Motorola 92FT7048 Users manual

m
APX O5 Control Head
Mobile Radio User Guide
m
ASTRO® APX™ O5 Control Head Mobile Radio Quick Reference Card
Product Safety and RF Exposure Compliance
Before using this product, read the operating instructions for safe usage contained in the Product
!
Safety and RF Exposure booklet enclosed with your
Caution
radio.
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructio ns in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF energy exposure limits.
Radio Controls
Volume Knob
Dim Button
Home Button
Accessory Port (Microphone)
© 2009, 2010 by Motorola, Inc. All Rights Reserved. 10/10 1301 E. Algonquin Rd., Schaumburg, IL 60196-1078, U.S.A.
ATTENTION!
Power On/Off Button
Indicators
LED Indicators
Menu Entries
Menu Select Button
Mode Knob
Orange Button ______
Navigation Button
Radio On/Off
Press the Power On/Off button to toggle the power on or off.
Adjusting Volume
Turn the Volume Knob clockwise to increase volume or counterclockwise to decrease the volume.
Selecting a Zone
1 > or < to ZONE. 2 > or < button until the desired zone is displayed. 3 Press H or the PTT button to confirm the selected
zone number.
4 Press the PTT button to begin transmitting on the
displayed zone channel.
Selecting a Channel
_
1 Press and hold > to scroll to CHAN and press the
Menu Select button directly below CHAN. The
display shows the current zone and channel.
2 Rotate the Mode knob to the desired channel. 3 Press H or the PTT button to confirm the channel. 4 Press the PTT button to transmit on the displayed
zone channel.
Receiving and Transmitting
1 Take the microphone off hook. 2 Select zone/channel. 3 Listen for a transmission.
OR Turn the Volume Knob. OR
> or < to MON then press the Menu Select button
directly below MON and listen for activity.
4 Adjust volume, if necessary. 5 Press the PTT button to transmit; release to receive.
Sending an Emergency Alarm
1 Press the Emergency button. A tone sounds and the
display alternates EMERGENCY and the home display.
2 A dispatcher acknowledgment ACK RECEIVED
display follows.
AND, Trunking Only:
A high-pitched tone indicates that the alarm has been received by the trunked system’s central controller.
3 Press and hold the emergency button or the PTT
button to return to normal operation.
T o exit emergency at any time, press and hold the Emergency button.
*PMLN5592B*
PMLN5592B
English
Sending an Emergency Call (Trunking Only)
F
1 Press Emergency button. 2 A tone sounds and the display alternates
EMERGENCY and the home display.
OR
A talk prohibited tone sounds when the selected channel does not support emergency.
3 Press and hold the PTT button. Speak clearly into
the microphone.
4 Release the PTT to end the transmission.
To exit emergency at any time, press and hold the Emergency button.
Sending a Silent Emergency Alarm
1 Press the preprogrammed Emergency button to
activate the silent alarm feature.
2 The display does not change; the LED does not light
up, and there is no tone.
If silent emergency alarm is used with emergency call, pressing the PTT button exits the silent mode and initiates the emergency call.
Display Status Icons
Receiving a call or data.
u
Transmitting a call or data.
t
Received an Individual Call. The more stripes, the stronger the signal
strength for the current site (trunking only).
V
Direct radio-to-radio communication or
O
communication through a repeater.
On = Direct Off = Repeater
This channel is being monitored.
M
Voice muting the af filiated trunkin g t alkgroup or selected conventional channel.
K
On = Enabled Off = Disabled
HOR .
L = Radio is set at Low power. H = Radio is set at High power.
Scanning a scan list.
i
Blinking dot = Detects activity on the
j
Steady dot = Detects activity on the Priority-
Radio is in the view or program mode.
On steady = View mode. Blinking = Program mode.
Priority-One Channel during scan.
Two Channel during scan.
Menu Navigation
< or > to Menu Entry.
g directly below Menu Entry to
select.
The vote scan feature is enabled.
k
On = Secure operation. Off = Clear operation.
m
Blinking = Receiving an encrypted voice
On = AES Secure operation. Off = Clear operation.
l
Blinking = Receiving an encrypted voice
On = Location feature enabled, and location
G
Off = Location feature disabled. Blinking = Location feature enabled, but
On = User is currently associated with the
n
Off = User is currently not associated with Blinking = Device registration or user
Data activity is present.
o
call.
call.
signal available.
location signal unavailable.
radio.
the radio.
registration with the server failed due to an invalid username or pin.
< or > to scroll through sub-list.
English
H to exit.
g directly below Menu Entry to
select.

Declaration of Conformity

This declaration is applicable to your radio only if your radio is labeled with the FCC logo shown below.
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: Motorola, Inc. 1301 E. Algonquin Rd.Schaumburg, IL60196-1078, U.S.A. Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: APX 7500 / APX 6500
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Declaration of Conformity
English
i
Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
ii
English
Contents
This User Guide contains all the information you need to use the APX™ Mobile Radios.
Declaration of Conformity . . . . . . . . . . . . . . . . . .i
Important Safety Information . . . . . . . . . . . . . .ix
Product Safety and RF Exposure Compliance . . . . ix
Software Version . . . . . . . . . . . . . . . . . . . . . . . .ix
Computer Software Copyrights . . . . . . . . . . . . x
Documentation Copyrights . . . . . . . . . . . . . . . . x
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . 1
How to Use This User Guide . . . . . . . . . . . . . . . . . . 1
Notations Used in This Manual . . . . . . . . . . . . . . . . .1
Additional Performance Enhancement . . . . . . . . . . .2
Dynamic System Resilience (DSR) . . . . . . . . . . . . . .2
CrossTalk Prevention . . . . . . . . . . . . . . . . . . . . . . . .2
Encrypted Integrated Data (EID) . . . . . . . . . . . . . . . .2
SecureNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What Your Dealer/System Administra to r
Can Tell You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparing Your Radio for Use . . . . . . . . . . . . . .3
Turning On the Radio . . . . . . . . . . . . . . . . . . . . . . . . 4
Validating Compatibility During Power Up . . . . . . . . 4
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . 5
Identifying Radio Controls . . . . . . . . . . . . . . . . .5
Radio Parts and Controls . . . . . . . . . . . . . . . . . . . . . 6
O5 Control Head and Microphone . . . . . . . . . . . . . 6
Programmable Features . . . . . . . . . . . . . . . . . . . . . . 7
Assignable Radio Functions . . . . . . . . . . . . . . . . . . 7
Assignable Settings or Utility Functions . . . . . . . . . . 9
Accessing the Preprogrammed Functions . . . . . . . . 9
Using the Menu Select Buttons . . . . . . . . . . . . . . . . 9
Using the Advance Programmable Buttons . . . . . . 10
Using the Navigation Buttons . . . . . . . . . . . . . . . . 10
Home Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Data Feature Button . . . . . . . . . . . . . . . . . . . . . . . 10
4-Way Navigation Button . . . . . . . . . . . . . . . . . . . 11
Volume Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mode Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Keypad . . . . . . . . . . . . . . . . . . . . . 12
Contents
iii
English
Keypad Characters – Uppercase Mode . . . . . . . . . 12
Keypad Characters – Lowercase Mode . . . . . . . . . 13
Keypad Characters – Numeric Mode . . . . . . . . . . . 14
Keypad Characters – Hexadecimal Mode . . . . . . . 15
Push-To-Talk (PTT) Button . . . . . . . . . . . . . . . . . 16
Identifying Status Indicators . . . . . . . . . . . . . .16
Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Text Messaging Service (TMS) Icons . . . . . . . . . . 19
Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . 20
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Intelligent Lighting Indicators . . . . . . . . . . . . . . . 22
Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
General Radio Operation . . . . . . . . . . . . . . . . .26
Selecting a Zone . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Selecting a Radio Channel . . . . . . . . . . . . . . . . . . . 27
Receiving and Responding to a Radio Call . . . . . . 27
Receiving and Responding to a Talkgroup Call . . . 28
Contents
iv
Receiving and Responding to a Private Call
(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Receiving and Responding to a Telephone Call . . 29
Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . 30
Making a Talkgroup Call . . . . . . . . . . . . . . . . . . . . .30
Making a Private Call (Trunking Only) . . . . . . . . . . .31
Making a Telephone Call . . . . . . . . . . . . . . . . . . . .32
Repeater or Direct Operation . . . . . . . . . . . . . . . . . 33
Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . 33
Monitoring a Channel . . . . . . . . . . . . . . . . . . . . . . .33
Conventional Mode Operation . . . . . . . . . . . . . . . .34
Advanced Features . . . . . . . . . . . . . . . . . . . . . 35
Advanced Call Features . . . . . . . . . . . . . . . . . . . . . 35
Calling a Phone Not in the List . . . . . . . . . . . . . . . .35
Receiving and Making a Selective Call
(Conventional Only) . . . . . . . . . . . . . . . . . . . . . . . .36
Receiving a Selective Call . . . . . . . . . . . . . . . . . . .36
Making a Selective Call . . . . . . . . . . . . . . . . . . . . .36
Using the Talkgroup Call Feature (Conventional
Operation Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Selecting a Talkgroup . . . . . . . . . . . . . . . . . . . . . . .37
Sending a Status Call . . . . . . . . . . . . . . . . . . . . . . .38
Using the Dynamic Regrouping Feature
(Trunking Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Requesting a Reprogram . . . . . . . . . . . . . . . . . . . .39
Classifying Regrouped Radios . . . . . . . . . . . . . . . .39
Multiple Control Head Features . . . . . . . . . . . . . . . 40
Multiple Control Head Features . . . . . . . . . . . . . . .40
Setting the Initial Control Head’s ID . . . . . . . . . . . .40
English
All Active Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Intercom Feature in All Active Mode . . . . . . . . . . .41
One Active Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Making a Private Call from Contacts . . . . . . . . . . . .43
Adding a New Contact Entry . . . . . . . . . . . . . . . . . .45
Deleting a Contact Entry . . . . . . . . . . . . . . . . . . . . .46
Adding a Contact to a Call List or Phone List . . . . .46
Editing a Contact in a Call List or a Phone List . . . .47
Editing an Entry Alias . . . . . . . . . . . . . . . . . . . . . . .47
Editing as Entry ID . . . . . . . . . . . . . . . . . . . . . . . . .47
Editing a Call Type . . . . . . . . . . . . . . . . . . . . . . . . .48
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Viewing a Scan List . . . . . . . . . . . . . . . . . . . . . . . . .49
Editing the Scan List . . . . . . . . . . . . . . . . . . . . . . . .49
Changing the Scan List Status . . . . . . . . . . . . . . . .50
Viewing and Changing the Priority Status . . . . . . . .50
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Turning Scan On or Off . . . . . . . . . . . . . . . . . . . . . .51
Turning Scan On While Disregarding the
Squelch Code (Conventional Channels Only) . . . . .51
Transmitting While the Scan is On . . . . . . . . . . . . .51
Radio Programmed for Talkback Scan . . . . . . . . .51
Radio Programmed for Non-Talkback Scan . . . . .52
Deleting a Nuisance Channel . . . . . . . . . . . . . . . . .52
Restoring a Nuisance Channel . . . . . . . . . . . . . . . .52
Changing Priorities Status While Scan is On . . . . . 53
Restoring Priorities in a Scan List . . . . . . . . . . . . . 53
Hang Up (HUB) . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Call Alert Paging . . . . . . . . . . . . . . . . . . . . . . . . . .54
Receiving a Call Alert Page . . . . . . . . . . . . . . . . . . 54
Sending a Call Alert Page . . . . . . . . . . . . . . . . . . . 55
In-Call User Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Emergency Operation . . . . . . . . . . . . . . . . . . . . . . .56
Sending an Emergency Alarm . . . . . . . . . . . . . . . . 57
Sending an Emergency Call (Trunking Only) . . . . 57
Sending an Emergency Alarm with
Emergency Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Sending a Silent Emergency Alarm . . . . . . . . . . . . 58
Special Considerations for Emergencies . . . . . . . . 59
Automatic Registration Service (ARS) . . . . . . . . . . 60
Selecting or Changing ARS Mode . . . . . . . . . . . . . 60
Accessing the User Login Feature . . . . . . . . . . . . . 61
Logging In as a User . . . . . . . . . . . . . . . . . . . . . . . 61
Logging Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Text Messaging Service (TMS) . . . . . . . . . . . . . . . . 63
Accessing TMS Feature . . . . . . . . . . . . . . . . . . . . 63
Composing and Sending a New Text Message . . . 64
Sending a Quick Text Message . . . . . . . . . . . . . . . 65
Using the Priority Status and Request Reply
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Appending or Removing a Priority Status to a
Contents
v
English
Contents
vi
Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Appending or Removing a Request Reply to a
Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Appending a Priority Status and a Reply Request
to a Text Message . . . . . . . . . . . . . . . . . . . . . . . . .67
Removing a Priority Status and a Reply Request
from a Text Message . . . . . . . . . . . . . . . . . . . . . . .68
Managing Text Messages . . . . . . . . . . . . . . . . . . . 68
Receiving a Text Message . . . . . . . . . . . . . . . . . .68
Viewing a Text Message from the Inbox . . . . . . . . 69
Replying to a Received Text Message . . . . . . . . . 70
Accessing the Drafts Folder . . . . . . . . . . . . . . . . . . 71
Managing Sent Text Messages . . . . . . . . . . . . . . . 71
Viewing a Sent Text Message . . . . . . . . . . . . . . . . 7 1
Sending a Sent Text Message . . . . . . . . . . . . . . . 72
Deleting Text Messages . . . . . . . . . . . . . . . . . . . . 73
Secure Operations . . . . . . . . . . . . . . . . . . . . . . . . . 73
Managing Encryption . . . . . . . . . . . . . . . . . . . . . . . 73
Loading a Single Encryption Key . . . . . . . . . . . . . .73
Loading the Group Encryption Keys . . . . . . . . . . . 74
Using the Multikey Feature . . . . . . . . . . . . . . . . . . 74
Selecting an Encryption Key (Conventional Only) . 75
Enabling Secure Transmission . . . . . . . . . . . . . . .75
Accessing the Secure Feature . . . . . . . . . . . . . . .75
Selecting a Keyset . . . . . . . . . . . . . . . . . . . . . . . . .76
Erasing the Selected Encryption Keys . . . . . . . . . .76
Requesting an Over-the-Air Rekey . . . . . . . . . . . . 77
MDC Over-the-Air Rekeying (OTAR) Page . . . . . .77
Hear Clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
The Global Positioning System (GPS) . . . . . . . . . . 78
Understanding the GPS Feature . . . . . . . . . . . . . . .78
Enhancing GPS Performance . . . . . . . . . . . . . . . . .79
The Outdoor Location Feature (Using GPS) . . . . . . 79
Accessing the Outdoor Location Feature . . . . . . . .80
Saving a Waypoint . . . . . . . . . . . . . . . . . . . . . . . . .81
Viewing a Saved Waypoint . . . . . . . . . . . . . . . . . . .82
Editing the Alias of a Waypoint . . . . . . . . . . . . . . . .83
Editing the Coordinates of a Waypoint . . . . . . . . . .83
Deleting a Single Saved Waypoint . . . . . . . . . . . . .84
Deleting All Saved Waypoints . . . . . . . . . . . . . . . .85
Measuring the Distance and Bearing from a
Saved Waypoint . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Using the Location Feature While in
Emergency Mode . . . . . . . . . . . . . . . . . . . . . . . . . .86
Trunking System Controls . . . . . . . . . . . . . . . . . . . 86
Using the Failsoft System . . . . . . . . . . . . . . . . . . . .86
Going Out-of-Range . . . . . . . . . . . . . . . . . . . . . . . .87
SmartZone® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Using Site Trunking Feature . . . . . . . . . . . . . . . . . .87
Locking and Unlocking a Site . . . . . . . . . . . . . . . . .88
Viewing and Changing a Site . . . . . . . . . . . . . . . . .88
Viewing the Current Site . . . . . . . . . . . . . . . . . . . . .88
Changing the Current Site . . . . . . . . . . . . . . . . . . .89
Trunked Announcement . . . . . . . . . . . . . . . . . . . . .89
English
Initiating an Announcement . . . . . . . . . . . . . . . . . .90
Ignition Switch Options . . . . . . . . . . . . . . . . . . . . . . 90
Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Tx Inhibit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
PTT Tx Inhibit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Soft Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Ignition Only Power Up . . . . . . . . . . . . . . . . . . . . . .91
Emergency Power Up . . . . . . . . . . . . . . . . . . . . . . .91
Auto Power Off Timer . . . . . . . . . . . . . . . . . . . . . . .92
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Viewing Recent Calls List . . . . . . . . . . . . . . . . . . . .92
Selecting the Power Level . . . . . . . . . . . . . . . . . . . .93
Selecting a Radio Profile . . . . . . . . . . . . . . . . . . . . .93
Controlling the Display Backlight . . . . . . . . . . . . . . .94
Turning Keypad Tones On or Off . . . . . . . . . . . . . .94
Turning Voice Mute On or Off . . . . . . . . . . . . . . . . .95
Using the Time-Out Timer . . . . . . . . . . . . . . . . . . . .95
Using the Conventional Squelch
Operation Features . . . . . . . . . . . . . . . . . . . . . . . . .96
Analog Options . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Digital Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Using the PL Defeat Feature . . . . . . . . . . . . . . . . . .97
Using the Digital PTT ID Feature . . . . . . . . . . . . . .97
Using the Smart PTT Feature (Conventional Only) 97
Accessing General Radio Information . . . . . . . . . . .98
Accessing Radio Information . . . . . . . . . . . . . . . . 98
Viewing IP Information . . . . . . . . . . . . . . . . . . . . . 99
Viewing Control Assignments . . . . . . . . . . . . . . . . 99
Using Optional External Alarms
(Horn and Lights) . . . . . . . . . . . . . . . . . . . . . . . . . 100
Using Non-Permanent Horn and Lights . . . . . . . 100
Using Permanent Horn and Lights . . . . . . . . . . . 100
Changing the Selected Alarms . . . . . . . . . . . . . . 101
Receiving a Call While Alarms are Turned On . . 101 Turning Off Non-Rearmable External Alarms . . . 101
Turning Off Rearmable External Alarms . . . . . . . 102
Using the Voice Announcement . . . . . . . . . . . . . 102
Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Appendix: Maritime Radio Use in the VHF
Frequency Range . . . . . . . . . . . . . . . . . . . . . .106
Special Channel Assignments . . . . . . . . . . . . . . . 106
Emergency Channel . . . . . . . . . . . . . . . . . . . . . . 106
Non-Commercial Call Channel . . . . . . . . . . . . . . 106
Operating Frequency Requirements . . . . . . . . . . .107
Contents
vii
English
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Commercial Warranty and Service . . . . . . . .113
Contents
viii
English

