Mr. Coffee BVMC-EL1 User Manual

Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions,

Boca Raton, Florida 33431.

U.S. 1-800-MR COFFEE (1-800-672-6333)

Canada 1-800-667-8623

Visit us at www.mrcoffee.com

You will find exciting and entertaining tips and ideas,

including great recipes!

SPR-062911-529

de Jarden Consumer Solutions, Boca Raton, Florida 33431.

Visítenos en www.mrcoffee.com

Ahí encontrará consejos e ideas excitantes y entretenidos,

¡incluyendo excelentes recetas!

Printed in China/Impreso en China P.N. 147733

User Manual / Manual del Usuario

Café Latte Café Latte

www.mrcoffeelatte.com

IMPORTANT SAFEGUARDS

To reduce the risk of fire, electric shock and/or injury to persons, basic safety precautions should always be followed when using electrical appliances, including the following:

1. READ ALL INSTRUCTIONS BEFORE USING THE COFFEEMAKER.

2. Turn the appliance off and unplug the power cord from the power source when the appliance is not in use and before cleaning. Allow the appliance parts to cool before putting on or taking off parts and before cleaning the appliance.

3. Do not touch the appliance’s hot surfaces. Use handles or knobs.

4. To protect against electric shock, do not immerse the power cord, power plug or appliance in water or any other liquid.

5. Close adult supervision is necessary when this appliance is used by or near children.

6. Do not operate any appliance with a damaged power cord or power plug, or operate it after the appliance malfunctions, or has been damaged in any manner. Return this appliance only to the nearest Authorized Service Center for examination, repair, or adjustment.

7. The use of accessory attachments other than MR. COFFEE® brand products may cause hazards or injuries.

8. Do not use the appliance outdoors.

9. Do not let the power cord hang over the edge of table or counter, or allow it to come into contact with hot surfaces.

10. Do not place this appliance on or near a hot gas stove or electric burner or in a heated oven.

11. To disconnect the appliance, turn it OFF, then remove the power plug from the power supply.

12. Place the appliance on a hard, flat level surface to avoid interruption or airflow underneath the appliance.

13. To protect against electric shock, do not immerse this appliance including power base, in water or any other liquid.

14. Unplug the power base from the power outlet when not in use, before repositioning and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance

15. Do not attempt to remove the pitcher from the power base until it is switched off manually.

16. This appliance is designed for household use only.

17. Do not use appliance for other than intended use.

18. Only operate with the pitcher in the base.

19. Avoid getting liquid in the connector.

20. Scalding may occur if the lid is opened during the brewing cycles.

English 2

Decanter Use and Care

Follow the instructions below to reduce or eliminate the chance of breaking the glass pitcher:

•฀฀This฀pitcher฀is฀designed฀for฀use฀with฀your฀MR.฀COFFEE

therefore must never be used on a range top or in any oven, including a microwave oven.

•฀฀Do฀not฀use฀a฀cracked฀pitcher฀or฀a฀pitcher฀having฀a฀loose฀or฀

weakened handle.

•฀฀Do฀not฀clean฀the฀pitcher฀with฀abrasive฀cleaners,฀steel฀wool฀

pads or other abrasive materials.

•฀Protect฀the฀pitcher฀from฀sharp฀blows,฀scratches฀or฀rough฀handling.

WARNING! To reduce the risk of fire or electric shock, do not remove any service covers. There are no user serviceable parts inside the Café Latte. Only authorized personnel should repair the Café Latte.

Please read ALL of the instructions in this manual carefully before you begin to use this appliance. Proper care and maintenance will ensure a long life and a trouble-free operation for this appliance. Please save these instructions and refer to them for cleaning and care tips.

Café Latte and

SAVE THESE INSTRUCTIONS

Introduction

Welcome and congratulations on the purchase of your new MR. COFFEE® Café Latte. Your new Café Latte will wake up with you in the morning and provide you breaks and treats during your hectic daily activities.

How you enjoy your MR. COFFEE® Café Latte is up to you!

Special Cord Set Instructions

1. A short power supply cord is provided to reduce the hazards resulting

from a person or pet becoming entangled in, or tripping over, a longer cord.

2. An extension cord may be used if care is exercised in its use.

3. If an extension cord is used, the marked electrical rating of the extension

cord must be at least 10 amps and 120 volts. The resulting extended cord must be arranged so that it will not drape over a countertop or tabletop where it can be pulled on by children or tripped over accidentally.

