TELUS
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
HELLOMOTO
Introducing your new Mike i576 wireless phone. Here’s a quick anatomy lesson.
check it out
Main Menu
Main Menu
Home Screen
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service,
please contact the Motorola Customer Support Center at:
1-800-453-0920 (United States)
contents
check it out . . . . . . . . . . . . . . . . . 2
menu map . . . . . . . . . . . . . . . . . . 6
use and care . . . . . . . . . . . . . . . . 8
essentials . . . . . . . . . . . . . . . . . . 9
accessories. . . . . . . . . . . . . 23
for more information . . . . . 23
main attractions . . . . . . . . . . . 24
media center . . . . . . . . . . . . 24
redial . . . . . . . . . . . . . . . . . . . 47
voice names . . . . . . . . . . . . . 47
caller ID. . . . . . . . . . . . . . . . . 48
call forward . . . . . . . . . . . . . 48
contacts . . . . . . . . . . . . . . . . 64
datebook . . . . . . . . . . . . . . . . 65
GPS . . . . . . . . . . . . . . . . . . . . 66
handsfree . . . . . . . . . . . . . . . 67
personalize . . . . . . . . . . . . . . 67
pc applications . . . . . . . . . . 68
TTY . . . . . . . . . . . . . . . . . . . . . 68
security . . . . . . . . . . . . . . . . . 68
Safety and General
Index . . . . . . . . . . . . . . . . . . . . . 94
menu map
main menu
1
Browser
L
Java Apps
• Java System
E
Messages
• [Create Message]
•Voice Mail
B
Recent Calls
o
Profiles
J
My Info
•My Name
• Line 1
• Line 2
l
Memo
N
PT Manager
• Send Picture
• Send Event
• Send My Info
• Send Contact
settings menu
Display/Info
• Wallpaper
•Text Size
• Theme
• Home Icons
• Backlight
•Clock
• Menu View
• Large Dialing
• Language
Phone Calls
2-Way Radio
• Tkgrp Silent
•Tkgrp Area
• One Touch PTT
• Alert Type
• PTT Quick Notes
•On/Off PTT
• Store Rcvd Info
• PTT Backlight
Personalize
• Menu Options
Security
• Phone Lock
• Keypad Lock
• SIM PIN
•GPS PIN
• Change Passwds
Advanced
• Alert Timeout
• Headset/Spkr
• Connectivity
• Reset Defaults
use and care
Use and Care
To care for your Mike phone, please keep it away from:
liquids of any kind dust and dirt
essentials
Caution:
Before using the phone for the first
time, read the Important Safety and Legal
information included in the gray edged pages
at the back of this guide.
3
Press the center key O to select it.
symbols
This means a feature is network/
SIM card
insert the SIM card
Turn off your phone and remove your battery
before you install or remove a SIM card.
Carefully slide the SIM chip into your phone,
Warning:
To avoid loss or damage, do not
remove your SIM chip from your phone unless
absolutely necessary.
battery
Battery Use & Battery Safety
•
Important:
Motorola mobile devices are
designed to work best with qualified
batteries. If you see a message on your
display such as
Invalid Battery
or
Unable to
Charge
, take the following steps:
•
Remove the battery and inspect it
to confirm that it bears a Motorola
temperature. Never expose batteries to
temperatures below 0°C (32°F) or
above 45°C (113°F) when charging.
Always take your mobile
device with
you when you leave your vehicle.
•
When storing your battery, keep it in a
cool, dry place.
Authorized Service Center before
using.
Do not attempt to dry it with an
appliance or heat source, such as a hair
dryer or microwave oven.
•Use care when handling a charged
battery
: Particularly when placing it
inside a pocket, purse, or other
battery installation
1
Slide the battery door up until it is
released.
charge using the charger
1
Pull out the connector cover, and insert
the charger into the accessory connector
on your phone as shown.
3
Insert battery as shown below. Push the
battery down until it snaps in place.
USB cable from your phone’s micro-USB port
to a high power USB connector on a
computer (not a low-power one, such as the
USB connector on your keyboard or buspowered USB hub). Typically, USB high-power
connectors are located directly on your
computer.
charging under a very low battery condition, it
is recommended to use the rapid charger
supplied with the handset.
