User Guide
RM Series™/Séries RM™ Two-Way Radios Radios bidirectionnelles
Page 2
Page 3
CONTENTS
CONTENTS
Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Product Safety. . . . . . . . . . . . . . . . . . . . . . . .4
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . .5
FCC Licensing Information . . . . . . . . . . . . .7
Canada Licensing Information. . . . . . . . . . .9
Batteries and Chargers
Installing the Lithium-Ion
(Li-Ion) Battery . . . . . . . . . . . . . . . . . . 15
Removing the Lithium-Ion
(Li-Ion) Battery . . . . . . . . . . . . . . . . . . 15
Holster . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power Supply, Adaptor and
Drop-in Tray Charger . . . . . . . . . . . . . 16
Battery Life Information . . . . . . . . . . . . . 17
Page 4
Microphone Gain. . . . . . . . . . . . . . . . . . .30
Hands Free Without Accessories
(iVOX) . . . . . . . . . . . . . . . . . . . . . . . . .30
Power Up - Tone Mode. . . . . . . . . . . . . .30
Reset to Factory Defaults . . . . . . . . . . . .30
Toggle Voice Prompt in User Mode . . . .31
Programming Features . . . . . . . . . . . . . . . .32
Advanced Configuration Mode . . . . . . . . . . .32
Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Editing Scan List . . . . . . . . . . . . . . . . . . 39
Nuisance Channel Delete . . . . . . . . . . . 39
Customer Programming Software (CPS) . . . 40
Bandwidth Select
(Only for Canada models) . . . . . . . . . 41
Time-Out Timer . . . . . . . . . . . . . . . . . . . 41
Power Select . . . . . . . . . . . . . . . . . . . . . 41
Page 5
CONTENTS
Frequency and Code Charts . . . . . . . . . . .53
RMU2043 – UHF Default Frequencies
Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
RMU2040 – UHF Default Frequencies
Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
RMM2050 – VHF-MURS Default
Frequencies Chart . . . . . . . . . . . . . . . . . . .55
CTCSS and PL/DPL Codes . . . . . . . . . . . . .56
Page 6
PRODUCT SAFETY
PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE
Notice to Users (FCC and Industry Canada)
This device complies with Part 15 of the FCC rules and RSS 210 of the Industry Canada rules per the conditions listed below:
1. This device may not cause harmful interference.
2. This device must accept any interference
received including interference that may cause undesired operation.
Before using this product, read the operating instructions and RF energy
Page 7
INTRODUCTION
INTRODUCTION
Thank you for purchasing the Motorola® RM Series™ Radio. This radio is a product of Motorola's 80 plus years of experience as a world leader in the designing and manufacturing of communications equipment. The RM Series™ radios provide cost-effective
Business Radios, RPSD 1C15, Motorola 8000 West Sunrise Boulevard Plantation, Florida 33322
PACKAGE CONTENTS
Radio
Holster
Page 8
This User Guide can be downloaded from www.motorolasolutions.com/RMSeries. For product-related questions, contact:
1-800-448-6686 in the USA 1-800-461-4575 in Canada 1-888-390-6456 on TTY (Text Telephone)
Page 9
FCC LICENSING
INFORMATION
FCC LICENSING INFORMATION
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful
To transmit on these frequencies, you are required to have a license issued by the FCC. Application is made available on FCC Form 601 and Schedules D, H, and Remittance Form
159.
To obtain these FCC forms, request document 000601 which includes all forms and
Page 10
Before filling out your application, you must decide which frequency(ies) you can operate on. See “Frequencies and Code Charts”. For questions on determining the radio frequency, call Motorola Product Services at:
1-800-448-6686
Changes or modifications not expressly
Replacement of any transmitter component (crystal, semiconductor, etc.) not authorized by the FCC equipment authorization for this radio could violate FCC rules.
Use of this radio outside the country where it was intended to be distributed is subject to government regulations and may be prohibited
Page 11
CANADA LICENSING
INFORMATION
CANADA LICENSING INFORMATION
GENERAL INFORMATION
The operation of your Motorola radio is subject to the Radiocommunications Act and must comply with rules and regulations of the Federal Government’s department of Industry
THE LICENSE APPLICATION
General Instructions
1. Fill in the items as per the instructions. If you
need additional space for any item use the reverse side of the application.
2. Be sure to use a typewriter or print legibly.
3. Make a copy for your files.
Page 12
BATTERIES AND CHARGERS SAFETY INFORMATION
This document contains important safety and operating instructions. Read these instructions carefully and save them for future reference.
3. To reduce risk of damage to the electric plug
and cord, pull by the plug rather than the cord when disconnecting the charger.
4. An extension cord should not be used unless
absolutely necessary. Use of an improper extension cord could result in risk of fire and electric shock. If an extension cord must be used, make sure that the cord size is 18AWG
Page 13
BATTERIES AND CHARGERS
SAFETY INFORMATION
OPERATIONAL SAFETY GUIDELINES
Turn the radio OFF when charging battery.
The charger is not suitable for outdoor use. Use only in dry locations/conditions.
