ve the server pulled out of the rack  Replace the cover after installing components  Beware of high temperatures  Do not get your fingers caught when installing components

CAUTION

Important

BRACKET KEY：This equipment intended for installation in restricted access

location.

 Access can only be gained by SERVICE PERSON or b y USERS who have

been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken.

 Access is through the use of a TOOL or lock and key, or other means of

security, and is controlled by the authority responsible for the location.

If the server is mounted on a rack, use UID Switch to identify the target server.

1. See Chapter 2 (1.4 Confirming Servers (UID Switch)).

Remove the front bezel.

See Chapter 2 (1.5 Removing the Front Bezel).

Turn off the server.

See Chapter 3 (6. Turning off the Server).

Disconnect the power cord from the outlet and the server.

Important

After disconnecting the power cord from the server, wait for at least 5 seconds before continuing to work because the components on the motherboard might still be operating for 3 to 4 seconds e ven after the pow er cord was disconnected.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

When installing or removing the Internal Flash Memory, DIMMs, RAID controllers, PCI cards, or

5. optical disk drives, dismount the server from the rack and place it on a flat and hard desk.

See Chapter 2 (2.1.2 Installing the server to the rack or removing it from the rack – (2) Removal

procedure).

If installing only additional hard disk drives, go to step 11.

1. Installing Internal Optional Devices

Important

Do not leave the server open on the rack.

Remove the top cover.

6. See Chapter 2 (1.6 Removing the Top Cover).

Depending on the components to be installed or removed, follow the procedure in order.

7. See Chapter 2 (1.7 Internal Flash Memory to 1.13 Optical Disk Drive).

Connect cables.

See Chapter 2 (1.10.1 Connecting cables).

Attach the top cover.

9. See Chapter 2 (1.19 Attaching the Top Cover).

10.

Mount the server onto the rack.

See Chapter 2 (2.1.2 (1) Installation).

11.

Install hard disk drives.

See Chapter 2 (1.15 3.5-inch Hard Disk Drive or 1.16 2.5-inch Hard Disk Drive).

Attach the front bezel.

12. See Chapter 2 (1.20 Attaching the Front Bezel).

Continue the setup with reference to Chapter 2 (2.2 Connection).

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.4

Confirming Servers (UID Switch)

Using UID Switch helps you to identify the target server. When the server is working, be sure to identify the target server by using UID Switch first.

When UID Switch is pressed, UID LED lights blue. When it is pressed again, the LED is unlit.

Front

Rea

UID LED

UID switch/LED

UID Switch

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.5

Removing the Front Bezel

Remove the front bezel when turning the server on or off, or handling an optical disk drive.

Unlock the front bezel by using the attached bezel lock key.

Hold the right end of the front bezel carefully to pull it toward you.

Slide the front bezel to the left a little to release the tab from the frame and then remove the front bezel

3. from the server.

1.6

Bezel lock key slot

Removing the Top Cover

Remove the top cover when installing or removing the Internal optional drives connections.

Unlock the chassis, if necessary.

Slide back the top cover while pressing its release button.

Lift the top cover off the server.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.7

1.7.1

Internal Flash Memory

This section describes the procedure for installing the Internal Flash Memory.

Internal Flash Memory Connector

Installation

Install the Internal Flash Memory in the following procedure.

See steps 1 to 4 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

Attach the Internal Flash Memory and fix it with the screw provided with the Internal Flash Memory Kit.

Attach the cover provided with the Kit to the Internal Flash Memory.

1.7.2

Removal

To remove the Internal Flash Memory, reverse the installation procedure.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.8

1.8.1

TPM Kit

This section describes the procedure for installing optional TP M Kit.

Installation

TPM kit connector

Install the TPM Kit in accordance with the following procedure.

Note

See steps 1 to 6 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

Lift the air duct and remove it.

Install the TPM Kit and secure it by

3. pushing the nylon rivet provided with the TPM Kit.

The TPM kit once installed cannot be removed.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

DIMM

1.9

Install a Dual Inline Memory Module (DIMM) to a DIMM socket on the motherboard in the server. The motherboard provides four sokets to install DIMMs.

Important

 Use only the DIMMs provided by NEC.  Read through Chapter 2 (1.2 Anti-static Measures) beforehand.

Tips

Up to 32 GB (8 GB  4) of memory can be installed.

The server supports 2-way interleaved memory system. In 2-way interleaved memory system, the data transfer rate of the memory is twice that of a no n-interleaved

memory system.

1.9.1

Maximum supported memory size

The maximum available memory size on the server dep ends on the architecture (x86 arc hitecture) and OS specs.

A list of maximum memory sizes

Windows Server 2008 Standard x86 Edition

Windows Server 2008 R2 Standard 32 GB Windows Server 2008 Enterprise 64 GB

Windows Server 2008 R2 Enterprise 2 TB

Windows Server 2012 Standard Windows Server 2012 Datacenter

Red Hat Enterprise Linux 5 (x86) Red Hat Enterprise Linux 6 (x86)

Red Hat Enterprise Linux 5 (EM64T) 1 TB

Red Hat Enterprise Linux 6 (x86_64) 3 TB

VMware ESXi 5.1 2 TB

The maximum memory size

supported on each OS

4 GB 4 GB (using HW-DEP feature)

4 TB

16 GB

The maximum memory size supported on

the server

* Default factory settings About 3.5 GB (not using HW-DEP feature)

Note: When Execute Disable Bit (XD Bit) is

set to Disabled in BIOS SETUP.

32 GB

16 GB

32 GB

32 GB Up to 1 TB of the main memory is available to each virtual machine.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.9.2

DIMM installation order

Install DIMMs one by one in order of increasing memory size into slots in the order of DIMM#1, DIMM#2, DIMM#3, and DIMM#4.

