Motion Composites MOVE User Manual

MOVE - EDITION - V 1.0

User

Manual

70156-a.1-MOVE EN-User Manual 1.1

User

Manual

Ultralight Folding Wheelchairs

1

Maintenance
manual&

warranty
information

Dealer: This manual must be given to the user of the MOVE
wheelchair before its first use.

User: Prior to using the MOVE wheelchair, carefully read this
manual and keep it for future reference.

For more information about this product, its parts/accessories
and the services provided, please visit:
www.motioncomposites.com

MOVE

Thank you for selecting the MOVE (Usual name of wheelchair).
Please do not hesitate to send us your feedback or questions
regarding this product’s reliability, safety, usability, as well as
any repair/maintenance services offered by an authorized
Motion Composites dealer.

Contact information:

Motion Composites Inc.

519 J-Oswald Forest, suite 101
Saint-Roch-de-l’Achigan, Quebec
J0K 3H0 Canada
Phone: [phone]
Fax: [phone]
[e-mail]

Follow us!

www.motioncomposites.com

European
authorized
representative :

Advena Ltd
Pure Offices
Plato Close
Tachbrook Park
Warwick
CV34 6WE
United Kingdoms

Sophisticated meets affordable.

We took the knowledge acquired through the creation process
of the Series and made it available in an entry-level package.

The lowest seat-to-floor height.

The innovative frame design of the MOVE lets you achieve
a super low 13” seat-to-floor height with a 4” caster on a
standard frame. That’s the same frame that can go up to 21”!

Truly innovative armrest.

Our new composites lightweight armrest quickly converts
from flip-back to single post for easier configuration. Height
adjustments are just a flick away thanks to a simple trigger
system. On top of this, experience safer transfers with our
enhanced rubber grip finish.

Important information

If you have any questions about safety, adjustments,
accessories, use, or maintenance, please contact your
authorized Motion Composites dealer.

Please record the following information for future reference:

Date of purchase

Serial Number

Supplier

Address

Telephone

2

T [phone] - 1 866 650-6555 F [phone]

[e-mail]

MOVE - EDITION - V 1.0

User

Manual

Table of contents

WELCOME TO MOVE
CONTACTING US
IMPO RTANT INFORMATION

TABLE OF CONTENTS

3.
PARTS LIST

4.

4.1 GENERAL WARNING

4.1.1 NOTE TO USERS

4.1.2 IMPORTANT WARNING

4.1.3 NOTE TO DEALERS AND QUALIFIED TECHNICIANS

4.2 SYMBOLS

4.3 LABEL LOCATION

5.

5.1 STRUCTURE

5.2 DIMENSIONS

5.3 ADJUSTABILITY

6.

6.1 PERIODIC CHECKLIST

6.2 WEIGHT LIMITATION

6.3 WEIGHT TRAINING AND SPORTING ACTIVITIES

7.

8.

8.1.1 TO REDUCE THE RISK OF ACCIDENT

8.1.2 ENVIRONMENTAL CONDITIONS

8.1.3 CAREGIVERS

8.2 RIDING YOUR WHEELCHAIR

8.2.1 BALANCE POINT

8.2.2 WHEELIES

8.2.3 TRANSFERRING 8

8.2.4 GETTING DRESSED

8.2.5 REACHING/LEANING/BENDING

8.2.6 MOVING BACKWARDS

8.2.7 RAMPS, SLOPES & SIDE HILLS

8.2.8 OBSTACLES

8.2.9 CURBS AND STEPS

8.2.10 MOVING WITH ASSISTANCE 9

8.2.11 STAIRS

8.2.12 ESCALATORS

9.

9.1 FOLDING & UNFOLDING

9.1.1 FOLDING

9.1.2 UNFOLDING

9.2 WHEEL LOCKS

9.3 FRONT RIGGINGS 10

9.3.1 INSTALLING

9.3.2 UNINSTALLING

9.4 FOOTREST

9.4.1 INSTALLING THE ELEVATING LEGREST

9.4.2 ADJUSTING THE ELEVATING LEGREST

9.5 ARMRESTS

9.5.1 FLIP-BACK ARMRESTS

9.5.2 REMOVABLE T ARMRESTS

9.6 SEAT BELTS 11

9.6.1 AUTO BUCKLE AND AIRCRAFT BUCKLE SEATBELTS

9.6.2 VELCRO™ BELT

9.7 ANTI-TIPPER

9.8 REAR WHEELS

9.8.1 QUICK-RELEASE AXLES

9.8.2 FIXED AXLES

9.9 SEAT SLINGS

PRODUCT OVERVIEW

BEFORE USE

TECHNICAL SPECIFICATIONS

SAFETY

TUTORIAL

RIDING YOUR MOVE

HOW TO USE YOUR MOVE

2

3

4

5

6

6

6

7

9

10.

