Front Tine Rototiller
Operators Manual
Transport Position
F-041303L
Operating Position
Includes Models
FT6000X92A
F041303L
2
MODEL INFORMATION
MODEL IDENTIFICATION .............................................. 3
WARRANTY.................................................................... 4
SAFETY RULES ............................................................. 5
Owner's Responsibility ................................................. 5
General ........................................................................ 5
Preparation .................................................................. 5
Operation ..................................................................... 6
Maintenance and Storage ............................................. 6
Safety Decals .............................................................. 7
FEATURES ..................................................................... 8
UNPACKING AND ASSEMBLY....................................... 9
Unpack Tiller ................................................................ 9
Install the Depth Regulator Lever ................................ 10
Fill Engine Crankcase ................................................ 10
CONTROLS .................................................................. 11
Drive Safety Control Lever .......................................... 11
ADJUSTMENTS ........................................................... 12
Belt Tension Adjustment ............................................ 12
Depth Regulator Lever ................................................ 13
OPERATION ................................................................. 14
Pre-Start Inspection ................................................... 14
Start-up ...................................................................... 14
Shutting Down ........................................................... 15
Tilling ......................................................................... 15
NORMAL CARE ............................................................ 16
Schedule ................................................................... 16
Servicing The Rototiller............................................... 17
STORAGE .................................................................... 20
Prepare For Storage ................................................... 20
TROUBLESHOOTING AND REPAIR ............................ 21
Troubleshooting Guide ............................................... 21
Parts Listings ............................................................ 22
Notes ......................................................................... 26
MODEL IDENTIFICATION
Record your model number, manufacturer number and
serial number in the space provided for easy reference.
The model and manufacturer numbers can be found on the
unit I.D. plate located on the units left engine mount. Refer
to the Engine Owners Manual for location of engine serial
number.
WARNING
You must read, understand and comply with all
safety and operating instructions in this manual
before attempting to setup and operate your
rototiller.
Failure to comply with all safety and operating
instructions can result in loss of machine control,
serious personal injury to you and/or bystanders,
and risk of equipment and property damage. The
triangle in the text signifies important cautions or
warnings which must be followed.
ROTOTILLER REFERENCE DATA
Model Description/Number
M/N (Manufacturer's Number) S/N (Serial Number)
Dealer Name Date Purchased
ENGINE REFERENCE DATA
Engine Make/Model Engine ID/Serial Number
WARNING
Engine exhaust from this product contains
chemicals known, in certain quantities, to cause
cancer, birth defects, or other reproductive harm.
F041303L
3
WARRANTY
Thank You . . .
for purchasing an Murray front tine rototiller. We guarantee that this front tine rototiller conforms to applicable North
American safety standards, and have worked to ensure that it will meet your exacting standards for usability and
durability. With proper care, your rototiller will provide many years of service.
Please take time to read this manual carefully to learn how to operate and service your rototiller correctly. Failure
to do so could result in personal injury or equipment damage. This manual should be considered a permanent part of
your rototiller. Congratulations on your investment in quality.
MURRAY, INC. Two Year Limited Warranty
TILLER PRODUCT 2 YEAR WARRANTY
Murray, Inc. warrants to the original purchaser that this unit shall be free from defects in material and workmanship
under normal use and service for a period of Two (2) Years from the date of purchase; however, this warranty does
not cover Normal Wear Parts (except as noted below) or engines, accessories, transmissions, and transaxles
supplied through other companies that furnish their own warranties and provide service through their authorized
field service facilities. For additional information, see the warranties covering these particular parts. If you are
uncertain whether your unit contains or is equipped with one or more of these parts, consult your dealer prior to
purchase. Subject to the terms and conditions noted in this Limited Warranty, we shall, at our option, repair or
replace at no cost to the original purchaser any part covered by this Limited Warranty during the applicable
warranty period.
Normal Wear Parts are defined as belts, tines, pulley adapters, wheels, and pneumatic tires. These parts are
warranted to be free from defects in material and workmanship as delivered with the product. Any claim for repair
or replacement of Normal Wear Parts must be made within thirty (30) days of the date of purchase. No claims involving
damage caused from material use, abuse or misuse will be honored.
This Murray, Inc. Two (2) Year Limited Warranty is your exclusive remedy; however, this warranty is void or does
not apply to any unit that has been tampered with, altered, misused, abused or used for rental or other commercial
and/or professional (nonhomeowner) uses. Your warranty does not cover minor mechanical adjustments which
are not due to any defect in material or workmanship. For assistance in making such adjustments, consult your
Instruction Book.
