User Guide

i776 by Motorola

www.nextel.com

8/6/08

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com

Note: Do not ship your phone to the above address. If you need to return your phone for repairs, replacement or warranty service, please contact the Motorola Customer Support Center at:

1-800-453-0920 (United States) 1-877-483-2840 (TTY/TDD United States for hearing impaired)

Product Support:

www.motorola.com/support

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

Manual number: NNTN7499A

FCC Notice to Users

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID: IHDP56HS1 on the product label.

Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15. 21.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

䢇 Reorient or relocate the receiving antenna. 䢇 Increase the separation between the equipment and the

receiver.

䢇 Connect the equipment to an outlet on a circuit different from

that to which the receiver is connected.

䢇 Consult the dealer or an experienced radio/TV technician for

help.

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

Your Phone’s Menu. . . . . . . . . . . . . . . . . . . . . . . . ii

Use and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Section 1: Getting Started. . . . . . . . . . . . . . . . . . 1

1A. Setting Up Service . . . . . . . . . . . . . . . . . . . . 2

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . 2

Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . 3

Setting Up Your Voicemail . . . . . . . . . . . . . . . . . . . 3

Enabling Security . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Account Passwords . . . . . . . . . . . . . . . . . . . . . . . . . 4

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1B. Phone Basics . . . . . . . . . . . . . . . . . . . . . . . . 6

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Getting Started With Your Phone . . . . . . . . . . . . . . 8

Features of Your Phone . . . . . . . . . . . . . . . . . . . . . 15

Navigating Through Phone Menus

and Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Displaying Your Phone Number and

Direct Connect Number . . . . . . . . . . . . . . . . . . . . 19

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Section 2: Using Your Phone. . . . . . . . . . . . . . . 27

2A. Making and Answering Calls . . . . . . . . . . 28

Types of Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Making and Answering Phone Calls . . . . . . . . . 29

Making and Answering Direct Connect Calls . 36 Making and Answering Group Connect Calls . 39

Nextel Direct Send . . . . . . . . . . . . . . . . . . . . . . . . . 44

Making and Answering Talkgroup Calls . . . . . . 51

Call Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Making and Answering Direct Talk Calls . . . . . . 55

2B. Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Using the Settings Menu . . . . . . . . . . . . . . . . . . . 60

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Messaging Settings . . . . . . . . . . . . . . . . . . . . . . . . 71

Temporarily Turning Off Transmissions

(Airplane Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Setting One Touch Direct Connect . . . . . . . . . . . 74

Headset Options . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Phone Setup Options . . . . . . . . . . . . . . . . . . . . . . 80

2C. Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

SIM Card Security . . . . . . . . . . . . . . . . . . . . . . . . . 84

Your Phone’s Lock Feature . . . . . . . . . . . . . . . . . 86

Your Phone’s Keypad Lock . . . . . . . . . . . . . . . . . 86

Resetting Your Phone . . . . . . . . . . . . . . . . . . . . . . 87

GPS Privacy Options . . . . . . . . . . . . . . . . . . . . . . . 88

Java Applications & GPS Security . . . . . . . . . . . 89

2D. Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . 92

About Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . 92

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . 95

Recent Calls Options . . . . . . . . . . . . . . . . . . . . . . 95

Saving Items From Recent Calls . . . . . . . . . . . . . 96

Deleting Items From Recent Calls . . . . . . . . . . . 96

Prepending a Phone Number From

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

2E. Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

About Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Creating Contacts Entries . . . . . . . . . . . . . . . . . . . 99

Viewing Contacts . . . . . . . . . . . . . . . . . . . . . . . . . 102

Adding a Number or Address to an Entry . . . 103

Editing Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Deleting Entries . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Assigning Speed Dial Numbers . . . . . . . . . . . . 104

Selecting a Ringer Type for an Entry . . . . . . . . 105

Checking Capacity . . . . . . . . . . . . . . . . . . . . . . . 105

Dialing Nextel Customer Service . . . . . . . . . . . 105

2F. Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Datebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Java Applications . . . . . . . . . . . . . . . . . . . . . . . . 113

Digital Rights Management (DRM) . . . . . . . . . 117

GPS Enabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Memo Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Voice Records . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Media Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Call Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

2G. Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Taking Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Camera Options . . . . . . . . . . . . . . . . . . . . . . . . . 136

2H. Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Turning Bluetooth On and Off . . . . . . . . . . . . . . 138

Using the Bluetooth Menu . . . . . . . . . . . . . . . . . 139

Pairing Bluetooth Devices . . . . . . . . . . . . . . . . . 140

Transferring Items Via Bluetooth . . . . . . . . . . . 146

Section 3: Service Features . . . . . . . . . . . . . . 149

3A. Service Features: The Basics . . . . . . . . 150

Message Center . . . . . . . . . . . . . . . . . . . . . . . . . 150

Receiving Messages . . . . . . . . . . . . . . . . . . . . . . 151

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Multimedia Messages . . . . . . . . . . . . . . . . . . . . 154

Text Messaging (SMS) . . . . . . . . . . . . . . . . . . . . . 173

Caller ID Blocking . . . . . . . . . . . . . . . . . . . . . . . . 174

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Putting a Call on Hold and Making a

Second Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Making a Three-Way Call . . . . . . . . . . . . . . . . . . 176

Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Making International Calls . . . . . . . . . . . . . . . . . 179

Special Dialing Codes . . . . . . . . . . . . . . . . . . . . . 179

Nextel Phone Services . . . . . . . . . . . . . . . . . . . 180

3B. Data Services . . . . . . . . . . . . . . . . . . . . . . 182

Wireless Data Services . . . . . . . . . . . . . . . . . . . 182

Downloading Content . . . . . . . . . . . . . . . . . . . . 185

Using Your Phone as a Modem . . . . . . . . . . . 185

Section 4: Safety and Warranty

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

4A. Important Safety Information . . . . . . . . 190

General Precautions . . . . . . . . . . . . . . . . . . . . . . 190

Maintaining Safe Use of and Access to

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Using Your Phone With a Hearing

Aid Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Caring for the Environment by Recycling . . . . 195

Caring for the Battery . . . . . . . . . . . . . . . . . . . . . 195

Export Law Assurances . . . . . . . . . . . . . . . . . . . 197

Radio Frequency (RF) Energy . . . . . . . . . . . . . . 198

Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Patent and Trademark Information . . . . . . . . . . 201

Software Copyright Notice . . . . . . . . . . . . . . . . . 201

Privacy and Data Security . . . . . . . . . . . . . . . . . 202

Smart Practices While Driving . . . . . . . . . . . . . . 202

4B. Manufacturer’s Warranty . . . . . . . . . . . . 204

Motorola Limited Warranty

for the United States and Canada . . . . . . . . . . 204

Service and Repairs . . . . . . . . . . . . . . . . . . . . . . 209

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Introduction

This User Guide introduces you to your wireless service and all the features of your new phone. It’s divided into four sections:

⽧ Section 1: Getting Started

⽧ Section 2: Using Your Phone

⽧ Section 3: Service Features

⽧ Section 4: Safety and Warranty Information

Throughout this guide, you’ll find tips that highlight special shortcuts and timely reminders to help you make the most of your new phone and service. The Table of Contents and Index will also help you quickly locate specific information.

You’ll get the most out of your phone if you read each section. However, if you’d like to get right to a specific feature, simply locate that section in the Table of Contents and go directly to that page. Follow the instructions in that section, and you’ll be ready to use your phone in no time.

User Guide Note

WARNING

Because of updates in phone software, this printed guide may not be the most current version for your phone. Visit and sign in to access the most recent version of the user guide.

Please refer to the Important Safety Information section on page 190 to learn about information that will help you safely use your phone. Failure to read and follow the Important Safety Information in this phone guide may result in serious bodily injury, death, or property damage.

www.nextel.com

Your Phone’s Menu

The following table outlines your phone’s menu structure. For more information about using your phone’s menus, see “Navigating Through Phone Menus and Options” on page 18.

Net

Java Apps

Settings

1: Display/Info

1: Wallpaper

1: Buy Wallpapers 2: Auto Cycle 3: Wallpaper

2: Text Size

1: Zoom 2: Standard 3: Compressed

3: Theme

1: Onyx 2: Blue Ice 3: Crimson

4: Home Icons

5: Backlight

6: Clock

7: Menu View

1: Icon View 2: List View

8: Large Dialing

9: Language

2: Phone Calls

1: S et Li ne

2: Any Key Ans

3: Auto Redial

4: Call Waiting

5: Auto Ans

6: Flip Activation

7: Minute Beep

8: Call Duration

9: TTY

10: Hearing Aid

11: Notifications

12: DTMF Dialing

13: Prepend

3: DC/GC Options

1: Tkgrp Silent

2: Tkgrp Area

3: One Touch DC

4: Alert Type

5: On/Off Settings

6: Store Rcvd Info

7: PTT Backlight

4: Personalize

1: Menu Options

1: Reorder Menu 2: Add/Remove Apps

2: Up Key

3: Down Key

4: Left Key

5: Right Key

6: Center Key

7: Left Sftkey

8: Right Sftkey

9: Power Up

5: Volume

6: Security

1: Phone Lock

2: Keypad Lock

3: SIM PIN

4: GPS PIN

5: Change Passwds

7: A dva nced

1: Alert Timeout

2: Headset/Spkr

3: Connectivity

4: Reset Defaults

5: Return to Home

6: Transmitters

iii

7: Baud Rate

Ring Tones

1: Buy Ring Tones

2: Vibr ate A ll

3: < list of ringtones >

4: Vibrate

5: Silent

Contacts

Messages

1: [ Crea te M esg]

2: Voice Mail

3: Inbox

4: Drafts

5: Sent Items

6: Net Alert

7: S MS

Call Forward

Downloads

Bluetooth

1: H ands Free

2: Link to Devices

3: Device History

4: Setup

5: Find Me

My Info

Direct Talk

1: Go To Direct Talk

2: Setu p

1: Direct Launch

2: State Tone

3: Help

Direct Connect

VoiceRecord

GPS

1: Pos it ion

2: Privacy

3: Interface

Datebook

Memo

Call Timers

1: Last Call

2: Phone Reset

3: Phone Lifetime

4: DC/GC Reset

5: DC/GC Lifetime

6: Kbytes Reset

Recent Calls

Shortcuts

Profiles

1: [New Profile]

2: Standard

3: Car

4: Meeting

5: Office

6: Outdoors

7: H ead set

8: PRVT Only

9: CONTCS Only

10: Surveillance

Call Alert

Camera

Media Center

a.The Messaging menus may look slightly different, depending on the messaging setup of your phone.

Please keep in mind that the menu options and order shown here may change as updates become available and as you set your own preferences through the

Settings > Personalize > Menu Options feature.

Use and Care

To care for your Motorola phone, keep it away from:

liquids of any kind

Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture.

extreme heat or cold

Avoid temperatures below -10°C/14°F or above 45°C/113°F.

microwaves

Don’t try to dry your phone in a microwave oven.

dust and dirt

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.

cleaning solution s

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

the ground

Don’t drop your phone.

Section 1

Getting Started

Section 1A

Setting Up Your Phone

Setting Up Service

⽧ Setting Up Your Phone (page 2)

⽧ Activating Your Phone (page 3)

⽧ Setting Up Your Voicemail (page 3)

⽧ Enabling Security (page 4)

⽧ Account Passwords (page 4)

⽧ Getting Help (page 5)

Setting up service on your new phone is quick and easy.

section walks you through the necessary steps to unlock your phone, set up your voicemail, establish passwords, and contact Nextel for assistance with your wireless service.

2 Section 1A. Setting Up Service

This

1. Make Sure your SIM card is in Place.

2. Install the battery.

䡲 See “Installing the Battery” on page 11.

3. Press P to turn the phone on.

䡲 If your phone is activated, it will turn on, search for

service, and enter standby mode.

䡲 If your phone is not yet activated, see “Activating

Your Phone” on page 3 for more information.

You may see a prompt to update your browser

Note

information. Press the left softkey (the top left key below the display screen) to select the task.

Ok and complete

4. Make your first call.

䡲 Use your keypad to enter a phone number. 䡲 Press N.

Your phone’s battery should have enough charge for

Note

your phone to turn on and find a signal, set up your voicemail, and make a call. You should fully charge your battery as soon as possible. See “Charging the Battery” on page 12 for details.

encounter security messages, call Nextel Customer Service at 1-800-639-6111 from any other phone.

Setting Up Your Voicemail

Activating Your Phone

䢇 If you purchased your phone at a Nextel Store, it is

probably activated and ready to use.

䢇 If your phone is not activated, please call Nextel

Customer Service at 1-800-639-6111 from any other phone.

You must be in an area covered by the Nextel

Tip

National Network when you first power up your phone.

䢇 When you power up your phone the first time, it

performs a series of security checks. For example, it verifies the phone is Nextel-approved and the correct SIM card is installed. If you don’t pass the security checks, your phone displays messages and screen prompts showing what to do next. If you still

All unanswered calls to your phone are automatically transferred to your voicemail, even if your phone is in use or turned off. Therefore, it is recommended that you set up your voicemail and personal greeting as soon as your phone is activated.

1. Using your i776 phone, call your wireless phone

number.

2. Follow the system prompts to:

䡲 Create your passcode. 䡲 Record your name announcement. 䡲 Record your greeting.

For more information about using your voicemail, see “Voicemail” on page 153.

Section 1A. Setting Up Service 3

Setting Up Service

Enabling Security

Account Passwords

You must enable security the first time you power on your phone or within ten days of first activation of your phone.

1. Press and hold P for two seconds to power on

your phone.

2. Press Ok (right softkey).

3. You are prompted to enable security. Press Yes

(right softkey). A series of screens followed by the default homepage displays.

4. Press P to return to standby mode.

4 Section 1A. Setting Up Service

With Nextel service, you enjoy unlimited access to your personal account information and voicemail account. To ensure that no one else has access to your information, you need to create passwords to protect your privacy.

Account Username and Password

If you are the account owner, you will create an account username and password when you sign on to

www.nextel.com. (Click Need to register for access? to get

started.) If you are not the account owner (if someone else receives the bill for your service), you can get a sub-account password at

When you go to www.nextel.com, you will be

Note

redirec ted to sign in instructions above to access your Nextel account.

www.nextel.com.

www.sprint.com by default. Follow the

Voicemail Password

You’ll create your voicemail password (or passcode) when you set up your voicemail. See “Setting Up Your Voicemail” on page 3 for more information on your voicemail password.

Getting Help

Managing Your Account

Online: www.nextel.com

䢇 Access your account information. 䢇 Check your minutes used (depending on your

service plan).

䢇 View and pay your bill. 䢇 Enroll for online billing and automatic payment. 䢇 Purchase accessories. 䢇 Shop for the latest phones. 䢇 View available service plans and options.

From Your i776 Phone

䢇 Press

N to check minute usage and account

balance.

