NAPCO LIBRA DXK4RF-319, LIBRA DXK4RF-433, LIB-P432EX, LIB-P432EXT, LIB-P432EXT-230 Installation Instructions Manual

KEYPAD
INSTALLATION
INSTRUCTIONS

333 Bayview Avenue

Amityville, New York 11701

For Sales and Repairs, [phone]

For Technical Service, [phone]

Publicly traded on NASDAQ Symbol: NSSC

R

LIBRA DXK4RF-319
LIBRA DXK4RF-433

Digital Icon Keypads with Integral RF Receiver

This Guide includes programming instructions for the LIBRA

LIB-P432EX, LIB-P432EXT, LIB-P432EXT-230 Control Panels.

This Guide is to be used in conjunction with the control panel Programming Instructions WI1690 and/or WI1771.

Quick Start:

1. Referring to the control panel wiring diagram, connect siren, auxiliary
power, PGM output, remote bus, earth ground, zone and telephone wiring.
NOTE: See Installation Instructions for the appropriate control panel.

2. Connect AC power first and then the battery.

3. Configure the keypad (see page 3).

4. Access the Easy Menu Driven (Dealer Program) Mode:

Press w456789

Press NO (q) Until "17" appears on the keypad display.

Press YES (p) to Enter Easy Menu Driven Dealer Program Mode.

The Easy Menu Driven Program Mode allows you to complete all basic
programming functions by answering questions which allow the automatic
programming of the control panel.

© NAPCO 2008

Dealer Code

u

DXK4RF-319 Keypad
DXK4RF-433 Keypad

WI1788 9/08

1

THE LIBRA-DXK4RF SERIES KEYPAD

DESCRIPTION

The LIBRA-DXK4RF series keypad is a multi-segment LCD digital keypad that is compatible with the LIBRA LIB­P432EX, LIB-P432EXT, LIB-P432EXT-230 control panels. Refer to User Guide OI349 for keypad operation
instructions. While the LIBRA-DXK4RF series keypads may be used to fully program the control panel, the

GEM-DXRP1 or GEM-DXK1 keypads, with their easy to read two-line LCD displays, provide the optimum in
ease of keypad programming. Note: Do not mix "RP" series keypads with "K Series" keypads within one system.

The wireless system comprises a compatible LIBRA LIB-P432EX series control panel, at least one LIBRA-RECV re­ceiver and one or more companion LIBRA-Series transmitters. Built inside the LIBRA-DXK4RF series keypad is a re­ceiver to save space and simplify installation. The transmitters may be wireless smoke detectors, space-protection de­vices, window/door sensors, or other devices that report zone status and supervision information to the receiver with­out the use of wires.

The integral receiver inside the keypad will accommodate up to 32 wireless points. The receiver is connected to the
control panel's 4-wire bus through the same 4 wires as the keypad. The receiver monitors each transmitter, updating
transmitter status as reports are received, and conveys this information to the control panel. Also monitored is the
elapsed time since the last report from each transmitter. If no report is received within a programmed time, a Supervi­sory Failure will result.

COMPATIBLE CONTROL PANELS

See WI1752 for installation and programming instructions with the GEM-P816, GEM-P1632, GEM-P3200 and GEM­P9600 control panels.

SPECIFICATIONS

Operating Voltage: 12VDC (supplied by panel)
Current Drain: 75 mA Standby
Note: Subtract keypad current from combined auxiliary current of the control panel.
Operating Temperature: 0° C to 49° C
Storage Temperature: 20° C to + 85° C
Power Requirements: 12VDC, 75mA (supplied by panel)
Antenna: ¼-wave (external wire), and internal antennas.
Dimensions: 5 7/8" x 4 3/8" x 1" (WxHxD)

ORDERING INFORMATION

Note: Any of the following Napco wireless transmitters may be used with the LIBRA-RECV Series Receivers. Bat-

teries are included with all transmitters.

LIBRA-TRANS433 - Window/Door Sensor. This supervised, two-point transmitter provides an internal magnetic reed

switch and/or terminals for two external normally-closed devices, or one external normally-open device.

LIBRA-PIR433 - Wireless PIR Motion Sensor.
LIBRA-SMK433 - Wireless Photoelectric Supervised smoke detector.
LIBRA-KEYF433 - Hand-Held Keyfob Transmitter. Key chain/Pendant remote arming or emergency transmitter.
LIBRA-GB433 - Glass-break sensor.

