Professional Radio
P080
User Guide
68P64110B68
Issue: September 1999
Radio Communications Supply &
Installation Specialist
Website
www.radiotronics.co.uk
Email
sales@radiotronics.co.uk
Telephone Numbers
0345 0 955 955
02087 190 180
Motorola P080 User Guide
CONTENTS
Radio Overview . . . . . . . . . . . . . . . . . . . . 3
Parts of the Radio . . . . . . . . . . . . . . . . . . . 3
On-Off/Volume Knob. . . . . . . . . . . . . . . 4
Channel Selector Knob . . . . . . . . . . . . . 4
Push-to-Talk (PTT) Button . . . . . . . . . . 4
Microphone . . . . . . . . . . . . . . . . . . . . . . 4
LED Indicator . . . . . . . . . . . . . . . . . . . . 4
Programmable Buttons . . . . . . . . . . . . . 4
Menu Keys . . . . . . . . . . . . . . . . . . . . . . 6
Keypad Keys. . . . . . . . . . . . . . . . . . . . . 6
LCD Screen . . . . . . . . . . . . . . . . . . . . . 6
Indicator Tones . . . . . . . . . . . . . . . . . . . . . 8
Programmable ButtonsÕ Audio Indicators. . 8
Improved Audio Features. . . . . . . . . . . . . . 8
Low Level Expansion (LLE) . . . . . . . . . 8
Companding . . . . . . . . . . . . . . . . . . . . . 8
Attaching the Battery . . . . . . . . . . . . . .11
Removing the Battery . . . . . . . . . . . . . .11
Attaching the Antenna . . . . . . . . . . . . . 12
Removing the Antenna. . . . . . . . . . . . .12
Attaching the Belt Clip . . . . . . . . . . . . .13
Removing the Belt Clip . . . . . . . . . . . . .13
Turning the Radio On or Off . . . . . . . . . . .14
Adjusting the RadioÕs Volume . . . . . . . . . .14
Selecting a Radio Channel . . . . . . . . . . . .14
Sending a Call . . . . . . . . . . . . . . . . . . . . . .15
Receiving a Call. . . . . . . . . . . . . . . . . . . . .15
Radio Call Information . . . . . . . . . . . . . .16
Repeater or Talkaround Mode. . . . . . . . . .16
Setting Tight or Normal Squelch . . . . . . . .16
Setting the Power Level. . . . . . . . . . . . . . .17
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
CONTENTS
Getting Started . . . . . . . . . . . . . . . . . . . . . 9
Battery Information. . . . . . . . . . . . . . . . . . . 9
Battery Care and Tips . . . . . . . . . . . . . . 9
Recycling or Disposal of Batteries . . . 10
Charging your Battery . . . . . . . . . . . . . 10
Accessory Information . . . . . . . . . . . . . . . 11
Starting or Stopping a Scan Operation . . .18
Talkback . . . . . . . . . . . . . . . . . . . . . . . . . .19
Deleting a Nuisance Channel . . . . . . . . . .19
Adding a Deleted Nuisance Channel
back to the Scan List . . . . . . . . . . . . . . . . .19
Prioritization of a Scan List member . . . . .19
1
English
Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
C
CONTENTS
Making a Phone Call . . . . . . . . . . . . . . . . 20
Phone List . . . . . . . . . . . . . . . . . . . . . . . . 23
Audio/Tone Settings . . . . . . . . . . . . . . . 25
General Instructions . . . . . . . . . . . . . . . . . 25
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Entering the Phone Mode . . . . . . . . . . 20
Sending the Access Code. . . . . . . . . . 20
Sending the Phone Number . . . . . . . . 21
The Phone Conversation . . . . . . . . . . 22
Ending the Phone Call . . . . . . . . . . . . 22
Adding an Entry to the Phone List . . . 23
Deleting an Entry . . . . . . . . . . . . . . . . 23
Editing an Entry. . . . . . . . . . . . . . . . . . 24
Electromagnetic
Interference/Compatibility. . . . . . . . . . . 28
Operational Warnings. . . . . . . . . . . . . . 28
Operational Cautions . . . . . . . . . . . . . . 29
General Radio Care . . . . . . . . . . . . . . .29
General Instructions . . . . . . . . . . . . . . . . . 26
Safety Information . . . . . . . . . . . . . . . . . 27
Safe and Efficient Operation
of Motorola Two-Way Radios. . . . . . . . . . 27
Exposure To Radio Frequency Energy 27
Portable Radio Operation
and EME Exposure . . . . . . . . . . . . . . . 28
English
2
omputer Software Copyright
The products described in this manual may include copyrighted computer
programmes stored in semiconductor memories or other media. Laws in the
United States of America and other countries preserve for Motorola Europe
and Motorola Inc. certain exclusive rights for copyrighted computer
programmes, including the right to copy or reproduce in any form the
copyrighted computer programme. Accordingly, any copyrighted computer
programmes contained in the products described in this manual may not be
copied or reproduced in any manner without the express written permission of
the holders of the rights. Furthermore, the purchase of these products shall not
be deemed to grant either directly or by implication, estoppel, or otherwise, any
licence under the copyrights, patents, or patent applications of the holders of
the rights, except for the normal non-exclusive royalty free licence to use that
arises by operation of the law in the sale of the product.
