Section 1:Overview

Congratulations on purchasing the Motorola Wireless Ethernet Bridge WE800G.

With the WE800G, any Ethernet-equipped hardware can join a wireless home or small office network. That’s desktops, printers, peripherals, game consoles… anything with an Ethernet port. Even better, this smart device is able to seamlessly transition between two separate networks. Say, your home and office. Or home and the coffee shop. Or wherever you want to connect.

Add the WE800G to a game console or other Ethernet equipped device to join an 802.11g wireless network. Once connected, you can access an Internet broadband connection on a wireless network. And, that’s just the beginning. You can also share files, pictures, peripherals, printers, and more. You’ll need one WE800G for each device and a router or switch.

The WE800G is built with both the popular 802.11b wireless standard and the new nearly 5-times-faster 802.11g standard, providing you the ultimate in flexibility and speed. With Wired Equivalent Privacy (WEP) supported, your wireless connections are robust and secure, giving you the security to communicate without fear that your signal might be compromised.

Upgradeable firmware keeps the WE800G control software up-to-date. The WE800G captures the latest technology in a package that stays current, connects various products to your home network, and provides you easy home network management.

WE800G 1-1

Section 1

Overview

Wireless Ethernet Bridge WE800G

Features

The WE800G has the following features:

! Connect any Ethernet equipped device to your wireless network;

for example, a gaming console, a laptop or desktop computer, or a printer

! Compatibility with both 802.11g and 802.11b standards

! CD-ROM based Installation Wizard for easy installation

! Built-in Web interface for easy configuration

! Firmware upgrade to stay current with latest specification

Your Motorola WE800G enables you to extend your wireless network and increase your productivity.

1-2 WE800G

Overview

Understanding your User Guide

The User Guide is divided into the following sections:

SECTION 1

Overview

Installation

Configuration

Glossary

Describes the WE800G and its functions, the technology used, and the recommended methods for positioning the WE800G.

It is assumed that you will use the Installation Wizard on the CD-ROM to set up your WE800G. If not, refer to this section for instructions on getting your WE800G up and running.

Once you have completed this section, your WE800G will be active and ready to work.

Describes the Configuration Manager that controls your WE800G.

List of terms and acronyms.

WE800G 1-3

Section 1

Box Contents

Overview

Your box contains the following:

CD-ROM

Power

Supply

Antenna

Ethernet

Cable

Base Station Stand

WE800G

Quick Start

Guide

1-4 WE800G

Overview

Understanding Functions

Before installing your WE800G, please take a few minutes to review the wireless networking functions described in this section.

Wireless Ethernet Bridge Connectivity

Your WE800G allows you to:

! Connect wired and wireless networks together

! Create your own private wireless ad-hoc network by configuring

multiple clients such as laptops, each using their own WE800G

The mechanics behind the connectivity are explained in the following sections.

TCP/IP

Transmission Control Protocol/Internet Protocol (TCP/IP) comprises the backbone of the Internet. IP moves packets of data between nodes while TCP verifies delivery from client to server. Every device you hook up to your wireless router identifies itself with an IP address. You are able to assign devices on your network with either a static or dynamically assigned IP address.

SECTION 1

LAN

Local Area Network. A local area network provides a full-time, high-bandwidth connection over a limited area such as a home, building, or campus. Ethernet is the most widely used LAN standard.

Static IP Address

A static IP address is a fixed address that is assigned manually to a device on the network. Static IP addresses must be unique and cannot be shared, therefore they are used in situations where the address should never change, like print servers or PC servers.

Dynamic IP Address

A dynamic IP address is a temporary IP address, dynamically or randomly generated by a DHCP server. The address lasts only as long as the server specifies, usually in the space of a day or two. When the IP address expires, the client is automatically reassigned a new IP address, ensuring smooth communication.

WE800G 1-5

Section 1

Positioning Your Wireless Ethernet Bridge

To achieve the best wireless performance, review these guidelines before deciding where to place your WE800G:

! Placing your WE800G in the physical center of your network is

the best location because the antenna sends out the signal in all directions.

! Placing the WE800G in a higher location, such as on top of a

cabinet, helps to disperse the signal cleanly, especially to receiving locations on upper stories.

! If possible, position your WE800G so there is a direct line of sight

between the WE800G and your other home network devices.

