Safety and General Information
Portable Phone Operation and EME
Exposure
Antenna Care
Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the phone and may violate FCC
regulations.
Do NOT hold the antenna when the phone is in use.
Holding the antenna affects call quality and may cause the
phone to operate at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you
would a wireline telephone. Speak directly into the
microphone.
Body-Worn Operation
To maintain compliance with FCC RF exposure guidelines, if you
wear a phone on your body when transmitting, always place the
phone in a Motorola-supplied or approved clip, holder,
holster, case, or body harness. Use of
non-Motorola-approved accessories may exceed FCC RF
exposure guidelines. If you do not use a body-worn
accessory, and are not holding the phone in the normal
use position at the ear, ensure the phone and its
antenna are at least one inch (2.5 centimeters) from
your body when transmitting.
15
Safety and General Information
Data Operation
When using any data feature of the phone, with or without an
accessory cable, position the phone and its antenna at
least one inch (2.5 centimeters) from your body.
Approv ed Accessor ies
For a list of approved Motorola accessories, visit our website at
www.motorola.com.
Electromagnetic Interference/
Compatibility
Note: Nearly every electronic device is susceptible to
electromagnetic interference (EMI) if inadequately shielded,
designed, or otherwise configured for electromagnetic
compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility
conflicts, turn off your phone in any facility where posted notices
instruct you to do so. Hospitals or health care facilities may be
using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your phone when on board an
aircraft. Any use of a phone must be in accordance with
applicable regulations per airline crew instructions.
16
Phoenix TDMA
Wireless Telephone
Basic User’s Guide
Draft
December 21, 2000
Menu Map
N
This i
Main Menu
• Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
• Phonebook
• Datebook
• Quick Dial
• Radio
• Messages
• Voicemail
• Text Msgs
• Browser Alerts
• Quick Notes
• Outbox
• Drafts
• Shortcuts
• Voice Notes
• Browser
• Settings
(see reverse)
ote:
layout. You or your service
provider may have modified the
menu structure or changed some
feature names. Not all features
may be available for all users. For
example, the
displayed only when the FM
radio headset accessory is
plugged into the accessory
connector port on your phone.
Change display zoom:
Press
press and hold
Lock/unlock keypad:
Press
Display my phone number:
Press
Go to dialed calls list:
Press
s the standard menu
Radio
feature is
Shortcuts
M
, then
M
M *
M #
N
Settings Menu
• Ring/Vibrate
• Alert
Alert
Detail
•
• Phone Status
• My Tel. Number
• Battery Meter
• Other Information
• Connection
• Incoming Call
• In-Call Setup
• In-Call Timer
• Answer Options
• Security
• Phone Lock
• Lock Keypad
• Lock Application
• Restrict Calls
• New Passwords
• Other Settings
• Personalize
• Main Menu
• Keys
• Greeting
• Banner
• Quick Dial
• Initial Setup
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
• Status Light
• Zoom
• Scroll
• Animation
• Language
• Battery Save
• Contrast Setting
• DTMF
• Master Reset
• Master Clear
• Network
• Car Settings
• Headset
Welcome
Welcome to the world of
Motorola digital wireless
communications!
Motorola is a global
leader in
communications
technology. We are
pleased that you have
chosen the Motorola
V
Series 60t
wireless phone to keep
you connected with
ease.
All Motorola phones are designed and manufactured to
meet Motorola’s rigorous specifications and world-class
quality standards. During development, our testing
through rigorous
team took the Motorola
durability tests including temperature, humidity, shock,
dust, vibration, and drop tests.
V
We are confident that you and your callers will find your
wireless phone to be a convenient and reliable way to
V
stay in touch. Thank you for choosing Motorola
and enjoy your new phone!
,
1
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
MOTOROLA, the Stylized M Logo and all other
trademarks indicated as such herein are trademarks of
Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. TrueSync is a
trademark of Starfish, Inc., a wholly owned independent
subsidiary of Motorola, Inc. All other product or service
names are the property of their respective owners.
© 2000 Motorola, Inc. All rights reserved. Printed in the
U.S.A.
Manual number: 6809435A45-O
Cover number: 8988485L07
2
Phone Diagram
Display
Headset Jack
Insert headset
accessory for
hands-free use.
Left Soft Key
Perform functions
identified by left
display prompt.
Volume Keys
Adjust earpiece
and ringer volume.
End Key
End phone calls,
exit menu system.
Smart Key
Select menu
items, send and
end calls.
Power Key
Earpiece
Accessory
Connector Port
Insert charger and
phone accessories.
Menu Key
Status Light
See incoming call
and service status.
Right Soft Key
Perform functions
identified by right
display prompt.
Voice Key
Record voice notes,
phonebook and
shortcut names.
Send Key
Send and answer
calls, view recent
dialed calls list.
Scroll Key
Move through
menus and lists.
Microphone
3
Contents