If the phone is turned on while charging from
a computer, it will not fully charge the battery.
In this case, the battery charge will be
maintained approximately between 80% and
turn it on & off
To turn on your
phone, press
and hold
E
for a
few seconds or
until the display
turns on.
Note:
For best call quality avoid covering the
antenna with your hand.
To hang up press
E
.
answer a phone call
When your phone rings and/or vibrates, you
make a private call
With Private calls service, you use your phone
as a long-range, digital 2-way radio using oneto-one Private calls or one-to-many group
calls.
Your Private ID is the number at which you
3
Release the PTT button to listen.
To end the call press
O
.
Note:
A Private call ends automatically if there
is no activity on the call for a few seconds.
Tip:
To let someone know you want to talk to
them on a Private call, press
-
under
Alert
.
store a phone number
or private ID
You can store a phone number or Private ID in
Contacts
:
1
Press M >
Contacts
>
[New Contact]
.
addresses, IP addresses, or Talkgroup IDs.
You can assign each number a speed dial
number and voice name. You can also create
Contact entries that are groups of Private IDs
called Group IDs.
After you have saved the number, the new
Contacts entry is displayed.
taken to all the contact names starting
with the letter you pressed.
2
If the Contacts entry contains more than
one number, scroll left or right until the
type of the number you want to call is
displayed (
Mobile, Private, Work1, Work2, Home
,
etc.).
your phone number and
Private ID
Find it: M >
My Info
Tip:
Want to see your phone number or
Private ID while you’re on a call? Press
M
>
My Info
.
mail/NetMail/OAP alert. It will remain on until
there are no unread items in Message Center
or until it reaches the 30 minute timeout.
set it up
Before you begin using text messaging, you
may need to set up your signature, service
Srvc Cntr No:
Enter the phone number of your
service center. If you do not know this
number, contact your service provider.
Expire After:
This is the amount of time
messages you send are saved at the
service center if they cannot be delivered.
option
2
To dismiss the message notification press
-
under
Exit
.
Note:
If your phone is powered off when you
receive a text message, your phone notifies
you the next time you power it on. If you are
out of your coverage area, your phone alerts
you when you return to your coverage area.
3
To reply to the message, press - under
Reply
or to see all other choices, including
forwarding and deleting the message,
calling the sender, or storing the sender’s
number in
Contacts
, press M.
create and send text messages
Calls, Contacts
or
Memo
to find the number you
want. Press
-
under
Back
when done.
3
Select
Msg
and press O. Enter the text of
the message, or to use a quick note press
-
under
Browse
and scroll to the quick
note you want. Press
O
when done.
4
Press M >
Set Send Method
and select
Text
,
1
Select the draft you want to edit. You also
have the choice to create new text
messages from this menu.
2
To edit the fields you want to change,
follow step 2 through step 5 in “create
and send text messages” above.
1
Scroll to the message you want to delete.
2
Press - under
Delete
.
3
Press - under
Yes
to confirm.
delete all unlocked sent messages
Shortcut:
From the home screen press -
under
Mesg
>
Outbox
>
Text Outbox
.
If the outbox and drafts folder memory is full,
you cannot send messages or save drafts
until you delete some.
To view the amount of memory available in
your text inbox:
Shortcut:
From the home screen press -
under
Mesg
> M >
Text Msg Setup > Mem Mtr-Inbox
.
connect with a USB cable
Use a USB cable to connect your
handset to a laptop, handheld device, or
desktop computer.
1
Pull out the connector cover, and insert
the charger into micro USB connector on
your phone as shown.
(available separately). For more information on
setting up your computer and your handset
for packet and circuit data calls, contact your
service provider.
accessories
main attractions
media center
The media center lets you access pictures and
Pictures in the media center can be sent in
Private calls using Send via PTT. See “PTV
features” on page 25.
PTV features
You can choose to send My Info and contact
information to any Private ID.
You can choose to send pictures and events
to the Private ID you are engaged in a a
Private call with, Private IDs on the
Recent Calls
list, and Private IDs stored in
Contacts
.
