Multiquip 382V User Manual

PARTS AND OPERATION MANUAL

A DIVISION OF MULTIQUIP INC.

FLEXIBLE SHAFT

MODELS 314V AND 382V

© COPYRIGHT 2002, MULTIQUIP INC.

Revision #0 (04/08/02)

MULTIQUIP INC

18910 WILMINGTON AVE. 800-427-1244
CARSON, CALIFORNIA 90746 FAX: [phone]
310-537-3700
800-421-1244 800-478-1244
FAX: [phone] FAX: [phone]

E-mail:[e-mail] • www:multiquip.com

Atlanta • Boise • Dallas • Houston • Newark
Montreal, Canada • Manchester, UK
Rio De Janiero, Brazil • Guadalajara, Mexico

..

. PARTS DEPARTMENT:

..

SERVICE DEPARTMENT/TECHNICAL ASSISTANCE:

HERE'S HOW TO GET HELP

PLEASE HAVE THE MODEL AND SERIAL NUMBER
ON-HAND WHEN CALLING

PARTS DEPARTMENT

800-427-1244 or 310-537-3700
FAX: [phone] or 310-637-3284

SERVICE DEPARTMENT/TECHNICAL ASSISTANCE

800-478-1244 or 310-537-3700
FAX: [phone]

WARRANTY DEPARTMENT

888-661-4279, or 310-661-4279
FAX: [phone]

MAIN

800-421-1244 or 310-537-3700
FAX: [phone]

PAGE 2 — MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02)

MQ-STOW — Model 314/382
Vibrator Flexible Shafts

Here's How To Get Help ........................................... 2

Table Of Contents .................................................... 3

Parts Ordering Procedures ...................................... 4

Rules For Safe Operation ........................................ 5

Specifications ........................................................... 6

Operation ................................................................. 7

Operation and Maintenance .................................... 8

Terms and Conditions of Sale -Parts ....................... 9

TABLE OF CONTENTS

NOTE

Specification and
part number are
subject to change
without notice.

MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02) — PAGE 3

VIBRATOR SHAFT MODEL 314/382 — PARTS ORDERING PROCEDURES

n

Dealer account number

n

Dealer name and address

n

Shipping address (if different than billing address)

n

Return fax number

n

Applicable model number

n

Quantity, part number and description of each part

n

Specify preferred method of shipment:

UPS Ground

•

UPS Second Day or Third Day*

•

UPS Next Day*

•

Federal Express Priority One (please provide us with your Federal

•

Express account number)*

Airborne Express*

•

Truck or parcel post

•

*Normally shipped the same day the order is received, if prior to 2PM west coast time.

Earn Extra Discounts when

you order by FAX!

All parts orders which include complete part numbers
and are received by fax qualify for the following extra
discounts:

Number of
line items ordered Additional Discount

1-9 items 3%
10+ items** 5%

Get special freight allowances
when you order 10 or more
line items via FAX!**

n

UPS Ground Service at no charge for freight

n

UPS Third Day Service at one-half of actual freight
cost

No other allowances on freight shipped by any other carrier.
**Common nuts, bolts and washers (all items under $1.00 list price)

do not count towards the 10+ line items.

Extra Fax DiscountExtra Fax Discount

Extra Fax Discount

Extra Fax DiscountExtra Fax Discount

for Domestic USAfor Domestic USA

for Domestic USA

for Domestic USAfor Domestic USA

Dealers OnlyDealers Only

Dealers Only

Dealers OnlyDealers Only

Now! Direct TOLL-FREE access

to our Parts Department!

Toll-free nationwide:

800-421-1244

Toll-free FAX:

*DISCOUNTS ARE SUBJECT TO CHANGE*

PAGE 4 — MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02)

800/6-PARTS-7 • 800-672-7877

VIBRATOR SHAFT MODEL 314/382 — RULES FOR SAFE OPERATION

CAUTION:

Failure to follow instructions in this manual
may lead to serious injury This
equipment is to be operated by trained

and qualified personnel only! This
equipment is for industrial use only.

