User’s Manual

E705 E805

Index

Declaration of conformity .............................................................................................................................. English-1

Important Information ...................................................................................................................................English-2

WARNING ....................................................................................................................................... English-2

CAUTION ........................................................................................................................................ English-2

Safety Precautions, Maintenance & Recommended Use ............................................................................. English-3

Contents ....................................................................................................................................................... English-4

Installation ....................................................................................................................................................English-5

Attaching Mounting Accessories ..................................................................................................... English-6

Parts Name and Functions ........................................................................................................................... English-8

Control Panel .................................................................................................................................. English-8

Terminal Panel ................................................................................................................................ English-9

Wireless Remote Control ................................................................................................................ English-10

Operating Range for the Remote Control ....................................................................................... English-11

Setup ............................................................................................................................................................ English-12

Connections ................................................................................................................................................. English-14

Wiring Diagram ............................................................................................................................... English-14

Connecting a Personal Computer ................................................................................................... English-15

Connecting a DVD Player or Computer with HDMI out ................................................................... English-15

Connecting a Computer with DisplayPort ....................................................................................... English-15

Basic Operation ............................................................................................................................................ English-16

Power ON and OFF Modes ............................................................................................................. English-16

Power Indicator ...............................................................................................................................English-17

Initial settings .................................................................................................................................. English-17

Using Power Management .............................................................................................................. English-17

Picture Aspect ................................................................................................................................. English-17

Information OSD ............................................................................................................................. English-18

Picture Mode ................................................................................................................................... English-18

OSD (On-Screen-Display) Controls .............................................................................................................. English-19

PICTURE ........................................................................................................................................ English-20

ADJUST .......................................................................................................................................... English-20

AUDIO ............................................................................................................................................. English-21

SCHEDULE ....................................................................................................................................English-22

PIP .................................................................................................................................................. English-22

OSD ................................................................................................................................................ English-23

MULTI DISPLAY .............................................................................................................................. English-23

DISPLAY PROTECTION ................................................................................................................. English-25

EXTERNAL CONTROL ..................................................................................................................English-25

ADVANCED OPTION1 .................................................................................................................... English-26

ADVANCED OPTION2 .................................................................................................................... English-28

Remote Control Function ............................................................................................................................. English-30

Controlling the LCD monitor via RS-232C Remote Control.......................................................................... English-31

Controlling the LCD monitor via LAN Control ............................................................................................... English-33

Connecting to a Network ................................................................................................................ English-33

Network Setting by Using an HTTP Browser .................................................................................. English-33

POINT ZOOM ............................................................................................................................................... English-42

Features .......................................................................................................................................................English-43

Troubleshooting ............................................................................................................................................ English-44

Speciﬁcations - E705 .................................................................................................................................... English-45

Speciﬁcations - E805 .................................................................................................................................... English-46

Pin Assignment ............................................................................................................................................ English-47

Manufacturer’s Recycling and Energy Information ....................................................................................... English-48

Declaration of conformity

FCC Information

1. Use the attached speciﬁed cables with this display so as not to interfere with radio and television reception. (1) Please use the supplied power cord or equivalent to ensure FCC compliance. (2) Please use a good quality shielded video signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

2. This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may ﬁnd the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Ofﬁce, Washington, D.C., 20402, Stock No. 004-000-00345-4.

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. OmniColor is a registered trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland. DisplayPort and DisplayPort Compliance Logo are trademarks owned by the Video Electronics Standards Association. All other brands and product names are trademarks or registered trademarks of their respective owners.

English

HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and other countries and areas.

CRESTRON and ROOMVIEW are registered trademarks of Crestron Electronics, Inc. in the United States and other countries.

GPL/LGPL Software Licenses The product includes software licensed under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), and others. For more information on each software, see “readme.pdf” inside the “about GPL&LGPL” folder on the supplied CD-ROM.

