Motorola T720 User Manual

Download

Page 1

START HERE >

Page 2

Page 3

Welcome

Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola T720 CDMA wireless phone.

Left Soft Key

Perform functions

identified by left

display prompt.

Headset Jack

Insert headset

accessory for

hands-free use.

Power Key & End Key

Turn phone on and

off, end phone calls,

exit menu system.

Volume Keys

Adjust earpiece and

ringer volume.

Microphone

Accessory Connector Port

Insert charger and phone accessories.

Menu Key

Status Light

See incoming call and service status.

Right Soft Key

Perform functions identified by right display prompt.

Voice Key

Record voice notes, phonebook and shortcut names.

Send Key

Send and answer calls, view recent dialed calls list.

4-Way Navigation Key

Scroll through menus and lists, set feature values.

Page 4

Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)

www.motorola.com www.motorola.ca

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Manual number: 6809464A67-O Cover number: 8988485L61-O

(United States)

(Canada)

Page 5

Safety and General Information Getting Started

What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Changing the Convertible Covers . . . . . . . . . . . . . . . . . 17

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 18

Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Changing the Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . 20

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 20

Learning to Use Your Phone

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the 4-Way Navigation Key . . . . . . . . . . . . . . . . . . 25

Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Using the Status Light . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Using the External Display . . . . . . . . . . . . . . . . . . . . . . 40

Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 40

Changing a Code or Password . . . . . . . . . . . . . . . . . . . 41

If You Forget a Code or Password. . . . . . . . . . . . . . . . . 42

Setting Up Your Phone

Storing Your Name and Phone Number . . . . . . . . . . . . 43

Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 43

Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

. . . . . . . . . . . . . . . . . . . . . . . . . . 43

. . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . . 21

Page 6

Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 44

Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 44

Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . . 46

Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 47

Setting Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Hiding or Showing Location Information . . . . . . . . . . . . . 48

Calling Features

Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 49

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 49

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 51

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 51

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 54

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 56

Calling With One-Touch Dial. . . . . . . . . . . . . . . . . . . . . . 56

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Phone Features

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 61

Specific Absorption Rate Data Additional Health and Safety Information Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

. . . . . . . . . . . . . . . . . . . . 71

. . . . . . . . . . . 73

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Page 7

Product Registration Export Law Assurances RF Energy Interference Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . . . . . . . . . 86

. . . . . . . . . . . . . . . . . . . . . . . . . 86

. . . . . . . . . . . . . . . . . . . . . . 95

Page 8

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety information in user guides published prior to December 1, 2002.

Exposure To Radio Frequency (RF) Energy

Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

To assure optimal phone performance and make sure human exposure to RF energy is within the guidelines set forth in the relevant standards, always adhere to the following procedures.

External Antenna Care

Use only the supplied or Motorola-approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone.

Do NOT hold the external antenna when the phone is IN USE. Holding the external antenna affects call quality and may cause the phone to operate at a higher power level than needed. In addition, use of unauthorized antennas may result in non-compliance with the local regulatory requirements in your country.

Page 9

Phone Operation

When placing or receiving a phone call, hold your phone as you would a wireline telephone.

Body-Worn Operation

To maintain compliance with RF energy exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this phone, if available. Use of accessories not approved by Motorola may exceed RF energy exposure guidelines. If you do not use one of the body-worn accessories approved or supplied by Motorola, and are not using the phone held in the normal use position, ensure the phone and its antenna are at least 1 inch (2.5 centimeters) from your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory cable, position the phone and its antenna at least 1 inch (2.5 centimeters) from your body.

Approved Accessories

Use of accessories not approved by Motorola, including but not limited to batteries and antenna, may cause your phone to exceed RF energy exposure guidelines. For a list of approved Motorola accessories, visit our website at

RF Energy Interference/Compatibility

Note:

interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your phone may cause interference.

Facilities

Turn off your phone in any facility where posted notices instruct you to do so. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

www.Motorola.com

Nearly every electronic device is susceptible to RF energy

Page 10

Aircraft

When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker.

Persons with pacemakers should:

•

ALWAYS keep the phone more than 6 inches (15 centimeters) from your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for interference.

•

Turn OFF the phone immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

Use While Driving

Check the laws and regulations on the use of phones in the area where you drive. Always obey them.

Page 11

When using your phone while driving, please:

•

Give full attention to driving and to the road.

•

Use hands-free operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

Responsible driving best practices may be found in the “Wireless Phone Safety Tips” at the end of this manual and at the Motorola website:

www.Motorola.com/callsmart

Operational Warnings

For Vehicles With an Air Bag

Do not place a phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless it is a phone type especially qualified for use in such areas and certified as “Intrinsically Safe.” Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.

Note:

The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Areas with potentially explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in

Page 12

areas posted “Turn off electronic devices.” Obey all signs and instructions.

Batteries

Batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

and chargers.

Your battery or phone may contain symbols, defined as follows:

Symbol Definition

Important safety information will follow.

Your battery or phone should not be disposed of in a fire.

Your battery or phone may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Your battery or phone should not be thrown in the trash.

LiIon BATT

Your phone contains an internal lithium ion battery.

Use only Motorola original batteries

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to blinking lights, such as when watching television or playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your doctor before

Page 13

playing video games on your phone or enabling a blinking-lights feature on your phone. (The blinking-light feature is not available on all products.)

Parents should monitor their children's use of video game or other features that incorporate blinking lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation.

To limit the likelihood of such symptoms, please take the following safety precautions:

•

Do not play or use a blinking-lights feature if you are tired or need sleep.

•

Take a minimum of a 15-minute break hourly.

•

Play in a room in which all lights are on.

•

Play at the farthest distance possible from the screen.

Repetitive Motion Injuries

When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow these instructions to avoid problems such as tendonitis, carpal tunnel syndrome, or other musculoskeletal disorders:

•

Take a minimum 15-minute break every hour of game playing.

•

If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.

•

If you continue to have sore hands, wrists, or arms during or after play, stop playing and see a doctor.

Page 14

Getting Started

What’s in the Box?

Your digital wireless phone typically comes equipped with a battery and a charger. You can purchase other accessory items to customize your phone for maximum performance and portability.

To purchase Motorola Original™ accessories, contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.

Getting Started

About This Guide

This guide introduces you to your Motorola wireless phone.

Note: A More Here reference guide for your phone is also available that describes your phone’s features in more detail.

To obtain the More Here guide for your phone, or another copy of this guide, see the Motorola Web site at:

http://motorola.com/consumer/manuals http://motorola.ca/consumer

or contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.

(U.S.A.)

(Canada)

Page 15

Optional Features

This label identifies an optional network or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service

provider for more information.

Optional Accessories

This label identifies a feature that requires an optional Motorola Original™ accessory.

Installing the Battery

You must install and charge the battery to use your phone.

Your phone is designed to be used only with Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.

Action

Remove the battery from its protective clear plastic case.

If necessary, slide down the battery door release latch and lift the door off of the phone.

Release

latch

Getting Started

Page 16

Action

Insert the battery, printed arrow first,

Getting Started

under the tabs

the bottom of the battery compartment and push down.

Insert the teeth at the bottom of the battery door into the slot at the base of the phone, then push the door down. Slide the release latch up to lock the door in place.

Charging the Battery

New batteries are shipped partially charged. Before you can use your phone, you need to install and charge the

Page 17

battery as described below. Some batteries perform best after several full charge/discharge cycles.

Action

Plug the travel charger into your phone with the release tab facing up.

Plug the other end of the travel charger into the appropriate electrical outlet.

When your phone indicates that the battery is fully charged ( release tab and remove the travel charger.

Release

tab

Charge Complete

), press the

Note:

When you charge the battery, the battery level indicator in the upper right corner of the display shows how much of the charging process is complete. At least one segment of the battery level indicator must be visible to ensure full phone functionality while charging.

Battery Use

Getting Started

Battery performance depends on many factors, including your wireless carrier’s network configuration; signal strength; the temperature at which you operate your phone; the features and/or settings you select and use; items attached to the phone’s accessory connector port; and your voice, data, and other application usage patterns.

Page 18

Caution:

objects to contact or short-circuit the battery terminals.

•

Getting Started

•

for battery type. Contact your local recycling center for proper disposal methods. Never dispose of batteries in a fire because they may explode.

To prevent injuries or burns, do not allow metal

To maximize your battery’s performance:

•

Always use Motorola Original™ batteries and battery chargers. The phone warranty does not cover damage caused from using non-Motorola

batteries and/or battery chargers.

