Datasheet
MultiSync® P484
LCD 48" Professional Large Format Display
The Definition of Digital Signage
Modular and scalable, NEC’s MultiSync®P484 display brings powerful capability for Digital Signage. Deliver your message with impact and seamless
simplicity for the most convincing results.
Compelling readability even in bright ambient light conditions is guaranteed with high brightness levels of 700 cd/m² combined with an anti-glare surface.
Its modern, slim design forms an elegant digital surface which perfectly complements the surrounding architecture and integrates seamlessly into any
environment. The wide range of connectivity options and compatibility with high resolution signals up to 4K/60Hz secure a futureproof investment. The
Open Modular Intelligence (OMI) approach provides tailor-made Signage Solutions, where scalable computing power such as Raspberry Pi compute
modules or OPS Slot-in PCs are seamlessly embedded into the display.
The 48” MultiSync®P484 is the perfect choice for short and medium viewing distances in retail environments, passenger information, quick service
restaurants and all other public spaces.
Benefits
Superb readability in bright light environments – crisp playback of content thanks to high brightness output of 700 cd/m² and anti-reflective screen
surface delivers clearly visible messages even under varying and demanding ambient conditions.
Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity
via the Spectraview Engine for precise, natural images.
Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
Future Ready with Open Modular Intelligence Expansion – upgrade the power of your display at any time by seamlessly integrating one of NEC’s
options for OPS Slot-in PCs, Raspberry Pi compute modules or signal interfaces for content feed and computing.
Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage
scenarios accompany an impressive and continuous viewer experience.
Ease of use and operation – Smart installation, operation and maintenance functionality ensures accurate performance over the entire lifetime of the
display saving time, effort and resources.
All-in-one Signage solution integrated – the integrated mediaplayer for simple signage use supports easy content playback and management.
LCD 48 Professional Large Format Display - MultiSync® P484 (1 / 4)
Free Download of Multi-Display Management Software – with NaViSet Administrator 2 you can manage all your connected display devices from a
centralised location.
Product Information
Product Name MultiSync®P484
Product Group LCD 48" Professional Large Format Display
Order Code 60004040
Display
Panel Technology S-PVA with edge LED backlights
Active Screen Area (W x H) [mm] 1,054.1 x 592.9
Screen Size [inch/cm] 48 / 120.9
Brightness [cd/m²] 700, 500 Eco (shipment setting)
Contrast Ratio (typ.) 4000:1
Viewing Angle [°] 178 / 178 (at contrat ratio > 10:1)
Colour Depth [bn] 1.073 (10bit)
Response Time (typ.) [ms] 8 (grey-to-grey)
Haze Level [%] Pro (25)
Supported Orientation Landscape, Portrait, Face Up, Face Down
Synchronisation Rate
Horizontal Frequency [kHz] 31.5 - 91.1 (analog and digital)
Vertical Frequency [Hz] 24 - 85
Resolution
Native Resolution 1920 x 1080
Supported Resolutions 4096 x 2160; 3840 x 2160; 1920 x 2160; 1920 x 1200; 1920 x 1080; 1680 x 1050; 1600 x 1200; 1440 x 900;
1400 x 1050; 1366 x 768; 1360 x 768; 1280 x 1024; 1280 x 960; 1280 x 800; 1280 x 720; 1024 x 768; 800 x
600; 640 x 480
Connectivity
Input Video Analogue 1 x VGA
Input Video Digital 1 x DVI-D (with HDCP); 2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
Input Audio Analogue 2 x 3,5 mm jack
Input Audio Digital 2 x DisplayPort; 2 x HDMI
Input Control 1 x LAN 100Mbit; 1 x Remote Control (3.5 mm jack); 1 x RS232
Input Data 1 x microSD (MediaPlayer); 1 x USB 2.0 (MediaPlayer); 1 x USB 2.0 (Service); 1 x USB Type-B (Upstream);
2 x USB 2.0 (Compute Module, 1 x 5V/2A powered)
Output Video Digital 1 x DisplayPort (loop through: DisplayPort, OPS slot-in PC)
Output Audio Analogue 1 x 3,5 mm jack