When you make or receive a Private call, your
.gif
640 x 480
.jpg
640 x 480
.wbmp
127 x 127
FormatMax. Image Size (in pixels)
send pictures
You can send pictures stored in
Media
Center
through Private calls. The picture you
send appears on the Private call recipient’s
display.
If the recipient accepts the picture, their
phone saves the picture.
4
Wait while the picture is transmitted. The
Private call is temporarily interrupted
while a picture is transmitted.
5
When prompted, press the PTT button to
resume the Private call.
start a call by sending a picture
from the PT Manager:
Find it: M >
PT Manager
>
Send Picture
1
Select
A Contact
, or
A Recent Call
to see a list of
entries that can receive pictures.
2
Select the entry containing the Private ID
you want to send the message to.
Pictures you receive are saved to your phone’s
memory. They are accessible through
Media
Center
.
When you see a message asking if you want
to accept the picture, press
Yes
to accept or No
to decline.
Tip:
If you want to stop the transmission
person who sent it. This does not delete the
picture from
Media Center
.
send events
You can send an event already stored in your
phone’s Datebook or create a new Datebook
event to send. When you create a new event
If you want to chose an event from
Datebook, select the event you want to
send.
3
If the event is a recurring event: Select
This
Event Only
to send only the event selected.
Select
Repeat Events
to send all occurrences
of the event.
set my info sending option
You can control what portion of the
information in
My Info
is sent and
whether it is sent automatically in every call or
only when you choose to send it.
Find it: M >
PT Manager
>
Configure
>
PTT My Info
>
Info to Send
1
Select On or
Off
.
When you make a call in which your
information is sent automatically, the name
you entered in the
My Name
field of
My Info
appears on the display of the recipient’s
phone, even if your name and Private ID are
not stored in the recipient’s Contacts.
2
Enter the Private ID number of the person
you want to send the Contact information
to or press
-
under
Browse
.
3
Select from
Recent Calls, Contacts
, or
Memo
.
4
Select the contact information you want
to send and push the PTT button.
one touch PTT
Find it: M >
PT Manager
>
Configure
>
One Touch PTT
One Touch PTT
sets your phone to do any of the
following each time you press the PTT button
from the home screen:
option
you are sending, select a contact and
press the PTT button to send.
or
2
Select
Configure
to configure your
PTT My Info
,
One Touch PTT
, or
On/Off PTT
.
Send Picture
: Go to the first screen to send
pictures. See “send pictures” on page 26.
Send Event
: Go the the first screen to send a
Datebook event.
Send My Info
: Go to the first screen to send My
option
access the microbrowser
The first time you use the microbrowser, you
will be required to go through a security setup
process that takes approximately one to three
minutes. Please follow the on-screen prompts
to complete the security setup process. This
setup process will only occur the first time
navigate the microbrowser
When you use the microbrowser, some keys
on your handset operate differently than
during a normal phone call. These keys are
explained below:
E
Home key
- press to return to the
3
Press - under Ok to initiate the option.
option
Exit Browser
- closes the browser and returns
you to the idle screen. Use this option
when you want to return to the page
currently viewed at a later time, without
navigating through the entire menu
Mark Site
- identifies sites you would like to
visit easily and quickly from your
microbrowser.
About Phone.com
- contains information about
the version of the Phone.com browser
loaded on your handset.
option
The Bluetooth connection menu contains an
option to search for audio devices.
turn Bluetooth On or Off
You can turn your phone’s Bluetooth feature
on or off. While Bluetooth power is on, your
phone can communicate with other devices.
make a Bluetooth connection
connect your phone with a Bluetooth
headset
Find it: M >
Bluetooth > Hands Free > [Find Devices]
1
Follow the instructions on your Bluetooth
headset to set it up to be found.
Bluetooth device’s user guide to locate
this information.
If a device ships without a Bluetooth PIN,
then refer to its user guide to set the PIN
on that device. To establish a connection
to that device, enter the same PIN for
both your phone and the device. For
1
Select the device you want from the list of
found devices on your screen.
2
Create a bond if you are prompted to do
so.
Tip:
If you have previously connected to a
device, the device will be stored on your
phone so you can connect with it easily.
send information via Bluetooth
You can use your phone to send Contacts
entries, or Datebook events to another
Bluetooth device.
