Motorola MDV850T User Manual

MDV850T

User’s Manual

CAUTION

RISK OF ELECTRIC SHOCK

CAUTION:

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Symbols and supplementary warning on the terminal button.

Alert

To prevent fire or shock hazard, do not expose this device to rain or moisture.

Repair

Please contact your cable TV operator to have it repaired or replaced, if necessary.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

The lightning symbol with an arrow inside the equilateral triangle indicates that the user should pay attention to “dangerous voltage" un-insulated in the frame, which is sufficient to be harmful to humans.

The exclamation mark inside the equilateral triangle indicates that there is important operation and service (maintenance) instructions in the attached printed documents.

Note:

No extension cord, socket, or other lead wire should be used with the plug, to avoid electrical shock. The plug should be fully plugged in, with no part exposed.

Never place the device where fluids may drop or splash. Never place any object with fluids, such as vases, on the device.

In line with IS15245: 2002- BIS Rules

The installation shall be performed by qualified service personnel in line with local rules and laws.

Important Safety Measures

1 Reading Instructions

Read through all safety and operation instruction prior to operating the device.

2 Keeping Instructions

Keep all safety and operation instructions for future reference.

3 Note & Warning Description

All warning descriptions on the device and in the operation instructions should be followed.

4 Operate according to Instructions

All operation instructions should be followed.

5 Cleaning

Unplug the device from its power supply prior to cleaning. Never use fluid detergent or aerosol. Instead, simply clean with a wet cloth.

6 Accessories

Any accessory not recommended should not be used, and may result in danger.

7 Water and Moisture

Do not use this device near a bathtub, basin, sink, washtub, swimming pool or other place near a water supply, nor in a damp basement; any of which may cause a “grounding” effect.

8 Supporting Equipment

Don’t place the device on an unstable cart, block, tripod, bracket, or table. It may fall, resulting in serious personal injuries or damage to the device.

9 Ventilation

Openings and drilled holes in the cabinet are for ventilation to ensure its reliable operation and to prevent overheating. Do not place the device on a bed, sofa, carpet, or similar surface; otherwise, the openings may be blocked. Do not place the device near or on a radiator or hot air vent, nor inside a bookcase or shelf, unless proper ventilation is provided. Never stack other electronic equipment on the device.

10 Power Supply (110V)

Only the power designated on the tab can be used (110V). If you are not sure what voltage your outlets support, please consult your local power supply company.

11 Protection of Power Cord

The power cord should not be walked upon nor overlaid by other cords or connectors.

12 Lightning Strike

To properly protect the device in a lightning strike, or when unattended or not in use for a long time, please unplug from the power supply or disconnect the antenna or cable network. By doing so, the damage to the video product from lightning strikes or the over-loading of the power supply (surge) can be prevented.

13 Overloading

Never overload the power supply circuit with other appliances, for it might lead to fire or electrical shock.

Inflow of Articles or Fluids

Never insert anything into the device, because foreign a rticles may contac t dangerous high-voltage points or lead to a short circuit, causing fire or electrical shock. Never drop any fluid on the device.

15 Repair

Do not try to repair device yourself, for you may be exposed to dangerous voltage or other risks after removing or opening the cover. Have it repaired by experienced professional repair personnel.

16 Damage to Be Repaired

Unplug the device from the wall socket and have it repaired by qualified repair personnel if any of the following should occur:

a The power cord or plug is damaged. b The device is exposed to rain or

flooded with water.

c Fluids or foreign objects fall into it.

d The device does not operate properly

after following the directions for use described in this manual. If this occurs, adjust only the controls introduced in the instructions, because any improper adjustment of other controls may result in damage, and, in most cases, may require work by a qualified technician to have it work properly again.

e The device falls or the cabinet is

damaged.

f Its performance undergoes obvious

changes, which indicate a repair is required.

17 Replacing Parts

When it is necessary to replace a part, be sure to have it replaced by service technicians with the part stipulated by the manufacturer or one having the same features as the original. Using unauthorized replacement parts may result in fire, electrical shock, or other dangers.

18 Safety Inspection

Whenever the device has been serviced or repaired, have it inspected for safety by a service technician (insulation standard testing) to ensure its proper operation.

FCC Compliance

This device is intended to be attached to a receiver that is not used to receive over-the-air broadcast signals. Connection of this device in any other fashion may cause harmful interference to radio communications and is in violation of the FCC Rules, Part 15.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.

derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Motorola may make improvements or changes in the product(s) described in this manual at any time. MOTOROLA and the Stylized M logo are registered trademarks of Motorola, Inc. All other products or service names are the sole property of their respective owners.

CONTENTS

Introduction ...........................................................2

Front Panel.......................................................3

Back Panel........................................................5

Remote Control .....................................................7

Main Service...................................................11

Basic Front Panel Operations............................12

Power On/Off..................................................12

Change Channel.............................................12

Rear Panel Audio-Video Connections ..............13

Record Connections...........................................14

Rear Panel Connection — Mono........................15

Rear Panel Connection — Stereo......................16

Troubleshooting..................................................18

INTRODUCTION

Congratulations on your purchase of a Motorola MDV850T Set-top

Box. The MDV850T brings a series of interactive applications for your

TV program viewing that allow you to enjoy digital TV programs with quality sound and video at home.

This manual describes the basic features of the MDV850T and provides several solutions for integrating the box with your current entertainment audio and video system. Please contact your service provider to ensure that the service is provided in your area. Your service provider also provides instructions on optional services.

With other available applications and networks, the MDV850T can provide hundreds of digital and analogue video channels.

If you encounter any difficulty in using this set-top box, please refer to the related part of the manual or consult your network program provider.

INTRODUCTION

Front Panel

There are 7 keys and 2 indicators on the front panel of the MDV850T. The keys perform basic functions. Each control and their possible functions are described in the following figure and table.
