Mtd SC2450 operators Manual

INTRODUCTION

Welcome to the World of Cub Cadet Yanmar Tractor

Thank you for purchasing our tractor product that has been designed and manufactured based on our state-of-the-art technology and rich expertise in developing and manufacturing tractor products.

Handle your tractor correctly by following the instructions contained in this Operator’s Manual so that it provides you long years of reliable and faithful service.

This manual constitutes an indispensable part of your Cub Cadet Yanmar tractor product. Always keep the manual readily accessible. Carefully study this manual to get familiar with the instructions and information contained in it. These instructions and information are helpful in using your tractor correctly and safely, and avoiding personal injury and other accidents during operation and servicing of the tractor. When using any implement together with your tractor, also carefully study its operation manual so that you can use it safely, correctly and efficiently. This manual is organized with sections arranged in a particular order so that you can better understand the safety messages and the controls on your tractor to help you operate your tractor correctly and safely. This manual will also help you answer questions about operation and servicing. An index is available at the end of this manual to assist you in quickly finding necessary information. The machine shown in this manual may somewhat differ from your actual machine. However, this manual will still assist you in understanding the instructions associated with your tractor. Before delivery of your machine, your Cub Cadet Yanmar dealer has performed a pre-delivery check to ensure that your tractor can long remain problem-free.

All information, descriptions, specifications, drawings, illustrations, and pictures in this manual are based on the latest information available at the time this manual was published. Yanmar reserves the right to make changes at any time without prior notice. © 2009 - 2010 Yanmar Co., Ltd. Yanmar licenses the usage rights of this manual in North America to CUTSCO (Compact Utility Tractor Supply LLC). © 2009 - 2010

Sc2450 Operator’s Manual

PICTOGRAPHS

To help assist the operator in operating the tractor, various easy-to-understand pictographs have been developed and are used throughout this manual. They are listed below together with their meanings.

Safety alert symbol

Headlight beam

Turn signal

Fuel level

Revolutions per minute

Engine coolant warning light

Preheater pilot light

Engine oil pressure

Alternator/battery charging light

Engine start

Headlight and work light

Hazard warning light

Slow

Fast

Hydro Static Transmission (HST) pressure locked position Hydro Static Transmission (HST) pressure released position

Position for moving only the Mid-Power Take Off (PTO)

Position for moving the Mid- and Rear Power Take Off (PTO) at the same time

Engine run

Engine shut-off

Preheating

Turn signal

Headlight

Sc2450 Operator's Manual

Position for moving only the Rear Power Take Off (PTO)

Position control raised position

Position control lowered position

Hydraulic flow control/stop

4-wheel drive on

2-wheel drive on

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ................................................................................... 1-1

About This Manual............................................................................................................ 1-1

Safety Precautions for the Tractor .................................................................................. 1-2

1. Safety-Alert Symbol................................................................................................................. 1-2

2. Precautions Before Operating Your Tractor............................................................................ 1-3

3. Safe Practices for Operating Your Tractor .............................................................................. 1-4

4. Operate Your Tractor on Slopes ............................................................................................. 1-6

5. Travel on a Road..................................................................................................................... 1-7

6. Safe Practices for Parking Your Tractor.................................................................................. 1-7

7. Operate the Power Take Off (PTO)......................................................................................... 1-8

8. Use the 3-Point Hitch (Option) ................................................................................................1-8

9. Safety Frame (Roll-Over Protective Structure) (ROPS) Precautions ...................................... 1-8

10.Safe Practices for Servicing Your Tractor ............................................................................... 1-9

11.Understand the Tractor Safety Decals .................................................................................. 1-11

 Safety-Alert Symbol.............................................................................................................................................1-11

 Care of DANGER, WARNING and CAUTION Decals.........................................................................................1-11

2. SERVICE THE PRODUCT .................................................................................. 2-1

3. SPECIFICATIONS............................................................................................... 3-1

Specifications of the Tractor ........................................................................................... 3-1

1. Specifications Table ................................................................................................................ 3-1

2. Traveling Speeds (Reference) ................................................................................................ 3-2

4. IMPLEMENT CAPACITIES................................................................................. 4-1

5. NAMES AND FUNCTIONS OF COMPONENTS ................................................ 5-1

Tractor Control Overview................................................................................................. 5-1

1. Overview ................................................................................................................................. 5-1

2. Operator Station Controls........................................................................................................ 5-2

 Names of Components..........................................................................................................................................5-2

 Function of Components .......................................................................................................................................5-3

3. Instrument Panel, Switches and Hand Controls.................................................................... 5-11

6. PRE-OPERATION CHECK ................................................................................. 6-1

Pre-Operation Check of Tractor ...................................................................................... 6-1

1. Pre-Operation Check............................................................................................................... 6-1

2. Precautions Before the Operation........................................................................................... 6-1

3. Routine Check......................................................................................................................... 6-1

4. Prevent Damage to the Plastic Surfaces and Painted Surfaces ............................................. 6-1

Sc2450 Operator's Manual

TABLE OF CONTENTS

7. OPERATE THE ENGINE .................................................................................... 7-1

1. Start the Engine....................................................................................................................... 7-2

 Opening/Closing the Fuel Shut-Off Valve..............................................................................................................7-2

 Adjust the Operator's Seat.....................................................................................................................................7-2

 Reverse the Operator's Seat .................................................................................................................................7-2

 Fasten the Retractable Seat Belt...........................................................................................................................7-4

 Engage the Parking Brake.....................................................................................................................................7-5

 Check the Lights on the Instrument Panel.............................................................................................................7-8

 Warm Up the Engine in Cold Weather ..................................................................................................................7-9

2. Shut Down the Engine........................................................................................................... 7-10

3. Restart a Stalled Engine........................................................................................................ 7-11

8. OPERATION ....................................................................................................... 8-1

Operate the Tractor........................................................................................................... 8-1

1. Operate a New Tractor............................................................................................................ 8-2

2. Raise and Lower the Roll-Over Protective Structure (ROPS)................................................. 8-3

 Lower (Fold Down) the Roll-Over Protective Structure (ROPS) ............................................................................8-3

