NEC Express5800/R110f-1E
Configuration Guide
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC Express5800 server.
July 17, 2013
Revision 1.0
NEC Corporation
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Contents
TECHNICAL SPECIFICATION ........................................................................................ 3
Key Features .......................................................................................................................................... 3
Specification .......................................................................................................................................... 3
EXTERNAL VIEWS ......................................................................................................... 7
Front and Rear Views ........................................................................................................................... 7
Dimensions (mm) .................................................................................................................................. 9
CONFIGURATION DIAGRAM ....................................................................................... 10
EXPANSION SLOTS ..................................................................................................... 11
SERVER CONFIGURATION ......................................................................................... 12
1 Base Models ................................................................................................................................. 12
2 Processor ..................................................................................................................................... 12
3 Memory ......................................................................................................................................... 13
4 Internal Hard Disk Drives ............................................................................................................ 14
4.1 RAID Configuration .............................................................................................................. 14
4.2 2.5-inch Drive Configuration ................................................................................................ 16
4.3 3.5-inch Drive Configuration ................................................................................................ 27
5 Optical Drive ................................................................................................................................. 30
6 PCI Card ........................................................................................................................................ 31
6.1 Network Interface Controller ................................................................................................ 31
6.2 External Storage Controller ................................................................................................. 32
6.3 Serial Port Adapter .............................................................................................................. 33
7 Other Add-in Components .......................................................................................................... 33
7.1 Cooling Fan Kit .................................................................................................................... 34
7.2 Trusted Platform Module Kit ................................................................................................ 34
7.3 Internal Flash Memory ......................................................................................................... 34
7.4 Flash FDD............................................................................................................................ 34
7.5 Front Bezel .......................................................................................................................... 35
8 Add-on Components ................................................................................................................... 36
8.1 17-inch LCD Console Drawer .............................................................................................. 36
8.2 KVM Switch ......................................................................................................................... 36
8.3 Server Management License............................................................................................... 37
8.4 Dust Proof Filter Kit ............................................................................................................. 37
REFERENCES............................................................................................................... 38
Server Management ............................................................................................................................ 38
OS Support Matrix for PCI Cards and Embedded Controllers ....................................................... 39
Supported PCI cards and Installable Slots....................................................................................... 40
Copyright Notice and Liability Disclaimer ........................................................................................ 41
REVISION HISTORY ..................................................................................................... 42
NEC Corporation Revision 1.0 – July 17, 2013 2
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Model
R110f-1E
Part Number
N8100-1999F, N8100-2000F
Processor
Type
Intel®
Xeon®
Processor
E3-1220v3
Intel®
Xeon®
Processor
E3-1230Lv3
Intel®
Xeon®
Processor
E3-1230v3
Intel®
Xeon®
Processor
E3-1265Lv3
Intel®
Xeon®
Processor
E3-1270v3
Clock Speed
3.10 GHz
1.80 GHz
3.30 GHz
2.50 GHz
3.50 GHz
Number of Processor
1
Cache
8 MB
Cores and Threads
4C / 4T
4C / 8T
Chipset
Intel® C224 Chipset
Memory
Type
DDR3-1600 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA HDD: 8 TB (8 x 1 TB)
SAS HDD : 9.6 TB (8 x 1.2 TB)
SAS SSD 3.2 TB (8 x 400 GB)
Disk Controller
SATA : 6 Gb/s (Integrated)
SAS : 6 Gb/s (Optional)
RAID
SATA : RAID 0/1/10 (Standard 1 ), RAID 5/6/50/60 (Optional)
SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
4
Expansion Slots
Total: 2 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 2.0 x4 (x8 connector)
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
3 USB3.0 (1 front, 2 rear)
4 USB2.0 (1 front, 2 rear, 1 internal)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 100BASE-TX LAN connector for management (RJ-45, 1 rear)
Technical Specification
Key Features
High performance with the latest Intel® Xeon® processor E3-1200 v3 product family
Up to 32 GB of high speed DDR3-1600 memory
High energy efficiency with intelligent fan control, power capping feature and 80 PLUS® Platinum or
Gold power supply
Full manageability by integrated EXPRESSSCOPE Engine 3
Specification
2.5-inch Drive Model
NEC Corporation Revision 1.0 – July 17, 2013 3
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Model
R110f-1E
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
1 400 Watt 80 PLUS® Platinum certified non-Hot plug PSU
2 500 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
127VA
/ 118W
119VA
/ 110W
127VA
/ 118W
127VA
/ 118W
127VA
/ 118W
(Max. Config,
Operating)
229VA
/ 222W
168VA
/ 159W
230VA
/ 223W
196VA
/ 187W
230VA
/ 223W
Acoustic Noise
(Sound Pressure
Level) 3
Minimum Config.
47.7 dB
44.4 dB
47.7 dB
44.4 dB
47.7 dB
Maximum Config.
