APPLICANT: MOTOROLA, INC. FCC ID: IHDT56AA1

INSTRUCTION MANUAL

A preliminary draft copy of the Users Manual follows:

EXHIBIT 8

CDMA Panther Wireless

Telephone Basic User’s Guide

Preliminary Draft

June 16, 2000

Contents

Safety Information Getting Started

Opening the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Turning On Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Learning More Tasks

Navigating to Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Storing an Entry in the Phonebook . . . . . . . . . . . . . . . . . . . . . 25

Using Text Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . . . . . 33

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Unanswered Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Dialing Emergency Numbers . . . . . . . . . . . . . . . . . . . . . . . . . 37

Additional Dialing Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Contents

Using In-Call Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Phone Fundamentals

Phone Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Status Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

When You’re Ready to Do More

Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Menu Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Conference Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

VoiceNotes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Datebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Conﬁguring Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Troubleshooting

Contents

FDA Update Index Patent Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

. . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Safety Information

Important:

handheld phone.

Read this information before using your wireless

Exposure to Radio Frequency Signals

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

In August 1996, The Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies:

• American National Standards Institute (ANSI) IEEE. C95. 1-1992

• National Council on Radiation Protection and Measurement (NCRP). Report 86

• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996

Safety Information

• Ministry of Health (Canada), Safety Code 6

Those standards were based on comprehensive and periodic evaluations of the relevant scientiﬁc literature. For example, over 120 scientists, engineers, and physicians from universities,

government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those standards). For additional information concerning exposure to radio frequency signals, see the statement by the FDA at the end of this user guide.

To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the Motorola-supplied or approved carrying case, holster, or other body-worn accessory.

If you do not use a body-worn accessory, ensure the antenna is at least one inch (2.5 centimeters) from your body when transmitting. Use of non-Motorola accessories may violate FCC RF exposure guidelines.

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modiﬁcations, or attachments could damage the phone and may violate FCC regulations.

Safety Information

Phone Operation

Normal Operation

Hold the phone as you would any other telephone, with the antenna pointed up and over your shoulder.

Tips on Efﬁcient Operation

Observe the following guidelines to operate your phone most efﬁciently.

• Extend your antenna fully, if applicable.

• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Batteries

Safety Information

Caution:

burns if a conductive material, such as jewelry, keys or beaded chains, touches exposed terminals. The material may complete an electrical circuit and become quite hot. To protect against such unwanted current drain, exercise care in handling any charged battery, particularly when placing it inside your pocket, purse, or other container with metal objects. When the battery is detached from the phone, your batteries are packed with a protective battery cover; please use this cover for storing your batteries when not in use.

All batteries can cause property damage, injury, or

Driving

Check the laws and regulations on the use of wireless telephones in the areas where you drive. Always obey them. Observe the following guidelines when using your phone while driving.

• Give full attention to driving--driving safely is your ﬁrst responsibility.

• Use hands-free phone operation, if available.

• Pull off the road and park before making or answering a call if driving conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Safety Information

Persons with pacemakers:

• should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON

• should not carry the phone in a breast pocket

• should use the ear opposite the pacemaker to minimize the potential for interference

• should turn the phone OFF immediately if you have any reason to suspect that interference is taking place

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Safety Information

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

Switch OFF your phone before boarding an aircraft. Airline regulations prohibit using your phone while in the air. Check and comply with the policy of your airline regarding the use of your phone while the aircraft is on the ground.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off twoway radio.” Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF, do not remove your battery when you are in any area with a potentially explosive atmosphere, and obey all

Safety Information

signs and instructions. Sparks from your battery in such areas could cause an explosion or ﬁre resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include: fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or storage facilities; areas where fuel odors are present (for example, if a gas/propane leak occurs in a car or home); areas where the air

contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you normally would be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inﬂates with great force. Do NOT place objects, including both installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If invehicle wireless equipment is improperly installed and the air bag inﬂates, serious injury could result.

US021600

Safety Information

Getting Started

Opening the Box

Your digital wireless phone typically comes equipped with a charger and at least one battery. A large selection of accessory options can customize your wireless phone for maximum performance and portability. The following illustration shows the standard package options.

Note:

Your phone and accessories may not look exactly as

pictured.

Lithium Battery

Getting Started

Motorola

Telephone

Holster

Battery

Before you can use your phone, you will need to install and charge the battery.

We recommend that you use only Motorola Original™ batteries and accessories, and that you store batteries in their protective covers when not in use.

Installing the Battery

Do This

Remove the battery’s protective cover.

Push down the battery door release latch, then slide the door down and lift off.

Getting Started

Do This

Insert the battery, printed arrows ﬁrst, into the battery compartment and push down.

Replace and close the battery door.

Charging the Battery

Do This

Plug the AC adapter into your phone with the release tab facing up

Getting Started

Plug the other end of the AC adapter into the appropriate electrical outlet.

Illustration

to come

Turning On Your Phone

Do This To

Press and hold the power key

turn on your phone

Do This To

Enter your unlock code and press

OK (+)

unlock your phone, if necessary

Placing a Call

To place a call, your phone must be turned on, be unlocked, and be in contact with the network.

Press To

keypad keys enter the phone number

Tip: If you make a mistake, press

DELETE (-) to delete the last digit, or press

and hold

Note: You can enter a phone number up to a maximum of 32 digits, but only the last 24 digits appear in the display.

place the call

DELETE (-) to clear all digits.

Ending a Call

Getting Started

Press To

end the call

Redialing a Number

If you hear an ordinary busy signal, the phone number you dialed is busy.

Press To

hang up

redial the busy number

Receiving a Call

To receive a call, your phone must be turned on and be in contact with the network.

When you receive a call, your phone rings and/or vibrates and displays an incoming call message.

Press To

N or ANSWER (+)

answer the call

Getting Started

Viewing Y our Phone Number

Press To

M #

display your phone number

Learning More Tasks

Navigating to Features

You can access many of your phone’s features through a menu system. Use these keys to move through the menu system and ﬁnd the feature you want:

Learning More Tasks

Left Soft Key

Perform the function shown in the lower left corner of the display (usually

EXIT

BACK

)

Menu Key

Enter the menu system

End Key

Exit the menu system without making changes

Main Menu

Recent Calls

Fixed Dial

EXIT SELECT

Right Soft Key

Perform the function shown

in the lower right corner of the display (usually

SELECT

the highlighted menu item)

Scroll Key

Move up or down through menus and lists

Some features that are described in this guide are designated with this logo. These are optional network and subscription-dependent features. Contact your service provider for information about availability.

This guide provides navigation instructions that show you how to get to speciﬁc menu features as follows:

Find the

M > Recent Calls > Dialed Calls

Feature

The > symbol means that you should scroll to and select the indicated feature. To locate and select the

Dialed Calls feature as

shown in the above example:

Do This

12:00

Ready

From the idle display, press

to enter the

menu system

Learning More Tasks

PH BOOK M MESSAGE

Do This

Main Menu

Recent Calls

Fixed Dial

EXIT SELECT

Recent Calls

Received Calls

Dialed Calls

EXIT SELECT

Recent Calls

is already highlighted because it is the ﬁrst item in the menu list

Press

SELECT

(+) to select

Recent Calls

Press S to scroll to

Dialed Calls

Learning More Tasks

Do This

Recent Calls Received Calls

Dialed Calls

EXIT SELECT

Press

SELECT

(+) to

select

Dialed Calls

Your phone displays the dialed calls list

Using Menu Features

To set or adjust a phone feature, you may have to select an item from a list of options, or use the keypad to enter information.

Some features prompt you to select from a list of items or actions:

Scroll down to view additional items.

Press

BACK

(-) to go back to the previous screen.

• In a numbered list, press a number key to highlight the item.

• In an alphabetized list, press a key multiple times to cycle through the letters on the key and highlight the closest matching list item.

Dialed Calls

10) John Smith

9) Mary Smith

BACK M VIEW

Press

to open a contextsensitive sub-menu.

Highlighted item

Press

VIEW

(+) to view details of the highlighted item.

Learning More Tasks

• When a ﬁeld contains a predeﬁned list of values, press the left and right to scroll and view the entire entry.

S to

Other features, such as the phonebook and datebook applications, require you to enter information in multiple ﬁelds:

Scroll down to view additional ﬁelds.

Entry Details

Name:John Smith

No.:2125551212

CANCEL CHANGE

Highlighted ﬁeld

Press

CANCEL

(-) to go back to the previous screen and cancel any changes.

Press to edit the information in the ﬁeld.

• Enter information in an empty ﬁeld by typing numbers or text from the keypad. (See “Entering Text” on page 22.)

• When a ﬁeld contains a predeﬁned list of values, press the left and right to scroll through and select a value.

Learning More Tasks

CHANGE

(+)

S to

The message center application lets you compose and send alphanumeric text messages. A ﬂashing I-beam cursor indicates the text insertion point:

Flashing I-beam cursor indicates insertion point.

Press

CANCEL

to exit without making changes.

Msg:

___________________

____________________ CANCEL M BROWSE

(-)

Press to open the sub-menu.

Press

BROWSE

to select data from a list of entries.

