SEMICONDUCTOR TECHNICAL DATA
1
REV 7
Motorola, Inc. 1997
2/97
% %% ! '#%
&# #'#
'# (%
!"% "&%$
High–Performance Silicon–Gate CMOS
The MC54/74HCT244A is identical in pinout to the LS244. This device
may be used as a level converter for interfacing TTL or NMOS outputs to
High–Speed CMOS inputs. The HCT244A is an octal noninverting buffer
line driver line receiver designed to be used with 3–state memory address
drivers, clock drivers, and other bus–oriented systems. The device has
non–inverted outputs and two active–low output enables.
The HCT244A is the noninverting version of the HCT240. See also
HCT241.
• Output Drive Capability: 15 LSTTL Loads
• TTL NMOS–Compatible Input Levels
• Outputs Directly Interface to CMOS, NMOS, and TTL
• Operating Voltage Range: 4.5 to 5.5 V
• Low Input Current: 1 µA
• In Compliance with the Requirements Defined by JEDEC Standard
No. 7A
• Chip Complexity: 112 FETs or 28 Equivalent Gates
LOGIC DIAGRAM
DATA INPUTS
A1
A2
A3
A4
B1
B2
B3
B4
17
15
13
11
8
6
4
218
16
14
12
9
7
5
3
YB4
YB3
YB2
YB1
YA4
YA3
YA2
YA1
NONINVERTING
OUTPUTS
PIN 20 = V
CC
PIN 10 = GND
OUTPUT
ENABLES
ENABLE A
ENABLE B
1
19
PIN ASSIGNMENT
FUNCTION TABLE
Inputs Outputs
Enable A,
Enable B A, B YA, YB
LLL
LHH
HXZ
Z = high impedance
X = don’t care
A3
A2
YB4
A1
ENABLE A
GND
YB1
A4
YB2
YB3 5
4
3
2
1
10
9
8
7
6
14
15
16
17
18
19
20
11
12
13
YA2
B4
YA1
ENABLE B
V
CC
B1
YA4
B2
YA3
B3
DW SUFFIX
SOIC PACKAGE
CASE 751D–04
N SUFFIX
PLASTIC PACKAGE
CASE 738–03
ORDERING INFORMATION
MC54HCTXXXAJ
MC74HCTXXXAN
MC74HCTXXXADW
MC74HCTXXXASD
MC74HCTXXXADT
Ceramic
Plastic
SOIC
SSOP
TSSOP
DT SUFFIX
TSSOP PACKAGE
CASE 948E–02
J SUFFIX
CERAMIC PACKAGE
CASE 732–03
1
20
1
20
SD SUFFIX
SSOP PACKAGE
CASE 940C–03
1
20
1
20
1
20
MC54/74HCT244A
MOTOROLA High–Speed CMOS Logic Data
DL129 — Rev 6
2
MAXIMUM RATINGS*
Symbol
Parameter
Value
Unit
V
CC
DC Supply Voltage (Referenced to GND)
– 0.5 to + 7
V
V
in
DC Input Voltage (Referenced to GND)
– 0.5 to VCC + 0.5
V
V
out
DC Output Voltage (Referenced to GND)
– 0.5 to VCC + 0.5
V
I
in
DC Input Current, per Pin
± 20
mA
I
out
DC Output Current, per Pin
± 35
mA
I
CC
DC Supply Current, VCC and GND Pins
± 75
mA
Î
Î
Î
P
D
ОООООООООООО
Î
ОООООООООООО
Power Dissipation in Still Air,Plastic or Ceramic DIP†
SOIC Package†
SSOP or TSSOP Package†
ÎÎÎÎ
Î
ÎÎÎÎ
750
500
450
Î
Î
Î
mW
Î
T
stg
ОООООООООООО
Storage Temperature
ÎÎÎÎ
– 65 to + 150
Î
_
C
Î
Î
Î
Î
T
L
ОООООООООООО
Î
ОООООООООООО
Î
Lead Temperature, 1 mm from Case for 10 Seconds
(Plastic DIP, SOIC, SSOP or TSSOP Package)
(Ceramic DIP)
ÎÎÎÎ
Î
ÎÎÎÎ
Î
260
300
Î
Î
Î
Î
_
C
*Maximum Ratings are those values beyond which damage to the device may occur .