English-1

Important Information

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION: Please use the power cord provided with this monitor in accordance with the table below. If a power cord is not supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

This symbol warns user that uninsulated voltage within the unit may have sufﬁcient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

Plug Type North America

Plug Shape

Region

Voltage

* When operating the monitor with its AC 125-240V power supply, use a power supply cord that matches the power supply

voltage of the AC power outlet being used.

NOTE: This product can only be serviced in the country where it was purchased.

Use the power cord which has BSMI mark at both ends when you use this monitor in Taiwan.

• The intended primary use of this product is as an Information Technical Equipment in an ofﬁce or domestic environment.

• The product is intended to be connected to a computer and is not intended for the display of television broadcast signals.

U.S.A./

Canada

120*

This is a class A product. In a domestic environment this product may cause radio interference in

Taiwan EU (except U.K.) U.K. China Japan

110

which case the user may be required to take adequate measures.

European

Continental

230 230 220 100

Warning

U.K. Chinese Japanese

English-2

Safety Precautions, Maintenance & Recommended Use

FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE

FOLLOWING WHEN SETTING UP AND USING

THE MULTI-FUNCTION MONITOR:

• DO NOT OPEN THE MONITOR. There are no user

serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualiﬁed service personnel.

• Do not spill any liquids into the cabinet or use your monitor

near water. Do not insert objects of any kind into the cabinet slots, as they

•

may touch dangerous voltage points, which can be harmful or fatal or may cause electric shock, ﬁre or equipment failure.

• Do not place any heavy objects on the power cord.

Damage to the cord may cause shock or ﬁre.

• Do not place this product on a sloping or unstable cart, stand

or table, as the monitor may fall, causing serious damage to the monitor.

Do not mount this product face up, face down or upside down

•

for an extended period of time as it may cause permanent damage to the screen.

• The power supply cord you use must have been approved by

and comply with the safety standards of your country. (Type H05VV-F 3G 1mm

• In UK, use a BS-approved power cord with molded plug

having a black (13A) fuse installed for use with this monitor.

• Do not place any objects onto the monitor and do not use the

monitor outdoors.

• Do not bend, crimp or otherwise damage the power cord.

• If glass is broken, handle with care.

• Do not cover vent on monitor.

• Do not use monitor in high temperature, humid, dusty, or oily

areas.

• If monitor or glass is broken, do not come in contact with the

liquid crystal and handle with care.

• Allow adequate ventilation around the monitor, so that heat

can properly dissipate. Do not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of the monitor.

• The power cable connector is the primary means of detaching

the system from the power supply. The monitor should be installed close to a power outlet, which is easily accessible.

Do not move or mount this product by hanging a rope or wire

•

to the backside handle. Do not mount or secure this product by using the backside handle. It may fall and cause personal injury.

• Handle with care when transporting. Save packaging for

transporting.

• If using the cooling fan continuously, it is recommended to

wipe holes clean a minimum of once a month.

• Please clean the holes of back cabinet to reject dirt and dust

at least once a year because of set reliability.

• When using a LAN cable, do not connect to a peripheral

device with wiring that might have excessive voltage.

• Do not use monitor under rapid temperature and humidity

change condition or avoid cold air from air-conditioning outlet directly, as it may shorten the lifetime of the monitor or cause condensation. If condensation happens, let the monitor stand unplugged until there is no condensation.

Connecting to a TV*

• Cable distribution system should be grounded (earthed) in

accordance with ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.

• The screen of the coaxial cable is intended to be connected

to earth in the building installation.

should be used in Europe)

Immediately unplug your monitor from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions:

• When the power supply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the monitor.

•

• If the monitor has been exposed to rain or water.

• If the monitor has been dropped or the cabinet damaged.

• If you notice any structural damage such as cracks or unnatural wobbling.

• If the monitor does not operate normally by following operating instructions.

Recommended Use

• For optimum performance, allow 20 minutes for warm-up.

• Rest your eyes periodically by focusing on an object at least 5 feet away. Blink often.

• Position the monitor at a 90° angle to windows and other light sources to minimize glare and reﬂections.

• Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid using any cleaning solution or glass cleaner!