The receiving device must be within 32 feet
(10 meters) of your phone in order to connect
with yours.
4
Select the device you want to transfer the
contact information to.
or
Search for the device by selecting
[Find
Devices]
.
5
If prompted, bond with the device.
To send only the selected instance of the
event, select
This Event Only
.
or
To send all instances of the event, select
Repeat Events
.
3
Press - under
Yes
to power On
basics
See page 1 for a basic phone diagram.
display
Soft key labels show the current soft key
functions. For soft key
-
locations, see
page 1.
connection. You can’t make or receive
calls when
1
or
0
shows.
2Active Phone Line:
1 indicates phone line
1 is ready to make calls.
3Speaker Off:
Sounds associated with
Private calls and group calls are set to
come through the earpiece rather than
text entry
Some features let you enter text.
Your phone provides convenient ways to enter
words, letters, punctuation, and numbers
whenever you are prompted to enter text (for
example, when adding a Contacts entry or
2
Select one of the following options:
word mode
Word English Text Input lets you enter text
into your phone by pressing keys just once
per letter.
Word English Text Input analyzes the letters
you enter using an intuitive word database
and creates a suitable word. (The word may
entry modes
Alpha
Press a key several times for
each character.
Word
Enter words using a predictive
text entering system that lets
3
To accept a word and insert a space,
press
#
.
alpha mode
enter characters by tapping the keypad:
1
Select the
Alpha
mode.
Characters scroll in the following order:
characters
1
Space . 1 ? ! , @ & : ; “ - ( ) ‘ ¿ ¡ %
£ $ ¥
2
A B C 2 Á Ã Â À Ç
3
D E F 3 É Ê È
volume
Press the volume keys up
or down to:
•
turn off an incoming
call alert
•
change the earpiece
navigation key
Press the navigation key
up, down, left, or right
to scroll to items in the
display. When you scroll
to something, press
O
.
call will redirect the audio back to the
earpiece.
transmitters
Note:
Consult airline staff about the use of
the Transmitters feature during flight. Turn off
use GPS with map
software
Your phone is enabled with a highly-capable
GPS receiver that sends location information
to a USB port on a PC, laptop, or PDA.
Note:
No serial port connectivity is provided
0183 standard. Consequently it's unsuitable
for conventional marine NMEA-0183
equipment use. Its intended use is for normal
"terrestrial" mobile users who want to enable
their USB hosting computing devices such as
a PC, laptop or PDA with the phone's highlycapable GPS functionality.
USB Communications Device Class
device.
Note:
A mini USB to micro USB adapter
may be required to connect other devices.
3
Ensure no application in your host device
is using the created COMM port. You
may need to ensure that the created
5
Set your phone to start sending NMEA0183 formatted location information.
Find it: M >
GPS
>
Interface
>
NMEA OUT
>
On
Your phone is now actively sending location
NMEA-0183 formatted GPS data to your USB
host device.
laptop in order for it to provide full 500mA
charging current capability to the phone.
calls
To make and answer calls, see page 15.
recent calls
Find it:
M
>
Recent Calls
Tip:
You can also access the Recent Calls list
by pressing the navigation key
down.
1
Scroll to or select the item you want to
store.
2
Press - under
Save
to store the
information as a new entry in the
Contacts list.
or
voice names
You can place calls by speaking comands to
your phone if you have previously assigned a
voice name to your contacts.
assign voice names to contacs
1
Press - under
Contcs
and select
[New
caller ID
Caller ID allows people to identify a
caller before answering the phone by
displaying the number of the incoming call. If
you do not want your number displayed when
you make a call, just follow these easy steps.
different numbers depending on the reason
you missed the call. You can forward phone
lines 1 and 2 independently.
Find it: M >
Call Forward
1
To forward all calls select
All Calls
and select
To
to enter the phone number you want all
your calls forwarded to.
emergency calls
TELUS programs one or more emergency
phone numbers that you can call under any
circumstances, even when your phone is
locked or the SIM card is not inserted.
Note:
Emergency numbers vary by country.
When you make an emergency call, your
phone’s GPS Enabled feature can help
emergency service personnel find you, if you
are in a location where your phone's GPS
antenna has established a clear view of the
open sky and your local emergency response
center has the equipment to process location
information. Because of the limitations of this
international access code (indicated by +).