4. This appliance has a polarized plug (one blade is wider than the other).

To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

English 3

TABLE OF CONTENTS

Important Safeguards 2

Introduction 3

Diagram of Parts 5

Quick Start Guide 6

Using your Café Latte

•฀Clean฀first 9

•฀Making฀Lattes 9

•฀Making฀Hot฀Chocolate 10

Regular Cleaning and Maintenance 11

Frequently Asked Questions 12

Troubleshooting 13

Service and Maintenance 14

Warranty Information 15

English 4

DIAGRAM OF PARTS

1. Brew Basket Lid

2. Brew Basket (inside unit)

3. Water Reservoir

4. Selection Switch

5. Latte Pitcher

6. Frothing Arm and Whisk

7. Power Cord

8. Base

9. Pitcher Lid

10. Power Lever (down to

turn on / up to turn off)

11. Power Light Indicator

English 5

QUICK START GUIDE

Assemble the lid and whisk

A. Remove whisk from brew basket and

snap into place on the inside of the lid.

Just Add Water and Coffee

A. Lift the brew basket lid up and

put a paper filter into the brew basket along with ground espresso or coffee. (3 TBSP Single, 6 TBSP Double)

B. Add cold water into the reservoir

up to desired water level marking, single ( 4 oz) or double serving ( 8 oz). .

Now add ingredients to the latte pitcher

A. Remove the pitcher from its base and remove the lid by

twisting counter clockwise.

B. Add milk to the desired level marking, single or double serving

(should correspond to the water level used in the reservoir).

C. Add any other ingredients per the recipe book.

D. Secure the

lid onto the pitcher, by twisting clockwise, and place the pitcher back onto the base with the pitcher handle facing out.

English 6

Easy to use controls

A. Make sure the appliance is plugged in.

B. Push the selector switch up to the latte function.

• For heat/froth only, push down (NOTE: This will

not activate the brewing feature).

C. Lower the on/off lever to turn the appliance on.

D. The power light will illuminate while the cycle is

active and turn off when complete.

English 7

Ready to serve

A. Raise the on/off lever and remove

the latte pitcher from the base.

B. Pour latte into serving glasses and

spoon any additional foam desired to complete your latte.

Pour & Enjoy

CLASSIC LATTE

Double Serving

)

(

6 tablespoons

Espresso or Coffee

)

(

13 oz

Milk

)

(

8 oz

Water

+ Add 6 Tablespoons of ground espresso or coffee

+ Add water to the double serving marking in the

+ Add milk to the double serving marking in the

Use sugar or sweetener as desired

Froth volume will vary with the type of milk used. For Soy,

Almond, or Non-fat milk, use less milk to avoid pitcher overflow.

reservoir (8 ounces).

pitcher (13 ounces).

English 8

USING YOUR CAFÉ LATTE

CLEAN YOUR APPLIANCE BEFORE USING THE FIRST TIME

Make sure your first latte is as good as can be by cleaning your MR. COFFEE® Café Latte before its first use. Just follow these simple steps:

1. Wash latte pitcher and lid using a mild, non-abrasive detergent and water with a soft cloth.

IMPORTANT! Do not immerse your pitcher/lid in water or place in a dishwasher. This may permanently damage the product and void the warranty.

2. Replace the pitcher onto the appliance and run a cycle with water only, without

adding coffee or coffee filter. Fill the water reservoir to the single serving level and fill the latte pitcher to the single serving level.

3. When cycle is complete, turn your appliance off, discard the water in the pitcher and wash by sponge or soft damp cloth.

Your appliance is now ready to use. Enjoy it!

CLEAN YOUR LATTE PITCHER AFTER EVERY USE

The MR. COFFEE® Café Latte should be cleaned after every use.

1. Pour out remaining liquids from the latte pitcher.

2. Remove the lid and wipe with damp sponge or cloth.

3. Wash the pitcher by pouring a combination of a mild detergent and water into the pitcher and wipe clean with a soft damp cloth. Do not use any abrasive detergents or scouring pads, as this will scratch the glass and heating element of the pitcher.

IMPORTANT! Do not immerse your pitcher/lid in water or place in a dishwasher. This may permanently damage the product and void the warranty.

4. Wipe the exterior of the machine with a damp cloth.

MAKING LATTES

1. Just Add Water and Coffee.

a. Lift the brew basket lid up and put a paper filter into the brew basket along

with ground espresso or coffee.

b. Add cold water into the reservoir up to desired water level marking, single

or double serving .

2. Now add ingredients to the latte pitcher.

a. Remove the pitcher from its base and remove the lid by twisting counter

clockwise.

b. Add milk to the desired level marking, single

(should correspond to the water level used in the reservoir). c. Add any other ingredients per the recipe book. d. Secure the lid onto the pitcher, by twisting clockwise, and place the pitcher

back onto the base with the pitcher handle facing out.

NOTE: Do not exceed the max fill line as it could cause liquid to enter the motor located in the pitcher lid and permanently damage the frothing function.

English 9

or double serving