To make a claim under this Murray, Inc. Two (2) Year Limited Warranty, return the unit (or if authorized in advance,
the defective part) along with your proof of purchase to an Authorized Service Center near you. To locate the nearest
Authorized Service Center, call the Central Parts Distributor for your area shown in the list provided with your unit
or check the Yellow Page listings in your local telephone directory. If you return the entire unit, we will repair the unit.
If we authorize the return of the defective part only, we will either replace or repair the part. In the case of a defect in
a transmission or differential (as distinguished from a transaxle), the entire transmission or differential must be
returned since they do not include user serviceable parts.
This Murray, Inc. Two (2) Year Limited Warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. This Limited Warranty is given in lieu of all other expressed and implied warranties
including the implied warranty of merchantability and warranty of fitness for a particular purpose. If you need
additional information on this written warranty or assistance in obtaining service, write or call:
MURRAY, INC.
Outdoor Power Equipment
Customer Service Department
P.O. Box 268; Brentwood, Tennessee 370240268
18002518007
F041303L
4
SAFETY RULES
OWNER'S RESPONSIBILITY
Safe and effective use of the rototiller is the owner's
responsibility.
1. Read and follow all safety instructions.
2. Maintain the tiller according to directions and schedule
included.
3. Ensure that anyone who uses the tiller is familiar with
all controls and safety precautions.
GENERAL
The Safety Alert symbol shown here is used to
alert you to important safety information that must
be read, fully understood, and followed at all times when
handling, transporting, operating, servicing, or storing your
rototiller unit.
Each safety alert symbol is followed by a "signal word"
that advised you of the relative intensity, or level, of the
hazard the safety alert instructions pertain to.
The following list of signal words is being provided to help
you understand the intensity levels associated with each
signal word used in this manual.
DANGER
The signal word "DANGER" is used when a serious
injury or fatality will result if the safety instructions
that follow this signal word are not obeyed.
WARNING
The signal word "WARNING" is used when a serious
injury or fatality could result if the safety instructions
that follow this signal word are not obeyed.
CAREFULLY READ THIS MANUAL AND FOLLOW
ALL INSTRUCTIONS.
Be familiar with all controls before operating the tiller.
Your tiller is equipped with a safety device that enables
you to stop the tines quickly in an emergency. Learn
how the drive safety control lever works and how to
control the tiller at all times.
Never allow children to operate the tiller. Keep small
children away from the area being tilled. Do not allow
adults to operate the tiller without proper instruction.
Do not operate the tiller under the influence of alchohol
or drugs.
PREPARATION
Dress appropriately when operating the tiller. Always
wear sturdy footwear. Never wear sandals, sneakers,
or open shoes, and never operate the tiller with bare
feet. Do not wear loose clothing that might get caught
in moving parts.
Carefully inspect the area to be tilled, and remove all
foreign objects. Do not till above underground water
lines, gas lines, electric cables, or pipes. Do not
operate the tiller in soil with large rocks and foreign
objects which can damage the equipment.
Disengage drive safety control lever before starting the
engine.
Handle fuel with care; it is highly flammable.
a. Use an approved fuel container.
b. Never add fuel to a running engine or hot engine.
c. Fill fuel tank outdoors with extreme care. Never fill
fuel tank indoors.
d. Replace gasoline cap securely and clean up spilled
fuel before restarting.
CAUTION
The signal word "CAUTION" is used when personal
injury, or property or equipment damage could
result if the safety instructions that follow this signal
word are not obeyed.
Provides helpful information for proper assembly,
operation, or maintenance of your rototiller.
F041303L
Never attempt to make any adjustments while the
engine is running.
Engine is shipped from factory without oil. You must
add engine oil before starting engine.
5
SAFETY RULES
OPERATION
Never operate the tiller without guards, covers, and
hoods in place.
Keep hands, feet, and clothing away from rotating
parts. Keep clear of tiller tines at all times.
Tines rotate when tiller is engaged in forward-- in
forward, tines rotate when the drive safety control
lever is pulled down. Releasing the drive safety
control lever to neutral stops the tines.
Exercise extreme caution when operating on or
crossing gravel drives, walks, or roads. Stay alert for
hidden hazards or traffic.
After striking a foreign object, stop the engine, remove
the wire from the spark plug and secure, thoroughly
inspect the tiller for any damage, and repair the
damage before restarting and operating the tiller.
If vegetation clogs the tines, STOP THE ENGINE
AND DISCONNECT THE SPARK PLUG WIRE
before removing vegetation by hand.