46.8 dB
41.8 dB
46.8 dB
41.8 dB
46.8 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40 ° C / 50° to 104 ° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, UL, CB, RoHS, WEEE, BSMI, CCC, RCM
Operating Systems and Virtualization
Software
Microsoft® Windows Server® 2008 x86 Standard
Microsoft® Windows Server® 2008 x86 Enterprise
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Red Hat Enterprise Linux 5.9 or later 4
Red Hat Enterprise Linux 5.9 or later (EM64T) 4
Red Hat Enterprise Linux 6.4 or later (x86) 4
Red Hat Enterprise Linux 6.4 or later (x86_64) 4
VMware ESXi 5.1 update 1
1
Embedded SATA RAID controller is supported only on Windows operating systems.
2
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K
colors.
3
Noise emission was measured in accordance with ISO 7779. The actual value may vary by the
operating environment.
4
For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html
NEC Corporation Revision 1.0 – July 17, 2013 4
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Model
R110f-1E
Part Number
N8100-1986F, N8100-1998F
Processor
Type
Intel®
Xeon®
Processor
E3-1220v3
Intel®
Xeon®
Processor
E3-1230Lv3
Intel®
Xeon®
Processor
E3-1230v3
Intel®
Xeon®
Processor
E3-1265Lv3
Intel®
Xeon®
Processor
E3-1270v3
Clock Speed
3.10 GHz
1.80 GHz
3.30 GHz
2.50 GHz
3.50 GHz
Number of Processor
1
Cache
8 MB
Cores and Threads
4C / 4T
4C / 8T
Chipset
Intel® C224 Chipset
Memory
Type
DDR3-1600 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SATA : 16 TB (4 x 4 TB)
Disk Controller
SATA : 6Gb/s (Integrated)
RAID
SATA : RAID 0/1/10 (Standard 1 ), RAID 5/6 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
4
Expansion Slots
Total: 2 slots available
1 PCIe 3.0 x16 (x16 connector)
1 PCIe 2.0 x4 (x8 connector)
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 2
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
3 USB3.0 (1 front, 2 rear)
4 USB2.0 (1 front, 2 rear, 1 internal)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 100BASE-TX LAN connector for management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Optional, non-hot plug
Power Supply
1 400 Watt 80 PLUS® Platinum certified non-Hot plug PSU
2 500 Watt 80 PLUS® Gold certified Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
112VA
/ 104W
102VA
/ 94W
112VA
/ 104W
102VA
/ 94W
117VA
/ 108W
(Max. Config,
Operating)
212VA
/ 204W
148VA
/ 139W
222VA
/ 214W
173VA
/ 164W
225VA
/ 217W
Acoustic Noise
(Sound Pressure
Level) 3
Minimum Config.
47.7 dB
44.4 dB
47.7 dB
44.4 dB
47.7 dB
Maximum Config.
46.8 dB
41.8 dB
46.8 dB
41.8 dB
46.8 dB
Dimensions (W x D x H )
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
Weight (Minimum / Maximum)
10 kg / 17.5 kg, 22.05 lbs. / 38.58 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40 ° C / 50° to 104 ° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
3.5-inch Drive Model
NEC Corporation Revision 1.0 – July 17, 2013 5
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Model
R110f-1E
Regulatory and Safety
FCC, CE, UL, CB, RoHS, WEEE, BSMI, CCC, RCM
Operating Systems and Virtualization
Software
Microsoft® Windows Server® 2008 x86 Standard
Microsoft® Windows Server® 2008 x86 Enterprise
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Red Hat Enterprise Linux 5.9 or later 4
Red Hat Enterprise Linux 5.9 or later (EM64T) 4
Red Hat Enterprise Linux 6.4 or later (x86) 4
Red Hat Enterprise Linux 6.4 or later (x86_64) 4
VMware ESXi 5.1 update 1
1
Embedded SATA RAID controller is supported only on Windows operating systems.
2
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K
colors.
3
Noise emission was measured in accordance with ISO 7779. The actual value may vary by the
operating environment.
4
For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/en/global/prod/express/linux/index.html
NEC Corporation Revision 1.0 – July 17, 2013 6
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Legend
A.
Drive Bays
H.
UID LED
B.
Optical Drive Bay
I.
System Status LED
C.
USB Connectors
J.
BMC Reset Switch
D.
Power LED
K.
Dump (NMI) Switch
E.
Drive Activity LED
L.
UID LED Button
F.
Data LAN 1 Activity LED
M.
Power Button
G.
Data LAN 2 Activity LED
N.
Pull-out Tab
B
A
C D LJ
K
F H
IGE
M
N
C D LJ
K
F H
IGE
M
N
A
B
External Views
Front and Rear Views
Front View for 2.5-inch Drive Model
Front View for 3.5-inch Drive Model
NEC Corporation Revision 1.0 – July 17, 2013 7
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Legend
A.
PCI Slot (Low profile)
G.
UID LED / Button
B.
PCI Slot (Low profile)
H.
Power LED
C.
Data LAN 1 Connector
I.
Serial Port Connector
D.