RADIO OVERVIEW
PARTS OF THE RADIO
Channel Selector
On-Off/Volume
Knob
Side Button 1
(programmable)
Side Button 2
(programmable)
Push-to-Talk
(PTT) Button
Knob
LED Indicator
Microphone
LCD Screen
Menu Keys
Keypad
Dust Cover
covering the
Accessories
Port
(Pull down from
top to open)
RADIO OVERVIEW
3
English
RADIO OVERVIEW
On-Off/Volume Knob
Turns the radio on or off, and adjusts the radioÕs
volume.
Channel Selector Knob
Switches the radio to different channels.
Push-to-Talk (PTT) Button
Press and hold down to talk; release it to listen.
Microphone
Speak clearly into the microphone when sending a
message.
LED Indicator
Provides visual feedback on radio status. The
operation of the indicator depends upon how the
radio has been programmed by your dealer.
Basic Features
LED State/Colour Indication
Radio Call
Continuous Red
Blinking Red
Scan
Blinking Green
Low Battery
Blinking Red when
sending message
Sending message.
Receiving message.
Scanning for activity.
Low battery level.
Optional Transmit Power Level Indicator
LED State/Colour Indication
Power Level
Continuous Red
Continuous Green
Sending message in high power.
Sending message in low power.
Optional Transmit Battery Status Indicator
LED State/Colour Indication
Battery Status
(while pressing PTT)
Blinking Green
Continuous Green
Continuous Orange
Continuous Red
Blinking Red
Battery is fully charged.
Battery is optimally charged.
Battery is half charged.
Low battery level.
Very low battery level.
Programmable Buttons
Your radioÕs two side buttons can be programmed by
your dealer as short-cut buttons for many of the
radioÕs features.
Check with your dealer for a complete list of the
functions your radioÕs programmable buttons
support.
English
4
The table below shows the functions available by
¥
short press
- quickly pressing and releasing
the programmable buttons, or
¥
long press
- pressing and holding the
programmable buttons for a period of time
(programmable by your dealer) before
releasing, or
¥
hold down
- pressing and holding down the
programmable buttons while checking status
or making adjustments.
Depending on how your radio has been
programmed by your dealer, these functions are
activated
press, but
EITHER
NOT
both.
through short press OR long
Button Short Press/Long Press Hold Down
Monitor Ñ
Volume Set Ñ
Scan Starts or stops the Scan operation. Ñ
Nuisance Channel
Delete
Power Level
Repeater/
Talkaround
Squelch
Keypad Lock* Locks or unlocks your radioÕs keypad. Ñ
Phone Makes a Phone Call. Ñ
Speed Dial Accesses the phone numbers in your phone list. Ñ
Light Turns on your radioÕs backlight. Ñ
* Activated by long press only.
Deletes a nuisance channel while scanning. Ñ
Toggles your radioÕs transmit power level between High
and Low settings.
Toggles between using a repeater and transmitting
directly to another radio.
Toggles your radioÕs squelch level between tight and
normal settings.
Monitors the selected channel for
any activity.
Sounds a tone for adjusting the
radioÕs volume level.
RADIO OVERVIEW
Ñ
Ñ
Ñ
5
English
RADIO OVERVIEW
Menu Keys
Exit Up Menu/Select
(<)
Keypad Keys
123
456
789
>
Down
Menu/Select Key
Enters Menu Mode. When already in Menu Mode,
makes Menu selections.
Exit Key
Backs up one level in the Menu hierarchy (short
press); also exits the Menu Mode (long press).
Up Key
Used for scrolling when in Menu Mode. Used as a
backspace key when editing.
