FIELD SERVICE BULLETIN

FSB Number: LVCCFSB2005-65
Author: Tony Bryan
Date: March 22, 2005
Total No. of Pages: 3
Subject: SNN5683A Battery – LiShen E14 EPROM
Accessories: SNN5683A
Phone Models: GSM V300, V303, V400, V500, V505, V525, V600
E550/V535, V550/V545, V620/V600i, V547, V551, V555,

V330, V635, A630, A780, A768i
CDMA V260, V262, V265
Level of Repair: 1

Problem

Service is aware of an accessory issue that affects proper Battery Metering when
using some SNN5683A batteries. The SNN5683A batteries, manufactured with
LiShen E14 cells, were programmed with incorrect metering values. Relevant
batteries will show the wrong steps on meter during discharge.
discharge should be shown on the battery meter according first column below,
but the problematic batteries show different behavior (most time on 1 bar).
Customer will notice batteries transition early from 3 to 2 bars, and 2 to 1 bar,
which may be interpreted as “Short Battery Life”.

Intended Programming Faulty Programming

3 Bars – 100% - 45% left 3 Bars – 100% - 69% left
2 Bars – 45% - 20% left 2 Bars - 69% - 54% left
1 Bar – 20% - 5% left 1 Bar - 54% - 3% left
Low Battery Warning: below 5% left Low Battery Warning: below 3% left

Shipments of approximately 2 million affected SNN5683A batteries with LiShen
E14 cells were made by (or for) Motorola, between

WW47 ‘04 – WW05 ‘05. The

information below indicates the estimated exposure quantities per region.

Affected Inventory Shipped Quantities:

467K to Tainjin DC – Greater China

689K to Texas DC – NA / LA

680K to Singapore DC – South Asia / EMEA

Usually battery

MOTOROLA INTERNAL USE ONLY Page 1

`

Consumer Solutions & Support
US Competency Center
600 North US Highway 45
Libertyville, Illinois 60048

Website: gs.mot.com

The SNN5683A batteries of concern can be easily identified by the Cell Code
“6U”. These are the 2

nd

and 3rd characters on the battery’s date code which is

directly beside the battery part number. See Image Below.

Example: SNN5638A G6UU40CTOEJG.FI

Impacted Cell Date Codes: OEH – PAF

Good Cell Date Codes: PAG and later

The Cell Date Code can be used to identify 6U cells that were manufactured
during the relevant timeframe WW47 ’04 thru WW05 ‘05. These are the
characters 9-11 on the battery’s date code which is directly beside the battery
part number. See Image Above.

Solution

All internal inventories of the SNN5683A battery have been separated in the
distribution centers. A total of 263K affected batteries were identified after
screening from all locations. This was completed on 3/9/2005. All concerned
material has been purged. Re-Programming of the affected batteries was
determined not to be a cost-effective solution.

Field Service Action

Customer Returns:

When servicing customer returns for the affected products listed above,
regardless of customer complaint, then:

1. Inspect the customer’s battery to determine if it is impacted by this issue.
a. If the customer’s battery is determined to not be impacted by this

issue, then follow normal troubleshooting techniques to identify and
repair fault, per the customer complaint.

2. Replace customer’s battery.

Service Inventory:
Please use the information, contained in this FSB, to immediately purge existing
SNN5683A inventory of relevant LiShen E14 cells.