New batteries or batteries that have been stored for long periods of time may require a longer charge time.

Maintain the battery at or near room temperature when charging.

Do not expose batteries to temperatures below

-10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

When you do not intend to use a battery for a while, store it uncharged in a cool, dark, dry place, such as a refrigerator.

Over extended periods of time, batteries gradually wear down and require longer charging times. This is normal. If you charge your battery regularly and notice a decrease in talk time or an increase in charging time, then it is probably time to purchase a new battery.

The rechargeable batteries that power this product must be disposed of properly and may need to be recycled. Refer to your battery’s label

Page 19

Changing the Convertible Covers

You can change the flip cover and battery cover on your phone to personalize its appearance. Matching front and back cover sets are available in a variety of colors and

designs.

Your phone is designed to be used only with Motorola Original accessories. See your Motorola retailer for these convertible covers.

Removing a Flip Cover

Action

Insert your fingertip or fingernail into the slot at the base of the flip cover, then

firmly

pull up and lift

the cover off the phone

Notes:

•

Do not use tools to remove a flip cover. Using tools to remove a flip cover will damage the cosmetic appearance of the phone.

•

The flip cover is attached tightly to the phone, and considerable force is required to remove it.

Getting Started

Page 20

Attaching a Flip Cover

Action

Insert the tabs at the bottom of the cover into the slots at the base of the phone, then push the cover down and snap it into place.

Turning Your Phone On

Getting Started

Action

Open your phone

Press and hold P for three seconds to turn on the phone

If necessary, enter your four-digit unlock code and press

The unlock code is originally set to 1234. Your service provider may change this number before you receive your phone.

(+) to unlock the phone

Power

key

Page 21

Adjusting Volume

Press the up and down volume keys to:

•

increase and decrease earpiece volume during a call

•

increase and decrease the ringer volume setting when the idle display is visible (flip must be open)

Tip:

At the lowest volume setting, press the down volume key to switch to silent alert. Press the up volume key to reset ring alert.

•

turn off an incoming call alert

Making a Call

Action

Extend the antenna

Press the keypad keys to dial the phone number

Tip:

If you make a mistake, press delete the last digit, or press and hold to clear all digits.

Press N to make the call

Volume

keys

DELETE

(-) to

Getting Started

(-)

Press O to end the call and “hang up” the phone when you are finished

Note:

You must dial the phone number from the idle

display. See page 21.

Page 22

Answering a Call

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

Press To

ANSWER

Tip:

When the phone flip is active, simply open the phone to answer the call. (To activate, press >

In-Call Setup >Answer Options >Open to Answer

Getting Started

Note:

If the phone is locked, you must unlock it to answer

the call.

answer the call

(+)

end the call and “hang up” the phone when you are finished

Settings

)

Changing the Call Alert

With the phone flip open, press the down volume key to switch the alert for incoming calls and other events to silent alert. Press the up volume key to reset ring alert.

Volume

keys

Viewing Your Phone Number

To view your phone number from the idle display, press

While you are on a call, press

My Tel. Numbers

Page 23

Learning to Use Your Phone

See page 1 for a basic phone diagram.

Using the Display

The idle display (shown below) is the standard display you see when you are not on a call or using the menu. You must be in the idle display to dial a phone number.

#8?IM VQ5^

Service Provider

Clock

Shortcuts

Web Browser

10:00am 10/10/02

Messages

Datebook

Press the 4-way navigation key ( to select one of the four menu feature icons in the idle display.

RECENTPH.BOOK

Menu Indicator

Soft Key Labels

) left, right, up, or down

Learning to Use Your Phone

Page 24

The e (menu) indicator at the bottom center of the display

indicates you can press the menu key ( menu to see more features.

Labels at the bottom corners of the display show the current soft key functions. Press the left soft key ( right soft key ( left or right soft key label.

Status indicators are grouped at the top of the display:

➌

➋

➊

) to perform the function indicated by the

In Use Indicator

Digital/Analog Signal Indicator

Signal Strength Indicator

➍

Roam Indicator

Service Provider

#8?

10:00am 10/10/02

➎

) to go to the main

Active Line Indicator

➏

ALI Indicator

➐

Battery Level Indicator

➑

Ring Style Indicator

) or

RECENTPH.BOOK

Learning to Use Your Phone

➊

Signal Strength Indicator

strength of the network connection. You cannot make or receive calls when the

➋

Digital/Analog Signal Indicator

whether you are receiving a digital or analog signal:

Vertical bars show the

(no signal) indicator is displayed.

➒

Message Waiting Indicator

Shows

Page 25

= digital signal

= 13K digital

= packet data

service

➌

In Use Indicator

indicators can include:

= secure CSD

call

= secure packet

data transfer

;

= secure

application connection

➍

Roam Indicator

seeking or using another network system outside your home network.

=3G roam

=2G roam

On text entry screens, shows text entry status information:

= symbol mode

= caps lock on

Shows that a call is in progress. Other

= analog signal

=8K digital

= unsecure CSD

call

= unsecure packet

data transfer

= unsecure

application connection

Shows that your phone is

=3G home

=2G home

= numeric mode

= normal text entry

Learning to Use Your Phone

➎

Active Line Indicator

active phone line:

= line 1

Shows the current

= line 2

Page 26

➏

ALI Indicator

automatic location information feature:

=ALI on

On text entry screens, shows text entry status information:

= tap method

➐

Battery Level Indicator

charge level. Recharge the battery when you see

Low Battery

➑

Ring Style Indicator

=limited character

Learning to Use Your Phone

and hear the low battery alert.

= loud ring =vibrate = silent

➒

Message Waiting Indicator

you receive a text message. Other indicators can include:

=voicemail

message

count (text entry screen)

Shows the status of the

=ALI off

= iTAP mode

Vertical bars show the battery

Shows the ring style setting:

=soft ring

= vibrate and ring

= voicemail and

Appears when

text message

Page 27

Using the 4-Way Navigation Key

Use the 4-way navigation key like a joystick to navigate the menu system, change feature settings, and play games. From the idle display, press

to select one of the four menu feature icons

in the idle display.

Tip:

Down and up are your primary movements within menus. Move left and right to change feature settings, navigate the datebook, and edit text.

4-way

navigation

key

Learning to Use Your Phone

Page 28

Using Menus

From the idle display, press M to go to the main menu.

Menu Key

Enter menu

system, or open

a sub-menu.

Left Soft Key

Perform left

function.

End Key

Exit menu

without making

changes.

Learning to Use Your Phone

Press menu. Select The following icons represent features that may appear in

to highlight a menu feature icon in the main

(?) to see additional menu features.

Main Menu

Media Center

EXIT

SELECT

Current selection.

Right Soft Key

Perform right function.

4-Way Navigation Key

Scroll up,

left

, or

down

right

Page 29

the main menu, depending on your service provider and service subscription options.

Icon

Tip:

text-based list rather than graphic icons. See page 63.

Feature

Media Center

Voice Notes

Calculator

Datebook

Recent Calls

You can set your phone to display the main menu as a

Selecting a Menu Feature

This guide shows you how to select a menu feature as follows, starting from the idle display:

Find the Feature

This example shows that from the idle display, you must

press menu, then scroll to and select scroll, and the left/right soft keys to select the functions

listed in the bottom left and right corners of the display.

, scroll to and select

Icon

Feature

Phonebook

Ring Styles

Settings

Web Browser

Messages

Shortcuts

More >Phonebook

(?) from the main

Phonebook

. Use S to

Learning to Use Your Phone

Page 30

Selecting a Feature Option

Some features require you to select an item from a list:

Dialed Calls

V5^

10) John Smith

9) Lisa Owens

8) Adda Thomas

Press

BACK

to go back to

•

Press S to scroll up or down to highlight the item you want.

•

In a numbered list, press a number key to highlight the item.

•

In an alphabetized list, press a key multiple times to cycle through the letters on the key and highlight the closest matching list item.

Learning to Use Your Phone

(-)

screen.

Press

7) Jack Bradsh..

6) Mary Smith

5) Dave Thomp...

VIEWBACK

to open sub-menu.

Highlighted item

Press

VIEW

(+) to view details of highlighted item.

Page 31

Entering Feature Information

Some features require you to enter information:

Entry Details

Press

scroll down to

other items.

Press

CANCEL

changes. enter or edit information.

Name:John Smith

No.:2125551212 Type:Work Voice Name: Speed No.:2 Ringer ID:Contin...

