Motorola Mike i877 User Manual

Download

TELUS

i877 Mike Phone

DECLARATION OF CONFORMITY

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party Name: Motorola, Inc.

harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio

HELLOMOTO

Introducing your new Mike i877 wireless phone. Here’s a quick anatomy lesson.

Left Soft Key

Right Soft Key

check it out

Home Screen

Main Menu

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com

1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada)

Product Support:

www.motorola.com/iden

functionality of such features may be limited in certain devices, or by certain wireless carriers. Contact your wireless carrier about feature availability and functionality.

OPEN SOURCE SOFTWARE INFORMATION You may choose to obtain a copy of any source code being made

publicly available by Motorola directly from the Motorola website opensource.motorola.com.

Additionally, for instructions on how to obtain a copy of any source code being made publicly available by Motorola related to

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Java and all other Javabased marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

contents

check it out . . . . . . . . . . . 2

menu map. . . . . . . . . . . . 7

Use and Care . . . . . . . . . 9

call a stored phone number or private ID . 22 find your phone number

and Private ID . . . . . . . 23

PT manager . . . . . . . . 55

MMS . . . . . . . . . . . . . 55

Mike’s wireless web

services . . . . . . . . . . . 72

features for the

hearing impaired . . . . . 88

features for the

vision impaired . . . . . . 90

customize. . . . . . . . . . . . 92

volume. . . . . . . . . . . . . 92

ring tones . . . . . . . . . . 92

net alerts . . . . . . . . . . 102

other features . . . . . . . 103

advanced calling . . . . 103

alarm clock. . . . . . . . . 104

contacts. . . . . . . . . . . 105

datebook . . . . . . . . . . 106

GPS . . . . . . . . . . . . . . 107

Motorola Limited Warranty for the United States

and Canada . . . . . . . . . 124

Hearing Aid

Compatibility . . . . . . . . 129

Information From the World Health

menu map

main menu

Multimedia

• Shop

• Media Center

• Camera

• Audio Player (Music Player)

• Ring Tones

Games and Apps

• Alarm Clock Plus

• Music Player

•PhotoEditor

•iHelp

• Calculator Suite

• Bluetooth

• Audio Devices

• Pair to Devices

• Device History

• Setup

• Find Me

•GPS

settings menu

Display/Info

• Wallpaper

• Internal

• External

•Text Size

• Theme

•Mike

•Ruby

•Onyx

• High Contrast

• Home Icons

• Backlight

Phone Calls

• Set Line

•Any Key Ans

• Auto Redial

• Call Waiting

• Auto Ans

• Flip Activation

• Minute Beep

• Call Duration

•TTY

• Hearing Aid

• Notifications

Voice Playback

• Speak Text

• Speak Caller

•Voice

• Multimedia Volume

Memory Card

• Remove Card

• Store Media

• Format Card

•Help

Security

Use and Care

To care for your Motorola phone, please keep it away from:

liquids of any kind dust and dirt

essentials

Caution:

Before using the phone for the first time, read the Important Safety and Legal Information located in the gray-edged pages at the back of this guide.

Press the navigation key to scroll to

Phone Calls

, and press the center key r to

select it.

activate your Mike account

Before you can begin using your handset, you need to activate your Subscriber Identity Module (SIM) card on The Mike Network. Your SIM card holds the information required

SIM card

insert the SIM card

Turn off your phone and remove your battery before you install or remove a SIM card.

Carefully slide the SIM card into your

Warning:

To avoid loss or damage, do not remove your SIM card from your phone unless absolutely necessary.

SIM card security

Your SIM card stores all your Contacts information. Since this information is stored

entering the PIN

You may be required to enter a SIM PIN when you first use your handset.

When you receive your handset, the SIM PIN is 0000. Change your PIN to prevent fraudulent use of the SIM card. See “security” on page 112.

memory card

A memory card is a removable flash memory card that you can use to store pictures, videos, and audio files. The memory card can be inserted in your phone or connected to your computer using the memory card reader.

loaded in the phone to save or delete music, images, videos, or audio files.