Important Safety Information

Product Safety and RF Exposure Compliance

Before using this product, read the operating
!
Caution
This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements.
Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number 6881095C99) to ensure compliance with RF energy exposure limits.
For a list of Motorola-approved antennas and other accessories, visit the following website:
http://www.motorola.com/governmentandenterprise
instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio.
ATTENTION!

Software Version

Important Safety Information
All the features described in the following sections are
supported by the radio's software version R05.00.00 or later.
Accessing Radio Information on page 98 to determine your radio's software version.
Check with your dealer or system administrator for more details of all the features supported.
English
ix

Computer Software Copyrights

Documentation Copyrights

The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distr ibuted in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either di rectly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product.
Computer Software Copyrights
No duplication or distribution of this document or any portion thereof shall take place without the express written permission of Motorola. No part of this manual may be reproduced, distributed, or transmitted in any form or by any means, electronic or mechanical, for any purpose without the express written permission of Motorola.

Disclaimer

The information in this document is carefully examined, and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Furthermore, Motorola reserves the right to make changes to any products herein to improve readability, function, or design. Motorola does not assume any liability arising out of the applications or use of any product or circuit described herein; nor does it cover any license under its patent rights, nor the rights of others.
x
English

Getting Started

Take a moment to review the following:
How to Use This User Guide. . . . . . . . . . . . . . . . . . . . . page 1
Notations Used in This Manual . . . . . . . . . . . . . . . . . . . page 1
Additional Performance Enhancement . . . . . . . . . . . . . page 2
What Your Dealer/System Administrator Can Tell You . page 3

How to Use This User Guide

This User Guide covers the basic operation of the APX™ Mobile Radios.
However, your dealer or system administrator may have customized your radio for your specific needs. Check with your dealer or system administrator for more information.

Notations Used in This Manual

Throughout the text in this publication, you will notice the use of WARNING, Caution, and Note. These notations are used to emphasize that safety hazards exist, and the care that must be taken or observed.The following special notations identify
certain items:
An operational procedure, practice, or condition,
!
!
W A R N I N G
!
Caution
etc., which may result in injury or death if not carefully observed.
An operational procedure, practice, or condition, etc., which may result in damage to the equipment if not carefully observed.
Getting Started
Note:
An operational procedure, practice, or condition, etc., which is essential to emphasize.
1
English

CrossTalk Prevention

Example Description
Home button
or
H
PHONE
>
Buttons and keys are shown in bold print or as an icon.
Menu entries are shown similar to the way they appear on the radio’s display.
This means “Press the right side of the 4-way Navigation button.”

Additional Performance Enhancement

The following are some of the latest creations designed to enhance the security, quality and efficiency of APX mobile radios.

Dynamic System Resilience (DSR)

DSR ensures the radio system is seamlessly switched to a backup master site dynamically in case of system failure. DSR also provides additional indication e.g. failure detection, fault recovery, and redundancy within the system to address to the user in need. Mechanisms related to the Integrated Voice and Data (IV & D) or data centric are all supported by DSR.
Getting Started
This feature prevents crosstalk scenario from happening, especially when a wideband antenna is used. This feature allows the adjustment of the Trident Transmitting SSI clock rate in the radio to be varied from the Receiving Frequency. This subsequently reduced the possibilities of radio frequency interfering spurs and prevents the issues of crosstalk.

Encrypted Integrated Data (EID)

EID provides security encryption and authentication of IV & D data bearer service communication between the radio and the Customer Enterprise Network.

SecureNet

SecureNet allows user to perform secured communications on an Analog or Motorola Data Communication (MDC) channel. The MDC OTAR feature will allow users to perform OTAR activities on an MDC channel.
2
English
What Your Dealer/System Administrator
Can Tell You
You can consult your dealer or system administrator about the following:
Is your radio preprogrammed with any preset conventional
channels?
Which buttons have been programmed to access other
features?
What optional accessories may suit your needs?

Preparing Your Radio for Use

Preparing Your Radio for Use
Turning On the Radio. . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Validating Compatibility During Power Up. . . . . . . . . .page 4
Adjusting the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . .page 5
English
3

Turning On the Radio

Press the Power On/Off Button briefly to power on the radio.
After a short time, the red, yellow and green LEDs light up. The display then shows Zone and channel text, and menu items display on the screen.
The backlight will turn on to the last selected dim level. Note: Pressing the Power On/Off Button before the LED
lights up will be ignored. If FAIL ##/## appears in the display, the radio will not
function until the condition has been corrected.
Power On/ Off Button
To turn off the radio, press the Power On/Off Button after the LEDs light up.

Validating Compatibility During Power Up

The radio validates and updates the software and hardware of your control head(s) during power up. Follow the procedure below when your radio runs this task.
Procedure:
1 The display shows MAINTENANCE MODE REMOTE DEVICE;
promptly followed by other maintenance statuses.
2 The display shows UPDATE DONE PLEASE RESET upon
completion.
OR
The display shows UPDATE FAILED PLEASE RESET when it fails to update.
If ERROR ##/## appears, some non-critical data has been changed. If either of these displays appear, if the display goes blank, or if the unit appears to be locked up, see Helpful Tips on page 104 for more information.
If CH MISMATCH appears, means that either the Control Head has been connected to an incompatible
Preparing Your Radio for Use
If your radio does not power up, contact your dealer.
transceiver, or vice versa.
4
English
3 Press the Power On/Off Button to reset. The radio runs the
usual power up operation if the software updates are complete.
OR
The radio runs the Maintenance Mode if the updates are not complete and repeat step 1.
Note: If SW INCOMPLETE appears, use Flashport Recovery
Tool to update the co ntrol heads before you power on the radio again.

Adjusting the Volume

To increase the volume, rotate the Volume Knob clockwise.
To decrease the volume, rotate the Volume Knob counterclockwise.
Volume Knob

Identifying Radio Controls

Identifying Radio Controls
Take a moment to review the following:
Radio Parts and Controls. . . . . . . . . . . . . . . . . . . . . . . .page 6
O5 Control Head and Microphone . . . . . . . . . . . . . . .page 6
Programmable Features . . . . . . . . . . . . . . . . . . . . . . . .page 7
Assignable Radio Functions. . . . . . . . . . . . . . . . . . . .page 7
Assignable Settings or Utility Functions . . . . . . . . . . .page 9
Accessing the Preprogrammed Functions. . . . . . . . . . .page 9
Using the Menu Select Buttons . . . . . . . . . . . . . . . . .page 9
Using the Advance Programmable Buttons . . . . . . .page 10
Using the Navigation Buttons. . . . . . . . . . . . . . . . . .page 10
Using the Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 12
Keypad Characters – Uppercase Mode . . . . . . . . . .page 12
Keypad Characters – Lowercase Mode . . . . . . . . . .page 13
Keypad Characters – Numeric Mode . . . . . . . . . . . .page 14
Keypad Characters – Hexadecimal Mode . . . . . . . .page 15
Push-To-Talk (PTT) Button. . . . . . . . . . . . . . . . . . . . . .page 16
English
5

Radio Parts and C ont rols

O5 Control Head and Microphone

Volume Knob
16
1
*These controls/buttons are programmable.
Identifying Radio Controls
Dim Button
15
Home Button
14
Power On/Off Button
13
Indicators
12
Menu Entries
3
Menu Select Button*
2
Accessory Port (Microphone)
LED Indicators
4
Mode Knob
11
Navigation
5
Button
Orange Button*
10
9
Push-to-Talk (PTT) Button
Accy No-Dot
8
Button (Purple)*
Accy 1-Dot
7
Button*
Accy 2-Dot
6
Button*
Navigation Button
22
(Microphone)
Data Feature Button*
Home Button (Microphone)
*This button is programmable.
Keypad Buttons
17 18
19
Cancel Button
21
(
2
)
Okay/Select
20
Button (
3
)
Note: The microphone is not part of a radio. It is an optional
accessory.
6
English

Programmable Features

Any reference in this manual to a control that is “preprogrammed” means that the control must be programmed by a dealer or a qualified radio technician using the radio’s programming software, in order to assign a feature to that control.
The programmable buttons can be programmed as shortcuts to radio functions or preset channels/groups depending on the duration of a button press:
Press Pressing and releasing rapidly.
Long press Pressing and holding for the programmed
duration (between 0.25 seconds and 3.75 seconds).
Hold down Keeping the button pressed.

Assignable Radio Functions

Call Alert – Allows the radio to function like a pager, or to verify
if a radio is active on the system. Call Response Allows you to answer a private call or phone
call.
Channel – Selects a channel. Contacts – Selects the Contacts menu.
Dynamic Priority (Conventional Only) – Allows any channel
in a scan list (except for the Priority-One channel) to temporarily replace the Priority-Two channel.
Emergency Depending on the programming, initiates or cancels an emergency alarm or call.
Information Displays the basic radio information, IP-related information, and buttons or switches control mapping.
Intercom Enables users of multiple control heads to talk to each other via the control heads in a multi-control head setup.
Internet Protocol Address Displays the Internet Protocol (IP) address, device name, and status of the radio.
Location Determines the current location (latitude, longitude, time and date), and also the distance and bearing to another location. Or, turns the GPS functionality on or off for all locations.
Message – Enters the current message list. Monitor (Conventional Only) – Monitors a selected channel
for all radio traffic until function is disabled. Multiple Private Line (Conventional Only) Selects the
Multiple Private Line lists. Nuisance Delete – Temporarily removes an unwanted channel,
except for priority channels or the designated transmit channel, from the scan list.
Identifying Radio Controls
English
7
One Touch 1 – 4 – Launches a specific feature with one single
button-press. You can setup as much as four separately programmed buttons for four different features.
Phone – Allows you to make and receive calls similar to standard phone calls.
Private Call (Trunking Onl y ) Allows a call from an individual radio to another individual radio.
Radio Profiles Allows for easy access to a set of preprogrammed visual and audio settings of the radio.
Recent Calls Allows for easy access to the list of calls recently received or made.
Rekey Request Notifies the dispatcher that you require a new encryption key.
Repeater Access Button (RAB) (Conventional Only) – Allows to manually send a repeater access codeword.
Reprogram Request (T runking Only) – Notifies the dispatcher that you want a new dynamic regrouping assignment.
Request-To-Talk (Conventional Only) – Notifies the dispatcher that you want to send a voice call.
Scan – Toggles scan on or off. Secure/Clear – Toggles secure transmission on or off.
Identifying Radio Controls
Selective Call (Conventional Only) – Calls an assigned radio.
Site Display (Trunking Only) – Views the current site or
enable a site search for SmartZone operation. Site Lock/Unlock (Trunking Only) – T oggles between lock and
unlock mode when using the SmartZone option. Status Sends data calls to the dispatcher about a predefined
status. Talkaround/Direct (Conventional Only) Toggles between
using a repeater and communicating directly with another radio. Talkgroup (Conventional Only) – Allows a call from an
individual radio to a group of radios. Text Messaging Service (TMS) – Selects the text messaging
menu.
TMS Quick Text – Selects a predefined message. User – Automatically registers with the server.
Zone Down
radio.
Zone Select – Allows selection from a list of zones. Zone Up – Toggles upward through the zones in the radio.
Toggles downward through the zones in the
8
English

Assignable Settings or Utility Functions

Accessing the Preprogrammed Functions

Dim – Changes the display brightness. Front/Rear – Switches one of two control heads to be active at
one time.
Horns/Lights – Toggles horns and lights feature on or off. Low Power – Toggles transmit power level between high and
low. Voice Announcement – Audibly indicates the current feature
mode, Zone or Channel the user has just assigned. Voice Mute – Toggles voice mute on or off for the channels
which have enabled In-Call User Alert. When Voice Mute is active, the radio remains muted to all conventional dispatch calls and affiliated trunking group calls.
You can access various radio functions through one of the following ways:
A short or long press of the relevant programmable buttons.
OR
Use the Menu Select Button (g).