Functional operation should be restricted to the Recommended Operating Conditions.
†Derating — Plastic DIP: – 10 mW/_C from 65_ to 125_C
Ceramic DIP: – 10 mW/_C from 100_ to 125_C
SOIC Package: – 7 mW/_C from 65_ to 125_C
SSOP or TSSOP Package: – 6.1 mW/_C from 65_ to 125_C
For high frequency or heavy load considerations, see Chapter 2 of the Motorola High–Speed CMOS Data Book (DL129/D).
RECOMMENDED OPERATING CONDITIONS
Symbol
Parameter
Min
Max
Unit
V
CC
DC Supply Voltage (Referenced to GND)
4.5
5.5
V
Vin, V
out
DC Input Voltage, Output Voltage (Referenced to GND)
0
V
CC
V
T
A
Operating Temperature, All Package Types
– 55
+ 125
_
C
tr, t
f
Input Rise and Fall Time (Figure 1)
0
500
ns
DC ELECTRICAL CHARACTERISTICS (Voltages Referenced to GND)
Guaranteed Limit
ÎÎ
Symbol
ООООООО
Parameter
ООООООО
Test Conditions
ÎÎ
V
CC
V
ÎÎ
– 55 to
25_C
ÎÎ
v
85_C
ÎÎ
v
125_C
Î
Unit
ÎÎ
Î
V
IH
ООООООО
Î
Minimum High–Level Input
Voltage
ООООООО
Î
V
out
= 0.1 V or VCC – 0.1 V
|I
out
| v 20 µA
ÎÎ
Î
4.5
5.5
ÎÎ
2
2
ÎÎ
Î
2
2
ÎÎ
Î
2
2
Î
Î
V
ÎÎ
Î
V
IL
ООООООО
Î
Maximum Low–Level Input
Voltage
ООООООО
Î
V
out
= 0.1 V or VCC – 0.1 V
|I
out
| v 20 µA
ÎÎ
Î
4.5
5.5
ÎÎ
0.8
0.8
ÎÎ
Î
0.8
0.8
ÎÎ
Î
0.8
0.8
Î
Î
V
ÎÎ
Î
V
OH
ООООООО
Î
Minimum High–Level Output
Voltage
ООООООО
Î
Vin = VIH or V
IL
|I
out
| v 20 µA
ÎÎ
Î
4.5
5.5
ÎÎ
4.4
5.4
ÎÎ
Î
4.4
5.4
ÎÎ
Î
4.4
5.4
Î
Î
V
ÎÎÎОООООООÎООООООО
Î
Vin = VIH or V
IL
|I
out
| v 6 mA
ÎÎ
Î
4.5
ÎÎ
3.98
ÎÎ
Î
3.84
ÎÎ
Î
3.7
Î
Î
ÎÎ
Î
V
OL
ООООООО
Î
Maximum Low–Level Output
Voltage
ООООООО
Î
Vin = VIH or V
IL
|I
out
| v 20 µA
ÎÎ
Î
4.5
5.5
ÎÎ
0.1
0.1
ÎÎ
Î
0.1
0.1
ÎÎ
Î
0.1
0.1
Î
Î
V
ÎÎÎОООООООÎООООООО
Î
Vin = VIH or V
IL
|I
out
| v 6 mA
ÎÎ
Î
4.5
ÎÎ
0.26
ÎÎ
Î
0.33
ÎÎ
Î
0.4
Î
Î
I
in
Maximum Input Leakage Current
Vin = VCC or GND
5.5
± 0.1
± 1.0
± 1.0
µA
This device contains protection
circuitry to guard against damage
due to high static voltages or electric
fields. However, precautions must
be taken to avoid applications of any
voltage higher than maximum rated
voltages to this high–impedance circuit. For proper operation, Vin and
V
out
should be constrained to the
range GND v (Vin or V
out
) v VCC.