Find it: M > u >

Connections > USB

insert the memory card

Slide open the memory card slot cover.

Slide in the memory card until it clicks into place.

selecting the

Remove Card

option could result in

loss of data.

battery

Battery Use & Battery Safety

• Important

: Motorola mobile devices are designed to work best with qualified batteries. If you see a message on your display such as

Invalid

Battery

Unable to Charge

, take the

following steps:

•

Remove the battery and inspect it to

temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging. Always take your mobile device with you when you leave your vehicle.

•

When storing your battery, keep it in a cool, dry place.

Authorized Service Center before using.

Do not

attempt to dry it with an appliance or heat source, such as a hair dryer or microwave oven.

• Use care when handling a charged battery

- particularly when placing it

inside a pocket, purse, or other

battery installation

Slide the release button back until it releases the battery door.

When you charge the battery, the battery level indicator at the upper right of the screen shows charging progress. At least one segment of the indicator must be visible to ensure full phone functionality while charging.

charge from your computer

You can partially charge your phone’s

Replace the battery door and press it gently until you hear a click.

the USB cable is connected between the computer and the phone, the phone will power up in charging mode. This mode allows the phone to charge fastest and quickest.

Note:

If the battery is very low, the phone will not turn On, but will continue to charge at a low rate. The phone will power up in charging

overcharging. Of course, unplugging the charger from the wall will avoid current drain.

turn it on & off

To turn on your phone, press and hold

for a

make a phone call

Enter a phone number and press N to make a call or use of voice command. See“place a call using voice name” on page 99.

To hang up press

or close the flip.

Tip:

For best performance avoid touching the

If you want to answer the call using the ear speaker, just open the flip and press

. To hang up press O or close the flip.

Note:

You must have the

Flip Activation

feature On. See “advanced calling” on page 103.

If you are using a Bluetooth headset, you

to make a private call

Enter the Private ID you want to call.

Press and hold the PTT button. Begin talking after your phone emits a chirping sound.

Release the PTT button to listen.

The recipient has the following options:

Option

Answer

: Begin a Private call with the sender.

Queue

: Store the call alert to the call alert

queue.

Clear

: Dismiss and delete the call alert.

Private call, wait for the caller to finish speaking.

Press and hold the PTT button and begin talking after your phone emits a chirping sound.

Release the PTT button to listen.

Clear the call alert by pressing - under

Clear

store a phone number or private ID

Tip:

Before saving the entry, you can save more information. You can add a picture, choose a special ringer, store an Email address, an IP address, assign a Group, and more. You can also create Contact entries that are groups of Private IDs called Group IDs.

After you have saved the number, the new

Search Option

. If you select

Full Name Search

, a new window will appear to allow you to type the name of the contact you are looking for. If you select

First Letter Search

, your handset will find the nearest match to the letter you enter.

If the Contacts entry contains more than

holding the PTT button, even if the Private ID is not the type of number displayed.

find your phone number and Private ID

Find it:

> m >

My Info

set it up

Before you begin using text messaging, you may need to set up your signature, service center number, and expiration information.

Shortcut:

From the home screen press -

under

Msgs

[Create Message]

Text Msg

Setup

Srvc Cntr No:

Enter the phone number of your service center. If you do not know this number, contact your service provider.

Expire After:

This is the amount of time messages you send are saved at the service center if they cannot be delivered.

option

Quick Notes

: Are short, pre-written text messages that you can create, edit, and send in your text messages. You can store up to 20 quick notes. A quick note may be up to 30 characters long.

Select

Quick Notes

to create a

[New Note]

option

you the next time you power it on. If you are out of your coverage area, your phone alerts you when you return to your coverage area.

Tip:

While reading a text and numeric message that contains a phone number, you can press

to call that number.

calling the sender, or storing the sender’s number in

Contacts

, press

create and send text messages

From the home screen press - under

Msgs

[Create Message] > [Create Text Msg]

Select

Msg

: and enter the text of the

message or to use a quick note press

under

Browse

and scroll to the quick note

you want.

