Contents
About This Manual
Conventions ...................................................................................................................xi
Related Documentation..................................................................................................xii
Chapter 1
Introduction
KWP2000 (Key Word Protocol 2000)...........................................................................1-1
Transport Protocol ...........................................................................................1-2
Diagnostic Services .........................................................................................1-2
Diagnostic Service Format ..............................................................................1-2
Connect/Disconnect.........................................................................................1-3
GetSeed/Unlock...............................................................................................1-3
Read/Write Memory........................................................................................1-3
Measurements..................................................................................................1-4
Diagnostic Trouble Codes ...............................................................................1-4
Input/Output Control .......................................................................................1-4
Remote Activation of a Routine ......................................................................1-4
External References.........................................................................................1-4
UDS (Unified Diagnostic Services)...............................................................................1-5
Diagnostic Services .........................................................................................1-5
Diagnostic Service Format ..............................................................................1-5
External References.........................................................................................1-6
OBD (On-Board Diagnostic) .........................................................................................1-6
Chapter 2
Installation and Configuration
Installation .....................................................................................................................2-1
LabVIEW Real-Time (RT) Configuration ....................................................................2-2
Hardware and Software Requirements ..........................................................................2-2
Chapter 3
Application Development
Choosing the Programming Language ..........................................................................3-1
LabVIEW ........................................................................................................3-1
LabWindows/CVI............................................................................................3-1
© National Instruments Corporation v Automotive Diagnostic Command Set User Manual
Contents
Visual C++ 6 ................................................................................................... 3-2
Other Programming Languages ...................................................................... 3-2
Debugging an Application............................................................................................. 3-3
Chapter 4
Using the Automotive Diagnostic Command Set
Structure of the Automotive Diagnostic Command Set................................................ 4-1
Automotive Diagnostic Command Set API Structure................................................... 4-2
General Programming Model ........................................................................................ 4-3
Available Diagnostic Services....................................................................................... 4-4
Tweaking the Transport Protocol .................................................................................. 4-4
Chapter 5
Automotive Diagnostic Command Set API for LabVIEW
Section Headings ........................................................................................................... 5-1
Purpose............................................................................................................ 5-1
Format ............................................................................................................. 5-1
Input and Output ............................................................................................. 5-1
Description ...................................................................................................... 5-1
List of VIs...................................................................................................................... 5-2
General Functions.......................................................................................................... 5-8
Close Diagnostic.vi ......................................................................................... 5-8
Convert from Phys.vi ...................................................................................... 5-10
Convert to Phys.vi........................................................................................... 5-12
Create Extended CAN IDs.vi..........................................................................5-14
Diag Get Property.vi ....................................................................................... 5-15
Diag Set Property.vi........................................................................................ 5-17
Diagnostic Service.vi ...................................................................................... 5-19
DTC to String.vi.............................................................................................. 5-21
OBD Open.vi .................................................................................................. 5-22
Open Diagnostic.vi.......................................................................................... 5-24
VWTP Connect.vi........................................................................................... 5-26
VWTP Connection Test.vi.............................................................................. 5-28
VWTP Disconnect.vi ...................................................................................... 5-30
KWP2000 Services........................................................................................................ 5-32
ClearDiagnosticInformation.vi ....................................................................... 5-32
ControlDTCSetting.vi ..................................................................................... 5-35
DisableNormalMessageTransmission.vi......................................................... 5-38
ECUReset.vi.................................................................................................... 5-40
EnableNormalMessageTransmission.vi.......................................................... 5-42
InputOutputControlByLocalIdentifier.vi ........................................................ 5-44
ReadDataByLocalIdentifier.vi ........................................................................ 5-46
Automotive Diagnostic Command Set User Manual vi ni.com
Contents
ReadDTCByStatus.vi ......................................................................................5-48
ReadECUIdentification.vi ...............................................................................5-51
ReadMemoryByAddress.vi .............................................................................5-53
ReadStatusOfDTC.vi.......................................................................................5-55
RequestRoutineResultsByLocalIdentifier.vi ...................................................5-58
RequestSeed.vi ................................................................................................5-60
SendKey.vi ......................................................................................................5-62
StartDiagnosticSession.vi................................................................................5-64
StartRoutineByLocalIdentifier.vi ....................................................................5-66
StopDiagnosticSession.vi ................................................................................5-68
StopRoutineByLocalIdentifier.vi ....................................................................5-70
TesterPresent.vi ...............................................................................................5-72
WriteDataByLocalIdentifier.vi........................................................................5-74
WriteMemoryByAddress.vi ............................................................................5-76
UDS (DiagOnCAN) Services ........................................................................................5-78
UDS ClearDiagnosticInformation.vi...............................................................5-78
UDS CommunicationControl.vi ......................................................................5-81
UDS ControlDTCSetting.vi ............................................................................5-83
UDS DiagnosticSessionControl.vi ..................................................................5-85
UDS ECUReset.vi ...........................................................................................5-87
UDS InputOutputControlByIdentifier.vi.........................................................5-89
UDS ReadDataByIdentifier.vi.........................................................................5-91
UDS ReadMemoryByAddress.vi ....................................................................5-93
UDS ReportDTCBySeverityMaskRecord.vi...................................................5-95
UDS ReportDTCByStatusMask.vi..................................................................5-98
UDS ReportSeverityInformationOfDTC.vi ....................................................5-101
UDS ReportSupportedDTCs.vi .......................................................................5-104
UDS RequestSeed.vi .......................................................................................5-107
UDS RoutineControl.vi ...................................................................................5-109
UDS SendKey.vi .............................................................................................5-111
UDS TesterPresent.vi ......................................................................................5-113
UDS WriteDataByIdentifier.vi........................................................................5-115
UDS WriteMemoryByAddress.vi ...................................................................5-117
OBD (On-Board Diagnostics) Services .........................................................................5-119
OBD Clear Emission Related Diagnostic Information.vi ...............................5-119
OBD Request Control Of On-Board Device.vi...............................................5-121
OBD Request Current Powertrain Diagnostic Data.vi....................................5-123
OBD Request Emission Related DTCs.vi.......................................................5-125
OBD Request Emission Related DTCs During Current Drive Cycle.vi.........5-128
OBD Request On-Board Monitoring Test Results.vi......................................5-131
OBD Request Powertrain Freeze Frame Data.vi.............................................5-133
OBD Request Supported PIDs.vi ....................................................................5-135
OBD Request Vehicle Information.vi .............................................................5-137
© National Instruments Corporation vii Automotive Diagnostic Command Set User Manual
Contents
Chapter 6
Automotive Diagnostic Command Set API for C
Section Headings ........................................................................................................... 6-1
Purpose............................................................................................................ 6-1
Format ............................................................................................................. 6-1
Input and Output ............................................................................................. 6-1
Description ...................................................................................................... 6-1
List of Data Types ......................................................................................................... 6-2
List of Functions............................................................................................................ 6-3
General Functions.......................................................................................................... 6-12
ndCloseDiagnostic .......................................................................................... 6-12
ndConvertFromPhys ....................................................................................... 6-13
ndConvertToPhys............................................................................................ 6-15
ndCreateExtendedCANIds.............................................................................. 6-17
ndDiagnosticService ....................................................................................... 6-19
ndDTCToString .............................................................................................. 6-21
ndGetProperty ................................................................................................. 6-22
ndOBDOpen.................................................................................................... 6-24
ndOpenDiagnostic...........................................................................................6-26
ndSetProperty.................................................................................................. 6-28
ndStatusToString............................................................................................. 6-30
ndVWTPConnect ............................................................................................ 6-32
ndVWTPConnectionTest ................................................................................ 6-34
ndVWTPDisconnect ....................................................................................... 6-35
KWP2000 Services........................................................................................................ 6-36
ndClearDiagnosticInformation........................................................................ 6-36
ndControlDTCSetting ..................................................................................... 6-38
ndDisableNormalMessageTransmission......................................................... 6-40
ndECUReset.................................................................................................... 6-41
ndEnableNormalMessageTransmission.......................................................... 6-43
ndInputOutputControlByLocalIdentifier ........................................................ 6-44
ndReadDataByLocalIdentifier ........................................................................ 6-46
ndReadDTCByStatus ...................................................................................... 6-48
ndReadECUIdentification............................................................................... 6-51
ndReadMemoryByAddress.............................................................................6-53
ndReadStatusOfDTC ...................................................................................... 6-55
ndRequestRoutineResultsByLocalIdentifier................................................... 6-58
ndRequestSeed ................................................................................................ 6-60
ndSendKey ...................................................................................................... 6-62
ndStartDiagnosticSession................................................................................ 6-64
ndStartRoutineByLocalIdentifier.................................................................... 6-66
ndStopDiagnosticSession................................................................................ 6-68
ndStopRoutineByLocalIdentifier .................................................................... 6-69
Automotive Diagnostic Command Set User Manual viii ni.com
Contents
ndTesterPresent ...............................................................................................6-71
ndWriteDataByLocalIdentifier........................................................................6-73
ndWriteMemoryByAddress ............................................................................6-75
UDS (DiagOnCAN) Services ........................................................................................6-77
ndUDSClearDiagnosticInformation ................................................................6-77
ndUDSCommunicationControl .......................................................................6-79
ndUDSControlDTCSetting..............................................................................6-81
ndUDSDiagnosticSessionControl ...................................................................6-82
ndUDSECUReset ............................................................................................6-83
ndUDSInputOutputControlByIdentifier..........................................................6-85
ndUDSReadDataByIdentifier..........................................................................6-87
ndUDSReadMemoryByAddress .....................................................................6-89
ndUDSReportDTCBySeverityMaskRecord....................................................6-91
ndUDSReportDTCByStatusMask...................................................................6-94
ndUDSReportSeverityInformationOfDTC......................................................6-97
ndUDSReportSupportedDTCs ........................................................................6-100
ndUDSRequestSeed ........................................................................................6-103
ndUDSRoutineControl ....................................................................................6-105
ndUDSSendKey ..............................................................................................6-107
ndUDSTesterPresent .......................................................................................6-109
ndUDSWriteDataByIdentifier.........................................................................6-111
ndUDSWriteMemoryByAddress ....................................................................6-113
OBD (On-Board Diagnostics) Services .........................................................................6-115
ndOBDClearEmissionRelatedDiagnosticInformation ....................................6-115
ndOBDRequestControlOfOnBoardDevice .....................................................6-116
ndOBDRequestCurrentPowertrainDiagnosticData .........................................6-118
ndOBDRequestEmissionRelatedDTCs ...........................................................6-120
ndOBDRequestEmissionRelatedDTCsDuringCurrentDriveCycle .................6-122
ndOBDRequestOnBoardMonitoringTestResults ............................................6-124
ndOBDRequestPowertrainFreezeFrameData..................................................6-126
ndOBDRequestVehicleInformation ................................................................6-128
Appendix A
Technical Support and Professional Services
Index
© National Instruments Corporation ix Automotive Diagnostic Command Set User Manual
About This Manual
This manual provides instructions for using the Automotive Diagnostic
Command Set. It contains information about installation, configuration,
and troubleshooting, and also contains Automotive Diagnostic Command
Set function reference for LabVIEW-based and C-based APIs.