DL123A - Replacement Lithium Battery for LIBRA-TRANS433, LIBRA-PIR433 (2), and LIBRA-GB433 (2) (bulk

packed).

LIBRA-RECV8-433: Wireless Receiver, 8 Zones
LIBRA-RECV16-433: Wireless Receiver, 16 Zones
LIBRA-RECV96-433: Wireless Receiver, 96 Zones (maximum 32 zones supported)
LIBRA-RECV255-433: Wireless Receiver, 255 Zones (maximum 32 zones supported)

2

For Sales and Repairs, call toll free: [phone]

For direct line to Technical Service, call toll free: [phone]

Internet: http://www.napcosecurity.com

INSTALLATION

Designing the System

A keypad should be located near each exit/entry door. However, give careful consideration to the location of the key­pad, since it has a receiver built inside it. Regardless of where the control panel is mounted, the keypad should be
centrally located within the premises, that is, equally distant from all transmitters. Metal objects close to the installation
may adversely affect reception. Draw a layout of the system, identifying all proposed transmitter locations and antici­pated keypad location. Also include notations indicating construction materials in use. Although wood and wallboard
construction will have little effect upon signal strength at the receiver, concrete or brick can reduce signal strength by
up to 35%, while steel-reinforced concrete or metal lath and plaster can reduce transmitter strength as much as 90%.
Note: In difficult installations wherein distant transmitters pose reception problems, the use of multiple keypads and/or
LIBRA-REC16433's throughout the premises is recommended. (The LIB-P432EX control panel will accommodate up
to two receivers). Receivers are connected to the panel's 4-wire bus. They should be uniquely addressed (see AD-
DRESSING MULTIPLE RECEIVERS). Note: If receivers are intermixed, the panel will only recognize the capacity of
the lowest one.

After determining the general location for the keypad, additional time should be spent determining the exact location of
keypad using the template provided. In addition to the hole in the wall used to connect the bus wires to the keypad, an
additional hole should be made into the wall to allow the antenna wire to be recessed into the wall. The design of the
keypad keeps the antenna as far away from the bus wires as possible so that RF noise emitted from the bus wires
does not affect the sensitivity of the receiver. If the placement of both these holes are not carefully considered, addi­tional effort may be required to drill through or chisel existing wall beams. In addition the tamper is located close to the
antenna hole. If care is not taken to leave sufficient space between the antenna hole and the tamper, the tamper may
not function correctly.

To open the case, insert a screwdriver into either slot at the bottom and push up with a slight twisting motion to release
the retainer tab. Repeat for the other slot. Pull out at the bottom and lift off the two hooks at the top.
The LIBRA-DXK4RF series keypads feature a handy pull-up reference label. Before mounting the keypad onto the
wall, push the Sliding Label Plate (with label and felt backing affixed and handle facing forward) down the guides at the
rear of the keypad until it snaps into place. Once installed, the Sliding Label Plate cannot be removed without first
removing the keypad from the wall. Note: The keypad fire and panic keys should not be considered a substitute for a
listed manual initiating device, such as a pull box.
If installing onto a double-gang box, insert mounting screws through the two vertical elongated holes on the left side of
the case and into the box. If the box is visible when viewed from the front, adjust the keypad vertically and tighten the
screws. Then, using hardware suitable for the mounting surface, add one or two screws at the right side of the keypad
case directly into the wall to ensure a secure installation. Note: Do not over tighten the screws! Uneven walls may
cause the keypad case to distort.

WIRING

After the bus wires are brought through the bus wire hole, and the keypad back case is
mounted the wires can be connected as shown in the table at the right. After connecting the
wires care must be taken to loop the antenna wire carefully into the antenna hole as the
front cover is connected to the keypad back case. The antenna should fall easily into the
wall cavity away from the keypad bus wires. The wire should hang as straight as possible
below the keypad for optimal reception. If the wire cannot be hung inside the wall, it is better
for the wire to be cut flush with the printed circuit board rather than to have the wire become
tangled behind the keypad.

COLOR TERMINAL

RED 9

BLACK 10

GREEN 11

YELLOW 12

WHITE* N/O PANIC
WHITE* N/O PANIC

*Cut and insulate 2 white
wires if not used.