Connect charger only to an appropriately fused
In equipment using fuses, replacements must comply with the type and rating specified in the equipment instructions.
Maximum ambient temperature around the power supply equipment must not exceed 40°C (104°F).
Power output from the power supply unit must not exceed the ratings stated on the product label
Page 14
RADIO OVERVIEW
PARTS OF THE RADIO
Antenna
On/Off/Volume Knob
Page 15
RADIO OVERVIEW
On/Off/Volume Knob
Used to turn the radio ON or OFF and to adjust the radio’s volume.
Accessory Connector
Used to connect compatible audio accessories.
Model Label
Indicates the model of the radio.
Side Buttons
Push-to-Talk (PTT) Button
Press and hold down this button to talk, release it to listen.
Side Button 1 (SB1)
The Side Button 1 is a general button that can be configured by the Customer Programming Software - CPS. The default setting of SB1 is
Page 16
This User Guide covers multiple RM Series models, and may detail some features your radio does not have. The radio’s model is shown on the bottom of the radio and provides the following information:
Table 1: RM Series Radio Specifications
Frequency
Transmit
Number of
Page 17
RADIO OVERVIEW
BATTERY FEATURES
About the Li-Ion Battery
The RM Series™ radio comes equipped with a rechargeable Li-Ion battery. This battery should be charged fully before initial use to ensure optimum capacity and performance.
Battery life is determined by several factors.
Motorola batteries are designed specifically to be used with a Motorola charger and vice versa. Charging in non-Motorola equipment may lead to battery damage and void the battery warranty. The battery should be at about 77°F (25°C) (room temperature), whenever possible. Charging a cold battery (below 50° F [10°C]) may result in leakage of
Page 18
Battery Recycling and Disposal
Li-Ion rechargeable batteries can be recycled. However, recycling facilities may not be available in all areas. Under various U.S. state laws and the laws of several other countries, batteries must be recycled and cannot be disposed of in landfills or incinerators. Contact your local waste management agency for
Many retailers and dealers participate in this program. For the location of the drop-off facility closest to you, access RBRC's Internet web site at:
www.rbrc.com
or call:
1-800-8-BATTERY
Page 19
RADIO OVERVIEW
Installing the Lithium-Ion (Li-Ion) Battery
Removing the Lithium-Ion (Li-Ion) Battery
Attach
Press until click
Detach
Press Latch
Page 20
Holster
Power Supply, Adaptor and Drop-in Tray Charger
Page 21
RADIO OVERVIEW
Battery Life Information
When the Battery Save feature is set to ON (enabled by default), the battery life lasts longer. The following table summarizes battery life estimations:
Table 2: Li-Ion Battery Life with Tx Power 2 Watts
Battery Type Battery Save OFF Battery Save ON
Page 22
Charging the Battery
The RM Series radio offers two types of Power Supplies:
Standard Power Supply and,
Rapid Power Supply
Note: The radio comes with a Standard Power
Supply.
To charge the battery (with the radio attached),
Charging with the Drop-in Tray Single Unit Charger (SUC)
Drop-in Tray SUC Port
Power Supply (Transformer)
Page 23
RADIO OVERVIEW
Note: When charging a battery attached to the
radio, turn the radio OFF to ensure a full charge. See “Operational Safety Guidelines” on page 9 for more information.
Charging A Stand-Alone Battery
above. Align the slots in the battery with the alignment ribs in the Drop-in Tray Single Unit Charger.
Table 3: Motorola Authorized Batteries
Part Number Description
PMNN4434_R Standard Li-Ion Battery
Page 24
Drop-in Tray Charger LED Indicators
Table 4: Charger LED Indicator
Status LED Indicator Comments
Power On
Green for approximately 1 second
Charging
Steady Red
Page 25
RADIO OVERVIEW
If there is NO LED indication:
1. Check if the radio with battery, or the battery alone, is inserted correctly. (refer to step 4 of "Charging with the
Drop-in Tray Single Unit Charger (SUC)" on page 18)
2. Ensure that the power supply cable is securely plugged into the charger socket using an appropriate AC
outlet and there is power to the outlet.
3. Confirm that the battery being used with the radio is listed in Table 3.
Estimated Charging Time
Page 26
Charging a Radio and Battery using a Multi Unit-Charger - MUC (Optional Accessory)
1. Place the Multi-Unit Charger on a flat surface.
2. Insert the power cord plug into the MUC’s dual
pin connector at the bottom of the MUC.
3. Plug the power cord into an AC outlet.
4. Turn the radio OFF.
5. Insert the radio or battery into the charging
pocket with the radio or battery facing away
Page 27
RADIO OVERVIEW
Multi-Unit Charger LED Indicators
Table 6: Charger LED Indicator
Status LED Indicator Comments
Power On
Green for approximately 1 second
Charging
Steady Red
Page 28
If there is NO LED indication:
1. Check if the radio with battery or the battery
alone, is inserted correctly (refer to step 5 of "Charging a Radio and Battery using a Multi Unit-Charger - MUC (Optional Accessory)" on page 22).
2. Make sure the power cord is securely plugged
into the MUC and the appropriate AC outlet.
