Mustek PVR USER GUIDE
Remindings...
CAUTION
Keep product out of direct sunlight. Exposure to direct sunlight or extreme
heat may cause damage or malfunction.
To prevent fi re or shock hazard, do not expose to rain or moisture.
CAUTION WHILE DRIVING
Use of headphones while operating an automobile or moving vehicle is not
recommended. Be careful and attentive on the road. Stop operation of the
unit if you fi nd it disruptive or distracting while driving.
BACK UP YOUR DATA
As with any device that has fl ash memory, you should back up the drive
regularly.
IMPORTANT BATTERY INFORMATION
The battery used in this device may present a risk of fi re or chemical burn
if mistreated. Do not separately recharge, disassemble, heat abo
(140˚F), or incinerate.
Battery replacement should only be made by trained technicians.
Do not attempt to open the unit. No user serviceable parts inside.
Keep the unit away from children. Do not disassemble or dispose product
in fi re.
Use only the specifi ed chargers which were packaged with the product. Use
of another charger may present a risk of fi re or explosion.
Keep charger plugged in to device for at least 3 hours before attempting to
operate device if battery is completely run down and is insuffi cient to power
up device.
2 PVR User Guide
ve 60˚C
Table of Contents
First Time Use >>-------------------------------------------------------------- 4
Identifying the Parts >>------------------------------------------------------ 5
Software Installation >>----------------------------------------------------- 7
Synchronizing Files between PC and PVR >>-------------------------- 8
Converting and Transferring Files >>-------------------------------------- 8
Mass Storage Mode >>------------------------------------------------------ 9
Disconnecting the PVR from your COMPUTER>>------------------ 10
OSD Menu >>------------------------------------------------------------------ 12
A. Photo Player >>---------------------------------------------------------- 13
B. Video Player >>-----------------------------------------------------------16
C. Audio Player >>---------------------------------------------------------- 19
D. MP3 Player >>----------------------------------------------------------- 23
E. AV Recorder >>---------------------------------------------------------- 27
F. Slide Show >>------------------------------------------------------------ 29
G. Calendar >>-------------------------------------------------------------- 30
H. Game >>------------------------------------------------------------------ 33
I. Setup Menu >>------------------------------------------------------------35
Direct Print >>---------------------------------------------------------------- 37
Specifi cations >>------------------------------------------------------------- 40
PVR User Guide 3
First Time Use
Thanks for your purchase of this product. This multi-functional portable
device enables you to:
• Play MPEG-4 videos
• View JPEG images
• Record digital videos
• Record digital audios
• Listen to MP3 fi les
• Use it as an USB Portable Disk
• Use it as a SD/MMC card reader
• Record TV show (MPEG 4 compatible ASF fi le format)
• Print photos directly without attaching to a PC (DPS-ready)
• Use it as an alarm clock
• Convert multiple video fi le formats into MPEG4 compatible ASF format
4 PVR User Guide
Identifying the Parts
1. Function Scroller
[Play/Pause] : Press the center button of the scroller to start or pause the
playing in Video/Audio/MP3 Player Mode.
Note: The center button of the scroller behaves as the OK button on the PVR front panel.
You may press the OK button when you have to press the center button.
[Previous/Next] : Scroll up/down and release the scroller to go to
previous/next item in Photo/Video/Audio/MP3 Player Mode.
[F.Fwd/F.Bwd] : Scroll up/down and hold the scroller to speed up the
playing of advancing/reversing in Video/Audio/MP3 Player Mode.
[Volume Up/Down] : Press the button and then scroll up/down to
adjust the volume during playback in Video/Audio/MP3 Player mode.
2. Hold
Switch to / to lock/unlock the buttons (including the scroller) on
the PVR.
3. DC IN jack
[Power Supply] :
[Charge] :
Connect the power adapter to DC IN jack while using PVR.
Connect the power adapter to DC IN jack to charge the battery.
PVR User Guide 5
4. Strap Holder
5. AV IN jack
Connect the AV cable to this AV IN jack while recording TV programs.
6. Earphone jack
7. USB port
8. SD/MMC CARD slot
9. Battery Cover
10. Mode/INFO button
Press the Mode button to switch to different modes.
Press the Info button to turn on/off the information while reviewing
photos and videos or recording TV shows.
11. Speaker
12. Record/Vol button
13. Microphone
A built-in microphone for voice record.
14. Power button
15. Menu/Stop button
Use this button to call up the menu under each mode.
16. Play/Pause/OK button
6 PVR User Guide
Software Installation
The installation CD bundled with the PVR contains all the necessary
software and useful informtion (PVR User Guide PDF) you need before operating PVR. Please follow the instructions below to complete the software
installation.
1. Insert the Installation CD into CD-ROM. The Select Language dialog
box appears.
2. Select your preferred language and click “OK”
to continue.