CHANGECANCEL

(-) to exit without making

DONE

(-) appears when you

Highlighted item

Press

CHANGE

enter or edit information.

(+) to

•

Enter numbers or text with the keypad.

•

When an item has a list of possible values, press S to the left or right to scroll through and select a value.

•

When an item has a list of possible numeric values, press a number key to set the value.

•

If you enter or edit information and do not want to save

V5^

your changes, press

to exit without saving.

Learning to Use Your Phone

Page 32

The message center lets you compose and send text messages. A flashing cursor shows where text will appear:

Msg:

PV5^

Flashing cursor

indicates

insertion point.

INSERTCANCEL

Press

CANCEL

(-) to exit without making changes.

When you enter text using the standard tap method (see page 31), the flashing cursor changes to a block cursor, and the soft key functions change:

Block cursor

indicates

highlighted

character.

Learning to Use Your Phone

After two

seconds, block

cursor reverts

to flashing

cursor and

moves to next

position.

Msg:

OKDELETE

Press

DELETE

character to left of insertion point.

Press sub-menu.

Press

INSERT

insert quick note, picture, or sound.

Press accept and store text.

(-) to delete

to open

(+) to

Page 33

Entering Text

Multiple text entry methods make it easy for you to enter names, numbers, and messages on your phone.

Choosing a Text Mode

Most text entry screens let you enter letters, numbers, and/ or symbols as required. Press from a text entry screen to select a text mode:

iTAP

Let the phone predict each word as you

enter it. See page 34.

Tap Method

Numeric

Symbol

Browse

Note:

change it by selecting another mode.

Enter letters, numbers, and symbols by

pressing a key one or more times. See following section.

Enter numbers only.

Enter symbols only. See page 38.

Browse your phonebook or recent call

lists to select a name or number.

The text mode you select remains active until you

Using Tap Method

(or M >

Entry Method)

Learning to Use Your Phone

This is the standard mode for entering text on your phone.

Page 34

Press M> select the

Learning to Use Your Phone

Entry Method

Tap Method

Press To

A number key one or more times

Number keys enter the remaining

(+) store the text when you are

from any text entry screen and

menu option.

select a letter, number, or symbol shown in the “Character Chart” on page 34

characters

finished

Page 35

General Text Entry Rules

Press a number key repeatedly to cycle through its characters. See the “Character Chart” on page 34.

Press a number

key as many

times as

necessary to

enter desired

character at

flashing cursor

location.

MSG:

CANCEL

BROWSE

Press

down

to change

letter in block cursor to uppercase or lowercase.

Learning to Use Your Phone

Press and hold a

number key to

cycle between

text and numeric

entry modes.

•

If you do not press a key for two seconds, the character in the block cursor is accepted, and the cursor moves to the next position.

•

The first character of every sentence is capitalized. (Press

down to force the character to lowercase

while it is highlighted by the block cursor).

Press

left

to move flashing cursor to left or right in text message.

right

Page 36

Character Chart

Use this chart as a guide for entering characters with the tap method.

space . 1 ? ! , @ _ & ~ : ; " -

( ) ' ¿ ¡ % £ $ ¥

a b c 2 ä å á à â ã

d e f 3

g h i 4 ï í î γ η

j k l 5 κ

m n o 6 ñ ö ø ó ò ô õ µ υ

p q r s 7

t u v 8

w x y z 9

+ - 0 x * / \ [ ] = > < # §

Note:

This chart may not reflect the exact character set

available on your phone.

ë é è ê ε

ü ú ù û

ξ ψ

α β

Using iTAP™ Software Predictive Text Entry Method

Learning to Use Your Phone

iTAP™ software is a predictive text entry method that lets you enter a word using a single keypress per letter.

Press

select the

Entry Method

iTAP

menu option.

from any text entry screen and

Note:

text mode. Press you want to use.

You can switch languages within a message in iTAP

Entry Method

to select the language

Page 37

Entering Words

Action

Press a number key one time to enter the first letter of the word

The letters associated with the key are shown at the bottom of the display.

Press number keys (one per letter) to enter the rest of the word

Alternative words and letter combinations are shown at the bottom of the display. The word choices are updated with each keypress.

Press S to highlight the word you want

Press

SELECT

(+) to enter the word at the

flashing cursor location

A space is automatically inserted after the word.

For example, to spell the word “art,” press 2 7 8. The display shows:

Flashing cursor

indicates

insertion point.

Press

Msg:

scroll and see additional word choices.

Learning to Use Your Phone

Press

DELETE

clear last letter.

(-) to

Art Apt Cpu Cst

SELECTDELETE

Press

SELECT

insert

}

highlighted word.

(+) to

Page 38

Entering Novel Words

You may enter a word that the iTAP software does not recognize. If the word you want is not displayed:

Action

Press

DELETE

(-) one or more times to delete letters until you see a letter combination that matches the start of the word

Press S left or right to highlight the letter or letter combination

Press

SELECT

(+), then press S to the left to shift the text entry cursor to the left and “lock” the selected word portion

Continue to enter letters and highlight letter combinations to spell the word

Entering Punctuation

Press To

Learning to Use Your Phone

enter punctuation or other characters as shown in the “Character Chart” on page 34

Page 39

Using Capitalization

The first word of a sentence is automatically capitalized, with following words in lowercase.

Press To

up or down

Entering Numbers

Action

Enter the first digit and then highlight it to put the iTAP software in number entry mode

Press number keys to add digits to the number

Press

SELECT

flashing cursor location

Deleting Letters and Words

Place the cursor to the right of the text you want to delete, and then do the following:

change the words to initial character capitalized, all uppercase characters, or all lowercase characters

(+) to enter the number at the

Learning to Use Your Phone

Action

Press

DELETE

Hold

DELETE

(-) to delete one letter at a time

(-) to delete the entire message

Page 40

Using Symbol Mode

Your phone provides an alternate way to enter symbol characters in a message. Press any text entry screen and select the

Action

Press a number key one time to display its symbol options at the bottom of the display

See the “Symbol Chart” on page 38.

Press S, or press the number key multiple times, to highlight the symbol you want

Press

SELECT

(+) to enter the symbol at the flashing cursor location

Entry Method

Symbol

from

menu option.

Symbol Chart

Use this chart as a guide for entering characters in symbol mode.

space . ? ! , @ _ & ~ : ; "

- ( ) ' ¿ ¡ % £ $ ¥

@ _ \

Learning to Use Your Phone

/ : ;

" & '

( ) [ ] { }

¿ ¡ ~

< > =

$ £ ¥

Page 41

# % *

+ - x * / = > < # §

Using the Status Light

The status light shows when you have an incoming call or message, or when your phone is roaming (using a non-home system).

Status light

Indication Status

alternating red/green incoming call flashing green in service, home system flashing yellow roaming, non-home system flashing red no service

You can turn off the status light to extend battery life and increase your phone’s standby time, the length of time that your phone’s battery retains power when the phone is turned on but is not in use.

To turn the status light on or off:

Find the Feature

Settings

Initial Setup

Status Light

Learning to Use Your Phone

Page 42

Using the External Display

When the flip is closed, the external display shows the time, date, and phone status information. It also displays messages to notify you of incoming calls and other events. See pages 22–24 for descriptions of the status indicators that may appear in the external display.

Locking and Unlocking Your Phone

You can lock your phone manually or set the phone to

lock automatically whenever you turn it off.

To use a locked phone, you must enter the unlock code. A locked phone still rings or vibrates for incoming calls or messages,

You can make emergency calls on your phone even when it is locked. For more information, see page 51.

Locking Your Phone Manually

but you must unlock it to answer

Find the Feature

Learning to Use Your Phone

Press To

keypad keys enter your unlock code

(+) lock the phone

Settings >Security

Phone Lock

Lock Now

Page 43

Unlocking Your Phone

Tip:

Your phone’s unlock code is originally set to 1234 at the factory. Many service providers reset the unlock code to the last four digits of your phone number.

At the

Enter Unlock Code

Press To

keypad keys enter your unlock code

(+) unlock your phone

prompt:

Setting Your Phone to Lock Automatically

You can set your phone to lock every time you turn it off.

Learning to Use Your Phone

Find the Feature

Press To

keypad keys enter your unlock code

(+) activate automatic lock

Settings >Security

Phone Lock

Automatic Lock >On

Changing a Code or Password

Your phone’s four-digit unlock code is originally set to 1234, and the six-digit security code is originally set to 000000 at the factory. Your service provider may reset these numbers before you receive your phone.