Page 29
GETTING STARTED
GETTING STARTED
For the following explanations, refer to “Parts Of The Radio” on page 10.
TURNING RADIO ON/OFF
To turn ON the radio, rotate the On/Off/Volume Knob clockwise. The radio plays one of the following:
Note: Do not hold the radio too close to the ear
when the volume is high or when adjusting the volume
SELECTING A CHANNEL
To select a channel, press the SB2 button until you reach the desired channel. An audible voice indicates the selected channel.
Page 30
Notes:
To listen to all activity on a current channel, short press the SB1 to set the CTCSS/DPL code to 0. This feature is called ‘CTCSS/DPL Defeat (Squelch set to SILENT)’.
(*) This assumes SB1 is not being programmed for a different mode.
TALK RANGE
TALK RANGE
Model
Industrial Multi-Level
Inside steel/
concrete Industrial
buildings
Inside multi-
level buildings
UHF 2W Up to 250,000 Sq. Ft. Up to 20 Floors
Page 31
GETTING STARTED
To establish a proper two-way communication, the channel, frequency, and interference eliminator codes must be the same on both radios. This depends on the stored profile that has been preprogrammed on the radio:
1. Channel: Current channel that the radio is
using, depending on radio model.
4. Scramble Code: Codes that make the
transmissions sound garbled to anyone listening who is not set to that specific code.
5. Bandwidth: Some frequencies have selectable
channel spacing, which must match other radios for optimum audio quality (only available for RMU2043).
For details on how to set up frequencies and
Page 32
RADIO LED INDICATORS
RADIO STATUS LED INDICATION
Channel Busy Solid Orange
Cloning Mode Double Orange Heartbeats
Cloning In Progress Solid Orange
Fatal Error at Power up
One Green Blink, One Orange Blink, One Green Blink, then repeat for 4 seconds
Page 33
GETTING STARTED
HANDS-FREE USE/VOX
1. Turn the radio OFF.
2. Open accessory cover.
3. Insert the audio accessory’s plug firmly into
accessory port.
4. Turn radio ON. The LED Indicator will blink
double red
5. Lower radio volume BEFORE placing
Page 34
Setting VOX Sensitivity
The sensitivity of the radio's accessory or microphone can be adjusted to suit different operating environments. VOX sensitivity can be programmed via the CPS.
Default value is OFF. If you want to use the VOX feature, VOX level should be set at a
turning ON the radio.
Pressing the PTT button can temporarily disable the iVOX operation.
Note: There is a short delay between the time
when you start stalking and when the radio transmits.
Power Up - Tone Mode
Page 35
GETTING STARTED
Toggle Voice Prompt in User Mode
Short press the SB1 button while turning ON the radio to enable/disable Voice Prompt in User mode. This mode is set to ON by default.
Page 36
PROGRAMMING FEATURES
To easily program all the features in your radio, it is recommended to use the Customer Programming Software (CPS) and the programming cable.
Auto-Scan and,
Active Channels
The Select Frequencies feature allows you to choose frequencies from a pre-defined list.
The Interference Eliminator Code (CTCSS/ DPL) helps minimize interference by providing you with a choice of code combinations that
Page 37
PROGRAMMING FEATURES
Entering Advanced Configuration Mode
Note: Before configuring the features, make sure
your radio is set to the channel you wish to program. You can do so before entering Advanced Configuration Mode or at any time during the Advanced Configuration Mode by pressing the SB2 button until you reach the desired channel.
Once you are in the ‘Idle’ Programming Mode, you will be able to hear the Frequencies, Codes, Auto-Scan and Active Channels settings by short pressing the PTT button to navigate along the different programmable features.
Entering Frequencies Values
Page 38
Reading CTCSS / DPL Values
Cycle through the features available for configuration by short pressing the PTT button until you hear the current code. The radio moves to the programming CTCSS/PL codes mode.
Enter a new code value using the SB1 and SB2
Active Channels
While in Auto-Scan mode, short pressing the PTT button shifts the radio to ‘Active Channels’ feature. Modify the amount of channels available using the SB1 and SB2 buttons.
Saving Settings
Once you are satisfied with the settings, you
Page 39
PROGRAMMING FEATURES
Programming Mode FAQ
1. I got distracted while programming and forgot
which feature I was programming. What should I do?
Return to ‘Idle’ Programming Mode and start over. You will not be able to return to Programming Mode (the radio does not provide
codes pool. For example, if you try to program code 220, the radio would not accept it as the maximum value allowed is 219. Same goes for the frequencies. Refer to the“Frequency and Code Charts” on page 53 to make sure you are programming a valid value.
3. I am trying to enter the Programming Mode but
the radio would not do it.
Page 40
Turn OFF the radio and start over.
5. I just programmed the value I wanted. How do I
exit the Programming Mode?
