Motorola APX Mobile User Manual

APXTM TWO-WAY RADIOS

APX MOBILE
O2 CONTROL HEAD

USER GUIDE

m

ASTRO® APX™
O2 Control Head Mobile Radio
Quick Reference Card

RF Energy Exposure and Product Safety Guide for
Mobile Two-Way Radios

ATTENTION!

This radio is restricted to Occupational use only. Before using the
radio, read the RF Energy Exposure and Product Safety Guide for
Mobile Two-Way Radios which contains important operating
instructions for safe usage and RF energy awareness and control
for Compliance with applicable standards and Regulations.

Radio Controls

Radio On/Off

Adjusting Volume

Selecting a Zone

Selecting a Channel

Receiving and Transmitting

Sending an Emergency Alarm

To exit emergency at any time, press and hold the
Emergency button or the PTT button.

Power Button

LED Indicators

Emergency
Button*

Multi-function Knob
(MFK)*

Home Button

Menu Select Buttons*

Accessory Port (Microphone)

*These controls/buttons are programmable.

Dimmer Button

Up & Down
Buttons*

Press the Power button to turn the radio on or off.

If volume is set as the primary mode,

1 Turn the MFK clockwise to increase volume or

counterclockwise to decrease the volume.

If volume is not set as the primary mode, press the MFK
once and repeat step 1.

If zone is set as the primary mode,

1 Turn the MFK until the display shows the desired

zone and press the PTT button to begin transmitting
on the displayed zone.

If zone is not set as the primary mode, press the MFK
once and repeat step 1.

OR

2 > or < (on the keypad mic.) to scroll to Zone.

3 Press the Menu Select button directly below Zone.
4 Rotate the MFK or D or U to the desired zone.

5 Press the Menu Select button directly below Sel or

the  button (on the keypad mic.) to confirm the
selected zone number.

6 Press the PTT button to begin transmitting on the

displayed zone.

If channel is set as the primary mode,

1 Turn the MFK until the display shows the desired

channel and press the PTT button to begin
transmitting on the displayed channel.

If channel is not set as the primary mode, press the MFK
once and repeat step 1.

OR

2 > or < (on the keypad mic.) to scroll to Chan.

3 Press the Menu Select button directly below Chan.
4 Rotate the MFK or press D or U to the desired

channel.

5 Press the Menu Select button directly below Sel or

the  button (on the keypad mic.) to confirm the
channel.

6 Press the PTT button to transmit on the displayed

channel.

1 Take the microphone off the hook.
2 Select zone/channel.
3 Listen for a transmission.

OR

> or < (on the keypad mic.) to Mon then press the

Menu Select button directly below Mon and listen for
activity.

4 Adjust volume, if necessary.
5 Press the PTT button to transmit; release to receive.

1 Press the Emergency button. A tone sounds and the

display alternates Emergency and the home display.

2 A dispatcher acknowledgment Ack received display

follows.

AND, Trunking Only:

A high-pitched tone indicates that the alarm has been
received by the trunked system’s central controller.

*PMLN6193C*

PMLN6193C

MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motor ola
Trademark Holdings, LLC and are used under license. All o ther trademarks are the property of their respective owner s.

Sending an Emergency Call (Trunking Only)

To exit emergency at any time, press and hold the
Emergency button.

Sending a Silent Emergency Alarm

If silent emergency alarm is used with emergency call,
pressing the PTT button exits the silent mode and
initiates the emergency call.

Display Status Icons

1 Press Emergency button.

2 A tone sounds and the display alternates

Emergency and the home display.

OR

A short low-pitched tone sounds when the selected
channel does not support emergency.

3 Press and hold the PTT button. Speak clearly into the

microphone.

4 Release the PTT to end the transmission.

1 Press the preprogrammed Emergency button to

activate the silent alarm feature.

2 The display does not change; the LED does not light

up, and there is no tone.

Receiving a call or data.

Transmitting a call or data.

Received an Individual Call.

The more stripes, the stronger the signal
strength for the current site (trunking only).

u

t

F

V

Direct radio-to-radio communication or
communication through a repeater.

On = Direct
Off = Repeater

This channel is being monitored.

Voice muting the affiliated trunking talkgroup
or selected channel.

On = Enabled
Off = Disabled

L = Radio is set at Low power.
H = Radio is set at High power.

Scanning a scan list.

Blinking dot = Detects activity on the

Priority-One Channel during
scan.

Steady dot = Detects activity on the Priority-

Two Channel during scan.

The vote scan feature is enabled.

O

M

K

HOR .

i

j
k

On = Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice

call.

On = AES Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice

call.

On = Location feature enabled, and location

signal available.

Off = Location feature disabled.
Blinking = Location feature enabled, but

location signal unavailable.

Inverted = User is currently associated with

the radio.

On = Packet data is activated.
Off = Packet data is deactivated.
Blinking = Device registration or user

registration with the server failed
due to an invalid username or
pin.

Data activity is present.

MFK is in Mode Change feature

Turn the MFK to change channel.

MFK is in Volume Change feature

Turn the MFK to adjust the volume.

m

l

G

n

o

Menu Navigation

< or > to Menu Entry

(on the keypad mic.).

g directly below Menu Entry

to select.

H to exit.

U or D to scroll through sub-list.

g directly below Menu Entry to select.

Declaration of Conformity

i

Declaration of Conformity

This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.

DECLARATION OF CONFORMITY

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party
Name: Motorola Solutions, Inc.

Address: Motorola Solutions, Inc., 1303 East Algonquin Road Schaumburg, IL60196, U.S.A.
Phone Number: 1-800-927-2744

Hereby declares that the product:

Model Name: APX Mobile

conforms to the following regulations:

FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)

Class B Digital Device

As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

ii

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Declaration of Conformity

iii

Additional FCC Notes to Users

The following FCC information applies to Bluetooth radio options

IC Model Name: PMHN4193A

Description: O2 Bluetooth Option Board

FCC ID: AZ492FT6002

IC: 109U-92FT6002

Conforms to the following regulations: FCC Part 15, Section 15.19, 15.12, and 15.105

Note: Changes or modifications not expressly approved by Motorola may void the users authority, as authorized by the

FCC, to operate this device and should not be made. See 47 CFR Part 15.21. Information to user.The users manual
or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications
not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation. See 47 CFR Part. 15.19(3).

This device has been tested and found to comply with the limits of Part 15.15 of the FCC rules. Parties responsible for
equipment compliance should note that the limits specified in this part will not prevent harmful interference under all
circumstances.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. See Part 15.105b These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.

Declaration of Conformity

iv

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industry Canada (IC) Statements:

This Class B digital apparatus complies with ICES-003 and Radio Standards Specification (RSS) 210.

Contents

v

Contents

Declaration of Conformity . . . . . . . . . . . . . . . . . .i

Important Safety Information. . . . . . . . . . . . . . .xi

RF Energy Exposure and Product Safety

Guide for Mobile Two-Way Radios . . . . . . . . . . . . . .xi

Software Version . . . . . . . . . . . . . . . . . . . . . . . xii

Notice to Users (FCC and Industry Canada) . . . . . . xii

Informations importantes sur la sécurité. . . . xii

Exposition aux radiofréquences et sécurité

du produit pour radios bidirectionnelles portatives . xii

Version du logiciel . . . . . . . . . . . . . . . . . . . . . .xiii

Avis aux utilisateurs (FCC et Industrie Canada) . . .xiii

Computer Software Copyrights. . . . . . . . . . . .xiv

Documentation Copyrights . . . . . . . . . . . . . . .xiv

Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv

Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . .1

How to Use This User Guide . . . . . . . . . . . . . . . . . . . 1

Notations Used in This Manual . . . . . . . . . . . . . . . . . 1

Additional Performance Enhancement . . . . . . . . . . . 2

Dynamic System Resilience (DSR) . . . . . . . . . . . . . 2

ASTRO 25 Enhanced Data. . . . . . . . . . . . . . . . . . . . 2

CrossTalk Prevention . . . . . . . . . . . . . . . . . . . . . . . . 2

Encrypted Integrated Data (EID) . . . . . . . . . . . . . . . 2

SecureNet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

P25 Digital Vehicular Repeater System (DVRS) . . . 2

What Your Dealer/System Administrator

Can Tell You. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Preparing Your Radio for Use . . . . . . . . . . . . . .3

Turning On the Radio. . . . . . . . . . . . . . . . . . . . . . . . . 4

Validating Compatibility During Power Up . . . . . . . . 4

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . 5

Identifying Radio Controls . . . . . . . . . . . . . . . . .5

Radio Parts and Controls. . . . . . . . . . . . . . . . . . . . . . 6

O2 Control Head and Microphone . . . . . . . . . . . . . . 6

Programmable Features . . . . . . . . . . . . . . . . . . . . . . 7

One Touch Button . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Assignable Radio Functions . . . . . . . . . . . . . . . . . . . 7

Contents

vi

Assignable Settings or Utility Functions . . . . . . . . . . 9

Accessing the Preprogrammed Functions . . . . . . . 10

Using the Menu Select Buttons . . . . . . . . . . . . . . . . 10

Using the Advance Programmable Buttons. . . . . . . 11

Using the Navigation Buttons . . . . . . . . . . . . . . . . . 11

Home Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Multi-function Knob. . . . . . . . . . . . . . . . . . . . . . . . . 12

Using the Keypad . . . . . . . . . . . . . . . . . . . . . 14

Keypad Characters – Uppercase Mode . . . . . . . . . 14

Keypad Characters – Lowercase Mode . . . . . . . . . 15

Keypad Characters – Numeric Mode . . . . . . . . . . . 16

Keypad Characters – Hexadecimal Mode . . . . . . . . 17

Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . . 18

Identifying Status Indicators . . . . . . . . . . . . . .18

Status Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Text Messaging Service (TMS) Icons . . . . . . . . . . . 21

Status Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . 22

Call Type Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Multi-function Knob - Concentric Ring LED . . . . . . 24

Intelligent Lighting Indicators . . . . . . . . . . . . . . . 25

Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

General Radio Operation . . . . . . . . . . . . . . . . . 31

Selecting a Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Selecting a Radio Channel . . . . . . . . . . . . . . . . . . . 32

Receiving and Responding to a Radio Call. . . . . . . 32

Receiving and Responding to a Talkgroup Call . . . .33

Receiving and Responding to a Private Call

(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Receiving and Responding to a Telephone Call . . .34

Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . 35

Making a Talkgroup Call . . . . . . . . . . . . . . . . . . . . .35

Making a Private Call (Trunking Only) . . . . . . . . . . .36

Making a Telephone Call . . . . . . . . . . . . . . . . . . . . .37

Repeater or Direct Operation . . . . . . . . . . . . . . . . . 37

Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . 38

Monitoring a Channel . . . . . . . . . . . . . . . . . . . . . . . .38

Conventional Mode Operation . . . . . . . . . . . . . . . . .39

Advanced Features . . . . . . . . . . . . . . . . . . . . . 40

Advanced Call Features . . . . . . . . . . . . . . . . . . . . . 40

Calling a Phone Not in the List. . . . . . . . . . . . . . . . .40

Receiving and Making a Selective Call

(Conventional Only) . . . . . . . . . . . . . . . . . . . . . . . . .41

Contents

vii

Receiving a Selective Call. . . . . . . . . . . . . . . . . . . .41

Making a Selective Call. . . . . . . . . . . . . . . . . . . . . .41

Using the Talkgroup Call Feature (Conventional

Operation Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Selecting a Talkgroup . . . . . . . . . . . . . . . . . . . . . . .42

Sending a Status Call. . . . . . . . . . . . . . . . . . . . . . . .43

Using the Dynamic Regrouping Feature

(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Requesting a Reprogram . . . . . . . . . . . . . . . . . . . .44

Classifying Regrouped Radios . . . . . . . . . . . . . . . .45

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Making a Private Call from Contacts . . . . . . . . . . . .46

Adding a New Contact Entry . . . . . . . . . . . . . . . . . .47

Deleting a Contact Entry . . . . . . . . . . . . . . . . . . . . .48

Adding a Contact to a Call List or Phone List. . . . . .49

Editing a Contact in a Call List or a Phone List . . . .49

Editing an Entry Alias . . . . . . . . . . . . . . . . . . . . . . .49

Editing as Entry ID . . . . . . . . . . . . . . . . . . . . . . . . .50

Editing a Call Type . . . . . . . . . . . . . . . . . . . . . . . . .51

Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Viewing a Scan List . . . . . . . . . . . . . . . . . . . . . . . . .51

Editing the Scan List . . . . . . . . . . . . . . . . . . . . . . . .52

Changing the Scan List Status. . . . . . . . . . . . . . . . .52

Viewing and Changing the Priority Status . . . . . . . .53

Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Turning Scan On or Off . . . . . . . . . . . . . . . . . . . . . .53

Turning Scan On While Disregarding the Squelch

Code (Conventional Channels Only) . . . . . . . . . . . 54

Transmitting While the Scan is On . . . . . . . . . . . . . 54

Radio Programmed for Talkback Scan . . . . . . . . . 54

Radio Programmed for Non-Talkback Scan . . . . . 55

Deleting a Nuisance Channel . . . . . . . . . . . . . . . . . 55

Restoring a Nuisance Channel . . . . . . . . . . . . . . . . 55

Changing Priorities Status While Scan is On . . . . . 56

Restoring Priorities in a Scan List. . . . . . . . . . . . . . 56

Hang Up Box (HUB) . . . . . . . . . . . . . . . . . . . . . . . . 56

Call Alert Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Receiving a Call Alert Page . . . . . . . . . . . . . . . . . . 57

Sending a Call Alert Page. . . . . . . . . . . . . . . . . . . . 58

In-Call User Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . 59

Sending an Emergency Alarm . . . . . . . . . . . . . . . . 60

Sending an Emergency Call (Trunking Only) . . . . . 60

Sending an Emergency Alarm with Emergency

Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Sending a Silent Emergency Alarm . . . . . . . . . . . . 61

Special Considerations for Emergencies . . . . . . . . 62

Automatic Registration Service (ARS) . . . . . . . . . . . 63

Selecting or Changing ARS Mode . . . . . . . . . . . . . 63

Accessing the User Login Feature . . . . . . . . . . . . . 64

Logging In as a User . . . . . . . . . . . . . . . . . . . . . . . 64

Logging Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Contents

viii

Text Messaging Service (TMS) . . . . . . . . . . . . . . . . 66

Accessing TMS Feature . . . . . . . . . . . . . . . . . . . . . 66

Composing and Sending a New Text Message . . . 67

Sending a Quick Text Message. . . . . . . . . . . . . . . . 68

Using the Priority Status and Request Reply

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Appending or Removing a Priority Status to

a Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Appending or Removing a Request Reply to

a Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Appending a Priority Status and a Reply

Request to a Text Message . . . . . . . . . . . . . . . . . . 70

Removing a Priority Status and a Reply

Request from a Text Message . . . . . . . . . . . . . . . . 71

Managing Text Messages . . . . . . . . . . . . . . . . . . . . 71

Receiving a Text Message . . . . . . . . . . . . . . . . . . . 71

Viewing a Text Message from the Inbox. . . . . . . . . 72

Replying to a Received Text Message . . . . . . . . . . 73

Accessing the Drafts Folder . . . . . . . . . . . . . . . . . . 74

Managing Sent Text Messages . . . . . . . . . . . . . . . . 74

Viewing a Sent Text Message . . . . . . . . . . . . . . . . 74

Sending a Sent Text Message . . . . . . . . . . . . . . . . 75

Deleting Text Messages . . . . . . . . . . . . . . . . . . . . . 76

Secure Operations . . . . . . . . . . . . . . . . . . . . . . . . . 76

Managing Encryption. . . . . . . . . . . . . . . . . . . . . . . . 76

Loading a Single Encryption Key . . . . . . . . . . . . . . 76

Loading the Group Encryption Keys . . . . . . . . . . . . 77

Using the Multikey Feature . . . . . . . . . . . . . . . . . . .77

Selecting an Encryption Key (Conventional

Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Enabling Secure Transmission . . . . . . . . . . . . . . . .78

