NEC 1080Xd User Manual

Download

()

■■■■■■■

EXPRESS5800/1080Xd

User’s Guide

■■■■■■■

Proprietary Notice and Liability Disclaimer

The information disclosed in this document, including all designs and related materials, is the valuable property of NEC Solutions (America), Inc. and/or its licensors. NEC Solutions (America), Inc. and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are expressly granted to others.

The NEC Solutions (America), Inc. product(s) discussed in this document are warranted in accordance with the terms of the Warranty Statement accompanying each product. However, actual performance of each product is dependent upon factors such as system configuration, customer data, and operator control. Since implementation by customers of each product may vary, the suitability of specific product configurations and applications must be determined by the customer and is not warranted by NEC Solutions (America), Inc.

To allow for design and specification improvements, the information in this document is subject to change at any time, without notice. Reproduction of this document or portions thereof without prior written approval of NEC Solutions (America), Inc. is prohibited.

Trademarks

Windows is a registered trademark of Microsoft Corporation. Intel and Itanium are registered trademarks of Intel Corporation.

All other product, brand, or trade names used in this publication are the trademarks or registered

trademarks of their respective trademark owners.

PN: 456-01683-001 November 2003

NEC Solutions (America), Inc

10850 Gold Center Drive, Suite 200,

Rancho Cordova, CA 95670

Proprietary Notice Using This Guide

Text Conventions...............................................................................................................viii

Related Documents .............................................................................................................. ix

Safety Notices....................................................................................................................... x

Safety Notices for Users Outside of the U.S.A. and Canada.......................................... xi

Care and Handling...............................................................................................................xii

1 System Overview

Overview............................................................................................................................1-2

System Features..................................................................................................................1-3

System Chassis................................................................................................................... 1-5

Front View....................................................................................................................1-5

Top View ......................................................................................................................1-6

Right Side View............................................................................................................1-7

Internal View ................................................................................................................ 1-8

Main Components.........................................................................................................1-9

Itanium 2 Processors............................................................................................. 1-9

System Memory....................................................................................................1-9

PCI-X Core Module.............................................................................................. 1-9

Service Processor Board......................................................................................1-10

Power/Status LEDs .............................................................................................1-10

System Functions.............................................................................................................1-10

Partitioning..................................................................................................................1-10

Chipset and Crossbar Switch......................................................................................1-11

Server Management....................................................................................................1-11

Expansion.........................................................................................................................1-12

CELLV Board.............................................................................................................1-13

CPUs...........................................................................................................................1-13

Memory....................................................................................................................... 1-13

Optional PCIX Unit ....................................................................................................1-13

Peripheral Devices......................................................................................................1-14

Security ............................................................................................................................ 1-14

2 System Operation

Setting Up the Server.........................................................................................................2-2

Starting Up the System.......................................................................................................2-4

Shutting Down the System................................................................................................. 2-8

Using Exception Procedures............................................................................................2-10

Dump...........................................................................................................................2-10

Cold Reset...................................................................................................................2-10

Restart.........................................................................................................................2-11

Power On Reset...........................................................................................................2-11

Booting the OS.................................................................................................................2-12

OS Boot from Boot Manager......................................................................................2-12

OS Boot from the EFI Boot Manager.........................................................................2-12

EFI Shell .....................................................................................................................2-13

EFI Shell Commands.................................................................................................. 2-14

Contents iii

OS Boot from EFI Shell..............................................................................................2-16

Notes for OS Installation.............................................................................................2-17

EFI Device Path...........................................................................................................2-17

Checking Failure.........................................................................................................2-18

Using the DVD-ROM Drive.............................................................................................2-19

Inserting a Disc in the DVD-ROM Drive....................................................................2-19

Removing a Disc from the DVD-ROM Drive.............................................................2-19

Using an Optional Tape Drive..........................................................................................2-20

Environmental DAT Specifications ............................................................................2-20

DAT Cartridge Labels.................................................................................................2-21

Write Protection ..........................................................................................................2-21

DAT Cartridge Insertion and Removal.......................................................................2-22

3 Service Processor

SP Console..........................................................................................................................3-2

SP Console Connections ...............................................................................................3-2

Console Operations.......................................................................................................3-3

Console Status and Login Authentication.....................................................................3-3

Login and Main Menu...................................................................................................3-6

OS (BIOS) Console............................................................................................................3-8

Virtual SOP.........................................................................................................................3-9

Partition State Display.................................................................................................3-10

SP Command Console......................................................................................................3-12

SP Command Console Buffer .....................................................................................3-12

SP Command Prompt..................................................................................................3-13

SP Message Header.....................................................................................................3-13

SP Command List........................................................................................................3-14

SP Command Reference...................................................................................................3-16

CM (Change Command Mode)...................................................................................3-17

DF (Shut Down System Power <override>)...............................................................3-18

DL (Display SP Logs).................................................................................................3-19

DN (Shut Down System Power)..................................................................................3-23

DP (System Dump) .....................................................................................................3-25

DT (SP Date and Time)...............................................................................................3-26

EN (Environmental Information)................................................................................3-27

FV (Firmware Versions)..............................................................................................3-31

HC (Hardware Configuration).....................................................................................3-32

HE (Help)....................................................................................................................3-52

ML (Message Log)......................................................................................................3-53

PC (Power Cycle)........................................................................................................3-55

RS (Cold Reset System)..............................................................................................3-57

UP (Bring Up System) ................................................................................................3-58

4 BIOS Setup

Setup Overview..................................................................................................................4-2

What is Setup?...............................................................................................................4-2

When You Should Change the Settings ........................................................................4-2

Some Setting Errors Exist......................................................................................4-2

Settings of CMOS and/or NVRAM Are Cleared..................................................4-3

Adding or Deleting a Boot Device........................................................................4-3

The BIOS Version Has Changed...........................................................................4-4

The Host Bus Bridge Configuration Has Changed................................................4-4

iv Contents

Starting Setup................................................................................................................ 4-4

Screen Description........................................................................................................4-5

Menu Tree..........................................................................................................................4-6

Main Menu Overview...................................................................................................4-7

Advanced Menu Overview...........................................................................................4-8

Security Menu Overview.............................................................................................. 4-9

System Hardware Menu Overview............................................................................. 4-10

Exit Menu Overview...................................................................................................4-12

Menu Options and Settings.............................................................................................. 4-13

Main Menu.................................................................................................................. 4-13

Advanced Menu..........................................................................................................4-15

Advanced Submenu ............................................................................................ 4-17

Peripheral Configuration Submenu.....................................................................4-18

Monitoring Configuration Submenu................................................................... 4-20

Option ROM Submenu ....................................................................................... 4-22

Extended PCI Slot Submenu...............................................................................4-24

Numlock Submenu.............................................................................................. 4-27

Security Menu.............................................................................................................4-29

System Hardware Menu..............................................................................................4-31

HBB Configuration Submenu.............................................................................4-33

PCI Bus Parity Error Assert Submenu................................................................4-35

Master Latency Timer Submenu......................................................................... 4-37

Multi Transaction Timer Subm enu..................................................................... 4-39

Low MMIO Configuration Submenu.................................................................. 4-41

High MMIO Configuration Submenu................................................................. 4-43

IO Space Configuration Submenu.......................................................................4-45

PCI Bus Configuration Submenu........................................................................4-47

Console Redirection Submenu............................................................................4-49

Console Redirection – System Serial Port ..........................................................4-51

Console Redirection – Serial Port 1.................................................................... 4-53

Shrink Total Number of Interrupt Vectors Submenu..........................................4-55

Memory Mapped I/O > 4GB Submenu...............................................................4-56

Exit Menu............................................................................................................ 4-57

BIOS Virtual DIP Switch................................................................................................. 4-59

What is BIOS Virtual DIP Switch?.............................................................................4-59

PCI Online Maintenance (PCI Hot Plug).........................................................................4-60

Available PCI Online Maintenance Function.............................................................4-60

Preparing the Resources..............................................................................................4-60

If a Reboot Occurs......................................................................................................4-61

HBB Configuration Submenu Precaution........................................................................ 4-63

5 I/O Board Installation

Identifying PCI Slots in the Core Module..........................................................................5-2

Identifying PCI Slots in the PCIX Unit..............................................................................5-5

Selecting a Slot...................................................................................................................5-8

Installing a Board in the Core Module...............................................................................5-9

Installing a Board in the PCIX Unit.................................................................................5-14

6 Problem Solving

Solving Simple Problems................................................................................................... 6-2

Troubleshooting the System...............................................................................................6-4

Contents v

A Technical Specifications

Main Chassis......................................................................................................................A-2

DVD-ROM Drive..............................................................................................................A-3

Tape Drive.........................................................................................................................A-4

FDD...................................................................................................................................A-5

B Memory Upgrades

Memory Configurations ....................................................................................................B-2

DIMM Installation.............................................................................................................B-3

C Windows 2003 Installation

Installing Microsoft Windows 2003..................................................................................C-2

Creating a Mirrored Drive of Windows 2003....................................................................C-3

Index

vi Contents

Using This Guide

This User’s Guide provides a quick reference to information about your server system. Its goal is to familiarize you with your system and the tasks necessary for system setup and operation.

This guide contains the following information:

! Chapter 1, “System Overview,” provides an overview of your system and describes your

system’s major system components. See this chapter to familiarize yourself with your system.

! Chapter 2, “System Operation,” tells you how to set up the server, how to start up, shut

down, and reboot the system, how to boot the OS, and how to use the DVD-ROM drive and optional tape drive.

! Chapter 3, “Service Processor,” describes service processor functions. This chapter

includes information about the SP console, OS console, Virtual SOP, and service processor commands.

! Chapter 4, “BIOS Setup,” provides you with a description of the BIOS Setup utility and

its options for configuring the server.

! Chapter 5, “I/O Board Installation,” shows you how to install I/O boards in the server.

Information includes slot identification and board installation in both the core module and the optional PCIX unit.

! Chapter 6, “Problem Solving” contains helpful information for solving problems that

might occur with your system.

! Appendix A, “Technical Specifications” provides specifications for your server system. ! Appendix B, “Memory Upgrade” provides memory configuration information necessary

for adding memory to the server. Information includes allowable memory configurations, memory slot locations, and how to allocate memory.

! Appendix C, “Windows 2003 Installation” provides information for installing

Microsoft® Windows® 2003 on the Express5800/1000 series server and for creating a mirrored drive of Windows 2003.

Using This Guide vii

Text Conventions

This guide uses the following text conventions. Warnings, cautions, and notes have the following meanings:

Warnings alert you to situations that could result in serious personal injury or loss of life.

Cautions indicate situations that can damage the system hardware or software.

Note: Notes give important information about the material being described.

! Names of keyboard keys are printed as they appear on the keyboard. For example, Ctrl,

Alt, or Enter.

WARNING

CAUTION

! Text or keystrokes that you enter appear as boldface type. For example, type abc123 and

press ENTER.

! File names are printed in uppercase letters. For example, AUTOEXEC.BAT.

viii Using This Guide

Safety Notices

To avoid a risk of injuries, installation should be performed by trained technical personnel.

Your server is equipped with a front stabilizer. Engage the front stabilizer during installation. For stability and to distribute the weight, also attach side stabilizers. Otherwise, the rack may topple over and cause injuries.

If you extend two or more devices from the rack at the same time, the rack may topple over on you. Extend only one device from the rack at a time.

Exercise great care not to hurt your fingers on the rail when you mount/dismount the equipment into/from the rack.

Lithium batteries can be dangerous. Improper handling of lithium batteries may result in an explosion. Dispose of lithium batteries as required by local ordinance. Replace only with the same or equivalent type battery.

The DVD-ROM drive uses a laser beam. Do not look or insert a mirror inside while the system is on. A laser beam is invisible; if your eyes get exposed to it, there is a risk of losing your eyesight.

WARNING

! Elevated Operating Ambient Temperature – If installed in a closed or multi-unit rack

assembly, the operating ambient temperature of the rack environment may be greater than the room ambient environment. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum rated ambient temperature of 89.6°F.

! Reduced air Flow – Installation of the equipment in a rack should be such that the

amount of air flow required for safe operation of the equipment is not compromised.

! To prevent fires, and damage to rack equipment and supply wiring, make sure that the

rated load of the power branch circuit is not exceeded. Equipment nameplate ratings should be used when addressing this concern. For more information on installation and wiring of power-related facilities, contact your electrician or local power company.

! To prevent electrical shock, connect all rack and rack support equipment to the same

electrical circuit of the building wiring. If you are unsure, check the building wiring to avoid remote earth conditions.

! For safe operation, only connect the equipment to a building supply that is in accordance

with current wiring regulations in your country. In the USA those wiring standards are regulated by Underwriter Laboratories (UL); in the U.K. by the Institution of Electrical Engineers, (IEE) and in Canada by the Canadian Standards Association (CSA).

x Using This Guide

WARNING

Some locations within the server have high voltage and therefore are very

dangerous. To avoid risk of electric shock, turn off all server power and

disconnect power cables before working inside the server unit.

The main power of your server is turned off by turning off the power source to the

server or removing the power cable.

Before touching the parts in the server, wait for at least 10 to 15 seconds until

residual voltage is disc harged.

Safety Notices for Users Outside of the U.S.A. and Canada

PELV (Protected Extra-Low Voltage) Integrity: To ensure the extra-low voltage integrity of the equipment, connect only equipment with mains-protected electricallycompatible circuits to the external ports.

! Remote Earths: To prevent electrical shock, connect all local (individual office)

computers and computer support equipment to the same electrical circuit of the building wiring. If you are unsure, check the building wiring to avoid remote earth conditions.

! Earth Bonding: For safe operation, only connect the equipment to a building supply

that is in accordance with current wiring regulations in your country. In the USA those wiring standards are regulated by Underwriter Laboratories (UL); in the U.K., by the Institution of Electrical Engineers, (IEE) and in Canada by the Canadian Standards Association (CSA).

Using This Guide xi

Care and Handling

Use the following guidelines to properly handle and care for your system.

Protect the system from extremely low or high temperatures. Let the system warm (or cool) to room temperature before using it.

Keep the system away from magnetic forces.

Keep the system dry. Do not wash the system with a wet cloth or pour fluid into it.

Protect the system from being bumped or dropped.

Check the system for condensation. If condensation exists, allow it to evaporate before powering on the system.

Keep the system away from dust, sand, and dirt.

xii Using This Guide

System Overview

! Overview ! System Features ! System Chassis

! System Functions ! Expansion ! Security

Overview

Your Express5800/1080Xd server is a modular, multiprocessing server based on the Intel® Itanium® 2 64-bit processor. The combination of Intel Itanium 2 architecture, along with your server’s innovative crossbar switch and high-speed memory access technology, provides for massive power and scalability using the latest available operating systems. Your server is ideal for large-scale applications as well as compute intensive environments. Your server is conveniently housed in a rack-mount cabinet (see Figure 1-1).

