SOUNDBOOST SPEAKER
Attach your Moto Mods™
Align the camera lens on the back of your phone
with the speaker, and then align the sides and
bottom of the phone with the speaker until they
snap together.
Note: Make sure the connectors are clean and dry.
Also, remove your phone case if you use one.
Moto Mods
Connectors
Caution: Before using your device, please read
the safety, regulatory, and legal information at
the back of this guide.
Compatibility Requirements: Moto Z Phone with
Moto Mods Platform 1.0 or later
Quick setup
When you attach the speaker, your phone
automatically guides you through setup. Follow
the on-screen instructions to get started.
Play media
Once your speaker is attached, begin using your
phone as usual to play music or watch videos.
Media will automatically play through the JBL
SoundBoost speaker when attached to the phone.
Adjust volume
To change the volume for your speaker, use your
phone’s volume controls.
Charge it
Fully charge before using your speaker.
Tip: If your phone is still attached to the speaker,
charging the phone is the best way to charge both
at the same time.
Charging port
Charge level button
Charging status lights
slow blinking greenCharging
Full charge
Partially charged:
51-99%
16-50%
6-15%
Very low power
rapid blinking green, or
steady green when
charging
steady green, then off
steady amber, then off
steady red, then off
rapid blinking red
Remove it
To detach the speaker
from your phone, place
your finger in the notch
at the bottom of the
speaker and pull it away
from your phone.