Data LAN 2 Connector
J.
VGA Connector
E.
Management LAN Connector
K.
Power Unit
F.
USB Connectors
L.
AC Inlet
L
K A BC D
F
I
J
E
G
K
L
K
L
A BC D
F
I
J
E
G
Rear View for Non-redundant PSU Configuration
Rear View for Redundant PSU Configuration
NEC Corporation Revision 1.0 – July 17, 2013 8
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Dimensions (mm)
NEC Corporation Revision 1.0 – July 17, 2013 9
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Configuration Diagram
2.5-inch Drive Model
Legend: Minimum requirement components Standard components
3.5-inch Drive Model
Legend: Minimum requirement components Standard components
NEC Corporation Revision 1.0 – July 17, 2013 10
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Legend
#1A
PCIe 3.0 x8, x16 connector, Low profile, up to 173 mm length
#1B
PCIe 2.0 x4, x8 connector, Low profile, up to 173 mm length
PCI 1A PCI 1B
Expansion Slots
NEC Corporation Revision 1.0 – July 17, 2013 11
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Product Name / Description
Part Number
NEC Express5800/R110f-1E
No CPU, no RAM, no 3.5-inch HDD, no Cooling FAN, no Front bezel
Including:
3.5-inch Drive Cage, 400 Watt non-hot plug power supply, EXPRESSBUILDER DVD
N8100-1986F
NEC Express5800/R110f-1E
No CPU, no RAM, no 3.5-inch HDD, no Cooling FAN, no Front bezel
Including:
3.5-inch Drive Cage, 500 Watt hot plug power supply, EXPRESSBUILDER DVD
N8100-1998F
NEC Express5800/R110f-1E
No CPU, no RAM, no 2.5-inch HDD, no Cooling FAN, no Front bezel
Including:
2.5-inch Drive Cage, 400 Watt non-hot plug power supply, EXPRESSBUILDER DVD
N8100-1999F
NEC Express5800/R110f-1E
No CPU, no RAM, no 2.5-inch HDD, no Cooling FAN, no Front bezel
Including:
2.5-inch Drive Cage, 500 Watt hot plug power supply, EXPRESSBUILDER DVD
N8100-2000F
Category
Product Name / Description
Part Number
Processors
Required
Xeon E3-1220 v3 Processor Kit
Intel® Xeon ® Processor E3-1220 v3 (3.10 GHz, 4C/4T, 8 MB)
N8101-626F
Xeon E3-1230L v3 Processor Kit
Intel® Xeon ® Processor E3-1230L v3 (1.80 GHz, 4C/8T, 3 MB)
N8101-627F
Xeon E3-1230 v3 Processor Kit
Intel® Xeon ® Processor E3-1230 v3 (3.30 GHz, 4C/8T, 8 MB)
N8101-628F
Xeon E3-1265L v3 Processor Kit
Intel® Xeon ® Processor E3-1265L v3 (2.50 GHz, 4C/8T, 8 MB)
N8101-629F
Xeon E3-1270 v3 Processor Kit
Intel® Xeon ® Processor E3-1270 v3 (3.50 GHz, 4C/8T, 8 MB)
N8101-639F
Server Configuration
1 Base Models
NOTE:
The base model must be ordered with a processor kit and a cooling fan kit.
2 Processor
Available sockets: 1
NOTE:
The processor kit must be ordered with the base model.
NEC Corporation Revision 1.0 – July 17, 2013 12
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Product Name / Description
Part Number
2GB DDR3-1600 UNB Memory Kit
2GB Unbuffered ECC DIMM, DDR3L-1600(PC3-12800)
N8102-523F
4GB DDR3-1600 UNB Memory Kit
4GB Unbuffered ECC DIMM, DDR3L-1600(PC3-12800)
N8102-524F
8GB DDR3-1600 UNB Memory Kit
8GB Unbuffered ECC DIMM, DDR3L-1600(PC3-12800)
N8102-525F
Maximum Memory Size Supported by Operating Systems
Maximum Available Memory
Microsoft Windows Server 2008 Standard
4 GB
4 GB( HW-DEP enabled)
App. 3.5 GB (HW-DEP disabled)
Microsoft Windows Server 2008 R2 Standard
32 GB
32 GB
Microsoft Windows Server 2008 Enterprise
64 GB
32 GB
Microsoft Windows Server 2008 R2 Enterprise
2 TB
32 GB
Microsoft Windows Server 2012 Standard
Microsoft Windows Server 2012 Datacenter
4 TB
32 GB
Red Hat Enterprise Linux 5
Red Hat Enterprise Linux 6
16 GB
16 GB
Red Hat Enterprise Linux 5 (EM64T)
1 TB
32 GB
Red Hat Enterprise Linux 6 (x86_64)
3 TB
32 GB
VMware ESXi 5.1 1
2 TB
32 GB
3 Memory
Available slots: 4
NOTE:
Minimum one memory kit must be installed.
To install by double of memory kit is recommended in order to increase memory transfer
speed by the dual-channel symmetric configuration.