• Adjust the monitor’s brightness, contrast and sharpness controls to enhance readability.

• Avoid displaying ﬁxed patterns on the monitor for long periods of time to avoid image persistence (after image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomic beneﬁts, we recommend the following:

• Use the preset Size and Position controls with standard signals.

• Use the preset Color Setting.

• Use non-interlaced signals.

• Do not use primary color blue on a dark background, as it is difﬁcult to see and may produce eye fatigue due to insufﬁcient contrast.

Cleaning the LCD Panel

• When the liquid crystal panel is dusty, please gently wipe with a soft cloth.

• Please do not rub the LCD panel with hard material.

• Please do not apply pressure to the LCD surface.

• Please do not use OA cleaner as it will cause deterioration or discolor on the LCD surface.

Cleaning the Cabinet

• Unplug the power supply

• Gently wipe the cabinet with a soft cloth

• To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and follow with a dry cloth.

NOTE: DO NOT clean with benzene thinner, alkaline detergent,

alcoholic system detergent, glass cleaner, wax, polish cleaner, soap powder, or insecticide. Rubber or vinyl should not be in contact with the cabinet for an extended period of time. These types of ﬂuids and materials can cause the paint to deteriorate, crack or peel.

* The product you purchased may not have this feature.

English

English-3

Your new monitor box* should contain the following:

• LCD monitor

• Power cord*

• Video Signal Cable

• Wireless Remote Control and AAA Batteries

Video Signal Cable

(DVI-D to DVI-D cable)

• Setup Manual

• Clamp x 1

• Screw with washer (M4 x 10) x 1

• CD-ROM

Power Cord*

CD-ROM

Screw with washer

(M4 x 10) x 1

Clamp x 1

Setup Manual

Wireless Remote Control

and AAA Batteries

* Remember to save your original box and packing material to transport or ship the monitor.

Type and number of power cords included will depend on the where the LCD monitor is to be shipped. When more than one

power cord is included, please use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

English-4

Installation

This device cannot be used or installed without the Tabletop Stand or other mounting accessory for support. For proper installation it is strongly recommended to use a trained, NEC authorized service person. Failure to follow NEC standard mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty does not cover damage caused by improper installation. Failure to follow these recommendations could result in voiding the warranty.

Mounting

DO NOT mount the monitor yourself. Please ask dealer. For proper installation it is strongly recommended to use a trained, qualiﬁed technician. Please inspect the location where the unit is to be mounted. Mounting on wall or ceiling is the customer’s responsibility. Not all walls or ceilings are capable of supporting the weight of the unit. Product warranty does not cover damage caused by improper installation, remodelling, or natural disasters. Failure to comply with these recommendations could result in voiding the warranty.

DO NOT block ventilated openings with mounting accessories or other accessories.

For NEC Qualiﬁed Personnel:

To ensure safe installation, use two or more brackets to mount the unit. Mount the unit to at least two points on the installation location.

Please note the following when mounting on wall or ceiling

• When using mounting accessories other than those that are NEC approved, they must comply with the VESAcompatible (FDMlv1) mounting method.

• NEC recommends mounting interfaces that comply with UL1678 standard in North America.

• NEC strongly recommends using size M8 screws (15-17 mm + thickness of bracket and washers in length). If using screws longer than 15-17 mm, check the depth of the hole. (Recommended Fasten Force: 1125 - 1375N•cm). Bracket hole should be under ϕ 10 mm.

• Prior to mounting, inspect the installation location to insure that it is strong enough to support the weight of the unit so that the unit will be safe from harm.

• Refer to the instructions included with the mounting equipment for detailed information.

• Make sure there is no gap between the monitor and the bracket.

under

ϕ 10 mm

Unit

No thread

6 mm

15-17 mm

No gap

Mounting Bracket

Washers

Screw

Thickness of bracket and washers

Mounting location

• The ceiling and wall must be strong enough to support the monitor and mounting accessories.

• DO NOT install in locations where a door or gate can hit the unit.

• DO NOT install in areas where the unit will be subjected to strong vibrations and dust.