(+)

When you begin entering data, the I-beam cursor change to a block cursor and the soft key functions change appropriately:

Block cursor indicates current highlighted character.

Msg:

T __________________

____________________ DELETE M OK

Learning More Tasks

Press

CANCEL

(-) to delete the character to the left of the insertion point.

Press OK (+) to accept and store the data.

Entering Text

General Text Entry Rules

Use the number keys to enter letters, numbers, and other characters. Press the same key repeatedly to cycle through available characters (see “Character Chart” on page 23):

Press a number key to enter text at I-beam cursor location

Press a number key as many times as necessary to enter the desired character

Learning More Tasks

Press and hold a number key to cycle between uppercase and lowercase characters

Enter Text:

__________________

___________________

CANCEL M BROWSE

Press up or down to mov e I-beam cursor up or down one line, change character in block cursor to uppercase or lowercase

Press left or right to move I-beam cursor to the left or right, change block cursor to I-beam cursor

• If you do not press a key for two seconds, the character in the block cursor is accepted and the cursor moves to the next position.

• The ﬁrst character of every sentence is capitalized unless you manually override it.

Character Chart

Use this chart as a guide for producing characters. Press and hold a key to cycle between uppercase and lowercase characters.

1 [space] . 1 ? ! , @ _ & : " ( ) ' ¿ ¡ % £ $ ¥ 2 A B C 2 Ä Å à α β Ç 3 D E F 3 ∆ É è Φ 4 G H I 4 Γ ì 5 J K L 5 Λ 6 M N O 6 Ñ Ö Ø Ò Ω 7 P Q R S 7 Π ß Σ 8 T U V 8 Θ Ü ù

9 W X Y Z 9 Ξ Ψ

0 + - 0 x * / = > < # §

Learning More Tasks

Using iTAP

iTAP lets you type the letters of a word using only one keypress per letter. To use iTAP, press prompted to enter text.

When you activate iTAP, the third line of the display becomes a working area that shows a list of the most common words and letter combinations based on the keys you press. The list is updated with each keypress. When you have entered all the letters of a word, press

S to scroll left and right through the list and select

the word you want.

M and select iTAP when you are

For example, to spell the word “act,” press

2 2 8. The

display shows:

I-beam cursor indicates the text insertion point.

Learning More Tasks

Press

DELETE

clear the last letter entered.

___________________

____________________

Cat Act Bat Abu

DELETE SELECT

(-) to

Press S to scroll and view additional word choices in the working area.

Press

SELECT

enter the highlighted word at the insertion point.

If the word you are spelling is not in the iTAP dictionary, an appropriate letter combination may not appear in the word list. Delete one or more characters until you see an accurate letter

(+) to

combination, then highlight it to lock that portion of the word. Continue entering letters and highlighting letter combinations to spell the word.

• The ﬁrst word of a sentence is automatically capitalized, with following words in lowercase. Press up/down times to force initial character capitalization, all uppercase, or all lowercase characters.

S one or more

• A space is automatically added after each word. When you add punctuation, the space before the punctuation is removed. Press characters as shown in the “Character Chart” on page 23.

• To type a number, enter the ﬁrst digit and then highlight it in the working area. Following keypresses add digits to the number until you press the insertion point.

1 or 0 to enter punctuation or special

SELECT (+) to enter the number at

Storing an Entry in the Phonebook

You can store a list of names and phone numbers in your phone’s electronic phonebook. You can view and dial these entries directly from your phone.

Learning More Tasks

Fields in a Phonebook Entry Form

Voice Name

a recorded Voice Name. (You can call the entry by saying the name when your phone is idle.)

Type

icon is the type of phone number

Work

Home

Main

Mobile

Fax

Pager

icon indicates

$*Carlo Emrys

01543372151410

Speed No.15

BACK M EDIT

Returns to list view

Opens phone menu

The title is the entry’s name of the person or group) or

Speed Number

you can enter from idle to “speed dial” the entry).

Opens entry form

Name

(the number

No.

is the

phone number.

Speed Number

Storing a Phonebook Entry

Note: You can also use the following procedure to store a ﬁxed

Learning More Tasks

dial entry by scrolling to and selecting

Fixed Dial.

(the

Find the Feature

M > Phonebook M > New

Entering Required Fields

Some ﬁelds are required for a phonebook entry.

Press To

S scroll to Name

Change (+) select Name

keypad keys enter a name for the phonebook entry (see

“Entering Text” on page 22)

OK (+) store the name

S scroll to No.

Change (+) select No.

keypad keys enter the phone number

OK (+) store the phone number

Recording a Voice Name

You can also optionally record a voice name for a phonebook entry.

Press To

S scroll to Voice Name

Record (+) record a voice name

Learning More Tasks

The phone displays

say name.

Press Voice Key then

Press To

voice key and say the entry’s name (in two seconds)

record the voice name The phone displays

REPEAT name.

Press Voice Key then

voice key and repeat the name

Entering Optional Fields

conﬁrm the voice name The phone displays Trained: Voice Name.

Continue by entering some optional ﬁelds, if needed.

Press To

S scroll to Type

Change (+) select Type

S scroll to the type of phone number

Select (+) select the type of phone number

S scroll to Speed No.

Select (+) select Speed No.

Learning More Tasks

The phone automatically ﬁlls in the ﬁrst available number on a new form.

keypad keys enter a different speed number if desired

Save (+) save the modiﬁed speed number

If your chosen speed number is already assigned to another entry, you are asked if you want to replace that entry.

Press To

S scroll to More

Select (+) select More if you want to create another

entry with the same

Name

Using Text Messages

Text messages are brief messages that appear on your phone display. A text message may include phone numbers or URLs. You must set up a text message inbox before you can send and receive these messages. Your inbox holds up to 10 messages.

Setting Up the Text Message Inbox

Learning More Tasks

Find the Feature

Press To

S scroll to the Service Center No. ﬁeld

Change (+) open the Service Center No. editor

M > Messages M > Text Msg Setup

keypad keys enter the phone number for the service

center that handles your outgoing messages

OK (+) store your service center number

S scroll to the Expire After ﬁeld

Change (+) open the Expire After editor

Press To

keypad keys enter the expiration period—the number

of days your network tries to send unreceived messages

OK (+) store the expiration period

S scroll to the Reply Type ﬁeld

Change (+) open the Reply Type editor

S scroll to the type of replies you want to send

Select (+) store the reply type

S scroll to the Cleanup Period ﬁeld

Change (+) open the Cleanup Period editor

S scroll to the period that messages stay in

your inbox

Select (+) store the cleanup period

If you select

Custom, continue. Otherwise,

the procedure is complete.

S change the entry in the active Custom ﬁeld

Learning More Tasks

* and # switch between the number and label ﬁelds

Done (-) store the custom cleanup period

Reading T ext Messages

Note: You must set up your inbox before reading text messages. See “Setting Up the Text Message Inbox” on page 29.

Find the Feature

Press To

S scroll to the message you want (! = unread

Read (+) open the message

M > Messages > Text Msgs

and urgent,

M = read, f = read and locked)

Dialing Numbers from Text Messages

Note: You must set up your inbox before opening text messages. See “Setting Up the Text Message Inbox” on page 29.

Find the Feature

Press To

S scroll to the message with the number M open the text message menu S scroll to Call Back

Select (+) dial the number stored with the message

M > Messages > Text Msgs

Learning More Tasks

Note: If the phone lists more than one number for the message,

S to scroll to a number and press Select (+) to dial.

press

Using V oicemail

You can listen to your voicemail messages by calling your network voicemail phone number.

Storing Y our Voicemail Number

Store your voicemail number in your phone to make it faster and easier to use voicemail.

Find the Feature

Press To

M > Messages M > VoiceMail Setup

keypad keys enter the phone number for your voicemail

OK (+) store the number

Listening to Voicemail Messages

Note: Store your voicemail number before using this procedure.

Find the

Learning More Tasks

Feature

Your phone calls the voicemail number you stored. Contact your service provider for information about your voicemail features.

M > Messages > VoiceMail

Locking and Unlocking Your Phone

You can lock your phone manually, or you can set your phone to lock automatically whenever you turn it off.

When you try to use a locked phone, it prompts you for your unlock code. A locked phone still rings or vibrates for incoming calls or messages.

Locking Your Phone Manually

Find the Feature

Press To

keypad keys enter your four-digit unlock code

OK (+) lock the phone

Press

M > Settings > Security > Phone Lock

> Lock Now

Setting Your Phone to Lock Automatically

Find the Feature

Press To

keypad keys enter your four-digit unlock code

OK (+) set the phone to lock automatically

Press

M > Settings > Security > Phone Lock

> Automatic Lock > On

Learning More Tasks

Unlocking Y our Phone

At the Enter Unlock Code prompt:

Press To

keypad keys enter your four-digit unlock code

OK (+) unlock the phone

Press

If You Forget a Code or Password

If you forget a security code (originally set to 000000), contact your service provider.

If you forget your phone’s unlock code (originally set to 1234), try the last four digits of your phone number. If that does not work, do the following when you see the

Press To

display the security code prompt

Enter Unlock Code prompt:

keypad keys enter your security code

OK (+) bypass the Unlock Code prompt

Learning More Tasks

Locking and Unlocking Your Keypad

Press To

M * lock or unlock your keypad

Note: Incoming calls and messages unlock the keypad.

