M&S Systems 8-Ohm User Manual
8-Ohm Ceiling Speakers
For Music and Home Theater
Owners Manual
INTRODUCTION
M&S ceiling speakers are designed to provide clear,
sharply-focused audio reproduction while remaining unobtrusively in the background. You’ll find a variety of power
ratings and designs in flush-mount or recessed versions.
M&S Systems has a full range of ceiling speakers that will
bring out the best in any home-theater or whole-house stereo music system. These products also offer many features,
including the following:
• Swivel tweeter (S40C, S50C, S70C)
• Designed to handle power requirements of most stereo
amplifiers
• Ceiling mount
• Discrete design
• Cam-lock mounting system
DESCRIPTION
STEREO CEILING SPEAKERS (SOLD IN PAIRS)
S70C
Frequency Response 35 Hz to 20 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 10 ¾” Diameter x 4” Depth
Specifications
Mounting Dimensions 9 3/8” Diameter x 3 ½” Depth
Grille Metal
Color White
Page 1
70 Watts
Two way; 8” woofer, 1” soft
dome swivel tweeter
Page 2
S50C
Frequency Response 50 Hz to 20 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 9” Diameter x 3 3/8” Depth
Specifications Two way; 6½” woofer, 1” soft
Mounting Dimensions 7 ¾” Diameter x 3” Depth
Grille Metal
Color White
50 Watts
dome swivel tweeter
S40C
Frequency Response 60 Hz to 20 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 9” Diameter x 3 3/8” Depth
Specifications
Mounting Dimensions 7 ¾” Diameter x 3” Depth
Grille Metal
Color White
40 Watts
Two way; 6½” woofer, 1” mylar
swivel tweeter
S30C
Frequency Response 70 Hz to 16 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 10 ¾“ Diameter x 3 ¼” Depth
Specifications
Mounting Dimensions 9 3/8” Diameter x 2 ¾” Depth
Grille Metal
Color White
30 Watts
Dual cone 8”, wide range response
S30C3
Frequency Response 70 Hz to 16 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 10 ¾” Diameter x 4” Depth
Specifications Dual cone 8”, wide range
Mounting Dimensions 9 1/2” Diameter x 3 3/4” Depth
Grille Metal
Color White
30 Watts
response
S30C2
Frequency Response 100 Hz to 15 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 7 ¾” Diameter X 3 3/8” Depth
Specifications Dual cone 5 ¼”, wide range re-
Mounting Dimensions 6 ½” Diameter X 3 1/8” Depth
Grille Metal
Color White
30 Watts
sponse
S100CS*
Frequency Response 35 Hz to 20 kHz
Maximum Power
Rating
Impedance 8 Ohms
Overall Dimensions 10¾” Diameter x 4 1/8” Depth
Specifications
Mounting Dimensions 9 3/8” Diameter x 3 5/8” Depth
Grille Metal
Color White
*Note: Recommend using MR82 mounting rings with this speaker.
Page 3
100 Watts
Two way; 8” woofer, 1” swivel
tweeter