Figure 1-1. Express5800/1080Xd Server

Advanced features of your Express5800/1080Xd server include:

! High-speed processing and high scalability

High-speed processing is realized through a combination of the new Intel CPU and NEC crossbar switch and high-speed memory access technologies. In addition to support for up to 8 CPUs, the server employs the advanced PCI-X bus to connect peripheral and network devices and can be configured with up to 26 I/O slots, demonstrating the high scalability ideal for large-scale configurations.

! Partitioning functionality for flexible system operation

Your server can be partitioned at the hardware level, enabling each subsystem to operate as an independent computer system. It is possible to divide an 8 CPU system configuration into two subsystems, each of which has 4 CPUs, and let them each operate separately. In this way, it’s possible to allocate processor capacity according to workload status, resulting in flexible system operation and guaranteed security.

! High reliability and availability

Many hardware components allow redundancy, and the CPU/memory cell board and I/O card hardware are hot-swap compliant. Easy system recovery is possible even at the time of failure.

1-2 System Overview

System Features

Your system features the following major components:

! Quad high-performance Intel

processors per CellV Board.

! Up to two CELLV Boards, each supporting the installation of up to 4 CPUs

(Intel Itanium 2 processors) for a total of 8 CPUs in the system. Each CELLV Board has 16 DIMM sockets and supports from 4 GB (using four

1-GB DIMMs) to 16 GB (using sixteen 1-GB DIMMs) of ECC SDRAM fourway interleaved memory.

! Core Module that includes:

 Interface to connect with the optional PCIX Unit (1.6G interface)  Twelve PCI-X expansion slots for add-in boards. A Basic I/O Board and

VGA card are installed in two of the PCI-X expansion slots. The Core Module includes eight 64-bit/66-MHz hot-swap PCI-X slots and four 64-bit/133-MHz hot-swap PCI-X slots.

Itanium® 2 64-bit 1.3GHz/3MB or 1.5GHz/6MB

 Two USB interface ports, two IDE interface ports, Mouse interface and

Keyboard interface ports.

 ATI RAGE XL Video Graphics Array (VGA) controller with 8MB of video

memory (VRAM)

 DVD-ROM unit  Bay for an optional DAT drive or optional USB FDD unit  Four hot-swap SCSI hard disk drive bays accessible from the front of the

chassis; each drive bay can contain a 36-GB, 73-GB, or 146-GB SCSI hard disk drive.

! Intelligent Service Processor-Clock (iSP-C) Board which provides diagnostic

functions and clock distribution.

! Hot-swap SCSI disk drive backplane; a failed drive can be removed and replaced

with a new drive without system power being turned off (if software mirror has been configured).

! Hardware monitors (temperature, fans, and voltage) and software monitors to

indicate failures.

! The main chassis supports three power supply modules. Only two of the modules

are required to power the system. The additional power supply module provides hot-swappable redundant power (i.e., the system will continue to operate with a single power supply failure). With three power modules installed, one power module can be easily removed or installed from the front of the chassis without turning the system power off.

System Overview 1-3

! Ten fan modules are located throughout the system. Any fan module can easily

be removed and installed, without powering down the system.

! Optional PCIX Unit in two versions, Base Unit and Core Unit:

 14 PCI-X expansion slots in a Base Unit model  12 PCI-X expansion slots, a Basic I/O Board with 2 USB, 2 IDE, and

1 Keyboard interfaces, a VGA card with an analog interface, and a DVD-ROM unit in a Core Unit model to allow a second bootable partition.

 Bay for an optional DAT or optional USB FDD unit  Six hot-swap SCSI hard disk drive bays for up to 6 hard drives.

See Appendix A, “Technical Specifications,” for a list of system specifications.

1-4 System Overview

System Chassis

The following figures show the external and internal server features.

Front View

Figure 1-2 shows the front system features (front door and covers are not shown in the figure).

E F

A AC Power Switch H PCIX Power Unit with Two

Power Supplies (optional)

B AC Power Switches for

Optional Power Supply

Modules C Filler Panels J 1080Xd Main Chassis D Power/Status LEDs K Main Chassis Power Supply

E Bay for optional DAT Tape

Drive or USB FDD F Hard Disk Drive Bays M Emergency AC Power Switch

I Base or Core PCIX Unit

(optional)

Modules

L DVD-ROM Drive

(for optional PCIX Unit)

G Cell Cooling Fans

Figure 1-2 Front View

System Overview 1-5

Top View

Figure 1-3 shows the components within the Main Chassis.

A DVD ROM Drive D Core Module Ejector B Power Supply Modules (3) E PCI-X Expansion Slots C Core Module Fans F Hard Disk Drive Fans

Figure 1-3. Main Chassis

1-6 System Overview

Right Side View

Figure 1-4 shows the system right side features.

CDE

Figure 1-4. 1080Xd Right Side View

A Service Processor and

Clock (ISP-C) B 1080Xd Main Chassis E Cabinet C Cell #3 Board

D Cell #0 Board

System Overview 1-7

Internal View

Figure 1-5 shows internal views of CELLV Board features.

Side A

Side B

A CPU Slot #1 E CPU Slot #2 B CPU Slot #3 F CPU Slot #0 C DIMM Slots G Power Pods D Power Pods

1-8 System Overview

Figure 1-5. CELLV Board

Main Components

The following sections provide information about the components in the main chassis.

Itanium 2 Processors

Depending on system configuration, your system includes four or eight Intel Itanium 2 64-bit 1.3-GHz/3-MB or 1.5-GHz/6.0-MB processors. Four Intel Itanium 2 processors are installed within one CELLV board. See Figure 1-5. A second CELLV board has an additional four Intel Itanium 2 processors. All processors installed in your system must be of identical bus and core speed.

System Memory

Each CELLV board in your system contains sixteen 168-pin DIMM sockets. See Figure 1-5. Memory DIMMs must be populated four at a time with 1-GB ECC SDRAM DIMMs. Depending on the number of DIMMs installed, your system may include from 4 GB up to a maximum of 32 GB of memory using 1-GB DIMMs.

PCI-X Core Module

The server’s expansion capabilities meet the needs of file and application servers for high performance I/O by providing twelve hot-swap PCI-X expansion slots within the Core Module. The Core Module consists of a CrossBar Controller (XBC) and an I/O Router (IOR). The Core Module can be connected with up to two CELLV Boards, to control data transfers between the CELLV Boards.

The Core Module includes five full-length and three half-length 64-bit/66-MHz hotswap PCI-X slots and three full-length and one half-length 64-bit/133-MHz hot-swap PCI-X slots. The PCI-X slots allow PCI-X boards to be installed or removed while the server is powered on (if the operating system supports the Hot Plug PCI function). A Basic I/O Board to support standard I/O interface and a video VGA controller board are installed in the Core Module. The Basic I/O Board and video VGA board are not hotswappable.

Note: Your operating system must support the Hot Plu g PCI

function.

A DVD-ROM drive is installed in the Core Module as standard equipment. Optionally, a DAT tape drive or USB FDD and up to 4 disk storage hard disk drives may be added to the Core Module. See Figure 1-2.

System Overview 1-9

Service Processor Board

The Service Processor Board (iSP-C Board) controls power and monitors status of all components (see Figure 1-4). The board uses a PowerPC chip as the processor for iSP-C, memory, LAN, serial interface, and clock distribution functionality. The Service Processor Board performs initialization of the system, RAS functions, diagnostic functions, failure management of the system, and clock generation and distribution.

Power/Status LEDs

Three LEDs are visible on the front of the server system cabinet (see Figure 1-2):

! AC ! DC ! Status.

See Table 1-1 for a description of the LEDs.

LED LED State Description

Table 1-1. Power/Status LEDs

Status LED

Green On OS ready (one node or more). Amber

System Functions

The following subsections describe select system functions.

Partitioning

If your system includes two CELLV Boards and an optional core PCIX expansion unit, your server may be partitioned at the hardware level into two distinct subsystems, enabling each subsystem to operate as an independent computer system, each with its own operating system.

On AC power on. AC Green Off AC power off.

On DC power on (lights when DC48V is supplied). DC Green Off DC power off.

On System is in Maintenance mode (execution of the SP “cm”

command).

Off Failure or offline state.

It is possible to divide the eight-CPU system into two subsystems, each of which has four CPUs, and let them each function separately. In this way it’s possible to allocate processor capacity according to workload status, resulting in flexible system operation.

Each partition is physically isolated by the hardware settings; a software error does not affect the other partitions. Thus the system can maintain high security.

1-10 System Overview

Each partition consists of a CELLV Board and a core PCIX unit. Multiple OS instances can run on different partitions independently. If a partition has at least one PCIX unit with basic I/O, the CELLV Boards and the PCIX units can be flexibly assigned to any partition.

The Service Processor manages the partitioning settings and configuration changes.

Chipset and Crossbar Switch

NEC developed a high-performance chipset and crossbar switch that is based on supercomputer mainframe technology. The crossbar switch connects the CELLV boards. The crossbar switch has a low latency as well as high data bandwidth. While comprising Cache Coherent Non-Uniform Memory Access (cc-NUMA) architecture, the system employs the chipset and crossbar switch technology in achieving near uniform high-speed memory access.

Server Management

The Service Processor supports many management functions compatible to the Advanced Configuration and Power Interface (ACPI) and Intelligent Platform Management Interface (IPMI).

The system supports the following ACPI features:

! Configuration information tables interface from a platform. ! Software power off controls, etc.

The Service Processor also works as a management controller defined in IPMI. It supports the following IPMI features.

! Provides Field Replaceable Unit (FRU) information to System Management

Services (SMS) running on the operating system.

! Monitors system power, fan speed, and temperature conditions. ! Monitors stall occurrences during the power-up sequence, OS loading, and

normal running using a watchdog timer, etc.

The Service Processor provides the following management features:

! Error handling (error monitoring, logging, diagnostics, and reporting) ! System reset ! System configuration management ! Firmware update, etc.

The SMS running on a PC can control the above functions using the Service Processor’s system management LAN port, which can support TELNET, FTP, and SNMP protocol. With the combination of the Service Processor and the SystemGlobe/GlobalMaster software, the Express 5800/1080Xd supports automatic reconfiguration of partitions based on the conditions pre-defined in the SystemGlobe/GlobalMaster.

System Overview 1-11

Expansion

The Express5800/1080Xd server can be expanded by adding:

! Memory ! I/O boards ! Disk drives ! PCIX Expansion Unit.

See Figure 1-6 for a diagram of the Express5800/1080Xd system configuration. See the following sections for a description of system expansion capabilities.

I t ani um2

Standard: one CELLV Board with 4 CPUs (Itanium 2); a second CELLV Board with 4 CPUs (Itanium2)

Core Module

DVD-ROM drive DVD-ROM/ CD-ROM

Magnetic tape

DD4 or USB FDD (Optional)

10/ 100B A SE -TX

RS 232C

(Consol e)

4 GB memory upgrade (using 1-GB DIMMs)

Up to 4 sets of the above memory per CELLV Board or up to 16 GB can be installed per board.

SP Console

(Standard)

Server Management

LAN Interface

Ethernet cable

Up to 4 HDDs (Disk Storage) can be installed.

Figure 1-6. Express5800/1080Xd System Configuration

1-12 System Overview

1. 6G

1.6G cable

Optional PCIX Unit

N E C

DVD-ROM drive DVD-ROM/ CD-ROM

Magnetic tape

DD4 or USB FDD (Optional)

CELLV Board

Each CELLV Board supports:

! 4 Intel Itanium 2 processors ! 16 DIMMs.

The system supports 2 CELLV Boards for a total of eight Itanium 2 processors and up to 32 DIMMs.

CPUs

Each CELLV Board supports 4 Itanium 2 processors. The system supports the following processor types:

! Intel Itanium 2 1.3GHz/3MB of level 3 cache

CAUTION

Contact qualified personnel, such as your System Administrator or an NEC Technician, for adding or removing server components.

Memory

! Intel Itanium 2 1.5GHz/6MB of level 3 cache

The same type processor must be used in the system. The two types cannot be mixed within a single system.

Each CELLV Board supports up to 16 DIMMs in the following configurations:

! Memory must be installed in groups of 4 DIMMs of the same capacity. ! Memory capacity can vary between different groups ! At least one group of four DIMMs is required in the system. ! Each CELLV Board supports up to 4 groups of 4 DIMMs.

! A memory group currently includes a group of four 1-GB DDR DIMMs for total

capacity of 4 GB in a group.

! Maximum memory capacity using currently available 1-GB DIMMs is 16 GB

per CELLV board or 32 GB on two CELLV boards.

For detailed memory configuration information, see Appendix B. in this guide.

Optional PCIX Uni t

A PCIX Unit can be added and connected to the Main Chassis. The PCIX Unit connects to the Core Module via a 1.6-GB interface cable (dedicated cable for connecting the unit).

A PCIX Unit requires a Power Bay Unit. Up to six Distributed Power Supply (DPS) modules can be installed in a Power Bay Unit.

System Overview 1-13

Peripheral Devices

Disk drives can connect to a SCSI board, and ATA devices can connect to the Basic I/O Board. You can also connect peripheral devices via PCI cards installed in the optional PCIX Unit.

Security

To help prevent unauthorized entry or use of the system, the server provides the following security features:

! Locked areas require a security key for entry. Locked areas include the rear

chassis door and drive bay units.

! The BIOS Setup utility provides user and administrative password security,

protecting the system from unauthorized operation.

! Console operation requires the entry of login authentication with a login account

and password.

1-14 System Overview

System Operation

! Setting Up the Server ! Starting Up the System ! Shutting Down the System

! Rebooting the System ! Booting the OS ! Using the DVD-ROM Drive ! Using an Optional Tape Drive

Setting Up the Server

Use the following procedure to set up the server.

Note: See Chapter 1 of this user’s guide to become

familiar with server features, such as the location of system switches, indicators, and main chassis components.

1. Check that the server has been installed as described in the

Express5800/1080Xd/1160Xd/1320Xd Site Preparation Guide and Express5800/1080Xd Installation Procedures. This server requires

installation by qualified personnel such as an NEC technician and system administrator.

2. Make sure that any optional components other than I/O cards or boards,

have been installed by an NEC technician. If you have an I/O card or board to install, install it now (see Chapter 5, “I/O

Board Installation”).

3. Unlock the rear door of the server with the security key. Open the door by

lifting the handle and turning it clockwise (see Figure 2-1). Server cable connectors for system setup are located at the rear of the server.

A Lift Handle B Turn Clockwise

Figure 2-1. Opening the Rear Server Door

2-2 System Operation

4. Locate the server LAN cable at the rear of the server cabinet. Connect a

client PC to the server LAN connection.