Conventions
The following conventions appear in this manual:
» The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a tip, which alerts you to advisory information.
This icon denotes a note, which alerts you to important information.
bold Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
italic Italic text denotes variables, emphasis, a cross-reference, or an introduction
to a key concept. Italic text also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames, and extensions.
monospace italic
© National Instruments Corporation xi Automotive Diagnostic Command Set User Manual
Italic text in this font denotes text that is a placeholder for a word or value
that you must supply.
About This Manual
Related Documentation
The following documents contain information that you might find helpful
as you read this manual:
• ANSI/ISO Standard 11898-1993, Road Vehicles—Interchange of
Digital Information—Controller Area Network (CAN) for High-Speed
Communication
• CAN Specification Version 2.0, 1991, Robert Bosch GmbH.,
Postfach 106050, D-70049 Stuttgart 1
• CiA Draft Standard 102, Version 2.0, CAN Physical Layer for
Industrial Applications
• ISO 14229:1998(E), Road Vehicles, Diagnostic Systems, Diagnostic
Services Specification
• ISO 14230-1:1999(E), Road Vehicles, Diagnostic Systems, Keyword
Protocol 2000, Part 1: Physical Layer
•ISO 14230-2:1999(E), Road Vehicles, Diagnostic Systems, Keyword
Protocol 2000, Part 2: Data Link Layer
• ISO 14230-3:1999(E), Road Vehicles, Diagnostic Systems, Keyword
Protocol 2000, Part 3: Application Layer
• ISO 15765-1:2004(E), Road Vehicles, Diagnostics on Controller Area
Networks (CAN), Part 1: General Information
• ISO 15765-2:2004(E), Road Vehicles, Diagnostics on Controller Area
Networks (CAN), Part 2: Network Layer Services
• ISO 15765-3:2004(E), Road Vehicles, Diagnostics on Controller Area
Networks (CAN), Part 3: Implementation of Unified Diagnostic
Services (UDS on CAN)
• NI-CAN Hardware and Software Manual
Automotive Diagnostic Command Set User Manual xii ni.com
Introduction
Diagnostics involve remote execution of routines, or services, on ECUs. To
execute a routine, you send a byte string as a request to an ECU, and the
ECU usually answers with a response byte string. Several diagnostic
protocols such as KWP2000 and UDS standardize the format of the
services to be executed, but those standards leave a large amount of room
for manufacturer-specific extensions. A newer trend is the emission-related
legislated OnBoard Diagnostics (OBD), which is manufacturer
independent and standardized in SAE J1979 and ISO 15031-5. This
standard adds another set of services that follow the same scheme.
Because diagnostics were traditionally executed on serial communication
links, the byte string length is not limited. For newer, CAN-based
diagnostics, this involves using a transport protocol that segments the
arbitrarily long byte strings into pieces that can be transferred over the CAN
bus, and reassembles them on the receiver side. Several transport protocols
accomplish this task. The Automotive Diagnostic Command Set
implements the ISO TP (standardized in ISO 15765-2) and the
manufacturer-specific VW TP 2.0.
1
Note The Automotive Diagnostic Command Set is designed for CAN-based diagnostics
only. Diagnostics on serial lines (K-line and L-line) are not in the scope of the Automotive
Diagnostic Command Set.
KWP2000 (Key Word Protocol 2000)
The KWP2000 protocol has become a de facto standard in automotive
diagnostic applications. It is standardized as ISO 14230-3. KWP2000
describes the implementation of various diagnostic services you can access
through the protocol. You can run KWP2000 on several transport layers
such as K-line (serial) or CAN.
© National Instruments Corporation 1-1 Automotive Diagnostic Command Set User Manual
Chapter 1 Introduction
Transport Protocol
Note For KWP2000, the Automotive Diagnostic Command Set supports only the ISO TP
(standardized in ISO 15765-2) and manufacturer-specific VW TP 2.0 transport protocols.
Diagnostic Services
As KWP2000 uses messages of variable byte lengths, a transport protocol
is necessary on layers with only a well defined (short) message length, such
as CAN. The transport protocol splits a long KWP2000 message into pieces
that can be transferred over the network and reassembles those pieces to
recover the original message.
KWP2000 runs on CAN on various transport protocols such as ISO TP
(ISO 15765-2), TP 1.6, TP 2.0 (Volkswagen), and SAE J1939-21.
The diagnostic services available in KWP2000 are grouped in functional
units and identified by a one-byte code (ServiceId). The standard does not
define all codes; for some codes, the standard refers to other SAE or ISO
standards, and some are reserved for manufacturer-specific extensions. The
Automotive Diagnostic Command Set supports the following services:
• Diagnostic Management
• Data Transmission
• Stored Data Transmission (Diagnostic Trouble Codes)
• Input/Output Control
• Remote Activation of Routine
Note Upload/Download and Extended services are not part of the Automotive Diagnostic
Command Set.
Diagnostic Service Format
Diagnostic services have a common message format. Each service defines
a Request Message, Positive Response Message, and Negative Response
Message.
The Request Message has the ServiceId as first byte, plus additional
service-defined parameters. The Positive Response Message has an echo of
the ServiceId with bit 6 set as first byte, plus the service-defined response
parameters.
The Negative Response Message is usually a three-byte message: it has the
Negative Response ServiceId as first byte, an echo of the original ServiceId
Automotive Diagnostic Command Set User Manual 1-2 ni.com
Connect/Disconnect
Chapter 1 Introduction
as second byte, and a ResponseCode as third byte. The only exception to
this format is the negative response to an EscapeCode service; here, the
third byte is an echo of the user-defined service code, and the fourth byte
is the ResponseCode. The KWP2000 standard partly defines the
ResponseCodes, but there is room left for manufacturer-specific
extensions. For some of the ResponseCodes, KWP2000 defines an error
handling procedure. Because both positive and negative responses have an
echo of the requested service, you can always assign the responses to their
corresponding request.
KWP2000 expects a diagnostic session to be started with
StartDiagnosticSession and terminated with StopDiagnosticSession.
However, StartDiagnosticSession has a DiagnosticMode parameter that
determines the diagnostic session type. Depending on this type, the ECU
may or may not support other diagnostic services, or operate in a restricted
mode where not all ECU functions are available. The DiagnosticMode
parameter values are manufacturer specific and not defined in the standard.
For a diagnostic session to remain active, it must execute the TesterPresent
service periodically if no other service is executed. If the TesterPresent
service is missing for a certain period of time, the diagnostic session is
terminated, and the ECU returns to normal operation mode.
GetSeed/Unlock
A GetSeed/Unlock mechanism may protect some diagnostic services.
However, the applicable services are left to the manufacturer and not
defined by the standard.
You can execute the GetSeed/Unlock mechanism through the
SecurityAccess service. This defines several levels of security, but the
manufacturer assigns these levels to certain services.
Read/Write Memory
Use the Read/WriteMemoryByAddress services to upload/download data
to certain memory addresses on an ECU. The address is a three-byte
quantity in KWP2000 and a five-byte quantity (four-byte address and
one-byte extension) in the calibration protocols.
The Upload/Download functional unit services are highly manufacturer
specific and not well defined in the standard, so they are not a good way to
provide a general upload/download mechanism.
© National Instruments Corporation 1-3 Automotive Diagnostic Command Set User Manual
Chapter 1 Introduction
Measurements
Use the ReadDataByLocal/CommonIdentifier services to access ECU data
in a way similar to a DAQ list. A Local/CommonIdentifier describes a list
of ECU quantities that are then transferred from the ECU to the tester. The
transfer can be either single value or periodic, with a slow, medium, or fast
transfer rate. The transfer rates are manufacturer specific; you can use the
SetDataRates service to set them, but this setting is manufacturer specific.
Note The Automotive Diagnostic Command Set supports single-point measurements.
Diagnostic Trouble Codes
A major diagnostic feature is the readout of Diagnostic Trouble Codes
(DTCs). KWP2000 defines several services that access DTCs based on
their group or status.
Input/Output Control
KWP2000 defines services to modify internal or external ECU signals. One
example is redirecting ECU sensor inputs to stimulated signals. The control
parameters of these commands are manufacturer specific and not defined
in the standard.
Remote Activation of a Routine
These services are similar to the ActionService and DiagService
functions of CCP. You can invoke an ECU internal routine identified by a
Local/CommonIdentifier or a memory address. Contrary to the CCP case,
execution of this routine can be asynchronous; that is, there are separate
Start, Stop, and RequestResult services.
The control parameters of these commands are manufacturer specific and
not defined in the standard.
External References
For more information about the KWP2000 Standard, refer to the
ISO 14230-3 standard.
Automotive Diagnostic Command Set User Manual 1-4 ni.com
UDS (Unified Diagnostic Services)
The UDS protocol has become a de facto standard in automotive diagnostic
applications. It is standardized as ISO 15765-3. UDS describes the
implementation of various diagnostic services you can access through the
protocol.