Caller ID

The Calling line identiﬁcation (caller ID) feature lets you see who is calling before you answer.

• If the caller’s name is stored in your phonebook, the name is displayed.

• If the name is not in your phonebook, the caller’s phone number is displayed.

• If caller ID information is not available, your phone displays the message

Incoming Call.

Automatic Redial

You may be unable to complete a call if the wireless system is busy. When this happens, the system transmits a fast busy signal, and your phone displays the message reason for the failure.

WIth automatic redial, your phone repeats the call attempt over the next four minutes.

Call Failed along with the

Learning More Tasks

Press To

N or RETRY (+) activate automatic redial

When the call goes through, your phone rings or vibrates one time, displays

Redial Successful, and then connects the call.

Call Waiting

If you subscribe to call waiting, you may hear a tone while you are on a call. This tone indicates that you have received a second call.

To place the ﬁrst call on hold while you answer the second call:

Press To

N answer the new call N (analog mode)

SWITCH (+)

(digital mode)

To end the ﬁrst call and answer the second call:

Press To

O end the current call

Learning More Tasks

switch back to the ﬁrst call

Your phone rings to signal the new call. answer the new call

Unanswered Calls

When you cannot answer a call, your phone keeps a record of your unanswered calls and displays the

T (missed calls) icon and the

message Missed Calls (or Unknown if caller ID information is not available).

Press To

VIEW (+) view the unanswered calls list

S scroll through the list and select a call that you

want to return

N dial the number

Dialing Emergency Numbers

Your service provider programs one or more emergency phone numbers that you can dial even if your phone is locked or restricted.

Press To

any keypad key display the enter code or locked prompt keypad keys enter the emergency number (such as 911)

N dial the emergency number

Additional Dialing Features

Learning More Tasks

In addition to simply dialing numbers on your keypad, you can insert numbers or characters and dial calls in a variety of ways.

To insert numbers or characters:

Do This To Insert

Press 0 for two seconds and enter rest of

international access code for country from which you are calling

number

M and then

Press scroll to and select one of the following:

Insert Pause (to

•

insert a

•

Wait (to insert a w)

•

Insert 'n' (to insert

special character when making a calling card call:

• Pause tells your phone to wait

• Wait tells your phone to wait

• 'n' tells your phone to stop and

M > Attach digits to precede the number to call

Press

Learning More Tasks

Press

Add Digits

digits at the end of the number to call

until the call connects before it dials the next digit in a series

until the call connects, then prompt you before it sends the remaining digits

prompt you for a number before it continues dialing

To dial a call:

Do This To Dial

Press the two-digit phonebook index number of the entry

speed dial number

Do This To Dial

Press and hold the single-digit phonebook index number

one-touch dialing number

Press voice key and say the name (in

voice dial number

two seconds) Press M > Recent Calls

Received Calls or Dialed Calls

missed or recent call

> entry to call

Using In-Call Features

While you are on a call, you can perform the following tasks:

Do This To

Press M > Hold place a call on hold

M > Mute mute a call

Press

M > Spkrphone On activate the speakerphone

Press

(hands-free mode)

M > My Tel. Number View your phone number

Press

M > Send Tones Send digits as DTMF tones,

Press

for example for credit card dialing or password entry

Learning More Tasks

Phone Fundamentals

Phone Diagram

Power Key & Status Light

Turn the phone on and off, view call, service, and message status

Headset Jack

Connect an optional headset

Volume Keys

Adjust earpiece and ringer volume

Soft Keys

Perform functions

Phone Fundamentals

identiﬁed by display prompts

End Key

End phone calls

Speaker Key

Activates/ deactivates hands-free mode

Earpiece

Ultra-compact phone speaker

Voice Key

Record V oiceNotes, phonebook and datebook entries

Display

(see “Display Indicators” on page 17)

Menu Key

Enter the menu system

Send Key

Place and answer calls

Scroll Key

Scroll through menu features, move the cursor when entering text

Accessory Connector Port

Connect the battery charger and accessories

Speakerphone

For hands-free phone operation

Microphone

Display

The top section of the display shows phone status indicators. Text and number messages, keypad input, and menu options appear in the middle of the display. Text labels at the bottom of the display identify the current soft key and menu key functions.

Display Indicators

➋ In Use

Indicator

➊ Signal

Strength Indicator

➑ Digital/

Analog Signal Indicator

➌ Roam

Indicator

5 F

➐ Alert Indicator

➍ Message W aiting

Indicator

➎ Voice Message

Waiting Indicator

12:00

Clock

➏ Battery

Level Indicator

➊ Signal Strength Indicator Shows the strength of your

phone’s connection with the local wireless system.

Strong

54321j

No signal

You cannot make or receive calls when the no signal indicator is displayed.

Phone Fundamentals

➋ In Use Indicator Appears when a call is in progress. ➌ Roam Indicator Appears when your phone accesses a

wireless system outside your home network. When you leave your wireless service area, your phone roams or seeks another service area.

➍ Message Waiting Indicator Displayed when

your phone receives a text message.

➎ Voice Message Waiting Indicator Displayed

when your voicemail receives a message.

➏ Battery Level Indicator Shows the amount of charge left

in your battery. The more segments visible, the greater the charge.

High

Recharge your battery as soon as possible when you see the

Low Battery warning message.

EDCB

Empty

Phone Fundamentals

➐ Alert Indicator Indicates the current selected alert. The

default alert is a ringer.

Ringer on

Vibrate on

(add) Vibrate then ring

Ring then vibrate

Silent

Vibrate with all tones off

All Alerts off

➑ Digital ( )or Analog ( ) Signal Indicator

Indicates whether you are receiving a digital or analog signal.

Status Light

The status light provides information regarding your type of service, and incoming call or message status.

The status light changes color and ﬂashes or remains on to indicate different states:

Indication State

alternating red/green incoming call ﬂashing green in service, home-type system ﬂashing yellow roaming, non-home-type system ﬂashing red no service alternating red/service color

(green, yellow, or red)

Status

light

text message or voicemail message received

Phone Fundamentals

Volume Ke ys

Use the upper and lower volume keys to adjust your phone’s earpiece and ringer volume.

When Press To

During a call volume keys increase or decrease earpiece

Volume

keys

speaker volume

When you are not on a call

volume keys increase or decrease ringer

volume

Battery Use

Caution: To prevent injuries or burns, do not allow metal objects to contact or short-circuit the battery terminals.

Phone Fundamentals

Maximizing Battery Life

To ensure that you enjoy maximum battery life and use your battery to its fullest capacity:

• Always use Motorola approved batteries and battery chargers.

• Maintain the battery at or near room temperature when charging.

• New batteries or batteries that have been stored for long periods of time may not rapid charge properly. In these instances, the battery requires an overnight charge.

• When you do not intend to use a battery for a while, store it uncharged in a cool, dark, dry place, such as a refrigerator.

• To prolong the life of your batteries, do not expose them to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your car.

• Over extended periods of time, batteries gradually wear down and require longer charging times. This is normal. If you charge your battery regularly and notice a decrease in talk time or an increase in charging time, then it is probably time to purchase a new battery.

Disposing of Batteries

To dispose of batteries, check with your local recycling center for a battery recycler near you. Never dispose of batteries in a ﬁre.

Phone Fundamentals

When You’re Ready to Do More

Menu Map

This is the standard menu layout. Your service provider may have modiﬁed the menu structure or changed some feature names. And, you can change the menu structure, as well. Not all features may be available for all users.

• Recent Calls

• Received Calls (53)

• Dialed Calls (52)

• Notepad (53)

• Call Times (52)

• Phonebook (51)

• Datebook (47)

• Quick Dial (52)

• Radio (52)

• Messages (48)

• Info on Demand (48)

• Shortcuts (54)

• VoiceNotes (54)

• Browser (47)

• Settings

• Ring/Vibrate

When You’re Ready to Do More

• Alert (53)

• Detail (53)

• Settings (continued)

• Phone Status

• My Tel. No. (51)

• Phone: Line 1/2 (51)

• Battery Meter (51)

• Credit Info (51)

• Other Information (51)

• Connection

• IrDA Link (47)

• In Call Setup

• In Call Timer (48)

• Answer Options (47)

• Call Waiting (48)

• Security

• Phone Lock (54)

• Lock Keypad (53)

• Lock Application (53)

• Restrict Calls (54)

• New Passwords (54)

• Other

• Personalize (50)

• Initial Setup (49)

• Network (50)

• Car Settings (49)

• Headset (49)

Menu Feature Descriptions

ROWSER

ONNECTION

IrDA Link

ATEBOOK

IN C

Answer Options

Access Web pages and run Web-based

applications. The Browser delivers WAP (Wireless Application

Protocol) pages from your wireless service provider directly to your phone. These pages give you current information on selected topics.

You can connect your phone to a computer or fax machine to send and receive fax and data calls on the connected machine. You can connect your phone using a cable and PCMCIA card, a cable only, or an Infrared Data Association (IrDA) link.