Using the Menu Select Buttons

The Menu Select Buttons allow to access the menu entries of features.
Note: Check with your dealer or system administrator for the
list of features activated in your radio.
Y our radio may be preprogrammed differently from the following example, but the steps for selecting a channel may appear as shown below:
Press the Menu Select button (g) directly below CHAN.
Identifying Radio Controls
Menu Select Button
9
English

Using the Advance Programmable Buttons

This feature is to help you to shorte n th e process of applying certain common features.
Orange Button*

Using the Navigation Buttons

Home Button
The H button returns you to the home (default) display. In most cases, this is the current mode.
Menu Select Button*
* These programmable buttons support the One Touch Button feature.
(Quick Access) One Touch Button Enters a menu wi th a short press on the preprogrammed One T ouch button. Features
Identifying Radio Controls
assigned to these buttons are Call, Call Alert, Phone, Repeater Access, MDC RTT Button Access, Status and Message.
10
English
Accy No-Dot Button (Purple)*
Accy 1-Dot Button*
Accy 2-Dot Button*
For selected radio features, the user-edited radio settings or information before returning you to the Home screen.
Note: Some features do not require you to press
the Home screen. Refer to the individual feature sections in this manual for further details on saving user-edited radio settings or information.
H button also can revert to home channel. Check with
The your dealer or system administrator for more information.
Data Feature Button
Use this button to access data-related features, such as the Text Messaging Service (TMS) feature screen.
H button is also used to save
H to go to
4-Way Navigation Button
Use this button to scroll up, down, left or right. Press and release one of the button to scroll from one entry to
the next one. Press and hold one of the button to have the radio toggles through the list automatically (release the button to stop).
Volume Knob
Use this Volume Knob to adjust the volume of the speakers by turning it clockwise or counterclockwise.
Mode Knob
Use this Mode Knob to scroll through the channels by turning it clockwise or counterclockwise.
Identifying Radio Controls
11
English

Using the Keypad

You can use the 3 x 4 alphanumeric keypad on the keypad microphone to access your radio’s features. The keypad functions in a manner similar to a standard telephone keypad when entering numeric digits. When the keypad is used to edit a list, each key can generate different characters of the alphabet. The tables below show the number of times a key needs to be pressed to generate the required character.

Keypad Characters – Uppercase Mo de

Number of Times Key is Pressed
Key123456789101112131415161718192021
1 2 3 4 5 6 7 8 9 0
Identifying Radio Controls
* #
1.,?!;@_-*#&$/+=\“‘() ABC DEF GH I
JKL MNO PQRS TUV8
WXY Z Toggle between mixed ca se mode, uppercase mode, and lowercase mode.
Space Toggle between numeric and letter mode.
12
English

Keypad Characters – Lowercase Mode

Number of Times Key is Pressed
Key123456789101112131415161718192021
Identifying Radio Controls
1 2 3 4 5 6 7 8 9 0 * #
1.,?!;@_-*#&$/+=\“‘() abc def ghi
jkl
mno
pqrs
tuv
wxyz
Toggle between mixed ca se mode, uppercase mode, and lowercase mode. Space
Toggle between numeric and letter mode.
13
English

Keypad Characters – Numeric Mode

Number of Times Key is Pressed
Key123456789101112131415161718192021
1 2 3 4 5 6 7 8 9 0 * #
1.,?!;@_-*#&$/+=\“‘() 2 3 4 5 6 7 8 9
0
Space Toggle between numeric and letter mode.
Identifying Radio Controls
14
English

Keypad Characters – Hexadecimal Mode

Number of Times Key is Pressed
Key123456789101112131415161718192021
Identifying Radio Controls
1 2 3 4 5 6 7 8 9 0 * #
1 2ABC 3DEF 4 5 6 7 8 9
0
Not applicable Not applicable
15
English

Push-To-Talk (PTT) Button

The PTT button on the side of the microphone serves two basic purposes:
PTT
Button
While a call is in progress, the
PTT button allows the radio to transmit to other radios in the call.
Press and hold down PTT button to talk. Release the PTT button to listen.
The microphone is activated when the PTT button is pressed.
While a call is not in progress, the PTT button is used to make
a new call. See Making a Radio Call on page 30 for more information.

Identifying Status Indicators

Identifying Status Indicators
Your radio indicates its operational status through the following:
Status Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 17
Text Messaging Service (TMS) Icons . . . . . . . . . . . . .page 19
Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 19
TMS Menu Options . . . . . . . . . . . . . . . . . . . . . . . . .page 20
LED Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 21
Intelligent Lighting Indicators . . . . . . . . . . . . . . . . . . . . page 22
Alert Tones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 23
16
English

Status Icons

The liquid crystal display (LCD) of your radio shows the radio status, text entries, and menu entries.
The following are the icons that appear on the radio’s display.
Receiving
u
t
Radio is receiving a call or data.
Transmitting
Radio is transmitting a call or data.
Direct
N
M
On = Radio is currently configured for direct
radio-to-radio communication (during conventional operation only).
Off = Radio is connected with other radios
through a repeater.
Monitor (Carrier Squelch)
Selected channel is being monitored (during conventional operation only).
In-Call User Alert
Identifying Status Indicators
F
V
Call Received
Radio has received an Individual Call.
Received Signal Strength Indicator (RSSI)
The number of bars displayed represents the received signal strength for the current site, for trunking only. The more stripes in the icon, the stronger the signal.
H
K
or .
i
On = The feature is enabled. Voice muting of
the affiliated trunking talkgroup or selected conventional channel is activated.
Off = The feature is disabled. Voice muting of
the affiliated trunking talkgroup or selected conventional channel is deactivated.
Power Level
L = Radio is set at Low power.
H = Radio is set at High power.
Scan
Radio is scanning a scan list.
17
English
j
k
m
Identifying Status Indicators
18
l
Priority Channel Scan
Blinking dot = Radio detects activity on
channel designated as Priority-One.
Steady dot = Radio detects activity on channel
designated as Priority-Two.
View/Program Mode
Radio is in the view or program mode.
On steady = View mode
Blinking = Program mode
Vot e Scan Enabled
The vote scan feature is enabled.
Secure Operation
On = Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice call.
AES Secure Operation
On = AES Secure operation.
Off = Clear operation.
Blinking = Receiving an encrypted voice call.
G
n
o
{
Location Signal
On = Location feature is enabled, and location
signal is available.
Off = Location feature is disabled.
Blinking = Location feature is enabled, but no
location signal is available.
User Login Indicator (IP Packet Data)
On = User is currently associated with the
radio.
Off = User is currently not associated with the
radio.
Blinking = Device registration or user
registration with the server failed due to an invalid username or pin.
Data Activity
Data activity is present.
Hexadecimal
Indicates that the text entry is currently in hexadecimal mode.
English

Text Messaging Service (TMS) Icons

This feature allows you to send and receive text messages. See Text Messaging Service (TMS) on page 63 for more information.

Status Icons

The following icons appear on the radio’s display for TMS features:
Inbox Full
,
[
The Inbox is full.
Message Sent
The text message is sent successfully.
]
3/6
I
P
Read Message
The selected text message in the Inbox has been read.
Message Index
Indicates the index of the current message the user is viewing.
Example: If the user is looking at the third message out of a total of 6 messages in the Inbox folder, the icon is displayed as the icon on the left column.
Priority Status
The “Priority” feature is toggled on before the
message is sent.
Messages in the Inbox folder are flagged with
“Priority”.
Identifying Status Indicators
Z
r
Message Unsent
The text message cannot be sent.
Unread Message
User receives a new message.
The selected text message in the Inbox has
not been read.
;
p
Request Reply
The “Request Reply” feature is toggled on
before the message is sent.
Messages in the Inbox folder are flagged with
“Request Reply”.
19
English
Priority Status and Request Reply

TMS Menu Options

q
2 1
3
}
Identifying Status Indicators
20
User is composing a message with a priority
status and a request for a reply.
Messages in the Inbox folder are flagged with
”Priority” and “Request Reply”.
Numeric
Indicates that the text entry is currently in numeric mode.
Mixed Case
Indicates that the text entry is currently in normal text mode.
Uppercase
Indicates that the text entry is currently in uppercase mode.
Lowercase
Indicates that the text entry is currently in lowercase mode.
Menu Option Description/Function
INBX
COMP Brings you to the compose screen.
DRFT Brings you to the saved message screen.
SENT Brings you to the sent messages screen.
BACK
EDIT
SAVE RPLY Replies to a message.
DEL NEW Creates a new message.
LIST
IMPT
RQRP
Brings you to your incoming messages screen.
Brings you back to the previous menu screen.
Edits a draft message or key in a target address.
Saves the messages you have edited to the Draft folder.
Deletes a message or a character text during editing mode.
Brings you to the predefined messages screen.
Toggles the “Priority Status” icon on or off for an outgoing message.
Toggles “Request Reply” icon on or off for an outgoing message.
English
Menu Option Description/Function
CURR Deletes the current selected message.
ALL
YES
NO Cancel the delete all messages options.
EXIT Exits to the Home screen.
OPTN Brings you to the Options main screen.
SEL Selects a predefined message or address.
SEND Sends the message.
Selects to delete all the messages in the current folder.
Deletes all the messages in the current folder.

LED Indicator

LED indicator shows the operational status of your radio.
Red LED
Yellow LED
Green LED
Solid red – Radio is transmitting.
Rapidly blinking red – Radio has failed the self test upon
powering up or encountered a fatal error.
Solid yellow – Channel is busy.
Blinking yellow – Radio is receiving a secured transmission.
Solid green – Radio is powering up, or is on a non-priority
channel while in the Scan List Programming mode.
Blinking green – Radio is receiving an individual or telephone
call, or is on a Priority-Two channel while in the Scan List
Programming mode.
Rapidly blinking green Radio is on a Priority-One channel
while in the Scan List Programming mode.
Identifying Status Indicators
21
English

Intelligent Lighting Indicators

This feature temporary changes the radio’s display backlight color and the alert text background color to help signal that a radio event has occurred.
Note: This feature must be preprogrammed by a qualified radio technician.
Backlight Event When
Orange Emergency Alerts
Red Critical Alerts
Green Call Alerts
The radio initiates an emergency alarm or call. The radio receives an emergency alarm or call. The radio is out of range. The radio enters failsoft mode. The radio is unable to establish a full connection with the system. The radio is unable to authenticate or register with the system. The radio receives a private call. The radio receives a phone call. The radio receives a call alert. The radio receives a selective call.
Identifying Status Indicators
22
English

Alert Tones

An alert tone is a sound or group of sounds. Your radio uses alert tones to inform you of your radio’s conditions. The following table lists these tones and when they occur.
You Hear Ton e Name Heard
Radio Self Test Fail When radio fails its power-up self test.
Reject When an unauthorized request is made.
Short,
Low-Pitched
Tone
Long,
Low-Pitched
Tone
A Group of
Low-Pitched
Tones
Time-Out Timer Warning Four seconds before time out.
No ACK Received When radio fails to receive an acknowledgment.
Individual Call Warning Tone
Time-Out Timer
Timed Out
Talk Prohibit/PTT Inhibit (When PTT button is pressed) transmissions are not allowed.
Out of Range (When PTT button is pressed) the radio is out of range of the system.
Invalid Mode When radio is on an unpreprogrammed channel.
Busy When system is busy.
When radio is in an individual call for greater than 6 seconds without any activity.
When the Time-Out Timer has expired.
Identifying Status Indicators
23
English
You Hear Ton e Name Heard
Short,
Medium-Pitched
Tone
Long,
Medium-Pitched
Tone
A Group of
Medium-Pitched
Tones
Identifying Status Indicators
Valid Key-Press When correct key is pressed.
Radio Self Test Pass When radio passes its power-up self test.
Clear Voice At beginning of a non-coded communication.
Priority Channel
Received
Emergency Alarm Entry When entering the emergency state.
Central Echo When central controller has received a request from a radio.
Volume Set When volume is changed on a quiet channel.
Emergency Exit When exiting the emergency state.
Failsoft When the trunking system fails.
Automatic Call Back When voice channel is available from previous request.
Talk Permit (When PTT button is pressed) verifying system accepting transmissions.
Keyfail When encryption key has been lost.
Console Acknowledge When status, emergency alarm, or reprogram request ACK is received.
Received Individual Call When Call Alert or Private Call is received.
Call Alert Sent When Call Alert is received by the target radio.
Site Trunking When a SmartZone trunking system fails.
When activity on a priority channel is received.
24
English
You Hear Ton e Name Heard
Fast Ringing When system is searching for target of Private Call.
Ringing
Gurgle Dynamic Regrouping (When the PTT button is pressed) a dynamic ID has been received.
Unique,
Low-Pitched
Chirp
Unique,
High-Pitched
Chirp
Enhanced Call Sent When waiting for target of Private Call to answer the call.
Phone Call Received When a land-to-mobile phone call is received.
New Message When a new message is received.
Priority Status When a priority message is received.
Identifying Status Indicators
25
English

General Radio Operation

Once you understand how your APX Mobile Radio is configured, you are ready to use your radio.
Use this navigation guide to familiarize yourself with the basic Call features:
Selecting a Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 26
Selecting a Radio Channel . . . . . . . . . . . . . . . . . . . . . page 27
Receiving and Responding to a Radio Call. . . . . . . . . page 27
Making a Radio Call . . . . . . . . . . . . . . . . . . . . . . . . . . page 30
Repeater or Direct Operation . . . . . . . . . . . . . . . . . . . page 33
Monitoring Features . . . . . . . . . . . . . . . . . . . . . . . . . . page 33
General Radio Operation

Selecting a Zone

A zone is a group of channels. Note: Y our radio must be preprogrammed to allow you to use
these features.
Procedure:
1 > or < to ZONE. 2 Press the Menu Select button directly below ZONE. The
display shows the current zone and channel.
3 > or < button until the desired zone is displayed. 4 Press H or the PTT button to confirm the selected zone
number.
5 Press the PTT button to begin transmitting on the displayed
zone channel.
26
English