As UDS uses messages of variable byte lengths, a transport protocol is
necessary on layers with only a well defined (short) message length, such
as CAN. The transport protocol splits a long UDS message into pieces that
can be transferred over the network and reassembles those pieces to recover
the original message.
UDS runs on CAN on various transport protocols.
Note The Automotive Diagnostic Command Set supports only the ISO TP (standardized
in ISO 15765-2) and manufacturer-specific VW TP 2.0 transport protocols.
Diagnostic Services
The diagnostic services available in UDS are grouped in functional units
and identified by a one-byte code (ServiceId). Not all codes are defined in
the standard; for some codes, the standard refers to other standards, and
some are reserved for manufacturer-specific extensions. The Automotive
Diagnostic Command Set supports the following services:
• Diagnostic Management
• Data Transmission
• Stored Data Transmission (Diagnostic Trouble Codes)
• Input/Output Control
• Remote Activation of Routine
Chapter 1 Introduction
Diagnostic Service Format
Diagnostic services have a common message format. Each service defines
a Request Message, a Positive Response Message, and a Negative
Response Message. The general format of the diagnostic services complies
with the KWP2000 definition; most of the Service Ids also comply with
KWP2000. The Request Message has the ServiceId as first byte, plus
additional service-defined parameters. The Positive Response Message has
an echo of the ServiceId with bit 6 set as first byte, plus the service-defined
response parameters.
© National Instruments Corporation 1-5 Automotive Diagnostic Command Set User Manual
Chapter 1 Introduction
Note Some parameters to both the Request and Positive Response Messages are optional.
Each service defines these parameters. Also, the standard does not define all parameters.
The Negative Response Message is usually a three-byte message: it has the
Negative Response ServiceId (0x7F) as first byte, an echo of the original
ServiceId as second byte, and a ResponseCode as third byte. The UDS
standard partly defines the ResponseCodes, but there is room left for
manufacturer-specific extensions. For some of the ResponseCodes, UDS
defines an error handling procedure.
Because both positive and negative responses have an echo of the requested
service, you always can assign the responses to their corresponding request.
External References
For more information about the UDS Standard, refer to the ISO 15765-3
standard.
OBD (On-Board Diagnostic)
On-Board Diagnostic (OBD) systems are present in most cars and light
trucks on the road today. On-Board Diagnostics refer to the vehicle’s
self-diagnostic and reporting capability, which the vehicle owner or a
repair technician can use to query status information for various vehicle
subsystems.
The amount of diagnostic information available via OBD has increased
since the introduction of on-board vehicle computers in the early 1980s.
Modern OBD implementations use a CAN communication port to provide
real-time data and a standardized series of diagnostic trouble codes
(DTCs), which identify and remedy malfunctions within the vehicle. In the
1970s and early 1980s, manufacturers began using electronic means to
control engine functions and diagnose engine problems. This was primarily
to meet EPA emission standards. Through the years, on-board diagnostic
systems have become more sophisticated. OBD-II, a new standard
introduced in the mid 1990s, provides almost complete engine control and
also monitors parts of the chassis, body, and accessory devices, as well as
the car’s diagnostic control network.
The On-Board Diagnostic (OBD) standard defines a minimum set of
diagnostic information for passenger cars and light and medium-duty
trucks, which must be exchanged with any off-board test equipment.
Automotive Diagnostic Command Set User Manual 1-6 ni.com
Installation and Configuration
This chapter explains how to install and configure the Automotive
Diagnostic Command Set.
Installation
This section discusses the Automotive Diagnostic Command Set
installation for Microsoft Windows.
Note You need administrator rights to install the Automotive Diagnostic Command Set on
your computer.
Follow these steps to install the Automotive Diagnostic Command Set
software:
1. Insert the Automotive Diagnostic Command Set CD into the CD-ROM
drive.
2. Open Windows Explorer.
3. Access the CD-ROM drive.
4. Double-click on
5. Start the installation. The installation program guides you through the
rest of the installation process.
6. If you have not already installed NI-CAN, the Automotive Diagnostic
Command Set installer automatically installs the NI-CAN driver on
your computer.
Within the Devices & Interfaces branch of the MAX Configuration
tree, NI CAN hardware is listed along with other hardware in the local
computer system. If the CAN hardware is not listed here, MAX is not
configured to search for new devices on startup. To search for the new
hardware, press <F5>. To verify installation of the CAN hardware,
right-click the CAN device, then select Self-test. If the self-test passes,
the card icon shows a checkmark. If the self-test fails, the card icon
shows an X mark, and the Test Status in the right pane describes the
problem.
autorun.exe to launch the software interface.
2
© National Instruments Corporation 2-1 Automotive Diagnostic Command Set User Manual
Chapter 2 Installation and Configuration
Refer to Appendix A, Troubleshooting and Common Questions, of the
NI-CAN User Manual for information about resolving hardware
installation problems.
When installation is complete, you can access the Automotive Diagnostic
Command Set functions in your application development environment.
LabVIEW Real-Time (RT) Configuration
LabVIEW Real-Time (RT) combines easy-to-use LabVIEW programming
with the power of real-time systems. When you use a National Instruments
PXI controller as a LabVIEW RT system, you can install a PXI CAN card
and use the NI-CAN APIs to develop real-time applications. As with any
NI software library for LabVIEW RT, you must install the Automotive
Diagnostic Command Set software to the LabVIEW RT target using the
Remote Systems branch in MAX. For more information, refer to the
LabVIEW RT documentation.
After you install the PXI CAN cards and download the Automotive
Diagnostic Command Set software to the LabVIEW RT system, you must
verify the installation.
Hardware and Software Requirements
The Automotive Diagnostic Command Set requires National Instruments
NI-CAN hardware Series 1 or 2 or USB-CAN and the NI-CAN driver
software version 2.4 or later installed.
Automotive Diagnostic Command Set User Manual 2-2 ni.com
Application Development
This chapter explains how to develop an application using the Automotive
Diagnostic Command Set API.
Choosing the Programming Language
The programming language you use for application development
determines how to access the Automotive Diagnostic Command Set APIs.
LabVIEW
Automotive Diagnostic Command Set functions and controls are in the
LabVIEW palettes. In LabVIEW, the Automotive Diagnostic Command
Set palette is in the top-level NI Measurements palette.
Chapter 5, Automotive Diagnostic Command Set API for LabVIEW,
describes each LabVIEW VI for the Automotive Diagnostic Command Set
API.
3
To access the VI reference from within LabVIEW, press <Ctrl-H> to open
the Help window, click the appropriate Automotive Diagnostic Command
Set VI, and follow the link. The Automotive Diagnostic Command Set
software includes a full set of LabVIEW examples. These examples teach
programming basics as well as advanced topics. The example help
describes each example and includes a link you can use to open the VI.
LabWindows/CVI
Within LabWindows™/CVI™, the Automotive Diagnostic Command Set
function panel is in Libraries»Automotive Diagnostic Command Set. As
with other LabWindows/CVI function panels, the Automotive Diagnostic
Command Set function panel provides help for each function and the
ability to generate code. Chapter 6, Automotive Diagnostic Command Set
API for C, describes each Automotive Diagnostic Command Set API
function. You can access the reference for each function directly from
within the function panel. The Automotive Diagnostic Command Set API
header file is
API library is
© National Instruments Corporation 3-1 Automotive Diagnostic Command Set User Manual
nidiagcs.h. The Automotive Diagnostic Command Set
nidiagcs.lib. The toolkit software includes a full set of
Chapter 3 Application Development
LabWindows/CVI examples. The examples are in the LabWindows/CVI
\samples\Automotive Diagnostic Command Set directory. Each
example includes a complete LabWindows/CVI project (
example description is in comments at the top of the
Visual C++ 6
The Automotive Diagnostic Command Set software supports Microsoft
Visual C/C++ 6. The header file and library for Visual C/C++ 6 are
in the
Diagnostic Command Set\MS Visual C
Automotive Diagnostic Command Set API, include the
header file in the code, then link with the
C applications (files with a
a
#include to the beginning of the code, as follows:
#include "nidiagcs.h"
For C++ applications (files with a .cpp extension), define _cplusplus
before including the header, as follows:
#define _cplusplus
#include "nidiagcs.h"
.prj file). The
.c file.
\ProgramFiles\National Instruments\Automotive
folder. To use the
nidiagcs.h
nidiagcs.lib library file. For
.c extension), include the header file by adding
The _cplusplus define enables the transition from C++ to the C language
functions.
Chapter 6, Automotive Diagnostic Command Set API for C, describes each
function. The C examples are in the
Set\MS Visual C
folder. Each example is in a separate folder. The
example description is in comments at the top of the
Automotive Diagnostic Command
.c file. At the
command prompt, after setting MSVC environment variables (such as
with MS
vcvars32.bat), you can build each example using a command
such as:
cl /I..
GetDTCs.c
..\nidiagcs.lib
Other Programming Languages
The Automotive Diagnostic Command Set software does not provide
formal support for programming languages other than those described in
the preceding sections. If the programming language includes a mechanism
to call a Dynamic Link Library (DLL), you can create code to call
Automotive Diagnostic Command Set functions. All functions for the
Automotive Diagnostic Command Set API are in
programming language supports the Microsoft Win32 APIs, you can load
Automotive Diagnostic Command Set User Manual 3-2 ni.com
nidiagcs.dll. If the
Chapter 3 Application Development
pointers to Automotive Diagnostic Command Set functions in the
application. The following section describes how to use the Win32
functions for C/C++ environments other than Visual C/C++ 6. For more
detailed information, refer to Microsoft documentation.