Press

Set Send Method

and select

Text

Fax, x400, Paging, Email, ERMES

, or

Voice

If you want to send the message, press

To edit the fields you want to change, follow step 2 through step 5 in “create and send text messages” above.

resend text messages

Shortcut:

From the home screen press -

under

Msgs

Sent Items > Text Msg Outbox

delete all unlocked sent messages

Shortcut:

From the home screen press -

under

Msgs

Sent Items > Text Msg Outbox

Press

M >

Delete All.

Press - under

Yes to confirm.

manage memory

Shortcut:

From the home screen press -

under

Msgs

Text Msg Setup > Inbox Mem Mtr

To view the amount of memory available in your text sent items:

Shortcut:

From the home screen press -

under

Msgs

Text Msg Setup > Outbox Mem

Mtr

Slide open the connector cover, and insert the USB data cable into the mini USB connector on your phone as shown.

Connect the other end

use your phone as a modem

You can use your phone as a modem (Packet Data only) with a laptop, handheld device, or desktop computer. Circuit Data is not supported. In order to use your handset as a

Pull out the connector cover, and insert the USB cable into the mini USB connector on your phone as shown.

Insert the data plug

When used as a modem, your handset is enabled for

Data Modem

transfer mode, which is

used for small file transfers such as email.

Note:

To use these services, you must install the iDEN Wireless Data Services software (available separately). For more information on setting up your computer and your handset

accessories

Your handset comes with a battery, and a charger.

To order additional accessories, log on to our Web site

www.telusmobility.com

contact your Mike Dealer.

main attractions

music player

Your phone includes a music player that you

You can send details of the podcast to a friend and send feedback to the podcast creator using MMS messages.

understanding the folder

filename rules

When naming files stored on the memory card, the following rules apply:

•

The filename can only contain ASCII characters.

•

The filename can be up to 32 characters long, including the file

WMA v9 L2 WMA v3, v7, v8

.wma

Up to 320 kbps

Up to 48 kHz

Format Bit Rate Sampling

Rate

Tip:

The Songs folder contains all the music files on the memory card in a single list.

To play the first music file in the folder, press

under

Play

. (If the selected folder contains subfolders, this plays the first music file in the first of the subfolders.)

play music while loading files

The first time the music player finds music files on your memory card, it loads and organizes these files. This may take a long time for a large number of files.

To play music while files are loading:

The following options become available through the navigation panel:

The music player can be set up with the following options:

option

Pause and Resume

Press - under

Pause

or r to pause, and

press

under

Play

or rto resume playing

Option

Repeat

: lets you set the music player to play one or all the music files in a list or folder repeatedly. While in the music player press

Setup

Repeat

All

One

3D Music

lets you experience surround effects. While in the music player press

M > Setup

3D Music

If you set the

3D Music

feature to On, you can

select a 3D effect from the list of

Music

Reverbs

Option

Use Bluetooth

lets you route the audio from the music player to a wireless Bluetooth stereo headset. Additionally the handset can be connected to a Bluetooth Home Stereo Adapter to stream content from your home entertainment system and

Option

create a playlist

Find it:

> j >

Audio Player > Playlists > [Create

New]

Enter a playlist name.

Note:

If you do not assign a name, the

playlist is named

Playlist

followed by a

number. For example, the first playlist you

When you are finished selecting files, press

under

Done

and - under

Save

The following options are available for existing playlists:

option

Edit a Playlist

Remove Songs

You can remove some or all music files while creating or editing a playlist.

Before you have saved a new playlist or while editing a playlist, press

and scroll

option

Delete a Playlist

While in the music player select

Playlists

. Scroll to the playlist you want to delete and press

Delete Playlist

. Press - under

Yes

to confirm.

option

Select the song you want to add to your favorites and press

Add To Favorites

work with podcasts

Find it:

> j >

Music Player

Podcasts

Note:

The Podcasts folder is empty until you

download podcasts from your computer.

podcast. To play the podcast, press

Play

. After you begin playing the podcast, pressing

pauses and resumes the

podcast.