You can either:
long press the PTT button twice to exit if you’re in the Programming Mode or,
Long press the PTT button once if you are
PROGRAMMING VALUES EXAMPLE
Example of Programming a Frequency
Assuming current frequency value is set to Channel 1, with the UHF default frequency set to ‘02’ (equivalent to 464.5500 MHz), and you want to change it to Frequency Number = ‘13’ (which is mapped to 461.1375 MHz), follow this
Page 41
PROGRAMMING FEATURES
Example of Programming a Code
Assuming the current code value is set to factory default ‘001’, and you want to change it to CTCSS/DPL Code = 103. Follow the sequence indicated below:
1. Enter Advanced Configuration Mode.
2. Short press the PTT button twice. The radio
Example of Programming Auto-Scan
Auto-Scan is the third available feature in the Programming Mode and can be set to either ON or OFF on a particular channel.
To set Auto-Scan to ON:
Enter Advanced Configuration Mode and select the desired channel.
Page 42
Example of Programming Active Channels
Active Channels is the last Programming Mode. It allows you to modify the number of active channels the radio is programmed to support.
To set Active Channels:
Enter Advanced Configuration Mode and select
OTHER PROGRAMMING FEATURES
Scan
Scan allows you to monitor other channels to detect conversations. When the radio detects a transmission, it stops scanning and goes to the active channel. This allows you to listen and talk to people in that channel without having to
Page 43
PROGRAMMING FEATURES
which was previously selected before Scan is activated. If no transmission occurs within 5 seconds, scanning resumes.
If you want to scan a channel without the Interference Eliminator Codes (CTCSS/DPL), set the code settings for the channels to ‘0’ in the CTCSS/DPL Programming Selection Mode.
Note: Whenever the radio is set to Scan, the LED
Nuisance Channel Delete
Nuisance Channel Delete allows you to temporarily remove channels from the Scan List. This feature is useful when irrelevant conversations on a ‘nuisance’ channel ties up the radio’s scanning feature.
To delete a channel from the Scan List:
Page 44
CUSTOMER PROGRAMMING SOFTWARE (CPS)
To program, connect the RM Series radio via the Drop-in Charger Tray and CPS Programming Cable as shown in Figure 1 on page 40.
CPS allows you to program frequencies, PL/ DPL Codes as well as other features such as: Bandwidth Select, Time-out Timer, Power Select, Scan List, Call Tones, Scramble,
Radio to be programmed
Page 45
PROGRAMMING FEATURES
Bandwidth Select (Only for Canada models)
All US models are compliant with the narrowbandwidth FCC regulation.
Default setting for Bandwidth Select depends on the specific frequency and channel. Some frequencies have selectable channel spacing, which must match with other radios for
Note: Some frequencies may have FCC transmit
power restrictions that do not allow them to be set at a higher power level. For details see the Frequencies and Code Chart Section.
Call Tones
Call Tones feature allows you to transmit an audible tone to other radios on the same
Page 46
Reverse Burst
Reverse Burst eliminates unwanted noise (squelch tail) during loss of carrier detection. You can select values of either 180 or 240 to be compatible with other radios. The default value is 180.
Notes:
CLONING RADIOS
You can clone RM Series radio profiles from one Source radio to a Target radio by using any one of these 3 methods:
Using a Multi Unit Charger (MUC- optional accessory),
Using two Single Unit Chargers (SUC) and a
Page 47
PROGRAMMING FEATURES
Cloning with a Multi Unit Charger (MUC)
4 and 5.
When cloning, the MUC does not need to be plugged into a power source, but ALL radios require charged batteries.
1. Turn ON the Target radio and place it into one of
the MUC Target Pockets
2. Power the Source radio following the sequence
Pocket 1
“CLONE” symbol
Pocket 2 “CLONE” symbol Pocket 5
Pocket 4
Page 48
show ‘Pass’ or ‘Fail’ on the display (a voice announcement will be played within 5 seconds).
5. Once you have completed the cloning process,
turn the radios OFF and ON to exit the ‘cloning’ mode.
Further details on how to clone radios are explained in the Instructions Sheet provided with the MUC.
CPS and Cloning Cables (Optional Accessory)
Both CPS and Cloning Cables are made to work either with RM Series radios or RDX Series radios. Cloning cable supports a mix of RM and RDX series radios.
CPS cable programs RM series radios. Make sure the cable switch is in “Flash” position. To
Page 49
PROGRAMMING FEATURES
CPS Cable Cloning Radio using the Radio to Radio
(R2R) Cloning Cable (Optional Accessory)
Cloning Cable
Page 50
2. Unplug any cables (power supply or USB
cables) from the SUCs.
3. Plug one side of the cloning cable mini USB
connector to the first SUC and the other end to the second SUC.
Note: During the cloning process, no power is
being applied to the SUC. The batteries will not be charged. Only data communication is
“successful” (cloning is successful) or “fail” (cloning process has failed). If the Source Radio is a display model radio, it will either show ‘Pass’ or ‘Fail’ on the display (a tone will be heard within 5 seconds).
8. Once the cloning process is completed, turn the
Radios OFF and ON or, long press the PTT button to exit the ‘cloning’ mode.
Page 51
PROGRAMMING FEATURES
4. Ensure that there is no debris in the charging
tray or on the radio contacts.
5. Ensure that the Target radio is turned ON.
6. Ensure that the Source radio is in cloning mode.
7. Ensure that the two radios are both from the
same frequency band, same region and have the same transmission power.