Engine muffler will be hot from operation. Do not
touch it with bare skin or a severe burn may result.
If the unit should start to vibrate abnormally, stop the
engine and check immediately for the cause. Vibration
is generally a warning of trouble.
Do not run the engine indoors; exhaust fumes are
dangerous.
Do not overload the machine capacity by attempting
to till too deep at too fast a rate.
Never allow bystanders near the unit.
Never operate the tiller without good visibility or light.
Take all possible precautions when leaving the
machine unattended. Disengage drive control lever,
stop the engine, wait for all moving parts to stop, and
make certain guards and shields are in place.
When leaving the operating position for any reason:
- shut off the engine.
- wait for all moving parts to stop.
MAINTENANCE AND STORAGE
Keep machine, attachments, and accessories in safe
working condition.
Check shear bolts, engine mounting bolts, and other
bolts at frequent intervals for proper tightness to be
sure the equipment is in safe working condition.
To prevent accidental starting, always disconnect the
spark plug wire from the spark plug before performing
tiller maintenance.
Never run the engine indoors. Exhaust fumes are
deadly.
Always allow muffler to cool before filling fuel tank.
Never store equipment with gasoline in the tank inside
a closed building where fumes may reach an open
flame or spark. Allow the engine to cool before storing
in any building.
Always refer to the operator's guide instructions for
important details if the tiller is to be stored for an
extended period.
F041303L
6
SAFETY RULES
SAFETY DECALS
This rototiller unit has been designed and manufactured to provide you with the safety and reliability you would expect
from an industry leader in outdoor power equipment manufacturing.
Although reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge
to operated this equipment safely and effectively, we have placed several safety labels on the tiller to remind you of this
important information while you are operating the unit.
These important safety labels are illustrated below, and are shown here to help familiarize you with the location and
content of the safety messages you will see as you perform normal tilling operations. Please review these labels now,
and if you have any questions regarding their meaning or how to comply with these instructions, reread the complete
safety instruction text on the preceding pages, or contact your local dealer.
Should any of these labels become unreadable because of being worn, faded, or otherwise damaged during the use of
your tiller, please use the part number information provided to order a replacement label from your local authorized dealer.
These labels are easily applied, and will act as a constant visual reminder to you, and others who may use the
equipment, to follow the safety instructions necessary for safe, effective operation of your rototiller.
F041303L
Part No. 48x5318
TINES DANGER/OPERATION
Hood Decal
Part No. 48x5322
WARNING
Belt Cover Decal
Part No. 48x5321
WARNING
Pivot Mount Decal
7
Part No. 48x5410
HOOD WARNING
Hood Decal
Part No. 48x5320
CLUTCH ENGAGE
Handlebar Decal
– 1 –
T
FEATURES
drive safety control lever
forward cable
belt guard
hand knob
3-way adjustable tine widths
The advantage of the MURRAY gear drive rototiller over other front tine tillers, is the exclusive
unfolding and flexible drag bar. This gives the Murray gear drive tiller its stability and its
versatility. For easy transport, fold the wheels under the engine. During operation, the wheels
unfold back and the drag bar folds down. The long length between the tines and the depth
regulator level make this the most comfortable front tine tiller on the market.
Transport Position
Operating Position
F041303L
8
UNPACK TILLER
1. Open top of carton and remove handlebar assembly.
UNPACKING AND ASSEMBLY
CAUTION
Do not try to lift the rototiller from the carton.
2. Cut open end of carton and remove machine:
a. Tines are pre-assembled at 21 width. Sharp edge
of tine will be away from operator at top or face down
at front of machine.(Figure 2)
b. Outside tines have two positions- wide 21 & narrow
16. For narrow width - assemble with short side of
tine holder pipe towards center of machine. For 11
width, remove outside tine sets. (Figure 1)
c. For wide width - move left tine to right side and right
to left side. Assemble with long half of tine pipe
towards machine. (Figure 2)
d. Remove two (2) hand knobs & bolts and slide top
handle of handlebar over lower loop. Put
5/16-18 x 1-3/4 bolts thru both holes from inside
out, and tighten with hand knobs.
e. Check upper and lower jam nuts for tightness. See
Figure 4, Belt Tension Adjustment.
f. Add and check engine oil.
The right and left sides of your
rototiller are determined from
the operating position as you
face the direction of forward
travel.