Note: A LAN cable either comes already connected to

the Service Processor board or it is connected by the NEC technician during the server installation.

5. Connect peripheral devices, such as a monitor, mouse, and keyboard, to the

rear of the server. See Figure 2-2 for server connector locations.

A VGA Monitor Connector B Mouse and Keyboard Connectors

Figure 2-2. Server Connector Locations

CAUTION

When connecting a cable to an I/O board, be sure to leave enough cable free for sliding the main chassis or PCIX unit out of the cabinet. Route the cable so it does not get pinched or damaged.

Route the external device cables under the rear door frame and out of the way of the rear server door.

6. Close and lock the rear server door.

System Operation 2-3

Starting Up the System

Start up the server system as follows.

1. Make sure all external devices, such as the console, keyboard, and mouse

have been connected, and the power cords are connected (see the previous section, “Setting Up the Server”).

2. Turn on the circuit breaker or main switch to the system power source.

Note: If the server power cord is connected to a power

control unit such as an UPS (Uninterruptive Power Supply), make sure that the power control unit is powered on.

3. Power on the console and any other external devices.

4. At the rear of the server cabinet, turn on the AC power circuit breaker for the

Main Chassis (see Figure 2-3), and if installed, for the optional PCIX Unit (see Figure 2-4).

A AC Power Circuit Breaker

Figure 2-3. Main Chassis AC Power Circuit Breaker

2-4 System Operation

A AC Power Circuit Breaker

Figure 2-4. PCIX Unit AC Power Circuit Breaker

5. On the front of the server cabinet, power on the AC POWER switch at the

top of the system (see Figure 2-5).

A AC Power Switch

Figure 2-5. AC Power Switch

Note: If the AC-Link function has been enabled, following the AC

power being turned on, and if the operating system has been installed, the system will automatically boot up the operating system without further intervention (refer to the description of the SU command in the Express5800/1080X Service Guide).

If the AC-Link function has not been enabled, then continue with this “Starting Up the System” procedure.

System Operation 2-5

6. Press Esc on the service processor (SP) keyboard. The iSP (service

processor) login prompt appears.

7. Enter the login name spfw and password nec. (The login name and

password are default values.) The iSP Main Menu screen appears (see Figure 2-6).

8. At the iSPyz prompt, enter the iSP command

s to enter the SP command

mode.

9. Press

Esc.

Integrated Service Processor. Cabinet-ID:xx, Location:y, State:ssssss

iSP login: spfw<ENTER> iSP password: xxxxxxxx<ENTER>

iSP MAIN MENU

0) OS(BIOS) serial console of partition#0 (INITIALIZING)

1) OS(BIOS) serial console of partition#1 (RUNNING) V) Virtual System Operator Panel S) iSP commands E) Exit

iSPyz> s ***** SP Command Mode **** ***** enter ESC to do the command input effectively ***** ***** enter CTRL+B to quit *****

iSPyz:--->

Figure 2-6. SP Console Screen – SP Firmware Activated

2-6 System Operation

10. Enter up on the SP console to bring up the specified partitions

(see Figure 2-7). The service processor turns on power to the specified partitions, initializes

the hardware, and hands off the control to the BIOS. The BIOS boots the operating system.

iSPyz:---> up<ENTER> This command will bring up the specified partition.

Enter partition number (0-7/all/CR=exit) : all<ENTER> Execute OK? (y/[n]) y UP command was accepted. All partitions will run soon.

[iSPyz:INFO.ccc] partition 0 : power on sequence started. [iSPyz:INFO.ccc] partition 1 : power on sequence started. : [iSPyz:INFO.ccc] partition 1 : power on sequence completed normally. : [iSPys:INFO.ccc] partition 1 : handed off the control to BIOS.

<ENTER>

Figure 2-7. System Startup Screen

System Operation 2-7

Shutting Down the System

Shut down the system as follows.

1. Select a method to shut down the system:

Note: If supported by your operating system, Windows

Shut Down is the recommended method of shutting down the system.

! Recommended shutdown – Windows Shut Down

(if supported by the operating system): Shut down the operating system (OS). The related partition(s) automatically shutdown and power off (see Figure 2-8).

! Shutdown using the DN command.

Enter dn on the SP console to shut down the system. If software is not running, this command powers off the selected partition(s) (see Figure 2-9).

! Shutdown system power using the DF command:

Enter df on the SP console to force a shut down of the system (see Figure 2-10). This power shutdown method forces a partition shutdown without prior warning to the operating system.

CAUTION

This SP df command turns off system power regardless of OS or BIOS operation and without notifying either. This command corresponds to a power button override function of a system with a physical power button.

[iSPyz:INFO.ccc] partition 0 : power off sequence started. : : : [iSPyz:INFO.ccc] partition 0 : power off sequence completed normally.

2-8 System Operation

Figure 2-8. OS Shut Down Screen

iSPyz:---> dn<ENTER> System power will be turned off if the software (OS) is NOT running. Only power button interrupt will be generated if the software (OS) is running. If you want to turn off the system power in any system state, use DF command.

Enter partition number (0-7/all/CR=exit) : all<ENTER> Execute OK? (y/[n]) y<ENTER> DN command was accepted. System power of all partitions will be turned off or

power button interrupt will be generated soon.

[iSPyz:INFO.ccc] partition 0 : power button interrupt. [iSPyz:INFO.ccc] partition 1 : power off sequence started. : [iSPyz:INFO.ccc] partition 1 : power off sequence completed normally.

Figure 2-9. DN Command Power Shut Down Screen

iSPyz:---> df<ENTER> CAUTION: System power will be turned off without any notice to the softwares

even if they are running.

Enter partition number (0-7/all/CR=exit) : all<ENTER> Execute OK? (y/[n]) y<ENTER> DF command was accepted. System power of all partitions will be turned off soon.

[iSPyz:INFO.ccc] partition 0 : power off sequence started. [iSPyz:INFO.ccc] partition 1 : power off sequence started. : : : [iSPyz:INFO.ccc] partition 1 : power off sequence completed normally.

Figure 2-10. DF Command Power Shut Down Screen

2. Check that the DC power is off. The SP console displays a “power off”

message (see Figures 2-8, 2-9, and 2-10). This is a normal system “power off.” For a complete system power off,

perform the following steps.

Note: The following steps perform a “complete system

power off.” A “complete power off” is not normally performed.

System Operation 2-9

3. Power off the console.

4. Turn off AC power to the system:

! At the top front of the system cabinet, press the AC power switch. ! At the rear of the system, power off the circuit breaker to the optional

PCIX Unit, if installed.

! At the rear of the system, power off the circuit breaker to the Main

Chassis.

5. Power off peripheral devices not powered by the server.

6. Power off the main circuit breaker or power distribution board.

Note: If the server power cord is connected to a power

control unit such as an UPS (Uninterruptible Power Supply), refer to the UPS user's guide for proper power-off procedures.

Using Exception Procedures

The following sections describe exception procedures for restarting the system.

Dump

Use the dump function to request the operating system to perform its memory dump process. You can select either to restart or not to restart using the operating system settings. To use the dump function, the system must be running the operating system.

To dump, enter

Cold Reset

Use a cold reset to reset the entire system, including memory, when there is a hardware error condition.

Perform a cold reset as follows:

1. Stop the operating system.

Note: For detailed information about SP commands,

see “SP Command Reference” in Chapter 3.

dp at the SP command prompt.

2. Enter

2-10 System Operation

rs at the SP command prompt.

Restart

Perform a system restart as follows:

1. Stop the operating system.

2. Enter pc at the SP command prompt.

Power On Reset

Perform a power on reset as follows:

1. Stop the operating system.

2. Enter dn at the SP command prompt. Check that the main chassis fans stop

rotating.

3. Turn off AC power to the system:

! At the top front of the system cabinet, press the AC power switch. ! At the rear of the system, power off the circuit breaker to the optional

PCIX Unit, if installed, and to the main chassis.

4. Wait 10 to 15 seconds to discharge residual voltage.

5. Turn on AC power to the system:

! At the rear of the server, power on the AC power circuit breaker to the

main chassis, and if installed to the PCIX Unit.

! On the front top of the server cabinet, power on the AC power switch.

6. On the SP console, enter the login account and password.

7. On the SP console, enter up at the SP command prompt. The service

processor turns on DC power and initializes the hardware. The BIOS boots the operating system.

System Operation 2-11

Booting the OS

The following sections include information about the EFI Boot Manager, EFI shell, shell commands, and booting the OS from the EFI shell.

OS Boot from Boot Manager

The EFI Boot Manager automatically starts after a BIOS bootup (see Figure 2-11). From the EFI Boot Manager, you can choose to go to:

! EFI applications ! EFI shell prompt ! Boot maintenance menu.

EFI Boot Manager ver 1.10 [14.56] Please select a boot option Acpi(PNP0A03,0)/Pci(2|1)/Ata(Primary,Master)/CDROM(Entry1) Acpi(PNP0A03,1)/Pci(3|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig17FB0000) EFI Shell [Built-in]

Boot option maintenance menu

Use the arrow keys to change settings

Figure 2-11. EFI Boot Manager Screen

OS Boot from the EFI Boot Manager

When the OS is installed, OS boot options are automatically registered in the EFI Boot Manager. You can select and boot the OS from the EFI Boot Manager.

Figure 2-12 shows an example of a boot path defined “Acpi(PNP0A03,0)/Pci(3|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig17FB0000)” as the OS boot disk.

To boot the OS from the EFI Boot Manager, select the boot path using arrow keys and press

2-12 System Operation

Enter.

EFI Shell

Boot option maintenance menu

Use the arrow keys to change settings

Indicates OS Boot Disk

Figure 2-12. OS Boot from EFI Boot Manager Screen

From the EFI Boot Manager, you can activate the EFI shell. Use the EFI shell to:

! Read the system file of the Boot device. ! Copy files.

When you select the EFI Shell from the EFI Boot Manager, the EFI Shell screen appears (see Figure 2-13).

Loading.: EFI Shell [Built-in] EFI Shell version 1.10 [14.56] Device mapping table fs0 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig0A7C0000) blk0 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0) blk1 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig0A7C0000) blk2 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part2,Sig0A7C0000) blk3 : Acpi(PNP0A03,0)/Pci(2|1)/Ata(Primary,Master) Shell>

EFI shell prompt

List of disk drives identified by the system

Figure 2-13. EFI Shell Screen

System Operation 2-13

EFI Shell Commands

The following table lists and describes the shell commands in the EFI shell. To execute an EFI shell command, enter the EFI shell command at the EFI shell

prompt and press Enter.

Command Description

alias alias [-d|-v|-b] [sname] [value] Displays, creates, and deletes the alias

attrib attrib [+a|-a] [+s|-s] [+h|-h] [+r|-r]

[-b] [file ...] [directory ...]

Table 2-1. EFI Shell Commands

definition in the EFI Shell environment. Displays and changes the attributes of the

file/directory.

bcfg bcfg driver|boot [dump –v] [add

# file “desc”] [rm #] [mv # #] break break Executes a debugger breakpoint. cd cd [path] Displays and changes the current

child child Handle Displays the device tree under the handle. cls cls [color] Clears the standard output. comp comp file1 file2 Compares the contents of the two files. connect connect [-r] Handle# |

DeviceHandle# DriverHandle# cp cp [-r] src [src ...] [dst] Copies the file/directory. date date [mm/dd[yy]yy] Displays and sets the date. dblk dblk device [Lba] [blocks] Dumps the block device. dh dh [-p prot_id] [-b] | [handle] Displays the handle in the EFI

disconnect disconnect DeviceHandle#

[DriverHandle# [ChildHandle#]]

| [-r] Dmem dmem [Address] [Size] [;MMIO] Dumps memory.

Displays and changes the configuration of the driver/boot.

directory.

Binds the driver to the device and starts the driver.

environment. Disconnects the device and the driver.

dmpstore dmpstore Displays the NVRAM variable. echo echo [-on|-off]

edit edit [file] Edits the ASCII/UNICODE file. EfiCompress EfiCompress [InFile] [OutFile] Compresses the file. EfiDecompress EfiDecompress [InFile] [OutFile] Decompresses the file. err err [ErrorLevel] Displays and changes the error level. exit exit Exit from the EFI Shell. getmtc getmtc Displays the current counter value. guid guid [-b] Displays the GUID in the EFI

2-14 System Operation

echo [message]

Displays messages, or switches on/off echo.

environment.

Table 2-1. EFI Shell Commands (continued)

Command Description

help help [-b] | [cmd] Displays the help information. hexedit hexedit [[-f] FileName | [-d

DiskName Offset Size] | [-m

Offset Size] load load file [file ...] Loads the EFI driver. LoadPciRom LoadPciRom [FileName] Loads the PCI option ROM image from

ls ls [-b] [-r] [-a [attrib]] [file] Displays the directory/file list. map map [-r|-v|-d] [sname] [handle] [-

b] memmap memmap [-b] Displays the memory map. mkdir mkdir dir [dir ...] Creates a directory. mm mm Address [Width 1|2|4|8]

[;MMIO| ; MEM| ; IO | ;PCI]

[:Value] [-n] mode mode [row col] Displays and changes the mode of the

mount mount BlkDevice [sname] Mounts the file system on the block

mv mv src [src ...] [dst] Moves the file/directory. OpenInfo OpenInfo Handle Displays the protocol of the handle/agent.

Edits in hexadecimal mode.

the file.

Displays and defines the mapping information.

Displays and changes MEM/IO/PCI.

console output device.

device.

pause pause Displays a message and waits for input. pci pci [Bus Dev [Func] [-i] [-s

[Seg]]] reset reset [-w [string]] Resets the system. rm rm [-q] file [file ...]

rm [-q] directory [directory ...] set set [-d|-v|-b] [sname [value]] Displays, creates, changes, and deletes

setsize setsize newsize file Sets the file size. stall stall microseconds Stalls the processor in units of

time time [hh:mm[:ss]] Displays the current time or sets the time. touch touch [-r] filename Sets the current date/time to the date/time

type type [-a|-u] [-b] file [file ...] Displays the content of the file. unload unload [-n] [-v] HandleIndex Unloads the protocol image. ver ver Displays the version information.

Displays the configuration space of the PCI device.

Deletes the file/directory.

the EFI environment variable.

microseconds.

attribute of the file.

System Operation 2-15

OS Boot from EFI Shell

You can boot the OS from the EFI Boot Manager. You can also boot the OS by entering commands from the EFI Shell.

An example follows for booting the OS from the SCSI hard disk drive in a hardware configuration containing:

! IDE DVD-ROM (Master) ! SCSI HDD: OS boot disk ! External LAN card built into the Expansion PCI slot.