 Raise (Unfold) the Roll-Over Protective Structure (ROPS) ...................................................................................8-4

3. Operate the Tractor................................................................................................................. 8-5

 Function of Implement Lock Lever ........................................................................................................................8-7

 Engage the Cruise Control ....................................................................................................................................8-9

 Disengage the Cruise Control ...............................................................................................................................8-9

4. Stop the Tractor..................................................................................................................... 8-10

 Stop in an Emergency .........................................................................................................................................8-10

5. Verify During Driving ............................................................................................................. 8-11

 Fuel Gauge..........................................................................................................................................................8-12

 Engine Coolant Warning Light .............................................................................................................................8-12

 Hour Meter...........................................................................................................................................................8-13

6. Park the Tractor..................................................................................................................... 8-14

 Apply the Parking Brake ......................................................................................................................................8-14

 Release the Parking Brake..................................................................................................................................8-14

7. Safe Practices for Operation ................................................................................................. 8-15

 Engage the Differential Lock ...............................................................................................................................8-15

 Disengage the Differential Lock...........................................................................................................................8-15

 Hydro Static Transmission (HST) Pressure Release Lever.................................................................................8-20

 Uphill/Downhill .....................................................................................................................................................8-23

 Steep Downhill.....................................................................................................................................................8-23

8. Accessory.............................................................................................................................. 8-24

 12V DC Outlet .....................................................................................................................................................8-24

9. POWER TAKE OFF (PTO) ................................................................................. 9-1

1. Operate the Power Take Off (PTO)......................................................................................... 9-1

 Rear Power Take Off (PTO) ..................................................................................................................................9-2

 Mid- Power Take Off (PTO)...................................................................................................................................9-2

 Engage the Power Take Off (PTO) .......................................................................................................................9-2

 Disengage the Power Take Off (PTO)...................................................................................................................9-4

2. Install an Implement to the Power Take Off (PTO) Drivelines................................................. 9-5

3. Operate the Power Take Off (PTO) while the Tractor is Traveling

in the Reverse Direction (Reverse Override Function)............................................................ 9-5

Sc2450 Operator's Manual

TABLE OF CONTENTS

10.3-POINT HITCH (Option) ................................................................................. 10-1

1. 3-Point Hitch.......................................................................................................................... 10-1

 Right Lift Link.......................................................................................................................................................10-2

 Top Link...............................................................................................................................................................10-2

 Sway Link ............................................................................................................................................................10-2

 Hitch ....................................................................................................................................................................10-2

11.HYDRAULIC SYSTEM...................................................................................... 11-1

1. 3-Point Hitch Control System ................................................................................................ 11-1

 Operate the 3-Point Hitch Control/Cutting Height Adjustment Lever to Raise or Lower the 3-Point Hitch..........11-1

 Hydraulic Flow Control/Stop Knob.......................................................................................................................11-2

12.TIRES, WHEELS AND BALLAST .................................................................... 12-1

1. Tires ...................................................................................................................................... 12-1

 Tire Inflation Pressure .........................................................................................................................................12-2

 Wheel Bolt Tightening Torque .............................................................................................................................12-2

2. Ballast.................................................................................................................................... 12-3

 Front Ballast ........................................................................................................................................................12-3

 Rear Ballast .........................................................................................................................................................12-4

13.MAINTENANCE ................................................................................................ 13-1

1. Maintenance Check List ........................................................................................................ 13-1

 Tractor .................................................................................................................................................................13-1

2. Lubricants.............................................................................................................................. 13-3

3. Replacement Parts................................................................................................................ 13-3

14.PERIODIC SERVICE ........................................................................................ 14-1

■

Warranty and Repair of the Engine....................................................................................... 14-1

Periodic Service of the Tractor...................................................................................... 14-2

1. Open/Close the Hood............................................................................................................ 14-2

 Open the Hood ....................................................................................................................................................14-2

 Close the Hood....................................................................................................................................................14-3

2. Daily Checks ......................................................................................................................... 14-4

 Visual Checks ......................................................................................................................................................14-4

 Refill the Fuel Tank..............................................................................................................................................14-4

 Check the Engine Oil Level .................................................................................................................................14-8

 Check the Transmission/Hydraulic Oil Level .......................................................................................................14-9

 Check the Radiator Hoses and Clamps ............................................................................................................14-10

 Clean the Radiator Cooling Fins and Screen ....................................................................................................14-10

 Clean the Rear Grille Screen.............................................................................................................................14-11

 Check the Cooling System ................................................................................................................................14-12

 Check the Fuel Line...........................................................................................................................................14-13

 Check the Intake Air Hoses and Clamps...........................................................................................................14-13

 Check the Safety Interlock System....................................................................................................................14-14

 Check and Adjust the Brake ..............................................................................................................................14-16

 Check the Seat Belt and Roll-Over Protective Structure (ROPS)......................................................................14-16

 Check the Wheel Bolt Tightening Torque ..........................................................................................................14-17

 Check the Inflation Pressure .............................................................................................................................14-17

 Check the Light Bulbs........................................................................................................................................14-18

 Check the Tie-rod Rubber Boots .......................................................................................................................14-18

 Check and Clean the Electrical System ............................................................................................................14-18

 Adjust Front Axle Pivot ......................................................................................................................................14-19

Sc2450 Operator's Manual

TABLE OF CONTENTS

 Check the Hydraulic Hoses ...............................................................................................................................14-20

3. First 50 Hours...................................................................................................................... 14-22

 Change the Engine Oil ......................................................................................................................................14-22

 Replace the Engine Oil Filter.............................................................................................................................14-22

 Change the Transmission/Hydraulic Oil ............................................................................................................14-22

 Replace the Transmission/Hydraulic Oil Filter...................................................................................................14-22

4. Every 50 Hours.................................................................................................................... 14-22

 Check the Front Axle Oil Level ..........................................................................................................................14-22

 Checking the Fuel/Water Separator ..................................................................................................................14-23

 Adjust the Fan Belt ............................................................................................................................................14-24

 Grease and Lubricate ........................................................................................................................................14-25

5. Every 100 Hours.................................................................................................................. 14-27