If you want to run the server in 2Way Interleave mode, observe the following installation rules:

 Install them in pairs  The two DIMMs installed together must be of the same specifications and memory size.  Install the pairs as DIMM#1 and DIMM#2, or DIMM#3 and DIMM#4. The installation order between the

pairs does not matter.

Installation examples

Example 2Way Interleave DIMM#1 DIMM#2 DIMM#3 DIMM#4

1 Available 2 GB DIMM 2 GB DIMM Not installed Not installed 2 Available 2 GB DIMM 2 GB DIMM 2 GB DIMM 2 GB DIMM 3 Not available 2 GB DIMM 2 GB DIMM 2 GB DIMM Not installed 4 Not available 2 GB DIMM 2 GB DIMM Not installed 2 GB DIMM

1. Installing Internal Optional Devices

Rear

DIMM#2 DIMM#4 DIMM#1 DIMM#3

Front

Motherboard

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.9.3

Installation

Install a DIMM by using the following procedure.

See steps 1 to 4 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

2. Lift the duct off the server.

3. Open both levers of the target DIMM slot outward and push the DIMM straight into the socket. When the DIMM is inserted correctly, the lever automatically closes.

1. Installing Internal Optional Devices

Notch

Key

Important

4. Attach the duct.

5. Assemble the server.

6. Turn on the server and confirm that no error messages are displayed in POST screen. If any error messages are displayed, see Chapter 3 (1. POST Error Message) in "Maintenance Guide".

7. Run the BIOS Setup Utility. On the Advanced menu, choose Memory Configuration, Memory Information. Make sure the capacity of added DIMM is displayed properly. See Chapter 2 (1. System BIOS) in "Maintenance Guide".

 Align the notch on the DIMM with the key on the slot.  Do not apply too much pressure when you push a DIMM into the socket.

8. On the Advanced menu, cho ose Memory Configuration, Memory Retest and then specify Yes. Choose Save Changes and Exit to restart.

9. Set the paging file size to the recommended value (Total memory size x 1.5) or more. When using a Windows OS, see Chapter 1 (6.1 Specifying Memory Dump Settings (Debug Information)) in "Installation Guide (Windows)". For other OS, see the manual provided with the operating system or contact your sales representative.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.9.4

Removal

Remove a DIMM in the following procedure.

1. Installing Internal Optional Devices

Note

See steps 1 to 4 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

2. Lift the duct off the server.

3. Open both levers of DIMM slot to unlock DIMM.

4. Remove DIMM by pulling it up straight.

 When removing a defective DIMM, check error messages displayed at POST or

NEC ESMPRO and check the DIMM socket where the defective DIMM is installed.

 At least one DIMM needs to be installed for the server to operate.

5. Assemble the server.

6. Turn on the server and confirm that no error messages are displayed on POST. If any error message is displayed, see Chapter 3 (1. POST Error Message) in "Maintenance Guide".

7. Run the BIOS Setup Utility. On the Advanced menu, choose Memory Configuration, Memory Retest and then specify Yes. Choose Save Changes and Exit to restart.

8. Set the paging file size to the recommended value (Total memory size x 1.5) or more. When using a Windows OS, see Chapter 1 (6.1 Specifying Memory Dump Settings (Debug Information)) in "Installation Guide (Windows)". For other OS, see the manual provided with the operating system or contact your sales representative.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.10

Jumper Settings and Cable Connections Based on Internal Hard Disk Drive Configuration

This section describes the jumper settings and cable connections when using h ard disk dr ives installed in HDD cages in a non-RAID System or RAID System.

Important

Note

Tips

Set the jumper on the motherboard according to your system, as shown below.

Important

If you use hard disk drives in the RAID system or change the RAID level, initialize the hard disk drives. If the hard disk drive contains valuable data, be sure to backup the hard disk drive before installing the RAID controller and configuring the RAID system.

In the RAID system, use hard disk drives that have the same specifications (capacity, rotational speed, and standard) for each disk array.

Logical drives can be created even with only one physical device.

Avoid static electricity to work with the procedure below. For details, see Chapter 2 (1.2 Anti-static Measures).

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

(a) Using on-board SATA controllers (LSI Embedded MegaRAIDTM)

Jumper on motherboard (SWRAID)

Change the jumper setting to 2-3 (Enabled).

1. Installing Internal Optional Devices

3 2 1

Enabled

Motherboard

Change the jumper setting of the backplane for the hard disk drive.

Backplane for 3.5-inch hard disk drive (J3)

3 2 1

Disabled

(Factory setting)

SWRAID

Backplane for 2.5-inch hard disk drive (J3)

Optional RAID controller

Onboard SATA controller

Onboard SAT controller

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

(b) Using an optional RAID controller

Jumper on motherboard (SWRAID)

Change the jumper setting to 1-2 (Disabled).

1. Installing Internal Optional Devices

3 2 1

Enabled

3 2 1

Disabled

(Factory seting)

WRAID

Motherboard

Change the jumper setting of the backplane for the hard disk drive.

Backplane for 3.5-inch hard disk drive (J3)

Backplane for 2.5-inch hard disk drive (J3)

Note

When installing an optional RAID Controller, start the BIOS Setup utility, select PCI Configuration from the Advanced menu, and then make sure that the parameter of PCI Slot xx ROM (xx is PCI slot number) is set to Enabled.

Important

Do not change the mode to hibernate when building a RAID System.

Optional RAID Controller

Optional RAID controller

Onboard SATA controller

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

For the instruction of installing the optional RAID controller , see Chapter 2 (1.12 PCI Card).

1. Installing Internal Optional Devices

Important

When connecting a RAID controller, set the boot priorit y to 8th or higher in the Boot menu of the BIOS Setup utilit y. If the setting is 9th or lower, the configuration menu for RAID controllers cannot be launched.

