Mr. Coffee AT13 User Manual

©2005 Sunbeam Products, Inc., d/b/a Jarden Consumer Solutions.
All rights reserved. Home Cafe,®Folgers,®Millstone®and its logos are trademarks of
The Procter & Gamble Company, Cincinnati, Ohio used under license by Sunbeam
Products, Inc. Lipton®is a registered trademark of the Unilever Group of
Companies. Used with permission. Distributed by Sunbeam Products, Inc., d/b/a
Jarden Consumer Solutions, Boca Raton, FL 33431

©2005 Sunbeam Products, Inc., d/b/a Jarden Consumer Solutions. Todos los
derechos reservados. Home Cafe,®Folgers,®Millstone®y sus respectivos logotipos
son marcas comerciales de The Procter & Gamble Company, Cincinnati, Ohio,
usadas bajo licencia por Sunbeam Products, Inc. Lipton®es una marca comercial
registrada de Unilever Group of Companies. Marca utilizada con autorización.
Distribuido por Sunbeam Products, Inc., d/b/a Jarden Consumer Solutions,
Boca Raton, FL 33431

Visit us at www.home-cafe.com

Visítenos en www.home-cafe.com

Printed in China/Impreso en China

P

.N. 116634

USER MANUAL

MANUAL DEL USUARIO

SingleServe The

One Cup

Coffeehouse

™

Cafetera de

una taza

SingleServe

™

Models/Modelos: AT13

FOR HOUSEHOLD USE ONLY. PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.

W

arranty Ser

vice and Replacement Par

ts:

U.S. Call 1-800-MR COFFEE (1-800-672-6333).

Pods: V

isit your favorite retail store to find your favorite Folgers

®

and

Millstone®cof

fee pods or Lipton

®

tea pods, or go to www

.home-cafe.com.

SÓLO P

ARA USO DOMÉSTICO. LEA TODAS LAS INSTRUCCIONES ANTES DE UTILIZAR EST

A UNIDAD.

Servicio en garantía y repuestos: En los EE.UU., llame al

1-800-MR COFFEE (1-800-672-6333).

Bolsitas: Visite su tienda favorita y obtenga sus bolsitas de café preferidas de

Folgers®y Millstone®o bolsitas de té Lipton®o bien visite www.home-cafe.com.

1

INTRODUCTION

Thank you for selecting the MR. COFFEE®Home Café®SingleServe™coffeemaker, a
ground-breaking single cup appliance designed to make a full variety of drinks and
bring the coffeehouse to your home.Your new unit can brew a delicious cup of your
favorite coffee, specialty beverage or premium tea in about a minute using expertly
prepared coffee pods with no measuring, no mess and no waste.

Please read ALL of the instructions in this manual carefully before you begin to use
this appliance. Proper care and maintenance will ensure a long life and a trouble­free operation.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and/or injury to persons including
the following:

1. READ ALL INSTRUCTIONS BEFORE
USING THE APPLIANCE.

2. Do not touch hot surfaces. Use
handles or knobs.

3. To protect against electric shock, do
not put cord, plugs or coffeemaker in
water or any other liquids.

4. Close adult supervision is necessary
when this appliance is used by or
around children.

5. Unplug from outlet when Home Café

®

coffeemaker is not in use and before
cleaning. Allow to cool before putting
on or taking off parts and before
cleaning the appliance.

6. The use of accessory attachments that
are not MR. COFFEE®HOME CAFÉ

®

brand may cause hazards or injuries.

7. Do not use outdoors.

8. Do not let cord hang over edge of
table or counter, or touch hot surfaces.

9. Only use water in the water reservoir.

10.Do not place this appliance on or

near a hot gas or electric burner or
in a heated oven.

11.To disconnect, turn unit off, then
remove plug from wall outlet.

12.Do not use appliance for other than
its intended use.

13.Use on a hard, flat level surface only,
to avoid interruption of air flow
underneath the appliance.

14.Scalding may occur if the lid is
removed during the brewing cycle.

Helpful Hint: Stop light must be red
before your can open the lid for pod
removal.

