Motorola MOTOSTART H500 User Manual

Start Here > > >

H500

Bluetooth®

Handsfree Headset

Get Connected in

4 Quick Steps

1 - CHARGE
2 - START
BLUETOOTH
FEATURE
3 - PAIR
4 - TEST AND USE

BEFORE YOU

BEGIN

Before using this product, read the Important Safety and
Legal Information pamphlet and follow its instructions.

Take a moment before you get started to
familiarize yourself with your new
H500 Handsfree Headset.

Earhook

Microphone

Volume
Buttons

Call Button

Blue

Indicator

Light

CHARGE

1

Charge your headset's battery for 2 hours:

Plug the Motorola charger into the end of

1

the headset.

The blue indicator light turns on when the
battery is charging. It may take up to 1
minute for the light to turn on. When the
headset's battery is fully charged (about 2
hours), the blue indicator light turns off.

Unplug the charger from the headset.

2

Note: Headset is not functional while charging.

Your Headset's Battery

2

START BLUETOOTH

Feature

On Your Phone

Your phone's Bluetooth feature is off by
default. To use your headset, turn on the
Bluetooth feature in your phone.

For most Motorola phones:

M

Select (

1

Bluetooth Link > Setup.

Scroll to Power.

2

3

Press Change.

Scroll to On.

4

Press Select to turn on the Bluetooth

5

feature. Bluetooth feature remains on until
you turn it off.

Note: These steps are for most Motorola phones. For
other phones, see your phone's user's guide.

Menu) > Settings > Connection >

TROUBLESHOOTING

My phone does not find my headset.

Make sure the blue light on your headset is
steadily lit when your phone is searching for
devices (see step 3).

My headset worked before but now it's
not working.

Make sure your phone is on and the
Bluetooth feature is turned on in your phone
(see step 2). If the Bluetooth feature has
been turned off or was turned on only
temporarily, you may need to restart the
Bluetooth feature (see step 2). If you have
confirmed the Bluetooth feature is on in your
phone, pair your phone and headset again

(see step 3).

Support.
If you need more help, contact us at
1-877-MOTOBLU or visit us at
www.hellomoto.com/bluetooth and click

Support.

Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196

www.hellomoto.com
1-877-MOTOBLU
1-888-390-6456 (TTY/TDD United States for
hearing impaired)

Guide Number: 6809494A56-C

MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. The use of wireless devices and their
accessories may be prohibited or restricted in certain areas.
Always obey the laws and regulations on the use of these
products. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. All other
product or service names are the property of their respective
owners.

© Motorola, Inc. 2006.

PAIR

3

Step A - PUT HEADSET IN PAIRING MODE

Before you can use your headset, you must
pair (link) it with your phone.

With the headset power off, press and hold

1

the Call button for 6 to 10 seconds until the
blue indicator light turns on and remains
steadily lit. (The light will flash while you
hold the Call button.)

If the indicator light is flashing or does not

2

remain steadily lit, turn off the headset and
repeat step 1.

Note: To turn off headset, see "Turning On and Off" on the
reverse side of this guide.

Your Headset

Call Button

Blue Indicator Light

PAIR

Your Phone

Step B - SET THE PHONE TO LOOK FOR
YOUR HEADSET

For most Motorola phones:

Select (

1

Menu) > Settings > Connection >

M

Bluetooth Link > Handsfree > Look for Devices.

The phone lists all Bluetooth devices it finds.
Select Motorola H500.

2

Press OK or Yes to pair (link) the handsfree

3

device.
Enter the passkey 0000 and press OK.

4

Note: Passkey cannot be changed
from 0000.

When your headset is successfully paired with
your phone, the blue indicator light changes
from steadily lit to flashing.

Note: These steps are for most Motorola phones. For other
phones, see your phone's user's guide.

4

TEST AND USE

Your phone and headset are now paired and
ready to make and receive calls. To confirm
they are operating properly, make a call:

Place the headset over your ear. See

1

"Wearing the Headset" on the reverse side
of this guide.

On your phone, dial the number you want

2

to call and press the Send key.

If your phone and headset are successfully

3

paired, you will hear ringing on the headset.

After you have successfully paired your phone
and headset, you do not need to repeat these
initial setup steps each time you use the
headset.