Note: Cards are available if they are supported by the

application programs or OS.

1. Specify the file system. Change the current file system to the file system

with the connected boot device by entering the device at the Shell prompt. For the example in the following screen (see Figure 2-14), enter fs0: for the

fs0 boot device.

Shell> map Device mapping table

fs0 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig0A7C0000) fs1 : Acpi(PNP0A03,0)/Pci(2|1)/Ata(Primary,Master)/CDROM(Entry1) blk0 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0) blk1 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part1,Sig0A7C0000) blk2 : Acpi(PNP0A03,3)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part2,Sig0A7C0000) blk3 : Acpi(PNP0A03,0)/Pci(2|1)/Ata(Primary,Master) blk4 : Acpi(PNP0A03,0)/Pci (2|1)/Ata(Primary,Master)/CDROM(Entry1)

Shell> fs0:

Enter fs0:

Boot device

Figure 2-14. Specifying the File System on the Shell Screen

2. Change the current working directory to the directory in which the OS

loader is stored. For example, enter

cd os and press Enter at the Fs0:\ prompt.

3. At the fs0:\os prompt, enter

files (see the following Figure 2-15). The list includes the OS loader file name.

2-16 System Operation

ls and press Enter to display a directory list of

4. Start the OS loader by entering the directory file name, in this example,

setupldr.efi, at the fs0:\os prompt and press Enter.

fs0:\> cd os fs0:\os> ls Directory of fs0:\os 03/13/00 05:44p <DIR> 2,048 . 03/13/00 05:44p <DIR> 512 .. 12/22/99 00:58p r 635,392 setupldr.efi

1 File 635,392 bytes 2 Dirs 2,560 bytes

fs0:\os> setupldr

Start OS Loader.

Figure 2-15. Starting the OS Loader from Shell

Notes for OS Installation

See the following notes requiring attention when installing the OS:

! Adding a SCSI card to a free slot and connecting a disk to the SCSI card

after the OS installation, might change the numbering of the disk and prevent an OS boot from that disk.

! PCI12 slot is set to not run Option ROM BIOS as default. Running

Option ROM BIOS on PCI12 slot requires changing the settings of the slot with BIOS setup before booting the OS.

EFI Device Path

Each device installed in the system is managed with an “EFI Device Path.” The following information describes EFI device paths.

See the following examples and Table 2-2 for device path formats for devices conforming to EDD3.0 specification:

Example: SCSI cards and disks installed on the PCI bus:

Acpi(PNP0A03, 1)/Pci(2|0)/Scsi(Pun0,Lun0)/HD(Part1,SigFF050000)

Example: DVD-ROM device connected to the IDE Secondary channel:

Acpi(PNP0A03,0)/Pci(2|1)/Ata(Secondary,Master)/CDROM(Entry1)

System Operation 2-17

Table 2-2. Formats Conforming to EDD3.0 Specification

Path Display Description

Acpi(PNP0A03, X) Indicates that the device is installed under the PCI host bus.

X: PCI host bus bridge number (starting with 0).

Pci(D|F) Indicates PCI installation information of the device.

D: PCI device number (Device numbers 2 – 5 correspond to slot numbers 1 – 4.)

F: PCI function number.

Scsi(Pun0,Lun0) Installation location of the SCSI device (disk) connected to

the SCSI card.

HD(Part1,SigFF050000) SCSI disk drive information.

See the following example and Table 2-3 for device path formats for devices that do NOT conform to EDD3.0 specification:

Example: SCSI cards and fixed disks installed on the PCI bus:

VenHw(Unknown Device:80)/HD(Part1,Sig6D5319DE)

Table 2-3. Formats for Devices Not Conforming to EDD3.0 Specification

Path Display Description

VenHw(Unknown Device:80) Example: The device does not conform to EDD3.0

HD(Part1,Sig6D5319DE) SCSI disk drive information.

Checking Failure

When a failure is detected in the system, it can be checked in the Virtual System Operator Panel (SOP) on the SP console. Virtual SOP provides the following information:

! Partition configuration of the system ! Failure information.

specification. 80: a consecutive number (called a drive number) assigned

to the disk under the SCSI card by the system BIOS. The drive numbers are as follows: 80 or higher: fixed disk drive 9F: DVD-ROM drive

For more information about Virtual SOP, see “Virtual SOP” in Chapter 3.

2-18 System Operation

Using the DVD-ROM Drive

A DVD-ROM drive comes standard in the Main Chassis. The DVD-ROM drive supports DVD-ROM and CD-ROM media. See the following sections for information about using DVD-ROM or

CD-ROM discs in the DVD-ROM drive.

WARNING

Take care when inserting and removing DVD-ROM media. To prevent injury, keep hands away from the tray when ejecting or inserting the tray.

Inserting a Disc in the DVD-ROM Drive

Insert a DVD-ROM or CD-ROM disc in the DVD-ROM drive as follows (see Figure 2-16).

1. Open the server door.

2. Press the Eject button on the DVD-ROM drive to eject the drive tray.

3. Place the disc on the tray, label facing up.

4. Press the Eject button on the DVD-ROM drive to insert the tray.

Removing a Disc from the DVD-ROM Drive

Remove a DVD-ROM or CD-ROM disc from the DVD-ROM drive as follows (see Figure 2-16)

1. Open the server door.

2. Check that the drive access LED (orange) is off.

3. Press the Eject button on the DVD-ROM drive to eject the tray.

4. Remove the disc.

5. Press the Eject button on the DVD-ROM drive to insert the tray.

System Operation 2-19

DVD-ROM Drive

Eject Button

Figure 2-16. Inserting/Removing a DVD-ROM/CD-ROM Disc

DVD-ROM/CD-ROM

Tray

Using an Optional Tape Drive

You can add an optional digital audio tape (DAT) drive to the Main chassis and to the PCIX Unit. See the following sections for information about:

! environmental DAT specifications ! DAT cartridge labels ! write protection ! cartridge insertion and removal.

Environmental DAT Specifications

The following information provides environmental conditions for using 4-mm digital audio tape in the DAT drive.

Operating Environment:

! Temperature: 41 to 89.6°F (5 to 32°C) ! Humidity: 20 to 60%, no condensation ! Maximum wet bulb humidity: 78.8°F (26°C)

Storage Enironment:

! Temperature: 41 to 113°F (5 to 45°C) ! Humidity: 20 to 80%, no condensation ! Maximum wet bulb humidity: 78.8°F (26°C)

2-20 System Operation

DAT Cartridge Labels

Use the following labeling information:

! Place labels securely on the DAT cartridge in the position shown in

Figure 2-17. Be sure to write the start date of DAT cartridge use on the attached Index label.

! If you need to change the contents for the DAT, replace the label with a

new one. (Do not erase the label contents.) Be sure to remove the old label before attaching the new label.

! If you use a label other than the specified INDEX label, be sure the label

size is correct, the label can be easily replaced, and the label doesn’t leave adhesive after removal.

NEC

Figure 2-17. Digital Audio Tape Label Positions

Write Protection

You can protect written data on the audio digital tape from being erased. To protect the data, open the write protect slider on the label side of the digital audio tape cartridge (see Figure 2-18).

To write or overwrite data on the digital audio tape, close the write protect slider.

System Operation 2-21

Figure 2-18. Write Protection Slider on the DAT Cartridge

DAT Cartridge Insertion and Removal

Use the following information to insert and remove DAT cartridges (see Figure 2-19).

! To insert a DAT cartridge:

Hold the DAT cartridge horizontally, with the label side up, and insert it slowly into the drive until it is pulled into the drive.

! To remove a DAT cartridge:

Check that the access LED on the DAT drive is off (green). Press the eject button on the DAT drive and carefully remove the cartridge.

DAT Drive

Eject Button

DAT Cartridge

Cover

Figure 2-19. Inserting and Removing a DAT Cartridge

2-22 System Operation

Service Processor

! SP Console ! OS Console ! Virtual SOP

! SP Command Console ! SP Command Reference

SP Console

The service processor (SP) in the Express5800/1080Xd main chassis provides the interface for system management and RAS functions. The SP is on the service processor and clock (ISP-C) board.

The following sections describe:

! SP console connections ! Console operations ! Console status and login authentication ! Login and Main Menu.

SP Console Connections

The service processor supports two types of console connections (see Figure 3-1):

! serial (local console) ! LAN via TCP port 5001 (LAN console).

Both serial and LAN console connections provide the same operation. However, the LAN console requires an initial configuration which can only be done using the local console. See Table 3-1 for console configuration settings.

ISP-C Board

Serial Connector 0

LAN Connector

ull Modem Cable

TCP5001

Local

Console

LAN

Console

Figure 3-1. Express5800/1080Xd Console Connection

3-2 Service Processor

Table 3-1. Console Configuration Settings

Console Type Configuration Item Default Settings

Serial

LAN

Note: The most effective connection method between the

Express5800/1000 Series and the Service Processor is by using a telnet utility. Multiple instances of the telnet utility can be running at once, providing multiple windows with which to monitor and control the system. These utilities also provide logging features, which can be very useful in back-tracking system settings and status reports. Be sure to set VT100 emulation mode.

Console Operations

Baud rate 9600 Data bit length 8 STOP bit length 1 Parity bit None Flow control RTS/CTS TCP port (Do not use 21, 23. They are for

factory use.) IP address 10.1.1.1 Subnet mask 255.255.255.0 Gateway IP address N/A

5001

You can use the consoles to:

! Operate the service processor using SP commands ! Redirect the operating system (BIOS) serial console (in main chassis) ! Display the Virtual SOP (Virtual System Operator Panel).

Console Status and Login Authentication

To use the consoles, you must first log into the service processor. When you log into the service processor, the iSP Main Menu appears.

From the iSP Main Menu, you can switch to one of the following functions:

! Virtual SOP – displays the system operating state for each partition with periodic

updates.

! OS Console – redirects the serial input/output for the operating system (including

BIOS).

! SP Command Console – allows you to monitor service processor output

messages required for system operation and maintenance and to enter commands for the service processor. The SP Command Console lets you run commands required for system operation.

Service Processor 3-3

Table 3-2 lists the login account and login password default values for entering the Main Menu and using menu functions.

Table 3-2. Login Account and Password Defaults

Note: Only one connection to the OS Console per partition, up

to five connections to the Virtual SOP in the entire system, and only one prime connection to the SP Command Console in the entire system can be made simultaneously. If LAN is used, additional SP Command Consoles can be attached using hubs, but they will be in monitor mode only, and commands can be entered only via the prime connection.

See Figure 3-2 for a diagram of using console modes.

3-4 Service Processor

Serial Console

not Available

Select Exit

Press ESC Key

Password Required

iSP login Pr om p t

Main Menu

TCP-5001

not Connected

Connect TCP5001

Select Exit

Select SOP

Vi r tu al SOP

Press ^ B Key

Select SP

SP Command Normal Mode

Press ^ B Key

Select OS

Figure 3-2. Express5800/1080Xd Console Mode Operations

OS Console

Service Processor 3-5

Login and Main Menu

The initial state of a console connected to the service processor is the login wait state with the login prompt displayed. When you enter the login account and password, the iSP Main Menu appears.

The characters you enter for the login account and password are case-sensitive. However, alphabetic characters you enter in the Main Menu are not case-sensitive. For example, the lowercase letter “e” and the uppercase letter “E” are processed the same.

Table 3-3. Login and Main Menu Screen

Screen Image Reference

Integrated Service Processor. Cabinet-ID:xx, Location:y, State:ssssss

iSP login: spfw<ENTER> iSP password: xxxxxxxx<ENTER>

iSP MAIN MENU

0) OS(BIOS) serial console of partition#0 (INITIALIZING )

1) OS(BIOS) serial console of partition#1 (RUNNING ) V) Virtual System Operator Panel S) iSP commands E) Exit

DISCONNECTALL) disconnect all console connections

iSPyz> E

3-6 Service Processor

Table 3-4. Login and Main Menu Screen References

Reference Description

A “xx “is the ID for identification of a cabinet in a system composed of multiple

cabinets. (“xx” is the system number specified by the SU command.) “y” indicates the installation location of the service processor - clock board with 0. “ssssss” becomes “master.”

B Entry for login account and password.

The password is not displayed.

C Display of service processor firmware (iSP FW) version information. D Display of iSP Main Menu options.

The OS Console menu also displays a partition state summary.

E Display of the iSP Main Menu selection prompt.

“y” indicates the service processor-clock board number for 0. “z” becomes “m.”

Table 3-5. Main Menu Login Events and Operations

Event Operation

The account or password is invalid. Displays “incorrect” and then displays the login

prompt again.

The account or password is invalid three times in a row.

Left for 5 minutes in login or password prompt state.

A character not on the menu is entered. Displays the menu again. Left for 5 minutes in menu display state. Displays “timeout” and then disconnects the

0 – 3 selected. Switches to the OS (BIOS) serial console

S selected. Switches to the SP Command Console. V selected. Switches to the Virtual SOP. E selected. Disconnects the session. DISCONNECTALL selected. Disconnects all connections with the service

Disconnects the session.

Displays “timeout” and then disconnects the session.

session.

redirection.

processor except the current connection. This operation occurs only in special situations

(such as the case where a connection with the service processor was actually disconnected but remains under service processor management due to irregular access of a client to the service processor; as a result, any further operation cannot be performed).

The number of simultaneous connections allowed for the selected menu is exceeded.

After a DISCONNECTALL is selected, authentication with Maintenance Mode is performed.

Displays “N connections to the selected mode are already established. Try it later.” Displays the Main Menu again.

Service Processor 3-7

OS (BIOS) Console

When you select the OS (BIOS) Console on the iSP Main Menu, input/output is redirected to the OS (BIOS) serial controller.

To return to the Main Menu, press ^B (CTRL+B). The image displayed and the operation during redirection depend on the BIOS and OS

running in the partition; they are therefore not recognized by the service processor firmware (iSPFW).

Table 3-6. OS (BIOS) Console Operation

Screen Image Reference

iSP MAIN MENU

0) OS(BIOS) serial console of partition#0 (INITIALIZING )

1) OS(BIOS) serial console of partition#1 (RUNNING ) V) Virtual System Operator Panel S) iSP commands E) Exit

DISCONNECTALL) disconnect all console connections iSPyz> 0<ENTER>

*****redirection of serial console 0 ***** *****enter CTRL+B to quit ***** : : : : : <CTRL>+<B> *****returned from serial console 0 redirection *****

A B

D E

Table 3-7. Login and Main Menu Screen References

Reference Description

A B The starting message of OS Console redirection is displayed.

C “:” is input and output during the OS Console redirection depend on the OS and

When you enter 0-3, the menu is redirected to the OS Console of the corresponding partition.

BIOS. D Pressing ^B terminates the redirection of the OS Console. E A message is displayed to indicate the end of the redirection. Returns to Main Menu.

