Morphy Richards 71077 VACUUM CLEANER, 71078 VACUUM CLEANER, PERFORMAIR ENDURANCE BAGLESS CYLINDER VACUUM CLEANER, 71067 User Manual

PPeerrffoorrmmAAiirr EEnndduurraannccee bbaagglleessss
ccyylliinnddeerr vvaaccuuuumm cclleeaanneerr

Please read and keep these instructions

Getting the best from your new cleaner...

If your cleaner is not picking up as well as it should, please check

FFiilltteerrss

It is important to rotate the filter dial prior to emptying.
This action shakes clean the dust canister pleated filter. See page 6.

BBlloocckkaaggeess

Check the nozzle, tubes and hose for blockages.

TTuurrbboo nnoozzzzllee

((cceerrttaaiinn mmooddeellss oonnllyy))

Regularly remove hair and dirt caught around the brush bar.

SSaaffeettyy ccuutt oouutt

If the product switches itself off during use, refer to page 7 for instructions.

VC71067 MUK Rev 3

For replacement parts, help with using your Morphy Richards product,
problems and lots more, contact us by phone or through our website.

UUKK HHeellpplliinnee:: 00884444 887711 00994499
RReeppllaacceemmeenntt PPaarrttss:: 00884444 887733 00771155
IIrreellaanndd HHeellpplliinnee:: 11880000 440099 111199

To register for your 3 year guarantee, ring the Helpline numbers below
within 28 days of purchase. This offer is only available in the UK.
Please have the following information available:
Serial number: Model number:
(see page 8 for guarantee details).

71067 Rev3 20/3/08 10:29 Page 1

22

IMPORTANT
SAFETY
INSTRUCTIONS

The use of any electrical
appliance requires the
following common sense
safety rules.

Primarily there is danger of
injury or death and
secondly the danger of
damage to the appliance.
These are indicated in the
text by the following two
conventions:

WARNING: Danger to
the person!

IMPORTANT: Damage to
the appliance!

In addition, we offer the
following safety advice.

Please read before using
the appliance.

Location

• Do not use or keep this
product outside.

• Do not store the appliance
near hot surfaces eg.
ovens or heating
appliances.

Mains lead

• Do not allow the mains
lead to become strained or
run this appliance over it.

• If the electrical cable
becomes damaged, the
cable assembly must be
replaced. Do not attempt
this task yourself, contact
the helpline number at the
bottom of the page.

Personal safety

• The plug must be removed
from the wall socket before
cleaning or maintaining the
appliance.

• Never modify the cleaner in
any way.

• Never use in the presence
of explosive liquids or
vapours.

• Never pick up inflammable
or poisonous liquids such
as petrol, copier toner or
other volatile substances.
Never pick up acids,
asbestos or asbestos dust.

• Repairs to electrical
appliances are only to be
undertaken by trained
personnel. Unprofessional
repairs can be dangerous
for users.

• Use only genuine Morphy
Richards spare parts and
accessories.

• The appliance must never
be left running when
unsupervised.

• This vacuum cleaner is
intended for domestic use
only. Misuse or use for
commercial or any other
purpose will render the
guarantee invalid.

• This appliance is not
intended for use by
persons (including children)
with reduced physical,
sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been
given supervision or
instruction concerning the
use of the appliance by a
person responsible for their
safety.

Product safety

• Never use the appliance
without the filters being
installed.

• Never use the appliance to
vacuum hot ashes, broken
glass, sharp objects or
liquids.

Children

• Children do not understand
the dangers associated
with operating electrical
appliances. Never allow
children to use this
appliance.

• Children should be
supervised to ensure that
they do not play with the
appliance, or stumble over
the power cord.

ELECTRICAL
REQUIREMENTS

Check that the voltage on
the rating plate of your
appliance corresponds with
your house electricity
supply which must be A.C.
(Alternating current).

If the socket outlets in your
home are not suitable for
the plug supplied with this
appliance, the plug should
be removed and the
appropriate one fitted.

If you cut off the plug and
let go of the cable, it will
rewind into the machine,
therefore, you must pull out
a length of cable and
secure it before cutting the
plug off and re-fitting a new
one.

WARNING: The plug
removed from the mains
lead, if severed, must be
destroyed, as a plug with
a bared flexible cord is
hazardous if engaged
into a live socket outlet.

Should the fuse in the 13
amp plug require changing,
a 13 amp BS1362 fuse
must be fitted.

UUKK HHeellpplliinnee 00884444 887711 00994499 RReeppllaacceemmeenntt PPaarrttss 00884444 887733 00771155 IIrreellaanndd HHeellpplliinnee 11880000 440099 111199

71067 Rev3 20/3/08 10:29 Page 2

FEATURES

⁄ Hose inlet

¤ Dust canister

‹ Dust canister release

button

› Carrying handle

fi On/off power switch

fl Eco Switch

‡ Parking slot

· Tool storage drawer

‚ Plug recess

„ Cable rewind switch

‰ Exhaust filter grille

 Exhaust filter

Ê Dust canister lid

Á Pleated, washable dust

canister filter

Ë Mesh filter cover

È Hose

Í Hose handle with airflow

regulator

Î Tube(s): 2 separate

attachable tubes, or 1
single telescopic tube
(length adjustable),
dependant on model.

Ï Combination floor nozzle

Ì Hard floor nozzle

(certain models only)

Ó Turbo nozzle

(certain models only)

Ô Hair and Stair tool

(certain models only)

 Upholstery nozzle

Ò Clip on brush

(attached to )

Ú Crevice tool

Note: ,Ò,Ú are stored
in the tool storage drawer

·

Û Filter cleaning brush

Ù Dust canister lid release

33

⁄

¤

‹

›

fi

fl

‡

‚

Ê

‰

¤

„

Â

Ë

È

·

Í

Î

Ï

Ì



Ó

Á

Ò

Ú

Û

Ù

Ô

71067 Rev3 20/3/08 10:29 Page 3