• DO NOT install near where the main power supply enters the building.

• Do not install in where people can easily grab and hang onto the unit or the mounting apparatus.

• When mounting in a recessed area, as in a wall, leave at least 4 inches (100 mm) of space between the monitor and the wall for proper ventilation.

• Allow adequate ventilation or provide air conditioning around the monitor, so that heat can properly dissipate away from the unit and mounting apparatus.

Mounting on ceiling

• Ensure that the ceiling is sturdy enough to support the weight of the unit and the mounting apparatus over time, against earthquakes, unexpected vibrations, and other external forces.

• Be sure the unit is mounted to a solid structure within the ceiling, such as a support beam. Secure the monitor using bolts, spring lock washers, washer and nut.

• DO NOT mount to areas that have no supporting internal structure. DO NOT use wood screws or anchor screws for mounting. DO NOT mount the unit to trim or to hanging ﬁxtures.

Maintenance

• Periodically check for loose screws, gaps, distortions, or other problems that may occur with the mounting apparatus. If a problem is detected, please refer to qualiﬁed personnel for service.

• Regularly check the mounting location for signs of damage or weakness that may occur over time.

English

English-5

Attaching Mounting Accessories

The monitor is designed for use with the VESA mounting system.

1. Attach eyebolts (not included) for mounting

This model is equipped with attachable eyebolts to aid in mounting.

• Screw the eyebolts into eyebolt holes as shown in the

picture.

• Be sure eyebolts are secure.

• In order to move the monitor into position, use a lifting

device attached to the eyebolts.

DO NOT mount the monitor using only the eyebolts.

Eyebolt (M10) (not included)

Eyebolt Hole

2. Attach Mounting Accessories

Be careful to avoid tipping monitor when attaching accessories.

VESA Mounting Interface (M8)

3. Using Option Board

1. Turn off the main power switch.

2. Remove the attached slot cover by unscrewing the installed screws (Figure 1).

3. Insert option board in to the monitor. Attach the slot cover by using the removed screws.

NOTE: Please contact your supplier for available option

boards. Do not apply excessive force to manipulate the optional board before ﬁxing it with screws.

Figure 1

4. Installing and removing optional table

top stand

CAUTION: Installing and removing the stand must be done

by four or more people.

To install, follow those instructions included with the stand or mounting apparatus. Use only those devices recommended by the manufacturer.

NOTE: Use ONLY screws which are included with the

optional table top stand.

400 mm

Mounting accessories can be attached with the monitor in the face down position. To avoid damaging the screen face, place the protective sheet on the table underneath the LCD. The protective sheet was wrapped around the LCD in the original packaging. Make sure there is nothing on the table that can damage the monitor.

When using mounting accessories other than NEC compliant and approved, they must comply with the VESA-compatible mounting method.

NOTE: • Do not leave the monitor in the face-up or face-

down position for more than one hour as this may result in a negative effect on the screen’s performance.

• Prior to installation, be sure to place the monitor on a ﬂat area with adequate space.

When installing the LCD monitor stand, handle the unit with care to avoid pinching your ﬁngers.

Optional table top stand

Table

Protective Sheet

NOTE: Install the stand in the direction of the arrow

which is imprinted on the surface of the stand. Use the ST-801.

English-6

5. Ventilation Requirements

When mounting in an enclosed space or recessed area, leave adequate room between the monitor and the enclosure to allow heat to disperse, as shown below.

Allow adequate ventilation or provide air conditioning around the monitor, so that heat can properly dissipate away from the unit and mounting apparatus; especially when you use monitors in multiple screen.

NOTE: The sound quality of the internal speakers will

differ according to the acoustics of the room.

English

6. Prevent Tipping

When using the display with the optional table top stand fasten the LCD to a wall using a cord or chain that can support the weight of the monitor in order to prevent the monitor from falling. Fasten the cord or chain to the monitor using the provided clamps and screws are included with the optional table top stand.

400 mm

Screw Holes

Clamp

Screw (M4)

Before attaching the LCD monitor to the wall, make sure that the wall can support the weight of the monitor.