Narrow Tine Width
Figure 1
tension spring link
beehive spring
1/4 stretch
upper jam nut
lower jam nut
forward cable
Figure 4
lower
handlebar
loop
hand knob
Wide Tine Width
upper handlebar
Figure 2
Figure 3
F041303L
9
– 1 –
UNPACKING AND ASSEMBLY
INSTALL THE DEPTH REGULATOR
LEVER
1. Install the depth regulator lever through hole in bracket
from the bottom up with curve to rear of unit and
secure with detent pin.
depth
regulator
lever
detent pin
FILL ENGINE CRANKCASE
Engine is shipped from factory without oil. You
must add engine oil before starting engine.
1. Add oil according to engine manual. Do not overfill.
Use a clean, high quality detergent oil. Container must
be marked A.P.I. Service SF - SJ. Use no special
additives with recommended oils. Do not mix oil with
gasoline. Oil level must be full. Check the oil level by
removing the dipstick. Oil level should be at FULL line
on dipstick.
2. Always check oil level before starting engine. Refer to
engine manual for capacity and type of oil to use.
Figure 5
F041303L
10
– 1 –
.
CONTROLS
DRIVE SAFETY CONTROL LEVER
Engage tines into forward, releasing returns machine to
neutral.
Pulling down on drive safety control lever engages the
tines. Releasing the drive safety control lever disengages
the tines to a neutral position.
drive safety control
lever disengaged
Figure 6
CAUTION
This information is provided here only to introduce
the controls. DO NOT START THE ENGINE AT THIS
TIME. Starting and operating instructions are given
on page 11. Please read this section and all
operating and safety instructions before starting your
tiller.
WARNlNG
Engine should be off before adjusting any
controls.
CAUTION
As a safety precaution, the drive safety control
levers will not lock in the forward position.
To stop the wheels and tines at any time
release the drive safety control levers.
Extreme caution should be used when operating
rototiller in the forward direction.
WARNlNG
F041303L
11
ADJUSTMENTS
BELT TENSION ADJUSTMENT
Proper belt tension is critical to good performance. After
half hour of operation, all cables may have to be adjusted
due to initial stretch. Thereafter, check tension after every
2 hours of operation.
To increase belt tension:
1. Loosen upper jam nut. Turn nut up cable in 1/8"
increments.
2. Tighten lower jam nut.
3. Check adjustment.
This procedure can be repeated until conduit adjustment
bolts have no more adjustment left. If no more adjustment
can be made, belt may have to be replaced.
tension spring link
beehive spring
1/4 stretch
upper jam nut
lower jam nut
forward cable
Figure 4
F-041303L
12
– 1 –
DEPTH REGULATOR LEVER
Tilling depth is controlled by the height of the depth
regulator lever.
To adjust tilling depth:
1. Remove detent pin.
2. Raise the depth regulator lever to position tines at
chosen tilling depth.
3. Align hole in depth regulator lever with hole in depth
regulator bracket and replace detent pin.
ADJUSTMENTS
depth
regulator
lever
detent pin
Figure 8
CAUTION
Do not adjust tilling depth unless drive safety control
lever is released to the neutral position.
F-041303L
13
OPERATION
PRE-START INSPECTION
1. Make sure all safety guards are in place and all nuts
and bolts are secure.
2. Check oil level in engine crankcase. See your engine
manual for procedure and specifications.
Engine is shipped from factory without oil. You
must add engine oil before starting engine.
3. Inspect air cleaner for cleanliness. See your engine
manual for procedure.
4. Check the fuel supply. Fill the fuel tank no closer than
1 inch from top of tank to provide space for expansion.
See your engine manual for fuel recommendations.
5. Be sure spark plug is tightened securely and spark plug
wire is attached.
6. Check depth regulator lever position.
CAUTION
Please do not start your tiller until you have read
the Manual that came with your engine, and the
sections in this manual titled Controls, Adjustments
and Safety. If you have read these, follow the steps
below to start your tiller. Always perform this prestart checklist before starting the engine.
WARNING
Gasoline is highly flammable and must be handled
with care. Never fill the tank when the engine is
hot or running. Always move outdoors to fill the
tank.
START-UP
The controls required to start and run the rototiller are
located on the engine and are marked "Choke" and
"Throttle".
A more detailed description of engine operation and all
related precautions and procedures can be found in the
engine manufacturer's manual that accompanies each
tiller.
Cold Starts
1. Move choke lever to full choke position.
2. Move throttle lever to "start".
3. When starting, operator should place free hand where
indicated and start the engine from the operator
position.
4. Pull starting rope out slowly one time and allow to
return normally.
5. Pull starting rope out rapidly, and allow rope to return
normally.
6. When engine starts, gradually move choke lever to
"no choke" position and increase throttle speed.