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
The maximum available memory is less than the maximum physical memory supported by your system
because some chipsets require PCI resource space of about 750MB. PCI resource requirements vary
depending on the type and the number of PCI cards you are using.
1
Up to 1 TB of the main memory is available to each virtual machine.
NEC Corporation Revision 1.0 – July 17, 2013 13
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Non-RAID
RAID 5/6
512 MB Cache
1GB Cache/
Battery
512 MB Cache
Refer to 4.2.1
Refer to 4.2.3
Refer to 4.2.5
Refer to 4.2.6
RAID 0/1/10
SATA
SAS, SATA
SAS, SATA
SAS, SATA
Available Interface
Embedded SATA
RAID Controller
Optional RAID
Controller
Refer to 4.2.2
SATA
Refer to 4.2.4
No Cache
SAS, SATA
1GB Cache/
CacheCade
Refer to 4.2.7
SAS, SATA
RAID 5/6
512 MB Cache
1GB Cache/
Battery
512 MB Cache
Refer to 4.2.8
Refer to 4.2.10
Refer to 4.2.11
RAID 0/1/10
SAS, SATA
SAS, SATA
SAS, SATA
Available Interface
Refer to 4.2.9
No Cache
SAS, SATA
1GB Cache/
CacheCade
Refer to 4.2.12
SAS, SATA
4 Internal Hard Disk Drives
4.1 RAID Configuration
Refer to the section in accordance with your disk form factor and RAID configuration.
4.1.1 Up to six 2.5-inch Drive
4.1.2 Up to eight 2.5-inch Drive
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Hot plug insertion/removal is not supported with the Embedded SATA non-RAID controller.
Internal optical drive cannot be installed when N8154-52 2.5-inch Hot Plug Drive Cage Kit is installed.
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in
order to minimize the risk of becoming multiple hard drives failure during the RAID rebuilding process.
All drives within a RAID array should be of the same type, capacity and rotation speed.
All SAS hard drives within a system should be of the same rotation speed.
Mixing SAS and SATA hard drives in the same system is not supported.
NEC Corporation Revision 1.0 – July 17, 2013 14
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Non-RAID
RAID 5/6
512 MB Cache
1GB Cache/
Battery
512 MB Cache
Refer to 4.3.1
Refer to 4.3.3
Refer to 4.3.5
Refer to 4.3.6
RAID 0/1/10
SATA
SATA
SATA
SATA
Available Interface
Embedded SATA
RAID Controller
Optional RAID
Controller
Refer to 4.3.2
SATA
Refer to 4.3.4
No Cache
SATA
1GB Cache/
CacheVault
Refer to 4.3.7
SATA
4.1.3 3.5-inch Drive
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Hot plug insertion/removal is not supported with the Embedded SATA non-RAID controller.
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 1.0 – July 17, 2013 15
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4x 6Gb/s SATA
(Standard)
Cable
Required
Internal SAS/SATA Cable
MiniSAS to 4x Single SATA
K410-289(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 slots
available
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4x 6Gb/s SATA
(Standard)
Cable
Required
Internal SAS/SATA Cable
MiniSAS to 4x Single SATA
K410-289(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 slots
available
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
4.2 2.5-inch Drive Configuration
4.2.1 Up to four Drives with Embedded SATA non-RAID Controller
NOTE:
Hot plug insertion/removal is not supported with the Embedded SATA non-RAID controller.
4.2.2 Up to four Drives with Embedded SATA RAID Controller
NOTE
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 1.0 – July 17, 2013 16
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (0MB, RAID 0/1)
LSI MegaRAID SAS 9240-8i
RAID0/1/10, 0MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-171
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA, for 5th and 6th hard drives
NOTE: To install five drives or more, the cable is required.
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 to 6 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
4.2.3 Up to six Drives with RAID 0/1 Controller without Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 17
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID0/1/10, 512MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA, for 5th and 6th hard drives
NOTE: To install five drives or more, the cable is required.
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 to 6 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.4 Up to six Drives with RAID 0/1 Controller with 512 MB Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 18
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA, for 5th and 6th hard drives
NOTE: To install five drives or more, the cable is required.
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 to 6 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.5 Up to six Drives with RAID 5/6 Controller with 512 MB Cache
NOTE:
NEC Corporation Revision 1.0 – July 17, 2013 19
All drives within a RAID array should be of the same type, capacity and rotation speed.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA, for 5th and 6th hard drives
NOTE: To install five drives or more, the cable is required.
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 to 6 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.6 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 20
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9270CV-8i(with CV)
RAID0/1/5/6/10/50/60, 1GB Cache, Int. 8ports, PCIe 3.0(x8),
6Gb/s, flash cache protection modules included
N8103-152
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA, for 5th and 6th hard drives
NOTE: To install five drives or more, the cable is required.