•

If the podcast you are playing contains highlights, pressing and releasing the right or left

skips to the next or

You can play all the highlights in a podcast and skip everything that is not marked as a highlight using

Highlights Only

add a highlight marker

While playing a Podcast press M >

Add

Highlights

an MMS message that the person can save and download onto their computer.

If played on a phone with a music player, like yours, they will see any highlight markers created within the podcast.

Find it: M > j>

Audio Player > Podcasts

> M >

Forward Details

Send.

play music in the background

Find it:

> j>

Audio Player

Songs

Select a music file and press

to play

the song.

Press

Hide Player

The music player continues playing and the

•

Musical ring tones in the list of ring tones

•

Audio recordings saved from MMS messages received

•

Audio recordings downloaded to your phone

Media files supported by the Media Center include:

Format Bit Rate Sampling

Rate

AMR-NB

.amr, .3gp, .3ga, .mp4

4.75 kbps – 12.20 kbps (supports all 3GPP specified

Enhanced AAC+

.aac, .m4a, .3ga, .mp4

Up to 128 kbps (16 to 128 kbps)

Up to 48 kHz

MP3

Up to 320kbps Up to

Format Bit Rate Sampling

Rate

Supported video file formats include:

8-bit mulaw PCM

.waw, .au

Up to 704 kbps Up to 44 kHz

(8, 11.05, 12, 16, 22,44 kHz)

WMA v9 L2 (also

Up to 320 kbps 48 kHz

Format Bit Rate Sampling

Rate

iMelody

.imy

1 – 3.5 kHz Monophonic

N/A

Format Bit Rate Sampling

Rate

camera

The 1.3 MP camera with a digital, external viewfinder in your phone, takes pictures and records videos. You can save these pictures and videos in your phone’s memory or to a memory card inserted in your phone’s memory card slot, depending on the storage

Note:

If you insert a memory card into the phone now, you are prompted to save the picture you have just captured to the memory card. Choosing to save the picture to the memory card does not change your storage preferences after the picture is saved.

To save the picture, press

The following options become available:

option

Record Video

Recording a video is similar to taking a picture. If you store videos in phone memory, you can record videos up to 60

Self Timer

Delay capturing the picture for a selected number of seconds. The values are:

Off

(default), 10 seconds, 15 seconds, 20 seconds

To turn off the timer before the picture is

option

digital viewfinder

The external digital viewfinder allows you to take self-portraits with convenience and accuracy compared to a mirror.

pictures with crop, resize, flip and color adjustment tools. You can also add graphics and text to your pictures.

Find it:

> j >

Media Center.

Select the picture you want to edit.

Press

Edit.

access the media center

You can access the media center from the camera at any time by pressing

Media

Center

, except when you are using the

Camera

Setup

menu or viewing the memory screen.

Press

Media Center

customize the camera

The

Camera Setup

menu lets you customize the

camera as follows:

option

Ask for Name

If this option is On, you are prompted to

PTV features

You can choose to send messages, pictures, events, My Info, contacts or location information to the Private ID you are engaged in a Private call with, Private IDs on the

Recent

Calls

list, and Private IDs stored in

Contacts

When you make or receive a Private call, your phone automatically determines whether the

Default Quality

Sets the default value for the

Picture Quality

option.

option

send messages

The Push to View Messages feature lets you send short text messages through Private calls.

When you send a message, it appears on the display of the phone you are engaged in the Private call with. After the call, the message

begin a message from the contacts or the recent calls list

From the

Contacts

or the

Recent Calls

list, select the entry containing the Private ID you want to send the message to.

Press M >

Use PTT Feature

Send Message

send. Your message may be up to 400 characters long.