(d) Removal

To remove the optional RAID controller, reverse the installation procedure. If you intend to use with the card removed, be sure to attach the blank cover attached to the riser card.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.10.1

Connecting cables

To use an on-board RAID controller or optional RAID controller, connect the interface cable. See the figures below for how to connect cables.

1. Installing Internal Optional Devices

Important

Both SAS hard disk drives and SATA hard disk dri ves cannot be installed.

Tips

When using SAS hard disk drives, install a RAID controller to the server.

Using the on-board RAID controller for a 3.5-inch drive model

 Prepar e the optional SAS/SATA cable K410-288(00).  Connect the P0 to P3 connectors of the K410-288(00) to the SATA0 to SATA3 connectors on the

backplane, respectively.

 While match ing the pin 1 (indicated by the triangle) of the S1 and the pin 1 (indicated by the bold line) of

the SGPIO1, connect the S1 connector of the K410-288(00) to the SGPIO1 connector on the backplane.

 Connect the miniSAS connector of the K410-288(00) to the MINISAS_1 connector on the motherboard.

Motherboard Hard disk drive Backplane

SLOT 0 SATA 0

MINISAS_1

SLOT 1 SATA 1 SLOT 2 SATA 2

SLOT 3 SATA 3

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Using optional RAID controller for a 3.5-inch drive model

 Prepar e the optional SAS/SATA cable K410-240(00).  Connect the P0 to P3 connectors of the K410-240(00) to the SATA0 to SATA3 connectors on the

backplane, respectively.

 While match ing the pin 1 (indicated by the triangle) of the S1 and the pin 1 (indicated by the bold line) of

the SGPIO1, connect the S1 connector of the K410-240(00) to the SGPIO1 connector on the backplane.

 Connect the miniSAS connector of the K410-240(00) to the connectors for ports 0 to 3 on the optional

RAID controller.

1. Installing Internal Optional Devices

Optional RAID Controller Hard disk drive Backplane

SLOT 0 SATA 0

Ports 0 to 3

SLOT 1 SATA 1

SLOT 2 SATA 2

SLOT 3 SATA 3

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

In the 2.5-inch drive model, where to connect on the backplane differs depending on the number of hard disk drives installed (6 or 8). See the description below for the backpl ane number and the slot number on the hard disk drive.

Using the on-board SATA controller in a 2.5-inch drive model with six hard disk drives installed (1 to 4 drives)

 Prepar e the optional SAS/SATA cable K410-289(00).  Connect the P0 to P3 connectors of the K410-289(00) to the SATA2 to SATA5 connectors on the

backplane, respectively.

 While match ing the pin 1 (indicated by the triangle) of the S1 and the pin 1 (indicated by the bold line) of

the SGPIO1, connect the S1 connector of the K410-289(00) to the SGPIO1 connector on the backplane.

 Connect the miniSAS connector of the K410-289(00) to the MINISAS_1 connector on the motherboard.

1. Installing Internal Optional Devices

Motherboard Hard disk drive Backplane

SLOT 0 SATA 2

MINISAS_1

SLOT 1 SATA 3 SLOT 2 SATA 4

SLOT 3 SATA 5

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Using optional RAID controller for a 2.5-inch drive model with six hard disk drives installed (1 to 6 drives)

 Prepar e the optional SAS/SATA cables K410-240(00) and K410-204(00).  Connect the P0 to P3 connectors of the K410-240(00) to the SATA2 to SATA5 connectors on the

backplane, respectively.

 Connect the P4 and P5 connectors of the K410-204(00) to the SATA6 and SATA7 connectors on the

backplane, respectively.

 While match ing the pin 1 (indicated by the triangle) of the S1 and the pin 1 (indicated by the bold line) of

the SGPIO1, connect the S1 connector of the K410-240(00) to the SGPIO1 connector on the backplane.

 While match ing the pin 1 (indicated by the triangle) of the S2 and the pin 1 (indicated by the bold line) of

the SGPIO2, connect the S2 connector of the K410-204(00) to the SGPIO2 connector on the backplane.

 Connect the miniSAS connector of the K410-240(00) to the connectors for ports 0 to 3 on the optional

RAID controller.

 Connect the miniSAS connector of the K410-204(00) to the connectors for ports 4 to 7 on the optional

RAID controller.

1. Installing Internal Optional Devices

Optional RAID controller Hard disk drive Backplane

SLOT 0 SATA 2

Ports 0 to 3

Ports 4 to 7

SLOT 1 SATA 3

SLOT 2 SATA 4

SLOT 3 SATA 5

SLOT 4 SATA 6

SLOT 5 SATA 7

 

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Using optional RAID controller for a 2.5-inch drive model with eight hard disk drives installed (1 to 8 drives)

 Prepar e the optional SAS/SATA cables K410-240(00) and K410-204(00).  Connect the P0 to P3 connectors of the K410-240(00) to the SATA0 to SATA3 connectors on the

backplane, respectively.

 Connect the P4 to P7 connectors of the K410-204(00) to the SATA4 to SATA7 connectors on the

backplane, respectively.

 While match ing the pin 1 (indicated by the triangle) of the S1 and the pin 1 (indicated by the bold line) of

the SGPIO1, connect the S1 connector of the K410-240(00) to the SGPIO1 connector on the backplane.

 While match ing the pin 1 (indicated by the triangle) of the S2 and the pin 1 (indicated by the bold line) of

the SGPIO2, connect the S2 connector of the K410-204(00) to the SGPIO2 connector on the backplane.

 Connect the miniSAS connector of the K410-240(00) to the connectors for ports 0 to 3 on the optional

RAID controller.

 Connect the miniSAS connector of the K410-204(00) to the connectors for ports 4 to 7 on the optional

RAID controller.