Selecting a Radio Channel

Receiving and Responding to a Radio Call

A channel is a group of radio characteristics, such as transmit/ receive frequency pairs.
Use the following procedure to select a channel. Note: Y our radio must be preprogrammed to allow you to use
this feature. If you select a channel that is not within the preprogrammed band, the radio indicates that it is on an unsupported frequency with both audio and visual warnings.
Consult a qualified radio technician for the right choice between the following methods.
Procedure:
Rotate the Mode knob until the display shows the desired channel.
OR
1 Press and hold > to scroll to CHAN and press the Menu
Select button directly below CHAN. The display shows the
current zone and channel.
2 Rotate the Mode knob to the desired channel. 3 Press H or the PTT button to confirm the channel.
Press the PTT button to transmit on the displayed zone channel.
Once you have selected the required channel and/or zone, you
can proceed to receive and respond to calls.
Red LED
Yellow LED
Green LED
You see solid red while the radio is transmitting, and solid
yellow when the radio is receiving a transmission (conventional
mode only). There is no LED indication when the radio receives
a transmission in trunking mode.
If the radio is receiving a secure transmission, the LED blinks
yellow.
General Radio Operation
27
English


Receiving and Responding to a Talkgroup Call

To receive a call from a group of users, your radio must be configured as part of that talkgroup.
Procedure:
When you receive a talkgroup call (while on the Home screen), depending on how your radio is preprogrammed:
1 ASTRO Conventional Only:
The LED lights up solid yellow. The display shows the talkgroup alias or ID, and the caller alias or ID.
OR Trunking Only:
The display shows the caller alias or ID.
2 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
3 Press the PTT button to respond to the call. The LED ligh ts
up solid red.
4 Release the PTT button to listen.
See Making a T alkgrou p Call on page 30 for details on making a Talkgroup Call.
General Radio Operation
Receiving and Responding to a Private Call
(Trunking Only)
A Private Call is a call from an individual radio to another individual radio.
These one-to-one calls between two radios are not heard by others in the current talkgroup. The calling radio automatically verifies that the receiving radio is active on the system and can display the caller ID.
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon featu r e ex it.
Procedure:
When you receive a Private Call:
1 You hear two alert tones and the LED blinks green. The
display shows CALL RECEIVED and the caller alias or ID.
2 Press the Menu Select button directly below RESP within 20
seconds after the call indicators begin.
3 During the call, the display shows the caller alias (name), if it
is in the call list.
OR
During the call, the display shows the caller ID (number), if the caller’s name is not in the call list.
28
English
4 Press and hold the PTT button to talk. Release the PTT
button to listen.
5 Press H to hang up and return to the Home screen.

Receiving and Responding to a Telephone Call

This feature allows you to receive calls similar to standard
phone calls from a landline phone.
General Radio Operation
Note: If you press PTT button before pressing the Menu
Select button directly below RESP, your conversation
will be heard by all members of the talk group. If 20 seconds pass before you press the Menu Select
button directly below the RESP, you will not respond privately to the call just received. Instead, you initiate a Private Call.
See Making a Private Call (Trunking Only) on page 31 for details on making a Private Call.
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon featu r e ex it.
Procedure:
1 You hear a telephone-type ringing and the LED blinks green.
The backlight of the screen turns green. The display shows PHONE CALL and the call received icon blinks.
2 Press the Menu Select button directly below RESP.
3 Press and hold the PTT button to talk. Release the PTT
button to listen.
4 Press H or the Menu Select button directly below EXIT to
hang up and return to the Home screen.
See Making a Telephone Call on page 32 for details.
29
English

Making a Radio Call

You can select a zone, channel, subscriber ID, or talkgroup by using:
The preprogrammed Zone menu
The Mode Knob
A preprogrammed One Touch button
The Contacts list (see Contacts on page 43).
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon feature exit.

Making a Talkgroup Call

To make a call to a group of users, your radio must be configured as part of that talkgroup.
Procedure:
1 > or < to TGRP and press the Menu Select button directly
below TGRP. The display shows the last-selected talkgroup. Press the Menu Select button directly below SEL.
General Radio Operation
OR
Rotate the Mode Knob to select the channel with the desired talkgroup.
2 Hold the micro phone vertically 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
3 Press the PTT button to make the call. 4 ASTRO Conventional Only:
The LED lights up solid red. The display shows the talkgroup alias or ID.
OR Trunking Only:
The LED lights up solid red.
5 Speak clearly into the microphone. 6 Release the PTT button to listen.
30
English

Making a Private Call (Trunking Only)

This feature allows you to send an individual Call Alert or page if there is no answer from the target radio. Your radio must be preprogrammed to allow you to use this feature.
Procedure: Press the preprogrammed Quick Access (One-Touch) Enhanced Private Call button to dial the preprogrammed ID
and proceed to Step 5.
OR
Follow the procedure below.
1 > or < to CALL. 2 Press the Menu Select button directly below CALL. The
display shows the last transmitted or received.
3 Press the Menu Select button directly below CNTS to scroll
through and select the required ID. OR Press the Menu Select button directly below LIST to go to the first number of the call list.
OR
> or < to the required ID.
OR
Use the keypad to enter the required ID.
4 Press the PTT button to start the Private Call.
5 A telephone-type ringing sounds if the receiving unit is in
service. The display shows CALLING...<NUMBER> or CALLING...<ALIAS>.
6 Hold the micro phone vertically 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
7 When you are connected, the displa y shows the ID of the
target radio. Press and hold the PTT button to talk. Release the PTT button to listen.
OR
If no acknowledgment is received, the display shows NO ACKNOWLEDGE.
OR
If the target radio does not respond before the time out, the display shows NO ANSWER.
8 Press H to return to the Home screen.
See Sending a Call Alert Page on page 55 for more
information.
General Radio Operation
31
English

Making a Telephone Call

This feature allows you to make calls similar to standard phone calls to a mobile or landline phone.
Procedure: Press the preprogrammed Quick Access (One-Touch) Phone Call button to dial the preprogrammed phone number and
proceed to Step 5.
OR
Follow the procedure below.
1 > or < to PHON. 2 Press the Menu Select button directly below PHON. Th e
display shows the last transmitted phone number.
3 Press the Menu Select button directly below CNTS to scroll
through and select the required ID.
OR
Press the Menu Select button directly below LIST to go to the first number of the call list.
OR
> or < to the required phone number.
OR
Use the keypad to enter the required phone number.
4 Press and release the PTT button to dial the phone number.
General Radio Operation
5 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
6 When your call is answered, press the PTT button to talk. 7 Release the PTT button to listen. 8 Press H to return to the Home screen.
See Alert Tones on page 23 for more information if your call is NOT answered.
32
English

Repeater or Direct Operation

Monitoring Features

The REPEATER operation increases the radio’s range by connecting with other radios through a repeater. The transmit and receive frequencies are different.
The DIRECT or “talkaround operation” allows you to bypass the repeater and connect directly to another radio. The transmit and receive frequencies are the same.
Procedure: Press the preprogrammed Repeater/Direct switch to toggle between talkaround and repeater modes. OR Follow the procedure below.
1 > or < to DIR. 2 Press the Menu Select button directly below DIR. 3 The display shows REPEATER MODE if the radio is currently
in Repeater mode.
OR
The display shows DIRECT MODE and the T alkaround icon if the radio is currently in Direct mode (during conventional operation only).
You can repeat step 2 to toggle between the two modes. Once in Direct Mode, press PTT button to start conversation with the radios nearby.
Radio users who switch from analog to digital radios often
assume that the lack of static on a digital channel is an
indication that the radio is not working properly. This is not the
case.
Digital technology quiets the transmission by removing the
“noise” from the signal and allowing only the clear voice or data
information to be heard.
Monitor a channel to ensure the channel is clear before
transmitting.

Monitoring a Channel

Procedure:
Lift the microphone off hook.
Conventional Modes Only:
1 Listen for activity on that channel.
2 Adjust the Volume knob if necessary.
3 If you hear no activity, press and hold the PTT button to start
your conversation.
OR
General Radio Operation
33
English
Trunked Modes Only:
1 Press the PTT button. 2 If you hear two, short, high-pitched tones, or if you hear no
tone and the t indicator lights steadily, then proceed with your message.
3 Release the PTT button to receive (listen).
If you are not in the range of the system, you may hear a continuous low-pitched tone and the display shows
RANGE
.
OUT OF

Conventional Mode Operation

This feature allows you to monitor channel traffic on conventional channels by defeating the coded squelch. Thus you can to listen to another user active on the channel. This way, you may be prevented from talking over someone else’s conversation.
Note: This feature must first be enabled by a qualified radio
technician or system administrator.
Procedure:
Take the control head off hook. (This is the same as monitor on. You hear all channel traffic.)
OR
1 At Home mode where the default zone and channel are
being displayed, > or < button to MON.
2 Press the Menu Select button directly below MON
momentarily to activate monitoring. The display shows MONITOR ON.
3 Press the Menu Select button to deactivate the monitoring.
The display shows MONITOR OFF.
General Radio Operation
34
English
MONITOR ON
monitoring. Pressing the Menu Select button again turns monitor off and you don’t hear all channel traffic. If you try to transmit on a receive-only channel, you hear an invalid tone until you release the PTT button.
shown on the display indicates that the radio is

Advanced Features

Use this navigation guide to learn more about advanced features available with your radio:
Advanced Call Features . . . . . . . . . . . . . . . . . . . . . . . page 35
Multiple Control Head Features. . . . . . . . . . . . . . . . . . page 40
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 43
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 49
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 51
Call Alert Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 54
Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . . . page 56
Automatic Registration Service (ARS). . . . . . . . . . . . . page 60
Text Messaging Service (TMS) . . . . . . . . . . . . . . . . . . page 63
Secure Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . page 73
The Global Positioning System (GPS) . . . . . . . . . . . . page 78
Trunking System Controls. . . . . . . . . . . . . . . . . . . . . . page 86
Ignition Switch Options . . . . . . . . . . . . . . . . . . . . . . . . page 90
Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 92

Advanced Call Features

Calling a Phone Not in the List

1 > or < to PHON.
2 Press the Menu Select button directly below PHON.
3 Enter the desired phone number from the optional keypad
microphone. The display updates as the numbers are entered.
4 Press 3 button on the keypad microphone to make the call.
5 Press and hold the PTT button to talk. Release the PTT
button to listen.
6 Press H or Menu Select button directly below PHON to exit.
Advanced Features
35
English
Receiving and Making a Selective Call
(Conventional Only)
This feature allows yo u to receiv e a cal l from or to cal l a spec ific individual. It is intended to provide privacy and to eliminate the annoyance of having to listen to conversations that are of no interest to you.
Receiving a Selective Call
Procedure:
1 When you receive a Selective Call, you hear two alert tones
and the LED lights up solid yellow. The call received icons blink and the display alternates between CALL RECEIVED and the home display.
2 The sp eaker unmutes. 3 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
4 Press and hold the PTT button to talk. Release the PTT
button to listen.
Note: If you press PTT button before pressing the Menu
Select button directly below CALL, your conversation
will be heard by all members of the talk group.
Advanced Features
If 20 seconds pass before you press the Menu Select button
CALL
directly below the just received. Instead, you initiate a Selective Call. See Making a Selective Call on page 36.
Making a Selective Call
Procedure: Press the preprogrammed Quick Access (One-Touch) Selective Call button to dial the preprogrammed ID and
proceed to Step 4.
OR
Follow the procedure below.
, you will not respond privately to the call
1 > or < to CALL. 2 Press the Menu Select button directly below CALL. T he
display shows the last transmitted or received ID.
3 Press the Menu Select button directly below CNTS to scroll
through and select the required ID.
OR
Press the Menu Select button directly below LIST to go to the last number dialed.
OR
> or < to the required ID.
OR
Use the keypad to enter the required ID.
36
English
4 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
5 Press and hold the PTT button to start the Selective Call.
The display shows the ID of the target radio.
6 Release the PTT button to listen. 7 Press H to return to the Home screen.
If you do not press H button to hang up, your radio will remain in Selective Call state with the other unit. You will miss all subfleet traffic and incoming phone calls.
Using the Talkgroup Call Feature (Conventional
Operation Only)
This feature allows you to define a group of conventional system users so that they can share the use of a conventional channel.
Note: Encryption keys are associated to talkgroups. When
talkgroups are enabled, encryption keys are changed by changing the active talkgroup. See Secure Operations on page 73 for more information.
Selecting a Talkgroup
Procedure:
2 Press the Menu Select button directly below TGRP. The
display shows the last talkgroup that was selected and stored.
3 > or < to PSET for the preset preprogrammed talkgroup.
OR
> or < to the required talkgroup.
OR
Use the keypad to enter the number of the corresponding talkgroup in the list.
4 Press the Menu Select button directly below SEL to save
the currently selected talkgroup and return to the Home screen.
5 If the encryption key associated to the new talkgroup is
erased, a momentary key fail tone sounds and the display shows KEY FAIL.
OR
If the encryption key that is associated to the new talkgroup is not allowed, a momentary key fail tone sounds and the display shows ILLEGAL KEY.
6 Press H or the PTT button to exit.
Advanced Features
1 > or < to TGRP.
37
English

Sending a Status Call

This feature allows you to send data calls to the dispatcher about a predefined status.
Each status can have up to a 14-character name. A maximum of eight status conditions is possible.
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon feature exit.
Procedure: Press the preprogrammed Status button and proceed to Step 3. OR
Follow the procedure below.
1 > or < to STS. 2 Press the Menu Select button directly below STS. 3 The display shows the last acknowledged status call, or the
first status in the list.
4 > or < to the required status.
OR
Use the keypad to enter a number corresponding to the location in the status list.
Advanced Features
5 Press the PTT button to send the status. The display shows
PLEASE WAIT.
6 When the dispatcher acknowledges, four tones sound and
the display shows ACK RECEIVED. The radio returns to normal dispatch operation.
OR
If no acknowledgment is received, a low-pitched tone sounds and the display shows NO ACKNOWLEDGE.
7 Press H to return to the Home screen.
No traffic is heard on trunked channels while Status Calls is selected. If the radio detects no Status Call activity for six
seconds, an alert tone sounds until you press H or the PTT button.
Using the Dynamic Regrouping Feature (Trunking
Only)
This feature allows the dispatcher to temporarily reassign selected radios to a single special channel so they can communicate with each other. This feature is typically used during special operations and is enabled by a qualified radio technician.
You will not notice whether your radio has this feature enabled until a dynamic regrouping command is sent by the dispatcher.
Note: If you try to access a zone or channel that has been
reserved by the dispatcher as a dynamically regrouped mode for other users, an invalid tone sounds.
38
English
Procedure:
1 When your radio is dynamically regrouped, it automatically
switches to the dynamically regrouped channel. A “gurgle” tone sounds and the display shows the dynamically regrouped channel’s name.
2 Press the PTT button to talk. Release PTT button to listen.
the radio returns to the Home screen.
OR
If the dispatcher does not acknowledge the reprogram request within six seconds, a low-pitched alert tone sounds and the display shows NO ACKNOWLEDGE.
Try again or press screen.
H to cancel and return to the Home
Advanced Features
When the dispatcher cancels dynamic regrouping, the radio automatically returns to the zone and channel that you were using before the radio was dynamically regrouped.
Requesting a Reprogram
This feature lets you notify the dispatcher that you want a new dynamic regrouping assignment.
Procedure:
Press the preprogrammed Reprogram Request button to send reprogram request to the dispatcher and proceed to Step 3. OR Follow the procedure below.
1 > or < to RPGM. 2 Press the Menu Select button directly below RPGM to send
reprogram request to the dispatcher.
3 The display shows REPROGRAM RQST and PLEASE WAIT. 4 If you hear five beeps, the dispatcher has acknowledged the
reprogram request. The display shows ACK RECEIVED and
Classifying Regrouped Radios
The dispatcher can classify regrouped radios into either of two
categories: Select Enabled or Select Disabled.
Select-enabled radios are free to change to any available
channel, including the dynamic-regrouping channel, once the user has selected the dynamic-regrouping position.
Select-disabled radios cannot change channels while
dynamically regrouped. The dispatcher has forced the radio to remain on the dynamic-regrouping channel.
The Scan or Private Call feature cannot be selected while your
radio is Select Disabled.
English
39

