Motorola T6QH1 User Guide
Moto Surround S505
Quick Start Guide
Product Overview
1
2
3
5 6 7 8 9 10 11
4
Headband
1
Adjustable slider
2
Adjust the headband to fit your head size.
Left earpiece
3
Built-in rechargeable battery.
Right earpiece
4
Micro USB power port
5
Connect an USB cable for charging.
6
Microphone
Use to speak for a call or voice recognition.
LED indicator
7
Adjustable slider
8
Adjust the headband to fit your head size.
Charging the Built-in Battery
The unit has been equipped a built-in rechargeable battery. To charge it, connect one end of the
USB cable to the Micro USB power port of this unit, the other end to computer USB port or
USB power adapter. The LED indicator will display the charging status:
You can also check the built-in battery power by pressing + and – button simultaneously when
this unit is not in a call. The LED indicator will display the battery power level as follows:
To compute USB port,
or USB power adapter
Note:
• When this unit is connected to an iOS device, a battery icon will appear on the screen
next to the Bluetooth icon to indicate the built-in battery power of this unit.
Lights in red
Lights in green
Lights in red
Lights in yellow
MFB button
9
- Press to start/pause music playback.
- Press to answer/end a call.
Volume +/– button
10
- Press to adjust the volume levels.
- During music playback, press and hold + button to skip to
the next track; press and hold – button to skip to the
previous track.
- When a call is coming, press and hold + or – button to
dismiss it; during a call, press + and – button simultaneously to mute the microphone.
Power button
11
Press to turn on/off this unit.
Power is less than 90%
Power is more than 90%, or full charged
0~19%
20%~70%
71%~100%Lights in green
Playing Back via Bluetooth
To Establish a Bluetooth Connection
1.
Press Power button to turn on this unit. The unit will enter pairing mode automatically with the
LED indicator blinking in blue.
2. Open the Bluetooth settings menu on your Bluetooth-enabled device. Once this unit is
recognized, S505 will appear in the list of Bluetooth devices. Select S505 in the Devices list
to pair with your device. On the Bluetooth-enabled device, enter 0000 as the PIN, if
prompted. Once this unit is successfully connected, the LED indicator will turn solid and you
can also hear a prompt tone.
3. Press MFB button on this unit or Play button on your Bluetooth-enabled device to start
music playback.
Power buttonMFB button
Notes:
• You can change the playback volume by either pressing VOLUME +/– buttons on this unit,
or changing the volume on your paired device.
• If you want to establish a new Bluetooth connection with other Bluetooth-enabled devices,
you need to turn off the Bluetooth function of all the paired Bluetooth-enabled devices, and
then follow the steps above.
To Connect Two Bluetooth Devices
1. Turn off the Bluetooth function of the paired Bluetooth-enabled devices.
2. Turn off this unit.
3. Establish a new Bluetooth connection with another Bluetooth-enabled device following the
steps in To Establish a Bluetooth Connection section above.
4. Open the Bluetooth settings menu on one of the paired Bluetooth-enabled devices, and turn
on Bluetooth function, you will hear a tone when it connects. Now both the Bluetoothenabled devices are connected to this unit simultaneously.
5.
Start playback of one paired device to stream music to this unit. If you want to play from the
other paired device, pause the current playback and start playback on the other paired device.
To Access the Voice Recognition
After connected successfully via Bluetooth, press and hold MFB button to access the voice
assistant (such as MotoSpeaker, Google Voice, Siri, etc.) of your Bluetooth-enabled device.
Using Hands-free Calling
1. Press Power button to turn on this unit.
2. Establish the Bluetooth connection between this unit and your mobile phone.
To Answer a Call
When a call arrives, the music playback fades out and a ring tone is heard from this unit. Press
MFB button and speak using the microphone.
Notes:
• The music playback is muted, and will be resumed after the call has finished.
• Press VOLUME +/– buttons on this unit simultaneously to mute the microphone. Press
VOLUME +/– buttons simultaneously again to resume the microphone.
Power buttonMFB button
• Press MFB button again to finish the call.
• During a call, if another call is coming, press MFB button to answer it, and the first call is
held on; press MFB button to finish the second call, then the first call resumes.
To Reject a Call
When a call arrives, press and hold VOLUME + or – button to reject the call.
safe, smart, protected
en-USen-US
Safety, Regulatory & Legal
Battery Use & Safety
War nin g:
Your product contains a battery that should only be removed by a
Motorola approved service center or recycler.