Unused inputs must always be
tied to an appropriate logic voltage
level (e.g., either GND or VCC).
Unused outputs must be left open.
MC54/74HCT244A
High–Speed CMOS Logic Data
DL129 — Rev 6
3 MOTOROLA
DC ELECTRICAL CHARACTERISTICS (Voltages Referenced to GND)
Unit
Guaranteed Limit
V
CC
V
Test Conditions
Parameter
Symbol
Unit
v
125_C
v
85_C
– 55 to
25_C
V
CC
V
Test Conditions
Parameter
Symbol
ÎÎ
Î
I
OZ
ООООООО
Î
Maximum Three–State
Leakage Current
ООООООО
Î
Output in High–Impedance State
Vin = VIL or V
IH
V
out
= VCC or GND
ÎÎ
Î
5.5
ÎÎ
± 0.5
ÎÎ
Î
± 5.0
ÎÎ
Î
± 10
Î
Î
µA
ÎÎ
Î
I
CC
ООООООО
Î
Maximum Quiescent Supply
Current (per Package)
ООООООО
Î
Vin = VCC or GND
I
out
= 0 µA
ÎÎ
Î
5.5
ÎÎ4ÎÎ
Î
40
ÎÎ
Î
160
Î
Î
µA
∆I
CC
Additional Quiescent Supply
Vin = 2.4 V, Any One Input
=
≥ –55_C
25_C to 125_C
ÎÎ
ООООООО
Current
ООООООО
V
i
n
=
V
CC
or
GND, Other Inputs
l
out
= 0 µA
ÎÎ
5.5
ÎÎÎ
2.9
ÎÎÎ
2.4
Î
mA
NOTES:
1. Information on typical parametric values along with frequency or heavy load considerations can be found in Chapter 2 of the Motorola High–
Speed CMOS Data Book (DL129/D).
2. Total Supply Current = ICC + Σ∆ICC.
AC ELECTRICAL CHARACTERISTICS (V
CC
= 5.0 V ± 10%, CL = 50 pF, Input tr = tf = 6 ns)
Guaranteed Limit
ÎÎ
Î
Symbol
ООООООООООООООООО
Î
Parameter
ÎÎ
Î
– 55 to
25_C
ÎÎ
Î
v
85_C
ÎÎ
Î
v
125_C
Î
Î
Unit
t
PLH
,
t
PHL
Maximum Propagation Delay, A to YA or B to YB
(Figures 1 and 3)
20
25
30
ns
ÎÎ
Î
t
PLZ
,
t
PHZ
ООООООООООООООООО
Î
Maximum Propagation Delay, Output Enable to YA or YB
(Figures 2 and 4)
ÎÎ
Î
26
ÎÎ
Î
33
ÎÎ
Î
39
Î
Î
ns
ÎÎ
Î
t
PZL
,
t
PZH
ООООООООООООООООО
Î
Maximum Propagation Delay, Output Enable to YA or YB
(Figures 2 and 4)
ÎÎ
Î
22
ÎÎ
Î
28
ÎÎ
Î
33
Î
Î
ns
t
TLH
,
t
THL
Maximum Output Transition Time, Any Output
(Figures 1 and 3)
12
15
18
ns
C
in
Maximum Input Capacitance
10
10
10
pF
ÎÎ
Î
C
out
ООООООООООООООООО
Î
Maximum Three–State Output Capacitance (Output in High–Impedance
State)
ÎÎ
Î
15
ÎÎ
Î
15
ÎÎ
Î
15
Î
Î
pF
NOTE:For propagation delays with loads other than 50 pF , and information on typical parametric values, see Chapter 2 of the Motorola High–
Speed CMOS Data Book (DL129/D).
Typical @ 25°C, VCC = 5.0 V
C
PD
Power Dissipation Capacitance (Per Enabled Output)*
55
pF
*Used to determine the no–load dynamic power consumption: PD = CPD V
CC
2
f + ICC VCC. For load considerations, see Chapter 2 of the
Motorola High–Speed CMOS Data Book (DL129/D).