Restarting A Warm Engine
Restarting an engine that is already warm from previous
running does not normally require use of the choke.
F041303L
1. Move throttle lever to "start" position.
2. When starting, operator should place free hand where
indicated and start the engine from the operator
position.
3. Pull starting rope out rapidly until engine starts. Allow
rope to return normally.
4. Adjust throttle speed to "high" for best tiller action.
Idle Speed
Use the "low" position on the throttle lever to reduce stress
on the engine when tilling is not being performed. Lowering
the engine speed to "idle" the engine will help extend the
life of the motor, as well as conserve fuel and reduce the
noise level of the equipment.
Operating Speed
For normal tilling, set the throttle lever to "fast".
14
OPERATION
DANGER
Always keep hands and feet clear of rotating
machine parts.
WARNING
Temperature of muffler and near by areas may
exceed 150° F. Avoid these areas.
WARNING
Do not move choke control to CHOKE to stop
engine. Backfire or engine damage may occur.
SHUTTING DOWN
DANGER
Engine and surrounding parts become extremely
hot during normal use, and will cause serious burn
injuries if touched before the engine has cooled.
Allow engine to cool completely before touching
these hot surfaces.
TILLING
1. Adjust the depth regulator lever to desired tilling depth.
NOTE: Raise depth regulator lever up one hole at a
time, testing tiller operation after each raise. Raising
depth regulator lever too high can result in loss of
control of tiller!
2. Move the throttle control to fast.
3. Place the tiller in forward by pushing down on the
drive control lever--this will engage the tines.
CAUTION
To stop the tines at any time, release drive safety
control lever to the neutral position.
CAUTION
Always release drive safety control lever to the
neutral position before adjusting the depth regulator
lever.
To stop the engine at any time, move throttle
control to the off position. To stop tines at any
time, release drive safety control lever to the
neutral position.
F041303L
15
noitarepOecnanetniaM egaP esUhcaEerofeB
rosrh05
nosaeSyrevE
noisnettlebkcehC71X
tlebdrawrofegnahC71X
ecnanetniamenignE81X X
lioenignellifrokcehCME,81X 2
esaergnoissimsnartrellitkcehC91X
tfahselxaenitnaelC91X
tnemtsujdalortnocelttorhtkcehCME1
NORMAL CARE
SCHEDULE
Your rototiller has been designed and produced by the industry's leading manufacturer of outdoor power equipment to
provide you with years of reliable operation.
Keeping your tiller in top running condition will prolong its life, and help you obtain optimum performance whenever you
wish to till your garden.
Please read this normal care schedule, and observe these recommended care operating intervals to extend the life of
your unit.
belt
EM = See engine manual
1 Adjust throttle control after first 3 hours of operation or if engine is hard to start or run-on occurs.
2 Change oil after first 5-8 hours of use, then after every 50 hours or every season. Change oil every 25 hours
when operating under heavy load or in high temperatures.
F041303L
16
NORMAL CARE
SERVICING THE ROTOTILLER
General
The following information will help you make the necessary
checks and perform the procedures required to follow the
normal care recommendations made for your rototiller unit.
If you prefer, your local authorized service dealer can make
these checks and perform the required procedures for you.
Check Belt Tension
Belt tension may decrease over time. It must be adjusted
within the first half hour of operation, and checked after
every two hours of operation. Proper adjustment will
assure long belt life. Too much or too little belt tension will
cause premature belt failure. To check and adjust the
forward belt tension:
1. Turn off engine. Engine must be cool.
2. Remove spark plug wire from spark plug and secure.
3. With drive safety control lever in the neutral position,
measure length of spring when compressed.
4. Pull down on drive safety control lever and measure
length of spring when stretched out. Ideal length would
be 1/4" longer.
Belt Replacement
1. Turn off engine. Engine must be cool.
2. Remove spark plug wire from spark plug and secure.
3. Remove belt guard. (Fig. 11)
4. Remove dirt shield from bottom of tiller. (Fig. 10)
remove the belt from the engine pulley:
Dirt Shield
Figure 10
1"
1-1/4"
Figure 9
WARNING
Check forward belt tension regularly. Too much
or too little tension will cause premature belt
failure.
- force the belt down from engine pulley and slowly
rotate pulley by pulling the starter cord.
- remove the belt from transmission pulley.
- push the belt forward and out front of machine.
install new belt:
- place new belt onto transmission pulley.
- force belt up onto engine pulley while rotating
pulley with engine starter cord.
