Precise and flexible dispensing systems
MYSmart™ series MYD10™/MYD50™ in-line dispensers
Introducing the MYD series
Fully automated compact dispensing
The MYSmart series o ers a wide range of in-line dispense solutions together with a comprehensive portfolio of valve technologies. The compact MYD10 enables highly advanced non-contact jetting for enhanced dispensing uniformity, throughput and material utilization. For higher-precision applications such as
complex chip packaging, the powerful MYD50 platform further boosts productivity with linear motor motion control. The MYSmart in-line dispensing solutions, proven in the most advanced production environments, make it possible to handle a vast array of current and emerging products, assembly fluids and package types.
1 Unsurpassed value by combining high end technology with low total cost of ownership.
2 From underfill to solder paste the MYD series o•ers many unique jetting and dispensing technologies o•ering enhanced flexibility for high volume manufacturing.
3 Built in AVI capabilities enables automatic inspection of dispense results.
MYD series automated in-line dispensing systems can handle a wide range of dispensing applications.
FLEXIBLE
MYD series can handle di•erent substrate sizes and compositions to meet specifi c process requirements. A lot of di•erent applications can be achieved through possibilities such as tilt and rotate, contact and non-contact heating and dual head configurations.
COST-EFFICIENT
Smaller machine dimensions, high quality build and streamlined mechanical design allow the system to run for longer periods of time with less maintenance and lower downtimes. The reduced amount of wear parts in our jets further reduce cost of ownership making the MYD series a cost-e•ective dispensing machine.
IMPROVED PRODUCTIVITY
Precise temperature controls, on-the-fl y fi ducial search, robust vision algorithms, low motion Z axis and non-contacting dispensing are some of the feautures included to increase productivity.
Unmatched
production value
Non-contact
jetting technology
Semior full automation
Low maintenance and long service life
High-precision dispensing volume control
2 |
3 |
KEY APPLICATIONS, CONSUMER ELECTRONICS
•Hot melt
•Underfi ll
•Pin encapsulation
•Edge/corner bonding
•Surface mount package
•Package on package
•Dam and fi ll
•SMA
•FPC component
•Reinforcement materials
MYD series
Cross-industry capable platform
The MYD series automatic inline dispensing system is proven across many industries such‘as electronics, medical devices, optics and industrial assembly to name a few.
Consumer electronics |
Automotive electronics |
SMT electronics |
LED and medical industry |
5