Be sure to remove the cord or chain from the wall before moving the LCD.

Cord or chain

English-7

Parts Name and Functions

Control Panel

A POWER button ( )

Switches the power on/off. See also page 16.

B MUTE button (MUTE)

Switches the audio mute ON/OFF.

C INPUT button (INPUT)

Acts as SET/POINT ZOOM button within OSD menu. (Toggle switches between [DVI], [DPORT], [HDMI], [VGA] or [Y/Pb/Pr], [HDMI2]). These are available input only, shown as their factory preset name.

D PLUS button (+)

Acts as (+) button to increase the adjustment with OSD menu. Increases the audio output level when the OSD menu is turned off.

E MINUS button (-)

Acts as (-) button to decrease the adjustment with OSD menu. Decreases the audio output level when the OSD menu is turned off.

F UP button ( )

Activates the OSD menu when the OSD menu is turned-off. Acts as adjustment items within OSD menu.

button to move the highlighted area up to select

G DOWN button ( )

Activates the OSD menu when the OSD menu is turned-off. Acts as adjustment items within OSD menu.

button to move the highlighted area down to select

H EXIT button (EXIT)

Activates the OSD menu when the OSD menu is turned-off. Acts as EXIT button within the OSD to move to previous menu.

I Remote control sensor and Power Indicator

Receives the signal from the remote control (when using the wireless remote control). See also page 11. Glows green when the LCD monitor is in active mode*. Glows red when the LCD is in POWER OFF mode. Glows amber when the monitor is in Power Save Mode. Green and Amber blink alternately while in Power Standby mode with the “SCHEDULE SETTINGS” function enabled. When a component failure is detected within the monitor, the indicator will blink red. * If “OFF” is selected in “POWER INDICATOR” (see page 24), LED will not light when the LCD monitor is in active mode.

J Room light sensing sensor

Detects the level of ambient light, allowing the monitor to make automatic adjustments to the backlight setting, resulting in a more comfortable viewing experience. Do not cover this sensor. See page 28.

Control Key Lock Mode

This control completely locks out access to all Control Key functions. To activate the control key lock function, press

and and hold down simultaneously for more than

both 3 seconds. To resume user mode, press both and and hold simultaneously for more than 3 seconds.

*: This function depends on which option board you use.

English-8

Terminal Panel

English

A AC IN connector

Connects with the supplied power cord.

B Main Power Switch

On/Off switch to turn main power ON/OFF.

C EXTERNAL SPEAKER TERMINAL

To output the audio signal from AUDIO 1, DPORT and HDMI. Red terminal is plus (+). Black terminal is minus (-). NOTE: This speaker terminal is for 15 W + 15 W (8 ohm) speaker.

D Internal/External speaker switch

: Internal speaker : External speaker. NOTE: Please power off the monitor when you use the Internal/External speaker switch.

E AUDIO OUT

To output the audio signal from the AUDIO IN 1, 2, DPORT and HDMI to an external device (stereo receiver, ampliﬁer, etc.).

F Service port

This USB slot is for future software upgrades.

G LAN port (RJ-45)

LAN connection. See page 33.

8 AUDIO IN 1, 2

To input audio signal from external equipment such as a computer or DVD player.

J VGA IN (mini D-Sub 15 pin)

To input analog RGB signals from a personal computer or from other RGB equipment. This input can be used with an RGB or COMPONENT source. Please select signal type in TERMINAL SETTING. See page 27. NOTE: When you use this connector for COMPONENT, please use a suitable signal cable. If you have any questions, please ask your dealer.

K DisplayPort connectors

To input DisplayPort signals.

L HDMI IN

To input digital HDMI signals.

M DVI IN (DVI-D)

To input digital RGB signals from a computer or HDTV device having a digital RGB output. * This connector does not support analog input.

N Kensington Lock

For security and theft prevention.

O Option board slot

Slot 2 type accessories are available. Please contact your supplier for detailed information. NOTE: Please contact your supplier for available option board.