ALWAYS use safety guidelines when connecting the flexible
shaft to the vibrator.

GENERAL SAFETY

■

DO NOT operate or service this equipment
before reading this entire manual.

■

This equipment should not be operated
by persons under 18 years of age.

■

NEVER operate this equipment without proper
protective clothing, shatterproof glasses, steel­toed boots and other protective devices required
by the job.

■

Manufacture does not assume responsibility for any accident
due to equipment modifications.

■

NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage to
the equipment and/or injury to user may result.

■

This flexible shaft assembly is component part of a vibration
unit. You should obtain the safety and operating instructions
for the vibrator motor unit and the vibrator head. These
instructions should be read and fully understood before
operation of the vibration unit.

■

Before connecting the flexible shafting to the vibrator motor

make certain

unplugged from the power source.

■

Warning!,
motor while it is running.

■

Warning!,
assembly for any reason.

■

Only use this flexible shaft to power vibrator heads.

■

Inspect the unit before each use for damage. If unit is found
to be damaged, have unit repaired by an authorized repair
person.

the switch is in the off position and the unit is

never

attempt to connect the core to the vibrator

never

attempt to run the core outside of the casing

■

NEVER operate this equipment when not
feeling well due to fatigue, illness or taking
medicine.

■

NEVER operate this equipment under the
influence or drugs or alcohol.

■

ALWAYS wear proper eye protection
equipment when operating the vibrator.

■

When servicing unit, use only recommended replacement
parts.

■

Save these instructions for future reference

MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02) — PAGE 5

VIBRATOR SHAFT MODEL 314/382 — SPECIFICATIONS

snoitacificepStinUrewoP.1elbaT

TINUREWOPTFAHSEZISDAEH

PH1413

PH2283

PH3283

TFAHS.XAM

HTGNEL

009

0001

.tf12

0031

0041

.tf82

0071

0012

.tf12

0041
0071
0012

.tf53

0062

snoitacificepS283dna413ledoM.2elbaT

).TF(HTGNEL

.ONLEDOMTFAHSNOITPIRCSED.ONTRAPWOTS2570121418112

413.yssAgnisaC&eroC90631

ylnOeroC91331

ylnOgnisaC01631

205-505-705-015-215-415-815-125-

283.yssAgnisaC&eroC92831

ylnOeroC72831

ylnOgnisaC02831

PAGE 6 — MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02)

VIBRATOR SHAFT MODEL 314/382 — OPERATION

Preparation and Operation

1. Before connecting the flexible shaft to the vibrator motor
head, read and fully understand all of the safety and operat­ing instructions for the flexible shaft, vibrator motor and the
head.

2. The flexible shaft is shipped from the factor ready to use.

3. Use only the combination of flexible shafts, motors and heads
shown in the Table 1 (specifications).

4. Operate the flexible shaft in a straight configuration as
possible. Sharp bends increase the load on the core and the
vibrator motor, which will result in early core failure and
possible damage to the vibrator motor.

The following steps are for connecting the flexible shaft,

5. When storing the flexible shaft, it is recommended that it be
stored flat, either laid out straight or in a large radius. Keep
the ends covered to keep out foreign matter. Check lubrica­tion before each use.

Model 382 to a 2 or 3 HP vibrator motor:

5. Warning!:

and the

Figure 1. Motor End Bell

make certain

OFF/ON

switch is in the

the vibrator motor us unplugged

OFF

position.

6. CAUTION!: If the shaft begins to helix (buckle) excessively
during operation, stop and correct the problem, this is an
indication of an overload condition. The problem could be the
core or the head.

CONNECTING THE SHAFT
The following steps are for connecting the flexible shaft

(Model 314) to the 1 HP vibrator motor:

1. Warning!:
and the OFF/ON switch is in the

2. Slide the core out of the shaft casing far enough to allow it to
be screwed into the fitting adapter (

handed

If the connection is not tight the torque of the motor plus the
load of the head will jam the fittings together, making it
extremely difficult to break the connection loose for disas­sembly.