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive
4 to 6 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.7 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 21
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (0MB, RAID 0/1)
LSI MegaRAID SAS 9240-8i
RAID 0/1/10, 0MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-171
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive Cage
Required
2.5-inch Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-52F
Drive
8 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
4.2.8 Up to eight Drives with RAID 0/1 Controller without Cache
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 22
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1/10, 512MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive Cage
Required
2.5-inch Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-52F
Drive
8 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.9 Up to eight Drives with RAID 0/1 Controller with 512 GB Cache
NOTE:
NEC Corporation Revision 1.0 – July 17, 2013 23
All drives within a RAID array should be of the same type, capacity and rotation speed.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive Cage
Required
2.5-inch Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-52F
Drive
8 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.10 Up to eight Drives with RAID 5/6 Controller with 512 GB Cache
NEC Corporation Revision 1.0 – July 17, 2013 24
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug drive bays
(Standard)
Drive Cage
Required
2.5-inch Drive Cage Kit
2 x 2.5-inch hot plug drive bays
N8154-52F
Drive
8 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.11 Up to eight Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
NEC Corporation Revision 1.0 – July 17, 2013 25
All drives within a RAID array should be of the same type, capacity and rotation speed.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9270CV-8i(with CV)
RAID0/1/5/6/10/50/60, 1GB Cache, Int. 8ports, PCIe 3.0(x8),
6Gb/s, flash cache protection modules included
N8103-152
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-204(00)
Drive Cage
2.5-inch Drive Cage
6 x 2.5-inch hot plug hard drive bays
(Standard)
Drive Cage
Required
2.5-inch Drive Cage Kit
2 x 2.5-inch hot plug hard drive bays
N8154-52F
Drive
8 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
4.2.12 Up to eight Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.
NEC Corporation Revision 1.0 – July 17, 2013 26
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
MiniSAS, 6Gb/s SATA
(Standard)
Cable
Required
Internal SAS/SATA Cable
MiniSAS to 4x Single-SATA
K410-288(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
4x 6Gb/s SATA, 6Gb/s SATA
(Standard)
Cable
Required
Internal SAS/SATA Cable
MiniSAS to 4x Single-SATA
K410-288(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug hard drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
4TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-395
4.3 3.5-inch Drive Configuration
4.3.1 Up to four Drives with Embedded SATA non-RAID Controller
NOTE
Hot plug insertion/removal is not supported with the embedded SATA non-RAID controller.
4.3.2 Up to four Drives with Embedded SATA RAID Controller
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
Embedded SATA RAID Controller does not support RAID 10 configured with 2TB or more HDDs.
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 1.0 – July 17, 2013 27
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (0MB, RAID 0/1)
LSI MegaRAID SAS 9240-8i
RAID0/1/10, 0MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-171
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
4TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-395
4.3.3 Up to four Drives with RAID 0/1 Controller with 0 MB Cache
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.3.4 Up to four Drives with RAID 0/1 Controller with 512 MB Cache
NOTE:
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 1.0 – July 17, 2013 28
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
4TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-395
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID0/1/5/6/10/50/60, 1 GB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-154
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
4TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-395
4.3.5 Up to four Drives with RAID 5/6 Controller with 512 MB Cache
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.3.6 Up to four Drives with RAID 5/6 Controller with 1 GB Cache/Battery
NOTE:
All hard drives within a RAID array should be of the same capacity.
NEC Corporation Revision 1.0 – July 17, 2013 29
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID 0/1/5/6)
LSI MegaRAID SAS 9270CV-8i(with CV) RAID0/1/5/6/10/50/60,
1GB Cache, Int. 8ports, PCIe 3.0(x8), 6Gb/s, flash cache
protection modules included
N8103-152
Cable
Required
Internal SAS Cable
1x Mini-SAS to 4x Single SATA
K410-240(00)
Drive Cage
3.5-inch Drive Cage
4 x 3.5-inch hot plug drive bays
(Standard)
Drive
4 slots available
500GB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-363
1TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-364
2TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-354
3TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 3 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-355
4TB 7.2K Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-395
Category
Product Name / Description
Part Number
Internal
1 slot available
Internal Slim DVD-ROM drive
Slim DVD-ROM drive
N8151-119
Internal DVD Super Multi Drive
Slim DVD Super Multi drive, not including writing software
N8151-107F
External
External DVD-ROM drive
DVD-ROM drive, Bus powered, 1.2 A required
N8160-91
4.3.7 Up to four Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault
NOTE:
All hard drives within a RAID array should be of the same capacity.
5 Optical Drive
NOTE:
Up to 1 optical drive can be connected.
N8154-52 2.5-inch Hot Plug Drive Cage Kit cannot be installed when an internal optical drive is
installed.