5. Replace belt guard and dirt shield.
6. Attach spark plug wire.
belt guard
removed
take belt out
from front
F041303L
Figure 11
17
NORMAL CARE
CAUTION
Do not operate tiller before reading the engine
manual provided in the parts packet.
WARNING
Temperature of muffler and near by areas may
exceed 150° F. Avoid these areas.
Engine can overheat and become damaged if debris
blocks the cooling system or rotating screen.
Engine is shipped from factory without oil. You
must add engine oil before starting engine.
Check or Fill Engine Oil
1. Add oil according to engine manual. Do not overfill.
Use a clean, high quality detergent oil. Container must
be marked A.P.I. Service SF - SJ. Use no special
additives with recommended oils. Do not mix oil with
gasoline. Oil level must be full. Check the oil level by
removing the dipstick. Oil level should be at FULL line
on dipstick.
2. Always check oil level before starting engine. Refer to
engine manual for capacity and type of oil to use.
Never run engine without complete air cleaner
installed on engine.
Engine Maintenance
Refer to the engine manual included in your parts packet
for information on engine maintenance. Your engine
manual provides detailed information and a maintenance
schedule for performing the following tasks:
1. Check oil level before each use or after every 8 hours
of operation.
2. Change oil after first 5-8 hours of operation. Change oil
` while engine is warm. Refill with new oil of recommended
grade.
4. Check spark plug yearly or every 100 hours of operation.
5. Service air cleaner.
6. Keep engine and parts clean.
7. Check engine and equipment often for loose nuts and
bolts, keep these items tightened.
Change Engine Oil
1. Remove the fasteners that secure the dirt shield at the
bottom of the tiller.
2. Take off the dirt shield and you can see the oil drain.
3. Refer to the engine manual for how to change oil.
Dirt Shield
Figure 12
F041303L
18
NORMAL CARE
Check Tiller Transmission Grease
Tiller transmission is shipped from factory with
the proper amount of grease.
To add grease, remove both high and low grease ports.
Inject grease in bottom until you see some at top hole,
transmission is now full.
grease out,
high grease
port
Clean Tine Axle Shaft
1. Turn off engine. Engine must be cool.
2. Remove spark plug wire from spark plug and secure.
3. Remove all vegetation, string, wire, and other material
that may have accumulated on the axle between the
inside set of tines and the seal on the transmission
housing.
4. Replace spark plug wire.
grease in,
low grease
port
Figure 12
F041303L
19
STORAGE
PREPARE FOR STORAGE
Follow the steps below to prepare your tiller for storage.
Read your engine manual for detailed instructions on
preparing the engine for storage.
1. Protect wheels and axles from rust:
- Coat the axles lightly with axle grease.
2. Run with gas stabilizer in fuel.
3. Drain the fuel tank. Run the engine until it stops.
4. While engine is still warm, drain the oil from the
engine. Refill with fresh oil of the recommended grade.
5. Remove spark plug, pour one-half ounce of clean
engine oil into cylinder. Pull starter handle slowly
several times to distribute oil. Replace spark plug.
6. Clean entire tiller.
7. Store your tiller in a clean, dry building.
CAUTION
Do not store tiller in an non-ventilated area where
fuel fumes may reach flame, sparks, pilot lights or
an ignited object. Drain fuel outdoors away from
any ignition sources. Use only approved fuel
containers.
F041303L
20
TROUBLESHOOTING AND REPAIR
TROUBLESHOOTING GUIDE
While normal care and routine maintenance will extend
the life of your rototiller, prolonged or constant use may
eventually require that service be performed to allow it to
continue operating properly. The troubleshooting guide
below lists the most common problems, causes and
remedies.
PROBLEM REMEDY/ACTION
Engine will not start
Engine runs rough, floods during operation
Engine is hard to start
Engine misses or lacks power
CAUTION
Practice safety at all times. Engine must be turned
off and allowed to cool, and spark plug wire must
be disconnected and secured before attempting
any maintenance or repair.