1. Installing Internal Optional Devices

Optional RAID controller Hard disk drive Backplane

SLOT 0 SATA 0

Ports 0 to 3

Ports 4 to 7

SLOT 1 SATA 1

SLOT 2 SATA 2

SLOT 3 SATA 3

SLOT 4 SATA 4

SLOT 5 SATA 5 SLOT 6 SATA 6

SLOT 7 SATA 7

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.10.2

Notes on setting up a RAID System

Note the following points when setting up a RAID system.

 The number of hard disk drives required varies in each RAID level.  If on-board RAID controllers or the optional RAID controllers (N8103-171/172) are used, the RAID system

cannot be built in RAID5/RAID6.

RAID level

RAID 0 1 1 RAID 1 2 2 RAID 5 3 RAID 6 3

RAID 10 4 4

1. Installing Internal Optional Devices

The minimum number of hard disk drives required to set up a RAID system

On-board RAID Controller or

N8103-171/172

N8103-168/173/174/161

RAID 50 6

RAID 60 6

 Use SAS/SATA hard disk dr ives or SSDs that have the same capacity and rotational speed.  When installing an OS in your RAID system, you can easily complete the setup process, including RAID

configuration and OS installation, by using EXPRESSBUILDER. If you want to install the OS manually, use the RAID system configuration utility (WebBIOS or SuperBuild utility). The utility can be run during POST which starts immediately after the server is turned on. For details, see Chapter 2 (4. RAID System Configuration) in "Maintenance Guide" or the manual supplied with the optional RAID controller.

Important

 Do not change the RAID system mode to hibernate.  Build a disk array in the RAID system using hard disk drives that have the

same specifications (capacity, rotational speed, and interface).

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

HDD slot numbering

3.5-inch drive model

Slot 0 Slot 1 Slot 3 Slot 2

2.5-inch drive model (1 to 6 drives)

1. Installing Internal Optional Devices

slot

2.5-inch drive model (1 to 8 drives)

Slot 0 Slot 1

Slot 0

Slot 1

Slot 2

Slot 3

Slot 2 Slot 4 Slot 6

Slot 3 Slot 5

Slot 4

Slot 5

Slot 7

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.11

1.11.1

1.11.2

Extra Battery for RAID Controller

The optional extra battery is used in order to avoid data loss caused by accidents during a write-back operation. The model of the extra battery to be used depends on a RAID controller.

 For N810 3-172/173/174, use N8103-154 extra battery  For N810 3-161/168, use flash backup unit that comes with RAID controller.

Handling precautions

Observe the following precautions to use the extra battery.

 Use the extra batter y that supports the RAID controll er used.  The extra battery is a very delicate electronic device. Before installation, touch the metal frame part of

the server to discharge the static electricity from your body.

 Do not drop or bump the backup battery.  For rec ycling a nd disposing the backup battery, refer to the manual that comes with it.

Installing N8103-154 extra battery (for N8103-172/173/174)

This section describes the procedure of installing an extra battery for RAID controller.

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

Remove the RAID controller.

3. While matching the marking, connect the battery control cable that comes with extra battery to RAID controller.

Remove one screw securing the riser

4. card. Hold the both sides of the card and lift it straight off the server.

Black marking

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Remove one screw from the riser card

5. and remove the PCI 1B blank cover.

Attach the RAID controller to the riser

6. card.

Insert the riser card into the slot of the

7. motherboard and fix the riser card with the screw which you removed in step 5. Position the terminal part of the riser card in the slot of the motherboard and then securely insert it.

1. Installing Internal Optional Devices

PCI 1A slot

PCI 1B slot

Unscrew the battery bracket securing the

8. battery.

Write down the installation date (year and

month) on the SET UP DATE LABEL and attach it to the position shown in the right figure.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

While matching the marking, connect the

10. battery control cable to the battery pack, as shown in the right figure.

Attach the extra battery to the battery

11. bracket by using three screws. The installation position of the extra battery is PCI 1B side.

1. Installing Internal Optional Devices

Black marking

Attach the bracket using one screw you

12. removed in step 8.

Reassemble the server.

13.

Attach the battery for RAID Controller installed in PCI 1A

Attach the battery for RAID Controller installed in PCI 1B

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.11.3

Installing flash backup unit that comes with N8103-161/-168

This section describes the procedure of installing a flash backup unit that comes with N8103-161/-168 RAID controller.

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

1. Installing Internal Optional Devices

Connect FBU control cable (600 mm)

3. that comes with the N8103-161/-168 RAID controller.

Remove one screw securing the riser

4. card. Hold the both sides of the card and lift it straight off the server.

Remove one screw from the riser card

5. and remove the PCI 1B blank cover.

Black marker

PCI 1A slot

Attach the RAID controller to the riser

6. card.

Insert the riser card into the slot of the

7. motherboard and fix the riser card with the screw which you removed in step 4. Position the terminal part of the riser card in the slot of the motherboard and then securely insert it.

PCI 1B slot

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Unscrew the battery bracket securing the

8. battery.

Attach the flash backup unit to the battery

9. bracket by using one screw. The installation position of the flash backup unit is the PCI 1B side.

1. Installing Internal Optional Devices

Connect FBU control cable (600) to flash

10.

Attach the battery for RAID

controller installed in PCI 1A Attach the battery for RAID Controller installed in PCI 1B

backup unit.

11.

Attach the bracket using one screw you

removed in step 8.

Reassemble the server.

12.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.12

PCI Card

The server provides a riser card where you can install a PCI card on the motherboard. The riser card can have two low-profile PCI cards installed.

Connect PCI cards for network expansion or file device function into PCI card slots provided on the riser card.

Important

Note

Tips

3.5-inch hard disk drive model

PCI 1B side

Avoid static electricity to work with the procedure below. For details, see Chapter 2 (1.2 Anti-static Measures).

Only Low-profile type of PCI cards can be installed in the riser card of the server. Check the card spec before installation.