•
Don’t try to remove or replace the battery yourself. Attempting to remove
or replace the battery may damage the battery and may cause burning and
injury.
•
Don’t try to take apart or fix your product. Attempting to take apart or fix
your produc t may damage the battery and may cause burning and injury.
•
Don’t crush, bend, or expose your product to heat or liquid. This may
damage the battery and may cause burning and i njury.
Battery Charging
Battery Charging
Notes for charging your product’s battery:
•
During charging, keep your product and charger near room temperatu re
for efficient battery charging.
•
New batteries are not fully charged.
•
New batteries and batteries that have been stored for a while may take
longer to charge.
•
Motorola batteries and charging systems have circuitry that protects t he
battery from damage from overcharging.
Third Party Accessories
Using third party accessories, i ncluding but not limited to batteries, chargers ,
headsets, covers, cases, screen protectors, and memory cards, may impact
en Safety, Regulatory & Legal 1
your product’s performance. Using a non-Motorola battery or charger may
present a risk of fi re, explosion, leakage, or other hazard. Motorola’s warranty
doesn’t cover damage to the product caused by non-Motorola batteries and/or
chargers. For a list of Motorol a accessories, visit
www.motorola.com/us/consumers/Accessories/accessories,en_US,sc.html
(in English only).
Driving Precautions
Driving Precautions
Responsible and safe driving is your primary responsibility when driving a
vehicle. Always obey local laws and regulations.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Use a handsfree device if available or requ ired by law in your area.
•
Enter destination information into a navigation device
•
Use voice activated features (such as voice dial) a nd speaking features
(such as audible directions), if available.
•
Concentrate on driving, and stop using the device if you can’t concentrate.
Pull over safely before using your mobile device to send messages, surf the
web, or use other applications.
Caution About High Volume Usage
War nin g:
Exposure to loud noise from any source for extended
periods of time may affect your hearing. The louder the sound, the
less time is required before your hearing could be affected. To
protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
2 Safety, Regulatory & Legal en
before
driving.
If you experience hearing discomfort, including the sensation of pressure or
fullness in your ears, ringing in your ears, or muffled speech, you sho uld stop
listening to the device through your headset or headphones and have your
hearing checked.
Children
Children
Keep your mobile device and its accessories away from small children.
These products are not toys and may be hazardous to small children. For
example, a chokin g hazard may exist for small, detachabl e parts.
Supervise access.
monitor their access to help prevent loss of data or unexpected charges for
data or application purchases.
Allergens
Glass Parts
Motorola Mobility avoids using known allergens i n our products. From time to
time, trace am ounts of an allergen may be added dur ing manufacture of a
device or device component that could cause discomfort for some individuals.
This approach is common for many types of products. We recommend that
you monitor any products that may be in prolonged contact with your skin, and
remove them if you experience skin irritation.
Use & Care
Use & Care
To care for your Motorola product, please observe the foll owing.
•Liquids:
sweat, or other liquids.
•Drying:
conventional oven, or dryer.
If a child does use your mobile device and accessories,
Don’t expose your product to water, rain, extreme humidity,
Don’t try to dry your product using a microwave oven,
en Safety, Regulatory & Legal 3
•Extreme heat or cold:
032374o
032376o
60°C (140°F). For battery powered accessories, do not recharge your
accessory in temperatures below 0°C (32°F) or above 45°C (113°F).
•Dust and dirt:
materials.
•Cleaning:
alcohol or other cleaning solutions.
• Shock and vibration:
vibration.
•Protection:
connector and compartment covers are closed and s ecure, and avoid
carrying it with h ard objects such as keys or coins.
Symbol Key
Your battery, charger, accessory product, user’s gui de, or packaging may
contain symbols, defined as follows:
Avoid temperatures below -10°C (14°F) or above
Don’t expose your product to dust, dirt, sand, food, or similar
To clean your product , use only a dry soft cl oth. Don’t use
Don’t drop your product or expose it to strong
To help protect your product, always make sure that all
Symbol Defin itio n
Important safety i nformation follows.
Don’t dispose of your battery or accessory
product in a fire.
4 Safety, Regulatory & Legal en
Symbol Defin itio n
032375o
Your battery or accessory product may require
recycling in accordance with local laws. Contact
your local regulatory a uthorities for more
information.