 Engine Oil ..........................................................................................................................................................14-27

 Change the Engine Oil ......................................................................................................................................14-27

 Clean the Fuel/Water Separator........................................................................................................................14-28

 Service the Air Cleaner Element .......................................................................................................................14-29

6. Every 200 Hours.................................................................................................................. 14-31

 Replace the Engine Oil Filter.............................................................................................................................14-31

 Adjust the Toe-in ...............................................................................................................................................14-32

7. Every 300 Hours.................................................................................................................. 14-33

 Transmission/Hydraulic Oil................................................................................................................................14-33

 Change the Transmission/Hydraulic Oil and Replace the Transmission/Hydraulic Oil Filter ............................14-33

8. Every 500 Hours.................................................................................................................. 14-35

 Front Axle Case Oil ...........................................................................................................................................14-35

 Change the Front Axle Case Oil........................................................................................................................14-35

 Replace the Fuel Filter Element (in the Fuel/Water Separator).........................................................................14-36

 Replace the Fuel Filter ......................................................................................................................................14-36

9. Every 1000 Hours................................................................................................................ 14-37

 Coolant ..............................................................................................................................................................14-37

 Flush the Cooling System..................................................................................................................................14-38

 Change the Coolant...........................................................................................................................................14-40

10.Every 1 Year........................................................................................................................ 14-41

 Replace the Air Cleaner Element ......................................................................................................................14-41

 Flush the Cooling System..................................................................................................................................14-41

 Change the Coolant...........................................................................................................................................14-41

11.Every 2 Years...................................................................................................................... 14-41

 Replace the Radiator Hoses and Clamp ...........................................................................................................14-41

 Replace the Fuel Line........................................................................................................................................14-41

 Replace the Intake Air Hose..............................................................................................................................14-41

 Replace the Hydraulic Hoses ............................................................................................................................14-41

 Replace Power Steering Hose ..........................................................................................................................14-41

Sc2450 Operator's Manual

TABLE OF CONTENTS

15.SERVICE THE ELECTRICAL SYSTEM ........................................................... 15-1

1. Battery ................................................................................................................................... 15-1

 Special Note for the Battery.................................................................................................................................15-1

 Service the Battery Safely ...................................................................................................................................15-2

 Inspect the Battery...............................................................................................................................................15-3

 Remove and Install the Battery ...........................................................................................................................15-3

 Clean the Battery and Terminals .........................................................................................................................15-4

 Use a Booster Battery .........................................................................................................................................15-5

2. Fuses..................................................................................................................................... 15-6

 Replace the Accessory Fuses .............................................................................................................................15-6

 Check the Alternator Fuse and the Main Fuse ....................................................................................................15-6

3. Bulb ....................................................................................................................................... 15-7

 Replace the Headlight Bulb .................................................................................................................................15-7

 Replace the Work Light Bulb ...............................................................................................................................15-8

 Replace the Tail Light Bulb..................................................................................................................................15-9

 Replace the Turn Signal/Hazard Lights Bulb.......................................................................................................15-9

 Replace the Instrument Panel Light Bulb ..........................................................................................................15-10

4. Headlights ........................................................................................................................... 15-10

 Adjust the Headlights.........................................................................................................................................15-10

16.STORE THE TRACTOR ................................................................................... 16-1

1. Safe Practices for Storage .................................................................................................... 16-1

 Fuel......................................................................................................................................................................16-2

 Engine .................................................................................................................................................................16-2

2. Prepare the Stored Tractor for Operation.............................................................................. 16-3

17.TROUBLESHOOTING ...................................................................................... 17-1

1. Guide in Using the Troubleshooting Table............................................................................ 17-1

18.OPTIONS .......................................................................................................... 18-1

19.INDEX................................................................................................................ 19-1

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

About This Manual

This Operator’s Manual presents you messages that help you remain aware of potential hazards and possible machine damage in operating and servicing your machine. Carefully study all the information in it so that you can avoid personal injury and damaged properties.

NOTE

●Unless otherwise stated, the expressions–righthand side, left-hand side, front side, and rear side, used throughout this manual see the sides relative to the direction of forward movement with the tractor.

●All pictures in this manual show the tractor with the front loader and backhoe installed. Refer to the front loader and backhoe Operator's Manuals for the safe operating instructions and all other information relating to these attachments.

RIGHT

3016402

REAR

FRONT

LEFT

! WARNING

Avoid injury:

●Always remove the backhoe before installing the mid-mount mower.

●The tractor can be used when the front loader and either the mid-mount mower or the backhoe is installed.

●Never install the mid-mount mower and the backhoe at the same time.

Sc2450 Operator's Manual

1-1

1. SAFETY PRECAUTIONS

Safety Precautions for the Tractor

1. Safety-Alert Symbol

The safety-alert symbols appear with most safety statements. It means attention, become alert, your safety is involved! Please read and strictly observe the message that follows the safety-alert symbols.

! DANGER

Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

! WARNING

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

WARNING: READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE YOUR TRACTOR. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.

WARNING: The engine exhaust, some of its constituents, and certain vehicle components

contain or emit chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.

! CAUTION

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE

Indicates a situation which can cause damage to the machine, personal property and/or the environment or cause the equipment to operate improperly.

IMPORTANT: Means that implement or

property damage could occur if instructions are ignored.

NOTE: Provides useful information.

DANGER: Your tractor was built to be operated according to the rules for safe operation in this

manual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. To help prevent accidents, read and take the following precautions before operating this tractor. Failure to observe the following safety instructions could result in serious injury or death.

1-2

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

2. Precautions Before Operating Your Tractor

1. Understand the performance and limitations of

your tractor. Carefully study this Operator’s Manual and learn the instructions in it before operating or servicing your tractor. Keep the Operator’s Manual in an easily accessible place.

2. Strictly follow the statements given in the

DANGER, CAUTION and WARNING safety decals attached to the tractor.