The following C language code fragment shows how to call Win32
LoadLibrary to load the Automotive Diagnostic Command Set API DLL:
#include <windows.h>
#include "nidiagcs.h"
HINSTANCE NiDiagCSLib = NULL;
NiMcLib = LoadLibrary("nidiagcs.dll");
Next, the application must call the Win32 GetProcAddress function to
obtain a pointer to each Automotive Diagnostic Command Set function the
application uses. For each function, you must declare a pointer variable
using the prototype of the function. For the Automotive Diagnostic
Command Set function prototypes, refer to Chapter 6, Automotive
Diagnostic Command Set API for C. Before exiting the application, you
must unload the Automotive Diagnostic Command Set DLL as follows:
FreeLibrary (NiDiagCSLib);
Debugging an Application
To debug your diagnostic application, use the LabVIEW example
Diagnostic Monitor.vi. This example monitors the CAN traffic the
diagnostic protocols generate on the level of individual CAN messages. It
works with all other Automotive Diagnostic Command Set examples and
diagnostic applications using the Automotive Diagnostic Command Set.
To launch this tool, open the LabVIEW Example Finder and search for
Diagnostic Monitor.vi under Hardware Input and Output/CAN/
Automotive Diagnostic Command Set/Diagnostic Monitor.
© National Instruments Corporation 3-3 Automotive Diagnostic Command Set User Manual
4
Using the Automotive
Diagnostic Command Set
Structure of the Automotive Diagnostic Command Set
Diagnostic Services Layer
Auxiliary
KWP2000
Services
Connection
Management
UDS (DiagOnCAN)
Services
Diagnostic Transport Layer
OBD(OnBoard
Diag) Services
Service
Execution
Routines
Auxiliary
Routines
Transport Protocols
ISO TP
(ISO 15765-2)
CAN Layer (C++ DLL)
NI-CAN 2.3.3 (or Higher)
© National Instruments Corporation 4-1 Automotive Diagnostic Command Set User Manual
VW TP 2.0
Chapter 4 Using the Automotive Diagnostic Command Set
The Automotive Diagnostic Command Set is structured into three layers of
functionality:
• The top layer implements three sets of diagnostic services for the
diagnostic protocols KWP2000, UDS (DiagOnCAN), and OBD
(On-Board Diagnostics).
• The second layer implements general routines involving opening and
closing diagnostic communication connections, connecting and
disconnecting to/from an ECU, and executing a diagnostic service on
byte level. The latter routine is the one the top layer uses heavily.
• The third layer implements the transport protocols needed for
diagnostic communication to an ECU. The second layer uses these
routines to communicate to an ECU.
All three top layers are fully implemented in LabVIEW.
The transport protocols then execute CAN Read/Write operations through
a specialized DLL for streamlining the CAN data flow, especially in higher
busload situations.
Automotive Diagnostic Command Set API Structure
The top two layer routines are available as API functions. Each diagnostic
service for KWP2000, UDS, and OBD is available as one routine. Also
available on the top level are auxiliary routines for converting scaled
physical data values to and from their binary representations used in the
diagnostic services.
On the second layer are more general routines for opening and closing
diagnostic communication channels and executing a diagnostic service.
Auxiliary routines create the diagnostic CAN identifiers from the logical
ECU address.
Automotive Diagnostic Command Set User Manual 4-2 ni.com
General Programming Model
Open Diagnostic
Chapter 4 Using the Automotive Diagnostic Command Set
VW TP?
No
Execute a
Diagnostic Service
VW TP?
No
No
Done?
Ye s
VW TP?
No
Close Diagnostic
Ye s
Ye s
Ye s
VWTP Connect
Periodically Execute
VWTP ConnectionTest
VWTP Disconnect
First, you must open a diagnostic communication link. This involves
initializing the CAN port and defining communication parameters such as
the baud rate and CAN identifiers on which the diagnostic communication
takes place. No actual communication to the ECU takes place at this stage.
For the VW TP 2.0, you then must establish a communication channel to
the ECU using the VWTP Connect routine. The communication channel
properties are negotiated between the host and ECU.
After these steps, the diagnostic communication is established, and you can
execute diagnostic services of your choice. Note that for the VW TP 2.0,
you must execute the VWTP ConnectionTest routine periodically (once per
second) to keep the communication channel open.
© National Instruments Corporation 4-3 Automotive Diagnostic Command Set User Manual
Chapter 4 Using the Automotive Diagnostic Command Set
When you finish your diagnostic services, you must close the diagnostic
communication link. This finally closes the CAN port. For the VW TP 2.0,
you should disconnect the communication channel established before
closing.
Available Diagnostic Services
The standards on automotive diagnostic define many different services for
many purposes. Unfortunately, most services leave a large amount of room
for manufacturer-specific variants and extensions. National Instruments
implemented the most used variants while trying not to overload them with
optional parameters.
However, all services are implemented in LabVIEW and open to the user.
If you are missing a service or variant of an existing service, you can easily
add or modify it on your own.
In the C API, you can also implement your own diagnostic services using
the ndDiagnosticService routine. However, the templates from the existing
services are not available.
Tweaking the Transport Protocol
A set of global constants controls transport protocol behavior. These
constants default to maximum performance. To check the properties of an
implementation of a transport protocol in an ECU, for example, you may
want to change the constants to nonstandard values using the Get/Set
Property routines.
The transport protocols also are fully implemented in LabVIEW and open
to the user. In LabVIEW, you can even modify the protocol behavior (for
example, you can send undefined responses to check the behavior of an
implementation).
However, be sure to save the original routine versions to restore the original
behavior.
In the C API, changing the global constants is the only way to modify the
transport protocol.
Automotive Diagnostic Command Set User Manual 4-4 ni.com
Automotive Diagnostic
Command Set API for LabVIEW
This chapter lists the LabVIEW VIs for the Automotive Diagnostic Command Set API and
describes the format, purpose, and parameters for each VI. The VIs are listed alphabetically
in four categories: general functions, KWP2000 services, UDS (DiagOnCAN) services, and
OBD (On-Board Diagnostics) services.
Section Headings
The following are section headings found in the Automotive Diagnostic Command Set API
for LabVIEW VIs.
Purpose
Each VI description briefly describes the VI purpose.
Format
The format section describes the VI format.
5
Input and Output
The input and output sections list the VI parameters.
Description
The description section gives details about the VI purpose and effect.
© National Instruments Corporation 5-1 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
List of VIs
The following table is an alphabetical list of the Automotive Diagnostic Command Set VIs.
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW
Function Purpose
ClearDiagnosticInformation.vi Executes the ClearDiagnosticInformation
service and clears selected Diagnostic
Trouble Codes (DTCs).
Close Diagnostic.vi Closes a diagnostic session.
ControlDTCSetting.vi Executes the ControlDTCSetting service and
modifies the generation behavior of selected
Diagnostic Trouble Codes (DTCs).
Convert from Phys.vi Converts a physical data value into a binary
representation using a type descriptor.
Convert to Phys.vi Converts a binary representation of a value
into its physical value using a type
descriptor.
Create Extended CAN IDs.vi Creates diagnostic CAN IDs according to
ISO 15765-2.
Diag Get Property.vi Gets a diagnostic global internal parameter.
Diag Set Property.vi Sets a diagnostic global internal parameter.
Diagnostic Service.vi Executes a generic diagnostic service. If a
special service is not available through the
KWP2000, UDS, or OBD service functions,
you can build it using this VI.
DisableNormalMessageTransmission.vi Executes the
DisableNormalMessageTransmission
service. The ECU no longer transmits its
regular communication messages (usually
CAN messages).
DTC to String.vi Returns a string representation (such as
P1234) for a 2-byte Diagnostic Trouble
Code (DTC).
ECUReset.vi Executes the ECUReset service and resets
the ECU.
Automotive Diagnostic Command Set User Manual 5-2 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW (Continued)
Function Purpose
EnableNormalMessageTransmission.vi Executes the
EnableNormalMessageTransmission
service. The ECU starts transmitting its
regular communication messages (usually
CAN messages).
InputOutputControlByLocalIdentifier.vi Executes the
InputOutputControlByLocalIdentifier
service. Modifies the ECU I/O port behavior.
OBD Clear Emission Related Diagnostic
Information.vi
Executes the OBD Clear Emission Related
Diagnostic Information service. Clears
emission-related Diagnostic Trouble Codes
(DTCs) in the ECU.
OBD Open.vi Opens an OBD-II diagnostic session on a
CAN port.
OBD Request Control Of On-Board Device.vi Executes the OBD Request Control Of
On-Board Device service. Use this VI to
modify ECU I/O port behavior.
OBD Request Current Powertrain Diagnostic
Data.vi
Executes the OBD Request Current
Powertrain Diagnostic Data service. Reads a
data record from the ECU.
OBD Request Emission Related DTCs.vi Executes the OBD Request Emission
Related DTCs service. Reads all
emission-related Diagnostic Trouble Codes
(DTCs).
OBD Request Emission Related DTCs During
Current Drive Cycle.vi
Executes the OBD Request Emission
Related DTCs During Current Drive Cycle
service. Reads the emission-related
Diagnostic Trouble Codes (DTCs) that
occurred during the current (or last
completed) drive cycle.
OBD Request On-Board Monitoring Test
Results.vi
Executes the OBD Request On-Board
Monitoring Test Results service. Reads a test
data record from the ECU.
© National Instruments Corporation 5-3 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW (Continued)
Function Purpose
OBD Request Powertrain Freeze Frame Data.vi Executes the OBD Request Powertrain
Freeze Frame Data service. Reads a data
record from the ECU that has been stored
while a Diagnostic Trouble Code occurred.
OBD Request Supported PIDs.vi Executes the OBD Request Current
Powertrain Diagnostic Data service to
retrieve the valid PID values for this service.
OBD Request Vehicle Information.vi Executes the OBD Request Vehicle
Information service. Reads a set of
information data from the ECU.
Open Diagnostic.vi Opens a diagnostic session on a CAN port.
Communication to the ECU is not yet
started.
ReadDataByLocalIdentifier.vi Executes the ReadDataByLocalIdentifier
service. Reads a data record from the ECU.
ReadDTCByStatus.vi Executes the
ReadDiagnosticTroubleCodesByStatus
service. Reads selected Diagnostic Trouble
Codes (DTCs).