Then, press the keypad keys to dial the
country code and phone number.
You can additionally enable a predefined prefix
to the dialing number by using
Prepend
dialing.
Find it: M >
Settings
>
Phone Calls
>
Prepend
speed dial
Each phone number stored in Contacts is
assigned a Speed Dial number, which you can
use to call that number.
1
From the home screen, use the keypad to
enter the Speed Dial number assigned to
voice mail
Note:
To receive voice mail messages,
you must first set up a voice mail
account with TELUS.
receive a message
Note:
By default, the Messaging LED
indicator will turn off after 30 seconds.
advanced voice mail with fax
Mike's Advanced Voice Mail with Fax allows
you to receive faxes directly to your handset
and store them along with your voice
fax mail Indicator
Your handset is equipped with a Fax Mail
indicator to notify you when you have
received a fax through Mike's Advanced Voice
Mail with Fax.
Shortcut:
From the home screen press -
under
Mesg
>
Fax Mail
.
Mike’s Talk Around
TM
Mike’s Talk Around allows direct two-way
handset-to-handset communications between
two or more handsets equipped for Mike’s
Talk Around. You can make and receive Mike’s
Talk Around calls even when network service
is not available. You can talk to anyone on your
•
On-network phone calls
•
On-network Private calls
•
Data transmission
•
Incoming message notification
•
Musical ring tones
•
Call forwarding
are set to appears on the second line of the
display and
TA Ready
appears just above the
softkeys.
Note:
When switching from the network to
Talk Around
, the last channel and code that were
set appear on the
Talk Around
idle screen.
While in
Talk Around
, this icon m appears on the
channels and codes
Your phone has 10 channels and 15 codes.
Channels
are divided into sets of frequencies
that allow you to make and receive Talk
Around calls. Other parties may also be
talking on the same channel.
set a channel
1
From the Talk Around idle screen, press
-
under
Edit
.
2
Scroll to
Channel
and press - under
Edit
.
3
Select a channel number from 1 to 10.
4
When you are finished, press
-
under
3
Select a code number from 1 to 15 or one
of the following options:
option
Receive All:
Sets your phone to receive Talk Around
transmissions from any phone that is set to
Pvt Only
Allows you to have a private conversation
with another person using Talk Around.
When on a private Talk Around call, no
other parties can hear your conversation. In
order to make a private Talk Around Call,
option
make and receive code calls in
Talk Around
To make a code call in Talk Around:
1
Push and hold the PTT button.
TA Transmit
appears on the first line of display. Begin
speaking after your phone emits the Talk
Note:
An incoming Talk Around call can be
terminated at any time by pressing
P
.
make a private Talk Around call
1
Enter the 10-digit PTN of the person you
want to call on your channel, or press
-
under
Contacts
and select a contact, or scroll
receive a private Talk Around
call
1
The number or name of the person who
initiated the call will appear in the first line
of the display.
2
You can reply within 6 seconds simply by
automatically exit Talk Around mode and
attempt to find a network signal.
Note:
If you are out of network coverage your
phone will not be able to make an emergency
911 cellular call until you go back into the
network coverage area.
You must wait until the phone reconnects to
The following options become available:
option
Direct Launch
Launchs your phone directly into Talk
Around when you select Talk Around from
the Main Menu. If
Direct Launch
is set to On,
customize
ring tones
To set the ring tone your phone makes when
making a sound;
Silent
sets your phone to
neither vibrate nor make a sound.
Tip:
Highlighting a ring tone lets you hear
messages notifications, pictures sent using
Send via PTT, and Datebook reminders.
Find it:
M
>
Ring Tones
>
Vibrate All
•
Setting this option to On will set your
phone to vibrate when receiving all
calls, alerts, notifications, pictures and
reminders.
4
When you are finished, press - under
Done
.
wallpaper
Set a photo or picture as a wallpaper
(background) image in your phone’s home
backlight
Set the amount of time that the display and
java apps. backlights remain on, or turn off the
backlight feature to extend battery life.