䢇 Press

N to make a payment.

From Any Other Phone

䢇 Nextel Customer Service: 1-800-639-6111. 䢇 Business Customer Service: 1-800-3 90-9545

Operator Services

Operator Services provides assistance when you place collect calls or when you place calls billed to a local telephone calling card or third party.

䊳 Press

For more information or to see the latest in products and services, visit us online at

www.nextel.com.

Section 1A. Setting Up Service 5

Setting Up Service

Section 1B

21. External Display Screen

12. Display Screen

7. Charger Connector

14. Smart Button

16. Camera Lens

17. Volume Button

1. Left Softkey

11. Right Softkey

4. Navigation Key

9. End/Power Key

3. Talk Key

10. Camera Key

2. Menu Key

15. Speaker Button

18. Direct Connect Button

5. Headset Jack

8. OK key

6. Speaker/Microphone

13. Antenna

20. Messaging LED

19. Bluetooth LED

Phone Basics

⽧ Your Phone (page 6)

⽧ Getting Started With Your Phone (page 8)

⽧ Features of Your Phone (page 15)

⽧ Navigating Through Phone Menus and Options (page 18)

⽧ Displaying Your Phone Numbe r and Direct Connect

Number (page 19)

⽧ Entering Text (page 21)

⽧ Accessories (page 25)

Your phone is packed with features that simplify your life and expand your ability to stay connected to the people and information that are important to you.

you through the basic functions and calling features of your phone.

6 Section 1B. Phone Basics

This section will guide

Your Phone

Key Functions

1. Left Softkey (-) lets you select softkey actions or

menu items corresponding to the bottom left line on the display screen.

2. Menu (M) lets you access the phone’s menu from

standby mode and allows you to access contextsensitive menus from other screens.

3. Talk K ey (N) allows you to place or receive calls,

answer Call Waiting, or use Three-Way Calling.

4. Navigation Key scrolls through the phone’s menu

options and acts as a shortcut key from standby mode.

䡲 Press Up to access Ringtones. 䡲 Press Down to access Recent Calls. 䡲 Press Right to launch Java Applications. 䡲 Press Lef t to access Net.

5. Headset Jack allows you to plug in either a stereo

headset or an optional headset for convenient, hands-free conversations. Your Direct Connect headset can only use this connector.

WARNING

Inserting an accessory into the incorrect jack may damage the phone.

6. Speaker/Microphone lets you hear the caller and

automated phone prompts when using speakerphone mode and allows other callers to hear you clearly when you are speaking to them.

7. Charger Connector allows you to connect your

battery charger or other accessories to your phone.

8. OK Key (r) selects the highlighted choice when

navigating through a menu.

9. End/Power Key (P) allows you to end calls, return to

standby mode, or turn the phone on or off.

10. Camera Key (e) allows you to activate the phone’s

built-in camera.

11. Right Softkey (-) lets you select softkey actions

corresponding to the bottom right line on the display screen.

12. Display Screen displays all the information needed to

operate your phone, such as the call status, the Contacts list, the date and time, and the signal and battery strength.

Section 1B. Phone Basics 7

Phone Basics

Antenna delivers the best receiption when fully

13.

extended.

14 . Smart Button (() anticipates the next action you

are likely to perform. For example, when you highlight a menu item, you can press the

to select it. You can also use the Smar t Button

Button

Smart

to make and end calls, navigate menus or exit applications when your phone is closed.

15. Speaker B utton ()) lets you place or receive calls in

speaker mode. In standby mode, pressing the speaker button turns Direct Connect speaker mode on and off.

16. Camera Lens lets you capture clear pictures and videos.

17. Vo lume B utton allows you to adjust the ringer

volume in standby mode (with the phone open) or adjust the voice volume during a call. The volume key can also be used to scroll up or down to navigate through the different menu options.

18. Direct Connect Button allows you to use Nextel

Direct Connect on your Nextel phone. (See “Making and Answering Direct Connect Calls” on page 36.)

8 Section 1B. Phone Basics

19. Bluet ooth LED glows solid while the device is pairing

to a Bluetooth accessory or is discoverable and blinks while connected. The LED turns off when no Bluetooth accessories are connected to the device.

20. Messaging LED blinks when new messages are

received.

21. External Display Screen provides information about

your phone’s status and options.

The use of wireless phones while driving may cause

Note

distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain area is. Always obey the laws and regulations on the use of these products.

Getting Started With Your Phone

To start using your i776 phone:

䢇 Make sure your SIM card is in place. 䢇 Charge the battery. 䢇 Turn on your phone.

After you’ve completed these items, you are ready to begin using your new phone.

You r SIM Car d

Locating the SIM Card

Your SIM (Subscriber Identity Module) card is a small card inserted into the SIM card holder within your phone behind the battery area.

If no SIM card came with your phone, contact Nextel Customer Service at 1-800-639-6111.

Most users will never need to remove or insert the SIM card. However, if you wish to, follow the instructions in “Removing and Inserting the SIM Card” on page 9.

Important

The SIM card is designed for optimal Contacts storage and feature use. For Nextel SIM card compatibility information, visit

www.nextel.com/sim.

In some cases, Contacts and Groups may not be accessible if you move your SIM card to another phone. Contacts and Groups created with your i776 phone may not be readable by an older iDEN SIM-based phone.

Removing and Inserting the SIM Card

Important

To remove your SIM card:

1. With your phone powered off, remove the battery

door and battery. See “Removing the Battery” on page 12.

2. Lift the rubber flap directly above the SIM card

holder, and then with your fingernail, carefully slide the SIM card out from under the edge.

To avoid losing information stored in your SIM card, do not remove it from your phone unless absolutely necessary.

Section 1B. Phone Basics 9

Phone Basics

Protect your SIM card as you would any delicate

Note

object. Store it carefully.

To insert your SIM card:

1. With your phone powered off, remove the battery

door and battery. See “Removing the Battery” on page 12.

2. Lift the rubber flap directly above the SIM card

holde r, and then carefully slide the SI M card int o your phone, until it lies flat in the SIM card holder.

Important

Do not touch the gold-colored areas of your SIM card.

10 Section 1B. Phone Basics

Using Your Phone’s Battery and Charger

WARNING

Nextel-approved and Motorola -approved batteries and accessories can be found at Sprint Stores or through Motorola. You may order online at calling1-866-866-7509.

Battery Capacity

Your phone is equipped with a Lithium Ion (Li-Ion) battery. It allows you to recharge your battery before it is fully drained.

When the battery reaches 5% of its capacity, your phone makes a sound and displays a message. When there are approximately two minutes of talk time left, the phone sounds an audible alert and then turns off.

Use only Nextel-approved or Motorolaapproved batteries and chargers with your phone. The failure to use a Nextel-approved or Motorola-approved battery and charger may increase the risk that your phone will overheat, catch fire, or explode, resulting in serious bodily injury, death, or property damage.

www.nextel.com or by

Long backlight settings, searching for service, vibrate

Note

mode, browser use, and other variables may reduce the battery’s talk and standby times.

Watch your phone’s battery level indicator and

Tip

charge the battery before it runs out of power.

Installing the Battery

1. With your thumbs, press down on the battery cover

on the back of your phone and slide it up toward the antenna to release it.

2. Remove the battery cover from the back of the

phone

Phone Basics

3. Insert the battery into the opening, making sure the

connectors align. Gently press down to secure the battery.

Section 1B. Phone Basics 11

Replace the battery cover and press down until

you hear a click.

Removing the Battery

1. Make sure the power is off so that you don’t lose

any stored numbers or messages.

2. Remove the battery cover and remove the battery

from the phone.

WARNING

12 Section 1B. Phone Basics

Do not handle a damaged or leaking Li-Ion battery as you can be burned.

Charging the Battery

Charge your battery as soon as possible so you can begin using your phone.

Keeping track of your battery’s charge is important. If your battery level becomes too low, your phone automatically turns off, and you will lose any information you were just working on. For a quick check of your battery level, glance at the battery charge indicator located on your display screen.

Always use a Nextel-approved or Motorola-approved desktop charger, travel charger, or vehicle power adapter to charge your battery.

Using the Phone Charger

䊳 Plug the flat end of the charger into the phone’s

charger connector and the other end into an electrical outlet.

● Your display screen lets you know the battery

is charging.

● Both the battery icon and a text message

show the charging status.

With the approved Li-Ion battery, you can recharge the battery before it becomes completely run down.

Battery Use and Battery Safety

䢇 Motorola recommends you always use Motorola-branded

batteries and chargers.

damage caused by non-Motorola batteries and/or chargers.

WARNING

䢇 Battery usage by children should be supervised.

The warranty does not cover

Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard. Improper battery use, or use of a damaged battery, may result in a fire, explosion, or other hazard.

Section 1B. Phone Basics 13

Phone Basics

Important

䢇 New batteries or batteries stored for a long time may

Motorola mobile devices are designed to work best with qualified batteries. If you see a message on your display such as

Battery

or Unable to Charge, take the

following steps:

• Remove the battery and inspect it to confirm that it bears a Motorola “Original Equipment” hologram;

• If there is no hologram, the battery is not a qualified battery;

• If there is a hologram, replace the battery and retry charging it;

• If the message remains, contact a Motorola Authorized Service Center.

Invalid

take more time to charge.

䢇 Charging precautions: When charging your battery,

keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging. Always take your mobile device with you when you leave your vehicle.

䢇 When storing your battery, keep it in a cool, dry

place.

14 Section 1B. Phone Basics

䢇 It is normal for battery life to decrease over time, and

for the battery to exhibit shorter runtime between charges or require more frequent or longer charging times.

䢇 Avoid damage to battery and mobile device. Do not

disassemble, open, crush, bend, deform, puncture, shred, or submerge the battery or mobile device. Avoid dropping the battery or mobile device, especially on a hard surface. If your battery or mobile device has been subjected to such damage, take it to a Motorola Authorized Service Center before

Do not attempt to dry it with an appliance or

using. heat source, such as a hair dryer or microwave oven.

䢇 Use care when handling a charged battery — particularly

when placing it inside a pocket, purse, or other container with metal objects. Contact with metal objects (e.g., jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which could cause damage or injury.

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center for proper battery disposal.

WARNING

Never dispose of batteries in a fire because they may explode.

Turning Your Phone On and Off

Turning Your Phone On

䊳 Press and hold P for approximately two seconds.

As your phone connects to the network, you see a connecting message. Your phone may require you to enter identifying information to use it or to access specific features.

Turning Your Phone Off

䊳 Press and hold P for two seconds until you see

the powering down animation on the display screen.

Your screen remains blank while your phone is off (unless the battery is charging).

Features of Your Phone

The i776 is easy to use, and reliable, and it offers many features and service options. This list previews some of those features and provides page numbers where you can find out more:

䢇 Nextel Direct Connect provides instant, coast-to-coast

2-way “walkie-talkie-style” communication at the click of a button (page 36).

䢇 Nextel Direct Talk allows for two-way radio

communication “off the network” between two or more phones equipped with this capability (page 55).

䢇 Text Messaging (also known as Multimedia

Messaging), provides quick and convenient messaging capabilities (page 154).

䢇 Built-in Speakerphone allows you to enjoy easy

hands-free communication.

䢇 Games, ringers, s creen savers , and other applications can

be downloaded to make your phone as unique as you are (page 185). Additional charges may apply.

Section 1B. Phone Basics 15

Phone Basics

䢇 Your Co ntacts list allows you to store up to 600

entries, with several numbers or addresses per entry (page 98).

䢇 The built-in Datebook offers several personal

information management features to help you manage your busy lifestyle (page 106).

䢇 The GPS Enabled feature works in connection with

available location-based services (page 118).

䢇 Word English Text Input lets you quickly type messages

with one keypress per letter (page 21).

䢇 Bluetooth

capability that allows you to wirelessly connect to other Bluetooth enabled devices (page 138).

䢇 Speed dial lets you dial phone numbers quickly

(page 35).

Viewing the Status Information

Your phone’s display screen provides information about your phone’s status and options. This list identifies the symbols you’ll see on your phone’s display screen:

16 Section 1B. Phone Basics

abc def gd

opq rs

Battery Strength — A fuller battery indicates a

greater charge.

Signal Strength — More bars next to the

antenna indicate a stronger signal.

No Service — Your phone is without service.

You cannot make or receive any type of call.

Phone In Use — Your phone is active on a

phone call.

Direct Connect In Use — Your phone is active

on a Direct Connect call.

Group In Use — Your phone is active on a

Group Connect call.

Direct Talk — Your phone is off network and

set to Direct Talk mode.

Talkgroup In Use — Your phone is active on a

Talkgroup call.

GLI

JHK

QR M

Bluetooth In Use — Your phone is using

Bluetooth. If this icon is blinking, then your phone is in discoverable mode. If this icon is static, your phone is active in a Bluetooth connection.

Active Phone Line — 1 indicates phone line 1

is ready to make calls; 2 indicates phone line 2 is ready to make calls.

Call Forward — Your phone is set to forward

calls. See “Call Forwarding” on page 176.

Ringer Off — Your phone is set to not ring.

See “Vibrate All” on page 67.

Speaker Off — Direct Connect sound is set to

come through the earpiece rather than through the speaker.

Messages — You have one or more

messages. See “Message Center” on page 150.

QRS

TUV

Y Z

N O

Tex t In pu t — You are using one of the phone’s

text entry methods. See “Selecting a Text Input Mode” on page 21.

Internet — You are ready to browse the

Internet or are browsing the Internet using a secure connection. See “Data Services” on page 182.

Tra nsm itt ers — Your phone is set not to

receive calls and other transmissions. See “Temporarily Turning Off Transmissions (Airplane Mode)” on page 73.

Packet D ata — You are ready to transfer

packet data or are transferring packet data. See “Using Your Phone as a Modem” on page 185.

TTY — You are ready to use your phone to

make calls using a teletypewriter device. See “Telecommunications Relay Service” on page 179.

Section 1B. Phone Basics 17

Phone Basics

Hearing Aid — Your phone is set for use with a

hearing aid and is active on a phone call. See “Using Your Phone With a Hearing Aid Device” on page 193.

Voice Record — You have one or more voice

records stored. See “Voice Records” on page 126.

Navigating Through Phone Menus and Options

The navigation key on your phone lets you scroll through menus quickly and easily.

To navigate through a list-type menu, simply press your navigation key up or down. The scroll bar at the right of the menu keeps track of your position in the menu at all times.

For a diagram of your phone’s menu, please see “Your Phone’s Menu” on page ii.