Accessing the Secure Feature . . . . . . . . . . . . . . . .79

Selecting a Keyset. . . . . . . . . . . . . . . . . . . . . . . . . .79

Erasing the Selected Encryption Keys . . . . . . . . . .79

Requesting an Over-the-Air Rekey . . . . . . . . . . . . .80

MDC Over-the-Air Rekeying (OTAR) Page. . . . . . .80

Infinite UKEK Retention. . . . . . . . . . . . . . . . . . . . . .80

Hear Clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

The Global Positioning System (GPS) . . . . . . . . . . 81

Understanding the GPS Feature . . . . . . . . . . . . . . .81

Enhancing GPS Performance . . . . . . . . . . . . . . . . .82

The Outdoor Location Feature (Using GPS) . . . . . .82

Accessing the Outdoor Location Feature . . . . . . . .83

Saving a Waypoint . . . . . . . . . . . . . . . . . . . . . . . . .84

Viewing a Saved Waypoint . . . . . . . . . . . . . . . . . . .85

Editing the Alias of a Waypoint . . . . . . . . . . . . . . . .86

Editing the Coordinates of a Waypoint . . . . . . . . . .86

Deleting a Single Saved Waypoint . . . . . . . . . . . . .87

Deleting All Saved Waypoints . . . . . . . . . . . . . . . . .88

Measuring the Distance and Bearing from a

Saved Waypoint . . . . . . . . . . . . . . . . . . . . . . . . . . .88

Using the Location Feature While in

Emergency Mode . . . . . . . . . . . . . . . . . . . . . . . . . .89

Trunking System Controls. . . . . . . . . . . . . . . . . . . . 89

Contents

ix

Using the Failsoft System . . . . . . . . . . . . . . . . . . . .89

Going Out-of-Range. . . . . . . . . . . . . . . . . . . . . . . . .90

SmartZone®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Using Site Trunking Feature . . . . . . . . . . . . . . . . . .90

Locking and Unlocking a Site. . . . . . . . . . . . . . . . . .91

Viewing and Changing a Site . . . . . . . . . . . . . . . . . .91

Viewing the Current Site . . . . . . . . . . . . . . . . . . . . .91

Changing the Current Site . . . . . . . . . . . . . . . . . . .92

Trunked Announcement. . . . . . . . . . . . . . . . . . . . . .92

Initiating an Announcement . . . . . . . . . . . . . . . . . .93

Ignition Switch Options . . . . . . . . . . . . . . . . . . . . . . 93

Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

Tx Inhibit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

PTT Tx Inhibit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93

Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

Soft Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

Ignition Only Power Up . . . . . . . . . . . . . . . . . . . . . .94

Emergency Power Up . . . . . . . . . . . . . . . . . . . . . . .94

Auto Power Off Timer. . . . . . . . . . . . . . . . . . . . . . . .95

Voice Announcement. . . . . . . . . . . . . . . . . . . . . . . . 95

Using Site Selectable Alerts (ASTRO 25) . . . . . . . . 96

Sending SSA Notification to Single Site. . . . . . . . . .96

Sending SSA Notification to Single Site Via

Manual Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Sending SSA Notification to All Sites . . . . . . . . . . . .98

Sending SSA Notification to All Available Sites . . . .99

Stopping SSA Notification of a Single Site . . . . . . . 99

Stopping SSA Notification of a Single Site Via

Manual Entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Stopping SSA Notification of All Sites. . . . . . . . . . 100

Stopping SSA Notification of All Available Sites . . 101

Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Viewing Recent Calls List . . . . . . . . . . . . . . . . . . . 101

Selecting the Power Level . . . . . . . . . . . . . . . . . . 102

Selecting a Radio Profile . . . . . . . . . . . . . . . . . . . 102

Controlling the Display Backlight . . . . . . . . . . . . . 103

Turning Keypad Tones On or Off . . . . . . . . . . . . . 103

Turning Voice Mute On or Off. . . . . . . . . . . . . . . . 104

Using the Time-Out Timer . . . . . . . . . . . . . . . . . . 104

Using the Conventional Squelch Operation

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Analog Options . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Digital Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Using the PL Defeat Feature . . . . . . . . . . . . . . . . 106

Using the Digital PTT ID Feature . . . . . . . . . . . . . 106

Using the Smart PTT Feature (Conventional

Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Accessing General Radio Information . . . . . . . . . 107

Accessing Radio Information . . . . . . . . . . . . . . . . 107

Viewing IP Information. . . . . . . . . . . . . . . . . . . . . 108

Viewing Control Assignments . . . . . . . . . . . . . . . 109

Using Siren, PA and Light . . . . . . . . . . . . . . . . . . 109

Using Keypad as Siren Type Selector . . . . . . . . 109

Contents

x

Using Keypad as Light Type Selector. . . . . . . . . . 110

Using the Public Address Button on the

Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Using the External Public Address Button on the

Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Using Optional External Alarms (Horn and

Lights) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Using Non-Permanent Horn and Lights . . . . . . . . 111

Using Permanent Horn and Lights . . . . . . . . . . . . 111

Changing the Selected Alarms . . . . . . . . . . . . . . . 112

Receiving a Call While Alarms are Turned On . . . 112

Turning Off Non-Rearmable External Alarms . . . . 112

Turning Off Rearmable External Alarms. . . . . . . . 113

Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . .113

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .114

Appendix: Maritime Radio Use in the VHF

Frequency Range. . . . . . . . . . . . . . . . . . . . . . .115

Special Channel Assignments. . . . . . . . . . . . . . . . 115

Emergency Channel . . . . . . . . . . . . . . . . . . . . . . . 115

Non-Commercial Call Channel . . . . . . . . . . . . . . . 116

Operating Frequency Requirements . . . . . . . . . . . 116

Declaration of Compliance for the Use of

Distress and Safety Frequencies . . . . . . . . . . . . . 118

Technical Parameters for Interfacing

External Data Sources. . . . . . . . . . . . . . . . . . . . . 118

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Commercial Warranty and Service . . . . . . . . 123

Important Safety Information

xi

Important Safety Information

RF Energy Exposure and Product Safety
Guide for Mobile Two-Way Radios

ATTENTION!

This radio is restricted to Occupational use only.

Before using the radio, read the RF Energy Exposure and
Product Safety Guide for Mobile Two-Way Radios which
contains important operating instructions for safe usage
and RF energy awareness and control for Compliance
with applicable standards and Regulations.

For a list of Motorola-approved antennas and other
accessories, visit the following website:

http://www.motorolasolutions.com/apx

Any modification to this device, not expressly authorized
by Motorola, may void the user’s authority to operate this
device.

Under Industry Canada regulations, this radio transmitter
may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so

chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful
communication.

This radio transmitter has been approved by Industry
Canada to operate with the Motorola-approved antenna
types with the maximum permissible gain and required
antenna impedance for each antenna type indicated.
Antenna types not included, having a gain greater than
the maximum gain indicated for that type, are strictly
prohibited for use with this device.

Note: Setting up the radio as an RF Modem takes complete

control of the radio. In this mode, the radio no longer
responds to button and PTT presses nor will it unmute
to voice activity. This mode is designed to receive and
pass specifically formatted over the air data to a
tethered computer with RF modem enabled
applications. This mode can only be exit by
reprogramming the radio with Customer Programming
Software (CPS) to not operate in RF modem mode and
cycling power.

Software Version

xii

Software Version

All the features described in the following sections are

supported by the radio's software version R11.00.00 or
later.

Accessing Radio Information on page 107 to
determine your radio's software version.

Check with your dealer or system administrator for more
details of all the features supported.

Notice to Users (FCC and Industry Canada)

This device complies with Part 15 of the FCC rules, Industry

Canada license-exempt RSS standard(s) and RSS 210 of
the Industry Canada rules

per the conditions listed below:

1 This device may not cause harmful interference.

2 This device must accept any interference received, including

interference that may cause undesired operation.

3 Changes or modifications made to this device, not expressly

approved by Motorola, could void the user's authority to
operate this equipment.

Informations importantes sur la
sécurité

Exposition aux radiofréquences et sécurité
du produit pour radios bidirectionnelles
portatives

ATTENTION!

Cette radio ne doit être utilisée qu'à des fins
professionnelles. Avant d'utiliser la radio, lisez le guide

Exposition aux radiofréquences et sécurité du produit
pour radios bidirectionnelles portatives, qui contient
d'importantes instructions de fonctionnement pour une
utilisation sécuritaire et des informations sur l'exposition
aux fréquences radioélectriques afin d'assurer la
conformité aux normes et règlements applicables.

Pour obtenir une liste d'antennes et d'autres accessoires
approuvés par Motorola, consultez le site Web:

http://www.motorolasolutions.com/apx

Toute modification effectuée à cet appareil sans
l'autorisation explicite de Motorola peut annuler
l'autorisation d'utiliser cet appareil.

Version du logiciel

xiii

Selon la règlementation d'Industrie Canada, cet émetteur
radio ne peut être utilisé qu'avec une antenne dont le
type et le gain maximal (ou minimal) sont approuvés par
Industrie Canada pour cet émetteur. Afin de limiter les
interférences radio pour les autres utilisateurs, le type et
le gain de l'antenne doivent être choisis de façon à ce
que la puissance isotrope rayonnée équivalente (P.I.R.E.)
ne soit pas plus forte qu'il ne le faut pour établir la
communication.

Le présent émetteur a été approuvé par Industrie Canada
pour fonctionner avec les types d'antenne agréés par
Motorola et ayant un gain admissible maximal ainsi que
l'impédance requise pour chaque type d'antenne indiqué.
Les types d'antenne non inclus, dont le gain est supérieur
au gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.

Remarque: Régler la radio en tant que modem RF prend le

contrôle complet de la radio. Dans ce mode, la
radio ne répond plus aux pressions des boutons de
commande et PTT, et ne reçoit aucun signal vocal.
Ce mode est conçu pour recevoir et transmettre
des données spécifiquement formatées pour la
liaison radio avec un ordinateur attaché doté
d'applications compatibles avec le modem RF. Ce
mode ne peut être désactivé qu'en reprogrammant
la radio avec un logiciel CPS (programmation

client) afin qu'elle ne fonctionne plus en mode
modem RF et en la redémarrant.

Version du logiciel

Toutes les fonctionnalités décrites dans les sections

suivantes sont prises en charge par la version du logiciel
R11.00.00 ou ultérieure de la radio.

Vérifiez auprès de votre détaillant ou de l'administrateur
de système pour obtenir des renseignements sur les
fonctionnalités prises en charge.

Avis aux utilisateurs (FCC et Industrie
Canada)

Cet appareil est conforme à la Partie 15 des règlements
de la FCC, normes CNR (cahiers des charges sur les
normes radioélectriques) pour les appareils exempts de
licence d’Industrie Canada et RSS 210 du règlement
d'Industrie Canada selon les conditions énumérées ci­dessous:

1 Ce dispositif ne doit pas causer d'interférences nuisibles.

2 Cet appareil doit accepter toute interférence reçue, y compris

les interférences qui peuvent perturber le fonctionnement.

Computer Software Copyrights

xiv

3 Les changements ou les modifications apportées à ce

dispositif, non expressément approuvées par Motorola,
peuvent annuler le droit de l'utilisateur à utiliser cet
équipement.

Computer Software Copyrights

The Motorola products described in this manual may
include copyrighted Motorola computer programs stored
in semiconductor memories or other media. Laws in the
United States and other countries preserve for Motorola
certain exclusive rights for copyrighted computer
programs including, but not limited to, the exclusive right
to copy or reproduce in any form the copyrighted
computer program. Accordingly, any copyrighted
Motorola computer programs contained in the Motorola
products described in this manual may not be copied,
reproduced, modified, reverse-engineered, or distributed
in any manner without the express written permission of
Motorola. Furthermore, the purchase of Motorola
products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Motorola,
except for the normal non-exclusive license to use that
arises by operation of law in the sale of a product.

Documentation Copyrights

No duplication or distribution of this document or any
portion thereof shall take place without the express
written permission of Motorola. No part of this manual
may be reproduced, distributed, or transmitted in any
form or by any means, electronic or mechanical, for any
purpose without the express written permission of
Motorola.

Disclaimer

The information in this document is carefully examined,
and is believed to be entirely reliable. However, no
responsibility is assumed for inaccuracies. Furthermore,
Motorola reserves the right to make changes to any
products herein to improve readability, function, or
design. Motorola does not assume any liability arising out
of the applications or use of any product or circuit
described herein; nor does it cover any license under its
patent rights, nor the rights of others.

Getting Started

1

Getting Started

Take a moment to review the following:

How to Use This User Guide. . . . . . . . . . . . . . . . . . . . . page 1

Notations Used in This Manual . . . . . . . . . . . . . . . . . . . page 1

Additional Performance Enhancement . . . . . . . . . . . . . page 2

What Your Dealer/System Administrator Can Tell You . page 3

How to Use This User Guide

This User Guide covers the basic operation of the APX™
Mobile Radios.

However, your dealer or system administrator may have
customized your radio for your specific needs. Check with your
dealer or system administrator for more information.

Notations Used in This Manual

Throughout the text in this publication, you will notice the use of
WARNING, Caution, and Note. These notations are used to
emphasize that safety hazards exist, and the care that must be

taken or observed.The following special notations identify
certain items:

An operational procedure, practice, or condition,
etc., which may result in injury or death if not
carefully observed.

An operational procedure, practice, or
condition, etc., which may result in damage
to the equipment if not carefully observed.

Note:

An operational procedure, practice, or condition,
etc., which is essential to emphasize.

Example Description

Home button

or

H

Buttons and keys are shown in bold print or as
an icon.

PHONE

Menu entries are shown similar to the way they
appear on the radio’s display.

>

This means “Press the right side of the 4-way
Navigation button.” (Using keypad mic)

!

W A R N I N G

!

!

Caution

Getting Started

2

Additional Performance Enhancement

The following are some of the latest creations designed to
enhance the security, quality and efficiency of APX mobile
radios.

Dynamic System Resilience (DSR)

DSR ensures the radio system is seamlessly switched to a
backup master site dynamically in case of system failure.
DSR also provides additional indication e.g. failure detection,
fault recovery, and redundancy within the system to address to
the user in need. Mechanisms related to the Integrated Voice
and Data (IV & D) or data centric are all supported by DSR.

ASTRO 25 Enhanced Data

ASTRO 25 Enhanced Data is optimized to handle different
message sizes and variable update rates from different
applications of the radio. Add Enhanced Data to the Integrated
Data system with a software installation to improve data
channel efficiency and enable denser network traffic.

CrossTalk Prevention

This feature prevents crosstalk scenario from happening,
especially when a wideband antenna is used. This feature
allows the adjustment of the Trident Transmitting SSI clock rate
in the radio to be varied from the Receiving Frequency. This
subsequently reduced the possibilities of radio frequency
interfering spurs and prevents the issues of crosstalk.