SWITCHING W AVEFORMS
Figure 1. Figure 2.
3 V
GND
t
f
t
r
INPUT
A OR B
OUTPUT
YA OR YB
0.3 V
1.3 V
2.7 V
10%
1.3 V
90%
t
TLH
t
PLH
t
PHL
t
THL
ENABLE
A OR B
OUTPUT Y
OUTPUT Y
1.3 V
1.3 V
1.3 V
90%
10%
t
PZL
t
PLZ
t
PZHtPHZ
3 V
GND
HIGH
IMPEDANCE
V
OL
V
OH
HIGH
IMPEDANCE
MC54/74HCT244A
MOTOROLA High–Speed CMOS Logic Data
DL129 — Rev 6
4
TEST CIRCUITS
*Includes all probe and jig capacitance
CL*
TEST POINT
DEVICE
UNDER
TEST
OUTPUT
Figure 3.
*Includes all probe and jig capacitance
CL*
TEST POINT
DEVICE
UNDER
TEST
OUTPUT
Figure 4.
CONNECT TO VCC WHEN
TESTING t
PLZ
AND t
PZL
.
CONNECT TO GND WHEN
TESTING t
PHZ
AND t
PZH
.
1 k
Ω
LOGIC DETAIL
DATA INPUT
A OR B
ENABLE A OR ENABLE B
TO THREE OTHER
A OR B INVERTERS
ONE OF 8
BUFFERS
YA
OR
YB
V
CC
MC54/74HCT244A
High–Speed CMOS Logic Data
DL129 — Rev 6
5 MOTOROLA
OUTLINE DIMENSIONS
J SUFFIX
CERAMIC PACKAGE
CASE 732–03
ISSUE E
N SUFFIX
PLASTIC PACKAGE
CASE 738–03
ISSUE E
DW SUFFIX
PLASTIC SOIC PACKAGE
CASE 751D–04
ISSUE E
NOTES:
1. LEADS WITHIN 0.25 (0.010) DIAMETER, TRUE
POSITION AT SEATING PLANE, AT MAXIMUM
MATERIAL CONDITION.
2. DIMENSION L TO CENTER OF LEADS WHEN
FORMED PARALLEL.
3. DIMENSIONS A AND B INCLUDE MENISCUS.
DIM MIN MAX MIN MAX
INCHESMILLIMETERS
A 23.88 25.15 0.940 0.990
B 6.60 7.49 0.260 0.295
C 3.81 5.08 0.150 0.200
D 0.38 0.56 0.015 0.022
F 1.40 1.65 0.055 0.065
G 2.54 BSC 0.100 BSC
H 0.51 1.27 0.020 0.050
J 0.20 0.30 0.008 0.012
K 3.18 4.06 0.125 0.160
L 7.62 BSC 0.300 BSC
M 0 15 0 15
N 0.25 1.02 0.010 0.040
____
A
20
110
11
B
F
C
SEATING
PLANE
D
H
G
K
N
J
M
L
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. DIMENSION L TO CENTER OF LEAD WHEN
FORMED PARALLEL.
4. DIMENSION B DOES NOT INCLUDE MOLD
FLASH.
M
L
J
20 PL
M
B
M
0.25 (0.010) T
DIM MIN MAX MIN MAX
MILLIMETERSINCHES
A 25.66 27.171.010 1.070
B 6.10 6.600.240 0.260
C 3.81 4.570.150 0.180
D 0.39 0.550.015 0.022
G 2.54 BSC0.100 BSC
J 0.21 0.380.008 0.015
K 2.80 3.550.110 0.140
L 7.62 BSC0.300 BSC
M 0 15 0 15
N 0.51 1.010.020 0.040
____
E
1.27 1.770.050 0.070
1
11
10
20
–A–
SEATING
PLANE
K
N
FG
D
20 PL
–T–
M
A
M
0.25 (0.010) T
E
B
C
F
1.27 BSC0.050 BSC
NOTES:
1. DIMENSIONING AND TOLERANCING PER
ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETER.