3. For operator safety, always install the Roll-Over

Protective Structure (ROPS). Keep the seat belt fastened while operating the tractor with the Roll-Over Protective Structure (ROPS). This practice will reduce the possibility of injury or death in the event of roll-over accident. If the Roll-Over Protective Structure (ROPS) has been removed for any reason, be sure to reinstall all the associated parts before operating the tractor. Do not alter the Roll-Over Protective Structure (ROPS). The altered Roll-Over Protective Structure (ROPS) may fail to provide the designed protection. Replace the damaged Roll-Over Protective Structure (ROPS) immediately. Contact your local Cub Cadet Yanmar dealer for technical assistance. NEVER alter or repair the Roll-Over Protective Structure (ROPS). Welding, bending, drilling, grinding, or cutting may weaken the Roll-Over Protective Structure (ROPS). Contact your local Cub Cadet Yanmar dealer for technical assistance.

4. Always fasten the seat belt while operating the

tractor with the Roll-Over Protective Structure (ROPS). Check the seat belt for any damage. Replace the damaged seat belt immediately. Contact your local Cub Cadet Yanmar dealer for technical assistance.

Do not use the seat belt if the tractor does not have the Roll-Over Protective Structure (ROPS).

5. Check overhead clearance carefully before driving under power lines, wires, bridges or low hanging tree branches, before entering or leaving building, or in any other situation where the operator and/or Roll-Over Protective Structure (ROPS) may be struck, which could result in serious injury.

6. Make sure that any person who will operate the tractor studies this Operator’s Manual before operation. Know the controls and how to stop the machine quickly.

7. Make sure that any person or obstacle is not under or around the tractor before and during operation. Be sure to maintain sufficient overhead clearance above the tractor.

8. Do not operate your tractor and/or implement installed to it while you are under the influence of alcohol, drug, medicine or controlled substance(s) or when you are not fit for operation of your tractor.

9. For operation, wear close-fitting clothing. When operating the tractor or working around the tractor, do not wear loose-fitting clothes or jewelry, or baggy or damaged clothing. When caught by a moving part of the tractor, an accident can result. Cut-off pants or shorts do not provide protection against flying debris. Never operate the tractor in bare feet, sandals, or sneakers. Wear additional protections including non-slip safety boots or shoes, and safety goggles and gloves, etc. as appropriate or required by currently applicable local laws and regulations. Wear ear protection in a noisy environment to prevent hearing damage and reduce operator fatigue.

10.NEVER allow a passenger on any portion of the tractor.

11.Remain seated in the operator’s station when operating the tractor.

12.Make sure that the brakes, other mechanical components are free from misadjustment and excessive wear. Replace any excessively worn or damaged component immediately. At regular intervals, check that all the nuts, bolts and screws are appropriately tightened. (For details, see “Chapter 13. MAINTENANCE”)

Sc2450 Operator's Manual

1-3

1. SAFETY PRECAUTIONS

13.Always keep your tractor clean. Dust, grease or grass clippings accumulated on your tractor can lead to fire accidents or personal injury.

14.Use the handholds and running board steps when getting on and off the tractor to help prevent accidental falls. Keep the running boards clear of mud and debris.

15.Only use the implements that satisfy the requirements in this manual or are approved by your Cub Cadet Yanmar dealer. (See “4. IMPLEMENT CAPACITIES”)

16.When using only front or rear mounted implements, install an appropriate weight(s) or counter balance to the front or rear of your tractor to prevent upsetting of the tractor. If you choose to use the front loader, mount an implement or ballast to the 3-point hitch in order to get the tractor to stabilize. Observe the instructions about safety in the manual for the implement to be used.

17.Do not attempt to modify your tractor. Modification can deteriorate the performance and/or safety of your tractor, possibly leading to personal injury or property damage.

3. Safe Practices for Operating Your Tractor

1. Starting Your Tractor

1. Remain seated in the operator’s station when starting the engine, or actuating the levers or controls. Do not start the engine or operate controls while standing beside the tractor.

2. Before starting the engine, make sure that the forward and reverse drive pedal are in the neutral positions, the parking brake is engaged, and the Power Take Off (PTO) is disengaged.

3. Always keep the seat belt fastened around your waist whenever the tractor has the Roll-Over Protective Structure (ROPS).

4. Start the engine of your tractor only by using the starter key switch. Do not attempt to start the engine by short-circuiting across the starter solenoid terminals with a jumper wire, or by bypassing the safety start switch. This defeats the safety interlock circuit and the tractor may begin to move and/or the Power Take Off (PTO) shafts may begin to rotate, possibly leading to personal injury or property damage.

5. Do not run or idle the engine in a confined area that is poorly ventilated or not ventilated at all. The engine emits carbon monoxide gas that is colorless, odorless and can cause death.

6. Before operation, check that all the safety features are functioning correctly. Never tamper with safety devices. Check their proper operation regularly. Contact your Cub Cadet Yanmar dealer if safety devices malfunction.

7. Avoid accidental contact with control pedals while the engine is running, as this can cause unexpected movement of the tractor.

8. Never leave a running machine unattended.

9. Do not attach or use towed equipment by a drawbar or a drawing device/attachment. Usage of the drawbar or drawing device/attachment is/ are not allowed in this tractor.

1-4

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

2. Working with Your Tractor

1. Make sure that all the covers and guards are in correct position. Replace any missing or damaged cover immediately.

2. Before turning or when traveling on a rough terrain, or before stopping, decrease the tractor speed in order to prevent upsetting.

3. Use extra caution when operating over rough ground, when crossing ditches or slopes, and when turning corners.

4. Do not attempt to turn with the differential lock engaged. Attempting to turn the tractor while the differential lock is engaged can lead to a roll-over.

5. Stay clear of ditches, holes, embankments or ponds. A hazard of tractor upset can occur more easily if the ground is soft or wet. Before entering an area covered with tall grass, walk the area to detect any obstacles.

6. Always watch where you are going, especially at blind corners, trees, or other objects that can obscure your vision. Remain alert when you are approaching the end of a row, trees or any obstacle.

7. When two or more people are working in one area, always keep in good communication with each other.

8. Do not get on or off a moving tractor.

9. Make certain all tractor lights are illuminated when operating at night.

3. Considerations for Safety of Children

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine. They do not understand the dangers. Never assume they will remain where you last saw them.