Down Key
Used for scrolling when in Menu Mode. Moves the
cursor right or inserts a space when editing.
English
6
*0#
Used to dial a phone number or enter programming
list entries.
When entering information for the programming
lists, each key can generate numeric information.
LCD Screen
Used to display channel, menu as well as other
iconic information.
ABCDEFGHJ
Symbol Name and Description
Symbol Name and Description
A
B
D
G
E
C
Companding Indicator
Indicates that companding is active.
Power Level Indicator
ÒLÓ is lit up when your radio is conÞgured
to transmit in Low Power, while ÒHÓ is lit
up when your radio is conÞgured to
transmit in High Power.
Phone Indicator
Indicates that you are performing a
Phone operation.
Scan Indicator
Indicates that you have activated the
Scan feature.
Priority 1 Scan Indicator ( ßashing )
During Scan, indicates that there is some
activity on a Priority 1 channel.
Monitor Indicator
Indicates that you are monitoring the
selected channel.
F
G
H
J
Talkaround Indicator
When lit, indicates that you are not
transmitting through the repeater. When
not lit, you are transmitting through the
repeater.
Programming Mode Indicator
Indicates that you are editing one of the
Program Lists.
Keypad Lock Indicator
Indicates that your keypad is locked.
Option Board Indicator
Indicates that an option board is
activated.
RADIO OVERVIEW
7
English
RADIO OVERVIEW
INDICATOR TONES
High pitched tone Low pitched tone
Self Test Pass Tone
Self Test Fail Tone
Positive Indicator Tone
Negative Indicator Tone
PROGRAMMABLE BUTTONSÕ AUDIO
INDICATORS
Some programmable keys function as toggles
(alternating between two different choices). These
keys use audio indicators to indicate the change.
Button
Scan
Power
Level
Squelch*
Positive
Indicator Tone
Start
Scan
operation
Radio transmits at
high
power
Radio operates in
tight
squelch
Negative
Indicator Tone
Stop
Scan
operation
Radio transmits at
low
power
Radio operates in
normal
squelch
Button
Repeater/
Talkaround
Keypad
Lock
* There is no visual indicator for the Squelch function.
Positive
Indicator Tone
Radio
DOES NOT
use the repeater
RadioÕs keypad is
locked
.
Negative
Indicator Tone
Radio uses the
repeater
RadioÕs keypad is
unlocked
.
IMPROVED AUDIO FEATURES
Your radio may be programmed by your dealer to
utilise ONE of the following audio enhancement
features.
Low Level Expansion (LLE)
LLE improves voice quality by reducing unwanted
background noise when receiving a message. It is
compatible with most major types of audio
processing systems available today.
Companding
Companding improves voice quality by compressing
your voice at transmission, and expanding it when
receiving. Companding also reduces extraneous
noise. However, to enjoy this beneÞt,
transmitting and receiving radios must have this
feature activated.
ALL
English
8
GETTING STARTED
BATTERY INFORMATION
Battery Care and Tips
This product is powered by a nickel-cadmium (NiCd)
or a nickel-metal-hydride (NiMH) rechargeable
battery.
The following battery tips will help you obtain the
highest performance and longest cycle life from your
Motorola rechargeable battery.
¥ Charge your new battery overnight (
hours
) before using it to obtain maximum
battery capacity and performance.
¥ Charging in non-Motorola equipment may lead
to battery damage and void the battery warranty.
¥ When charging a battery that is attached to the
radio, turn the radio off to ensure a full charge.
¥ The battery should be at about 25¡C (room
temperature) whenever possible. Charging a
cold battery (below 10¡C) may result in leakage
of electrolyte and ultimately, in failure of the
battery.
14-16
¥ Charging a hot battery (above 35¡C) results in
reduced discharge capacity, affecting the
performance of the radio. Motorola rapid-rate
battery chargers contain a temperature-sensing
circuit to ensure that the battery is charged
within these temperature limits.
¥ New batteries can be stored up to two years
without signiÞcant cycle loss. Store new/unused
batteries in a cool dry area.
¥ Batteries which have been in storage should be
charged overnight.
¥ Do not return fully charged batteries to the
charger for an Òextra boostÓ. This action will
signiÞcantly
¥ Do not leave your radio and battery in the
charger when not charging. Continuous charging
will shorten battery life. (Do not use your charger
as a radio stand.)