ReadECUIdentification.vi Executes the ReadECUIdentification
service. Returns ECU identification data
from the ECU.
ReadMemoryByAddress.vi Executes the ReadMemoryByAddress
service. Reads data from the ECU memory.
ReadStatusOfDTC.vi Executes the
ReadStatusOfDiagnosticTroubleCodes
service. Reads selected Diagnostic Trouble
Codes (DTCs).
RequestRoutineResultsByLocalIdentifier.vi Executes the
RequestRoutineResultsByLocalIdentifier
service. Returns results from a routine on the
ECU.
RequestSeed.vi Executes the SecurityAccess service to
retrieve a seed from the ECU.
Automotive Diagnostic Command Set User Manual 5-4 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW (Continued)
Function Purpose
SendKey.vi Executes the SecurityAccess service to send
a key to the ECU.
StartDiagnosticSession.vi Executes the StartDiagnosticSession service.
Sets up the ECU in a specific diagnostic
mode.
StartRoutineByLocalIdentifier.vi Executes the StartRoutineByLocalIdentifier
service. Executes a routine on the ECU.
StopDiagnosticSession.vi Executes the StopDiagnosticSession service.
Brings the ECU back in normal mode.
StopRoutineByLocalIdentifier.vi Executes the StopRoutineByLocalIdentifier
service. Stops a routine on the ECU.
TesterPresent.vi Executes the TesterPresent service. Keeps
the ECU in diagnostic mode.
UDS ClearDiagnosticInformation.vi Executes the UDS
ClearDiagnosticInformation service. Clears
selected Diagnostic Trouble Codes (DTCs).
UDS CommunicationControl.vi Executes the UDS CommunicationControl
service. Use this VI to switch on or off
transmission and/or reception of the normal
communication messages (usually CAN
messages).
UDS ControlDTCSetting.vi Executes the UDS ControlDTCSetting
service. Modifies Diagnostic Trouble Code
(DTC) generation behavior.
UDS DiagnosticSessionControl.vi Executes the UDS
DiagnosticSessionControl service. Sets up
the ECU in a specific diagnostic mode.
UDS ECUReset.vi Executes the UDS ECUReset service. Resets
the ECU.
UDS InputOutputControlByIdentifier.vi Executes the UDS
InputOutputControlByIdentifier service.
Use this VI to modify ECU I/O port
behavior.
© National Instruments Corporation 5-5 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW (Continued)
Function Purpose
UDS ReadDataByIdentifier.vi Executes the UDS ReadDataByIdentifier
service. Reads a data record from the ECU.
UDS ReadMemoryByAddress.vi Executes the UDS ReadMemoryByAddress
service. Reads data from the ECU memory.
UDS ReportDTCBySeverityMaskRecord.vi Executes the
ReportDTCBySeverityMaskRecord
subfunction of the UDS
ReadDiagnosticTroubleCodeInformation
service. Reads selected Diagnostic Trouble
Codes (DTCs).
UDS ReportDTCByStatusMask.vi Executes the ReportDTCByStatusMask
subfunction of the UDS
ReadDiagnosticTroubleCodeInformation
service. Reads selected Diagnostic Trouble
Codes (DTCs).
UDS ReportSeverityInformationOfDTC.vi Executes the
ReportSeverityInformationOfDTC
subfunction of the UDS
ReadDiagnosticTroubleCodeInformation
service. Reads selected Diagnostic Trouble
Codes (DTCs).
UDS ReportSupportedDTCs.vi Executes the ReportSupportedDTCs
subfunction of the UDS
ReadDiagnosticTroubleCodeInformation
service. Reads all supported Diagnostic
Trouble Codes (DTCs).
UDS RequestSeed.vi Executes the UDS SecurityAccess service to
retrieve a seed from the ECU.
UDS RoutineControl.vi Executes the UDS RoutineControl service.
Executes a routine on the ECU.
UDS SendKey.vi Executes the SecurityAccess service to send
a key to the ECU.
UDS TesterPresent.vi Executes the UDS TesterPresent service.
Keeps the ECU in diagnostic mode.
Automotive Diagnostic Command Set User Manual 5-6 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Table 5-1. Automotive Diagnostic Command Set API VIs for LabVIEW (Continued)
Function Purpose
UDS WriteDataByIdentifier.vi Executes the UDS WriteDataByIdentifier
service. Writes a data record to the ECU.
UDS WriteMemoryByAddress.vi Executes the UDS WriteMemoryByAddress
service. Writes data to the ECU memory.
VWTP Connect.vi Establishes a connection channel to an ECU
using the VW TP 2.0.
VWTP Connection Test.vi Maintains a connection channel to an ECU
using the VW TP 2.0.
VWTP Disconnect.vi Terminates a connection channel to an ECU
using the VW TP 2.0.
WriteDataByLocalIdentifier.vi Executes the WriteDataByLocalIdentifier
service. Writes a data record to the ECU.
WriteMemoryByAddress.vi Executes the WriteMemoryByAddress
service. Writes data to the ECU memory.
© National Instruments Corporation 5-7 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
General Functions
Close Diagnostic.vi
Purpose
Closes a diagnostic session.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-8 ni.com
Output
Description
The diagnostic session specified by diag ref in is closed, and you can no longer use it for
communication to an ECU. Note that this command does not communicate the closing to the
ECU before terminating; if this is necessary, you must manually do so (for example, by
calling StopDiagnosticSession.vi) before calling Close Diagnostic.vi.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-9 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Convert from Phys.vi
Purpose
Converts a physical data value into a binary representation using a type descriptor.
Format
Input
type descriptor is a cluster that specifies the conversion of the physical
value to its binary representation:
Start Byte gives the start byte of the binary representation. For
Convert from Phys.vi, this value is ignored and always assumed
to be 0.
Byte Length is the binary representation byte length.
Byte Order is the byte ordering of the data in the binary
representation:
0: MSB_FIRST (Motorola)
1: LSB_FIRST (Intel)
Data Type is the binary representation format:
0: Unsigned. Only byte lengths of 1–4 are allowed.
1: Signed. Only byte lengths of 1–4 are allowed.
2: Float. Only byte lengths of 4 or 8 are allowed.
Scale Factor defines the physical value scaling:
Phys = (Scale Factor) * (binary representation) + (Scale Offset)
Scale Offset (refer to Scale Factor)
value is the physical value to be converted.
Automotive Diagnostic Command Set User Manual 5-10 ni.com
Output
Description
Data input to diagnostic services (for example, WriteDataByLocalIdentifier.vi) is usually a
byte stream of binary data. If you have a description of the data input (for example, byte 3 and
4 are engine RPM scaled as .25 *
from Phys.vi to convert the physical value to the byte stream by filling an appropriate type
descriptor cluster.
Convert from Phys.vi converts only the portion specified by one type descriptor to a binary
representation. If your data input consists of several values, you can use Convert from
Phys.vi multiple times and concatenate their outputs.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
data out is the binary representation of the physical value. If you build a
record of multiple values, you can concatenate the outputs of several
instances of Convert from Phys.vi.
×
RPM in Motorola representation), you can use Convert
© National Instruments Corporation 5-11 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Convert to Phys.vi
Purpose
Converts a binary representation of a value into its physical value using a type descriptor.
Format
Input
type descriptor is a cluster that specifies the conversion of the binary
representation to its physical value:
Start Byte gives the binary representation start byte in the data in
record.
Byte Length is the binary representation byte length.
Output
Byte Order is the byte ordering of the data in the binary
representation:
0: MSB_FIRST (Motorola)
1: LSB_FIRST (Intel)
Data Type is the binary representation format:
0: Unsigned. Only byte lengths of 1–4 are allowed.
1: Signed. Only byte lengths of 1–4 are allowed.
2: Float. Only byte lengths of 4 or 8 are allowed.
Scale Factor defines the physical value scaling:
Phys = (Scale Factor) * (binary representation) + (Scale Offset)
Scale Offset (refer to Scale Factor)
data in is the data record from which physical values are to be extracted.
value is the physical value extracted from the record.
Automotive Diagnostic Command Set User Manual 5-12 ni.com
Description
Data output from diagnostic services (for example, ReadDataByLocalIdentifier.vi) is
usually a byte stream of binary data. If you have a description of the data output (for example,
byte 3 and 4 are engine RPM scaled as .25 *
use Convert to Phys.vi to extract the physical value from the byte stream by filling an
appropriate type descriptor cluster.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
×
RPM in Motorola representation), you can
© National Instruments Corporation 5-13 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Create Extended CAN IDs.vi
Purpose
Creates diagnostic CAN IDs according to ISO 15765-2.
Format
Input
addressing mode specifies whether the ECU is physically or functionally
addressed.
transport protocol specifies whether normal or mixed mode addressing is
used.
source address is the logical address of the host (diagnostic tester).
target address is the ECU logical address.
Output
transmit ID is the generated CAN identifier for sending diagnostic request
messages from the host to the ECU.
receive ID is the generated CAN identifier for sending diagnostic response
messages from the ECU to the host.
Description
ISO 15765-2 specifies a method (extended/29 bit) of creating CAN identifiers for diagnostic
applications given the addressing mode (physical/functional), the transport protocol
(normal/mixed), and the 8-bit source and target addresses. This VI implements the
construction of these CAN identifiers. You can use them directly in Open Diagnostic.vi.
Automotive Diagnostic Command Set User Manual 5-14 ni.com
Diag Get Property.vi
Purpose
Gets a diagnostic global internal parameter.
Format
Input
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
property ID defines the parameter whose value is to be retrieved. You can
create the values using an Enum control.
0 Timeout Diag Command is the timeout in milliseconds the master
waits for the response to a diagnostic request message. The default is
1000 ms.
1 Timeout FC (Bs) is the timeout in milliseconds the master waits for
a Flow Control frame after sending a First Frame or the last
Consecutive Frame of a block. The default is 250 ms.
2 Timeout CF (Cr) is the timeout in milliseconds the master waits for
a Consecutive Frame in a multiframe response. The default is
250 ms.