Output Control 1 x LAN 100Mbit
Open Modular Intelligence
OPS Slot Slot Technology: Open pluggable specification (NEC / Intel OPS standard)
OPS Max. Current / Power
Consumption [A / W]
Compute Module Slot Slot Technology: Compute Module Slot (NEC proprietary standard)
10 / 61
Sensors
LCD 48 Professional Large Format Display - MultiSync® P484 (2 / 4)
Ambient Light Sensor Integrated, triggered actions programmable
Human Sensor Optional, external, 4-5m range, triggered actions programmable
Temperature Sensor Integrated, 3 sensors, triggered actions programmable
NFC Sensor Integrated, 2cm range, free NEC Android App required
Electrical
Power Consumption [W] 115 Eco (shipment setting), 140
Power Savings Mode [W] 3 (Networked Standby); < 0.5 (ECO Standby)
Power Management VESA DPMS
Environmental Conditions
Operating Temperature [°C] +0 to +40
Operating Humidity [%] 20 to 80
Mechanical
Dimensions (W x H x D) [mm] 1,086.5 x 625.3 x 54.7
Weight [kg] 17.6
Bezel Width [mm] 13.2 (left and right); 13.2 (top and bottom)
VESA Mounting [mm] 300 x 300 (FDMI); 4 holes; M6
Ingress Protection IP5X (front); IP2X (back)
Additional Features
Special Characteristics Ambient Light Sensor; AMX NetLinx Support; ASCII Control Commands; Auto ID assignment; Auto tiling
function; Automated Email Alert; CEC Support; Crestron RoomView Support; DICOM support; Display
Browser Control; Emergency Notification; Full System Scheduler; Hardware colour calibration possible;
Image flip; Intelligent Wireless Data (based on NFC); KeyGuide; MediaPlayer with Browser Control; NaViSet
Administrator 2; OmniColor Control; OSD rotation for portrait mode; PJLink Support; Point Zoom Function;
Powered USB-Port; Programmable 12-bit LUT with 3 memory banks; Removable Logo; Secure Mode
Operation; Slim LED Indicator; SNMP Support; TileMatrix (10 x 10); User readable log function; Various
picture in picture options
Colour Versions Black Front Bezel, Black Back Cabinet; optional coloured overframes
Safety and Ergonomics C-tick; CE; EMC Class B; FCC; PSB; RoHS; TÜV GS; UL/C-UL or CSA; VCCI
Audio Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W)
Shipping Content CD-ROM (User Guides/Manuals); Display; DVI-D cable; Power Cable; Remote Control
Warranty 3 years warranty incl. backlight; additional services available; optional 4. + 5. year warranty extension
Operating Hours 24/7
Available Options
Accessories Feet (ST-401); Speaker ((TBD)); Trolley (PDMHM-L); Wall mount (PDW S 32-55 L and P, PD02W T M L,
PD03W T M P)
Compute Module Slot NEC Compute Module; Raspberry Pi Compute Module 1 and 3
OPS Slot HD-SDI 1.5G, 3G; HDBaseT receiver; Intel® Atom, Celeron and Core CPUs; OPS-2C HDMI + DP Interface;
OPS-2C Quad 3G SDI
MediaPlayer
Supported Image Formats JPG (baseline, progressive, RGB, CMYK); max. resolution 5000 x 5000; PNG (interlace, alpha channel);
max. resolution 4000 x 4000
Supported Video Formats MP4 / MOV / FLV (video H.264, audio MP3, AAC); max. resolution 1080p at 30 Hz, 1080i at 60 Hz; MPG
(video mpeg1/2, audio mpeg audio layer2/3, AAC-LC); MP @ ML, MP @ HL; WMV (video H.264, wmv
advanced L3, wmv simple / main, audio mp3 wmv std); max. resolution 1080p at 30 Hz, 1080i at 60 Hz
Supported Audio Formats MP3 (MP3); max. bit-rate 320 kBit/s; WAV (LPCM); max. 48 kHz sampling
LCD 48 Professional Large Format Display - MultiSync® P484 (3 / 4)
Supported File Storage / File
System
MicroSDHC / FAT16, FAT32; USB 2.0 / FAT16, FAT32
Green Features
Energy Efficiency Ambient light sensor; Annual energy consumption: 168 kWh (based on 4 operating hours per day); Carbon
savings meter; ECOMode; Energy efficiency class: B; Human Sensor
Ecological Materials Manuals on CD; Optional feet
Ecological Standards EnergyStar (TBD).(TBD)
This document is © 2017 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the
respective manufacturers. All specifications are subject to change without notice. Errors and omissions are excepted. 05.02.2017
LCD 48 Professional Large Format Display - MultiSync® P484 (4 / 4)
