Vent 20000 mAh
USB-C PD Fast
Wireless Power Bank
Instruction Manual
7121-74
Features:
1.
Wireless Charging Output Surface
2.
Digital Battery Indicator
3.
ON/OFF Button
4.
Micro-USB Input Port
5.
Type-C Input/Output Port
6.
USB Output
What’s included:
1 x 20000mAh PD Wireless Power Bank
1 x Instruction Manual
1 x Type-C to Type-C Cable
•
Capacity: 20000mAh/3.7V/74Wh
•
Micro-USB Input: DC 5V/2.4A 3A(Max)
•
Type-C Input: DC 5V/2.4A 3A(Max) 9V/2A
•
Type-C Output: DC 5V/3A 9V/2A 12V/1.5A
•
USB A Output: DC 5V/3A 9V/2A 12V/1.5A
•
Total Output: 18W (Max)
•
Wireless Output: 5W/7.5W/10W
LED Indicators
ON/OFF Button(3): Press once to view the
•
remaining power capacity on Digital Battery
Indicator(2).
INSTRUCTIONS:
1.
Charging the PowerBank:
•
Charge the powerbank fully before usage.
•
Connect the provided Type-C to Type-C
cable to a power source and to Type-C
input port on the powerbank(5).
•
Once connected the Digital Battery
and stop blinking once fully charged.
2.
Charging Electronic Devices with the
Power Bank, like some laptops:
•
Connect the appropriate cable to your
mobile phone/device then connect the
other end of the cable into the Type-C
output port(5) or USB A output port(6).
•
Digital Battery Indicator(2) will illuminate
when charging.
•
Remove the cable from your mobile device
and powerbank once fully charged.
3.
Charging Electronic Devices with the
Wireless Charging:
•
Press the Powerbank ON/OFF(3) to turn
on the wireless charging function.
Digital Battery Indicator(2) will illuminate
once the powerbank is in wireless
charging standby mode.
•
Place the wireless charging supported
mobile device on the charging surface(1),
Digital Battery Indicator( 5) will illuminate
when device is charging.
•
Remove the mobile device and powerbank
once fully charged.
**
"188" ,an unkown object being detected
between the wireless charging area and
by FOD(Foreign Object Detection).
the phone
(Indicator will flash
PD means power delivery.
SAFETY PRECAUTIONS:
•
WARNING-When using this product, basic
precautions should always be followed:
1.
Read all the instructions before use.
2.
Never store or use this product in
temperatures below 32°F (0°C) or above
115°F (45°C).
3.
Do not overcharge your phone. The
unit may become hot under excessive
use. Remove your phone once it is fully
charged. Never charge your phone for
more than 7 hours at a time.
4.
The unit will only achieve full performance
after 2 or 3 completed charge and
discharge cycles.
5.
To reduce the risk of injury, close
supervision is required when the product is
used near children.
6.
Do not expose the device to moisture.
7.
Do not use the device in excess of its
output rating. Overload outputs above the
8.
Do not use the device if damaged or
9.
explosion or risk of injury.
10.
Do not disassemble the device. For
professional. Incorrect reassembly may
11.
or temperatures above 104°F (40°C) may
result in explosion.
10 seconds, then light off)
12.
To ensure product safety, ensure that
identical replacement parts.
13.
Attachments on the back of your phone can
impede the effectiveness of the wireless
charger, and lead to overheating. Please
remove attachments from the phone before
charging on this device.
FCC Statement:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
This device may not cause harmful
(1)
interference, and
This device must accept any interference
(2)
received, including interference that may
cause undesired operation.
Warning:
*
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
MADE IN CHINA
![](/html/3e/3eca/3eca982bfb94b485797a5efaa908d789b9aa9d7e1136418948171c7489c3ddbd/bg2.png)
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
