MOVON MC710 Users Manual

User Manual

SMART
CONTROLLER

MC710

ENCLOSURE

1. SMART CONTROLLER 2. Micro USB charger 3. Manual

PRODUCT COMPONENTS OF SMART CONTROLLER UNIT

3.5 audio jack

Indication LED

Option button

Power On / O

Navigation button

Play/Pause/OK button
Up / Volume Up
Down / Volume Down
Left / Previous/ REW
Right / Next/ FF

Home button

Previous (Cancel) button

Charging port

Speaker

Mode Switching
button

Call button
Call End button

Microphone

-1-

CHARGING

Connect a micro USB charger to the charging port and plug it into USB
port of PC. Before using the unit, charge the battery completely.
The LED blinks in RED while charging and will be o when charging
is completed.

Low battery alarm : When the battery is low, the LED will blink in RED
three time and beep sound every 30 seconds. Once MC710 alerts, please charge
immediately, otherwise MC710 will be powered o within approx. 10 minutes.

PAIRING WITH YOUR BLUETOOTH DEVICES

TURN ON/OFF
Turning On: LED blinks in Blue

Turning On Turning O

PAIRING

1) Put your device in pairing mode.

2) Press the OK button and slide power button up simultaneously, the LED blinks in BLUE rapidly.

3) Your device will  nd the “Smart Controller”.

4) Accepting by pressing “Yes” or “Okay” . (PIN or passkey: 0000)

[Note] In case of unsuccessful pairing, please repeat the step 1 ~ 4.

-2-
