Mossloo MSL W2002Q User Manual

5000 mAh

Wireless Power Bank

Instruction Manual

SM-2822

Features:

1.

Powerbank ON/OFF Button

2.

USB Output 1

3.

Micro-USB Input

4.

USB Output 2

5.

LED Indicator

6.

Wireless Charging Surface

What’s included:

1 x 5,000 mAh Wireless Power Bank
1 x USB to Micro-USB charging cable
1 x Instruction Manual

5000mAh/3.7V/18.5Wh

•
Input power: DC 5V/2A

•
Output 1/Output 2: DC 5V/2A Max

•
Wireless Output: 5W

•

LED Indicators

Press the Powerbank ON/OFF Button(1)

•
once to view the remaining power capacity.
Press the button twice to turn OFF.

•

100

INSTRUCTIONS:

1.

Charging the PowerBank:

•

Charge the powerbank fully before usage.

•

Connect the provided charging cable to a
power source and to the micro-USB Input
port(3) on the powerbank.

•

Once connected the LED Indicator(5)will

•

2.

Charging Electronic Devices with the
Power Bank:

•

Connect the charging cable to your mobile
phone/device using the appropriate
connector.

•

Connect the USB part of the cable to either
USB Output 1 or USB Output 2, the LED
Indicator will illuminate when charging.

•

Remove the charging cable from your
mobile device when fully charged.

3.

Charging Electronic Devices with the
Wireless Charging:

•

PressPowerbank ON/OFF button(1)
LED indicator will show Green once the
powerbank is in wireless charging standby
mode.
Place wireless charging enable device on

•
Wireless Charging Pad. The device will
begin to charge, LED indicator will turn
RED when charging.

**

an unknown object is being detected
between the wireless charging pad and the
phone by FOD(Foreign Object Detection).
(The device will not begin to charge until
object is removed.)

66 34

SAFETY PRECAUTIONS:

WARNING-When using this product, basic

•
precautions should always be followed:
Read all the instructions before use.

1.
Never store or use this product in

2.
temperatures below 32°F (0°C) or above
115°F (45°C).
Do not overcharge your phone. The

3.
unit may become hot under excessive
use. Remove your phone once it is fully
charged. Never charge your phone for
more than 7 hours at a time.
The unit will only achieve full performance

4.
after 2 or 3 completed charge and
discharge cycles.
To reduce the risk of injury, close

5.
supervision is required when the product is
used near children.
Do not expose the device to moisture.

6.
Do not use the device in excess of its

7.
output rating. Overload outputs above the

Do not use the device if damaged or

8.

9.

explosion or risk of injury.
Do not disassemble the device. For

10.

professional. Incorrect reassembly may

11.

or temperatures above 104°F (40°C) may
result in explosion.
To ensure product safety, ensure that

12.

identical replacement parts.
Attachments on the back of your phone

13.

can impede the effectiveness of the
wireless charger, and lead to overheating.
Please remove attachments from the phone
before charging on this device.

FCC WARNING

This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
inaccordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following
measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment
should be installed and operated with minimum 20cm distance between the
radiator your body: Use only the supplied antenna

MADE IN CHINA