KEYPAD AND RECEIVER ADDRESS JUMPERS

If more than one receiver is being utilized, each must be individually addressed so that it can be identified by the con­trol panel. This is accomplished by the placement of jumper "RX" located in the upper right corner of the back of the
keypad, as shown below. Factory default is no jumper, therefore making the receiver inside the keypad as RF Re­ceiver #1. With the jumper in place, it is receiver #2. Refer to the Wiring Diagram for jumper configuration. Note:
Each receiver leaves the factory internally configured as #1, therefore, if only one receiver is being used, address as­signment is not required.

In summary, if more than one keypad is installed:

• Each must be assigned a unique address (that is, no two keypads may be numbered alike).

• Keypads must be addressed consecutively (that is, missing numbers are not permitted).

• Only Keypad No. 1 may be used for programming. (However, for ease of programming, it is recommended that a

GEM-DXK1 be selected as Keypad #1).

Up to seven (7) LIBRA-DXK4RF series keypads may be addressed to the control panel (Keypads 1–7).

3

Keypads are configured by the proper selection of jumpers. Refer to the label on the keypad circuit board for jumper
locations and a summary of settings. The keypad may be configured to disable touchpad backlight and entry sounder.

KEYPAD OPTION JUMPERS

A: DISABLE PUSHBUTTON BACKLIGHT

Cut Jumper A to disable touchpad pushbutton back-lighting.

B: DISABLE LCD BACKLIGHT

Cut Jumper B to disable liquid crystal display back-lighting.

C: DISABLE KEYPAD SOUNDER
Cut Jumper C to disable the keypad sounder.
D: ENABLE KEYPAD TAMPER

Cut Jumper D to enable the keypad tamper switch.

Option Jumpers

A C

D B

DISABLE PUSHBUTTON BACKL IGHT

A

DISABLE LCD BACKLIGHT

B

DISABLE KEYPAD SOUNDER

C

ENABLE KEYPAD TAMP ER

D

Left Jumper ("RX") determines Receiver Number.

If empty, default is “1”. Receiver number 2 if shorted.

Other three jumpers determine Keypad number, as per table
below:

RX

Receiver

Number

(OPEN BACK OF KEYPAD

Jumper ON = Receiver #2

Address Jumpers

RX 3 2 1

Address Jumper

3 2 1

OFF OFF OFF or

OFF ON OFF 2

OFF ON ON 3

ON OFF OFF 4

ON OFF ON 5

ON ON OFF 6

ON ON ON 7

Jumper OFF = Receiver #1

ON

Keypad
Number

1

GETTING UP AND RUNNING

(Use the GEM-DXK1 to program. For the LIBRA-DXK4RF series keypads, see page 12, "RF Transmitter

Points". Also see "Quick Method", which follows).

Using the GEM-DXK1 keypad, for each transmitter, enter:

• the zone number to which the transmitter will be mapped;

• the 6-digit ID Code: 1-digit checksum number printed on the transmitter and box;

• the wireless point number.

Note: When programming the ID Code at the keypad,

press

G0 for "A"

press G1 for "B"
press G2 for "C"
press G3 for "D"
press G4 for "E"
press G5 for "F"

Press u to save and r (p) to continue.

Keyfob Transmitters. Referring to the programming instructions for the control panel, enter the following:

• an assigned Keyfob Transmitter number (1—16);

4

• the Area number(s) to which the Keyfob Transmitter is designated;

• the 6-digit hexadecimal identification code with 1-digit checksum number printed on the transmitter (enter all

numbers and/or letters, including leading zeros, if any);

• Aux. 1 options (see programming worksheets);

• Aux. 2 options (see programming worksheets).

Quick Method (Using the GEM-DXK1 keypad)

If a receiver is already installed in the panel, Napco Transmitter wireless points can be programmed automatically
("enrolled"). Note: (1) The transmitter point will be enrolled only if the signal strength is 3 or greater. (2) Enroll a sin-
gle-point device by merely powering it up. (3) Quick Method is not applicable to keyfob transmitters.

Enter the Program Mode. Scroll to the RF Transmitter Points entry screen and proceed as follows:

1. Enter the zone number to which the transmitter point will be mapped.

2. Press

x to enter the Enroll Mode. The red and green LED's on the keypad will flash and will display as shown

below (GEM-DXK1).

ZN# XMIT#+CS P

3. Open the loop of the point that is to be programmed.

4. Install the transmitter battery. The keypad will indicate that the point has been successfully enrolled.

Multi-point transmitters can be mapped to successive zones simultaneously (Example 1) or to selected point by point
(Example 2).