Find it: M >
Settings
>
Display/Info
>
Backlight
You can view or change these options:
option
Start View
: Sets Datebook to start in day view,
week view, or month view when you
access Datebook.
Daily Begin
: Sets the beginning of your day.
hide or show
location information
Your phone is equipped with a Location
feature for use in connection with locationbased services that may be available in the
future.
permission. GPS-enhanced 911 is not
available in all areas.
set your privacy options
Find it: M >
GPS
>
Privacy
Select
Restricted, Unrestricted
, or
Ask Access
.
other features
advanced calling
feature
3-way call
Make or receive a
phone call and press
feature
contacts
flip
activation
To make your handset to
answer and end calls by
opening and closing the flip
press
M
> u >
Phone Calls
>
Flip Activation
.
Select
Flip To Ans
> On and
Flip
feature
feature
edit/delete
contact entry
Press - under
Contacts
.
Select a contact and press
M
>
Edit
. Change the
desired content and press
datebook
feature
create
datebook
events
To create a new Datebook
event press
M
>
D
>
[New Event]
.
see datebook
To see a calendar event
receive
datebook
events via
PTT
To view the information
while still in the Private call
press
r
.
The 5 most recent events
received from a Private ID
are stored with the that
feature
GPS
To improve GPS performance:
•
Stay in the open,
•
Move away from other electrical or
electronic devices
set GPS
privacy
options
To set the level of privacy for
your GPS system press
M
>
GPS
>
Privacy
.
If your GPS PIN security
feature is enabled, enter your
GPS PIN and select the
feature
handsfree
Note:
The use of wireless phones while
driving may cause distraction. Discontinue a
call if you can't concentrate on driving.
Additionally, the use of wireless devices and
their accessories may be prohibited or
restricted in certain areas. Always obey the
personalize
feature
language
To set the language of your
menu press
M
>
Settings
>
Display/Info
>
Language
.
backlight time
To select how long the
pc applications
feature
other PC
applications
For a list of complete PC
applications visit
www.motorola.com/support
change the
TTY baud
rate
From the home screen
press
M
>
Settings
>
Phone
Calls
>
TTY
>
Baud
.
Select
45.45
or
50.00
.
change TTY
While in the TTY call, press
feature
keypad lock
To lock the keypad press M
>
Settings > Security
>
Keypad Lock
>
Lock Now
or
Auto Lock
.
Shortcut:
To lo ck t h e
keypad press
M
> *.
feature
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your phone. Read this information
before using your integrated multi-service portable radio.*
Exposure to Radio Frequency (RF)
•
United States Federal Communications Commission, Code
of Federal Regulations; 47 CFR part 2 sub-part J.
•
American National Standards Institute (ANSI) / Institute of
Electrical and Electronics Engineers (IEEE). C95. 1-1992.
•
Institute of Electrical and Electronics Engineers (IEEE).
C95. 1-2005 Edition.*
electrical, magnetic, and electromagnetic fields in the
radio frequency range between 9 kHz and 300 GHz."
"Attachment to Resolution 303 from July 2, 2002."
Operational Precautions
To assure optimal radio product performance and to be sure that
human exposure to RF does not exceed the guidelines set forth in
the relevant standards, always follow these instructions and
precautions:
When using your radio product as a traditional
two-way radio,
hold the radio product in a
vertical position with the microphone one
to two inches (2.5 to 5 cm) away from the
lips
.
If you wear a radio product on your body when
transmitting, always place the radio product in a Motorola
approved clip, holder, holster, case or body harness. If you do not
use a body-worn accessory supplied or approved by Motorola and
are not using the radio product in the intended use positions along
Follow Instructions to Avoid Interference
Problems
Turn OFF your radio product where posted notices instruct you to
do so.
In an aircraft, turn off your radio product whenever instructed to do
so by airline staff. If your radio product offers an airplane mode or
similar feature, consult airline staff about using it in flight.
Implantable Medical Devices
your wireless phone with your implantable medical device, consult
your health care provider.
Hearing Aids
Some phones may interfere with some hearing aids. In the event of
such interference, you may want to consult your hearing aid
manufacturer or physician to discuss alternatives.