Set up a wireless infrared connection. Your phone

must be within one meter of the linking device.

Schedule appointments in the datebook calendar.

You can display events for the week, a day, or details for a speciﬁc event. See “Datebook” on page 59.

ALL SETUP

Customize settings that provide information during a phone call, such as timers and call-answering options.

Turn call answering options on or off:

When You’re Ready to Do More

Multi-Key answer by pressing any key

Call Waiting

When another call arrives while you are already on a call, call waiting can play a tone to notify you of the new call.

In Call Timer

You can set the following options for your display:

Time displays the elapsed time for the

Off no in-call display for the timer

NFO ON DEMAND

from your service provider.

ESSAGES

messages. Your voicemail records voice messages from people

who call you when you are unavailable. Voicemail messages are stored on the network rather than on your phone. When you receive a voicemail message, your phone displays

VoiceMail &. See “Using Voicemail” on page 32.

Your phone can also receive text and information services messages which may include text, phone numbers, and

When You’re Ready to Do More

URLs.

Activate and deactivate call waiting.

Adjust call timer settings.

current call

Request and receive information

Listen to voicemail, send and receive text

New

• Text messages are brief messages that you can enter, send,

and receive (such as “Where are we meeting?”).

• Information services messages are broadcast or browser

messages that you can only receive (such as stock updates or other news).

When you receive a new message, your phone displays

Message X and gives an alert. You must set up your

message inboxes before you can use text or information services messages. See “Using Text Messages” on page 29.

THER

Car Settings

Adjust hands-free car kit settings.

When your phone is connected to a car kit or headset, it can automatically answer calls after two rings. You can route your calls directly to a connected car kit or headset.

Headset Initial Setup

Animation switches on and off smooth scrolling

Adjust headset settings.

Set several basic phone options:

within and between text ﬁelds (off conserves the battery)

Auto PIN Dial automatically dials your PIN Battery Save conserves power (if available) Auto Redial automatically redials calls that fail due

to network conditions

Backlight Display changes the backlight display, which

usually changes based on the amount of ambient light

New

When You’re Ready to Do More

DTMF switches DTMF tones to long or short

form

Language sets the language for phone menus Master Clear performs master reset and clears all

user-selectable options, resettable timer, recent call lists, and phonebook

Master Reset resets all options back to their original

factory settings except for the unlock and security codes

Scroll tells the cursor to stop or wrap around

when it reaches the top or bottom of a list in the display

Status Light turns the status light off (to conserve

battery power) and on

Time and Date set the phone’s time and date Zoom switches to three or four lines of display

Network

Your service provider registers your phone to a network. You may need to change the network registration to do things like connecting to a TTY device or using your phone as a wireless

When You’re Ready to Do More

modem.

Personalize

Banner

View and adjust your phone’s network settings.

Set several personal phone options:

changes the text displayed in the idle state

Greeting

changes the text displayed when you turn on your phone

Keys

changes the functions of the soft keys in the idle state (see “Customizing the Soft Key Functions” on page 66)

Main Menu

changes the order of the main menu (see “Customizing the Order of Menu Items” on page 65)

Quick Dial

HONE STATUS

Battery Meter Credit Info

Prepay users can view current credit

changes quick dial numbers

View a detailed battery charge meter.

information. If you use a prepay option, you can view the credit

available, its expiration date, and the date of the last deposit.

My Tel. No. Other Information

Change the way your phone number displays.

view speciﬁcations for your phone’s

features (if available).

Phone: Line 1/2

Change the active phone line (on dual line phones) to place or receive calls from either of the available numbers.

When You’re Ready to Do More

HONEBOOK

Open the phonebook list, where you can dial or

store numbers. To store names and phone numbers in your phonebook, see

“Storing an Entry in the Phonebook” on page 25.

You can dial phonebook entries by selecting them from the phonebook list. You can also perform several other tasks:

• check your phonebook’s capacity to see how many entries

• tell your phone to sort your phonebook list by speed dial

• use PIM (Personal Information Management) software to

UICK DIAL

numbers. Your wireless service provider may program one or

more quick dial numbers into your phone. These numbers usually include the customer service number, and you can dial them by selecting them from the quick dial list.

Note: Your service provider may use a different name for this feature.

ADIO

ECENT CALLS

Call Times

When You’re Ready to Do More

You can view ﬁve timers that track time spent on dialed calls, received calls, and all calls. See “Call Timers” on page 66.

Dialed Calls

you have used and how many more are available

number (the standard), name, or Voice Dial

synchronize your phone with a computer, so you can edit phonebook entries on your phone and on the computer

Dial pre-programmed customer service

Tune, store presets, and listen to AM/FM radio stations.

View call timers.

View a list of recently dialed calls.

Your phone keeps a list of phone numbers from calls you recently dialed (even if the calls did not connect). The list is

sorted from newest to oldest. Each entry tells you the person’s name and number (if available) and whether or not the call connected.

Notepad

Call or store the last number entered from the

keypad. You can use this notepad to view the last number you entered,

even if you did not call the number.

Received Calls

View a list of recently received calls.

Your phone keeps a list of the numbers from calls you recently received (even if you did not answer). The list is sorted from newest to oldest. Each entry tells you the person’s name and number (if available) and whether or not the call connected.

ING/VIBRATE

Alert

See “Ring/Vibrate” on page 62.

Select a type of ring or vibration alert for incoming calls

and messages.

Detail

Change details about the type of ring or vibration alert

you select.

ECURITY

Lock Application

Lock and unlock speciﬁc phone applications (such as phonebook and datebook) so that users must enter the unlock code to use them.

Lock Keypad

Lock and unlock your keypad. See “Locking

and Unlocking Your Phone” on page 33.

When You’re Ready to Do More

New Passwords

Change your unlock code (originally set to

1234) or your security code (originally set to 000000).

Phone Lock

Lock and unlock your phone. See “Locking and

Unlocking Your Phone” on page 33.

Restrict Calls

Restrict incoming and outgoing calls.

You can stop all outgoing or incoming calls, or you can restrict them to the numbers stored in your phonebook.

HORTCUTS

Create keypad or voice shortcuts to menu features.

See “Shortcuts” on page 64.

OICENOTES

Record messages and phone calls using your

voice key. See “VoiceNotes” on page 55. You can view, play back, lock, and delete VoiceNotes in your

VoiceNote list.

Conference Call

To talk to more than one person on a call, you can make a conference call. Call the ﬁrst person, call the second person, then link the two calls together.

Press To

keypad keys enter the ﬁrst person’s number

When You’re Ready to Do More

dial the call

keypad keys enter the next person’s number

Press To

dial the call Your phone displays

l next to the ﬁrst call (on hold).

and

Link (-) connect the two calls

end the entire call

W next to the active call

VoiceNotes

VoiceNotes allow you to record personal messages or phone calls. You can play them back at any time.

Recording a VoiceNote

There are no pre-recorded VoiceNotes on your phone when you receive it. To record a VoiceNote:

Find the Feature

Do This Result

Press the voice key and hold for one second.

M > VoiceNotes

A tone sounds in the earpiece and the phone displays the recording message.

When You’re Ready to Do More

Continue holding the voice key, and speak your voice message into the phone.

The phone records the message and displays a recording timer.

Do This Result

Release the voice key to stop recording.

The phone displays the VoiceNotes list number and the total recording time.

Viewing the VoiceNotes List

The VoiceNotes list shows all your VoiceNotes along with other important information and features.

Find the Feature

Scroll through list

Locked VoiceNote

To previous screen

New VoiceNote appears at the end of the list or by itself if no

When You’re Ready to Do More

VoiceNotes are stored. Select

M > VoiceNotes

---VoiceNotes---

4) 2:20pm 23-Mar

3) 4:05pm 22-Mar

EXIT M PLAY

T o V oiceNotes

sub-menu

New VoiceNote to view instructions

on how to record a new VoiceNote.

Time/Date Received

Plays the selected VoiceNote

Playing a VoiceNote

To play a recorded VoiceNote:

Find the Feature

Press To

M > VoiceNotes

S highlight VoiceNote for playback

PLAY (+) play a VoiceNote

Tip: You can play a VoiceNote while taking a call. It won’t be transmitted to the other party.

Playback Screen

While the VoiceNote is playing, the playback screen is displayed.

Indicates % played

Rewind

To previous screen

VoiceNote 3f

SAVE DELETEM

To VoiceNotes menu

VoiceNote number

Locked VoiceNote

Fast forward

Erases VoiceNote

When You’re Ready to Do More

VoiceNote Keys

While playing back a VoiceNote, use these keys to do the following:

Stop playback and go to VoiceNotes menu

Stop playback and return to VoiceNotes list

Stop playback and scroll up/ down to next VoiceNote

Rewind three seconds, resume playing

When You’re Ready to Do More

Press and hold to rewind to the beginning

GRAPHIC

FOR

PLACEMENT

ONLY

When playback is complete, press to restart

VoiceNote Unlocked: Stop

playback and display

VoiceNote ?

VoiceNote Locked: Stop

playback and unlock VoiceNote

Number keys alternately stop and start playback

Fast forward three seconds, resume playing

Press and hold to fast forward to end

Delete

Datebook

The datebook lets you schedule and organize appointments and keeps track of special events. It can display events for the week, a day, or details for a speciﬁc event.