P Internal speaker

I RS-232C (D-Sub 9 pin)

Connect RS-232C input from external equipment such as a PC in order to control RS-232C functions.

English-9

Wireless Remote Control

E AUDIO INPUT button

Selects audio input source [IN1], [IN2], [OPTION]* [DPORT], [HDMI2].

, [HDMI],

A POWER button

Switches the power on/standby.

F OPTION MENU button*

G KEYPAD

Press buttons to set and change passwords, change channel and set REMOTE ID.

H ENT button*

I DISPLAY button

Turns on/off the information OSD. See page 18.

J MENU button

Turns on/off the menu mode.

K AUTO SET UP button

Enters auto setup menu. See page 20.

L EXIT button

Returns to previous menu within OSD menu.

M UP/DOWN button ( / )

Acts as to select adjustment items within OSD menu. Small screen which adjusted “PIP” mode moves up or down.

button to move the highlighted area up or down

N MINUS/PLUS (-/+) button

Increases or decreases the adjustment level within OSD menu settings. Small screen which adjusted “PIP” mode moves left or right and increases or decreases the size.

B INPUT button

Selects input signal. DVI: DVI HDMI: HDMI, HDMI2 DisplayPort: DPORT VGA: VGA Y/Pb/Pr: Y/Pb/Pr OPTION: Depends on your connection

C PICTURE MODE button

Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [CUSTOM1], [CUSTOM2]. See page 18.

HIGHBRIGHT: for moving images such as DVD. STANDARD: for images. sRGB: for text based images. CINEMA: for movies. CUSTOM1 and CUSTOM2: activate auto dimming function. See page 28.

D ASPECT button

Selects picture aspect, [FULL], [WIDE], [DYNAMIC], [1:1], [ZOOM] and [NORMAL]. See page 17.

O SET/POINT ZOOM button

Makes selection. Activates POINT ZOOM function when OSD menu is not shown.

P VOLUME UP/DOWN button (VOL +/-)

Increases or decreases audio output level.

Q CH/ZOOM UP/DOWN button (CH/ZOOM +/-)*

Increases or decreases POINT ZOOM level.

R GUIDE button*

S MUTE button

Turns on/off mute function.

T STILL button

ON/OFF button: Activates/deactivates still picture mode. STILL CAPTURE button: Captures still picture. NOTE: This function is released when activating IMAGE FLIP.

IMAGE FLIP button

Toggle switches between H FLIP, V FLIP, 180° ROTATE and NONE. See page 21.

English-10

PIP (Picture In Picture) button

ON/OFF button: Toggle switches between PIP, POP,

PICTURE BY PICTURE-ASPECT and PICTURE BY PICTURE-FULL. See page 22.

INPUT button: Selects the “picture in picture” input signal. CHANGE button: Replaces to the main picture and sub

picture. NOTE: Enable to change the sub picture size by pressing SET/POINT ZOOM button during PIP mode.

Main picture Connector

DPORT DisplayPort No Yes Yes Yes Yes Yes Yes

DVI DVI-D Yes No Yes Yes Yes Yes Yes

HDMI HDMI Yes Yes No Yes Yes Yes Yes

VGA Y/Pb/Pr Yes Yes Yes No No Yes Yes OPTION Option Yes Yes Yes Yes Yes No Yes

HDMI2 HDMI2 Yes Yes Yes Yes Yes Yes No

DPORT DVI HDMI VGA

D-Sub

Yes Yes Yes No No Yes Yes

Sub picture

Y/Pb/Pr

OPTION HDMI2

REMOTE ID button

Activates REMOTE ID function.

MTS button*

*1: This button’s action depends on which option board you use. Refer to the option board’s manual for further information.

*2: This function depends on which option board you use.

*: Button with no description does not function.

Operating Range for the Remote Control

Point the top of the remote control toward the LCD monitor’s remote sensor during button operation.

Use the remote control within a distance of about 7 m (23 ft.) from remote control sensor or at a horizontal and vertical angle of within 30° within a distance of about 3.5 m (10 ft.).