If SAS controllers, RAID controllers, LAN adapter (network boot), or Fibre Channel controllers are used without connecting to hard disk drives with OS installed, set the Option ROM for the card to Disabled. For the setting, see Chapter 2 (1. System BIOS) in "Maintenance Guide".

Riser card

PCI 1A side

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

2.5-inch hard disk drive model

1. Installing Internal Optional Devices

Riser card

PCI 1B side

PCI 1A side

1.12.1

Notes

Read the following notes when installing or removing a PCI card.  Do not touch the terminals of the riser cards and the leads of electronic components with your bare hand.

Fingerprints and dust left on them cause the server to malfunction due to a connection failure or damage to the leads.

 The server provides no connector to connect a LED connector which is supplied in RAID Controller used

to indicate disk access.

 The search ord er for PCI bus slot on bo ot is as follows.

Slot 1A  Slot 1B

 The PCI devices of the same type (including onboard PCI device) may be recognized in different order

from that described above, depending on OS or RAID System BIOS utility. Check the slot location of PCI device by PCI bus number, device number and function number shown in the table below.

PCI device PCI bus number Device number Function number Onboard NIC1 Onboard NIC2 Slot 1A Slot 1B

 Set Disabled for the optional ROM of a LAN device not to be booted by using the BIOS Setup utilit y.

39h 0 0 39h 0 1

1h 0 2h 0

 

 If an additional boota ble PCI card (such as a RAID Controller, SAS controller, or LAN card) is installed,

the boot priority may change. After the installation, set the boot priority in the Boot menu of the BIOS Setup utility.

 If a bootable device such as a PCI card or USB device is added, the boot order may change.

In the BIOS Setup utility, select Hard Drive BBS Priorities from the Boot menu, and then specify a higher priority for the boot device. Boot  Hard Drive BBS Priorities  Check the display If the boot device is an HDD under an optional RAID Controller, the display is (Bus xx Dev 00) PCI RAID Adapter. Note that the value for xx changes depending on the PCI s lo t wh er e a R A I D C on t r o l ler is installed.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.12.2

Supported cards and available slots

The following tables list supported cards and slots available for them. For details, see the manual supplied with the card.

1. Installing Internal Optional Devices

Tips

 Different cards mounted on the same bus operate at the lower frequency.  When the operation performance of a PCI card is higher than the P CI slot on the

server, the PCI card operates with the performance of the PCI slot on the server.

 Standard network

Teaming among standard network controllers (both on-board cards) is supported.

 For the N8117-01A, use a cable with the following product name and

designation:

Product name: RS-232C (B) Designation: 804-062746-820

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

(1/2)

PCI 1A PCI 1B

PCI slot performance

X16 lane x4 lane

Model name

N8103-142

N8103-171

N8103-172

N8103-173

N8103-174

N8103-168

N8103-161

N8190-153

N8190-154

N8190-157

N8190-158

N8104-145

Transfer bandwidth (per lane) 8 Gb/s 5 Gb/s

Product

name

SAS controller (Card performance: PCI EXPRESS 2.0 (x8))

RAID Controller (RAID 0/1) (Card performance: PCI EXPRESS 2.0 (x8))

RAID Controller (512MB,RAID 0/1) (Card performance: PCI EXPRESS 3.0 (x8))

RAID Controller (512MB,RAID 0/1/5/6) (Card performance: PCI EXPRESS 3.0 (x8))

RAID Controller (1 GB, RAID 0/1/5/6) (Card performance: PCI EXPRESS 3.0 (x8))

RAID Controller (1 GB, RAID 0/1/5/6)

(Card performance: PCI EXPRESS 3.0 (x8))

RAID Controller (1GB, RAID 0/1/5/6) (Card performance: PCI EXPRESS 3.0 (x8))

Fibre Channel controller (8 Gbps/Optical) (Card performance: PCI EXPRESS 2.0 (x8))

Fibre Channel controller (2 ch) (8 Gbps/Optical) (Card performance: PCI EXPRESS 2.0 (x8))

Fibre Channel controller (16 Gbps/Optical) (Card performance: PCI EXPRESS 3.0 (x8))

Fibre Channel controller (2 ch) (16 Gbps/Optical) (Card performance: PCI EXPRESS 3.0 (x8))

1000BASE-T connection board (2ch) (Card performance: PCI EXPRESS 2.0 (x4))

Slot size Low profile

PCI card type x16 socket x8 socket

Available card size Up to 173 mm

 



 



 



Remark

Dedicated to connecting external devices

Dedicated to connecting internal disks Cannot be installed with N8103-160

Dedicated to connecting internal disks An extra battery (N8103-154) can be connected

For connecting internal disks The RAID cache can be backed up by using the flash backup unit that comes with N8103-168. For connecting HDDs The RAID cache can be backed up by using the flash backup unit that comes with N8103-161. Cannot be installed with N8103-171 For connecting an external Fibre Channel Cannot be installed with N8190-157/158 For connecting an external Fibre Channel Cannot be installed with N8190-157/158. For connecting an external Fibre Channel Cannot be installed with N8190-153/154. The case of Pentium G3220 is until one piece. For connecting an external Fibre Channel



Cannot be installed with N8190-153/154. The case of Pentium G3240 model can not install. For additional LAN(Intel) Teaming (AFT/SFT/ALB) and bonding with only N8104-145 is supported. Cannot be installed with N8104-138/132.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

(2/2)

PCI 1A PCI 1B

PCI slot performance

X16 lane x4 lane

Model name

N8104-138

N8104-132

N8104-133

N8104-128

Transfer bandwidth (per lane) 8 Gb/s 5 Gb/s

Product

name

1000BASE-T connection board (1ch) (Card performance: PCI EXPRESS 2.0 (x1)) 1000BASE-T connection board (2ch) (Card performance: PCI EXPRESS 2.0 (x1)) 1000BASE-T connection board (4ch) (Card performance: PCI EXPRESS 2.0 (x4))