If your service provider has not reset these numbers, we recommend that you change them to prevent other users

Page 44

from accessing your personal information. The unlock code must contain four digits, and the security code must contain six digits.

To change a code or password:

Find the Feature

Settings >Security

New Passwords

If You Forget a Code or Password

If you forget your security code, contact your service

provider.

If you forget your unlock code, try entering 1234 or the last four digits of your phone number. If that does not work, do the following at the

Enter Unlock Code

prompt:

Press To

go to the unlock code bypass

screen

keypad keys enter your security code

(+) submit your security code

Learning to Use Your Phone

Page 45

Setting Up Your Phone

Storing Your Name and Phone Number

To store or edit user name and phone number information on your phone:

Find the Feature

Settings

Phone Status

My Tel. Numbers

Setting the Time and Date

You must set the time and date to use the datebook.

Find the Feature

Settings

Initial Setup

Time and Date

Setting a Ring Style

Your phone rings or vibrates to notify you of an incoming call or other event. This ring or vibration is called an alert.

You can select one of five different ring styles:

= loud ring =vibrate = silent

=soft ring

= vibrate and ring

Setting Up Your Phone

Page 46

The ring style indicator in the display shows the current ring style (see page 22).

To set a ring style:

Find the Feature

Press To

SELECT

(+) select the ring style

Each ring style contains settings for specific event alerts, ringer ID, and ringer and keypad volume. To change these settings, press

Ring Styles

Ring Styles >Style

scroll to the ring style

> Style

Detail

Setting Answer Options

You can use different methods to answer an incoming call.

Find the Feature

The

Answer Options

Multi-Key Open to Answer

answer by pressing any key

Settings

In-Call Setup

Answer Options

menu includes:

answer by opening the flip

Setting a Wallpaper Image

Setting Up Your Phone

You can set a picture or animation as a wallpaper (background) image in your phone’s idle display.

Page 47

Note:

When you set an animation as a wallpaper image,

only the first frame of the animation is displayed.

Find the Feature

Press To

8 9

CHANGE

SELECT

CHANGE

SELECT DONE

(+) open the picture viewer

up or down

(+) select the image

(+) adjust the image layout

(+) confirm the layout setting

(-) save wallpaper settings

Settings

Personalize

Wallpaper

scroll to

scroll to a picture/animation

Scroll to wallpaper image.

scroll to

Center

the center of the display and, if necessary, shrinks the image to fill the display.

Tile

adjacent copies of the image


(None)

Layout

Center

places the image in

fills the display with

to turn off the

Tile

Setting Up Your Phone

Page 48

Setting a Screen Saver Image

You can set a picture or animation as a screen saver image. The image is displayed when the phone flip is open and no keypresses are detected for a period of time.

The screen saver image is shrunk to fill the display, if necessary. An animation repeats for one minute, then the first frame of the animation is displayed.

Tip:

Turn off the screen saver to extend battery life.

Find the Feature

Setting Up Your Phone

8 9

Settings

Personalize

Screen Saver

Press To

CHANGE

(+) open the picture viewer

up or down

SELECT

(+) select the image

CHANGE

(+) set the delay interval

SELECT

(+) confirm the delay setting

DONE

(-) save screen saver settings

scroll to

scroll to a picture/animation

Scroll to screen saver image.

scroll to

scroll to the inactivity interval that triggers the screen saver


(None)

Delay

to turn off the

Page 49

Zooming In and Out

Press and release M, then press and hold M to zoom in and out on display text. Zoom in to increase text size, zoom out to display more information.

You can also zoom in and out from the menu:

Find the Feature

Settings

Initial Setup >Zoom

Setting Display Contrast

Find the Feature

Settings

Initial Setup

Contrast

Setting Display Color

You can select the color palette that your phone uses to display indicators, highlights, and soft key labels.

Find the Feature

Settings

Personalize

Color Style

Adjusting the Backlight

You can set the amount of time that the display and keypad backlights remain on, or turn off backlights to extend battery life.

Find the Feature

Settings

Initial Setup

Backlight

Setting Up Your Phone

Page 50

Hiding or Showing Location Information

Your phone can use the automatic location information (ALI) feature to tell the network

where you are physically located.

When ALI is set to displays the known location to provide useful information (for example, driving directions, or the location of the nearest bank). Your phone prompts you when the network or a service asks for your location. You can refuse at this point.

When ALI is set to

(ALI off) indicator, and the phone does not send location information unless you call the emergency phone number (such as 911).

(ALI on) indicator. Services may use your

911 Only

Find the Feature

Press To

SELECT

(+) select the setting

Location On

, your phone displays the M

, your phone

Settings >Location

scroll to

911 Only

Location On

To view or change the location transmission status of your phone during a call, press

Setting Up Your Phone

Location

Page 51

Calling Features

For basic instructions on how to make and answer calls, see page 19.

Changing the Active Line

Change the active phone line to make and receive calls from your other phone number.

Find the Feature

The active line indicator in the display shows the current active phone line. See page 22.

Settings

Phone Status

Active Line

Redialing a Number

If you hear an ordinary busy signal:

Press To

hang up

redial the busy number

Using Automatic Redial

If the network is busy, you hear a fast busy signal, and your phone displays

Call Failed

Calling Features

Page 52

With automatic redial, your phone automatically redials the number for four minutes. When the call goes through, your phone rings or vibrates one time, displays

Redial Successful

You must turn on automatic redial to use the feature. To turn automatic redial on or off:

, and then connects the call.

Find the Feature

When automatic redial is turned off, you can manually activate the feature to redial a phone number. When you hear a fast busy signal and see

Press To

RETRY

(+)

Settings

Initial Setup Auto Redial

Call Failed

activate automatic redial

Calling Features

Using Caller ID

Calling line identification (caller ID) displays the phone number for incoming calls in your phone’s external and internal displays.

The phone displays the caller’s name when the name is stored in your phonebook, or when caller ID information is not available.

Incoming Call

Page 53

Canceling an Incoming Call

While the phone is ringing or vibrating:

Press To

IGNORE

(-)

Depending on your phone settings and/or service subscription, the call may be forwarded to another number, or the caller may hear a busy signal.

cancel the incoming call

Turning Off a Call Alert

You can turn off your phone’s incoming call alert before answering the call.

Press To

either volume key turn off the alert

Calling an Emergency Number

Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked.

Note:

Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be

Calling Features

Page 54

placed due to network, environmental, or interference issues.

Press To

keypad keys dial the emergency number

call the emergency number

Viewing Recent Calls

Your phone keeps a list of the calls you recently received and dialed, even if the calls did not connect. The lists are sorted from newest to oldest entries. The oldest entries are deleted as new ones are added.

Shortcut:

from the idle display.

Find the Feature

Calling Features

Press N to go directly to the dialed calls list

Press To

SELECT

(+) select the list

scroll to

Dialed Calls

scroll to an entry

Note: < means the call

connected.

More >Recent Calls

Received Calls

Page 55

Press To

call the entry’s number

Tip:

Press and hold N for two seconds to send the number as DTMF tones during a call.

VIEW

(+)

The

Last Calls Menu

Option Description

Store

Create a phonebook entry with

Delete Delete All Send Message

Add Digits Attach Number

Send Tones

Open a new text message with

Add digits after the number.

Attach a number from the

Send the number to the network

view entry details

open the perform other procedures

can include the following options:

Last Calls Menu

the number in the Delete the entry. Delete all entries in the list.

the number in the

phonebook or recent call lists, after the highlighted number.

as DTMF tones.

Note:

This option appears only

during a call.

No.

Calling Features

field.

Page 56

Returning an Unanswered Call

Your phone keeps a record of your unanswered calls, and displays:

•

the T (missed call) indicator

•

X Missed Calls

Press To

VIEW

, where X is the number of missed calls

(+) see the received calls list

select a call to return

make the call

Using the Notepad

Your phone stores the most recent string of digits entered on the keypad in a temporary memory location called the notepad. This can be a phone number that you called, or a

Calling Features

number that you entered but did not call. To retrieve the number stored in the notepad:

Find the Feature

More >Recent Calls

Notepad

Page 57

Press To

STORE

(+)

call the number

open the attach a number or insert a special character

create a phonebook entry with the number in the field

Dialing Menu

Attaching a Number

While dialing (with digits visible in the display):

Press To

Attach Number

attach a number from the phonebook or recent call lists

No.