1. Keep children out of the operating area and in the watchful care of an adult other than the operator.

2. Be alert if a child enters the work area, stop your tractor immediately.

3. Never allow a child to ride on the tractor. They may fall off and be seriously injured or interfere with safe machine operation.

4. Never allow children under 16 years old to operate the machine. Children 16 years and over should only operate machine under close parental supervision and proper instruction.

5. Be extremely careful when backing the tractor. Before and during backing, look back and downward. A child may be in your path.

6. Use extra care when approaching blind corners, shrubs, trees or other objects that may obscure your vision of a child or other hazard.

7. Never allow a child to play on the tractor or implement.

8. Keep children away from hot or running engines. They may suffer burns.

9. Park your tractor on a solid, flat and level place. Engage the parking brake securely, remove the key from the starter key switch to prevent unauthorized operation. If parking on a slope is unavoidable, park the tractor across the slope and chock the wheels.

Sc2450 Operator's Manual

1-5

1. SAFETY PRECAUTIONS

4. Operate Your Tractor on Slopes

On a slope, the tractor is less stable and more prone to tip-over, possibly leading to serious injury or death. Remain very cautious when your tractor is on any slope.

A2019005

DO:

●Operate up and down slopes, not across.

●Remove obstacles such as rocks, limbs, etc.

●Watch for holes, ruts or bumps. Uneven terrain

could overturn the machine. Tall grass can hide such obstacles.

●Place the transmission in the slow range when climbing or descending slopes.

●Keep all movement on the slopes slow and gradual. Do not make sudden changes in speed or direction. Rapid engagement or braking could cause the front of the machine to lift and rapidly flip over backwards which could cause serious injury.

●Avoid starting or stopping on a slope. If tires lose traction, disengage the Power Take Off (PTO) and proceed slowly straight down the slope.

●To avoid upset, move backward up a steep slope. If backing on the slope is not comfortable, do not attempt to continue. Avoid an extremely steep slope.

●When moving forward to escape from a ditch, or deep mud, or when traveling on a steep slope, the risk of the tractor upsetting backward is high. Always move backward to escape these situations. In the 4-wheel drive mode, special caution is needed to avoid false confidence in the tractor’s ability to climb slopes.

DO NOT:

●Do not mow near drop-offs, ditches or embankments. The mower could suddenly turn over if a wheel goes over the edge of a cliff or ditch, or if an edge caves in.

! WARNING

●Before approaching a slope, select an appropriate speed setting. Be sure to run the tractor at a lower speed on slopes.

●Suddenly starting the tractor on an uphill can cause the front wheels to jump off the ground, and this situation poses an extreme danger. To avoid this problem, run the engine at a lower speed, and gently start the tractor.

●Do not park the tractor on a slope. If parking on a slope is unavoidable, chock the tires, and engage the parking brake securely.

1-6

Sc2450 Operator's Manual

5. Travel on a Road

1. SAFETY PRECAUTIONS

1. Disengagement of the 4-wheel drive is recommended.

2. Remember that the braking characteristics differ between the 2-wheel drive and 4-wheel drive modes. Be aware of the current drive mode and use carefully.

3. Before turning, always slow down the tractor. High-speed turn may cause the tractor to tip over.

4. When traveling on a road, be sure that the Slow Moving Vehicle (SMV) emblem is on the tractor and is clearly visible. Use the hazard lights and turn lights as required by the currently effective local laws or regulations.

5. Strictly observe all the currently effective local traffic and safety laws and regulations.

6. Turn ON the headlights as required by the currently effective local laws or regulations.

7. Always travel at a speed that allows you to

8. Avoid engaging differential lock while traveling on

9. While traveling on a road, do not suddenly turn

10.While on a road, do not attempt to operate an

6. Safe Practices for Parking Your Tractor

1. Disengage the Power Take Off (PTO), lower the implement to the ground, set the forward and reverse drive pedal in the neutral positions, engage the parking brake securely, stop the engine and remove the key from the starter key switch.

2. Before leaving your tractor, be sure the tractor is completely stopped.

3. Do not park on a steep slope. Rather, park on

4. Allow the tractor to cool at least 5 minutes before

maintain control of the tractor.

a road. It may cause the operator to lose control of the tractor.

the steering wheel. Such an action can lead to loss in the stability of the tractor, and can cause an extremely dangerous situation.

implement. During transportation, put the 3-point hitch control/cutting height adjustment lever in its raised position and lock it with the position stop knob. Do not fully close the hydraulic flow control/ stop knob.

solid, flat, level ground whenever possible. If parking on a slope is unavoidable, park the tractor across the slope, and lower the implement to the ground and chock the wheels.

being stored.

Sc2450 Operator's Manual

1-7

1. SAFETY PRECAUTIONS

7. Operate the Power Take Off (PTO)

1. Before getting off the tractor, connecting/ disconnecting an implement, adjusting, cleaning or servicing a Power Take Off (PTO)-driven implement, make sure that all the moving components are at a standstill.

2. Ensure that the Power Take Off (PTO) shaft cover is always in place. Replace the Power Take Off (PTO) shaft cap only when the shaft is at a standstill.

8. Use the 3-Point Hitch (Option)

3. Before installing or operating Power Take Off (PTO)-driven implement, carefully study the manufacturer’s Operator’s Manual and the safety decals on the implement.

4. When installing the Power Take Off (PTO)- driven implements, engage the parking brake securely and chock the four wheels. Do not approach or access any rotating component.

1. Use the 3-point hitch only in conjunction with the implement that is specifically designed for use with the 3-point hitch.

2. Before using a 3-point hitch mounted implement, the appropriate counterbalance may need to be installed on the front of the tractor.

9. Safety Frame (Roll-Over Protective Structure) (ROPS) Precautions

Your tractor is equipped with a Roll-Over Protective Structure (ROPS) which must be maintained in a fully functional condition. Check overhead clearance carefully before driving under power lines, wires, bridges or low hanging branches, before entering or leaving buildings, or in any other situation where the operator and/or Roll-Over Protective Structure (ROPS) may be stuck, which could result in serious injury.