Many features provide context-sensitive menus that let you access related features and actions. This icon S

18 Section 1B. Phone Basics

appears any time a context-sensitive menu is available. Press M to access the menu

When scrolling through the main menu, it may be

Tip

necessary to select menu options. Depending on which menu view you’re using, either highlight

More (right softkey).

press

More to view additional main

More and press r or

Selecting Menu Items

As you navigate through the menu, menu options are highlighted. Select an item by highlighting it and pressing r

For example, to view your text messages:

1. Press M to access the main menu.

2. Select Messages by highlighting Messages and

3. Select Inbox by highlighting it and pressing r.

Note

pressing r.

(If you have any text messages, they are displayed.)

For the purposes of this guide, the above steps condense into “Press M

> Messages > Inbox.”

Backing Up Within a Menu

To go to the previous menu:

䊳 Press Back (right softkey).

To return to standby mode:

䊳 Press P.

Shortcuts and Personalized Keys

In standby mode, your phone gives you ways to quickly access features you use frequently:

䢇 Use the Shortcuts feature (page 80) to quickly access

most menu options by pressing a number on your keypad or saying the voice name of the shortcut.

䢇 Use the Personalize feature (page 62) to assign main

menu items to the navigation keys, softkeys, r, and M, as well as setting a main menu item to appear

when your turn on your phone.

Help

Your phone contains an in-device help program to help you understand complicated or seldom used features. When you access a feature, appears as a menu item or softkey. Select

Help sometimes

Help and

read the text for a quick overview of the feature. For more information, refer to this guide.

Displaying Your Phone Number and Direct Connect Number

My Info

My Info lets you view your phone number, Direct

Connect number, and other phone information.

To view information about your phone:

1. Press

Note

2. Press r.

3. Scroll to see your information:

> My Info.

You may need to select More to display My Info.

䡲 My Name — You can enter your name here. 䡲 Line 1 and Line 2 — your phone numbers for

phone lines 1 and 2. Each number appears when you receive your alert notification after enabling security on your phone.

Section 1B. Phone Basics 19

Phone Basics

䡲 Direct Co nnect — the number that others use to

contact you using Nextel Direct Connect. This number appears when you receive your alert notification after enabling security on your phone.

䡲 Group ID — the number of the Talkgroup you have

joined.

䡲 Carrier IP — the IP address assigned to Nextel. This

number appears when you register for packet data services.

䡲 IP1 Address and IP2 Address — the IP addresses

you use to access the Internet with your phone.

If you request equipment-related transactions on

Note

your account, Nextel Customer Service may require you to provide specific information about your phone. By pressing submenu will appear that includes your phone's service status, unit information, and phone identification numbers including IMEI, SIM ID, and Serial Number (SN). Please be prepared to supply the representative with this information when requesting these types of transactions.

anytime while in My Info, a

20 Section 1B. Phone Basics

Editing My Info

You can edit My Info to enter or change the text that appears in

1. Press

2. Press Edit (left softkey).

3. Select Name.

4. Enter the name you want to appear. See “Entering

You can also edit the information in but your changes are only temporary. The next time your phone registers on the network, your actual phone numbers appear again in My Info.

My Name.

> My Info.

Text” on page 21. When you are finished, press r.

Line 1 and Line 2,

Entering Text

Selecting a Text Input Mode

Your phone provides convenient ways to enter letters, numbers, and symbols whenever you are prompted to enter text (for example, when adding a Contacts entry or when composing text and multimedia messages).

To choose a text input mode:

1. At a screen requiring you to enter text, press M to

change the text input mode.

2. Select one of the following options:

䡲 Alpha to cycle through the alpha characters

associated with the letters on the keypad. (See page 22.)

䡲 Word to enter text using a predictive text system

that reduces the number of key presses required while entering a word. (See page 21.)

䡲 Symbols to enter punctuation and other symbols.

(See page 23.)

䡲 Numeric to enter numbers by pressing the

numbers on the keypad. (See page 23.)

䡲 Languages to change the language of the text

input database (See page 22).

䡲 Add QNotes to enter preset messages (See

page 23). (You can also access Quick Notes by pressing

Qnotes [left softkey] when beginning a

message.)

When entering text, press the # (Shif t) key to

Tip

change letter capitalization (ABC

> Abc > abc).

Entering Text Using Word Text Input

Word Text Input (T9) analyzes the letters on the keypad buttons you press and arranges them to create words. As you type, Word mode matches your keystrokes to words in its database and displays the most commonly used matching word. You can add your own words to this database.

1. Select the Word text input mode.

2. Press the corresponding keys once per letter to

enter a word. (For example, to enter the word “Bill,” press 2455.) (If you make a mistake, press

Delete [left softkey] to erase a single character.

Press and hold entire word.)

Delete [left softkey] to erase an

Section 1B. Phone Basics 21

Phone Basics

If the word that appears is not the desired word,

press 0 to change the word on the display to the next most likely word in the database. Repeat until the desired word appears.

Adding a Word to the Database

If a word you want to enter is not displayed as an option when you are using Word Text Input, add it to the database.

1. Select the Alpha text input mode. (See “Selecting a

Text Input Mode” on page 21.)

2. Enter the word. (See “Entering Text Using Alpha

Mode” on page 22.)

3. Select the Word text input mode.

4. Press #.

The word will appear as an option the next time you scroll through options during Word Text Input.

For more information about Word Text Input, visit

www.nuance.com /T9/textinput/ .

You cannot store alphanumeric combinations such

Note

as Y2K

22 Section 1B. Phone Basics

To change the language of the database:

1. At a screen that requires you to enter text,

press M.

2. Select Languages.

3. Select the language you want for your database.

Entering Text Using Alpha Mode

1. Select the Alpha mode. (See “Selecting a Text Input

Mode” on page 21.)

2. Press the corresponding keys repeatedly until the

correct letter appears. (For example, to enter the word “Bill,” press 2 twice, 4 three times, 5 three times, and 5 three times again. If you make a mistake, press single character. Press and hold to erase an entire word.)

By default, the first letter of an entry is capitalized and the following letters are lower cased. After a character is entered, the cursor automatically advances to the next space after two seconds or when you enter a character on a different key.

Delete [left softkey] to erase a

Delete [left softkey]

Characters scroll in the following order:

English Sequence

Key

Space . ? ! , @ & : ; “ - ( ) ‘ ¿ ¡ % £ $ ¥ A B C 2 Á Ã Â À Ç D E F 3 É Ê È G H I 4 Í Ì J K L 5 M N ñ O 6 Ó Õ Ô Ò P Q R S 7 ß T U V 8 Ú Ü Û Ù W X Y Z 9 + - 0 * / \ [ ] = > < # § Space Shift Caps Lock

Back

ABC

DEF

GHI

JKL

MNO

PQRS

TUV

WXYZ

Entering Symbols, Numbers, and Quick Notes

To enter symbols:

䊳 Select the Symbols mode. (See “Selecting a Text

Input Mode” on page 21.) To enter a symbol, press the appropriate key indicated on the display.

To enter numbers:

䊳 Select the Numeric mode and press the appropriate

key. (See “Selecting a Text Input Mode” on page 21.)

To enter Quick Notes:

1. From a text entry screen, press QNotes (left softkey).

2. Select a message and press r.

To add a quick note after you have already started

Tip

entering a message, press M, select and select a message.

Quick Notes preset messages make composing text

Note

messages easier by allowing you to enter quick messages, such as “Meet me at,” “Let’s get lunch,” or a customized message of your own.

Section 1B. Phone Basics 23

Add QNotes,

Phone Basics

Special Function Keys

Some of the phone’s keys assume different functions while in Alpha or Word mode.

Spaces

Press # for a space.

Capitalization

When you press and hold the # key, it acts as a three-way toggle. Press and hold # to make the next letter typed uppercase (shift), to make all subsequent letters typed uppercase (caps lock), or to go back to lowercase letters.

These icons appear:

R or U Shift is on.

S or V Caps lock is on.

24 Section 1B. Phone Basics

When none of these icons appear, letters typed are lowercase. Scrolling up after typing a letter makes that letter uppercase.

When creating a text message, you may not be able

Note

to make a letter uppercase by scrolling up, depending on the type of text message and the text entry mode.

Your phone automatically makes the first letter of a sentence uppercase.

Punctuation

Press 1 or 0 to insert punctuation. Continue to press the key to view the list of symbols available through that key. Pause to select the symbol you want.

Additional punctuation symbols are available in

Note

Symbols mode.

Accessories

Your phone comes with the following accessories:

䢇 A Li-Ion battery and charger. 䢇 A 128K SIM card.

Various accessories are available for use with your i776 phone, including cases, vehicle power chargers, data cables, hands-free accessories, and more.

To order additional accessories, go to or call 1-866-866-7509. You can also contact your Nextel Authorized Representative or stop by any Sprint Store. For information on Sprint Store locations, go to

www.sprints torelocator.com.

www.nextel.com

Using a Remote Direct Connect Button

If you are using a headset or other optional accessory with a remote Direct Connect button, you can use the remote Direct Connect button for phone calls, Direct Connect calls, and Group Connect calls.

For phone calls, use the remote Direct Connect button to answer calls, switch between calls, and end calls. Hold the remote Direct Connect button for less than two seconds to answer calls and switch between calls. Hold the remote Direct Connect button for more than two seconds to end calls.

For Direct Connect calls and Group Connect calls, use the remote Direct Connect button as you would the Direct Connect button on your phone.

When using a headset, the Direct Connect button on your phone works the same way as when you are not using a headset. Direct Connect and Group Connect sounds will be heard through the headset.

Section 1B. Phone Basics 25

Phone Basics

Section 2

Using Your Phone

Section 2A

Types of Calls

Making and Answering Calls

⽧ Types of Calls (page 28)

⽧ Making and Answering Phone Calls (page 29)

⽧ Making and Answering Direct Connect Calls (page 36)

⽧ Making and Answering Group Connect Calls (page 39)

⽧ Nextel Direct Send (page 44)

⽧ Making and Answering Talkgroup Calls (page 51)

⽧ Call Alerts (page 53)

⽧ Making and Answering Direct Talk Calls (page 55)

Your i776 phone offers many different ways to connect to your family, friends, and associates.

wireless phone calls, you can make Nextel Direct Connect calls to both individuals and groups, participate in Talkgroups, use Nextel Direct Talk, and send Call Alerts.

28 Section 2A. Making and Answering Calls

In addition to traditional

With the Nextel National Network, Nextel Direct Connect, and your i776 phone, you have the following traditional wireless phone and Nextel Direct Connect services available to you:

䢇 Digital Wireless Phone Calls offer clear calls and many

extra services, including missed call notification, Three-Way Calling, speakerphone, and speed dialing (page 29).

䢇 Direct Connect Calls allow two-way radio

communication with other Nextel Direct Connect users within the Nextel National Network (page 36).

䢇 Group Connect Calls allow coast-to-coast two-way

radio calling to up to 20 Nextel Direct Connect customers simultaneously (page 39).

䢇 Nextel Direct Send allows you to send contact

information about yourself and others in Nextel Direct Connect calls and Nextel Group Connect calls and send pictures in Nextel Direct Connect calls (page 44).

䢇 Talkgroup Calls allow two-way radio calling to up to

100 Nextel Talkgroup customers simultaneously (page 51).

To learn more about the differences between Nextel

Note

Group Connect calls and Talkgroup calls, please see “Difference Between Group Connect and Talkgroup Calls” on page 51.

䢇 Nextel Direct Talk allows for two-way radio

communication “off the network” between two or more phones equipped with this capability (page 53).

Making and Answering Phone Calls

Making Calls

Placing a traditional wireless phone call from your i776 is as easy as making a call from any landline phone.

1. Make sure your phone is on.

2. Enter a phone number from standby mode. (If you

make a mistake while dialing, press softkey] to erase the numbers.)

Delete [right

3. Press N.

4. Press P when you are finished.

To redial your last outgoing call, press and hold N.

Tip

You can also place calls from your phone by using Voice Names (page 35), speed dialing numbers from your Contacts (page 35), and using your Recent Call list (page 34).

Answering Calls

1. Make sure your phone is on.

When your phone is off, calls go directly to voicemail.

Note

2. Press N to answer an incoming call.

Depending on your settings, you may also answer incoming calls by opening the phone, or pressing any number key. See “Call Answer Mode” on page 82 for more information.

Section 2A. Making and Answering Calls 29

Making Calls

When the phone is closed, you can answer a call by

Tip

pressing

To set the phone to answer and end calls by opening and closing the phone, press M

Phone Calls > Flip Activati on Flip To End

to On.

> Settings >

and set Flip To Ans and

Your phone notifies you of incoming calls in the following ways:

䢇 The phone rings or vibrates. 䢇 The indicator light flashes. 䢇 The backlight illuminates. 䢇 The screen displays an incoming call message.

If the incoming call is from a number stored in your Contacts, the entry’s name is displayed. The caller’s phone number may also be displayed, if available.

Ending a Call

䊳 To end a call press P or close the phone.

Sending a Call to Voicemail

䊳 Press

30 Section 2A. Making and Answering Calls

, press No (right softkey), or press the

Smart Button.

Missed Phone Calls

Missed phone calls are forwarded to voicemail. When an incoming call is not answered, a Missed Call notification is displayed on your screen.

To display the Missed Call entry from the notification screen:

䊳 Press View (left softkey). (To dial the phone number,

press N after displaying the call entry.)

To display a Missed Call entry from standby mode:

1. Press M > Recent Calls. (You may also be able to

press the navigation key down to display Recent Calls.)

2. Select the entry you wish to view and press r.

Calling Emergency Numbers

Your phone supports emergency calling. Emergency phone calls can be made even when your SIM card is blocked or not in your phone.

䊳 Dial 911 and press N to be connected to an

emergency response center. If you are on an active call, you must end it before calling 911.

When you make an emergency call, your phone’s GPS Enabled feature can help emergency service personnel find you, if you are in a location where your phone's GPS antenna has established a clear view of the open sky and your local emergency response center has the equipment to process location information. See “GPS Enabled” on page 118, and particularly “IMPORTANT: Things to Keep in Mind” on page 119 and “Making an Emergency Call” on page 120, for more information on the limitations of this feature. Because of the limitations of this feature, always provide your best knowledge of your location to the emergency response center when you make an emergency call.

Important

Always report your location to the 911 operator when placing an emergency call.

designated emergency call takers, known as Public Safety Answering Points (PSAPs) may not be equipped to receive GPS location information from your phone.

Emergency calls cannot be placed while the keypad is locked.

If you have not registered on the network, emergency calls cannot be placed while your SIM card is in your phone.

If you are bringing your phone number to Nextel from your previous carrier, you may receive a temporary telephone number while your Nextel phone is being programmed with your permanent phone number. If you make a call to 911 and the call fails, the 911 emergency response center will not be able to call you back on your Nextel phone if in the meantime, your Nextel phone has been programmed with your permanent telephone number. If the call is disconnected before location and details have been provided, call 911 again and advise that you were disconnected.