Calling Features

Page 58

Calling With Speed Dial

Each entry you store in your phonebook is assigned a unique speed dial number. To speed dial a phonebook entry:

Press To

keypad keys enter the speed dial number

for the entry you want to call

submit the number

Note:

Some networks let you skip this step for speed dial numbers 1 through 99.

call the entry

Calling Features

Calling With One-Touch Dial

To call phonebook entries 1 through 9, just press and hold the one-digit speed dial number for one second.

We recommend that you reserve phonebook entry 1

(speed dial number 1) for storing and dialing your voicemail phone number. Usually, your service provider has already done this for you. If necessary, see your reference guide for information on how to store your voicemail number as a phonebook entry.

Page 59

Using Voicemail

Voicemail messages that you receive are stored on the network. To listen to your messages, you must call your voicemail phone number.

Note:

Your service provider may include

additional information about using this feature.

Listening to Voicemail Messages

Find the Feature

The phone calls your voicemail phone number. If no voicemail number is stored, your phone prompts you to store one.

Shortcut:

voicemail phone number as phonebook entry number 1. If so, you can press and hold message(s).

Your service provider may also store your

More >Messages

VoiceMail

to listen to your voicemail

Receiving a Voicemail Message

When you receive a voicemail message, your phone

displays the

New VoiceMail

Press To

CALL

(+) listen to the message

The phone calls your voicemail phone number. If no voicemail number is stored, your phone prompts you to store one.

(voice message waiting) indicator and notification.

Calling Features

Page 60

Storing Your Voicemail Phone Number

If necessary, use the following procedure to store your voicemail phone number on your phone. Usually, your service provider has already done this for you.

Find the Feature

Press To

keypad keys enter your voicemail number

(+) store the number

Your service provider additionally may store your voicemail phone number as phonebook entry number 1, so you can use one-touch dial to listen to your voicemail messages. If necessary, see your reference guide for information on how to store your voicemail number as a phonebook entry.

Calling Features

Muting the Phone

To mute your phone during a call, press

available) or

Mute

More >Messages

VoiceMail Setup

MUTE

Using Call Waiting

When you are on a call, an alert tone sounds to indicate that you have received a second call.

Press To

answer the new call

switch back to the first call

(+) (if

Page 61

Phone Features

Main Menu

This is the standard main menu layout.

organization and feature names may vary on your phone.

If you do not find a feature in the main menu,

select features may be available for all users.

' w

a /

g L

(?) to see additional menu features. Not all

Media Center

• Picture Viewer

• My Tones

• Radio

Voic e N o tes

Ring Styles

•Style

• Style Detail

Calculator

Settings

(see next page)

Datebook

Web Browser

•Home

• Go To URL

•Mark Site

• Reload

• About Openwave

•Advanced

(go to following menu items)

: à

Messages

•Voicemail

• Create Message

•Inbox

• Outbox

• Quick Notes

•Drafts

•Browser Alerts

Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

•Data Times

•Data Volumes

Shortcuts

Phonebook

Phone Features

Page 62

Settings Menu

•Personalize

• Main Menu

• Home Keys

• Color Style

•Greeting

• Banner

• Banner Graphic

• Wallpaper

• Screen Saver

•Browser Setup

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Phone Status

•My Tel. Numbers

• Active Line

• Battery Meter

• Other Information

• Security

• Phone Lock

• Lock Application

• Restrict Calls

•New Passwords

• Initial Setup

• Time and Date

• Auto Redial

• Backlight

• Status Light

•Zoom

• TTY Setup

•Scroll

• Language

Phone Features

• Contrast

•DTMF

•Master Reset

• Master Clear

• Location

•Network

• Car Settings

•Headset

Shortcuts

Change display zoom:

Press M, then press and hold M

Change ringer alert:

Open flip, press down volume key to decrease volume, then switch to silent alert. Press up volume key to reset ring alert and increase volume.

Display my phone number:

Press

(in idle)

Go to dialed calls list:

Press N (in idle)

Exit menu system:

Press O

Page 63

Feature Quick Reference

You can do more with your phone than make and receive phone calls! For example, you can store frequently called numbers in the phonebook for easy dialing, organize your meetings and other events in the datebook, browse the Web, send messages, and more.

Use this chapter to locate features on your phone that are not described in this guide. For more detailed information, see the More Here guide.

Calling Features

Feature Description

Three-Way Call

Restrict Calls

TTY Calls

During a call: Dial third party’s number, press

to call, press N

again to connect Restrict outgoing or

incoming calls:

Settings >Security

Restrict Calls

Set up your phone for use

with an optional TTY device:

Settings >Initial Setup

TTY Setup

Phone Features

Page 64

Messages

Phonebook

Phone Features

Feature Description

Send Message

Insert Pictures & Ring Tone s

Receive Message

Download Pictures & Ring Tone s

Feature Description

Create Entry

Send a text message:

More >Messages

Create Message

While composing a message:

Insert

Read a new text message that you have received: Press

READ

(+)

Highlight a picture or ring tone in a message, then:

Store

Create a new phonebook entry:

More >Phonebook

New

Email Address

Phone Number

Page 65

Feature Description

Dial Number

Voice Dial Number

Call a number stored in the

phonebook:

More >Phonebook

Voice dial a number stored in the phonebook: Press and release the voice key, and say the entry’s name (in two seconds)

Personalizing Features

Feature Description

Ring Alert

Ring Volume

Keypad Volume

Menu View

Change the ring alert for an event:

Ring Styles

> event name Set ringer volume:

Ring Styles

Ring Volume

Set keypad keypress volume:

Ring Styles

Key Volume

Display the main menu as graphic

icons or as a text-based list:

Settings >Personalize

Main Menu>View

> entry to call

> Style

Detail

Phone Features

Page 66

Feature Description

Soft Keys & Menu Icons

Shortcuts

Menu Features

Feature Description

Language

Master Reset

Phone Features

Master Clear

Change soft key labels and menu feature icons in the idle display:

Settings >Personalize

Home Keys

Create a shortcut to a menu item:

Highlight the menu item, then press and hold

Select a shortcut:

> shortcut name

Set menu language:

Language

Reset all options except unlock code, security code, lifetime timer:

Master Reset

Reset all options except unlock code, security code, lifetime timer, clear all user settings and entries:

Master Clear

More >Shortcuts

Settings >Initial Setup

Page 67

Dialing Features

Feature Description

DTMF Tones

Activate DTMF tones:

Settings >Initial Setup >DTMF

Send DTMF tones during a call: Press number keys

Send stored numbers as DTMF tones during a call: Highlight a number in the phonebook or recent call lists, then press >

Send Tones

Call Monitoring

Network connection time

moment you connect to your service provider's network to the moment you end the call by pressing includes busy signals and ringing.

The amount of network connection time you track on your resettable timer may not equal the amount of time for which you are billed by your service provider. For

is the elapsed time from the

. This time

Phone Features

Page 68

billing information, please contact your service provider directly.

Feature Description

Call Times

In-Call Timer

Data Times

Data Volumes

View call timers:

More >Recent Calls

Call Times

Display time or cost information during a call:

Settings >In-Call Setup

In-Call Timer

View data call timers:

More >Recent Calls

Data Times

View data volume meters:

More >Recent Calls

Data Volumes

Handsfree Features

Note:

The use of wireless devices and their accessories

may be prohibited or restricted in certain areas. Always

Phone Features

Page 69

obey the laws and regulations on the use of these products.

Feature Description

Speakerphone

Auto Answer

(car kit or headset)

Auto HandsFree

(car kit)

Power-Off Delay

(car kit)

Charger Time

(car kit)

Activate a connected external speakerphone during a call: Press

SPEAKER

available) or Automatically answer calls

when connected to a car kit or headset:

Settings >Car Settings

Headset >Auto Answer

Automatically route calls to a car kit when connected:

Settings >Car Settings

Auto Handsfree

Set the phone to stay on for a period of time after the ignition is switched off:

Settings >Car Settings

Power-Off Delay

Charge the phone for a period of time after the ignition is switched off:

Settings >Car Settings

Charger Time

(+) (if

Spkrphone On

Phone Features

Page 70

Data and Fax Calls

Feature Description

Send Data or Fax

Receive Data or Fax

Connect your phone to the device, then place the call through the device application

Connect your phone to the device, then:

Settings >Connection

Incoming Call >Next Call

Data In Only

Reset normal voice operation:

Settings >Connection

Incoming Call >Next Call >Normal

FaxInOnly

Network Features

Feature Description

Network Settings

Phone Features

View network information and adjust network settings:

Settings >Network

Page 71

Personal Organizer Features

Feature Description

Add Datebook Event

View Datebook Event

Event Reminder

Record Voice Note

Play Voice Note

Calculator

Currency Converter

Add an event to the datebook:

Datebook

New

View or edit event details:

Datebook

View event reminder:

VIEW

(+)

Dismiss event reminder:

EXIT

(-)

Record a voice note: Press and hold voice key, speak voice note, release voice key

Note:

to varying state and federal laws regarding privacy and recording of conversations.