You can choose from a list of ready-made words or short phrases called Quick Notes. You can use a Quick Note as it is or edit it before you send it. Editing a Quick Note changes the Quick Note for this message only

reply to a message

View the message.

Press - under

Create the message and push the PTT button to send it.

send a picture during a call

While in a Private call, press - under


or press M >

Use PTT Feature

Send

Picture.

A list of pictures that can be included in a Private call appears.

Select the picture you want to send.

Press

M > Send Via...

Send Via PTT

Select

A Contact

A Recent Call

A list of contacts that have Private IDs and are able to receive pictures appears.

Select the name of the person you want

Select

Browse Picture

Capture Picture

Press the PTT button to send the picture.

Once picture has been sent, when prompted press the PTT button to resume the call.

receive a picture

clear a picture from the display

If you want to clear a picture from your phone’s display while still on a call, press

Clear Screen

The picture will not appear on the display again the next time you receive a call from person who sent it. This does not delete the

set my info sending option

You can control what portion of the information in

My Info

is sent and whether it is sent automatically in every call or only when you choose to send it.

Find it: M >

p > PT Manager

Configure

PTT

My Info

Info to Send

Select On or

Off

When you make a call in which your information is sent automatically, the name you entered in the My Name field of My Info appears on the display of the recipient’s phone, even if your name and Private ID are not stored in the recipient’s

Enter the Private ID number of the person you want to send the Contact information to or press

under

Browse

Select from

Recent Calls, Contacts

, or

Memo

Select the contact information you want to send and push the PTT button.

A list of contacts that have Private IDs and are able to receive pictures appears.

Select the name of the person you want to send your location to.

Press the PTT button to send your location.

Check or uncheck Messages, Pictures Events and/or Location.

one touch PTT

Find it: M >

p > PTT Options

One Touch PTT.

One Touch PTT sets your phone to do any of

Assigned Number

Call a Private ID you assign. Enter the number using your keypad, or press

under

Search.

Select

Contacts, Recent Calls

, or

Memo

option

Find it: M > p >

PT Manager

Select

Send Message, Send Picture, Send Event, Send

My Info

Send Contact

Send Location

. After choosing what PTT item you are sending, select a contact and press the PTT button to send.

Send Picture

Go to the first screen to send pictures. See “send pictures” on page 49.

Send My Info

Go to the first screen to send My Info.

option

menu items and the steps you take to access features may differ.

create a message

Shortcut:

From the home screen press -

under

Msgs

[Create Message]

[Create MMS Msg]

Tip:

To remove a phone number or email address from the list of message recipients, scroll to the phone number or email address and press

under

Remove

When you are finished addressing the message, press

under

Back

To enter or edit the body of the message:

The following options become available:

option

Subject

Create or edit the subject line.

Attach

Attach a picture, audio file, video or voice

Report

Set receipt confirmation

On Delivery

Valid Until

Set a date after which attempts to deliver the message end. Or press

under

No Date.

option

A list of short phrases appears. Select any of these phrases to add it to your messages or select

[Create Reply]

Edit any message fields you want to change.

Press - under

Send

insert a picture, video, and audio recording from the media center

You can insert one or more pictures, videos, and audio recordings from the media center into the body of the message. You can include text in the body of your message in addition

Tip:

To view or listen to the item before

inserting it, highlight it and press

Preview

remove an inserted item

To remove an item from the message you are creating, highlight it and press

under

Delete

Select the picture, video, or audio recording you want to attach.

Tip:

To view or listen to the item before

attaching it, highlight it and press

under

Preview

If you want to attach more items, select

[New Attachment]

Take the picture. For instructions on how to take pictures, see “camera” on page 43.

When you have captured the picture you want, press

Save

. This will automatically save it to your media center and attaches it to your message.

To view the video without saving it, press

Review

To save the video, press

or press

To discard the video without saving it, press

Discard

The picture is attached to the message

When you are finished, press - under

Done

The voice record is attached to the message and saved to the media center and the list of voice records.

remove an attachment

You can continue to create the message. The version you saved in the MMS drafts folder will not change.

send a draft

Shortcut:

From the home screen press -

under

Msgs

Drafts > MMS Drafts

delete a draft

When you send a draft, it is removed from the MMS drafts folder.