Information on how to clone using the CPS is available either in:
the CPS Help File --> Content and Index --> Cloning Radios, or
in the CPS Programming Cable Accessory Leaflet.
Page 52
TROUBLESHOOTING
Symptom Try This...
No Power
Recharge or replace the Li-Ion battery. Extreme operating temperatures may affect battery life. Refer to “About the Li-Ion Battery” on page 13
Page 53
TROUBLESHOOTING
Limited talk range
Steel and/or concrete structures, heavy foliage, buildings or vehicles decrease range. Check for clear line of sight to improve transmission. Wearing radio close to body such as in a pocket or on a belt decreases range. Change location of radio. To increase range and coverage, you can reduce obstructions or increase power. UHF radios provides greater coverage in industrial and commercial buildings. Increasing power provides greater signal range and increased penetration through obstructions.
Symptom Try This...
Page 54
Heavy static or interference
Radios are too close; they must be at least five feet apart. Radios are too far apart or obstacles are interfering with transmission. Refer to “Talking and Monitoring” on page 25.
Low batteries
Recharge or replace Li-Ion battery. Extreme operating temperatures affect battery life. Refer to “About the Li-Ion Battery” on page 13.
Symptom Try This...
Page 55
TROUBLESHOOTING
Cannot activate VOX
VOX feature might be set to OFF. Use the CPS to ensure that the VOX Sensitivity level is not set to ‘0’. Accessory not working or not compatible. Refer to “Hands-Free Use/VOX” on page 29.
Battery does not charge
Check drop-in tray charger is properly connected and correspond to a compatible power supply. Refer to “Charging with the Drop-in Tray Single Unit Charger (SUC)” on
Symptom Try This...
Page 56
USE AND CARE
Page 57
FREQUENCY AND CODE
CHARTS
FREQUENCY AND CODE CHARTS
RMU2043 – UHF DEFAULT FREQUENCIES CHART
RM UHF 4CH Radios Default Frequencies – RMU2043
Channel Frequency #
Frequency
(MHz)
Code # Code Bandwidth
Page 58
RMU2040 – UHF DEFAULT FREQUENCIES CHART
RM UHF 4CH Radios Default Frequencies – RMU2040
Channel Frequency #
Frequency
(MHz)
Code # Code Bandwidth
1 2 464.5500 1 67.0 Hz 12.5 kHz
2 8 467.9250 1 67.0 Hz 12.5 kHz
Page 59
FREQUENCY AND CODE
CHARTS
RMM2050 – VHF-MURS DEFAULT FREQUENCIES CHART
RM VHF-MURS 5CH Radios Default Frequencies – RMM2050
Channel Frequency #
Frequency
(MHz)
Code # Code Bandwidth
1 1 154.5700 1 67.0 Hz 20.0 kHz
2 2 154.6000 1 67.0 Hz 20.0 kHz
Page 60
CTCSS AND PL/DPL CODES
CTCSS Codes
CTCSS Hz CTCSS Hz CTCSS Hz
1 67.0 14 107.2 27 167.9
2 71.9 15 110.9 28 173.8
3 74.4 16 114.8 29 179.9
4 77.0 17 118.8 30 186.2
Page 61
FREQUENCY AND CODE
CHARTS
PL/DPL Codes
DPL Code DPL Code DPL Code
39 23 55 116 71 243
40 25 56 125 72 244
41 26 57 131 73 245
42 31 58 132 74 251
43 32 59 134 75 261
Page 62
87 365 104 565 121 754
88 371 105 606 123 645
89 411
106 612 124 Customized PL
90 412 107 624 125 Customized PL
91 413 108 627 126 Customized PL
PL/DPL Codes (Continued)
DPL Code DPL Code DPL Code
Page 63
FREQUENCY AND CODE
CHARTS
139 Inverted DPL 48 156 Inverted DPL 65 173 Inverted DPL 82
140 Inverted DPL 49 157 Inverted DPL 66 174 Inverted DPL 83
141 Inverted DPL 50 158 Inverted DPL 67 175 Inverted DPL 84
142 Inverted DPL 51 159 Inverted DPL 68 176 Inverted DPL 85
143 Inverted DPL 52 160 Inverted DPL 69 177 Inverted DPL 86
PL/DPL Codes (Continued)
DPL Code DPL Code DPL Code
Page 64
190 Inverted DPL 99 200 Inverted DPL 109 210 Inverted DPL 119
191 Inverted DPL 100 201 Inverted DPL 110 211 Inverted DPL 120
192 Inverted DPL 101 202 Inverted DPL 111 212 Inverted DPL 121
193 Inverted DPL 102 203 Inverted DPL 112 213 Inverted DPL 123
194 Inverted DPL 103 204 Inverted DPL 113 214 Customized DPL
PL/DPL Codes (Continued)
DPL Code DPL Code DPL Code
Page 65
FREQUENCY AND CODE
CHARTS
Notes
Page 66
MOTOROLA LIMITED WARRANTY FOR THE UNITED STATES AND CANADA
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its telephones, pagers, and
Products and Accessories
Products Covered Length of Coverage
Products and Accessories as defined
above, unless otherwise provided for below.