Open the datebook to schedule or see events.

Find the Feature

M > Datebook

Datebook Views

When you open the datebook, your phone displays a calendar for the week.

Untimed

events

12 hour window

Return to previous screen

15 NOV-21 NOV S M T W T F S

EXIT M VIEW

Display menu

End of week

Day of week

Event

Go to speciﬁc day

When You’re Ready to Do More

Lines or ﬁlled in boxes under each day indicate that events have been scheduled.

Press To

* or # scroll left or right to past or future days

S scroll up or down

VIEW (+) to open a speciﬁc day

M to display the datebook sub-menu

Day View

Press View (+) to view the day’s events. You can store, edit, view, copy, and delete any event from the day view.

When You’re Ready to Do More

Untimed events

Down scroll arrow

Alarm Return to

previous screen

THU 19-NOV

••••Joe’s B-day 9:00+ Marie,mtg

BACK M VIEW

Display menu

Day of week

Event

Display event details

Event View

Press View (+) to open the detailed event view. You can edit, copy, and delete events from the event view. Event details include call alerts, times, days, and other event data.

Down scroll arrow

+THU 12:00 pm

vent date

and time

When You’re Ready to Do More

Alarm

Return to previous screen

9:00 Marie, new product meeting

BACK M EDIT

Display menu

Display event edit form

Storing a New Event

Find the Feature

Press To

SELECT (+) open the event entry form

keypad keys enter the event name

S move from one entry ﬁeld to the next

M > Datebook > New

Once you reach a ﬁeld, complete the event details. A title is required. Other ﬁelds include time, duration, date, repeating events, and alarms.

Event details

Press To

DONE (-) store the new event and return to the week

view

Conﬁguring Settings

You can adjust a wide variety of phone settings and conﬁgure the phone to suit your needs.

Ring/Vibrate

Your phone rings or vibrates when you have incoming calls or other events. You can customize the ring and apply it to all events or select different ring styles for speciﬁc events.

Selecting a Ring/Vibration for All Events

Find the Feature

Press To

M > Setting > Ring/Vibrate > Alert

S scroll to and select a ring or vibration

SELECT (+) select a type

The phone displays the

When You’re Ready to Do More

message.

Changed: Alert

Selecting a Ring/Vibration for Speciﬁc Events

When you select a ring/vibration type for a speciﬁc event, it overrides the ring set for all events.

Find the Feature

Press To

M > Settings > Ring/Vibrate

> alert type Detail

S scroll to the event that should have a special

alert

SELECT (+) select the event

The phone displays the

Alert menu.

S scroll to the alert you want

SELECT (+) select the alert

The phone displays the

alert

message.

Canceling the Ring or Vibrate Alert

Changed:

event

While the phone is ringing:

Press To

O or IGNORE (-)

cancel the ring or vibrate alert

Depending on your phone conﬁguration and the type of subscription you have with your service provider, the call may be forwarded or the calling party may receive a busy signal.

When You’re Ready to Do More

Shortcuts

You can create shortcuts to mark frequently used menu items. There are no default shortcuts.

Setting Up Shortcuts

You can set up a shortcut from any highlighted item on the phone, except for items in a context-sensitive menu or items that are grouped together in a form.

Available Shortcuts

Type Example

data object Phonebook entry or text message list alarm setting options highlighted item meter editors time or date editor form blank form, such as new Phonebook

value time setting for the backlight

Voicemail menu item Battery Meter

entry

browser service web page

When You’re Ready to Do More

SIM Toolkit applications

SIM Toolkit initial screen

Creating Shortcuts

Find the Feature

Do This Result

Press and hold

M > the item to which you want to

assign a shortcut

The phone displays:

Assign Shortcut “Item” to key no: #?

where Item is the name of the item you selected, and # is the number of the next available shortcut.

OK (+). The phone conﬁrms the new shortcut.

Press

Customizing the Order of Menu Items

You can customize the order of the items in your phone’s main menu, depending upon your usage.

Find the Feature

Press To

SELECT (+) open the main menu

M > Settings > Other Settings

> Personalize > Main Menu

When You’re Ready to Do More

S scroll to the menu item you want to want to

move

GRAB (+) grab the menu item you want to move

S move the item up or down the menu

INSERT (+) insert the item in the new location

Customizing the Soft Key Functions

When your phone is idle, you can relabel the soft keys (- and

+) to access any of three main menu items: Messages, Recent

Calls, or Phonebook.

Find the Feature

Press To

SELECT (+) display the key editor

S scroll to

SELECT (+) open the key editor

M > Settings > Other Settings

> Personalize > Keys

Left, Right, or Smart

S scroll to the new key function

SELECT (+) conﬁrm the new function

The soft key label will reﬂect the new selection whenever the phone is idle.

Call Timers

Network connection time is the elapsed time, in one-minute intervals, from the moment you connect to your service provider’s network to the moment you end the call by pressing

When You’re Ready to Do More

includes busy signals and ringing.

O. The time

You can view the approximate network connection time elapsed during the following calls:

Timer Records time spent on

Last Call your last call Dialed Calls dialed calls since last reset Received Calls received calls since last reset All Calls all calls since last reset Lifetime all calls

Note: The amount of network connection time you track on your resettable timer may not equal the amount of time for which you are billed by your wireless service provider. For billing information, please contact your service provider directly.

When You’re Ready to Do More

Find the Feature

M > Recent Calls > Call Times

To view the timer:

Press To

S scroll to the timer

Select (+) display the timer

To reset the timer:

Press To

Reset (+) reset the time (if available) Yes (+) conﬁrm the reset

Troubleshooting

Question Answer

I pressed the power button, but nothing happened. What’s wrong with my phone?

Be sure to press and hold the power key until the display appears and you hear an audible alert. If nothing still happens, check that you have installed a battery and that the battery is charged. For more information about batteries and charging see the sections on batteries starting with “Installing and Removing Batteries” on page xx.

The display says, “Locked.” How do I unlock my phone?

Troubleshooting

Enter the last four digits of your wireless number. If that doesn’t work, use the factory preset unlock code: 1234. If all else fails, call your service provider (the company that sends you your monthly wireless bill). (See “Locking/Unlocking Your Phone” on page xx for more information on security features.)

Question Answer

My battery didn’t last as long as I expected. What can I do to extend battery life?

Your battery’s “talk time” and “standby time” are relative measurements of the battery’s capacity. The more you talk on the phone, the less standby time you have, and vice versa.

To get the most from your battery, allow it to charge fully. To charge the battery to 100% of its capacity, leave it in the charger for an extra hour after the charger’s light turns green.

You can also turn off the status light to extend battery life.

Use only Motorola approved batteries that are compatible with your phone.

Exposing your battery to extreme temperatures—below -10°C (14°F) or above 45°C (113°F)—can shorten battery life. Batteries are especially sensitive to high temperatures. As a good rule, always take your phone with you when you leave your car.

Troubleshooting

Question Answer

I tried to place a call and received a fast busy signal.

The wireless system did not process your call. For example, the wireless system may be overloaded with call attempts. To

redial, press attempt, or press

again later. (See “Redialing a Number” on page xx.)

O before ending your call

N and try the call

I tried to place a call and received an alternating high/low tone.

Troubleshooting

I tried to listen to my voicemail (or use a paging service, a calling card, etc.) but nothing happened.

Your call did not reach the wireless system. You may have dialed the number too soon after turning the phone on. Wait until the phone display

Ready before placing a call.

says An alternating tone may also indicate

that your phone’s signal is blocked. Make sure you are clear of any obstructions such as bridges, parking garages, or tall buildings.

You may have turned off the scratchpad tones. Place your call, enter the access numbers when prompted by the

recording, then press problem in the future, follow the directions “Turning Scratchpad Tones On and Off” on page xx to turn the Scratchpad tones on.

N. To avoid this

Question Answer

I tried to place a calling card call using the Phonebook, but it didn’t work.

You may have turned off your Scratchpad tones. Follow the directions in “Turning Scratchpad Tones On and Off” on page 107 to turn the Scratchpad tones on.

Check that you stored your calling card information in the correct order, and make sure the groups of numbers are separated by pauses. The easiest way to correct the sequence may be to start from scratch. Enter your calling card information again, and store it in the same memory location as your previous attempt.

Also keep in mind that when using your calling card, you must enter the number you are calling with the area code, but without the initial “1.” Check with your long distance carrier for details on using your calling card.

Troubleshooting

Question Answer

I plugged the data cable into my phone but my phone did not beep. How do I know if the data cable is ready to go?

Troubleshooting

The beep indicates that you are setup correctly. If you did not hear the beep, the ﬁrst thing to check is that your phone is data capable. To do so, see “Using Data Features” on page xx.

Next, make sure that both ends of the data cable are connected—the smaller end to your phone and larger to your computer. Also, check the model number of the cable to be sure you have the right one. Look for SYN7464 printed on the cable.

If all of the above checks out, your computer may have deactivated the port to save power. Try opening an application that uses the port, like a fax or dial-up application, and your computer will automatically activate the port.