Encrypted Integrated Data (EID)

EID provides security encryption and authentication of IV & D
data bearer service communication between the radio and the
Customer Enterprise Network.

SecureNet

SecureNet allows user to perform secured communications on
an Analog or Motorola Data Communication (MDC) channel.
The MDC OTAR feature will allow users to perform OTAR
activities on an MDC channel.

P25 Digital Vehicular Repeater System (DVRS)

Motorola Solutions offers an MSI Certified APX compatible, 3rd
Party, P25 Digital Vehicular Repeater System (DVRS) that
provides low cost portable radio coverage in areas where only
mobile radio coverage is available and portable radio coverage
is either intermittent or non-existent.





Preparing Your Radio for Use

3

What Your Dealer/System Administrator

Can Tell You

You can consult your dealer or system administrator about the
following:

• Is your radio preprogrammed with any preset conventional

channels?

• Which buttons have been programmed to access other

features?

• What optional accessories may suit your needs?

Preparing Your Radio for Use

Turning On the Radio. . . . . . . . . . . . . . . . . . . . . . . . . . page 4

Validating Compatibility During Power Up. . . . . . . . . . page 4

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . .page 5

Preparing Your Radio for Use

4

Turning On the Radio

Press the Power Button briefly
turn on the radio.

After a short time, the red,
yellow and green LEDs light up.
The display then shows Zone
and channel text, and menu
items display on the screen.

The backlight will turn on to the
last selected dim level.

Note: Pressing the Power Button before the LED lights up

will be ignored.

If Fail ##/## appears in the display, the radio will not
function until the condition has been corrected.

If Error ##/## appears, some non-critical data has
been changed. If either of these displays appear, if the
display goes blank, or if the unit appears to be locked
up, see Helpful Tips on page 113 for more information.

If the power-up test is unsuccessful, you see Error
XX/YY (XX/YY is an alphanumeric code).
Turn off the radio, check the battery, and turn the radio
back on. If the radio fails the power-up test again,
record the Error XX/YY code and contact your dealer.

If

CH Mismatch appears, means that either the Control

Head has been connected to an incompatible
transceiver, or vice versa.

If your radio does not power up, contact your dealer.

To turn off the radio, press the Power Button after the LEDs
light up.

Validating Compatibility During Power Up

The radio validates and updates the software and hardware of
your control head(s) during power up. Follow the procedure
below when your radio runs this task.

Procedure:

1 The display shows Maintenance mode remote device;

promptly followed by other maintenance statuses.

2 The display shows Update done please reset upon

completion.

OR

The display shows Update failed please reset when it
fails to update.

3 Press the Power Button to reset. The radio runs the usual

power up operation if the software updates are complete.

OR

The radio runs the Maintenance Mode if the updates are not
complete and repeat step 1.

Power Button

LEDs



Identifying Radio Controls

5

Note: If Sw incomplete appears, use Flashport Recovery

Tool to update the control heads before you power on
the radio again.

Adjusting the Volume

To increase the volume,
rotate the Multi-Function
Knob (MFK) clockwise.

To decrease the volume,
rotate the MFK
counterclockwise.

The display shows volume
bars and volume level
when you change the
volume.

Identifying Radio Controls

Take a moment to review the following:

Radio Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . .page 6

O2 Control Head and Microphone . . . . . . . . . . . . . . .page 6

Programmable Features . . . . . . . . . . . . . . . . . . . . . . . .page 7

Assignable Radio Functions. . . . . . . . . . . . . . . . . . . .page 7

Assignable Settings or Utility Functions . . . . . . . . . . .page 9

Accessing the Preprogrammed Functions . . . . . . . . . .page 10

Using the Menu Select Buttons . . . . . . . . . . . . . . . .page 10

Using the Advance Programmable Buttons . . . . . . . page 11

Using the Navigation Buttons . . . . . . . . . . . . . . . . . . page 11

Using the Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 14

Keypad Characters – Uppercase Mode . . . . . . . . . .page 14

Keypad Characters – Lowercase Mode . . . . . . . . . .page 15

Keypad Characters – Numeric Mode . . . . . . . . . . . .page 16

Keypad Characters – Hexadecimal Mode . . . . . . . . page 17

Push-To-Talk (PTT) Button. . . . . . . . . . . . . . . . . . . . . .page 18

Multi-Function Knob

Identifying Radio Controls

6

Radio Parts and Controls

O2 Control Head and Microphone

Note: The microphone is not part of a radio. It is an optional

accessory.



Power Button

LED Indicators

Emergency Button*

Push-to-Talk
(PTT) Button

Accy No-Dot
Button (Purple)*

Accy 2-Dot
Button*

Multi-function Knob
(MFK)*

Home Button

Menu Select Buttons*

Accessory Port (Microphone)

*These controls/buttons are programmable.

Accy 1-Dot
Button*

Dimmer Button

Up & Down Buttons*

Check with your dealer or system administrator for more details
of all the features supported

Bluetooth Indicator**

Home Button
(Microphone)

Data Feature
Button*

Okay/Select
Button (



)

Cancel Button
(



)

Navigation
Button
(Microphone)

Keypad

*This button is programmable.

Identifying Radio Controls

7

Programmable Features

Any reference in this manual to a control that is
“preprogrammed” means that the control must be programmed
by a dealer or a qualified radio technician using the radio’s
programming software, in order to assign a feature to that
control.

The programmable buttons can be programmed as shortcuts to
radio functions or preset channels/groups depending on the
duration of a button press:

• Press – Pressing and releasing rapidly.

• Long press – Pressing and holding for the programmed

duration (between 0.25 seconds and 3.75 seconds).

• Hold down – Keeping the button pressed.

One Touch Button

Each of the four Menu Select buttons, the Emergency button
and the three Accy buttons on the microphone are
programmable buttons which can be preprogrammed by a
qualified radio technician to a default function which is activated
upon a short press.

Assignable Radio Functions

Auxiliary – Switches back and forth between two radios that
are attached to the same control head.

Call Alert – Allows the radio to function like a pager, or to verify

if a radio is active on the system.

Call Response – Allows you to answer a private call or phone
call.

Channel – Selects a channel.

Contacts – Selects the Contacts menu.

Delete – Deletes digit, or deletes a nuisance channel in Scan.

Digital Vehicle Repeater System – Toggles between the

Digital Vehicle Repeater System (VRS) mode.

Dynamic Priority (Conventional Only) – Allows any channel
in a scan list (except for the Priority-One channel) to temporarily
replace the Priority-Two channel.

Emergency – Depending on the programming, initiates or
cancels an emergency alarm or call.

Information – Displays the basic radio information, IP-related
information, and buttons or switches control mapping.

Intercom – Enables users of multiple control heads to talk to
each other via the control heads in a multi-control head setup.

Internet Protocol Address – Displays the Internet Protocol (IP)
address, device name, and status of the radio.

Location – Determines the current location (latitude, longitude,
time and date), and also the distance and bearing to another





Identifying Radio Controls

8

location. Or, turns the GPS functionality on or off for all
locations.

Message – Enters the current message list.

Monitor (Conventional Only) – Monitors a selected channel

for all radio traffic until function is disabled.

Multiple Private Line (Conventional Only) – Selects the
Multiple Private Line lists.

Nuisance Delete – Temporarily removes an unwanted channel,
except for priority channels or the designated transmit channel,
from the scan list. The designated transmit channel refers to the
user’s selected zone/channel combination from which scan is
initiated.

One Touch 1 – 4 – Launches a specific feature with one single
button-press. You can setup as much as four separately
programmed buttons for four different features.

Phone – Allows you to make and receive calls similar to
standard phone calls.

Private Line Defeat (Conventional Only) – Overrides any
coded squelch (DPL or PL) that is preprogrammed to a channel.

Private Call (Trunking Only) – Allows a call from an individual
radio to another individual radio.

Radio Profiles – Allows for easy access to a set of
preprogrammed visual and audio settings of the radio.

Ext PA On/Off – Toggles the audio routing between the
connected public address (PA) loudspeaker amplifier and the
radio’s internal public address (PA) system.

Recent Calls – Allows for easy access to the list of calls
recently received or made.

Rekey Request – Notifies the dispatcher that you require a new
encryption key.

Repeater Access Button (RAB) (Conventional Only) –
Allows to manually send a repeater access codeword.

Reprogram Request (Trunking Only) – Notifies the dispatcher
that you want a new dynamic regrouping assignment.

Request-To-Talk (Conventional Only) – Notifies the
dispatcher that you want to send a voice call.

Scan – Toggles scan on or off.

Scan List Programming – Selects the scan list for editing.

Secure/Clear

– Toggles secure transmission on or off.

Select – Selects the assigned list for editing.

Selective Call (Conventional Only) – Calls an assigned radio.

Site Display (Trunking Only) – Views the current site or

enable a site search for SmartZone operation.

Site Lock/Unlock (Trunking Only) – Toggles between lock and
unlock mode when using the SmartZone option.

Identifying Radio Controls

9

Site Search (Trunking Only) – Performs site search for AMSS

(Automatic Multiple Site Select) or SmartZone operation.

Status – Sends data calls to the dispatcher about a predefined
status.

Talkaround/Direct (Conventional Only) – Toggles between
using a repeater and communicating directly with another radio.

Talkgroup (Conventional Only) – Allows a call from an
individual radio to a group of radios.

Text Messaging Service (TMS) – Selects the text messaging
menu.

TMS Quick Text – Selects a predefined message.

User Login – Automatically registers with the server.

Zone Down – Toggles downward through the zones in the

radio.

Zone Select – Allows selection from a list of zones.

Zone Up – Toggles upward through the zones in the radio.

Assignable Settings or Utility Functions

Air Horn – Toggles the external airhorn alert tone on or off.

All Tones/Alerts – Toggles all tones on or off.

Dimmer – Changes the display brightness.

External Radio – Toggles external radio on or off.

Front/Rear – Switches one of two control heads to be active at

one time.

HiLo – Toggles the Hilo Airhorn tones on or off.

Backlight – Toggles display backlight on or off.

Horns/Lights – Toggles horns and lights feature on or off.

Keypad Mute – Toggles the keypad tones on or off.

Keypad Lock – Locks the radio’s keypad, or even locks in the

radio’s currently operating channel when the Mode Knob scrolls
to other channels.

Low Power – Toggles transmit power level between high and
low.

Manual – Toggles the manual tone on or off.

Public Address On/Off – Toggles the radio’s internal public

address (PA) system on or off.

Siren – Toggles external siren alert tone on or off.



Identifying Radio Controls

10

Squelch – Toggles squelch level between normal open and

tight.

TX Power Level – Toggles transmit power level between high
and low.

Voice Announcement – Audibly indicates the current feature
mode, Zone or Channel the user has just assigned.

Voice Mute – Toggles voice mute on or off for the channels
which have enabled In-Call User Alert. When Voice Mute is
active, the radio remains muted to all conventional dispatch
calls and affiliated trunking group calls.

Vol u m e Set Tone – Adjusts the volume of the speakers, or
adjusts the volume of the radio’s alert tones.

Wail – Toggles the external wail alert tone on or off.

Yel p – Toggles the external yelp alert tone on or off.

Accessing the Preprogrammed Functions

You can access various radio functions through one of the
following ways:

• A short or long press of the relevant programmable buttons.

OR

• Use the Menu Select Button (g).

Using the Menu Select Buttons

The Menu Select Buttons allow you to access the menu
entries of features.

Note: Check with your dealer or system administrator for the

list of features activated in your radio.

Your radio may be preprogrammed differently from the following
example, but the steps for selecting a zone may appear as
shown below:

• Press the Menu Select button (g) directly below Zone.



Identifying Radio Controls

11

Using the Advance Programmable Buttons

This feature is to help you to shorten the process of applying
certain common features.

* These programmable buttons support the One

Touch Button feature.

(Quick Access) One Touch Button – Enters a menu with a

short press on the preprogrammed One Touch button. Features
assigned to these buttons are Call, Call Alert, Phone, Repeater
Access, MDC RTT Button Access, Status and Message.

Using the Navigation Buttons

Your radio is equipped with navigation buttons. The navigation
buttons will allow you to access the features in the radio.

Up and Down Buttons

By default, the U and D buttons are used as up and down

arrow input.

These buttons are programmable. They can be programmed to
navigate through zones, channels and to increase and
decrease the volume of the radio.

Right and Left Buttons

The > and < buttons mentioned throughout the manual can be

found on the keypad microphone (keypad mic.).

These buttons will allow you to navigate the lists in the radio.



Accy No-Dot Button
(Purple)*

Accy 1-Dot Button*

Accy 2-Dot Button*

Menu Select Buttons*

Emergency Button*

Up & Down Buttons



Identifying Radio Controls

12

Home Button

The H button returns you to the home (default) display. In most
cases, this is the current mode.

For selected radio features, the

H button is also used to save

user-edited radio settings or information before returning you to
the Home screen.

Note: Some features do not require you to press

H to go to

the Home screen. Refer to the individual feature
sections in this manual for further details on saving
user-edited radio settings or information.

The

H button also can revert to home channel from any other

zone and mode in the radio. Check with your dealer or system
administrator for more information.

Dimmer Button

Use this button to adjust the brightness of the display. Long
press to toggle between day and night mode.

Multi-function Knob

The MFK button on your radio is programmable to the following
features :

Mode Change - Press the MFK once and turn clockwise

to scroll the channel list.

Volume Change -Turn the MFK clockwise or
counterclockwise to adjust the volume level of the speaker.

The volume level can be adjusted in 16 steps or 32 steps. A fast
turn of the MFK adjusts the volume level in 16 steps with large
increments in volume level. A slow turn of the MFK adjusts the
volume level in 32 steps with small increments in volume level.

The display shows the volume level and bars to indicate the
current level. The level of last selected volume when your radio
powers down remains the same when the radio powers up.

The main display shows the icon of the secondary feature.The
main display does not show the icon of primary feature.

Your radio by default is set to use the primary feature. Short
press the MFK to toggle it to work on either the secondary or
primary feature.

The concentric ring LED on the MFK will blink in green when the
knob is set to secondary feature.



Identifying Radio Controls

13

The secondary feature has an inactivity timer. This timer starts
when the secondary feature is idle. The radio returns to primary
feature when the timer expires.

If the MFK is set to operate only one feature, it is recommended
that it be set to Volume Change.

Consult your dealer or system administrator for the best option
available for MFK.

Concentric
Ring LED

Identifying Radio Controls

14

Using the Keypad

You can use the 3 x 4 alphanumeric keypad on the keypad microphone to access your radio’s features. The keypad functions in a
manner similar to a standard telephone keypad when entering numeric digits. When the keypad is used to edit a list, each key can
generate different characters of the alphabet. The tables below show the number of times a key needs to be pressed to generate the
required character.

Keypad Characters – Uppercase Mode

Number of Times Key is Pressed

Key123456789101112131415161718192021

1

1. ,?! ;@_-*#&$/+=\“ ‘ ( )

2

ABC

3

DEF

4

GH I

5

JKL

6

MNO

7

PQRS

8

TUV

9

WX Y Z

0

Toggle between mixed case mode, uppercase mode, and lowercase mode.

*

Space

#

Toggle between numeric and letter mode.



Identifying Radio Controls

15

Keypad Characters – Lowercase Mode

Number of Times Key is Pressed

Key123456789101112131415161718192021

1

1. ,?! ;@_-*#&$/+=\“ ‘ ( )

2

abc

3

de f

4

gh i

5

jkl

6

mn o

7

pqr s

8

tuv

9

wxyz

0

Toggle between mixed case mode, uppercase mode, and lowercase mode.