Don’t dispose of your battery or accessory
product with your household waste. See “ Disposal
& Recycling” for more information.
For ind oor us e on ly.
Only use you r charg er ind oors.
en Safety, Regulatory & Legal 5
European Union Directives
Type
Name
Conformance Statement
EU Conformance
The following CE compliance information is applicable to Motorola products
that carry one of the following CE marks:
0168
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive
1999/5/EC
•
All other relevant EU Di rectives
For products that support Wi-Fi 802.11a/ac (as defined in your product
information): This device is restricted to indoor use when operating i n the 5.15
to 5.25 GHz (802.11a/ac) Wi-Fi frequency band.
The following gives an example of a typical Type name:
6 Safety, Regulatory & Legal en
You can view your product’s Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at
only). To find your DoC, enter the Type name from your product’s label in the
“Search” bar on the website.
Regulatory authorities within the EU may obtain compliance information by writing to: Product Safety and
Compliance, Motorol a Mobility UK Ltd., Redwood, Crockfo rd Lane, Chineham Busines s Park, Basingstoke,
RG24 8WQ, UNITED KINGDOM.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo
and/or FCC ID on the product label.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec.
15.105(b). These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interf erence to radio
communications. However, there is no guarantee that interference will not
occur in a particular i nstallation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a c ircuit different from that to which
the receiver is connected.
•
Consult the dealer or an experienced ra dio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
www.motorola.com/rtte
(in En glish
en Safety, Regulatory & Legal 7
and (2) this device must accept any interference received, including
interference that may cause undesired operation. See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the
user. Any changes or modifications could void the user’s authority to operate
the equipment. See 47 CFR Sec. 15.21.
For products that support Wi-Fi 802.11a/ac (as defined in product information):
In the United States, do not use your device outdoors while connected to an
802.11a/ac Wi-Fi network. The FCC prohibits such outdoor use since
frequencies 5.15-5.25 GHz can cause interference with Mobile Satellite
Services (MSS). Public Wi-Fi access points in this range are optimized for
indoor use.
Industry Canada Notice to Users
Industry Canada Notice
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not
cause interference and (2) This device must accept any interference, in cluding
interference that may cause undesired operation of the device. See RSS-Gen,
Section 8.4. This device complies with ICES-003 requirements for Class B ITE
(Information Technology Equipment).
For products that support Wi-Fi 802.11a/ac/ac (as defined in your product
information): Do not use your device outdoors while connected to an
802.11a/ac/ac Wi-Fi network, or when using Mobile Hotspot or Wi-Fi Direct
features in the 5 GHz band. Industry Canada prohibits outdoor use of Wi-Fi
devices between 5.15 and 5.25 GHz, as this may cause interference with the
Mobile Satellite Service (MSS).
CAN ICES-3 (B)/NMB-3(B)
8 Safety, Regulatory & Legal en
Disposal & Recycling
Recycling
Products & Accessories
Please don’t dispose of products or electrical accessories (such as
chargers, headsets, or batteri es) with your household waste.
Warning: Never dispose of batteries, either separately or within
a mobile device, i n a fire because they may explo de.
should be disposed of in accordance with the national collection and recycling
schemes operated by your local or regional authority. Or, you may return
unwanted Motorola products and electrical accessories to any Motorola
Approved Service Center in your region. For details on approved national
recycling schemes and Motorola recycling activities, go to:
www.motorola.com/recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in
accordance with national coll ection and recycling requirements. Please
contact your regional authorities for more details.
Software Copyright
Software Copyright Notice
Motorola products may include copyrighted Motorola and third-party software
stored in semiconductor memories or other media. Laws in the United States
and other countries preserve f or Motorola and third-party software providers
certain exclusive rights for copyrighted softwa re, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of Motorola products shall not be
deemed to grant either directly or by implication, estoppel, or otherwise, any
license under the copyrights, patents, or patent applications of Motorola or any
en Safety, Regulatory & Legal 9
These items
third-party software provider, except for the normal, non-exclusive, royalty-free
license to use that aris es by operation of law in the sale of a product.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of
America and Canada. The Governments of the United States of America and
Canada may restrict the exportation or re-exportation of this product to certain
destinations. For further information contact the U.S. Department of
Commerce or the Canadian Department of Foreign Affairs and International
Tr a d e .