3. DIMENSIONS A AND B DO NOT INCLUDE
MOLD PROTRUSION.
4. MAXIMUM MOLD PROTRUSION 0.150
(0.006) PER SIDE.
5. DIMENSION D DOES NOT INCLUDE
DAMBAR PROTRUSION. ALLOWABLE
DAMBAR PROTRUSION SHALL BE 0.13
(0.005) TOTAL IN EXCESS OF D DIMENSION
AT MAXIMUM MATERIAL CONDITION.
–A–
–B–
20
1
11
10
S
A
M
0.010 (0.25) B
S
T
D20X
M
B
M
0.010 (0.25)
P10X
J
F
G
18X
K
C
–T–
SEATING
PLANE
M
R
X 45
_
DIM MIN MAX MIN MAX
INCHESMILLIMETERS
A 12.65 12.95 0.499 0.510
B 7.40 7.60 0.292 0.299
C 2.35 2.65 0.093 0.104
D 0.35 0.49 0.014 0.019
F 0.50 0.90 0.020 0.035
G 1.27 BSC 0.050 BSC
J 0.25 0.32 0.010 0.012
K 0.10 0.25 0.004 0.009
M 0 7 0 7
P 10.05 10.55 0.395 0.415
R 0.25 0.75 0.010 0.029
__
__
MC54/74HCT244A
MOTOROLA High–Speed CMOS Logic Data
DL129 — Rev 6
6
OUTLINE DIMENSIONS
DT SUFFIX
PLASTIC TSSOP PACKAGE
CASE 948E–02
ISSUE A
DIMAMIN MAX MIN MAX
INCHES
6.60 0.260
MILLIMETERS
B 4.30 4.50 0.169 0.177
C 1.20 0.047
D 0.05 0.15 0.002 0.006
F 0.50 0.75 0.020 0.030
G 0.65 BSC 0.026 BSC
H 0.27 0.37 0.011 0.015
J 0.09 0.20 0.004 0.008
J1 0.09 0.16 0.004 0.006
K 0.19 0.30 0.007 0.012
K1 0.19 0.25 0.007 0.010
L 6.40 BSC 0.252 BSC
M 0 8 0 8
____
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETER.
3. DIMENSION A DOES NOT INCLUDE MOLD FLASH,
PROTRUSIONS OR GATE BURRS. MOLD FLASH
OR GATE BURRS SHALL NOT EXCEED 0.15
(0.006) PER SIDE.
4. DIMENSION B DOES NOT INCLUDE INTERLEAD
FLASH OR PROTRUSION. INTERLEAD FLASH OR
PROTRUSION SHALL NOT EXCEED 0.25 (0.010)
PER SIDE.
5. DIMENSION K DOES NOT INCLUDE DAMBAR
PROTRUSION. ALLOWABLE DAMBAR
PROTRUSION SHALL BE 0.08 (0.003) TOTAL IN
EXCESS OF THE K DIMENSION AT MAXIMUM
MATERIAL CONDITION.
6. TERMINAL NUMBERS ARE SHOWN FOR
REFERENCE ONLY.
7. DIMENSION A AND B ARE TO BE DETERMINED
AT DATUM PLANE –W–.
110
1120
PIN 1
IDENT
A
B
–T–
0.100 (0.004)
C
D
G
H
SECTION N–N
K
K1
JJ1
N
N
M
F
–W–
SEATING
PLANE
–V–
–U–
S
U
M
0.10 (0.004) V
S
T
20X REFK
L
L/2
2X
S
U0.15 (0.006) T
DETAIL E
0.25 (0.010)
DETAIL E
6.40 0.252
––– –––
S
U0.15 (0.006) T
SD SUFFIX
PLASTIC SSOP PACKAGE
CASE 940C–03
ISSUE B
20 11
101
H
A
B
F
M
K20X REF
S
U
M
0.12 (0.005) V
S
T
L
L/2
PIN 1
IDENT
S
U
M
0.20 (0.008) T
–V–
–U–
D
C
0.076 (0.003)
G
–T–
SEATING
PLANE
DETAIL E
N
N
0.25 (0.010)
K
J
J1
K1
SECTION N–N
DIMAMIN MAX MIN MAX
INCHES
7.07 7.33 0.278 0.288
MILLIMETERS
B 5.20 5.38 0.205 0.212
C 1.73 1.99 0.068 0.078
D 0.05 0.21 0.002 0.008
F 0.63 0.95 0.024 0.037
G 0.65 BSC 0.026 BSC
H 0.59 0.75 0.023 0.030
J 0.09 0.20 0.003 0.008
J1 0.09 0.16 0.003 0.006
K 0.25 0.38 0.010 0.015
K1 0.25 0.33 0.010 0.013
____
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETER.