10.1 SERVICE

10.2 REPLACEMENT PARTS
ORDERING INFORMATION:

10.3 TOOLS NEEDED 12

10.4 GENERAL MAINTENANCE

10.4.1 TIRE PRESSURE

10.4.2 CLEANING YOUR WHEELCHAIR

10.4.3 STORING AND SHIPPING YOUR WHEELCHAIR

10.5 BACKREST

10.5.1 REMOVING/INSTALLING THE BACK CANES

10.5.2 ADJUSTING THE BACK ANGLE

10.5.3 REMOVING/INSTALLING THE SEAT BELT

10.6 ARMRESTS 13

10.6.1 INSTALLING FLIP-BACK ARMRESTS

10.6.2 ADJUSTING THE HEIGHT OF FLIP-BACK ARMRESTS

10.7 FRONT RIGGINGS

10.7.1 ADJUSTING FOOTREST LENGTH

10.8 SEAT 14

10.8.1 REPLACING SEAT UPHOLSTERY

10.9 SEAT-TO-FLOOR HEIGHT

10.9.1 CHANGING THE FRONT SEAT-TO-FLOOR HEIGHT

10.9.2 CHANGING REAR SEAT-TO-FLOOR HEIGHT

10.9.3 CHANGING FRONT & REAR SEAT-TO-FLOOR HEIGHT

10.10 FRONT CASTORS, FORKS AND FORK STEM ASSEMBLIES

10.10.1 REMOVING/INSTALLING/REPOSITIONING THE FRONT WHEELS

10.10.2 REMOVING/INSTALLING THE CASTER HOUSING

10.10.3 REMOVING/INSTALLING THE STEM BOLT ASSEMBLY 15

10.10.4 ADJUSTING THE CASTOR HOUSING ANGLE

10.11 REAR WHEELS

10.11.1 ADJUSTING QUICK-RELEASE AXLES

10.11.2 REPLACING/ADJUSTING HAND RIMS

10.11.3 ADJUSTING THE REAR AXLE HEIGHT
USE A PLASTIC TIRE REMOVAL TOOL TO TAKE OFF THE TIRE.

10.11.3 ADJUSTING THE REAR AXLE HEIGHT 16

10.11.4 ADJUSTING REAR WHEEL SPACING

10.12 WHEEL LOCKS

10.12.1 REPLACING/ADJUSTING THE WHEEL LOCKS

10.13 LOCK EXTENSIONS

10.13.1 REPLACING/ADJUSTING THE LOCK EXTENSIONS

10.14 ANTI-TIPPERS 17

10.14.1 ADJUSTING THE HEIGHT OF THE ANTI-TIPPERS

10.15. HEADREST KIT AND HEADREST SUPPORT

10.15.1 INSTALLING A HEADREST SUPPORT

10.15.2 INSTALLING HEADREST KIT

10.16 AMPUTEE AXLE PLATE 18

11

12

12.1

12.2

12.3

13

14

15

I.

ADJUSTMENTS AND MAINTENANCE OF YOUR MOVE

MOTION COMPOSITES LIMITED WARRANTY

PARTICULAR DAMAGES

DAMAGE REQUIRING SERVICE
SPECIAL DAMAGE
REPAIR PROCEDURE

SAFETY INSPECTION CHECKLIST

DECLARATION OF CONFORMITY

NOTES

APPENDIX

22-23

20

20

18

11

19

21

3

3. Product Overview

Parts List

1 Push handle 10 Caster housing

2 Back cane 11 Wheel lock

3 Arm pad* 12 Crossbrace

4 Rear wheel 13 Rear wheel mounting plate

5 Seat rail 14 Armrest pivot

6 Front rigging 15 Armrest*

7 Footplate* 16 Anti-tipper

8 Caster*

9 Fork

* May be different than shown, depending on order configuration.

4

T [phone] - 1 866 650-6555 F [phone]

[e-mail]

MOVE - EDITION - V 1.0

2015

Anti-tipper
Anti-basculant

Y
Année de fabrication

User

Manual

4. Before use

4.1 General Warning

Your MOVE wheelchair has been designed by professionals
with proper use of aluminum in mind. DO NOT TRY TO
MODIFY THE FRAME BY ANY MEANS. THE FRAME MAY
BE SEVERELY DAMAGED IN THE EVENT OF DRILLING AND
GRINDING, THUS VOIDING THE WARRANTY. Only use Motion
Composites approved and designed clamps and accessories on
your MOVE wheelchair.