Other Medical Devices and Health Care Facilities
If you use any other personal medical devices, consult your
Driving Precautions
Check the laws and regulations on the use of radio products in the
area where you drive. Always obey them.
When using your radio product while driving, please:
•
Give full attention to driving and to the road. Using a
phone may be distracting. Discontinue a call if you can’t
concentrate on driving.
•
Use hands free operation, if available.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not
always posted, and can include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, or areas
where the air contains chemicals or particles, such as grain, dust
or metal powders.
When you are in such area, turn off your handset, and do not
remove, install, or charge batteries unless it is a radio product type
especially qualified for use in such areas as “Intrinsically Safe” (for
Glass Parts
Some parts of your phone may be made of glass. This glass could
break if the product is dropped on a hard surface or receives a
substantial impact. If glass breaks, do not touch or attempt to
remove. Stop using your phone until the glass is replaced by a
qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts
Your battery or phone may
require recycling in
accordance with local laws.
Contact your local regulatory
authorities for more
information.
Do not throw your battery or
phone in the trash.
Symbol Definition
032375o032375o
Repetitive Motion
When you repetitively perform actions such as pressing keys or
entering finger-written characters, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of
your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
Service & Repairs
If you have questions or need assistance, we’re here to help.
Go to www.motorola.com/support
, where you can select from a
number of customer care options. You can also contact the
Motorola Customer Support Center at 1-800-453-0920 (United
States), 1-877-483-2840 (TTY/TDD United States for hearing
impaired).
Export Law Assurances
Specific Absorption Rate Data
ALL MODELS WITH FCC IHDP56HS1 MEET THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits
general, the closer you are to a wireless base station antenna, the
lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that is does not exceed the limit
established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g.,
1. In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg) averaged over
one gram of tissue. The standard incorporates a substantial margin
of safety to give additional protection for the public and to account
for any variations in measurements.
2. The SAR information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for
this product.
Motorola Limited Warranty for the United States and
Canada
Warra nt y
What Does this Warranty Cover?
Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES
consumers in the United States or Canada, which are
accompanied by this written warranty:
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories
. Defects or
damage that result from the use of Non-Motorola branded or
certified Products, Accessories, Software or other peripheral
equipment are excluded from coverage.
Unauthorized Service or Modification
. Defects or damages
resulting from service, testing, adjustment, installation,
maintenance, alteration, including without limitation, software
Software
as defined
above. Applies only to
physical defects in the
media that embodies
the copy of the software
(e.g. CD-ROM, or floppy
disk).
Ninety (90) days from the date
of purchase.
Products Covered Length of Coverage
uninterrupted or error free, or that all defects in the software
products will be corrected.
Software NOT Embodied in Physical Media
. Software that is
not embodied in physical media (e.g. software that is downloaded
from the internet), is provided "as is" and without warranty.
Who is covered?
This warranty extends only to the first
consumer purchaser, and is not transferable.
What will Motorola Do?
Motorola, at its option, will at no
charge repair, replace or refund the purchase price of any Products,
copy of your receipt, bill of sale or other comparable proof of
purchase; (b) a written description of the problem; (c) the name of
your service provider, if applicable; (d) the name and location of the
installation facility (if applicable) and, most importantly; (e) your
address and telephone number.
What Other Limitations Are There?
ANY IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from
state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for
Motorola certain exclusive rights for copyrighted Motorola
software such as the exclusive rights to reproduce and distribute
copies of the Motorola software. Motorola software may only be
copied into, used in, and redistributed with, the Products
associated with such Motorola software. No other use, including
without limitation disassembly of such Motorola software or
c.Should the Product or parts become, or in MOTOROLA'S opinion
be likely to become, the subject of a claim of infringement of a
United States patent, that such purchaser will permit MOTOROLA,
at its option and expense, either to procure for such purchaser the
right to continue using the Product or parts or to replace or modify
the same so that it becomes non-infringing or to grant such
purchaser a credit for the Product or parts as depreciated and
accept its return. The depreciation will be an equal amount per
year over the lifetime of the Product or parts as established by
MOTOROLA.
granted by implication, estoppel or otherwise under MOTOROLA
patent rights or copyrights.