3-8 Service Processor

Table 3-8. OS (BIOS) Console Events and Operations

Event Operation

^B (CTRL+B) is pressed. Displays a message indicating the exit of the

session from the OS (BIOS) Console and then returns to the Main Menu and prompt.

The SP command deletes the displayed partition.

Virtual SOP

When you select Virtual SOP (Virtual System Operator Panel) on the iSP Main Menu, Virtual SOP appears. The Virtual SOP periodically refreshes the display of the state of all the partitions.

To return to the Main Menu from the Virtual SOP, press ^B (CTRL+B).

Screen Image Reference

iSP MAIN MENU

0) OS(BIOS) serial console of partition#0 (INITIALIZING )

1) OS(BIOS) serial console of partition#1 (RUNNING )

2) OS(BIOS) serial console of partition#2 (STOPPED )

3) OS(BIOS) serial console of partition#3 (FAULT ) V) Virtual System Operator Panel S) iSP commands E) Exit

DISCONNECTALL) disconnect all console connections

Displays a message indicating the exit of the session from the OS (BIOS) Console and then returns to the Main Menu and prompt.

Table 3-9. Virtual SOP Screen

iSPyz> V<ENTER>

----- Virtual System Operator Panel --------------------- 01/31/2001,19:30:20 ----xx 0 HW INITIALIZING yyyyyy xx 1 RUNNING yyyyyy

BIOS messages BIOS messages SP messages SP messages

xx 2 STOPPED yyyyyy xx 3 FAULT yyyyyy BIOS messages BIOS messages SP messages SP messages

----- Enter CTRL+B to quit ----------------------------------------------------------------- :

: : : :

Service Processor 3-9

Table 3-10. Virtual SOP Screen References

Reference Description

A When you enter “V,” the Virtual SOP appears. B Virtual SOP image is displayed. C The Virtual SOP is periodically displayed. D Pressing ^B terminates the Virtual SOP. Return to Main Menu.

Partition State Display

The state display for each partition is described in the following figure and table.

1 2

xx N sssssssssssssss cccccc

3 4

t t t t t t t t t t t t t t t t t t t t t t t t t t t t t t t

uuuuuuuuuuuuuuuuuuuuuuuuuuuuuuu

Figure 3-3. Partition State Display

Table 3-11. Reference to Partition State Display

Reference No.

1 Numeral ID for identifying a cabinet in a super scalable cluster composed

Display Description

of multiple cabinets. 2 Numeral (0 – 3) Partition number. 3

3-10 Service Processor

String State of the partition. POWER OFF DC OFF state. STOPPED In DC ON state, has no failure, and is being stopped. HW INITIALIZING ISP is initializing the hardware. The BIOS has not started yet. SW ININIALIZING BIOS is initializing the system. OS BOOTING OS booting is in progress. RUNNNG BIOS has finished initialization of the system and the control

has been passed to the EFI.

Table 3-11. Reference to Partition State Display (cont’d)

Reference No.

3 (cont’d)

4 6-digit hexadecimal Latest chassis code is sent from the BIOS or OS. 5

Display Description

FAULT Indicates that the BIOS has finished initialization of the system

and control has been passed to EFI.

SHUT DOWN iSP is shutting down the hardware. NOT CONFIGURED Partition is not configured.

String Displayed when any error code is sent from the BIOS. The code

has 4 figures. For information about the code, see the BIOS section.

Deleted at next system startup.

String Displayed when any warning error message is sent from the

SP. The message is similar to the activity log. When the message is long, the latter part of the message will be omitted.

Deleted at next system startup.

Service Processor 3-11

SP Command Console

When you select the iSP commands on the iSP Main Menu, the SP Command Console appears. Initially, the SP Command Console is in Normal Mode for general operation. You can switch to Maintenance Mode (which allows all operations) by using the CM command.

To return to the Main Menu from the SP Command Console, press ^B (CTRL+B).

Table 3-12. SP Command Console Operation

Screen Image Reference

iSP MAIN MENU

0) OS(BIOS) serial console of partition#0 (INITIALIZING )

1) OS(BIOS) serial console of partition#1 (RUNNING )

2) OS(BIOS) serial console of partition#2 (STOPPED )

3) OS(BIOS) serial console of partition#3 (FAULT ) V) Virtual System Operator Panel S) iSP commands E) Exit

DISCONNECTALL) disconnect all console connections iSPyz> S<ENTER>

: : : : : <CTRL>+<B>

Table 3-13. SP Command Screen References

Reference Description

A When you enter S, the SP Command Console appears. B “:” indicates the monitoring of the SP command input and SP message output. C Pressing ^B exits the session from the SP Command Console and returns to the

Main Menu.

SP Command Console Buffer

SP Command Console output from the service processor might contain important information, such as the cause of a system state change. With the LAN console, however, you cannot monitor the console output from the end of iSP startup until the LAN console connection is established. Therefore, the iSP has a function to save a certain amount of message output in a buffer while the connection is being established to the SP Command Console. About 1,000 lines of messages can be stored in this buffer. The buffer stores the latest 1,000 lines of messages. You can use the ML command to view the messages stored in the buffer.

3-12 Service Processor

SP Command Prompt

In SP command mode (Normal Mode or Maintenance Mode), one of the following types of command prompt is displayed when you press the ESC key.

Interactive operations for each SP command and prompts for subcommand entry depend on the SP command.

Table 3-14. SP Command Mode Prompts

Prompt Description

ISPyz:--> Command prompt in Normal Mode. ISPyz:MNT> Command prompt in Maintenance Mode.

SP Message Header

SP messages have a header in the formats listed in the following table. No message header is added to the prompts and messages that appear during interactive

operations in each SP command.

Table 3-15. SP Message Header Formats

Message Header Description

[iSPyz:INFO.cccc] string Indicates an information message.

“cccc” is the ID assigned to each message.

“string” is the message body. [iSPyz:WARN.cccc] string Indicates a warning message. [iSPyz:ERRORcccc] string Indicates an error message.

Service Processor 3-13

SP Command List

The following table lists the SP commands by category.

Table 3-16. System Control Commands

CMD

DF Shut Down System Power

DN Shut Down System Power If the specified partition is in SO state, the iSP

DP System Dump The iSP generates the INIT signal to the

PC Power Cycle The iSP turns off the DC power of the

RS Cold Reset System The iSP initializes the specified partition

UP Bring Up System The iSP turns on the DC power of the

Command Name

(override)

Function

The iSP turns off the DC power of the specified partition without notifying the SW (OS) even if it is running.

only generates the SCI(POWBTN). Otherwise, the iSP turns off the DC power directly.

specified partition. SW(OS) will enter its dump routine.

specified partition without notifying the SE(OS) even if it is running, turns on the DC power, initializes HW and hands off the control to the BIOS.

without notifying the SW(OS) even if it is running.

specified partition and initializ e s H W and hands off the control to the BIOS. The BIOS boots the operating system.

NML Mode

X X

MNT Mode

DC OF F

UP/PC

DN/DF

DC ON

Not running

UP/PC/RS

Ready

SW running

Figure 3-4. System State Transitions and System Control Commands

DN/DP (only t r igger)

3-14 Service Processor

Table 3-17. Configuration Command

CMD

HC Hardware Configuration The iSP displays and/or modifies the hardware

Command Name

Function

configuration, including partitions.

NML Mode

X X

MNT Mode

Table 3-18. Normal Mode Commands

CMD

CM Change Command Mode Enter into or exit from the maintenance mode. X X DL Display SP logs Display the logs stored in iSP. X X DT SP Date and Time Display the SP RTC (Real Time Clock) and set

EN Environmental Information Display the environmental information such as

FV Firmware Version Display the iSP FW version and BIOS version. X X HE Help Display help information. X X ML Message Log Display the iSP’s message buffer. X X

Command Name

Function

it.

the power state and the temperature sensors.

NML Mode

X X

MNT Mode

Service Processor 3-15

SP Command Reference

The following sections provide detailed information about SP commands. The commands listed can be executed in Normal mode or Maintenance mode. Basically, SP commands and subcommands are not case-sensitive. Any need for case-

sensitivity (for example, accounts and passwords) is described.

3-16 Service Processor

CM (Change Command Mode)

Execution: This command can be executed in the AC POWER ON state or DC POWER ON state. Entering Maintenance mode requires the entry of a password.

Function:

Changes from Normal mode to Maintenance mode. When the system is in Maintenance mode, the Status LED on the front of the server is amber.

Note: The CM command can be executed in Normal mode or

Maintenance mode.

Table 3-19. CM Command Screen

Screen Image Reference

iSPyz:---> cm<ENTER> Password is needed to enter maintenance mode.

maintenance password : xxxxxxxx <ENTER> incorrect. maintenance password : xxxxxxxx <ENTER>

Command Mode was changed to maintenance mode. B

Table 3-20. CM Screen References

Reference Description

A To switch from Normal mode to Maintenance mode, a password is required.

If you enter a another password entry. If you enter an incorrect password three times in a row, the command terminates.

Passwords are case sensitive.

B After the mode change to Maintenance mode is displayed, the command terminates.

wrong password, a message is displayed and the system waits for

Service Processor 3-17

DF (Shut Down System Power <override>)

Execution: This command can be executed on a partition which is in one of the following states:

! Automatic startup has completed or the UP command has been executed. (The

partition is in the DC POWER ON state)

! The ON command has been executed. (The partition is in the DC POWER ON

state.)

Function:

This command turns off system power (DC). This command turns off the system regardless of the operation state of the OS or BIOS

and without notifying either. (This corresponds to the power button override function of a system that has a physical power button.)

Note: The DF command can be executed in Normal mode or

Maintenance mode.

Table 3-21. DF Screen

Screen Image Reference

iSPyz:---> df<ENTER> CAUTION:

System power will be turned off without any notice to the softwares even if they are running.

Enter partition number (0-3/all/CR=exit) : all<ENTER>

Execute OK? (y/[n]) y<ENTER>

DF command was accepted. System power of all partitions will be turned off soon. C

[iSPyz:INFO.ccc] partition 0 : power off sequence started. [iSPyz:INFO.ccc] partition 1 : power off sequence started. : :

: [iSPyz:INFO.ccc] partition 1 : power off sequence completed normally.

Table 3-22. DF Screen References

Reference Description

A Enter a partition number. If you select “all”, all the configured partitions become the

B C Displays the DF command acceptance message. D Displays the state of the process running in the background.

3-18 Service Processor

targets. Displays the confirmation message. To continue, enter “y”.

DL (Display SP Logs)

Execution: This command can be executed in the AC POWER ON state or DC POWER ON state.

Function:

This command displays the logs stored in the iSP. You can upload the logs as a file to an FTP server.

The detailed log (HW fatal-iSP snapshot) is linked and managed with the activity log entry. When the log storage area is full, a new activity log is written over the oldest activity log. When this happens, you cannot refer to the oldest detailed log. You should display the important log and store it as a screen log of the terminal software. Or, upload the important log to the FTP server.

Note: The DL command can be executed in Normal mode or

Maintenance mode.

Screen Image Reference

iSPyz:---> dl<ENTER>

Table 3-23. DL Screen

Log area status (03/01/2002 18:59:00 iSPFW R01.01): Type Entries Latest No. Earliest Latest

--------------------- --------- -------------- ------------------------------- ---------------------------------activity 1000 404 01/31/2002 12:24:50 02/29/2004 13:54:12 HW fatal 16 0 01/31/2002 12:24:50 02/29/2004 13:54:12 HW recoverable 64 32 01/31/2002 12:24:50 02/29/2004 13:54:12 processor MCA 128 20 01/31/2002 12:24:50 02/29/2004 13:54:12 processor CMC 64 2 01/31/2002 12:24:40 02/29/2004 13:54:12 processor INIT 64 1 01/31/2002 12:24:40 01/31/2002 13:54:12 system dump 8 7 01/31/2002 12:24:40 02/29/2004 13:54:12 iSP snapshot 8 3 02/29/2004 15:34:51 02/29/2004 13:54:12

Display or FTP upload the activity logs? (d[isplay]/f[tp]/CR=exit) : f<ENTER> IP of FTP server [default=10.0.0.2] (CR=skip) : 10.0.0.3<ENTER>

account [default=necuser] : necus er<ENTER> password [default=********] : xxxxxxxx<ENTER> file path : log/activity.log<ENTER> connecting... connected. uploaded.

Display or FTP upload? (d[isplay]/f[tp]/CR=back) : d<ENTER> Filter logs by partition? (a[ll]/0-3/CR=back) : a<ENTER>

D E

Service Processor 3-19

Table 3-23. DL Screen (cont’d)

Screen Image Reference

Filter logs by category? a ... all 1 ... system control 7 ... fatal error

2 ... system configuration 8 ... recoverable error 3 ... BIOS event 9 ... dump event 4 ... IPMI SEL 11 ... proc. MCA event 5 ... system init. error 12 ... proc. INIT event 6 ... SP event 13 ... proc. CMC event (a/1-13/CR=back) : a<ENTER>

select display mode (i[nteractive per page]/a[ll]/CR=back) : i<ENTER>

1023 10:30:32,12/31/2002 part.0--- CONT ROL system state S5.

1022 10:30:31,12/31/2002 part.0--- CONT ROL timeout. (Shutdown WDT)

1021 10:29:31,12/31/2002 part.0--- CONT ROL going to system state S5.

1020 10:29:30,12/31/2002 par t.0--- IPM ISEL 01234567 89abcdef 01234567 89abcdef

1019 10:29:29,12/31/2002 part.0--- IPM I stop IPMI WDT.

1018 10:29:25,12/31/2002 part.0--- CONT ROL POWBTN# asserted.

1017 10:20:00,12/31/2002 par t.-1-- HR(012) ATT1(CELL2:Memory SBE, addr=0020304050607080, ROW25)

action? (h=help/CR=next) : h<ENTER>

h : help r : refresh l : latest entry o : oldest entry p : previous page n : next page q : quit

<nnnn> : jump to the entry which is numbered nnnn. <hh:mm:ss,MM/DD/YYYY> : search the first entry after specified time. d <nnnn> : display detailed log dump if present. a <nnnn> : display detailed log analysis if present. f <nnnn> : ftp detailed log data if present.

action? (h=help/CR=next) : d 1017<ENTER> ***** LOG DUMP START *****

: : : ***** LOG DUMP END *****

action? (h=help/CR=next) : a 1017<ENTER>

3-20 Service Processor

Table 3-23. DL Screen (cont’d)

Screen Image Reference

***** LOG ANALYSIS RESULT ***** :

: : ***** LOG ANALYSIS END *****

action? (h=help/CR=next) : q<ENTER>

Log area status (03/01/2002 18:59:00 iSPFW R01.01): Type Entries Latest No. Earliest Latest

---------------------- ------------ ------------- ----------------------------- ------------------------------activity 1000 404 01/31/2002 12:24:50 02/29/2004 13:54:12 HW fatal 16 0 01/31/2002 12:24:50 02/29/2004 13:54:12 HW recoverable 64 32 01/31/2002 12:24:50 02/29/2004 13:54:12 processor MCA 128 20 01/31/2002 12:24:50 02/29/2004 13:54:12 processor CMC 64 2 01/31/2002 12:24:40 02/29/2004 13:54:12 processor INIT 64 1 01/31/2002 12:24:40 01/31/2002 13:54:12 system dump 8 7 01/31/2002 12:24:40 02/29/2004 13:54:12 iSP snapshot 8 3 02/29/2004 15:34:51 02/29/2004 13:54:12

Display or FTP upload the activity logs? (d[isplay]/f[tp]/CR=exit) : <ENTER> DL command terminated.