· Connect spark plug wire to spark plug
· Throttle must be positioned at choke for a cold start
· Clean or replace air cleaner
· Drain old fuel and replace with fresh. Use gas stabilizer
at end of season
· Make sure spark plug wire is securely attached to spark
plug
· Drive control safety lever must be released to neutral to
start the engine
· Clean or replace air cleaner
· Improper carburetor adjustment, take to authorized
engine service center
· Replace spark plug and adjust gap
· Drain and refill gas tank and carburetor
Engine will not stop when throttle control is positioned at
stop
Tiller moves forward during starting
Tiller is difficult to control when tilling (machine jumps or
lurches forward)
Belts squeal in neutral
Belts squeal in forward operation
· See engine manual to check and adjust throttle linkage
· Drive safety control lever must be released to neutral to
start the engine
· Raise the tines for shallower tilling by raising the depth
regulator lever, see page 10
· Lower engine speed in hard ground
· Adjust belt guide:
- turn engine off and allow muffler to cool
- disconnect spark plug wire from spark plug
- remove the dirt shield
- pull down on drive safety control lever
- manually bend belt guide so there is 1/16 inch
or less clearance between belt guide and belt
- replace the dirt shield
- replace spark plug wire
· Turn engine off and allow muffler to cool
· Disconnect spark plug wire from spark plug
· Release drive safety control lever to neutral
· Adjust engage cable
· Replace spark plug wire
F041303L
21
HANDLEBAR ASSEMBLY
1
3
FT6000X92A
2
5
4
6
8
6
9
11
10
10
13
14
15
14
KEY NO. PART # DESCRIPTION
1 AR3262E701 FRONT TINE DRIVE LEVER, WELDED
2 028X23 PUSH CAP, 3/8 Dia.
3 AR3261 FRONT TINE TENSION SPRING LINK
4 15x146 NUT-Nyloc, #10-24
5 AR53530 SPRING-Bee Hive, Forward Cable Adjust
6 15x147 NUT-Jam, 5/16"-24
8 7401038 TOP HANDLE ASSEMBLY
9 AR3108A CABLE ASSEMBLY WITH FERREL
10 094068 KNOB - Wing
11 AR3264E201 BOTTOM HANDLE
13 315288 BOLT 5/16-18 UNC X 1.75 CURVED HD
14 01x137 BOLT-Hex Hd, 3/8-16 x 1.00, Grade 5
15 015X84 NUT-Hex, 3/8-16
F-041303L
22
SHAFT ASSEMBLY
FT6000X92A
1
2
3
4
5
6
51
16
19
13
61
7
62
18
19
18
19
17
17
KEY NO. PART # DESCRIPTION
1 37X138 BELT-Forward
2 001X64 CAPSCREW-Hex Hd, 5/16-24 x 3/4
3 018X15 LOCKWASHER-Spring, 5/16
4 17x146 WASHER, .34 ID X 1.2X 11GA THK
5 AR746 SPACER, 11/16 ID x 3/8 THK
6 AR3179 TRANSMISSION PULLEY
7 ARM1000 TRANSMISSION ASSEMBLY
13 2001022 KEY-Square, 3/16 x 3/4
16 AR3323E701 TINE SET-Outside Right
17 001X75 BOLT-Hex Hd, 5/16-18 x 1-3/4
18 AR3324E701 TINE SET-Inside
19 015X88 NUT-Biway Lock, 5/16-18
20 AR3326E701 TINE SET-Outside Left
51 01X199 BOLT-Hx Hd, 1/4-20 x 7-1/2
61 018X32 LOCKWASHER - Spring .25
62 15X116 NUT - .25-20 HEX NYLOCK B2
20
19
F-041303L
23
MOTOR MOUNT & HOOD ASSEMBLY
1
FT6000X92A
2
17
3
4
10
11
10
9
5
12
6
7
8
9
15
16
27
28
39
20
19
24
27
38
26
25
29
35
36
16
21
19
41
20
30
44
30
20
33
6
9
37
36
43
9
38
F-041303L
24
MOTOR MOUNT & HOOD ASSEMBLY FT6000X92A
KEY NO. PART # DESCRIPTION
1 01X175 BOLT-Hex Hd, 5/16-18 x 2
2 01X139 BOLT-Hex Hd, 5/16-18 x 1-1/4
3 01X198 BOLT-Hex Hd, 5/16-18 x 3-1/4
4 ---------- ENGINE*
5 1901051 PULLEY-1 -Drive, 7/8 ID
6 17X124 WASHER, .406 ID x .812 OD, Eng. Pulley
7 018X31 LOCKWASHER-Spring, 3/8
8 01X194 3/8-24 x 1.75 BES
9 028X22 PUSH NUT, 1/2 Dia
10 AR1714250 WHEEL & TIRE ASSEMBLY
11 1001701 DETENT PIN, 5/16
12 AR3266E201 DRAG BAR MOUNT
15 AR3157E701 DEPTH REGULATOR LEVER
16 01X100 BOLT-HHCS, 1/4-20 x 1/2
17 AR3130AE201 FRAME-Engine Mount
19 AR744 SPACER
20 015X88 HEX FLG, NUT, 5/16-18
21 AR1407 SPRING-Idler Arm
24 AR3182A Z BELT GUIDE & MOUNT
25 AR53596 Z CABLE YOKE
26 AR3360 Z IDLER ARM-Forward
27 26X263 SCREW-Sheet Metal, .25-20X.59
28 AR3237E201 FRONT BELT COVER
29 29X107 LINK PIN
30 01X137 BOLT-HEX HD, 3/8-16 x .1.00, Grade 5
33 030X20 COTTER PIN
35 50793 PULLEY-Forward Idler
36 015X84 NUT-Hex flange, 3/8-16
37 1901049E201 DIRT SHIELD
38 15X116 NUT-Nyloc, 1/4
39 7401039 SHIELD ASSEMBLY
41 7401040 REAR COVER ASSEMBLY
43 AR3149 Z WHEEL SHAFT, 1/2 Hinge
44 017X48 Washer, .390 ID X .750OD X 13 GA THK
* Parts are available from an Authorized Service Center. See Engines, Gasoline or Gasoline Engines in the
yellow pages of the telephone directory.