¥ For optimum battery life and operation use only
Motorola brand chargers. They were designed to
operate as an integrated energy system.
reduce cycle life.
GETTING STARTED
9
English
GETTING STARTED
Recycling or Disposal of
Batteries
NiCd
At the end of its useful life, the NiCd battery
can be recycled. However, recycling facilities may
not be available in all areas.
Motorola endorses and encourages the recycling of
all re-chargeable batteries. Contact your local
Motorola dealer for further information.
Charging your Battery
When the battery level is very low, a blinking red
LED indicator lights up during transmit mode, and
an alert tone sounds. You will need to recharge the
battery before you can continue to use your radio.
Place the radio with the battery attached or the
battery alone in the charger. The chargerÕs LED
indicator will indicate the charging progress.
LED color Status
Single ßash of Green Successful charger power-up.
Flashing Red* Battery is unchargeable.
Flashing Yellow
Red Battery is charging.
Flashing Green
Green Battery is fully charged.
*
Remove the battery from charger and use a pencil eraser to
clean the four metal contacts on the bottom of the battery.
Place the battery back into the charger. If the LED indicator
continues to ßash red, replace the battery.
A standard battery may require one hour to charge to 90%
capacity.
Charger is getting ready to
charge.
Battery is 90% charged.
NOTE:
Since new batteries or batteries that have
not been used for several months could
prematurely indicate full charge (solid green
LED), charge the batteries for 14 to 16 hours
prior to initial use to achieve optimal
performance.
English
10
ACCESSORY INFORMATION
Attaching the Battery
2
1
1.
Fit the extensions at the bottom of the battery
into the slots at the bottom of the radioÕs
body.
2.
Press the top part of the battery toward the
radio until you hear a click.
Removing the Battery
battery latches
2
3
1.
Turn off the radio, if it is turned on.
2.
Slide the battery latches on both sides of the
battery downwards.
3.
Pull the top part of the battery away from the
radio body.
GETTING STARTED
11
English
GETTING STARTED
Attaching the Antenna Removing the Antenna
Turn the antenna clockwise to attach it.
English
12
Turn the antenna counter-clockwise to remove it.
Attaching the Belt Clip Removing the Belt Clip
belt clip tab
1
2
1.
Align the grooves of the belt clip with those of
the battery.
2.
Press the belt clip downward until you hear a
click.
1.
Use a key to press the belt clip tab away
from the battery.
2.
Slide the belt clip upward to remove it.
GETTING STARTED
13
English
GETTING STARTED
TURNING THE RADIO ON OR OFF ADJUSTING THE RADIOÕS VOLUME
If one of the radio side buttons has been
programmed as a Volume Set button by your
dealer, it may be used as follows:
1.
Press and hold the preprogrammed
Set
button; you will hear a continuous tone.
2.
ON OFF
1.
Turn the
wise to turn on the radio. You will hear the
Self Test Pass Tone ( ) and see a
green LED if the radio powers up successfully. If the radio fails its self test, you will hear
the Self Test Fail Tone ( ). Switch
off and on again and if fault persists contact
your dealer.
2.
To turn off the radio, turn the
Control
hear a click.
On-Off/Volume Control
On-Off/Volume
knob counter-clockwise, until you
knob clock-
Turn the
adjust the volume level.
3.
Release the preprogrammed
button.
SELECTING A RADIO CHANNEL
Your radio offers 16 channels for easy access to
required conventional channels. Some channels on
your radio may not be programmed. Check with your
dealer for more information.
Turn the
counter-clockwise until you reach the desired
channel.
On-Off/Volume Control
Channel Selector
knob and
Volume Set
knob clockwise or
Volume
English
14
SENDING A CALL
1.
Turn your radio on.
2.
Use the
desired channel.
3.
Hold the radio in a vertical position, press the
PTT
2.5 to 5 cm (one to two inches) from the
microphone.
4.
Release the
Channel Selector
button, and talk at a distance of about
PTT button to listen.
knob to select the
RECEIVING A CALL
1. Turn your radio on.
2. Adjust the radioÕs volume.
3. Switch to the desired channel.
4. If at any time a call comes through, you will
hear the call at the volume level you have set.
GETTING STARTED
15
English
RADIO CALL INFORMATION
RADIO CALL
REPEATER OR TALKAROUND MODE
Talkaround Mode enables you to communicate with
another radio when either:
¥ the repeater is not operating
¥ your radio is out of the repeaterÕs range but
NOTE: The F symbol will appear on the LCD
screen when Talkaround Mode is selected.