Multiple Control Head Features

Multiple Control Head Features

This feature allows a transceiver to control as many as four O5 control heads on APX 7500 and, up to two O5 control heads on APX 6500. You can use the CAN cables to connect in any configuration that does not exceed 131 feet (40 meters) in combined length. Refer the O5 Control Head Installation Manual (HLN6947) for further information.
The Multiple Control Head (MCH) feature consists of 2 modes that can be programmed via Customer Programming Software (CPS):
All Active mode
One Active mode
Note: If two or more control heads are connected to the
system before enabling the MCH feature in the CPS, the radio will display EXTRA CH or CH ID # ERR. Both errors are FATAL.
Advanced Features
Setting the Initial Control Head’s ID
This feature allows you to setup the control head in the Front Panel Programming (FPP) mode. During the setup, the control
heads are defined as Control Head Number 1, Control Head Number 2, Control Head Number 3 and Control Head Number
4.
Procedure:
1 Press the Power button to power off the radio. 2 Press and hold the left-most Menu Select button and the
emergency button simultaneously.
3 While contin uing to depress these two buttons, press the
Power button to power on the radio and the control head.
4 The radio and the control head will power on into FPP
mode. The display shows control head’s ID number.
5 Turn the Mode knob to change the control head’s ID
number.
6 Press the Power button to power off the radio and exit FPP
mode.
7 Repeat steps 1 to 5 above to set the ID number for the rest
of the attached control heads.
40
English

All Active Mode

The All Active mode enables all connected control heads attached to the radio to operate concurrently with each other. When you activate a feature on one control head, the rest of the control heads will have the same activated features and indicators on their respective display.
Note: The multiple control head feature allows only control
heads of the same type to be connected. Upon power up, if a control head of a different type is connected to the radio, the radio reports the FATAL error CH MISMATCH on the display of all attached control heads.
Intercom Feature in All Active Mode
The intercom feature allows one control head user to talk to another control head user in a Multiple Control Head configuration. At any given time, when a control head being operated has priority for the intercom call, all other control heads are blocked until the active control head releases PTT button.
This can be made on any attached control head. This feature only applies to control heads in the All Active mode.
Procedure:
1 Press the Menu Select button directly below INTC to
activate the intercom feature of any of the control heads.
2 Press the PTT button to initiate an intercom transmission.
All control heads that are attached will receive the same intercom call.
3 The display of the control heads receiving the intercom call
shows the alias/ID number of the transmitting control head.
4 Press the Menu Select button directly below EXIT to
deactivate the intercom feature.
OR
Press H to deactivate the intercom feature.
The intercom feature also deactivates when user initiates a
mode change. If the radio is on an emergency channel,
pressing of the
footswitch button on any control head also deactivates the
intercom feature.

One Active Mode

The One Active mode enables only one control head to be
visibly active at a time in a two control head system.
Note: In the One Active mode, if more than two control heads
The active control head commands the system normally while
the inactive control head is in remote mode with its display
shows REMOTE.
EMERGENCY
are present upon power up, the radio shows a FATAL error EXTRA CH on the display of all attached control heads.
button or the emergency
Advanced Features
41
English
The Volume knob, DIM button, Front/Rear (F/R) softkey and Emergency button remain active on the inactive control head,
while all other controls are disabled. Emergency footswitch and VIP inputs remain active on the inactive control head. The VIP input control head is configurable in the CPS and VIP should be attached to the control head selected in the CPS.
Note: Only two (2) control heads are supported in the one
active mode.
Transceiver
Z1
CHAN
ZONE
PWR
SQL
Active Radio
REMOTE
F/R
Non-Active Radio
Follow the procedure below to change the command between the two control heads.
Procedure: Press the Menu Select button directly below F/R.
OR
Press the Menu Select button preprogrammed user button on the keypad microphone.
Advanced Features
42
English

Contact s

This feature provides “address-book” capabilities on your radio. Each entry corresponds to an alias (name) or ID (number) that you use to initiate a call.
Contact entries are alphabetically sorted according to entry alias. Each alias can have up to 5 IDs of different call types associated with it.
Additionally, each entry, depending on context (conventional, trunking, or phone), associates with one or more of the four types of calls: Phone Call, Selective Call, Private Call, or Call Alert.
Each entry within Contacts displays the following information:
Call Alias (Name)
Call ID (Number)
Call Type (Icon)
WACN ID (Astro 25 Trunking IDs only)
System ID
Note: Your radio must be preprogrammed to allow you to
add, edit, or delete the contact entries.
Your radio also supports a maximum of 50 call lists. Each list can store up to 100 IDs (numbers).
Note: Your radio is prepro grammed with a number of
contacts per Call Lists. Check with your dealer or system administrator for more information.
If the feature inactivity timer is enabled, your radio automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon featu r e ex it.

Making a Private Call from Contacts

Note: Y our radio must be preprogrammed to allow you to use
this feature.
Procedure:
Use the Options Menu.
1 > or < to CNTS.
2 Press the Menu Select button directly below CNTS to the
call list. The display shows Contact Alias.
3 > or < to the required subscriber alias.
4 Press the Menu Select button directly below OPTN.
5 > or < to CALL and press the Menu Select button directly
below SEL.
6 > or < to select the call type.
Advanced Features
43
English
7 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
6 Press the PTT button to initiate the call. Duri ng the call, the
display shows the subscriber alias.
8 Press the PTT button to initiate the call. During the call, the
display shows the subscriber alias.
9 Press and hold the PTT button to talk. The LED lights up
solid red.
OR
Release the PTT button to listen. The LED lights up solid green.
10If there is no voice activity for a programmed period of time,
the call ends.
OR
The call ends when it reaches the maximum ring time.
OR Use the PTT button:
1 > or < to CNTS. 2 Press the Menu Select button directly below CNTS. 3 > or < to the required subscriber alias. 4 Press the Menu Select button directly below CNTS. The
Advanced Features
display shows Contact Alias.
5 Hold the microphone vertica lly 1 to 2 inches (2.5 to 5.0 cm)
from your mouth.
7 Press and hold the PTT button to talk. The LED lights up
solid red.
OR
Release the PTT button to listen. The LED lights up solid yellow.
8 If there is no voice activity for a preprogrammed period of
time, the call ends. OR The call ends when it reaches the maximum ring time.
44
English

Adding a New Contact Entry

Procedure:
1 > or < to CNTS. 2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to {NEW CONTACT} and press the Menu Select
button directly below SEL.
4 The display shows NAME. Press the Menu Select button
directly below EDIT. Use the keypad to enter the name.
Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
5 Press the Menu Select button directly below OK once you
have entered the name.
OR
Press the Menu Select button directly below CNCL to return to the previous screen.
6 > or < to {ADD NUMBER} and press the Menu Select button
directly below SEL. The display shows TYPE 1 <DEFAULT TYPE>.
7 Press Menu Select button directly below EDIT.
8 > or < to the required channel and press the Menu Select
button directly below OK.
9 > or < to NUMBER 1 and press the Menu Select button
directly below EDIT. The display shows NUMBER 1 and a cursor appears. Use the keypad to enter the number.
Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button directly below DEL to delete
any unwanted characters.
10Press the Menu Select button directly below OK once you
have entered the number.
OR
Press the Menu Select button directly below CNCL to return to the previous screen.
11 Press the Menu Select button directly below DONE once
you have finished.
12The display shows <ENTRY> STORED, confirming that the
contact entry has been added.
Advanced Features
13The radio returns to the main Contacts screen.
45
English


Deleting a Contact Entry

Procedure:

Adding a Contact to a Call List or Phone List

Procedure:
1 > or < to CNTS. 2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to the entry you want to delete and press the Menu
Select button directly below OPTN.
4 > or < to DELETE and press the Menu Select button directly
below SEL. The display shows <ENTRY> CONFIRM DEL?.
5 Select YES to delete the entry.
The display shows <ENTRY> DELETED and the radio returns to the main screen for Contacts.
OR
Select NO to return to the main screen for Contacts.
Advanced Features
1 > or < to CNTS. 2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to the entry you want to add to the call list and press
the Menu Select button directly below OPTN.
4 > or < to ADD TO CALLLST or ADD TO PHONLST and
press the Menu Select button directly below SEL.
5 > or < until the display shows {AVAILABLE} and press the
Menu Select button directly below ADD to add as a new
entry.
OR
> or < until the display shows <ENTRY> and its associated
number and press the Menu Select button directly below RPLC to replace the existing entry.
6 The display shows <ENTRY> ADDED, confirming the
addition of the contact to the list.
7 The radio returns to the main display for Contacts.
46
English

Editing a Contact in a Call List or a Phone List

Editing an Entry Alias
Procedure:
1 > or < to CNTS.
7 Press the Menu Select button directly below OK once you
have finished. The display returns to the Edit Contact screen.
8 Press the Menu Select button directly below DONE to save
your changes and return to the main screen for Contacts.
Advanced Features
2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to the entry you want to edit and press the Menu
Select button directly below OPTN.
4 > or < to EDIT and press the Menu Select button directly
below SEL.
5 > or < to the entry alias you wish to change and press the
Menu Select button directly below EDIT.
6 A cursor appears.
Use the keypad to edit the name. Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
Editing as Entry ID
Procedure:
1 > or < to CNTS.
2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to the entry you want to edit and press the Menu
Select button directly below OPTN.
4 > or < to EDIT and press the Menu Select button directly
below SEL.
5 > or < to the entry ID you wish to change and press the
Menu Select button directly below EDIT.
6 A cursor appears.
Use the keypad to edit the number. Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters.
English
47
Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
7 Press the Menu Select button directly below OK once you
have finished. The display returns to the Edit Contact screen.
8 Press the Menu Select button directly below DONE to save
your changes and return to the main screen for Contacts.
Editing a Call Type
Procedure:
1 > or < to CNTS. 2 Press the Menu Select button directly below CNTS. The
entries are alphabetically sorted.
3 > or < to the entry you want to edit and press the Menu
Select button directly below OPTN.
4 > or < to EDIT and press the Menu Select button directly
below SEL.
5 > or < to TYPE and press the Menu Select button directly
below EDIT.
6 > or < to choose from the list of call types given and press
the Menu Select button directly below OK to select.
7 The display re turns to the Edit Contact screen. 8 Press the Menu Select button directly below DONE to save
your changes and return to the main screen for Contacts.
Advanced Features
48
English

Scan Lists

Scan lists are created and assigned to individual channels/ groups. Your rad io scans for voice activity by cycling through the channel/group sequence specified in the scan list for the current channel/group.
Your radio supports different types of Scan Lists:
• Trunking Priority Monitor Scan List
• Conventional Scan List
• Talkgroup Scan List A maximum of 200 Scan Lists can be programmed in your
radio. These lists must be preprogrammed by a qualified radio technician.

Viewing a Scan List

Procedure:
1 > or < to SCNL. 2 Press the Menu Select button directly below SCNL. 3 > or < to view the members on the list. 4 Press the H to exit the current display and return to the
Home screen.

Editing the Scan List

This feature lets you change scan list members and priorities.
Procedure:
1 > or < to SCNL.
2 Press the Menu Select button directly below SCNL. The
display shows the lists that can be changed.
3 > or < to the entry you want to edit.
4 Press the Menu Select button directly below SEL to add
and/or change the priority of the currently displayed channel in the scan list.
OR
Press the Menu Select button directly below DEL to delete the currently displayed channel from the scan list.
OR
Press the Menu Select button directly below RCL to view the next member of the scan list.
5 > or < to select more channels to be added or dele ted.
OR
Use the keypad to go directly to additional channels to be added or deleted.
OR
Use the Mode Knob to select additional channels to be added or deleted.
Advanced Features
49
English
6 Press H to exit scan list programming and return to the
Home screen.
5 Press H to exit scan list programming and return to the
Home screen.
See V iewing and Changing the Priority Status on page 50 for more information on how to add and/or change the priority of the currently displayed channel in the scan list.

Changing the Scan List Status

Procedure:
1 Long press the preprogrammed Scan side button. 2 > or < to the member yo u want to edit. 3 Press the 3 button or press the Menu Select button
directly below SEL once to add the currently displayed channel to the scan list.
OR
Press the directly below SEL, one or more times to change the scan
list status icon of the currently displayed channel.
3 button or press the Menu Select button
4 > or < to select more list members whose scan status you
want to change.
OR
Use the keypad to go directly to that scan list member.
Advanced Features
OR Use the Mode Knob to select another scan list member.
50

Viewing and Changing the Priority Status

Procedure:
1 Below the SEL, DEL, and RCL screen, press the Menu
Select button directly below SEL to view and/or change the
priority status of the currently displayed channel. OR
Below the SEL, DEL, and RCL screen, press the press the Menu Select button directly below SEL, one or
more times to view and/or change the scan list status icon of the currently displayed channel.
3 button or
2 A Scan icon indicates that the current channel is in the scan
list as a non-priority channel. The LED lights up solid green.
OR
A Priority-Two Channel Scan icon indicates that the current channel is in the scan list as the Priority-Two channel. The LED blinks green.
OR
A Priority-One Channel Scan icon indicates that the current channel is in the scan list as the Priority-One channel. The LED rapidly blinks green. You hear all traffic on the Priority­One channel, regardless of traffic on non-priority channels.
OR
No icon indicates that the current channel is deleted from the scan list.
English

Scan

This feature allows you to monito r traffic on different channels by scanning a preprogrammed list of channels.