My phone was stolen. What should I report and to whom?

Report a stolen phone to the police and to your service provider—the company that sends you your monthly wireless service bills.

Question Answer

My phone beeped when I attached the data cable but my fax and data applications don’t work at all. What’s wrong?

You must be in an area with digital coverage. Check your phone’s display for the digital icon digital coverage area.

Some wireless networks may not support data or fax transmission. If you see the digital indicator, but you are roaming on an unfamiliar network, this may be the case.

Also, remember that data and fax transmission usually requires a subscription. Call your service provider for more information.

F to be sure you’re in a

Troubleshooting

When sending data with the data cable, why does the computer show a connection rate of 19200 Kbps?

19200 is the rate of the connection between your computer and the phone. The rate of the connection between your phone and the network is displayed on your phone, and will be either 14400 or

9600.

Question Answer

I can’t end my data call by closing the application on my computer. What can I do?

If necessary, try pressing phone. Also try disconnecting the cable or turning off the phone. If possible, always close the connection through your computer. These alternative methods may disrupt the application on your computer.

N on the

I launched the Browser but the display says: Service Not Available. What is wrong?

I launched the Browser but the

Troubleshooting

display says: Data Server Unavailable. What is wrong?

You are in an area without service. If you have wireless service, look in the display for the Digital indicator. If you don’t see it, you may have only Analog service or no service at all. If you do see the Digital indicator, you may be connected to digital network that does not support Internet access.

Try again in a few minutes. The servers may be temporarily busy.

The U.S. Food and Drug Administration's Center f or Devices and Radiological Health Consumer Update on Mobile Phones

FDA has been receiving inquiries about the safety of mobile phones, including cellular phones and PCS phones. The following summarizes what is known—and what remains unknown— about whether these products can pose a hazard to health, and what can be done to minimize any potential risk. This information may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio frequency energy (i.e., radio frequency radiation) in the microwave range while being used. They also emit very low levels of radio frequency energy (RF), considered non-signiﬁcant, when in the stand-by mode. It is well known that high levels of RF can produce biological damage through heating effects (this is how your microwave oven is able to cook food). However, it is not known whether, to what extent, or through what mechanism, lower levels of RF might cause adverse health effects as well. Although some research has been done to address these questions, no clear picture of the biological effects of this type of radiation has emerged to date. Thus, the available science does not allow us to conclude that mobile phones are absolutely safe, or that they are unsafe. However, the available scientiﬁc evidence does not demonstrate any adverse health effects associated with the use of mobile phones.

FDA Update

What kinds of phones are in question?

Questions have been raised about hand-held mobile phones, the kind that have a built-in antenna that is positioned close to the user's head during normal telephone conversation. These types of mobile phones are of concern because of the short distance between the phone's antenna—the primary source of the RF— and the person's head. The exposure to RF from mobile phones in which the antenna is located at greater distances from the user (on the outside of a car, for example) is drastically lower than that from hand-held phones, because a person's RF exposure decreases rapidly with distance from the source. The safety of so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house and which operate at far lower power levels and frequencies, has not been questioned.

How much evidence is there that hand-held mobile phones might be harmful?

FDA Update

Brieﬂy, there is not enough evidence to know for sure, either way; however, research efforts are on-going. The existing scientiﬁc evidence is conﬂicting and many of the studies that have been done to date have suffered from ﬂaws in their research methods. Animal experiments investigating the effects of RF exposures characteristic of mobile phones have yielded conﬂicting results. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. In one study, mice genetically altered to be predisposed to developing one type of cancer developed more than twice as many such cancers when they were exposed to RF energy compared to

controls. There is much uncertainty among scientists about whether results obtained from animal studies apply to the use of mobile phones. First, it is uncertain how to apply the results obtained in rats and mice to humans. Second, many of the studies that showed increased tumor development used animals that had already been treated with cancer-causing chemicals, and other studies exposed the animals to the RF virtually continuously—up to 22 hours per day.

For the past ﬁve years in the United States, the mobile phone industry has supported research into the safety of mobile phones. This research has resulted in two ﬁndings in particular that merit additional study:

1. In a hospital-based, case-control study, researchers looked for

an association between mobile phone use and either glioma (a type of brain cancer) or acoustic neuroma (a benign tumor of the nerve sheath). No statistically signiﬁcant association was found between mobile phone use and acoustic neuroma. There was also no association between mobile phone use and gliomas when all types of types of gliomas were considered together. It should be noted that the average length of mobile phone exposure in this study was less than three years.

FDA Update

When 20 types of glioma were considered separately, however, an association was found between mobile phone use and one rare type of glioma, neuroepithelliomatous tumors. It is possible with multiple comparisons of the same sample that this association occurred by chance. Moreover, the risk did

not increase with how often the mobile phone was used, or the length of the calls. In fact, the risk actually decreased with cumulative hours of mobile phone use. Most cancer causing agents increase risk with increased exposure. An ongoing study of brain cancers by the National Cancer Institute is expected to bear on the accuracy and repeatability of these

results.

2. Researchers conducted a large battery of laboratory tests to

assess the effects of exposure to mobile phone RF on genetic material. These included tests for several kinds of abnormalities, including mutations, chromosomal aberrations, DNA strand breaks, and structural changes in the genetic material of blood cells called lymphocytes. None of the tests showed any effect of the RF except for the micronucleus assay, which detects structural effects on the genetic material. The cells in this assay showed changes after

FDA Update

exposure to simulated cell phone radiation, but only after 24 hours of exposure. It is possible that exposing the test cells to radiation for this long resulted in heating. Since this assay is known to be sensitive to heating, heat alone could have caused the abnormalities to occur. The data already in the literature on the response of the micronucleus assay to RF are conﬂicting. Thus, follow-up research is necessary.

FDA is currently working with government, industry, and academic groups to ensure the proper follow-up to these industryfunded research ﬁndings. Collaboration with the Cellular Telecommunications Industry Association (CTIA) in particular is

expected to lead to FDA providing research recommendations and scientiﬁc oversight of new CTIA-funded research based on such recommendations.

Two other studies of interest have been reported recently in the literature:

1. Two groups of 18 people were exposed to simulated mobile

phone signals under laboratory conditions while they performed cognitive function tests. There were no changes in the subjects' ability to recall words, numbers, or pictures, or in their spatial memory, but they were able to make choices more quickly in one visual test when they were exposed to simulated mobile phone signals. This was the only change noted among more than 20 variables compared.

2. In a study of 209 brain tumor cases and 425 matched

controls, there was no increased risk of brain tumors associated with mobile phone use. When tumors did exist in certain locations, however, they were more likely to be on the side of the head where the mobile phone was used.

Because this occurred in only a small number of cases, the increased likelihood was too small to be statistically signiﬁcant.

FDA Update

In summary, we do not have enough information at this point to assure the public that there are, or are not, any low incident health problems associated with use of mobile phones. FDA continues to work with all parties, including other federal agencies and industry, to assure that research is undertaken to

provide the necessary answers to the outstanding questions about the safety of mobile phones.

What is known about cases of human cancer that have been reported in users of hand-held mobile phones?

Some people who have used mobile phones have been diagnosed with brain cancer. But it is important to understand that this type of cancer also occurs among people who have not used mobile phones. In fact, brain cancer occurs in the U.S. population at a rate of about 6 new cases per 100,000 people each year. At that rate, assuming 80 million users of mobile phones (a number increasing at a rate of about 1 million per month), about 4800 cases of brain cancer would be expected each year among those 80 million people, whether or not they used their phones. Thus it is not possible to tell whether any individual's cancer arose because of the phone, or whether it would have happened anyway. A key question is whether the risk of getting a particular form of cancer

FDA Update

is greater among people who use mobile phones than among the rest of the population. One way to answer that question is to compare the usage of mobile phones among people with brain cancer with the use of mobile phones among appropriately matched people without brain cancer. This is called a case-control study. The current case-control study of brain cancers by the National Cancer Institute, as well as the follow-up research to be sponsored by industry, will begin to generate this type of information.

What is FDA's role concerning the safety of mobile phones?

Under the law, FDA does not review the safety of radiation-emitting consumer products such as mobile phones before marketing, as it does with new drugs or medical devices. However, the agency has authority to take action if mobile phones are shown to emit radiation at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of mobile phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.

Although the existing scientiﬁc data do not justify FDA regulatory actions at this time, FDA has urged the mobile phone industry to take a number of steps to assure public safety. The agency has recommended that the industry:

• support needed research into possible biological effects of RF of the type emitted by mobile phones

• design mobile phones in a way that minimizes any RF exposure to the user that is not necessary for device function

• cooperate in providing mobile phone users with the best possible information on what is known about possible effects of mobile phone use on human health

FDA Update

At the same time, FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of mobile phone safety to ensure a coordinated effort at the federal level. These agencies are:

• National Institute for Occupational Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

• Occupational Health and Safety Administration

• National Telecommunications and Information Administration

The National Institutes of Health also participates in this group.

In the absence of conclusive information about any possible risk, what can concerned individuals do?