10GBASE-T connection board (SFP+/2 ch) (Card performance: PCI EXPRESS 2.0 (x8))

Slot size Low profile

PCI card type x16 socket x8 socket

Available card size Up to 173 mm

 

Remark

For additional LAN

For additional LAN Prepare SFP module [N8104-129] if needed. Teaming (AFT/SFT/ALB) and bonding on the same board is supported. Only 1 team per system. For RHEL6 (x86), only one board can be installed

N8104-146

N8104-147

N8118-01

N8117-01A Additional RS-232C connector kit

Infiniband connection board (1ch) (Card performance: PCI EXPRESS 3.0 (x8))

Infiniband connection board (2ch) (Card performance: PCI EXPRESS 3.0 (x8))

PCI SSD adapter (Card performance:PCI EXPRESS 2.0(x4))



○

 

For Infiniband FDR(56Gbps)

For Infiniband FDR(56Gbps) For storing data

Cannot be used as an OS boot sector. For additional serial (RS-232C) port Up to 1

 Installed as standard  Can be installed  Cannot be installed *1 Lane: Indicates the transfer performance (transfer bandwidth).

<e.g.> For PCI Express

1 lane = 2.5 Gbps (unidirectional), 4 lanes = 10 Gbps (unidirectional) For PCI Express 2.0 1 lane = 5 Gbps (unidirectional), 4 lanes = 20 Gbps (unidirectional) For PCI Express 3.0 1 lane = 8 Gbps (unidirectional), 4 lanes = 32 Gbps (unidirectional) Socket: Indicates the connector size. A card up to the number of sockets can be connected.

<e.g.> x4socket = x1card, x4card can be installed. x8 card cannot be installed.

* Maximum card depth that can be inserted.

LowProfile: Up to 173 mm * For details of functions of each card, refer to the technical guide. * The card performance described in the parentheses after the Product name indicates the maximum operation

performance of the card.

* When the operation performance of a PCI card is higher than the PCI slot on the server, the PCI card operates with the

performance of the PCI slot on the server.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.12.3

Installation

Install a riser card to a PCI card in the following procedure.

1. Installing Internal Optional Devices

Important

When installing a PCI card, make sure the connector of the card fits the connector of the riser card.

Note

Check the card type (low profile or full-height type) which respective riser card supports and the type of PCI card to be installed.

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

2. Remove one screw securing the riser

card. Hold the both ends of the riser card and lift it off.

Note

Be careful not to contact with other parts.

Confirm the installation position with the reference to the table on the previous pages.

4. Remove one screw from the riser card

and remove the blank cover.

PCI 1A slot

PCI 1B slot

Note

Keep the blank cover for future use.

Install a PCI card to the riser card.

When installing the card, position the terminal part of the PCI card to the riser card slot and insert it.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

Important

Do not touch the terminal part of riser cards or PCI cards and the signal pins of electric parts installed on the card. Installing cards with dirt or oil can cause malfunction.

Tips

If you have trouble installing the card, remove the card once and try again. If you apply excessive pressure on the card, a PCI card or riser card might break.

Note

 Make sure that the head of a PCI card bracket is seated into the fixed slot.  Depending on type of PCI cards, the terminal part of the PCI card may be too

large to fit in the connector.

Fix the PCI card with the screw you removed in step 5.

PCI 1B slot

PCI 1A slot

Tips

If the cable which is to be connected to the connector on the motherboard of the server is provided on the board, connect it to the board before installing the riser card to the server.

Connect the riser card to the mother

board slot and fix the card with the screw you removed in step 3. When connecting the card, position the terminal part of the card to the slot on the motherboard and insert it.

Reassemble the server.

Turn on the server and make sure that no error messages are displayed on POST screen.

10.

For details on POST error messages, see Chapter 3 (1. POST Error Message) in "Maintenance Guide".

To set up the PCI card, run the configuration utility on the installed the card, if necessary. For details,

11.

refer to the manual that comes with the card. If a RAID controller, SAS controller or LAN card which connects to any bootable device is added, the boot priority is changed to the default settings. Configure the boot priority in the Boot menu of the BIOS Setup Utility. For details, see Chapter 2 (1.2.5 Boot) in "Maintenance Guide".

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Using the optional RAID controller

For details, refer to the manual that comes with optional RAID controller.

1. Installing Internal Optional Devices

1.12.4

Important

Avoid static electricity to work with the procedure below. For details, see Chapter 2 (1.2 Anti-static Measures).

Note

 When installing an optional RAID controller, run the BIOS Setup Utility, select

PCI Configuration from the Advanced menu, and then make sure that the parameter of PCI Slot xx ROM (xx is PCI slot number) is set to Enabled.

 When connecting a RAID controller, set the boot priority to 8th or higher in the

Boot menu of the BIOS Setup Utility. If the setting is 9th or lower, the configuration menu for RAID controllers cannot be launched.

Important

Do not change the mode to hibernate when building a RAID system.

Removal

To remove a riser card, reverse the installation procedure. Hold the riser card to which the PCI card is attached firmly and remove it.

If using the server while the PCI card is removed, attach the blank cover that comes with the riser card.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.13

1.13.1

(a) 3.5-inch drive model

Optical Disk Drive

This section describes the procedure for installing the optional optical disk drive.

Installation

Install an optical disk drive in the following procedure.

Important Do not install any unsupported optical disk dri ve.

Optical disk drive bay

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

2. Unscrew one screw securing the bracket

of the optical disk drive and remove the optical disk drive cover.

Important

Install the optical disk drive.

Screw the bracket you removed in step 2

to secure the optical disk drive in place.