NEC Corporation Revision 1.0 – July 17, 2013 30
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Adapter
GbE
1000BASE-T Adapter
Broadcom ® BCM5718 Gigabit Ethernet Controller
PCIe 2.0 x1
N8104-138
Dual Port 1000BASE-T Adapter
Broadcom ® BCM5718 Gigabit Ethernet Controller
PCIe 2.0 x1
N8104-132
Dual Port 1000BASE-T Adapter
Intel® 82580 Gigabit Ethernet Controller
PCIe 2.0 x4
N8104-145
10GbE
10GBASE Adapter (SFP+/2ch)
Broadcom NetXtreme II BCM957711 10G SFP+ Dual Port
Network Interface Card
PCIe 2.0 x8
NOTE:
- N8104-129 SFP+ Module is required to connect with an optical
cable.
- Up to 2 SFP+ Modules can be installed.
- Supports either 10Gb Converged Network Adapter or 10Gb
Network Adapter in RHEL 6 operating systems.
N8104-128
Dual Port 10Gb Converged Network Adapter
BROCADE 1020 Dual Port 10Gbps Converged Network Adapter
PCIe 2.0 x8, 2 x SFP modules, Max. one adapter
NOTE:
- Supports either 10Gb Converged Network Adapter or 10Gb
Network Adapter in RHEL 6 operating systems.
N8104-131
SPF+
Module
SFP+ Module (10G-SR)
1 x SFP+ Module for N8104-128
N8104-129
6 PCI Card
Please refer to Supported PCI cards and Installable Slots with regard to the position of PCI slot which
can mount PCI card supported.
6.1 Network Interface Controller
NEC Corporation Revision 1.0 – July 17, 2013 31
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Network Interface
Team
Operating Systems
1GbE NIC
Embedded 1GbE NIC and N8104-138/-132
Up to four teams per one system
Up to four ports per one team
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Red Hat Enterprise Linux
1GbE NIC
N8104-145
Up to four teams per one system
Up to four ports per one team
Windows Server 2008
Windows Server 2008 R2
10GbE NIC
N8104-128
Up to two teams per one system
Up to two ports per one team
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
RHEL5.9(EM64T)* or later
RHEL6.4(x86_64)* or later
Categor
Network Interface
Operating Systems
1GbE
Embedded 1GbE NIC
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
N8104-138
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
N8104-132
Windows Server 2008 R2, Windows Server 2012, Red Hat Linux, VMware
10GbE
N8104-128
Windows Server 2008, Windows Server 2008 R2, Red Hat Linux, VMware
NIC Teaming feature - NIC Teaming and bonding features
See the table below for supported network interfaces and OS combinations.
Windows Server 2008 support BASP (Broadcom Advanced Server Program) teaming while Windows
Server 2012 and Linux support teaming with bonding function supported by OS.
* RHEL : Red Hat Enterprise Linux
NOTE:
NIC Teaming feature is not supported on iSCSI interfaces.
The network interfaces for teaming must be the same.
When 10GbE and 1GbE NIC teaming are mixed, the teams must be up to four per one system.
Using iSCSI
See the table below for supported network interfaces and OS combinations.
NOTE:
NIC Teaming feature is not supported on iSCSI interfaces.
NEC Corporation Revision 1.0 – July 17, 2013 32
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Controller
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9285-8e
RAID0/1/5/6/10/50/60, 1GB, Ext. 8, PCIe 2.0 x8, SAS 6Gb/s,
SATA 6Gb/s
N8103-160
RAID BBU
RAID Battery Backup Unit
for LSI MegaRAID SAS 9285-8e
N8103-162
Category
Product Name / Description
Part Number
Fibre Channel
Fibre Channel Controller (1ch)
Emulex LightPulse LPe1250-F8 Host Bus Adapter
8Gb/s, Optical, PCIe 2.0 x8
N8190-153
Fibre Channel Controller (2ch)
Emulex LightPulse LPe12002-M8 Host Bus Adapter
8Gb/s, Optical, PCIe 2.0 x8
N8190-154
Fibre Channel Controller (1ch)
Emulex LightPulse LPe16000B-M6 Host Bus Adapter
16Gb/s, Optical, PCIe 3.0 x8
N8190-157
Fibre Channel Controller (2ch)
Emulex LightPulse LPe16002B-M6 Host Bus Adapter
16Gb/s, Optical, PCIe 3.0 x8
N8190-158
SAS
SAS Controller
LSI SAS9212-4i4e Host Bus Adapter
6Gb/s SAS, Int. 4 / Ext. 4, 7-pin SATA / SFF-8088, PCIe 2.0 x8
N8103-142
Product Name / Description
Part Number
Serial Port Adapter
Serial port fixed to PCI bracket
N8117-01A
6.2 External Storage Controller
6.2.1 RAID Controller
NOTE:
To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in
order to minimize the risk of becoming multiple hard drives failure during the RAID rebuilding process.
It is recommended to set RAID array configuration drives less than eight in order to minimize the risk
of becoming multiple hard drives failure.
6.2.2 Fibre Channel / SAS Controller
6.3 Serial Port Adapter
NOTE:
Up to one Serial Port Adapter can be installed.
