LM733/LM733C Differential Amplifier
LM733/LM733C Differential Amplifier
August 1989
General Description
The LM733/LM733C is a two-stage, differential input, differential output, wide-band video amplifier. The use of internal
series-shunt feedback gives wide bandwidth with low phase
distortion and high gain stability. Emitter-follower outputs
provide a high current drive, low impedance capability. Its
120 MHz bandwidth and selectable gains of 10, 100 and
400, without need for frequency compensation, make it a
very useful circuit for memory element drivers, pulse amplifiers, and wide band linear gain stages.
The LM733 is specified for operation over the
a
125§C military temperature range. The LM733C is speci-
fied for operation over the 0
Ctoa70§C temperature range.
§
b
55§Cto
Connection Diagrams
Dual-In-Line Package
Features
Y
120 MHz bandwidth
Y
250 kX input resistance
Y
Selectable gains of 10, 100, 400
Y
No frequency compensation
Y
High common mode rejection ratio at high frequencies
Applications
Y
Magnetic tape systems
Y
Disk file memories
Y
Thin and thick film memories
Y
Woven and plated wire memories
Y
Wide band video amplifiers
Metal Can Package
Note: Pin 5 connected to case.
Top View
Order Number LM733H or LM733CH
See NS Package Number H10D
TL/H/7866– 2
Top View
TL/H/7866– 1
Order Number LM733CN
See NS Package Number N14A
C
1995 National Semiconductor Corporation RRD-B30M115/Printed in U. S. A.
TL/H/7866
Absolute Maximum Ratings
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales
Office/Distributors for availability and specifications.
Diffential Input Voltage
Common Mode Input Voltage
V
CC
Output Current 10 mA
g
5V
g
6V
g
8V
Power Dissipation (Note 1) 500 mW
Junction Temperature
Storage Temperature Range
Operating Temperature Range
LM733
LM733C 0
b
b
a
150§C
65§Ctoa150§C
55§Ctoa125§C
Ctoa70§C
§
Lead Temperature (Soldering, 10 sec.) 260§C
Electrical Characteristics (T
Characteristics
Test
Circuit
e
25§C, unless otherwise specified, see test circuits, V
A
Test Conditions
LM733 LM733C
Min Typ Max Min Typ Max
e
g
6.0V)
S
Units
Differential Voltage Gain
Gain 1 (Note 2) 300 400 500 250 400 600
Gain 2 (Note 3) 1 90 100 110 80 100 120
Gain 3 (Note 4) R
L
e
2kXV
e
3 Vp-p 9.0 10 11 8.0 10 12
OUT
Bandwidth
Gain 1 40 40 MHz
Gain 2 2 90 90 MHz
Gain 3 120 120 MHz
Rise Time
Gain 1 V
Gain 2 2 4.5 10 4.5 12 ns
e
1 Vp-p 10.5 10.5 ns
OUT
Gain 3 2.5 2.5 ns
Propagation Delay V
Gain 1 7.5 7.5 ns
OUT
e
1 Vp-p
Gain 2 2 6.0 10 6.0 10 ns
Gain 3 3.6 3.6 ns
Input Resistance
Gain 1 4.0 4.0 kX
Gain 2 20 30 10 30 kX
Gain 3 250 250 kX
Input Capacitance Gain 2 2.0 2.0 pF
Input Offset Current 0.4 3.0 0.4 5.0 mA
Input Bias Current 9.0 20 9.0 30 mA
Input Noise Voltage BWe1 kHz to 10 MHz 12 12 mVrms
Input Voltage Range 1
g
1.0
g
1.0 V
Common Mode Rejection Ratio
e
Gain 2 1 V
Gain 2 V
g
1V fs100 kHz 60 86 60 86 dB
CM
e
g
1V fe5 MHz 60 60 dB
CM
