DIGITAL WIRELESS
TELEPHONE
User's Guide >
Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola Model 66 wireless phone.
Headset Jack
Insert headset accessory for hands-free use.
Status Light
See incoming call and service status.
Left Soft Key
Perform functions identified by left display prompt.
Volume Keys
Adjust earpiece and ringer volume.
Smart Key
Select menu items, send and end calls.
End Key
End phone calls, exit menu system.
Power Key
Earpiece
Accessory Connector Port
Insert charger and phone accessories.
Display
Menu Key
Right Soft Key
Perform functions identified by right display prompt.
Voice Key
Record voice notes, phonebook and shortcut names.
Send Key
Send and answer calls, view recent dialed calls list.
4-Way Navigation Keys
Scroll through menus and lists, set feature values.
Microphone
1
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada)
www.motorola.com (United States) www.motorola.ca (Canada)
MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. TrueSync, Sidekick, Starfish and the Stylized Starfish Logo are registered trademarks of Starfish Software, Inc., a wholly owned independent subsidiary of Motorola, Inc. All other product or service names are the property of their respective owners.
© 2001 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
Manual number: 6809435A60-B
Cover number: 8988485L49-O
2
Main Menu
•Recent Calls
•Received Calls
•Dialed Calls
•Notepad
•Call Times
•Call Cost
•Service Dial
•Fixed Dial
•Phonebook
•Datebook
•Quick Dial
•Radio
•Messages
•Voicemail
•Text Msgs
•Browser Alerts
•Info Services
•Quick Notes
•Outbox
•Drafts
•Shortcuts
•Voice Notes
•SIM Applications
•Browser
•Calculator
•Games
•Settings
(see next page)
Note: This is the standard phone menu layout. You or your service provider may have changed the menu layout or changed some feature names. Not all features may be available for all users.
For example, the Radio feature on the main menu (left) is displayed only when the optional FM Stereo Radio Headset accessory is plugged into the accessory connector port on your phone (see phone illustration, page 1).
Shortcuts
Change display zoom:
Press M, then press and hold M
Display my phone number:
Press M#
Go to dialed calls list:
Press N
Exit menu system:
Press O
3
Settings Menu
•Ring/Vibrate
•Alert
•Alert Detail
•My Tones
•Call Forward
•Voice Calls
•Fax Calls
•Data Calls
•Cancel All
•Forward Status
•Phone Status
•My Tel. Numbers
•Credit Info/Available
•Active Line
•Battery Meter
•Other Information
•Browser Setup
•In-Call Setup
•In-Call Timer
•Call Cost Setup
•My Caller ID
•Talk and Fax
•Answer Options
•Call Waiting
•Security
•Phone Lock
•Lock Application
•Fixed Dial
•Call Barring
•SIM Pin
•New Passwords
•Other Settings
•Personalize
•Main Menu
•Keys
•Greeting
•Quick Dial
•Initial Setup
•Time and Date
•1-Touch Dial
•Auto Redial
•Backlight
•Status Light
•Zoom
•Scroll
•Animation
•Language
•Battery Save
•Contrast Setting
•DTMF
•Master Reset
•Master Clear
•Network
•Car Settings
•Headset
4
Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Safety and General Information. . . . . . . . . . . . . . . . . . . 12
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
22 |
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . . |
23 |
Sending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
24 |
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
25 |
Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . |
25 |
About Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Changing the Zoom Setting . . . . . . . . . . . . . . . . . . . . . . . 29
Status Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4-Way Navigation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sending and Receiving Calls. . . . . . . . . . . . . . . . . . . . . . 34
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . . 36
Dialing an Emergency Number . . . . . . . . . . . . . . . . . . . . . 36
Entering Numbers in the Notepad . . . . . . . . . . . . . . . . . . 37
5
Contents
Muting the Ring or Vibrate Alert . . . . . . . . . . . . . . . . . . . . |
37 |
Terminating an Incoming Call . . . . . . . . . . . . . . . . . . . . . |
38 |
Dialing With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . |
38 |
Dialing With 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . |
39 |
Dialing a Number In a Text Message . . . . . . . . . . . . . . . . |
39 |
Additional Dialing Features . . . . . . . . . . . . . . . . . . . . . . . |
40 |
Using Features While On a Call . . . . . . . . . . . . . . . . . . . 43 Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Making a Conference Call . . . . . . . . . . . . . . . . . . . . . . . . 44 Transferring a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Additional On-Call Features . . . . . . . . . . . . . . . . . . . . . . . 46
Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . . . . . 49 Entering Feature Information . . . . . . . . . . . . . . . . . . . . . . 50 Entering Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Predictive Text Entry with iTAP™ Software . . . . . . . . . . . . 57 Menu Feature Descriptions. . . . . . . . . . . . . . . . . . . . . . . 62 Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Viewing the Received Calls or Dialed Calls List . . . . . . . . . 78 Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Viewing and Resetting Call Timers . . . . . . . . . . . . . . . . . . 82 Viewing and Resetting Call Costs . . . . . . . . . . . . . . . . . . . 83
Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
86 |
Fields in a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . |
86 |
Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . |
87 |
6
Contents
Recording a Voice Name For a Phonebook Entry . . . . . . . |
. 90 |
Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . |
91 |
Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . |
92 |
Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . |
93 |
Copying Phonebook Entries Between the Phone and SIM Card |
|
93 |
|
Checking Phonebook Capacity . . . . . . . . . . . . . . . . . . . . . |
96 |
Synchronizing with TrueSync Software . . . . . . . . . . . . . . . |
97 |
Setting Up the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . |
97 |
Datebook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
99 |
Week View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
99 |
Day View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
100 |
Event View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
100 |
Storing a New Event . . . . . . . . . . . . . . . . . . . . . . . . . . . |
101 |
Changing Event Information . . . . . . . . . . . . . . . . . . . . . |
102 |
Copying an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
103 |
Deleting an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
104 |
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
105 |
Turning the Radio On and Off . . . . . . . . . . . . . . . . . . . . |
105 |
Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
105 |
Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
106 |
Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
106 |
Sending and Receiving Calls With the Radio On . . . . . . . |
106 |
Messages—Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . |
108 |
Storing Your Voicemail Number . . . . . . . . . . . . . . . . . . . |
108 |
Receiving a New Voicemail Message . . . . . . . . . . . . . . . |
108 |
Listening to a Voicemail Message . . . . . . . . . . . . . . . . . . |
109 |
Messages—Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Setting Up the Text Message Inbox . . . . . . . . . . . . . . . . . 110
7
Contents
Receiving a Text Message . . . . . . . . . . . . . . . . . . . . . . . |
112 |
Reading, Locking, or Deleting a Text Message . . . . . . . . |
113 |
Sending a Text Message . . . . . . . . . . . . . . . . . . . . . . . . |
115 |
Viewing the Status of Sent Text Messages . . . . . . . . . . . |
117 |
Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Standard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
User-Settable Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . 118
Creating a Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Using Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Voice Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
122 |
Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . |
122 |
Viewing the Voice Notes List . . . . . . . . . . . . . . . . . . . . . |
123 |
Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . . |
124 |
Locking and Unlocking a Voice Note . . . . . . . . . . . . . . . |
126 |
Deleting a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . |
127 |
Micro-Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Starting a Micro-Browser Session . . . . . . . . . . . . . . . . . . 128
Interacting With Web Pages . . . . . . . . . . . . . . . . . . . . . . 129
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Calculating Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Converting Currency . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Selecting and Starting a New Game . . . . . . . . . . . . . . . . 133
Ending a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Playing a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Adjusting Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . 138
Ring/Vibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
8
Contents
Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . 148
Customizing a Soft Key Function . . . . . . . . . . . . . . . . . . 148
Hands-Free Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Data and Fax Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
152 |
Connecting Your Phone to an External Device . . . . . . . . . |
152 |
Sending a Data or Fax Call . . . . . . . . . . . . . . . . . . . . . . . |
154 |
Receiving a Data or Fax Call . . . . . . . . . . . . . . . . . . . . . . |
155 |
Sending a Talk Then Fax Call . . . . . . . . . . . . . . . . . . . . . |