NEC Corporation Revision 1.0 – July 17, 2013 33
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Product Name / Description
Part Number
Redundant Fan Kit
Non-hot plug cooling fan for R110f-1E
N8181-111F
Non-redundant Fan Kit
Non-hot plug cooling fan for R110f-1E
N8181-115F
Product Name / Description
Part Number
Trusted Platform Module Kit
TPM 1.2 module
N8115-15
Product Name / Description
Part Number
Internal Flash Memory
Internal flash memory to enable software and tools in the EXPRESSBUILDR DVD without
DVD media
NOTE:
Before use, software and tools must be copied from the EXPRESSBUILDER DVD to the
flash memory.
The following operations can be performed with the flash memory:
- Installation of Windows server with express setup
- Installation of Starter Pack—the package of NEC qualified drivers and system setting
tools
- Installation of NEC ESMPRO Agent and Universal RAID Utility
- Performance of the Test and Diagnosis Tool
N8115-14
Product Name / Description
Part Number
Flash FDD
USB flash emulating USB floppy disk, Native capacity 1.44 MB
N8160-86
7 Other Add-in Components
7.1 Cooling Fan Kit
NOTE:
One of the fan kits must be installed.
7.2 Trusted Platform Module Kit
NOTE:
The kit is not available in China.
The kit is not removable after attachment.
"TPM Support" in BIOS setup menu must be activated prior to use of this kit.
To use Windows BitLocker drive encryption, be sure to keep the "recovery password" of BitLocker
function. The recovery password is required to restore data for hardware replacement during a
system error.
7.3 Internal Flash Memory
Available socket: 1
7.4 Flash FDD
Choose the Flash FDD if you need to prepare an alternative device for a floppy drive.
NEC Corporation Revision 1.0 – July 17, 2013 34
NOTE:
Up to one drive can be connected.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Product Name / Description
Part Number
Front Bezel
Front bezel for R110f-1E
N8146-38F
7.5 Front Bezel
NEC Corporation Revision 1.0 – July 17, 2013 35
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Category
Product Name / Description
Part Number
Drawer
w/ KVM
Drawer
17-inch LCD Console Drawer (8 port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port
KVM switch, 1U height
N8143-77F
Cable
Switch Unit Connection Cable Set (USB, 1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB, 3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(03)
Switch Unit Connection Cable Set (USB, 5m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(05)
Drawer
w/o KVM
Drawer
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height,
4-pin USB B to 4-pin USB A cable 2 m, PS/2 Y-splitter cable 2m,
15-pin mini D-sub VGA cable 2 m
N8143-76F
17inch LCD Console Drawer (1 port)
17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad
with 3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8
m, Two PS/2 cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m
N8143-84F
Keypad
Keyboard Unit (JP)
JP 108-keys Keyboard with 10-key for N8143-84F 17inch LCD
Console Drawer (1 port)
N8143-85
Keyboard Unit (UK)
UK 104-keys Keyboard with 10-key, for N8143-84F 17inch LCD
Console Drawer (1 port)
N8143-87
Category
Product Name / Description
Part Number
KVM Switch
Server Switch Unit (8 server)
1U USB 8 port KVM switch
N8191-12F
Cable
KVM
Switch Unit Connection Cable Set (USB,1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(1A)
Switch Unit Connection Cable Set (USB,3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(03)
Switch Unit Connection Cable Set (USB,3m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin
USB A
K410-118(05)
Cascading
Switch Unit Connection Cable 1.8 m
1.8 m, 1 x 15-pin mini D-sub - 1x 15-pin mini D-Sub / 2x PS/2
K410-119(1A)
8 Add-on Components
8.1 17-inch LCD Console Drawer
8.2 KVM Switch
NEC Corporation Revision 1.0 – July 17, 2013 36
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Product Name / Description
Part Number
Remote KVM and Media License kit
License for one server.
Remote console and remote media are enabled regardless of OS status.
Remote KVM:
- Displays a graphics console on the web browser of the remote terminal
(PC/server).
- Controls keyboard and mouse via the remote terminals' web browser
Remote media:
Enables the user to use the CD / DVD / FD / Flash memory of the remote terminals
(PC/server) as if accessing the local drives.
N8115-04
Product Name / Description
Part Number
Dust Proof Filter
10 sheets, dust proof filter for R110f-1E
N8147-07
8.3 Server Management License
The server integrates the EXPRESSSCOPE Engine 3 as standard. Refer to Server Management for the
standard management features. For more extensive remote KVM and remote media features, choose the
following kit.
NOTE:
Remote KVM and remote media features are not available for virtual machines.
8.4 Dust Proof Filter Kit
The server supports the dust resistant feature. Choose the following kit to install the system in dusty
places.
NOTE:
The filter kit is make-to-order product. Please consult our sales representative in regards to
production lead time.