Keep the screw and dummy tray in the optical disk drive for future use.

Reassemble the server.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

(b) 2.5-inch drive model

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations. See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

1. Installing Internal Optional Devices

Remove the two screws on the front and

the two screws securing the optical disk drive tray, and pull the tray out.

Remove the optical disk drive cover.

Important

Unscrew and remove the bracket

securing the optical disk drive tray which you pulled out in step 3.

Install the optical disk drive.

Keep the screws and dummy tray in the optical disk drive for future use.

Screw the bracket securing the optical

disk drive.

Insert the optical disk drive tray and

secure four screws removed in step 3 to fix the optical disk drive tray to chassis.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Connect the optical disk drive cable.

Reassemble the server.

10.

1.13.2

Removal

To remove an optical disk drive, reverse the installation procedure above.

1. Installing Internal Optional Devices

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.14

1.14.1

Replace the standard cooling fan with an optional redundant fan to make redundant fan configuration.

Replacing the standard fan unit with redundant fan unit

3. Disconnect the fan cable from the

4. Lift the fan unit straight to remove it.

Redundant Fan

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations. See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

backplane.

Fan cable

Important

5. Install the redundant fan unit.

Important

Keep the removed fan unit for future use.

Make sure that the fan unit faces rearward of the c hassis as shown by the arrows that indicate the air flow.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

6. Connect the fan cables to the backplane. Make sure that the fan cables are not caught in the top cover, fan, or chassis.

Backplane for 3.5-inch hard disk drive

1. Installing Internal Optional Devices

Fan cables

FAN2

(W)

(B) (W) (B) (W) (B) (W) (B) (W) (B) (W) (B)

Backplane for 2.5-inch hard disk drive

(W) (B) (W) (B) (W) (B) (W) (B) (W) (B) (W) (B)

FAN11FAN12FAN9 FAN10FAN7 FAN8FAN5 FAN6FAN3 FAN4FAN1

FAN11FAN12FAN9 FAN10FAN7 FAN8FAN5 FAN6FAN3 FAN4FAN1 FAN2

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

7. Change the jumper settings on the motherboard, as sho wn in the figure below.

1. Installing Internal Optional Devices

Redundant fans

Non-redundant fans

Important

Do not change the other jumper pins.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.15

1.15.1

The hard disk drive bays can install up to four hard disk drives.

Installation

3.5-inch Hard Disk Drive

Slot 0 Slot 1 Slot 3Slot 2

Important

Install a hard disk drive by using the following procedure.

 Use hard disk drives provided by NEC.  Hard disk drives with different types of interfaces or different rotational

speeds cannot be installed together.

 If using hard disk drives in a RAID system, confirm the jumper settings and

cabling.

Important

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. Locate the slot where you install the hard disk drive.

The server provides four slots. Install hard disk drives in ascending order of slot number.

Remove the dummy trays.

Important

Unlock the handle of the tray.

In the RAID system, install the hard disk drives that have the same specifications (capacity, rotational speed and interface).

 Keep the dummy trays for future use.  Keep the dumm y trays installed where hard disk drives are not installed.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Hold the tray and its handle, and then

insert it into the slot.

1. Installing Internal Optional Devices

Note

 Push it all the way until the handle’s lock touches the frame.  Hold the tray firmly with both hands.

Slowly close the handle.

The tray is locked making a clicking sound.

Important

Be careful that your finger is not caught between the handle and the tray.

Note

When you push the drive into the slot, confirm the handle got hooked on the frame.

Turn on the server, run the BIOS Setup Utility, and then specify the boot order from the Boot menu. For

details about the Boot menu, see Chapter 2 (1.2.5 Boot) in "Maintenance Guide".

See Chapter 2 (1.20 Attaching the Front Bezel) to put the front bezel back.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.15.2

Removal

Remove a hard disk drive in the following procedure.

1. Installing Internal Optional Devices

Important

If you dispose of the removed hard disk drive, follow instructions described in Chapter 1 (1. Transfer, Movement, and Disposal) in “Maintenance Guide”.

Note

If you remove a failed hard disk drive, check the DISK LED lit in amber.

DISK LED

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. Push the lever to unlock and open the

handle.

Hold the handle and tray firmly and pull

the hard disk drive out. Do not pull the handle only.

Fill the open slot with the dummy tray, if

necessary.

Turn on the server, run the BIOS Setup Utility, and then specify the boot order from the Boot menu. For

details about the Boot menu, see Chapter 2 (1.2.5 Boot) in "Maintenance Guide".

See Chapter 2 (1.20 Attaching the Front Bezel) to put the front bezel back.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.15.3

Replacing a hard disk drive in the RAID system

In the RAID system, you can use the auto rebuild feature to restore the data back t o the state before the failure.

The auto rebuild feature is enabled in logical drives set to RAID 1, RAID 5, RAID 6, RAID 10, and RAID 50. The disk is automatically rebuilt when hot swapping a failed hard disk drive. During the auto rebuild, the DISK LED on the hard disk drive flashes green and amber alternately to indicate

that auto rebuild is being performed.

Observe the following precautions whenever executing auto rebuild.

 Do not turn off the server until auto rebuild completes.  Leav e an interval of at least 90 seconds between a hard disk drive removal and a hard d isk drive

installation.

 Do not replace another disk during the auto rebuilding.

1. Installing Internal Optional Devices

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.16

2.5-inch Hard Disk Drive

The hard disk drive bays can install up to six hard disk drives as standard.

Slot 0 Slot 2 Slot 4

Slot 1 Slot 3 Slot 5

Slot 2

Slot 4

Slot 6

Slot 0

Slot 1 Slot 3

Important

 Use hard disk drives provided by NEC.  Hard disk drives with different types of interfaces or different rotational

speeds cannot be installed together.

 If using hard disk drives in a RAID system, confirm the jumper settings and

cabling.