3. Screw the shaft casing ferrule into the motor end bell (threads
are right handed). See Figure 1.

make certain

).

the vibrator motor us unplugged

OFF

position.

threads are right

6. Because all of these units use the quick disconnect system,
Model 314 Q.D. coupling must be used (Figure 2). Reference
P/N 24380-402, which includes the spindle P/N 25013-001
and coupling P/N 24372-001.

Figure 2. Motor End Bell

MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02) — PAGE 7

VIBRATOR SHAFT MODEL 314/382 — OPERATION/MAINTENANCE

Connecting the QD Coupling to the Core.

1. Slide the core out of the casing far enough to thread the
spindle into the core fitting and tighten. If the connection is not
tight, the torque of the motor plus the load of the head will jam
the two fittings together, making it extremely hard to loosen
them for disassembly.

2. Thread the Q.D. coupling into the casing ferrule and tighten.

3. To connect the shaft assembly and Q.D. coupling to the
vibrator motor, pull up on the lock pin a d slide the shaft into
the end bell. Release the lock pin and give the shaft assembly
a twist to make certain the lock pin is seated in one of the 3
holes in the shaft coupling.

Connecting Two Flexible Shafts (Model 382)

1. Use coupling P/N 13883-501 when joining the two flexible
shafts (Model 382) together.

2. Connect both flexible shafts as shown in Figure 3.

MAINTENANCE
Daily Inspection

1. Following daily use remove any dirt and concrete from the
shaft, motor and head.

2. Inspect the unit for any damage to any of the three compo­nents and have repaired before further use. Refer to the
respective instruction bulletins for repair of the power unit
and head.

3. Inspect the casing for any cuts or holes through the covering,
loose ferrules, or a permanent kink in the shaft. If any of these
conditions are found, replace the casing.

100 Hour Maintenance

1. Remove the shaft form the motor.

2. If the shaft is equipped with a quick disconnect coupling,
unscrew it from the casing ferrule. Threads are right

handed.

Figure 3. Connecting Two Flexible Shafts

NOTE

When ordering core or
casing part numbers
use Table 2.

Example: (Model 314)

A complete Core and Casing Assembly

ber would be 13609. If a 12 foot shaft is desired, select

512. The new complete par t number using a 12 ft. shaft
would be 1309-512.

part num-

3. Unscrew the vibrator head from the shaft casing. Threads
are left handed. Heat should be used to loosen the
anaerobic sealant in the threads.

4. Pull the core out of the casing, wiping the grease off as it is
pulled form the casing.

5. Inspect the core for broken wires, a permanent set, or other
damage such as an area that shows high wear of having run
overheated. Replace with a new core if these conditions
exist.

6. Use the core to push a cleaning patch through the casing to
remove the old grease and any foreign matter.

7. Thoroughly clean the core if it is being reused.

8. Relube the core. Coat it with
good grade of ball bearing grease. Only a light coating is
needed. CAUTION: DO NOT
with grease. Excessive lubrication will cause overheating.

9. Reassemble using the reverse procedure.

10. When connecting the head to the casing, clean the mating
threads with an anaerobic sealant primer and allow to dry for
several minutes. Apply a ring of anaerobic sealant to the
middle of the casing ferrule threads. Screw the head tightly
to the casing and wait for one hour before using.

DuBois "TPG"

"pack"

lubricant or a

the shaft assembly

PAGE 8 — MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02)

TERMS AND CONDITIONS OF SALE — PARTS

PAYMENT TERMS

Terms of payment for parts are net 10 days.

FREIGHT POLICY

All parts orders will be shipped collect or
prepaid with the charges added to the invoice.
All shipments are F.O.B. point of origin.
Multiquip’s responsibility ceases when a
signed manifest has been obtained from the
carrier, and any claim for shortage or damage
must be settled between the consignee and the
carrier.

MINIMUM ORDER

The minimum charge for orders from Mul­tiquip is $15.00 net. Customers will be asked
for instructions regarding handling of orders
not meeting this requirement. If possible, ad­ditional fast moving parts will be added to the
order to total $15.00 minimum.