*

Space

#

Toggle between numeric and letter mode.



Identifying Radio Controls

16

Keypad Characters – Numeric Mode

Number of Times Key is Pressed

Key123456789101112131415161718192021

1

1. ,?! ;@_-*#&$/+=\“ ‘ ( )

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

0

0

*

Space

#

Toggle between numeric and letter mode.



Identifying Radio Controls

17

Keypad Characters – Hexadecimal Mode

Number of Times Key is Pressed

Key123456789101112131415161718192021

1

1

2

2ABC

3

3DEF

4

4

5

5

6

6

7

7

8

8

9

9

0

0

*

Not applicable

#

Not applicable



Identifying Status Indicators

18

Push-To-Talk (PTT) Button

The PTT button on the side of the
microphone serves two basic
purposes:

• While a call is in progress, the

PTT button allows the radio to
transmit to other radios in the
call.

Press and hold down PTT
button to talk. Release the PTT
button to listen.

The microphone is activated
when the PTT button is pressed.

• While a call is not in progress, the PTT button is used to make

a new call. See Making a Radio Call on page 35 for more
information.

Identifying Status Indicators

Your radio indicates its operational status through the following:

Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 19

Text Messaging Service (TMS) Icons . . . . . . . . . . . . . page 21

Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21

TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . page 22

LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 24

Intelligent Lighting Indicators . . . . . . . . . . . . . . . . . . . . page 25

Alert Tones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 26

PTT

Button

Identifying Status Indicators

19

Status Icons

The liquid crystal display (LCD) of your radio shows the radio
status, text entries, and menu entries.

The following are the icons that appear on the radio’s display.

Receiving

Radio is receiving a call or data.

Transmitting

Radio is transmitting a call or data.

Call Received

Radio has received an Individual Call.

Received Signal Strength Indicator (RSSI)

The number of bars displayed represents the
received signal strength for the current site, for
trunking only. The more stripes in the icon, the
stronger the signal.

Direct

• On = Radio is currently configured for direct

radio-to-radio communication (during
conventional operation only).

• Off = Radio is connected with other radios

through a repeater.

u

t

F

V

N

Monitor (Carrier Squelch)

Selected channel is being monitored (during
conventional operation only).

In-Call User Alert

• On = The feature is enabled. Voice muting of

the affiliated trunking talkgroup or selected
channel is activated.

• Off = The feature is disabled. Voice muting of

the affiliated trunking talkgroup or selected
channel is deactivated.

Power Level

• L = Radio is set at Low power.

• H = Radio is set at High power.

Scan

Radio is scanning a scan list.

Priority Channel Scan

• Blinking dot = Radio detects activity on

channel designated as
Priority-One.

• Steady dot = Radio detects activity on channel

designated as Priority-Two.

M

K

H or .

i

j

Identifying Status Indicators

20

Vote Scan Enabled

The vote scan feature is enabled.

Secure Operation

• On = Secure operation.

• Off = Clear operation.

• Blinking = Receiving an encrypted voice call.

AES Secure Operation

• On = AES Secure operation.

• Off = Clear operation.

• Blinking = Receiving an encrypted voice call.

Location Signal

• On = Location feature is enabled, and location

signal is available.

• Off = Location feature is disabled.

• Blinking = Location feature is enabled, but no

location signal is available.

k

m

l

G

User Login Indicator (IP Packet Data)

• Inverted = User is currently associated with the

radio.

• On = Packet data context activated.

• Off = Packet data context deactivated.

• Blinking = Device registration or user

registration with the server failed due to an
invalid username or pin.

Data Activity

Data activity is present.

Hexadecimal

Indicates that the text entry is currently in
hexadecimal mode.

MFK is in Mode Change feature

Turn the MFK to change channel.

MFK is in Volume Change feature

Turn the MFK to adjust the volume.

n

o

{

Identifying Status Indicators

21

Text Messaging Service (TMS) Icons

This feature allows you to send and receive text messages. See
Text Messaging Service (TMS) on page 66 for more
information.

Status Icons

The following icons appear on the radio’s display for TMS
features:

Inbox Full

The Inbox is full.

Message Sent

The text message is sent successfully.

Message Unsent

The text message cannot be sent.

Unread Message

• User receives a new message.

• The selected text message in the Inbox has

not been read.



,

[

Z

r

Read Message

The selected text message in the Inbox has been
read.

3/6

Message Index

Indicates the index of the current message the
user is viewing.

Example: If the user is looking at the third
message out of a total of 6 messages in the
Inbox folder, the icon is displayed as the icon on
the left column.

Priority Status

• The “Priority” feature is toggled on before the

message is sent.

• Messages in the Inbox folder are flagged with

“Priority”.

Request Reply

• The “Request Reply” feature is toggled on

before the message is sent.

• Messages in the Inbox folder are flagged with

“Request Reply”.

]

I

P

;

p

Identifying Status Indicators

22

TMS Menu Options

Priority Status and Request Reply

• User is composing a message with a priority

status and a request for a reply.

• Messages in the Inbox folder are flagged with

”Priority” and “Request Reply”.

Numeric

Indicates that the text entry is currently in
numeric mode.

Mixed Case

Indicates that the text entry is currently in normal
text mode.

Uppercase

Indicates that the text entry is currently in
uppercase mode.

Lowercase

Indicates that the text entry is currently in
lowercase mode.

Lowercase

Indicates that the text entry is currently in
lowercase and with predicted words shown at the
bottom of the screen.

q

2

1

3

}

Mixedcase Predictive

Indicates that the text entry is currently in mixed
case and with predicted words shown at the
bottom of the screen.

Uppercase Predictive

Indicates that the text entry is currently in
uppercase and with predicted words shown at
the bottom of the screen.

Menu Option Description/Function

Back

Brings you back to the previous menu
screen.

Edit

Edits a draft message or key in a target
address.

Save

Saves the messages you have edited to the
Draft folder.

Rply Replies to a message.

Del

Deletes a message or a character text during
editing mode.

New Creates a new message.

Impt

Toggles the “Priority Status” icon on or off for
an outgoing message.



Identifying Status Indicators

23

Call Type Icons

The following icons appear on the radio’s main display, when
you make or receive a call, or view selected call lists, to indicate

the different call types associated with an alias or ID.

Rqrp

Toggles “Request Reply” icon on or off for an
outgoing message.

Yes

Deletes all the messages in the current
folder.

No Cancel the delete all messages options.

Exit Exits to the Home screen.

Optn Brings you to the Options main screen.

Sel Selects a predefined message or address.

Send Sends the message.

Radio number.

Radio number added to a Call List.

Menu Option Description/Function

U

Mobile number.

Mobile number added to a Call List.

Landline phone number.

Landline phone number added to a Call List.

Incoming call or data.

Outgoing call or data.

?

%

Identifying Status Indicators

24

LED Indicator

LED indicator shows the operational status of your radio.

Solid red – Radio is transmitting.

Blinking red – Radio is transmitting at low power condition.

Double blinking red – Radio is in Emergency Mode.

Rapidly blinking red – Radio has failed the self test upon

powering up or encountered a fatal error.

Solid yellow – Channel is busy.

Blinking yellow – Radio is receiving a secured transmission.

Solid green – Radio is powering up, or is on a non-priority

channel while in the Scan List Programming mode.

Blinking green – Radio is receiving an individual or telephone
call, or is on a Priority-Two channel while in the Scan List
Programming mode.

Rapidly blinking green – Radio is on a Priority-One channel
while in the Scan List Programming mode.

Multi-function Knob - Concentric Ring LED

The concentric ring LED blinks green when the MFK is using
the secondary feature. See Multi-function Knob on page 12 to
understand the functionality of MFK.

If Intelligent Lighting is activated, the concentric ring LED will
not blink green when the MFK is in the secondary mode. The
LED turns into solid color of orange, red or green depending on
the status of Intelligent Lighting. See Intelligent Lighting
Indicators on page 25 for different status of Intelligent Lighting.

Red LED

Yellow LED

Green LED

Concentric
Ring LED

Identifying Status Indicators

25

Intelligent Lighting Indicators

This feature temporarily changes the radio’s display backlight color and the alert text background color to help signal that a radio event
has occurred.

Note: This feature must be preprogrammed by a qualified radio technician.

Backlight Event When

Orange Emergency Alerts

The radio initiates an emergency alarm or call.

The radio receives an emergency alarm or call.

Red Critical Alerts

The radio is out of range.

The radio enters failsoft mode.

The radio is unable to establish a full connection with the system.

The radio is unable to authenticate or register with the system.

Green Call Alerts

The radio receives a private call.

The radio receives a phone call.

The radio receives a call alert.

The radio receives a selective call.

Identifying Status Indicators

26

Alert Tones

An alert tone is a sound or group of sounds. Your radio uses alert tones to inform you of your radio’s conditions. The following table
lists these tones and when they occur.

You Hear Tone N a m e Heard

Short,

Low-Pitched

Tone

Radio Self Test Fail When radio fails its power-up self test.

Reject When an unauthorized request is made.

Time-Out Timer Warning Four seconds before time out.

No ACK Received When radio fails to receive an acknowledgment.

Individual Call
Warning Tone

When radio is in an individual call for greater than 6 seconds without any activity.

Long,

Low-Pitched

Tone

Time-Out Timer

Timed Out

When the Time-Out Timer has expired.

Talk Prohibit/PTT Inhibit (When PTT button is pressed) transmissions are not allowed.

Out of Range (When PTT button is pressed) the radio is out of range of the system.

Invalid Mode When radio is on an unpreprogrammed channel.

A Group of

Low-Pitched

Ton es

Busy When system is busy.

Identifying Status Indicators

27

Short,

Medium-Pitched

Tone

Valid Key-Press When correct key is pressed.

Radio Self Test Pass When radio passes its power-up self test.

Clear Voice At beginning of a non-coded communication.

Priority Channel

Received

When activity on a priority channel is received.

Emergency Alarm Entry When entering the emergency state.

Central Echo When central controller has received a request from a radio.

Long,

Medium-Pitched

Tone

Volume Set When volume is changed on a quiet channel.

Emergency Exit When exiting the emergency state.

A Group of

Medium-Pitched

Ton es

Failsoft When the trunking system fails.

Automatic Call Back When voice channel is available from previous request.

Talk Permit (When PTT button is pressed) verifying system accepting transmissions.

Keyfail When encryption key has been lost.

Console Acknowledge When status, emergency alarm, or reprogram request ACK is received.

Received Individual Call When Call Alert or Private Call is received.

Call Alert Sent When Call Alert is received by the target radio.

Site Trunking When a SmartZone trunking system fails.

You Hear Tone N a m e Heard

Identifying Status Indicators

28

Ringing

Fast Ringing When system is searching for target of Private Call.

Enhanced Call Sent When waiting for target of Private Call to answer the call.

Phone Call Received When a land-to-mobile phone call is received.

Gurgle Dynamic Regrouping (When the PTT button is pressed) a dynamic ID has been received.

Unique,

Low-Pitched

Chirp

New Message When a new message is received.

Unique,

High-Pitched

Chirp

Priority Status When a priority message is received.

You Hear Tone N a m e Heard

Identifying Status Indicators

29

You Hear Ton e N ame When

Two high-pitched tones Private Conversation When a Private Call is received.

Four high-pitched tones

every five seconds

Call Alert When a Call Alert page is received.

Single, high-pitched

tone

Central Acknowledge When a Call Alert, emergency alarm, reprogram request, or status/message

transmission is received by the system’s central controller.

Four high-pitched tones Mobile Unit Acknowledge When a Call Alert page is received by the intended unit, or the emergency

alarm, reprogram request, or status/message transmission is acknowledged by
the intended dispatcher.

Sound similar to a

telephone busy signal

System Busy When the PTT button is pressed, indicates transmission fail because all system

radio channels are in use. Release the PTT button and wait for call back.

A series of two short,

high-pitched tones

Automatic Call Back When a channel is now available for your previously requested transmission.

Talk Permit (Optional) When the PTT button is pressed, indicates the system is accepting your

transmission.

A series of low-pitched

tones followed by a

series of high-pitched

tones

Scan Alert On When Scan feature is activated through the preprogrammed button.

A series of high-pitched

tones followed by a

series of low-pitched

tones

Scan Alert Off When Scan feature is deactivated through the preprogrammed button.

Identifying Status Indicators

30

Continuous, low-pitched

tone

Talk-Prohibit (When the PTT button is pressed) the system is out of service.

Smart PTT Inhibit (When the PTT button is pressed) the channel is busy with the Smart PTT

feature enabled.

Out-of-Range (When the PTT button is pressed) indicates the radio is not in the range of the

trunked radio system.

Illegal Mode When you have entered a mode where normal system traffic will be missed,

or you are attempting something which is not permitted.
Examples include: forgetting to exit the telephone interconnect mode after a

call ends (fleet and subfleet calls cannot be received), attempting to transmit on
a receive-only conventional mode, attempting to select a dynamic mode where
no dynamic ID assignment has been made.

Auto Power Off Powers off the radio when no user actions occur during a preprogrammed

length of time.

Single, high-pitched

tone every nine seconds

Failsoft When a trunked system central controller failure in an unmuted receive

condition. The radio reverts from trunked operation to a system similar to
conventional radio repeater operation. Other system users can be heard
sharing the channel.

Brief low-pitched tone Time-Out Timer Warning

or

Menu Inactive Exit

When your present transmission will soon be disabled.

Single, short,

high-pitched tone

Valid Key When you pressed a valid key, or you entered a feature configuration state, or

you are receiving or transmitting in the clear mode on secure models (with TX
Clear Alert Tones enabled).

Single, low-pitched tone Invalid Key When you tried to make an invalid key press, or that an emergency alarm,

reprogram request, or status/message was not acknowledged.

You Hear Ton e N ame When

General Radio Operation

31

General Radio Operation

Once you understand how your APX Mobile Radio is
configured, you are ready to use your radio.

Use this navigation guide to familiarize yourself with the basic
Call features:

Selecting a Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 31

Selecting a Radio Channel . . . . . . . . . . . . . . . . . . . . . page 32

Receiving and Responding to a Radio Call . . . . . . . . . page 32

Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . . . page 35

Repeater or Direct Operation . . . . . . . . . . . . . . . . . . . page 37

Monitoring Features. . . . . . . . . . . . . . . . . . . . . . . . . . . page 38

Selecting a Zone

A zone is a group of channels.

Note: Your radio must be preprogrammed to allow you to use

these features.

Procedure:

If zone is set as the primary mode,

1 Turn the MFK until the display shows the desired zone and

press the PTT button to begin transmitting on the displayed
zone.

If zone is not set as the primary mode, press the MFK once and

repeat step 1.

OR

2 > or < (on the keypad mic.) to Zone.

3 Press the Menu Select button directly below Zone. The

display shows the current zone.

4 Rotate the MFK or press U or D to the desired zone is

displayed.

5 Press the Menu Select button directly below Sel or the



button (on the keypad mic.) to confirm the selected zone

number.

General Radio Operation

32

6 Press the PTT button to begin transmitting on the displayed

zone.

Selecting a Radio Channel

A channel is a group of radio characteristics, such as transmit/
receive frequency pairs.

Use the following procedure to select a channel.

Procedure:

If channel is set as the primary mode,

1 Turn the MFK until the display shows the desired channel

and press PTT to begin transmitting on the displayed.