Slot 5

Slot 7

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.16.1

Installation

Install a hard disk drive by using the following procedure. Follo w the same installation procedure for other bays.

1. Installing Internal Optional Devices

Important

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. Locate the slot where you install the hard disk drive.

The server provides six slots as standard. Install hard disk drives in ascending port number order.

Remove the dummy trays.

Important

Unlock the handle of the tray.

In the RAID system, install the hard disk drives that have the same specifications (capacity, rotational speed and interface). HDD and SSD can not use together in the same RAID system.

 Keep the dummy trays for future use.  Keep the dumm y trays installed where hard disk drives are not installed.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

Hold the tray and its handle, and then

insert it into the slot.

1. Installing Internal Optional Devices

Note

 Push it all the way until the handle’s lock touches the frame.  Hold the tray firmly with both hands.

Slowly close the handle.

The tray is locked making a clicking sound.

Important

Be careful that your finger is not caught between the handle and the tray.

Note

When you push the drive into the slot, confirm the handle got hooked on the frame.

Turn on the server, run the BIOS Setup Utility, and then specify the boot order from the Boot menu. For

details about the Boot menu, see Chapter 2 (1.2.5 Boot) in "Maintenance Guide".

See Chapter 2 (1.20 Attaching the Front Bezel) to put the front bezel back.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.16.2

Removal

Remove a hard disk drive in the following procedure.

1. Installing Internal Optional Devices

Important

If you dispose of the removed hard disk drive, follow instructions described in Chapter 1 (1. Transfer, Movement, and Disposal) in “Maintenance Guide”.

Note

If you remove a failed hard disk drive, check the DISK LED lit in amber.

DISK LED

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. Push the lever to unlock and open the

handle.

Hold the handle and tray firmly and pull

the hard disk drive out. Do not pull the handle only.

Fill the open slot with the dummy tray, if

necessary.

Turn on the server, run the BIOS Setup Utility, and then specify the boot order from the Boot menu. For

details about the Boot menu, see Chapter 2 (1.2.5 Boot) in "Maintenance Guide".

See Chapter 2 (1.20 Attaching the Front Bezel) to put the front bezel back.

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1.16.3

Replacing a hard disk drive in the RAID system

In the RAID system, you can use the auto rebuild feature to restore the data back t o the state before the failure.

The auto rebuild feature is enabled in logical drives set to RAID 1, RAID 5, RAID 6, RAID 10, RAID 50 and RAID 60.

The disk is automatically rebuilt when hot swapping a failed hard disk drive. During the auto rebuild, the DISK LED on the hard disk drive flashes green and amber alternately to indicate

that auto rebuild is being performed.

Observe the following precautions whenever executing the auto rebuild

 Do not turn off the server until the auto rebuild completes.  Leav e an interval of at least 90 seconds between a hard disk drive removal and a hard d isk drive

installation.

 Do not replace another disk during the auto rebuilding.

1. Installing Internal Optional Devices

Express5800/R110g-1E User’s Guide

Chapter 2 Preparations

1. Installing Internal Optional Devices

1.17

1.17.1

Extra 2.5-inch HDD Cage

You can use eight hard disk drives when the extra 2.5-inch HDD cage N8154-52 is installed.

 To use the extra cage, prepare the optional SAS/SATA cables K410-240(00) and K410-204(00).

Slot 0

Slot 1 Slot 3

Slot 2

Slot 4

Slot 5

Slot 7

Installation

Install the extra 2.5-inch HDD cage by using the following procedure.

See Chapter 2 (1.3 Overview of Installation and Removal) for preparations.

1. See Chapter 2 (1.6 Removing the Top Cover) to remove the top cover.

2. Remove the two screws from the

front panel and two screws from the optical disk drive, and then pull out the optical disk drive tray.

Remove the cover from the optical disk drive.

Important

Keep the removed cover for future use.

Slot 6

100

Insert the extra 2.5-inch HDD cage

into the slot, and secure it to the server chassis with the four screws removed in step 3.

Express5800/R110g-1E User’s Guide

NEC Express5800-R110g-1E User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Documents for This Product

Contents

Notations Used in This Document

Notations used in the text

Optical disk drive

Hard disk drive

Removable media

Abbreviations of Operating Systems (Windows)

Trademarks

License Notification

Regulatory Notices

Warnings and Additions to This Document

Latest editions

Precautions for Use (Be Sure to Read)

Safety precautions

Symbols used in this document and on warning labels

Safety notes

General

Rack installation

Power supply and power cord use

Installation, relocation, storage, and connection

Cleaning and working with internal devices

During operation

Warning labels

External view

Handling precautions

Anti-static measure

1. Introduction

2. Accessories

3. Standard Features

Management Features

Firmware and Software Version Management

4. Names and Functions of Parts

Front View (With Front Bezel)

Front View (Without Front Bezel)

Rear View

External View

Internal View

Motherboard

Status Indicators

Optical Disk Access LED

UID LED (ID)

LED on a hard disk drive

LEDs for LAN connectors

1. Installing Internal Optional Devices

Safety Precautions

Anti-static Measures

Overview of Installation and Removal

Confirming Servers (UID Switch)

Removing the Front Bezel

Removing the Top Cover

Internal Flash Memory

Installation

Removal

TPM Kit

Installation

DIMM

Maximum supported memory size

DIMM installation order

Installation

Removal

Jumper Settings and Cable Connections Based on Internal Hard Disk Drive Configuration

Connecting cables

Notes on setting up a RAID System

Extra Battery for RAID Controller

Handling precautions

Installing N8103-154 extra battery (for N8103-172/173/174)

Installing flash backup unit that comes with N8103-161/-168

PCI Card

Notes

Supported cards and available slots

Installation

Removal

Optical Disk Drive

Installation

Removal