! Avoid placing the WE800G next to large solid objects like

computer cases, monitors, walls, fireplaces, etc. This helps the signal penetrate more cleanly.

! Other wireless devices like televisions, radios, microwaves and

2.4 GHz cordless telephones can interfere with the signal. Keep devices away from the WE800G.

Overview

Wireless Range

The following lists the expected wireless range of the WE800G. This table is only a guide and coverage varies due to local conditions.

Data Rate Open Area Closed Area

54 Mbps

11 Mbps

5.5 Mbps

2 or 1 Mbps

Up to 100 ft (30m) Up to 60 ft (18m)

Up to 900 feet (275 m) Up to 160 feet (49 m)

Up to 1300 feet (396 m) Up to 200 feet (61 m)

Up to 1500 feet (457 m) Up to 300 feet (91 m)

1-6 WE800G

Overview

SECTION 1

Technical Specifications

Your WE800G uses a radio transmission technology defined by the Institute of Electrical and Electronics Engineers (IEEE) called 802.11 or Wi-Fi (Wireless Fidelity). This 802.11 standard is subdivided into distinct categories of speed and the frequency spectrum used, designated by the lower case letter after the standard.

For example, your WE800G supports both the ‘b’ and ‘g’ specifications. The 802.11b standard specifies transmission rates up to 11 Mbps while the 802.11g standard specifies transmission rates up to 54 Mbps. The radio waves radiate out in a donut-shaped pattern. The waves travel through walls and floors, but transmission power and distance are affected. The theoretical distance limit is 1,000 feet (305 meters), but actual throughput and distance varies.

Both the 802.11b and 802.11g standards operate in the 2.4 GHz range, meaning other electrical appliances also might interfere with the WE800G – televisions, radios, microwave ovens, and 2.4 GHz cordless telephones. Therefore, positioning your WE800G where it encounters the least interference gains the greatest benefit to maintaining a quality connection.

WE800G 1-7

Section 1

Types of Networks

Overview

Your WE800G can be used in several ways. The following examples illustrate the flexibility of your WE800G. Some scenarios require additional hardware.

Wireless Ethernet Bridge Infrastructure Mode

In this mode, the WE800G functions like a bridge, connecting wired Ethernet clients to a wireless network. This is how you will most likely use the WE800G, because it shares an Internet connection with your laptop or other wireless client.

1-8 WE800G

Overview

SECTION 1

Wireless Ethernet Bridge Ad-Hoc Mode

This mode is very similar to the WE800G Infrastructure mode, except the WE800G will connect to other client devices using Ad-Hoc mode. One limitation of operating in this mode is that all client devices must be within wireless range of each other, as opposed to a network with an Access Point, where all wireless devices must be within range of the Access Point.

WE800G 1-9

Section 1

Overview

Multiple Clients Mode

In this mode, the WE800G connects multiple clients to your network wirelessly.

1-10 WE800G

Overview

Wireless Ethernet Bridge Physical Description

The following sections describe the physical characteristics of the WE800G.

For instructions on installing your WE800G, see Section 2: Installation.

Back of WE800G

The following illustration shows the WE800G back panel:

SECTION 1

Power

Receptacle

LAN Port

Feature Description

Power Receptacle

LAN Port

The receptacle where you plug in the power adapter.

The receptacle where you plug in an Ethernet cable.

Reset

Button

ntennaLANPower

ntenna

WE800G 1-11

Section 1

Overview

Feature Description

Reset Button

Antenna

Resets your WE800G or returns the WE800G to the default login settings.

If the WE800G experiences trouble connecting to the Internet, briefly press and release the Reset button to reset the router. This retains the router’s configuration information.

To reset the WE800G to the factory defaults, while the unit is powered up, press and hold the Reset button for more than five seconds. This clears the WE800G’s user settings, including User ID, Password, IP Address, and Subnet mask. To re-configure the WE800G, see Section 3: Configuration.

The antenna used for wireless connections. You are able to rotate and tilt the antenna to gain the best signal reception.

1-12 WE800G

Overview

SECTION 1

Front of WE800G

The following illustration shows the WE800G front panel:

1. 2. 3.

The LEDs of the WE800G indicate its operational status.

WE800G 1-13

Section 1

LED Description

The underlined items represent network activity.