To delete a message in the MMS drafts folder without sending it, scroll to the message you want to delete and press

under

Delete

Make editions if you wish, select the recipient and press

under

Send

resend

If a message was not sent from your handset, you can resend it.

Shortcut:

From the home screen press -

Scroll to the message you want to view.

Press

Delivery Status

delete a message

Scroll to the message you want to delete.

Press

Delete Message

If the message fills more than one screen, scroll to read it.

embedded objects and attachments

Messages may contain pictures, videos, or audio recordings as part of the body of the

Highlight the attachment you want to open. Attachments appear at the end of a message.

Press r.

Note:

Attachments that are of an unknown type cannot be opened, but they can be deleted.

Press - under

Delete

and - under

Yes

confirm.

forward a message

Press

Forward

Create and send your message. Embedded objects and attachments are

field, the To field, the Cc field, the

Subject

line, or the body of the message, you can call or send a call alert to that number.

send a call alert

View the message.

Highlight the Private ID or Talkgroup ID

store message information to contacts

If a message you receive contains a phone number, Private ID, Talkgroup ID, or an email address in the

From

field, the To field, the Cc

field, the

Subject

line, or the body of the

message, you can store this information to

Contacts type you want to assign the number or email address.

Press

under

Save

go to a website

If a message contains one or more website URLs, you can go to that website.

A slide show may contain a series of pictures that display in sequence. It may also include one or more audio recordings.

When you view a message containing a slide show, this icon

appears.

view a slide show in a message

save an embedded picture, video, or audio recording

To save a picture, video, or audio recording that is part of the body of a message you receive:

View the message.

delete an embedded picture, video, or audio recording

To delete a picture, video, or audio recording that is part of the body of a message you receive:

View the message.

Selected items save to the default storage location.

Note:

Some types of pictures, videos, and audio recordings can be viewed or played, but not saved.

delete attachments

save audio

View the slide show.

Press

Save Audio

If the slide show contains more than one audio recording, a list of the audio recordings appears. Select the audio

customize MMS

Shortcut:

From the home screen press -

under

Msgs

M >

MMS Setup

Find it: M > g > M >

MMS Setup

This option is available from many context-

Quick Notes

: Lets you create new Quick Notes and edit or delete Quick Notes you have created.

Replies

: Lets you create new reply phrases and edit or delete reply phrases you have created.

option

new quick notes and reply phrases

Note:

These Quick Notes are not the same as the quick notes used with MOSMS messages. Each messaging service has its own quick notes feature.

Edit the text and press

delete only Quick Notes and reply phrases you have created

From the MMS Setup menu, select

Quick

Notes

Replies

Scroll to the Quick Note or reply phrase

cleanup options

The cleanup option controls how long messages remain in the Inbox and Sent Itmes before they are deleted. You set the cleanup option for the Inbox and Outbox separately.

The cleanup option deletes only read, unlocked messages.

5 Messages

: If you have more than 5 messages, messages are deleted in the order they were received, starting with the oldest, until 5 are left.

10 Messages

: If you have more than 10

messages, messages are deleted in the

option

Press - under

Yes t

o automatically delete

messages now or press

under No to

delete messages later.

Mike’s wireless web services

Your handset is equipped with a microbrowser that can be used to access Mike's Wireless Web Services and other upto-the-minute information. You can view

Custom

: Lets you create a clean-up option of

up to 99 messages or 99 days. for the inbox

option

Once connected, the Homepage (or the last page visited) will be displayed. To access the Home menu page from any other menu in the microbrowser, press

To view additional text while visiting a site, use the navigation key to scroll to read

* Asterisk/Back key

- press to return to the previous page viewed before the current page.

0 0/+ Next key

- press after using the back key to return to the original page viewed.

customize your microbrowser

You can adjust the size of the display and the font in your microbrowser.