15.Do not operate any appliance with a
damaged cord or plug or after the
appliance malfunctions, or has been
damaged in any manner. Return this
appliance only to the nearest
Authorized Service Center for
examination, repair or adjustment.

16.WARNING: To reduce the risk of fire
or electric shock, do not remove any
service covers including the bottom
cover. No user serviceable parts
inside. Repair should be done by
authorized personnel only. Opening
the bottom service cover will void
the warranty.

SPECIAL CORD SET INSTRUCTIONS

Supplied with your appliance is a short power supply cord to reduce the hazards
resulting from a person or pet tripping, or becoming entangled, by a longer cord.
A polarized plug (one blade is wider than the other) has been included with this
appliance. This plug will fit in a polarized outlet only one way, and reduces the risk
of electric shock. Reverse the plug if it does not fit into the outlet fully. Call a qualified
electrician if the plug still does not fit. Never try to modify the plug in any way. An
extension cord may be purchased and used if care is exercised with its use. If an
extension cord is used, the marked electrical rating of the extension cord must be at
least 12 amps and 120 volts. The resulting extended cord must be arranged so that
it will not drape over the counter top or table top where it can be pulled on by
children or tripped over accidentally

PLEASE SAVE THESE INSTRUCTIONS

AND REFER TO THEM FOR

CLEANING AND CARE TIPS.

2

5

3

2

4

9

a
b
c
d
e

10

6

1

8

7

11

DIAGRAM OF PARTS

1 Removable 32oz. Water Reservoir
2 Water Reservoir Lid
3 Coffeemaker Lid
4 Brew Basket
5 Open Button
6 Adjustable Dispensing Spout
7 Drip Tray
8 Drip Tray Grid
9 Base
10Rotating Water Reservoir Base

11 Control Panel

a 7 oz. Button/Indicator Light
b 9 oz. Button/Indicator Light

c 14 oz. Button/Indicator Light
d Specialty Pod Button/Indicator Light

e Stop/Reset Button/Indicator Light

12 Single-Pod Pod Holder for Coffee Pods

or Tea Pods

13 Double-Pod Pod Holder for Coffee Pods

or Tea Pods

14 Specialty-Pod Pod Holder for Specialty

Pods

15 Home Cafe’®Folgers®Millstone®and

Lipton®Pod

16 Home Cafe’®Folgers®and Millstone

®

Specialty Pod (for cappuccinos, lattes
and other specialty beverages)

15

16

14

13

12

(Single)

(Double)

(Specialty)

PREPARING YOUR HOME CAFÉ

®

COFFEEMAKER BEFORE FIRST USE

1. Wash Water Reservoir in warm soapy water. Rinse thoroughly.

2. Open the lid by pushing the OPEN Button located on the
upper right front of the appliance. Read and remove the
yellow insert. Remove and wash Pod Holders and Brew Basket
with attached Adjustable Dispensing Spout (top rack only
dishwasher safe).

3. Replace the above parts and selected pod holder in the
coffeemaker and close the lid by pushing down firmly until it
locks into place.

4. You MUST prime the coffeemaker PRIOR to the very first use.
To prime the unit and clean the inside of your coffeemaker:

m Fill the Water Reservoir with water. (Picture 1) Press the

OPEN Button to open the Coffeemaker Lid. (Picture 2)
Read and remove the yellow insert. Insert a Pod Holder
without a pod. Plug the unit in. The red STOP Indicator
Light will turn on.

m Place a mug on the coffeemaker large enough to fill

9oz. capacity

.

m Push the 7 oz. Button and the Specialty Button simultaneously. (Picture

3)

A green Brew Button light will remain on until the cycle is finished. When the
green Brew Button light turns off a signal will sound. Wait one minute until the
red STOP indicator light turns on again before opening the Coffeemaker Lid.
Discard the water from the mug and follow instructions below

.