Supply Voltage Rejection Ratio
e
Gain 2 1 DV
g
0.5V 50 70 50 70 dB
S
Output Offset Voltage
Gain 1 1 R
Gain 2 and 3 0.35 1.0 0.35 1.5 V
Output Common Mode Voltage 1 R
Output Voltage Swing 1 R
e %
L
e %
L
e
2k 3.0 4.0 3.0 4.0
L
0.6 1.5 0.6 1.5 V
2.4 2.9 3.4 2.4 2.9 3.4 V
Output Sink Current 2.5 3.6 2.5 3.6 mA
Output Resistance 20 20 X
Power Supply Current 1 R
L
e %
18 24 18 24 mA
2
Electrical Characteristics (Continued)
(The following specifications apply for
g
6.0V)
Characteristics
Test
Circuit
b
55§CkT
k
125§C for the LM733 and 0§CkT
A
Test Conditions
Min Typ Max Min Typ Max
k
70§C for the LM733C, V
A
LM733 LM733C
e
S
Units
Differential Voltage Gain
Gain 1 200 600 250 600
Gain 2 1
e
R
2kX,V
L
OUT
e
3 Vp-p
80 120 80 120
Gain 3 8.0 12.0 8.0 12.0
Input Resistance Gain 2 8 8 kX
Input Offset Current 56mA
Input Bias Current 40 40 mA
Input Voltage Range 1
Common Mode Rejection Ratio
Gain 2 1 V
Supply Voltage Rejection Ratio
Gain 2 1 DV
Output Offset Voltage
Gain 1 1 R
Gain 2 and 3 1.2 1.5 V
Output Voltage Swing 1 R
e
g
1V fs100 kHz 50 50 dB
CM
e
g
0.5V 50 50 dB
S
e %
L
e
2k 2.5 2.8 V
L
g
1
g
1V
1.5 1.5 V
pp
Output Sink Current 2.2 2.5 mA
Power Supply Current 1 R
Note 1: The maximum junction temperature of the LM733 is 150§C, while that of the LM733C is 100§C. For operation at elevated temperatures devices in the TO-
100 package must be derated based on a thermal resistance of 150
package is 90
Note 2: Pins G1A and G1B connected together.
Note 3: Pins G2A and G2B connected together.
Note 4: Gain select pins open.
Note 5: Refer to RETS733X drawing for specifications of LM733H version.
C/W.
§
e %
L
C/W junction to ambient or 45§C/W junction to case. Thermal resistance of the dual-in-line
§
27 27 mA
Typical Performance Characteristics
Pulse Response Temperature
Phase Shift
vs Frequency
Pulse Response vs
Phase Shift
vs Frequency
Pulse Response vs
Supply Voltage
Differential Overdrive
Recovery Time
TL/H/7866– 6
3
Typical Performance Characteristics (Continued)
Voltage Gain vs Frequency Temperature
Voltage Gain vs R
Output Voltage Swing vs
Frequency
ADJ
Gain vs Frequency
Voltage Gain vs Temperature Supply Voltage
Supply Current, Output Voltage
and Current Swing vs Supply
Voltage
Gain vs Frequency vs
Supply Voltage
Voltage Gain vs
Output Voltage Swing vs
Load Resistance
Common Mode Rejection
Ratio vs Frequency
Input Noise Voltage vs
Source Resistance
4
Supply Current and Input
Resistance vs Temperature
TL/H/7866– 7
Test Circuits
Test Circuit 1
Test Circuit 2
Schematic Diagram
TL/H/7866– 3
Voltage Gain Adjust Circuit
e
V
(Pin numbers apply to TO-5 package)
e
6V, T
S
25§C
A
TL/H/7866– 4
TL/H/7866– 5
TL/H/7866– 8
5
Physical Dimensions inches (millimeters)
Metal Can Package (H)
Order Number LM733H or LM733CH
NS Package Number H10D
LM733/LM733C Differential Amplifier
Molded Dual-In-Line Package (N)
Order Number LM733CN
NS Package Number N14A