4.1.1 Note to users:

The MOVE wheelchair is a manually operated device intended
to be used as a means of mobility for persons restricted to a
sitting position. It is not indicated for the pediatric population.

Carefully read the instructions in this manual before using
or servicing your wheelchair. If you have any questions or
difficulties understanding the following instructions, please
contact a qualified technician; you may also wish to contact a
Motion Composites technician by phone or email (see contact
information on previous page).

4.1.2 Important warning for using the MOVE as

transportation in a motor vehicle while seated

Please note the MOVE has not been tailored to be used as a
transportation device in a motor vehicle while seated. Always
transfer from the wheelchair when boarding a motor vehicle.

4.2 Symbols

The following symbols are used throughout this manual. Please
familiarize yourself with their meaning.

The warning sign indicates important information to
prevent injuries and property damage.

Useful information for the user

Initial setup of your MOVE wheelchair must be done by
a qualified technician.

The latest version of this manual can be found on our
website at motioncomposites.com

Regular maintenance of your MOVE will extend the life
of the wheelchair. Take your wheelchair to a qualified
technician every year for inspection and servicing.

Do not use air or electric tool, tightening should be
done manually.

4.1.3 Note to dealers & qualified technicians

Read this manual before servicing, repairing, operating
or adjusting the wheelchair. If you have any questions or
difficulties understanding the following instructions, please
contact a qualified technician; you may also wish to contact a
Motion Composites technician by phone or email (see contact
information on previous page).

4.3 Label Locations

Quick release
Essieux à dégagement rapide

QUICK RELEASE

Quick-release axles are

Do not attempt to

adjust the axle

ID plate
Plaque d’identification

19565

N° série / Serial no.

519 J-Oswald Forest

Saint-Roch-de-l'Achigan

Québec J0K 3H0

CANADA

ear of manufacture

WARNING

AVERTISSEMENT

Refer to manual for proper anti-tipper setting
Référez-vous au manuel pour un réglage adéquat

Do not operate with-out the anti-tipper tubes installed
Ne pas utiliser sans les tubes anti-basculants

WARNING

AVERTISSEMENT

pre-adjusted in the factory.

AXE À BLOCAGE RAPIDE
Les axes à blocage rapide

sont préréglés à l’usine. Ne

tentez pas de régler l’axe.

WARNING

AVERTISSEMENT

WARNING

AVERTISSEMENT

STABILITY
Various adjustments like
seat height/depth, back

angle, camber/size/position
of the wheels and position

of the front riggings could
aect the stability of the

Wheelchair. All adjustments

should be done by an

experienced technician.

STABILITÉ

Les réglages de la hauteur et
profondeur du siège, l’angle

du dossier, inclinaison/-

taille/position des roues et

des accessoires avant

peuvent aecter la stabilité

du fauteuil roulant. Tout
réglage doit-être exécuté
par un technicien qualié.

Stability
Stabilité

Do not remove or alter any labels
(Fig 1) on the wheelchair. If the label
is damaged, replace it with a new
one.

Fig. 1

Weight capacity Sticker
Autocollant de capacité de poids

5

5. Technical Specifications

6. Safety

5.1 Structure

Frame Folding with aluminum cross brace

Material aluminum alloy

Weight 19 lbs (8.61 kg)
(w/o rear wheels & footrest)

Weight capacity 250 lb (113.3 kg)
Kit HD : 350 lb (158.7 kg)

5.2 Dimensions

Width 14’’ (35.5 cm)
to 16’’, 18, 20’’ & 22’’ (55.8 cm)

Depth 16’’ (40.6 cm)
to 18” & 20’’ (50.7 cm)

Front seat-to-floor height 13’’ (33.0 cm) to 20 1/4’’ (52.7 cm)

Rear seat-to-floor height 12 1/2’’ (31.7 cm) to 20’’ (50.7 cm)

5.3 Adjustability

Upholstery Tension adjustable or bolt on

Back height 16” (40.6 cm) or 20” (50.7 cm)

6.1 Periodic Checklist

See related appendix (section 14).

6.2 Weight Limitation

The MOVE wheelchair has a weight limit of 250 lbs (or 350 lbs
with an HD kit). The specified weight capacity includes: both
the rider and any luggage. A user with a 10 lbs backpack, for
example, should not exceed a weight of 240 lbs (or 340 lbs with
the HD kit). It is of utmost importance that the total weight be
below the above specified capacity.
The wheelchair is designed to support only one person. Please
do not stand up on the footrests.
Motion Composites is not responsible for any damages or
injuries caused by the misuse of this wheelchair.