5. Your unit is now primed and ready to brew.
Note: Steaming and noise is normal during this process

43

HOME CAFE®COFFEEMAKER
FEATURES AND BENEFITS

m Pressure Brewing Technology – The Home Café®coffeemaker is different

from your regular coffeemaker because it uses pre-measured sealed coffee pods
and unique pressure brewing found in leading coffeehouses. Pressure brewing
creates a perfectly balanced cup of coffee by forcing a precise amount of water
through the coffee pod consistently producing a high quality single serving
of coffee in about a minute.

m Variety of Blends, Flavors and Roasts – Personalize your brewing

experience by using a variety of Folgers®and Millstone®coffee pods and
Lipton®tea pods.

m Specialty Pods Compatible – Your coffeemaker comes with a Specialty Pod

Holder for use with Lattes, Cappuccinos, etc. Make sure to keep it in a safe place
for future use. Go to www.home-cafe.com for more information or call
1-800-HOME CAFE.

m Mug/Cup Size Flexibility – Choose to brew 7 oz., 9 oz. and

14 oz. in your favorite cup, mug or travel

mug.

m Adjustable Brew Strength – Personalize your coffee experience by using

one or two pods to achieve a stronger beverage.

m Adjustable Dispensing Spout – Adjust the height of the Dispensing Spout

and avoid splashing when using shorter cups or mugs i.e.: Specialty or

7 oz. or 9 oz. mug size.

m Removable Rotating Water Reservoir – Allows you to brew multiple

cups of coffee without refilling the reservoir. Removable for easy cleaning.
Rotates to easily fit your counter space.

m Removable Pod Holders – For easy use and cleaning.
m On/Off Brew Indicator Lights – Lets you know which option you’ve

selected when brewing coffee.

m Removable Drip Tray & Grid – To fit a taller travel mug and for easy use

and cleaning.

m Auto–Off – Coffeemaker automatically turns off after each brew.

USING HOME CAFɮPODS

Your Home Café®coffeemaker has been designed to use versatile, pre-packed,
Folgers®and Millstone®pods to brew coffee and Lipton®tea pods to brew premium
tea. Pods contain pre-measured amounts of coffee grounds or hand picked teas
packed in filter paper, with the added convenience of no-fuss handling and mess­free disposal.

To prepare your favorite coffee or when using tea pods, place the pod or pods
inside the appropriate pod holder and follow the “Using your Home Café

®

Coffeemaker” instructions. For best results, make sure to position the pod with
the flat side up.

1

2

3

Coffee Pods Measurement Chart

Visit your favorite retail store to find Folgers,

®

Millstone®and Lipton®pods or go to
www.home-cafe.com.

NOTE:

• Do not use same pod twice. The best coffee
flavors are extracted the first time water
passes through the pod.

• Do not use torn, ripped or broken pods.

• Do not use another manufacturer’s pod,
espresso pods, tea bags or regular ground
coffee. Your Home Café®coffeemaker is
specially designed to work with Home Café

®

pods. Using other brands of coffee pods or using loose grounds with a filter may
clog or damage your Home Café®unit, or not produce the desired quality of coffee.

For Specialty Pods see “Using Your Home Café®Coffeemaker with Specialty Pods” section.

7 oz 9 oz

14 oz

Strong

StrongExtra Strong

Regular

Regular

N/A

USING YOUR HOME CAFɮCOFFEEMAKER

Make sure you have completed the “Preparing Your Home Café

®

Coffeemaker before first Use” steps.

1. Remove and fill the Water Reservoir with water and replace it
in the unit. (Picture 1)

2. Plug in the unit.

3. Open the lid by pushing the Open Button on the right front of
the appliance. (Picture 2)

4. Insert a Folgers

®

or Millstone®pod or Lipton®Tea pod with the
flat side up in the appropriate pod holder. (Picture 3) Use the
Single Pod Holder with 1 pod, Double Pod Holder for 2 pods
and the Specialty Pod Holder for specialty pods. Refer to
“Coffee Pods Measurement Chart” to help determine how
many pods you may want to use.