3. A Welcome dialog box appears. Click “Next”.
4. The Select Components dialog box appears.
Click and select the software you want to
install and then click “Next“.
5. The Select Program Folder dialog box ap-
pears telling you that setup program is about
to add a program icon to your system, you can
change the folder name listed in the text box,
or simply click “Next” to continue.
6. The Start Copying Files dialog box appears
confi rming that the listed software will be
installed. Click “Next” to continue.
7. Follow the on-screen instructions to continue
and complete the installation.
PVR User Guide 7
Synchronizing fi les between PC and
PVR
Converting and Transferring Files
To synchronize the fi les between PC and your PVR, read and follow the
instructions below.
1. Power on the PVR. Connect the PVR to the computer with the USB cable
provided in the package. The following appears. Then the Multimedia
Converter dialog box appears.
2. Press
fi les will be listed as thumbnails in the Source fi eld.
3. Press
will reside before uploading to PVR.
4. Press Convert button. The conversion starts.
Note: Multimedia Converter only supports Windows 2000/XP.
Browse button to select the path where your fi les reside. The
Browse button to select the path where your temporary fi les
8 PVR User Guide
5. The Convert Progress dialog box appears listing the conversion detail. To
cancel the coversion, press button to stop.
Mass Storage Mode
For PC Users
Connect your PVR to a computer, an extra disk drive (USB Portable Disk)
will appear. Your PVR is now in Mass Storage Mode. In this mode, you can
copy, move or delete fi les (pictures) exactly the way you manipulate fi les in
Windows user interface.
Note: Do not put the fi les you want to play on the PVR via Mass Storage Mode. For those fi les
you want to play on the PVR, use only the Multimedia Converter to convert and upload.
For MAC Users
(Mac OS: 9.x and 10.1 above)
By connecting your PVR to a MAC computer (refer to the previous page),
it will automatically detect Mass Storage drive. You can easily manipulate
your fi les the way you do in MAC user interface.
PVR User Guide 9
Disconnecting the PVR from your
Computer
We strongly recommend you to safely remove the PVR from your computer
when it is not in use.
Windows XP
1. Click “Safely Remove Hardware” ( ) icon in the taskbar.
2. Select Safely remove USB Mass Storage
Device from the menu.
Windows 2000
1. Click “Unplug or Eject Hardware” ( )
icon in the taskbar.
2. Select “Stop USB Mass Storage Device” from the menu (Windows 2000).
Select “Stop USB Disk” from the menu (Windows Me).
Mac OS 9.x and 10.1 above
1. Select the camera icon (shown as ‘NO_NAME’or ‘untitled’ drive) on the
desktop.
2. Drag and drop the drive to the Trash.
10 PVR User Guide
Notice:
• If the PVR is not connected to your PC while opening the Multimedia Con-
verter program, a “no device” dialog box will
appear, simply click
The program will launch and all the converted
fi le(s) will be saved and placed in the temporary
folder.
Once the PVR is connected to your PC, the
previously converted fi les will then automatically be uploaded to the PVR.
• If you don’t want to keep the fi les on your pc for backup, check the option “de-
lete temporary fi le(s) after the transfer?“, then the fi les saved in the temporary
fi les folder will be deleted after uploading to PVR.
• The Destination window will be disabled if there is no PVR connected.
If the PVR is connected to your PC, you will see 4 folders labeled PHOTO,
VIDEO, AUDIO and MP3 in this window. The folders are automatically built
by the system. All the converted fi les will be sorted and saved to these folders
according to their type.
• To delete the fi les in PVR, select the fi le in the Destination window and then
click
.
to continue.
PVR User Guide 11
OSD Menu
Power on the PVR, a startup screen appears, then the OSD (on-screen display) menu comes up. The OSD menu contains 9 categories. Each of them
provides different functions for users to select. We will introduce how to use
the versatile PVR via OSD menu.
Before operating the PVR practically, we have to remind you some important points. Please read and follow.
• All the fi les (.asf/.jpg/.mp3/.wav) to be played on the PVR must be converted by
Multimedia Converter fi rst.
• The PVR has internal memory, if you want to save the fi le in the internal
memory, do not insert external memory card. If an external memory card is
inserted in the PVR, only the external memory can be read.
• For better playback speed and viewing quality, all the photos converted by Mul-
timedia Converter will be resized to 640 x 480 pixels to fi t the PVR screen size.
• The PVR calendar can record the date up to the year 2036.
• The timer record and alarm clock setting can be preset within 24 hours.
• Only one song can be set for alarm clock music. If you pick up a song in AU-
DIO menu and pick up another song in MP3 menu, the system will only choose
the most up-to-date one for alarm clock music.
• It’s strongly recommended to turn off the LCD display and plug in the AC
adapter while using the PVR for timer record.
• When you choose to format the data in the built-in memory, do not insert a
memory card in the PVR, otherwise PVR will erase the data in the memory card
instead.