Table 3-24. DL Screen References

Reference Description

A On the DL command MENU, select “a”. B, D Select whether to display all the activity logs or upload them to the FTP server.

(Uploading detailed logs individually is described later.) C This is an example of uploading to the FTP server. E If you choose to display, select a partition number first.

When you enter a partition number (0-3), only the events related to the partition can

be displayed. (In this case, events common to the partitions are included in the

display.)

If you select “all”, no filtering by partition number is done. F Select a category.

You can display only the events of the specified category.

If you select “all”, no filtering by category is done. G Select to display all the events at the same time or to prompt you every 25 lines. H This is an example of activity logs.

Service Processor 3-21

Table 3-24. DL Screen References (cont’d

Reference Description

I If you enter “h” in response to “action?”, Help for the action appears.

If you specify an activity log number, you jump to the log number. If you specify the time, you jump to the oldest log after the specified time. The log with the display of “XXX log was collected.” has a link to the detailed log.

The operations listed below are available to the log: If you enter “d <nnnn>”, hexadecimal dump output of the detailed log is done. If you enter “f <nnnn>”, the detailed log is uploaded to the FTP server. If you enter “a <nnnn>”, the result of the analysis of the detailed log with analyzing

program is displayed. The detailed logs with program analysis are as follows: HW fatal, HW recoverable, processor MCA, iSP snapshot.

J If you enter “q” in response to “action?”, the display exits from the log display.

3-22 Service Processor

DN (Shut Down System Power)

Execution:

This command can be executed on a partition if Automatic startup has completed or the UP command has been executed. (The partition is in the DC POWER ON state.)

Function:

This command turns off system power (DC). If software is not running (for example, in the S0 state), this command turns off the

system. If any software, such as the OS and BIOS, is running (for example, in the S0 state), this

command only reports a power button interrupt to the software, and the process for the power button interrupt depends on the software. (The software may ignore the power button interrupt, or may perform a shutdown and turn off the power.)

Even if the iSP recognizes that some software is running, the software may not be able to process the power button interrupt due to stalling. In this case, use the DF command to force the system to turn off.

Note: The DN command can be executed in Normal mode or

Maintenance mode.

Table 3-25. DN Screen

Screen Image Reference

iSPyz:---> dn<ENTER> System power will be turned off if the software (OS) is NOT running.

Only power button interrupt will be generated if the software (OS) is running. If you want to turn off the system power in any system state, use DF command.

Enter partition number (0-3/all/CR=exit) : all<ENTER> Execute OK? (y/[n]) y<ENTER> DN command was accepted. System power of all partitions will be turned off or power

button interrupt will be generated soon.

[iSPyz:INFO.ccc] partition 0 : power button interrupt. [iSPyz:INFO.ccc] partition 1 : power button interrupt. [iSPyz:INFO.ccc] partition 2 : power off sequence started. : : : [iSPyz:INFO.ccc] partition 2 : power off sequence completed normally.

A B C

Service Processor 3-23

Table 3-26. DN Screen References

Reference Description

A Enter a partition number.

If you select “all,” all configured partitions become the targets.

B Displays the confirmation message.

To continue, enter “y”.

C Displays the command acceptance message.

The actual process runs in the background.

D Displays the state of the process running in the background.

3-24 Service Processor

DP (System Dump)

Execution:

This command can be executed on a partition if Automatic startup has completed or the UP command has been executed. (The partition is in the DC POWER ON state.)

Function:

This command generates a dump interrupt in the system. The actual operation of the dump processing and the following system reset depend on

the software (OS or BIOS). This command only generates a dump interrupt. Obviously, nothing happens if no software is running.

Note: The DP command can be executed in Normal mode or

Maintenance mode.

Screen Image Reference

iSPyz:---> dp<ENTER>

Table 3-27. DP Screen

Dump button interrupt will be generated.

Enter partition number (0-3/all/CR=exit) : all<ENTER> Execute OK? (y/[n]) y<ENTER> DP command was accepted. Dump button interrupt will be generated soon. C

[iSPyz:INFO.ccc] partition 0 : dump button interrupt. [iSPyz:INFO.ccc] partition 1 : dump button interrupt. : : :

Table 3-28. DP Screen References

Reference Description

A Enter a partition number.

If you select “all,” al configured partitions become the targets. B Displays the confirmation message.

To continue, enter “y”. C Displays the command acceptance message.

The actual process runs in the background.

A B

D Displays the state of the process running in the background.

Service Processor 3-25

DT (SP Date and Time)

Execution:

This command can be executed in the AC POWER ON or DC POWER state.

Function:

Displays and changes the time of the real-time clock built into the iSP. This command only displays time in Normal Mode.

Note: The DT command can be executed in Normal mode or

Maintenance mode.

Screen Image Reference

iSPyz:---> dt<ENTER>

Table 3-29. DT Screen

current iSP RTC : 19:20:57,01/31/2002 +09:00 syncronized with NTP server (10.20.30.40) DT command terminated

A: In Normal Mode, the command terminates after displaying the current time.

3-26 Service Processor

EN (Environmental Information)

Execution:

This command can be executed in the AC POWER ON or DC POWER state.

Function:

Lists the states of the system’s detected temperature and fan errors, etc. The components in the DC POWER OFF state are not supervised.

Note: The EN command can be executed in Normal mode or

Maintenance mode.

Table 3-30. EN Screen

Screen Image Reference

iSPyz:---> en<ENTER>

---- Power Box/Bay Units -------------------------------------------------- 19:20:57,01/31/2002 --- state DPS0 DPS1 DPS2 DPS3 DPS4 DPS5 PBAY00 ON --- -- PBAY01 ON --- -- * EXT PBAY10 ON --- --- ALARM

----------------------------------------------------------------------------------------------------------------------

---- Main Chassis FANs ---------------------------------------------------- 19:20:57,01/31/2002 --- CELL FR0 FF0 FR1 FF1 ALARM HIGH HIGH HIGH

XIC/XBR FRL FRR FR2 FF2 ALARM

PCIV0 FM0 FM1 FM2 FM3 ALARM

---------------------------------------------------------------------------------------------------------------------Next page? (n[ext]/e[xit]/CR=next) : <ENTER>

---- CELL/XIC/XBR board DD-con/Temp alarm ---------------------- 19:20:57,01/31/2002 --- state DD-con Temp CELL0 ON * CELL1 OFF ALARM * CELL2 NORESP * CELL3 OFF ALARM

* XIC OFF ALARM * XBR NORESP

----------------------------------------------------------------------------------------------------------------------

---- PCIX-BOX DD-con/Temp/FAN alarm ------------------------------ 19:20:57,01/31/2002 --- state DD-con Temp FAN Local/Remote * PCIX0(V) ON ALARM -- * PCIX1(F) OFF ALARM ALARM Remote * PCIX2(F) ON --- ALARM Local * PCIX3(F) OFF --- ALARM Remote

----------------------------------------------------------------------------------------------------------------------

Service Processor 3-27

Table 3-30. EN Screen (cont’d)

Screen Image Reference

Previous/Next page? (p[revious]/n[ext]/e[xit]/CR=next) : <ENTER>

---- Temperature (Celsius) [1/4] ------------------------------------------ 19:20:57,01/31/2002 --- current threshold comment FAN IPMI ACPI CELL0 46 45/ 50 60/ 62 80 PROC00 50 80/ 85 100/102 105 * PROC01 82 80/ 85 100/102 105 FAN High-speed PROC02 - - - PROC03 - - - - * CELL1 52 45/ 50 60/ 62 80 FAN High-speed PROC10 - - - PROC11 - - - PROC12 70 80/ 85 100/102 105 * PROC13 103 80/ 85 100/102 105 reported to the software

---------------------------------------------------------------------------------------------------------------------Previous/Next page? (p[revious]/n[ext]/e[xit]/CR=next) : <ENTER>

---- Temperature (Celsius) [2/4] ------------------------------------------ 19:20:57,01/31/2002 --- current threshold comment FAN IPMI ACPI CELL2 49 45/ 50 60/ 62 80 FAN High-speed PROC20 52 80/ 85 100/102 105 PROC21 53 80/ 85 100/102 105 PROC22 54 80/ 85 100/102 105 PROC23 55 80/ 85 100/102 105 CELL3 46 45/ 50 60/ 62 80 PROC30 52 80/ 85 100/102 105 PROC31 53 80/ 85 100/102 105 PROC32 54 80/ 85 100/102 105 PROC33 55 80/ 85 100/102 105

---------------------------------------------------------------------------------------------------------------------Previous/Next page? (p[revious]/n[ext]/e[xit]/CR=next) : <ENTER>

---- Temperature (Celsius) [3/4] ------------------------------------------ 19:20:57,01/31/2002 --- current threshold comment FAN IPMI ACPI * XBC0(XIC) 52 - 60/ 62 65 FAN High-speed * XBC1(XBR) 61 - 60/ 62 65 reported to the software

FAN WARN1 WARN2 * AIR FLOW IN 30 23/ 27 32 34 FAN High-speed

---------------------------------------------------------------------------------------------------------------------Previous/Next page? (p[revious]/n[ext]/e[xit]/CR=next) : <ENTER>

3-28 Service Processor

Table 3-30. EN Screen (cont’d)

Screen Image Reference

---- Temperature (Celsius) [4/4] --------------------------------------- 19:20:57,01/31/2002 --- current threshold comment

FAN IPMI ACPI PCIX0(V) 45 - 60/ 62 65 DBP 52 - 60/ 62 65 PCIX1(F) - - - - IORB - - - - DBP - - - - PCIX2(F) 45 - 60/ 62 65 IORB 63 - 60/ 62 65 reported to the software DBP - - - - PCIX3(F) 45 - 60/ 62 65 IORB 52 - 60/ 62 65 DBP - - - -

---------------------------------------------------------------------------------------------------------------------Previous page? (p[revious]/e[xit]/CR=exit) : <ENTER>

Table 3-31. EN Screen References

Reference Description

A Displays the state of the Power Bay/Power Bay Unit in the chassis/cabinet.

If an alarm occurs, an asterisk (*) mark appears at the beginning of the line.

State

ON : Indicates that DC (48V) is supplied to the devices in the cabinet.

OFF: Indicates that DC (48V) is not supplied to the devices in the cabinet.

---: Indicates that no Power Bay Unit exists (not detected by the iSP).

DPSx

(blank): Indicates the normal state.

ALARM : Indicates an alarm state.

---: Indicates that no Distributed Power Supply Module exists

(not detected by the iSP).

((blank): Displays no indication on normal state.) B Displays the state of the Fan Units located in the Main Chassis and Expansion

Chassis.

If an alarm occurs, an asterisk (*) mark appears at the beginning of the line.

The Fan Units for the CELLV Board have high rotation speed and low rotation speed.

-- : Indicates that it does not exist. (blank): In the case of XIC Board/XBR Board/PCIV Mother Board, indicates a

normal state.

ALARM: Indicates an alarm state. low: Indicates low-speed operation state. HIGH: Indicates high-speed operation state.

Service Processor 3-29

Table 3-31. EN Screen References (cont’d)

Reference Description

C When you press ENTER, the next page is displayed D Displays an alarm state for the DCDC converter on the CELLV Board/XIC/XBR Board

in the Main Chassis and Expansion Chassis. If an alarm occurs, an asterisk (*) mark appears at the beginning of the line.

E Disp lays an alarm state for the DCDC converter/fan/temperature of the PCIX Unit

and PCIV (Core Module). If an alarm occurs, an asterisk (*) mark appears at the beginning of the line. For information on the Fan Unit in the PCIV (Core Module), refer to B.

F Displays the temperature detected by the board/unit temperature sensor.

If an alarm occurs, an asterisk (*) mark appears at the beginning of the line. Also displays the threshold values hard-coded in iSPFW. "FAN" indicates the threshold values for high-speed and low-speed fan rotation. "IPMI" indicates the threshold values at which a report is sent to the software via the

IPMI interface. " ACPI " indicates the threshold values at which a report is sent to the software via

the ACPI interface.

3-30 Service Processor

FV (Firmware Versions)

Execution:

This command can be executed in the AC POWER ON or DC POWER ON state.

Function:

Displays the version information of the iSPFW and BIOS. Performs a checksum of the storage area.

Note: The FV command can be executed in Normal mode or

Maintenance mode.

Screen Image Reference

iSPyz:---> fv<ENTER>

Table 3-32. FV Screen

Firmware Versions : (currently running firmware is Rxx.xx) iSP BOOT (*) : xx.xx generated on mm/dd/yyyy hh:mm:ss iSP FW bank0 : xx.xx generated on mm/dd/yyyy hh:mm:ss iSP FW bank1 (*) : xx.xx generated on mm/dd/yyyy hh:mm:ss BIOS bank (*) : xx.xx generated on mm/dd/yyyy hh:mm:ss

Do you want to check the flash memory? (y/[n]) : y<ENTER> checking iSP BOOT bank...

passed. checking iSP FW bank0... passed. checking iSP FW bank1... passed. checking BIOS bank... passed.

FV command terminated.

Table 3-33 FV Screen References

Reference Description

A Displays the state of the current FW storage area. B To perform a checksum test of the storage area, enter “y”.

C Displays the state of the checksum test.

Service Processor 3-31

HC (Hardware Configuration)

Execution:

Conditions for executing subcommands are described in the following subcommand table.

Function:

Displays and changes the configuration information of the hardware. Displays and changes the partition settings. See Table 3-38, “HC – ALL Display Screen” for an example of the HC display screen. See the following tables for a list of hardware components and subcomponents and for a

list of subcommands and descriptions.

Note: The HC command can be executed in Normal mode or

Maintenance mode.