One (1) year from the date of purchase by the first consumer purchaser of the product unless otherwise provided for below.
Decorative
Page 67
MOTOROLA LIMITED
WARRANTY FOR THE UNITED
Exclusions
Normal Wear and Tear. Periodic maintenance,
repair and replacement of parts due to normal wear and tear are excluded from coverage.
Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.
Abuse & Misuse. Defects or damage that result
Use of Non-Motorola Products and Accessories. Defects or damage that result from
the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.
Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than
Page 68
Communication Services. Defects, damages, or the failure of Products, Accessories or Software due to any communication service or signal you may subscribe to or use with the Products Accessories or Software is excluded from coverage.
Software
Software NOT Embodied in Physical Media.
Software that is not embodied in physical media (e.g. software that is downloaded from the internet), is provided “as is” and without warranty.
WHO IS COVERED?
This warranty extends only to the first consumer purchaser, and is not transferable.
HOW TO OBTAIN WARRANTY SERVICE OR
Products Covered Length of Coverage
Page 69
MOTOROLA LIMITED
WARRANTY FOR THE UNITED
Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non­exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
PATENT NOTICE
EXPORT LAW ASSURANCES
This product is controlled under the export regulations of the United States of America. The Governments of the United States of America may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce.
Page 70
ACCESSORIES
AUDIO ACCESSORIES
BATTERY
SOFTWARE APPLICATIONS
Part No. Description
53815 Headset w/Boom Mic BR
HMN9026_R Remote Speaker Mic BR
Part No. Description
PMNN4434_R Standard Li-Ion Battery
PMNN4453_R High Capacity Li-Ion Battery
Page 71
ACCESSORIES
CHARGERS
Part No. Description
PMLN6384_
Multi-Unit Charger (MUC) Kit ­North America
PMLN6394_ Standard Drop-In Tray Charger
Page 72
Notes
Page 73
TABLE DES MATIÈRES
TABLE DES MATIÈRES
Table des matières . . . . . . . . . . . . . . . . . . . .1
Produit Sécurité. . . . . . . . . . . . . . . . . . . . . . .4
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . .6
Contenu de l’emballage. . . . . . . . . . . . . . . . . .6
Informations sur les licenses
de la FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Antenne . . . . . . . . . . . . . . . . . . . . . . . . . 11
Témoin lumineux . . . . . . . . . . . . . . . . . . 11
Boutons latéraux . . . . . . . . . . . . . . . . . . 11
La batterie au Lithium-Ion (Li-Ion) . . . . . 11
Caractéristiques de la batterie . . . . . . . . . . . 13
À propos de la batterie Li-Ion. . . . . . . . . 13
Recyclage et traitement de la batterie . . 14 Installation de la batterie au
Page 74
Sélection d’un canal . . . . . . . . . . . . . . . . . . .25
Transmission et contrôle . . . . . . . . . . . . . . . .25
Réception d’un appel. . . . . . . . . . . . . . . . . . .27
Portée de transmission . . . . . . . . . . . . . . . . .27
Témoins lumineux de la radio . . . . . . . . . . . .29
Utilisation kit mains-libres/VOX . . . . . . . . . . .30
Avec accessoires compatibles VOX . . . .30
Réglages sensibilité VOX . . . . . . . . . . . .31
Exemple de valeurs de programmation . . . . 38
Exemple de programmation d’une
fréquence . . . . . . . . . . . . . . . . . . . . . . 38
Exemple de programmation
d’un code . . . . . . . . . . . . . . . . . . . . . . 38
Exemple de programmation
d’auto-balayage . . . . . . . . . . . . . . . . . 39
Exemple de programmation
Page 75
TABLE DES MATIÈRES
Clonage de radios . . . . . . . . . . . . . . . . . . . . .44
Clonage avec un chargeur
multi-unités (MUC) . . . . . . . . . . . . . . .44
CPS et Câble de clonage
(Accessoire en option) . . . . . . . . . . . .46
Clonage radio en utilisant le câble
de clonage (R2R) Radio à Radio
(Accessoire en option) . . . . . . . . . . . .47
Accessoires audio . . . . . . . . . . . . . . . . . . . . 68
Batterie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Logiciels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Câbles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Chargeurs . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Accessoires de transport . . . . . . . . . . . . . . . 69
Page 76
PRODUIT SÉCURITÉ
SÉCURITÉ DU PRODUIT ET CONFORMITÉ D’EXPOSITION AUX FRÉQUENCES RADIO
Le modèle RMM2050 est conforme à la population globale et aux conditions incontrôlées d'environnement.
Avis aux utilisateurs (FCC et Canada d'industrie)
Cet appareil est conforme à l’a partie 15 de la réglementation FCC et du RSS 210 des règles de l’Industrie du Canada par conditions
Avant d’utiliser ce produit, lisez les instructions
Page 77
PRODUIT SÉCURITÉ
maximum approuvés pour l'émetteur par l’Industrie du Canada. Pour reduire des interférences radio potentielles avec d'autres utilisateurs, on devrait ainsi choisir le type d'antenne et son gain de facon a ce que l'équivalent de la puissance isotropique rayonnée (e.i.r.p.) ne depasse pas celle nécessaire de la communication réussie.