To select either Repeater Mode or Talkaround
Mode:
Press the Repeater/Talkaround button (only
available if programmed by your dealer) to toggle
between the two modes. A positive indicator tone
indicates that the radio is in talkaround mode, while
a negative indicator tone indicates that the radio is
in repeater mode.
1.
2.
ÑorÑ
within communicating distance of another
radio.
ÑorÑ
) to enter Menu Mode.
< or > until
TLK ARD
3.
) to select
4.
< or > until
(talk through repeater),
TLK ARD
OFF
or until
(talk directly without going
through repeater).
5.
) to select the desired option.
ON
SETTING TIGHT OR NORMAL SQUELCH
Use this feature to Þlter out nuisance (unwanted)
calls and/or background noise. However, tightening
squelch could cause calls from remote locations to
be Þltered out as well. In this case, normal squelch
may be more desirable.To select tight or normal
squelch:
Press the Squelch button (only available if
programmed by your dealer) to toggle between tight
and normal squelch. A positive indicator tone
indicates that the radio is operating in tight squelch,
while a negative indicator tone indicates that the
radio is operating in normal squelch.
English
16
ÑorÑ
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
5.
) to select
6.
< or > until
(tighten channelÕs squelch),
UTILITY
UTILITY
SQUELCH
SQUELCH
TIGHT
or until
(channel operates under normal squelch).
7.
) to select the squelch setting.
NORMAL
SETTING THE POWER LEVEL
Your radio has a predeÞned transmit power level that
can be changed.
¥ High power (H icon) allows the radio to
transmit over greater distances.
¥ Low power (L icon) conserves the batteryÕs
charge.
To set the power level:
Press the Power Level button (only available if
programmed by your dealer) to toggle between low
and high transmit power level. A positive indicator
tone indicates that the radio is in high power mode,
while a negative indicator tone indicates that the
radio is in low power mode.
ÑorÑ
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
5.
) to select
6.
< or > until
(to transmit at high power),
or until
(to transmit at low power).
7.
) to select the power level.
UTILITY
UTILITY
TX PWR
TX PWR
HIGH
LOW
RADIO CALL
17
English
SCAN
SCAN
You can monitor several channels in order to receive
any call that is transmitted on any of these channels.
Sixteen different channels can be programmed into
each scan list by the dealer.
Once the radioÕs scan operation is activated and the
radio detects a call coming through a channel in its
scan list, it switches to that channel for you to
receive the call.
STARTING OR STOPPING A SCAN
OPERATION
The E symbol, and the channel you are
transmitting on, will appear on the LCD screen when
you start a scan operation.
The LED indicator blinks green during a scan
operation.
NOTE: If you enter Menu Mode while the radio is
scanning, scanning will stop. It will resume when
you exit Menu Mode.
To start or stop a scan operation:
1. Press the Scan button (only available if
programmed by your dealer) to start a scan
operation. You will hear a positive indicator
tone.
2. Press the preprogrammed Scan button again
to stop the scan operation. You will hear a
negative indicator tone.
ÑorÑ
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
(to start a scan operation),
or until
(to stop a scan operation).
5.
) to select the desired option.
NOTE: The LED indicator will blink (green) during a
scan operation.
SCAN
SCAN
ON
OFF
English
18
TALKBACK
If the programmable Talkback option is set, you can
respond to any calls received during the scan
operation by pressing the PTT before the
programmed hang-time ends. Check with your
dealer for details.
DELETING A NUISANCE CHANNEL
If a channel continually generates unwanted calls or
noise (a ÒnuisanceÓ Channel), you can temporarily
remove it from the scan list by performing a
Nuisance Channel Delete operation.
1. While the radio is on the Nuisance Channel,
press the Nuisance Channel Delete button
(only available if programmed by your dealer)
until you hear a tone.
2. Release the Nuisance Channel Delete
button. The nuisance channel is deleted.
NOTE: You cannot perform a Nuisance Channel
Delete on a priority channel or if there is only
one remaining channel in the scan list.
ADDING A DELETED NUISANCE CHANNEL
BACK TO THE SCAN LIST
1. Press the Scan button to stop the scan
operation.
2. Press the Scan button again to re-start the
scan operation. The Deleted Nuisance
Channel is reinstated to the scan list.
PRIORITIZATION OF A SCAN LIST
MEMBER
You may want your radio to check a particular
channel more frequently for calls. Prioritization of
scan list members is done by your dealer using the
Customer Programming Software. Check with your
dealer for details.