Table 3-34. HW Components and Subcomponents

Component Subcomponent (1) Subcomponent (2)

CELLV Board Processor x4

MMC x2

TAG x8 CXI x2

XIC Board CXI x4

1.6G x4 MOVER x2 SERIAL CONSOLE x4

PCIV/PCIX Unit IOR

GXB x4 or GXB x2

-ROW x8

CACHE x8

1.6G x2 IOC x2

3-32 Service Processor

Table 3-35. HC Subcommands

cmd arg1 arg2 arg3 arg4 Description

help - - - - Displays the list of subcommands.

This command can be executed in the AC POWER ON or DC POWER ON state.

quit exit

disp

- - - -

all - - part - - -

main - - -

Exits from the HC command. Before an exit, the check subcommand is

automatically executed. This command can be executed in the AC

POWER ON state or DC POWER ON state. Used to display states.

Displays Help for “disp” when the argument is omitted or an error exists.

This command can be executed in the AC POWER ON or DC POWER ON state.

Displays all the states. Displays the following partition division

information for each partition:

• State summary

• Physical CELLV Board number and logical

CELLV Board number

• Physical IOR chip number and logical IOR chip

number.

Displays the state summary of the system configuration.

cellx

mmcxy

tagx

xbcx

- - -

Displays the state of the CELLV Board. “x” is the physical CELLV Board number (0-3).

Displays the detailed state of the ROW under control of the MMC specified by “xy”.

“x” is the physical CELLV Board number (0-3) on which MMC is installed.

“y” is the MMC number (0-1) in the CELLV Board.

Displays the detailed state of the TAG. “x” is the physical CELLV Board number (0-3) on

which TAG is installed. Displays the state of the XBC chip.

“x” is the physical XBC chip number (0-1).

Service Processor 3-33

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

disp (cont’d)

attach

pcixx

pbayxy

- - - - Used to associate partition numbers to CELLV

- - - Displays the state of the PCIV/PCIX Unit. “x” is the DGI/I2C cable port number (0-3) from

the iSP-C Board to the PCIV/PCIX Unit. IOR0 is installed on the XIC Board. But the

IOR0 is displayed with the PCIX0(V) to realize the same operation as the PCIX Unit.

- - - Displays the state of the Power Bay/Power Bay Unit.

“x” is the chassis number.

0: Power Bay in the Main/Expansion Chassis 1: Power Bay Unit

“y” is the ID number.

0 for the Power Bay in the Main Chassis 1 for the Power Bay in the Expansion Chassis 0 for the Power Bay Unit

Boards and IORs. The number of CELLV Boards in a partition

must be the same or greater than the number of IORs.

Displays Help for “attach” when the argument is omitted or an error is made.

This subcommand can be executed in the DC POWER OFF state of the partition.

When the online configuration and deconfiguration function is released, this restriction will be relieved.

cellx n m

- Associates the CELLV Board having the physical number x with the logical CELLV Board number m of partition n. (m: The number recognizable by the BIOS and software.)

This command can also be used to change a logical CELLV Board number if it has already been associated.

Each logical CELLV Board number must be unique among the CELLV Boards.

You cannot change the logical number of the CELLV Board in the online state.

3-34 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

attach (cont’d)

iorx n m p

Associates the IOR having the physical number x with the logical IOR number m of partition n. (m: The number recognizable by the BIOS and software.)

“p” (0-9) sets the priority. Indicates which IOR is used with a higher

priority if the number of normal CELLV Boards is smaller than the number of normal IORs due to CELLV Board failure in the partition. (Smaller values have a higher priority, and the IORs with larger values get isolated one by one. If the priority number is the same, the one with a smaller physical IOR number has a higher priority.)

This command can be used to change the logical IOR number and priority if it has been already associated.

The logical IOR number must be unique within the partition.

You cannot change the logical IOR number or priority of the IOR which is in the online state.

"Priority 0" is allowed one time for one partition and a Basic I/O Board must be connected. If any failure occurs in this IOR, the partition cannot be started.

The IOR0 must have priority 0.

detach - - - - Used to cancel the associations between

partition numbers and CELLV Boards/IORs. You cannot detach any component that is in the

online state. The number of CELLV Boards in a partition

must be greater than or equal to the number of IORs.

Displays Help of “detach” when the argument is omitted or an error is made.

cellx

iorx

- - - Disassociates the CELLV Board having the physical number x from the currently associated partition.

- - - Disassociates the IOR having the physical number x from the currently associated partition.

Service Processor 3-35

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

swap - - - - Used to swap a CELLV Board with another

CELLV Board while the software is operating.

This subcommand is not supported at present.

(This is not a combination of “attach” and “detach”. The process dedicated for “swap” is executed.)

Displays Help for “swap” when the argument is omitted or an error is made.

This subcommand can be executed on the partition in the DC POWER ON state. An execution of “swap” on the partitions requires the online configuration and de-configuration function of the OS.

smem

This subcommand is not supported at present.

cellx celly

- - - - Used to specify the size of the shared memory

n mmm

- - Swaps the operating CELLV Board having the

- - Specifies the size of the shared memory of

physical number x with the CELLV Board having the physical number y.

No partition must be associated with CELLVy. When the swap is complete, CELLVx is

disassociated from the partition and CELLVy is associated to the partition.

The logical CELL Board number is transferred from CELLVx to CELLVy.

of the partition. Displays Help for “smem” when the argument is

omitted or an error is made. This subcommand can be executed on the

partition in the DC POWER OFF state.

partition n in units of MB. You cannot make any change to the partitions

currently in operation. If the size is not a multiple of 128 MB, it is

rounded up.

3-36 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

add

- - - - Used to instruct the iSP to add components manually. The management state of the iSP changes from “nonexist” to “power-off”.

Displays Help for “add” when the argument is omitted or an error is made.

This subcommand can be executed in the AC POWER ON state or DC POWER ON state. When the Power Bay Unit is added, all partitions must be in the DC POWER OFF state.

pbayxy

dpsxyz

- - - Adds a Power Bay/Power Bay Unit. “x” is the chassis number.

0: Power Bay in the Main/Expansion Chassis 1: Power Bay Unit

“y” is the ID number.

0 for the Power Bay in the Main Chassis 1 for the Power Bay in the Expansion Chassis 0 for the Power Bay Unit

- - - Adds DPS to the Power Bay/Power Bay Unit. “x” and “y” are the same as described in “pbay”

above. “z” is the number of Distributed Power Supply

Module (DPS) in the Power Bay Unit (0-5). But the number assigned in the Power Bay of the Main Chassis and Expansion Chassis is 0,1 or

xbcx

cellx

procxy

- - - Adds a XBC chip. “x” is the physical number of the XBC chip (0-1).

0: Used for the XBC chip on the XIC Board. 1: Used for the XBC chip on the XBR Board.

- - - Adds a CELLV Board. “x” is the physical number of the CELLV Board

(0-3). 0 or 3 is assigned to the CELLV Board in the

Main Chassis.

- - - Adds a processor. “x” is the physical CELLV Board number (0-3). “y” is the processor installation location on the

CELLV Board (0-3).

Service Processor 3-37

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

add (cont’d)

delete

pcixx

- - - - Used to delete a component from the iSP

[bio] Adds a PCIV/PCIX Unit.

“x” is the DGI/I2C port number of the iSP-C Board side (0-3).

If PCIV is specified, “0” must be specified to x. If a PCiX Unit is specified, 1,2 or 3 must be specified to x.

If the Basic I/O Board is attached, specify “bio” as the second argument.

“bio” must be specified in the case of the PCIX0(V).

IOR0 is installed on the XIC Board. But the IOR0 is added when the PCIX0(V) is added to realize the same operation as the PCIX Unit.

management. If you do not delete it from the iSP management, the component which has been physically removed will still be managed as “INVISIBLE”.

You cannot delete any components in the DC ON state (except Distributed Power Supply Module (DPS)).

Displays Help for “delete” when the argument is omitted or an error is made.

enable

<arg1>

- - - - Used to enable a component managed as

pbayxy

- - -

- - - Enables a Power Bay/Power Bay Unit.

<arg1> is the same as described in “add”.

”DISABLE”. Displays Help for ”enable” when the argument is

omitted or an error is made. This subcommand can be executed in the DC

POWER OFF state of the partition that will use the component.

When the online configuration and deconfiguration function is released, this restriction will be relieved.

“x” is the chassis number.

0: Power Bay in the Main/Expansion Chassis 1: Power Bay Unit

“y” is the ID number.

0 for the Power Bay in the Main Chassis 1 for the Power Bay in the Expansion Chassis 0 for the Power Bay Unit

3-38 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

enable (cont’d)

xbcx

[all] - - Enables the XBC chip.

“x” is the XBC chip number (0-1). When the second argument is omitted, only the

XBC is enabled, and the states of any other subcomponents do not change.

When “all” is specified as the second argument, not only the XBC but also its subcomponents become enabled.

cxix

- - Enables the CELLV Board interface part within the XBC chip.

“x” is the interface part number (0-3). The correspondence between CXI number of

the CELLV Board and the CXI number of the XBC chip depends on the type of System Back Plane.

System Back Plane (8-way):

CELL0 CXI0 - CXI0 XBC0 CELL0 CXI1 - CXI1 XBC0 CELL3 CXI0 - CXI2 XBC0 CELL3 CXI1 - CXI3 XBC0

When the CXI port within the XBC chip is enabled, corresponding CXI port in the CELLV Board is also enabled (and vice versa).

In the case of the System Back Plane (8-way), refer to below.

When port 0 is enabled, port 1 is also enabled. When port 1 is enabled, port 0 is also enabled. When port 2 is enabled, port 3 is also enabled. When port 3 is enabled, port 2 is also enabled.

ncix

moverx

- - Enables the NC interface part within the XBC chip.

“x” is the interface number (0-1).

0: 1.6G cable port 0 1: 1.6G cable port 1

When the 1.6G port of XBC chip is enabled, corresponding port in the NC chip/IOR chip is also enabled (and vice versa).

- - Enables the MOVER part within the XBC chip. “x” is the mover number (0-1).

Service Processor 3-39

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

enable (cont’d)

cellx

serialx

[all] - - Enables the CELLV Board.

cxiy

- - Enables the serial controller part within the XBC chip.

“x” is the serial controller number (0-3). A partition requires a serial controller. When a

partition contains plural CELLV Boards, a serial controller is selected from available serial controllers automatically .

“x” is the physical CELLV Board number (0-3). When the second argument is omitted, only the

CELLV Board is enabled, and the states of any other subcomponents do not change. In this case, operation is rejected if some required components are disabled.

When “all” is specified as the second argument, not only the CELLV Board but also its subcomponents become enabled.

- - Enables the XBC interface part within the CELLV Board.

“y” is the interface part number (0-1). For information on the relationship between the

CXI within the CELLV Board and the CXI within the XBC chip, refer to “cxix” of “xbcx” in “enable”.

procxy

mmcxy

- - - Enables the Processor. “x” is the physical CELLV Board number (0-3). “y” is the Processor number (0-3) within the

CELLV Board .

[all] - - Enables the MMC.

“x” is the physical CELLV Board number (0-3). “y” is the MMC number (0-1) within the CELLV

Board. When the second argument is omitted, only the

MMC is enabled, and the states of any other subcomponents do not change.

When “all” is specified as the second argument, not only the MMC but also its subcomponents become enabled.

rowz

- - Enables the ROW. “z” is the ROW number (0-3). DIMM is not controlled individually. DIMMs are automatically detected at the time of

startup.

3-40 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

enable (cont’d)

mmcxy (cont’d)

tagx[sy]

pcixx

iorx

cachez

- - - Enables the TAG.

all - - Enables the PCIV/PCIX Unit.

[all] - - Enables the IOR chip.

- - Enables the Cache. “z” is the Cache number (0-7).

“x” is the physical CELLV Board number (0-3). “s” is either “e” (EVEN side) or “o” (ODD side). “y” is the TAG number (0-3). When “sy” is omitted, all the TAGs under the

CELLV Board specified by “x” beco me ena bled .

“x” is the DGI/I2C cable port number (0-3) of the cable from the ISP-C Board to the PCIV/PCIX Unit.

“all” must be specified as the second argument. Then, not only the PCIV /PCIX Unit but also its subcomponents become enabled.

IOR0 is installed on the XIC Board. But the IOR0 is managed with the PCIX0(V) to realize the same operation as the PCIX Unit.

“x” is the physical IOR chip number (0-3). When the second argument is omitted, only the

IOR chip is enabled, and the states of any other subcomponents do not change.

When “all” is specified as the second argument, not only the IOR chip but also its subcomponents become enabled.

nciy

iocy

- - Enables the 1.6G interface part. “y” is the interface number (0 only). When the 1.6G port of IOR chip is enabled,

corresponding 1.6G port in the XBC chip/NC chip is also enabled (and vice versa).

- - Enables the IOC. “y” is the IOC number (0 or 1) within the IOR

Daughter Board.

Service Processor 3-41

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

enable (cont’d)

disable

online

gxbxy

- - - - Used to disable a component manually.

- - - - Used to dynamically configure an offline

- - - Enables the GXB. “x” is the DGI/I2C cable port number of the

cable from the iSP-C Board to the PCIV /PCIX Unit (0-3).

“y” is the GXB number (0-3) within the PCIV/PCIX Unit. PCIV does not have GXB number (1).

busA |busB

- - Enables the busA side and busB side of GXB.

Displays Help for “disable” when the argument is omitted or an error is made.

If the component is online state, the component can not be disabled.

- -

<arg1> and <arg2> are the same as described in “enable” above.

“all” cannot be specified.

component while the OS is running. This command functions only with the support of

the software (OS and BIOS). This SP command may be unnecessary

depending on the OS. Displays Help for “online” when the argument is

omitted or an error is made.

offline

cellx xbcx moverx iorx

- - - - Used to dynamically disconfigure an online

- - - Configures the CELLV Board for the OS.

- - Configures the XBC chip’s mover for the OS.

- - - Configures the IOR chip for the OS.

component while the OS is running. This command functions only with the support of

the software (OS and BIOS). This SP command may be unnecessary

depending on the OS. Display Help for “offline” when the argument is

omitted or an error is made.

- - Same as described in “online” above.

3-42 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

ncconn

ncdis

- - - - Used to set connection information of the 1.6G cable.

Displays Help for “ncconn” when the argument is omitted or an error is made.

This subcommand can be executed when all partitions are in the DC POWER OFF state.

xbcx nciy iors ncit iors ncit xbcx nciy

- - - - Used to disconnect the 1.6G cable.

xbcx nciy

- - Removes the connection of the 1.6G port with

Specifies the connection between the 1.6G port with the port number y in the XBC chip with the physical number x and the 1.6G port with the port number t in the IOR chip with the physical number s.

t must be (0).

Displays Help for “ncdis” when the argument is omitted or an error is made.

This subcommand can be executed when all partitions are in the DC POWER OFF state.

the port number y in the XBC chip with the physical number x.