Some

Section 2A. Making and Answering Calls 31

Making Calls

In-Call Options

Pressing M during a call displays a list of available in-call features. To select an option, highlight the option and press r. The following options may be available through the Options menu:

䢇 Hold to place the call on hold. 䢇 3 Way to initiate a three-way call. 䢇 Use Bluetooth to switch from the phone’s microphone

to a Bluetooth device.

䢇 2nd Call to place a second. 䢇 Contacts to display your Contacts list. 䢇 Recent Calls to display Recent Calls list. 䢇 My Info to display your phone’s Information. 䢇 Memo to display the phone’s electronic notepad. 䢇 Datebook to enter a datebook event. 䢇 Messages to create a message. 䢇 Store to store a new contact. 䢇 Record to record the phone call. 䢇 GPS to enter the GPS application. 䢇 In Call Setup to modify the in-call features.

32 Section 2A. Making and Answering Calls

Spkr (right softkey) during a call to route the

Press phone’s audio through the speaker or the earpiece.

WARNING

Because of higher volume levels, do not place the phone near your ear during speakerphone use.

Press Mute (left softkey) during a call to mute the microphone. Press

Unmute (left softkey) to unmute the

microphone.

End-of-Call Options

After you receive or make a call, the call duration is briefly displayed. You are then automatically taken to the Recent Calls list.

To save a number that is n ot in your contacts:

䊳 Highlight the entry you want to add to your

Contacts and press a Phone Number” on page 33.)

To view Call Details and Call Info:

1. Select a recent call.

2. Press r to view the Call Details.

3. Press r to view the Call Info.

Save (left softkey). (See “Saving

After you receive a call from or make a call to a phone number that is already in your Contacts, you are automatically taken to the Recent Calls list. Highlight the Recent Calls entry and press r to view the name of the contact, the time the call was received or made, and the call duration.

The End-of-Call options are not displayed for calls

Note

identified as No ID or Restricted.

Saving a Phone Number

Your phone can store up to 10 phone numbers in each of 600 Contacts entries. Each entry’s name can contain 20 characters. Your phone automatically sorts the Contacts entries alphabetically. (For more information, see “Contacts” on page 98.)

1. Enter a phone number and press M.

2. Select Store Number and press r.

3. To store the number as a new entry, select

[New Contact] and press r to add the new entry.

– or – Search for an existing contact name and press r

to save the new number.

4. Enter or edit information as necessary. When you

are finished press Contact.

Save (left softkey) to save the

Finding a Phone Number

To find Contacts entries you can either scroll through the list using your navigation key or you can search Contacts entries by name.

1. Press Contcs (left softkey).

2. Press Search (left softkey).

3. Enter the first few letters of a Contact's name and

press r. (The first contact entry that matches the entered text will be highlighted.)

4. To display the Contacts entry, press r. To dial the

entry's default phone number, press N.

Dialing and Saving Phone Numbers With Pauses

You can dial or save phone numbers with pauses for use with automated systems, such as voicemail or credit card billing numbers.

Section 2A. Making and Answering Calls 33

Making Calls

There are two types of pauses available on your phone:

䢇 Wait sends the next set of numbers when prompted. 䢇 Paus e automatically sends the next set of numbers

after three seconds.

You can have multiple pauses in a phone number

Note

and combine waits and pauses.

To dial or save phone numbers with pauses:

1. Enter the phone number.

2. Press and hold * until the letter P appears. The P

represents a three-second pause. If you want a pause longer than three seconds, press and hold * more than once. Each

P represents a three-

second pause.

– or – Press and hold * until the letter

W means your phone waits before dialing further. A

W appears. The

message appears asking if you want to send the rest of th e d ig its.

3. Enter additional numbers.

4. Press N to dial the number.

– or –

34 Section 2A. Making and Answering Calls

Press M

> Store Number to save the number in

your Contacts.

When dialing a number with a wait, press Yes (left

Note

softkey) to send the next set of numbers.

Dialing From the Contacts List

1. Press M > Contacts.

Shortcut

From standby mode, press Contacts (left softkey) to list entries.

2. Highlight the entry you want to call and press N to

dial the entry’s default phone number.

– or –

To dial another number from the entry, highlight the name, press the navigation key right or left until the correct number type appears, and then press N.

Making a Call From Recent Calls

If you have numbers stored in the Recent Calls list, you can use these numbers to make calls. For information on the Recent Calls list, see “Recent Calls” on page 92.

1. Press M > Recent Calls.

2. Select an entry and press N.

– or –

Press the Direct Connect button to make a Direct Connect or Group Connect call.

You cannot make calls from recent Calls to entries

Note

identified as

No ID or Restricted.

Making a Phone Call Using a Voice Name

If you have created a voice name in Contacts for the number you want to call (see page 101), say the voice name into your phone to enter the number.

1. Press and hold

you to say the voice name.

2. Speaking into the microphone, say the voice name

assigned to the number you want to call. Your phone plays the name back to you.

3. The call is placed automatically.

To stop a phone call from being completed, press

Tip

P or (.

until a prompt appears telling

Using Speed Dialing

Each phone number stored in Contacts is assigned a Speed Dial number, which you can use to call that number. You can store up to 600 numbers in your phone’s speed dial memory.

To use speed dialing:

1. Enter a speed dial number and then press #.

2. Press N to dial the number.

To use Turbo Dial

䊳 Press and hold the appropriate key for

for speed dial locations 1–9:

approximately two seconds. The display confirms that the number has been dialed when it shows “Calling...”.

Redialing the Last Number

䊳 Press and hold N.

Section 2A. Making and Answering Calls 35

Making Calls

Using Speakerphone

Turning on speakerphone makes incoming sound come out of the phone’s speaker instead of the earpiece. Speakerphone is available whenever you are on an active phone call.

To turn speakerphone on or off:

䊳 Press

or press Spkr (right softkey).

Using Mute

Muting calls lets you listen to incoming sound without transmitting sound. Mute is available whenever you are on an active call.

To turn mute on:

䊳 Press Mute (left softkey).

While mute is on, option.

To turn mute off:

䊳 Press Unmute (left softkey).

36 Section 2A. Making and Answering Calls

Unmute appears as the left softkey

Making and Answering Direct Connect Calls

Nextel offers the following Direct Connect services:

䢇 Nationwide Direct Connect allows coast-to-coast Direct

Connect calling to Nextel subscribers to and from anywhere on the Nextel National Network (U.S.).

䢇 International Direct Connect allows Direct Connect

calling to and from select countries.

䢇 Group Connect allows nationwide Direct Connect

calling to up to 20 Nextel subscribers simultaneously. (See “Making and Answering Group Connect Calls” on page 39).

䢇 Talkgroups allows Direct Connect calling to up to 100

Nextel subscribers in the same Direct Connect network. (See “Making and Answering Talkgroup Calls” on page 51).

www.nextel.com for more details on these Direct

See Connect services. Pricing for each of these services is based on your service contract.

Making Direct Connect Calls

1. Enter the Direct Connect number you want to call.

(See “Dialing Nextel Direct Connect Numbers” below.)

2. Press and hold the Direct Connect button on the

side of your phone. Begin talking after your phone emits a chirping sound.

3. Release the Direct Connect button to listen.

A Direct Connect call ends automatically after there is no activity on the call for several seconds.

Dialing Nextel Direct Connect Numbers

Every Direct Connect number has three parts:

䢇 An area ID. 䢇 A network ID. 䢇 A member ID.

An asterisk separates each part (for example: 999*999*9999). When you enter a number containing all three parts, you must separate them with asterisks.

The number of digits in each part of a Direct

Note

Connect number may vary. For example, your Direct Connect number may be formatted as 999*999*9999, while another valid number may appear as 555*555555*55.

If you are calling or saving a Direct Connect number for a Sprint phone with Direct Connect capabilities, the Direct Connect number may be the same as the wireless phone number. When saving the Direct Connect number, insert asterisks in place of hyphens (913*555*1234).

When you store a Direct Connect number in

Tip

Contacts, be sure to include the entire number, including the asterisks.

Using Just the Member ID

If you are contacting someone sharing your network and area IDs, you only need to enter the member ID (the last part of the number).

1. Enter the member ID of a Direct Connect number.

2. Press and hold the Direct Connect button on the

side of your phone. Continue as you would on any Direct Connect call.

Section 2A. Making and Answering Calls 37

Making Calls

Making Direct Connect Calls From Contacts

If you have numbers stored in Contacts, you can use these numbers to make calls. For information on entering numbers into Contacts, see “About Contacts” on page 98.

1. Press M > Contacts.

2. Scroll to the name or number you want to call.

3. Press and hold the Direct Connect button on the

side of your phone.

Your phone places the call to the Direct Connect number stored in the Contacts entry, even if the Direct Connect icon is not displayed.

Making Direct Connect Calls From Recent Calls

If you have numbers stored in the Recent Calls list, you can use these numbers to make calls. For information on the Recent Calls list, see “Recent Calls” on page 92.

1. Press M > Recent Calls.

2. Scroll to the item containing the Direct Connect

number you want to call.

3. Press and hold the Direct Connect button.

38 Section 2A. Making and Answering Calls

To make calls while viewing the details of an item on the Recent C alls list:

1. From the Recent Calls list, select the item

containing the number you want to call. If you

My Info from another phone, you can make

scroll to a call to the Direct Connect number of the phone that sent the information.

2. Press and hold the Direct Connect button.

Making a Direct Connect Call Using a Voice Name

If you have created a voice name in Contacts for the number you want to call, say the voice name into your phone to enter the number.

1. Press and hold the Speaker Bu tton (

prompt appears telling you to say the voice name.

2. Speaking into the microphone, say the voice name

assigned to the number you want to call. Your phone plays the name back to you.

3. Press and hold the Direct Connect button.

) until a

Answering Direct Connect Calls

When you receive a Direct Connect call, your phone emits a tone or vibrates. You then hear the voice of your caller.

1. Wait for the caller to finish speaking.

2. Press and hold the Direct Connect button on the

side of your phone. Continue as you would on any Direct Connect call.

3. Press P to end the call.

A Direct Connect call ends automatically after there is no activity on the call for several seconds.

Making and Answering Group Connect Calls

A Group Connect call is similar to a Direct Connect call to one user, but is made to multiple Direct Connect subscribers at once. You can create Groups from your phone and call up to 20 other Group Connectcompatible phones* anywhere on the Nextel National

Network. You can create a Group for one-time use or store it to Contacts so you can call it at any time.

* Not all phones are Group Connect-compatible. See

www.nextel.com for more details on Group Connect.

In order to store Groups to your i776 phone, you

Note

must use the 128K SIM card that came with your phone. The 128K SIM card is labeled “Nextel 600 Contcs & 25 Grps”. With this SIM card, a maximum of 25 groups can be added to your i776 phone. Group entries created with your i776 phone may not be readable by older iDEN SIM-based phones.

Making Group Connect Calls

1. From Contacts or the Recent Calls list, scroll to or

select the Group you want.

– or – Press and hold s until a prompt appears telling

you to say the voice name. Say the voice name assigned to the Group you want.

– or –

Enter or select a Direct Connect number and add more Direct Connect numbers. See “Starting a

Section 2A. Making and Answering Calls 39

Making Calls

Group Connect Call With a Direct Connect Number” on page 41.

2. Press the Direct Connect button.

Answering Group Connect Calls

䊳 Proceed as if answering a Direct Connect call from

one user. Only one person at a time may speak on a Group Connect call.

Creating Groups in Contacts

1. Press M > Contacts.

2. Select [New Group].

3. If you want to assign a name to the Group, enter

the name.

If you do not assign a name, the Group is named

Note

“Group” followed by the number of members in the Group. For example, “Group (8)” for a group with eight members.

4. Add Group members. See “Adding Group

Members” on page 40.

40 Section 2A. Making and Answering Calls

5. If you want to create a voice name for the Group,

[Options] > Voice Name. As directed by the

select screen prompts, say and repeat the voice name you want to assign to the Group. Speak clearly into the microphone. When you have finished, press

Back (right softkey).

6. Press Save (left softkey).

Adding Group Members

You can add Group members that have a Direct Connect number and Group Connect-compatible phone to your Group by selecting them from Contacts, the Recent Calls list, Memo, or by manually entering the Direct Connect number from your keypad. You can also add all members in an existing Group to another Group by selecting the Group name from Contacts.

To add Group members from Contacts, the Recent Calls list, or Memo:

1. While creating a Group, select [Add Member].

– or –

[Add Number] and press Browse (left softkey).

Select

To move between Contacts, the Recent Calls list, and

Note

Memo, scroll left or right, or press * or #.

2. Scroll to the members you want from Contacts and

press r. To chose a number from the Recent Calls list, or Memo, press M. A checkmark appears next to each selected member.

To deselect a member, scroll to a selected member

Note

and press r.

3. Press Done (left softkey) and then press Save (left

softkey) to save the group.

To add Group members manually from the keypad:

1. While creating a Group, select [Add Number].

2. Enter the Direct Connect number using the

keypad.

3. Press r and then press Save (left softkey) to save

the group.

Starting a Group Connect Call With a Direct Connect Number

1. Press M > Direct Connect, choose the Contacts

entries containing the Direct Connect numbers you want in the Group Connect call, and go to step six. (To add members or numbers from Recent Calls or Memo, go to step four.)

– or –

From standby mode, enter the Direct Connect number.

– or –

From Contacts or Recent Calls, scroll to an entry containing the Direct Connect number.

2. Press M.

3. Select Call New Group.

4. Add more Group members. See “Adding Group

Members” on page 40.

Section 2A. Making and Answering Calls 41

Making Calls

If you want to save the Group you have created,

press M and select

– or –

If you do not want to save the Group, press

Done (left softkey).

Store Group.

6. To make the call, press the Direct Connect button.

Removing Members or Groups

To remove a member from a Group:

1. From Contacts, scroll to the Group you want to

delete the member from.

2. Press Edit (left softkey).

3. Scroll to the member you want to remove.

4. Press M.

5. Select Remove Member.

6. Press Save (left softkey).

42 Section 2A. Making and Answering Calls

To remove all members from a Group:

1. From Contacts, select a Group.

2. Press Edit (left softkey).

3. Press M.

4. Select Remove All.

5. Press Ye s (left softkey).

To delete a Group from Contacts:

1. From Contacts, highlight a Group.

2. Press M.

3. Select Delete Group.

4. Press Ye s (left softkey).

Storing Groups

To store a group to Contacts from the Recent Calls list:

1. From the Recent Calls list, select a Group.

2. Press Save (left softkey).

3. If you want, add more information to the entry.

4. Press Save (left softkey).

To store a group to Contacts from an active Group Connect call:

1. During an active Group Connect call, press M.

2. Select Store Group.

3. If you want, add more information to the entry.

You cannot record a voice name during an active

Note

call.