Caution: Important, the remote control

system may not function when direct sunlight or strong illumination strikes the remote control sensor or when there is an object in the path.

English

Handling the remote control

• Do not subject to strong shock.

• Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately.

• Avoid exposure to heat and steam.

• Other than to install the batteries, do not open the remote control.

English-11

Setup

1. Determine the installation location

CAUTION: Installing your LCD monitor must be done by a

qualiﬁed technician. Contact your dealer for more information.

CAUTION:

CAUTION: Do not mount or operate the monitor upside

CAUTION: This LCD has a temperature sensor and cooling

IMPORTANT: Lay the protective sheet, which was wrapped

MOVING OR INSTALLING THE LCD MONITOR MUST BE DONE BY FOUR OR MORE PEOPLE. Failure to follow this caution may result in injury if the LCD monitor falls.

down, face up or face down.

fan, including a fan for the option board. If the LCD becomes too hot, the cooling fan will turn on automatically. The option board’s fan is active although the temperature is lower than normal operating temperature for cooling the option board. If the LCD becomes overheated while the cooling fan is running, a “Caution” warning will appear. If the “Caution” warning appears, discontinue use and allow the unit to cool. Using the cooling fan will reduce the likelihood of early circuit failure and may help reduce image degradation and “Image Persistance”. If the LCD is used in an enclosed area or if the LCD panel is covered with a protective screen, please check the inside temperature of the monitor by using the “HEAT STATUS” control in the OSD (see page 25). If the temperature is higher than the normal operating temperature, please turn the cooling fan to ON within the FAN CONTROL menu within the OSD (see page 25).

around the LCD monitor when it was packaged, beneath the LCD monitor so as not to scratch the panel.

NEC recommends the following battery use:

• Place “AAA” size batteries matching the (+) and (-) signs on each battery to the (+) and (-) signs of the battery compartment.

• Do not mix battery brands.

• Do not combine new and old batteries. This can shorten battery life or cause liquid leakage of batteries.

• Remove dead batteries immediately to prevent battery acid from leaking into the battery compartment.

• Do not touch exposed battery acid, it may injure skin.

NOTE: If you do not intend to use the Remote Control for

a long period of time, remove the batteries.

3. Connect external equipment

(See pages 14 and 15)

• To protect the external equipment; turn off the main power before making connections.

• Refer to your equipment user manual for further information.

NOTE: Do not connect/disconnect cables when turning

on the monitor or other external equipment as this may result in a loss of the monitor image.

4. Connect the supplied power cord

• The equipment should be installed close to an easily accessible power outlet.

• Please fasten power cord to the LCD monitor by attaching the screw and clamp.

• Fully insert the prongs into the power outlet socket. A loose connection may cause image degradation.

NOTE: Please refer to the “Safety Precautions and

Maintenance” section of this manual for proper selection of AC power cord.

2. Install the remote control batteries

The remote control is powered by two 1.5V AAA batteries. To install or replace batteries:

A. Press and slide to open the cover. B. Align the batteries according to the (+) and (–) indications

inside the case.

C. Replace the cover. CAUTION: Incorrect usage of batteries can result in leaks or

bursting.

English-12

Screw

Clamp

5. Switch on the power of all the attached external equipment

When connected with a computer, switch on the power of the computer ﬁrst.

6. Operate the attached external equipment

Display the signal from the desired input source.

7. Adjust the sound

Make volume adjustments when required.

8. Adjust the screen (See pages 20 and 21)

Make adjustments of the screen display position when necessary.

9. Adjust the image (See page 20)

Make adjustments such as backlight or contrast when required.

10. Recommended Adjustments

To reduce the risk of the “Image Persistence”, please adjust the following items based on the application being used: “SCREEN SAVER”, “SIDE BORDER COLOR” (See page 25) “DATE & TIME”, “SCHEDULE SETTINGS” (See page 22). It is recommended that the “FAN CONTROL” setting (See page 25) be turned to ON also.

English

English-13

+ 35 hidden pages