Example 1: A 2 point transmitter has the ID Code number 410078. Map the two points to Zones 11 and 12 respectively.

1. Enter the Enroll mode as described in step 2 above.

2. Enter Zone "11".

3. Open the loops of points 1 and 2.

4. Install the transmitter battery. The keypad will beep twice to indicate that two points have been enrolled.

• Transmitter 410078, point 1 will be mapped to Zone 11

• Transmitter 410078, point 2 will be mapped to Zone 12

The keypad will now display Zone 12, the last zone enrolled.

Example 2: A 2-point transmitter has the 1D Code number 287613. Map point 1 to Zone 6 and point 2 to Zone 9.

1. Enter the Enroll mode as described above.

2. Enter Zone 06.

3. Open point-1 loop.

4. Install the battery. The keypad will beep once to indicate that one point has been programmed. (Transmitter point
1 will be mapped to Zone 6).

5. Enter Zone "09"

6. Open point-2 loop.

7. Remove the transmitter battery, then re-install it. The keypad will beep once to indicate that one point has been
programmed. (Transmitter 287613, point 2 is Zone 9).

CHECKING TRANSMITTERS

The status of each transmitter may be checked at the keypad. Referring to the control panel installation instructions
and the user's guide for the keypad in use, display transmitter status to show (a) the zone to which transmitter point is
mapped; (b) the transmitter's 6-digit RF ID number (c) the point number; (d) transmitter status (normal, open, low bat­tery, etc.); and (e) the signal strength of its last transmission.

Testing Wireless Signal Strength

To test the operation of wireless transmitters, proceed as follows.

 1. Enter the Fault-Find Mode from the Function Menu (use Dealer Security Code to enter).
 2. Fault a point of the transmitter to be tested by opening the loop. If the signal strength of the transmitter is 3 or

greater, the keypad will beep, as follows:

5

WIRELESS SIGNAL STRENGTH
Signal Power Beeps

0-2 0

3 1
4-5 2
6-7 3

8-10 4

 3. Restore the wireless point (close the loop). When restored, the keypad will beep once regardless of signal

strength.

Note: With the LIBRA-DXK4RF series keypads, signal strength is not displayed but is annunciated by beeps as per the
above table. For installations that include several transmitters, multiple receivers may be connected to the panel. (Only
the highest signal strength will be displayed). Note: When using the Fault-Find Mode on wireless zones, the keypad will
beep when the zone is opened or closed only if the signal strength of the transmitter is 3 or greater. Signal strengths
less than 3 will be entered into the system log (except in the Fault-Find Mode).

WIRELESS SYSTEM TROUBLES

The following system-trouble codes displayed at the keypad(s) are related to wireless operation.

Transmitter Troubles

Note: Also displayed with the transmitter trouble code are the zone number ("NN") to which Point 1 is mapped and the

transmitter's identification number.

WI LOBATT - E05-NN. Transmitter low battery. Note: If all transmitters were installed at the same time, it is rec-

ommended to replace all transmitter batteries to avoid service callbacks.

LOBATT KEYFOB - E18-NN. Keyfob transmitter low battery.
WL TRBL - E04-NN. Supervisory failure. Indicates that a transmitter has not "checked in" within the programmed

timeout. Check the transmitter for a dead battery (see note above). Also, check for an object in the path of the
transmitter blocking reception.

WL TAMPER - E15-NN. Tamper condition indicates that a transmitter case is open . Re-install cover

Receiver Troubles

Note: Also displayed with the receiver trouble code is the receiver number ("NN").

RF REC JAMMED - E16-NN. Transmitter interference from nearby radio-frequency source.
RF REC RES TRBL - E06-NN. Receiver response trouble (data failure between receiver and control panel).

Check the wiring between the receiver and the panel.

RF REC TAMPER - El 7-NN. Receiver open. Install cover.

LED INDICATIONS

Note: The LED's are located on the back of the keypad, centered on the printed circuit board on top. DS2 is on the left
and DS10 is on the right.

Red LED (DS10)

RED LED RECEIVER CONDITION

OFF No Power

ON Powered, but not communicating with panel

FLASHING Powered, properly communicating with panel

Green LED (DS2)

The green LED will flash while receiving a transmission having a signal strength of 4 or greater, indicating a signal of
sufficient strength. Caution: A green LED display with no transmitter in operation is a sign of high ambient RF inter-
ference. If the green LED remains lit continuously, relocate the receiver.

.

6