4. Press Save (left softkey).

Storing Members of Groups

To store a member from the Recent Calls list or within Contacts:

1. Display the Group containing the number or

member you want to store.

2. Press M.

3. Select Store Number.

4. Select the number or member you want to store.

5. If you want, add more information to the entry.

6. Press Save (left softkey).

To store a member from an active Group Connect call:

1. During an active Group Connect call, press M.

2. Press M.

3. Select Store Number.

4. Select the number or member you want to store.

5. If you want, add more information to the entry.

You cannot record a voice name during an active

Note

call.

6. Press Save (left softkey).

Group Connect Call Information

While you are in a Group Connect call, the following appears on the screen:

䢇 The name of the Group. 䢇 The name or the Direct Connect number of the

person speaking.

䢇 The number of members who are participating in the

Group Connect call.

Section 2A. Making and Answering Calls 43

Making Calls

Group Connect Call Details

During a Group Connect call, you can view details about the other group members, such as their name or Direct Connect number, and their status on the call.

To view Group Connect call details:

䊳 Press Details (left softkey).

In the Details view, these icons appear next to member names or Direct Connect numbers:

The member of the Group who is

speaking.

A member of the Group who is active on

the Group Connect call, but not speaking.

A member of the Group who has exited

the call.

A member of the Group who could not be

reached on the Group Connect call.

A member of the Group whose status is

unknown.

44 Section 2A. Making and Answering Calls

Nextel Direct Send

Nextel Direct Send lets you exchange pictures, My Info, contact information, and Groups with other phones that have this capability. You do this through Direct Connect calls.

Nextel Direct Send cannot be used during Talkgroup calls. Pictures cannot be sent in Group Connect calls.

Sending a Picture

When you send a picture using Nextel Direct Send, the picture you send appears on the display of the phone you are engaged in the Direct Connect call with, and is saved by that phone.

Sending a Picture During a Call

You can send a picture at any time during a Direct Connect call, whether you made or received the call*.

* Additional charges may apply.

You cannot talk or listen on a Direct Connect call while a picture is being transmitted. Other activities, such as searching for a picture, do not prevent you from talking or listening.

To send a picture during a call:

1. While in a Direct Connect call, press Pi cture (right

softkey). A list of pictures that can be included in a Direct Connect call appears.

2. Select the picture you want to send.

3. Press the Direct Connect button to send the

picture.

4. Wait while the picture is transmitted. The Direct

Connect call is temporarily interrupted while a picture is transmitted.

5. When prompted, press the Direct Connect button

to resume the Direct Connect call.

The first time you send a stored picture after turning

Note

the phone on, the message Picture Fees May Apply appears and you are prompted to respond. Press Yes (left softkey) to send the picture. Press No (right softkey) to not send the picture.

Starting a Call by Sending a Picture

You can start a call by choosing a stored picture from the Media Center.

To do this, you must have the Direct Connect number and IP address of the person you want to send to stored in your Contacts.

When a person sends you My Info from his or her

Tip

phone, including his or her Direct Connect number and IP address, you can then easily store this information to Contacts from the Recent Calls list

To start a call by sending a picture:

1. Press M > Media Center and then scroll to or select

the picture you want to send in a Direct Connect call.

2. Press M.

3. Select Send Via... > Send via PTT.

4. Select A Contact or A Recent Call. These names have

Direct Connect numbers and IP addresses stored.

5. Select the name of the person you want to send

the picture to.

Section 2A. Making and Answering Calls 45

Making Calls

Press the Direct Connect button to send the

picture.

7. Wait while the picture is transmitted. The Direct

Connect call is temporarily interrupted while a picture is transmitted.

8. When prompted, press the Direct Connect button

to resume the Direct Connect call.

Receiving a Picture

When someone sends you a picture using Nextel Direct Send, your phone emits a tone or vibrates and a message appears on the display asking you if you want to accept the picture.

Pictures you receive are saved to your phone’s memory and are accessible through the Media Center.

When you receive a picture, it appears every time you are in a Direct Connect call with the person who sent it unless you delete the picture from the Media Center. This occurs for the last 20 people who sent you pictures.

46 Section 2A. Making and Answering Calls

Accepting a Picture

1. When you see the message asking you if you want

to accept the picture, press

2. Wait while the picture is transmitted. The Direct

Connect call is temporarily interrupted while a picture is transmitted.

3. When prompted, press the Direct Connect button

to resume the Direct Connect call.

The first time you accept a stored picture after

Note

turning the phone on, the message Messaging Fees May Apply appears and you are prompted to

respond. Press Yes (left softkey) to accept the picture. Press No (right softkey) to not accept the picture.

If you want to stop the transmission before it is

Tip

finished, press Cancel (right softkey).

Yes (left softkey).

Declining a Picture

䊳 When you see the message asking you if you want

to accept the picture, press

The picture is not transmitted.

No (right softkey).

Setting Picture Capability

To turn your phone’s ability to send and receive pictures in Direct Connect calls on or off:

1. Press M > Settings > DC/GC Options >

On/Off Settings.

2. Select Pictures and press r to check or uncheck

the box.

3. Press Done (left softkey) to save the setting.

This setting does not affect your phone’s ability to send and receive My Info or contact information.

Sending My Info and Contact Information

When you send My Info or contact information using Nextel Direct Send, the information you send appears on the display of the phone you are engaged in the Direct Connect call with. After the call, the information appears on the Recent Call list of that phone.

Sending My Info

You can control what portion of the information in My Info is sent and whether it is sent automatically in every Direct Connect call or only when you choose to send it.

When you send My Info, certain information, such as

Tip

your email address or fax number, cannot be included. To send complete contact information, create an entry for yourself in Contacts and send it.

The information your phone sends always includes My Name and Direct Connect.

It may include the options provided by your service provider and how you set your sending options.

The default setting is

To change which fields are sent:

1. Press M > My Info.

2. Press M.

3. Select Direct Send Setup > Info To Send.

Section 2A. Making and Answering Calls 47

Line 1, Line 2, and Carrier IP depending on

Line 1 only.

Making Calls

A checkmark appears next to the fields that will be

sent. To add or remove the checkmark, select the field.

5. When you are finished, press Done (left softkey).

To control whether your information is sent automatically:

1. Press M > My Info.

2. Press M.

3. Select Direct Send Setup > Auto Send.

4. Select On to send your information automatically,

Off to send your information only when you

or choose to send it.

When you receive your phone, it is set to send your

Note

information automatically.

To send My Info during a call:

1. While in a Direct Connect call, press M.

2. With Direct Send My... highlighted, press r.

3. When Ready to Send appears on the display, press

the Direct Connect button to send the information.

48 Section 2A. Making and Answering Calls

To start a call by sending My Info:

1. Press M > My Info.

2. Press M.

3. With Direct Send My Info highlighted, press r.

4. Use the keypad to enter the Direct Connect

number you want to send the information to.

– or –

Browse (left softkey). Select Contacts, Recent

Press

Calls, or Memo. Select the number you want to

enter.

5. When Ready to Send appears on the display, press

the Direct Connect button to send the information.

Sending Contact Information

You can send contact information by selecting a Contacts entry.

Contacts entries that contain only addresses cannot be sent. When Contacts entries are received, they do not include ring tones or pictures.

To send contact information during a call:

1. While in a Direct Connect call, press M.

2. Select Contacts.

3. Scroll to the Contacts entry you want to send and

Send Via... > Send via PTT.

select

If the Contacts entry you scrolled to is a Group, you

Note

may be prompted to allow yourself to be a part of the group being sent. Press part of the group.

Yes (left softkey) to become

4. When Ready to Send appears on the display, press

the Direct Connect button to send the contact information.

To start a call by sending contact information:

1. From Contacts, scroll to or select the entry you

want to send.

2. Press M and select Send Via... > Send via PTT.

If the Contacts entry you scrolled to is a Group, you

Note

may be prompted to allow yourself to be a part of the group being sent. Press part of the group.

Yes (left softkey) to become

3. Use the keypad to enter the Direct Connect

number you want to send the contact to.

– or –

Browse (left softkey). Select Recent Calls,

Press

Contacts, or Memo. Select the number you want to

enter.

4. When Ready to Send appears on the display, press

the Direct Connect button to send the contact information.

Receiving My Info or Contact Information

When you receive My Info or contact information from another phone, an icon appears on the display.

My Info

Contact Information

To view the information while still in the Direct Connect call:

1. Press M.

2. Select View Contact.

Section 2A. Making and Answering Calls 49

Making Calls

You can also view My Info from other phones on the Recent Calls list. See “Recent Calls” on page 92.

Sending Groups Using Direct Send

You can send a Group using Nextel Direct Send so that the person who receives the Group can use the list.

To send a Group from the Recent Calls list:

1. From Recent Calls, scroll to the Group you want to

send and press M.

2. Select Send Via... > Send via PTT.

3. To include yourself in the Group, press Yes (left

softkey). To exclude yourself, press softkey).

If you choose to include yourself and the Group

Note

already contains 20 members, you will be prompted that the list is full. You will be excluded from the list.

4. Use the keypad to enter the Direct Connect

number you want to send the contact to.

– or –

50 Section 2A. Making and Answering Calls

No (right

Browse (left softkey). Select Contacts, Recent

Press

, or Memo. Select the number you want to

Calls

enter.

5. When Ready to Send appears on the display, press

the Direct Connect button to send the contact information.

To send a Group from Contacts:

1. From Contacts, scroll to the Group you want to

send and press M.

2. Select Send Via....

3. To include yourself in the Group, press Yes (left

softkey). To exclude yourself, press softkey).

If you choose to include yourself and the Group

Note

already contains 20 members, you will be prompted that the list is full. You will be excluded from the list.

No (right

4. Select Send via PTT.

5. Use the keypad to enter the Direct Connect

number you want to send the contact to.

– or –

Browse (left softkey). Select Contacts, Recent

Press

, or Memo. Select the number you want to

Calls

enter.

6. When Ready to Send appears on the display, press

the Direct Connect button to send the contact information.

The Group will display in the Recent Calls list on the phone that you send the Group to.

Making and Answering Talkgroup Calls

A Talkgroup is a predetermined group of Direct Connect users, created by an account administrator. Talkgroups can contain up to 100 members.

Difference Between Group Connect and Talkgroup Calls

In a Group Connect call, you or another caller determines who can participate in the call. By contrast, participation in a Talkgroup is determined by an administrator. Here are the ways Group Connect and Talkgroup calls differ.

Group Talkgroup

Group Icons

Geography

Maximum Group Size

Setup

Voice Activated Dialing

Section 2A. Making and Answering Calls 51

S I

Nationwide Limited to local

21 (including originator)

Dynamically, via your phone

Yes No

market and network (fleet)

100

Predefined, via Nextel administrator using Talkgroup Management

Making Calls

Joining a Talkgroup

To participate in a Talkgroup, the account administrator must first add you to the membership and then you must “join” the Talkgroup.

1. Press Contacts (right softkey).

2. Scroll to the Talkgroup you want to join.

3. Press Join (left softkey).

You can now receive communications from other members of this Talkgroup.

You will hear all active Talkgroup conversations on your phone. To silence them, press M

DC/GC Options > Tkgrp Silent and then select On.

> Settings >

Adding More Talkgroups

You can be included in additional Talkgroups by doing one of the following:

䢇 Using Talkgroup Management at www.nextel.com. You

must be an account administrator to use Talkgroup Management.

䢇 Contacting your Nextel Sales Representative at the

time of activation.

52 Section 2A. Making and Answering Calls

Making Talkgroup Calls

1. Press

using the keypad.

– or –

Select the Talkgroup from Contacts or the Recent Calls list

2. Press the Direct Connect button and continue as if

making a Direct Connect call.

and then enter the Talkgroup number

Receiving Talkgroup Calls

䊳 Answer it as you would a regular Direct Connect

call.

Only one person at a time may speak on a Talkgroup call. The Direct Connect number or name of the person who is speaking appears on the display screen below the Talkgroup number.

During and immediately after a Talkgroup call ends,

Options (right softkey). Your phone displays

press actions you can take at this time.

Call Alerts

Sending a Call Alert lets the recipient know you want to talk to him or her on a Nextel Direct Connect call. When you send a Call Alert, the recipient’s phone alerts them and displays your name or Direct Connect number.

Sending Call Alerts

1. Enter the Direct Connect number you want to send

the alert to.

2. Press Alert (left softkey).

3. When “Ready to Alert” appears, press the Direct

Connect button to send the Call Alert.

You can send a Call Alert from Recent Calls or

Note

Contacts. Find the Direct Connect number you want to send a Call Alert to and continue as explained above.

Responding to a Call Alert

You can set a distinctive ringer for Call Alerts. See

Note

“Ring Tones” on page 65.

To answer a Call Alert:

䊳 Press the Direct Connect button to make a Direct

Connect call to the sender.

To clear a Call Alert:

䊳 Press Clear (right softkey).

To store a Call Alert in the Call Alert queue:

䊳 Press Queue (left softkey).

The Recent Calls list also stores Call Alerts you have

Note

received. They appear as Direct Connect calls. Call Alerts remain in your Recent Calls list until you delete them or until they reach the end of the list.

Section 2A. Making and Answering Calls 53

Making Calls

Using the Call Alert Queue

When you queue a Call Alert, it remains in the Call Alert queue until you make a Direct Connect call to the sender or delete it.

Viewing Call Alerts

1. Press M > Call Alert.

2. Scroll through the list.

Viewing Date and Time

To view the date and time a Call Alert was received:

1. Press M > Call Alert.

2. Select the Call Alert you want information on and

press r.

54 Section 2A. Making and Answering Calls

Responding to Call Alerts in the Queue

After you queue a Call Alert, you can respond to it by making a Direct Connect call to the sender or sending a Call Alert to the sender.

To make a Direct Connect call to the sender:

1. Press M > Call Alert.

2. Scroll to the Call Alert you want to respond to.

3. Press the Direct Connect button to begin the call.

This removes the Call Alert from the queue.

To send a Call Alert to the sender:

1. Press M > Call Alert.

2. Scroll to the Call Alert you want to respond to.

3. Press Alert (left softkey). Ready to Alert appears on

the display.

4. Press the Direct Connect button until Alert

Successful

appears on the display.

Deleting Call Alerts

To delete a Call Alert from the queue:

1. From the Call Alert queue, scroll to the Call Alert

you want to delete.

2. Press M.

3. Select Delete.

4. Press r or press Yes (left softkey) to confirm.

To delete all Call Alerts from the queue:

1. From the Call Alert queue, press M.

2. From the Call Alert menu, select Delete All.

3. Press r or press Yes (left softkey) to confirm.

Making and Answering Direct Talk Calls

Nextel Direct Talk allows for two-way radio communication “off the network” between two or more phones equipped with this capability. This feature is very useful in areas without network coverage.