156 |
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Assigning a New Code or Password . . . . . . . . . . . . . . . . 157
If You Forget a Code or Password . . . . . . . . . . . . . . . . . . 158
Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . 159
Barring Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Protecting the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . 161
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Specific Absorption Rate Data . . . . . . . . . . . . . . . . . . . 174
Additional Health and Safety Information . . . . . . . . . 177
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Export Law Assurances . . . . . . . . . . . . . . . . . . . . . . . . . 194
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Wireless Phone Safety Tips . . . . . . . . . . . . . . . . . . . . . . 209
9
AboutThis Guide
UsingYour Phone’s Features
This user guide introduces you to the many features in your Motorola wireless phone. A reference guide for your phone is also available that explains the phone’s features in more detail. To obtain a copy of the reference guide or another copy of this user guide, see the Motorola Web site at:
http://motorola.com/consumer/manuals (United States) http://www.motorola.ca/manuals (Canada)
or contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.
NavigatingTo a Menu Feature
You can access many of your phone’s features through the menu system. This guide shows you how to navigate to a specific menu feature as follows:
Find the Feature |
M > Recent Calls |
|
> Dialed Calls |
The > symbol means that you should scroll to and select the feature. This example shows that you must press M, scroll to and select Recent Calls, then scroll to and select Dialed Calls to view the dialed calls list.
10
About This Guide
Optional Features
Features marked with this label are optional network, SIM card, and/or subscription-dependent features. These features may not be offered by all service providers in all geographical areas. Contact your service provider for information about availability.
Optional Accessories
Features marked with this label require the use of an optional Motorola Original™ accessory.
11
Safety and General
Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR PHONE.
RF Operational Characteristics
Your phone contains a transmitter and a receiver. When it is ON, it receives and transmits radio frequency (RF) energy. The phone is capable of transmitting in the frequency ranges of 880 MHz to 915 MHz, 1710 MHz to 1785 MHz, and 1850 MHz to 1910 MHz in digital mode.
When you communicate with your phone, the system handling your call controls the power levels at which your phone transmits. The output power level typically may vary over a range from 0.0 watts to 1.67 watts in digital mode for the 900MHz band, 0.0 watts to 0.89 watts in digital mode for the 1800MHz band, and 0.0 watts to 0.89 watts in digital mode for the 1900MHz band.
ExposureTo Radio Frequency Energy
Your Motorola phone is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME):
•United States Federal Communications Commission, Code of Regulations; 47 CFR part 2 sub-part J
12
Safety and General Information
•American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992
•Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
•National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986
•International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
•Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999
•Australian Communications Authority Radiocommunications (Electromagnetic Radiation-Human Exposure) Standard 1999
To assure optimal phone performance and make sure human exposure to radio frequency electromagnetic energy is within the guidelines set forth in the above standards, always adhere to the following procedures:
Portable Phone Operation and EME
Exposure
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or
13
Safety and General Information
attachments could damage the phone and may violate FCC regulations.
Do NOT hold the antenna when the phone is in use.
Holding the antenna affects call quality and may cause the phone to operate at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would a wireline telephone. Speak directly into the microphone.
Body-Worn Operation
To maintain compliance with FCC/Health Canada RF exposure guidelines, if you wear a phone on your body when transmitting, always place the phone in a Motorola-supplied or approved clip, holder, holster, case, or body harness for this product. Use of non-Motorola-approved accessories may exceed FCC/Health Canada RF exposure guidelines. If you do not use a body-worn accessory, and are not holding the phone in the normal use position at the ear, ensure the phone and its antenna are at least one inch
(2.5 centimeters) from your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory cable, position the phone and its antenna at least one inch (2.5 centimeters) from your body.