Play back a recorded voice note:

Voice Notes

Calculate numbers:

Calculator

Convert currency:

Calculator

Exchange Rate

> day

> day > event name

Recording phone calls is subject

> voice note

Phone Features

Enter exchange rate, press OK(+), enter amount, select

function

Page 72

Security

Feature Description

Lock Application

Lock phone applications:

News and Entertainment

Feature Description

Launch MicroBrowser

Download Picture or Ring Tone from Web Page

Picture Viewer

Phone Features

My Tones

Radio

Use the optional Motorola

Start a micro-browser session:

Download an image or sound file from a Web page: highlight the file, press

SELECT

Manage pictures and animations:

Compose your own ring tones,

manage ring tones that you have composed or downloaded:

Original™ FM Stereo Radio Headset accessory:

Settings >Security

Lock Application

Web Browser >Home

(+), press

Media Center

Picture Viewer

Media Center >My Tones

Media Center >Radio

STORE

(+)

Page 73

Specific Absorption Rate Data

The model wireless phone meets the government’s requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government and by the Canadian regulatory authorities. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC and by the Canadian regulatory authorities is

1.6 W/kg. positions accepted by the FCC and by Industry Canada with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and Canada, it must be tested and certified to the FCC and Industry Canada that it does not exceed the limit established by each government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) reported to the FCC and available for review by Industry Canada. The highest SAR value for this model phone when tested for use at the ear is 1.53 W/kg, and when worn on the body, as

Tests for SAR are conducted using standard operating

Page 74

described in this user guide, is 1.30 W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and regulatory requirements).

While there may be differences between the SAR levels of various phones and at various positions, they all meet the governmental requirements for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) Web site:

http://phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

2. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

Page 75

The U.S. Food and Drug Administration's Center for Devices and Radiological Health Consumer Update on Mobile Phones

Additional Health and Safety Information

FDA has been receiving inquiries about the safety of mobile phones, including cellular phones and PCS phones. The following summarizes what is known—and what remains unknown—about whether these products can pose a hazard to health, and what can be done to minimize any potential risk. This information may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio frequency energy (i.e., radio frequency radiation) in the microwave range while being used. They also emit very low levels of radio frequency energy (RF), considered non-significant, when in the stand-by mode. It is well known that high levels of RF can produce biological damage through heating effects (this is how your microwave oven is able to cook food). However, it is not known whether, to what extent, or through what mechanism, lower levels of RF might cause adverse health effects as well. Although some research has been done to address these questions, no clear picture of the biological effects of this type of radiation has emerged to date. Thus, the available science does not allow us to conclude that mobile phones are absolutely safe, or that they are unsafe. However, the available scientific evidence does not demonstrate any adverse health effects associated with the use of mobile phones.

What kinds of phones are in question?

Questions have been raised about hand-held mobile phones, the kind that have a built-in antenna that is positioned close to the user's head during normal telephone conversation. These types of mobile phones are of concern because of the short distance between the phone's

Page 76

antenna—the primary source of the RF—and the person's head. The exposure to RF from mobile phones in which the antenna is located at greater distances from the user (on the outside of a car, for example) is drastically lower than that from hand-held phones, because a person's RF exposure decreases rapidly with distance from the source. The safety of so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house and which operate at far lower power levels and frequencies, has not been questioned.

How much evidence is there that hand-held mobile phones might be harmful?

Briefly, there is not enough evidence to know for sure, either way; however, research efforts are on-going. The existing scientific evidence is conflicting and many of the studies that have been done to date have suffered from flaws in their research methods. Animal experiments investigating the effects of RF exposures characteristic of mobile phones have yielded conflicting results. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. In one study, mice genetically altered to be predisposed to developing one type of cancer developed more than twice as many such cancers when they were exposed to RF energy compared to controls. There is much uncertainty among scientists about whether results obtained from animal studies apply to the use of mobile phones. First, it is uncertain how to apply the results obtained in rats and mice to humans. Second, many of the studies that showed increased tumor development used animals that had already been treated with cancer-causing chemicals, and other studies exposed the animals to the RF virtually continuously—up to 22 hours per day.

For the past five years in the United States, the mobile phone industry has supported research into the safety of mobile phones. This research has resulted in two findings in particular that merit additional study:

In a hospital-based, case-control study, researchers looked for an association between mobile phone use and either glioma (a type of brain cancer) or acoustic neuroma (a benign tumor of the nerve

Page 77

sheath). No statistically significant association was found between mobile phone use and acoustic neuroma. There was also no association between mobile phone use and gliomas when all types of types of gliomas were considered together. It should be noted that the average length of mobile phone exposure in this study was less than three years.

When 20 types of glioma were considered separately, however, an association was found between mobile phone use and one rare type of glioma, neuroepithelliomatous tumors. It is possible with multiple comparisons of the same sample that this association occurred by chance. Moreover, the risk did not increase with how often the mobile phone was used, or the length of the calls. In fact, the risk actually decreased with cumulative hours of mobile phone use. Most cancer causing agents increase risk with increased exposure. An ongoing study of brain cancers by the National Cancer Institute is expected to bear on the accuracy and repeatability of these results.

Researchers conducted a large battery of laboratory tests to assess the effects of exposure to mobile phone RF on genetic material. These included tests for several kinds of abnormalities, including mutations, chromosomal aberrations, DNA strand breaks, and structural changes in the genetic material of blood cells called lymphocytes. None of the tests showed any effect of the RF except for the micronucleus assay, which detects structural effects on the genetic material. The cells in this assay showed changes after exposure to simulated cell phone radiation, but only after 24 hours of exposure. It is possible that exposing the test cells to radiation for this long resulted in heating. Since this assay is known to be sensitive to heating, heat alone could have caused the abnormalities to occur. The data already in the literature on the response of the micronucleus assay to RF are conflicting. Thus, follow-up research is necessary.

FDA is currently working with government, industry, and academic groups to ensure the proper follow-up to these industry-funded research findings. Collaboration with the Cellular Telecommunications Industry Association (CTIA) in particular is expected to lead to FDA providing research

Page 78

recommendations and scientific oversight of new CTIA-funded research based on such recommendations.

Two other studies of interest have been reported recently in the literature:

Two groups of 18 people were exposed to simulated mobile phone signals under laboratory conditions while they performed cognitive function tests. There were no changes in the subjects' ability to recall words, numbers, or pictures, or in their spatial memory, but they were able to make choices more quickly in one visual test when they were exposed to simulated mobile phone signals. This was the only change noted among more than 20 variables compared.

In a study of 209 brain tumor cases and 425 matched controls, there was no increased risk of brain tumors associated with mobile phone use. When tumors did exist in certain locations, however, they were more likely to be on the side of the head where the mobile phone was used.

Because this occurred in only a small number of cases, the increased likelihood was too small to be statistically significant.

In summary, we do not have enough information at this point to assure the public that there are, or are not, any low incident health problems associated with use of mobile phones. FDA continues to work with all parties, including other federal agencies and industry, to assure that research is undertaken to provide the necessary answers to the outstanding questions about the safety of mobile phones.

What is known about cases of human cancer that have been reported in users of hand-held mobile phones?

Some people who have used mobile phones have been diagnosed with brain cancer. But it is important to understand that this type of cancer also occurs among people who have not used mobile phones. In fact, brain cancer occurs in the U.S. population at a rate of about 6 new cases per 100,000 people each year. At that rate, assuming 80 million users of

Page 79

mobile phones (a number increasing at a rate of about 1 million per month), about 4800 cases of brain cancer would be expected each year among those 80 million people, whether or not they used their phones. Thus it is not possible to tell whether any individual's cancer arose because of the phone, or whether it would have happened anyway. A key question is whether the risk of getting a particular form of cancer is greater among people who use mobile phones than among the rest of the population. One way to answer that question is to compare the usage of mobile phones among people with brain cancer with the use of mobile phones among appropriately matched people without brain cancer. This is called a case-control study. The current case-control study of brain cancers by the National Cancer Institute, as well as the follow-up research to be sponsored by industry, will begin to generate this type of information.