You can make:

䢇 Code calls – two-way radio calls conducted off the

network and using open channels and codes. In these calls, anyone using your same channel and code can hear your conversation.

䢇 Private calls – two-way radio calls conducted off the

network and using the wireless phone numbers of the participants. In these calls, others using the same channel cannot listen in.

When using Direct Talk mode, the two phones should be a minimum of six feet apart to maximize performance and improve transmission range. You can only make Direct Talk calls to users located within your range. This varies according to terrain, man-made structures, and atmospheric conditions.

Section 2A. Making and Answering Calls 55

Making Calls

The following features are not available while in Direct Tal k mo d e:

䢇 On-network phone calls. 䢇 On-network Direct Connect, Group Connect,

Talkgroup calls, and Call Alerts.

䢇 Data services. 䢇 Sending and receiving messages. 䢇 Call timer. 䢇 Sending Call Alerts. 䢇 Call forwarding.

Setting Your Phone to Direct Talk

Before you and another caller can use Direct Talk, both of your phones must be set to Direct Talk mode.

1. Press

2. Select Go To Direct Talk.

After a few seconds, your channel and code appear on the display screen. Your phone displays the last channel and code used for Direct Talk.

56 Section 2A. Making and Answering Calls

> Direct Talk.

To return to network mode from Direct Talk:

1. Press

> DT Options.

2. Select Exit Direct Talk.

After a few seconds, your phone returns to network service.

Code Direct Talk Calls

Your phone has 10 channels and 15 codes within each channel. Channels represent the radio frequencies on which you make and receive Nextel Direct Talk calls. Codes allow you to minimize interference from others using the same channel as you.

To make Direct Talk Code calls, both parties must be on the same channel and code and have their phones set to Direct Talk. Be aware that others using both your same code and channel can hear your conversation. And, you can hear their conversations as well.

To set a channel and code:

1. In Direct Talk mode, press Edit (left softkey).

2. Select Channel.

3. Select a channel.

4. Select Code.

5. Select a code.

6. Press Back (right softkey) to return to the Direct Talk

standby screen.

Making and Receiving Code Calls in Direct Talk Mode

To make a Code call using Direct Talk:

䊳 In Direct Talk mode, press and hold the Direct

Connect button. Your phone displays along with the channel and code selected.

The tone emitted from your phone when making a Direct Talk call is four beeps and sounds different from the tone heard on Direct Connect calls conducted on the network.

If you receive an error message, this means:

䢇 There may be no parties on your channel or code. 䢇 You are out of range.

When you receive a Code call using Direct Talk, your phone displays

Receiving, along with the channel and

Tra ns mi tt in g,

code selected. Answer a Direct Talk Code call just like you would any other Direct Connect call.

Private Direct Talk Calls

Private Direct Talk allows you to silence all the calls on a channel that are not directed specifically at you. To do this, you must first set your phone to Private Only.

To set your phone to Private Only:

1. In Direct Talk mode, press Edit (left softkey).

2. Select Code.

3. Select Pvt Only.

4. Press Back (right softkey) to return to the Direct Talk

standby screen.

To reach you, other Direct Talk callers must be on your same channel and dial your ten-digit wireless phone number to reach you.

Section 2A. Making and Answering Calls 57

Making Calls

Receiving a Private Direct Talk Call

The number or name of the person who initiated the call appears on your display screen. Answer the call in the same way you answer a regular Direct Connect call.

A Private Direct Talk call ends a short time after the last party releases the Direct Connect button. The display screen returns to Direct Talk standby mode.

You do not need to set your phone to Private Only to

Note

receive Private calls. As long as you are on the same channel as your caller, you can receive Private Direct Talk calls.

Making a Private Direct Talk Call

You can make Private Direct Talk calls to any person on your same channel. You do not need to set your phone to Private Only.

To make a private Direct Talk Call:

1. In Direct Talk mode, enter the ten-digit wireless

phone number of the person you want to call on your channel. (You can also scroll to the number in Contacts or Recent Calls list.)

58 Section 2A. Making and Answering Calls

2. Make the call in the same way you make a regular

Direct Connect call. The number or name of the person you are calling appears on your display screen.

If you receive an error message, it means:

䢇 You may not be using a valid wireless phone

number.

䢇 The person that you are trying to reach may not be in

Direct Talk mode.

䢇 The person that you are trying to reach is set to a

different channel, or is out of range.

Receiving All Calls on a Channel

You can set your phone to receive all Direct Talk transmissions that are within range and set to the same channel. Do this by selecting code.

However, you cannot initiate a call when the code is set to Receive All. If you press the Direct Connect button to initiate a Direct Connect call and your code is set to Receive All, you receive an error message.

Receive All, instead of a

To set the code to Receive All:

1. In Direct Talk mode, press Edit (left softkey).

2. Select Code.

3. Select Receive All.

4. Press Back (right softkey) to return to the Direct Talk

standby screen.

Making Emergency Calls While in Direct Talk Mode

If you attempt to make an emergency 911 call while in Direct Talk mode, your phone automatically exits Direct Talk mode and attempts to find a network signal.

If you are out of network coverage, your phone cannot make an emergency 911 call until you return to a network coverage area. You must wait until the phone reconnects to a network before attempting to make an emergency 911 call.

Making Calls

Section 2A. Making and Answering Calls 59

Section 2B

Using the Settings Menu

Settings

⽧ Using the Settings Menu (page 60)

⽧ Sound Settings (page 65)

⽧ Display Settings (page 70)

⽧ Messaging Settin gs (page 71)

⽧ Temporarily Turning Off Transmissions (Airplane Mode)

(page 73)

⽧ Setting One Touch Direct Connect (page 74)

⽧ Headset Options (page 75)

⽧ Profiles (page 76)

⽧ Phone Setup Options (page 80)

You can customize your phone to sound, look, and operate just the way you want it to.

change your phone’s settings to best suit your needs. Take a few moments to review these options and to adjust or add settings that are right for you.

60 Section 2B. Settings

This section describes how to

The Settings menu contains many submenus that let you customize your phone.

To access the Settings menu and submenus:

1. Press M > Settings.

2. Select the submenu you want.

For information on applying groups of settings to your phone together, see “Profiles” on page 76.

Display/Info Features

The Display/Info menu controls how the keypad and display appear:

䢇 Wallpaper — changes the wallpaper that appears on

the display screens.

䢇 Tex t Si ze — sets the size of text on the display. 䢇 Theme — changes the look of the display. 䢇 Home Icons — controls whether main menu icons

appear in standby mode.

䢇 Backlight — controls backlight illumination.

䢇 Clock — controls whether the time and date appear in

standby mode; sets time and date format; sets year.

䢇 Menu View — controls whether the items on your main

menu and Java applications menu appear as large icons or a list.

䢇 Large Dialing — sets large digits to appear in standby

mode when you enter a number.

䢇 Language — sets the language that your phone

displays.

Phone Calls Features

The Phone Calls menu controls how your phone handles phone calls:

䢇 Set Line — sets phone line 1 or phone line 2 as the

active line for outgoing calls. If you are not provisioned for a second line and you set your line to line 2, you will not be able to make or receive calls.

䢇 Any Key Ans — lets you answer calls by pressing any

key on the keypad.

䢇 Auto Redial — sets your phone to automatically redial

calls you make when the system is busy.

䢇 Call Waiting — See “Call Waiting” on page 174.

䢇 Auto Ans — sets your phone to automatically answer

an incoming call after a specified number of rings. When this feature is on, the phone answers by connecting you to the caller; it does not send the call to voicemail, unless you are out of coverage or on the line.

䢇 Flip Activation — sets your phone to answer a call by

opening the phone or end a call by closing the phone.

䢇 Minute Beep — causes a beep to sound every minute

of an active call.

䢇 Call Duration — causes the duration of a call to appear

on the display when the call ends.

䢇 TTY — See “Telecommunications Relay Service” on

page 179.

䢇 Hearing Aid — Supports the use of select Hearing Aid

devices. Set to

Off, Microphone or Tele co il depending

on your Hearing Aid device. See “Using Your Phone With a Hearing Aid Device” on page 193.

䢇 Notifications — See “Message Notifications” on

page 151.

䢇 DTMF Dialing — sets whether you can hear DTMF (dual

tone multi-frequency) tones with your keypad

Section 2B. Settings 61

Settings

presses. Set to Always to always hear keypad presses; set to

In Call Only to hear keypad presses only while in

set to

Never to never hear keypad presses;

a call.

䢇 Prepend — lets you specify a prefix, such as a country

code for international calls, to be automatically added to phone numbers you dial.

DC/GC Options Features

The DC/GC Options menu controls how your phone handles Direct Connect calls, Group Connect calls, and Talkgroup calls:

䢇 Tkgrp Silent — controls whether you hear your

Talkgroup calls.

䢇 Tkgrp Area — lets you define your Talkgroup area. 䢇 One Touch DC — sets One Touch Direct Connect. 䢇 Alert Type — controls how your phone notifies you

when you receive Direct Connect calls, Group Connect calls, and Talkgroup calls.

䢇 On/Off Settings — sets your phone’s ability to send and

receive pictures in Direct Connect calls. See “Starting a Call by Sending a Picture” on page 45.

62 Section 2B. Settings

䢇 Store Rcvd Info — lets you specify a prefix, such as a

country code for international calls, to be automatically added to phone numbers you receive in My Info from other phones, when you store the My Info to Contacts. Select added. Set

Add Prefix to Ask Me to set your phone to

Prefix to enter the prefix to be

display a prompt asking you whether you want the prefix added as you save My Info from other phones to Contacts.

䢇 PTT B acklig ht — controls whether or not the backlight

displays when using Direct Connect.

Personalize Features

The Personalize menu makes main menu items easier to access from standby mode.

䢇 Menu Options — has two submenus to control menus:

䡲 Reorder Menu — lets you change the order of the

items on the main menu by grabbing and moving them.

䡲 Add/Remove Apps — lets you create a shortcut to a

Java application on the main menu.

䢇 Up Key — sets the main menu item you access when

you scroll up in standby mode.

䢇 Down Key — sets the main menu item you access

when you scroll down in standby mode.

䢇 Left Key — sets the main menu item you access when

you scroll left in standby mode.

䢇 Right Key — sets the main menu item you access

when you scroll right in standby mode.

䢇 Center Key — sets the main menu item you access

when you press r in standby mode.

䢇 Left Sf tkey — sets the main menu item you access

when you press the left softkey in standby mode.

䢇 Right Sftkey — sets the main menu item you access

when you press the right softkey in standby mode.

䢇 Power Up — sets the main menu item you see when

you power on your phone. To set standby mode to be the first thing you see when you power on your phone, select

Default Ready.

Volume Features

The Volum e menu sets the volume of sounds your phone makes:

䢇 Line 1 — sets ringer volume for phone line 1. 䢇 Line 2 — sets ringer volume for phone line 2. 䢇 Messages — sets the volume of message notifications

and Datebook reminders.

䢇 Earpiece — sets the volume of sound coming out of

the earpiece.

䢇 Speaker — sets the volume of sound coming out of

the speaker.

䢇 Keyp ad — sets the volume of sound associated with

pressing keys and buttons.

䢇 Java Earpiece — sets the volume of sound associated

with Java applications coming out of the earpiece.

䢇 Java Spkr — sets the volume of sound associated with

Java applications coming out of the speaker.

䢇 Data — sets the volume of sounds that notify you that

you are receiving a circuit data call.

Section 2B. Settings 63

Settings

Security Features

The Security menu lets you turn security features on and off and change passwords:

䢇 Phone Lock — turns on a feature that locks your

䢇 Keyp ad Lock — locks the phone’s keypad, either

䢇 SIM PIN — enables and disables your phone’s SIM

䢇 GPS PIN — enables and disables your phone’s GPS

䢇 Change Passwds — changes your phone unlock code,

64 Section 2B. Settings

Lock No w takes effect immediately; Auto Lock

phone: takes effect when your phone is powered off and then on. An unlock code is required to enable this feature, to unlock the phone, and to set a new unlock code. Contact Nextel Customer Service for your default unlock code.

immediately or automatically after a set period of inactivity.

PIN security feature. See “Turning SIM PIN On and Off” on page 84.

PIN security feature. See “Setting the GPS PIN Security Feature” on page 89.

security code, SIM PIN, and GPS PIN.

Advanced Features

The Advanced menu contains advanced Settings features.

䢇 Alert Timeou t — sets the amount of time a tone

continues to sound and the logo backlight continues to flash when you receive a message notification, Call Alert, or Datebook reminder.

䢇 Headset/Spkr — sets headset options. See “Headset

Options” on page 75.

䢇 Connectivity — Network ID sets the phone’s network IDs

and their roaming options under the direction of Nextel Customer Service; Customer Service reset your service in the event of a security or provisioning problem.

䢇 Reset Defaults — Reset Settings returns all settings to

their original defaults; their original defaults and erases all stored lists. Use only under the direction of Nextel Customer Service.

䢇 Return to Home — After Phone controls how long the

Recent Calls list displays after phone calls; controls how long the Recent Calls list displays after Direct Connect calls.

Master Reset lets Nextel

Reset All returns all settings to

After DC

䢇 Tra ns mi tt er s — controls your phone’s radio

transmitters. Selecting

Off prevents your phone from

making or receiving phone calls, Direct Connect calls, Group Connect calls, or Talkgroup calls, or transferring data.

䢇 Baud Rate — sets the baud rate at which your phone

communicates with a laptop computer or similar device.

Sound Settings

Ring Tones

Ringer types help you identify incoming calls and messages. You can assign ringer types to individual Contacts entries, types of calls, and types of messages.

Selecting Ringer Types

Your phone provides a variety of ringer options that allow you to customize your ring and volume settings. These options allow you to identify incoming calls by the ring.

1. Press M > Ring Tones.

2. Scroll through the list of ring tones. A sample

ringer will sound as you highlight each option.

3. Press r or press Assign (left softkey).

4. Select the function(s) to which you want to assign

the current ringer by highlighting the option and pressing r. (A check mark will appear next to selected options).

䡲 Phone Line 1 䡲 Phone Line 2 䡲 Call Alert 䡲 Voice Mail 䡲 Messages 䡲 Net Alert 䡲 Direct Send Alert 䡲 Reminders

5. When you are finished, press Done (left softkey) to

assign the ringer to the selected function(s).

Section 2B. Settings 65

Settings

Assigning a Ring Tone to a Contact

You can also assign a ringer to a specific contact entry so you know who's calling without looking at the phone.

1. Press M > Ring Tones.

2. Scroll through the list of ring tones and select the

one you want to assign. A sample ringer will sound as you highlight each option

3. Press r or press Assign (left softkey).

4. Select A Contact....

5. Highlight the Contacts entry to which you want to

assign the ring tone.