14
Safety and General Information
Approved Accessories
For a list of approved Motorola accessories, visit our website at www.motorola.com.
Electromagnetic Interference/
Compatibility
Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or otherwise configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your phone in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your phone when on board an aircraft. Any use of a phone must be in accordance with applicable regulations per airline crew instructions.
Medical Devices
Pacemakers
The Advanced Medical Technology Association recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a handheld wireless phone and a pacemaker. These recommendations are consistent with the
15
Safety and General Information
independent research by, and recommendations of, the United States Food and Drug Administration.
Persons with pacemakers should:
•ALWAYS keep the phone more than six inches
(15 centimeters) from your pacemaker when the phone is turned ON.
•NOT carry the phone in the breast pocket.
•use the ear opposite the pacemaker to minimize the potential for interference.
•turn OFF the phone immediately if you have any reason to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.
Safety and General
Use While Driving
Check the laws and regulations on the use of phones in the area where you drive. Always obey them.
16
Safety and General Information
When using your phone while driving, please:
•give full attention to driving and to the road.
•use hands-free operation, if available.
•pull off the road and park before making or answering a call if driving conditions so require.
Operational Warnings
For Vehicles With an Air Bag
Do not place a portable phone in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive atmosphere, unless the phone is a model specifically identified as being “Intrinsically Safe.” Do not remove, install, or charge batteries in such areas. Sparks in a potentially explosive atmosphere can cause an explosion or fire resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres referred to above include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles, such as grain, dust, or metal powders, and any other area where you would normally be
17
Safety and General Information
advised to turn off your vehicle engine. Areas with potentially explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your phone when you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.
Operational Cautions
Antennas
Do not use any portable phone that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily injury such as burns if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.
ITC01-076
18
Your digital wireless phone typically comes equipped with a battery and a charger. Other accessory options can customize your phone for maximum performance and portability.
To purchase Motorola Original™ accessories, please contact the Motorola Customer Call Center at 1-800-331-6456 in the United States or 1-800-461-4575 in Canada.
Your SIM (Subscriber Identity Module) card contains your phone number, service details, and phonebook/message memory. It is stored in a compartment on the flip of your phone.
Caution: Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water, or dirt.
DoThis
1Pull up at the base of the SIM card cover plate and
lift the cover plate off of the phone.
19
Getting Started
DoThis
2Slide the SIM card door down (toward the base of the phone) and lift open.
3Insert the SIM card into the SIM card door with the notch in the upper left corner and the gold plate facing down.
4Close the SIM card door and slide it up to lock the SIM card in place.
5Replace the SIM card cover plate, then push down and snap it into place.
20
Getting Started
Before you can use your phone, you need to install and charge the battery.
Your phone is designed to be used only with Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.
DoThis
1Remove the battery from its protective clear plastic case.
2Insert the tabs at the
base of the battery into the slots at the bottom of the battery compartment.
3 Push the battery down and snap it into place.
21
Getting Started
Before you can use your phone, you need to install and charge the battery.
DoThis
1 Plug the travel charger into your phone with the release tab facing up.
2Plug the other end of the travel charger into the appropriate electrical outlet.
3When your phone indicates that the battery is fully charged (Charge Complete), press the release tab and remove the travel charger.
Note: When you charge the battery, the battery level indicator in the upper right corner of the display shows how much of the charging process is complete. See the “Battery Level Indicator” item on page 28.
22
Getting Started
TurningYour Phone On
DoThis |
To |
|
1 |
Open your phone |
expose the keypad |
|
|
|
2 |
Press and hold P |
turn on your phone |
|
(the power key) |
|
Power
key
3If necessary, enter your SIM card PIN code and press OK (+)
unlock your SIM card
Caution: If you enter an incorrect PIN code three times in a row, your SIM card is disabled and your phone displays the message SIM Blocked. (For more information, see “Protecting the SIM Card” on page 161.)