Find it:

Browser >

Preferences

Look & Feel.

To adjust the size of the display, select

Reload

- reloads the current Wireless Web page viewed, refreshing the information with the most current from the information provider.

Home

- returns you to your default Home

page, the first page you see when launching

option

headset. Additionally the handset can be connected to a Bluetooth Home Stereo Adapter to stream content from your home entertainment system and listen wirelessly from your headset withouth missing a call.

All stereo audio includes ring tones, music and Java sound.

Select

Name

if you wish to assign a name

to your handset.

Select

Find Me Duration

to determine the amount of time in which your handset can be found by other Bluetooth devices.

Tip:

You can turn off Bluetooth if you want to

prolong battery life or if you enter an area

until it finds it. Press

when you see the name of the Bluetooth headset on your screen.

Your phone requires that you create a bond in order to connect with a Bluetooth headset. Press

under

Yes

when you are

prompted to bond with the headset.

Note:

This model offers bluetooth auto pair feature with auto pair compatible Motorola devices. When bonded via bluetooth with a certain device, the pin will not be required.

connect your phone with another device using Bluetooth

Find it:

Bluetooth > Pair To Devices.

Note:

If the

Audio Devices

list contains only one device, then your phone will automatically try to connect to that device.

While in a call, press

Use Bluetooth.

Press - under

Yes

to power On

Bluetooth.

send Contacts

Shortcut:

From the home screen press -

under

Contcs.

Select the contact you want to send.

Press

Send Via... > Bluetooth

Press - under

Yes

to power On

Select the datebook event you want to send.

Press

Send Via... > Bluetooth

If the event you select repeats, then you will be prompted to choose whether to send the selected instance of the event or all instances of the event.

Search for the device by selecting

[Look for

Devices]

If prompted, bond with the device. Your phone connects with the device and

sends the datebook event.

send audio files, pictures, and videos

Search for the device by selecting

[Look for

Devices]

If prompted, bond with the device. Your phone connects with the device and

sends the datebook event.

clock screen saver

Your phone comes with a clock screen saver that shows the time and day of the month through the external display when the phone is in power save mode.

When a key is pressed the screen saver is

basics

See page 1 for a basic phone diagram.

display

status indicators

Status indicators are shown at the top of the home screen:

2 Active Phone Line:

1 indicates phone line 1 is ready to make calls; 2 indicates phone line 2 is ready to make calls.

3Speaker On/Off:

Sounds associated with Private calls and group calls can be set to come through the earpiece rather than through the speaker.

main menu

All your phone’s features can be accessed through the main menu. You can set the main menu to appear as

List View, Icon View

, or as

Tab

View

Find it: M > u >

Display/Info

Menu View

Select one of the following options:

text message service such as concatenated SMS, the page counter is also displayed.

word method

The Word English text input method lets you enter text into your phone by pressing keys just once per letter.

entry modes

Alpha

Press a key several times for different characters.

Word

Enter words using a predictive text entering system that lets

enter the word

Bill

, press

2455

(If you make a mistake, press

to erase

a single character. Press and hold

delete an entire entry.)

To accept a word and insert a space, press

To accept a word completion (such as

and

three times again. If you make a

mistake, press

Delete

to erase a single

character. Press and hold

Delete

to erase an

entire word.)

By default, the first letter of an entry is capitalized and the following letters are lowercased. After a character is entered, the

handsfree speaker

You can use your phone’s handsfree speaker to make calls without holding the phone to your ear.

During a call (with the flip open), press

under

Speaker

to turn the handsfree speaker

T U V 8 Ú Ü Û Ù

W X Y Z 9

+ - 0 * / \ [ ] = > < # §

Space

Back

characters

codes & passwords

The Security menu lets you turn security features on and off and change passwords. See “security” on page 112.

lock & unlock phone

Phone Lock

- Turns on a feature that locks your

phone:

Lock Now

takes effect immediately;

Auto

Lock

takes effect when your phone is powered off and then on. An unlock code is required to enable this feature, to unlock the phone, and to set a new unlock code. Contact your

option

SIM PIN

- Enables and disables your phone’s

transmitters

Note:

Consult airline staff about the use of the Tra n s m i tte r s O ff feature during flight. Turn off your phone whenever instructed to do so by airline staff.