If channel is not set as the primary mode, press the MFK once
and repeat step 1.

OR

2 > or < (on the keypad mic.) to scroll to Chan.

3 Press the Menu Select button directly below Chan. The

display shows the current channel.

4 Rotate the MFK or press U or D to the desired channel.

5 Press the Menu Select button directly below Sel or the 

button (on the keypad mic.) to confirm the channel.

6 Press the PTT button to transmit on the displayed channel.

Receiving and Responding to a Radio Call

Once you have selected the required channel and/or zone, you
can proceed to receive and respond to calls.

You will see solid red LED while the radio is transmitting. You
will see solid yellow LED when the radio is receiving a
transmission in conventional mode and there is no LED
indication when the radio receives a transmission in trunking
mode.

If the radio is receiveing a secure transmission, the yellow LED
blinks.

Red LED

Yellow LED

Green LED

General Radio Operation

33

Receiving and Responding to a Talkgroup Call

To receive a call from a group of users, your radio must be
configured as part of that talkgroup.

Procedure:

When you receive a talkgroup call (while on the Home screen),
depending on how your radio is preprogrammed:

1 ASTRO Conventional Only:

The LED lights up solid yellow. The display shows the
talkgroup alias or ID, and the caller alias or ID.

OR
Trunking Only:

The display shows the caller alias or ID.

2 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

3 Press the PTT button to respond to the call. The LED lights

up solid red.

4 Release the PTT button to listen.

See Making a Talkgroup Call on page 35 for details on making
a Talkgroup Call.

Receiving and Responding to a Private Call

(Trunking Only)

A Private Call is a call from an individual radio to another

individual radio.

These one-to-one calls between two radios are not heard by

others in the current talkgroup. The calling radio automatically

verifies that the receiving radio is active on the system and can

display the caller ID.

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Procedure:

When you receive a Private Call:

1 You hear two alert tones and the LED blinks green. The

display shows Call received and the caller alias or ID.

2 Press the Menu Select button directly below Resp within 20

seconds after the call indicators begin.

3 During the call, the display shows the caller alias (name), if it

is in the call list.

OR

During the call, the display shows the caller ID (number), if
the caller’s name is not in the call list.





General Radio Operation

34

4 Press and hold the PTT button to talk. Release the PTT

button to listen.

5 Press H to hang up and return to the Home screen.

Note: If you press PTT button before pressing the Menu

Select button directly below Resp, your conversation

will be heard by all members of the talk group.

If 20 seconds pass before you press the Menu Select
button directly below the Resp, you will not respond
privately to the call just received. Instead, you initiate a
Private Call.

See Making a Private Call (Trunking Only) on page 36 for
details on making a Private Call.

Receiving and Responding to a Telephone Call

This feature allows you to receive calls similar to standard
phone calls from a landline phone.

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Procedure:

1 You hear a telephone-type ringing and the LED blinks green.

The backlight of the screen turns green. The display shows
Phone call and the call received icon blinks.

2 Press the Menu Select button directly below Resp.

3 Press and hold the PTT button to talk. Release the PTT

button to listen.

4 Press H or the Menu Select button directly below Exit to

hang up and return to the Home screen.

See Making a Telephone Call on page 37 for details.



General Radio Operation

35

Making a Radio Call

You can select a zone, channel, subscriber ID, or talkgroup by
using:

• The preprogrammed Zone switchmenu

• The Multi-function Knob

• A preprogrammed One Touch button

• The Contacts list (see Contacts on page 45).

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Making a Talkgroup Call

To make a call to a group of users, your radio must be

configured as part of that talkgroup.

Procedure:

1 > or < (on the keypad mic.) to Tgrp and press the Menu

Select button directly below Tgrp.

The display shows the last-selected talkgroup.

2 Press the Menu Select button directly below Sel.

OR

Rotate the MFK or U or D to select the channel with the
desired talkgroup the press the Menu Select button directly

below Sel.

3 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

4 Press the PTT button to make the call.

5 ASTRO Conventional Only:

The LED lights up solid red. The display shows the
talkgroup alias or ID.

OR
Trunking Only:

The LED lights up solid red.

6 Speak clearly into the microphone.

7 Release the PTT button to listen.



General Radio Operation

36

Making a Private Call (Trunking Only)

This feature allows you to send an individual Call Alert or page if
there is no answer from the target radio. Your radio must be
preprogrammed to allow you to use this feature.

Procedure:
Press the preprogrammed Quick Access (One-Touch)
Enhanced Private Call button to dial the preprogrammed ID

and proceed to Step 5.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Call.

2 Press the Menu Select button directly below Call. The

display shows the last transmitted or received.

3 Press the Menu Select button directly below Cnts to scroll

through and select the required ID.

OR

D or U to the required ID.

OR

Use the keypad to enter the required ID.

4 Press the PTT button to start the Private Call.

5 A telephone-type ringing sounds if the receiving unit is in

service. The display shows Calling...<Number> or
Calling...<Alias>.

6 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

7 When you are connected, the display shows the ID of the

target radio. Press and hold the PTT button to talk. Release
the PTT button to listen.

OR

If no acknowledgment is received, the display shows No
acknowledge.

OR

If the target radio does not respond before the time out, the
display shows No answer.

8 Press H to return to the Home screen.

See Sending a Call Alert Page on page 55 for more
information.



General Radio Operation

37

Making a Telephone Call

This feature allows you to make calls similar to standard phone
calls to a mobile or landline phone.

Procedure:
Press the preprogrammed Quick Access (One-Touch) Phone
Call button to dial the preprogrammed phone number and

proceed to Step 5.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Phon.

2 Press the Menu Select button directly below Phon. The

display shows the last transmitted phone number.

3 Press the Menu Select button directly below Cnts to scroll

through and select the required ID.

OR

D or U to the required phone number.

OR

Use the keypad to enter the required phone number.

4 Press and release the PTT button to dial the phone number.

5 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

6 When your call is answered, press the PTT button to talk.

7 Release the PTT button to listen.

8 Press H to return to the Home screen.

See Alert Tones on page 26 for more information if your call is

NOT answered.

Repeater or Direct Operation

The REPEATER operation increases the radio’s range by

connecting with other radios through a repeater. The transmit

and receive frequencies are different.

The DIRECT or “talkaround operation” allows you to bypass the

repeater and connect directly to another radio. The transmit and

receive frequencies are the same.

Procedure:

Press the preprogrammed Repeater/Direct switch to toggle

between talkaround and repeater modes.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Dir.

2 Press the Menu Select button directly below Dir.

3 The display shows Repeater mode if the radio is currently

in Repeater mode.

OR

The display shows Direct mode and the Talkaround icon if



General Radio Operation

38

the radio is currently in Direct mode (during conventional
operation only).

You can repeat step 2 to toggle between the two modes. Once
in Direct Mode, press PTT button to start conversation with the
radios nearby.

Monitoring Features

Radio users who switch from analog to digital radios often
assume that the lack of static on a digital channel is an
indication that the radio is not working properly. This is not the
case.

Digital technology quiets the transmission by removing the
“noise” from the signal and allowing only the clear voice or data
information to be heard.

Monitor a channel to ensure the channel is clear before
transmitting.

Monitoring a Channel

Procedure:

Lift the microphone off hook.

Conventional Modes Only:

1 Listen for activity on that channel.

2 Adjust the volume by rotating the MFK if necessary.

3 If you hear no activity, press and hold the PTT button to start

your conversation.

OR

Trunked Modes Only:

1 Press the PTT button.

2 If you hear two, short, high-pitched tones, or if you hear no

tone and the t indicator lights steadily, then proceed with
your message.

3 Release the PTT button to receive (listen).

If you are not in the range of the system, you may hear a
continuous low-pitched tone and the display shows

Out of

range

.



General Radio Operation

39

Conventional Mode Operation

This feature allows you to monitor channel traffic on
conventional channels by defeating the coded squelch. This
way, you can listen to another user active on the channel. Thus,
you may be prevented from talking over someone else’s
conversation.

Note: This feature must first be enabled by a qualified radio

technician or system administrator.

Procedure:

Take the control head off hook. (This is the same as monitor on.
You hear all channel traffic.)

OR

1 At Home mode where the default zone and channel are

being displayed, > or < button (on the keypad mic.) to Mon.

2 Press the Menu Select button directly below Mon

momentarily to activate monitoring. The display shows
Monitor on.

3 Press the Menu Select button to deactivate the monitoring.

The display shows Monitor off.



Advanced Features

40

Advanced Features

Use this navigation guide to learn more about advanced
features available with your radio:

Advanced Call Features . . . . . . . . . . . . . . . . . . . . . . . page 40

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 45

Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 51

Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 53

Call Alert Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 57

Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . . . page 59

Automatic Registration Service (ARS) . . . . . . . . . . . . page 63

Text Messaging Service (TMS). . . . . . . . . . . . . . . . . . page 66

Secure Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . page 76

The Global Positioning System (GPS) . . . . . . . . . . . . page 81

Trunking System Controls. . . . . . . . . . . . . . . . . . . . . . page 89

Ignition Switch Options . . . . . . . . . . . . . . . . . . . . . . . . page 93

Voice Announcement . . . . . . . . . . . . . . . . . . . . . . . . . page 95

Using Site Selectable Alerts (ASTRO 25). . . . . . . . . . page 96

Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 101

Advanced Call Features

Calling a Phone Not in the List

1 > or < (on the keypad mic.) to Phon.

2 Press the Menu Select button directly below Phon.

3 Enter the desired phone number from the optional keypad

microphone. The display updates as the numbers are
entered.

4 Press

 button or the PTT button (on the keypad mic.) to

make the call.

5 Press and hold the PTT button to talk. Release the PTT

button to listen.

6 Press H or Menu Select button directly below Phon to exit.



Advanced Features

41

Receiving and Making a Selective Call

(Conventional Only)

This feature allows you to receive a call from or to call a specific
individual. It is intended to provide privacy and to eliminate the
annoyance of having to listen to conversations that are of no
interest to you.

Receiving a Selective Call

Procedure:

1 When you receive a Selective Call, you hear two alert tones

and the LED lights up solid yellow. The call received icons
blink and the display alternates between Call received and
the home display.

2 The speaker unmutes.

3 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

4 Press and hold the PTT button to talk. Release the PTT

button to listen.

Note: If you press PTT button before pressing the Menu

Select button directly below Call, your conversation will

be heard by all members of the talk group.

If 20 seconds pass before you press the Menu Select button

directly below the

Call

, you will not respond privately to the call

just received. Instead, you initiate a Selective Call. See Making

a Selective Call on page 41.

Making a Selective Call

Procedure:

Press the preprogrammed Quick Access (One-Touch)

Selective Call button to dial the preprogrammed ID and

proceed to Step 4.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Call.

2 Press the Menu Select button directly below Call. The

display shows the last transmitted or received ID.

3 Press the Menu Select button directly below Cnts to scroll

through and select the required ID.

OR

D or U to the required ID.

OR

Use the keypad to enter the required ID.

4 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

5 Press and hold the PTT button to start the Selective Call.

The display shows the ID of the target radio.



Advanced Features

42

6 Release the PTT button to listen.

7 Press H to return to the Home screen.

If you do not press H button to hang up, your radio will remain
in Selective Call state with the other unit. You will miss all
subfleet traffic and incoming phone calls.

Using the Talkgroup Call Feature (Conventional

Operation Only)

This feature allows you to define a group of conventional
system users so that they can share the use of a conventional
channel.

Note: Encryption keys are associated to talkgroups. When

talkgroups are enabled, encryption keys are changed
by changing the active talkgroup. See Secure

Operations on page 76 for more information.

Selecting a Talkgroup

Procedure:

1 > or < (on the keypad mic.) to Tgrp.

2 Press the Menu Select button directly below Tgrp. The

display shows the last talkgroup that was selected and
stored.

3

U or D to Pset for the preset preprogrammed talkgroup.

OR

D or U to the required talkgroup.

OR

Use the keypad to enter the number of the corresponding
talkgroup in the list.

4 Press the Menu Select button directly below Sel to save the

currently selected talkgroup and return to the Home screen.

5 If the encryption key associated to the new talkgroup is

erased, a momentary key fail tone sounds and the display
shows Key fail.

OR

If the encryption key that is associated to the new talkgroup
is not allowed, a momentary key fail tone sounds and the
display shows Illegal key.

6 Press H or the PTT button to exit.





Advanced Features

43

Sending a Status Call

This feature allows you to send data calls to the dispatcher
about a predefined status.

Each status can have up to a 14-character name. A maximum
of eight status conditions is possible.

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Procedure:
Press the preprogrammed Status button and proceed to Step 3.
OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Sts.

2 Press the Menu Select button directly below Sts.

3 The display shows the last acknowledged status call, or the

first status in the list.

4

D or U to the required status.

OR

Use the keypad to enter a number corresponding to the
location in the status list.

5 Press the PTT button to send the status. The display shows

Please wait.

6 When the dispatcher acknowledges, four tones sound and

the display shows Ack received. The radio returns to
normal dispatch operation.

OR

If no acknowledgment is received, a low-pitched tone
sounds and the display shows No acknowledge.

7 Press H to return to the Home screen.

No traffic is heard on trunked channels while Status Calls is

selected. If the radio detects no Status Call activity for six

seconds, an alert tone sounds until you press

H or the PTT

button.



Advanced Features

44

Using the Dynamic Regrouping Feature

(Trunking Only)

This feature allows the dispatcher to temporarily reassign
selected radios to a single special channel so they can
communicate with each other. This feature is typically used
during special operations and is enabled by a qualified radio
technician.

You will not notice whether your radio has this feature enabled
until a dynamic regrouping command is sent by the dispatcher.

Note: If you try to access a zone or channel that has been

reserved by the dispatcher as a dynamically regrouped
mode for other users, an invalid tone sounds.

Procedure:

1 When your radio is dynamically regrouped, it automatically

switches to the dynamically regrouped channel. A “gurgle”
tone sounds and the display shows the dynamically
regrouped channel’s name.

2 Press the PTT button to talk. Release PTT button to listen.

When the dispatcher cancels dynamic regrouping, the radio
automatically returns to the zone and channel that you were
using before the radio was dynamically regrouped.

Requesting a Reprogram

This feature lets you notify the dispatcher that you want a new
dynamic regrouping assignment.

Procedure:

Press the preprogrammed Reprogram Request button to send
reprogram request to the dispatcher and proceed to Step 3.
OR
Follow the procedure below.

1 > or < (on the keypad mic.) to Rpgm.

2 Press the Menu Select button directly below Rpgm to send

reprogram request to the dispatcher.

3 The display shows Reprogram rqst and Please wait.

4 If you hear five beeps, the dispatcher has acknowledged the

reprogram request. The display shows Ack received and
the radio returns to the Home screen.

OR

If the dispatcher does not acknowledge the reprogram
request within six seconds, a low-pitched alert tone sounds
and the display shows No acknowledge.

Try again or press H to cancel and return to the Home
screen.





Advanced Features

45

Classifying Regrouped Radios

The dispatcher can classify regrouped radios into either of two
categories: Select Enabled or Select Disabled.

• Select-enabled radios are free to change to any available
channel, including the dynamic-regrouping channel, once the
user has selected the dynamic-regrouping position.

• Select-disabled radios cannot change channels while
dynamically regrouped. The dispatcher has forced the radio
to remain on the dynamic-regrouping channel.