If there is a risk from these products—and at this point we do not know that there is—it is probably very small. But if people are concerned about avoiding even potential risks, there are simple steps they can take to do so. For example, time is a key factor in how much exposure a person receives. Those persons who spend

FDA Update

long periods of time on their hand-held mobile phones could consider holding lengthy conversations on conventional phones and reserving the hand-held models for shorter conversations or for situations when other types of phones are not available.

People who must conduct extended conversations in their cars every day could switch to a type of mobile phone that places more distance between their bodies and the source of the RF, since the exposure level drops off dramatically with distance. For example, they could switch to:

• a mobile phone in which the antenna is located outside the vehicle

• a hand-held phone with a built-in antenna connected to a different antenna mounted on the outside of the car or built into a separate package

• a headset with a remote antenna to a mobile phone carried at the waist

Again, the scientiﬁc data do not demonstrate that mobile phones are harmful. But if people are concerned about the radio frequency energy from these products, taking the simple precautions outlined above can reduce any possible risk.

Where can I ﬁnd additional information?

For additional information, see the following websites: Federal Communications Commission (FCC) RF Safety

Program (select “Information on Human Exposure to RF Fields from Cellular and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

World Health Organization (WHO) International Commission on Non-Ionizing Radiation Protection (select Qs & As):

http://www.who.int/emf

FDA Update

United Kingdom, National Radiological Protection Board:

http://www.nrpb.org.uk

Cellular Telecommunications Industry Association (CTIA):

http://www.wow-com.com

U.S. Food and Drug Administration (FDA) Center for Devices and Radiological Health:

http://www.fda.gov/cdrh/consumer/

1. Muscat et al. Epidemiological Study of Cellular Telephone Use and Malignant Brain Tumors. In: State of the Science Symposium;1999 June 20; Long Beach, California.

2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other laboratory assays. In: Annual Meeting of the Environmental Mutagen Society; March 29, 1999, Washington, D.C.; and personal communication, unpublished results.

3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey, A. Effect of a 915-MHz simulated mobile phone signal on cognitive function in man. Int. J. Radiat. Biol., April 8, 1999.

4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular telephones and the risk for brain tumors: a case-control study. Int. J. Oncol., 15: 113-116, 1999.

FDA020400

FDA Update

Index

accessories 10 alert

canceling 63 event alert 63 setting 62

alert indicator

deﬁned 42–43

illustration 41 animation 49 auto PIN dial 49 automatic redial

activating 49

using 35

backlight display feature 49 banner feature 50 battery

charging 12

conserving power 49, 50

disposal 45

installing 11–12

maximizing life 44–45, 69 battery level indicator

deﬁned 42

illustration 41

battery meter 51 battery save feature 49 block cursor 21 browser 47 busy signal 70

call

adding digits to number 38 alert, canceling 63 alert, setting 62 answering 14 answering options 47 attaching digits to precede

phone number 38 calling card 38 dialed calls list 39, 52 emergency number 37 ending 13 event alert, setting 63 hold, placing call on 39 in call timer 48 international access code 38 muting 39 placing 13 received calls list 39, 53

Index

call (continued)

receiving 14 redialing last number 14 restricting 54 unanswered call 36 voice dial 39

call timers

deﬁned 66–67 resetting 67 viewing 52, 67

call waiting

activating/deactivating 48 using 36

caller ID

features 35

calling card calls

Index

dialing 38 storing information 71

car settings 49 codes. See passwords conference call 54–55 connecting to external device

47 credit information 51 customer service 52

data calls 47

date, setting 50 datebook

adding an event 61–62 calendar 59–60 day view 60 deﬁned 59

event view 61 dialed calls list 39, 40, 52 display

greeting 51

idle text 50

zoom 50 DTMF tones

setting 50

using 39

earpiece

illustration 40

volume, adjusting 44 emergency number 37 end key 40

menu functions 15 ending a call 13

Enter Unlock Code message

fax calls 47 ﬁxed dial

storing entry 26–29

greeting feature 51

hands-free car kit settings 49 hands-free mode 39 headset

adjusting settings 49 hold, placing call on 39 holster 10

I-beam cursor 21 in call timer 48 in use indicator

deﬁned 42

illustration 41

Incoming Call message 35

indicators

alert 41, 42–43

battery level 41, 42

in use 41, 42

message waiting 41, 42

indicators (continued)

roam 41, 42 signal 41, 43 signal strength 41

voice message waiting 41, 42 info on demand 48 international access code 38 IrDA link 47 iTAP text entry 24–25

key

end 15, 40

left soft key 15, 66

menu 15

power 40

right soft key 15, 66

scroll 15, 40

send 40

soft 40

speaker 40

voice 27–28, 40, 55–56

language 50 left soft key

customizing 66

menu functions 15

Index

lock

keypad 34 phone 33–34

lock application feature 53

making a call 13 master clear 50 master reset 50 menu

customizing 65 diagram 46 entering text 22–25 features 47–54 language, setting 50 locking applications 53

Index

navigating 15–18 rearranging features 65 scroll feature, setting 50 shortcuts 64–65

using features 19–25 menu key 15 message

dialing number from 31

inbox setup 29–30

information services 48

reading 31

text 29–31, 48

voicemail 32, 48

message waiting indicator

deﬁned 42 illustration 41

Missed Calls message 37

muting a call 39 my telephone number 39, 51

network settings 50 notepad 53

one-touch dialing

using 39

passwords

changing 54 if you forget a password 34

phone

accessories 10 active phone line 51 alert, canceling 63 connecting to an external

device 47 date, setting 50 feature speciﬁcations 51

phone (continued)

keypad, locking/unlocking

34 language, setting 50 locking 33–34 muting a call 39 network settings 50 one-touch dialing 39 passwords 34, 54 security code 34 speed dial, using 38 time, setting 50 turning on/off 12 unlock code 34 unlocking 13, 33–34 voice dial 39

phone number

adding digits 38 attaching preceding digits 38 viewing your own 14, 39

phonebook

features 51–52 ﬁelds 26 number type icon 26 one-touch dialing 39 speed dial, using 38 speed number 26, 28 storing an entry 25–29

phonebook (continued)

Voice Name entry 27–28 Voice Name icon 26

PIN code

dialing automatically 49 placing a call 13 power key 12, 40

quick dial

setting number 51

using 52

radio 52 received calls list 39, 53 receiving a call 14 redial

automatic redial 35

last number 14 restrict calls 54 right soft key

customizing 66

menu functions 15 ring/vibrate alert

canceling 63

event alert 63

setting 62

Index

ringer

setting 62 volume, adjusting 44

roam indicator

deﬁned 42 illustration 41

scratchpad tones 70, 71 scroll feature 50 scroll key 15, 40 security code 34 send key 40 shortcuts 64–65 signal indicator

deﬁned 43

Index

illustration 41

signal strength indicator

deﬁned 41 illustration 41

SIM PIN code

dialing automatically 49 soft key 40 soft keys 15, 66 speaker key 40 speakerphone 39 speed dial 38

speed number

deﬁned 26 selecting 28

status light 40, 43

activating/deactivating 50

text

block cursor 21 character chart 23 entering from keypad 22–25 I-beam cursor 21

iTAP text entry 24–25 text message 29–31, 48 time, setting 50 timers

deﬁned 66–67

resetting 67

viewing 52, 67 tone, alternating high/low 70

Unknown message 37

unlock

keypad 34

phone 33–34 unlock code 34 unlocking phone 13

voice dial 39 voice key 40

recording Voice Name 27–28 recording VoiceNote 55–56 voice dial 39

voice message waiting indicator

deﬁned 42 illustration 41

Voice Name

phonebook icon 26

recording 27–28 voicemail 32, 48, 70 VoiceNotes

key controls 58

playback screen 57

playing 57–58

recording 55–56

viewing VoiceNotes list 56 volume

earpiece 44

ringer 44 volume keys 44

Index

zoom feature 50

Patent Information

Manufactured under one or more of the following U.S. patents:

Patent Information

4291475 4302845 4312074 4365221 4369516 4369520 4369522 4374370 4378603 4390963 4398265 4400584 4400585 4434461 4455534 4486624 4491972 4523155 4546329 4574243 4581602 4581749 4585957 4593155 4594657 4602218 4605987 4616314 4617520

4628529 4629829 4633141 4636593 4636741 4648125 4649543 4654655 4680787 4704588 4711361 4715063 4717884 4730195 4731813 4736277 4737976 4741018 4742562 4761621 4764737 4775998 4791527 4794489 4797929 4797947 4798975 4802236 4803726

4809356 4811377 4811404 4817157 4827507 4829543 4831647 4843621 4845772 4851966 4852090 4860336 4860341 4868576 4870686 4872196 4873683 4876552 4876656 4876740 4879533 4885553 4887050 4890199 4896124 4896361 4897873 4903326 4903327

4904549 4904992 4905288 4905301 4912602 4916262 4918431 4918732 4922178 4941203 4942570 4945570 4956854 4959851 4963812 4964121 4970475 4972355 4972432 4972455 4975808 4977589 4977616 4979207 4984219 4984290 4989230 4992753 4996529