Page 78
INTRODUCTION
Nous vous remercions d’avoir acheté une radio Motorola® RM Series™ Cette radio est le produit de plus de 80 ans d’expérience de Motorola comme leader mondial de la conception et fabrication d’équipements de communication. Les radios RM Series™ offrent
Business Radios, RPSD 1C15, Motorola 8000 West Sunrise Boulevard Plantation, Floride 33322
CONTENU DE L’EMBALLAGE
Radio
•Étui
Page 79
INTRODUCTION
Pour obtenir une copie d’une version imprimable en gros caractères de ce guide de l’utilisateur, visitez notre site :
www.motorolasolutions.com/RMSeries
Pour des questions relatives au produit, veuillez contacter :
1-800-448-6686 aux É.-U. 1-800-461-4575 au Canada
Page 80
INFORMATIONS SUR LES LICENSES DE LA FCC
INFORMATIONS SUR L’INTERFÉRENCE
Ce dispositif est conforme à la Partie 15 des règles de la FCC. Le fonctionnement est soumis à la condition que ce dispositif ne provoque pas d’interférence nuisible.
la FCC. Pour en faire la demande, veuillez compléter le formulaire 601 et les annexes D, H, ainsi que le formulaire de règlement 159 de la FCC.
Pour obtenir ces formulaires de la FCC, veuillez demander le document 000601 qui comprend tous les formulaires et instructions. Si vous désirez que ce document vous soit
Page 81
INFORMATIONS SUR LES
LICENSES DE LA FCC
Avant de remplir votre demande, vous devez déterminer la ou les fréquence(s) que vous pouvez utiliser. Veuillez consulter la section «Diagrammes de fréquences et de codes». Pour toute question concernant les radiofréquences, veuillez communiquer avec le Service des produits Motorola au:
1-800-927-2744
Le remplacement de toute composante de l’émetteur (cristal, semi-conducteur, etc.) non autorisée par la FCC pour cette radio pourrait contrevenir aux règles de la FCC.
L’utilisation de cette radio à l’extérieur de la région d’émission prévue est sujette à la réglementation du gouvernement et pourrait être prohibée.
Page 82
INFORMATIONS SUR L’ACCORD DE LICENCE POUR LE CANADA
INFORMATIONS GÉNÉRALES
Le fonctionnement de votre radio Motorola fait l’objet d’une loi sur les radiocommunications et
LA DEMANDE DE LICENSE
Instructions générales
1. Remplissez les éléments comme indiqué dans
les instructions. Si vous avez besoin de plus d’espace pour un élément, utilisez le verso de la demande.
2. Assurez-vous d’utiliser une machine à écrire ou
Page 83
INFORMATIONS SUR L’ACCORD
DE LICENCE POUR LE CANADA
Pour obtenir le dernier formulaire de demande de license pour le Canada, veuillez vous rendre à :
www.ic.gc.ca
Page 84
CONSIGNES DE SÉCURITÉ POUR LES BATTERIES ET LES CHARGEURS
Ce document contient les instructions de fonctionnement et les consignes de sécurité. Veuillez lire attentivement ces instructions et les conserver pour y faire référence plus tard.
blessures.
3. Pour réduire les risques de dommages à la
prise et au cordon électriques, tirez sur la prise plutôt que sur le cordon lors que vous déconnectez le chargeur.
4. Un cordon d’extension ne doit pas être utilisé
sauf en cas d’absolue nécessité. L’utilisation d’un cordon d’extension non approprié pourrait
Page 85
CONSIGNES DE SÉCURITÉ POUR LES
BATTERIES ET LES CHARGEURS
pas disponibles. Le démontage du chargeur peut engendrer un risque de choc électrique ou d’incendie.
7. Pour réduire le risque de choc électrique,
débranchez le chargeur de la prise d’alimentation secteur avant de tenter toute maintenance ou nettoyage.
connectée doit être proche et facilement accessible.
Pour une installation avec fusibles, les pièces de rechange doivent respecter le type et les valeurs indiqués dans les instructions de l’installation.
La température ambiante maximale autour de l’installation électrique ne doit pas dépasser
Page 86
VUE GÉNÉRALE DE LA RADIO
ÉLÉMENTS DE LA RADIO
Antenne
Bouton Marche/ Arrêt/Volume
Page 87
VUE GÉNÉRALE DE LA RADIO
Bouton Marche/Arrêt/Volume
Utilisé pour allumer ou éteindre la radio et ajuster le volume.
Connecteur d’accessoire
Utilisé pour connecter des accessoires audio compatibles.
Étiquette modèle
Boutons latéraux
Bouton PTT (Push-to-talk/Presser pour parler)
Appuyez et maintenez enfoncé ce bouton pour parler, relâchez-le pour écouter.
