M&S Systems Home Theater System User Manual

Mini-Cube Home Theater Package

Model MNCS / MNCSB

Mini-Cube Speakers

Model MNC / MNCB

Instruction Manual

INTRODUCTION

M&S Systems is introducing cube speakers (MNC) and a cube speaker
package for Home Theater applications (MNCS) offering quality sound at
an affordable price. The compact size allows for installation in any room
without being intrusive to your decor. These products also offer many
features, including the following:

• 360° swivel speaker allow for full area coverage

• A complete frequency range when a subwoofer is added

• Ceiling or wall mount

• Compact design

• Shielded magnets for the cubes and center channel

• Mounting bracket for the cubes

DESCRIPTION

MNC units have dual 2-1/2”, two-way speakers with paper cones. Each
package consists of one pair of speakers per MNC which are available in
white (MNC) and black (MNCB) matte finishes.

Frequency Response 250 Hz to 15 kHz
Maximum Power Rating 70 Watts
Continuous Power Rating 35 Watts
Impedance 4 Ohms
Height 6.5 “
Width 3.5 “
Depth 4.5 “
Weight 2.33 lbs.

The center channel for the Mini-Cube Home Theater Package has dual
4” speakers with polypropylene cones and a ½” polycarbonate dome
tweeter. It is available in a black matte finish.

Frequency Response 250 Hz to 15 kHz
Maximum Power Rating 70 Watts
Continuous Power Rating 35 Watts
Impedance 6 Ohms
Height 5.4 “
Width 14.5 “
Depth 5.9 “
Weight 8 lbs.

1 of 7

The subwoofer for the Mini-Cube Home Theater Package has an 8”
active woofer. It is available in a black matte finish.

RMS Power Rating 100 Watts
Frequency Response 40 Hz to 350 Hz
Crossover 40 Hz to 180Hz (Adjustable)
Controls Power, Volume, Crossover

Frequency, Phase
Connections RCA Jacks and Spring Terminals
Height 13.3 “
Width 9.8 “
Depth 13.7 “
Weight 20 lbs.

UNPACKING YOUR SPEAKERS

After carefully unpacking your speakers, the carton and the packing
material should be saved for possible use later. If any speaker appears
to be damaged, do not attempt to repair or to connect the unit to the
amplifier. Repack the speaker and notify your distributor or M&S
Systems for replacement or repair.

SPEAKER PLACEMENT

The cube units can be mounted on the ceiling or walls of the room,
therefore, many combinations are possible. The MNC or the front and
rear cube speakers of the MNCS package should be separated by 6 to 8
feet for good stereo separation. They should not be any closer than 2
feet to any adjacent surface (wall or ceiling). The cube brackets should
be attached to a stud or mounted anchor with bolts to provide secure
mounting.

NEVER MOUNT THE BRACKETS TO SHEETROCK

WITHOUT SOME TYPE OF ANCHOR. The placement of the center

channel and the subwoofer (MNCS system only) are not as critical. The
center channel is best located on top of the TV cabinet or on a shelf
above the TV. The subwoofer should be placed near a corner at the front
or rear of the room for best bass sound.

The MNC unit is designed with a swivel joint between the two speakers.
Each speaker can be aimed individually. The unit also comes with a
mounting bracket for attachment to a wall or ceiling. The bracket screws
into the threaded socket on the bottom of the unit, and may be adjusted
so that the speakers point in the desired direction. (See figure 1)

Note: When mounting speakers from wall surfaces additional tightening
of the hex screw may be required.

2 of 7