5008925 5010309 5010570 5014294 5014346 5017856 5018188 5020076 5020091 5020092 5020093 5023580 5023866 5023911 5025387 5027388 5028083 5028859 5029233 5036532 5038253 5040127 5042071 5045824 5053924 5055800 5055802 5055803 5057762

5058136 5059885 5060264 5063340 5065408 5067139 5070310 5077757 5077790 5081674 5083304 5087004 5093632 5095503 5107487 5109400 5111162 5113400 5113436 5117073 5117441 5117449 5117450 5121047 5121288 5121412 5122480 5122722 5124889

5127040 5127042 5127100 5128834 5133010 5134717 5140286 5140635 5142551 5142696 5144533 5146620 5148471 5148473 5150075 5150359 5150384 5151643 5152006 5152007 5153590 5157693 5160898 5162144 5163159 5164652 5166596 5166642 5168522

5170173 5170485 5170492 5175729 5175759 5175874 5182749 5185566 5185790 5187640 5187809 5192924 5193223 5195106 5195108 5198887 5200655 5201069 5203009 5203012 5203013 5203021 5204977 5205751 5210793 5211581 5212815 5212826 5214675 5214774 5216389 5220290 5220936

5222078 5222104 5222251 5230007 5230093 5233506 5233633 5235492 5237257 5237570 5239127 5241545 5241548 5241592 5241688 5242767 5243355 5247544 5247565 5249302 5251331 5255292 5257414 5259005 5260170 5260988 5261119 5262710 5263052 5263055 5265271 5267230 5276588

5276707 5276913 5276915 5278832 5278994 5280630 5280637 5280644 5285443 5287013 5287553 5287555 5287556 5289505 5297142 5299232 5301365 5308716 5321705 5321737 5321847 5323421 5325405 5325429 5327578 5327642 5331123 5333153 5336984 5338909 5343213 5349588 5351245

5359696 5361400 5363071 5365549 5366826 5367538 5367558 5371791 5373101 5375143 5375258 5379324 5381114 5384825 5392000 5392023 5392331 5396654 5401927 5402447 5402448 5404580 5404582 5406146 5406562 5408693 5410275 5410741 5414711 5420759 5424689 5428362 5428820

5428836 5430416 5432017 5434947 5436802 5438684 5442680 5444764 5446763 5446766 5448763 5448770 5448771 5453997 5457744 5459640 5459774 5461643 5463351 5463406 5463628 5463646 5463674 5463688 5463694 5465409 5465412 5469177 5471671 5475752 5477192 5485506 5485513

5486843 5487184 5488649 5490177 5491739 5493198 5493700 5493714 5495206 5495208 5497126 5497382 5497383 5499273 5499394 5499397 5502437 5504494 5504812 5506490 5508709 5509048 5510693 5511235 5513078 5513996 5519303 5519346 5519506 5519777 5524276 5526398 5528666

5530399 5530922 5533119 5535258 5535434 5539360 5542016 5542103 5542106 5542116 5544250 5546275 5546380 5551078 5551627 5553137 5553376 5554996 5555550 5557743 5559471 5559522 5559806 5561436 5561437 5561852 5565881 5566224 5568548 5570453 5572223 5572224 5574976

Patent Information

5577267 5577268 5583520 5584054 5586146 5588041 5589796 5590177 5594778 5594951 5598129 5598431 5600341 5604050 5604468 5604787 5606332 5606560 5606730 5613229 5613863 5615233 5615259 5615260 5621763 5621766 5625316 5625683 5628001 5628057 5628089 5629979 5630159

5630210 5630213 5630215 5631538 5633484 5633786 5634202 5640690 5642368 5646576 5649306 5649309 5656914 5656917 5657418 5659601 5660945 5661433 5664973 5666429 5668871 5670912 5673001 5673003 5673287 5674326 5675591 5675702 5678201 5678221 5678227 5680063 5684384

5691947 5692046 5692101 5696497 5696821 5699070 5699389 5699408 5701130 5701244 5701589 5703470 5703539 5703909 5706019 5706313 5708445 5710862 5710987 5711001 5715520 5715524 5717307 5722052 5724004 5726983 5729221 5732350 5737327 5737685 5738954 5739792 5740525

5742894 5745116 5745566 5745848 5747970 5748727 5754141 5754455 5754583 5754645 5754956 5758271 5760714 5761300 5761610 5764100 5764111 5764730 5764743 5766794 5771182 5771471 5777521 5777856 5784368 5784419 5784585 5787128 5787577 5793315 5793866 5796822 5797101

5798716 5799011 5799256 5801513 5801567 5802111 5805992 5807012 5808585 5808586 5809020 5809419 5809421 5809430 5809433 5809544 5812093 5812542 5812590 5814798 5815507 5815570 5815804 5815805 5815807 5815820 5821820 5822726 5826224 5831826 5832080 5832388 5835006

5835535 5835785 5838202 5841851 5842122 5844943 5846094 5848072 5848152 5848356 5848718 5850440 5854549 5854785 5854972 5856763 5856766 5857148 5857192 5859522 5859567 5859890 5861853 5862460 5862493 5864799 5865487 5867063 5867127 5867140 5867510 5870670 5872744

5877633 5878075 5878209 5878336 5878353 5880637 5880646 5881377 5889737 5889768 5889859 5892410 5893036 5894597 5896054 5896261 5898933 5900829 5901347 5901357 5903825 5903852 5905956 5907418 5907615 5909102 5910944 5912648 5920549 5920550 5923007 5924044 5925835

5925942 5926119 5926503 5926751 5930268 5930288 5930299 5933330 5936516 5936972 5939939 5940452 5940746 5943027 5945852 5945964 5946395 5949020 5950131 5950139 5953413 5954817 5955700 5955999 5956626 5963848 5963876 5964858 5966101 5966667 5966671 5969545 5974042

5977916 5980268 5982881 5983082 5987012 5988577 5995050 5996178 5999115 5999821 5999832 6002922 6002937 6005498 6006104 6008636 6009168 6009309 6009325 6009336 6009552 6011699 6011784 6011959 6011961 6012634 6014376 6014552 6016312 6016422 6018584 6018651 6018671

6021332 D284759 D285439 D288432 D288683 D289156 D292578 D292920 D295627 D295973 D295975 D296187 D297734 D297735 D297736 D299136 D299137 D299232 D300742 D300827 D301473 D301476 D301883 D302015 D303656 D304189 D305427 D305717 D306015 D306163 D306293 D306299 D306441

D306583 D306594 D307271 D309301 D309451 D314173 D315330 D315346 D315543 D315559 D315565 D315907 D316417 D316859 D320780 D322783 D324024 D324388 D325028 D325029 D325032 D325583 D325915 D327061 D327062 D328302 D332261 D332785 D334746 D337332 D338012 D338887 D339127

D339335 D339336 D339337 D339564 D339578 D339581 D339582 D340709 D340710 D340711 D340906 D341589 D342248 D342663 D342729 D342730 D342741 D343173 D343615 D343616 D343834 D343835 D343836 D344087 D344271 D344444 D344511 D344512 D344945 D345977 D346785 D346786 D346798

D348071 D348250 D348427 D348470 D348665 D348666 D348668 D348674 D348880 D349273 D349701 D350113 D350348 D350349 D350350 D351375 D351840 D352497 D352503 D352946 D353131 D353361 D353587 D353588 D353591 D354055 D354062 D355181 D355895 D356084 D356309 D357224 D357249

D357457 D357680 D357681 D358148 D359052 D359734 D359735 D359959 D360398 D360632 D361070 D361763 D362840 D362852 D365094 D365817 D366872 D367640 D368479 D368696 D369162 D369359 D369797 D370016 D370463 D370672 D372237 D372481 D372703 D372896 D372919 D373585 D373764

Patent Information

D374013 D374014 D374227 D374424 D374872 D375732 D375733 D375734 D375932 D375935 D375952 D376127 D377792 D377934 D378366 D378911 D379558 D379624 D379981 D379982 D380468

Other patents pending.

Patent Information

D380751 D381021 D381664 D382537 D382538 D382872 D383115 D383748 D383749 D383759 D384080 D384662 D384951 D384952 D385271 D385283 D385555 D385873 D385874 D385875 D385877

D385888 D386175 D386494 D386757 D387054 D387055 D387199 D387346 D388078 D388079 D388080 D388081 D388082 D388424 D388429 D388430 D388775 D388783 D388793 D389157 D389476

D389478 D389488 D389641 D390221 D390222 D390509 D391567 D391955 D391966 D393470 D394256 D394423 D394425 D394433 D394438 D394439 D395301 D395302 D395431 D395642 D395875

D396472 D397337 D397689 D397694 D398926 D400161 D400165 D400204 D400209 D400496 D400526 D400527 D400874 D401554 D401929 D403265 D404397 D405080 D405782 D405801 D406098

D406191 D406586 D406695 D406812 D407063 D407685 D407708 D408401 D408402 D408418 D408783 D408815 D409186 D410459 D410460 D410929 D411165 D411196 D411202 D411204 D411507

D411535 D411843 D411844 D412000 D412487 D412709 D413893 D413898 D414159 D415122 D415499 D416226 D417224 D417449 D419155 D419290 D419565

PAT022500

Motorola T56AA1 Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