3 Receive Block Size (BS) is the number of Consecutive Frames the
slave sends in one block before waiting for the next Flow Control
frame. A value of 0 (default) means all Consecutive Frames are sent
in one run without interruption.
4 Wait Time CF (STmin) defines the minimum time for the slave to
wait between sending two Consecutive Frames of a block. Values
from 0 to 127 are wait times in milliseconds. Values 241 to 249
(Hex F1 to F9) mean wait times of 100 µs to 900 µs, respectively. All
other values are reserved. The default is 5 ms.
5 Max Wait Frames (N_WFTmax) is the maximum number of WAIT
frames the master accepts before terminating the connection. The
default is 10.
© National Instruments Corporation 5-15 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
6 Wait Frames to Send (N_WAIT) is the number of WAIT frames the
master sends every time before a CTS frame is sent. If this value is
set to a negative number (for example, 0xFFFFFFFF = –1), the
master sends an OVERLOAD frame instead of a WAIT, and
reception is aborted. The default is 0 for maximum speed.
7 Time between Waits (T_W) is the number of milliseconds the
master waits after sending a WAIT frame. The default is 25.
8 Fill CAN Frames returns whether a CAN frame is transmitted with
8 bytes or less.
0: Short CAN frames are sent with DLC < 8 (default).
1: Short CAN frames are filled to 8 bytes with Fill Byte (necessary
for OBD, for example).
9 Fill Byte returns the CAN frame content if filled with defined data or
random data bytes.
0–255: Byte is used optionally to fill short CAN frames.
256: Short CAN frames are filled optionally with random bytes.
10 Invalid Response as Error returns how the toolkit handles an
invalid ECU response.
0: Invalid response is indicated by success? = FALSE only (default).
1: Invalid response is returned as an error in addition.
Output
property value is the requested property value.
Description
Use this VI to request several internal diagnostic parameters, such as timeouts for the
transport protocol. Use Diag Set Property.vi to modify them.
Automotive Diagnostic Command Set User Manual 5-16 ni.com
Diag Set Property.vi
Purpose
Sets a diagnostic global internal parameter.
Format
Input
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
property ID defines the parameter whose value is to be retrieved. You can
create the values using an Enum control.
0 Timeout Diag Command is the timeout in milliseconds the master
waits for the response to a diagnostic request message. The default is
1000 ms.
1 Timeout FC (Bs) is the timeout in milliseconds the master waits for
a Flow Control frame after sending a First Frame or the last
Consecutive Frame of a block. The default is 250 ms.
2 Timeout CF (Cr) is the timeout in milliseconds the master waits for
a Consecutive Frame in a multiframe response. The default is
250 ms.
3 Receive Block Size (BS) is the number of Consecutive Frames the
slave sends in one block before waiting for the next Flow Control
frame. A value of 0 (default) means all Consecutive Frames are sent
in one run without interruption.
4 Wait Time CF (STmin) defines the minimum time for the slave to
wait between sending two Consecutive Frames of a block. Values
from 0 to 127 are wait times in milliseconds. Values 241 to 249
(Hex F1 to F9) mean wait times of 100 µs to 900 µs, respectively. All
other values are reserved. The default is 5 ms.
5 Max Wait Frames (N_WFTmax) is the maximum number of WAIT
frames the master accepts before terminating the connection. The
default is 10.
© National Instruments Corporation 5-17 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
6 Wait Frames to Send (N_WAIT) is the number of WAIT frames the
master sends every time before a CTS frame is sent. If this value is
set to a negative number (for example, 0xFFFFFFFF = –1), the
master sends an OVERLOAD frame instead of a WAIT, and
reception is aborted. The default is 0 for maximum speed.
7 Time between Waits (T_W) is the number of milliseconds the
master waits after sending a WAIT frame. The default is 25.
8 Fill CAN Frames specifies whether a CAN frame is transmitted with
8 bytes or less.
0: Short CAN frames are sent with DLC < 8 (default).
1: Short CAN frames are filled to 8 bytes with Fill Byte (necessary
for OBD, for example).
9 Fill Byte specifies the CAN frame content, filled with defined data or
random data.
0–255: Byte is used optionally to fill short CAN frames.
256: Short CAN frames are filled optionally with random bytes.
10 Invalid Response as Error specifies how the toolkit handles an
invalid ECU response.
0: Invalid response is indicated by success? = FALSE only (default).
1: Invalid response is returned as an error in addition.
property value is the value of the property to be set.
Output
None.
Description
Use this VI to set several internal diagnostic parameters such as timeouts for the transport
protocol. Use Diag Get Property.vi to read them out.
Automotive Diagnostic Command Set User Manual 5-18 ni.com
Diagnostic Service.vi
Purpose
Executes a generic diagnostic service. If a special service is not available through the
KWP2000, UDS, or OBD service functions, you can build it using this VI.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
require response? indicates whether a diagnostic service expects a
response (TRUE) or not (FALSE). In the latter case, error code is returned
as 0, and data out as an empty array.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
data in defines the diagnostic service request message sent to the ECU as
a stream of bytes.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-19 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
error code is the error code sent with a negative response message. In
addition, the error cluster indicates an error and gives a more detailed
description. If no negative response message occurred, 0 is returned.
data out returns the diagnostic service response message (positive or
negative) the ECU sends as a stream of bytes.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
Diagnostic Service.vi is a generic routine to execute any diagnostic service. The request and
response messages are fed unmodified to the data in input and retrieved from the data out
output, respectively. No interpretation of the contents is done, with one exception: the error
number is retrieved from a negative response, if one occurs. In this case, an error also is
communicated through the error out cluster.
All specialized diagnostic services call Diagnostic Service.vi internally.
Automotive Diagnostic Command Set User Manual 5-20 ni.com
DTC to String.vi
Purpose
Returns a string representation (such as P1234) for a 2-byte Diagnostic Trouble Code (DTC).
Format
Input
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
DTC (num) is the DTC number as returned in the clusters of
ReadDTCByStatus.vi, ReadStatusOfDTC.vi,
UDS ReportDTCBySeverityMaskRecord.vi,
UDS ReportDTCByStatusMask.vi,
UDS ReportSeverityInformationOfDTC.vi,
UDS ReportSupportedDTCs.vi, OBD Request Emission Related
DTCs.vi, or OBD Request Emission Related DTCs During Current
Drive Cycle.vi.
Note This VI converts only 2-byte DTCs. If you feed in larger numbers, the VI returns
garbage.
Output
DTC (string) is the DTC string representation.
Description
The SAE J2012 standard specifies a naming scheme for 2-byte DTCs consisting of one letter
and four digits. Use DTC to String.vi to convert a DTC numerical representation to this
name.
© National Instruments Corporation 5-21 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
OBD Open.vi
Purpose
Opens an OBD-II diagnostic session on a CAN port.
Format
Input
CAN interface specifies the CAN interface on which the diagnostic
communication should take place. The values are CAN0, CAN1, and so on.
baudrate is the diagnostic communication baud rate.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster
to a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-22 ni.com
Output
Description
Use this VI to open a diagnostic communication channel to an ECU for OBD-II. The CAN
port specified as input is initialized, and a handle to it is stored (among other internal data) in
the diag ref out cluster, which serves as reference for further diagnostic functions.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a cluster containing all necessary diagnostic session
information. Wire this cluster as a handle to all subsequent diagnostic
VIs and close it using Close Diagnostic.vi.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster
to a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
First, communication to the ECU is tried on the default 11-bit OBD CAN identifiers; if that
fails, the default 29-bit OBD CAN identifiers are tried. If that also fails, the VI returns an
error.
You can overwrite the default OBD CAN identifiers optionally with any other identifiers.
In general, it is not necessary to manipulate the diag ref out cluster contents.
© National Instruments Corporation 5-23 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Open Diagnostic.vi
Purpose
Opens a diagnostic session on a CAN port. Communication to the ECU is not yet started.
Format
Input
CAN interface specifies the CAN interface on which the diagnostic
communication should take place. The values are CAN0, CAN1, and so on.
baudrate is the diagnostic communication baud rate.
transport protocol specifies the transport protocol for transferring the
diagnostic service messages over the CAN network. The following values
are valid and can be obtained through an enum control:
0 ISO TP—Normal Mode: The ISO TP as specified in ISO 15765-2
is used; all eight data bytes of the CAN messages are used for data
transfer.
1 ISO TP—Mixed Mode: The ISO TP as specified in ISO 15765-2 is
used; the first data byte is used as address extension.
2 VW TP 2.0
transmit ID is the CAN identifier for sending diagnostic request messages
from the host to the ECU. To specify an extended (29-bit) ID, OR the value
with 0x20000000.
receive ID is the CAN identifier or sending diagnostic response messages
from the ECU to the host. To specify an extended (29-bit) ID, OR the value
with 0x20000000.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
Automotive Diagnostic Command Set User Manual 5-24 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
diag ref out is a cluster containing all necessary diagnostic session
information. Wire this cluster as a handle to all subsequent diagnostic VIs
and close it using Close Diagnostic.vi.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
Open Diagnostic.vi opens a diagnostic communication channel to an ECU. The CAN port
specified as input is initialized, and a handle to it is stored (among other internal data) in the
diag ref out cluster, which serves as reference for further diagnostic functions.
Note No communication to the ECU takes place at this point. To open a diagnostic session
on the ECU, call StartDiagnosticSession.vi or UDS DiagnosticSessionControl.vi.
In general, it is not necessary to manipulate the diag ref out cluster contents, with one notable
exception: If you use the ISO TP—Mixed Mode transport protocol, you must store the
address extensions for transmit and receive in the appropriate cluster members.
© National Instruments Corporation 5-25 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
VWTP Connect.vi
Purpose
Establishes a connection channel to an ECU using the VW TP 2.0.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
channel ID defines the CAN identifier on which the ECU responds for this
connection. The ECU defines the ID on which the host transmits.
application type specifies the type of communication that takes place on
the communication channel. For diagnostic applications, specify
KWP2000 (1). The other values are for manufacturer-specific purposes.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-26 ni.com
Output
Description
For the VW TP 2.0, you must establish a connection to the ECU before any diagnostic
communication can occur. This VI sets up a unique communication channel to an ECU for
subsequent diagnostic service requests.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Note You must maintain the communication link you created by periodically (at least once
a second) calling VWTP Connection Test.vi.