1. Never modify the Roll-Over Protective Structure (ROPS) in any way.

2. Never attempt to straighten or re-weld any part of the main frame or retaining brackets that have been damaged. Doing so may weaken the structure and endanger your safety.

3. Never secure any parts on the main frame or attach the safety frame with anything other than the special fasteners specified.

4. Never attach ropes, chains, or cables to the RollOver Protective Structure (ROPS) for pulling purposes.

5. Although the Roll-Over Protective Structure (ROPS) provides the operator the maximum protection possible, never take unnecessary risks.

1-8

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

10. Safe Practices for Servicing Your Tractor

Before starting any servicing work, park your tractor on solid, level ground, engage the parking brake securely, disengage the Power Take Off (PTO), lower the implement to the ground, set the forward and reverse drive pedal to the neutral position, stop the engine and remove the key from the starter key switch.

1. Always keep a first-aid kit and a fire extinguisher readily available.

2. Before accessing the engine, muffler, radiator or other possibly hot components, wait until the tractor has fully cooled off.

3. Use extreme care in handling diesel fuels. They are extremely flammable and the vapors are explosive. Use only an approved container.

4. Be sure to stop the engine before refueling. After refueling, replace fuel cap securely and wipe off any spilled fuel before starting the engine as it may cause a fire or explosion.

5. Do not smoke while refueling. Keep any spark or open flame away from the fuel tank.

6. Never refuel the machine indoors because fuel vapors will accumulate in the area.

7. Never store the fuel container or machine inside where there is an open flame or spark, such as a gas hot water heater, space heater or furnace.

8. Do not smoke while working around the battery. Keep any spark or open flame away from the battery. The battery emits hydrogen and oxygen gas, in particular, during recharging and can pose a hazard of explosion.

9. Prior to “jump starting” a tractor that has a fully depleted battery, read and follow all the instructions in “Chapter 15. SERVICE THE ELECTRICAL SYSTEM”.

10.Carefully loosen the radiator cap to the first stop, and allow excessive pressure to escape, and only then remove the radiator cap. If the tractor is equipped with a coolant reserve tank, add coolant or water to the reserve tank, not to the radiator (See “Check the Cooling System” on page 14-12 in “Chapter 14. PERIODIC SERVICE”).

11.Before working on or around electric components, first disconnect the battery ground cable.

12.To prevent a spark occurring from short-circuit, disconnect the battery grounding (–) terminal first and reconnect last.

13.The operator must not mount a tire onto a rim. Only qualified personnel should do this task.

14.Always keep the tires at a correct pressure level. Do not exceed the recommended tire pressure specified in the Operator’s Manual.

Sc2450 Operator's Manual

15.Keep the tractor securely supported while changing the wheels. Be sure to tighten the wheel bolts at the specified tightening torque.

1-9

1. SAFETY PRECAUTIONS

16.Avoid working under any hydraulically supported devices. Such devices can settle, suddenly leak down, or be accidentally lowered. If working beneath the tractor, or an implement, is unavoidable, be sure to support the tractor or implement with appropriate stands or lift apparatus.

17.High pressure hydraulic fluid, when released, can penetrate human skin, possibly leading to serious personal injury. Before disconnecting any hydraulic line, fully release the internal pressure. Before exerting a pressure to the hydraulic system, make sure that all connections are tight and all the lines, pipes and hoses are free from fissure/crack or any other damage.

18.Check brake operation frequently. Adjust and service as required.

19.Do not change the engine governor settings or overspeed the engine. Excessive engine speeds are dangerous.

20.Observe proper disposal laws and regulations. Prior to disposal, determine the proper method to dispose of waste from your local Environmental Protection Agency. Recycling centers are established to properly dispose of materials in an environmentally safe fashion.

21.Use proper containers when draining fluids. Do not use food or beverage containers that may mislead someone into drinking from them. Properly dispose of the containers immediately following the draining of fluids.

22.DO NOT pour oil or other fluids into the ground, down a drain or into a stream, pond, lake or other body of water. Observe Environmental Protection Agency regulations when disposing of oil, fuel, coolant, brake fluid, filters, batteries, tires and other harmful waste.

23.We do not recommend the use of a pressure washer or garden hose to clean your unit. They may cause damage to electrical components; spindles; pulleys; bearings; or the engine. The use of water will result in shortened life and reduce serviceability.

WARNING: YOUR RESPONSIBILITY: Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the machine.

1-10

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

11. Understand the Tractor Safety Decals

■ Safety-Alert Symbol

The tractor safety decals illustrated in this section are provided in critical areas on the tractor so that people including the operator can remain always aware of potential hazards. The tractor safety decals contain the words DANGER, WARNING and CAUTION together with the safety-alert symbols. DANGER and WARNING stand for the most serious hazards. The Operator’s Manual also contains special safety messages that explain potential hazards about which the operator must remain cautious. These messages are presented together with the word CAUTION and the safety-alert symbols.

■ Care of DANGER, WARNING and CAUTION Decals

1. Always keep all the danger, warning and caution

decals clean and clearly legible.

2. Clean the danger, warning and caution decals with

soap water, and wipe dry with clean soft cloth.

3. Replace damaged or missing danger, warning and

caution decals with new decals available from your local Cub Cadet Yanmar dealer.

4. If a component having a danger, warning or caution

decals is replaced with a new one, make sure that a new decal is on the same location as on the old component.

5. Affix a new danger, warning or caution decals flat on a

clean, dry surface, squeezing out trapped air.

Sc2450 Operator's Manual

1-11

1. SAFETY PRECAUTIONS

(A) CY-1A8160-65300

! DANGER

TO AVOID INJURY OR DEATH:

●Do not start engine by shorting across starter

terminals or bypassing safety start switch.

●Start engine only from seat with transmission and

PTO OFF.

(B) CY-1A7880-65610

! WARNING

STAY CLEAR OF ENGINE FAN AND FAN BELT

3016482

P3014961

DANGER

(A)

TO AVOID INJURY OR DEATH:

Do not start engine by

䇭shorting across starter 䇭terminals or bypassing 䇭safety start switch.

Start engine only from

䇭seat with transmission 䇭and PTO OFF.