5. Close the lid and push down firmly to lock in place.

6. Center your favorite cup or mug under the Dispensing Spout.

7. Adjust the Dispensing Spout by sliding it up or down to fit
your mug height. (Picture 4)

8. Push the Brew Button corresponding to the amount of
coffee/tea you want to brew ( 7oz., 9 oz., 14 oz.
or Specialty). The 7oz. Brew Button is recommended
when using tea pods. Remove the drip tray to accommodate
tall mugs. The green Brew Button Indicator Light will blink
while the unit heats to the proper brewing temperature. The
unit will begin brewing, the pump will turn on and the green
indicator light will remain lit while the coffee is brewing. During
the Specialty brew cycle the coffeemaker produces more noise
than during other brewing selections. (Picture 5)

9. You can stop the brewing process at any time by pressing the
Stop Button.

10. When the brew is complete a signal will sound. You may remove your mug and
enjoy!

11. After hearing the signal, wait one minute until the red STOP Indicator light turns
on again before opening the Coffeemaker Lid. Open the lid and remove the
Pod Holder and with the pod in place, dispose of the used pod and replace the
Pod Holder. Pod and Pod Holder are hot after brewing:

HANDLE WITH

CARE.

Note: The Red Indicator Light will stay on to indicate the unit is plugged in and

ready to brew.
Note: Use the 7oz. Brew Button and flush with water in between tea and coffee

brewing to avoid coffee tasting tea.
WARNING! The lid is designed to stay locked until the brewing cycle is complete,

however if for any reason the lid is managed to be opened during the brew cycle it
will stop the brew cycle. Closing the lid and restarting will initiate a new cycle. We
recommend replacing the pod and starting over.

56

USING YOUR HOME CAFɮCOFFEEMAKER
WITH SPECIALTY PODS

Your coffeemaker comes already with a Specialty Pod Holder that you can use only
with specialty pods such as cappuccinos, lattes, etc. Make sure you keep it in a safe
place for future use.

When using Specialty Pods:

1. Follow steps 1 through 3 in the “Using Your Home Café®Coffeemaker” section.

2. Use the Specialty Pod Holder. (Picture 1)

3. Insert a Specialty Pod in the Specialty Pod Holder with
the flat side up.

4. Close the lid and push down firmly in place.

5. Center a cup/mug under the Dispensing Spout.

6. Adjust Dispensing Spout to fit your mug height.

7. Press the Specialty Brew Button. The Brew Button Indicator Light will blink while
the unit heats to the proper brewing temperature. The unit will begin brewing,
the pump will turn on and the indicator light will remain steady. During the
Specialty brew cycle the coffeemaker produces more noise than during other
brewing selections.

8. Follow steps 9 through 11 in “Using Your Home Café®Coffeemaker” section.

9. For best results when brewing Specialty Pods, clean the Specialty Pod Holder,
Brew Basket and Dispensing Spout daily.

CARE AND MAINTENANCE OF YOUR
HOME CAFÉ

®

COFFEEMAKER

Regular Cleaning

1. Before cleaning, unplug the unit and allow it to cool fully.

2. Open the lid by pressing the Open Button.

3. Remove the Pod Holder and discard the pod.

4. Remove the Brew Basket and wash the Brew Basket and Pod Holder with mild
detergent.

5. Wipe surface with a clean, damp cloth. Do not use abrasive cleaners, as they
may scratch the surface.

6. Rinse and dry all parts thoroughly. Never immerse the unit/base in water or in
any other liquid.

Dishwasher safe (top rack): Removable Pod Holder, Brew Basket, Drip Tray Grid,
Drip Tray and Water Reservoir Lid.

Not dishwasher safe: Water Reservoir.
Any other servicing should be performed by an authorized service representative.

Decalcifying Y

our Coffeemaker

Minerals (calcium/limestone) found in water will leave deposits in your coffeemaker
and will affect it’s performance. It’s recommended that you regularly remove these
deposits by using white household vinegar. Suggested cleaning interval: Soft water
– every 80 brew cycles: Hard water every 40 brew cycles.

1. Remove the Pod Holder.

2. Pour 8 oz. white household vinegar into the water reservoir, then add 10-oz.
fresh water. Make sure the Brew Basket is in place.

3. Set a 14 oz. or larger mug on the brewing plate.

4. Press the 9 oz. Brew Button and let the cleaning solution brew through
the unit.

1

1

2

3

4

5

UP

DOWN