F-041303L
25
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
MURRAY, INC. CENTRAL PARTS DISTRIBUTORS
BILLIOUS, INC.
1343 South Main St.
Porterville, CA. 93257
(559)784-4102 or 1-877-245-5468
FAX 1-800-266-7337
Arizona, California, Hawaii,
Nevada
BROWN & WISER, INC.
9991 S.W. Avery Street
Tualatin, OR. 97062
(503)692-03301-800-882-4782
FAX (503)691-2041
Alaska, Idaho (counties Ada,
Adams, Benewah, Boise, Bonner,
Boundry, Canyon, Clearwater,
Elmore, Gem, Idaho, Kooten,
Latah, Lewis, NEZ Perce, Owyee,
Payette, Ravalli, Shoshone, Valley,
Washington), Montana (counties
Flathead, Lake, Lincoln, Mineral,
Missoulo, Ravalli, Sanders),
Oregon, Washington
CPT CANADA POWER
TECHNOLOGY LIMITED
Mississauga
161 Watline Avenue
Mississauga, Ontario L4Z-1P2
(905)890-6900 or 1-800-861-9559
Edmonton
101-10411-178 Street
Edmonton, Alberta T5S 1R5
(780)453-5791or 1-800-861-9559
Ville St-Laurent
234 Migneron Street
Ville St-Laurent, Quebec H4T 1Y7
(514)731-35591-800-861-9559
Canada
FRANK EDWARDS CO.
3626 Parkway Blvd.
West Valley City, UT 84120
1-800-318-0201
FAX (801)736-8067
Colorado, Idaho (counties
Bannock Bearlake, Bingham,
Blaine, Booneville, Butte, Camas,
Caribou, Cassia, Custer, Franklin,
Fremont, Gooding, Jefferson,
Jerome, Lemhi, Lincoln, Madison,
Minidoka, Oneida, Power, Teton,
Twin Falls) Montana (all counties
except Flathead, Lake, Lincoln,
Mineral, Missoulo, Ravalli,
Sanders), Utah, Wyoming
GARDNER, INC.
3641 Interchange Road
Columbus, OH. 43204-1499
1-800-848-8946
FAX 1-800-626-4735
Alabama, Arkansas, (except these
counties: Hempstead, Howard,
Lafayette, Little River, Miller,
Nevada, Pike, Sevier),
Connecticut, Delaware, District
of Columbia, Florida, Georgia,
Illinois (South of Hwy. 80),
Indiana, Iowa, Kansas, Kentucky,
Louisiana, Maine, Maryland,
Massachusetts, Michigan (except
upper Peninsula), Mississippi,
Missouri, Nebraska, New
Hampshire, New Jersey, New
York, North Carolina, Ohio,
Pennsylvania, Rhode Island,
South Carolina, Tennessee,
Vermont, Virgina, West Virginia
Puerto Rico
GULF COAST ENGINE, INC.
4202 Russell Dr.
Corpus Christi, TX. 78408
1-800-825-6999
FAX (888)888-7036
Arkansas (counties Hempstead,
Howard, Lafayette, Little River,
Miller, Nevada, Pike, Sevier) New
Mexico, Oklahoma, Texas,
Mexico
WISCONSIN MAGNETO,
INC.
4727 N. Teutonia Ave.
Milwaukee, WI. 53209
1-800-733-7388
FAX 1-800-733-0127
Illinois (N. of Hwy. 80), Michigan
(upper Peninsula), Minnesota,
North Dakota, South Dakota,
Wisconsin
Loading...