6. Press r to assign the ringer.

Viewing Ring Tone Assignments

1. Press M > Ring Tones.

2. Make sure Vibrate All is set to Off.

3. Highlight any ring tone and then

press M

66 Section 2B. Settings

> Overview.

4. Scroll to view ring tones assigned to features and

Contact entries.

Downloading More Ring Tones

If you want to use other ring tones, you can download them into your phone for a fee.

Check the catalog of additional items available for purchase and download directly from your phone. You can also access downloadable ring tones from the menu.

To purchase and download new ringtones:

䊳 Press M > Ring Tones > Buy Ring Tones.

Note

Downloads menu option on your phone for a

Ring Tones

Ring tones may be downloaded only once. If you delete a ring tone from your phone and wish to reassign it, you must purchase it again.

Managing Memory

To view the amount of memory available for custom ring tones:

1. Press M > Ring Tones.

2. Make sure Vibrate All is set to Off.

3. Highlight any ring tone and press M >

Memory Usage.

Deleting custom ring tones frees memory.

Ring tones are stored in your phone using the same

Note

memory space used to store messages, voice records, pictures, and Java application data that are stored in your phone’s memory. Deleting or moving some of these other items frees memory for ring tones.

Deleting Custom Ring Tones

Deleting a ring tone from the list of ring tones deletes it from your phone.

Except for DRM ring tones, if you delete a ring tone that you purchased from your phone, you will have to purchase it again. Under certain conditions, some DRM vendors will not charge you if you download an item multiple times within a given time frame. Please contact the DRM vendor to learn more about their download regulations.

To delete a custom ring tone:

1. Press M > Ring Tones.

2. Make sure Vibrate All is set to Off.

Vibrate Settings

Vibrate All

The Vibrate All option allows you to be notified of calls and messages with a vibration instead of an audible alert.

To activate Vibrate All:

䊳 With the phone open, press and hold the volume

button down in standby mode. (Pressing and holding displays “VibeAll: On.” Continuing to hold the button down displays “VibeAll: Locked.”

– or – Press M

On or Locked .

Tip

> Ring Tones > Vibrate All. Set this option to

Setting this option to Locked requires you to press and hold the volume control up to turn The

Locked option helps prevent you from

accidentally turning

Vibrate All off.

Section 2B. Settings 67

Settings

To deactivate Vibrate All:

1. Press and hold the volume key up to unlock

vibrate all.

2. Press the volume key up repeatedly to select a

volume level.

– or – Press M

These icons indicate how the ringer is set:

> Ring Tones > Vibrate All. Set this option

Off.

The phone always vibrates instead of making a sound.

The phone vibrates instead of making a sound for phone calls.

Direct Connect calls, Group Connect calls, and Talkgroup calls are heard through the earpiece, not the speaker.

68 Section 2B. Settings

Ring and Vibrate

To set your phone to ring and vibrate when you receive phone calls or Call Alerts:

1. Press M > Ring Tones.

2. Make sure Vibrate All is set to Off.

3. Scroll through the list of ring tones and highlight

the one you want to assign.

4. Press M > Assign w/Vibe.

5. Select Phone Line 1 and/or Phon e Line 2 and press

Done (left softkey).

This icon S appears on the display.

Silence All

The Silence All option allows you to mute all sounds without turning your phone off.

To activate Silence All:

䊳 With the phone in standby mode press and hold

the volume key down until the ringer level is set at 0. (The screen will display M.)

To deactivate Silence All:

䊳 Press the volume key up repeatedly to select a

volume level.

To set your phone to vibrate instead of making a sound for some features but not others:

1. Press M > Ring Tones.

2. Make sure Vibrate All is set to Off.

3. Select Vibrate from the list of ring tones.

4. Select the features you want to set to make no

sound.

5. When you are finished, press Done (left softkey).

To set ring options for Direct Connect calls, Group

Note

Connect calls, and Talkgroup calls, see “Vibrate Settings” on page 67.

Adjusting the Phone’s Volume Settings

Adjust your phone’s volume settings to suit your needs and your environment.

1. Press M > Settings > Volume.

2. Select Line 1, Line 2, Messages, Earpiece, Speaker,

Keyp ad, Java Earpiece, Java Spkr or Data.

3. Using the navigation key, choose a volume level

and press r.

You can adjust the ringer volume in standby mode

Tip

(or the earpiece volume during a call) by using the volume key on the left side of your phone.

4. Scroll to the ring tone you want to delete and

press M

> Delete.

5. Press Ye s (left softkey) to confirm.

Minute Beep

Set your phone to alert you with an audible tone once a minute during a voice call.

1. Press M > Settings > Phone Calls > Minute Beep.

2. Highlight On or Off and press r.

Section 2B. Settings 69

Settings

Display Settings

Changing the Backlight Time Length

Select how long the display screen and keypad remain backlit after any keypress is made.

1. Press M > Settings > Display/Info > Backlight.

2. Highlight an option, press r, and then choose a

setting.

䡲 For Timer or Java Timer, select a backlight timeout

time.

䡲 For Sensor, PTT Backlight, Bluetooth, or Message,

On or Off.

select

Long backlight settings reduce the battery’s talk and

Note

standby times.

Changing the Display Screen

Choose what you see on the display screen while powering on or off and when in standby mode.

1. Press M > Settings > Display/Info > Wallpaper.

70 Section 2B. Settings

2. Select Wallpaper and press r. (A list of available

images will be displayed.)

3. Select an image and press View (left softkey) to

view it. Press available images.

Back (right softkey) to return to the

4. Press r to assign an image.

Setting Wallpaper to Change Automatically

When you set your wallpaper to change automatically, your phone uses each of the pictures in wallpaper, cycling through them at a pace you choose.

1. Press M > Settings > Display/Info > Wallpaper >

Auto Cycle.

2. Select how often you want the wallpaper to

change.

Media Center as

Changing the Phone’s Menu Style

Choose how your phone’s menu is displayed on the screen.

1. Press M > Settings > Display/Info > Menu View.

2. Select an option and press r.

䡲 Icon View to view the main menu as a grid of

Icons. Icons animate when they are highlighted.

䡲 List View to display the menu as a list.

Changing the Theme

Customize your phone’s display appearance by selecting a theme to reflect your personality.

1. Press M > Settings > Display/Info > Theme.

2. Select an option and press r.

Changing the Clock Display

Select a format for the time and date display and choose whether the time and date appear in standby mode.

1. Press M > Settings > Display/Info > Clock.

2. Select Display, Time Format, or Date Format and then

press r.

3. Select an option and press r to apply the setting.

The year is set by the network, and even though it is

Note

an option, it cannot be changed.

Changing the Text Size

Adjust the font when entering text (for example, when using the notepad or when adding a Contacts entry).

1. Press M > Settings > Display/Info > Text Size.

2. Select Zoom, Standard, or Compressed and

press r.

Messaging Settings

Staying connected to your friends and family has never been easier. With your phone’s advanced messaging capabilities, you can send and receive many different kinds of text messages without placing a voice call. (For more information see “Multimedia Messages” on page 154.)

Messaging settings make text messaging easier by letting you decide how you would like to be notified of new messages, create a signature with each sent message, and create your own preset messages.

Section 2B. Settings 71

Settings

Setting Message Notification

When you receive a message, your phone notifies you by displaying an icon on your display screen. You can also choose to be notified with a sound while making a phone call.

1. Press M > Settings > Phone Calls > Notifications.

2. Select the and press r.

䡲 Receive All — Tones sound during calls for all types

of messages except MMS messages.

䡲 Msg Mail Only — Tones sound during calls for SMS

messages; tones for all other types of messages are held until you end calls.

䡲 Delay All — Tones for all types of messages are

held until you end calls.

Delay All is the default setting.

Note

To set notification options during a call press M >

Tip

In Call Set up > Notifications.

Deleting Old Messages

Delete messages you have read whenever you like, or have your phone delete them automatically for you.

72 Section 2B. Settings

To automatically delete read messages:

1. Press M > Messages > M > Setup > Cleanup.

2. Select Inbox or Sent Items and press r.

3. Choose a cleanup option.

4. To automatically delete messages now, press r

Yes (left softkey). Press No (left softkey) to

or press delete messages later.

Adding a Customized Signature

Add a customized signature to each message you send.

1. Press M > Messages > M > Setup > Signature. If you

do not wish to attach a signature to your outgoing messages, press

Delete (left softkey).

2. Enter a signature and press r. (See “Entering

Text” on page 21.)

Managing Preset Messages

Your phone is loaded with two types of preset messages, Quick Notes and Replies, to help make sending text messages easier. You can also create custom Quick Notes and Replies to suit your needs.

To add a new preset message:

1. Press M > Messages > M > Setup > Quick Notes or

. (The list of preset messages will be

Replies

displayed.)

2. To add a new message, press New (left softkey) or

[New Quicknote].

select

3. Enter your message (see “Entering Text” on

page 21), and press r. (Your new message will be added to the end of the list.)

To delete a custom Quick Note or Reply:

1. Press M > Messages > M > Setup > Quick Notes or

. (The list of preset messages will be

Replies

displayed.)

2. To delete a custom message, select it and press

Delete (left softkey).

– or –

To delete all custom messages, select a custom message and press M

> Delete All.

To edit a custom Quick Note or Reply:

䊳 From the Quick Notes or Replies list, select a

message, make your changes (see “Entering Text” on page 21), and press r.

Settings

Temporarily Tu rning Off Transmissions (Airplane Mode)

Sometimes you may want to have your phone on, but turn off its ability to make and receive calls and other transmissions.

To set your phone so that it cannot make or receive phone calls, Direct Connect calls, Group Connect calls, Talkgroup calls, or transfer data:

1. Press M > Settings > Advanced > Transmitters.

2. Select Off and press r.

3. Press Ye s (left softkey).

Section 2B. Settings 73

When in Transmitters Off mode, your phone’s standby screen displays “Transmitters Off.”

While powering on your phone, you can turn

Note

transmitters off by pressing seconds

P for more than five

To restore your phone’s ability to do all these things:

䊳 Set this option to On and then press Yes (left

softkey).

When Transmitters is set to Off, your phone’s

Note

Bluetooth capability is disabled, and all active Bluetooth connections are dropped.

Setting One Touch Direct Connect

One Touch Direct Connect sets your phone to call the most recent Direct Connect number or Group on the Recent Calls list, or a Direct Connect number you choose, every time you press the Direct Connect button.

74 Section 2B. Settings

To set your phone to quickly make a Direct Connect call, create an Group Connect list, or make a Group Connect call:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Quick PTT and press r.

To set your phone to call the most recent Direct Connect number or Group on the Recent Calls list:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Last Call and press r.

To set your phone to call a Direct Connect number you choose:

1. Press M > Settings > DC/GC Options >

One Touch DC > Assigned No.

2. Enter the Direct Connect number you want your

phone to call every time you press the Direct Connect button.

䡲 Enter the number using your keypad.

– or –

䡲 Press Search (left softkey). Select Contacts, Recent

, or Memo. Select the number you want to

Calls

enter.

If you are entering a Talkgroup number, enter #

Tip

before the number.

3. Press r.

To set your phone to send a picture:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Send Pic ture.

To set your phone to send your phone’s information:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Send My Info.

To set your phone to send a contact:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Send Contact.

To turn off One Touch Direct Connect:

1. Press M > Settings > DC/GC Options >

One Touch DC.

2. Set this option to Off.

Headset Options

To set your phone to send incoming sound to a headset only, or to a headset and a speaker at the same time:

1. Press M > Settings > Advanced > Headset/Spkr.

2. Select HdsetOnly to send incoming sound to the

headset only.

– or –

Hdset&Spkr to send incoming sound to the

Select headset and ring tones to the speaker.

Section 2B. Settings 75

Settings

Profiles

A profile is a group of settings saved together so that you can apply them to your phone easily.

A profile contains these settings:

䢇 Ring Tones — sets all options described in “Ring

Tones” on page 65, except assigning ring tones to Contacts.

䢇 Display/Info — sets Wallpaper, Theme, Te xt S ize, and

Backlight options. See “Display Settings” on page 70.

䢇 Phone Calls — sets Set Line and Auto Answer options.

See “Phone Calls Features” on page 61.

䢇 Volu me — sets all options described in “Volume

Features” on page 63.

䢇 Call Filter — controls which calls, Call Alerts, and

message notifications your phone responds to. See “Setting Call Filtering” on page 79.

䢇 Advanced — sets headset options. See “Headset

Options” on page 75.

Your phone arrives with preset profiles. You can also create your own profiles.

76 Section 2B. Settings

Viewing Profiles

To view the profiles stored in your phone:

1. Press M > Profiles.

2. Scroll to the profile you want to view.

3. Press View (left softkey).

The profile that is currently in effect on your phone

Tip

has a checkmark next to it.

4. Scroll to view settings.

Switching Profiles

To apply a profile to your phone:

1. Press M > Profiles.

2. Scroll to the profile you want to apply and

press r.

The profile you selected is now in effect.

How Changing Settings Affects Profiles

Many of the settings contained in profiles can be set without switching or editing profiles — for example, by selecting setting the volume of the phone’s ring using the volume controls.

When you do this, your phone either:

䢇 Updates the profile in effect to reflect these changes,

䢇 Creates a temporary profile that contains these

To set your phone to create a temporary profile that contains changes you make to settings:

To set your phone to update the profile in effect to reflect any changes you make to settings:

Settings or Ring Tones to set options, or by

without notifying you.

– or –

changes.

1. Press M > Profiles.

2. Press M and then select Setup > Temp Profile.

3. Set this option to On.

䊳 Set Temp Profile to Off in step 3 above.

Temporary Profiles

If your phone is set to create temporary profiles, a temporary profile is created when you make changes to settings without switching or editing profiles. These stay in effect until you switch profiles or power off your phone.

Temporary profiles and any settings you have changed are marked with asterisks (*).

Storing a Temporary Profile

To store a temporary profile as a new profile:

1. Press M > Profiles.

2. Scroll to the temporary profile.

3. Press M.

4. Select Store As New.

5. Enter the name you want to give the profile. When

you are finished, press r.

To overwrite the profile the temporary profile is based on:

1. Press M > Profiles.

2. Scroll to the temporary profile and then press M.

Section 2B. Settings 77

Settings

Select Store Changes.

The temporary profile is stored with the name of the

Note

profile it is based on. The profile it is based on, as it existed before you made changes to settings, is gone.

Creating Profiles

1. Press M > Profiles.

2. Select [New Profile].

– or – Scroll to any profile, press M, and then select

3. Enter the name you want to give the profile, and

then press r.

4. If you want to base this profile on an existing

profile, select you want to base this profile on. If you do not choose a profile to copy from, the new profile is based on a default profile.

5. Press Create (left softkey).

6. Scroll through the list of options and set their

values.