The Scan or Private Call feature cannot be selected while your
radio is Select Disabled.

Contacts

This feature provides “address-book” capabilities on your radio.
Each entry corresponds to an alias (name) or ID (number) that
you use to initiate a call.

Contact entries are alphabetically sorted according to entry
alias. Each alias can have up to 5 IDs of different call types
associated with it.

Additionally, each entry, depending on context (conventional,
trunking, or phone), associates with one or more of the four
types of calls: Phone Call, Selective Call, Private Call, or Call
Alert.

Each entry within Contacts displays the following information:

• Call Alias (Name)

• Call ID (Number)

• Call Type (Icon)

• WACN ID (Astro 25 Trunking IDs only)

• System ID

Note: Your radio must be preprogrammed to allow you to

add, edit, or delete the contact entries.

Your radio also supports a maximum of 50 call lists. Each list
can store up to 100 IDs (numbers).



Advanced Features

46

Note: Your radio is preprogrammed with a number of contacts

per Call Lists. Check with your dealer or system
administrator for more information.

If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Making a Private Call from Contacts

Note: Your radio must be preprogrammed to allow you to use

this feature.

Procedure:

Use the Options Menu.

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts to the

call list. The display shows Contact Alias.

3 D or U to the required subscriber alias.

4 Press the Menu Select button directly below Optn.

5

D or U (on the keypad mic.) to Call and press the Menu

Select button directly below Sel.

6 D or U to select the call type.

7 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.

8 Press the PTT button to initiate the call. During the call, the

display shows the subscriber alias.

9 Press and hold the PTT button to talk. The LED lights up

solid red.

OR

Release the PTT button to listen. The LED lights up solid
green.

10 If there is no voice activity for a programmed period of time,

the call ends.

OR

The call ends when it reaches the maximum ring time.

OR

Use the PTT button:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts.

3 D or U to the required subscriber alias.

4 Press the Menu Select button directly below Cnts. The

display shows Contact Alias.

5 Hold the microphone vertically 1 to 2 inches (2.5 to 5.0 cm)

from your mouth.



Advanced Features

47

6 Press the PTT button to initiate the call. During the call, the

display shows the subscriber alias.

7 Press and hold the PTT button to talk. The LED lights up

solid red.

OR

Release the PTT button to listen. The LED lights up solid
yellow.

8 If there is no voice activity for a preprogrammed period of

time, the call ends.
OR
The call ends when it reaches the maximum ring time.

Adding a New Contact Entry

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to {New Contact} and press the Menu Select

button directly below Sel.

4 The display shows Name. Press the Menu Select button

directly below Edit.
Use the keypad to enter the name.

Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

5 Press the Menu Select button directly below OK once you

have entered the name.

OR

Press the Menu Select button directly below Cncl to return
to the previous screen.

6

D or U to {Add Number} and press the Menu Select

button directly below Sel. The display shows Type 1
<Default Type>.

7 Press Menu Select button directly below Edit.

8

D or U to the required channel and press the Menu Select

button directly below OK.



Advanced Features

48

9 D or U to Number 1 and press the Menu Select button

directly below Edit.
The display shows Number 1 and a cursor appears.
Use the keypad to enter the number.

Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button directly below Del to delete
any unwanted characters.

10 Press the Menu Select button directly below OK once you

have entered the number.

OR

Press the Menu Select button directly below Cncl to return
to the previous screen.

11 Press the Menu Select button directly below Done once

you have finished.

12 The display shows <Entry> stored, confirming that the

contact entry has been added.

13 The radio returns to the main Contacts screen.

Deleting a Contact Entry

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to the entry you want to delete and press the Menu

Select button directly below Optn.

4

D or U to Delete and press the Menu Select button

directly below Sel. The display shows <Entry> confirm
del?.

5Select Yes to delete the entry.

The display shows <Entry> deleted and the radio returns
to the main screen for Contacts.

OR

Select No to return to the main screen for Contacts.



Advanced Features

49

Adding a Contact to a Call List or Phone List

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to the entry you want to add to the call list and press

the Menu Select button directly below Optn.

4

D or U to Add to CallLst or Add to PhonLst and press

the Menu Select button directly below Sel.

5

D or U until the display shows {Available} and press the

Menu Select button directly below Add to add as a new
entry.

OR

D or U until the display shows <ENTRY> and its

associated number and press the Menu Select button
directly below RPLC to replace the existing entry.

6 The display shows <ENTRY> added, confirming the

addition of the contact to the list.

7 The radio returns to the main display for Contacts.

Editing a Contact in a Call List or a Phone List

Editing an Entry Alias

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to the entry you want to edit and press the Menu

Select button directly below Optn.

4

D or U to Edit and press the Menu Select button directly

below Sel.

5

D or U to the entry alias you wish to change and press the

Menu Select button directly below Edit.

6 A cursor appears.

Use the keypad to edit the name.
Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.



Advanced Features

50

7 Press the Menu Select button directly below OK once you

have finished. The display returns to the Edit Contact
screen.

8 Press the Menu Select button directly below Done to save

your changes and return to the main screen for Contacts.

Editing as Entry ID

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to the entry you want to edit and press the Menu

Select button directly below Optn.

4

D or U to Edit and press the Menu Select button directly

below Sel.

5

D or U to the entry ID you wish to change and press the

Menu Select button directly below Edit.

6 A cursor appears.

Use the keypad to edit the number.
Press < to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

7 Press the Menu Select button directly below OK once you

have finished. The display returns to the Edit Contact
screen.

8 Press the Menu Select button directly below Done to save

your changes and return to the main screen for Contacts.



Advanced Features

51

Editing a Call Type

Procedure:

1 > or < (on the keypad mic.) to Cnts.

2 Press the Menu Select button directly below Cnts. The

entries are alphabetically sorted.

3

D or U to the entry you want to edit and press the Menu

Select button directly below Optn.

4

D or U to Edit and press the Menu Select button directly

below Sel.

5

D or U to TYPE and press the Menu Select button directly

below Edit.

6

D or U to choose from the list of call types given and press

the Menu Select button directly below OK to select.

7 The display returns to the Edit Contact screen.

8 Press the Menu Select button directly below Done to save

your changes and return to the main screen for Contacts.

Scan Lists

Scan lists are created and assigned to individual channels/
groups. Your radio scans for voice activity by cycling through the
channel/group sequence specified in the scan list for the current
channel/group.

Your radio supports different types of Scan Lists:

• Trunking Priority Monitor Scan List

• Conventional Scan List

• Talkgroup Scan List

A maximum of 200 Scan Lists can be programmed in your
radio. These lists must be preprogrammed by a qualified radio
technician.

Viewing a Scan List

Procedure:

1 > or < (on the keypad mic.) to ScnL.

2 Press the Menu Select button directly below ScnL.

3 D or U to view the members on the list.

4 Press the

H to exit the current display and return to the

Home screen.





Advanced Features

52

Editing the Scan List

This feature lets you change scan list members and priorities.

Procedure:

1 > or < (on the keypad mic.) to ScnL.

2 Press the Menu Select button directly below ScnL. The

display shows the lists that can be changed.

3 D or U to the entry you want to edit.

4 Press the Menu Select button directly below Sel to add and/

or change the priority of the currently displayed channel in
the scan list.

OR

Press the Menu Select button directly below Del to delete
the currently displayed channel from the scan list.

OR

Press the Menu Select button directly below Rcl to view the
next member of the scan list.

5

D or U to select more channels to be added or deleted.

OR

Use the keypad to go directly to additional channels to be
added or deleted.

OR

Use the MFK to select additional channels to be added or
deleted.

6 Press

H to exit scan list programming and return to the

Home screen.

See Viewing and Changing the Priority Status on page 53 for
more information on how to add and/or change the priority of
the currently displayed channel in the scan list.

Changing the Scan List Status

Procedure:

1 Long press the preprogrammed Scan side button.

2 D or U to the member you want to edit.

3 Press the

 button or press the Menu Select button

directly below Sel once to add the currently displayed
channel to the scan list.

OR

Press the

 button or press the Menu Select button

directly below Sel, one or more times to change the scan list
status icon of the currently displayed channel.

4

D or U to select more list members whose scan status you

want to change.

OR

Use the keypad to go directly to that scan list member.

OR
Use the MFK to select another scan list member.





Advanced Features

53

5 Press H to exit scan list programming and return to the

Home screen.

Viewing and Changing the Priority Status

Procedure:

1 Below the Sel, Del, and Rcl screen, press the Menu Select

button directly below Sel to view and/or change the priority
status of the currently displayed channel.
OR

Below the Sel, Del, and Rcl screen, press the

 button or

press the Menu Select button directly below Sel, one or
more times to view and/or change the scan list status icon of
the currently displayed channel.

2 A Scan icon indicates that the current channel is in the scan

list as a non-priority channel. The LED lights up solid green.

OR

A Priority-Two Channel Scan icon indicates that the current
channel is in the scan list as the Priority-Two channel. The
LED blinks green.

OR

A Priority-One Channel Scan icon indicates that the current
channel is in the scan list as the Priority-One channel. The
LED rapidly blinks green. You hear all traffic on the Priority­One channel, regardless of traffic on non-priority channels.

OR

No icon indicates that the current channel is deleted from
the scan list.

Scan

This feature allows you to monitor traffic on different channels
by scanning a preprogrammed list of channels.

Turning Scan On or Off

Procedure:
Press the preprogrammed Scan button.
OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Scan.

2 Press the Menu Select button directly below Scan.

3 The display shows Scan off if scan is disabled. Press the

Menu Select button directly below Scan to enable scan.
OR

The display shows Scan on and the scan status icon if scan
is enabled. Press the Menu Select button directly below
Scan to disable scan.

4 The radio returns to the Home screen.





Advanced Features

54

Turning Scan On While Disregarding the Squelch

Code (Conventional Channels Only)

Procedure:

1 > or < (on the keypad mic.) to Mon.

2 Press the Menu Select button directly below Mon.

3 The brief Monitor on display indicates that the radio is

disregarding the squelch code.

While scanning for activity, you can still receive fleetwide,
system-wide, dynamic regrouping, incoming telephone
interconnect and Private Conversation/Call Alert calls.

Respond to these types of calls as you would normally on the
selected channel. However, when scanning different channels
while in talkgroup scan, incoming Private Conversation/Call
Alert calls may be missed.

Transmitting While the Scan is On

Radio Programmed for Talkback Scan

Procedure:

1 Press the PTT button to transmit on the channel indicated

by the display.

The radio does not begin scanning again for a predetermined
hang time after you release the PTT button, allowing the other
party to respond. If the other party responds within the hang
time, scanning does not resume until the full hang time expires
after they have finished speaking, allowing the conversation to
be completed.

To transmit on the selected channel if another channel is active,
first turn scan off by pressing the Menu Select button below

Scan

momentarily.



Advanced Features

55

Radio Programmed for Non-Talkback Scan

Procedure:

1 Press the PTT button at any time to transmit on the selected

channel or fixed channel.

To make a Call Alert page, or Private Conversation call while
scanning, press either the Menu Select button directly below

Page

or

Call

. The call is entered on the selected channel and

scanning is halted until the call is exited by pressing

H

or

pressing the Menu Select button below either

Page

or

Call

.

Deleting a Nuisance Channel

If a channel continually generates unwanted calls or noise
(termed a “nuisance” channel), you can temporarily remove the
unwanted channel from the scan list.

This capability does not apply to priority channels or the
designated transmit channel.

Procedure:

1 When the radio is locked onto the channel to be deleted,

> or < (on the keypad mic.) to Nuis.

2 Press the Menu Select button directly below Nuis.

Restoring a Nuisance Channel

Procedure:

To restore the deleted nuisance channel, do one of the
following:

• Turn scan off, then on.

OR

• Change modes.

OR

• Turn off the radio, and then turn it back on.

Nuisance mode delete can be disabled by the system
administrator.



Advanced Features

56

Changing Priorities Status While Scan is On

While the radio is scanning, the dynamic priority change feature
allows you to temporarily change any channel in a scan list
(except for the Priority-One channel) to the Priority-Two
channel.

This change remains in effect until scan is turned off. Scan then
reverts to the preprogrammed (original) setting.

Procedure:

1 Press the Menu Select button directly below Dynp to

change the priority of a non-priority channel in the scan list
to Priority-Two.

2 Press

H momentarily to exit the scan list and resume

scanning.

Restoring Priorities in a Scan List

Procedure:

To restore the original channel priorities in a scan list, do one of
the following:

• Turn scan off, then on.

OR

• Change channels.

OR

• Turn off the radio, and then turn it back on.

Hang Up Box (HUB)

To temporarily suspend Scan Mode operation, remove the
control head from the Hang Up Box (HUB). You are allowed to
use the control head while scan is suspended. However, Priority
Member scanning is not suspended. This feature applies to all
Scan Lists and Scan Types. Scan is resumed once the control
head is returned to the holding clip and the preprogrammed
hang time has elapsed.

Note: Priority Scan List members are continuously scanned

only when the Scan List, Designated Tx Member field
is set to “Talkback” in the radio programming.
Otherwise, all scan mode operation is suspended.



Advanced Features

57

Call Alert Paging

This feature allows your radio to work like a pager.

Even if other users are away from their radios, or if they are
unable to hear their radios, you can send them an individual
Call Alert page. You can also verify if a radio is active on the
system.

Depending on how your radio is programmed, when you make
an Enhanced Private Call, the radio either automatically sends
a Call Alert page if there is no answer after the maximum ring
time, OR when you press the PTT button.

Note: This feature must be preprogrammed by a qualified

radio technician.

Receiving a Call Alert Page

Procedure:

When you receive a Call Alert page

1 You hear four repeating alert tone and the green LED blinks.

OR

You hear one alert tone and the green LED blinks if Call
Alert Tone Auto Reset is enabled.

2 The call received icons blinks and the display shows Page

received.

3 Press the PTT button to answer.

OR

Press any button to clear the Call Alert page.

See Making a Talkgroup Call on page 35 or Making a Private
Call (Trunking Only) on page 36 for more information.



Advanced Features

58

Sending a Call Alert Page

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Procedure:

Press the preprogrammed Quick Access (One-Touch) Call
Alert Paging button to send a page to the preprogrammed ID

and proceed to Step 5 of the procedure below.
OR
Follow the procedure below.

1 > or < (on the keypad mic.) to Page.

2 Press the Menu Select button directly below Page.

3 D or U to select the required ID.

4 Press the PTT button to send the page.

5 The display shows Paging...<Number> or <Alias>.

6 If the call alert page is sent successfully, four highpitch tone

sounds and the display shows Ack received.

OR

If the call alert page is not acknowledged, a low tone sounds
and the display shows No acknowledge.

7 The radio returns to the Home screen.

OR

Press the Menu Select button directly below OK to return to
the main screen for Contacts.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to Call.

2 Press the Menu Select button directly below Call.

3

D or U to select the required ID, press the PTT button to

initiate the call.

4 If the target radio does not respond after a preprogrammed

period of time, the display shows Send page?.

5 Press the Menu Select button directly below Yes to send

the call alert page.

OR

Press the Menu Select button directly below No to exit the
screen without sending the call alert page.

6 The display shows Paging...<Alias>.

7 If the call alert page is sent successfully, a tone sounds and

the display shows Ack received.

OR

If the call alert page is not acknowledged, a low tone sounds
and the display shows No acknowledge.



Advanced Features

59

8 The radio returns to the Home screen.

OR

Press the Menu Select button directly below OK to return to
the main screen for Contacts.