What is FDA's role concerning the safety of mobile phones?

Under the law, FDA does not review the safety of radiation-emitting consumer products such as mobile phones before marketing, as it does with new drugs or medical devices. However, the agency has authority to take action if mobile phones are shown to emit radiation at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of mobile phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions at this time, FDA has urged the mobile phone industry to take a number of steps to assure public safety. The agency has recommended that the industry:

•

support needed research into possible biological effects of RF of the type emitted by mobile phones

•

design mobile phones in a way that minimizes any RF exposure to the user that is not necessary for device function

Page 80

•

cooperate in providing mobile phone users with the best possible information on what is known about possible effects of mobile phone use on human health

At the same time, FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of mobile phone safety to ensure a coordinated effort at the federal level. These agencies are:

•

National Institute for Occupational Safety and Health

•

Environmental Protection Agency

•

Federal Communications Commission

•

Occupational Health and Safety Administration

•

National Telecommunications and Information Administration

The National Institutes of Health also participates in this group.

In the absence of conclusive information about any possible risk, what can concerned individuals do?

If there is a risk from these products—and at this point we do not know that there is—it is probably very small. But if people are concerned about avoiding even potential risks, there are simple steps they can take to do so. For example, time is a key factor in how much exposure a person receives. Those persons who spend long periods of time on their hand-held mobile phones could consider holding lengthy conversations on conventional phones and reserving the hand-held models for shorter conversations or for situations when other types of phones are not available.

People who must conduct extended conversations in their cars every day could switch to a type of mobile phone that places more distance between their bodies and the source of the RF, since the exposure level drops off dramatically with distance. For example, they could switch to:

•

a mobile phone in which the antenna is located outside the vehicle

Page 81

•

a hand-held phone with a built-in antenna connected to a different antenna mounted on the outside of the car or built into a separate package

•

a headset with a remote antenna to a mobile phone carried at the waist

Again, the scientific data do not demonstrate that mobile phones are harmful. But if people are concerned about the radio frequency energy from these products, taking the simple precautions outlined above can reduce any possible risk.

Where can I find additional information?

For additional information, see the following Web sites:

Federal Communications Commission

(select “Information on Human Exposure to RF Fields from Cellular and PCS Radio Transmitters”):

World Health Organization

Non-Ionizing Radiation Protection (select Qs & As):

http://www.who.int/emf

United Kingdom, National Radiological Protection Board

http://www.nrpb.org.uk

Cellular Telecommunications Industry Association

http://www.wow-com.com

U.S. Food and Drug Administration

Radiological Health:

http://www.fcc.gov/oet/rfsafety

(WHO) International Commission on

http://www.fda.gov/cdrh/consumer/

(FCC) RF Safety Program

(CTIA):

(FDA) Center for Devices and

Page 82

1. Muscat et al. Epidemiological Study of Cellular Telephone Use and Malignant Brain Tumors. In: State of the Science Symposium;1999 June 20; Long Beach, California.

2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other laboratory assays. In: Annual Meeting of the Environmental Mutagen Society; March 29, 1999, Washington, D.C.; and personal communication, unpublished results.

3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey, A. Effect of a 915-MHz simulated mobile phone signal on cognitive function in man. Int. J. Radiat. Biol., April 8, 1999.

4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular telephones and the risk for brain tumors: a case-control study. Int. J. Oncol., 15: 113-116, 1999.

Page 83

Motorola Limited Warranty for the United States and Canada

Warranty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, messaging devices, and consumer and professional two-way radios (excluding commercial, government or industrial radios) that operate via Family Radio Service or General Mobile Radio Service, Motorola-branded or certified accessories sold for use with these Products (“Accessories”) and Motorola software contained on CD-ROMs or other tangible media and sold for use with these Products (“Software”) to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below. This limited warranty is a consumer's exclusive remedy, and applies as follows to new Motorola Products, Accessories and Software purchased by consumers in the United States or Canada, which are accompanied by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

defined above, unless otherwise provided for below.

Motorola T720 Series and T730 Series

wireless phones sold and

purchased in Canada.

Decorative Accessories and Cases

. Decorative covers, bezels, PhoneWrap™ covers and cases.

One (1) year

purchase by the first consumer purchaser of the product unless otherwise provided for below.

Two (2) years

purchase by the first consumer purchaser of the product.

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

from the date of

for the

Page 84

Products Covered Length of Coverage

Monaural Headsets.

and boom headsets that transmit mono sound through a wired connection.

Consumer and Professional Two-Way Radio Accessories.

Products and Accessories that are Repaired or Replaced.

Exclusions

Normal Wear and Tear.

parts due to normal wear and tear are excluded from coverage.

Batteries.

their rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Only batteries whose fully charged capacity falls below 80% of

Ear buds

Periodic maintenance, repair and replacement of

Limited lifetime warranty

lifetime of ownership by the first consumer purchaser of the product.

Ninety (90) days

purchase by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

from the date returned to the consumer, whichever is longer.

for the

from the date of

Defects or damage that result from: (a) improper

Defects or damage

Page 85

Unauthorized Service or Modification.

from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.

Software

Products Covered Length of Coverage

Software.

in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

Exclusions

Software Embodied in Physical Media.

software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

embodied in physical media (e.g. software that is downloaded from the internet), is provided “as is” and without warranty.

Products or Accessories with (a) serial numbers or

Defects, damages, or the failure of Products,

Applies only to physical defects

Defects or damages resulting

Ninety (90) days

the date of purchase.

No warranty is made that the

Software that is not

from

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

Page 86

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information

USA

Phones

1-800-331-6456

Pagers

1-800-548-9954

Two-Way Radios

and Messaging Devices Canada All Products TTY

1-888-390-6456

For

Accessories

designated above for the product with which they are used.

You will receive instructions on how to ship the Products, Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

and

1-800-461-4575

Software

1-800-353-2729

, please call the telephone number

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF

Page 87

THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.

Page 88

Product Registration

Online Product Registration:

http://www.motorola.com/warranty

Product registration is an important step toward enjoying your new Motorola phone. Registering helps us facilitate warranty service, and permits us to contact you should your phone require an update or other service. Registration is for U.S. residents only and is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Export Law Assurances

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

RF Energy Interference

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 89

Index

accessories 12, 13, 17, 61 accessory connector port 1 active line indicator 22, 23 alert

creating 70 defined 43 downloading 62, 70 setting 63

turning off 19, 20, 51 ALI indicators 22, 24, 48 analog signal indicator 22 animation

downloading 62, 70

inserting in message 62

screen saver 46

viewing 70

wallpaper 44 answering a call 20, 44 antenna 19 application, locking and

unlocking 70

automatic location

information indicators 24 sending 48

automatic redial 49

backlight 47 battery

car kit charger time 67 charging 14 extending battery life 15,

39, 46, 47 installing 13 level indicator 15, 22, 24

block cursor 30, 33 browse text mode 31

calculator 69 call

adding digits after phone

number 53 alert, setting 63 alert, turning off 19, 20,

51 answer options 44 answering 20 call waiting 58 canceling 51 deleting 52 dialed calls list 52 dialing 19 emergency number 51

Page 90

call (continued)

ending 19, 20 making 19 muting 58 received calls list 52 receiving 20 recent calls 52 restricting 61 speakerphone 67 storing 52 three-way call 61 timers 66 unanswered call 54

Call Failed

call waiting 58 caller ID 50, 54 calling line identification.

car kit

automatic answer 67 automatic hands-free 67 charger time 67

power-off delay 67 character chart 34 clock

illustration 21

setting 43 codes

changing 41

default 18, 41

forgetting 42 color, setting 47

message 49

See caller ID

contrast, setting 47 convertible covers 17 cursor 30, 33 customizing the menu 63

data call

receiving 68 sending 68 timers 66

volume meters 66 date, setting 43 datebook 69

menu feature icon 21, 22 deleting a call 52 dialed calls list 52 dialing a number 19 digital signal indicator 22 display

backlight 47

color 47

contrast 47

description 21

idle display, defined 21

language 64

menu icons, personalizing

zooming in/out 47 DTMF tones

activating 65

sending 53, 65

Page 91

earpiece volume 19 emergency number 51 end key 1, 19, 20, 26 ending a call 19, 20