There is no equivalent for the ISO TP (ISO 15765-2), as the ISO TP does not use a special
communication link.
© National Instruments Corporation 5-27 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
VWTP Connection Test.vi
Purpose
Maintains a connection channel to an ECU using the VW TP 2.0.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
Automotive Diagnostic Command Set User Manual 5-28 ni.com
Description
For the VW TP 2.0, you must periodically maintain the connection link to the ECU so that
the ECU does not terminate it.
This VI sends a Connection Test message to the ECU and evaluates its response, performing
the steps necessary to maintain the connection.
There is no equivalent for the ISO TP (ISO 15765-2), as the ISO TP does not use a special
communication link.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-29 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
VWTP Disconnect.vi
Purpose
Terminates a connection channel to an ECU using the VW TP 2.0.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
Automotive Diagnostic Command Set User Manual 5-30 ni.com
Description
For the VW TP 2.0, you must disconnect the connection link to the ECU to properly terminate
communication to the ECU. This VI sends the proper disconnect messages and unlinks the
communication.
You can create a new connection to the same ECU using VWTP Connect.vi again.
There is no equivalent for the ISO TP (ISO 15765-2), as the ISO TP does not use a special
communication link.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-31 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
KWP2000 Services
ClearDiagnosticInformation.vi
Purpose
Executes the ClearDiagnosticInformation service and clears selected Diagnostic Trouble
Codes (DTCs).
Format
Input
DTC descriptor is a cluster that describes the DTC records the ECU
delivers:
DTC Byte Length indicates the number of bytes the ECU sends
for each DTC. The default is 2.
Status Byte Length indicates the number of bytes the ECU sends
for each DTC’s status. The default is 1.
Add Data Byte Length indicates the number of bytes the ECU
sends for each DTC’s additional data. Usually, there is no
additional data, so the default is 0.
Byte Order indicates the byte ordering for multibyte items:
0: MSB_FIRST (Motorola) (default)
1: LSB_FIRST (Intel)
The DTC descriptor is given here as a parameter basically to convert the
group of DTC parameter to a binary representation according to DTC
Byte Length and Byte Order.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
Automotive Diagnostic Command Set User Manual 5-32 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
group of DTC specifies the group of Diagnostic Trouble Codes to be
cleared. The following values have a special meaning, and you can specify
them through a ring control:
0x0000 All powertrain DTCs
0x4000 All chassis DTCs
0x8000 All body DTCs
0xC000 All network-related DTCs
0xFF00 All DTCs
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
© National Instruments Corporation 5-33 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI clears the diagnostic information on the ECU memory. If the group of DTC
parameter is present, the ECU is requested to clear all memory including the DTCs.
For further details about this service, refer to the ISO 14230-3 standard.
Automotive Diagnostic Command Set User Manual 5-34 ni.com
ControlDTCSetting.vi
Purpose
Executes the ControlDTCSetting service and modifies the generation behavior of selected
Diagnostic Trouble Codes (DTCs).
Format
Input
DTC descriptor is a cluster that describes the DTC records the ECU
delivers:
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
DTC Byte Length indicates the number of bytes the ECU sends
for each DTC. The default is 2.
Status Byte Length indicates the number of bytes the ECU sends
for each DTC’s status. The default is 1.
Add Data Byte Length indicates the number of bytes the ECU
sends for each DTC’s additional data. Usually, there is no
additional data, so the default is 0.
Byte Order indicates the byte ordering for multibyte items:
0: MSB_FIRST (Motorola) (default)
1: LSB_FIRST (Intel)
The DTC descriptor is given here as a parameter basically to convert the
group of DTC parameter to a binary representation according to DTC
Byte Length and Byte Order.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
data in specifies application-specific data that control DTC generation.
© National Instruments Corporation 5-35 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
group of DTC specifies the group of Diagnostic Trouble Codes to be
controlled. The following values have a special meaning, and you can
specify them through a ring control:
0x0000 All powertrain DTCs
0x4000 All chassis DTCs
0x8000 All body DTCs
0xC000 All network-related DTCs
0xFF00 All DTCs
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
Automotive Diagnostic Command Set User Manual 5-36 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-37 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
DisableNormalMessageTransmission.vi
Purpose
Executes the DisableNormalMessageTransmission service. The ECU no longer transmits its
regular communication messages (usually CAN messages).
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
response required? indicates whether the ECU answers this service
(TRUE, default) or not (FALSE). In the latter case, success? is TRUE.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-38 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-39 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
ECUReset.vi
Purpose
Executes the ECUReset service. Resets the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
mode indicates the reset mode:
Hex Description
01 PowerOn
This value identifies the PowerOn ResetMode, a simulated
PowerOn reset that most ECUs perform after the ignition
OFF/ON cycle. When the ECU performs the reset, the client
(tester) re-establishes communication.
02 PowerOnWhileMaintainingCommunication
This value identifies the PowerOn ResetMode, a simulated
PowerOn reset that most ECUs perform after the ignition
OFF/ON cycle. When the ECU performs the reset, the server
(ECU) maintains communication with the client (tester).
03–7F Reserved
80–FF ManufacturerSpecific
This range of values is reserved for vehicle manufacturer-specific
use.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
Automotive Diagnostic Command Set User Manual 5-40 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI requests the ECU to perform an ECU reset effectively based on the mode parameter
value content. The vehicle manufacturer determines when the positive response message is
sent.
© National Instruments Corporation 5-41 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
EnableNormalMessageTransmission.vi
Purpose
Executes the EnableNormalMessageTransmission service. The ECU starts transmitting its
regular communication messages (usually CAN messages).
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
response required? indicates whether the ECU answers this service
(TRUE, default) or not (FALSE). In the latter case, success? is TRUE.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-42 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-43 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
InputOutputControlByLocalIdentifier.vi
Purpose
Executes the InputOutputControlByLocalIdentifier service. Modifies ECU I/O port behavior.
Format
Input
data in defines application-specific data for this service.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the I/O to be manipulated. The values
are application specific.
mode defines the type of I/O control. The values are application specific.
The usual values are:
0: ReturnControlToECU
1: ReportCurrentState
4: ResetToDefault
5: FreezeCurrentState
7: ShortTermAdjustment
8: LongTermAdjustment
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
Automotive Diagnostic Command Set User Manual 5-44 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns application-specific data for this service.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI substitutes a value for an input signal or internal ECU function. It also controls an
output (actuator) of an electronic system referenced by the local ID parameter.
For further details about this service, refer to the ISO 14230-3 standard.
© National Instruments Corporation 5-45 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
ReadDataByLocalIdentifier.vi
Purpose
Executes the ReadDataByLocalIdentifier service. Reads a data record from the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the data to be read. The values are
application specific.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-46 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns the data record from the ECU. If you know the record data
description, you can interpret this record using Convert from Phys.vi.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI requests data record values from the ECU identified by the local ID parameter.
For further details about this service, refer to the ISO 14230-3 standard.
© National Instruments Corporation 5-47 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
ReadDTCByStatus.vi
Purpose
Executes the ReadDiagnosticTroubleCodesByStatus service. Reads selected Diagnostic
Trouble Codes (DTCs).
Format
Input
DTC descriptor is a cluster that describes the DTC records the ECU
delivers:
DTC Byte Length indicates the number of bytes the ECU sends
for each DTC. The default is 2.
Status Byte Length indicates the number of bytes the ECU sends
for each DTC’s status. The default is 1.
Add Data Byte Length indicates the number of bytes the ECU
sends for each DTC’s additional data. Usually, there is no
additional data, so the default is 0.
Byte Order indicates the byte ordering for multibyte items:
0: MSB_FIRST (Motorola) (default)
1: LSB_FIRST (Intel)
This VI interprets the response byte stream according to this description
and returns the resulting DTC records in the DTCs cluster array.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
Automotive Diagnostic Command Set User Manual 5-48 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
mode defines the type of DTCs to be read. The values are application
specific. The usual values are:
2: AllIdentified
3: AllSupported
group of DTC specifies the group of Diagnostic Trouble Codes to be read.
The following values have a special meaning, and you can specify them
through a ring control:
0x0000 All powertrain DTCs
0x4000 All chassis DTCs
0x8000 All body DTCs
0xC000 All network-related DTCs
0xFF00 All DTCs
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
Output
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
DTCs returns the resulting DTCs as an array of clusters:
DTC is the resulting Diagnostic Trouble Code. For the default
2-byte DTCs, you can use DTC to String.vi to convert this to
readable format as defined by SAE J2012.
© National Instruments Corporation 5-49 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Status is the DTC status. Usually, this is a bit field with the
following meaning:
Bit Meaning
0 testFailed
1 testFailedThisMonitoringCycle
2 pendingDTC
3 confirmedDTC
4 testNotCompletedSinceLastClear
5 testFailedSinceLastClear
6 testNotCompletedThisMonitoringCycle
7 warningIndicatorRequested
Add Data contains optional additional data for this DTC. Usually,
this does not contain valid information (refer to DTC descriptor)
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI reads DTCs by status from the ECU memory. If you use the optional group of DTC
parameter, the ECU reports DTCs only with status information based on the functional group
selected by group of DTC.
For further details about this service, refer to the ISO 14230-3 standard.
Automotive Diagnostic Command Set User Manual 5-50 ni.com
ReadECUIdentification.vi
Purpose
Executes the ReadECUIdentification service. Returns ECU identification data.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
mode indicates the type of identification information to be returned. The
values are application specific.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns the ECU identification data.
© National Instruments Corporation 5-51 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI requests identification data from the ECU. The mode parameter identifies the type of
identification data requested. The ECU returns identification data that the data out parameter
can access. The data out format and definition are vehicle manufacturer specific.