In-Call User Alert

You can enable and disable voice transmission, if needed.

Procedure:

1 Make sure you are in Home mode where the default zone

and mode are being displayed.

2 > or < (on the keypad mic.) to scroll to the Vmut.

3 Press the Menu Select button directly below Vmut.

4 Press the Menu Select button directly below Vmut or the

VMut preprogrammed button again to turn the feature off
and you will be able to hear to normal dispatch calls.

Pressing the Menu Select button directly below

Vmut

or the
VMut programmed button momentarily toggles between Voice
mute on and Voice mute off.

Voice mute on

shown on the
display indicates that the radio is muted to all conventional
dispatch calls and affiliated trunking group calls.

Emergency Operation

The Emergency feature is used to indicate a critical situation.

If the Orange button is preprogrammed to send an emergency
signal, this signal overrides any other communication over the
selected channel.

Your radio supports 5 Emergency modes:

• Emergency Call

• Emergency Alarm

• Emergency Alarm with Call

• Silent Emergency Alarm

• Special Considerations for Emergencies

Check with your dealer or system administrator for more
information on the programming of this feature.

Only one of the Emergency modes above can be assigned to
the preprogrammed Emergency button or the Emergency
footswitch.

Note: To exit emergency at any time, press and hold the

preprogrammed Emergency button for about a second.



Advanced Features

60

Sending an Emergency Alarm

This feature allows you to send a data transmission, which
identifies the radio sending the emergency, to the dispatcher.

Procedure:

1 Press the preprogrammed Emergency button. A tone

sounds and the display alternates Emergency and the
home display.

2 A dispatcher acknowledgment Ack received display

follows.

AND, Trunking Only:

A high-pitched tone indicates that the alarm has been
received by the trunked system’s central controller.

3 Press and hold the emergency button or the PTT button to

return to normal operation.

Sending an Emergency Call (Trunking Only)

Procedure:

1 Press preprogrammed Emergency button.

2 A tone sounds and the display alternates Emergency and

the home display.

OR

A short low-pitched tone sounds when the selected channel
does not support emergency.

3 Hold the microphone vertically 1 to 2 inches (2.0 to 2.5 cm)

from your mouth.

4 Press and hold the PTT button. Speak clearly into the

microphone.

5 Release the PTT to end the transmission.

6 Press and hold the preprogrammed Emergency button until

a tone sounds to exit Emergency mode.

Sending an Emergency Alarm with Emergency
Call

This feature gives your radio priority access on a channel for
conventional system, and to a talkgroup for trunking system.

If the radio has both emergency call and alarm features
enabled, it automatically proceeds to the call mode after the
alarm is acknowledged.

Procedure:

1 Press the preprogrammed Emergency button to activate

the emergency call/alarm feature.

2 The display alternates Emergency and the home display.



Advanced Features

61

3 A high-pitched tone sounds, indicating that the alarm has

been received by the trunked system’s central controller.
A dispatcher acknowledgment (four high-pitched tones)
follows, accompanied by an Ack received display.

4 Hold the microphone vertically 1 to 2 inches (2.0 to 2.5 cm)

from your mouth.

5 Press and hold the PTT button. Speak clearly into the

microphone.

6 Release the PTT to end the transmission.

7 Press and hold the preprogrammed Emergency button until

a tone sounds to exit Emergency mode.

Turning the radio off also cancels the emergency state.

Sending a Silent Emergency Alarm

This feature allows you to send an Emergency Alarm to the
system without triggering any audio or visual indicators.

This activated microphone state is also known as “hot mic”.

Note: If you press the PTT button during hot mic, and

continue to press it after the hot mic duration expires,
the radio continues to transmit until you release the
PTT button.

Procedure:

1 Press the preprogrammed Emergency button to activate

the silent alarm feature.

2 Press and hold the emergency button until a tone sounds to

exit the silent alarm mode.

If silent emergency alarm is used with emergency call, pressing
the PTT button exits the silent mode and initiates the
emergency call.



Advanced Features

62

Special Considerations for Emergencies

• If you press the emergency button while in a channel that has
no emergency capability, a low-pitched tone sounds.

• If the unit is out of the range of the system and/or the
emergency alarm is not acknowledged, a tone sounds and
the display shows No acknowledge.

• If you press the emergency button, then change to a mode
that has no emergency capability, the display shows
No Emergency and a continuous low-pitched tone sounds
until a valid emergency mode is selected or until the
emergency is cancelled.

• When an emergency is active, changing to another mode
where emergency is enabled (trunked or conventional)
causes an emergency alarm and/or emergency call to be
active on the new mode.



Advanced Features

63

Advanced Features

Automatic Registration Service (ARS)

This feature provides an automated data application registration
for the radio. When you turn on the radio, the device
automatically registers with the server.

Data applications within the fixed network can determine the
presence of a device on the system and send data to the
device. For example: Text Messaging Service (TMS).

The Automatic Registration Service for the radio consists of two
(2) modes:

• ARS Server Mode (default mode)

• ARS Non Server Mode

Note: The default ARS mode can be changed by a qualified

radio technician using the radio’s programming
software.

Selecting or Changing ARS Mode

Procedure:

1 After the zone you want is displayed, toggle until the display

shows the required channel.

OR

Press and hold

> or < (on the keypad mic.) to Chan.

Press the Menu Select button directly below Chan.
The display shows the current zone is not blinking, and the
channel is blinking.

2 D or U or press the MFK once and rotate the MFK to the

desired channel.

3 In ARS Server Mode, the display shows the User Login

Indicator icon, the zone, and ARS server channel.

OR

In ARS Non-Server Mode, the display shows the User Login
Indicator icon, the zone, and ARS non-server channel.

OR

If the channel or mode selected is unprogrammed, the
display shows Unprogrammed. Repeat Step 2.

4 Press H to confirm the displayed zone and channel.



Advanced Features

64

Accessing the User Login Feature

This feature allows you as the user to be associated with the
radio. With this association, every data application (Example:
Text Messaging Service) takes on a friendly username.

You can still send text messages without logging in as a user.
The user login feature only enables the recipient of your
message to identify you as the sender by assigning a username
to your message.

Note: Valid characters for a username entry are capital letters

(A – Z), small letters (a – z), numbers (0 – 9), symbols
(*, #, -, /), and the space character.

The maximum length for a username is eight (8)
characters. Usernames are not case sensitive in server
mode but are case sensitive in non-server mode.

A predefined username may sometimes be invalid
because the programming software that is used to set
predefined usernames allows you to set usernames
comprising of eight (8) characters or more.

Logging In as a User

Procedure:

1 > or < (on the keypad mic.) to User.

2 Press the Menu Select button directly below User.

3 The display shows the User Login screen.
4 Press the Menu Select button directly below ID.

5 A blinking cursor appears beside ID. Use the keypad to

enter a username using the keypad multi-tap function.

OR

D or U to scroll through the list of predefined usernames.

Press the Menu Select button to select a predefined
username.

OR

Press and hold

D or U to scroll through the list of

predefined usernames at a fast scroll rate.
Press the Menu Select button directly below Logn to select
a predefined username.

6 If the selected predefined username has more than eight (8)

characters, or an invalid character in it, the display
momentary shows Invalid ID. Repeat Step 5.

OR

Press the Menu Select button directly below PIN.

7 A blinking cursor appears beside PIN.

Enter your Personal Identification Number (PIN) number.





Advanced Features

65

The maximum PIN length is 4 digits. The PIN number will
appear as asterisks.

8 Press the Menu Select button directly below Logn.

9 In ARS server mode, the display shows the User Login

Indicator icon, the ID, In progress and Cncl.

OR

In ARS non-server mode, the display shows the User Login
Indicator icon, the ID, Logged in and Logt.
In non-ARS enabled mode, the display shows Offline and
Logt.

10 If the username is invalid, login fails and the user login

failure indicator (IP indicator) icon blinks. The display also
momentary shows Login failed. Repeat step 5.

OR

If the PIN is invalid, login fails and the user login failure
indicator (IP indicator) icon blinks. The display also
momentary shows Login failed. Repeat Step 7.

OR

Press the Menu Select button directly below Cncl to cancel
the login in progress screen and return to the initial user
login screen.

OR

Wait for the logged in confirmation screen. If the login
process is successful, the display shows the successful user
login indicator (IP indicator) icon and Logged in and Logt.

Logging Out

Once the data application registration is completed, you can log
out.

Procedure:

1 > or < (on the keypad mic.) to Logt.

2 Press the Menu Select button directly below Logt.

3 Display shows the User Login Indicator icon and Clear

private data?.

4Select Yes to clear all your private data. The display shows

momentary Private data cleared.

OR

Select No to keep your private data.

Note: Private data refers to all messages in the text

messaging Inbox, Draft and Sent folder. The next radio
user will be able to access your Inbox, Draft and Sent
messages if private data is not deleted.



Advanced Features

66

Text Messaging Service (TMS)

This feature allows you to send and receive text messages. The
maximum length of characters for a text message is 200.

There are three (3) types of text messages:

• A new text message (free form message)

• A predefined message (quick text message)

• An edited quick text message

The main menu consists of the following options:

• Inbox

• Compose

•Drafts

• Sent

Note: See Status Icons on page 21 for more details on the

TMS icons and TMS Menu Options on page 22 for
more details on each menu option.

Accessing TMS Feature

Note: If the feature inactivity timer is enabled, your radio

automatically exits the feature when your radio is left
idle long enough for the time to expire. You will hear the
Menu Inactive Exit Tone upon feature exit.

Press the Menu Select button directly below Back at
any time to return to the previous screen.

Procedure:

Press the preprogrammed Data Feature button or the TMS
button to access the TMS feature screen.

OR
Press and hold the preprogrammed Data Feature button or the
TMS button to access the Inbox screen.
OR

Follow the procedure below.

1 > or < (on the keypad mic.) to TMS.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3 D or U to scroll through the main menu options.



Advanced Features

67

Composing and Sending a New Text Message

Note: During the uppercase and lowercase mode, multi-

tapping the keys only scrolls through the letters. For
example, A->B->C, a->b->c.

During the num lock mode, except for 1, pressing
the keypad only enters the numeric digits. Subsequent
presses of the same key inserts the same digit to the
text message (no multi-tap).

Procedure:

1 > or < (on the keypad mic.) to f.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3 D or U to Compose. Press the Menu Select button directly

below Compose to see the compose options.

4 Press the Menu Select button directly below New to

compose a new message.

5 A blinking cursor appears on the Compose screen.

Use the keypad to type or edit your message.
Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button directly below Del to delete
any unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase

mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

6 Press the Menu Select button directly below Optn once the

message is composed.

7 D or U to Send and press the Menu Select button directly

below Send to send.

OR

D or U to Back and press the Menu Select button directly

below Back to return to Compose screen if you want to edit
the message.

8 D or U to scroll through the address list and press the

Menu Select button below Sel to select the required
address.

OR

D or U to {Other recpnt} and press the Menu Select

button below Edit.
A blinking cursor appears in the Enter address screen.
Use the keypad to type the address entry.

Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.



Advanced Features

68

9 Press the Menu Select button below Send to send the

message.

OR

Press the PTT button to send the message.

10 The display shows the Send message screen and

Sending msg.

11 If the message is sent, a tone sounds and the display shows

Msg sent.

OR

If the message is not sent, a low tone sounds and the
display shows Send failed.

If the message fails to send, the radio returns you to the main
TMS screen.

Note: You can append a priority status and/or a request reply

to your message. See Using the Priority Status and
Request Reply Features on page 70 for more
information.

Note: You can also select the DRFT option to save your

message in the Drafts folder to send it at a later time.
See Accessing the Drafts Folder on page 74 for
more details.

Sending a Quick Text Message

Quick Text messages are messages that are predefined and
usually consist of messages that are used most frequently.

Each Quick Text message has a maximum length of 50
characters.

Procedure:

Press the preprogrammed Quick Text button and proceed to
Step 3.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to TMS.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3

D or U tto Compose. Press the Menu Select button

directly below Compose to access the compose options.

4 D or U to List.

5

D or U to scroll through the list of messages and press the

Menu Select button directly below Sel to select the required
message.

6 The message appears on the Compose screen, with a

blinking cursor at the end of it.
Use the keypad to edit the message.

Press

< to move one space to the left.



Advanced Features

69

Press > to move one space to the right.
Press the Menu Select button directly below Del to delete

any unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

7 Press the Menu Select button directly below Optn.
8 D or U to Send and press the Menu Select button directly

below Sel to send the message.

9 D or U to scroll through the address list and highlight the

required address.

OR

D or U to {Other recpnt} and press the Menu Select

button below Edit.
A blinking cursor appears in the Enter address screen.
Use the keypad to type the address entry.

Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

10 Press the Menu Select button below Send to send the

message.

OR

Press the PTT button to send the message.

11 The display shows the screen and Sending msg.

12 If the message is sent, a tone sounds and the display shows

Msg sent.

OR

If the message is not sent, a low tone sounds and the
display shows Send failed.

If the message fails to send, the radio returns you to the main
TMS screen.

Note: You can append a priority status and/or a request reply

to your message. See Using the Priority Status and
Request Reply Features on page 70 for more
information.

Advanced Features

70

Using the Priority Status and Request Reply

Features

Before sending your message, you can append a priority
message and/or a request reply to your message.

Appending or Removing a Priority Status to
a Text Message

Note: The Priority Message icon on a message does not

imply that the message gets higher priority over the
other messages when it is being transmitted. It is just
an indication that can be embedded into a message to
let the receiver know that the message is important.

Procedure:

After the outgoing message is composed (see Composing and
Sending a New Text Message on page 67 for more

information):

1 Press the Menu Select button directly below Optn.

2 Press the Menu Select button directly below Impt.

The priority status icon appears beside the normal message
icon on the label bar.

3 Press the Menu Select button directly below Impt again.

The priority status icon and the normal message icon
disappear from the label bar.

Appending or Removing a Request Reply to
a Text Message

Procedure:

After the outgoing message is composed (see Composing and
Sending a New Text Message on page 67 for more

information):

1 Press the Menu Select button directly below Optn.

2 Press the Menu Select button directly below Rqrp.

The reply status icon appears beside the normal message
icon on the label bar.

3 Press the Menu Select button directly below Rqrp again.

The reply status icon and the normal message icon
disappear from the label bar.

Appending a Priority Status and a Reply
Request to a Text Message

Procedure:

After the outgoing message is composed (see Composing and
Sending a New Text Message on page 67 for more

information):

1 Press the Menu Select button directly below Optn.
2 D or U to Impt and press the Menu Select button directly

below Impt to indicate the message as important.

AND





Advanced Features

71

D or U to Rqrp and press the Menu Select button directly

below Rqrp to request for a reply.

3 The priority status and reply status icons appear beside the

normal message icon on the label bar.

Removing a Priority Status and a Reply
Request from a Text Message

When an outgoing message is indicated with priority status and
reply status icons, follow the procedure below to remove these
indicators.

Procedure:

1 Press the Menu Select button directly below Optn.
2 U or D to Impt and press the Menu Select button directly

below Impt to remove the priority status icon.

AND

D or U to Rqrp and press the Menu Select button directly

below Rqrp to remove the reply status icon.

3 The priority status, reply status and normal message icons

disappear from the label bar.

Managing Text Messages

Receiving a Text Message

Note: When you receive a message that is flagged with the

”Request Reply” icon, you must manually respond to
the sender that you have received the message. The
system will not automatically send back a notification
that the radio has received such message.