Enter Unlock Code

41, 42 event alert 63 external display 40

fax call

receiving 68

sending 68 flashing cursor 30, 33 flip

external display 40

open to answer 20, 44

replacing flip cover 17

screen saver 46 FM Stereo Radio Headset

4-way navigation key 1, 25,

hands-free use

automatic answer 67

automatic call routing 67

charger time 67

message

power-off delay 67 speakerphone, activating

headset

automatic answer 67 FM Stereo Radio Headset

70 headset jack 1 home keys, personalizing

idle display 21 in use indicator 22, 23

Incoming Call

incoming call, canceling 51 indicators

active line 22, 23 ALI 22, 24, 48 battery level 15, 22, 24 digital/analog signal 22 in use 22, 23 loud ring style 24, 43 menu 21 message waiting 22, 24 missed call 54 ring style 22 roam 22, 23 signal strength 22 silent ring style 24, 43 soft ring style 24, 43 text entry mode 24

message 50

Page 92

indicators (continued)

vibrate and ring style 24,

43 vibrate style 24, 43 voice message waiting

iTAP software 34

joystick 1, 26

key

end 1, 19, 20, 26 4-way navigation 1, 25,

26 left soft key 1, 22, 26, 64 menu 1, 26, 27 power 1, 18 right soft key 1, 22, 26,

64 send 1, 19, 20, 52 voice 1 volume control 1, 19

keypad

answering calls 44 backlight 47 volume, setting 63

language, setting 64 left soft key

functions 1, 22, 26 personalizing 64

location, sending to network

lock

application 70 phone 40

Low Battery

making a call 19 master clear 64 master reset 64 menu

entering text 29, 31 icons, changing in idle

icons, converting to text

icons, described 21 language, setting 64 lists 28 navigating 26 using features 28

view, changing 63 menu indicator 21 menu key 1, 26, 27

message 24

display 64

Page 93

message

menu feature icon 21 receiving 62 sending 62

message waiting indicator

22, 24

messages menu feature

icon 21 micro-browser, using 70 microphone 1 missed call indicator 54

Missed Calls

muting a call 58 my telephone number 20,

my tones 70

network settings 68 notepad 54 number

storing your number 43 viewing your number 20,

numeric text mode 31

one-touch dial

using 56 voicemail number 56

message 54

43, 60

optional accessory, defined

optional feature, defined 13

passwords. See codes phone

active line indicator 23 active line, changing 49 alert, setting 63 alert, turning off 19, 20,

51 answer options 44 automatic location

information 48 clear stored information

64 codes 41 date, setting 43 flip 17, 20 keypad, answering calls

44 language, setting 64 location 48 locking 40 network settings 68 reset all options 64 security code 41 time, setting 43 turning on/off 18 unlock code 41 unlocking 18, 40, 41, 42

Page 94

phone number

active line indicator 23 active line, changing 49 adding digits after 53 attaching two numbers

53, 55 redialing 49 storing in phonebook 62 storing your number 43 viewing your number 20,

phonebook

attaching two numbers

53, 55 dialing a number 63 one-touch dial 56 speed dial number 56 storing an entry 62 voice dialing 63


downloading 62, 70 inserting in message 62 screen saver 46 viewing 70 wallpaper 44

power key 1, 18 predictive text entry 34

radio 70 received calls list 52 recent calls 52

redial

automatic redial 49

busy number 49 reference guide 12 restricting calls 61 right soft key

functions 1, 22, 26

personalizing 64 ring alert

setting 19, 20, 63

turning off 19, 20, 51 ring style

personalizing 63

setting 43 ring style indicators 22, 24,

ring tone

creating 70

downloading 62, 70

inserting in message 62 ringer volume, setting 19,

roam indicator 22, 23

screen saver 46 security code

changing 41

default 41

forgetting 42 send key 1, 19, 20, 52 shortcuts 60, 64

Page 95

shortcuts icon 21 signal strength indicator 22 silent ring alert, setting 19,

20, 43

soft keys

functions 22, 26 illustration 1 labels 21 personalizing 64

sound

downloading 62, 70 inserting in message 62

speakerphone, activating

speed dial

number, defined 56 using 56

standby time, increasing

39, 46, 47 status light 1, 39 storing a call 52 symbol chart 38 symbol text entry 38

tap method text entry 31 telephone number

storing your number 43 viewing your number 20,

text

block cursor 30, 33 browse mode 31 character chart 34 entering 31 entry mode, changing 31 flashing cursor 30, 33 iTAP software predictive

text entry 34 numeric mode 31 symbol chart 38 symbol mode 38 tap method 31

text entry mode indicator 24 text mode, changing 31 three-way call 61 time, setting 43 timers 66 travel charger 15 TTY device 61

unlock

application 70 phone 40

unlock code

bypassing 42 changing 41 default 18, 41 entering 18, 40, 41 forgetting 42

Page 96

vibrate alert

setting 63

turning off 19, 20, 51 vibrate ring alert, setting 43 voice dial 63 voice key

dialing a number 63

illustration 1 voice message waiting

indicator 57 voice notes 69 voicemail

dialing with one-touch dial

using 57

volume

earpiece 19 keypad 63 ringer 19, 63

volume keys 1, 19

wallpaper 44 warranty 81 Web browser icon 21 Web pages 70

zooming in/out 47

U.S. patent Re. 34,976

Page 97

✂

art# 020827-O.eps

Wireless Phone Safety

Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

benefits of wireless phones, one that every user

When driving a car, driving is your first

responsibility. If you find it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

must uphold.

following tips:

1 Get to know your Motorola wireless phone and its

features such as speed dial and redial.

these features help you to place your call without taking your attention off the road.

If available,

Page 98

2 When available, use a hands-free device.

add an additional layer of convenience to your wireless phone with one of the many Motorola Original™ handsfree accessories available today.

3 Position your wireless phone within easy reach.

able to access your wireless phone without removing your eyes from the road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.

4 Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

snow, ice, and even heavy traffic can be hazardous.

5 If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers while driving.

through your address book takes attention away from your primary responsibility—driving safely.

6 Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before pulling into traffic.

be stationary. If you need to make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.

7 Do not engage in stressful or emotional

conversations that may be distracting.

you are talking with aware you are driving and suspend conversations which have the potential to divert your attention away from the road.

Jotting down a “to do” list or going

Try to plan calls when your car will

If possible,

Rain, sleet,

Make people

✂

Page 99

✂

8 Use your wireless phone to call for help.

other local emergency number in the case of fire, traffic accident or medical emergencies.*

9 Use your wireless phone to help others in

emergencies.

progress or other serious emergency where lives are in danger, call 9-1-1 or other local emergency number, as you would want others to do for you.*

10 Call roadside assistance or a special

non-emergency wireless assistance number when necessary.

serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*

If you see an auto accident, crime in

If you see a broken-down vehicle posing no

Dial 9-1-1 or

* Wherever wireless phone service is available.

Page 100

Check the laws and regulations on the use of

wireless telephones and their accessories in the

areas where you drive. Always obey them. The

use of these devices may be prohibited or

restricted in certain areas.

✂

For more information, please call 1-888-901-SAFE or visit the CTIA Web site at

www.wow-com.com

™

Motorola T720 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Welcome

Contents

Safety and General Information

Getting Started

What’s in the Box?

About This Guide

Installing the Battery

Charging the Battery

Battery Use

Changing the Convertible Covers

Turning Your Phone On

Adjusting Volume

Making a Call

Answering a Call

Changing the Call Alert

Viewing Your Phone Number

Learning to Use Your Phone

Using the Display

Using Menus

Entering Text

Using the Status Light

Using the External Display

Locking and Unlocking Your Phone

Changing a Code or Password

If You Forget a Code or Password

Setting Up Your Phone

Storing Your Name and Phone Number

Setting the Time and Date

Setting a Ring Style

Setting Answer Options

Setting a Wallpaper Image

Setting a Screen Saver Image

Zooming In and Out

Setting Display Contrast

Setting Display Color

Adjusting the Backlight

Hiding or Showing Location Information

Calling Features

Changing the Active Line

Redialing a Number

Using Automatic Redial

Using Caller ID

Canceling an Incoming Call

Turning Off a Call Alert

Calling an Emergency Number

Viewing Recent Calls

Returning an Unanswered Call

Using the Notepad

Attaching a Number

Calling With Speed Dial

Using Voicemail

Muting the Phone

Using Call Waiting

Phone Features

Main Menu

Feature Quick Reference

Specific Absorption Rate Data

Additional Health and Safety Information

Warranty

Product Registration

Export Law Assurances

RF Energy Interference

Index