USING YOUR H500

See Features and Functions Guide

on the reverse side

of this guide

for information on

using your H500.

Features and

Functions Guide

H500

Bluetooth®

Handsfree Headset

IMPORTANT:

Be sure to first follow the

Quick Start Guide

on the reverse side

of this guide

to complete initial setup

of your H500.

TURNING HEADSET

ON/OFF

To turn your headset on, press and hold the

Call button until the indicator light flashes.
Then, release the button.

Note: Headset may take up to 4 to 5 seconds to turn on.

To turn your headset off, press and hold
the Call button until the indicator light flashes
rapidly and then turns off.

Call

Button

WEARING THE

HEADSET

Open the earhook.

1

Loop the earhook over your ear.

2

Press the headset to your ear.

3

3

4

CHANGING FOR USE

ON OTHER EAR

You can wear your H500 headset on your left or
right ear. The headset comes ready for the right
ear. To change the headset for the left ear:

Open the earhook 90

1

degrees from the
headset.

Gently lift and pull the

2

top of the earhook up
and off the upper hinge
pin. Then, pull it away to
remove it.

Flip the headset over.

3

Hook the bottom of the

4

earhook onto the lower
hinge pin, then lift and pull
the top of the earhook over
the upper hinge pin.

040059o

1 Open Earhook

2 Pull Earhook Up

Hinge Pin

CHANGING VOLUME

BUTTON ORIENTATION

If you change your headset to wear on the
other ear, you can also change the
orientation of the volume buttons.

Turn the headset power off.

1

Press the Call button and the volume

2

button you want to assign as the
"volume up" button until the indicator
light flashes twice.

The headset power turns on.

Volume Buttons

Call Button

European Union Directives

Conformance Statement

Hereby, Motorola declares that this
product is in compliance with:

• The essential requirements and
other relevant provisions of Directive
1999/5/EC.

• All other relevant EU Directives.

0168

The above gives an example of a typical Product
Approval Number.

You can view your product’s Declaration of Conformity
(DoC) to Directive 1999/5/EC (to R&TTE Directive) at
www.motorola.com/rtte. To find your DoC, enter the
product Approval Number from your product’s label in
the “Search” bar on the web site.

Product

Approval

Number

MAKING CALLS

Function Action

Make a voice dial call Tap the Call button

and speak the
name after the tone

End a call Tap the Call button

Receive a call Tap the Call button

Reject a call Press and hold the

Call button until you
hear a beep

Redial last call Press and hold the

Call button until you
hear a beep

Answer a second Press and hold the
incoming call Call button (places

first call on hold)

Note: Your H500 supports both Handsfree and Headset
Profiles. Accessing call functions depends upon which
profile your phone supports. See your phone's user's guide
for more information.

MAKING CALLS

Function Action

Toggle between two Press and hold
active calls the Call button

Join a 3-way call Press and hold
both Volume buttons

Put an active call on Press and hold the
hold or resume a call Call button until you
on hold hear a beep

Disable or enable the Press and hold
indicator light both Volume
buttons for 3 to 4
seconds

Mute or unmute a call Tap both Volume
buttons

Note: Some features are phone/network dependent.

CONTINUED

INDICATOR LIGHTS

The indicator light provides information about
your headset status.

With the Charger Plugged In

Headset Indicator Headset Status

On (steady) Charging
Off Charging complete

With No Charger Plugged In

Headset Indicator Headset Status

Off Power off
On (steady) Pairing mode
10 rapid flashes Pairing successful
Slow pulse Connected

(on a call)

Quick flash Standby

(not on call)

Note: After 5 minutes of inactivity, the light stops flashing to
conserve power, but the headset remains in standby mode.

AUDIO TONES

The audio tones provide information about your
headset status.

Audio Tone Headset Status

Single high tone when Volume at minimum
pressing volume button or maximum

Five rapid high tones Low battery
repeated every 60 sec.

No audio indications; Out of range
deteriorating quality

Ring tone Incoming call
Single high tone Pairing confirmation
Single low tone Voice activation
Dual high/low tone Voice tag not

recognized
Single high tone End call
Low to high tone Phone network

not available
Two ascending tones Mute enabled
Two descending tones Mute disabled