1A8160-65300

(B)

1-12

STAY CLEAR OF ENGINE FAN AND FAN BELT

WARNING

㪈㪘㪎㪏㪏㪇㪄㪍㪌㪍㪈㪇

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

(C) CY-1A8160-51520

! DANGER/POISON (E)

●SHIELD EYES: EXPLOSIVE GASES CAN CAUSE

BLINDNESS OR INJURY.

●NO SPARKS, FLAMES, SMOKING.

●SULFURIC ACID CAN CAUSE BLINDNESS OR

SEVERE BURNS.

●FLUSH EYES IMMEDIATELY WITH WATER.

SEEK MEDICAL HELP RIGHT AWAY.

●KEEP OUT OF REACH OF CHILDREN. DO NOT

TIP.

●KEEP VENT CAPS TIGHT AND LEVEL.

(C)

P3014933

P3013722a

Sc2450 Operator's Manual

1-13

1. SAFETY PRECAUTIONS

(D) CY-1A7880-65601

! WARNING

READ OPERATOR'S MANUAL

1. Do not operate the machine without guard shields

and safety devices in place and working.

2. Keep all riders off tractor during operation.

3. Make certain everyone is clear of machine before

starting engine or operation.

4. Keep hands, feet and clothing away from power-

driven parts.

5. Use seat belt.

6. Reduce speed when turning or operating around

hazards, on rough ground or steep slopes.

7. Do not allow operation of the machine by

untrained personnel.

8. Stop engine, lower implement to ground and lock

park brake before dismounting.

9. Wait for all movement to stop before servicing

machinery.

10.Remove key if leaving tractor unattended.

11.Securely support tractor and implements before

working underneath.

12.On public roads use SMV emblem and hazard

lights.

13.Do not jump if machine tips.

(D)

P3014940

WARNING

(E) CY-1A7880-65630

IMPORTANT

12V DC OUTLET

1. DO NOT CONNECT A LIGHT OR LOAD OF

MORE THAN 120 WATTS.

2. DO NOT USE AS A CIGARETTE LIGHTER.

3. REMOVE PLUG FROM SOCKET WHEN NOT IN

USE.

4. DO NOT USE WHEN WET.

1A788

5601

(E)

P3014958

IMPORTANT

12V DC OUTLET

1.DO NOT CONNECT A LIGHT OR LOAD OF MORE THAN 120 WATTS.

2.DO NOT USE AS A CIGARETTE LIGHTER.

3.REMOVE PLUG FROM SOCKET WHEN NOT IN USE.

4.DO NOT USE WHEN WET.

1A7880-65630

1-14

Sc2450 Operator's Manual

1. SAFETY PRECAUTIONS

(F) CY-1A7880-65351

! WARNING

Only use PTO in reverse when there are no children or others around

(G) CY-1A7882-85230

! WARNING

TO AVOID INJURY OR DEATH FROM ROLLOVER:

• Keep Rollover Protective Structure (ROPS) fully extended.

• Do not jump if machine tips.

• Use seat belt.

(F)

P3014940

WARNING

Only use PTO in reverse when there are no children or others around

(G)

THERE IS NO OPERATOR PROTECTION WHEN THE ROPS IS IN THE FOLDED POSITION.

• Fold the ROPS only when absolutely necessary.

• When structure must be down:

• Do not use seat belt.

• Drive with extra care.

A3016424

WARNING

TO AVOID INJURY OR DEATH FROM ROLLOVER:

•

Keep Rollover Protective Structure (ROPS) fully extended.

• Do not jump if machine tips.

•

Use seat belt.

THERE IS NO OPERATOR PROTECTION WHEN THE ROPS IS IN THE FOLDED POSITION.

•

Fold the ROPS only when absolutely necessary.

When structure must be down:

•

Do not use seat belt.

•

Drive with extra care.

1A7882-85230

Sc2450 Operator's Manual

1-15

(H) CY-198220-65621

! WARNING

AVOID INJURY FROM PTO

●Keep all shields in place

●Keep hands, feet and clothing away

●Operate only with 540 RPM

1. SAFETY PRECAUTIONS

(I) CY-1A8160-65310

! WARNING

TO AVOID INJURY:

Before leaving or servicing machine,

●Stop engine.

●Set parking brake.

●Park on level ground.

●Lower all implements to the ground.

●Remove key.

P3014938

A3016425

(H)

WARNING

AVOID INJURY FROM PTO Keep all shields in place Keep hands,feet and clothing away Operate only with 540 RPM

(I)

1-16

Sc2450 Operator's Manual

2. SERVICE THE PRODUCT

Your Cub Cadet Yanmar dealer is committed to delivering the best possible service to our customers, including the enabling of optimal performance of the tractor. After carefully reading this manual, the tractor owner can be expected to perform certain service operations. However, when parts and components and major jobs are required, contact your local Cub Cadet Yanmar dealer. Specify the serial numbers of the tractor and that of the Roll-Over Protective Structure (ROPS). Find the serial numbers and enter them into the following table.

Type Se rial No.

Tractor

Engine

Roll-Over Protective Structure (ROPS)

Date of Purchase

Name of Dealer

3016482

(A)

(B)

(A) Tractor identification plate with tractor serial

number (B) Engine serial number (C) Roll-Over Protective Structure (ROPS) serial

number

P3014901

(C)

A3016424

Sc2450 Operator's Manual

2-1

3. SPECIFICATIONS

Specifications of the Tractor

1. Specifications Table

Model Sc2450

Power Take Off (PTO) Power hp (kW) 16.5 (12.3)

Maker YANMAR

Model 3TNM72

Type

Number of Cylinders 3

Bore and Stroke in. (mm) 2.834 × 2.913 (72 × 74)

Total Displacement cu. in. (L) 55.1 (0.903)

Engine

Capacities

Dimensions

Weight (with Roll-Over Protective Structure (ROPS) and R4 Tires) lb. (kg) 1356 (615)

Gross Power hp (kW) 24.0 (17.9)

Net Power hp (kW) 20.2 (15.1)

Rated Revolution

High Idle Speed

Low Idle Speed

Maximum Torque ft•lbs (N•m) 40.3 (54.6)