Turning Scan On or Off

Procedure: Press the preprogrammed Scan button. OR
Follow the procedure below.
1 > or < to SCAN. 2 Press the Menu Select button directly below SCAN. 3 The display shows SCAN OFF if scan is disabled. Press the
Menu Select button directly below SCAN to enable scan. OR
The display shows SCAN ON and the scan status icon if scan is enabled. Press the Menu Select button directly below SCAN to disable scan.
Turning Scan On While Disregarding the Squelch
Code (Conventional Channels Only)
Procedure:
1 > or < to MON.
2 Press the Menu Select button directly below MON.
3 The brief MONITOR ON display indicates that the radio is
disregarding the squelch code.
While scanning for activity, you can still receive fleetwide,
system-wide, dynamic regrouping, incoming telephone
interconnect and Private Conversation/Call Alert calls.
Respond to these types of calls as you would normally on the
selected channel. However, when scanning different channels
while in talkgroup scan, incoming Private Conversation/Call
Alert calls may be missed.

Transmitting While the Scan is On

Advanced Features
4 The radio returns to the Home screen.
Radio Programmed for Talkback Scan
Procedure:
1 Press the PTT button to transmit on the channel indica ted
by the display.
English
51
The radio does not begin scanning again for a predetermined hang time after you release the PTT button, allowing the other party to respond. If the other party responds within the hang time, scanning does not resume until the full hang time expires after they have finished speaking, allowing the conversation to be completed.
T o transmit on the selected channel if another channel is active, first turn scan off by pressing the Menu Select button below
SCAN
momentarily.
Radio Programmed for Non-Talkback Scan
Procedure:
1 Press the PTT button at any time to transmit on the selected
channel or fixed channel.
To make a Call Alert page, or Private Conversation call while scanning, press either the Menu Select button directly below
PAGE
or
CALL
. The call is entered on the selected channel and scanning is halted until the call is exited by pressing pressing the Menu Select button below either
PAGE
Advanced Features
H
or
or
CALL

Deleting a Nuisance Channel

If a channel continually generates unwanted calls or noise (termed a “nuisance” channel), you can temporarily remove the unwanted channel from the scan list.
This capability does not apply to priority channels or the designated transmit channel.
Procedure:
1 When the radio is locked onto the channel to be deleted,
> or < to NUIS.
2 Press the Menu Select button directly below NUIS.

Restoring a Nuisance Channel

Procedure:
To restore the deleted nuisan ce channel, do one of the following:
.
Turn scan off, then on.
OR
Change modes.
OR
Turn off the radio, and then turn it back on.
Nuisance mode delete can be disabled by the system administrator.
52
English


Changing Priorities Status While Scan is On

While the radio is scanning, the dynamic priority change feature allows you to temporarily change any channel in a scan list (except for the Priority-One channel) to the Priority-Two channel.
This change remains in effect until scan is turned off. Scan then reverts to the preprogrammed (original) setting.
Procedure:
1 Press the Menu Select button directly below DYNP to
change the priority of a non-priority channel in the scan list to Priority-Two.
2 Press H momentarily to exit the scan list and resume
scanning.

Restoring Priorities in a Scan List

Procedure:
To restore the original channel priorities in a scan list, do one of the following:
Turn scan off, then on.
OR
Change channels.
OR
Turn off the radio, and then turn it back on.

Hang Up (HUB)

To temporarily suspend Scan Mode operation, remove the control head from the Hang Up Box (HUB). You are allowed to use the control head while scan is suspended. However, Priority Member scanning is not suspended. This feature applies to all Scan Lists and Scan Types. Scan is resumed once the control head is returned to the holding clip and the preprogrammed hang time has elapsed.
Note: Priority Scan List members are continuously scanned
only when the Scan List, Designated Tx Member field is set to “Talkback” in the radio programming. Otherwise, all scan mode operation is suspended.
Advanced Features
53
English

Call Alert Paging

This feature allows your radio to w ork l ike a pager . Even if other users are away from their radios, or if they are
unable to hear their radios, you can send them an individual Call Alert page. You can also verify if a radio is active on the system.
Depending on how your radio is programmed, when you make an Enhanced Private Call, the radio either automatically sends a Call Alert page if there is no answer after the maximum ring time, OR when you press the PTT button.
Note: This feature must be preprogrammed by a qualified
radio technician.
Advanced Features

Receiving a Call Alert Page

Procedure:
When you receive a Call Alert page
1 You hear four repeating alert tone and the green LED blinks.
OR
You hear one alert tone and the green LED blinks if Call Alert Tone Auto Reset is enabled.
2 The call receiv ed icons blinks and the display shows PAGE
RECEIVED.
3 Press the PTT button to answer.
OR
Press any button to clear the Call Alert page.
See Making a Ta lkgroup Ca ll on p age 30 or Making a Private Call (Trunking Only) on page 31 for more information.
54
English

Sending a Call Alert Page

Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon feature exit.
Procedure: Press the preprogrammed Quick Access (One-Touch) Call
Alert Paging button to send a page to the preprogrammed ID
and proceed to Step 5 of the procedure below. OR Follow the procedure below.
1 > or < to PAGE. 2 Press the Menu Select button directly below PAGE. 3 > or < to select the required ID. 4 Press the PTT button to send the page. 5 The display shows PAGING...<NUMBER> or <ALIAS>. 6 If the call alert page is sent successfully, four highpitch tone
sounds and the display shows ACK RECEIVED.
OR
If the call alert page is not acknowledged, a low tone sounds and the display shows NO ACKNOWLEDGE.
7 The radio returns to the Home screen.
OR
Press the Menu Select button directly below OK to return to the main screen for Contacts.
Advanced Features
OR
Follow the procedure below.
1 > or < to CALL. 2 Press the Menu Select button directly below CALL. 3 > or < to select the required ID, press the PTT button to
initiate the call.
4 If the target radio does not respond after a preprogrammed
period of time, the display shows SEND PAGE?.
5 Press the Menu Select button directly below YES to send
the call alert page.
OR
Press the Menu Select button directly below NO to exit the screen without sending the call alert page.
6 The display shows PAGING...<ALIAS>. 7 If the call alert page is sent succe s sfully, a tone sounds and
the display shows ACK RECEIVED.
OR
If the call alert page is not acknowledged, a low tone sounds and the display shows NO ACKNOWLEDGE.
8 The radio returns to the Home scre en.
OR
55
English
Press the Menu Select button directly below OK to return to the main screen for Contacts.

In-Call User Alert

You can enable and disable voice transmission, if needed.
Procedure:
1 Make sure you are in Home mode where the default zone
and mode are being displayed.
2 > or < to scroll to the VMUT. 3 Press the Menu Select button directly below VMUT. 4 Press the Menu Select button directly below VMUT or the
VMut preprogrammed button again to turn the feature off and you will be able to hear to normal dispatch calls.
Pressing the Menu Select button directly below VMut programmed button momentarily toggles between Voice mute on and Voice mute off. display indicates that the radio is muted to all conventional dispatch calls and affiliated trunking group calls.
VOICE MUTE ON
VMUT
shown on the
Advanced Features
or the

Emergency Operation

The Emergency feature is used to indicate a critical situation. If the Orange button is preprogrammed to send an emergency
signal, this signal overrides any other communication over the selected channel.
Your radio supports 5 Emergency modes:
Emergency Call
Emergency Alarm
Emergency Alarm with Call
Silent Emergency Alarm
Special Considerations for Emergencies
Check with your dealer or system administrator for more information on the programming of this feature.
Only one of the Emergency modes above can be assigned to the preprogrammed Emergency button or the Emergency footswitch.
Note: To exit emergency at any time, press and hold the
preprogrammed Emergency button for about a second.
56
English


Sending an Emergency Alarm

This feature allows you to send a data transmission, which identifies the radio sending the emergency, to the dispatcher.
Procedure:
1 Press the preprogrammed Emergency button. A tone
sounds and the display alternates EMERGENCY and the home display.
2 A dispatcher acknowledgment ACK RECEIVED display
follows.
AND, Trunking Only:
A high-pitched tone indicates that the alarm has been received by the trunked system’s central controller.
3 Press and hold the emergency button or the PTT button to
return to normal operation.

Sending an Emergency Call (Trunking Only)

Procedure:
1 Press preprogrammed Emergency button. 2 A tone sounds and the display alternates EMERGENCY and
the home display.
OR
A short low-pitched tone sounds when the selected channel does not support emergency.
3 Hold the micro phone vertically 1 to 2 inches (2.0 to 2.5 cm)
from your mouth.
4 Press and hold the PTT button. Speak clearly into the
microphone.
5 Release the PTT to end the transmission. 6 Press and hold the preprogrammed Emergency button until
a tone sounds to exit Emergency mode.
Sending an Emergency Alarm with Emergency
Call
This feature allows you to send an Emergency Alarm to another radio. Upon acknowledgement, both radios can communicate over a preprogrammed Emergency channel.
If the radio has both emergency call and alarm features enabled, it automatically proceeds to the call mode after the alarm is acknowledged.
57
Advanced Features
English
Procedure:
1 Press the preprogrammed Emergency button to activate
the emergency call/alarm feature.
2 The display alternates EMERGENCY and the home display. 3 A high-pitched tone sounds, indica ting that the alarm has
been received by the trunked system’s central controller. A dispatcher acknowledgment (four high-pitched tones) follows, accompanied by an ACK RECEIVED display.
4 Hold the microphone vertica lly 1 to 2 inches (2.0 to 2.5 cm)
from your mouth.
5 Press and hold the PTT button. Speak clearly into the
microphone.
6 Release the PTT to end the transmission. 7 Press and hold the preprogrammed Emergency button until
a tone sounds to exit Emergency mode.
Turning the radio off also cancels the emergency state.

Sending a Silent Emergency Alarm

This feature allows you to send an Emergency Alarm to another radio without any audio or visual indicator.
Upon acknowledgement, your radio’s microphone is automatically activated, allowing you to communicate with the other radio without pressing the PTT button.
This activated microphone state is also known as “hot mic”. Note: If you press the PTT button during hot mic, and
continue to press it after the hot mic duration expires, the radio continues to transmit until you release the PTT button.
Procedure:
1 Press the preprogrammed Emergency button to activate
the silent alarm feature.
2 Press and hold the emergency button until a tone sounds to
exit the silent alarm mode.
If silent emergency alarm is used with emergency call, pressing the PTT button exits the silent mode and initiates the emergency call.
Advanced Features
58
English

Special Considerations for Emergencies

If you press the emergency button while in a channel that has
no emergency capability, a low-pitched tone sounds.
If the unit is out of the range of the system and/or the
emergency alarm is not acknowledged, a tone sounds and the display shows NO ACKNOWLEDGE.
If you press the emergency button, then change to a mode
that has no emergency capability, the display shows NO EMERGENCY and a continuous low-pitched tone sounds until
a valid emergency mode is selected or until the emergency is cancelled.
When an emergency is active, changing to another mode
where emergency is enabled (trunked or conventional) causes an emergency alarm and/or emergency call to be active on the new mode.
Advanced Features
59
English
Advanced Features

Automatic Registration Service (ARS)

This feature provides an automated data application registration for the radio. When you turn on the radio, the device automatically registers with the server.
Data applications within the fixed network can determine the presence of a device on the system and send data to the device. For example: Text Messaging Service (TMS).
The Automatic Registration Service for the radio consists of two (2) modes:
ARS Server Mode (default mode)
ARS Non Server Mode
Note: The default ARS mode can be changed by a qualified
radio technician using the radio’s programming software.

Selecting or Changing ARS Mode

Procedure:
1 After the zone you want is displayed, toggle until the display
shows the required channel.
OR
Press and hold > or < to CHAN. Press the Menu Select button directly below CHAN.
The display shows the current zone is not blinking, and the channel is blinking.
2 > or < or rotate the Mode Knob to the required channel. 3 In ARS Server Mode, the display shows the User Login
Indicator icon, the zone, and ARS server channel.
OR
In ARS Non-Server Mode, the display shows the User Login Indicator icon, the zone, and ARS non-server channel.
OR
If the channel or mode selected is unprogrammed, the display shows UNPROGRAMMED. Repeat Step 2.
4 Press H to confirm the displayed zone and channel.
Advanced Features
60
English


Accessing the User Login Feature

This feature allows you as the user to be associated with the radio. With this association, every data application (Example: Text Messaging Service) takes on a friendly username.
You can still send text messages without logging in as a user. The user login feature only enables the recipient of your message to identify you as the sender by assigning a username to your message.
Note: Valid characters for a username entry are capital
letters (A – Z), small letters (a – z), numbers (0 – 9), symbols (*, #, -, /), and the space character.
Logging In as a User
Procedure:
1 > or < to USER. 2 Press the Menu Select button directly below USER. 3 The display shows the User Login screen. 4 Press the Menu Select button directly below ID.
5 A blinking cursor appears besid e ID. Use the keypad to
enter a username using the keypad multi-tap function.
OR
> or < to scroll through the list of predefined usernames.
The maximum length for a username is eight (8) characters. Usernames are not case sensitive in server mode but are case sensitive in non-server mode.
A predefined username may sometimes be invalid because the programming software that is used to set predefined usernames allows you to set usernames comprising of eight (8) characters or more.
Press the Menu Select button to select a predefined username.
OR
Press and hold usernames at a fast scroll rate.
Press the Menu Select button directly below LOGN to select a predefined username.
> or < to scroll through the list of predefined
6 If the selected predefined username has more than eight (8)
characters, or an invalid character in it, the display momentary shows INVALID ID. Repeat Step 5.
OR Press the Menu Select button directly below PIN.
Advanced Features
7 A blinking cursor appears besid e PIN.
Enter your Personal Identification Number (PIN) number.
61
English
The maximum PIN length is 4 digits. The PIN number will appear as asterisks.
8 Press the Menu Select button directly below LOGN. 9 In ARS server mode, the display shows the User Login
Indicator icon, the ID, IN PPROGRESS and CNCL.
OR
In ARS non-server mode, the display shows the User Login Indicator icon, the ID, LOGGED IN and LOGT. In non-ARS enabled mode, the display shows OFFLINE and LOGT.
10If the username is invalid, login fails and the user login
failure indicator (IP indicator) icon blinks. The display also momentary shows
OR
If the PIN is invalid, login fails and the user login failure indicator (IP indicator) icon blinks. The display also momentary shows LOGIN FAILED. Repeat Step 7.
OR
Press the Menu Select button directly below CNCL to cancel the login in progress screen and return to the initial user login screen.
OR
Wait for the logged in confirmation screen. If the login process is successful, the display shows the successful user
Advanced Features
login indicator (IP indicator) icon and LOGGED IN and LOGT.
LOGIN FAILED. Repeat step 5.
Logging Out
Once the data application registration is completed, you can log out.
Procedure:
1 > or < to LOGT. 2 Press the Menu Select button directly below LOGT. 3 Display shows the User Login Indicator icon and CLEAR
PRIVATE DATA?.
4 Select YES to clear all your private data. The display shows
momentary PRIVATE DATA CLEARED.
OR
Select NO to keep your private data.
Note: Private data refers to all messages in the text
messaging Inbox, Draft and Sent folder. The next radio user will be able to access your Inbox, Draft and Sent messages if private data is not deleted.
62
English