Priority Channel Scanning Sequence
➠Ch2➠Ch3➠
None speciÞed
Channel 2
Even though your radio has switched to a nonpriority channel, your radio will still check for activity
on the priority channel. If activity is detected the
radio will switch to the priority channel.
Ch1
Ch4➠...Ch1
Ch2
➠Ch1➠Ch2➠Ch3➠
Ch2➠Ch4➠Ch2➠...Ch1
SCAN
19
English
PHONE
PHONE
You can use your radio to connect to a phone line to
make a phone call.
To do this, your radio must send an access code to a
station that connects it to a phone line. After you
have Þnished your call, the radio has to send a
deaccess code to shutdown the connection to the
phone line.
MAKING A PHONE CALL
You can make a phone call by using the menu or by
using the programmed Phone button (if Phone
operation is permitted on the current channel). The
D icon will light up on the LCD screen when you
are in Phone mode.
A complete phone session consists of
¥ entering the Phone mode
¥ sending the access code
¥ sending the phone number
¥ having the phone conversation
¥ ending the phone call.
Entering the Phone Mode
Before you can make a phone call, you must enter
the radioÕs Phone mode.
1. Press the Phone button.
To enter the Phone mode via the menu:
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
You will see the last phone
number dialled; for example
PHONE
PHONE
5554567
Sending the Access Code
Your radio can be programmed to send the access
code in any of the following ways:
¥ manual
¥ automatic delayed
¥ automatic immediate.
Check with your dealer for more details.
Method Steps to Take
Manual Dial the access code from the keypad.
Automatic
Delayed
Automatic
Immediate
Press and release the PTT; the radio
automatically sends the
preprogrammed access code.
You do not have to do anything; the
radio immediately sends the access
code when it enters phone mode.
English
20
Sending the Phone Number
After the access code is sent, you should wait for a
dialling tone before sending your phone number.
You can send
¥ a phone number that is stored in the radio, or
¥ a new number.
Additionally, depending on how your radio is
programmed, if you use the keypad to send a
number, the radio can send the numbers in one of
the following ways:
¥ live dial
¥ buffered dial.
Check with your dealer for details.
Sending a Stored Phone Number
You can access the stored phone numbers by
¥ recalling the last number dialled,
¥ using the phone list, or
¥ using the speed dial feature.
Method Steps to Take
Last
Number
Redial
Press and release the PTT; the radio sends
the last number dialled.
*
Method Steps to Take
1. Press < or > to scroll the phone list
Phone
List
Speed
Dial
*
The method described is not applicable for radios which
manually send the access code; these radios can access this
number from the phone list or the speed dial.
For radios that manually send the access code, press the
Down Key once to access the last number dialled.
until you reach the desired phone
number.
2. Press and release the PTT to send the
number.
1. Press and release the programmed Speed
Dial button.
2. Press the numbered keys (1-9)
corresponding to the Þrst nine phone
numbers in the phone list. Press Ò0Ó if you
want the last number dialled.
3. If your radio uses buffered dial, press and
release the PTT.
4. The radio sends out the phone number.
PHONE
21
English
PHONE
Sending a New Number
You enter the phone number by pressing the
relevant keys on the keypad.
Method Steps to Take
Enter the phone number by using the
Live Dial
Buffered
Dial
keypad; the radio sends out the numbers
as the keys are pressed.
1. Enter the phone number by using
the keypad; the radio saves the
selected numbers in a buffer.
2. Press and release the PTT; the
radio sends out the numbers in its
buffer.
The Phone Conversation
Once the radio has connected to the intended party,
you can begin the conversation. Even though this is
a phone call, your conversation mimics a radio call
(that is, both parties speak in turn).
1. Press and hold the PTT, while talking into the
microphone.
2. Release the PTT when you Þnish what you
want to say, and wait for the response.
3. Repeat steps 1 and 2 until the conversation
ends.
Ending the Phone Call
Just as the radio needs to send the access code
when starting a phone call, the radio needs to send
the deaccess code to end the phone call.
The radio can send the deaccess code in any of the
following ways:
¥ manual, and
¥ automatic.
Check with your dealer for details.
1. If your radio sends the deaccess code man-
ually, dial the deaccess code from the keypad.
2. Press the Phone button to exit phone mode.
NOTE: Radios using the automatic method
will send the deaccess code
automatically.
or
Exit the phone mode using the menu:
( to exit phone mode and
return to
or
Hold ( to exit the Menu Mode.