Motorola Limited Warranty
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Mobility LLC warrants its
mobile telephones (“Products”), Motorola-branded or certified accessories
sold for use with these Products (“Accessories” ), and Motorola software
contained on CD-ROMs or other tangible media and sold for use with these
Products (“Software”) to be free from defects in materials and workmanship
under normal consumer usage for the period(s) outlined below. This limited
warranty is a consumer's exclusive remedy, and applies as follows to new
Motorola Products, Accessories, and Software purchased by consumers, which
are accompanied by this written warranty:
10 Safety, Regulatory & Legal en
Products and Accessories
Products Covered Length of Coverage
Products and Accessories
defined above, unless otherwise
provided for below.
Decorative Accessories and
Cases.
Decorative covers, bezels,
and cases.
Monaural Headsets.
boom headsets that transmit mono
sound through a wired connection.
Products and Accessories that
are Repa ired or Repl aced.
Exclusions (Products and Access ories)
Normal Wear and Tear.
parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of their
rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse.
storage, misuse or abuse, accident or neglect, such as physical damage
en Safety, Regulatory & Legal 11
as
One (1 ) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Limited lifetime warranty
lifeti me of ownersh ip by the first
consumer purchaser of the
product.
Ear buds and
Periodic maintenance, repair and replacement of
Defects or damage that result from: (a) improper operation,
Limited lifetime warranty
lifeti me of ownersh ip by the first
consumer purchaser of the
product.
The balance of the ori ginal
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
for the
for the
(cracks, scratches, etc.) to the surface of the product resulting from misuse;
(b) contact with liquid, water, rain, extreme humidity or heavy perspiration,
sand, dirt or the like, extreme heat, or food; (c)use of the Products or
Accessories for commercial purposes or subject ing the Product or Accessory
to abnormal usage or conditions; or (d) other acts which are not the fau lt of
Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
result from the use of non-Motorola branded or certified Products, Accessor ies,
Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification.
service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, or its authorized
service centers, are excluded from coverage.
Altered Products.
that have been removed, altered or obliterated; (b) broken seals or that show
evidence of tampering; (c) mismatched board serial numbers; or
(d) nonconforming or non-Motorola housings, or parts, are excluded from
coverage.
Communication Services.
Accessories or Software due to any communication service or signal you may
subscribe to or use with the Products Accessories or Software is excluded from
coverage.
Software
Products Covered Length of Coverage
Softwa re.
defects in the media that
embodies the copy of the
software (e.g. CD-ROM).
12 Safety, Regulatory & Legal en
Products or Accessories with (a)serial numbers or date tags
Defects, damages, or the failure of Products,
Applies only to physical
Defects or damage that
Defects or damages resulting from
Ninety (90) days
purchase.
from the date of
Exclusions (Software)
Software Embodied in Physical Media.
will meet your requirements or will work i n combination wi th any hardware or
software applications provided by third parties, that the operation of the
software products will be uninterrupted or er ror free, or that all defects in the
software products will be corrected.
Software NOT Embodied in Physical Media.
in physical media (e.g. software that is downloaded from the Internet), is
provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the purchase
price of any Products, Accessories or Software that does not conform to this
warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or parts.
No data, software or applicatio ns added to your Product, Accessory or
Software, including but not li mited to personal contacts, games and ringer
tones, will be reinst alled. To avoid losing such dat a, software, and applications,
please create a back up prio r to requesting service.
No warranty is made that the software
Software that is not embodied
How to Obtain Warranty Service or Other
Information
Please contact Motorola using the contact details provided on the cu stomer
support website at
You will receive instructions on how and where to ship the Product for
assessment. We will generally need: (i) proof of purchase; (ii) a written
en Safety, Regulatory & Legal 13
www.motorola.com/support
.
description of the problem; (iii) the name of your mobile network service
provider, if applicable; (iv) your address and telephone number. We will only
use this information for the purposes of processing your claim under this
Limited Warranty.
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To obtain
service, you must include: (a) a copy of your receipt, bill of sale or other
comparable proof of purchase; (b) a written description of the problem; (c) the
name of your service provider, if applicable; (d) the name and location of the
installation facilit y (if applicable) and, most importantly; (e) your address and
telephone number.
What Other Limitations are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR
LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE
ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR
SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED
BY LA W.
14 en
Loading...