6.3 Weight Training and Sporting Activities

This wheelchair was not designed or tested as a weight training
or stretching apparatus. Do not attempt to use this wheelchair
for weight training or stretching exercises. The warranty shall
be void if the wheelchair has been used for any weight training
or stretching purposes.
This wheelchair is not intended to be used during sporting
activities.

Should you make any adjustments, repairs or do any
servicing, ensure that all fasteners are tightly secured
before use.

Exceeding the specified weight limit could damage the
wheelchair and/or cause severe injuries.

Adjustable angle from 70° to 110°

Footrest Swing out

Camber 0°

Centre of gravity from 1 1/4” (3.2 cm) to 2 1/4” (5.7

cm) + amputee axle plate option

This wheelchair was designed to be tailored to the
dimensions of its owner and as such should only be
used by its owner unless a qualified specialist,
approved by Motion Composites, has readjusted it.

7. Tutorial

To find the latest tutorial or information, please find our contact
team at:
http://www.motioncomposites.com/en/team/

6

T [phone] - 1 866 650-6555 F [phone]

[e-mail]

MOVE - EDITION - V 1.0

User

Manual

8. Riding your MOVE

Various adjustments of your wheelchair (seat height/
depth/system, back angle, rear & front wheels camber/
size/position, position of the front riggings) could affect
the center of gravity. The adjustments should be
performed by a professional and the wheelchair user
should be aware that the stability could be affected by
these adjustments.

DO NOT tilt the wheelchair or perform a wheelie
without assistance.
DO NOT stand on the wheelchair or part of the frame
of the wheelchair.
DO NOT sit or transfer into the wheelchair unless it is
fully open and the seat frame rails are fully seated into
the receivers.
DO NOT use the footplate as a platform when getting
in or out of the wheelchair or to reach for an object.

8.1.1 To reduce the risk of accident

We recommend that you review safe wheelchair use with your
physician prior to using this equipment.
Take the time to read the instructions in this manual to ensure
that you feel comfortable using the wheelchair without
assistance.
Always be aware of hazards. Always use anti-tippers.

8.1.2 Environmental Conditions

The HELIO A7 was designed to be used on hard and plane
surfaces like asphalt, concrete, and indoor hard flooring or
carpeting.
DO NOT operate on roads, streets or highways.
Beware that the maneuverability of the wheelchair is
significantly affected by different outside conditions such as
sand, mud, rain, snow and rough surfaces. If you use your
wheelchair in these conditions, it is recommended that you have
it frequently serviced.
Be careful when using your wheelchair on wet or slippery
surfaces.
Exposure to water or excessive moisture can be damaging and
may even cause the wheelchair to corrode over the long-term.
DO NOT leave your wheelchair in humid environments such as
the bathroom (e.g. while taking a shower). Store the wheelchair
in a dry and cool location. The wheel chair should be stored
away from a direct exposure to sunlight. If the wheelchair is
wet, dry all parts with a cloth before storing it.
DO NOT use your wheelchair in the shower, pool, or other
water situations.

8.2 Riding your wheelchair

Should you make any adjustments, make sure to
familiarize yourself with the wheelchair movements
before removing the anti-tippers.

The wheelchair should be dried with a cloth
immediately after being exposed to water.

8.2.1 Balance point

It is important to begin by learning all of the specific
characteristics of your wheelchair. Ask a health professional to
explain them to you. Carrying a backpack will affect the balance
point of your wheelchair. Be aware of resulting handling factors
in relation to your body position, posture or weight distribution.
The center of gravity is affected by the angle of the wheelchair
on a ramp or slope. This can be felt in forward and backward
as well as side to side movements. Make sure to review the
different riding techniques prior to using the wheelchair. Use
anti-tippers until you are skilled at riding your wheelchair in any
situation.

8.2.2 Wheelies

DO NOT attempt to perform a wheelie in
your wheelchair because of the dangerous
nature of this kind of maneuver. Motion
Composites recognizes that some
wheelchair users will ignore this Warning. If
you should choose to ignore this Warning,
you should follow these steps to help learn
to do a “wheelie” as safely as possible

NEVER attempt to learn to do a wheelie without first consulting
your health care advisor. NEVER attempt to learn to do a
wheelie without an assistant that can catch you if you should
happen to start to fall. NEVER attempt to learn to do a wheelie
unless you are a skilled rider on this chair.
Motion Composites always recommend using the anti-tippers
at all-time unless they need to be removed to go up or down a
curb/step. Anti-tippers should be reinstalled once the curb/step
is cleared.

8.1.3 Caregivers

• Never use removable parts (e.g. armrests, footrests) to push
the wheelchair and never use lifting supports since they could
cause injuries or damage.