NOTE: Radios using the automatic method
will send the deaccess code
automatically.
PHONE
English
22
PHONE LIST
Your radio can store a list of frequently accessed
phone numbers. The G icon will light up on the
LCD screen when you edit the phone list.
NOTE: The radio will not receive any calls when
you are editing the phone list.
Adding an Entry to the Phone List
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
5.
) to select
6.
< or > until
7.
) to select
PROGRAM
PROGRAM
PHONE
PHONE
ADD
ADD
8. Use the keypad to enter the phone number.
Press the numeric keys to enter the numbers.
You can also add a dash (press
Pause Indicator (press and hold
until the
changes to a Ò
) to store the phone number.
9.
# character on the LCD screen
PÓ).
>) and a
# the key
) again to conÞrm its storage.
10. ( to return to
or
Hold
(
to exit Menu Mode.
ADD
Deleting an Entry
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
PROGRAM
PROGRAM
PHONE
PHONE
You will see
NUMBER
5.
) to select
23
PHONE
English
6.
< or > until
DELETE
6.
< or > until
EDIT
PHONE
7.
) to select
8.
< or > until you see the entry you
wish to delete.
9. ) to select the entry.
) again to conÞrm the deletion.
( to return to
10.
or
Hold
(
to exit Menu Mode.
Editing an Entry
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
4.
< or > until
5.
) to select
DELETE
DELETE
PROGRAM
PROGRAM
PHONE
PHONE
7.
) to select
8.
< or > until you see the entry you
wish to edit.
9. ) to select the entry.
or until
(to edit the entryÕs phone
number),
or until
(to edit the entryÕs location in
the phone list).
11. ) to select the edit type.
12. Use the keypad to edit the entry. See Key-
pad Keys on page 6.
) to store the information.
13.
14. ( to return to
or
Hold
(
to exit Menu Mode.
EDIT
NUMBER
LOCATN
EDIT
English
24
AUDIO/TONES SETTINGS
The Audio/Tones menu allows you to customize the
audio and tone settings on your radio.
GENERAL INSTRUCTIONS
1.
) to enter Menu Mode.
2.
< or > until
3.
) to select
Menu Items Optional Settings Function
ALERT
KEYPAD
ON
OFF
ON
OFF
TONES
TONES
Allows you to turn all tones on or off.
Allows you to turn the tones associated with the radio keys on or off.
4.
< or > until you see the audio/tone
setting you wish to change.
5.
) to select the tones setting. You will see
the current status of the setting.
6.
< or > to see the available optional
settings.
7.
) to select the desired setting.
Use instructions above to change your radioÕs audio
and tones settings shown in the table below.
AUDIO/TONES
25
English
UTILITIES
UTILITIES
The Utilities menu allows you to customize some
general settings on your radio.
GENERAL INSTRUCTIONS
1.
2.
3.
SQUELCH
TX PWR
LIGHT
SOFTWAR Allows you to identify the version number of the software within the radio.
4.
< or > until you see the setting that
you wish to change.
5.
) to select the setting to change. You will
see the current status of the setting.
6.
< or > to see the available optional
) to enter Menu Mode.
< or > until
) to select
Menu Items Optional Settings Function
NORMAL
TIGHT
HIGH
LOW
ON
OFF
UTILITY
UTILITY
Allows you to change the squelch setting of the radio between normal
and tight.
Allows you to change the power level of the radio between high or low.
Allows you to turn the back-light feature of the radio on or off.
settings.
7.
) to select the desired setting.
Use the instructions above to change your radio
settings shown in the table below.
English
26
SAFETY INFORMATION
Safe and EfÞcient Operation of Motorola
Two-Way Radios
This section provides information and instructions for
the safe and efÞcient operation of Motorola Portable
and Mobile Two-Way Radios.
For information regarding radio use in hazardous
areas, please refer to the Factory Mutual (FM)
approval manual supplement or Instruction Card
which is included with radio models that offer this
capability.