Procedure:

When you receive a message, press and hold the
preprogrammed Data Feature button or the TMS Feature
button to access the Inbox and go to Step3.

OR

Follow the procedure below.

1 The new message icon appears and the display

momentarily shows New msg.

2 Press the Menu Select button directly below TMS to access

the message.

3 The display shows alias or ID with the sender of the latest

received message on top.



Advanced Features

72

Viewing a Text Message from the Inbox

The Inbox can hold up to thirty (30) messages.

Note:

D or U to read the message if fills more than one

screen.

Procedure:
Press the preprogrammed Data Feature button or the TMS
Feature button to access the TMS feature screen, and proceed

to Step 3.

OR
Press and hold the preprogrammed Data Feature button or the
TMS Feature button to access the Inbox screen and proceed to

Step 4.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to TMS.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3 Press the Menu Select button below Inbox to view Inbox

feature screen.

4 The display shows alias or IDs, with the sender of the latest

received message.

While on the review message screen, press the Menu Select
button directly below

Rply, Del

, or

Back

to access the option.

• Select

Rply

to reply the message.

• Select

Del

to delete the message.

• Select

Back

to return to the previous screen.

Note: The icon at the top right corner of the screen indicates

the status of the message. See Text Messaging
Service (TMS) on page 66 for more information.



Advanced Features

73

Replying to a Received Text Message

Note: The original date and time stamp, address and

message content is automatically appended to the
reply message.

Procedure:

1

D or U to the required aliases or ID and press the Menu

Select button below Sel to view the message.

2 Press the Menu Select button directly below Rply to reply to

a message.

3

D or U to NEW and press the Menu Select button directly

below NEW.

OR

D or U to LIST and press the Menu Select button directly

below LIST for a predefined message.

OR

D or U to scroll through the list of messages and press the

Menu Select button directly below Sel to select the required
message.

4 A blinking cursor appears on the screen.

OR

The predefined message appears on the Compose screen,
with a blinking cursor at the end of it.

5 Use the keypad to type or edit your message.

Press < to move one space to the left.

Press > to move one space to the right.
Press the Menu Select button below Del to delete any

unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

6 Press the Menu Select button directly below Optn once you

have finished writing the message.

7 D or U to Send and press the Menu Select button directly

below Send to send the message.

8 The display shows the Send Message screen and Sending

msg.

Press the Menu Select button directly below

Back

at any time to

return to the previous screen.

Note: You can append a priority message and/or a request

reply to your message. Using the Priority Status and
Request Reply Features on page 70 for more
information.



Advanced Features

74

Accessing the Drafts Folder

This folder stores the messages that were saved previously.
The Drafts folder can hold up to 10 messages. The oldest draft
in the folder is deleted when the 11th message comes in.

Procedure:

1 > or < (on the keypad mic.) to TMS.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3 D or U to DRFT and press the Menu Select button below

DRFT.

4 The display shows the first draft message.

Press the Menu Select button directly below

Edit, Del

, or

Back

to access the option.

• Select

Edit

to edit the message before sending it.

• Select

Del

to delete the message.

• Select

Back

to return to the previous screen.

Managing Sent Text Messages

Once a message is sent to another radio, it is saved in the Sent
folder. The most recent sent text message is always added to
the top of the Sent list.

The Sent folder is capable of storing a maximum of ten (10) last
sent messages. When the folder is full, the oldest text message
in the folder is deleted when the 11th message comes in.

Viewing a Sent Text Message

The icon at the top right corner of the screen indicates the
status of the message. See Text Messaging Service (TMS) on
page 66 for more information.

Procedure:

Press the preprogrammed Data Feature button or the TMS
Feature button to access the TMS feature screen, and proceed

to Step 3.

OR

Follow the procedure below.

1 > or < (on the keypad mic.) to TMS.

2 Press the Menu Select button directly below TMS to access

the TMS feature screen.

3 D or U to Sent and press the Menu Select button below

Sent.



Advanced Features

75

Press the Menu Select button directly below

Optn, Del

, or

Back

to access the option.

• Select

Optn

to send to the message.

• Select

Del

to delete the message.

• Select

Back

to return to the previous screen.

Note: The icon at the top right corner of the screen indicates

the status of the message. See Text Messaging

Service (TMS) Icons on page 21 for more information.

Sending a Sent Text Message

Procedure:

1 Press the Menu Select button directly below Optn while

viewing the message.

2 D or U to Send and press the Menu Select button directly

below Send to send the message.

3 D or U to scroll through the address list and highlight the

required address.

OR

D or U to {Other recpnt} and press the Menu Select

button below Edit.
A blinking cursor appears in the Enter address screen.
Use the keypad to type the address entry.

Press

< to move one space to the left.

Press

> to move one space to the right.

Press the Menu Select button below Del to delete any
unwanted characters.
Press * to add a space.
Press 0 to toggle between mixed case mode, uppercase
mode, and lowercase mode.
Press # to toggle between numeric and letter mode.

4 Press the Menu Select button below Send or the PTT

button to send the message.

5 The display shows the Send Message screen and

Sending msg.

6 Press the Menu Select button directly below Back to return

to the previous screen.

Note: You can append a priority message and/or a request

reply to your message. See Using the Priority Status
and Request Reply Features on page 70 for more
details.



Advanced Features

76

Deleting Text Messages

Procedure:

From the Inbox, Draft, or Sent screen:

1 D or U to scroll through the messages.

2 Press the Menu Select button directly below Del to view the

delete options.

3 Press the Menu Select button directly below Curr to delete

the current message.

OR

Press the Menu Select button directly below All to delete all
the messages.

Secure Operations

Secure radio operation provides the highest commercially
available level of voice security on both trunked and
conventional channels.

Unlike other forms of security, Motorola digital encryption
provides signaling that makes it virtually impossible for others to
decode any part of an encrypted message.

Managing Encryption

Note: Refer to the Key-Variable Loader (KVL) manual for

equipment connections and setup.

Loading a Single Encryption Key

Procedure:

1 Attach the KVL to your radio. Upon attaching the KVL, the

radio display shows Keyloading.

2 Press the Menu Select button below Target.
3 Press the Menu Select button below Load.

4 Press the Menu Select button below Key.
5 D or U to required key.

6 Press the Menu Select button below Load to load the key

to your radio.



Advanced Features

77

7 When the key has been loaded successfully, the radio

sounds a short tone for single-key radios.

Loading the Group Encryption Keys

Procedure:

1 Attach the KVL to your radio.
2 Press the Menu Select button below Target.

3 Press the Menu Select button below Load.
4 Press the Menu Select button below Group.

5 D or U to required group.

6 Press the Menu Select button below Load to load the key

to your radio.

7 Your mobile radio display shows Keyloading when it is

loading key(s) from KVL.

8 When the key has been loaded successfully, the radio

sounds an alternating tone for multikey radios.

Using the Multikey Feature

This feature allows the radio to be equipped with different
encryption keys and supports the DES-OFB algorithm.

There are two types of multikey:

• Conventional Multikey – The encryption keys can be tied
(strapped), on a one-per-channel basis, through Customer
Programming Software. In addition, you can have operator­selectable keys, operator-selectable keysets, and operator­selectable key erasure. If talkgroups are enabled in
conventional, then the encryption keys are strapped to the
talkgroups.

• Trunked Multikey – If you use your radio for both
conventional and trunked applications, you have to strap your
encryption keys for trunking on a per-talkgroup or
announcement-group basis. In addition, you may strap a
different key to other features, such as dynamic regrouping,
failsoft, or emergency talkgroup. You can have operator­selectable key erasure.





Advanced Features

78

Selecting an Encryption Key (Conventional
Only)

Procedure:

1 > or < (on the keypad mic.) to Key.

2 Press the Menu Select button directly below Key. The

display shows the last user-selected and stored encryption
key, and the available menu selections.

3 D or U to scroll through the encryption keys.

OR

Use the keypad to enter the number of the desired key.

4 Press the Menu Select button directly below Sel to save the

newly selected key and return to the Home screen.

OR

Press

H, the PTT button, or the Menu Select button directly

below Exit to exit.

Note: If the selected key is erased, a momentary keyfail tone

sounds and the display shows Key fail.

OR

If the selected key is not allowed, a momentary illegal
key tone sounds and the display shows Illegal key.

Enabling Secure Transmission

Procedure:

1 > or < (on the keypad mic.) to Sec and press the Menu

Select button directly below Sec. The display shows

m and

the current key if multi-key has been enabled.

2 Monitor the mode to be sure it is not in use.

3 Press PTT button to transmit.

Note: If the selected channel is preprogrammed for clear-only

operation – when you press the PTT button, an invalid
mode tone sounds and the display shows Clear Tx
only.

The radio does not transmit until you disable the secure
mode.

The radio can be configured to ignore the clear voice or
insecured transmission when the radio is in secured
transmission. Check with your agent for details.





Advanced Features

79

Accessing the Secure Feature

Procedure:

1 > or < (on the keypad mic.) to Sec.

2 Press and hold the Menu Select button directly below Sec

to display Secure feature screen.

3 The display shows the Secure screen.

Selecting a Keyset

This feature allows you to select one or more groups of several
encryption keys from among the available keys stored in the
radio.

For example, you could have a group of three keys structured to
one keyset, and another group of three different keys structured
to another keyset; by changing keysets, you would
automatically switch from one set of keys to the other.

Every channel to which one of the original keys was tied now
has the equivalent new key instead.

Note: Press

H, the PTT button, or the Exit menu selection to

exit this menu at any time without changing the keyset
selection.

Procedure:

1 > or < (on the keypad mic.) to Kset.

2 Press the Menu Select button directly below Kset.

The display shows the last user-selected and stored keyset,
and the available keyset menu selections.

3

D or U to scroll through the keysets.

OR

Use the keypad to enter the number of the desired keyset.

4 Press the Menu Select button directly below Sel to save the

newly selected keyset.

5 The radio exits keyset selection and returns to the Home

screen.

Erasing the Selected Encryption Keys

This feature allows you to erase all or selected encryption keys.

Procedure:

1 > or < (on the keypad mic.) to Eras.

2 Press the Menu Select button directly below Eras. The

display shows the last user-selected and stored encryption
key, and the available menu selections.

3 D or U to the desired encryption key.

OR

Use the keypad to enter the number of the desired key.

4 Press the Menu Select button directly below All to delete all

keys.

OR







Advanced Features

80

Press the Menu Select button directly below Sngl to delete
current shown key.

OR

Press the Menu Select button directly below Abrt to abort
this screen and return to Home screen.

Requesting an Over-the-Air Rekey

This feature, also known as OTAR, allows the dispatcher to
reprogram the encryption keys in the radio remotely. The
dispatcher performs the rekey operation upon receiving a rekey
request from the user.

Procedure:

1 > or < (on the keypad mic.) to Rekey.

2 Press the Menu Select button directly below Rekey.

3 Press the PTT button to send the rekey request.

OR

Press the PTT button again, or the H or Emergency button,
to exit the feature and transmit in normal mode.

4 If the rekey operation fails, a bad-key tone sounds and the

display shows Rekey fail.

Note: The rekey operation failure indicates that your radio

does not contain the Unique Shadow Key (USK). This
key must be loaded into the radio with the key-variable
loader (KVL) before the rekey request can be sent.

Refer to your local key management supervisor for
more information.

MDC Over-the-Air Rekeying (OTAR) Page

This feature allows to view or define MDC Over-the-Air
Rekeying (OTAR) features.It is applied only when operating in
secure encrypted mode and only for conventional
communications. In additional to Rekey Requests, OTAR
transmissions include Delayed Acknowledgements, and Power­up Acknowledgements.

Some of the options selected may also need to be set up at the
Key Management Controller (KMC) site to work properly.

Note: This feature must be preprogrammed by a qualified

radio technician. Check with your dealer or system
administrator for more information.

Infinite UKEK Retention

This feature enables Unique Key Encryption Key (UKEK) to be
permanently stored in the radio even when all of the encryption
keys is erased. Without this UKEK key, the radio could not be
over the air rekeyed.

Note: This feature must be preprogrammed by a qualified

radio technician. Check with your dealer or system
administrator for more information.



Advanced Features

81

Hear Clear

There are two components of Hear Clear.

1 Companding:

Reduces the channel noise, e.g. OTA transmission, that is
predominantly present in UHF2 and 900 MHz channel with
the following features.

• Compressor – reduces the background noise flow and the

speech signal at transmitting radio.

• Expander – expands the speech while the noise flow

remains the same at receiving radio.

2 Random FM Noise Canceller (Flutter Fighter):

Reduces the unwanted effects of random FM noise pulses
caused by channel fading under high Signal-to-Noise (S/N)
conditions such as in a moving in a transportation. The fading
effects, heard as audio pops and clicks, are cancelled without
affecting the desired audio signal.

The Random FM Noise Canceller operates only in receive
mode.

Note: This feature must be preprogrammed by a qualified

radio technician. Check with your dealer or system
administrator for more information.

The Global Positioning System (GPS)

This feature uses information from the Global Positioning
System (GPS) satellites orbiting the Earth to determine the
approximate geographical location of your radio, expressed as
latitude and longitude. The availability and accuracy of this
location information (and the amount of time that it takes to
calculate it) varies depending on the environment in which you
are using the GPS feature.

For example, GPS location fixes are very difficult to obtain
indoors, in covered locations, between high buildings, or in
situations where you have not established a clear broad view of
the sky.

Understanding the GPS Feature

The GPS technology uses radio signals from earth orbiting
satellites, to establish the location co-ordinates, maximizing
your view of clear unobstructed sky is essential for optimum
performance.

Where adequate signals from multiple satellites are not
available (usually because you cannot establish a view of a
wide area of the sky), the GPS feature of your radio will not
work. Such situations include but are not limited to:

• In underground locations

• Inside of buildings, trains, or other covered vehicles





Advanced Features

82

• Under any other metal or concrete roof or structure

• Between tall buildings or under dense tree-cover

• In temperature extremes outside the operating limits of your
radio

Even where location information can be calculated in such
situations, it may take longer to do so, and your location
estimate may not be as accurate. Therefore, in any emergency
situation, always report your location to your dispatcher.

Note: Even where adequate signals from multiple satellites

are available, your GPS feature only provides an
approximate location, usually within 20 meters from
your actual location, but sometimes further away.

Keep in mind that the accuracy of the location information and
the time it takes to obtain it varies depending upon
circumstances, particularly the ability to receive signals from an
adequate number of satellites.

Note: The satellites used by the GPS feature are controlled

by the U.S. government and are subject to changes
implemented in accordance with the Department of
Defense GPS user policy and the Federal Radio
Navigation Plan. These changes may affect the
performance of the GPS feature on your radio.

Enhancing GPS Performance

Sometimes, the GPS feature may be unable to complete a
location calculation successfully. You then see a message
indicating that your radio cannot connect to enough visible
satellites.

To maximize the ability of your radio to determine a fix, please
note the following guidelines:

• For your initial fix, hold the radio in the face position.

• Stay in the open. The GPS feature works best where there is
nothing between your radio and a large amount of open sky.

The Outdoor Location Feature (Using GPS)

This feature allows you to determine your current location using
a location menu, as well as your current distance and bearing in
relation to another location. Radio location may be requested
and reported over-the-air.

Your radio stores up to a maximum of sixty (60) programmable
location coordinates, also known as waypoints. When the
memory is full, the next waypoints automatically replaces the
oldest waypoints in the radio.