• Ensure that the wheelchair is equipped with push handles and
that its grips are securely in place.

• Turn anti-tipping devices upwards or remove them to avoid
tripping.

• Should you need to leave the wheelchair user unattended,
engage the wheel locks and place the anti-tipping devices
back in the downward position.

• Ask an experienced caregiver to explain safe assistance
methods to you.

• Ensure ongoing communication between you and the
wheelchair user as to avoid any kind of confusion.

• Maintain proper posture to tilt or lift the wheelchair; keep your
back straight and bend at the knees.

• Instruct the wheelchair user to lean his/her back when you are
tilting the wheelchair.

7

8.2.3 Transferring

8.2.7 Ramps, Slopes & Side Hills

Rotate the front casters forward to enhance
stability. Place the wheelchair as close to
your transfer location as possible. Engage
wheel locks. Position yourself as far back as
possible when transferring weight to reduce
risk of tipping forward. If you have good
upper body strength, balance and agility, you
may be able to perform transfers independently.
Rotate or remove footrests if at all possible as to avoid putting
weight on them. If possible, make use of a transfer board.

Always ask a healthcare provider to learn safe transfer
methods.
DO NOT sit or transfer into the wheelchair unless it is
fully open and the seat frame rails are fully seated into
the receivers.
DO NOT use the footplate as a platform when getting in
or out of the wheelchair or to reach for an object.

8.2.4 Getting Dressed

When dressing or undressing on the wheelchair, rotate the front
casters forward and lock anti-tippers in the lower position.
If your wheelchair is not equipped with anti-tippers, back it
against a wall and lock the rear wheels.

8.2.5 Reaching/Leaning/Bending

The balance point may shift when you are putting on
clothes and/or reaching for objects while sitting in the
wheelchair.

If at all possible, use a reaching device
or ask for assistance when reaching for
objects.
Move the wheelchair as close as possible to
the required object.
Rotate the casters as far forward as
possible from the rear wheels.

Never reach for objects between your legs,
but rather position yourself to the side of
these objects.
DO NOT shift your weight sideways,
but rather rise up from the seat or move
forward in the seat. Always use both
hands and grab the opposite side wheel
or armrest if you are capable of reaching sideways. Never
reach to the rear of the wheelchair unless it is equipped with
anti-tippers Never reach for objects over the seat back: reach
only as far as your arm naturally extends without moving on
the seat. DO NOT lock the rear wheels if you are reaching
backwards. Avoid putting pressure on the footrests.

Do not ride hills with an elevation slope of more
than 10% (one foot elevation change for every
10 feet). Try to move straight up or down the
slope. Avoid turning on a downhill slope.
Stay in the center of sidewalks and ensure
that there is enough space for the wheels.
Avoid stopping on slopes and never use the
wheel locks to slow yourself on a downhill slope. Maintain your
speed by holding the hand rims.

Do not ride on wet or slippery surfaces. Be
cautious for changes in terrain height or stairs
at the end of a slope (front casters may lock
from simply hitting a small bump).
Ask for help should any situations arise.
Incline yourself while moving down a slope as
to adjust your center of gravity.

8.2.8 Obstacles

Always look for obstacles or road hazards (potholes, broken
surfaces, etc.). Clear your own environment (work, home)
of any obstacles. Never use objects (furniture, ramps, and
doorknobs) to push yourself out of the wheelchair.
Lean your upper body slightly forward as you move up an
obstacle. Do the reverse while moving down an obstacle. Keep
both hands on the hand rims while passing over the obstacle.

8.2.9 Curbs and Steps

Curbs and steps are extremely dangerous obstacles.

NEVER attempt to go up or down a single curb or step
without an assistant unless you are a very skilled rider
of your chair. You need to have previously learned to
safely do a wheelie in your chair and you are sure you
have the strength and balance to control your chair
during any such maneuver.

ALWAYS unlock and rotate anti-tippers up and out of
the way so they do not prevent you from executing this
maneuver.
NEVER attempt to climb or descend a curb or step
more than 4” high.
ALWAYS go straight up or down a curb or step. NEVER
climb or descend at an angle.

ALWAYS be aware that the impact of dropping down
from a curb or step can damage your chair or cause
components to become loose. If you perform such
maneuvers, inspect your chair more frequently.
ALWAYS Rotate and lock the anti-tippers back to ride
safely.

8.2.6 Moving backwards

Lock anti-tippers in lower position. Move slowly: the wheelchair
is designed to provide you with more stability when moving
forward. Look around as often as possible to avoid obstacles
in your path.

8

T [phone] - 1 866 650-6555 F [phone]

[e-mail]