Exposure To Radio Frequency Energy
National and International Standards and
Guidelines
Your Motorola Two-Way Radio, which generates and
radiates radio frequency (RF) electromagnetic energy
(EME) is designed to comply with the following National
and International Standards and Guidelines regarding
exposure of human beings to radio frequency
electromagnetic energy:
¥ Federal Communications Commission Report and
Order No. FCC 96-326 (August 1996)
¥ American National Standards Institute
(C95.1 - 1992)
¥ National Council on Radiation Protection and
Measurements (NCRP - 1986)
¥ International Commission on Non-Ionizing Radi-
ation Protection (ICNRP - 1986)
¥ European Committee for Electrotechnical
Standardisation (CENELEC):
¥ ENV. 50166-1
1995 E
¥ ENV. 50166-2
1995 E
¥ Proceedings of
SC211/8 1996
To assure optimal radio performance and that
human exposure to radio frequency electromagnetic
energy is within the guidelines set forth in the above
standards, always adhere to the following
procedures:
Human Exposure to Electromagnetic Fields Low Frequency (0Hz to 10kHz)
Human Exposure to Electromagnetic Fields High Frequency (10kHz to 300GHz)
Safety Considerations for
Human Exposure to E.M.F.s
from Mobile Telecommunications Equipment (M.T.E.) in
the Frequency Range
30MHz - 6 GHz (E.M.F. Electromagnetic Fields)
SAFETY
27
English
SAFETY
A
Portable Radio Operation and
EME Exposure
When transmitting with a portable
radio, hold the radio in a vertical
position with its microphone 2.5 to 5
centimeters (1 to 2 inches) away from your mouth.
Keep antenna at least 2.5 centimeters (1 inch) from
your head and body.
If you wear a portable two-way radio on your body,
ensure that the antenna is at least 2.5 centimeters
(1 inch) from your body when transmitting.
MAN WITH R
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible
To avoid electromagnetic interference and/or
compatibility conßicts, turn off your radio in any
facility where posted notices instruct you to do so.
Hospitals or health care facilities may be using
equipment that is sensitive to external RF energy.
When instructed to do so, turn off your radio when
on board an aircraft. Any use of a radio must be in
accordance with airline regulations or crew
instructions.
to electromagnetic interference (EMI) if
inadequately shielded, designed or otherwise conÞgured for electromagnetic compatibility.
Operational Warnings
!
!
Vehicles With an Air Bag
Do not place a portable radio in the area over an air
bag or in the air bag deployment area. Air bags
inßate with great force. If a portable radio is placed
in the air bag deployment area and the air bag
inßates, the radio may be propelled with great force
and cause serious injury to occupants of the vehicle.
W A R N I N G
Potentially Explosive Atmospheres
Turn off your two-way radio when you are in any
area with a potentially explosive
atmosphere, unless it is a radio type especially
qualiÞed for use in such areas (for example, Factory
Mutual). Sparks in a potentially explosive
atmosphere can cause an explosion or Þre resulting
in bodily injury or even death.
Batteries
Do not replace or recharge batteries in a potentially
explosive atmosphere. Contact sparking may occur
while installing or removing batteries and cause an
explosion.
English
28
Blasting Caps and Areas
Batteries
To avoid possible interference with blasting
operations, turn off your radio when you are near
electrical blasting caps, in a blasting area, or in
areas posted: ÒTurn off two-way radio.Ó Obey all
signs and instructions.
Note:
The areas with potentially explosive atmospheres
referred to above include fueling areas such as:
below decks on boats; fuel or chemical transfer or
storage facilities; areas where the air contains
chemicals or particles, such as grain, dust or metal
powders; and any other area where you would
normally be advised to turn off your vehicle engine.
Areas with potentially explosive atmospheres are
often but not always posted.
Operational Cautions
!
Damaged Antennas
Do not use any portable two-way radio that has a
damaged antenna. If a damaged antenna comes
into contact with your skin, a minor burn can result.
C a u t i o n
All batteries can cause property damage and/or
bodily injury such as burns if a conductive material
such as jewellery, keys, or beaded chains touch
exposed terminals. The conductive material may
complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any
charged battery, particularly when placing it inside a
pocket, purse, or other container with metal objects.
General Radio Care
¥ The use of chemicals such as
detergents, alcohol, aerosol
sprays, and/or petroleum
products may be harmful to and damage the
radio housing.
¥ Avoid physical abuse of the radio such as
carrying it by the antenna.
¥ The accessory connector (if Þtted) has a
protective cap which should be left in place when
the connector is not in use.
¥ Clean the radio exterior using a cloth moistened
with clean water and a mild dishwashing liquid.
¥ The use of non-approved radio accessories may
damage the radio and invalidate warranty.
!
C a u t i o n
SAFETY
29
English
NOTES
NOTES
English
30
Loading...