NEC Corporation Revision 1.0 – July 17, 2013 37
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Standard
With Remote KVM
and Media License
kit
Hardware
monitoring
Temperature/fan/voltage/power
consumption/SystemLAN/degeneration(memory)
Hardware configuration information collection
Hardware event log collection
Boot monitoring
BIOS/POST stall, Booting, OS stall, shutdown
2
2
Alerting
HW error, Boot error and OS panic
(by SNMP, E-Mail)
Remote KVM
(via LAN)
POST/BIOS setup, ROM utility
1
Panic screen, Boot screen
1,3
CUI-based screen (OS console)
1,4
GUI-based screen (OS console)
-
Remote screen recording
-
Remote control
(via LAN)
Remote reset/power on-off/ dump
Remote power capping
BIOS/BMC FW update
Remote BIOS setup(partial configuration only)
OS shutdown
2
2
Remote media (CD/DVD/FD/USB)
-
CLP (Command Line Protocol) (DMTF compliant)
Remote control via web browser (multi user login
at the same time)
Scheduling (without UPS, require NEC ESMPRO
Manager)
2
2
Maintenance
EXPRESSSCOPE® Profile key
(Backup/restore BIOS/BMC setup information)
Others
Set automatic IP address via DNS/DHCP
LDAP/Active Directory verification/user control
Clock synchronization of main unit and the RTC
Access log collection
Industry
Standard
IPMI support
2.0
2.0
References
Server Management
The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system
management features listed in the table below.
1
The optional serial port is not available for the feature
NEC Corporation Revision 1.0 – July 17, 2013 38
2
The feature is not supported on VMware systems
3
Monitoring boot screens is not supported on VMware systems.
4
In VMware systems, only the direct console user interface is supported.
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Part Number
Product Name
WS 2012
WS 2008R2
WS 2008
WS 2008 x64
RHEL 6
RHEL 6 x64
RHEL 5
RHEL 5 x64
ESXi 5.1
-
Embedded SATA non-RAID Controller
-
-
Embedded SATA RAID Controller
- - - - -
-
-
Embedded 1GbE NIC
-
N8103-142
SAS Controller
-
N8103-171
RAID Controller (0MB, RAID 0/1)
-
-
N8103-149
RAID controller (512MB, RAID 0/1)
-
N8103-150
RAID controller (512MB, RAID 0/1/5/6)
-
N8103-151
RAID controller (1GB, RAID 0/1/5/6)
-
N8103-152
RAID controller (1GB, RAID 0/1/5/6)
-
N8103-160
RAID controller (1GB, RAID 0/1/5/6)
-
N8190-153
Fibre Channel Controller
-
N8190-154
Fibre Channel Controller (2ch)
-
N8190-157
Fibre Channel Controller
- - - - - -
N8190-158
Fibre Channel Controller (2ch)
- - - - - -
N8104-138
1000BASE-T Adapter (1ch)
-
N8104-132
1000BASE-T Adapter (2ch)
-
N8104-145
1000BASE-T Adapter (2ch)
-
N8104-128
10GBASE Adapter (SFP+/2ch)
-
N8104-131
Dual Port 10Gb Converged Network Adapter
-
-
-
OS Support Matrix for PCI Cards and Embedded Controllers
NEC Corporation Revision 1.0 – July 17, 2013 39
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Slots
Part Number
Product Name
#1
#2
N8103-142
SAS Controller
N8103-171
RAID Controller (0MB, RAID 0/1)
- N8103-149
RAID Controller (512MB,RAID 0/1)
-
N8103-150
RAID Controller (512MB,RAID 0/1/5/6)
- N8103-151
RAID Controller (1GB,RAID 0/1/5/6)
-
N8103-152
RAID Controller (1GB,RAID 0/1/5/6)
- N8103-160
RAID Controller (1GB,RAID 0/1/5/6)
N8190-153
Fibre Channel Controller
N8190-154
Fibre Channel Controller (2ch)
N8190-157
Fibre Channel Controller
N8190-158
Fibre Channel Controller (2ch)
N8104-138
1000BASE-T Adapter (1ch)
N8104-132
1000BASE-T Adapter (2ch)
N8104-145
1000BASE-T Adapter (2ch)
N8104-128
10GBASE Adapter (SFP+/2ch)
N8104-131
Dual Port 10Gb Converged Network Adapter
N8117-01A
Serial Port Adapter
Supported PCI cards and Installable Slots
NEC Corporation Revision 1.0 – July 17, 2013 40
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Copyright Notice and Liability Disclaimer
The information contained herein is subject to change without notice.
Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries
Intel and Xeon are registered trademarks or trademarks of Intel Corporation or its subsidiaries in the United
States and other countries.
Linux is a trademark of Linus Torvalds.
Red Hat is a registered trademark of Red Hat, Inc. in the U.S.
All other products, brands, or trade names used in this document are trademarks or registered trademarks
of their respective holders.
NEC shall not be liable for technical or editorial errors or omissions contained herein.
For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less.
NEC Corporation Revision 1.0 – July 17, 2013 41
CONFIGURATION GUIDE – NEC Express5800/R110f-1E
Revision
Date
Description
1.0
July 17, 2013
Initial release
Revision History
NEC Corporation Revision 1.0 – July 17, 2013 42
Loading...
