Specification
Sheet
MOTICAM A Series
MOTICAM A2
Canada | China | Germany | Spain | USA
www.moticamseries.com | www.moticeurope.com
MOTICAM A Series
MOTICAM A2
Sensor type
Sensor size
Imaging area
Capture resolution
Live display mode through USB
Pixel size
Scan mode
Shutter Mode
Data transfer
Max. frames per second (fps)
Operating temperature
Sensitivity
Support device
Supported OS
Minimum computer requirements
Lens mount
Focusable lens
Software
Functions
Power supply
Package includes
sCMOS
1/3.1”
5.95mm (Diagonal)
2MP
1920x1080, 1280x720 pixels
2.7x2.7μm
Progressive
Rolling Shutter
USB 2.0
1920x1080 @ 30 fps, 1280x720 @ 30 fps (*)
From -10 to +60 Degrees Celsius non condensing
>2000mV
TWAIN, SDK and Direct Show Driver
Microsoft Windows 7/8 /10, MAC OSX10.9, Linux UBUNTU1604 or higher
2GHz dualcore - RAM memory 2GB
C-Mount
12mm
MotiConnect for Windows/OSX/Linux (Download only)
Still image and video capture, still image measurement, image adjustments, white balance,
automatic & manual exposure, individual objective calibration system.
5V (USB supply)
CS ring adaptor, focusable lens, 30mm and 38mm eyepiece adapters, USB 2.0 cable,
Motic 4-dot calibration slide, macro tube, Calibration card
*Frames per second under optimal lighting conditions and in compliance with computer technical requirements.
