Page 1
DATA SHEET
7347-84
Netopia® VDSL2 Four-Port Wi-Fi Gateway
Designed for delivery of triple play services over ultra-broadband networks.
Product Overview
The Motorola Netopia 7347-84 uses technology
designed to handle demanding services like IPTV
and other triple play service such as VoIP, standard TV
and high definition TV (HDTV).
This full featured gateway integrates a highperformance network processor and DMT-based
VDSL2 modem. Ideal for FTTN applications, the
7347-84 gateway supports high-bandwidth VDSL2
over a single copper pair in the ‘first mile’ from the
subscriber’s home to the fiber node.
The 7347-84 gateway offers comprehensive
remote manageability, including centralized remote
provisioning, troubleshooting, and management as
well as the ability to manage devices connected to
the gateway through support for Broadband Forum
TR-069/TR-098, TR-111, and TR-104 specifications.
User Friendly Installation
The gateway’s friendly installation and ease of use
is ideal for consumers who want a gateway that
is simple to setup and protects their PC and other
networked devices from security threats. Motorola
gateways are supplied with an easy-to-use Motorola
installation wizard – an auto provisioning tool – which
seamlessly configures the gateway and provides
helpful tools and documentation for the user.
Service Assurance
The 7347-84 gateway with its advanced features
help service providers monetize broadband networks
while improving efficiency and reducing costs.
By combining the highest-performing and lowest
cost of ownership gateways in the industry,
with comprehensive remote management, highavailability, high-reliability, advanced security, easyto-use installation tools, Motorola is offering an all-inone approach to broadband home networking.
Motorola CPEs are configured to be remotely
manageable via industry standard TR-069, which
allows the CPE to be interoperable with any ACS
solution that follows the Broadband Forum’s TR-069/
TR-098 specification.
Motorola gateways include advanced security
features such as stateful packet inspection firewall
protection, Virtual DMZ, and Denial of Service (DoS)
protection. Motorola’s embedded firmware enables
deployments with high levels of quality, reliability,
and customer satisfaction, with low operational and
support costs for the service provider.
Page 2
DATA SHEET
COMPLIANT
7347-84
®
Netopia
VDSL2 Four-Port Wi-Fi Gateway
In addition to delivering highquality gateways to its customers,
Motorola is also committed to
helping its customers reduce
their environmental footprint. We
approach this in several ways:
improving the environmental
profile of our products, running
our operations in a safe and
energy-efficient manner and
helping our customers to be
greener when they use our
products.
Motorola’s Netopia gateways
help service providers lower
their energy consumption,
thereby helping them reduce
their carbon footprint. Motorola
has a global commitment to be
part of the solution to climate
change, and has worked for
years to continually improve our
environmental profile. We are in
step with our customers and their
increasing interest in partnering
with a company that helps them
reduce their environmental
impact, while offering compelling
products to help them grow their
eco-conscious customer base.
Motorola is working to make
products with a reduced
environmental impact. In
the development of our
next-generation Netopia
gateways, we have focused
on energy efficiency, lead-free
manufacturing, and packaging
/ recycling enhancements.
Depending on models and
market, our units are ENERGY
STAR qualified and compliant
with European Code of Conduct
regulations. In addition, the
devices and power supplies are
lead-free and RoHS compliant.
Finally, all new Netopia gateways
use environmentally friendly
package designs. They are
available in single bulk pack
boxes that eliminate the use of
suspension plastic and reduce box
size, thereby reducing waste and
transport costs. Motorola’s cable
modem and gateway packaging
is 100% recyclable and is marked
with standard recycling codes to
make it easier for our customers
to identify recycling opportunities.
INTERFACES
WAN
VDSL2, RJ-48
LAN
802.11b/g Wi-Fi
Four-Port 10/100 Ethernet Switch, RJ-45
EMBEDDED FIRMWARE
Encoding and Access Protocols
VDSL2 Support
ITU-T G.993.2 POTS, ISDN
Profile 8a, 8b, 8c, 8d, 12a, 12b, 17a
U0 Band (25kHz to 276kHz)
Packet Transfer Mode (PTM-EFM)
DHCP Client or 802.1x Supplicant Authentication
IP Addressing and Routing
IPv4 (IPv6 Capable)
DHCP Server/Relay
DNS Proxy, Dynamic DNS Support
Multiple Subnet Support
RIP1 & RIP2 and Static Routes
Traffic Management & QoS (Quality of Service)
Network Address Port Translation (NAPT)
Application Level Gateway (ALG) Support
IP Maps (Pinholes)
Diffserv QoS with Weighted Fair Queuing
IGMPv2, IGMPv3 with Fast Leave
IEEE 802.1P/Q VLANs
TR-101 Support
Security
Stateful Packet Inspection Firewall
Virtual DMZ/IP Pass-through
Denial of Service (DoS) Protection
VPN Pass-through (PPTP, L2TP, IPSec)
Device Management
Two-Level Password Protected Access
Statistics and Log Reporting
Remote Management
TR-069/TR-098, TR-104, TR-111, WebUI,CLI (Telnet), 802.1ag,
802.3ah
Local Management
TR-064, UPnP, WebUI, CLI (Telnet), Captive Portal
Utilities
Ping, Traceroute, Reverse DNS, NTP, Diagnostics
Localization
English
Optional: French, German, Italian, Portuguese (Brazil),
Spanish (Latin America)
INSTALLATION WIZARD
PC
Windows 2000, XP SP2, Vista, and 7
Macintosh
OSX
All features, functionality and other product specifications are subject to change
without notice or obligation.
WI-FI
3-D Reach Extreme Wi-Fi
IEEE 802.11b/g
100mW (20dBm transmit power on all channels)
Wi-Fi Characteristics
1x2 Integrated Omni-directional antennas with Diversity
Wi-Fi Features
Multiple BSSID (unique authentication per SSID)
Wi-Fi Multimedia (WMM), WMM-PS (power save)
Transmit Power Control
Wi-Fi Scheduler
Wi-Fi Security
WEP (64-bit, 128-bit, 256-bit) encryption
802.1x, WPA, WPA-PSK, 802.11i/WPA2, WPA2-PSK
EAP-TLS, EAP-TTLS, EAP-SIM
Block Wi-Fi Bridging
MAC Address Filtering
REGULATORY COMPLIANCE
Americas
UL 60950, CUL, CSA
FCC Part 15 Class B, ICES-003
FCC Part 68, CS-03
CEC Compliant, Energy Star
EMEA
EN 60950
EN 300 328, EN 301 489
RoHS Compliant
Code of Conduct (CoC) 2008 Compliant
K.21
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
20% to 80% (Non Condensing) Relative Humidity
Storage Temperature
0 °C to 70 °C (32 °F to 158 °F)
Power Consumption
Max 1.1A at 12VDC
PHYSICAL SPECIFICATION
Dimensions
2 in H x 8.3 in L x 6.8 in W
(5 cm x 21 cm x 17.2 cm)
Weight
2.5 lbs (1134g) (unit carton)
Placement
Horizontal desktop or Vertical wall mount placement
ORDERING INFORMATION
North America
AnnexA, POTS 7347-84-10NA
EMEA
AnnexA, POTS 7347-84-20EU,
AnnexB, ISDN 7357-84-20EU