Text Messaging Service (TMS)

Accessing TMS Feature

This feature allows you to send and receive text messages. The maximum length of characters for a text message is 200.
There are three (3) types of text messages:
A new text message (free form message)
A predefined message (quick text message)
An edited quick text message
The main menu consists of the following options:
Inbox
Compose
Drafts
Sent
Note: See Status Icons on page 19 for more details on the
TMS icons and TMS Menu Options on page 20 for more details on each menu option.
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon fea ture exit.
Press the Menu Select button directly below BACK at any time to return to the previous screen.
Procedure:
Press the preprogrammed Data Feature button or the TMS button to access the TMS feature screen.
OR Press and hold the preprogrammed Data Feature button or the TMS button to access the Inbox screen. OR
Follow the procedure below.
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 > or < to scroll through the main menu opti ons.
Advanced Features
63
English

Composing and Sending a New Text Message

Note: During the uppercase and lowercase mode, multi-
tapping the keys only scrolls through the letters. For example, A->B->C, a->b->c.
During the num lock mode, except for 1, pressing the keypad only enters the numeric digits. Subsequent presses of the same key inserts the same digit to the text message (no multi-tap).
Procedure:
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 Press the Menu Select button directly below COMP to see
the compose options.
4 Press the Menu Select button directly below NEW to
compose a new message.
5 A blinking cursor appears on the Compose screen.
Use the keypad to type or edit your message. Press
< to move one space to the left. > to move one space to the right.
Advanced Features
Press Press the Menu Select button directly below DEL to delete
any unwanted characters. Press * to add a space.
64
Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
6 Press the Menu Select button directly below OPTN once the
message is composed.
7 > or < to SEND and press the Menu Select button directly
below SEND to send.
OR
> or < to BACK and press the Menu Select button directly
below BACK to return to Compose screen if you want to edit the message.
8 > or < to scroll through the address list and press the Menu
Select button below SEL to select the required address. OR
> or < to {OTHER RECPNT} and press the Menu Select
button below EDIT. A blinking cursor appears in the ENTER ADDRESS screen. Use the keypad to type the address entry.
< to move one space to the left.
Press
> to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
English
9 Press the Menu Select button below SEND to send the
message.
OR Press the PTT button to send the message.
10The display shows the SEND MESSAGE screen and
SENDING MSG.
11 If the message is sent, a tone sounds and the display shows
MSG SENT.
OR
If the message is not sent, a low tone sounds and the display shows SEND FAILED.

Sending a Quick Text Message

Quick Text messages are messages that are predefined and usually consist of messages that are used most frequently.
Each Quick Text message has a maximum length of 50 characters.
Procedure:
Press the preprogrammed Quick Text button and proceed to Step 3.
OR
Follow the procedure below.
Advanced Features
If the message fails to send, the radio returns you to the main TMS screen.
Note: Y ou can append a priority status and/or a request reply
to your message. See Using the Priority Status and Request Reply Features on page 67 for more information.
Note: You can also select the DRFT option to save your
message in the Drafts folder to send it at a later time. See Accessing the Drafts Folder on page 71 for more details.
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 Press the Menu Select button directly below COMP to
access the compose options.
4 > or < to LIST. 5 > or < to scroll through the list of messages and press the
Menu Select button directly below SEL to select the required
message.
6 The message appears on the Compose screen, with a
blinking cursor at the end of it. Use the keypad to edit the message.
Press
< to move one space to the left.
English
65
Press > to move one space to the right. Press the Menu Select button directly below DEL to delete
any unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
7 Press the Menu Select button directly below OPTN. 8 > or < to SEND and press the Menu Select butto n directly
below SEL to send the message.
9 > or < to scroll through the address list and highlight the
required address.
OR
> or < to {OTHER RECPNT} and press the Menu Select
button below EDIT. A blinking cursor appears in the ENTER ADDRESS screen. Use the keypad to type the address entry.
Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space.
Advanced Features
Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
10Press the Menu Select button below SEND to send the
message.
OR Press the PTT button to send the message.
11 The display shows the screen and SENDING MSG. 12If the message is sent, a tone sounds and the display shows
MSG SENT.
OR
If the message is not sent, a low tone sounds and the display shows SEND FAILED.
If the message fails to send, the radio returns you to the main TMS screen.
Note: Y ou can append a priority status and/or a request reply
to your message. See Using the Priority Status and Request Reply Features on page 67 for more information.
66
English
Using the Priority Status and Request Reply
Features
Before sending your message, you can append a priority message and/or a request reply to your message.
Appending or Removing a Priority Status to a Text
Message
Note: The Priority Message icon on a message does not
imply that the message gets higher priority over the other messages when it is being transmitted. It is just an indication that can be embedded into a message to let the receiver know that the message is important.
Procedure:
After the outgoing message is composed (see Composing and Sending a New Text Message on page 64 for more
information):
1 Press the Menu Select button directly below OPTN. 2 Press the Menu Select button directly below IMPT.
The priority status icon appears beside the normal message icon on the label bar.
3 Press the Menu Select button directly below IMPT again.
The priority status icon and the normal message icon disappear from the label bar.
Appending or Removing a Request Reply to a Text
Message
Procedure:
After the outgoing message is composed (see Composing and Sending a New Text Message on page 64 for more
information):
1 Press the Menu Select button directly below OPTN. 2 Press the Menu Select button directly below RQRP.
The reply status icon appears beside the normal message icon on the label bar.
3 Press the Menu Select button directly below RQRP again.
The reply status icon and the normal message icon disappear from the label bar.
Appending a Priority Status and a Reply Request to a
Text Message
Procedure:
After the outgoing message is composed (see Composing and Sending a New Text Message on page 64 for more
information):
1 Press the Menu Select button directly below OPTN. 2 > or < to IMPT and press the Menu Select button directly
below IMPT to indicate the message as important.
AND
Advanced Features
67
English
> or < to RQRP and press the Menu Select button directly
below RQRP to request for a reply.
3 The priority status and reply status icons appear besi de the
normal message icon on the label bar.
Removing a Priority Status and a Reply Request from a Text Message
When an outgoing message is indicated with priority status and reply status icons, follow the procedure below to remove these indicators.
Procedure:
1 Press the Menu Select button directly below OPTN. 2 > or < to IMPT and press the Menu Select button directly
below IMPT to remove the priority status icon.
AND
> or < to RQRP and press the Menu Select button directly
below RQRP to remove the reply status icon.
3 The priority status, reply status and normal message icons
disappear from the label bar.
Advanced Features

Managing Text Messages

Receiving a Text Message
Note: When you receive a message that is flagged with the
”Request Reply” icon, you must manually respond to the sender that you have received the message. The system will not automatically send back a notification that the radio has received such message.
Procedure:
When you receive a message, press and hold the preprogrammed Data Feature button or the TMS Feature button to access the Inbox and go to Step3.
OR
Follow the procedure below.
1 The new message icon appears and the display
momentarily shows NEW MSG.
2 Press the Menu Select button directly below TMS to access
the message.
3 The display sh ows alias or ID with the sender of the latest
received message on top.
68
English
Viewing a Text Message from the Inbox
The Inbox can hold up to thirty (30) messages. Note: > or < to read the message if fills more than one
screen.
Procedure: Press the preprogrammed Data Feature button or the TMS Feature button to access the TMS feature screen, and proceed
to Step 3.
OR Press and hold the preprogrammed Data Feature button or the TMS Feature button to access the Inbox screen and proceed to
Step 4.
OR
Follow the procedure below.
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 Press the Menu Select button below INBX to view Inbox
feature screen.
4 The display shows alias or IDs, with the sender of the latest
received message.
Select
Select
Select
Note: The icon at the top right corner of the screen indicates
RPLY
to reply the message.
DEL
to delete the message.
BACK
to return to the previous screen.
the status of the message. See Text Messaging Service (TMS) on page 63 for more information.
Advanced Features
While on the review message screen, press the Menu Select button directly below
RPLY, DEL
, or
BACK
to access the option.
69
English
Replying to a Received Text Message
Note: The original date and time stamp, address and
message content is automatically appended to the reply message.
Procedure:
1 > or < to the required aliases or ID and press the Menu
Select button below SEL to view the message.
2 Press the Menu Select button directly below RPLY to reply
to a message.
3 > or < to NEW and press the Menu Select button directly
below NEW.
OR
> or < to LIST and press the Menu Select button directly
below LIST for a predefined message.
OR
> or < to scroll through the list of messages and press the
Menu Select button directly below SEL to select the required message.
4 A blinking cursor appears on the screen.
OR
The predefined message appears on the Compose screen,
Advanced Features
with a blinking cursor at the end of it.
5 Use the keypad to type or edit your message.
Press
< to move one space to the left.
70
Press > to move one space to the right. Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
6 Press the Menu Select button directly below OPTN once
you have finished writing the message.
7 > or < to SEND and press the Menu Select button directly
below SEND to send the message.
8 The display shows the Send Message screen and
SENDING MSG.
Press the Menu Select button directly below to return to the previous screen.
Note: You can append a priority message and/or a request
reply to your message. Using the Priority Status and Request Reply Features on page 67 for more information.
BACK
at any time
English

Accessing the Drafts Folder

Managing Sent Text Messages

This folder stores the messages that were saved previously. The Drafts folder can hold up to 10 messages. The oldest draft in the folder is deleted when the 11th message comes in.
Procedure:
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 > or < to DRFT and press the Menu Select button below
DRFT.
4 The display shows the first draft message.
Press the Menu Select button directly below
BACK
to access the option.
Select
Select
Select
EDIT
to edit the message before sending it.
DEL
to delete the message.
BACK
to return to the previous screen.
EDIT, DEL
, or
Once a message is sent to another radio, it is saved in the Sent folder. The most recent sent text message is always added to the top of the Sent list.
The Sent folder is capable of storing a maximum of ten (10) last sent messages. When the folder is full, the oldest text message in the folder is deleted when the 11th message comes in.
Viewing a Sent Text Message
The icon at the top right corner of the screen indicates the status of the message. See Text Messaging Service (TMS) on page 63 for more information.
Procedure: Press the preprogrammed Data Feature button or the TMS
Feature button to access the TMS feature screen, and proceed
to Step 3.
OR
Follow the procedure below.
1 > or < to TMS. 2 Press the Menu Select button directly below TMS to access
the TMS feature screen.
3 > or < to SENT and press the Menu Select button below
SENT.
Advanced Features
71
English
Press the Menu Select button directly below
BACK
to access the option.
Select
Select
Select
Note: The icon at the top right corner of the screen indicates
Procedure:
OPTN
to send to the message.
DEL
to delete the message.
BACK
to return to the previous screen.
the status of the message. See Text Messaging Service (TMS) Icons on page 19 for more information.
Sending a Sent Text Message
OPTN, DEL
1 Press the Menu Select button directly below OPTN while
viewing the message.
2 > or < to SEND and press the Menu Select butto n directly
below SEND to send the message.
3 > or < to scroll through the address list and highlight the
required address.
OR
> or < to {OTHER RECPNT} and press the Menu Select
button below EDIT.
Advanced Features
A blinking cursor appears in the ENTER ADDRESS screen. Use the keypad to type the address entry.
Press
< to move one space to the left.
, or
Press
> to move one space to the right.
Press the Menu Select button below DEL to delete any unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
4 Press the Menu Select button below SEND or the PTT
button to send the message.
5 The display shows the Send Message screen and
SENDING MSG.
6 Press the Menu Select button directly below BACK to return
to the previous screen.
Note: You can append a priority message and/or a request
reply to your message. See Using the Priority Status and Request Reply Features on page 67 for more details.
72
English
Deleting Text Messages

Secure Operations

Procedure:
From the Inbox, Draft, or Sent screen:
1 > or < to scroll through the messages. 2 Press the Menu Select button directly below DEL to view the
delete options.
3 Press the Menu Select button directly below CURR to delete
the current message.
OR
Press the Menu Select button directly below ALL to delete all the messages.
Secure radio operation provides the highest commercially available level of voice security on both trunked and conventional channels.
Unlike other forms of security, Motorola digital encryption provides signaling that makes it virtually impossible for others to decode any part of an encrypted message.

Managing Encryption

Note: Refer to the Key-Variable Loader (KVL) manual for
equipment connections and setup.
Loading a Single Encryption Key
Procedure:
1 Attach the KVL to your radio. Upon attaching the KVL, the
radio display shows KEYLOADING.
2 Press the Menu Select button below TARGET. 3 Press the Menu Select button below LOAD. 4 Press the Menu Select button below KEY.
5 > or < to required key. 6 Press the Menu Select button below LOAD to load the key
to your radio.
Advanced Features
73
English
7 When the key has been loaded successfully, the radio
sounds a short tone for single-key radios.
Loading the Group Encryption Keys
Procedure:
1 Attach the KVL to your radio. 2 Press the Menu Select button below TARGET. 3 Press the Menu Select button below LOAD. 4 Press the Menu Select button below GROUP.
5 > or < to required group. 6 Press the Menu Select button below LOAD to load the key
to your radio.
7 Your mobile radio display shows KEYLOADING when it is
loading key(s) from KVL.
8 When the key has been loaded successfully, the radio
sounds an alternating tone for multikey radios.
Advanced Features
Using the Multikey Feature
This feature allows the radio to be equipped with different encryption keys and supports the DES-OFB algorithm.
There are two types of multikey:
Conventional Multikey – The encryption keys can be tied
(strapped), on a one-per-channel basis, through Customer Programming Software. In addition, you can have operator­selectable keys, operator-selectable keysets, and operator­selectable key erasure. If talkgroups are enabled in conventional, then the encryption keys are strapped to the talkgroups.
Trunked Multikey – If you use your radio for both
conventional and trunked applications, you have to strap your encryption keys for trunking on a per-talkgroup or announcement-group basis. In addition, you may strap a different key to other features, such as dynamic regrouping, failsoft, or emergency talkgroup. You can have operator­selectable key erasure.
74
English

Selecting an Encryption Key (Conventional Only)
Enabling Secure Transmission
Procedure:
1 > or < to KEY. 2 Press the Menu Select button directly below KEY. The
display shows the last user-selected and stored encryption key, and the available menu selections.
3 > or < to scroll through the encryption keys.
OR
Use the keypad to enter the number of the desired key.
4 Press the Menu Select button directly below SEL to save the
newly selected key and return to the Home screen.
OR
H, the PTT button, or the Menu Select button directly
Press below EXIT to exit.
Note: If the selected key is erased, a momentary keyfail tone
sounds and the display shows KEY FAIL.
OR
If the selected key is not allowed, a momentary illegal key tone sounds and the display shows ILLEGAL KEY.
Procedure:
1 > or < to SEC and press the Menu Select button directly
below SEC. The display shows multi-key has been enabled.
m and the current key if
2 Monitor the mode to be sure it is not in use. 3 Press PTT button to transmit.
Note: If the selected channel is preprogrammed for clear-
only operation – when you press the PTT button, an invalid mode tone sounds and the display shows CLEAR TX only.
The radio does not transmit until you disable the secure mode.
Accessing the Secure Feature
Procedure:
1 > or < to SEC. 2 Press and hold the Menu Select button directly below SEC
to display Secure feature screen.
3 The display shows the Secure screen.
Advanced Features
75
English
Selecting a Keyset
This feature allows you to select one or more groups of several encryption keys from among the available keys stored in the radio.
For example, you could have a group of three keys structured to one keyset, and another group of three different keys structured to another keyset; by changing keysets, you would automatically switch from one set of keys to the other.
5 The radio exits keyset selection and returns to the Home
screen.
Erasing the Selected Encryption Keys
This feature allows you to erase all or selected encryption keys.
Procedure:
1 > or < to ERAS.
Every channel to which one of the original keys was tied now has the equivalent new key instead.
Note: Press H, the PTT button, or the EXIT menu selection
to exit this menu at any time without changing the keyset selection.
Procedure:
1 > or < to KSET. 2 Press the Menu Select button directly below KSET.
The display shows the last user-selected and stored keyset, and the available keyset menu selections.
3 > or < to scroll through the keysets.
OR
Advanced Features
Use the keypad to enter the number of the desired keyset.
4 Press the Menu Select button directly below SEL to save the
newly selected keyset.
76
English
2 Press the Menu Select button directly below ERAS. The
display shows the last user-selected and stored encryption key, and the available menu selections.
3 > or < to the desired encryption key.
OR
Use the keypad to enter the number of the desired key.
4 Press the Menu Select button directly below ALL to delete
all keys.
OR
Press the Menu Select button directly below SNGL to delete current shown key.
OR
Press the Menu Select button directly below ABRT to abort this screen and return to Home screen.