4If necessary, enter your four-digit unlock code and press OK (+)
unlock your phone
The unlock code is originally set to 1234. Your service provider may change this number before you receive your phone.
23
Getting Started
To call a number, your phone must be turned on, have a SIM card inserted, be unlocked, and have a network connection with adequate signal strength.
Press |
To |
|
1 |
keypad keys |
dial the phone number (up to 32 |
|
|
digits) |
|
|
Tip: If you make a mistake, press |
|
|
DELETE (-) to delete the last digit, |
|
|
or press and hold DELETE (-) to |
|
|
clear all digits. |
|
|
|
2 |
N(send key) |
send the call |
|
|
|
|
|
|
Note: You can make an emergency call even when the phone is locked, or when a SIM card is not inserted. See “Sending and Receiving Calls” on page 34.
Press |
To |
O(end key) |
end the call |
|
|
|
|
24
Getting Started
To receive a call, your phone must be turned on, have a SIM card inserted, and have a network connection with adequate signal strength. If your phone is locked, you must unlock the phone to answer the call.
Note: Your phone cannot receive calls when your SIM card is locked.
When you receive a call, your phone rings and/or vibrates and displays an incoming call message.
Press |
To |
Nor ANSWER (+) |
answer the call |
|
|
|
|
DisplayingYour Phone Number
From the idle display:
Press |
To |
M # |
see your phone number |
|
|
Note: Your phone number must be programmed on your SIM card in order to use this feature.
25
AboutYour Phone
See page 1 for a diagram of your phone that describes basic phone components.
The top section of the display shows phone status indicators. The following illustration shows some of the common indicators that you may see at the top of the display when using your phone.
Messages, phone numbers, and menu options appear in the middle of the display. Text labels at the bottom corners of the display show the current soft key functions. A M(menu) indicator in the bottom center of the display indicates that you can open the main menu or a feature sub-menu to see more options. For more information about the soft key and menu key labels, see “Using the Menu” on page 48.
Some of the phone functions described in this guide must be performed from the idle display. The term idle display refers to the standard display that you see when your phone is on and ready to use, when you are not on a call or using the menu system.
26
About Your Phone
In Use |
Roam |
Message Waiting |
|||
Indicator |
Indicator |
|
Indicator |
||
Signal |
|
|
|
Voice Message |
|
|
|
|
Waiting Indicator |
||
Strength |
|
|
|
||
|
|
|
|
||
Indicator |
|
|
|
Battery |
|
|
|
|
|
||
Alert Setting |
12:00am |
Level |
|||
Indicator |
|||||
|
|
|
|||
Indicator |
|
|
|
|
|
|
GPRS |
|
|
||
|
|
|
|
||
|
|
|
|
|
|
Clock |
Menu Indicator |
|
GPRS Indicators |
Signal Strength Indicator Shows the strength of your phone’s connection with the network.
Strong 5 4 3 2 1 j No signal
You cannot send or receive calls when the “no signal” indicator is displayed.
In Use Indicator Appears when a call is in progress.
Roam Indicator Appears when your phone uses another network system outside your home network. When you leave your home network area, your phone roams or seeks another network.
27
About Your Phone
Message Waiting Indicator Appears when your phone receives a text message.
Voice Message Waiting Indicator Appears when you receive a voicemail message.
Battery Level Indicator Shows the amount of charge left in your battery. The more segments visible, the greater the charge.
High E D C B Empty
Recharge your battery as soon as possible when you see the Low Battery warning message.
Note: When you charge the battery, the battery level indicator instead shows how much of the charging process is complete. See “Charging the Battery” on page 22.
GPRS Indicators Your service provider may use
one of these indicators to indicate that a GPRS
packet data connection is active. This type of connection may be used by your service provider to
allow faster data transfer speeds. The GPRS indicator does not mean that you are in a call; it indicates only that you are registered on the network via a GPRS connection.
Menu Indicator Indicates that you can press M to open a menu. See “Using the Menu” on page 48.
Clock Shows the current time.
28