3. DIMENSION A DOES NOT INCLUDE MOLD FLASH,
PROTRUSIONS OR GATE BURRS. MOLD FLASH OR
GATE BURRS SHALL NOT EXCEED 0.15 (0.006) PER
SIDE.
4. DIMENSION B DOES NOT INCLUDE INTERLEAD
FLASH OR PROTRUSION. INTERLEAD FLASH OR
PROTRUSION SHALL NOT EXCEED 0.15 (0.006) PER
SIDE.
5. DIMENSION K DOES NOT INCLUDE DAMBAR
PROTRUSION/INTRUSION. ALLOWABLE DAMBAR
PROTRUSION SHALL BE 0.13 (0.005) TOTAL IN
EXCESS OF K DIMENSION AT MAXIMUM MATERIAL
CONDITION. DAMBAR INTRUSION SHALL NOT
REDUCE DIMENSION K BY MORE THAN 0.07 (0.002)
AT LEAST MATERIAL CONDITION.
6. TERMINAL NUMBERS ARE SHOWN FOR REFERENCE
ONLY.
7. DIMENSION A AND B ARE TO BE DETERMINED AT
DATUM PLANE –W–.
L 7.65 7.90 0.301 0.311
M 0 8 0 8
DETAIL E
–W–
MC54/74HCT244A
High–Speed CMOS Logic Data
DL129 — Rev 6
7 MOTOROLA
Motorola reserves the right to make changes without further notice to any products herein. Motorola makes no warranty , representation or guarantee regarding
the suitability of its products for any particular purpose, nor does Motorola assume any liability arising out of the application or use of any product or circuit, and
specifically disclaims any and all liability, including without limitation consequential or incidental damages. “T ypical” parameters which may be provided in Motorola
data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals”
must be validated for each customer application by customer’s technical experts. Motorola does not convey any license under its patent rights nor the rights of
others. Motorola products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other
applications intended to support or sustain life, or for any other application in which the failure of the Motorola product could create a situation where personal injury
or death may occur. Should Buyer purchase or use Motorola products for any such unintended or unauthorized application, Buyer shall indemnify and hold Motorola
and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees
arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that
Motorola was negligent regarding the design or manufacture of the part. Motorola and are registered trademarks of Motorola, Inc. Motorola, Inc. is an Equal
Opportunity/Affirmative Action Employer.
Mfax is a trademark of Motorola, Inc.
How to reach us:
USA/EUROPE /Locations Not Listed: Motorola Literature Distribution; JAPAN: Nippon Motorola Ltd.; Tatsumi–SPD–JLDC, 6F Seibu–Butsuryu–Center,
P.O. Box 5405, Denver, Colorado 80217. 303–675–2140 or 1–800–441–2447 3–14–2 Ta tsumi Koto–Ku, Tokyo 135, Japan. 81–3–3521–8315
Mfax: RMFAX0@email.sps.mot.com – TOUCHTONE 602–244–6609 ASIA/PACIFIC: Motorola Semiconductors H.K. Ltd.; 8B Tai Ping Industrial Park,
– US & Canada ONLY 1–800–774–1848 51 Ting Kok Road, Ta i Po, N.T., Hong Kong. 852–26629298
INTERNET: http://www.mot.com/SPS/
MC74HCT244A/D
◊
Loading...