Hearing Aid Compatibility
A number of Motorola phones have been tested for hearing aid
compatibility. When some wireless phones are used with certain
hearing aids, users may detect a noise which can interfere with
the effectiveness of the hearing aid.
Some hearing aids are more “immune” than others to this
interference noise, and phones can also vary in the amount of
“M” Rating
: Phones rated M3 or M4 meet FCC requirements for
hearing aid compatibility and are likely to generate less
interference to hearing aids than unrated phones. (M4 is the
“better” or higher of the two ratings.) On those models with an
extendable antenna, this rating is determined only with the
antenna extended.
•
Any combined rating equal to four is considered usable.
Thus, if you use an M3 phone with a M3 hearing aid you will have
a combined rating of six for “excellent use.” This methodology
applies equally for T ratings.
More information about hearing aid compatibility may be found at:
www.motorola.com/accessibility
, www.fcc.gov, www.fda.gov, and
www.hearingloss.org/learn/cellphonetech.asp
Information From the World Health Organization
WHO Information
Present scientific information does not indicate the need for any
special precautions for the use of mobile phones. If you are
concerned, you may want to limit your own or your children’s RF
exposure by limiting the length of calls or by using hands-free
devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information: http://www.who.int./peh-emf
Wireless: The New Recyclable
Recycling
Your wireless phone can be recycled. Recycling your phone
reduces the amount of waste disposed in landfills and allows
recycled materials to be incorporated into new products.
The Cellular Telecommunications Industry Association (CTIA) and
its members encourage consumers to recycle their phones and
have taken steps to promote the collection and environmentally
As a phone user, you have an important role in ensuring that this
device is recycled properly. When it comes time to give this phone
up or trade it in for a new one, please remember that the phone,
the charger, and many of its accessories can be recycled. It's easy.
To learn more about CTIA's Recycling Program for Used Wireless
Devices, please visit us at:
Patent and Trademark Information
Patent and Trademark
MOTOROLA, the Stylized M Logo and all other trademarks
indicated as such herein are trademarks of Motorola, Inc. ® Reg.
U.S. Pat. & Tm. Off. © 2008 Motorola, Inc. All rights reserved.
Microsoft and Microsoft Internet Explorer are registered
trademarks of Microsoft Corporation.
T9 is a trademark owned by Tegic Communications.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and third party
Privacy and Data Security
Privacy and Data Security
Motorola understands that privacy and data security are important
to everyone. Because some features of your phone may affect your
privacy or data security, please follow these recommendations to
enhance protection of your information:
• Monitor access:
Keep your phone with you and do not
leave it where others may have unmonitored access. Lock
• Understanding AGPS:
In order to comply with
emergency caller location requirements of the FCC, certain
Motorola phones incorporate Assisted Global Positioning
System (AGPS) technology. AGPS technology also can be
used in non-emergency applications to track and monitor a
user’s location, for example, to provide driving directions.
Smart Practices While Driving
Driving Safety
Drive Safe, Call Smart
SM
Check the laws and regulations on the use of phones and
their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or
restricted in certain areas. Go to
www.motorola.com/callsmart
for more information.
road. If you receive an incoming call at an inconvenient
time, if possible, let your voice mail answer it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
• Use your phone to help others in emergencies.
If you
see an auto accident, crime in progress, or other serious
emergency where lives are in danger, call 911 or other
local emergency number, as you would want others to do
for you.*
• Call roadside assistance or a special
non-emergency wireless assistance number when
necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
Index
A
accessories 9, 67
active phone line 39
connect 34
send information 36
setting your phone 34
turning on or off 34
combined power/end/home
key 15
contacts 64
F
frequently asked questions
service and repairs 78
G
GPS 66
GPS enabled
L
language 67
low battery message 39
M
make a call 15
media center 24
O
one touch PTT 30
optional accessory 9, 67
optional feature 9
P
packet data 39
R
radio frequency 72
received calls 46
recent calls 46
recycling 89
redial 47
ring style indicator 39
send key 15
SIM card 10
change SIM PIN 69
enable SIM PIN 69
soft keys 38
speaker 39, 66
speed dial 50
store your number 18
drafts 21
memory 22
message center 20
receiving 19
resend messages 21
sending 20
sent messages 21
setting up 19
Loading...