Battery 12V BP24 , CCA: 540 A

Fuel Diesel Fuel No.1-D , No.2-D

Fuel Tank US gal (L) Approximately 5.8 (22)

Engine Oil US qt. (L) Approximately 2.2 (2.1)

Engine Coolant US qt. (L) Approximately 3.4 (3.2)

Transmission/Hydraulic Oil US gal (L) Approximately 2.0 (7.5)

Overall Length (without 3-Point Hitch) in. (mm) 82.7 (2100)

Overall Length (with 3P) in. (mm) 95.5 (2425)

Overall Width (with R4 Tires) in. (mm) 44.5 (1130)

Overall Height (with Roll-Over Protective Structure (ROPS), R4 Tires)

Overall Height (with R4 Tires) (Top of Steering Wheel)

Wheel Base in. (mm) 55.1 (1400)

Min. Ground Clearance (with R4 Tires) in. (mm) 7.5 (190)

Tread (with R4)

Front in. (mm) 34.6 (879)

Rear in. (mm) 32.2 (820)

-1

min

(rpm)

-1

(rpm)

min

-1

min

(rpm)

in. (mm) 83.46 (2120)

in. (mm) 49.9 (1267)

Indirect Injection, Vertical,

Water-Cooled, 4 Cycle Diesel

3200

3370

1150

3-1

Sc2450 Operator's Manual

3. SPECIFICATIONS

Traveling System

Hydraulic Unit

Power Take Off (PTO)

Ag (R1)

Tire

Clutch –

Steering Power Steering

Transmission

Drive Selected 4WD

Brake Wet plates

Minimum Turning Radius ft. (m) 7.2 (2.2)

Differential Lock Foot Pedal Control

Hydraulic Control System Type Position Control

Pump Capacity (main)

Pump Capacity (steering)

3-Point Hitch Limited Category I

Max. Lift Force

System Pressure psi (MPa) 1813 (12.5)

Type Electric Clutch

Rear

Mid

Turf (R3)

Industrial (R4)

Lift Point lb. (kg) 1036 (470)

24 in. Behind Lift Point lb. (kg) 661 (300)

Shaft Size SAE 1-3/8, 6-Splines

Type Independent

Speed/Engine

Shaft Size SAE 16/32, 15-Splines

Type Independent

Speed/Engine

Front 18 × 8.50-10

Rear 26 × 12.00-12

Front 18 × 8.50-10

Rear 26 × 12.00-12

Front 18 × 8.50-10

Rear 26 × 12.00-12

Hydrostatic Transmission,

2 Range Speeds

US gal/min

(L/min)

US gal/min

(L/min)

-1

min

(rpm)

-1

(rpm)

min

Approximately 3.4 (13.2)

540 / 3111

2100 / 3338

2. Traveling Speeds (Reference)

Model Sc2450

Range Gear Lever mph km/h

Forward Slow 0-5.8 0-9.4

Fast 0-9.0 0-14.6

Reverse Slow 0-3.5 0-5.6

Fast 0-5.4 0-8.7

Sc2450 Operator's Manual

3-2

4. IMPLEMENT CAPACITIES

The Cub Cadet Yanmar tractor has been carefully tested in the configuration equipped with implements sold or approved by Cub Cadet Yanmar and has proven to perform properly. Do not use any implement that has not been sold or recommended by a Cub Cadet Yanmar dealer, or that fails to satisfy the specified values given below. Never mount an implement that is not approved for the Cub Cadet Yanmar tractor. Using unapproved implements could result in malfunction, failure, and damage to the tractor and/or implement, and increase the possibility of injury to the operator or other people. The Cub Cadet Yanmar warranty does not cover any malfunction or failure that results from use of an unapproved implement.

24in. Behind Lift Point

Maximum

Lifting Capacity

lb. 661

kg 300 250 800

A3013714a

Implement Remarks Unit Amount

Front - End Loader

Mid - Mount

Mower

Rear Mount

Rotary Tiller

Box Scraper (Box Blade)

Rear Blade

Backhoe

Implement Weight

As specified in the list

Maximum Lift Capacity (at Pivot) lb. (kg) 700 317

Maximum Overhang (Pivot - Front Tire Center) in. (mm) 40 1022

Maximum Weight lb. (kg) 441 200

Maximum Oil Pressure psi (MPa) 1885 13

Maximum Cutting Width in. (mm) 60 1524

Maximum Weight lb. (kg) 254 115

Maximum Cutting Width in. (mm) 48 1219

Maximum Weight lb. (kg) 351 159

Maximum Tilling Width in. (mm) 42 1067

Maximum Weight lb. (kg) 342 155

Maximum Cutting Width in. (mm) 48 1219

Maximum Weight lb. (kg) 254 115

Maximum Cutting Width in. (mm) 60 1524

Maximum Weight lb. (kg) 176 80

Maximum Lift Capacity with boom and dipperstick fully extended no more than 36 in. (91 cm) above ground level.

Maximum Weight lb. (kg) 551 250

below.

Maximum Vertical

Hitch Load

551 1763

Gross Towing Load

lb. (kg) 205 93

Maximum

4-1

Sc2450 Operator's Manual

5. NAMES AND FUNCTIONS OF COMPONENTS

NAMES AND FUNCTIONS OF COMPONENTS

Tractor Control Overview

1. Overview

(1)

(2)

(3)

(4)

(11)

(5)

(6)

3016450

(12)

A3016422

(10)

3014906

(1) Headlights (2) Hood (3) Fuel inlet (4) Seat (5) Seat belt (6) Fender (7) Rear tires (8) Mid-Power Take Off (PTO) (9) Front tires

(9)

(13)

(8)

(7)

(18)

(17)

(16)

A3016423

(15)

(10) Work lights (11) Hood guard (12) Roll-Over Protective Structure (ROPS) (13) Hydraulic quick couplers (Option) (14) 12V DC outlet (for additional rear work light) (15) Rear Power Take Off (PTO) shaft (16) Tail lights (17) Turn signal/hazard lights (18) Slow Moving Vehicle (SMV) emblem

(14)

(13)

Sc2450 Operator's Manual

5-1

+ 124 hidden pages