For further details about this service, refer to the ISO 14230-3 standard.
Automotive Diagnostic Command Set User Manual 5-52 ni.com
ReadMemoryByAddress.vi
Purpose
Executes the ReadMemoryByAddress service. Reads data from the ECU memory.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
address defines the memory address from which data are to be read. Notice
that only three bytes are sent to the ECU, so the address must be in the range
0–FFFFFF (hex).
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
size defines the length of the memory block to be read.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-53 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
Data out returns the memory data from the ECU.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
Description
This VI requests memory data from the ECU identified by the address and size parameters.
The data out format and definition are vehicle manufacturer specific. data out includes
analog input and output signals, digital input and output signals, internal data, and system
status information if the ECU supports them.
For further details about this service, refer to the ISO 14230-3 standard.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-54 ni.com
ReadStatusOfDTC.vi
Purpose
Executes the ReadStatusOfDiagnosticTroubleCodes service. Reads selected Diagnostic
Trouble Codes (DTCs).
Format
Input
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
DTC descriptor is a cluster that describes the DTC records the ECU
delivers:
DTC Byte Length indicates the number of bytes the ECU sends
for each DTC. The default is 2.
Status Byte Length indicates the number of bytes the ECU sends
for each DTC’s status. The default is 1.
Add Data Byte Length indicates the number of bytes the ECU
sends for each DTC’s additional data. Usually, there is no
additional data, so the default is 0.
Byte Order indicates the byte ordering for multibyte items:
0: MSB_FIRST (Motorola) (default)
1: LSB_FIRST (Intel)
This VI interprets the response byte stream according to this description
and returns the resulting DTC records in the DTCs cluster array.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
© National Instruments Corporation 5-55 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
group of DTC specifies the group of Diagnostic Trouble Codes to be read.
The following values have a special meaning, and you can specify them
through a ring control:
0x0000 All powertrain DTCs
0x4000 All chassis DTCs
0x8000 All body DTCs
0xC000 All network-related DTCs
0xFF00 All DTCs
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
DTCs returns the resulting DTCs as an array of clusters:
DTC is the resulting Diagnostic Trouble Code. For the default
2-byte DTCs, you can use DTC to String.vi to convert this to
readable format as defined by SAE J2012.
Automotive Diagnostic Command Set User Manual 5-56 ni.com
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
Status is the DTC status. Usually, this is a bit field with the
following meaning:
Bit Meaning
0 testFailed
1 testFailedThisMonitoringCycle
2 pendingDTC
3 confirmedDTC
4 testNotCompletedSinceLastClear
5 testFailedSinceLastClear
6 testNotCompletedThisMonitoringCycle
7 warningIndicatorRequested
Add Data contains optional additional data for this DTC. Usually,
this does not contain valid information (refer to DTC descriptor)
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI reads diagnostic trouble codes from the ECU memory. If you use the optional group
of DTC parameter, the ECU reports DTCs based only on the functional group selected by
group of DTC.
For further details about this service, refer to the ISO 14230-3 standard.
© National Instruments Corporation 5-57 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
RequestRoutineResultsByLocalIdentifier.vi
Purpose
Executes the RequestRoutineResultsByLocalIdentifier service. Returns results from a routine
on the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the routine from which this VI
retrieves results. The values are application specific.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-58 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns application-specific output parameters from the routine.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
Description
This VI requests results (for example, exit status information) referenced by local ID and
generated by the routine executed in the ECU memory.
For further details about this service, refer to the ISO 14230-3 standard.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-59 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
RequestSeed.vi
Purpose
Executes the SecurityAccess service to retrieve a seed from the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
access mode indicates the security level to be granted. The values are
application specific. This is an odd number, usually 1.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-60 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
seed out returns the seed from the ECU.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
Description
The usual procedure for getting a security access to the ECU is as follows:
1. Request a seed from the ECU using RequestSeed.vi with access mode = n.
2. From the seed, compute a key for the ECU on the host.
3. Send the key to the ECU using SendKey.vi with access mode = n + 1.
4. The security access is granted if the ECU validates the key sent. Otherwise, an error is
source identifies the VI where the error occurred.
returned.
© National Instruments Corporation 5-61 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
SendKey.vi
Purpose
Executes the SecurityAccess service to send a key to the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
access mode indicates the security level to be granted. The values are
application specific. This is an even number, usually 2.
key in defines the key data to be sent to the ECU.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-62 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
The usual procedure for getting a security access to the ECU is as follows:
1. Request a seed from the ECU using RequestSeed.vi with access mode = n.
2. From the seed, compute a key for the ECU on the host.
3. Send the key to the ECU using SendKey.vi with access mode = n + 1.
4. The security access is granted if the ECU validates the key sent. Otherwise, an error is
returned.
© National Instruments Corporation 5-63 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
StartDiagnosticSession.vi
Purpose
Executes the StartDiagnosticSession service. Sets up the ECU in a specific diagnostic mode.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
mode indicates the diagnostic mode into which the ECU is brought. The
values are application specific.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-64 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
This VI enables different diagnostic modes in the ECU. The possible diagnostic modes are
not defined in the ISO 14230 standard and are application specific. A diagnostic session starts
only if communication with the ECU is established. For more details about starting
communication, refer to the ISO 14230-2 standard. If no diagnostic session has been
requested after Open Diagnostic.vi, a default session is automatically enabled in the ECU.
The default session supports at least the following services:
• The StopCommunication service (refer to Close Diagnostic.vi and the ISO 14230-2
standard).
• The TesterPresent service (refer to TesterPresent.vi and the ISO 14230-3 standard).
© National Instruments Corporation 5-65 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
StartRoutineByLocalIdentifier.vi
Purpose
Executes the StartRoutineByLocalIdentifier service. Executes a routine on the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the routine to be started. The values
are application specific.
data in defines application-specific input parameters for the routine.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-66 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns application-specific output parameters from the routine.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
Description
This VI starts a routine in the ECU memory. The routine in the ECU starts after the positive
response message is sent. The routine stops until StopRoutineByLocalIdentifier.vi is
issued. The routines could be either tests run instead of normal operating code or routines
enabled and executed with the normal operating code running. In the first case, you may need
to switch the ECU to a specific diagnostic mode using StartDiagnosticSession.vi or unlock
the ECU using the SecurityAccess service prior to using StartRoutineByLocalIdentifier.vi.
For further details about this service, refer to the ISO 14230-3 standard.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-67 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
StopDiagnosticSession.vi
Purpose
Executes the StopDiagnosticSession service. Returns the ECU to normal mode.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Output
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
Automotive Diagnostic Command Set User Manual 5-68 ni.com
Description
This VI disables the current ECU diagnostic mode. A diagnostic session stops only if
communication is established with the ECU and a diagnostic session is running. If no
diagnostic session is running, the default session is active. StopDiagnosticSession.vi cannot
disable the default session. If the ECU has stopped the current diagnostic session, it performs
the necessary action to restore its normal operating conditions. Restoring the normal
operating conditions of the ECU may include resetting all controlled actuators if they were
activated during the diagnostic session being stopped, and resuming all normal ECU
algorithms. You should call StopDiagnosticSession.vi before disabling communication with
Close Diagnostic.vi, but only if you previously used StartDiagnosticSession.vi.
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-69 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
StopRoutineByLocalIdentifier.vi
Purpose
Executes the StopRoutineByLocalIdentifier service. Stops a routine on the ECU.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the routine to be stopped. The values
are application specific.
data in defines application-specific input parameters for the routine.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-70 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
data out returns application-specific output parameters from the routine.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
Description
This VI stops a routine in the ECU memory referenced by the local ID parameter.
For further details about this service, refer to the ISO 14230-3 standard.
source identifies the VI where the error occurred.
© National Instruments Corporation 5-71 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
TesterPresent.vi
Purpose
Executes the TesterPresent service. Keeps the ECU in diagnostic mode.
Format
Input
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
response required? indicates whether the ECU answers this service
(TRUE, default) or not (FALSE). In the latter case, success? is TRUE.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-72 ni.com
Output
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
diag ref out is a copy of diag ref in. You can wire it to subsequent
diagnostic VIs.
success? indicates successful receipt of a positive response message for
this diagnostic service.
error out describes error conditions. If the error in cluster indicated an
error, the error out cluster contains the same information. Otherwise,
error out describes the error status of this VI.
status is TRUE if an error occurred.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Description
To ensure proper ECU operation, you may need to keep the ECU informed that a diagnostic
session is still in progress. If you do not send this information (for example, because the
communication is broken), the ECU returns to normal mode from diagnostic mode after a
while.
The TesterPresent service is this “keep alive” signal. It does not affect any other ECU
operation.
Keep calling TesterPresent.vi within the ECU timeout period if no other service is executed.
© National Instruments Corporation 5-73 Automotive Diagnostic Command Set User Manual
Chapter 5 Automotive Diagnostic Command Set API for LabVIEW
WriteDataByLocalIdentifier.vi
Purpose
Executes the WriteDataByLocalIdentifier service. Writes a data record to the ECU.
Format
Input
data in defines the data record written to the ECU. If you know the record
data description, you can use Convert from Phys.vi to generate this
record.
diag ref in specifies the diagnostic session handle, obtained from Open
Diagnostic.vi and wired through subsequent diagnostic VIs. Normally, it is
not necessary to manually manipulate the elements of this cluster.
local ID defines the local identifier of the data to be written. The values are
application specific.
error in is a cluster that describes error conditions occurring before the VI
executes. If an error has already occurred, the VI returns the value of the
error in cluster to error out.
status is TRUE if an er ror occurred. This VI is not executed when
status is TRUE.
code is the error code number identifying an error. A value of 0
means success. A negative value means error: the VI did not
execute the intended operation. A positive value means warning:
the VI executed intended operation, but an informational warning
is returned. For a description of the code, wire the error cluster to
a LabVIEW error-handling VI, such as the Simple Error
Handler.
source identifies the VI where the error occurred.
Automotive Diagnostic Command Set User Manual 5-74 ni.com