78 Section 2B. Settings

Copy From and then select the profile

7. When you are finished, press Done (right softkey).

Editing Profiles

1. Press M > Profiles.

2. Scroll to the profile you want to edit.

3. Press M and then select Edit.

4. Scroll through the list of options and set their

5. When you are finished, press Done (right softkey).

New.

Deleting Profiles

To delete a profile:

1. Press M > Profiles.

2. Scroll to the profile you want to delete.

3. Press M and then select Delete.

4. Press r or press Yes (left softkey).

To delete all profiles:

1. Press M > Profiles.

2. Press M and then select Delete All.

values.

3. Press r or press Yes (left softkey) to confirm.

Setting Call Filtering

The call filtering setting in each profile lets you control which calls, Call Alerts, and message notifications your phone notifies you of, and which it ignores.

1. While setting options for a profile, select Call Filter.

2. Select a filtering option

䡲 Phone – sets filtering options for phone calls.

● Off – sets your phone to notify you of all phone

calls.

● All – sets your phone to ignore all phone calls.

● All Contacts – sets your phone to notify you

only of phone calls from numbers stored in Contacts.

● Some Cnt cs – sets your phone to notify you

only of phone calls from specific Contacts entries. Select up to five Contacts entries that you want to be notified of calls from. When you are finished, press

Done (right softkey).

䡲 DC/GC – sets filtering options for Direct Connect

calls and Talkgroup calls.

● Off – sets your phone to notify you of all Direct

Connect calls and Talkgroup calls.

● On – sets your phone to ignore all Direct

Connect calls and Talkgroup calls.

䡲 Group – sets filtering options for Group Connect

calls.

● Off – sets your phone to notify you of all Group

Connect calls.

● On – sets your phone to ignore all Group

Connect calls.

䡲 Alerts – sets filtering options for Call Alerts.

● Off – sets your phone to notify you of all

Call Alerts.

● On – sets your phone to ignore all Call Alerts.

䡲 Notifications – sets filtering options for message

notifications.

● Off – sets your phone to notify you of all

messages.

Section 2B. Settings 79

Settings

● Voi ce Mes sages – sets your phone not to sound

a tone or vibrate when you receive voice messages.

● Te xt M ess age s – sets your phone not to sound

a tone or vibrate when you receive text messages.

● All – sets your phone not to sound a tone or

vibrate when you receive any message.

When you receive a message you have set not to

Note

sound a tone or vibrate, the message notification screen still appears.

3. Press Done (right softkey).

Phone Setup Options

Shortcuts

Your phone offers you the option of assigning shortcuts to favorite or often-used functions. Pressing the M key in standby mode followed by the assigned shortcut key will launch your personally designated shortcuts.

80 Section 2B. Settings

Creating a Shortcut

When you receive your phone, all number keys may

Note

already be assigned to shortcuts. If this is the case, you can create new shortcuts by deleting or replacing existing shortcuts

1. Go to the menu item you want to create a shortcut

for.

For example, if you want to create a shortcut to the screen for creating a new Contacts entry: Press M

[New Contact].

2. Press and hold M until a confirmation screen

appears.

3. Press r or press Yes (left softkey).

4. Select Key.

5. Press the number key you want to assign to the

shortcut and press r.

6. If you want to record a voice name for the shortcut,

select say and repeat the name you want to assign to the number. Speak clearly into the microphone.

> Contacts, and then highlight

Voice . As directed by the screen prompts,

7. Press Done (left softkey).

8. If the number key you chose is already assigned to

a shortcut, a prompt appears asking if you want to replace the existing shortcut.

䡲 Press Ye s (left softkey) to replace the existing

shortcut.

䡲 Press No (right softkey) if you want to keep the

existing shortcut and assign another number key to the shortcut.

Using a Shortcut

To access a shortcut using the shortcut number:

1. From standby mode, press M.

2. On your keypad, press the number assigned to the

shortcut.

To access a shortcut using the voice name:

1. Press and hold s.

2. Say the voice name you assigned to the shortcut.

The shortcut with that voice name is then highlighted.

To access a shortcut if you do not know the shortcut number:

1. Press M > Shortcuts.

2. Scroll to the shortcut you want to use and

press r.

Editing a Shortcut

To change the order of shortcuts:

1. Press M > Shortcuts.

2. With any shortcut highlighted, press M.

3. Select Reorder and then scroll to the shortcut you

want to move.

4. Press Grab (left softkey).

5. Scroll to the place where you want the shortcut to

appear.

6. Press Insert (left softkey).

7. Repeat step 4 through step 7 for all the items you

want to move.

8. Press Done (right softkey).

Section 2B. Settings 81

Settings

To change the number or voice name assigned to a shortcut:

1. Press M > Shortcuts.

2. Highlight any shortcut.

3. Press Edit (left softkey).

4. With Key or Voice highlighted, press r to change

assignments.

5. Press Done (right softkey).

Deleting Shortcuts

To delete a shortcut:

1. Press M > Shortcuts.

2. Scroll to the shortcut you want to delete.

3. Press M and then select Delete.

4. Press r or press Yes (left softkey) to confirm.

To delete all shortcuts:

1. Select M > Shortcuts.

2. With any shortcut highlighted, press M.

82 Section 2B. Settings

3. Select Delete All.

4. Press r or press Yes (left softkey) to confirm.

Call Answer Mode

Select how to answer incoming calls on your phone: whether you want to be required to press N or to press any number key.

1. Press M > Settings > Phone Calls.

2. Select an option and press r.

䡲 Any Key Answer: Press r and select On to allow an

incoming call to be answered by pressing any key.

– or –

Off to require N to be pressed to answer

Select all incoming calls.

䡲 Auto Ans to set your phone to automatically

answer an incoming call after a specified number of rings.

● Off to disable Auto-Answer.

● 1 Ring, 2 Rings, 3 Rings or 4 Rings to answer calls

automatically when the phone is connected to a hands-free car kit or a headset (sold

separately). Remember, your phone will answer calls in Auto-Answer mode even if you are not present.

䡲 Flip Activation to set your phone to answer calls by

opening the phone ( closing the flip (

● Select Off to require N to be pressed to

Flip To Ans) and end calls by

Flip To End).

answer all incoming calls, and to require P to be pressed to end all calls.

Display Language

You can choose to display your phone’s on screen menus in English, Spanish, or French.

1. Press M > Settings > Display/Info > Language.

2. Select English, Español, Français, or Automatic and

press r.

Setting Prepend Dialing

The Prepend feature lets you set a prefix to be added to the beginning of all dialed numbers, such as a country code for international calls.

1. Press M > Settings > Phone Calls > Prepend.

2. Select Prepend > On.

3. Enter a prefix in the Number field (such as +1 for

international calls) and then press r.

䡲 To deactivate this feature, select Off during step 2

above.

This setting does not apply to 911 or Sprint 411.

Note

Section 2B. Settings 83

Settings

Section 2C

SIM Card Security

Security

⽧ SIM Card Security (page 84)

⽧ Your Phone’s Lock Feature (page 86)

⽧ Your Phone’s Keypad Lock (page 86)

⽧ Resetting Your Phone (page 87)

⽧ GPS Privacy Options (page 88)

⽧ Java Applications & GPS Security (page 89)

By using the security settings on your phone, you receive peace of mind without sacrificing flexibility.

familiarize you with your phone’s security settings. With several options available, you can customize your phone to meet your personal needs.

84 Section 2C. Security

This section will

Important

Except for making emergency calls, your phone does not function without the SIM card.

SIM Card’s PIN

You can protect access to your phone by using the SIM card’s PIN (Personal Identification Number). When you enable SIM PIN, you must enter the PIN each time you power up the phone. You can change or disable the SIM PIN.

Turning SIM PIN On and Off

1. Press

2. Select On or Off.

3. Enter the current SIM PIN.

Important

4. Press Ok (left softkey).

> Settings > Security > SIM PIN.

The default SIM PIN is 0000. Change your PIN to prevent fraudulent use of the SIM Card.

Entering the PIN

1. Turn on your phone.

2. When the SIM PIN screen appears, enter your

SIM PIN and press

Important

If you enter your PIN incorrectly three times, your SIM card is blocked. See “Unblocking the PIN” on page 85

Ok (left softkey).

Changing the PIN

SIM PIN must be turned on in order to access this

Note

feature.

1. Press

2. Enter the current SIM PIN and press Ok (left

3. Enter the new SIM PIN and press Ok (left softkey).

4. Reenter the new SIM PIN to confirm.

5. Press Ok (left softkey).

> Settings > Security > Change Passw ds >

SIM PIN.

softkey).

Unblocking the PIN

If you enter your PIN incorrectly three times, your SIM card is blocked. To unblock your SIM card, you must contact Nextel Customer Service to get a PIN Unblock Code (PUK). Follow their instructions for unblocking your SIM PIN.

Important

If you unsuccessfully enter the PUK code ten times, your SIM card is permanently blocked and must be replaced. If this happens, you get a message to contact Nextel Customer Service. Except for making emergency calls, your phone does not function with a blocked SIM card.

Section 2C. Security 85

Security

Your Phone’s Lock Feature

Locking Your Phone

When your phone is locked, you can only make calls to

911. To lock and unlock your phone, you must enter your phone’s four-digit lock code. If you do not know your phone’s lock code, try 0000; if this does not work contact Nextel Customer Service for assistance.

1. Press M > Settings > Security.

2. Select Phone Lock > Lock Now, enter the unlock

code, and press phone to lock the next time it is turned on, select

Auto Lock.)

Unlocking Your Phone

䊳 At the “Enter Unlock Code” prompt, enter your

unlock code and press

Changing the Lock Code

1. Press

86 Section 2C. Security

Ok (left softkey). (To set your

Ok (left softkey).

> Settings > Security > Change Passwds.

2. Select Unlock Code, and then enter your current

unlock code and press

Ok (left softkey).

3. Enter and reenter your new lock code, pressing

Ok (left softkey) after each.

Calling in Lock Mode

You can place calls to 911 when in lock mode.

䊳 To call an emergency number, dial 911 and

press N.

Your Phone’s Keypad Lock

Locking the phone’s keypad prevents its buttons from being pressed. When the keypad is locked, you can only:

䢇 Power the phone on and off. 䢇 Unlock the keypad. 䢇 Respond to incoming calls, messages, and alerts.

Important

Emergency calls cannot be placed while the keypad is locked.

To l ock t he ke ypad:

䊳 From standby mode, press M and then press *.

If you press a key while the keypad is locked, instructions for unlocking the keypad display briefly.

To u nloc k the keypa d:

䊳 From standby mode, press M and then press *.

To automatically lock the key pad if there has been no activity for a specified time.

1. Press M > Settings > Security > Keypad Lock.

2. To lock the keypad immediately, select Lock Now.

You will be given the option to press M and * to lock and unlock the keypad.

3. To set a specific time for the keypad to lock if there

has been no activity, select

Auto Lock and then

select a time.

The keypad can be set to lock in 30 seconds or in 1, 5, 10, 15, or 20 minutes if the keypad is not touched during the specified time. To turn the auto lock off, repeat step 3 and select

Off.

Resetting Your Phone

Resetting Phone Settings

Resetting phone settings restores all the factory defaults, including the ringer types and display settings. The Contacts, History, Scheduler, and Messaging are not affected.

1. Press

2. Enter your phone’s six-digit security code and

Note

3. Read the prompt and press Ye s (left softkey) to

> Settings > Advanced > Reset Defaults >

Reset Settings

press

complete the reset. (Press

Ok (left softkey). (A disclaimer is displayed.)

Your security code is a six-digit number used for resetting your phone. Please contact Nextel Customer Service if you do not know your security code.

No [right softkey] to

cancel.)

Section 2C. Security 87

Security

Resetting All

Selecting Reset All resets phone settings and clears all phone data, including Contacts, History, Scheduler, and Messaging.

1. Press

> Settings > Advanced > Reset Defaults >

Reset All

2. Enter your security code and press Ok (left softkey).

3. Read the prompt and press Ye s (left softkey) to

complete the reset. (Press

No [right softkey] to

cancel.)

GPS Privacy Options

Your phone’s GPS privacy options control whether Java applications or other software applications on your phone may view the location of your phone. You may set your phone to one of these GPS privacy options.

Privacy options do not apply to the transmission of

Note

location information during emergency 911 calls.

88 Section 2C. Security

To set your GPS privacy options:

1. Press M > GPS > Privacy.

2. If your GPS PIN security feature is enabled, enter

your GPS PIN. (See “Setting the GPS PIN Security Feature” on page 89 for more information.)

3. Select the privacy option you want:

䡲 Restricted — No Java or similar software

applications may view the location of your phone. However, location information may still be available to the phone’s owner, fleet manager, or account administrator.

䡲 Unrestricted — All applications may view the

location of your phone, without notifying you.

䡲 Ask Access — When an application attempts to

view the location of your phone, you will be prompted to give permission. However, location information may still be available to the phone’s owner, fleet manager, or account administrator.

Motorola i776 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

FCC Notice to Users

Table of Contents

Introduction

Your Phone’s Menu

Use and Care

Getting Started

Setting Up Your Phone

Setting Up Service

Setting Up Your Voicemail

Activating Your Phone

Enabling Security

Account Passwords

Getting Help

Managing Your Account

Phone Basics

Your Phone

Key Functions

Getting Started With Your Phone

You r SIM Car d

Using Your Phone’s Battery and Charger

Battery Use and Battery Safety

Turning Your Phone On and Off

Features of Your Phone

Viewing the Status Information

Navigating Through Phone Menus and Options

Displaying Your Phone Number and Direct Connect Number

My Info

Editing My Info

Entering Text

Selecting a Text Input Mode

Entering Text Using Word Text Input

Entering Text Using Alpha Mode

Entering Symbols, Numbers, and Quick Notes

Special Function Keys

Accessories

Using a Remote Direct Connect Button

Using Your Phone

Types of Calls

Making and Answering Calls

Making and Answering Phone Calls

Making Calls

Answering Calls

Missed Phone Calls

Calling Emergency Numbers

In-Call Options

End-of-Call Options

Saving a Phone Number

Finding a Phone Number

Dialing and Saving Phone Numbers With Pauses

Dialing From the Contacts List

Making a Call From Recent Calls

Making a Phone Call Using a Voice Name

Using Speed Dialing

Redialing the Last Number

Using Speakerphone

Using Mute

Making and Answering Direct Connect Calls

Making Direct Connect Calls

Answering Direct Connect Calls

Making and Answering Group Connect Calls

Making Group Connect Calls

Answering Group Connect Calls

Creating Groups in Contacts

Adding Group Members

Starting a Group Connect Call With a Direct Connect Number

Removing Members or Groups

Storing Groups

Storing Members of Groups

Group Connect Call Information

Group Connect Call Details

Nextel Direct Send

Sending a Picture

Setting Picture Capability

Sending My Info and Contact Information

Sending Groups Using Direct Send

Making and Answering Talkgroup Calls