Bouton latéral 1 (SB1)
Le bouton latéral 1 est un bouton général qui peut être configuré avec le logiciel de programmation par ordinateur - CPS. Le réglage par défaut de
Page 88
Ce guide de l’utilisateur couvre de multiples modèles RM Series, et peut détailler des fonctions que votre radio ne possède pas. Le modèle de radio est indiqué à bas de la radio et vous fournit les informations suivantes :
Tableau 1: Radio RM Series Caractéristiques
Puissance
Page 89
VUE GÉNÉRALE DE LA RADIO
CARACTÉRISTIQUES DE LA BATTERIE
À propos de la batterie Li-Ion
La radio RM Series™ est livrée avec une batterie rechargeable Li-Ion. Cette batterie doit être complètement chargée avant la première utilisation pour assurer une capacité et des performances maximales.
Les batteries Motorola sont conçues spécialement pour être utilisées avec un chargeur Motorola et vice versa. La recharge avec un équipement non-Motorola peut causer des dommages à la batterie et annule la garantie de la batterie. La batterie doit être à une température d’environ 77° F (25° C) (température de la salle), autant que possible.
Page 90
Recyclage et traitement de la batterie
Les batteries Li-ion peuvent être recyclées. Cependant, les installations de recyclage peuvent ne pas être disponibles dans toutes les régions. Du fait de nombreuses lois d’état des États-unis et des lois de plusieurs autres pays, les batteries doivent être recyclées et ne peuvent pas être rejetées dans la nature ou
proche de chez vous, rendez vous sur le site internet de RBRC :
www.rbrc.com
ou appelez le :
1-800-8-BATTERY
Ce site internet et ce numéro de téléphone donnent aussi des informations utiles
Page 91
VUE GÉNÉRALE DE LA RADIO
Installation de la batterie au Lithium-Ion (Li-Ion)
Remarque:Pour en apprendre plus sur les
caractérisques de l’autonomie de la batterie Li-ion, référez-vous à « À propos de la batterie Li-Ion » à la page 13
Retirer la batterie au Lithium-Ion (Li-Ion)
Connecter
Appuyer
jusqu'au clic
Déconnecter
Appuyer sur le verrou
Page 92
Étui
Alimentation Életrique , Adaptateur et Bloc Chargeur
Page 93
VUE GÉNÉRALE DE LA RADIO
Informations sur l’autonomie de la batterie
Quand la fonction économie de batterie est allumée (activée par défaut), l’autonomie de la batterie est plus longue. Le tableau suivant résume les estimations de l’autonomie de la batterie :
Tableau 2: De la batterie Li-Ion avec Puissance Tx 2 Watts
Type de batterie
Économie de batterie
éteinte
Économie de batterie
allumée
Page 94
Recharge de la batterie
Les radios RM Series TM offrent deux types d’ alimentations électriques :
un alimentation électrique standard et
un alimentation électrique rapide
Remarque:La radio est livrée avec un alimentation
électrique standard
Recharge avec le bloc chargeur simple (SUC)
Port du support de charge
Alimentation électrique (Transformateur)
Page 95
VUE GÉNÉRALE DE LA RADIO
Règles générales de sécurité en fonctionnement » à la page 9 pour plus d’informations.
Recharge d’une batterie seule
la batterie s’engagent correctement dans le chargeur
Tableau 3: Batteries agréées Motorola
No de pièce Description
PMNN4434_R Batterie standard Li-Ion
Page 96
Témoins lumineux du bloc chargeur
Tableau 4: Voyant DEL du chargeur
État Voyant d'état Commentaires
Mise sous tension
Vert durant environ une seconde
Chargement en cours
Rouge continu
Page 97
VUE GÉNÉRALE DE LA RADIO
l’étape 4 de "Recharge avec le bloc chargeur simple (SUC)" à la page 18 )
2. Assurez-vous que le câble du bloc d'alimentation est correctement branché à la prise du chargeur.
3. Assurez-vous que la batterie utilisée figure bien dans la liste du Tableau 3.
Estimation du temps de charge
Le tableau suivant fournit les estimations des temps de charge de la batterie. Pour plus de détails, référez-vous à « Batterie » à la page 68.
Tableau 5: Estimation du temps de charge
Page 98
Recharge d’une radio et d’une batterie utilisant un chargeur multi unités MUC (accessoire optionnel)
batterie et étui ou des batteries seules, mais pas les deux .
1. Placez le chargeur sur une surface plane.
2. Insérez la prise du cordon d’alimentation dans
la prise au bas de la MUC.
3. Connectez le cordon sur une prise secteur.
4. Éteignez la radio.
Page 99
VUE GÉNÉRALE DE LA RADIO
Témoin lumineux du MUC
Tableau 6: Voyant DEL du chargeur
État Voyant d'état Commentaires
Mise sous tension
Vert durant environ une seconde
Chargement en cours
Rouge continu
Page 100
1. Assurez-vous que la radio et sa batterie, ou la
batterie seule, sont insérées correctement. (référez-vous à l’étape 5 de "Recharge d’une radio et d’une batterie utilisant un chargeur multi unités MUC (accessoire optionnel)" à la page 22 )
2. Assurez-vous que le câble du bloc
d'alimentation est correctement branché à la
Loading...