LED Condition Color Status

Overview

1. Power

2. Wireless

ON Green The device is powered on and operating normally.

Blinking Green Firmware update is in progress.

Blinking/ON Red The power LED turns red as soon as the reset

button is depressed.

If the reset button is held down for more than five seconds, the LED starts to blink, during which time the WE800G’s default user name, password, and IP address will be restored. The LED then turns off until the reset button is released.

The power LED continuously blinks red if the firmware is corrupted. The firmware needs to be restored.

OFF None No mobile station or AP has associated with this

device.

ON Red The wireless interface has been disabled by the

firmware.

ON/Blinking

Green Connection exists in this wireless domain/active

traffic present.

3. Device

1-14 WE800G

OFF None No external Ethernet device has been attached

and detected. The Ethernet link is down.

ON/Blinking

Amber 10BaseT link detected/active traffic present.

Green 100BaseT link detected/active traffic present.

Section 2:Installation

To get your network up and running:

1 Set up your hardware.

CAUTION!

2 Insert the CD-ROM for Software Setup. Follow the prompts.

If you prefer to set up the Wireless Ethernet Bridge software

manually, refer to the Manual Software Setup found in this section.

The following sections provide detailed instructions for completing these tasks.

Use only the Motorola supplied WE800G power adapter.

Hardware Setup

Hardware setup includes:

! Antenna Installation: connecting the antenna to the WE800G.

! Physical Installation: where you physically place your WE800G.

! Electrical Connection: how to power your WE800G.

WE800G 2-1

Section 2

Installation

Antenna Installation

When shipped, the antenna is already connected to the WE800G. If, for some reason, you have to detach and than re-attach the antenna to the WE800G:

1 Locate the antenna connection on the back of the Wireless

Ethernet Bridge (the threaded knob).

2 Screw the antenna connector (counter-clockwise to remove,

clockwise to attach) on to the threaded knob until removed or firmly seated. When attaching, do not over-tighten.

Wireless Ethernet Bridge Physical Installation

You can install the Wireless Ethernet Bridge horizontally or vertically. The Wireless Ethernet Bridge can also be mounted on a wall. Your own needs determine the best placement.

2-2 WE800G

Installation

Section 2

Horizontal Installation

To install the Wireless Ethernet Bridge horizontally, as shown in the illustration below:

1 Place the Wireless Ethernet Bridge in the desired location.

2 Follow the procedures in “Electrical Connection to Wireless

Ethernet Bridge” located later in this section to connect the WE800G.

WE800G 2-3

Section 2

Installation

Vertical Installation

To install the Wireless Ethernet Bridge vertically, as shown in the illustration below:

1 Insert the Wireless Ethernet Bridge into the supplied base.

Ensure that the antenna’s location is on top. The Wireless Ethernet Bridge’s foot slides snugly into the base to keep the WE800G stable.

2 Follow the procedures in “Electrical Connection to Wireless

Ethernet Bridge” located later in this section to connect the WE800G.

2-4 WE800G

Installation

Section 2

Wall Mount Installation

To mount the Wireless Ethernet Bridge on the wall, you must:

! Position the WE800G as specified by the local or national codes

governing residential or business communications services.

! Follow all local standards for installing a network interface

unit/network interface device (NIU/NID).

If possible, mount the Wireless Ethernet Bridge to concrete, masonry, a wooden stud, or other solid wall material. Use anchors when necessary; for example, if you must mount the WE800G on drywall.

To mount your Wireless Ethernet Bridge on the wall:

1 Print the Wall Mounting Template shown on this page:

3.15

[80.00]

MODE L WE800G

INPUT VOLTAGE: +5VDC, 2A FCC ID: F2NWE800G

MODEL: WE800G

Tes ted To C om pl y

With FCC Standards

FOR HOME OR OFFICE USE

PART NUMBER: AAAAAA-BBB-CC

S/N: PPPPMMYJJJSSSSSC AABBCCCC

WIRELESS MAC: AB CD EF 01 23 45

MADE IN TAIWAN

The illustration is drawn at a one-to-one scale, which means that

when printed, it provides the exact dimensions required to mount the WE800G. Be sure to measure the printed template with a ruler to ensure that it is the correct size.

WE800G 2-5

+ 54 hidden pages