RETURNED GOODS POLICY

Return shipments will be accepted and credit
will be allowed, subject to the following provi­sions:

1. A Returned Material Authorization must
be approved by Multiquip prior to ship­ment. A copy of the Authorization must
accompany the shipment to the desig­nated Warehouse. A copy of the original
Multiquip invoice to the customer must
also accompany the shipment.

2. Parts being returned must be listed as
currently supplied on the current parts
list.

3. Parts must be in new and resalable con-

4. Any item with a list price of $1.00 or less

5. Any parts with a limited shelf life (such as

6. Special order items are not returnable for

7. Engine parts other than 2-cycle engine

8. Credit on returned parts will be issued at

9. Credit issued will be applied to future

10. All parts must be returned freight prepaid

The sender will be notified of any material
received not meeting the above provisions.
Such material will be held for 30 days from
notification, pending instructions. If a reply is
not received within 30 days, the material will
be returned to the seller at his expense.

PRICING AND REBATES

Prices are subject to change without prior
notice.

Price changes are effective on a specific date
and all shipments on or after that date will be
billed at the revised price.

Rebates for price declines and added charges
for price increases will not be made for stock
on hand at the time of any price change.

Multiquip reserves the right to quote and sell
dition, in the original Multiquip package,
with Multiquip part numbers clearly
marked.

will not be accepted.

gaskets, seals, “O” rings, filters, etc.) that
are over six months old will not be ac­cepted.

credit.

parts will not be accepted.

dealer net price at time of original pur­chase, less a 15% restocking charge.

purchases only.

to Multiquip’s designated receiving point.
Freight is at the sender’s expense.

direct to Government agencies, and to Origi-

nal Equipment Manufacturer accounts who

use our products as integral parts of their own

products.

SPECIAL EXPEDITING SERVICE

A $20.00 to $50.00 surcharge will be added to

the invoice for special handling including bus

shipments, insured parcel post or in cases

where Multiquip must personally deliver the

parts to the carrier.

LIMITATION OF SELLER’S LIABILITY

Multiquip shall not be liable hereunder for

damages in excess of the purchase price of the

item with respect to which damages are

claimed, and in no event shall Multiquip be

liable for loss of profit or good will or for any

other special, consequential or incidental dam-

ages.

LIMITATION OF WARRANTIES

No warranties, express or implied, are made

in connection with the sale of parts or trade

accessories nor as to any engine not manufac-

tured by Multiquip. Such warranties made in

connection with the sale of new, complete units

are made exclusively by a statement of war-

ranty packaged with such units, and Multiquip

neither assumes nor authorizes any person to

assume for it any other obligation or liability

whatever in connection with the sale of its

products. Apart from such written statement of

warranty, there are no warranties, express,

implied or statutory, which extend beyond the

description of the products on the face hereof.

MODEL 314/382 FLEXIBLE SHAFT — PARTS & OPERATION MANUAL — REV. #0 (04/08/02) — PAGE 9

PARTS AND OPERATION MANUAL

HERE'S HOW TO GET HELP

PLEASE HAVE THE MODEL AND SERIAL NUMBER
ON-HAND WHEN CALLING

PARTS DEPARTMENT

800-427-1244 or 310-537-3700
FAX: [phone] or 310-637-3284

^^^^^*^^^^^^^^^^^^^^^^^^^^^^^^^*^6668

SERVICE DEPARTMENT/TECHNICAL ASSISTANCE

800-478-1244 or 310-537-3700
FAX: [phone]

WARRANTY DEPARTMENT

888-661-4279, or 310-661-4279
FAX: [phone]

MAIN

800-421-1244 or 310-537-3700
FAX: [phone]

MULTIQUIP INC.

POST OFFICE BOX 6254
CARSON, CA 90749
310-537-3700 • 800-421-1244
FAX: [phone]
E-MAIL: [e-mail]
WWW: multiquip.com

Quebec, Canada • Manchester, UK • Rio De Janiero, BR • Guadalajara, MX

Atlanta • Boise • Dallas • Houston • Newark