Transmitters Off mode turns off your phone’s

Note:

No serial port connectivity is provided by your phone. Applications on the host device which are expecting to receive the GPS location information via a serial port must instead use a Virtual Serial Comm Port.

The data sent to the host device is formatted as prescribed in the National Marine

get connected

Slide open the phone's bottom connector and insert a mini-USB cable into the phone's bottom connector.

Insert the other end of the mini-USB cable into a vacant USB receptacle of your host device. A virtual USB Comm Port will be

• Stop bits

: 1

•Flow control

: None.

Start the GPS application on your host device. Set the GPS application to start accepting NMEA-0183 formatted data from the created Virtual COMM port.

you need to manually restart it using the menu selections above.

Your USB host device will generally provide charging power (5V, up to 500mA) to your phone via the mini-USB cable therefore no other charging power to it will normally be required. However some laptops may require

optimize your handset position and orientation

While in a phone call slide your phone up and down, then left and right until best microphone coupling is obtained. You also may need to adjust your hearing aid (HA) volume setting

If you are unsure whether your HA is telecoil equipped or needs an auxiliary magnet, please refer to your HA user guide or contact a hearing aid professional or supplier.

positions when the handset is in the optimum orientation.

choose your hearing aid setting

Find it:

Settings > Phone Calls > Hearing Aid

Set this option to Microphone

. Microphone

coupling is now optimized.

Approximate telecoil location is within

6-13 mm of this location.

Off - Shut off

features for the vision impaired

voice playback

The Voice Playback feature allows you to use a simulated voice to guide you through phone

Note:

When you access the home

screen, you will hear “Home”

•

Main menu options as you scroll through the main menu

•

A prompt indicating that your phone is placing a call

high contrast theme

Your phone comes with a standard high contrast theme that provides black and white text with reverse text highlighting and very large icons for easy visualization of selection.

Find it:

> u >

Display/Info

Theme

High

Contrast

customize

volume

Press the volume

Note:

Only ring tones stored in your phone’s memory are available in the ring tones list. To assign a ring tone stored on a memory card

Select the features you want to assign the ring tone to.

When you are finished, press - under

Done

Note:

This icon M appears on the display if you set your phone to neither vibrate nor make a sound for phone calls.

Select

Vibrate from the list of ring tones.

Select the features you want to set to make no sound.

When you are finished, press - under

Done

If you want the wallpaper in the home screen only select

Idle Only

; if you want the wallpaper to show throughout all the menu screen, select

Throughout

Note:

You can set the internal and external wallpapers to change automatically after a certain period of time by turning on the

Auto

Daily Begin

- Sets the beginning of your day. This is the earliest time of day displayed in week view, if you have a 12-hour day view.

Delete After

- Sets the amount of time Datebook

waits to delete an event after it occurs.

Time Shift

- Lets you shift the times of all

Datebook events. This is useful if you are

based services that may be available in the future.

The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.

Note:

Turning Location on will allow the

network to detect your position using GPS

Select from the following options:

option

Restricted

: No Java or similar software applications may view the location of your phone. However, location information may still be available to the phone’s owner, fleet manager, or account administrator.

calls

To make and answer calls, see page 19.

turn off a call alert

•

short text messages received

•

pictures sent or received

•

Datebook events received

Find it:

Recent Calls

Scroll to or select the item you want to store.

Press - under

Save

to store the information as a new entry in the Contacts list.

caller ID

Caller ID allows people to identify a caller before answering the phone by displaying the number of the incoming call. If you do not want your number displayed when you make a call, just follow these easy steps.

Motorola Mike i877 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