It is linked to the disconnection of the corresponding port (and vice versa).

led

iors ncit

- - - - Used to turn on/off a component’s LED to

xbcx

on|off - - Turns on/off the LED of the XIC Board/XBR

- - Removes the connection of the 1.6G port with the port number t in the IOR chip with the physical number s. t must be (0).

It is linked to the disconnection of the corresponding port (and vice versa).

identify its location. Displays Help for “led” when the argument is

omitted or an error is made. For execution on XBC (XIC Board/XBR Board)

and CELLV Board, one of the partitions must be in the DC POWER ON state.

For execution on the PCIX, no condition is required.

For execution on the PCI slot, the superior GXB must be in the online state.

Board. “x” is specified as below.

0: XIC Board 1: XBR Board

Service Processor 3-43

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

led (cont’d)

cellx

on|off - - Turns on/off the LED of the CELLV Board.

“x” is the physical CELLV Board number (0-3).

pcixx

pcixx slotnn

gxbxy

on|off - - Turns on/off the LED of the PCIV/PCIX Unit.

busA| busB

“x” is the number of PCIV/PCIX Unit (0-3).

When the PCIV is specified, all alarm LEDs are turned on.

on|off - Turns on/off the LED of the PCI slot in the

PCIV/PCIX Unit. Slot number printed at the back side of the Unit must be designated.

“x” is the number of PCIV/PCIX Unit (0-3).

“nn” is the slot number printed at the back side of the Unit.

slotn

on|off Turn on/off the LED of the PCI slot in the

PCIV/PCIX Unit according to physical control number.

“x” is the PCIV/PCIX Unit number (0-3).

“y” is the GXB number (0-3) in the PCIV /PCIX Unit.

“n” is the slot number (0-3) in the unit of GXB bus.

fann

loc

main

- - - - Used to specify location information manually.

on|off - - Turn on/off the LED of the Fan Unit in the Main

Chassis. “n” is the Fan Unit number.

Displays Help for “loc” when the argument is omitted or an error is made.

This subcommand can be executed when all partitions are in the DC POWER OFF state.

- - Specifies the location of the Main Chassis. “d” is the position of the lower edge of the

chassis from the bottom of the cabinet in decimal (0-63) by using the EIA unit. (1 EIA unit = 44.45mm)

3-44 Service Processor

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

loc (cont’d)

check - - - - Checks the current configuration information

pbayxy d h

pcixx c d

- Specifies the location and height of the Power Bay Unit in the cabinet.

“x” is the unit ID number.

1: Power Bay Unit

0: Not allowed “y” is the ID number. (0) must be specified. “d” is the position of the lower edge of the unit in

decimal (0-63) by using the EIA unit. (1 EIA unit = 44.45mm)

“h” is the height of the unit (3).

Specifies the location and height of the PCIX

Unit in the cabinet. “x” is the PCIX Unit number (1-3). “c” must be (1). “d” is the position of the lower edge of the unit in

decimal (0-63) by using the EIA unit. (1 EIA unit = 44.45mm).

from the following points:

• Presence of units whose location information

is not entered

• Presence of “DISABLE” components

• Presence of “INVISIBLE” units

Configuration violating the installation

restrictions

Configuration with penalty in

performance/RAS. This subcommand can be executed in the AC

POWER ON state or DC POWER ON state.

Service Processor 3-45

Table 3-35. HC Subcommands (cont’d)

cmd arg1 arg2 arg3 arg4 Description

clear

mmcxy rowz

- - Clears the memory bit error counters of ROW. “x” is the physical CELLV Board number (0-3). “y” is the MMC number (0-1) within the CELLV

Board. “z” is the ROW number (0-3). Each ROW has 3 counters. 3 counters are

cleared at the same time. [Types of error counters]

• Single bit error counter:

Counts in the unit of DIMM in the ROW.

• Multi bit counter:

Counts in the unit of the ROW.

This subcommand can be executed in the AC POWER ON state or DC POWER ON state.

Table 3-36. HC State Display Strings

Displayed String Description

nonexist Indicates that a component is defined as non-existent (i.e. the iSP manages a

component as if it does not exist).

INVISIBLE The iSP manages a component as if it exists, but it does not exist when seen

from the iSP due to failure or other reasons. Once it is recognized by the iSP (regardless of auto detection or manual setting),

it will be managed as if it exists unless you delete it explicitly using the “delete” command.

power-off Indicates that the power supply (DC) is OFF.

For some components, the power supply (DC) becomes ON when AC is supplied.

power-on Indicates that the power supply (DC) is ON.

For some components, it is overwritten by the following state display.

offline Indicates that the power supply (DC) is ON and a component is not configured in

the software (OS or BIOS). This applies to the CELLV Board, XIC/XBR Board, PCIV/PCIX Unit, and their

subcomponents.

online Indicates that the power supply (DC) is ON and a component is configured in the

software (OS or BIOS).

master This is valid only for the state display of the ISP-C Board. Always Indicates that

enable Indicates that the component itself is enabled (used for system operation).

3-46 Service Processor

This applies to CELLV Board, XIC/XBR Board, PCIV/PCIX Unit, and their subcomponents.

it is operating as the master.

Table 3-36. HC State Display Strings (cont’d)

Displayed String Description

DISABLE Indicates that the component itself is disabled (not used for system operation).

In this state, it is detached from the system manually with the “disable” command.

DISABLE* Indicates that the component itself is disabled (not used for system operation).

In this state, it is detached from the system due to failure of the component itself or failure of the host interface.

It should not be configured in the system until the defective part is replaced.

DEG Indicates that some subcomponents are in the DISABLE state.

Table 3-37. HC Help Screen

Screen Image Reference

iSPyz:---> hcENTER> iSP FW version is Rxx.xx.

HC> help<ENTER> HC command help :

help : print this message. disp : display current status. smem : set size of shared memory of a partition. attach : attach CELLs and IORs to a partition. detach : detach CELLs and IORs from a partition. swap : swap CELLs in a partition. add : add a component. delete : delete a component. enable : enable a component. disable : disable a component. online : make a component online. offline : make a component offline. ncconn : connect 1.6G ports each other. ncdis : disconnect 1.6G ports. led : turn on/off maintenance LED of a component. loc : set location info. clear : clear memory bit error counters. check : check illegal configuration. quit : quit from HC command prompt.

A: Displays Help for the HC command when you enter “help”. B: Displays the list of HC commands.

Service Processor 3-47

Table 3-38. HC ALL Display Screen

Screen Image Reference

iSPyz:---> hcENTER> iSP FW version is Rxx.xx.

HC> disp all<ENTER>

==== Partitioning ================================= 19:20:23,01/31/2002 === part0(RUN ) CELL:01-- (01--) IOR:0--- (0---) part1(INIT) CELL:--2- (--2-) IOR:-1-- (-0--) part2(STOP) CELL:---3 (---3) IOR:--2- (--0-) part3(----) CELL:---- (----) IOR:---- (----) ==================================================================

==== Summary (15/0/29+8F) ======================== 19:20:23,01/31/2002 === PBAY00 (loc=15/0/29+8F) power-on enable DEG PBAY01 (loc=15/0/23+6F) power-on enable DEG PBAY10 (loc=15/1/00+3F) power-on enable DEG

iSP0 (loc=15/0/29+8F/30) master ------- -- XBC0 (loc=15/0/29+8F/08) offline enable DEG XBC1 (loc=15/0/23+8F/09) power-off DISABLE CELL0 (loc=15/0/29+8F/00) online enable DEG part.0 (LCN=0) CELL1 (loc=15/0/29+8F/01) offline DISABLE DEG part.0 (LCN=1) CELL2 (loc=15/0/23+8F/02) online enable part.1 (LCN=3) CELL3 (loc=15/0/23+8F/03) power-off enable part.2 (LCN=2)

PCIX0(V) (loc=15/0/23+8F) online enable DEG part.0 (LIN=0,PRI=0) PCIX1(F) (loc=15/0/17+4F) offline enable DEG part.0 (LIN=1,PRI=5) PCIX2(F) (loc=15/0/19+4F) online enable DEG part.1 (LIN=0,PRI=0) PCIX3(F) (loc=15/-/-----) power-off enable DEG part.2 (LIN=0,PRI=0) ==================================================================

---- CELL0 --------------------------------------------------------------------- 19:20:23,01/31/2002 -- CELL0 (loc=15/0/29+8F/00) online enable DEG part.0 (LCN=2) PROC00 offline DISABLE -- PROC01 online enable -- PROC02 offline DISABLE* -- PROC03 nonexist. MMC00 online enable DEG MMC01 offline enable DEG TAG0 --------- -------- DEG CXI0 --------- enable --- --->XBC0 CXI0 CXI1 --------- disable --- --->XBC1 CXI0 IOM port0 --------- -------- --- IOR0-IOC1 IOM port1 --------- -------- --- IOR0-IOC0

---- MMC00 -------------------------------------------------------------------- 19:20:23,01/31/2002 -- MMC00 online enable DEG ROW0[DIMM00:01] 1024MB --------- enable --- SBE=000:000 MBE=000 ROW1[DIMM10:11] 1024MB --------- enable --- SBE=000:000 MBE=000 ROW2[DIMM20:21] 1024MB --------- DISABLE --- SBE=000:000 MBE=000 ROW3[DIMM30:31] 1024MB --------- DISABLE --- SBE=000:021 MBE=000 cache000 --------- enable -- cache001 --------- enable -- cache002 --------- enable -- cache003 --------- enable -- cache004 --------- DISABLE* -- cache005 --------- enable -- cache006 --------- enable -- cache007 --------- DISABLE ---

3-48 Service Processor

Table 3-38. HC ALL Display Screen (cont’d)

Screen Image Reference

---- MMC01 -------------------------------------------------------------------- 19:20:23,01/31/2002 -- MMC01 offline enable DEG

ROW0[DIMM00:01] 512MB --------- enable --- SBE=000:000 MBE=000 ROW1[DIMM10:11] 512MB --------- enable --- SBE=000:000 MBE=000 ROW2[DIMM20:21] 1024MB --------- DISABLE --- SBE=000:000 MBE=000 ROW3[DIMM30:31] 1024MB --------- DISABLE --- SBE=000:021 MBE=000 cache010 --------- enable -- cache011 --------- enable -- cache012 --------- enable -- cache013 --------- enable -- cache014 --------- DISABLE* -- cache015 --------- enable -- cache016 --------- enable -- cache017 --------- DISABLE ---

---- TAG0 ----------------------------------------------------------------------- 19:20:23,01/31/2002 -- TAG0 --------- -------- DEG TAG0e0 --------- DISABLE -- TAG0e1 --------- enable -- TAG0e2 --------- DISABLE* -- TAG0e3 --------- enable -- TAG0o0 --------- enable -- TAG0o1 --------- DISABLE -- TAG0o2 --------- enable -- TAG0o3 --------- enable ---

---- CELL1 --------------------------------------------------------------------- 19:20:23,01/31/2002 -- : : :

---- XBC0 (XIC) --------------------------------------------------------------- 19:20:23,01/31/2002 -- XBC0 (loc=15/0/29+8F) online enable DEG CXI0 -------- enable --- --->CELL0 CXI0 CXI1 -------- DISABLE* --- --->CELL1 CXI0 CXI2 -------- enable --- --->CELL2 CXI0 CXI3 -------- DISABLE* --- --->CELL3 CXI0

1.6G port0 -------- enable --- --->IOR0 port0

1.6G port1 -------- DISABLE* --- --->IOR1 port0 MOVER0 -------- enable -- MOVER1 -------- DISABLE -- SERIAL0 -------- used --- part.0 SERIAL1 -------- not used -- SERIAL2 -------- used --- part.1 SERIAL3 -------- disable --- part.2

---- XBC1 (XBR) -------------------------------------------------------------- 19:20:23,01/31/2002 -- XBC1 (loc=15/0/23+8F) online enable DEG CXI0 -------- enable --- --->CELL0 CXI1 CXI1 -------- DISABLE* --- --->CELL1 CXI1 CXI2 -------- enable --- --->CELL2 CXI1 CXI3 -------- DISABLE* --- --->CELL3 CXI1

1.6G port0 -------- enable --- --->IOR2 port0

1.6G port1 -------- DISABLE* --- --->IOR3 port0 MOVER0 -------- enable -- MOVER1 -------- DISABLE -- SERIAL0 -------- used --- part.0 SERIAL1 -------- not used -- SERIAL2 -------- used --- part.1 SERIAL3 -------- disable --- part.2

Service Processor 3-49

Table 3-38. HC ALL Display Screen (cont’d)

Screen Image Reference

---- PCIX0(V) ------------------------------------------------------------------ 19:20:23,01/31/2002 -- IOR0 (loc=15/0/29+8F) online enable DEG part.0 (LIN=0,PRI=0)

1.6G port0 -------- enable --- --->XBC0 port0 IOC00 -------- enable DEG IOC01 -------- enable DEG GXB00 (loc=15/0/29+8F) -------- enable -- BUS-A -------- enable --- BIO BUS-B -------- enable -- GXB01 (loc=--/-/--+--) -------- nonexit -- BUS-A -------- nonexit -- BUS-B -------- nonexit -- GXB02 (loc=15/0/29+8F) -------- enable -- BUS-A -------- enable -- BUS-B -------- enable -- GXB03 (loc=15/0/29+8F) -------- enable -- BUS-A -------- enable -- BUS-B -------- enable ---

---- PCIX2(F) ------------------------------------------------------------------ 19:20:23,01/31/2002 -- IOR2 (loc=15/0/13+4F) offline enable DEG part.0 (LIN=2,PRI=9)

1.6G port0 -------- enable --- --->XBC2 port0 IOC20 -------- enable DEG IOC21 -------- enable DEG GXB20 (loc=15/1/13+4R) -------- enable -- BUS-A -------- enable --- BIO BUS-B -------- enable -- GXB21 (loc=15/1/13+4R) -------- enable -- BUS-A -------- enable -- BUS-B -------- enable -- GXB22 (loc=15/1/13+4R) -------- enable -- BUS-A -------- enable -- BUS-B -------- enable -- GXB23 (loc=15/1/13+4R) -------- enable -- BUS-A -------- enable -- BUS-B -------- enable ---

: : :

---- PBAYs --------------------------------------------------------------------- 19:20:23,01/31/2002 -- PBAY00 (loc=15/0/23+8F) power-on enable DEG DPS000 DPS001 INVISIBLE DPS002 PBAY01 (loc=15/0/23+8F) power-on enable DEG DPS010 DPS011 INVISIBLE DPS012 ALARM PBAY10 (loc=15/1/00+3F) power-on enable DEG DPS100 DPS101 DPS102 DPS103 INVISIBLE DPS104 ALARM DPS105