Requesting an Over-the-Air Rekey
MDC Over-the-Air Rekeying (OTAR) Page
This feature, also known as OTAR, allows the dispatcher to reprogram the encryption keys in the radio remotely. The dispatcher performs the rekey operation upon receiving a rekey request from the user.
Procedure:
1 > or < to REKY. 2 Press the Menu Select button directly below REKY. 3 Press the PTT button to send the rekey request.
OR
Press the PTT button again, or the H or Emergency button, to exit the feature and transmit in normal mode.
4 If the rekey operation fails, a bad-key tone sounds and the
display shows REKEY FAIL.
Note: The rekey operation failure indicates that your radio
does not contain the Unique Shadow Key (USK). This key must be loaded into the radio with the key-variable loader (KVL) before the rekey request can be sent.
Refer to your local key management supervisor for more information.
This feature allows to view or define MDC Over-the-Air Rekeying (OTAR) features.It is applied only when operating in secure encrypted mode and only for conventional communications. In additional to Rekey Requests, OTAR transmissions include Delayed Acknowledgements, and Power­up Acknowledgements.
Some of the options selected may also need to be set up at the Key Management Controller (KMC) site to work properly.
Note: This feature must be preprogrammed by a qualified
radio technician. Check with your dealer or system administrator for more information.
Advanced Features
77
English
Hear Clear

The Global Positioning System (GPS)

There are two components of Hear Clear.
1 Companding:
Reduces the channel noise, e.g. OTA transmission, that is predominantly present in UHF2 and 900 MHz channel with the following features.
Compressor – reduces the background noise flow and the
speech signal at transmitting radio.
Expander – expands the speech while the noise flow
remains the same at receiving radio.
2 Random FM Noise Canceller (Flutter Fighter):
Reduces the unwanted effects of random FM noise pulses caused by channel fading under high Signal-to-Noise (S/N) conditions such as in a moving in a transportation. The fading effects, heard as audio pops and clicks, are cancelled without affecting the desired audio signal.
The Random FM Noise Canceller operates only in receive mode.
Note: This feature must be preprogrammed by a qualified
radio technician. Check with your dealer or system administrator for more information.
Advanced Features
This feature uses information from the Global Positioning System (GPS) satellites orbiting the Earth to determine the approximate geographical location of your radio, expressed as latitude and longitude. The availability and accuracy of this location information (and the amount of time that it takes to calculate it) varies depending on the environment in which you are using the GPS feature.
For example, GPS location fixes are very difficult to obtain indoors, in covered locations, between high buildings, or in situations where you have not established a clear broad view of the sky.

Understanding the GPS Feature

The GPS technology uses radio signals from earth orbiting satellites, to establish the location co-ordinates, maximizing your view of clear unobstructed sky is essential for optimum performance.
Where adequate signals from multiple satellites are not available (usually because you cannot establish a view of a wide area of the sky), the GPS feature of your radio will not work. Such situations include but are not limited to:
In underground locations
Inside of buildings, trains, or other covered vehicles
78
English
Under any other metal or concret e ro of or structure
Between tall buildings or under dense tree-cover
In temperature extremes outside the operating limits of your
radio
Even where location information can be calculated in such situations, it may take longer to do so, and your location estimate may not be as accurate. Therefore, in any emergency situation, always report your location to your dispatcher.
Note: Even where adequate signals from multiple satellites
are available, your GPS feature only provides an approximate location, usually within 20 meters from your actual location, but sometimes further away.
Keep in mind that the accuracy of the location information and the time it takes to obtain it varies depending upon circumstances, particularly the ability to receive signals from an adequate number of satellites.
Note: The satellites used by the GPS feature are controlled
by the U.S. government and are subject to changes implemented in accordance with the Department of Defense GPS user policy and the Federal Radio Navigation Plan. These changes may affect the performance of the GPS feature on your radio.

Enhancing GPS Performance

Sometimes, the GPS feature may be unable to complete a location calculation successfully. You then see a message indicating that your radio cannot connect to enough visible satellites.
To maximize the ability of your radio to determine a fix, please note the following guidelines:
For your initial fix, hold the radio in the face position.
Stay in th e open . The GPS feature works best where there is
nothing between your radio and a large amount of open sky.

The Outdoor Location Feature (Using GPS)

This feature allows you to determine your cu rrent locati on using a location menu, as well as your current distance and bearing in relation to another location. Radio location may be requested and reported over-the-air.
Your radio stores up to a maximum of sixty (60) programmable location coordinates, also known as waypoints. When the memory is full, the next waypoints automatically replaces the oldest waypoints in the radio.
Advanced Features
79
English
The radio also stores four (4) preprogrammed waypoints. These coordinates cannot be deleted.
Programmable Waypoints Preprogrammed Waypoints
Fixed location coordinates:
Home
User-configurable location
coordinates.
Emergency
Last Known Location
Destination
Only the alias is editable, not
the coordinates.
Coordinates can be deleted one at a time, or all at once.
Note: If the feature inactivity timer is enabled, your radio
automatically exits the feature when your radio is left idle long enough for the time to expire. You will hear the Menu Inactive Exit Tone upon feature exit.
The Home and Destination coordinates are editable.
Coordinates cannot be deleted.
Advanced Features
Accessing the Outdoor Location Feature
Note: An ON menu key may be present on the location menu
if it is preprogrammed by the dealer or system administrator.
Procedure:
1 > or < to LOC. 2 Press the Menu Select button directly below LOC. The
display shows LOCATION OFF <LATITUDE>.
3 Press the Menu Select button directly below ON to turn on
the GPS. The display shows PREVIOUS LOC <LATITUDE>.
4 > or < to check the longitude, time and date of the last
successful location fix.
5 Press the Menu Select button directly below RFSH to obtain
a new location fix.
6 The top line temporarily displays PLEASE WAIT while the
new location is being determined. While the new location is being determined, the location signal can be a solid or blinking icon.
7 Once the location coordinates are fixed, the display shows
the current latitude. Toggle to see the longitude, time and date. The location coordinates are updated automatically every five seconds while the location signal is present.
80
English
8 Press the Menu Select button directly below EXIT to exit
the feature and return to the main screen.
OR
H or the PTT button (if preprogrammed) to exit this
Press menu.
OR
Follow the procedure below to turn off the GPS (This feature is enabled by a qualified radio technician.):
1 > or < to LOC. 2 Press the Menu Select button directly below LOC. The
display shows PREVIOUS LOC <LATITUDE>.
3 > or < to check the longitude, time and date of the last
successful location fix.
4 Press the Menu Select button directly below OPTN.
The radio also exits the menu if the emergency button is pressed.
Saving a Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to SAVE AS WAYPT and press the Menu Select
button directly below SEL.
OR
> or < to SAVE AS HOME and press the Menu Select
button directly below SEL and proceed to Step 5.
OR
> or < to SAVE AS DEST. and press the Menu Select
button directly below SEL and proceed to Step 5.
Advanced Features
5 > or < to TURN OFF GPS (if preprogrammed). 6 Press the Menu Select button directly below SEL to turn off
the GPS. The display shows LOCATION OFF.
7 Press the Menu Select button directly below EXIT to exit
the feature and return to the main screen.
OR
H or the PTT button (if preprogrammed) to exit this
Press menu.
3 A blinking cursor appears in the screen. Use the keypad to
type the alias via multi-tap. Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
English
81
4 Press the Menu Select button directly below OK once you
are done.
5 The display shows SAVED AS <WAYPOINT NAME>.
OR
The display shows SAVED AS HOME.
OR
The display shows SAVED AS DEST..
6 Press H or the PTT button (if preprogrammed) to exit this
menu.
Viewing a Saved Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to WAYPOINTS. 3 Press the Menu Select button directly below SEL. 4 > or < to desired waypoint. 5 Press the Menu Select button directly below OPTN. The
display shows VIEW.
6 Press the Menu Select button directly below SEL.
Advanced Features
7 > or < again to view longitude, time and date the waypoint
was detected.
82
8 Press the Menu Select button directly below BACK to return
to previous Waypoint screen.
OR
H or the PTT button (if preprogrammed) to exit this
Press menu.
English
Editing the Alias of a Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to WAYPOINTS. 3 Press the Menu Select button directly below SEL. 4 > or < to desired waypoints. 5 Press the Menu Select button directly below OPTN. 6 > or < to EDIT NAME and press the Menu Select button
directly below SEL.
7 A blinking cursor appears in the Edit Name screen.
Use the keypad to edit the alias. Press
< to move one space to the left. > to move one space to the right.
Press Press the Menu Select button below DEL to delete any
unwanted characters. Press * to add a space. Press 0 to toggle between mixed case mode, uppercase mode, and lowercase mode. Press # to toggle between numeric and letter mode.
8 Press the Menu Select button directly below OK once you
are done. OR
Press the Menu Select button directly below CNCL to return to the Waypoints main screen.
9 The display shows <WAYPOINT NAME> UPDATED. 10Press H or the PTT button (if preprogrammed) to exit this
menu.
Editing the Coordinates of a Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to WAYPOINTS and press the Menu Select button
directly below SEL.
3 > or < to desired waypoints. 4 Press the Menu Select button directly below OPTN. 5 > or < to EDIT LOCATION and press the Menu Select
button directly below SEL.
6 The first number blinks.
Press
< to move to the previous number/coordinates. > to move to the next number/coordinates.
Press
U or D to change the North (N), South (S), East (E)
Press or West (W) direction.
Advanced Features
83
English
Press the Menu Select button below EDIT to change the number/coordinates.
7 A blinking cursor appears in the EDIT LOCATION screen.
< to move one space to the left.
Press
> to move one space to the right.
Press Press the Menu Select button below Del to delete any
unwanted characters.
8 Press the Menu Select button directly below OK once you
are done.
OR
Press the Menu Select button directly below CNCL to return to the previous screen.
9 Press the Menu Select button directly below OK once you
are done with the new coordinates.
OR
Press the Menu Select button directly below CNCL to return to the previous screen then skip to step 11.
10The display shows {HOME} UPDATED and the radio returns
to the Waypoints main screen.
OR
The display shows {DESTINATION} UPDATED and the radio returns to the Waypoints main screen.
11 Press H or the PTT button (if preprogrammed) to exit this
Advanced Features
menu.
Deleting a Single Saved Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to WAYPOINTS. 3 Press the Menu Select button directly below SEL. 4 > or < to desired waypoints. 5 Press the Menu Select button directly below OPTN.
OR
Press the Menu Select button directly below DEL and then skip to step 7.
6 > or < to DELETE and press the Menu Select button directly
below SEL.
7 The display shows <WAYPOINT NAME> CONFIRM DEL?. 8 Press the Menu Select button directly below YES to delete.
The display shows <WAYPOINT NAME> DELETED.
OR
Press the Menu Select button directly below NO to return to previous Waypoint screen.
9 Press H or the PTT button (if preprogrammed) to exit this
menu.
84
English

Deleting All Saved Waypoints
Procedure:
1 Press the Menu Select button directly below OPTN. 2 > or < to WAYPOINTS and press the Menu Select button
directly below SEL.
3 > or < to desired waypoints and press the Menu Select
button directly below OPTN.
4 > or < to DELETE ALL and press th e Menu Select button
directly below SEL.
5 The display shows ALL SAVED WAYP CONFIRM DEL?. 6 Press the Menu Select button directly below YES to delete.
The display shows ALL SAVED WAYP DELETED.
OR
Press the Menu Select button directly below NO to return to previous Waypoint screen.
Measuring the Distance and Bearing from a Saved Waypoint
Procedure:
While in the current location display:
1 Press the Menu Select button directly below OPTN. 2 > or < to DIST FRM HERE and press the Menu Select button
directly below SEL.
3 > or < to the required waypoint, and press the Menu Select
button directly below SEL.
4 The display shows the distance and bearing from the current
to the selected coordinates.
5 Press the Menu Select button directly below BACK to return
to the previous Waypoint screen.
OR
Press
H or the PTT button (if preprogrammed) to exit this
menu.
7 Press H or the PTT button (if preprogrammed) to exit this
menu.
Advanced Features
85
English
Using the Location Feature While in Emergency Mode
When the Emergency feature is activated by pressing the emergency button, the radio exits the Location menu and returns to the home (default) display so that you can see which channel the emergency signal is going out on.
However, you may re-enter the Location menu while still in emergency mode, provided that Silent Emergency has not been activated.
If you have turned Location off using the ON/OFF menu key, it automatically turns back on when Emergency is activated.
If there is a solid location signal during Emergency, the current location and the location information received is saved as Emergency and Last Known Location waypoints, respectively.
Advanced Features

Trunking System Controls

Using the Failsoft System

The failsoft system ensures continuous radio communications during a trunked system failure. If a trunking system fails completely, the radio goes into failsoft operation and automatically switches to its failsoft channel.
The failsoft condition is indicated by a faint beeping tone every nine seconds (radio unsquelched) until the trunking system returns to normal operation.
To continue, in Failsoft, to communicate with other talkgroups, refer to the following procedure.
Procedure:
1 Rotate the Mode Knob to change to a different repeater
frequency.
2 Press the PTT button to talk, and release the button to
listen.
When the trunking system returns to normal operation, your radio automatically leaves failsoft operation and returns to trunked operation.
86
English
Loading...
